Communication, Cabriolet Audi A4 B6

General notes

Note. Further measures after re-connecting power supply

Refer to

1. 24 MULTIPORT FUEL INJECTION (MFI) for 1.8 LITER 4-CYL. 5V TURBO FUEL INJECTION & IGNITION, ENGINE CODE(S): AMB
2. «24 - MULTIPORT FUEL INJECTION (MFI)»(ref-278889-S34101423592008020700000) for 2.0 LITER 4-CYL. 4V TURBO FUEL INJECTION IGNITION, ENGINE CODE(S): BPG, BWT
3. 24 MULTIPORT FUEL INJECTION (MFI) for 3.0 LITER 6-CYL. 5V FUEL INJECTION & IGNITION, ENGINE CODE(S): AVK, BGN
4. «24 - FUEL INJECTION SYSTEM»(ref-278893-S37153426882008020700000) for 3.2 V6 4V FUEL INJECTION IGNITION, ENGINE CODE(S): BKH
5. «24 - MULTIPORT FUEL INJECTION (MFI)»(ref-278897-S07807171762008020700000) for 4.2 LITER V8 4V FUEL INJECTION AND IGNITION, ENGINE CODE(S): BNS
6. «24 MULTIPORT FUEL INJECTION (MFI)»(ref-278895-S12545223132008020700000) for 4.2 LITER V8 5V FUEL INJECTION AND IGNITION, ENGINE CODE(S): BHF

1. Before troubleshooting or servicing, technicians must be familiar with the functions and operation specifics of the applicable standard or optional radio system. Always read the radio owner's manual and review all radio, tape player and CD player/changer functions.
2. For additional information

Refer to Operating instructions

1. When retrofitting, repairing or troubleshooting

Refer to Electrical Wiring Diagrams, Troubleshooting & Component Locations, Cabriolet

Refer to Radio installation instructions

1. For detailed instructions (e.g. removing and installing trim panels)

Refer to 70 - INTERIOR TRIM

1. Wherever possible, only genuine Audi parts should be used. Only then can trouble-free installation and optimal reception be guaranteed.
2. All Audi radio systems are encoded for the instrument cluster in the convenience coding. It is not necessary to enter the code when disconnecting and reconnecting the power supply, removing and installing the same radio or removing and installing the same instrument cluster.
3. If the "Transport" message appears on display after switching on the radio, transport mode must be deactivated.

Do this using vehicle diagnostic, testing and information system VAS 5051.

Notes for retrofitting radio

1. The connectors on the factory installed radio wiring harness are designed for genuine Audi radios.
2. Radios with different types of connectors must be installed using adapter wires.
3. When other radio units are installed it can have an effect on the antenna amplifier, since the original Audi radio units have a remotely driven antenna (the voltage supply of the antenna amplifier is driven via a center wire of the high frequency cable). Use a remotely driven adaptor. Refer to parts catalog (vendor: Votex).

Note for retrofitting CD

For CD preparation, the wiring harness for the CD changer is already installed in vehicle. The connecting wire can only be used with genuine Audi CD changers.

Scheme 197

1 - CD Changer Unit -R41

1. Optional
2. In glove compartment
3. Removing and installing. Refer to «CD changer, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__cd-changer-removing-and-installing)
4. Check wire connection. Refer to «Check wire connection between radio and CD changer»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__check-wire-connection-between-radio-and)

2 - Center Mid/High Range Loudspeaker -R158

1. In instrument panel
2. Removing and installing. Refer to «Center treble speaker, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__center-treble-speaker-removing-and-installing)

3 - Radio -R

1. In center console
2. Radio "Concert II" removing and installing. Refer to «"Concert ll" radio, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__concert-ll-radio-removing-and-installing)
3. Radio "Symphony II" removing and installing. Refer to «"Symphony ll" radio, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__symphony-ll-radio-removing-and-installing)

4 - Amplifier -R12- for the rear speaker or BOSE amplifier (only with "BOSE sound system")

