Automatic Transmission - Special Tools BMW M3 E90

Automatic Trans 103 illustrations ~3812 words

0491628 240030 Adapter MW

Note. For pressure gauge 13 3 061/For checking the converter pressure

Storage Location

A4

Scheme 211

Scheme 211: Storage Location

0496482 242410 Adapter Minimum set: Mechanical tools MW

Note. (Adapter ring) For driving in radial shaft seal on output shaft.

B25

SI number

01 18 08 (482)

Scheme 212

Scheme 212: SI number

0491767 245190 Adapter MW

Note. For pressure gauge 13 3 061 for checking oil pressure in transmission

A4

01 03 90 (184)

Scheme 213

Scheme 213: SI number

0491635 240070 Adapter MW

Note. For testing the pump pressure

A4

Scheme 214

Scheme 214: Storage Location

0491674 241210 Angle MW

Note. (Sheet metal part) Retaining plate for disc package As of transmission number 11 2 300 not required

Z4

01 09 90 (282)

Scheme 215

Scheme 215: SI number

0491775 245270 Bush Minimum set: Mechanical tools MW

Note. For fitting the radial sealing ring of the selector shaft

B3

01 08 96 (080)

Scheme 216

Scheme 216: SI number

0491664 241050 Bush MW

Note. (Impact bush) For fitting radial shaft seal for torque converter in oil pump housing

Y7

Scheme 217

Scheme 217: Storage Location

0491665 241060 Bush MW

Note. (Impact bush) For driving in the radial seal ring for the torque converter in the oil pump housing and at the output flange

Y7

Scheme 218

Scheme 218: Storage Location

0491709 243140 Bush MW

Note. (Driver bush) For checking the oil pump for ease of movement

A10

Scheme 219

Scheme 219: Storage Location

0491768 245200 Bush MW

Replaced by: 0491781

Note. (Impact bush) For fitting the radial sealing ring of the selector lever shaft/Replaced by 24 5 360 (0 491 781)

01 03 90 (184)

Scheme 220

Scheme 220: SI number

0493254 241080 Bush Minimum set: Mechanical tools MW

Note. (bushing (aluminum)) For placing on the drive shaft during removal of the shaft seal from the oil pump housing

C4

01 03 98 (303)

Scheme 221

Scheme 221: SI number

0491773 245250 Bush Minimum set: Mechanical tools MW

Note. For pressing in the radial seal ring of the selector shaft

B3

01 02 95 (896)

Scheme 222

Scheme 222: SI number

0491666 241100 Bush MW

Note. (Impact bush) For driving in the radial seal ring for the output flange into the transmission extension

Scheme 223

Scheme 223: 0491666 241100 Bush MW

0495601 244380 Bush Minimum set: Mechanical tools MW

Note. (Bush with nut) For inserting radial shaft seal of selector shaft.

A24

01 02 07 (334)

Consisting of

1 = 0495788 Bush

2 = 0495789 Nut

Note. (Nut M8x1)

Scheme 224

Scheme 224: SI number

0493335 241090 Bush MW

Note. (Impact bush) For driving in the radial shaft seal on the output flange

01 08 98 (333)

Scheme 225

Scheme 225: SI number

0493253 241070 Bush Minimum set: Mechanical tools MW

Note. (Impact bush) For fitting radial shaft seal into oil pump housing

C17

01 03 98 (303)

Scheme 226

Scheme 226: SI number

0494213 242390 Cap Minimum set: Mechanical tools MW

Note. (protective cap) For sealing off the guide sleeve of the transmission connector

C49

01 14 01 (766)

Scheme 227

Scheme 227: SI number

Scheme 228

Scheme 228: 0491644 240150 Clip MW

Note. (Mounting bracket) For mounting the transmission on the assembly stand

Consisting of

6 = 0493913 Spindle

Note. With synchronizing key, transmission: All

3 = 0491645 Shaped part

Note. (Shaped part) For mounting the transmission/transmissions: A5S 310Z

2 = 0491646 Frame

Note. (Main frame)

3 = 0491647 Spindle

Note. (Spindle with rotary handle)

3 = 0491648 Bolt

Note. (Mounting bolts)

3 = 0491649 Bush

Note. (Spacer bush for spindle) Transmissions: A4S 310R

0491643 240140 Connection Minimum set: Mechanical tools MW

Replaced by: 0495498

Note. (Connection) For pressure gauge 13 3 061 and BMW diagnosis and information system for measuring the oil pressure in the transmission Replaced by 23 4 050 (0 495 498)

A4

01 01 92 (469)

Scheme 229

Scheme 229: SI number

0491618 240020 Connection Minimum set: Mechanical tools MW

Note. (Connections) Oil pressure testing accessory for pressure gauge 13 3 061 or BMW DIS for checking the oil pressure.

