33 1 300 Rillex Tapered Roller Bearing Extractor
Note. For bevel pinion and differential case (final drive) / for mounting sprocket wheel on crankshaft (M70) / for removing bearing inner race from drive flange (E36, E46)
Transmission: Rear axle differential type G, K, M
Storage location: B6, C6
Order number: 33 1 300
Rillex tapered roller bearing extractor
Consisting of
1 = 33 1 301 Connecting piece with spindle
1 = 33 1 311 Gripper
2 = 33 1 312 Thrust piece
Note. For removing bearing inner race from drive flange - Series: E36/5
In conjunction with: 00 7 500
5 = 33 1 305 Thrust piece (old)
6 = 33 1 306 Thrust piece
7 = 33 1 307 Thrust piece
8 = 33 1 308 Thrust piece
9 = 33 1 309 Thrust piece
Note. For final drive and for mounting sprocket wheel on crankshaft (M70)
In conjunction with: 00 8 500
Scheme 312
Minimum set: Mechanical tools
In conjunction with: 33 2 150 (E53)
Note. For removing and installing output shaft in drive flange as well as for removing front wheel bearing unit.
Series: E30, E31, E32, E34, E36, E38, E39, E46, E52, E53, E60, E61, E63, E64, E65, E66, E67, E70, E81, E83, E85, E86, E87, E90, E91, E92, E93, RR1, RR2
Storage location: C13, C14, C38
Order number: 33 2 110
Removal and installation tool
Consisting of
1 = 33 2 111 Pressure spindle
Note. For pressing out. Model series: E30, E31, E32, E36, E38, E39, E46, E53, E65, E66, E67, E83, E85
4 = 33 2 114 Spindle
Note. For installation / model series: E30
5 = 33 2 115 Nut with bearing
Note. Model series: E30, E31, E32, E36, E38, E39, E46, E52, E53, E60, E61, E65, E66, E67, E83, E85, RR1
6 = 33 2 116 Bridge
Note. New version 09/98 Model series: E30, E31, E32, E36, E38, E39, E46, E52, E53, E60, E61, E65, E66, E67, E83, E85, E90, RR1
7 = 33 2 117 Threaded piece
Note. Model series: E30, E31, E32, E36, E38, E39, E46, E53, E65, E66, E67, E83, E85
8 = 33 2 118 Spindle for installation
Note. Model series: E31, E52, E53, E60, E61, E65, E66, E67, E83
9 = 33 2 119 Spindle
Note. For installation / model series: E36, E46
Scheme 313
In conjunction with: 33 2 110
Note. For removing and installing output shaft in drive flange, front and rear, as well as for removing front wheel bearing unit
Series: E46, E53, E60, E61, E63, E64, E65, E66, E67, E70, E81, E83, E85, E86, E87, E90, E91, E92, E93, RR1
Storage location: C39
SI number: 1 17 03 (012)
Order number: 33 2 160
Spacer ring
Scheme 314
In conjunction with: 33 4 200, 33 5 070
Note. For removing and installing output shaft in drive flange as well as for removing front wheel bearing unit.
Series: E30, E31, E32, E34, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E52, E53, E60, E61, E63, E64, E65, E66, E67, E70, E83, E85, E86, E87, E90, E91, E92, E93, RR1, RR2
Order number: 33 2 200
Fixture
Consisting of
1 = 33 2 201 Basic body
2 = 33 2 202 Counterholder
In conjunction with: 33 5 070
3 = 33 2 203 Spindle M20x1.5 / length 150 mm
Note. For pressing out. Model series: E30, E31, E32, E36, E38, E39, E46, E53, E65, E66, E67, E83, E85
4 = 33 2 204 Spindle M20x1.5 / length 180 mm
Note. For drawing in. Model series: E30
5 = 33 2 205 Spindle M20x1.5 / length 190 mm
Note. For drawing in. Connection: M27x1.5 Model series: E31, E52, E53, E60, E61, E65, E66, E67, E83
6 = 33 2 206 Spindle M20x1.5 / length 190 mm
Note. For drawing in. Connection: M24x1.5 Model series: E36, E46
7 = 33 2 207 Threaded piece
8 = 33 2 208 Nut with thrust bearing
Note. Model series: E30, E31, E32, E36, E38, E39, E46, E52, E53, E60, E61, E65, E66, E67, E83, E85, RR1
33 3 100 Set of Tools