1. In rear right of luggage compartment behind side trim
2. Removing and installing. Refer to «Amplifier for the rear speakers or BOSE amplifier, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__amplifier-for-the-rear-speakers-or)

5 - Right Antenna Module -R109

1. Behind the rear lid trim
2. Removing and installing. Refer to «Antennas in rear lid - overview»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__antennas-in-rear-lid-overview)

6 - Left Antenna Module -R108

1. Behind the rear lid trim
2. Removing and installing. Refer to «Antennas in rear lid - overview»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__antennas-in-rear-lid-overview)

7 - Left Rear Speaker -R4-, Right Rear Speaker -R5

1. In rear side trim (bottom)
2. Speaker (active): Mid-range/bass with treble bridge
3. BOSE-speakers: Mid-range/bass
4. Removing and installing. Refer to «Removing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet)

8 - Treble speaker, left front -R20-, Treble speaker, right front -R22

1. In front door (top)
2. Removing and installing. Refer to «Front treble speaker, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__front-treble-speaker-removing-and-installing)

9 - Bass speaker, left front -R21-, Bass speaker, right front -R23

1. In front door trim (bottom)
2. Removing and installing. Refer to «Speakers in front doors, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__speakers-in-front-doors-removing-and)

10 - Left Front DSP Midrange Speaker -R103-, Right Front DSP Midrange Speaker -R104

1. In instrument panel
2. Removing and installing. Refer to «Speaker in instrument panel, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__speaker-in-instrument-panel-removing-and)

Scheme 198

1 - CD Changer Unit -R41

1. optional
2. in glove compartment
3. Removing and installing. Refer to «CD changer, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__cd-changer-removing-and-installing)
4. Check wire connection. Refer to «Check wire connection between radio and CD changer»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__check-wire-connection-between-radio-and)

2 - Left Front DSP Midrange Speaker -R103-, Right Front DSP Midrange Speaker -R104

1. in instrument panel
2. Removing and installing. Refer to «Speaker in instrument panel, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__speaker-in-instrument-panel-removing-and)

3 - Treble speaker, left front -R20-, Treble speaker, right front -R22

1. in front door (top)
2. Removing and installing. Refer to «Front treble speaker, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__front-treble-speaker-removing-and-installing)

4 - Center Mid/High Range Loudspeaker -R158

1. in instrument panel
2. Removing and installing. Refer to «Center treble speaker, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__center-treble-speaker-removing-and-installing)

5 - Amplifier for the rear speaker or Amplifier -R12- BOSE (only for "BOSE sound system")

1. in luggage compartment at rear, right side, behind side trim
2. Removing and installing. Refer to «Amplifier for the rear speakers or BOSE amplifier, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__amplifier-for-the-rear-speakers-or)

6 - Right Antenna Module -R109

1. behind the rear lid trim
2. Removing and installing. Refer to «Antennas in rear lid - overview»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__antennas-in-rear-lid-overview)

7 - Satellite Tuner Antenna -R172

1. behind the rear lid trim
2. Removing and installing. Refer to «Antennas in rear lid - overview»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__antennas-in-rear-lid-overview)

8 - Left Antenna Module -R108

1. behind the rear lid trim
2. Removing and installing. Refer to «Antennas in rear lid - overview»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__antennas-in-rear-lid-overview)

9 - Satellite Radio -R146

1. in luggage compartment at rear, left side, behind side trim
2. Removing and installing. Refer to «Satellite radio, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__satellite-radio-removing-and-installing)

10 - Left Rear Speaker -R4-, Right Rear Speaker -R5

1. in rear side trim (bottom)
2. Removing and installing. Refer to «Removing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet)

11 - Bass speaker, left front -R21-, Bass speaker, right front -R23

1. in front door trim (bottom)
2. Removing and installing. Refer to «Speakers in front doors, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__speakers-in-front-doors-removing-and)

12 - Radio -R

1. in center console
2. Radio "concert II" removing and installing. Refer to «"Concert ll" radio, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__concert-ll-radio-removing-and-installing)
3. Radio "symphony II" removing and installing. Refer to «"Symphony ll" radio, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__symphony-ll-radio-removing-and-installing)