B24

B23

Individual

Consisting of

1 = 0491619 Hose

Note. (Line) Pressure hose 1.7 m, connection M12x1.5 - M14x1.5 outer thread/For checking the different converter pressures/transmission: A4S 310R, A4S 270R

2 = 0491620 Connection

Note. (Connection) For checking the main pressure (3 HP 22, A5S 310Z) and clutch A (ZF transmission)/transmission: 3 HP 22, A5S 310Z, A5S 560Z and all ZF transmissions

Scheme 230

Scheme 230: Storage Location

3 = 0491621 Connection

Note. (Connection) Pipe bend, 145 mm, stretched length 145 mm/transmission: 4 HP 22, 4 HP 24

4 = 0491622 Connection

Note. (Connection) Pipe bend, 90 mm, stretched length 90 mm

5 = 0491623 Screw

Note. (Connection) Banjo bolt M20x1. - M18x1./For checking the converter pressure/transmission: 3 HP 12

6 = 0491624 Connection

Note. (Connection) Reducer M24x1.5 - 20x1.5/For checking the main pressure/transmission: 3 HP 20

7 = 0491625 Connection

Note. (Connection) Reducer M20x1.5 - M18x1.5/For checking the main pressure (3 HP 12) an converter pressure (3 HP 20)/Transmission: 3 HP 12, 3 HP 20

8 = 0491626 Screw

Note. (Screw) M18x1./For closing the engine oil feed pipe when checking the converter pressure/transmission: 3 HP 20

9 = 0491627 Adapter

Note. For closing the feed and return lines when checking the main pressure/transmission: 3 HP 22

0491657 240190 Counter support Minimum set: Mechanical tools MW

Note. (Steady device) For the output flange of the propeller shaft while releasing and tightening the slotted nut

01 06 92 (509)

Scheme 231

Scheme 231: SI number

0491676 241230 Device MW

Note. (Pressing device) For removing and installing the piston (cover) at brake C

Y6

01 14 93 (718)

Scheme 232

Scheme 232: SI number

0495444 241360 Device Minimum set: Mechanical tools MW

Note. (Locating fixture) For securing converter during removal and installation of transmission.

B52

01 17 05 (212)

Scheme 233

Scheme 233: SI number

0491730 244120 Device MW

Replaced by: 0491731

Note. For firmly holding torque converter in position while removing and fitting the transmission. Replaced by 24 4 130 (0 491 731)

Scheme 234

Scheme 234: 0491730 244120 Device MW

0491677 241240 Device MW

Note. (device) For determining the shims on the brake C

Y6

01 14 93 (718)

Scheme 235

Scheme 235: SI number

0495486 241370 Device Minimum set: Mechanical tools MW

Note. (locating fixture) For securing converter during removal and installation of transmission.

A20

B20

01 23 05 (224)

Scheme 236

Scheme 236: SI number

0491678 241250 Device MW

Note. (Lifting gear) For removing and installing the brake clutch unit D/G incl. the parking lock gear

Y3

Z3

01 14 93 (718)

Scheme 237

Scheme 237: SI number

0491774 245260 Device Minimum set: Mechanical tools MW

Note. (Pulling device) For pulling off the radial seal of the selector shaft/transmission with positioning switch

B3

01 02 95 (896)

Consisting of

1 = 0494592 Use

2 = 0494593 Bush

Scheme 238

Scheme 238: SI number

0493156 242310 Device MW

Note. (Device) Tool set for dismantling and fitting the R gear piston. For dismantling and assembling the transmission for "Sealing the intermediate plate".

