23 0 000 Attachment
Note. For car jack, for removing and installing manual and automatic transmissions
Order number: 23 0 000
Attachment
Special Tool (23 0 000). Scheme 47
23 0 020 Holder
Minimum set: Mechanical tools
Note. For all three- and four-hole flanges during releasing and tightening down
Series: E38, E39, E46, E52, E53, E60, E61, E63, E64, E65, E66, E67, E70, E71, E81, E82, E83, E85, E86, E87, E88, E90, E91, E92, E93, F01, F02
Transmission: A4S 200R, A5S 360R, A5S 390R, GA6 HP19Z, GA6 HP26Z, GA6 HP32Z, GS6-17BG, rear diff. type M, S5D 200G, S5D 250G
Storage location: A1, B1, C1
Special Tool (23 0 020). Scheme 48
Order number: 23 0 020
Holder
23 0 030 Support
Note. For Getrag transmission
Transmission: 280/5 Sport
Order number: 23 0 030
Support
Special Tool (23 0 030). Scheme 49
23 0 040 Support
In conjunction with: 00 2 030
Note. For transmissions for removal and installation. Replaced by 23 0 110.
Transmission: S6S 420G, S6S 560G
SI number: 1 05 90(207)
Order number: 23 0 040
Support
Special Tool (23 0 040). Scheme 50
Consisting of
1 = 23 0 041 Locating cage
Note. Transmission: S6S 560G
2 = 23 0 042 Support bracket
Note. Transmission: S6S 420G
23 0 050 Support
In conjunction with: 00 1 450
Note. For all 4-speed and 5-speed transmissions
Transmission: 242/4
Order number: 23 0 050
Support
Special Tool (23 0 050). Scheme 51
23 0 060 Support
In conjunction with: 00 1 450
Note. For Getrag transmission
Transmission: 245/5, 245/5 Sport
Order number: 23 0 060
Support
Special Tool (23 0 060). Scheme 52
23 0 070 Mounting bracket
In conjunction with: 00 1 450
Note. For Getrag transmission
Transmission: 265/5, 265/5 Sport
Order number: 23 0 070
Mounting bracket
Special Tool (23 0 070). Scheme 53
23 0 080 Fixture
Note. For removing 5th gear wheel
Transmission: 265/5, 265/5 Sport, 280/5 Sport
Order number: 23 0 080
Fixture
Consisting of
23 0 081 Puller jaws (2)
Special Tool (23 0 080). Scheme 54
23 0 090 Support
In conjunction with: 00 1 450
Note. For ZF and Getrag transmissions
Transmission: 240/5, 260/5, ZF S5-16
Order number: 23 0 090
Support
Special Tool (23 0 090). Scheme 55
23 0 100 Support
In conjunction with: 00 1 450
Note. For mounting transmission on assembly stand
Transmission: S5D 200G, S5D 250G, S5D 260Z, S5D 310Z, S5D 320Z
SI number: 1 07 90 (244)
Order number: 23 0 100
Support
Special Tool (23 0 100). Scheme 56
23 0 110 Support
In conjunction with: 00 2 030
Note. For removing and installing transmission.
Transmission: S6S 420G, S6S 560G
SI number: 1 02 00 (551)
Order number: 23 0 110
Support
Consisting of
Special Tool (23 0 110). Scheme 57
1 = 23 0 111 Take-up support
Note. Transmission: S6S 560G
2 = 23 0 112 Locating bracket (not shown)
Note. Transmission: S6S 420G
In conjunction with: 21 0 111 Take-up support
23 0 130 Take-up support for transmission
In conjunction with: 00 2 030
Note. For accommodating transmission during removal and installation.
Series: E39, E46, E52, E53, E60, E61, E63, E64, E65, E66, E67, E70, E83, E85, E86, E87, E90, E91, E92, E93
Transmission: GS6-17BG, GS6-37BZ, GS6-37DZ, GS6-53BZ, GS6-53DZ, GS7S47BG, S5D 280Z, S5D 320Z
SI number: 1 06 00 (575)
Special Tool (23 0 130). Scheme 58
Order number: 23 0 130
Take-up support for transmission
Consisting of
1 = 23 0 131 Basic body
2 = 23 0 132 Adjusting unit
3 = 23 0 133 Take-up support
Note. Transmission: S5D 280Z in E53
4 = 23 0 134 Take-up support
Note. Transmission: GS6-37BZ (H-transmission), GS6-17BG (i-transmission)
5 = 23 0 135 Take-up support
Note. Transmission: GS6-37BZ, GS6-53BZ SMG H-SMG
In conjunction with: 23 0 131/132, 23 0 134 (front take-up support)
6 = 23 0 136 Take-up support
Note. Transmission: GS6-53BZ, GS6-53DZ
7 = 23 0 137 Take-up support
Note. Transmission: GS6 37BZ, GS6 37DZ (H-transmission) in E87, E90.
In conjunction with: 23 0 131/132/134/136
23 0 138 Take-up support
Note. Transmission: GS6 37DZ (H-transmission) in E83/M47TU.
In conjunction with: 23 0 131/132/133
23 0 139 Take-up support
Note. Transmission: GS7S47BG in E60/S85 (M5)
In conjunction with: 23 0 131/132/133
23 0 140 Support
In conjunction with: 00 2 030
Note. For accommodating transmission during removal and installation. Transmission: F-transmission
Transmission: S5D 320Z, S5D 390Z
SI number: 1 20 98(378)
Order number: 23 0 140
Support
Special Tool (23 0 140). Scheme 59
23 0 150 Support
In conjunction with: 00 1 450
Note. For accommodating transmission on assembly stand. For ZF transmission.
