Heating and Air Conditioning - Special Tools - e92/93

Heating and Air Conditioning - Special Tools - e92/93 BMW M3 E90

64 0 000 Flashbox

Note. Only for technical campaign - independent heating --> Responsible: Webasto.

Series: E70, E90, E91, E92, E93

Order number: 64 0 000

Flashbox

64 1 020 Release hook

Minimum set: Mechanical tools

Note. For releasing and removing fresh air grille. For removing various trims.

Series: E36, E36/2, E36/3, E36/5, E36/7, E36/C, E36tou, E38, E38/3, E39, E39PL, E39tou, E46, E46/16, E46/2, E46/3, E46/5, E46/C, E52, E53, E60, E61, E63, E64, E65, E66, E67, E68, E70, E71, E81, E82, E83, E85, E86, E87, E88, E90, E91, E92, E93, F01, F02, R50, R52, R53, R55, R56, RR1, RR2, RR3

Storage location: A3, B3

SI number: 1 15 99(483)

Order number: 64 1 020

Release hook

Scheme 104

Scheme 104: 64 1 020 Release hook

64 1 090 Counter holder for removing drive plate

Note. Drive plate on A/C compressor belt drive - removal currently only possible from 4-cylinder diesel engines

Series: E87, E90, E91

SI number: 1 22 05 (221)

Order number: 64 1 090

Counter holder for removing drive plate

Scheme 105

Scheme 105: 64 1 090 Counter holder for removing drive plate

64 1 251 Spray lance, RHD vehicles

In conjunction Guide with: 64 1 252

Note. from spray apparatus set 64 1 250 (RHD vehicles)

SI number: 1 26 03 (044)

Order number: 64 1 251

Spray lance, RHD vehicles

Scheme 106

Scheme 106: 64 1 251 Spray lance, RHD vehicles

64 1 252 Guide

In conjunction with: Lance 64 1 251

Note. Guide from spray apparatus set 64 1 250

SI number: 1 26 03 (044)

Order number: 64 1 252

Guide

64 1 260 Spray equipment for air conditioning (LHD)

In conjunction with: Spray gun HRS 81 45 9 429 217

Note. For cleaning evaporator in E87, E88, E90, E91, E92, E93 (left-hand drive)

Series: E81, E82, E87, E88, E90, E91, E92, E93

SI number: 01 16 04 127

Order number: 64 1 260

Spray equipment for air conditioning (LHD)

Scheme 107

Scheme 107: 64 1 260 Spray equipment for air conditioning (LHD)

64 1 270 Spray equipment for air conditioning (RHD)

In conjunction with: Spray gun HRS 81 45 9 429 217

Note. For cleaning evaporator in E87, E88, E90, E91, E92, E93 (right-hand drive)

Series: E81, E82, E87, E88, E90, E91, E92, E93

SI number: 01 16 04 127

Order number: 64 1 270

Spray equipment for air conditioning (RHD)

Scheme 108

Scheme 108: 64 1 270 Spray equipment for air conditioning (RHD)

64 1 491 Spray lance (LHD vehicles)

In conjunction with: Guide 64 1 492

Order number: 64 1 491

Spray lance (LHD vehicles)

64 1 492 Guide for spray lance (LHD vehicles)

In conjunction with: Spray lance 64 1 491 for evaporator cleaning

Order number: 64 1 492

Guide for spray lance (LHD vehicles)

64 5 100 Set for sealing adapters

Note. For closing off line flanges of A/C components (evaporator, condenser, compressor) for leak testing. Special tool 64 5 101 replaced by 64 5 105 (from 01/2005).

Series: E32, E34, E36, E38, E39, E46, E53, E60, E61, E63, E64, E70, E81, E83, E87, E90, E91, E92, E93

SI number: 1 17 98 (359)

Order number: 64 5 100

Set of sealing adapters

Consisting of

1 = 64 5 104 Connecting hose

Note. For connecting pressure cylinder to filler adapter

2 = 64 5 102 Sealing adapter

Note. For closing off intake line

Scheme 109

Scheme 109: 64 5 100 Set for sealing adapters

3 = 64 5 103 Sealing adapter

Note. For closing of intake connection on compressor

4 = 64 5 105 Filler adapter

Note. For closing off the pressure line and connection at connecting hose (replacement for special tool SWZ 64 5 101 since 01/2005)

5 = 64 5 106 Sealing adapter

Note. For closing off line during leak test (included in scope of delivery from 01/2005)

6 = 64 5 107 Sealing adapter

Note. For closing off line during leak test for E81, E87, E90, E91, E92, E93 (included in scope of delivery from 02/2007)

7 = 64 5 108 Sealing adapter

Note. For closing off line during evaporator leak test in E70 (included in scope of delivery from 02/2007)

64 5 120 Test adapter set, A/C components

Minimum set: Mechanical tools

Series: E46, E60, E61, E63, E64, E70, E81, E82, E83, E85, E86, E87, E90, E91, E92, E93, R55, R56

SI number: 01 04 08 (435)

Order number: 64 5 120

Test adapter set, A/C components

Consisting of

1 = 64 5 121 Connecting hose with clamp

2 = 64 5 122 Test adapter, A/C condenser

3 = 64 5 123 Sealing plug, A/C condenser

Scheme 110

Scheme 110: 64 5 120 Test adapter set, A/C components

4 = 64 5 124 Test adapter, evaporator

Note. PL2, formerly 64 5 107

5 = 64 5 125 Test adapter, evaporator

Note. E46, E83, E70, R55, R56 (formerly 64 5 108)

6 = 64 5 126 Test adapter, evaporator

Note. E60, E61, E63, E64

7 = 64 5 127 Test adapter, evaporator

Note. E85, E86