01 22 97 (239)

Consisting of

1 = 0493157 Plate

Note. (Pressure plate) For removing and installing the spring cup

Scheme 239

Scheme 239: SI number

2 = 0493158 Spindle

Note. (Spindle with pressure plate) Spindle M14x1.5, nut M14, pressure plate and washer/For removing and installing the spring cup

3 = 0493159 Pin

Note. (Guide pin (2 pieces)) For fixing the gaskets and the intermediate plate on the intermediate case

4 = 0493160 Bush

Note. (Slip bush) For installing the piston in the cylinder of the intermediate plate

0491671 241180 Device MW

Note. For removing and installing oil pump

Z2

Z1

01 09 90 (282)

Consisting of

1 = 0494586 Tube

Note. (Retaining tube)

2 = 0494588 Spindle

Note. (Threaded spindle)

3 = 0494589 Ring

Note. (Clamping ring)

4 = 0496375 Ring

Note. (Clamping ring) Gearbox: GA6HP19Z, GA6HP26Z

Scheme 240

Scheme 240: SI number

0491636 240080 Device Minimum set: Mechanical tools MW

Note. (funnel) For filling the transmission with transmission oil

Scheme 241

Scheme 241: 0491636 240080 Device Minimum set: Mechanical tools MW

0491679 241260 Device MW

Note. (Removal and mounting device) For removing and installing the cylinders D/E with the planetary gear set

C1

C2

01 01 95 (892)

Consisting of

1 = 0491680 Handle

2 = 0491681 Spindle

Note. (Spindle with knurled nut)

3 = 0491682 Bush

Note. (Centering bush)

Scheme 242

Scheme 242: SI number

0491683 241270 Device MW

Note. Removal and mounting device) For removing and installing the drive clutch A/B/C

Y2

Z2

01 01 95 (892)

Consisting of

1 = 0491684 Pipe

Note. (Jack tube with ring bolt)

2 = 0491685 Pin

Note. (Locking pin)

Scheme 243

Scheme 243: SI number

0491781 245360 Device Minimum set: Mechanical tools MW

Note. For removing and installing the radial shaft seal of the gearshift shaft 24 5 361, 24 5 362, 24 5 364 and 24 5 366 for E90

C4

01 14 96 (105)

Consisting of

6 = 0494208 Bush

Note. For fitting the radial shaft seal on the selector shaft (emergency release) Transmission: GA6 HP26Z

Scheme 244

Scheme 244: SI number

1 = 0491782 Bush

Note. (Threaded bush)

2 = 0491783 Nut

Note. (Union nut)

3 = 0491784 Bush

Note. For transmission without positioning switch Transmission: A4S 310R

4 = 0491785 Nut

5 = 0491786 Sleeve

Note. (Sliding sleeve (5 pieces)) Transmission: A4S 310R

0491686 241280 Device MW

Note. (Assembly and disassembly tool) For removing and installing brake clutch F

Z4

Z3

01 01 95 (892)

Consisting of

1 = 0491687 Handle

Note. (Handle)

2 = 0491688 Nut

Note. (knurled nut)

3 = 0491689 Handle

Note. (Centering handle)

Scheme 245

Scheme 245: SI number

0491726 244080 Device MW

Note. For fixing torque converter in position while removing and installing transmission.

Individual

Scheme 246

Scheme 246: Storage Location

0491615 240010 Device MW

Note. For checking the side clearance of the drive shaft

Y3

Consisting of

1 = 0491616 Holder

Note. (Dial gauge holder)

2 = 0491617 Terminal

Note. (Terminal)

Scheme 247

Scheme 247: Storage Location

0491698 242140 Device MW

Note. (Tensioning device) For removal and installation of the snap ring before the centering plate on ZF transmissions

Scheme 248

Scheme 248: 0491698 242140 Device MW

0491652 240180 Fixture MW

Replaced by: 0495446

Note. For mounting the gearbox on the assembly stand. Replaced by 24 0 200 (0 495 446)

01 06 92 (509)

Consisting of

5 = 0495439 Adapter

Note. Replaced by 24 0 205 (0 495 492)

3 = 0491655 Spindle

Note. Replaced by 24 0 184 (0 491 656)

1 = 0491653 Frame

Note. (Main frame)

2 = 0491654 Spindle

Note. (Pressure spindle with star handle)

4 = 0491656 Spindle

Note. (spindle, long (2 pieces))

Scheme 249

Scheme 249: SI number

0495446 240200 Fixture MW

Note. For mounting the gearbox on the assembly stand.

