21 2 070 Gauge
Note. For checking lining thickness on clutch drive plate. Replaced in 8/95 by 21 2 080.
Transmission: S5D 200G, S5D 250G, S5D 260Z, S5D 310Z, S6S 420G, S6S 560G
Order number: 21 2 070
Gauge
Scheme 41
21 2 100 Drift
Note. For centering clutch disc while installing clutch
Transmission: 240/5, 260/5, 265/5, 265/5 Sport, 280/5 Sport
Storage location: C22
Order number: 21 2 100
Drift
Scheme 42
21 2 120 Clutch centering tool
Minimum set: Mechanical tools
Note. For centering drive plate when installing clutch and for pressing splined output shaft out of constant-velocity joint
Transmission: S6S 420G
Storage location: B4
SI number: 1 05 90 (207)
Order number: 21 2 120
Clutch centering tool
Scheme 43
21 2 130 Clutch centering tool
Minimum set: Mechanical tools
Note. For centering driving disc when installing clutch.
Transmission: S5D 200G, S5D 250G, S5D 260Z, S5D 310Z, S5D 320Z
Storage location: B4
SI number: 01 01 91 (312)
Order number: 21 2 130
Clutch centering tool
Scheme 44
21 2 140 Clutch centering mandrel (2 x)
Minimum set: Mechanical tools
Note. For centering clutch disc on flywheel while installing self-adjusting clutch (SAC) - Phase-in of SAC in E46, 09/97
Transmission: S5D 200G, S5D 250G, S5D 260Z, S5D 310Z, S5D 320Z, S6S 420G, S6S 560G
Storage location: B4
SI number: 1 13 96 (104)
Order number: 21 2 140
Clutch centering mandrel (2 x)
Consisting of
1 = 21 2 141 Clutch centering tool
Note. With M10 screw - Transmission: S6S 420G, S6S 560G
2 = 21 2 142 Clutch centering tool
Note. With M10 screw - Transmission: S5D 200G, S5D 250G, S5D 260Z, S5D 310Z, S5D 320Z
Scheme 45
21 2 170 Tensioning tool
Minimum set: Mechanical tools
In conjunction with: 21 2 180, 21 2 190, 21 2 141, 21 2 142
Note. For resetting adjustment ring and installing self adjusting clutch (SAC) on flywheel without tension.
Series: E34, E36, E38, E39, E46, E52, E53, E60, E61, E81, E83, E85, E86, E87, E88, E90, E91, E93
SI number: 1 16 00 (622)
Order number: 21 2 170
Tensioning tool
Consisting of
1 = 21 2 171 Star with adjusting spindle
2 = 21 2 172 Clamping claw (1 x)
3 = 21 2 173 Pressure spindle with disk
Scheme 46
21 2 180 Locating ring
Minimum set: Mechanical tools
In conjunction with: 21 2 170
Note. For locating and resetting adjustment ring of SAC clutch on all 6- and 8 cylinder engines.
Series: E34, E36, E38, E39, E46, E52, E53, E60, E61, E81, E83, E85, E86, E88, E90, E91, E93
Storage location: A44
SI number: 1 16 00 (622)
Order number: 21 2 180
Locating ring
Consisting of
1 = 21 2 181 Outer ring
2 = 21 2 182 Inner ring
3 = 21 2 183 Pin set
Scheme 47
21 2 200 Clutch aligning tool and M10 screw
Minimum set: Mechanical tools
Note. For centering clutch plate during installation.
Transmission: GS6-37BZ, GS6-37DZ
Storage location: B44, C44
SI number: 01 10 02 (907)
Order number: 21 2 200
Clutch aligning tool and M10 screw.
Scheme 48
21 2 220 Grease scraper ring
Minimum set: Mechanical tools
Note. Scraping grease off splines of transmission drive shaft
Series: E53, E60, E63, E64, E82, E83, E85, E86, E87, E88, E90, E91, E92, E93
Transmission: GS6-17BG, GS6-37BZ, GS6-37DZ
SI number: 01 10 02 (907)
Order number: 21 2 220
Grease scraper ring
Scheme 49
21 2 230 Clutch centering tool
Minimum set: Mechanical tools
Note. With M10 screw (G-transmission)
Transmission: GS6-53BZ, GS6-53DZ
Storage location: A47
SI number: 1 03 03 (960)
Order number: 21 2 230
Clutch centering tool
Scheme 50
21 2 240 Grease scraper ring
Minimum set: Mechanical tools
Note. For scraping grease on spline shaft teeth of transmission input shaft (G-transmission)
Transmission: GS6-53BZ, GS6-53DZ
Storage location: A47
SI number: 1 03 03 (960)
Order number: 21 2 240
Grease scraper ring
21 2 250 Clutch centering tool
Minimum set: Mechanical tools
Note. For centering drive plate during installation. Clutch plate with modified toothing. Transmission: S5D 250G (B transmission)
Transmission: S5D 250G
Storage location: A50
SI number: 1 20 04 (135)
Order number: 21 2 250
Clutch centering tool
Scheme 51
21 2 270 Clutch centering sleeve
Minimum set: Mechanical tools
Note. For centering drive plate to driven plate when installing clutch on engine. Transmission: GS6-53DG with M57T2, GS6-53BZ with N54 in E92, E60.
Transmission: GS6-53BZ, GS6-53DZ
SI number: 1 20 05 (218)
Order number: 21 2 270
Clutch centering sleeve
Scheme 52
21 2 280 Clutch centering tool
Note. For centering drive plate to driven plate when installing clutch on engine. Transmission: GS6-53DG with S85, S65
Transmission: GS6-53BZ
SI number: 01 18 06 (295)
Order number: 21 2 280
Clutch centering tool
Scheme 53
21 5 010 Adapter
In conjunction with: 17 0 002
Note. For expansion tank when bleeding hydraulic clutch system on automatic transmission
Transmission: S6S 420G
Storage location: C17
SI number: 1 06 97 (186)
Order number: 21 5 010
Adapter
Scheme 54
21 5 020 Bleeder flask
In conjunction with: 21 5 030
Note. For hydraulic fluid (Pentosin) - for bleeding hydraulic clutch system on sequential M-transmission.
Transmission: S6S 420G
SI number: 1 15 97 (211)
Order number: 21 5 020
Bleeder flask
