00 11 229 Changing/topping up/checking gear oil in manual transmission
| IMPORTANT | Gear oil: refer to MANUAL TRANSMISSION - OPERATING FLUIDS . Failure to comply with this instruction will result in serious damage to the transmission! |
Recycling
Catch and dispose of gear oil with suitable equipment.
Observe country-specific waste-disposal regulations.
Necessary preliminary tasks
- Remove «REAR UNDERBODY PROTECTION»(/bmw/m3/e90-2007-2013/remont/door-locks-anti-theft-systems/#body-equipment-repair-e90__51-47-491-removing-and-installingreplacing) .
Draining gear oil
Scheme 252
- Open oil drain plug (1) and drain gear oil
- Activate gear oil pump using DIS Tester for approx. 30 seconds The residual oil is pumped out of the pump circuit of the transmission oil cooler into the transmission housing and flows off
- Allow gear oil to flow off sufficiently
- Clean oil drain plug (1) and screw in Tightening torque «23 00 4AZ»(ref-381603-S36549337812010123000000) .
Release screw (1).
Tightening torque 23 41 17AZ .
Check transmission oil screen, replace if necessary.
Installation
Replace sealing ring
Scheme 253
Adding gear oil.
- Undo oil filler plug (2).
- Pour in oil until it overflows at inspection opening.
- Check gear oil level (see below).
Checking gear oil level
Note. Can also be carried out individually - without an oil change! Activate gear oil pump via DIS Tester. Open oil filler plug. Top up gear oil with pump running to lower edge of filler opening. Refit oil filler plug. Tightening torque 23 00 4AZ . Switch off pump activation.
00 Danger of poisoning if oil is ingested/absorbed through the skin
Danger of poisoning!
Ingesting oil or absorbing through the skin may cause poisoning!
Possible symptoms are
- Headaches
- Dizziness
- Stomach aches
- Vomiting
- Diarrhoea
- Cramps/fits
- Unconsciousness
Protective measures/rules of conduct
- Pour oil only into appropriately marked containers
- Do not pour oil into drinking vessels (drinks bottles, glasses, cups or mugs)
- Observe country-specific safety regulations
First aid measures
- Do not induce vomiting. If the person affected is still conscious, he/she must rinse out their mouth with water, drink plenty of water and consult a doctor immediately. If the person affected is unconscious, do not administer anything by mouth, place the person in the recovery position and seek immediate medical attention.
23 00 037 Installing replacement transmission (GS6-53BZ) S65
| IMPORTANT | After completion of work, check TRANSMISSION FLUID LEVEL . See MANUAL TRANSMISSION - OPERATING FLUIDS . |
Failure to comply with this instruction will result in serious damage to the transmission.
Catch and dispose of escaping transmission fluid.
Observe country-specific waste-disposal regulations
- Drain gear oil at oil drain plug. Tightening torque: «23 00 4AZ»(ref-381603-S36549337812010123000000) .
- «REMOVE TRANSMISSION»(/bmw/m3/e90-2007-2013/remont/manual-trans/#manual-transmission-repair-e90) .
Convert shift rod joint.
Push back retaining ring (1) and drive out dowel pin (2).
Scheme 254
Note. Check damping disk (6) for damage and replace if necessary.
Scheme 255
Convert following parts from previous transmission to new transmission.
- «RELEASE BEARING AND RELEASE LEVER»(/bmw/m3/e90-2007-2013/remont/clutches-manual-hydraulic/#clutch-repair-e90__21-51-500-removing-and-installing) .
- Ball pin and spring wire clip
- Studs for clutch slave cylinder
- «PULSE GENERATOR, CRANKSHAFT/TRANSMISSION»(/bmw/m3/e90-2007-2013/remont/gauges-instrument-panels/#engine-electrical-system-repair-e90__13-62-610-replacing-pulse-generator)
Add final details to vehicle.
Check oil level.
Installation
Observe GREASING SPECIFICATION .