01 27 06 (328)

Consisting of

1 = 0495488 Basic body

2 = 0495489 Spindle

Note. (spindle with synchronizing key)

3 = 0495490 Spindle

Note. (spindle with screw)

4 = 0495491 Shaped part

Note. (Shaped part)

5 = 0495492 Adapter

Note. (adapter (long))

6 = 0495493 Adapter

Note. (adapter (medium))

7 = 0495494 Adapter

Note. (adapter (short))

Scheme 250

Scheme 250: SI number

0491642 240130 Fixture MW

Replaced by: 0495498

Note. (Fixture for transmission) For removal and installation Replaced by 23 4 050 (0 495 498)

01 02 87 (721)

Scheme 251

Scheme 251: SI number

0491651 240170 Fixture MW

Replaced by: 0495498

Note. For removing and installing transmission. Replaced by 23 4 050 (0 495 498)

01 06 92 (509)

Consisting of

3 = 0493258 Bolt

Note. (Adjusting screw) Discontinuation and replaced by 23 4 050 (0 495 498)

Scheme 252

Scheme 252: SI number

0491661 240250 Fixture MW

Replaced by: 0495498

Note. (Fixture for transmission) For removing and installing the transmission. Replaced by 23 4 050 (0 495 498)

01 08 96 (080)

Scheme 253

Scheme 253: SI number

0491776 245300 Fixture MW

Note. (Fixtures) For supporting the gearbox during removal and fitting. Replaced by 23 4 050 (0 495 498)

01 03 90 (184)

Consisting of

1 = 0491777 Plate

Note. (Base plate) Discontinuation and replaced by 23 4 050 (0 495 498)

8 = 0494062 Fixture

Note. Transmission: GA6HP19Z (6HP19), GA6HP26Z/32Z (6HP26/32)

4 = 0494818 Fixture

Note. Transmission: GA6HP19Z (6HP19), GA6HP26Z (6HP26)

2 = 0491778 Fixture

Note. (support mount (2 pieces)) Transmission: A4S 310R

3 = 0491779 Bolt

Note. (mounting stud (4 pieces)) Transmission: A4S 310Z

Scheme 254

Scheme 254: SI number

6 = 0493287 Fixture

Note. (support mount (2 pieces)) Transmission: A5S 325Z

4 = 0493336 Fixture

Note. (support mount (2 pieces)) Transmission: A5S 390G

0491668 241120 Gauge MW

Note. For setting the position switch to "P position" during installation/model year: from 03/96

01 07 96 (068)

Scheme 255

Scheme 255: SI number

0496717 241440 Handle MW

Note. For installing and removing the torque converter. 8HPxx

01 17 09 (577)

Scheme 256

Scheme 256: SI number

0491697 242050 Handle MW

Replaced by: 0491633

Note. (Pulling handle) For sealing plug in the lower section of the transmission housing/Replaced by 24 0 050 (0 491 633)

0491715 244000 Handle Minimum set: Mechanical tools MW

Note. (Assembly handle (2 x)) For removing and installing the torque converter

B5

Scheme 257

Scheme 257: Storage Location

0491633 240050 Handle MW

Note. (extractor handle) For sealing plug in the lower section of transmission housing

Y5

Scheme 258

Scheme 258: Storage Location

0491772 245240 Holder MW

Note. (Counter support) For releasing and tightening the gear selector cable/transmission with position switch

A4

01 06 92 (509)

Scheme 259

Scheme 259: SI number

0491769 245210 Holder MW

Note. (counter support) For loosening and tightening the gear selector cable

A4

01 04 91 (372)

Scheme 260

Scheme 260: SI number

0491770 245220 Holder MW

Note. (Counter support) For slackening and tightening the gear selector cable

A4

01 04 91 (372)

Scheme 261

Scheme 261: SI number

0494451 244160 Holder Minimum set: Mechanical tools MW

Note. For securing converter during removal and installation of transmission

C46

A47

01 11 02 (908)

Consisting of

3 = 0494477 Shaped element

Note. For converter variantM57TU

1 = 0494478 Basic body

2 = 0494479 Shaped element

Note. For converter variantN73

4 = 0494622 Shaped element

Note. For converter variantM54

5 = 0494965 Shaped element

Note. Transmission: GA6 HP19 in E87, E90

6 = 0496061 Shaped element

Note. Transmission: GA6L45R (GM6) in E83/N52K

Scheme 262

Scheme 262: SI number

0491673 241200 Holding sleeve Minimum set: Mechanical tools MW

Note. (Assembly sleeve) For preventing damage to radial shaft seal when fitting it onto selector shaft