Scheme 199

Radio system "Concert II" and "Symphony ll"

1 - CD Changer Unit

1. Optional
2. In glove compartment

2 - Left antenna module

1. Behind the rear lid trim

3 - Right antenna module

1. Behind the rear lid trim

4 - Front treble speaker

1. In front door (top)

5 - Mid-range speaker, front

1. In instrument panel

6 - Bass speaker, front

1. In front door trim (bottom)

7 - Rear speaker

1. In rear side trim (bottom)
2. Speaker (active): Mid-range/bass with treble bridge
3. BOSE-speakers: Mid-range/bass

8 - Amplifier for the rear speakers

1. In luggage compartment right rear behind side trim

9 - Center mid-range loudspeaker

1. In instrument panel

Multi-pin harness connectors I, II, III, and IV on back of radio

Note. Terminals which are not listed are vacant/unassigned.

Scheme 200

Black, 20-pin multi-pin harness connector I

1 - Signal output, rear left

2 - Signal output, rear right

3 - Signal Ground (GND)

4 - Signal output, front left

5 - Signal output, front right

6 - Control plus for end amplifier

7 - CAN-Bus High (display)

10 - Ground (GND) (CD changer)

12 - CAN-Bus Low (display)

13 - CD Bus data in (CD changer)

14 - CD Bus Data out (CD changer)

15 - CD clock (CD changer)

16 - Continuous B+ (CD changer)

17 - Control plus for CD changer

18 - CD Ground (GND) (CD changer)

19 - Signal left channel (CD changer)

20 - Signal right channel (CD changer)

Multi-pin connector II, 8-pin, brown

3 - Loudspeaker + front right

4 - Loudspeaker - front right

5 - Loudspeaker + front left

6 - Loudspeaker - front left

Multi-pin connector III, 8-pin, black

1 - BOSE coding (free)

2 - Anti-theft warning system

3 - K diagnostic

7 - Terminal 30

8 - Terminal 31

Multi-pin connector IV, 10-pin, red

1 - Telephone mute (low frequency-mute)

3 - Telephone (low frequency +) (not for navigation equipment)

4 - Telephone (low frequency -) (not for navigation equipment)

5 - Navigation (low frequency +)

6 - Navigation (low frequency -)

7 - Navigation control wire

Multi-pin harness connectors at amplifier for rear loudspeakers

Note. Terminals which are not listed are vacant/unassigned.

Scheme 201

23-pin multi-pin harness connector

2 - Speaker (+) front left

3 - Speaker (-) front left

6 - Speaker (+) front right

9 - Speaker (-) front right

13 - Switched positive (from Radio)

14 - Signal, rear left (from Radio)

15 - Loudspeaker (-) rear left

16 - Signal, front left (from Radio)

17 - Signal, rear right (from Radio)

18 - Loudspeaker (-) rear right

19 - Signal - Ground -GND- (from Radio)

20 - Signal, front right (from Radio)

21 - Loudspeaker (-) rear right

22 - Terminal 31

23 - Terminal 30

Scheme 202

"Concert II" and "Symphony II" radio system with "BOSE sound system", layout

1 - CD Changer Unit

1. Optional
2. In glove compartment

2 - Left antenna module

1. Behind the rear lid trim

3 - Right antenna module

1. Behind the rear lid trim

4 - Front treble speaker

1. In front door (top)

5 - Mid-range speaker, front

1. In instrument panel

6 - Bass speaker, front

1. In front door trim (bottom)

7 - Rear speaker

1. In rear side trim (bottom)
2. Speaker (active): Mid-range/bass with treble bridge
3. BOSE-speakers: Mid-range/bass

8 - Center mid-range loudspeaker

1. In instrument panel

9 - BOSE amplifier

1. In luggage compartment right rear behind side trim

Scheme 203

Radio system "BOSE sound system" with SDARS

1 - CD Changer Unit

1. optional
2. in glove compartment

2 - Satellite radio

1. in luggage compartment at rear, left side, behind side trim

3 - Satellite tuner antenna

1. behind the rear lid trim

4 - Left antenna module (FM1/FM2/AM)