In conjunction with: 00 8 550
Note. For removing and installing rubber mount in rear axle carrier
Series: E23, E24, E28, E30, E31, E32, E34, E36, E70, RR1
Storage location: B10
Order number: 33 3 100
Set of tools
Consisting of
2 = 33 3 102 Moulded disk
Note. For extracting - Model series: E28
3 = 33 3 103 Spindle for installing
Note. Model series: E28, E30, E31, E36, RR1
4 = 33 3 104 Nut with bearing
Note. Model series: E28, E30, E31, E34, E36, RR1
5 = 33 3 105 Moulded disk
Note. For installing - Model series: E28
6 = 33 3 106 Moulded disk
Note. For gripping during installation - Model series: E28
7 = 33 3 107 Spindle
Note. For extracting - Model series: E28, E30, E31, E36
Scheme 315
In conjunction with: 33 3 220, 00 8 550, 33 3 110
Note. For removing and installing front/rear rubber mounts in rear axle carrier
Series: E36, E46, E70
Storage location: C12
SI number: 1 10 90(288)
Order number: 33 3 320
Threaded spindle (tool kit)
Consisting of
1 = 33 3 321 Shaped piece
Note. For removing rear rubber mount from rear axle carrier Model series: E36, E46
In conjunction with: 33 3 107, 00 8 550
2 = 33 3 322 Thrust washer
Note. For installing front/rear rubber mounts Model series: E36, E46
In conjunction with: 00 8 550, 33 3 103, 33 3 104, 33 3 107, 33 3 314, 33 3 315
3 = 33 3 323 Shaped piece
Note. For removing front rubber mounts from rear axle carrier Model series: E36, E46
In conjunction with: 00 8 550, 33 3 324
4 = 33 3 324 Spindle
Note. For removing front rubber mount Model series: E36, E46
Scheme 316
Note. For removing and installing ball joint and rubber mount in semi-trailing arm
Series: E31, E36, E38, E39, E46, E52, E60, E61, E63, E64, E65, E66, E67, E70, E83, E85, E86, RR1
Storage location: A14
SI number: 1 10 90(288)
Order number: 33 3 330
Removal and installation tool
Consisting of
1 = 33 3 331 Spacer sleeve
Note. For removing / model series: E36, E46
2 = 33 3 332 Extractor sleeve
Note. Model series: E36, E46
3 = 33 3 333 Spindle with forcing nut
4 = 33 3 334 Spacer sleeve
Note. For installing ball joint Model series: E31, E36, E38, E39, E46, E65, E66, E85
Scheme 317
In conjunction with: 33 4 150
Note. For removing rubber mount in rear axle carrier
Series: E36, E38, E39, E39tou, E46, E52, E61, E65, E66, E67, E70, E81, E83, E85, E86, E87, E90, E91, E92, E93, R53, RR1, RR2
Storage location: A7
SI number: 1 02 99 (417)
Order number: 33 4 140
Universal support
Consisting of
1 = 33 4 141 Threaded pipe
2 = 33 4 142 Support foot (2 x)
Note. Model series: E38, E39, E46
3 = 33 4 143 Sliding piece
4 = 33 4 144 Guide rod
5 = 33 4 145 Guide rod
Note. With threaded lug
6 = 33 4 146 Locating plate
Note. With screws
7 = 33 4 147 Thrust piece (2 x)
Note. With screws - Model series: E38, E39, E46
8 = 33 4 148 Support foot, long (2 x)
Note. Model series: E39/2, E65, E67, RR1
9 = 33 4 149 Thrust piece (2 x)
Note. With countersunk head screw - Model series: E39/2, E65, E67, E87
Scheme 318
In conjunction with: 33 4 140, 33 3 371
Note. For removing and installing rubber mount on rear axle carrier
Series: E38, E39, E39tou, E46, E52, E53, E60, E61, E63, E64, E65, E66, E67, E70, E83, E85, E86, RR1, RR2
Storage location: B38, B8, C7, C8
SI number: 1 06 94 (801)
Order number: 33 4 150
Removal and installation tool
Consisting of
1 = 33 4 151 Pressure plate
Note. For removal / model series: E38, E39, E46, E52
2 = 33 4 152 Pressure plate
Note. For installation Model series: E38, E39, E46, E52, RR1
3 = 33 4 153 Support plate
Note. For installation / model series: E38, E39, E46, E52