Transmission: ZF S5-16
Order number: 23 0 150
Support
Special Tool (23 0 150). Scheme 60
23 0 160 Support
In conjunction with: 00 1 450
Note. For Getrag transmission
Transmission: 262/4
Order number: 23 0 160
Support
23 0 170 Support
In conjunction with: 00 1 450
Note. For mounting F-transmission on assembly stand
Transmission: S5D 390Z
SI number: 1 14 99(482)
Order number: 23 0 170
Support
Special Tool (23 0 170). Scheme 61
Consisting of
1 = 23 0 171 Basic body
2 = 23 0 172 Spindle (2)
Note. With handle
23 0 180 Impact ring with slip sleeve
Minimum set: Mechanical tools
In conjunction with: 23 2 491
Note. For driving in radial shaft seal on drive side - F transmission
Transmission: S5D 390Z
SI number: 1 14 99(482)
Order number: 23 0 180
Impact ring with slip sleeve
Special Tool (23 0 180). Scheme 62
Consisting of
1 = 23 0 181 Impact ring
2 = 23 0 182 Slip sleeve
23 0 190 Impact bush
Minimum set: Mechanical tools
Note. For driving in radial shaft seal on output side -F transmission
Transmission: S5D 280Z, S5D 320Z, S5D 390Z
Storage location: B39
SI number: 1 14 99(482)
Order number: 23 0 190
Impact bush
Special Tool (23 0 190). Scheme 63
23 0 200 Socket 41 A/F
Minimum set: Mechanical tools
Note. Long version for releasing and tightening down output flange - F-transmission
Transmission: S5D 390Z
SI number: 1 14 99(482)
Order number: 23 0 200
Socket 41 A/F
Special Tool (23 0 200). Scheme 64
23 0 210 Extractor
Minimum set: Mechanical tools
Note. For removing rotary shaft seal on selector shaft - F-transmission
Transmission: GS6-17BG, S5D 200G, S5D 250G, S5D 260Z, S5D 280Z, S5D 310Z, S5D 320Z, S5D 390Z, S6S 420G
Storage location: A12
SI number: 1 14 99 (482)
Order number: 23 0 210
Extractor
Special Tool (23 0 210). Scheme 65
Consisting of
1 = 23 0 211 Basic body
2 = 23 0 212 Spindle
23 0 220 Impact bush
Minimum set: Mechanical tools
Note. For driving in radial shaft seal on selector shaft -F transmission
Transmission: GS6-17BG, S5D 200G, S5D 250G, S5D 260Z, S5D 280Z, S5D 310Z, S5D 320Z, S5D 390Z, S6S 420G
Storage location: B15
SI number: 1 14 99 (482)
Order number: 23 0 220
Special Tool (23 0 220). Scheme 66
Impact bush
23 0 250 Holder
Minimum set: Mechanical tools
Note. Assistance in releasing and tightening down output flange
Transmission: GS5-39DZ, S5D 280Z, S5D 320Z
Storage location: B41
SI number: 1 06 00(575)
Order number: 23 0 250
Holder
Special Tool (23 0 250). Scheme 67
23 0 320 Drift
Minimum set: Mechanical tools
Note. For driving in shaft seal on drive shaft.
Series: E60, E82, E87, E90, E91, E92
Transmission: GS6-17BG
Storage location: B54
SI number: 01 06 06 (249)
Order number: 23 0 320
Drift
Special Tool (23 0 320). Scheme 68
23 0 370 Drift
Minimum set: Mechanical tools
Note. For driving in shaft seal on differential on left and right (output shaft).