1. behind the rear lid trim

5 - Right antenna module (FM3/FM4)

1. behind the rear lid trim

6 - Radio

1. in center console, at top

7 - Front treble speaker

1. in front door (top)

8 - Front midrange speaker

1. in instrument panel

9 - Bass speaker, front

1. in front door trim (bottom)

10 - Rear speaker

1. in rear side trim (bottom)

11 - Center Mid/High Range Loudspeaker -R158

1. in instrument panel

12 - BOSE-amplifier

1. in luggage compartment at rear, right side, behind side trim

Multi-pin harness connectors I, II, III, and IV on back of radio

Note. Terminals which are not listed are vacant/unassigned.

Black, 20-pin multi-pin harness connector I

1 - Signal output, rear left

2 - Signal output, rear right

3 - Signal Ground (GND)

4 - Signal output, front left

5 - Signal output, front right

6 - Control plus for BOSE amplifier

7 - CAN-Bus High (display)

10 - Ground (GND) (CD changer)

12 - CAN-Bus Low (display)

13 - CD Bus data in (CD changer)

14 - CD Bus Data out (CD changer)

15 - CD clock (CD changer)

16 - Continuous B+ (CD changer)

17 - Control plus for CD changer

18 - CD Ground (GND) (CD changer)

19 - Signal left channel (CD changer)

20 - Signal right channel (CD changer)

Multi-pin connector II, 8-pin, brown

3 - Loudspeaker + front right

4 - Loudspeaker - front right

5 - Loudspeaker + front left

6 - Loudspeaker - front left

Multi-pin connector III, 8-pin, black

1 - BOSE coding (Ground GND)

2 - Anti-theft warning system

3 - K diagnostic

7 - Terminal 30

8 - Terminal 31

Multi-pin connector IV, 10-pin, red

1 - Telephone-muting (low frequency-mute)

3 - Telephone (low frequency +) (not for navigation equipment)

4 - Telephone (low frequency -) (not for navigation equipment)

5 - Navigation (low frequency +)

6 - Navigation (low frequency -)

7 - Navigation control wire

Multi-pin harness connectors on BOSE-amplifier

Note. Terminals which are not listed are vacant/unassigned.

Scheme 204

25-pin multi-pin harness connector

1 - Center speaker (-)

2 - Center speaker (+)

6 - Signal Ground -GND- (from Radio)

7 - Signal, rear right (from Radio)

8 - Signal, rear left (from Radio)

9 - Signal, front right (from Radio)

10 - Signal, front left (from Radio)

11 - Terminal 31

13 - Terminal 30

14 - Bass speaker (+), front

15 - Bass speaker (-), front

16 - Speaker (-) front left

17 - Speaker (+) front left

18 - Speaker (+) front right

19 - Speaker (-) front right

20 - Loudspeaker (+) rear left

21 - Loudspeaker (-) rear left

22 - Loudspeaker (+) rear right

23 - Loudspeaker (-) rear right

25 - Switched positive (from Radio)

Scheme 205

32-pin multi-pin harness connector

1 - Terminal 30

2 - Terminal 31

3 - Front loudspeaker (+)

4 - Loudspeaker (-) rear left

5 - Loudspeaker (+) rear right

6 - Switched positive (from Radio)

7 - Signal Ground -GND- (from Radio)

13 - Center speaker (+)

14 - Center speaker (-)

15 - Front loudspeaker (-)

16 - Loudspeaker (+) rear left

17 - Loudspeaker (-) rear right

19 - Signal, front left (from Radio)

20 - Signal, front right (from Radio)

21 - Signal, rear left (from Radio)

22 - Signal, rear right (from Radio)