B3

01 09 90 (282)

Scheme 263

Scheme 263: SI number

0491729 244110 Key Minimum set: Mechanical tools MW

Note. For releasing and tightening the slotted nut of the output flange

A10

01 06 92 (509)

Scheme 264

Scheme 264: SI number

0496312 244340 Lever MW

Note. For removing and installing oil filler cap.

B22

01 19 07 (397)

Scheme 265

Scheme 265: SI number

0491728 244100 Mandrel Minimum set: Mechanical tools MW

Note. (Drift) For driving in the radial seal ring on the drive side (behind converter)

A17

01 06 92 (509)

Scheme 266

Scheme 266: SI number

0495600 244370 Mandrel Minimum set: Mechanical tools MW

Note. (Drift) For driving in radial shaft seal of output shaft (4x2).

A24

01 02 07 (334)

Scheme 267

Scheme 267: SI number

0495603 244400 Mandrel Minimum set: Mechanical tools MW

Note. (Drift) For driving in oil filter sealing ring.

A24

01 02 07 (334)

Scheme 268

Scheme 268: SI number

2208426 240340 Mandrel MW

Note. For driving in the radial shaft seal on the output end.

01 09 10 (639)

Scheme 269

Scheme 269: SI number

0491637 240090 Mandrel MW

Replaced by: 0491639

Note. (Drift) For punching the radial sealing ring in the front section of the transmission housing/Replaced by 24 0 110 (0 491 639) November 96

Scheme 270

Scheme 270: 0491637 240090 Mandrel MW

0491639 240110 Mandrel MW

Note. (drift) For driving in the radial sealing ring in the front section of the transmission housing/Model year: from 90 and for the output flange of the transmissions S5D 200G and S5D 250G

B17

01 03 90 (184)

Consisting of

3 = 0491640 Washer

Note. (ring washer 1 mm) Transmissions: 4 HP 24 - no. 0 029 160, 4 HP 22 - no. 1 113 936

Scheme 271

Scheme 271: SI number

0496860 240330 Mandrel MW

Note. For driving in the radial shaft seal on the drive end.

01 09 10 (639)

Scheme 272

Scheme 272: SI number

0495255 244310 Mandrel Minimum set: Mechanical tools MW

Note. (Drift) For driving in the radial shaft seal of output shaft.

B50

01 04 05 (175)

Scheme 273

Scheme 273: SI number

2208427 240350 Mandrel MW

Note. For driving in shaft seal on selector shaft.

01 09 10 (639)

Scheme 274

Scheme 274: SI number

0494199 242370 Mandrel Minimum set: Mechanical tools MW

Note. (Drift) For inserting the radial shaft seal on the output flange

B46

A46

01 14 01 (766)

Scheme 275

Scheme 275: SI number

0491672 241190 Mandrel Minimum set: Mechanical tools MW

Note. (drift) For driving in the radial sealing ring in the front section of the transmission housing

A15

01 09 90 (282)

Scheme 276

Scheme 276: SI number

0494200 242360 Mandrel Minimum set: Mechanical tools MW

Replaced by: 0494506

Note. (Drift) For installing the radial shaft seal on the torque converter Replaced by 24 2 400 (0 494 506)

B46

01 14 01 (766)

Scheme 277

Scheme 277: SI number

0496719 241410 Mandrel Minimum set: Mechanical tools MW

Note. For driving in the radial shaft seal of the drive shaft.

01 17 09 (577)

Scheme 278

Scheme 278: SI number

0494506 242400 Mandrel Minimum set: Mechanical tools MW

Note. (Drift) For driving in shaft seal on torque converter

B47

01 08 03 (988)

Scheme 279

Scheme 279: SI number

0495497 244330 Mandrel MW

Note. (Drift) For driving in radial shaft seal of output shaft (all-wheel drive).

