On Board Diagnostic (OBD) - 5 Spd. Automatic Transmission 01v Audi A6 C5

On Board Diagnostic (OBD), function

The automatic transmission is controlled electro-hydraulically.

The automatic transmission control module -J217- receives information from components that effect selection of gears and passes the information on to solenoid valves that control the solenoid valves in the valve body. The solenoid valves convey the fluid pressure generated by the ATF pump to the appropriate clutches/brakes to be engaged.

Transmission control module -J217- fault recognition

The term "On Board Diagnostic (OBD)" is specifically for the electronic/electric control.

The control module is equipped with a DTC memory so that in the event of an electronic/electrical component failure or on open circuit the fault can be determined quickly. Fault are recognized by electrical signals and stored in the DTC memory together with an indication of the type of fault and fault location.

The control module recognizes faults during vehicle operation and stores them in a DTC memory. This information will remain available even if the system voltage fails.

The control module distinguishes between faults present (permanent) and temporary faults (sporadic).

If a fault is no longer present after a certain period or a lengthy drive, it will be converted to a sporadic (SP) DTC.

A fault will also be converted to sporadic when the DTC memory is not erased after repairs.

Faults which are stored in the memory as sporadically occurring faults, will be displayed as "sporadic DTCs" when checked by the scan tool VAG 1551. In such cases "SP" appears on the right of the display. If the printer is switched on, the print-out will show "sporadic DTC" after the identification of the fault.

If the sporadic DTC does not occur again after 40 cold engine starts (and subsequent transmission warm-up), the fault in DTC memory will be automatically erased.

The possibilities offered by On Board Diagnosis can only be fully utilized with the vehicle diagnostic, testing and information system VAS5051 or the VAG1551 scan tool (mode 1, rapid data transfer).

For available functions of vehicle diagnostic, testing and information system VAS5051 or the VAG1551 scan tool, see LIST OF SELECTABLE FUNCTIONS .

Security functions of the Transmission Control Module (TCM)

When one or more components or sensors fail, the Transmission Control Module (TCM) -J217- activates the appropriate replacement functions or emergency programs. This ensures destruction-free operation of the automatic transmission with some effect on the function and quality of shifting.

When critical malfunctions occur with an active transmission control module -J217-, the currently selected gear will be held. "Mechanical emergency running mode with the control module active" is activated by the transmission control module -J217- as soon as the driving situation regarding transmission security and engine security permits it.

Scheme 588

1. The transmission shifts out of all forward gears into hydraulic 4th gear. The torque converter clutch is unlocked (not applied). All solenoid valves are de-energized.
2. Maximum shift pressure is applied to the power-transmitting elements.
3. Reverse gear can be engaged. The shift locksolenoid is active (in "P" and "N").
4. All of the segments of the transmission range selector lever display are lit up completely.
5. The MIL lights up after 2 Dcy); check DTC memory ( «CHECK DTC MEMORY»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) ) and compare with «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

If the TCM -J217- malfunctions (e.g. if the power supply is faulty or the connector becomes disconnected), the transmission will immediately switch to "mechanical back-up mode with inactive control module" and continue to operate.

Mechanical backup with non-active control module

1. The transmission shifts out of all forward gears into hydraulic 4th gear. The torque converter clutch is unlocked (not applied). All solenoid valves are de-energized.
2. Maximum shift pressure is applied to the power-transmitting elements.
3. Reverse gear can be engaged. The shift lock solenoid is active (in "P" and "N").
4. All of the segments of the transmission range selector lever display are dark.
5. The MIL lights up when the Engine control module (ECM) has recognized a CAN-bus malfunction (missing data exchange between engine and transmission control modules) (after 2 Dcy); if necessary, check DTC memory of the control module.
6. Transmission control module -J217- does not function at all, i.e. it cannot be checked via On Board Diagnostic (OBD).

Scheme 589

Malfunction Indicator Lamp (MIL) function, checking

If emissions-influencing malfunctions are recognized by the TCM, the Malfunction Indicator Lamp (MIL) will be switched on.

Location of the MIL: integrated in speedometer in instrument cluster.

Scheme 590

Note. When the MIL is switched on, it will either blink or light continuously. In either case, the DTC memory for the TCM must be checked. See CHECK DTC MEMORY . MIL flashing: there is a malfunction that could damage the Three Way Catalytic Converter (TWC). In this case, drive only with reduced power. MIL continuously on: there is a malfunction that degrades emissions. Check DTC memory of the Engine Control Module (ECM) or the TCM. If there are driveability problems (e.g. a customer complaint) and the MIL is not on, the MIL functional test must be carried out, since malfunctions that do not immediately switch on the MIL can be stored.

MIL functional check

1. Switch ignition on. the MIL must come on. If the MIL does not come on when the ignition is switched on (with the engine not running): Check DTC memory. See «CHECK DTC MEMORY»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) . If necessary, check wiring per wiring diagram or replace light bulb.
2. Start engine and let idle: the MIL must be switched off after several seconds.

If the MIL is not switched off after the engine is started: Check DTC memory. See CHECK DTC MEMORY .

Conditions for recognition of a driving cycle (Dcy)

A driving cycle (Dcy) is considered complete when the ignition is switched on one time, the engine is started, the engine start is recognized by the control module, and the ignition is switched off again.

On Board Diagnostic (OBD), technical data

TECHNICAL DATA

For Electrical/electronic component locations, see ELECTRICAL/ELECTRONIC COMPONENTS AND LOCATIONS .

On Board Diagnostic II (OBD II), functions

Note. The following modes can be selected via address word 33

Scheme 591

Scheme 592

Electrical/electronic components and locations

Note. The following list refers to items in (Scheme 593).

1. Automatic transmission control module -J217- Location, see «AUTOMATIC TRANSMISSION CONTROL MODULE -J217»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) Removing, see «REMOVING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__removing) Installing, see «INSTALLING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__installing) Control modules are Checked via On Board Diagnostic (OBD). See «ON BOARD DIAGNOSTIC (OBD), INITIATING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
2. Engine control module Location, see «ENGINE CONTROL MODULE»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__engine-control-module) Control modules are Checked via On Board Diagnostic (OBD). See «ON BOARD DIAGNOSTIC (OBD), INITIATING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. Data Link Connector(DLC) Location, see «Data Link Connector (DLC)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__data-link-connector-dlc)
4. Conductor strip with transmission oil temperature sender (ATF) -G93- Location, see «WIRING HARNESS WITH INTEGRATED TRANSMISSION OIL TEMPERATURE SENDER (ATF) -G93»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__wiring-harness-with-integrated-transmission-oil) G93- is Checked via On Board Diagnostic(OBD)
5. Valve body Location, see «VALVE BODY»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__valve-body) The solenoid valves -N88-, -N89-, -N90-, -N91-, -N92-, -N93- and -N94- are attached to the valve body Components are Checked via On Board Diagnostic (OBD)
6. Multi-function switch -F125- Fitting location and removing and installing, see «MULTI-FUNCTION SWITCH -F125»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__multi-function-switch-f125) Checked via On Board Diagnostic (OBD)
7. Transmission input speed sender -G182- Fitting location and removing and installing, see «TRANSMISSION INPUT SPEED SENDER -G182»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) Checked via On Board Diagnostic (OBD)
8. Transmission speed sender -G38- (also referred to as transmission output RPM -G195-) Fitting location and removing and installing, see «TRANSMISSION SPEED SENDER -G38»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__transmission-speed-sender-g38) Checked via On Board Diagnostic (OBD) Records the transmission output speed
9. Tiptronic switch -F189- Fitting location and removing and installing, see «TIPTRONIC SWITCH -F189»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__tiptronic-switch-f189) The switch can be checked in the «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) and in the «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
10. Selector lever lock solenoid -N110- Location, see «SELECTOR LEVER LOCK SOLENOID -N110»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__selector-lever-lock-solenoid-n110) Removing and installing See «SERVICING - A/T (01V)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) . Can be checked electrically in «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) and via «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
11. Throttle valve potentiometer -G69- Location, see «THROTTLE VALVE POTENTIOMETER -G69»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__throttle-valve-potentiometer-g69) The throttle valve potentiometer signal will be checked via On Board Diagnostic (OBD) The throttle valve potentiometer signal is transmitted to the transmission control module via the engine control module. The signal can only be checked in «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) . If the On Board Diagnostic (OBD) indicates a fault in the throttle valve potentiometer, On Board Diagnostic (OBD) must also be performed for the engine control module.
12. Cruise control switch -E45- Location: The cruise control switch is on the steering column Removing and installing: See «LIGHTS, SWITCHES-EXTERIOR - UP TO 2000»(/audi/a6/c5-1997-2001/remont/cruise-control-systems/#lights-switches-exterior-up-to-2000) or «LIGHTS, SWITCHES-EXTERIOR - 2001 AND UP»(ref-196302) . Can be checked during electrical test. See «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
13. Starter inhibitor relay -J207- Location, see «STARTING INTERLOCK RELAY -J207»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__starting-interlock-relay-j207)
14. Selector lever position display -Y6- Location, see «TRANSMISSION RANGE SELECTOR LEVER DISPLAY -Y6»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__transmission-range-selector-lever-display-y6) Selector lever position indicator does not light up indicates that the transmission is in emergency running mode with the Transmission Control Module (TCM) inactive. All segments of selector lever position indicator light up indicates that the transmission is in emergency running mode with the transmission control module active.
15. Kick down switch -F8- Location, see «KICK DOWN SWITCH -F8»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__kick-down-switch-f8) Can be checked electrically in «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) and via «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
16. Brake light switch -F- Location, see «BRAKE LIGHT SWITCH -F»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__brake-light-switch-f) Removing and installing See «ABS/ESP SYSTEM COMPONENTS, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/anti-locktraction-control/#brake-system-abs) . Can be checked electrically in «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) and via «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .

Scheme 593

Scheme 594

The control module is located in front of the right-hand seat under the carpet in foot well.

Scheme 595

Removing

1. Removing lower right A-pillar trim and right door sill trim piece. See «TRIM PANELS (SEDAN)»(/audi/a6/c5-1997-2001/remont/exteriorinterior-trim/#interior-trim) .
2. Detach carpeting from inside of sill (right-side) below front door, and raise carpeting approx. 20 cm.
3. Unclip box at -A- by pulling it upward.
4. Unclip box at -B- as shown.
5. Unclip TCM from box (arrows).
6. Release catch on multi-pin connector and disconnect connector from TCM.

Scheme 596

Installing

Installation is the reverse of removal, with the following additional steps

Scheme 597

Scheme 598

1. Check that clip -1- is properly secured
2. Switch ignition off and wait approx. 30 seconds.
3. Release connector by pressing catch in direction of arrow.

Installation is the reverse of removal.

Engine control module

Location: in electronic box (E-box) in plenum chamber (left side).

Scheme 599

Removing and installing control module

See appropriate article in ENGINE PERFORMANCE.

Data Link Connector (DLC)

Location: The Data Link Connector (DLC) is located under driver's knee bar to left of steering wheel.

Scheme 600

1. Connect VAS5051 tester to vehicle with VAS5051/1 diagnostic wire. Alternately, VAG1551 Scan Tool can also be attached using VAG1551/3 adapter.
2. Enter address word "02 transmission electronics" and switch through until "selecting function XX" appears on display. See «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) .

Valve body

Location: The valve body is bolted to the underside of transmission housing inside the oil pan.

Scheme 601

The solenoid valves -N88-, -N89-, -N90-, -N91-, -N92-, -N93- and -N94- are attached to the valve body. The solenoid valves -N91-, -N92-, -N93- and -N94 are also referred to as pressure control valves 1 (-N215-, 2 (-N216-), 3 (-N217-) and 4 (-N218-).

Removing and installing valve body

See VALVE BODY ASSEMBLY .

A differentiation is made between two types of transmissions

1. For transmissions with hydraulic regulation -E17-, the transmission input speed sensor (inductive sensor) is secured to the underside of the valve body.
2. For transmissions with hydraulic regulation -E18/2-, the transmission input speed sensor (camshaft position sensor) is secured behind valve body at transmission housing.

