Seats Frames - Cabriolet Audi A4 B6

Seats 8 illustrations ~4319 words

Tools

Special tools, equipment, test equipment and auxiliary items required

Airbag adapter VAS 6036

Scheme 52

Scheme 52: Tools
Scheme 52: Tools

Front seat, assembly overview

Note. Before disconnecting the battery: obtain the radio code.

The following list pertains to (Scheme 53).

  1. Front seat Removing: Remove front seat rail covers. See «FRONT SEAT RAIL COVER, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-rail-cover-assembly-overview) . Remove rear seat rail covers. See «REAR SEAT RAIL COVER, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__rear-seat-rail-cover-assembly-overview) Move front seat -1- up and back as far as possible. Unscrew front bolts -2- (2x). Move seat forward. Unscrew rear bolts -2- (2x). CAUTION: Before removal of seat: Detach battery ground (GND) strap. Tilt front seat -1- back. Detach connectors. See «CONNECTORS, DISCONNECTING»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__connectors-disconnecting) . Connect airbag adapter. See «VAS 6036 AIRBAG ADAPTER, CONNECTING»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__vas-6036-airbag-adapter-connecting) . Installing: Installation is in reverse order of removal.
  2. Bolts (4x) Tightening torque 40 Nm

Front seat with faulty forward and backward seat adjustment motor or defective control unit, removing and installing

Note. If possible: Move seat up. For greater clarity, the illustration shows the seat pan without padding or backrest.

The following list pertains to (Scheme 54).

Scheme 53

Scheme 53: Front seat with faulty forward and backward seat adjustment motor or defective control unit, removin
Scheme 53: Front seat with faulty forward and backward seat adjustment motor or defective control unit, removin

Scheme 54

Scheme 54
Scheme 54
  1. Bolts (4x) Tightening torque 17 Nm
  2. Motor mounting plate
  3. Bolts (2x) Tightening torque 19 Nm
  4. Upper seat pan support Removing: Unscrew bolts -3- (2x). Fold seat forward. Unscrew bolts -1- (4x). Detach backrest with top support of seat pan. For faulty control unit: Detach connector at forward and backward seat adjustment motor. Move the forward and backward seat adjustment motor with an external power source until the bolts are visible. Unscrew the bolts. Remove control unit. See «CONTROL UNIT, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__control-unit-removing-and-installing) . For faulty forward and backward seat adjustment motor: Detach connector -3-. Unscrew bolts -4- (2x) from forward and backward seat adjustment motor. Disengage forward and backward seat adjustment motor -2- from the two shafts -1- and -5-. Move both seat rails using a power screwdriver via the long shaft -5-, until the concealed bolts are visible. Unscrew the bolts. Replace the lower seat support with forward and backward seat adjustment motor.

Front seat rail cover, assembly overview

The following list pertains to (Scheme 56).

  1. Front seat
  2. Seat rail covers (2x) Removing: Move front seat -1- back as far as possible. Remove securing clips -3- (2x). Remove seat rail covers -2- (2x). Installing: Installation is in reverse order of removal.
  3. Securing clips (2x)

Rear seat rail cover, assembly overview

  1. Front seat
  2. Securing clips (4x)
  3. Seat rail covers (3x) Removing: Move front seat -1- forward as far as possible. Remove securing clips -2- (4x). Remove seat rail covers -3- (3x). Installing: Installation is in reverse order of removal.

Connectors, disconnecting

Note. The mechanic must electrostatically discharge him/herself before disconnecting ignition and ground (GND) wires (briefly touch closing wedge for door or body).

The following list pertains to (Scheme 58).

  1. Front seat
  2. Buckle interrogation connector (black)
  3. Seat heating connector (green)
  4. Power supply connector (red)
  5. Airbag connector (yellow)
  6. Connection point cover
  1. Removing: Tilt front seat -1- back. Remove connection point cover -6- upward. Press tab on airbag connector -5- inboard side and remove airbag connector -5-. Connect airbag adapter. See «VAS 6036 AIRBAG ADAPTER, CONNECTING»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__vas-6036-airbag-adapter-connecting) . Press tab on power supply connector -4- inboard side and remove power supply connector -4-. Press tab on seat heating connector -3- inboard side and remove seat heating connector -3-. For vehicles with buckle interrogation: Press in tab on buckle interrogation connector -2- inboard side and remove buckle interrogation connector -2-.