Transmission: GS6-53BG, GS6-55BG
SI number: 01 23 06 (308)
Order number: 23 0 370
Drift
Special Tool (23 0 370). Scheme 69
23 0 490 Extractor
Note. For removing shaft seal
Transmission: GA6 HP19Z, GA6 HP26Z, GA6 HP32Z, GS5-39DZ, GS5-65BH, GS6-17BG, GS7S47BG, S5D 200G, S5D 250G, S5D 260Z, S5D 280Z, S5D 310Z, S5D 320Z, S5D 390Z, S6S 420G, S6S 560G
Storage location: A13, B13
SI number: 1 15 96 (106)
Order number: 23 0 490
Special Tool (23 0 490). Scheme 70
Extractor
Consisting of
1 = 23 0 491 Rod
Note. With self-tapping screw
2 = 23 0 492 Impact weight
23 1 000 Fixture
Note. For pressing-on transmission casing and deep groove ball bearing on transmission input shaft and in transmission casing
Transmission: 240/5, 242/4, 245/5, 245/5 Sport, 260/5, 262/4, 265/5, 265/5Sport, 280/5Sport, 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A4S 270R, A4S 310R, A5S 300J, A5S 310Z, A5S 440Z, A5S 560Z, BW 65, S5D 260Z
Storage location: C15, C16
Special Tool (23 1 000). Scheme 71
Order number: 23 1 000
Fixture
Consisting of
1 = 23 1 001 Sleeve
2 = 23 1 002 Dowel pin (2 x)
3 = 23 1 003 Thrust piece, long
4 = 23 1 004 Thrust piece, short
5 = 23 1 005 Handle
7 = 23 1 007 Thrust piece for Getrag transmissions
23 1 010 Fixture for removing rear section of transmission casing
Transmission: 280/5 Sport
Order number: 23 1 010
Fixture for removing rear section of transmission casing
Special Tool (23 1 010). Scheme 72
23 1 020 Fixture for removing transmission casing (front and rear section)
In conjunction with: 33 1 301
Transmission: 245/5 Sport
Storage location: C32
Order number: 23 1 020
Fixture for removing transmission casing (front and rear section)
Special Tool (23 1 020). Scheme 73
23 1 030 Drift for fitting inner bearing race on countershaft
Transmission: 245/5, 265/5
Storage location: C22
Order number: 23 1 030
Drift for fitting inner bearing race on countershaft
Special Tool (23 1 030). Scheme 74
23 1 040 Drift
Note. For mounting sliding section (5th gear) and driving water pipe out of crankcase Engine: N73
Transmission: 245/5Sport, S5D 200G, S5D 250G
Storage location: C23
Order number: 23 1 040
Drift
Special Tool (23 1 040). Scheme 75
23 1 050 Puller (Kukko)
Note. For 5th gear as well as reverse gear wheel
Transmission: 240/5, 245/5, 260/5, 265/5Sport, 280/5Sport, S5D 260Z, S5D 310Z, S5D 320Z, ZF S5-16
Order number: 23 1 050
Puller (Kukko)
Consisting of
1 = 23 1 051 Claw
Special Tool (23 1 050). Scheme 76
23 1 060 Fixture
In conjunction with: 33 1 301
Note. For removing inner bearing race - reverse gear wheel
Transmission: 245/5, 265/5 Sport
Storage location: B20
Order number: 23 1 060
Fixture
Consisting of
Special Tool (23 1 060). Scheme 77
1 = 23 1 061 Shells (2)
2 = 23 1 062 Threaded ring
3 = 23 1 063 Holding sleeve
23 1 070 Measuring ring
Note. For determining shim ring between outer bearing race and circlip of countershaft
Transmission: 245/5
Storage location: B28
Order number: 23 1 070
Measuring ring
Special Tool (23 1 070). Scheme 78
23 1 080 Drift
In conjunction with: 00 5 500
Note. For removing and installing outer bearing race in front section of transmission casing/centre section of countershaft and of ball bearing in rear section of transmission casing, input shaft
Transmission: 245/5, 265/5
Storage location: A28
Special Tool (23 1 080). Scheme 79
Order number: 23 1 080
Drift
23 1 090 Drift
In conjunction with: 00 5 500
Note. For removing and installing outer bearing race of input shaft in front section of transmission casing
Transmission: 245/5, 265/5, GS5-65BH
Storage location: A28
Order number: 23 1 090
Special Tool (23 1 090). Scheme 80
Drift
23 1 100 Puller claws
In conjunction with: 00 7 500
Note. For speedometer gear
Transmission: 245/5, 265/5, 280/5Sport
Storage location: B29
Order number: 23 1 100
Puller claws
Special Tool (23 1 100). Scheme 81
23 1 110 Drift
In conjunction with: 00 5 500
Note. For installing bearing of output shaft in rear section of transmission casing
Transmission: 245/5
Storage location: A28
Order number: 23 1 110
Drift
Special Tool (23 1 110). Scheme 82
23 1 120 Drift
In conjunction with: 00 5 500
Note. For removing outer bearing race of countershaft in centre section of transmission casing
Transmission: 240/5, 245/5, 260/5, 280/5Sport, ZF S5-16
Storage location: A29
Order number: 23 1 120
Special Tool (23 1 120). Scheme 83
Drift
23 1 130 Drift
Note. For removing bearing of input shaft and roller bearing in centre section of transmission casing
Transmission: 245/5, 280/5Sport