26 - Speaker (-) front right

27 - Speaker (+) front right

31 - Speaker (+) front left

32 - Speaker (-) front left

Scheme 206

Multi-pin connectors on rear of "Concert II" radio

1 - Multi-pin connector IV, 10-pin, red

2 - Multi-pin connector I, 20-pin, black

3 - Radio fuse

4 - Multi-pin connector III, 8-pin, black

5 - Multi-pin connector II, 8-pin, brown

6 - IF-wire

1. Only for "Concert II" radio

7 - Antenna connection (high frequency wire)

Scheme 207

Multi-pin connectors on rear of "Symphony II" radio

1 - Multi-pin connector IV, 10-pin, red

2 - Multi-pin connector I, 20-pin, black

3 - Radio security device

4 - Multi-pin connector III, 8-pin, black

5 - Multi-pin connector II, 8-pin, brown

6 - IF wiring

7 - Antenna connection sockets for radio (high frequency wire)

Harness connector at Satellite Radio -R146

Note. Terminals which are not listed are vacant/unassigned.

Scheme 208

A - 8-pin harness connector

1 - CAN-Bus High (display)

2 - CAN-Bus Low (display)

3 - CD-IN L (CD changer)

4 - CD-IN R (CD changer)

5 - LF - Ground -GND- (Radio)

6 - LF - left (Radio)

7 - LF - right (Radio)

8 - CD-Ground -GND- (CD changer)

B - 8-pin harness connector

1 - Terminal 30

2 - Terminal 31

C - Antenna connection for satellite tuner (Terr. brown)

D - Antenna connection for satellite tuner (Sat. green)

"Concert ll" radio, removing and installing

Special Tools and Equipment

Scheme 209

1. T10057 radio removal tool

Removing

Scheme 210

1. Push the two clips of radio removal tool T10057 into the front of the radio.
2. Pull the radio out of the instrument panel.
3. Unplug the connectors and the antenna wire.
4. Pull out the release tool from the radio - to do this, press in the locking tabs on the radio.

Installing

1. Plug in the connectors and the antenna wire.
2. Carefully insert the radio into the instrument panel and let it engage in the installation slot.
3. Perform coding if the radio was replaced.

Do this using vehicle diagnostic, testing and information system VAS 5051.

"Symphony ll" radio, removing and installing

Special Tools and Equipment

1. T10057 radio removal tool

Removing

Scheme 211

1. Push the four clips of radio removal tool T10057 into the front.
2. Pull the radio out of the instrument panel.
3. Unplug the connectors and the antenna wire.
4. Pull out the release tool from the radio - to do this, press in the locking tabs at the top and bottom on the radio.

Installing

1. Plug in the connectors and the antenna wire.
2. Carefully insert the radio into the instrument panel and let it engage in the installation slot.
3. Perform coding if the radio was replaced.

Do this using vehicle diagnostic, testing and information system VAS 5051.

CD changer, removing and installing

Special Tools and Equipment

1. T10057 radio removal tool

Removing

1. Open glove compartment.

Scheme 212

1. Insert two hooks of T10057 radio removal tool into the front of the CD changer.
2. Pull the CD changer out of its installation slot.
3. Detach connector.
4. Pull out the release tool from the CD changer - to do this, press in the locking tabs on the CD changer.

Installing

1. Plug in the connector.
2. Slide the CD changer into the installation slot until it engages.
3. After installation, it is essential that the wiring is checked. Refer to «Check wire connection between radio and CD changer»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__check-wire-connection-between-radio-and) .

Check wire connection between radio and CD changer

1. Switch off radio.

"Concert II" radio

1. Press the CD button on the radio and switch on the radio at the same time.

"Symphony II" radio

1. Press the "4" button on the radio and switch on the radio at the same time, keeping the ON button pressed in.

All models

1. Wire connection OK

Indication on radio display

"CONNECT"

2. Wire connection not OK

Indication on radio display

"NO CDC"

1. Check electrical harness connector at CD changer.
2. Repeat wiring check and if not OK, check wiring connector according to wiring diagram.