VAS 6036 Airbag adapter, connecting

Note. The mechanic must electrostatically discharge him/herself before disconnecting ignition and ground (GND) wires (briefly touch closing wedge for door or body).

CAUTIONThe airbag adapter VAS 5094 must remain connected to the seat until the seat is reinstalled.

The following list pertains to (Scheme 59).

  1. Seat connector power supply connector (red)
  2. Airbag adapter power supply connector (red)
  3. Airbag adapter connector (yellow)
  4. Airbag connector (yellow) Detach the ignition and ground (GND) wires. Connect the airbag connector -4- to the airbag adapter connector -3-. If present: Connect the airbag adapter power supply connector -2- to the seat connector power supply connector -1-.

Connector assignment for connection point

Note. Arrow points in direction of travel.

  1. 1 Side airbag
  2. 2 Power supply
  3. 3 Seat heating
  4. Buckle interrogation

Connector for side airbag, detaching

  1. Press retainer tab -3- of airbag connector -2- out of airbag adapter connector -1- and detach airbag connector -2-.

Note. After connecting the battery observe the necessary measures. See BATTERY DISCONNECT PRECAUTIONS . If airbag malfunction warning light -K75- signals a malfunction after assembly, the DTC memory must be interrogated with vehicle diagnostic, testing and information system VAS 5051, then erased and re-interrogated.

Scheme 55

Scheme 55
Scheme 55

Front seat backrest, assembly overview

WARNINGObserve relevant safety precautions for vehicles installed with side airbags. See appropriate Air Bag Restraint System article.

The following list pertains to see scheme 11.

  1. Backrest Removing: Remove seat. See «FRONT SEAT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-assembly-overview) . Remove side trim, outboard side. See «SIDE TRIMS (OUTBOARD SIDE), ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__side-trims-outboard-side-assembly-overview) . Remove side trim, inboard side. See «SIDE TRIM, INBOARD SIDE, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__side-trim-inboard-side-assembly-overview) .
  2. Wiring harness
  3. Bolts (4x) Tightening torque 20 Nm
  4. Plastic washer
  5. Bracket
  6. Bolt
  7. Bracket
  8. Seat pan

The following list pertains to see scheme 12.

  1. Cable tie (2x) Detach cable ties -1- (2x). Detach rubber straps -2- (2x). Detach connectors -5- (4x). Release cable tie -3- on wiring harness. Detach adhesive strips on mounting rails -4- (5x).
  2. Rubber belts (2x)
  3. Cable tie
  4. Mounting rails (5x)
  5. Connectors (4x)

The following list pertains to see scheme 13.

  1. Backrest Removing: Unscrew bolt -6-. Twist clip -7- upward. Unscrew bolts -3- (4x). Tilt backrest -1- forward onto seat. Move padding to one side and carefully lift wiring harness -2- out of seat pan -8-. Remove backrest -1-. Installing: To install clip -5-: Screw bolt -6- firmly to plastic washer -4-. Always use new bolts -3- (4x). Before inserting bolts -3- (4x) recut the thread in the backrest frame. For memory seat: After installing seat in vehicle perform basic setting of backrest and seat.
  2. Wiring harness
  3. Bolts (4x) Tightening torque 20 Nm
  4. Plastic washer
  5. Bracket
  6. Bolt
  7. Bracket
  8. Seat pan

Side trims (outboard side), assembly overview

The following list pertains to see scheme 14.

  1. Backrest
  2. Bolts (4x)
  3. Rear side trim, outboard side
  4. Front side trim, outboard side Removing: Remove seat. See «FRONT SEAT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-assembly-overview) . Unscrew bolts -2- (4x). Detach rear side trim -3- upward. Detach front side trim -4- forward. Detach connectors -5- (3x).
  5. Connector (3x)
  6. Side trim, inboard side
  7. Bolts (2x)
  8. Rubber strap of backrest cover

Side trim, inboard side, assembly overview

The following list pertains to see scheme 15.