Storage location: A29
Order number: 23 1 130
Drift
Special Tool (23 1 130). Scheme 84
23 1 160 Drift
Note. For fitting inner bearing race and bearing sleeve on output shaft (245) - fitting slide (5th gear - 265/5) - mounting output flange - mounting bearing on countershaft (S5D 310Z) - mounting centre bearing on propeller shaft, E46
Series: E36, E38, E46, E65, E70, E81, E85, E86, E87, E90, E92, E93, F01, F02
Transmission: 242/4, 245/5, 265/5, 280/5Sport, A5S 310Z, S5D 260Z, S5D 310Z, S5D 320Z
Storage location: B17
Special Tool (23 1 160). Scheme 85
Order number: 23 1 160
Drift
23 1 170 Fixture
Note. For removing front section of transmission casing
Transmission: 265/5
Order number: 23 1 170
Fixture
Consisting of
1 = 23 1 171 Plate
2 = 23 1 172 Knurled screw (3)
Special Tool (23 1 170). Scheme 86
23 1 180 Drift
In conjunction with: 00 0 500
Note. For fitting rotary shaft seal in guide tube of clutch release mechanism
Transmission: 260/5, 265/5, 265/5Sport, 280/5Sport
Storage location: A29
Order number: 23 1 180
Drift
Special Tool (23 1 180). Scheme 87
23 1 190 Drift
In conjunction with: 00 5 500
Note. For removing and installing ball bearing of input shaft in front section of transmission casing
Transmission: 265/5, 280/5 Sport
Order number: 23 1 190
Drift
Special Tool (23 1 190). Scheme 88
23 1 200 Guide bush
In conjunction with: 23 1 210
Note. For centering wrench socket when releasing and tightening transmission output flange and input flange of rear axle differential
Transmission: 265/5
Storage location: B30
Order number: 23 1 200
Guide bush
Special Tool (23 1 200). Scheme 89
23 1 210 Wrench socket WAF 30
In conjunction with: 23 1 200 and torque wrench
Note. For releasing and tightening transmission output flange and input flange of rear axle differential
Series: E82, E87, E90, E91, E92
Transmission: 240/5, 242/4, 245/5, 245/5Sport, 260/5, 262/4, 265/5, 265/5Sport, 280/5Sport, 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A4S 270R, A4S 310R, A5S 300J, A5S 310Z, A5S 440Z, A5S 560Z, BW 65, GS6-17BG, S5D 200G, S5D 250G
Special Tool (23 1 210). Scheme 90
Storage location: A9
Order number: 23 1 210
Wrench socket WAF 30
23 1 220 Drift
In conjunction with: 00 5 500
Note. For removing and installing roller bearing of countershaft shaft in front section of transmission casing
Transmission: 260/5, 265/5, A5S 310Z
Storage location: A29
Order number: 23 1 220
Special Tool (23 1 220). Scheme 91
Drift
23 1 230 Spindle (2)
In conjunction with: 00 7 500
Note. For removing inner bearing race from input shaft in front section of transmission casing
Transmission: 265/5
Order number: 23 1 230
Spindle (2)
Special Tool (23 1 230). Scheme 92
23 1 240 Drift
Minimum set: Mechanical tools
Note. For fitting rotary shaft seal on gearshift shaft
Transmission: 240/5, 242/4, 245/5, 245/5Sport, 260/5, 262/4, 265/5, 265/5Sport, 280/5Sport, 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A4S 270R, A4S 310R, A5S 300J, A5S 310Z, A5S 440Z, A5S 560Z, BW 65, S5D 200G, S5D 250G, S6S 420G, ZF S5-16
Storage location: A20
Order number: 23 1 240
Special Tool (23 1 240). Scheme 93
Drift
23 1 270 Drift
In conjunction with: 00 5 500
Note. For removing outer bearing race on countershaft in front section of transmission casing as well as for removing seal and needle bearing from oil pump housing (A5S 560Z)
Transmission: 240/5, 260/5, A5S 560Z
Storage location: A29
Order number: 23 1 270
Special Tool (23 1 270). Scheme 94
Drift
23 1 300 Fixture
Minimum set: Mechanical tools
In conjunction with: 23 2 150
Note. For fitting output flange on all manual and automatic transmissions, for installing deep groove ball bearing on transmission output shafts and for fitting input flange on all rear axle differentials
Series: E36, E36/2, E36/3, E36/5, E36/7, E36/C, E38, E39, E46, E52, E53, E60, E61, E63, E64, E65, E66, E67, E81, E82, E83, E85, E86, E87, E88, E90, E91, E92, E93
Special Tool (23 1 300). Scheme 95
Transmission: Rear diff. 188kom, rear diff. 220kom, rear diff. 225kom, rear diff. Type G, rear diff. Type K, rear diff. Type M, S5D 200G, S5D 250G
Storage location: C17
Order number: 23 1 300
Fixture
Consisting of
1 = 23 1 301 Adapter
2 = 23 1 302 Support disc
Note. For pressing drive flange onto rear differential
In conjunction with: 33 1 341, 23 1 300
3 = 23 1 303 Mandrel
23 1 310 Tool
Note. For fitting locking device on deflection lever
Transmission: 280/5 Sport
Order number: 23 1 310
Tool
Special Tool (23 1 310). Scheme 96