Information about which transmission is installed

See CODE LETTERS, ENGINE/TRANSMISSION APPLICATIONS, RATIOS, EQUIPMENT .

Wiring harness with integrated transmission oil temperature sender (ATF) -G93

Location: The wiring harness is secured to valve body

Scheme 602

The wiring harness can be removed with the valve body removed and the transmission installed.

Removing and installing wiring harness in transmission

See VALVE BODY ASSEMBLY .

Transmission oil temperature sender (ATF) -G93-, removing and installing

See TRANSAXLE FLUID TEMPERATURE SENSOR .

Multi-function switch -F125

Location: The multi-function switch -1- is located on left at transmission; Multi-pin connector for multi-function switch -arrow-.

Scheme 603

Removing and installing multi-function switch

See TRANSAXLE RANGE SWITCH .

Tiptronic switch -F189

Installation location: tiptronic switch is integrated into conductor strip of symbol insert which is located in cover of shift mechanism.

Note. This switch is not installed on shift mechanisms without tiptronic function.

Scheme 604

It consists of 3 hall-effect sensors (-A-, -B-, -C-), which are activated via a magnet on the lateral gate cover of gate cover.

1. Sensor for down-shift
2. Sensor for Tiptronic-recognition
3. Sensor for up-shift

1. If malfunctions occur, the switch for tiptronic must be checked for interference in «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) and during the «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

In case of interference, it must first be checked whether the magnet at lateral gate cover -C- of gate cover is properly attached, if necessary, replace gate cover. The symbol insert with integrated conductor strip may only be replaced after checking the wires. For vehicles with tiptronic-sport steering wheel, the buttons at steering wheel and its wire connections must also be checked.

Scheme 605

Tiptronic switch -F189 removing and installing

See SERVICING - A/T (01V) .

Transmission speed sender -G38

Location: The transmission speed sender is located at rear right in transmission. It is also referred to as the sensor for transmission output RPM -G195-.

Scheme 606

Removing and installing transmission speed sender

See TRANSAXLE VEHICLE SPEED SENSOR .

Installation location

On transmissions with hydraulic regulation -E17-, the transmission input speed sensor (inductive sensor) is secured to the underside of the valve body (see illustration). On these transmissions the sensor is an inductive sensor.

Scheme 607

On transmissions with hydraulic regulation -E18/2-, the transmission input speed sensor -A- is secured behind valve body at transmission housing. On these transmissions the sensor is a hall effect sensor.

Scheme 608

Information about which transmission is installed can be found in: CODE LETTERS, ENGINE/TRANSMISSION APPLICATIONS, RATIOS, EQUIPMENT .

Removing and installing transmission input speed sender

See TRANSAXLE RPM SENSOR .

Selector lever lock solenoid -N110

Location: The selector lever lock solenoid is located in the selector lever housing -arrow-.

Scheme 609

Removing and installing selector lever lock solenoid

See SERVICING - A/T (01V) .

Throttle valve potentiometer -G69

Location: integrated in throttle valve control module -J338- (gasoline engine) -arrow-.

Note. On TDI-engines and on engines with E-gas, the throttle position sensor (-G79, -G185) takes over the function of the throttle valve potentiometer.

Scheme 610

Starting interlock relay -J207

Installation location: The relay is located on the relay panel, relay No. 4. (Scheme 611)

Scheme 611

Transmission range selector lever display -Y6

Location: In dash panel insert

Scheme 612

Removing and installing transmission range selector lever display

See INSTRUMENTS - UP TO 2000 or INSTRUMENTS - 2001 AND UP .

Kick down switch -F8

Location: gasoline engine without E-Gas

Integrated in accelerator pedal cable, in plenum chamber, behind bulkhead -arrow-.

Scheme 613

Location: TDI engines and engines with E-gas

The kick down switch is integrated in the throttle position sensor (-G79, -G185).

A learning procedure must be performed for the shift point of the kick down switch for TDI engines and engines with E-gas if the throttle position sensor (-G79, -G185) is removed, the engine control module is exchanged or the battery is disconnected. Proceedure for learning can be found in the corresponding MULTIPORT FUEL INJECTION (MFI) article in ENGINE PERFORMANCE (Kick down shift point, checking).

Kick down-switch removing and installing

1. To remove and install the kick down switch, the accelerator pedal cable must be removed and installed and then adjusted, or the throttle position sensor (-G79, -G185) must be replaced. See «ACCELERATOR PEDAL (AP) CABLE, SERVICING - VEHICLES WITH MECHANICAL ACCELERATOR MECHANISM»(/audi/a6/c5-1997-2001/remont/fuel-system/#fuel-supply-system-all-engines) or «ACCELERATOR PEDAL (AP), SERVICING - VEHICLES WITH ELECTRONIC POWER CONTROL (EPC) (DRIVE BY WIRE)»(/audi/a6/c5-1997-2001/remont/fuel-system/#fuel-supply-system-all-engines__accelerator-pedal-ap-servicing-vehicles) .

Brake light switch -F

Location: Brake light switch is located on pedal cluster.

Scheme 614

Removing and installing brake light switch

See ABS/ESP SYSTEM COMPONENTS, REMOVING AND INSTALLING .

Note. For engine with E-gas, the brake light signal is transmitted from engine control module to transmission control module via the CAN-Bus.

Additional information

1. «OVERHAUL - 01VAUDI A6 REPAIR MANUAL, 5 SPD. AUTOMATIC TRANSMISSION 01V»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01v)
2. System Wiring Diagrams
3. Technical service bulletins
4. Parts catalog

Safety precautions

If special testing equipment is required during test drive, note the following

To reduce the risk of personal injury and/or damage of electric and electronic components, always observe the following

1. Always switch ignition off before connecting or disconnecting test/measurement tools.
2. It is possible that the control module will recognize a malfunction and store a DTC during some tests. After completing all tests and repairs, DTC memory should therefore be checked and erased if necessary.
3. Always switch ignition off before disconnecting and connecting battery to avoid damaging the transmission control module.

VAS5051 tester or VAG1551 scan tool, connecting and selecting functions

Test requirements

1. Selector lever in position "P" and parking brake applied.
2. Vehicle voltage supply OK
3. Power supply and fuses for respective system OK

1. Ground (GND) connections and Ground point for transmission OK

1. Check Ground connections for corrosion and damage and repair if necessary.
2. Check battery Ground (GND) strap and Ground strap between battery and transmission.
3. Switch ignition off.
4. Connect VAS5051 tester to vehicle with VAS5051/1 diagnostic wire. Alternately, VAG1551 Scan Tool can also be attached using VAG1551/3 adapter.

Note. The DLC is located below the front knee bar at the left side.

Scheme 615

Note. The following description only explains implementation of On Board Diagnostic using VAG1551 Scan tool: When using the VAS5051 make sure the tester instructions are followed.

Indicated on display

Scheme 616

Operating modes 1 and 2 are displayed alternately.

Note. Additional operating instructions can be retrieved by pressing the HELP key of VAG 1551. The => key is used for advancing within the program sequence. An automatic check (keys 00) can be carried out in the operating mode 1 "Rapid data transfer". Then all vehicle control modules will be checked automatically. See Scan tool VAG 1551 operating instructions.

1. Switch on ignition.
2. Switch on printer with the Print key (indicator lamp in key lights up).
3. Press key 1 for "Rapid data transfer" mode.

Indicated on display

Scheme 617

1. Press keys 0 and 2. (Enter the address word "transmission electronics" with 02.)

Indicated on display

Scheme 618

1. Confirm entry with key Q.

Appears on display

Scheme 619

The control module identification is displayed

Control module identification

Depending upon the software version, the control module may indicate a different control module identification, to that shown in the example. Allocation of control module. See Parts catalog.

1. 4B0927156 BT: Part number
2. AG5 01V: 5-speed automatic transmission 01V
3. 2.8l 5V: Engine version
4. USA: (country allocation), USA and CANADA
5. 1416: 14 = program version; 16 = data version
6. Coding 00002: Coding, see «CODE CONTROL MODULE (SCAN TOOL FUNCTION 07)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__code-control-module-scan-tool-function)
7. WSC 00000: Dealer number of VAG 1551, with which the last coding was performed.

Indicated on display

Scheme 620

1. By pressing the HELP key, a list of possible fault causes is printed out.
2. After eliminating the possible causes of faults, again enter address word 02 for "transmission electronics" and confirm.

If "Control module does not answer!" again appears

Indicated on display

Scheme 621

Check control module voltage supply.

Scheme 622

1. Perform test step 1 in «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
2. Check wiring connections to diagnostic sockets
3. Replace control module if necessary Location and removing and installing control module, see «AUTOMATIC TRANSMISSION CONTROL MODULE -J217»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v)
4. Press => key. Indicated on display
5. After the HELP key is pressed, a list of the possible functions is printed out.

List of selectable functions

Further functions, which can be printed out by pressing the HELP key, can be disregarded.

LIST OF SELECTABLE FUNCTIONS

1. After checking a function the VAG 1551 returns to the following start position

Scheme 623

Indicated on display

Scheme 624

1. Connect VAS5051 tester to vehicle using VAS5051/1 diagnostic wire. Alternately, VAG1551 Scan Tool can also be attached using VAG1551/3 adapter.
2. Advance until "Select function XX" appears in the display. See «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) .

Indicated on display

Scheme 625

1. Press keys 0 and 2. (The function "Check DTC memory" is selected with 02).

Indicated on display

Scheme 626

1. Confirm entry with key Q.

The number of faults stored or "No DTC recognized!" will be shown on the display.

The stored faults will be displayed and printed out one after the other.

1. Press the => key.
2. Repair malfunctions after displaying and printing out the last malfunction according to «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. Press the => key.

Indicated on display

Scheme 627

Note. After DTC memory has been checked and malfunctions have been repaired

Scheme 628

1. Erase DTC memory.

Important notes

Note. In the following, all possible malfunctions are listed in ascending order of DTC. These malfunctions can be recognized by the transmission control module -J217-. They are then displayed on the VAS5051 tester or VAG1551 scan tool when checking DTC memory content. Starting on the next page is a list of all the DTCs with all MIL conditions. The DTC is only printed out in the "Rapid data transfer" operating mode when the printer of the VAG1551 ST is switched on. Example: DTC 16987 P0603 If malfunctions only occur sometimes or if DTC memory was not erased after malfunction repair, these malfunctions are displayed as "sporadic malfunctions" for a pre-determined time period. For malfunction recognition of transmission control module, see ON BOARD DIAGNOSTIC (OBD), FUNCTION . If components are indicated as being faulty during the check of DTC memory, also test the wiring to the components for short circuit and open circuit according to wiring diagram.

List of all DTCs with the MIL condition

Note. Dcy = Driving cycle. For conditions for recognition of a Dcy, see CONDITIONS FOR RECOGNITION OF A DRIVING CYCLE (DCY) . For meaning of the Malfunction indicator Lamp (MIL), see MALFUNCTION INDICATOR LAMP (MIL) FUNCTION, CHECKING . The "MIL" column in the DTC table indicates the condition of for which the Malfunction Indicator Lamp (MIL) would be switched on. If, for example, "2 Dcy" is indicated in the table, the MIL would light up after two driving cycles. If "Off" is indicated, the malfunction has no influence on the MIL.. If "On" is indicated, the MIL will light up immediately after the malfunction occurs. For "Hydraulic control" column: Which transmission is equipped with which hydraulic control can be found in: See CODE LETTERS, ENGINE/TRANSMISSION APPLICATIONS, RATIOS, EQUIPMENT .

Scheme 629

Scheme 630

Scheme 631

Scheme 632

Scheme 633

Scheme 634

Scheme 635

Scheme 636

1. For output diagnostic test mode, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .

Scheme 637

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For output diagnostic test mode, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (SCAN TOOL FUNCTION 03)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__output-diagnostic-test-mode-dtm-scan) .
3. For electrical check, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Notes for malfunction recognition for DTC 00258 / P0753

1. Short circuit to B+ is already checked with ignition switched on. During operation, all malfunction types are recognized.