  1. Backrest
  2. Bolts (4x)
  3. Rear side trim, outboard side
  4. Front side trim, outboard side
  5. Connector (3x)
  6. Side trim, inboard side Removing: Remove seat. See «FRONT SEAT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-assembly-overview) . Disengage rubber strap of backrest cover -8-. Unscrew bolts -7- (2x). Detach side trim -6- upward.
  7. Bolts (2x)
  8. Rubber strap of backrest cover

Removing

  1. Press the handle -1- upward.
  2. Release the tab -2- in direction of arrow using a screwdriver and, at the same time, pull off handle -1-.
  3. Unclip the cover plate -1-.
  4. Detach connector -3-.
  5. Remove the cover plate -1-.

Note. In order to be able to press in the handle, the metal pin in the cover plate aperture must be pushed upward.

Scheme 56

Scheme 56
Scheme 56

Installing

  1. Install the easy-entry facility in the reverse sequence. Ensure that the handle -2- engages.

Bowden cable for backrest lock, assembly overview

Note. For the sake of illustration, the seat is depicted without seat pan in the illustration.

The following list pertains to see scheme 18.

  1. Adjustment devices for Bowden cable (2x)
  2. Bowden cable for backrest lock (2x) Removing Remove seat. See «FRONT SEAT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-assembly-overview) . Remove backrest panel. See «BACKREST COVER PANEL, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__backrest-cover-panel-assembly-overview) . Operate the Easy Entry handle of entry assistance and fold backrest forward. Disengage eyelets -4- (2x) at bottom left and right, using pliers. Using a screwdriver, pry out left and right retainers -3- (2x). Remove Bowden cables -2- (2x) upward. Slide seat cover upward in direction of arrow. Disengage Bowden cables at brackets -5- and -6-. Installing NOTE: For vehicles up to 05.02, VIN: 8H 3K 002 450: To prevent malfunctions of headrest and seatback adjustment, apply a cable tie -7-. Install Bowden cable for backrest lock in reverse order of removal. Adjust Bowden cables -2- (2x) using adjustment devices -1- (2x). Ensure that the lower pins at left and right are released simultaneously when the Easy Entry handle of entry assistance is operated.
  3. Retainers (2x)
  4. Eyelets (2x)
  5. Bracket
  6. Bracket
  7. Cable ties

Microswitch for seatback release, assembly overview

The following list pertains to see scheme 19.

Scheme 57

Scheme 57: Microswitch for seatback release, assembly overview
Scheme 57: Microswitch for seatback release, assembly overview
  1. Cable ties
  2. Connector
  3. Circlip
  4. Microswitch for seatback release Removing Remove seat. See «FRONT SEAT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-assembly-overview) . Remove door sill side seat trim. See «SIDE TRIMS (OUTBOARD SIDE), ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__side-trims-outboard-side-assembly-overview) . Remove tunnel side seat trim. See «SIDE TRIM, INBOARD SIDE, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__side-trim-inboard-side-assembly-overview) . Remove backrest. See «FRONT SEAT BACKREST, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-backrest-assembly-overview) . Remove backrest panel. See «BACKREST COVER PANEL, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__backrest-cover-panel-assembly-overview) . Remove backrest frame. See «BACKREST FRAME, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__backrest-frame-assembly-overview) . Remove backrest cover and cushion. Use a screwdriver to pry out circlip -3-. Press together catches -5- (2x) and remove microswitch -4-. Disconnect connector -2-. Installing Press in microswitch -4- until the catches -5- (2x) engage. Connect the connector -2-. Install backrest cover and cushion. Install backrest. See «FRONT SEAT BACKREST, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-backrest-assembly-overview) . Install seat. See «FRONT SEAT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-assembly-overview) . Adjust microswitch for seatback release. See «MICROSWITCH FOR SEATBACK RELEASE, ADJUSTING»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__microswitch-for-seatback-release-adjusting) . Insert the circlip -3-. Install backrest frame. See «BACKREST FRAME, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__backrest-frame-assembly-overview) . Install backrest panel. See «BACKREST COVER PANEL, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__backrest-cover-panel-assembly-overview) .
  5. Catches (2x)

Microswitch for seatback release, adjusting

Note. For vehicles up to 05.02, VIN: 8H 3K 002 450: To prevent malfunctions of headrest and seatback adjustment, apply a cable tie -1-.

The following list pertains to see scheme 20.