23 1 350 Puller fixture
In conjunction with: 33 1 301
Note. For rear section of transmission casing
Transmission: 265/5
Order number: 23 1 350
Puller fixture
Consisting of
1 = 23 1 351 Plate
Special Tool (23 1 350). Scheme 97
2 = 23 1 352 Screw, short (2)
3 = 23 1 353 Screw, long (2)
23 1 360 Drift
In conjunction with: 00 5 500
Note. For fitting rotary shaft seal on transmission input shaft
Transmission: 240/5, 245/5, 262/4, ZF S5-16
Storage location: A35
Order number: 23 1 360
Drift
Special Tool (23 1 360). Scheme 98
23 1 370 Drift
Note. For fitting rotary shaft seals on transmission output flanges
Transmission: 242/4, 262/4, 265/5, 265/5Sport
Storage location: B28
Order number: 23 1 370
Drift
Special Tool (23 1 370). Scheme 99
23 1 380 Drift
In conjunction with: 00 0 500
Note. For installing roller bearing of countershaft shaft in rear section of transmission casing
Transmission: 240/5, 245/5, 260/5, 280/5Sport
Storage location: B30
Order number: 23 1 380
Drift
Special Tool (23 1 380). Scheme 100
23 1 390 Drift
In conjunction with: 00 5 500
Note. For installing roller bearing of countershaft shaft in rear section of transmission casing
Transmission: 265/5, 280/5 Sport
Storage location: A29
Order number: 23 1 390
Drift
Special Tool (23 1 390). Scheme 101
23 1 400 Fixture
Note. For fitting rotary shaft seal in bush of speedometer pinion
Transmission: 242/4, 262/4
Order number: 23 1 400
Fixture
Consisting of
1 = 23 1 401 Fitting shaft
2 = 23 1 402 Radial plug
Special Tool (23 1 400). Scheme 102
3 = 23 1 403 Union sleeve
23 1 410 Drift
In conjunction with: 00 5 500
Note. For fitting ball bearing of output shaft in rear section of transmission casing and roller bearing of output shaft in centre section of transmission casing
Transmission: 260/5, 265/5
Storage location: A29
Order number: 23 1 410
Special Tool (23 1 410). Scheme 103
Drift
23 1 420 Fixture
In conjunction with: 33 1 301
Note. For removing slide (5th gear)
Transmission: 265/5
Storage location: C31
Order number: 23 1 420
Fixture
Consisting of
Special Tool (23 1 420). Scheme 104
23 1 421 Clamping screw
23 1 430 Thrust piece
Note. For fitting 5th gear wheel
Transmission: 265/5, 280/5 Sport
Storage location: A35
Order number: 23 1 430
Thrust piece
Special Tool (23 1 430). Scheme 105
23 1 440 Holding sleeve
Note. For fitting bearing bush and inner bearing race on output shaft as well as for removing bearing on output shaft (S5D 310Z)
Transmission: 265/5, 265/5Sport, 280/5Sport, S5D 310Z
Storage location: C22, C23
Order number: 23 1 440
Holding sleeve
Special Tool (23 1 440). Scheme 106
23 1 450 Guide pins (2 x)
Note. For fitting bearing bush in locking device of guide sleeve
Transmission: 245/5, 265/5
Storage location: C3
Order number: 23 1 450
Guide pins (2 x)
Special Tool (23 1 450). Scheme 107
23 1 460 Puller plate
In conjunction with: 33 1 301
Note. For front section of transmission casing
Transmission: 260/5, 280/5Sport, ZF S5-16
Storage location: A27
Order number: 23 1 460
Puller plate
Special Tool (23 1 460). Scheme 108
23 1 480 Drift
In conjunction with: 00 5 500
Note. For removing and installing deep groove ball bearing in front section of transmission casing
Transmission: 240/5, 242/4, 260/5, 280/5Sport
Storage location: A29
Order number: 23 1 480
Special Tool (23 1 480). Scheme 109
Drift
23 1 490 Fixture
Note. For removing gear wheels
Transmission: 240/5, 260/5, 280/5Sport, S5D 200G, ZF S5-16
Order number: 23 1 490
Fixture
Consisting of
23 1 491 Spacer
Special Tool (23 1 490). Scheme 110
23 2 000 Rillex ball bearing extractor 6206
Note. 9 balls with steel cage - for removing deep groove ball bearing of transmission input shaft
Order number: 23 2 000
Rillex ball bearing extractor 6206
Consisting of
1 = 23 2 001 Claw for Rillex 6206 (9 x)
2 = 23 2 002 Union sleeve
Special Tool (23 2 000). Scheme 111
3 = 23 2 003 Pressure spindle
23 2 010 Rillex ball bearing extractor 6206 E
Note. 8 balls with plastic cage - for removing deep groove ball bearing of transmission input shaft
Transmission: 242/4, 245/5Sport, 265/5
Order number: 23 2 010
Rillex ball bearing extractor 6206 E
Consisting of
1 = 23 2 011 Claw for Rillex 6206 E (8)
Special Tool (23 2 010). Scheme 112
2 = 23 2 012 Union sleeve
3 = 23 2 013 Pressure spindle
23 2 020 Rillex ball bearing extractor
Note. 7 balls - for removing deep groove ball bearing of transmission input shaft
Transmission: 245/5 Sport, 265/5 Sport
Order number: 23 2 020
Rillex ball bearing extractor
Consisting of
