Body Equipment - Special Tools - e90 BMW M3 E90

Adjuster Minimum set: Mechanical tools MW

Note. (Door lock tensioner) For pre-tensioning front and rear door locks when installing. Change to tool through use of noise-optimized locks from 02/2004. Illustration items: 1 = knurled nut 51 2 191 2 = support 51 2 192 3 = protection 51 2 196 4 = mandrel 51 2 197

Storage Location

B44

C44

Scheme 1103

SI number

01 06 02 (864)

Consisting of

2 = 0494472 Guard

Note. Is replaced by 51 2 196 with the use of noise-optimized locks from 02/2004 Replaced by 51 2 196 (0 494 906)

2 = 0494473 Mandrel

Note. Is replaced by 51 2 197 with the use of noise-optimized locks from 02/2004 Replaced by 51 2 197 (0 494 907)

4 = 0494907 Mandrel

Note. Replaces mandrel 51 2 194

1 = 0494470 Nut

Note. (Knurled nut)

2 = 0494471 Support

2 = 0494474 Shaped element

Note. E85 (discontinued)

3 = 0494906 Guard

Note. Replaces guard 51 2 193

Bridge

Note. Gantry crane

6 04 03 (046)

Drift

Note. Replaces drift 51 2 194

Gauge MW

Note. (Test gauge) For adjusting the bonded windscreen to fit Replaced by 51 0 010.(0 495 259)

C5

01 10 96 (097)

Scheme 1104

Gauge Minimum set: Mechanical tools MW

Note. For measurement of retraction depth of window glass (replaces special tool 51 3 080 as of 10/2009).

01 22 09 (587)

Scheme 1105

Note. (test gauge for installing windscreen and rear window) (replaces special tool 51 3 210 from 06/2005)

B2

01 10 05 (189)

Scheme 1106

Handle MW

Note. (pull handles) Cutting wire pull handles fore removing rear, quarterlight and side windows

01 13 03 (001)

Scheme 1107

Hoisting winch

Note. for windscreen/rear window locating fixture on gantry crane

6 04 03 (046)

51 0 108 Hoisting winch

Note. for side window locating fixture on gantry crane

6 04 03 (046)

Holder MW

Note. (Window glass holder) For holding the front and rear window glass when mounting the window glass/replaced by 51 3 010. (0 492 609)

Key MW

Note. For removing door lock finisher

B10

01 08 94 (820)

Scheme 1108

Lever MW

Note. (Clamp lifting gear) For unlocking trim panels and roofliner.

A23

A24

01 03 07 (337)

Scheme 1109

Note. For removing fixed rear side windows and for removing elasto-belt.

B1

A1

Scheme 1110

Protection

Note. Replaces protection 51 2 193

Roller MW

Note. (Contact roller) For pressing sound insulation into doors; various rubber seals and covers

B19

01 07 06 (271)

Consisting of

1 = 0495843 Handle

2 = 0495844 Roller

Scheme 1111

Side window locating fixture

Note. for gantry crane

6 04 03 (046)

Scheme 1112

Siphon MW

Note. (Siphon (2 pieces)) For removal and installation of the window glass. Is replaced by 81 64 2 184 377, see Service Information (bulletin) 08 01 10 (635).

01 05 86 (604)

Consisting of

1 = 0493119 Suction cup

Note. With elongated hole, suspension can be moved around all axles. Is replaced by 81 64 2 184 377, see Service Information (bulletin) 08 01 10 (635)

Scheme 1113

2 = 0493120 Suction cup

Note. With bore hole, suspension can only be moved in longitudinal direction. Is replaced by 81 64 2 184 377, see Service Information (bulletin) 08 01 10 (635).

3 = 0493121 Handle

Note. (Grab handle): Is replaced by 81 64 2 184 377, see Service Information (bulletin) 08 01 10 (635).

2 = 0493267 Plate

Note. (rubber plate without joint)

2 = 0493268 Joint

Note. (joint without rubber plate)

Suction cup MW

Note. (Suction cup) For lifting out side windows

01 17 00 (623)

Scheme 1114

Suction cup

Note. Gantry crane

6 04 03 (046)

Support MW

Note. For the engine compartment lid when removing the engine/Replaced by 51 2 140.(0 492 603)

Scheme 1115

Support Minimum set: Mechanical tools MW

Note. (Bonnet support (2 x)) For retaining the engine compartment lid in the working position

A2

01 15 99 (483)

Scheme 1116

Support, left

Note. Gantry crane

6 04 03 (046)

Support, right

Note. Gantry crane

6 04 03 (046)

Tool MW

Replaced by: 0496710

Note. For checking retraction depth when installing side window. From 10/2009 Replaced by 51 0 000.(0 496 710)

B6

01 05 90 (207)

Scheme 1117

Vacuum pump

Note. for gantry crane

6 04 03 (046)

Windscreen/rear window locating fixture

Note. Gantry crane

6 04 03 (046)

Scheme 1118