Refer to Electrical Wiring Diagrams, Troubleshooting & Component Locations, Cabriolet

Satellite radio, removing and installing

Removing

1. Remove left side luggage compartment trim.

Refer to 70 - INTERIOR TRIM

Scheme 213

1. Remove bolts -arrows- (14 Nm) and remove base plate.

Scheme 214

1. Disconnect harness connectors from satellite radio -1-.

Adapter -2- remains in base plate -3-.

1. Press both catches -arrows- on adapter -2- upward and pull out satellite radio -1- in direction of arrow.

Installing

Installation is performed in reverse order of removal.

Speakers in front doors, removing and installing

Front bass speakers, removing and installing

Removing

1. Remove front door trim.

Refer to 70 - INTERIOR TRIM

Scheme 215

1. Unplug the connector -1-.
2. Remove bolts -arrows- at speaker -2- and remove speaker.

Installing

Installation is the reverse of removal, paying attention to the following

1. Hook retaining clip of speaker into installation opening.
2. Tighten speaker bolts to 2 Nm.

Front treble speaker, removing and installing

Removing

Scheme 216

1. Remove speaker cover at top of door from mirror base -arrow 1-.
2. Next, remove speaker cover upward from door trim -arrow 2-.

Scheme 217

1. Unplug the connector -1-.
2. Disengage clips -arrows- and remove treble speaker -2-.

Installing

Installation is the reverse of removal.

Speaker in side trim, rear, removing and installing

Special Tools and Equipment

Scheme 218

1. Special hook for front end 3370

Scheme 219

1. Using 3370 special hook, carefully remove cover -1- from retaining clips at rear side trim.

Scheme 220

1. Pry out center piece -1- of side trim at upper edge from rear side trim and remove.

Scheme 221

1. Remove bolts -arrows-.
2. Unplug the connector.
3. Remove speaker.

Installing

Installation is the reverse of removal, paying attention to the following

1. Tighten speaker bolts to 2 Nm.

Speaker in instrument panel, removing and installing

Special Tools and Equipment

Scheme 222

1. 80-200 pry lever

Treble speaker, front, removing and installing

Removing

Scheme 223

1. Using 80-200 pry lever, carefully pry off speaker cover -1- from instrument panel.

Scheme 224

1. Remove bolts -arrows- at speaker -1- and remove speaker.
2. Unplug the connector.

Installing

Installation is the reverse of removal, paying attention to the following

1. Tighten speaker bolts to 2 Nm.

Center treble speaker, removing and installing

Removing

Scheme 225

1. Carefully pry off cover -A- of photo sensor.
2. Remove bolt -B-.
3. Unplug the connector.
4. Remove defroster vent.

Scheme 226

1. Remove bolts -arrows-.
2. Swing speaker out and disconnect harness connector.

Installing

Installation is the reverse of removal, paying attention to the following

1. Tighten speaker bolts to 2 Nm.
2. Tighten bolt for defroster vent and photo sensor to 0.8 Nm.

Amplifier for the rear speakers or BOSE amplifier, removing and installing

Removing

1. Remove right side trim in luggage compartment.

Refer to 70 - INTERIOR TRIM

Scheme 227

1. Remove nuts -arrows- and remove retaining plate with amplifier -1-.
2. Unplug the connector.
3. If necessary, unbolt amplifier from retaining plate.

Installing

Installation is the reverse of removal, paying attention to the following

1. Tighten threaded connections of retaining plate.

Tightening torques

Scheme 228

1 - Central Locking and Anti-theft Alarm System Antenna -R47

2 - Satellite Tuner Antenna -R172

1. Removing and installing. See «Satellite tuner antenna, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__satellite-tuner-antenna-removing-and-installing)

3 - Right Antenna Module -R109

1. Removing and installing. See «Right Antenna Module -R109- removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__right-antenna-module-r109-removing-and)

4 - Antenna for Navigation System (GPS) -R50

5 - Left Antenna Module -R108

1. Removing and installing. See «Left Antenna Module -R108- removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__left-antenna-module-r108-removing-and)

Scheme 229

Left Antenna Module -R108- removing and installing

1. Remove rear lid trim.

Refer to 70 - INTERIOR TRIM

1. Unplug the connectors -2-.
2. Remove bolts -arrows- and remove left antenna module -1-.
3. Connect harness connectors according to the color coding.
4. Tighten threaded connections of antenna module to 3.5 Nm.

