Self Leveling Suspension: Component Locations Audi A6 C5 facelift

Electrical/electronic component locations

Note. The following list refers to items in (Scheme 266).

1. Air supply unit The air supply unit consists of the following components: Level Control System Control Module -J197- Relay for compressor level control system -J403- Motor for compressor-level control system - V66- Solenoid for level control system -N111- Left Rear Suspension Strut Valve -N150- Right Rear Suspension Strut Valve -N151- Multi-pin connectors with assigned contacts If control module is replaced, select "Replacement" function for appropriate control module in "Guided fault-finding". Vehicle diagnostic, testing and information system VAS 5051 is to be used for this purpose.
2. Left rear air spring
3. Level Control System Sensor (ESP) -G84- Checked by On Board Diagnostic (OBD)
4. Right rear air spring

Scheme 266

Special tools and equipment

1. T 40002 Level regulating tool

1. VAG1383 A engine/transmission jack with universal transmission holder VAG1359/2

Scheme 267

Scheme 268

1. Carefully open and remove air connections -4-.

Note. To remove and install spring cylinder, use engine/transmission jackVAG1383 A with holder 1359/2.

Scheme 269

1. Remove bolt -2- on left and lower engine/transmission jack. see scheme 32
2. Unscrew bolt -1- and remove shock absorber.
3. Pull down rear axle, by second mechanic if necessary, and remove shock absorber.

Component locations

Note. The following list refers to items in see scheme 72.

1. Right front air strut
2. Operating unit
3. Right rear air strut
4. Right rear level control system sensor -G77
5. Control module Removing, see «LEVEL CONTROL SYSTEM CONTROL MODULE -J197- (ALLROAD)»(ref-196275-S14344117722005100800000) Installing, see «LEVEL CONTROL SYSTEM CONTROL MODULE -J197- (ALLROAD), INSTALLING»(ref-196275-S39221836332005100800000)
6. Pressure reservoir Assembly overview, see «PRESSURE RESERVOIR, ASSEMBLY OVERVIEW»(ref-196275-S06743502232005100800000)
7. Left rear level control system sensor -G76
8. Left rear air strut
9. Air supply unit with: Compressor Solenoid for level control system -N111- Lateral check-valves Level Control Pump Temperature Sensor -G290- Level Control Pressure Sensor-G291- Auxiliary noise insulation Component overview, see «COMPRESSOR (ALLROAD)»(ref-196275-S33296702392005100800000)
10. Electric/pneumatic lines
11. Left front air strut
12. Left front level control system sensor -G78
13. Right front level control system sensor -G289

Scheme 270