A23

Scheme 280

Scheme 280: Storage Location

0491727 244090 Mandrel Minimum set: Mechanical tools MW

Note. (drift) For fitting the radial sealing ring to the output end

A15

01 06 92 (509)

Scheme 281

Scheme 281: SI number

0493115 242330 Open-end wrench MW

Note. (Open-end wrench) Open-end wrench 1/2" for adjusting the brake band

01 24 97 (257)

Scheme 282

Scheme 282: SI number

0496715 241430 Pin MW

Note. For fixing the mechatronics in position during installation.

01 17 09 (577)

Scheme 283

Scheme 283: SI number

0496728 240320 Pin MW

Note. For securing transmission when installing in engine.

01 29 09 (601)

Scheme 284

Scheme 284: SI number

0491764 245160 Pin MW

Note. (centering pin) For centering the main housing to the intermediate and converter housing (2 x)

Y3

01 03 93 (663)

Scheme 285

Scheme 285: SI number

0491670 241170 Pin wrench Minimum set: Mechanical tools MW

Note. For loosening and tightening the slotted nut on the output flange

A13

01 09 90 (282)

Scheme 286

Scheme 286: SI number

0495599 244360 Puller Minimum set: Mechanical tools MW

Note. For withdrawing radial shaft seal of output shaft (4 x 2).

A24

01 02 07 (334)

Consisting of

1 = 0496113 Basic body

2 = 0496114 Claw

Note. (Claw (4 x))

3 = 0496115 Screw

4 = 0496116 Spindle

Scheme 287

Scheme 287: SI number

0494201 242350 Puller Minimum set: Mechanical tools MW

Note. For extracting radial shaft seal on torque converter and on output flange

A46

01 14 01 (766)

Consisting of

1 = 0494202 Puller

2 = 0494203 Spindle

Note. (Spindle M12 x 65 with ball head)

3 = 0494204 Synchronizing key

4 = 0495597 Synchronizing key

Note. Transmission: GA6L45R (GM6)

Scheme 288

Scheme 288: SI number

0495496 244320 Puller MW

Note. For withdrawing output shaft seal (four-wheel drive).

01 02 07 (334)

Consisting of

1 = 0495569 Basic body

2 = 0495570 Ring

Note. (Retaining ring)

3 = 0495571 Spindle

4 = 0495572 Hook wrench

Scheme 289

Scheme 289: SI number

0496718 245367 Puller Minimum set: Mechanical tools MW

Note. For removing the radial shaft seal of the gearshift shaft from the gearbox housing.

01 17 09 (577)

Scheme 290

Scheme 290: SI number

0496716 241420 Puller MW

Note. Removing radial shaft seal from torque converter.

01 17 09 (577)

Consisting of

1 = 2209493 Blade

Note. Replacement blade for 24 1 420

Scheme 291

Scheme 291: SI number

0495602 244390 Puller Minimum set: Mechanical tools MW

Note. For removing oil filter sealing ring.

A23

01 02 07 (334)

Scheme 292

Scheme 292: SI number

0491692 241310 Release tool MW

Note. (release tool) For releasing the retaining tabs on the disc carrier C

Y6

01 01 95 (892)

Consisting of

1 = 0494693 Shaped part

Note. (shaped part)

2 = 0494694 Basic body

Scheme 293

Scheme 293: SI number

0491771 245230 Ring Minimum set: Mechanical tools MW

Note. (Assembly ring) For pressing in the radial seal of the gearshift shaft

B3

01 04 91 (372)

Scheme 294

Scheme 294: SI number

0491789 245490 Sleeve Minimum set: Mechanical tools MW

Note. (sliding sleeve (5 x)) For prevention of damage to the radial sealing ring while fitting on the gearshift shaft

01 02 95 (896)

Scheme 295

Scheme 295: SI number

0491662 241010 Sleeve MW

Note. (Assembly sleeve) For removing the disc set (4-gear) and for pressing in the needle bearing in the oil pump housing (A5S 560Z)

X5

Scheme 296

Scheme 296: Storage Location

0494212 242380 Socket Minimum set: Mechanical tools MW

Note. (Socket AF 34) Double hex head for releasing and tightening the nut on the output flange

B44

01 14 01 (766)

Scheme 297

Scheme 297: SI number

0495598 244350 Socket Minimum set: Mechanical tools MW

Note. (Socket with special Torx profile) For releasing and tightening down screw connection of Mechatronic.