  1. Cable ties
  2. Connector
  3. Circlip
  4. Microswitch for seatback release Adjusting and checking function Remove backrest panel. See «BACKREST COVER PANEL, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__backrest-cover-panel-assembly-overview) . Use a screwdriver to pry out circlip -3-. Slide microswitch -4- only far enough so that backrest is switched off when release lever is lifted 1/3. Check backrest function at adjustment switch: Backrest is not activated when backrest release lever is lifted to 1/3. Backrest is activated when release lever is in rest position. Correct the position of microswitch -4- as necessary and check its function again.
  5. Catches (2x)

Microswitch for headrest, assembly overview

The following list pertains to see scheme 21.

  1. Cable ties
  2. Connector
  3. Circlip
  4. Microswitch for headrest Removing Remove backrest panel. See «BACKREST COVER PANEL, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__backrest-cover-panel-assembly-overview) . Use a screwdriver to pry out circlip -3-. Press together catches -5- (2x) and remove microswitch -4-. Disconnect connector -2-. Installing Press in microswitch -4- until the catches -5- (2x) engage. Connect the connector -2-. Install seat. See «FRONT SEAT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-assembly-overview) . Adjust microswitch for headrest. See «MICROSWITCH FOR HEADREST, ADJUSTING»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__microswitch-for-headrest-adjusting) . Insert the circlip -3-. Install backrest panel. See «BACKREST COVER PANEL, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__backrest-cover-panel-assembly-overview) .
  5. Catches (2x)

Microswitch for headrest, adjusting

Note. For vehicles up to 05.02, VIN: 8H 3K 002 450: To prevent malfunctions of headrest and seatback adjustment, apply a cable tie -1-.

The following list pertains to see scheme 22.

  1. Cable ties
  2. Connector
  3. Circlip
  4. Microswitch for headrest Adjusting and checking function Remove backrest panel. See «BACKREST COVER PANEL, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__backrest-cover-panel-assembly-overview) . Use a screwdriver to pry out circlip -3-. Slide microswitch -4- only far enough so that headrest is moved downward and switched off when release lever is lifted 1/3. Check function of headrest at adjustment switch: Headrest is not activated when backrest release lever is lifted to 1/3. Headrest is activated when release lever is in rest position. Correct the position of microswitch -4- as necessary and check its function again.
  5. Catches (2x)

Note. For improved clarity, the eye with Bowden cable on pin -4- is not shown in the illustration.

  1. Pull out cable -2-.
  2. Unscrew nuts -3- (2x).
  3. Remove the backrest release microswitch -1-. Installing: NOTE: After attaching the backrest release microswitch, -1- actuate the handle of the easy-entry facility. Ensure that metal tab -5- is in contact with pin -4- over the entire adjustment range. Install the backrest release microswitch -1- in the reverse sequence.

Backrest (standard seat), replacing

Note. Sports backrest only is available as replacement part. Convert the sports backrest for the standard seat.

The following list pertains to see scheme 24.

  1. Sports backrest Conversion: Detach wire clips -2- (2x) from sports backrest -1-. Paint layer must be made good again according to the Workshop Manual "Vehicle Painting" and, if necessary, the protection measures against corrosion must be carried out according to binder "Surface Technology, Chemical Working Materials".
  2. Wire clips (2x)

Seat pan (standard seat), replacing

Note. Sports seat pan only is available as replacement part. Convert the sports seat pan for the standard seat.

The following list pertains to see scheme 25.

  1. Sports seat pan Conversion: Detach wire clips -2- (2x) from sports seat pan -1-. Paint layer must be made good again according to the Workshop Manual "Vehicle Painting" and, if necessary, the protection measures against corrosion must be carried out according to binder "Surface Technology, Chemical Working Materials".
  2. Wire clips (2x)

Guide for side airbag, assembly overview

The following list pertains to see scheme 26.

