Steering and Wheel Alignment - Special Tools - e90 BMW M3 E90

Manual & Power Steering 10 illustrations ~511 words

Device MW

Note. For checking pump pressure in the hydraulic steering

Consisting of

2 = 0492059 Pressure gauge

Note. (Pressure gauge 160 bar)

11 = 0494385 Adapter

Note. (Adapter M14 x 1.5)

12 = 0494386 Adapter

Note. (Adapter M16 x 1.5)

Scheme 120

Scheme 120: Device MW

1 = 0492058 Pressure gauge

Note. (Pressure gauge 16 bar)

3 = 0492060 Device

Note. (Testing device without pressure gauge)

4 = 0492061 Lines

5 = 0492062 Connection piece

Note. For screwing into power steering pump/Model series: E23, E46, E52, E53, E64, E65, E66, E85

6 = 0492063 Connection piece

Note. For screwing into testing device 32 4 003/Model series: E23, E46, E52, E53, E64, E65, E66, E85

= 0492064

7 = 0492064 Connection piece

Note. (Connection piece M18 x 1.5) For screwing into pressure regulator/Model series: E32, E34

8 = 0492065 Connection piece

Note. (Connection piece M14 x 1.5) For screwing into testing device/Model series: E32, E34

9 = 0493264 Valve

Note. (Ball valve)

Gauge MW

Replaced by: 0492036

Note. (Test gauge) For measuring the drop arm - Replaced by 32 2 140.(0 492 036)

Consisting of

1 = 0492030 Spindle

Note. Discontinuation and replaced by 32 2 140.(0 492 036)

2 = 0492031 Shaped part

Note. (Shaped part) Discontinuation and replaced by 32 2 140.(0 492 036)

3 = 0492032 Bolt

Note. (Measuring bolt) Discontinuation and replaced by 32 2 140.(0 492 036)

Scheme 121

Scheme 121: Gauge MW

Lever Minimum set: Mechanical tools MW

Note. For disconnecting hydraulic lines from steering box and for locking adjustment unit (ASZE) at handbrake lever

Storage Location

C45

B45

SI number

01 14 01 (766)

Scheme 122

Scheme 122: SI number

Mandrel MW

Note. (Drift) For radial seal ring of inner steering sector shaft in steering box

A15

Scheme 123

Scheme 123: Storage Location

Open-end spanner MW

Note. (open-end spanner WAF 27) For adjusting left track rod on rack

Y4

Scheme 124

Scheme 124: Storage Location

Open-end wrench insert MW

Note. (Open-end wrench insert) SW34 For releasing and tightening down track rod connection to steering gear (rack)

A84

01 01 04 (065)

Scheme 125

Scheme 125: SI number

Pliers MW

Note. For opening and fastening hose clamps

01 02 01 (667)

Scheme 126

Scheme 126: SI number

Plug Minimum set: Mechanical tools MW

Note. (Plugs (set)) 27-piece, 3x per size - For sealing off hydraulic lines for brakes, steering etc.

01 14 01 (766)

Scheme 127

Scheme 127: SI number

Socket wrench Minimum set: Mechanical tools MW

Note. (Socket wrench) SW 38 For toe adjustment on front axle.

A11

01 15 99 (483)

Scheme 128

Scheme 128: SI number

Tool Minimum set: Mechanical tools MW

Note. (Adjustment tool) For adjusting the front camber.

B8

01 15 05 (200)

Consisting of

5 = 0493765 Spindle

Note. Replaced by 32 3 146 (0 495 355)

Scheme 129

Scheme 129: SI number

3 = 0494384 Ring

Note. (Support ring) Replaced by 32 3 145 (0 494 181)

2 = 0493558 Ring

Note. (Support ring) Replaced by 32 3 145 (0 494 181)

2 = 0493559 Holder

Note. Replaced by 32 3 146 (0 495 355)

5 = 0494181 Washer

Note. For adjusting the camber on the front axle.

6 = 0495355 Spindle

7 = 0495356 Bolt

Note. (Knurled screw)