Scheme 638

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For output diagnostic test mode, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (SCAN TOOL FUNCTION 03)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__output-diagnostic-test-mode-dtm-scan) .
3. For electrical check, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Note. For malfunction recognition for DTC 00260 / P0758

1. Short circuit to B+ is already checked with ignition switched on. During operation, all malfunction types are recognized.

Scheme 639

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For output diagnostic test mode, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (SCAN TOOL FUNCTION 03)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__output-diagnostic-test-mode-dtm-scan) .
3. For electrical check, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Note. For malfunction recognition for DTC 00262 / P0763

1. Short circuit to B+ is already checked with ignition switched on. During operation, all malfunction types are recognized.

Scheme 640

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For output diagnostic test mode, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (SCAN TOOL FUNCTION 03)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__output-diagnostic-test-mode-dtm-scan) .
3. For electrical check, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 641

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For output diagnostic test mode, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (SCAN TOOL FUNCTION 03)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__output-diagnostic-test-mode-dtm-scan) .
3. For electrical check, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 642

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For output diagnostic test mode, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (SCAN TOOL FUNCTION 03)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__output-diagnostic-test-mode-dtm-scan) .
3. For electrical check, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 643

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical check, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To replace transmission range switch F125, see «TRANSAXLE RANGE SWITCH»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Scheme 644

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical check, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To replace or adjust accelerator pedal cable, see «ACCELERATOR PEDAL (AP) CABLE, SERVICING - VEHICLES WITH MECHANICAL ACCELERATOR MECHANISM»(/audi/a6/c5-1997-2001/remont/fuel-system/#fuel-supply-system-all-engines) .

Note. For DTC 00296 / P1704: Requirements for malfunction recognition: throttle position signal is OK, throttle position value is less than 25 % and kick down input at Transmission Control Module (TCM) is shorted to Ground (GND) (equivalent to kick down signal). Short circuit to B+ between kick down switch -F8- and TCM cannot be detected by OBD.

Scheme 645

Scheme 646

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical check, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To check ATF level, see «CHECKING FLUID LEVELS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v__checking-fluid-levels) .
4. To replace transmission vehicle speed sensor G38, see «TRANSAXLE VEHICLE SPEED SENSOR»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Note. For malfunction recognition for DTC 00297 / P0722: The DTC recognition process includes a plausibility test: the ratio of transmission RPM to engine RPM and transmission input RPM with the gear currently engaged is implausible. Requirement for test: a driving mode must definitely be selected (not P or D) or between gate positions and the shift must be complete.

Scheme 647

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical check, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To check ATF level, see «CHECKING FLUID LEVELS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v__checking-fluid-levels) .

1. Pay attention to which hydraulic control the transmission has when selecting measuring value block. For a more detailed description, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .

1. A differentiation is made between vehicle types with and without CAN-bus. For a precise definition of which vehicles are equipped with CAN-bus, see «CODE LETTERS, ENGINE/TRANSMISSION APPLICATION»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01l-awd) .

Note. To check identification of TCM, see VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS .

Note. For DTC 00518 / P0121 for vehicles WITH CAN-Bus: The signal from the throttle position sensor -G39- is transmitted by the engine control module to the transmission control module via the CAN-bus. Requirements for malfunction recognition: Malfunction of the component is recognized by the Engine Control Module. This diagnostic is transmitted to the Transmission Control Module (TCM) via the CAN bus wiring. For DTC 00518 / P0121 for vehicles WITHOUT a CAN-Bus (Scheme 649)

Note. DTC 00518 / P0121 is for vehicles WITHOUT a CAN-Bus. For vehicles with a CAN-Bus (Scheme 648)

Scheme 648

1. One of these indications is also displayed for the relevant component.
2. On vehicle with Motronic fuel injection and ignition, the only malfunction that will be displayed is "Incorrect signal."
3. Pay attention to which hydraulic control the transmission has when selecting measuring value block. For a more detailed description, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .

1. A differentiation is made between vehicle types with and without CAN-bus. For a precise definition of which vehicles are equipped with CAN-bus, see «CODE LETTERS, ENGINE/TRANSMISSION APPLICATION»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01l-awd) .

Note. For DTC 00518 / P0121 for vehicle types WITHOUT CAN-Bus A): The signal is transmitted in digital form from the throttle position sensor "G69- via the Engine Control Module (ECM) to the Transmission Control Module (TCM). Malfunction recognition of DTC 00518 by the TCM is much more sensitive than detection by the ECM. This means that a brief interruption in the throttle position signal (up to 1 second) is not detected by the ECM, but is registered as a malfunction by the TCM. Requirements for malfunction recognition: frequency of digital signal to TCM is outside the permissible tolerance (signal pulse must occur at least every 30 ms). For DTC 00518 / P0121 for vehicles WITH a CAN-Bus (Scheme 648)

Scheme 649

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical check, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Note. For DTC 00526 / P0703: This malfunction is pre-set when the ignition is switched on and then cancelled when the brake pedal is pressed for the first time, provided that the brake light switch -F- is OK. Before checking DTC memory, press the brake pedal briefly to cancel the pre-set malfunction.

Note. DTC 00529 / P0727 for vehicles WITH the CAN-Bus (Scheme 651) For vehicles WITHOUT CAN-Bus (Scheme 652)

Scheme 650

Note. To check TCM identification, see VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS .

1. Pay attention to which hydraulic control the transmission has when selecting measuring value block. For a more detailed description, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .

1. A differentiation is made between vehicle types with and without CAN-bus. For a precise definition of which vehicles are equipped with CAN-bus: See «CODE LETTERS, ENGINE/TRANSMISSION APPLICATION»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01l-awd) .

Note. For DTC 00529 / P0727 for vehicle types WITH CAN-Bus: The engine speed signal is transmitted by the Engine Control Module (ECM) to the Transmission Control Module (TCM) via the CAN bus wiring. Requirements for malfunction recognition: Malfunction of the relevant component is recognized by the Engine Control Module. This diagnostic is transmitted to the Transmission Control Module (TCM) via the CAN bus wiring.

Note. DTC 00529 / P0727 for vehicles WITHOUT CAN-Bus (Scheme 652) For vehicles with CAN-Bus (Scheme 651)

Scheme 651

1. One of these indications is also displayed for the relevant component.
2. Pay attention to which hydraulic control the transmission has when selecting measuring value block. For a more detailed description, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .

1. A differentiation is made between vehicle types with and without CAN-bus. For a precise definition of which vehicles are equipped with CAN-bus: See «CODE LETTERS, ENGINE/TRANSMISSION APPLICATION»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01l-awd) .

Note. For DTC 00529 / P0727 for vehicle types WITHOUT CAN-Bus: Malfunction recognition of DTC 00529 / P0727 by the TCM is much more sensitive than detection by the ECM. This means that a brief interruption in the throttle position signal (up to 1 second) is not detected by the ECM, but is registered as a malfunction by the TCM. Malfunction detection for DTC 00529 / P0727 is based on a plausibility test relating the signal to the fuel consumption signal (or if not installed to throttle position value). Requirements for malfunction recognition: Multi-function TR switch -F125- OK, fuel consumption signal or throttle position signal OK, recognized value for transmission RPM above 200 RPM and 200 ms no engine RPM signal at Transmission Control Module (TCM).

Scheme 652

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical test, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 653

Scheme 654

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. To replace valve body, see «VALVE BODY ASSEMBLY»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Scheme 655

1. Pay attention to which hydraulic control the transmission has when selecting measuring value block. For a more detailed description, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .

Note. For malfunction recognition of DTC 00545 / P0702 (only malfunction type "harness connector): Condition for malfunction recognition: TCM is not receiving throttle position signal or consumption signal. Detected transmission input speed higher than 2000 RPM. This malfunction can only occur on vehicles WITHOUT CAN bus.

1. A differentiation is made between vehicle types with and without CAN-bus. For a precise definition of which vehicles are equipped with CAN-bus: See «CODE LETTERS, ENGINE/TRANSMISSION APPLICATION»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01l-awd) .

Scheme 656

Note. For DTC 00549: This malfunction can only occur for vehicles Without CAN bus.

1. A differentiation is made between vehicle types with and without CAN-bus. Precise definition of which vehicles are equipped with CAN-bus See «CODE LETTERS, ENGINE/TRANSMISSION APPLICATION»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01l-awd) .

Scheme 657

Note. For DTC 00638 / P0702 and 00638 / P1767: This malfunction can only occur for vehicles WITHOUT CAN bus.

1. A differentiation is made between vehicle types with and without CAN-bus. Precise definition of which vehicles are equipped with CAN-bus See «CODE LETTERS, ENGINE/TRANSMISSION APPLICATION»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01l-awd) .

Scheme 658

1. To check ATF level, see «CHECKING FLUID LEVELS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v__checking-fluid-levels) .
2. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
3. For output diagnostic test mode, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (SCAN TOOL FUNCTION 03)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__output-diagnostic-test-mode-dtm-scan) .
4. To replace valve body, see «VALVE BODY ASSEMBLY»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .
5. For transmission codes, see «CODE LETTERS, ENGINE/TRANSMISSION APPLICATION»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01l-awd) .

Scheme 659

1. The check TCM identification, see «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) .

Note. For malfunction recognition for DTC 00652 / P0732: The ratio of engine RPM to transmission input RPM and transmission RPM with driving mode selected is implausible. (Requirement for malfunction recognition: transmission input RPM and transmission RPM larger than 64 RPM and engine RPM larger than 1400 RPM.) Implausibility of gear ratio of second gear is recognized by the Transmission Control Module (TCM).

Scheme 660

1. To check ATF level, see «CHECKING FLUID LEVELS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v__checking-fluid-levels) .
2. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
3. For output diagnostic test mode, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (SCAN TOOL FUNCTION 03)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__output-diagnostic-test-mode-dtm-scan) .
4. To replace valve body, see «VALVE BODY ASSEMBLY»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .
5. For transmission codes, see «CODE LETTERS, ENGINE/TRANSMISSION APPLICATION»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01l-awd) .

Scheme 661

1. Pay attention to which hydraulic control the transmission has when selecting measuring value block. For a more detailed description,see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .

Note. For malfunction recognition for DTC 00652 / P0733: The ratio of engine RPM to transmission input RPM and transmission RPM with driving mode selected is implausible. (Requirement for malfunction recognition: transmission input RPM and transmission RPM larger than 64 RPM and engine RPM larger than 1400 RPM) Implausibility of gear ratio of third gear is recognized by the Transmission Control Module (TCM).

Scheme 662

1. To check ATF level, see «CHECKING FLUID LEVELS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v__checking-fluid-levels) .
2. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
3. For output diagnostic test mode, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (SCAN TOOL FUNCTION 03)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__output-diagnostic-test-mode-dtm-scan) .
4. To replace valve body, see «VALVE BODY ASSEMBLY»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .
5. For transmission codes, see «CODE LETTERS, ENGINE/TRANSMISSION APPLICATION»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01l-awd) .

Scheme 663

1. Pay attention to which hydraulic control the transmission has when selecting measuring value block. For a more detailed description, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .

Note. For malfunction recognition for DTC 00652 / P0734: The ratio of engine RPM to transmission input RPM and transmission RPM with driving mode selected is implausible. (Requirement for malfunction recognition: transmission input RPM and transmission RPM larger than 64 RPM and engine RPM larger than 1400 RPM.) Implausibility of gear ratio of third gear is recognized by the Transmission Control Module (TCM).

Scheme 664

1. To check ATF level, see «CHECKING FLUID LEVELS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v__checking-fluid-levels) .
2. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
3. For output diagnostic test mode, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (SCAN TOOL FUNCTION 03)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__output-diagnostic-test-mode-dtm-scan) .
4. To replace valve body, see «VALVE BODY ASSEMBLY»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .
5. For transmission codes, see «CODE LETTERS, ENGINE/TRANSMISSION APPLICATION»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01l-awd) .

Scheme 665

1. Pay attention to which hydraulic control the transmission has when selecting measuring value block. For a more detailed description, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .

Note. For malfunction recognition for DTC 00652 / P0735: The ratio of engine RPM to transmission input RPM and transmission RPM with driving mode selected is implausible. (Requirement for malfunction recognition: transmission input RPM and transmission RPM larger than 64 RPM and engine RPM larger than 1400 RPM) Implausibility of gear ratio of third gear is recognized by the Transmission Control Module (TCM).

Scheme 666

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Note. For DTC 00668 / P0560: When vehicle voltage (terminal 30) fails, application values are lost, i.e Transmission Control Module (TCM) must learn these values again when vehicle is started. During this renewed "learning", shifting quality may be worse than normal. This malfunction will only be registered by OBD if it occurs 5 times consecutively after the ignition is switched off and on.

Scheme 667

1. To check TCM identification, see «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) .

Scheme 668

1. To check ATF level, see «CHECKING FLUID LEVELS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v__checking-fluid-levels) .
2. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
3. To remove and install valve body, see «VALVE BODY ASSEMBLY»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .
4. To check TCM identification, see «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) .

Note. For malfunction recognition for DTC 01192 / P0741: The ratio of transmission speed and transmission input speed to engine speed (RPM) with the torque converter lock-up clutch closed (applied) is implausible.

Scheme 669

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
2. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
3. To check TCM identification, see «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) .

Note. For DTC 01196 / P1625: This malfunction can only occur on vehicle models with CAN-Bus. For function of CAN bus, see CAN-BUS, FUNCTION .

Scheme 670

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
2. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .

Scheme 671

1. To replace control module, see «REMOVING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__removing) .

Note. For DTCs 16987 / P 0603, 16989 / P0605 and 17086 / P0702: Only after determining possible malfunction cause and repairing the following malfunctions: mechanical malfunction hydraulic malfunction electrical/electronic components as well as wire connections

Scheme 672

1) Pay attention to which hydraulic control the transmission has when selecting measuring value block. For a more detailed description, see READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08) .

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. To replace brake light switch, see «ABS/ESP SYSTEM COMPONENTS, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/anti-locktraction-control/#brake-system-abs) .
3. To check TCM identification, see «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) .

Note. For DTC 17087 / P0703: The signal from brake light switch -F is transmitted by the Engine Control Module (ECM) to the Transmission Control Module (TCM) via the CAN-Bus wire. Conditions for malfunction recognition: The signals of the brake light switch and of the brake test switch are transmitted via the CAN-Bus wire to the transmission Control Module (TCM) and evaluated from there. In case of implausibility this DTC appears in Transmission Control Module (TCM).

Scheme 673

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To replace transmission range switch, see «TRANSAXLE RANGE SWITCH»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Scheme 674

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To replace transmission fluid temperature sensor, see «TRANSAXLE FLUID TEMPERATURE SENSOR»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Scheme 675

1. First check harness connectors for contact corrosion and water ingress, replace if necessary. If there are malfunctions indicated, pay particular attention to the 16-pin harness connector at transmission between valve body and cable harness.
2. Transmission fluid temperature sensor -G93- is integrated in the wiring harness in the transmission (at valve body).
3. Pay attention to which hydraulic control the transmission has when selecting measuring value block. For a more detailed description, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To replace transmission fluid temperature sensor, see «TRANSAXLE FLUID TEMPERATURE SENSOR»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Note. For DTC 17095 / P0711: Requirement for malfunction recognition: The transmission oil temperature does not increase after starting engine or makes temperature leaps.

Scheme 676

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To replace transmission fluid temperature sensor, see «TRANSAXLE FLUID TEMPERATURE SENSOR»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Scheme 677

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To replace transmission fluid temperature sensor, see «TRANSAXLE FLUID TEMPERATURE SENSOR»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Scheme 678

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To replace transmission RPM sensor, see «TRANSAXLE RPM SENSOR»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v__transaxle-rpm-sensor) .
4. To check ATF level, see «CHECKING FLUID LEVELS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v__checking-fluid-levels) .
5. For output diagnostic test mode, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (SCAN TOOL FUNCTION 03)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__output-diagnostic-test-mode-dtm-scan) .
6. To replace solenoid valves or valve body, see «VALVE BODY ASSEMBLY»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Scheme 679

Note. The following footnotes are for DTC 17100/P0716 (2 Of 2).

1. First check harness connectors for contact corrosion and water ingress, replace if necessary.
2. Pay attention to which hydraulic control the transmission has when selecting measuring value block. For a more detailed description, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .

Note. For DTC 17100 / P0716: Requirement for malfunction recognition: A drive mode (D, 4, 3 or 2) is definitely selected, no in-between positions. The engine speed while driving is larger than 608 RPM. The transmission output RPM while driving is larger than 416 RPM. The DTC will be displayed if the conditions for malfunction recognition have been met and the transmission input RPM is 0 RPM or larger than 8000 RPM.

Scheme 680

Scheme 681

Note. For malfunction recognition of DTC 17101 / P0717: Malfunction recognition includes a plausibility test: The ratio from transmission input RPM to engine RPM and transmission output RPM with drive mode selected is implausible. (Test requirement: a driving mode must clearly be selected, not -P- or -N- or between modes and gear must already be engaged).

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To replace transmission RPM sensor, see «TRANSAXLE RPM SENSOR»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v__transaxle-rpm-sensor) .
4. To check ATF level, see «CHECKING FLUID LEVELS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v__checking-fluid-levels) .
5. For output diagnostic test mode, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (SCAN TOOL FUNCTION 03)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__output-diagnostic-test-mode-dtm-scan) .
6. To replace solenoid valves or valve body, see «VALVE BODY ASSEMBLY»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Scheme 682

Scheme 683

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To replace transmission output RPM sensor, see «TRANSAXLE VEHICLE SPEED SENSOR»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .
4. To check ATF level, see «CHECKING FLUID LEVELS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v__checking-fluid-levels) .

Scheme 684

Scheme 685

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To replace transmission output RPM sensor, see «TRANSAXLE VEHICLE SPEED SENSOR»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .
4. To check ATF level, see «CHECKING FLUID LEVELS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v__checking-fluid-levels) .

Note. For malfunction recognition of DTC 17106 / P0722: Malfunction recognition includes a plausibility test: The ratio from transmission input RPM to engine RPM and transmission output RPM with drive mode selected is implausible. (Test requirement: a driving mode must clearly be selected, not -P- or -N- or between modes and gear must already be engaged).

Scheme 686

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. To check TCM identification, see «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) .
3. To check ECM DTCs, see appropriate ON-BOARD DIAGNOSTIC (OBD) article in ENGINE PERFORMANCE.

Note. For DTC 17110 / P0726: The engine speed signal is transmitted by the Engine Control Module (ECM) to the Transmission Control Module (TCM) via the CAN bus wiring.

Scheme 687

1. To check ATF level, see «CHECKING FLUID LEVELS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v__checking-fluid-levels) .
2. For output diagnostic test mode, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
4. To check TCM identification, see «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) .

Note. The following footnotes are for (Scheme 688).

Note. For malfunction recognition of DTC 17114 / P0730: Gear monitoring of the Transmission Control Module (TCM) checks the translation ratio by comparing transmission input RPM and transmission output RPM based on the currently selected gear. This malfunction is indicated when an unrecognized, unauthorized gear ratio occurs (implausibility). When checking the standstill RPM, the transmission input RPM in converter at standstill with gear selected must be close to zero. If this is not the case, this malfunction is also displayed since clutch may be damaged. See READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08) ; Display group number 001.

Scheme 688

1. For output diagnostic test mode, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
2. For clutch and solenoid valve logic, see «SHIFT ELEMENT POSITIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01v) .
3. To check TCM identification, see «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) .

Note. For malfunction recognition of DTC 17115 / P0731: Gear monitoring of the Transmission Control Module (TCM) checks the translation ratio by comparing transmission input RPM and transmission output RPM based on the currently selected gear. This malfunction is indicated when an unrecognized, unauthorized gear ratio occurs (implausibility).

Scheme 689

1. For output diagnostic test mode, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
2. For clutch and solenoid valve logic, see «SHIFT ELEMENT POSITIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01v) .
3. To check TCM identification, see «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) .

Note. For malfunction recognition of DTC 17116 / P0732: Gear monitoring of the Transmission Control Module (TCM) checks the translation ratio by comparing transmission input RPM and transmission output RPM based on the currently selected gear. This malfunction is indicated when an unrecognized, unauthorized gear ratio occurs (implausibility).

Scheme 690

1. For output diagnostic test mode, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
2. For clutch and solenoid valve logic, see «SHIFT ELEMENT POSITIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01v) .
3. To check TCM identification, see «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) .

Note. For malfunction recognition of DTC 17117 / P0733: Gear monitoring of the Transmission Control Module (TCM) checks the translation ratio by comparing transmission input RPM and transmission output RPM based on the currently selected gear. This malfunction is indicated when an unrecognized, unauthorized gear ratio occurs (implausibility).

Scheme 691

1. For output diagnostic test mode, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
2. For clutch and solenoid valve logic, see «SHIFT ELEMENT POSITIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01v) .
3. To check TCM identification, see «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) .

Note. For malfunction recognition of DTC 17118 / P0734: Gear monitoring of the Transmission Control Module (TCM) checks the translation ratio by comparing transmission input RPM and transmission output RPM based on the currently selected gear. This malfunction is indicated when an unrecognized, unauthorized gear ratio occurs (implausibility)

Scheme 692

1. For output diagnostic test mode, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
2. For clutch and solenoid valve logic, see «SHIFT ELEMENT POSITIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01v) .
3. To check TCM identification, see «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) .

Note. For malfunction recognition of DTC 17119 / P0735: Gear monitoring of the Transmission Control Module (TCM) checks the translation ratio by comparing transmission input RPM and transmission output RPM based on the currently selected gear. This malfunction is indicated when an unrecognized, unauthorized gear ratio occurs (implausibility).

Scheme 693

Scheme 694

1. To check ATF level, see «CHECKING FLUID LEVELS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v__checking-fluid-levels) .
2. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
3. To replace valve body, see «VALVE BODY ASSEMBLY»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .
4. To replace torque converter, see «TORQUE CONVERTER»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01v) .

Note. For malfunction recognition of DTC 17125 / P0741: The ratio from sensor for transmission RPM -G182- to engine RPM with torque clutch does not match (implausibility).

Scheme 695

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. To perform output diagnostic test mode, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (SCAN TOOL FUNCTION 03)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__output-diagnostic-test-mode-dtm-scan) .
3. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Note. For malfunction recognition of DTCs 17135 / P0751 and 17136 / P0752: Short circuit to B+ is already checked with ignition switched on. During operation, all malfunction types are recognized.

Scheme 696

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. To perform output diagnostic test mode, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (SCAN TOOL FUNCTION 03)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__output-diagnostic-test-mode-dtm-scan) .
3. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 697

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. To perform output diagnostic test mode, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (SCAN TOOL FUNCTION 03)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__output-diagnostic-test-mode-dtm-scan) .
3. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 698

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. To perform output diagnostic test mode, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (SCAN TOOL FUNCTION 03)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__output-diagnostic-test-mode-dtm-scan) .
3. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 699

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. To perform output diagnostic test mode, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (SCAN TOOL FUNCTION 03)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__output-diagnostic-test-mode-dtm-scan) .
3. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 700

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. To perform output diagnostic test mode, see «OUTPUT DIAGNOSTIC TEST MODE (DTM) (SCAN TOOL FUNCTION 03)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__output-diagnostic-test-mode-dtm-scan) .
3. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 701

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. To replace valve body, see «VALVE BODY ASSEMBLY»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Note. For DTC 17968 / P1560: Requirement for malfunction recognition: Engine RPM larger than 7400 RPM.

Scheme 702

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To check and adjust pedal position sensor, see «ACCELERATOR PEDAL CABLE, CHECKING - VEHICLES WITH AUTOMATIC TRANSMISSION (KICK-DOWN SWITCH, CHECKING)»(/audi/a6/c5-1997-2001/remont/fuel-system/#fuel-supply-system-all-engines) or «ACCELERATOR PEDAL (AP), SERVICING - VEHICLES WITH ELECTRONIC POWER CONTROL (EPC) (DRIVE BY WIRE)»(/audi/a6/c5-1997-2001/remont/fuel-system/#fuel-supply-system-all-engines__accelerator-pedal-ap-servicing-vehicles) .