  1. Guide for side airbag Removing: Remove seat. See «FRONT SEAT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-assembly-overview) . Remove backrest cover panel. See «BACKREST COVER PANEL, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__backrest-cover-panel-assembly-overview) . Remove side airbag. See appropriate Air Bag Restraint System article. Press clip -3- together and remove clip -3-. Pry out the retainer -2- from the inside. Detach the side airbag guide -1-. Installing: Installation is in reverse order of removal.
  2. Retainer
  3. Clip
  1. Remove seat. See «FRONT SEAT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-assembly-overview) .
  2. Remove seat side trim, outboard side. See «SIDE TRIMS (OUTBOARD SIDE), ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__side-trims-outboard-side-assembly-overview) .
  3. Unscrew bolts -5- (5x). Tightening torque 1.5 Nm
  4. Detach seat adjustment switch -2-.
  5. Remove the connection board with connectors -1-.
  1. Installation is in reverse order of removal.
  1. Remove seat. See «FRONT SEAT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-assembly-overview) .
  2. Remove seat side trim, outboard side. See «SIDE TRIMS (OUTBOARD SIDE), ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__side-trims-outboard-side-assembly-overview) .
  3. Unscrew bolts -4- (2x). Tightening torque 0.4 Nm.
  4. Detach switch for 4-way lumbar support -3-.
  1. Installation is in reverse order of removal.

Control unit, removing and installing

Note. The control unit for the memory seat and the electric seat is under the driver's seat.

If the control unit is defective, the top support of the seat pan and backrest must be removed. See FRONT SEAT WITH FAULTY FORWARD AND BACKWARD SEAT ADJUSTMENT MOTOR OR DEFECTIVE CONTROL UNIT, REMOVING AND INSTALLING .

  1. Remove seat. See «FRONT SEAT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-assembly-overview) .
  2. Unscrew bolts -2- (2x). Tightening torque 1.5 Nm.
  3. Turn control unit -1- over.
  4. Disengage the retaining clip -4- and remove the connector -5-.
  5. Press the retainer tabs -3- (2x) in and remove the connector -2-.
  6. Remove the control unit -1-.
  1. Installation is in reverse order of removal.

Forward and backward seat adjustment motor, assembly overview

Note. If the motor is faulty, the top support of the seat pan must be replaced. See FRONT SEAT WITH FAULTY FORWARD AND BACKWARD SEAT ADJUSTMENT MOTOR OR DEFECTIVE CONTROL UNIT, REMOVING AND INSTALLING .

The following list pertains to see scheme 31.

  1. Lumber support adjustment motors (2x)
  2. Seat height adjustment motor
  3. Seat inclination adjustment motor
  4. Forward and backward seat adjustment motor
  5. Backrest adjustment motor

Seat height adjustment motor, assembly overview

Note. If the motor is faulty, the top support of the seat pan must be replaced.

The following list pertains to see scheme 32.

  1. Lumbar support adjustment motors (2x)
  2. Seat height adjustment motor Removing: Remove seat. See «FRONT SEAT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-assembly-overview) . Remove side trim, outboard side. See «SIDE TRIMS (OUTBOARD SIDE), ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__side-trims-outboard-side-assembly-overview) . Remove side trim, inboard side. See «SIDE TRIM, INBOARD SIDE, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__side-trim-inboard-side-assembly-overview) . Remove backrest. See «FRONT SEAT BACKREST, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-backrest-assembly-overview) . Remove cover and padding from seat pan. Remove control unit. See «CONTROL UNIT, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__control-unit-removing-and-installing) . Remove belt buckle. Remove spring pad with wiring harness from seat pan. See «SEAT PAN SPRING PAD WITH WIRING HARNESS, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__seat-pan-spring-pad-with-wiring) . Detach the upper seat pan support from the lower seat pan support.
  3. Seat inclination adjustment motor
  4. Forward and backward seat adjustment motor
  5. Backrest adjustment motor

The following list pertains to see scheme 33.

  1. Connector
  2. Seat inclination adjustment motor Removing: Remove seat. See «FRONT SEAT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-assembly-overview) . Remove control unit. See «CONTROL UNIT, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__control-unit-removing-and-installing) . Detach connector -1-. Unscrew bolts -3- (2x). Remove seat inclination adjustment motor -2-. Installing: Installation is in reverse order of removal.
  3. Bolts (2x) Tightening torque 10 Nm
  4. Forward and backward seat adjustment motor
  5. Backrest adjustment motor

Seat cushion extension (sports seat), assembly overview

The following list pertains to see scheme 34.