Scheme 256
0 General information Complete transmission, transmission oil change, transmission designations
- Input shaft
- Guide tube
- Radial seal For drive shaft
- Transmission temperature sensor
- Transmission housing, front section
- Transmission housing, rear section shafts, gear wheels, gearshift components
- Radial seal For selector shaft
- Shift shaft
- Output shaft
- Output flange
- Radial seal For output flange
- Reversing light switch
- Zero-gear sensor
- Speed sensor (transmission main shaft)
- Crankshaft sensor
Notes
| IMPORTANT | After completing work: Check TRANSMISSION OIL LEVEL . See MANUAL TRANSMISSION - OPERATING FLUIDS . Failure to comply with this requirement will result in serious damage to the manual transmission. |
- «CLAMP OFF BATTERY»(/bmw/m3/e90-2007-2013/remont/gauges-instrument-panels/#engine-electrical-system-repair-e90__12-00-instructions-for-disconnecting-and)
- «MANUAL TRANSMISSION - OPERATING FLUIDS»(/bmw/m3/e90-2007-2013/remont/manual-trans/#manual-transmission-operating-fluids)
- «REMOVE PROPELLER SHAFT»(/bmw/m3/e90-2007-2013/remont/driveshaft-universal-joints/#propeller-shaft-repair-e90__26-11-000-removing-and-installing)
- Remove «FRONT UNDERBODY PROTECTION»(/bmw/m3/e90-2007-2013/remont/door-locks-anti-theft-systems/#body-equipment-repair-e90__51-47-490-removing-and-installingreplacing)
Disconnect plug connection (1) from reversing light switch.
Release cable from retainers.
Scheme 257
Disconnect plug connection (1).
Remove heat shield for crankshaft pulse generator.
Disconnect plug connection (2).
Release screws (3) and (4).
Scheme 258
Disconnect plug connection (1).
Unfasten screws (2).
Suspend holder (3) to one side.
Scheme 259
Release screws (1).
Tightening torque 23 00 1AZ .
Scheme 260
Disconnect plug connection (1).
Scheme 261
Disconnect plug connection (1).
Scheme 262
Note. Pressure line of clutch slave cylinder remains connected.
| IMPORTANT | Relieve tension on clutch slave cylinder slowly; otherwise air will be drawn in through sealing sleeve. |
Scheme 263
Unscrew nuts.
Remove clutch slave cylinder.
Tightening torque 21 52 5AZ .
Supporting transmission
Support transmission with special tools 234050 and 002030.
Secure transmission to mounting with tensioning strap (1).
Tasks are described in 23... Universal BMW transmission take-up .
After completion of work, check transmission oil level.
Scheme 264
Lever out retainer (1).
Clamp off shift rod (2).
Installation
Grease shift rod.
Grease, refer to MANUAL TRANSMISSION - OPERATING FLUIDS .
Make sure shims (3) are in correct position.
Scheme 265
Unlock bearing pin (1) in direction of arrow and remove.
Lift out shift arm.
Installation
Grease bearing pins (1).
Grease, refer to GEAR SHIFT MECHANISM - OPERATING FLUIDS .
Scheme 266
Lever support bearing (1) with a short screwdriver out of mounting.
Scheme 267
Installation
See GEAR SHIFT MECHANISM - OPERATING FLUIDS for greasing bearing pin of shift arm.
Fit support bearing (1) with opening (2) towards top rear onto holder.
Scheme 268
Bolt special tool 119990 with bolt (1) to front axle support.
Bolt (2) is required to secure the engine in the correct position.
Scheme 269
Adjust special tool 119990 until dimension A=50 mm is obtained between front axle support and tensioner.
Scheme 270
Disconnect plug connection (1) of zero gear sensor (on transmission).
Scheme 271
Release screws (1) and (2).
| IMPORTANT | Bolts (2) are longer than bolts (1) |
Tightening torque 23 00 1AZ .
Note. Bolt (3) must not be released. Bolt (3) is for securing the starter.
Scheme 272
| IMPORTANT | Do not allow the transmission to hang from the transmission input shaft during removal and installation as this will deform the clutch plate. |
To avoid damaging the sound insulation (1) on the bulkhead, raise the transmission after withdrawing the transmission pin from the pilot bearing against the direction of engine lowering to 0°.
For safety, a protective film (2) can also be placed between the transmission and the sound insulation.
Scheme 273
Installation
Pay attention to correction position of dowel sleeves.
Replace damaged dowel sleeves.
Ensure correct position of cover plate.
Scheme 274
REMOVE RELEASE UNIT AND RELEASE LEVER and clean.