Note. For DTC 18112 / P1704: Requirements and DTC recognition: Throttle valve signal is OK, throttle valve value smaller than 25% and kick down - input at transmission control module has a short circuit to Ground (GND) (corresponds kick down signal) or B+, engine must run. This malfunction can erroneously be displayed when the brake pedal is depressed and the accelerator pedal is depressed at the same time to kick down (WOT) even though the kick down switch is OK.

Scheme 703

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To replace selector lever gate cover, see «SERVICING - A/T (01V)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Note. For malfunction recognition for DTC 18141 / P1733: A malfunction is displayed if a shift of the back-switch 1) outside the selector lever position D was detected. This malfunction can only be indicated for vehicles with tiptronic shift operation.

Scheme 704

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To replace selector lever gate cover, see «SERVICING - A/T (01V)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Note. For malfunction recognition for DTC 18147 / P1739: A malfunction is displayed if a shift of the back-switch outside the selector lever position D was detected. This malfunction can only be indicated for vehicles with tiptronic shift operation.

Scheme 705

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To replace selector lever gate cover, see «SERVICING - A/T (01V)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Note. For malfunction recognition for DTC 18152 / P1744: A malfunction is displayed when the tiptronic recognition is recognized, even though the selector lever is not in the tiptronic gate. This malfunction can only be indicated for vehicles with tiptronic shift operation.

Scheme 706

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To replace TCM, see «REMOVING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__removing) .

Scheme 707

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To replace TCM, see «REMOVING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__removing) .

Scheme 708

1. To replace TCM, see «REMOVING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__removing) .

Note. For DTCs 18156 / P1748: Only after determining the possible malfunction cause and repairing the following malfunctions mechanical malfunction hydraulic malfunction electrical/electronic components as well as wire connections

Scheme 709

1. To check TCM identification, see «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) .
2. To code TCM, see «CODE CONTROL MODULE (SCAN TOOL FUNCTION 07)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__code-control-module-scan-tool-function) .
3. To replace TCM, see «REMOVING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__removing) .

Scheme 710

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To replace TCM, see «REMOVING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__removing) .

Note. For DTC 18158 / P1750: Requirement for malfunction recognition: Battery voltage smaller than 9 Volts, transmission shifts into emergency running mode. See SECURITY FUNCTIONS OF THE TRANSMISSION CONTROL MODULE (TCM) . When vehicle voltage (terminal 30) fails, application values are lost, i.e. Transmission Control Module (TCM) must learn these values again when vehicle is started. During this renewed "learning", shifting quality may be lower than normal.

Scheme 711

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Note. For DTC 18159 / P1751: Requirement for malfunction recognition: Battery voltage larger than 16 Volts. The battery monitoring differentiates four ranges: (U = Battery voltage). U < 7 Volts . Transmission switches into emergency running mode. See SECURITY FUNCTIONS OF THE TRANSMISSION CONTROL MODULE (TCM) . 7 Volts < U < 9 Volts. Gear is held for approx. 2.5 seconds, if voltage is still in this range, the transmission shifts into emergency running mode. See SECURITY FUNCTIONS OF THE TRANSMISSION CONTROL MODULE (TCM) . 9 Volts < U < 16 Volts. Voltage is OK U > 16 Volts. Transmission shifts into emergency running mode. See SECURITY FUNCTIONS OF THE TRANSMISSION CONTROL MODULE (TCM) .

Scheme 712

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Note. For DTC 18160 / P1752: Requirement for malfunction recognition: Battery voltage smaller than 9 Volts; ransmission does not shift into emergency running mode. See SECURITY FUNCTIONS OF THE TRANSMISSION CONTROL MODULE (TCM) . When vehicle voltage (terminal 30) fails, application values are lost, i.e. Transmission Control Module (TCM) must learn these values again when vehicle is started. During this renewed "learning", shifting quality may be lower than normal.

Scheme 713

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To replace symbol insert in shift mechanism, see «SERVICING - A/T (01V)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .
4. To replace TCM, see «REMOVING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__removing) .

Scheme 714

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To replace shift lock solenoid or symbol insert in shift mechanism, see «SERVICING - A/T (01V)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .
4. To replace TCM, see «REMOVING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__removing) .

Scheme 715

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To replace shift lock solenoid, see «SERVICING - A/T (01V)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .
4. To replace TCM, see «REMOVING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__removing) .

Scheme 716

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Note. For DTC 18180 / P1772 and 18179 / P1771: Requirement for malfunction recognition: no signal of the engine RPM signal or the throttle valve signal is detected, and no load signal for 245 ms. If a malfunction of the load signal is detected by the engine control module, this malfunction is communicated to the transmission control module.

Scheme 717

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Note. For DTC 18192 / P1784: This malfunction can only occur for vehicles without CAN bus.

1. A differentiation is made between vehicle types with and without CAN-bus.

Scheme 718

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Note. For DTC 18193 / P1785: This malfunction can only occur for vehicles without CAN bus.

1. A differentiation is made between vehicle types with and without CAN-bus.

Scheme 719

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 720

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 721

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 722

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 723

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 724

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 725

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 726

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 727

1. To check TCM identification, see «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) . To remove TCM, see «REMOVING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__removing) .

Scheme 728

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Note. For DTC 18258 / P1850: The transfer of data and information between the Transmission Control Module (TCM) and the control modules that communicate with the Transmission Control Module (TCM) occurs via a so-called CAN bus. All information signals are carried via 2 wires Function of CAN bus, see CAN-BUS, FUNCTION

Scheme 729

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To check ABS control module identification, see «ON BOARD DIAGNOSTIC (OBD)»(/audi/a6/c5-1997-2001/remont/anti-locktraction-control/#brake-system-on-board-diagnostic-obd-abs-esp) .
4. To check TCM identification, see «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) . To remove TCM, see «REMOVING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__removing) .

Note. Notes and footnotes for DTC 18259 / P1851 can be found on the next page.

Note. For DTC 18259 / P1851 (CAN-Bus): The transfer of data and information between the Transmission Control Module (TCM) and the control modules that communicate with the Transmission Control Module (TCM) occurs via a so-called CAN bus. All information signals are carried via 2 wires. Function of CAN bus, see CAN-BUS, FUNCTION .

Scheme 730

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To check ABS control module identification, see «ON BOARD DIAGNOSTIC (OBD)»(/audi/a6/c5-1997-2001/remont/anti-locktraction-control/#brake-system-on-board-diagnostic-obd-abs-esp) .
4. To check TCM identification, see «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) . To remove TCM, see «REMOVING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__removing) .

Note. Notes and footnotes for DTC 18262 / P1854 can be found on the next page.

Note. For DTC 18262 / P1854: The transfer of data and information between the Transmission Control Module (TCM) and the control modules that communicate with the Transmission Control Module (TCM) occurs via a so-called CAN bus. All information signals are carried via 2 wires Function of CAN bus, see CAN-BUS, FUNCTION .

Scheme 731

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
3. To check TCM identification, see «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) . To remove TCM, see «REMOVING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__removing) .

Note. For DTC 18263 / P1855 (CAN-Bus): The transfer of data and information between the Transmission Control Module (TCM) and the control modules that communicate with the Transmission Control Module (TCM) occurs via a so-called CAN bus. All information signals are carried via 2 wires Function of CAN bus, see CAN-BUS, FUNCTION .

Scheme 732

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. To check TCM identification, see «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) . To remove TCM, see «REMOVING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__removing) .

Note. For DTC 18264 / P1856: The signal for throttle position sensor -G69- is transmitted by the engine control module via the CAN-BUS wires to transmission control module. Requirements for malfunction recognition: Malfunction of the relevant component is recognized by the Engine Control Module. This diagnostic is transmitted to the Transmission Control Module (TCM) via the CAN bus wiring.

Scheme 733

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. To check TCM identification, see «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) . To remove TCM, see «REMOVING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__removing) .

Note. Notes and footnotes for DTC 18265 / P1857 can be found on the next page.

Note. For DTC 18265 / P1857: Requirements for malfunction recognition: Malfunction of the relevant component is recognized by the Engine Control Module. This diagnostic is transmitted to the Transmission Control Module (TCM) via the CAN bus wiring. Requirement for malfunction recognition: No malfunction of the engine RPM and throttle valve signal was recognized, and no load signal was recognized for 245 ms. If a malfunction of the load signal is recognized by the engine control module, this malfunction is communicated to the transmission control module via a transmittal of a duty cycle.

Scheme 734

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. To check TCM identification, see «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) . To remove TCM, see «REMOVING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__removing) .

Note. For DTC 18266 / P0727 for vehicle models with CAN-Bus: The engine speed signal is transmitted by the Engine Control Module (ECM) to the Transmission Control Module (TCM) via the CAN bus wiring. Requirements for malfunction recognition: Malfunction of the relevant component is recognized by the Engine Control Module. This diagnostic is transmitted to the Transmission Control Module (TCM) via the CAN bus wiring.

Scheme 735

Scheme 736

1. To replace TCM, see «REMOVING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__removing) .

Note. For DTC 65535: Only after determining the possible malfunction cause and repairing the following malfunctions: mechanical malfunction hydraulic malfunction electrical/electronic components as well as wire connections

Output Diagnostic Test Mode (DTM) (scan tool function 03)

Note. A differentiation is made between two types of transmissions: Transmission with hydraulic regulation -E17-, on which the transmission input speed sensor (inductive sensor) is secured to the underside of the valve body. Transmission with hydraulic regulation -E18/2-, on which the transmission input speed sensor (camshaft position sensor) is secured behind valve body at transmission housing.

For information on which transmission is installed, refer to

See CODE LETTERS, ENGINE/TRANSMISSION APPLICATIONS, RATIOS, EQUIPMENT .

Output Diagnostic Test Mode (DTM) for transmission with hydraulic regulation E17: See OUTPUT DIAGNOSTIC TEST MODE (DTM) (SCAN TOOL FUNCTION 03), TRANSMISSIONS WITH HYDRAULIC REGULATION -E17 .

Output Diagnostic Test Mode (DTM) for transmission with hydraulic regulation E18/2: See OUTPUT DIAGNOSTIC TEST MODE (DTM) (SCAN TOOL FUNCTION 03), TRANSMISSIONS WITH HYDRAULIC REGULATION -E18/2 .

Output Diagnostic Test Mode (DTM) (scan tool function 03), transmissions with hydraulic regulation -E17

Note. The Output Diagnostic Test Mode will be terminated if the engine is started. The Output Diagnostic Test Mode can only be performed when the selector lever is in position "P", the engine is not running and the vehicle is stationary. The function of the solenoid valves1 -N88-, 2- N89-, 3-N90- and the solenoids for the selector lever lock are checked acoustically during the Output Diagnostic Test Mode. Avoid noise in the surrounding area during the acoustic check, because the switching noise (clicking) of the actuators is very quiet. The solenoid valves 4 -N91-, 5 -N92-, 6 -N93- and 7-N94- are activated during the Output Diagnostic Test Mode. A direct functional check of these valves is not possible. But possible electrical faults which occur during the activation, will be recognized by the On Board Diagnostic (OBD) and stored in the DTC memory.

Note. When performing the Output Diagnostic Test Mode the individual actuators will be activated until the --> button is pressed. Only one complete Output Diagnostic Test Mode is possible after switching the ignition on. To repeat the Output Diagnostic Test Mode the ignition must be switched off and on again.

DIAGNOSTIC TEST MODE - TRANSMISSIONS WITH HYDRAULIC REGULATION -E17

Test sequence

1. Connect VAS5051 tester or VAG1551 scan tool and enter address word 02 for "Control module for Transmission electronics". See «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) .

Ignition must be switched off during this process.

