Heating and Air Conditioning - Special Tools - e90

Heating and Air Conditioning - Special Tools - e90 BMW M3 E90

Adapter MW

Note. (Seal adapter) For closing off the intake pipe

Scheme 113

Scheme 113: Adapter MW

Note. (Evaporator test adapter) E85, E86

Scheme 114

Scheme 114: Adapter MW

Note. (Evaporator test adapter) E60, E61, E63, E64

Note. (Sealing adapter) For closing off the line for the leakage test for E81, E87, E90, E91, E92, E93 (included in delivery from 02/2007)

Note. (Evaporator test adapter) E46, E83, E70, R55, R56 (formerly 64 5 108)

Note. (Evaporator test adapter) PL2, formerly 64 5 107

Replaced by: 0495257

Note. (Filling adapter) is replaced by 64 5 105 (from 01/2005) Replaced by 64 5 105 (0 495 257)

Note. (leak-tight adapter) For sealing the line during the evaporator leakage test in the E70 (included in the delivery specification from 02/2007)

Note. (Sealing adapter) Sealing adapter for closing off the line for the leakage test (included in delivery from 01/2005)

Adapter Minimum set: Mechanical tools MW

Note. (Climate component test adapter set)

SI number

01 04 08 (435)

Consisting of

0496223

0496224

0496258

0496259

0496260

0496299

0496300

Note. (Filler adapter) For sealing pressure line and connection to connecting hose (replaces special tool 64 5 101 from 01/2005)

Note. (Climate condenser test adapter)

Note. (Sealing adapter) For sealing suction connection on compressor

Electronics box MW

Note. (Flashbox) Only for auxiliary heating Technical Campaign --> Responsible: Webasto.

Electronics box MP

Note. Order number 81 34 2 209 944. Technical Campaign for E9x vehicles - Programming of WEBASTO auxiliary heater, see "Oscar" Service Information (bulletin) 0064600100.

Scheme 115

Scheme 115: Electronics box MP

Guide

In conjunction with: Lance 64 1 251

Note. Guide from spray apparatus set 64 1 250

1 26 03 (044)

Scheme 116

Scheme 116: SI number

Guide for spray lance (LHD vehicles)

In conjunction with: Spray lance 64 1 491 for evaporator cleaning

Holder MW

Note. (Counter support for drive plate removal) Drive plate on A/C compressor belt drive - removal currently only possible from 4-cylinder diesel engines

Storage Location

C52

B52

01 22 05 (221)

Scheme 117

Scheme 117: SI number

Hook Minimum set: Mechanical tools MW

Note. (release hook) For releasing and removing fresh air grille. For removing various trims.

01 15 99 (483)

Scheme 118

Scheme 118: SI number

Hose MW

Note. (connecting hose) For connecting the pressure cylinder to the filler adapter

Note. (Connection hose with clamp)

Plug MW

Note. (Climate condenser seal plug)

Spray lance (LHD vehicles)

In conjunction with: Guide 64 1 492

Spray lance, RHD vehicles

In conjunction with: Guide 64 1 252

Note. from spray apparatus set 64 1 250 (RHD vehicles)