Check lubrication of transmission input shaft for sticky consistency. If grease is sticky, REPLACE CLUTCH PLATE .
Check clutch plate for friction rust in taper splines and REPLACE IF NECESSARY .
Mechanically remove old grease and lining abrasion from the taper splines of the clutch disk (with a cloth).
Scheme 275
Installation
Greasing specification
- Remove release bearing and release lever.
- Push on grease scraper ring «21 2 240»(/bmw/m3/e90-2007-2013/remont/clutches-manual-hydraulic/#clutch-special-tools-e90) as far as it will go.
- Grease splines (1) of input shaft with a brush. Refer to «MANUAL TRANSMISSION - OPERATING FLUIDS»(/bmw/m3/e90-2007-2013/remont/manual-trans/#manual-transmission-operating-fluids) and «GEAR SHIFT MECHANISM - OPERATING FLUIDS»(/bmw/m3/e90-2007-2013/remont/automatic-trans/#gear-shift-mechanism-operating-fluids) .
- Detach grease scraper ring.
Scheme 276
Necessary preliminary work
- Remove gearbox
- Remove «CLUTCH RELEASE BEARING/LEVER»(/bmw/m3/e90-2007-2013/remont/clutches-manual-hydraulic/#clutch-repair-e90__21-51-500-removing-and-installing)
Drive a hole into the sealing cap (1) with a suitable tool (2).
| IMPORTANT | Do not use a drill as drillings may result in transmission malfunction. |
Scheme 277
Screw special tool 230490 into sealing cap.
Withdraw sealing cap from transmission housing with aid of impact weight.
Scheme 278
Apply transmission oil to the sealing lip of the sealing cap (1) and insert.
Scheme 279
Drive sealing cap firmly home with special tool 230330.
Scheme 280
- Remove underbody protection
- Remove right heat shields.
Catch and dispose of gear oil with suitable equipment.
Observe country-specific waste-disposal regulations.
Unlock plug (1) and remove.
Release screw (2).
Remove speed sensor.
Scheme 281
00 Risk of injury if oil comes into contact with eyes and skin
Danger of injury!
Contact with eyes or skin may result in injury!
Possible symptoms are
- Impaired sight
- Irritation of the eyes
- Reddening of the skin
- Rough and cracked skin
- Wear protective goggles
- Wear oil-resistant protective gloves
- Observe country-specific safety regulations
- Eye contact: Rinse eyes immediately with plenty of water for at least 15 minutes; if available, use an eye-rinsing bottle. If irritation of the eyes persists, consult a doctor.
- Skin contact: Wash off with soap and water immediately. If irritation persists, consult a doctor. NOTE: Do not use solvents/thinners.
00 Safety instructions for handling oil
| WARNING | DANGER OF POISONING if oil is ingested/absorbed through the skin! RISK OF INJURY if oil comes into contact with eyes and skin! |
Observe country-specific waste-disposal regulations.
Measures if oil is unintentionally released
- Personal precautionary measures: Danger of slipping! Keep non-involved persons away from the work area. Wear personal protective clothing/equipment.
- Environmental protection measures: Prevent oil from draining into drain channels, sewerage systems, pits, cellars, water and the ground.
- Limiting spread: Use oil blocks to prevent the surface spread of oil.
- Cleaning procedure: Bind and dispose of escaped oil with nonflammable absorbents. NOTE: Do not flush oil away with water or aqueous cleaning agents.