4 = 33 4 154 Spindle with lock nut
Note. Model series: E38, E39, E46, E52, E60, E61, E63, E64
5 = 33 4 155 Nut with bearing
In conjunction with: 33 3 371 (E46)
6 = 33 4 156 Spindle, long
Note. Model series: E39/2, E65, E66, E67, RR1
7 = 33 4 157 Pressure plate
Note. For installation - model series: E39/2, E65, E66, E67, RR1
8 = 33 4 158 Pressure plate
Note. For removal - model series: E53, E65, E66, E67, RR1
9 = 33 4 159 Support disk
Note. For installation - model series: E53, E65, E66, E67, RR1
Scheme 319
In conjunction with: 33 3 333
Note. For removing and installing ball joint on rear wheel carrier
Series: E38, E39, E52, E60, E61, E63, E64, E65, E66, E67, E70
Storage location: B33
SI number: 1 06 94 (801)
Order number: 33 4 190
Removal/installation thrust pieces
Consisting of
1 = 33 4 191 Support tube
Note. For removal and installation
2 = 33 4 192 Support plate
Note. For removal and installation
3 = 33 4 193 Thrust piece
Note. For removal
4 = 33 4 194 Thrust piece
Note. For installation
Scheme 320
In conjunction with: 33 2 116
Note. For removing rear wheel flange when replacing wheel bearings
Series: E12, E21, E23, E24, E28, E30, E31, E32, E34, E36, E38, E39, E46, E52, E53, E60, E61, E63, E64, E65, E66, E67, E70, E81, E83, E85, E86, E87, E90, E91, E92, E93, RR1
SI number: 1 06 94 (801)
Order number: 33 4 200
Tool kit / striker fixture
Consisting of
1 = 33 4 201 Impact rod with handle
3 = 33 4 203 Impact piece
5 = 33 4 205 Adapter
Note. For removing wheel guide joint from E53, E83
In conjunction with: Impact tool 33 4 200
33 4 204 M20 nut and M20 flat nut
Note. Nuts 33 4 204 are integrated in 33 4 201 33 4 204 is only continued as a spare part number.
Scheme 321
33 4 400 Puller Fixture
Note. For removing inner wheel bearing races on rear axle
Series: E12, E21, E23, E24, E28, E30, E30/C, E30tou, E31, E32, E32/3, E34, E34tou, E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E70, E81, E83, E85, E86, E87, E90, E91, E92, E93, RR1
SI number: 1 05 99 (426)
Order number: 33 4 400
Puller fixture
Consisting of
1 = 33 4 401 Basic body
2 = 33 4 402 Spindle
3 = 33 4 403 Wrench, large
4 = 33 4 404 Wrench, small
5 = 33 4 405 Clamping pliers (45...51 mm)
6 = 33 4 406 Clamping pliers (50...55 mm)
7 = 33 4 407 Clamping pliers (55...61 mm)
Note. Model series: E67
Scheme 322
33 4 426 Mounting Adapter
Note. Locator for E85 Z4 M. SI 01 10 06 (264)
SI number: 01 10 06 264
Order number: 33 4 426
Mounting adapter
Scheme 323
In conjunction with: 33 4 450
Note. For removing and installing camber arm rubber mount on rear axle carrier.
Series: E60, E61, E63, E64, E65, E66, E67, E70, E81, E85, E86, E87, E90, E91, E92, E93, RR1, RR2
Storage location: B49, C49
SI number: 1 15 04 (117)
Order number: 33 4 460
Set of tools
Consisting of
1 = 33 4 461 Draw-in disk
2 = 33 4 462 Pull-out disk
3 = 33 4 463 Counter support
4 = 33 4 464 Support sleeve
5 = 33 4 465 Spindle 205 mm, M12
6 = 33 4 466 Pressure nut
Scheme 324
33 5 014 Thrust Piece with Splined Key
Order number: 33 5 014
Thrust piece with splined key
Scheme 325
In conjunction with: 33 5 070
Note. For releasing and tightening down insert nut for bolt connection of propeller shaft to rear differential.
Series: E70, E90, E91, E92
SI number: 01 21 06 (300)
Order number: 33 5 040
Open-end wrench WAF 50 mm with locking clip
Consisting of
1 = 33 5 041 Basic body
2 = 33 5 042 Clip
3 = 33 5 043 Pin with chain (2 x)
Scheme 326
In conjunction with: 33 5 070
Note. For releasing and tightening down flange nut on rear differential.