Indicated on display

Scheme 737

1. Press keys 0 and 3. (03 selects the function "Output Diagnostic Test Mode(".

Indicated on display

Scheme 738

1. Confirm entry with key Q.

Indicated on display

Scheme 739

1. Valve is activated (clicks), to switch to the next actuator press --> key.
2. If the valve does not click, perform electrical check. See «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

1. Malfunction is stored in DTC memory. See «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Indicated on display

Scheme 740

1. Valve is activated (clicks), to switch to the next actuator press --> key.
2. If the valve does not click, perform electrical check. See «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Indicated on display

Scheme 741

1. Valve is activated (clicks), to switch to the next actuator press --> key.
2. If the valve does not click, perform electrical check. See «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Malfunction is stored in DTC memory. See DIAGNOSTIC TROUBLE CODE (DTC) TABLE .

Indicated on display

Scheme 742

1. Solenoid is activated (clicks), to switch to the next actuator press --> key.
2. If solenoid does not click, perform electrical check. See «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

1. Malfunction is stored in DTC memory. See «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Indicated on display

Scheme 743

1. Valve is activated (clicks), to switch to the next actuator press --> key.

Eventually electrical malfunctions will be stored in DTC memory of the On Board Diagnostic (OBD), DTC table. See DIAGNOSTIC TROUBLE CODE (DTC) TABLE .

Indicated on display

Scheme 744

1. Valve is activated (clicks), to switch to the next actuator press --> key.

Eventually electrical malfunctions will be stored in DTC memory of the On Board Diagnostic (OBD), DTC table. See DIAGNOSTIC TROUBLE CODE (DTC) TABLE .

Indicated on display

Scheme 745

1. Valve is activated (clicks), to switch to the next actuator press --> key.

1. Eventually electrical malfunctions will be stored in DTC memory of the On Board Diagnostic (OBD), DTC table. See «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Indicated on display

Scheme 746

1. Valve is activated (clicks), to switch to the next actuator press --> key.

Eventually electrical malfunctions will be stored in DTC memory of the On Board Diagnostic (OBD), DTC table. See DIAGNOSTIC TROUBLE CODE (DTC) TABLE .

Indicated on display

Note. It is not the kick-down switch -F8-, but the switch-off function for the air conditioner in transmission control module -J217- which is activated. If the kick-down switch is operated, the transmission control module Grounds the output to air conditioner. This briefly switches off the air conditioner compressor. Can be disregarded here. The signal can be checked in measured value block 011. See READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08) . For checking function of the kick-down switch -F8-, see ELECTRICAL TESTING .

1. Press --> key to switch to the next actuator.

Indicated on display

Scheme 747

1. Solenoid valves activated in position "P" are activated (click), press --> key to switch to the next actuator. Can be disregarded.
2. Press --> key.

Indicated on display

Scheme 748

1. Press --> key

Indicated on display

Scheme 749

1. Pressing the --> key will terminate the Output Diagnostic Test Mode.

Indicated on display

Scheme 750

1. To repeat the Output Diagnostic Test Mode the ignition must be switched off and then on again, then again select the function 03 -Output Diagnostic Test Mode.

Output Diagnostic Test Mode (DTM) (scan tool function 03), transmissions with hydraulic regulation -E18/2

Note. The Output Diagnostic Test Mode will be terminated if the engine is started. The Output Diagnostic Test Mode can only be performed when the selector lever is in position "P", the engine is not running and the vehicle is stationary. The function of the solenoid valves1 -N88-, 2 -N89-, 3-N90- and the solenoids for the selector lever lock are checked acoustically during the Output Diagnostic Test Mode. Avoid noise in the surrounding area during the acoustic check, because the switching noise (clicking) of the final controls is very quiet. The pressure control valves1 -N215-, 2 -N216-, 3 -N217- and 4 -N218- are activated during the Output Diagnostic Test Mode. A direct functional check of these valves is not possible. But possible electrical faults which occur during the activation, will be recognized by the On Board Diagnostic (OBD) and stored in the DTC memory.

Note. When performing the Output Diagnostic Test Mode the individual actuators will be activated until the --> button is pressed. Only one complete Output Diagnostic Test Mode is possible after switching the ignition on. To repeat the Output Diagnostic Test Mode the ignition must be switched off and on again.

DIAGNOSTIC TEST MODE - TRANSMISSIONS WITH HYDRAULIC REGULATION -E18/2

1. Connect VAS5051 tester or VAG1551 scan tool and enter address word 02 for "Control module for Transmission electronics". See «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) .

Ignition must be switched off during this process.

Indicated on display

Scheme 751

1. Press keys 0 and 3 (03 selects the function "Output Diagnostic Test Mode").

Indicated on display

Scheme 752

1. Confirm entry with key Q.

Indicated on display

Scheme 753

1. Valve is activated (clicks), to switch to the next actuator press --> key.
2. If the valve does not click, perform electrical check. See «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

1. Malfunction is stored in DTC memory, DTC table. See «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Indicated on display

Scheme 754

1. Valve is activated (clicks), to switch to the next actuator press --> key.
2. If the valve does not click, perform electrical check. See «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

1. Malfunction is stored in DTC memory, DTC table. See «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Indicated on display

Scheme 755

1. Valve is activated (clicks), to switch to the next actuator press --> key.
2. If the valve does not click, perform electrical check. See «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

1. Malfunction is stored in DTC memory, DTC table. See «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Indicated on display

Scheme 756

1. Solenoid is activated (clicks), to switch to the next actuator press --> key.
2. If solenoid does not click, perform electrical check. See «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

1. Malfunction is stored in DTC memory, DTC table. See «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Indicated on display

Scheme 757

1. Pressure control valve -N215- is activated (clicks), to switch to the next actuator press --> key.

1. Eventually electrical malfunctions will be stored in DTC memory of the On Board Diagnostic (OBD), DTC table. See «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Indicated on display

Scheme 758

1. Pressure control valve -N216- is activated (clicks), to switch to the next actuator press --> key.

1. Eventually electrical malfunctions will be stored in DTC memory of the On Board Diagnostic (OBD), DTC table. See «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Indicated on display

Scheme 759

1. Pressure control valve -N217- is activated (clicks), to switch to the next actuator press --> key.

1. Eventually electrical malfunctions will be stored in DTC memory of the On Board Diagnostic (OBD), DTC table. See «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Indicated on display

Scheme 760

1. Pressure control valve -N218- is activated (clicks), to switch to the next actuator press --> key.

1. Eventually electrical malfunctions will be stored in DTC memory of the On Board Diagnostic (OBD), DTC table. See «DIAGNOSTIC TROUBLE CODE (DTC) TABLE»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Note. "Pressure control valve -5- for automatic transmission -N233-" could now be displayed erroneously due to a software error, even though it does not exist. This display can be disregarded. Press --> button to switch over to the next actuator.

Scheme 761

Indicated on display

Scheme 762

Solenoid valves activated in position "P" are activated (click), press --> key to switch to the next actuator.

1. Can be disregarded.

1. Prss --> key.

Indicated on display

Scheme 763

1. Pressing the --> key will terminate the Output Diagnostic Test Mode.

Indicated on display

Scheme 764

1. To repeat the Output Diagnostic Test Mode the ignition must be switched off and then on again, then again select the function 03 -Output Diagnostic Test Mode.

Requirement

1. DTC memory checked. See «CHECK DTC MEMORY»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

After DTC memory has been checked

Indicated on display

Scheme 765

1. Press keys 0 and 5. (The function "Erase DTC memory" is entered with 05.)

Indicated on display

Scheme 766

1. Confirm entry with key Q.

Indicated on display

Scheme 767

Note. If the ignition was switched off, for example, between checking the DTC memory and erasing DTC memory, the DTC memory is then not erased.

1. Exactly adhere to work sequence. The DTC memory must first be checked.

Indicated on display

Scheme 768

The DTC memory will be erased approx. 5 seconds. after the display appears.

The DTC memory is now erased.

Note. Wait about 1 minute before again checking the DTC memory.

Indicated on display

Scheme 769

Print out with printer switched on

Scheme 770

Control module -J217- was not given sufficient time to recognize faults.

1. Wait about 1 minute before again checking the DTC memory.
2. After checking and erasing the DTC memory, carry out a test drive and again check the DTC memory.

When the DTC memory is checked, the following display should appear

"No DTC recognized!"

Code Control Module (scan tool function 07)

The Transmission Control Module (TCM) can be coded.

Procedure

1. Connect VAS5051 tester or VAG1551 scan tool and select Transmission Control Module (TCM) using "address word" 02. See «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool) .

Ignition must remain switched on for this.

Indicated on display

Scheme 771

Print out control module identification

1. Switch on printer by pressing the print button (indicator lamp in button lights up).
2. Press buttons -0- and -1-.
3. Press -Q- button to confirm input.

Indicated on display

Scheme 772

Control module identification is displayed

Depending on the control module version (software version), control module may indicate a different identification than shown in this example. Allocation of the control module

See Parts catalog.

Clarification of display

1. 4B0927156BT: Part number
2. AG5 01V: Automatic Transmission, 5-speed 01V
3. 2,8l 5V: Engine type
4. USA: Market, USA and Canada
5. 1416: 14 = software version, 16 = data version
6. Coding 00002: Coding (see «CODING TABLES»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) )
7. WSC 00000: Factory identification of VAG1551, with which the last coding was performed

1. Press --> button.

Transmission control module identification can only be printed out when printer is switched on.

Indicated on display

Scheme 773

Note. Read Transmission Control Module (TCM) identification to determine which transmission/engine combination is present in this particular case, see clarification above. Then use coding table to determine whether the appropriate code is entered.

1. Press buttons -0- and -7-. This selects "Coding Control Module", function 07.

Note. Coding can only be performed with ignition on and selector lever in position "P" or "N". Accelerator pedal must be in idle position. Vehicle must be stationary and engine must not be started.

Indicated on display

Scheme 774

1. Press -Q- button to confirm input.

Indicated on display

Scheme 775

1. Enter code

Note. Use control module identification to retrieve appropriate code from CODING TABLES . Enter it into tester. The Dynamic Shifting Program (DSP) should remain on at all times if possible.

1. Press -Q- button to confirm input.

Note. DTC memory in the control module is automatically erased following coding.

1. Press --> button.

Indicated on display

Scheme 776

1. Check control module version (press buttons -0- and -1-), confirm input with Q button and check coding. See «ON BOARD DIAGNOSTIC (OBD), INITIATING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__output-diagnostic-test-mode-dtm-scan) .

When indicated on display: An attempt was made to enter a coding that is not valid or unrecognized by the control module.

Scheme 777

Note. If an incorrect coding is entered, the control module will retain the old coding.

Indicated on display

Scheme 778

Note. A control module identification that has been incorrectly entered is only indicated alongside the old coding for older VAG1551 tester cards.

When indicated on display

Scheme 779

An attempt was made to perform coding in an unauthorized coding condition, for example, with vehicle in a driving mode.

Scheme 780

1. To determine if engine/transmission combination is equipped with E-Gas, see «CODE LETTERS, ENGINE/TRANSMISSION APPLICATIONS, RATIOS, EQUIPMENT»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01v) .

Scheme 781

1. To determine if engine/transmission combination is equipped with E-Gas, see «CODE LETTERS, ENGINE/TRANSMISSION APPLICATIONS, RATIOS, EQUIPMENT»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01v) .

Read Measuring Value Block (scan tool function 08)

Note. There is a distinction made between two types of transmission. Transmissions with hydraulic control E17, the sensor for transmission RPM (inductive sensor) is secured to bottom of valve body. Transmissions with hydraulic control E18/2, the sensor for transmission RPM (hall effect sensor) is secured to transmission housing behind valve body.

Information regarding which transmission is installed can be found in CODE LETTERS, ENGINE/TRANSMISSION APPLICATIONS, RATIOS, EQUIPMENT

Read measuring value block for transmission with hydraulic control E17: See READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08) FOR TRANSMISSIONS WITH HYDRAULIC CONTROL E17 .

Read measuring value block for transmission with hydraulic control E18/2: . See READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08) FOR TRANSMISSIONS WITH HYDRAULIC CONTROL E18/2 .

Read Measuring Value Block (scan tool function 08) for transmissions with hydraulic control E17

Note. For transmissions with hydraulic control E18/2, see READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08) FOR TRANSMISSIONS WITH HYDRAULIC CONTROL E18/2 .