Breakdown of BMW designation
| A5S 300J (former designation) | ||
|---|---|---|
| A | Transmission type | S = Manual gearbox A = Automatic transmission |
| 5 | Number of forward gears | |
| S | Type of top gear | D = Direct gear S = Overdrive gear |
| 300 | Max. input torque (Nm) | |
| J | Code letter of transmission manufacturer | G = Getrag J = Jatco R = GMPT (General Motors Powertrain) Z = ZF (Zahnradfabrik Friedrichshafen) |
| SMG | Notes | SMG = Sequential M gearbox/transmission |
BMW BREAKDOWN DESIGNATION - TRANSMISSION
| GS6-37BZ (new designation according to BMW Group Standard GS 90007) | ||
|---|---|---|
| G | Transmission | |
| S | Transmission type | S = Manual gearbox A = Automatic transmission |
| 6 | Number of forward gears | |
| = Standard with manual gearshift HP = Hydraulic planetary gear train DKG= Twin-clutch transmission/gearbox | ||
| 37 | Transmission type | 26 = D-transmission 31 = C-transmission 39 = F-transmission 37 = H-transmission 53 = G-transmission 17 = I-transmission 47= J transmission SMG -7-speed 45 = K transmission 36= Transmission DKG |
| B | Gear set | B = Gasoline gear ratio D = Diesel gear ratio S= Sport gear ratio |
| Z | Code letter of transmission manufacturer | G = Getrag Z = ZF (Zahnradfabrik Friedrichshafen) |
BMW BREAKDOWN DESIGNATION - SEQUENTIAL M GEARBOX
Manual gearbox
| BMW designation | Manufacturer | Manufacturer designation | Remarks |
|---|---|---|---|
| S5D 200G | Getrag | B transmission (220/5) | |
| S5D 200G | Getrag | B transmission (221/5) | For M41 engine only |
| S5D 250G | Getrag | B transmission (220/5) | Reinforced design |
| S5D 260Z | ZF | C-transmission (S5-31 D) | For M51 engine only |
| S5D 280Z | ZF | C-transmission (S5-31) | |
| S5D 310Z | ZF | C-transmission (S5-31) | Up to 9.95 |
| S5D 320Z | ZF | C-transmission (S5-31) | From 9.95 (reinforced design) |
| GS5S31BZ (SMG) | ZF | C transmission | SMG |
| GS5-39DZ | ZF | F transmission | |
| S6S 420G | Getrag | D-transmission (226/6) | |
| S6S 420G (SMG) | Getrag | D transmission SMG | |
| S6S 560G | Getrag | E-transmission (286/6) | |
| GS6-37BZ | ZF | H-transmission | |
| GS6S37BZ (SMG) | ZF | H-transmission | |
| GS6-37DZ | ZF | H-transmission | |
| GS6-37BG | Getrag | H-transmission | |
| GS6-53BZ | ZF | G-transmission | |
| GS6-53DZ | ZF | G-transmission | |
| GS6-17BG | Getrag | I-transmission | |
| GS6-17DG | Getrag | I-transmission | |
| GS7S47BG (SMG) | Getrag | J-transmission (247) | SMG -7-speed |
| GS7D36SG | Getrag | DKG (436) | DKG -7-speed |
| GS6- 45BZ | ZF | K transmission | |
| GS6- 45DZ | ZF | K transmission |
BMW BREAKDOWN DESIGNATION - MANUAL GEARBOX
Automatic transmission
| BMW designation | Manufacturer | Manufacturer designation | Remarks |
|---|---|---|---|
| A4S 200R | GMPT | GM4 | |
| A4S 270R | GMPT | THM-R1w | Transmission wide-stepped |
| A4S 310R | GMPT | THM-R1 | |
| A5S 300J | Jatco | Jatco | |
| A5S 310Z | ZF | 5HP-18 | |
| A5S 325Z | ZF | 5HP-19 | |
| A5S 440Z | ZF | 5HP-24 | |
| A5S 560Z | ZF | 5HP-30 | |
| A5S 360R/390R | GM | GM5 | |
| GA6HP19Z | ZF | 6HP19 | |
| GA6HP26Z | ZF | 6HP26 | |
| GA6HP32Z | ZF | 6HP32 | |
| GA6L45R | GM | GM6 | |
| GA8HP45Z | ZF | 8HP45 | |
| GA8HP70Z | ZF | 8HP70 | |
| GA8HP90Z | ZF | 8HP90 | |
| GA7AHSCD | Daimler | AHS-C | Hybrid |
BMW BREAKDOWN DESIGNATION - AUTOMATIC TRANSMISSION
Note. The universal transmission bracket is introduced for the E60 AWD Suitable for manual and automatic transmissions
| IMPORTANT | Front and rear supports (1) can be laterally adjusted by means of screws (2). Carrier (3) of rear supports (1) can be longitudinally adjusted by means of screw. Supports must be adapted in length and width to the transmission. |
Scheme 282
Support transmission with special tools 234050 and 002030.
| IMPORTANT | Transmission must be secured with tensioning strap (1). |
Note. The transmission retaining bridge 240200 is suitable for both manual and automatic transmissions
| IMPORTANT | Adapters and spindles must be adapted for positive locking to the transmission. (Risk of injury) |
Adapt adapters (1) and spindle with thrust piece (3) to transmission.