1 = 23 2 021 Claw for Rillex (7)
2 = 23 2 022 Union sleeve
Special Tool (23 2 020). Scheme 113
3 = 23 2 023 Pressure spindle
23 2 050 Rillex ball bearing extractor 6205
Note. For removing deep groove ball bearing of transmission countershaft and transmission output shaft
Transmission: 245/5 Sport, 262/4, 265/5 Sport
Order number: 23 2 050
Rillex ball bearing extractor 6205
Consisting of
1 = 23 2 051 Claw for Rillex 6305 (8)
Special Tool (23 2 050). Scheme 114
2 = 23 2 052 Union sleeve
3 = 23 2 053 Pressure spindle
23 2 060 Rillex ball bearing extractor 6306
Note. For removing deep groove ball bearing of input and output shaft
Transmission: 242/4, 262/4
Order number: 23 2 060
Rillex ball bearing extractor 6306
Consisting of
1 = 23 2 061 Claw for Rillex 6306 (8)
2 = 23 2 062 Union sleeve
Special Tool (23 2 060). Scheme 115
3 = 23 2 063 Pressure spindle
23 2 080 Adapter
Note. For removing guide sleeve - 2nd/3rd gear
Transmission: 260/5
Storage location: C21
Order number: 23 2 080
Adapter
Special Tool (23 2 080). Scheme 116
23 2 100 Pliers
Note. For removing and installing circlip on transmission output shaft
Transmission: 240/5, 242/4, 245/5, 245/5Sport, 260/5, 262/4, 265/5, 265/5Sport, 280/5Sport, 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A4S 270R, A4S 310R, A5S 300J, A5S 310Z, A5S 440Z, A5S 560Z, BW 65, S5D 200G, S5D 250G, S5D 260Z, S5D 310Z, S6S 420G, S6S 560G, ZF S5-16
Order number: 23 2 100
Pliers
Special Tool (23 2 100). Scheme 117
23 2 150 Pressure sleeve
In conjunction with: 23 1 300
Note. For fitting deep groove ball bearing of transmission output shaft (260/5, 245/5), for fitting front tapered roller bearing on drive pinion in all rear axle differentials as well as for mounting cover of countershaft (S5D 310Z)
Transmission: 245/5Sport, 260/5, S5D 260Z, S5D 310Z, S5D 320Z
Storage location: B29
Special Tool (23 2 150). Scheme 118
Order number: 23 2 150
Pressure sleeve
Note. For rotary shaft seal in rear section of transmission housing - output shaft
Transmission: 280/5Sport, ZF S5-16
Storage location: B28
Order number: 23 2 160
Impact bush
Special Tool (23 2 150). Scheme 119
23 2 170 Fixture
Note. For tensioning transmission leaf spring
Transmission: ZF S5-16
Order number: 23 2 170
Fixture
Special Tool (23 2 170). Scheme 120
23 2 180 Guide bush
Note. For mounting front section of transmission casing on selector shaft
Transmission: ZF S5-16
Order number: 23 2 180
Guide bush
Special Tool (23 2 180). Scheme 121
23 2 200 Circlip pliers (straight)
Note. For removing and installing external circlips on transmission shafts
Transmission: 240/5, 242/4, 245/5, 245/5Sport, 260/5, 262/4, 265/5, 265/5Sport, 280/5Sport, 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A4S 270R, A4S 310R, A5S 300J, A5S 310Z, A5S 440Z, A5S 560Z, BW 65, S5D 200G, S5D 250G, S5D 260Z, S5D 310Z, S6S 420G, S6S 560G, ZF S5-16
Order number: 23 2 200
Circlip pliers (straight)
Special Tool (23 2 200). Scheme 122
23 2 210 Circlip pliers (straight)
Note. For removing and installing internal circlips in transmission casings when replacing deep groove ball bearings
Transmission: 240/5, 242/4, 245/5, 245/5Sport, 260/5, 262/4, 265/5, 265/5Sport, 280/5Sport, 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A4S 270R, A4S 310R, A5S 300J, A5S 310Z, A5S 440Z, A5S 560Z, BW 65, S5D 200G, S5D 250G, S5D 260Z, S5D 310Z, S6S 420G, S6S 560G, ZF S5-16
Order number: 23 2 210
Special Tool (23 2 210). Scheme 123
Circlip pliers (straight)
23 2 220 Drift
Note. For bearing of countershaft shaft in front and rear section of transmission casing
Transmission: ZF S5-16
Order number: 23 2 220
Drift
Special Tool (23 2 220). Scheme 124
23 2 230 Disc
In conjunction with: 00 7 500
Note. For removing guide sleeve from gear wheel or output shaft with toothed lock washer
Transmission: 280/5 Sport
Order number: 23 2 230
Disc
Special Tool (23 2 230). Scheme 125
23 2 250 Bracket
Note. For tensioning main shaft to countershaft
Transmission: S5D 310Z
Storage location: C20, C24
SI number: 1 07 90(244)
Order number: 23 2 250
Bracket
Special Tool (23 2 250). Scheme 126
23 2 260 Installation drift
Minimum set: Mechanical tools
Note. For fitting rotary shaft seal on selector shaft of rear section of transmission casing
Transmission: S5D 310Z
Storage location: A20
SI number: 1 07 90(244)
Order number: 23 2 260
Installation drift
Special Tool (23 2 260). Scheme 127
23 2 270 Fixture
Note. For centering selector shaft while mounting front section of transmission casing