A23

01 02 07 (334)

Scheme 298

Scheme 298: SI number

0493114 242320 Socket wrench MW

Note. For hexagon socket screw 3/16" with 1/4" drive for adjusting the brake band

01 24 97 (257)

Scheme 299

Scheme 299: SI number

0491641 240120 Support MW

Note. (support) For removing and fitting the transmission. Replaced by 24 0 130 in March 87

0491675 241220 Support MW

Note. (Fixture for drive flange) When undoing the slotted nut

01 09 90 (282)

Scheme 300

Scheme 300: SI number

0496729 240300 Support MW

Note. For mounting transmission on assembly stand 00 2 300 and for transport.

01 29 09 (601)

Scheme 301

Scheme 301: SI number

0491780 245350 Support MW

Note. (Support for automatic transmission) Other: Only Japan and South Africa

Scheme 302

Scheme 302: 0491780 245350 Support MW

0494137 246080 Test cable Minimum set: Measuring and testing equipment MP

Note. (test cable 16-pin)

L204

02 06 01 (763)

Scheme 303

Scheme 303: SI number

0491791 246010 Test cable MW

Note. (Test cable, 9-pin) For automatic transmission (EH transmission)

02 03 91 (313)

Scheme 304

Scheme 304: SI number

0491796 246050 Test cable MW

Note. (Test cable, 10-pin) For Jatco gearbox (AMP plug connection)

02 01 93 (649)

0491790 246000 Test cable MW

Note. (Test cable, 8-pin) For automatic transmission (EH gearbox)

02 03 91 (313)

Scheme 305

Scheme 305: SI number

0493654 246070 Test cable MW

Note. (Test cable, 20-pin) For automatic transmission GM5

02 01 99 (468)

0491797 246060 Test cable MW

Note. (Test cable, 16-pin) For automatic transmission (EH gearbox)

02 02 93 (650)

Scheme 306

Scheme 306: SI number

0491792 246020 Test cable MW

Note. (Test cable, 14-pin) For automatic transmission (EH transmission)

00 02 99 (399)

Consisting of

5 = 0491793 Operating instructions

Scheme 307

Scheme 307: SI number

0491694 242020 Tool MW

Note. For squeezing the disc spring

X5

Scheme 308

Scheme 308: Storage Location

0491758 245120 Tool MW

Note. For centering the converter housing relative to the oil pump when mounting

B2

01 04 95 (906)

Consisting of

1 = 0491759 Bush

Note. (Centering bush)

2 = 0491760 Pin

Note. (Centering pin (3 pieces))

Scheme 309

Scheme 309: SI number

0491731 244130 Tool Minimum set: Mechanical tools MW

Note. (Locating tool) For fixing torque converter during removal and installation of gearbox

C6

01 05 97 (181)

Consisting of

7 = 0493804 Blade

Note. Transmission: A5S 360R

1 = 0491732 Basic body

Note. (basic body)

2 = 0491733 Blade

Note. Transmission: A5S 440Z, GA6HP26Z (N62)

3 = 0491734 Blade

Note. (Blade) Gearbox: A4S 310R and A5S 390G

4 = 0491735 Blade

Note. Transmission: A5S 310Z, A5S 560Z, A5S 300J and A5S 325Z

Scheme 310

Scheme 310: SI number

5 = 0491736 Blade

Note. Transmission: A5S 560Z, GA6 HP26Z (M67), GA6 HP32Z (N73)

6 = 0493180 Plate

Note. (Counter-support plate)

8 = 0496742 Blade

Note. For securing converter during removal and installation of transmission. In conjunction with: 24 4 131

0491691 241300 Tool MW

Note. (Striking tool) For securing the retaining tabs on disc carrier C

X5

01 01 95 (892)

Scheme 311

Scheme 311: SI number

0491696 242040 Tool MW

Note. For squeezing the disc spring

X6

0491695 242030 Tool MW

Note. For compressing the disc spring

X5

0491690 241290 Wedge MW

Note. (Wedges) For fixing the disc carrier C when securing the retaining tabs

X5

01 01 95 (892)

Scheme 312

Scheme 312: SI number

0491667 241110 Wrench socket Minimum set: Mechanical tools MW

Note. (Wrench socket with magnet) For loosening and tightening the converter fixation

A11

01 04 86 (566)

Scheme 313

Scheme 313: SI number