Adapt length with slide (2).
Screw in spindle (4).
| IMPORTANT | Before mounting on assembly stand 00 1 450, check retaining bridge for secure seating. |
Scheme 283
23 14 550 Removing/replacing zero gear sensor
| IMPORTANT | After installing the zero gear sensor, it is necessary to teach in the position of the zero gear sensor again. Calibration is carried out using the BMW Diagnosis System "Service Function" (Learn/record zero-gear sensor). |
- Lower transmission
Tasks are described in Removing TRANSMISSION .
Disconnect plug connection (1) on zero gear sensor.
Unfasten screws (2).
Remove zero gear sensor.
Tightening torque 23 14 2AZ .
Scheme 284
23 11 614 Replacing guide tube for clutch release unit (GS6-53BZ) (S85/S65)
Note. (transmission removed)
- Remove «CLUTCH RELEASE BEARING AND RELEASE LEVER»(/bmw/m3/e90-2007-2013/remont/clutches-manual-hydraulic/#clutch-repair-e90__21-51-500-removing-and-installing) from guide tube
Release screws.
Remove guide tube (1).
| IMPORTANT | Guide tube is coated with Teflon and must not be greased. |
Clean thread.
Install screws with Loctite 243.
Tightening torque 23 11 2AZ .
Scheme 285
Note. Remove sticker (1) and adhesive with a suitable solvent.
Scheme 286
- Remove rear underbody protection
GS6-17DG/BG and GS6-37DG/BG transmissions only.
Disconnect plug connection (1) on reverse gear switch.
Remove reverse gear switch.
Tightening torque 23 14 1AZ.
Note. Illustration similar
Scheme 287
GS6-53DG/BG transmission only
Disconnect plug connection (1) on reverse gear switch.
Remove reverse gear switch.
Tightening torque 23 14 1AZ.
Note. Illustration similar
Scheme 288
| IMPORTANT | After completion of work, check TRANSMISSION FLUID LEVEL . Use only approved fluid. See MANUAL TRANSMISSION - OPERATING FLUIDS . Failure to comply with this requirement will result in serious damage to the automatic transmission! |
Necessary preliminary tasks
- Remove «TRANSMISSION»(/bmw/m3/e90-2007-2013/remont/manual-trans/#manual-transmission-repair-e90) .
- Remove «CLUTCH RELEASE UNIT AND RELEASE LEVER»(/bmw/m3/e90-2007-2013/remont/clutches-manual-hydraulic/#clutch-repair-e90__21-51-500-removing-and-installing) from guide tube.
Release screws.
Tightening torque: 23 11 2AZ .
Remove guide tube (1).
Installation
Clean guide tube.
Do not grease guide tube.
Drive a hole into radial shaft seal (1) using a center punch.
| IMPORTANT | Do not use a drill as drillings may result in transmission malfunction. |
Screw in special tool 230490.
Drive out radial shaft seal (1) with impact weight (2).
Scheme 289
Installation
Coat sealing lips of radial seal with gear oil.
Push radial seal (1) onto drive shaft up to housing.
Drive in radial seal (1) as far as it will go with special tool 233240 and plastic hammer.
Scheme 290
| IMPORTANT | After completion of work, check TRANSMISSION OIL LEVEL . Use only approved fluids. See MANUAL TRANSMISSION - OPERATING FLUIDS . Failure to comply with this instruction will result in serious damage to the transmission. |
Necessary preliminary tasks
- Unflange propeller shaft from transmission and tie up to one side. Tasks are described in Removing propeller shaft.
Brace output flange with special tool 230020.
Release collar nut with special tool 232320.
Release E90, 91 M57T2, E60S85 with special tool 230200.
Installation
Mark flange with thermo pin and heat to min. 80°- 100°.
Scheme 291
| WARNING | Scalding hazard! Fit flange wearing suitable protective gloves only! |
| IMPORTANT | Do not drive on flange. |
Secure collar nut with Loctite 243.