  1. Seat cushion extension Removing: Remove seat. See «FRONT SEAT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-assembly-overview) . Detach cover and padding from seat pan. Detach seat cushion extension from cover and padding. Installing: Installation is in reverse order of removal.
  2. Bolts (4x)
  3. Panel Removing: Pry clips -4- (4x) off trim -3-. Installing: Installation is in reverse order of removal.
  4. Clips (4x)
  5. Handle Removing: Unscrew bolts -2- (4x). Remove handle -5-. Installing: Installation is in reverse order of removal.

Motor for backrest inclination adjustment, assembly overview

The following list pertains to see scheme 35.

Scheme 58

Scheme 58: Motor for backrest inclination adjustment, assembly overview
Scheme 58: Motor for backrest inclination adjustment, assembly overview
  1. Lumbar support adjustment motors (2x)
  2. Seat height adjustment motor
  3. Seat inclination adjustment motor
  4. Forward and backward seat adjustment motor
  5. Backrest adjustment motor Removing: Remove seat. See «FRONT SEAT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-assembly-overview) . Remove side trim, outboard side. See «SIDE TRIMS (OUTBOARD SIDE), ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__side-trims-outboard-side-assembly-overview) . Remove side trim, inboard side. See «SIDE TRIM, INBOARD SIDE, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__side-trim-inboard-side-assembly-overview) . Remove backrest cover panel. See «BACKREST COVER PANEL, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__backrest-cover-panel-assembly-overview) . NOTE: The illustration shows a front passenger seat backrest. Unscrew bolt from backrest adjustment motor. See «RELEASING FASTENING FOR BACKREST INCLINATION ADJUSTMENT MOTOR»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__releasing-fastening-for-backrest-inclination-adjustment) Using a screwdriver, pry off the spring washer -5- on the side of the backrest inclination adjustment motor (illustration detail -B-). Using a hammer and punch knock shaft -4- through the side of the backrest frame. Pull shaft -4- out of backrest frame -1- until backrest inclination adjustment motor can be removed. Installing: Adapt the splines of the new backrest inclination adjustment motor. See «RELEASING FASTENING FOR BACKREST INCLINATION ADJUSTMENT MOTOR»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__releasing-fastening-for-backrest-inclination-adjustment) Push shaft -4- through backrest inclination adjustment motor and through backrest frame -1-. Place seat on its side. Position a block of wood -2- under shaft -4- on the opposite side of the backrest inclination adjustment motor (illustration detail -A-). Using an 11 mm socket, knock spring washer -5- onto shaft -4- (illustration detail -C-). Tighten the bolt on the backrest adjustment motor and attach the connector. For memory seat: After installing the seat, perform basic setting of backrest and seat.

The following list pertains to see scheme 36.

  1. Backrest frame
  2. Wooden block
  3. 11 mm socket
  4. Shaft
  5. Spring lock washer

Releasing fastening for backrest inclination adjustment motor

  1. Detach connector -5-.
  2. Pull cover -3- and anti-squeak pad -2- to one side.
  3. Unscrew bolt -4-.

Preparing backrest inclination adjustment motor

  1. Using a screwdriver, turn asymmetric section of teeth -1- to align with shaft in backrest frame.

Backrest cover panel, assembly overview

The following list pertains to see scheme 39.

  1. Backrest frame
  2. Staples (3x)
  3. Backrest trim Removing: Pry off staples -2- (3x) on backrest cover panel -1-. Remove backrest cover panel -3- upward. Installing: Installation is in reverse order of removal.
  4. Clips (5x)

Backrest frame, assembly overview

The following list pertains to see scheme 40.

  1. Backrest frame Removing: Remove backrest cover panel. See «BACKREST COVER PANEL, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__backrest-cover-panel-assembly-overview) Pry off clips -4- (5x). Remove backrest frame -1-. Installing: Installation is in reverse order of removal.
  2. Staples (3x)
  3. Backrest trim
  4. Clips (5x)

4-way lumbar support, assembly overview

The following list pertains to see scheme 41.