Transmission: S5D 310Z
Storage location: C30
SI number: 1 07 90(244)
Order number: 23 2 270
Fixture
Special Tool (23 2 270). Scheme 128
23 2 280 Puller plate
In conjunction with: 33 1 301
Note. For front section of transmission casing
Transmission: S5D 310Z
Storage location: C31
SI number: 1 07 90(244)
Order number: 23 2 280
Puller plate
Special Tool (23 2 280). Scheme 129
23 2 290 Fixture
Note. For mounting front section of transmission casing
Transmission: S5D 310Z
Storage location: C18
SI number: 1 07 90(244)
Order number: 23 2 290
Fixture
Special Tool (23 2 290). Scheme 130
Consisting of
1 = 23 2 291 Base frame
2 = 23 2 292 Support
3 = 23 2 293 Ring
4 = 23 2 294 Set of shells
23 2 300 Drift
Minimum set: Mechanical tools
Note. For fitting rotary shaft seal of output shaft in rear section of transmission casing
Transmission: S5D 310Z
Storage location: B28
SI number: 1 07 90(244)
Order number: 23 2 300
Drift
Special Tool (23 2 300). Scheme 131
23 2 310 Fixture
Note. For removing 3rd and 4th gear wheel from countershaft
Transmission: S5D 310Z
Storage location: C30
SI number: 1 07 90(244)
Order number: 23 2 310
Fixture
Special Tool (23 2 310). Scheme 132
23 2 320 Socket for socket wrench WAF 36
Minimum set: Mechanical tools
Note. For loosening and tightening flanged nut
Transmission: S5D 310Z, S6S 420G, S6S 560G
Storage location: B30
SI number: 1 07 90(244)
Order number: 23 2 320
Socket for socket wrench WAF 36
Special Tool (23 2 320). Scheme 133
23 2 330 Fixture
Note. For installing complete gear train in rear section of transmission housing
Transmission: S5D 310Z
Storage location: C18
SI number: 1 07 90(244)
Order number: 23 2 330
Fixture
Special Tool (23 2 330). Scheme 134
23 2 340 Drift
Minimum set: Mechanical tools
Note. For fitting rotary shaft seal in front section of transmission casing
Transmission: S5D 310Z
Storage location: B29, C29
SI number: 1 07 90(244)
Order number: 23 2 340
Drift
Special Tool (23 2 340). Scheme 135
23 2 350 Drift
Note. For fitting sealing cover for notch pin of selector shaft
Transmission: S5D 310Z
Storage location: B14, C14
SI number: 1 07 90(244)
Order number: 23 2 350
Drift
Special Tool (23 2 350). Scheme 136
23 2 360 Drift
Note. For fitting end cover for notch pin
Transmission: S5D 310Z
Storage location: B14, C14
SI number: 1 07 90(244)
Order number: 23 2 360
Drift
Special Tool (23 2 360). Scheme 137
23 2 370 Fixture
In conjunction with: 23 1 050
Note. For removing gear train
Transmission: S5D 310Z
Storage location: C30
SI number: 1 02 91(330)
Order number: 23 2 370
Fixture
Special Tool (23 2 370). Scheme 138
23 2 380 Installation sleeve
Note. For retaining ring on input shaft
Transmission: S5D 310Z
Storage location: A5
SI number: 1 02 91(330)
Order number: 23 2 380
Installation sleeve
Special Tool (23 2 380). Scheme 139
23 2 460 Installation sleeve
Note. For retaining ring on input shaft
Transmission: S5D 200G, S5D 250G
Storage location: A6
SI number: 1 02 91(330)
Order number: 23 2 460
Installation sleeve
Special Tool (23 2 460). Scheme 140
23 2 470 Impact bush
Note. For fitting tab washer of securing nut on output flange
Transmission: S6S 420G, S6S 560G
Storage location: A25
SI number: 1 10 93(689)
Order number: 23 2 470
Impact bush
Special Tool (23 2 470). Scheme 141
23 2 480 Impact bush
Note. For installing radial seal on output shaft
Transmission: S6S 420G, S6S 560G
Storage location: A19
SI number: 1 10 93(689)
Order number: 23 2 480
Impact bush
Special Tool (23 2 480). Scheme 142
23 2 490 Impact bush and slip sleeve
Minimum set: Mechanical tools
Note. For fitting rotary shaft seal on input shaft
Transmission: GS5-65BH, S6S 420G, S6S 560G
Storage location: C29
SI number: 1 10 93(689)
Order number: 23 2 490
Impact bush and slip sleeve
Consisting of
Special Tool (23 2 490). Scheme 143
1 = 23 2 491 Impact bush
2 = 23 2 492 Slip sleeve (2-part)
23 3 010 Fixture
Note. For fitting output flange on output shaft
Transmission: S6S 420G, S6S 560G
Storage location: A26
SI number: 1 10 93(689)
Order number: 23 3 010
Fixture
Consisting of
Special Tool (23 3 010). Scheme 144
1 = 23 3 011 Adapter spindle
2 = 23 3 012 Pressure sleeve
3 = 23 3 013 Pressure nut with bearing
23 3 020 Mounting sleeve
Note. For installing gaiter of selector rod
Transmission: S6S 560G
Storage location: A14, B14
SI number: 1 10 93(689)
Order number: 23 3 020
Mounting sleeve
Special Tool (23 3 020). Scheme 145
23 3 110 Drift
Note. For driving in guide bushings for catch pins on manual transmissions.