Scheme 230

Right Antenna Module -R109- removing and installing

1. Remove rear lid trim.

Refer to 70 - INTERIOR TRIM

1. Unplug the connector -2-.
2. Remove bolts -arrows- and remove right antenna module -1-.
3. Tighten threaded connections of antenna module to 3.5 Nm.

Scheme 231

Satellite tuner antenna, removing and installing

1. Remove rear lid trim.

Refer to 70 - INTERIOR TRIM

1. Disconnect harness connectors -3-.
2. Remove bolts -2- and remove base plate -1- with antenna.
3. Remove bolts -4- and remove antenna from base plate -1-.

Installation is performed in the reverse order of removal.

Navigation system IV

Note. Further measures after reconnecting power supply

Refer to

1. 24 MULTIPORT FUEL INJECTION (MFI) for 1.8 LITER 4-CYL. 5V TURBO FUEL INJECTION & IGNITION, ENGINE CODE(S): AMB
2. «24 - MULTIPORT FUEL INJECTION (MFI)»(ref-278889-S34101423592008020700000) for 2.0 LITER 4-CYL. 4V TURBO FUEL INJECTION IGNITION, ENGINE CODE(S): BPG, BWT
3. 24 MULTIPORT FUEL INJECTION (MFI) for 3.0 LITER 6-CYL. 5V FUEL INJECTION & IGNITION, ENGINE CODE(S): AVK, BGN
4. «24 - FUEL INJECTION SYSTEM»(ref-278893-S37153426882008020700000) for 3.2 V6 4V FUEL INJECTION IGNITION, ENGINE CODE(S): BKH
5. «24 - MULTIPORT FUEL INJECTION (MFI)»(ref-278897-S07807171762008020700000) for 4.2 LITER V8 4V FUEL INJECTION AND IGNITION, ENGINE CODE(S): BNS
6. «24 MULTIPORT FUEL INJECTION (MFI)»(ref-278895-S12545223132008020700000) for 4.2 LITER V8 5V FUEL INJECTION AND IGNITION, ENGINE CODE(S): BHF

General description

All displays appear on the instrument cluster which is connected via the CAN-bus.

All entries are made via buttons on multi-function switch.

A radio with speakers is necessary for voice output

The system consists of

1. Multi-function switch (operating unit)
2. Instrument cluster (display unit)
3. Control module for navigation with CD-mechanism (central unit and navigation unit)
4. GPS-antenna

Scheme 232

1 - Center loudspeaker

1. In instrument panel
2. Removing and installing. Refer to «Center treble speaker, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__center-treble-speaker-removing-and-installing)

2 - Radio -R

1. In center console
2. Removing and installing, starting on. Refer to «"Concert ll" radio, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__concert-ll-radio-removing-and-installing)

3 - Display in instrument cluster

1. Removing and installing instrument cluster

Refer to 90 INSTRUMENTS

4 - Function Selector Switch II -E272

1. In center console
2. Removing and installing. Refer to «Function Selector Switch II -E272-, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__function-selector-switch-ii-e272-removing)

5 - Amplifier -R12- for the rear speaker or BOSE amplifier (only for "BOSE sound system")

1. In luggage compartment, right rear behind side trim
2. Amplifier for the rear speakers or BOSE amplifier removing and installing. Refer to «Amplifier for the rear speakers or BOSE amplifier, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__amplifier-for-the-rear-speakers-or)

6 - Right Antenna Module -R109

1. Behind the rear lid trim
2. Removing and installing. Refer to «Antennas in rear lid - overview»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet)

7 - Navigation antenna (GPS) -R50

1. Behind the rear lid trim
2. Removing and installing. Refer to «Antennas in rear lid - overview»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet)

8 - Left Antenna Module -R108

1. Behind the rear lid trim
2. Removing and installing. Refer to «Antennas in rear lid - overview»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet)