  1. Bowden cable for lumbar support height adjustment
  2. Bowden cable for lumbar support adjustment
  3. 4-way lumbar support Removing: Remove seat. See «FRONT SEAT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-assembly-overview) . Remove side trim, outboard side. See «SIDE TRIMS (OUTBOARD SIDE), ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__side-trims-outboard-side-assembly-overview) . Remove side trim, inboard side. See «SIDE TRIM, INBOARD SIDE, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__side-trim-inboard-side-assembly-overview) . Remove backrest. See «FRONT SEAT BACKREST, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-backrest-assembly-overview) . Remove backrest cover panel. See «BACKREST COVER PANEL, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__backrest-cover-panel-assembly-overview) . Remove backrest frame. See «BACKREST FRAME, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__backrest-frame-assembly-overview) . Disengage Bowden cable for lumbar support adjustment -2- from hook -4-. Disengage Bowden cable for lumbar support height adjustment -1- at retainer pin -5- and at idler wheel -6-. Disengage lower 4-way lumbar support -3- at positions -B- (2x). Disengage upper 4-way lumbar support -3- at positions -A- (2x). Installing: Installation is in reverse order of removal.
  4. Hook
  5. Retaining tabs
  6. Idler roller

Lumbar support adjustment motors, assembly overview

Note. On the driver's seat in the illustration, the lumbar support height adjustment motor is on the left and the lumbar support adjustment motor is on the right.

The following list pertains to see scheme 42.

  1. Lumber support adjustment motors (2x) Remove seat. See «FRONT SEAT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-assembly-overview) . Remove backrest cover panel. See «BACKREST COVER PANEL, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__backrest-cover-panel-assembly-overview) . Disconnect connector. Unscrew the bolts. Disengage Bowden cable at 4-way lumbar support. Replace motor.
  2. Seat height adjustment motor
  3. Seat inclination adjustment motor
  4. Forward and backward seat adjustment motor
  5. Backrest adjustment motor
  1. Remove the backrest cover panel. See «BACKREST COVER PANEL, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__backrest-cover-panel-assembly-overview) .
  2. Detach connector -4-.
  3. Press button -2-.
  1. Installation is in reverse order of removal.
  1. Press out rear footwell light -1- from rear.
  2. Disconnect connector -2-.
  1. Installation is in reverse order of removal.

Seat pan spring pad with wiring harness, assembly overview

The following list pertains to see scheme 45.

  1. Cable tie (4x)
  2. Spring pad with wiring harness Removing: Remove seat. See «FRONT SEAT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-assembly-overview) . Remove side trim, outboard side. See «SIDE TRIMS (OUTBOARD SIDE), ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__side-trims-outboard-side-assembly-overview) . Remove side trim, inboard side. See «SIDE TRIM, INBOARD SIDE, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__side-trim-inboard-side-assembly-overview) . Remove backrest. See «FRONT SEAT BACKREST, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-backrest-assembly-overview) . Remove cover and padding from seat pan. Remove cable tie -1- (4x) Disengage spring pad -2- at positions -A- (2x). Disengage spring pad -2- at positions -B- (4x). Place seat to side. Detach connectors -3- (3x). Unscrew bolt -5-. Remove spring pad with wiring harness -2- Installing: Installation is in reverse order of removal.
  3. Connector (3x)
  4. Shim
  5. Bolt

Seat wiring assignment

The following list pertains to see scheme 46.

  1. Seat heating wiring harness
  2. Seat adjustment connector (2x)
  3. 4-way lumbar support connector
  4. Electric lumbar support wiring harness, inboard side
  5. Backrest heating wiring harness
  6. Buckle interrogation connector (black)
  7. Seat heating connector (green)
  8. Power supply connector (red)
  9. Airbag connector (orange)
  10. Airbag wiring harness
  11. Electric lumbar support wiring harness for 4-pin side airbag

Backrest wiring assignment

The following list pertains to see scheme 47.

  1. Airbag wiring harness
  2. Electric lumbar support wiring harness for 4-pin side airbag
  3. Airbag connector
  4. Electric lumbar support connector for 4-pin side airbag
  5. Electric lumbar support connector
  6. Backrest heating connector
  7. Backrest heating wiring harness
  8. Electric lumbar support wiring harness, inboard side

Seat backrest wiring harness, assembly overview

The following list pertains to see scheme 48.