Transmission: GS5-39DZ, S5D 280Z, S5D 320Z, S5D 390Z
SI number: 1 12 02 (918)
Order number: 23 3 110
Drift
Special Tool (23 3 110). Scheme 146
23 3 150 Set of tools
Minimum set: Mechanical tools
Note. For removing and installing shaft seal on drive shaft Transmission: GS6-37BZ/DZ (H-transmission)
Transmission: GS6-37BZ, GS6-37DZ
Storage location: B44, C44
SI number: 01 10 02 (907)
Order number: 23 3 150
Set of tools
Special Tool (23 3 150). Scheme 147
Consisting of
1 = 23 3 151 Extractor
2 = 23 3 152 Drift
23 3 160 Set of tools
Minimum set: Mechanical tools
Note. Removing and installing shaft seal on output shaft
Transmission: GS6-37BZ, GS6-51BZ
SI number: 01 10 02 (907)
Order number: 23 3 160
Set of tools
Consisting of
1 = 23 3 161 Extractor
Special Tool (23 3 160). Scheme 148
2 = 23 3 162 Drift
23 3 169 Set of tools
Minimum set: Mechanical tools
Note. Removing and installing shaft seals on output side
Transmission: GS6-37BZ
Order number: 23 3 169
Set of tools
23 3 200 Extractor
Minimum set: Mechanical tools
Note. For removing shaft seal on drive shaft
Transmission: GS6-53BZ, GS6-53DZ
Storage location: A49, A50
SI number: 1 11 04 (093)
Order number: 23 3 200
Extractor
Special Tool (23 3 200). Scheme 149
23 3 210 Extractor
Minimum set: Mechanical tools
Note. For removing shaft seal on output shaft
Transmission: GS6-53BZ, GS6-53DZ
Storage location: A50
SI number: 1 11 04 (093)
Order number: 23 3 210
Extractor
Special Tool (23 3 210). Scheme 150
23 3 220 Drift
Minimum set: Mechanical tools
Note. For driving in shaft seal on drive shaft (G-transmission)
Transmission: GS6-53BZ, GS6-53DZ
Storage location: A49
SI number: 1 11 04 (093)
Order number: 23 3 220
Drift
Special Tool (23 3 220). Scheme 151
23 3 230 Drift
Minimum set: Mechanical tools
Note. For driving in shaft seal on output shaft (G-transmission)
Transmission: GS6-53BZ, GS6-53DZ
Storage location: A49
SI number: 1 11 04 (093)
Order number: 23 3 230
Drift
Special Tool (23 3 230). Scheme 152
23 4 000 Drift set
Minimum set: Mechanical tools
In conjunction with: 00 5 500
Note. For driving shaft seal into transmission
Transmission: GS6-85BG
Storage location: A49, B84
SI number: 1 02 02(823)
Order number: 23 4 000
Drift set
Special Tool (23 4 000). Scheme 153
Consisting of
1 = 23 4 001 Drift dia. 67 mm
2 = 23 4 002 Drift dia. 53 mm
23 4 010 Removal tool
Minimum set: Mechanical tools
Note. For pressing connector out of transmission
Transmission: GS6-85BG
Storage location: B83
SI number: 1 02 02 (823)
Order number: 23 4 010
Removal tool
Special Tool (23 4 010). Scheme 154
23 4 020 Drifts
Note. For driving in bearing bushings for locking pins, 5th and reverse gears.
Transmission: GS5-39DZ, S5D 320Z
Storage location: B49
SI number: 1 03 04 (070)
Order number: 23 4 020
Drifts
Special Tool (23 4 020). Scheme 155
Consisting of
1 = 23 4 021 Drift
Note. For driving in cover caps on gear notch, 5th and reverse gears.
2 = 23 4 022 Drift
Note. For driving in bearing bushing for locking pin, 5th gear.
3 = 23 4 023 Drift
Note. For driving in bearing bushing for locking pin, reverse gear.
23 4 030 Fixture
In conjunction with: 23 4 040 Grease gun
Note. For removing and installing guide bearing (pilot bearing) in transmission input shaft.
Transmission: GS6-53DZ
SI number: 01 05 06 (248)
Order number: 23 4 030
Fixture
Special Tool (23 4 030). Scheme 156
Consisting of
1 = 23 4 031 Bridge
2 = 23 4 032 M10x120 screws with nuts (2 x)
3 = 23 4 033 Grease cartridge
4 = 23 4 034 Brass adapter
5 = 23 4 035 Pressure spindle
6 = 23 4 036 Thrust member
23 4 040 Grease gun
In conjunction with: 23 4 030
Note. For actuating cartridge 23 4 033.
Transmission: GS6-53DZ
SI number: 01 05 06 (248)
Order number: 23 4 040
Grease gun
Special Tool (23 4 040). Scheme 157
23 4 050 Universal transmission bracket
In conjunction with: 00 2 030 Hydraulic lifter
Note. Bracket for removing and installing manual and automatic transmissions for BMW and RR.
Transmission: 240/5, 242/4, 245/5, 245/5Sport, 260/5, 262/4, 265/5, 265/5Sport, 280/5Sport, 3 HP 12, 3 HP 20, 3 HP 22, 4 HP 22, 4 HP 24, A4S 200R, A4S 270R, A4S 310R, A5S 300J, A5S 310Z, A5S 325Z, A5S 360R, A5S 390G, A5S 390R, A5S 440Z, A5S 560Z, BW 65, GA6 HP19Z, GA6 HP26Z, GA6 HP32Z, GA6L45R, GS5-39DZ, GS6-17BG, GS6-37BZ, GS6-37DZ, GS6-53BG, GS6-53BZ, GS6-53DG, GS6-53DZ, GS7S47BG, S5D 200G, S5D 250G, S5D 260Z, S5D 280Z, S5D 310Z, S5D 320Z, S5D 390Z, S6S 420G, S6S 560G, ZF S5-16
Special Tool (23 4 050). Scheme 158
SI number: 1 07 06 (256)
Order number: 23 4 050
Universal transmission bracket
Consisting of
1 = 23 4 051 Joint
2 = 23 4 052 Base frame
3 = 23 4 053 Foam inserts (1 set = 4 pcs.)
4 = 23 4 054 Tensioning strap
5 = 23 4 055 Locator for foam material insert
23 4 150 Universal transmission bracket
In conjunction with: 00 2 030
Note. Bracket for removing and installing manual and automatic transmissions for MINI.
Transmission: GA6F21WA, GS6-53BG, GS6-55BG
SI number: 01 23 06 (308)
Order number: 23 4 150
Universal transmission bracket
Special Tool (23 4 150). Scheme 159
Consisting of
1 = 23 4 151 Joint
2 = 23 4 152 Base frame
3 = 23 4 153 Foam inserts (1 set = 4 pcs.)
4 = 23 4 154 Tensioning strap
5 = 23 4 155 Locator for foam material insert