Procedure

1. Connect VAS5051 tester or VAG1551 scan tool and select Transmission Control Module (TCM) using "address word" 02. See «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) . Ignition must remain switched on for this.

Indicated on display

Scheme 782

1. Press PRINT button to turn on Scan Tool (ST) printer. Indicator lamp in button must light up.
2. Press buttons -0- and -8- to select "Read Measuring Value Block" and press -Q- button to confirm input.

When indicated on display

Scheme 783

1. Enter desired display group number. (Scheme 789)
2. Confirm input using the -Q- button.

Indicated on display (example) for display group 001

Scheme 784

Note. Clarification of values in the individual display fields, see TEST TABLE FOR TRANSMISSIONS WITH HYDRAULIC CONTROL E17 Display can be printed out on the paper roll when printer is switched on. To switch to a different display group, proceed (Scheme 787)

1. If specified values are obtained in all display fields, press --> button.

Indicated on display (function selection)

Scheme 785

Scheme 786

Scheme 787

Scheme 788

Scheme 789

Note. When the printer is switched on, the contents of the display will be printed out on the scan tool log. If specified values are not obtained in all display fields

1. Press --> button.

Indicated on display

Scheme 790

Scheme 791

1. For electrical test, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v).
2. To check TCM identification, see «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__vas5051-tester-or-vag1551-scan-tool).
3. For DTC 17100/P0716 (Scheme 679)

Scheme 792

1. For electrical test, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 793

1. For electrical test, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Notes for display group number 001, display field 1 to 3

1. Test conditions: Shifting process must be finished. Vehicle must not be in deceleration mode (no decline driving or engine brake).

Scheme 794

Note. Display Group 001, Display Field 4: On gear selected

1. Faulty solenoid valves or other diagnostic malfunctions can prevent the selection of certain gears.

Scheme 795

Scheme 796

1. For electrical test, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 797

1. For electrical test, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 798

1. For electrical test, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v).
2. For DTC 00532 (Scheme 653)

Note. For ATF temperature: an indicated temperature of minus 50°C indicates a short circuit to Ground (GND) an indicated temperature of minus 180°C indicates a short circuit to B+ or an open circuit

Scheme 799

1. For electrical test, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
2. To adjust selector lever cable, see «SELECTOR LEVER CABLE»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Scheme 800

1. For electrical test, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
2. To adjust selector lever cable, see «SELECTOR LEVER CABLE»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Note. For display field 3 of display group number 004: The input signals of the Multi-function Transmission Range (TR) switch -F125- 1) can be checked at the Transmission Control Module (TCM).

Scheme 801

Scheme 802

1. For electrical test, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
2. To replace TCM, see «REMOVING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__removing) .

Note. For display field 4 of display group number 004: This display field 4 is only valid for vehicles WITHOUT CAN bus (Scheme 806)for vehicles with CAN bus. A) Engine intervention is only activated during the shifting process. Depending on the driving situation, engine intervention may only be activated briefly, i.e. the relatively slow data transfer to the VAG1551 can miss this brief engine intervention under certain driving conditions.

There is a distinction made between vehicles with and without CAN bus. For information on which vehicles are equipped with CAN bus, see system wiring diagrams.

Scheme 803

Note. For display field 4 of display group number 004: This display field 4 is only valid for vehicles with CAN bus, refer to previous display field 4 for vehicles without CAN bus.

There is a distinction made between vehicles with and without CAN bus. For information on which vehicles are equipped with CAN bus, see system wiring diagrams.

Scheme 804

1. For electrical test, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 805

1. For electrical test, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Note. For display group number 5, display field 1 to 3; Un-switched solenoid valves are indicated with "0", switched solenoid valves are indicated with "1". Variable switching solenoid valves are indicated with "X".

Scheme 806

1. For electrical test, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 807

1. For electrical test, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Note. For specified current of solenoid valves: Faulty solenoid valves or clutches or other malfunctions can prevent shifting into certain gears.

Scheme 808

1. For electrical test, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 809

1. For transmission shift elements, see «SHIFT ELEMENT POSITIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01v) .

Note. Notes for display field 4 of display group number 004 are on the next page

Note. Test requirements for torque converter slip speeds: "TC closed": Shifting process must be complete (wait at least 1 sec.), the Torque Converter (TC) must be closed and the accelerator pedal value must be constant. "TC control": Indicated values are valid for the regulating condition of the throttle converter (control). Under inconvenient conditions (e.g. accelerating on a hill), this condition is not reached until 20 seconds after the shifting process has been completed. During this regulating phase, slip values of up to 350 RPM can be reached. Excessive torque slip speeds can also indicate slipping clutches or non-activated shifting elements.

Scheme 810

1. For electrical test, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 811

1. For electrical test, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 812

Scheme 813

Note. For display group number 009; This display group number 009 is only valid for vehicles with CAN bus, refer to display group number 009 on next page for vehicles without CAN bus.

There is a distinction made between vehicles with and without CAN bus.

Scheme 814

1. For electrical test, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Note. For display group number 009: This display group number 009 is only valid for vehicles without CAN bus, refer to previous display group number 009 for vehicles with CAN bus. A) For vehicles with motronic injection and ignition systems, engine torque is transmitted by the Engine Control Module (ECM). For these vehicles, the fuel consumption display is omitted or always indicates "00ms".

A) There is a distinction made between vehicles with and without CAN bus.

Scheme 815

1. For electrical test, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 816

1. For electrical test, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Read Measuring Value Block (scan tool function 08) for transmissions with hydraulic control E18/2

Note. For transmissions with hydraulic control E17, see READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08) FOR TRANSMISSIONS WITH HYDRAULIC CONTROL E17 .

Procedure

1. Connect VAS5051 tester or VAG1551 scan tool and select Transmission Control Module (TCM) using "address word" 02. See «VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Ignition must remain switched on for this.

Indicated on display

Scheme 817

1. Press PRINT button to turn on Scan Tool (ST) printer. Indicator lamp in button must light up.
2. Press buttons -0- and -8- to select "Read Measuring Value Block" and press -Q- button to confirm input.

When indicated on display

Scheme 818

1. Enter desired display group number. See «OVERVIEW OF SELECTABLE DISPLAY GROUP NUMBERS FOR TRANSMISSION WITH HYDRAULIC CONTROL E18/2»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
2. Confirm input using the -Q- button.

Indicated on display (example) for display group 001

Scheme 819

Note. Explanation of values in individual display fields, see TEST TABLE FOR TRANSMISSIONS WITH HYDRAULIC CONTROL E18/2 . Display can be printed out on the paper roll when printer is switched on. To switch to a different display group, proceed as follows

CHANGING SCAN TOOL DISPLAY GROUP

1. If specified values are obtained in all display fields, press --> button.

Indicated on display (function selection)

Scheme 820

Scheme 821

Scheme 822

Scheme 823

Note. When the printer is switched on, the contents of the display will be printed out on the scan tool log. If specified values are not obtained in all display fields

1. Press --> button.

Indicated on display

Scheme 824

Scheme 825

Scheme 826

Note. For display group number 001, display field 1 to 3: Test conditions: Shifting process must be finished. Vehicle must not be in deceleration mode (no decline driving or engine brake).

Scheme 827

Note. For display field 4 of display group number 001: Faulty solenoid valves or other diagnostic malfunctions can prevent the selection of certain gears.

Scheme 828

Scheme 829

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 830

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 831

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Note. For display field 3, speed: Display of the speedometer and values at VAS 5051 or VAG 1551 may deviate slightly from each other.

Scheme 832

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Note. For ATF temperature: an indicated temperature of minus 50°C indicates a short circuit to Ground (GND), an indicated temperature of minus 180°C indicates a short circuit to B+ or an open circuit

Scheme 833

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
2. To adjust selector lever cable, see «SELECTOR LEVER CABLE»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Scheme 834

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
2. To adjust selector lever cable, see «SELECTOR LEVER CABLE»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Note. For in-between positions: When the selector lever is shifted into one of the in-between positions indicated, the Scan Tool (ST) indicates "Z1", "Z2", "Z3" or "Z4". Display in instrument cluster must not indicate a gear selected, i.e. PRND432 is indicated without any particular gear highlighted.

Scheme 835

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
2. To adjust selector lever cable, see «SELECTOR LEVER CABLE»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Note. For display field 3 of display group number 004: The input signals of the Multi-function Transmission Range (TR) switch -F125- can be checked at the Transmission Control Module (TCM).

Scheme 836

Scheme 837

Scheme 838

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Notes for display group number 5, display field 1 to 3

1. Unswitched solenoid valves (inactive) are indicated with "0", switched solenoid valves (active) are indicated with "1".

Scheme 839

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Note. For display group number 5, display field 1 to 3: Unswitched solenoid valves (inactive) are indicated with "0", switched solenoid valves (active) are indicated with "1".

Scheme 840

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 841

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Note. For specified current of solenoid valves: Faulty solenoid valves or pressure control valves or clutches or other malfunctions can prevent shifting into a specific gear.

Scheme 842

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 843

1. To check ATF level, see «CHECKING FLUID LEVELS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v__checking-fluid-levels) .
2. To check transmission shift elements, see «SHIFT ELEMENT POSITIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01v) .

Note. Test requirements for torque converter slip speeds: "TC closed": Shifting process must be complete (wait at least 1 sec.), the Torque Converter (TC) must be closed and the accelerator pedal value must be constant. "TC control": Indicated values are valid for the "regulating condition" of the throttle converter (control). Under inconvenient conditions (for example, accelerating on a hill), this condition is not reached until 20 seconds after the shifting process has been completed. During this regulating phase, slip values of up to 350 RPM can be reached. Excessive torque slip speeds can also indicate slipping clutches or non-activated shifting elements.

Scheme 844

1. To check kickdown switch, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Note. For display field 1: The signal for actual engine torque is transmitted by the Engine Control Module (ECM) to the Transmission Control Module (TCM) via the CAN bus wiring.

Scheme 845

Scheme 846

Scheme 847

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 848

Scheme 849

Note. For display group number 013: Display field 2 and 4: When replacing the Engine Control Module (ECM), the same indication that appeared for the old control module should appear after installation. If this is not the case, the wrong Engine Control Module (ECM) is installed, or it is incorrectly coded.

Scheme 850

1. For electrical testing, see «ELECTRICAL TESTING»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Bus

The term bus refers to a system that transports and distributes data.

CAN

The Controller Area Network is a bus system that uses two wires. These are called bus wires. Data is transferred to the connected control modules serially (one after the other) across the bus wires.

These control modules communicate with each other via the CAN-bus.

Overview of power train data-BUS

Note. The following list refers to items in (Scheme 855).

1. Transmission Control Module -J217
2. Driver for BUS
3. Motronic Engine Control Module (ECM) -J220
4. Driver for BUS
5. Termination resistance
6. Power train data-BUS (CAN bus, twisted 2 line wire)
7. Termination resistance
8. Driver for BUS
9. ABS control module -J104

Scheme 851

Two-wire bus system, checking

The DTC table indicated you needed to check the bus

1. Using the relevant wiring diagram, determine how many control modules communicate with each other via the bus.
2. Press the -0- button twice to select the function "Automatic test sequence".
3. Before checking the bus wires, make sure that none of the control modules connected are malfunctioning.

A malfunction will disrupt communication to other control modules.

Is there is a malfunction?

1. Fix the malfunction before proceeding.
2. Note malfunction and erase DTC memory of all control modules.
3. Press buttons -0- and -6- to select "End Output" function 06. Press -Q- button to confirm input.
4. End output of Scan tool by selecting the function "end output". See «LIST OF SELECTABLE FUNCTIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__list-of-selectable-functions) .
5. Refer to the DTC table in the relevant repair manual for help in fixing the malfunction. You have fixed all malfunctions
6. Check bus wires if communication to the control modules is still faulty.