  1. Connector (3x)
  2. Wiring harness Removing: Remove seat. See «FRONT SEAT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-assembly-overview) . Remove side trim, outboard side. See «SIDE TRIMS (OUTBOARD SIDE), ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__side-trims-outboard-side-assembly-overview) . Remove side trim, inboard side. See «SIDE TRIM, INBOARD SIDE, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__side-trim-inboard-side-assembly-overview) . Remove backrest. See «FRONT SEAT BACKREST, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__front-seat-backrest-assembly-overview) . Remove backrest cover panel. See «BACKREST COVER PANEL, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__backrest-cover-panel-assembly-overview) . Remove cover and padding from backrest. Detach cable ties -3- (3x). Detach connectors -1- (3x). Remove wiring harness -2-. Installing: Installation is in reverse order of removal.
  3. Cable ties (3x)

Rear seat bench, assembly overview

The following list pertains to see scheme 49.

  1. Rear seat bench Removing: Pull rear seat bench -1- up and remove rear seat bench -1-. With seat heating: Detach connector for seat heating. Installing: Place protective cover -4- below buckles -3- (2x). With seat heating: Plug in connector for seat heating. Push rear seat bench -1- under rear seat backrest -2- and feed in buckles -3- (2x). Engage rear seat bench -1- in grommets -5- (3x).
  2. Rear seat backrest
  3. Buckles (2x)
  4. Protective cover
  5. Grommets (3x)

Rear seat backrest, assembly overview

The following list pertains to see scheme 50.

Scheme 59

Scheme 59: Rear seat backrest, assembly overview
Scheme 59: Rear seat backrest, assembly overview
  1. Rear seat backrest Removing: Remove rear bench seat. See «REAR SEATS»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet) . Remove head restraints-. See «HEAD RESTRAINTS, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet) . Removing head restraint guides. Disengage seatbelt guides (2x) at left and right. Remove rear seat backrest -1- upward. Remove cord at fabric cover of belt buckles. See «CORD AT FABRIC COVER OF BELT BUCKLES, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet__cord-at-fabric-cover-of-belt) . With seat heating: Detach connector for seat heating. Unscrew bolts -2- (2x). Installing: With seat heating: Plug in connector for seat heating. Guide rear seat backrest -1- in at bottom. Push rear seat backrest -1- upward and engage rear seat backrest -1- at top (3x). Press rear seat backrest -1- fully down. Install bolts -2- (2x). Install head restraint guides. Install head restraints. See «HEAD RESTRAINTS, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/seats/#seats-frames-cabriolet) .
  2. Bolts (2x) Tightening torque 8 Nm.

Cord at fabric cover of belt buckles, removing and installing

  1. Removing Remove cord -2- in direction of arrow.
  2. Installing Slide cord -2- in opposite direction of arrow into grip channel -1-.
  1. Press cover down and using a screwdriver, pry out clip -2- in direction of arrow.
  2. Pull out head restraints -1- (2x).
  1. Installation is in reverse order of removal.
  1. Detach piping -1-.
  1. Installation is in reverse order of removal.

See also:
• BATTERY DISCONNECT PRECAUTIONS
• FRONT SEAT RAIL COVER, ASSEMBLY OVERVIEW
• REAR SEAT RAIL COVER, ASSEMBLY OVERVIEW
• CONNECTORS, DISCONNECTING
• VAS 6036 AIRBAG ADAPTER, CONNECTING
• CONTROL UNIT, REMOVING AND INSTALLING
• FRONT SEAT, ASSEMBLY OVERVIEW
• SIDE TRIMS (OUTBOARD SIDE), ASSEMBLY OVERVIEW
• SIDE TRIM, INBOARD SIDE, ASSEMBLY OVERVIEW
• BACKREST COVER PANEL, ASSEMBLY OVERVIEW
• FRONT SEAT BACKREST, ASSEMBLY OVERVIEW
• BACKREST FRAME, ASSEMBLY OVERVIEW
• MICROSWITCH FOR SEATBACK RELEASE, ADJUSTING
• MICROSWITCH FOR HEADREST, ADJUSTING
• FRONT SEAT WITH FAULTY FORWARD AND BACKWARD SEAT ADJUSTMENT MOTOR OR DEFECTIVE CONTROL UNIT, REMOVING AND INSTALLING
• SEAT PAN SPRING PAD WITH WIRING HARNESS, ASSEMBLY OVERVIEW
• RELEASING FASTENING FOR BACKREST INCLINATION ADJUSTMENT MOTOR
• REAR SEATS
• CORD AT FABRIC COVER OF BELT BUCKLES, REMOVING AND INSTALLING

More articles — Accessories & Equipment