Series: E70, E90, E91, E92, E93
SI number: 01 21 06 (300)
Order number: 33 5 050
Multipoint ring wrench WAF 65 mm
Scheme 327
In conjunction with: 33 5 070
Note. For gripping transmission input shaft when releasing and tightening down flange nut.
Series: E70, E90, E91, E92, E93
SI number: 01 21 06 (300)
Order number: 33 5 060
Multipoint socket z34
Scheme 328
In conjunction with: 33 5 040, 33 5 050, 33 5 060
Note. Pull-out extension for 33 5 040, 33 5 050, 33 5 060.
Series: E36, E38, E39, E46, E52, E53, E60, E61, E63, E64, E65, E66, E67, E70, E81, E83, E85, E86, E87, E90, E91, E92, E93, RR1, RR2
SI number: 01 21 06 (300)
Order number: 33 5 070
Extension piece (2)
Consisting of
1 = 33 5 071 Extension (1 x)
Scheme 329
Note. For tensioning or removing and installing barrel spring on rear axle.
Series: E70
SI number: 01 22 06 (307)
Order number: 33 5 100
Spring tensioner
Consisting of
1 = 33 5 101 Spring plate
2 = 33 5 102 Spring plate
3 = 33 5 103 Spindle
4 = 33 5 104 Nut with thrust member
5 = 33 5 105 Ratchet ring wrench WAF 24
6 = 33 5 109 Case with insert
Scheme 330
Note. For removing and installing output shaft in rear differential.
Series: E70
SI number: 01 22 06 (307)
Order number: 33 5 120
Fixture
Consisting of
1 = 33 5 121 Basic body
2 = 33 5 122 Knurled screw with thrust member
3 = 33 5 123 Rod
4 = 33 5 124 Shaped section (shell)
5 = 33 5 125 Shaped section
Scheme 331
Note. For driving shaft seal of output shaft into rear differential. Rear differential: 188
Series: E70
SI number: 01 22 06 (307)
Order number: 33 5 130
Drift
Scheme 332
Note. For driving shaft seal of output shaft into rear differential. Rear differential: 215
Series: E70
SI number: 1 01 07 (333)
Order number: 33 5 140
Drift
Scheme 333
Note. For removing and installing rubber mount in rear differential at rear.
Series: E70
SI number: 01 22 06 (307)
Order number: 33 5 150
Fixture
Scheme 334
33 5 151 Disc
SI number: 01 22 06 (307)
Order number: 33 5 151
Disc
33 5 152 Holding Sleeve
SI number: 01 22 06 (307)
Order number: 33 5 152
Holding sleeve
33 5 153 Disc
SI number: 01 22 06 (307)
Order number: 33 5 153
Disc
33 5 154 Holding Sleeve
SI number: 01 22 06 (307)
Order number: 33 5 154
Holding sleeve
33 5 155 Disc
SI number: 01 22 06 (307)
Order number: 33 5 155
Disc
33 5 156 Disc
SI number: 01 22 06 (307)
Order number: 33 5 156
Disc
Note. For removing and installing rubber mount in rear differential at front.
Series: E70
SI number: 01 22 06 (307)
Order number: 33 5 160
Fixture
Consisting of
1 = 33 5 161 Washer
2 = 33 5 162 Sleeve
3 = 33 5 163 Washer
4 = 33 5 164 Sleeve
5 = 33 5 165 Washer
6 = 33 5 166 Nut M12x1.5
Scheme 335
Note. For removing and installing rubber mount in rear axle carrier.
Series: E70
SI number: 01 22 06 (307)
Order number: 33 5 170
Fixture
Consisting of
1 = 33 5 171 Shaped washer
2 = 33 5 172 Shaped washer
3 = 33 5 173 Shaped washer
Scheme 336
33 5 180 Mounting Adapter
Note. For supporting rear axle carrier during removal and installation.
Series: E70
SI number: 01 22 06 (307)
Order number: 33 5 180
Mounting adapter
Consisting of
1 = 33 5 181 Mounting adapters 1 and 2
2 = 33 5 182 Mounting adapters 3 and 4
Scheme 337
33 5 200 Support
In conjunction with: 00 2 030
Note. For holding rear differential during removal and installation.
Series: E70
SI number: 1 01 07 (333)
Order number: 33 5 200
Support
Consisting of
1 = 33 5 201 Joint
2 = 33 5 202 Base frame
3 = 33 5 203 Support
4 = 33 5 204 Support for foam material padding
5 = 33 5 205 Foam material padding (1 set = 2 pads)
33 5 206 Retaining strap