While checking the bus wires, make a distinction between the following two situations

1. Two control modules communicate via a "two-line bus system"
2. Three or more control modules communicate via a "two-line bus system"

Two control modules communicate via a "two-line bus system"

1. Switch ignition off.
2. Disconnect both control modules.
3. Check the bus wires for an open circuit.

Scheme 852

1. Check whether there is a short circuit between the bus wires.

Scheme 853

1. Check the bus wires for a short circuit to B+ or Ground (GND).

If no malfunctions could be found in the bus wires

1. As a test, replace one of the control modules. Select a control module that will take the least amount of time, and cost the least amount of money to replace.
2. If communication between the control modules across the bus is still interrupted, replace the second control module.

Scheme 854

Three or more control modules are communicating across a "two-line bus system"

1. Analyze the DTCs stored in the memories of the control modules.

Example 1

From the DTCs stored in the memories, you have determined that control module 1 is not communicating with control modules 2 and 3.

Scheme 855

Scheme 856

1. Switch ignition off.
2. Disconnect the control modules connected across the bus wires and check the bus wires for an open circuit.

1. Replace control module 1 if no malfunctions can be found in the bus wires.

Example 2

From the DTCs stored in the memories, you have determined that control module 2 is not communicating with control modules 1 and 3.

Scheme 857

Scheme 858

1. Switch ignition off.
2. Disconnect the control modules connected across the bus wires and check the bus wires for an open circuit.

1. Replace control module 2 if no malfunctions can be found in the bus wires.

Example 3

Using the DTCs stored in the memories, you have determined that none of the control modules are sending or receiving signals.

DTC MEMORIES - NONE OF THE CONTROL MODULES ARE SENDING OR RECEIVING SIGNALS

1. Switch ignition off.
2. Disconnect the control modules connected across the bus wires and check for a short circuit between the bus wires.

Scheme 859

1. Check the bus wires for short circuit to B+ or Ground (GND).

Scheme 860

1. If no malfunctions could be found in the bus wires: Check whether one of the control modules is responsible for a short circuit of the bus wires to each other, to B+ or to Ground (GND).

Disconnect each of the control modules connected via the bus wires one at a time and check whether the malfunction "Hardware faulty" is eliminated.

If it is eliminated, replace the control module that is currently disconnected. If it is not eliminated, re-connect that control module and disconnect the next control module connected via the bus wires.

Prepare the following special tools and test equipment

1. VAG1526A multimeter
2. VAG1598/20 test box
3. VAG1594A connector test kit

Scheme 861

1. «OVERHAUL - 01V»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01v)
2. Electrical Wiring Diagrams

Note. Use VAG1526A multimeter for the test. The tables list which measuring range to select before taking each measurement. The specified values are valid for an ambient temperature range of 0-40°C (32-104°F). If the values obtained differ from the specified values, determine the malfunction using the applicable wiring diagram. If the measured values only deviate slightly from the specified values clean sockets and connectors of testers and repeat test. Before replacing a component, test the wires and connections Especially if the specified values are below 10 ohms, repeat the resistance measurement on the component. Use VAG1598/20 adapter to connect test equipment. The contact numbers of the connector and the socket numbers of VAG 1598/20 test box match up. (Scheme 867)

Test requirements

1. Battery voltage OK
2. Fuses for Transmission Control Module (TCM) OK

1. Fuses for component being tested OK

The fuse holder is behind a cover on the side of the instrument cluster.

1. Ground (GND) connections OK

Check battery Ground (GND) strap and Ground (GND) strap between chassis and transmission.

Check Ground (GND) connections for Transmission Control Module (TCM).

Scheme 862

1. For all test steps, switch ignition off, disconnect multi-pin connector for Transmission Control Module (TCM) -J217- (located in front of passenger seat under carpet in foot well). See «AUTOMATIC TRANSMISSION CONTROL MODULE -J217»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) . Connect VAG1598/20 adapter to wiring harness connector.
2. If measuring values do not match specifications, follow instructions in right-hand column of test table.
3. Always perform all steps indicated in "Corrective action" column.
4. Only perform test steps recommended in DTC table (selective troubleshooting).

Scheme 863

Scheme 864

1. For read measuring value block, see «READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__read-measuring-value-block-scan-tool) .
2. Further information for CAN-BUS, see «CAN-BUS, FUNCTION»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

List of test steps (88-pin connector)

1. Only perform test steps for the relevant component, as listed in DTC and Read Measuring Value Block tables.

Scheme 865

Scheme 866

Scheme 867

1. To replace brake light switch, see «ABS/ESP SYSTEM COMPONENTS, REMOVING AND INSTALLING»(/audi/a6/c5-1997-2001/remont/anti-locktraction-control/#brake-system-abs) .

Scheme 868

1. To replace accelerator cable, see «ACCELERATOR PEDAL (AP) CABLE, SERVICING - VEHICLES WITH MECHANICAL ACCELERATOR MECHANISM»(/audi/a6/c5-1997-2001/remont/fuel-system/#fuel-supply-system-all-engines) .

Scheme 869

1. To check wiring between TCM and 8-pin connector, see «TESTING WIRING TO MULTI-FUNCTION TR SWITCH (8-PIN CONNECTOR)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 870

1. To check wiring between TCM and 8-pin connector, see «TESTING WIRING TO MULTI-FUNCTION TR SWITCH (8-PIN CONNECTOR)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 871

1. To check wiring between TCM and 16-pin connector, see «TESTING WIRING TO 16-PIN CONNECTOR ON TRANSMISSION»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v__testing-wiring-to-16-pin-connector-on) .

Scheme 872

1. To check wiring between TCM and 8-pin connector, see «TESTING WIRING TO MULTI-FUNCTION TR SWITCH (8-PIN CONNECTOR)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 873

1. To check wiring between TCM and 8-pin connector, see «TESTING WIRING TO MULTI-FUNCTION TR SWITCH (8-PIN CONNECTOR)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
2. To remove and install valve body, see «VALVE BODY ASSEMBLY»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Scheme 874

1. To replace shift lock solenoid, see «SERVICING - A/T (01V)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .
2. To replace accelerator cable, see «ACCELERATOR PEDAL (AP) CABLE, SERVICING - VEHICLES WITH MECHANICAL ACCELERATOR MECHANISM»(/audi/a6/c5-1997-2001/remont/fuel-system/#fuel-supply-system-all-engines) .

Scheme 875

1. To replace transmission VSS G38, see «TRANSAXLE VEHICLE SPEED SENSOR»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Scheme 876

1. To replace transmission RPM sensor G182, see «TRANSAXLE RPM SENSOR»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v__transaxle-rpm-sensor) .
2. To identifying transmissions equipped with E17 hydraulic control, see «CODE LETTERS, ENGINE/TRANSMISSION APPLICATION»(/audi/a6/c5-1997-2001/remont/automatic-trans/#overhaul-01v) .

Scheme 877

1. To check wiring between TCM and 8-pin connector, see «TESTING WIRING TO MULTI-FUNCTION TR SWITCH (8-PIN CONNECTOR)»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .
2. To remove and install valve body, see «VALVE BODY ASSEMBLY»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Scheme 878

Scheme 879

Scheme 880

Scheme 881

Scheme 882

1. To remove and install multi-function transmission range switch, see «TRANSAXLE RANGE SWITCH»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v) .

Scheme 883

1. For terminal assignment of multi-function transmission range switch (Scheme 889)
2. To remove and install multi-function transmission range switch, see «TRANSAXLE RANGE SWITCH»(/audi/a6/c5-1997-2001/remont/automatic-trans/#servicing-at-01v).

Notes for test step 27

1. Pull off spring catch securing 8-pin connector -2- to connector on wire for multi-function TR switch.

Scheme 884

1. Terminal assignment on 8-pin connector for multi-function transmission range (TR) switch.

Scheme 885

Scheme 886

Scheme 887

Scheme 888

Scheme 889

1. For further information on CAN-bus, see «CAN-BUS, FUNCTION»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Perform if

1. if the output Diagnostic Test Mode (DTM) or
2. the electrical testing indicates malfunctions in the transmission, the Transmission Control Module (TCM) -J217- or in the corresponding wiring.

Test conditions

1. Ignition switched off
2. VAG1598/20 adapter connected only to 88-pin connector on transmission wiring harness
3. Measurements performed with VAG1598/20 adapter outside vehicle

1. Remove noise insulation panel.
2. Remove bracket -1- for noise insulation panel.

Scheme 890

Testing wiring to 16-pin connector on transmission

1. Turn 16-pin connector -4- on transmission to release bayonet catch.

Scheme 891

1. Use multimeter (Fluke 83 or equivalent) to test for continuity between terminals on 16-pin connector and sockets on VAG1598/20 adapter. See «RESISTANCE SPECIFICATIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 892

Scheme 893

Scheme 894

Note. If readings obtained in these tests match the specifications, check the wiring harness in the transmission. See VALVE BODY ASSEMBLY . Only replace relevant solenoid valves if no malfunctions are found in the wiring harness in the transmission. See VALVE BODY ASSEMBLY .

Scheme 895

1. Pull off spring catch securing 8-pin connector -2- to connector on wire for multi-function TR switch.
2. Use multimeter (Fluke 83 or equivalent) to test for open circuits between terminals on 8-pin connector and sockets on VAG1598/20 adapter. See «RESISTANCE SPECIFICATIONS»(/audi/a6/c5-1997-2001/remont/automatic-trans/#on-board-diagnostic-obd-5-spd-automatic-transmission-01v) .

Scheme 896

Scheme 897

Note. If the readings obtained in these wiring tests match the specifications, replace the multi-function Transmission Range (TR) switch -F125-. See TRANSAXLE RANGE SWITCH .

See also:
• SERVICING - A/T (01V)
• LIGHTS, SWITCHES-EXTERIOR - UP TO 2000
• ABS/ESP SYSTEM COMPONENTS, REMOVING AND INSTALLING
• TRIM PANELS (SEDAN)
• CODE LETTERS, ENGINE/TRANSMISSION APPLICATIONS, RATIOS, EQUIPMENT
• TRANSAXLE RPM SENSOR
• INSTRUMENTS - UP TO 2000
• ACCELERATOR PEDAL (AP) CABLE, SERVICING - VEHICLES WITH MECHANICAL ACCELERATOR MECHANISM
• ACCELERATOR PEDAL (AP), SERVICING - VEHICLES WITH ELECTRONIC POWER CONTROL (EPC) (DRIVE BY WIRE)
• CHECKING FLUID LEVELS
• CODE LETTERS, ENGINE/TRANSMISSION APPLICATION
• ON BOARD DIAGNOSTIC (OBD)
• LIST OF SELECTABLE FUNCTIONS
• CHECK DTC MEMORY
• ELECTRICAL/ELECTRONIC COMPONENTS AND LOCATIONS
• REMOVING
• INSTALLING
• ENGINE CONTROL MODULE
• Data Link Connector (DLC)
• WIRING HARNESS WITH INTEGRATED TRANSMISSION OIL TEMPERATURE SENDER (ATF) -G93
• VALVE BODY
• MULTI-FUNCTION SWITCH -F125
• TRANSMISSION SPEED SENDER -G38
• TIPTRONIC SWITCH -F189
• READ MEASURING VALUE BLOCK (SCAN TOOL FUNCTION 08)
• SELECTOR LEVER LOCK SOLENOID -N110
• THROTTLE VALVE POTENTIOMETER -G69
• STARTING INTERLOCK RELAY -J207
• TRANSMISSION RANGE SELECTOR LEVER DISPLAY -Y6
• KICK DOWN SWITCH -F8
• BRAKE LIGHT SWITCH -F
• VAS5051 TESTER OR VAG1551 SCAN TOOL, CONNECTING AND SELECTING FUNCTIONS
• SAFETY PRECAUTIONS
• CODE CONTROL MODULE (SCAN TOOL FUNCTION 07)
• OUTPUT DIAGNOSTIC TEST MODE (DTM) (SCAN TOOL FUNCTION 03)
• ON BOARD DIAGNOSTIC (OBD), FUNCTION
• CONDITIONS FOR RECOGNITION OF A DRIVING CYCLE (DCY)
• MALFUNCTION INDICATOR LAMP (MIL) FUNCTION, CHECKING
• SECURITY FUNCTIONS OF THE TRANSMISSION CONTROL MODULE (TCM)
• TESTING WIRING TO 16-PIN CONNECTOR ON TRANSMISSION