- Loctite 243: BMW Parts Service.
- Tightening torque: «23 21 1AZ»(ref-381603-S30720459382010123000000) .
Detach output flange (1) with special tool 331150 and adapter plate 33 1 154 from output shaft.
Scheme 292
Release screw on special tool 233210.
Slide special tool 233210 over output shaft and screw into sealing ring firmly.
Scheme 293
Insert screw into special tool 233210 again and continue turning until sealing ring is pulled out of transmission housing.
If necessary, remove ring spring of sealing ring.
Scheme 294
Installation
Coat sealing lips of new radial seal with gear oil.
Drive in radial seal as far as it will go with special tool 233230 and plastic hammer.
Scheme 295
| IMPORTANT | After completion of work, check TRANSMISSION OIL LEVEL . Use only approved MANUAL TRANSMISSION - OPERATING FLUIDS . Failure to comply with this instruction will result in serious damage to the transmission. |
Necessary preliminary tasks
- Shift transmission into 2nd gear
- Unflange propeller shaft from transmission.
Tasks are described in Removing propeller shaft.
Lever retaining ring (1) out of groove with a small screwdriver.
Slide locking ring (1) towards rear.
Drive out cylinder pin (2).
Scheme 296
Screw in special tool 230210 until it is firmly connected with radial seal (1).
Pull out radial seal with special tool 230210.
Scheme 297
Coat sealing lips of radial seal and selector shaft with transmission oil.
Drive in radial seal with special tool 230220.
Scheme 298
23 12 506 Replacing the drive shaft radial shaft seal (GS6-85BG)
Note. After completion of work, check gearbox oil level. Use only the approved gearbox oil. Failure to comply with this requirement will result in serious damage to the manual transmission!
Necessary preliminary work
- Remove transmission.
- Remove clutch release bearing.
Release bolts (1) and remove guide tube (2).
Scheme 299
Note. The shaft seal and the guide tube are replaced together.
Installation note
Wrap adhesive tape round keyway splines of drive shaft to avoid damaging the sealing ring while it is being installed.
Lubricate sealing lip of sealing ring.
Replace mounting bolts of guide bush.
Tightening torque, see 23 11 1AZ in 23 11 CASE AND COVER .
| IMPORTANT | After installing the zero gear sensor, it is necessary to teach in the position of the zero gear sensor again. Calibration is carried out using the BMW Diagnosis System "Service Function" (Learn/record zero-gear sensor). |
- Lower transmission
Tasks are described in Removing TRANSMISSION .
Disconnect plug connection (1) on zero gear sensor.
Unfasten screws (2).
Remove zero gear sensor.
Tightening torque 23 14 2AZ .
- Remove rear underbody protection
GS6-17DG/BG and GS6-37DG/BG transmissions only.
Disconnect plug connection (1) on reverse gear switch.
Remove reverse gear switch.
Tightening torque 23 14 1AZ.
Note. Illustration similar
GS6-53DG/BG transmission only
Disconnect plug connection (1) on reverse gear switch.
Remove reverse gear switch.
Tightening torque 23 14 1AZ.
Note. Illustration similar
- Remove underbody protection
- If necessary, remove left heat shields
| IMPORTANT | After completion of work, check TRANSMISSION FLUID LEVEL . |
Catch and dispose of gear oil with suitable equipment.
Observe country-specific waste-disposal regulations.
Unlock plug (1) and remove.
Remove oil temperature sensor (2).
Scheme 300
See also:
• MANUAL TRANSMISSION - OPERATING FLUIDS
• REAR UNDERBODY PROTECTION
• RELEASE BEARING AND RELEASE LEVER
• PULSE GENERATOR, CRANKSHAFT/TRANSMISSION
• CLAMP OFF BATTERY
• REMOVE PROPELLER SHAFT
• FRONT UNDERBODY PROTECTION
• 21 52 5AZ
• CROSSMEMBER FOR TRANSMISSION MOUNTING (S65)
• GEAR SHIFT MECHANISM - OPERATING FLUIDS
• REPLACE CLUTCH PLATE
• 21 2 240
• TRANSMISSION FLUID LEVEL
• TRANSMISSION FLUID LEVEL
• REMOVE TRANSMISSION
• DANGER OF POISONING
• RISK OF INJURY