9 - Control module for navigation with CD mechanism -J401

1. In left base mount in luggage compartment
2. Removing and installing. Refer to «Control module for navigation with CD-mechanism -J401-, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__control-module-for-navigation-with-cd-mechanism)

10 - Left Rear Speaker -R4-, Right Rear Speaker -R5

1. In rear side trim (bottom)
2. Speaker (active): Mid-range/bass with treble bridge
3. BOSE-speakers: Mid-range/bass
4. Removing and installing. Refer to «Removing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet)

11 - Treble speaker, left front -R20-, Treble speaker, right front -R22

1. In front door (top)
2. Removing and installing. Refer to «Front treble speaker, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__front-treble-speaker-removing-and-installing)

12 - Bass speaker, left front -R21-, Bass speaker, right front -R23

1. In front door trim (bottom)
2. Removing and installing. Refer to «Speakers in front doors, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__speakers-in-front-doors-removing-and)

13 - Left Front DSP Midrange Speaker -R103-, Right Front DSP Midrange Speaker -R104

1. In instrument panel
2. Removing and installing. Refer to «Speaker in instrument panel, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__speaker-in-instrument-panel-removing-and)

Scheme 233

1 - Control module for navigation with CD-mechanism (central unit and navigation unit)

1. In left base mount in luggage compartment

2 - Instrument cluster (display unit)

3 - Board computer function selector switch (operating unit)

1. In center console

4 - to the speakers activated for voice output

5 - Navigation antenna (GPS)

1. Behind the rear lid trim

Scheme 234

1 - GPS antenna connection

2 - Retainer bar for antenna connection

3 - Multi-pin connector I, 20-pin, black

4 - Fuse

5 - Multi-pin connector II, 8-pin, brown

6 - Multi-pin connector III, 8-pin, black

7 - Multi-pin connector IV, 10-pin, red

Multi-pin harness connectors I, II, III, and IV on reverse side of Control module for navigation with CD-mechanism -J401

Note. Unmentioned connector terminals are not assigned.

Multi-pin connector I, 20-pin

2 - CAN-Bus high (display)

5 - CAN-Bus low (display)

13 - low frequency + (voice output)

14 - Radio muting (output)

15 - low frequency - (voice output)

16 - Telephone low frequency (+)

17 - Telephone muting (input)

19 - Telephone low frequency (-)

Multi-pin connector II, 8-pin, brown

Not assigned

Multi-pin connector III, 8-pin, black

1 - Gala (RPM signal)

2 - Reverse light switch

3 - L diagnostic

4 - Terminal 15

7 - Terminal 30

8 - Terminal 31

Multi-pin connector IV, 10-pin, red

Not assigned

Function Selector Switch II -E272-, removing and installing

Removing

1. Pull up parking brake lever.

Scheme 235

1. Unclip cover -2- below the parking brake lever at mounting springs -1-.

Scheme 236

1. Grasp opening below parking brake lever and press Convertible Top Operation Switch/navigation out of center console from bottom -arrows-.

Scheme 237

1. Disconnect electrical harness connectors -3 to 6-.
2. Carefully release catches -arrows- using a small screwdriver.
3. Remove Function Selector Switch II position 1 from mounting frame -2-.

Installing

Installation is the reverse of removal.

Control module for navigation with CD-mechanism -J401-, removing and installing

Special Tools and Equipment

1. T10057 radio removal tool

Removing

1. Open lid in left luggage compartment side trim.

Scheme 238

1. Insert two hooks of T10057 radio removal tool into the front of Control module for navigation with CD drive -2-.

1. Top L - left top
2. Top R - right top

1. Pull Control module for navigation with CD-mechanism out of mounting frame -1-.
2. Disconnect electrical harness connectors and antenna wire at rear of control module for navigation with CD-mechanism.
3. Remove radio removal tool from control module for navigation with CD-mechanism, press locking latches at control module to do so.

Installing

Installation is the reverse of removal, paying attention to the following

Note. After installation of a new control module for navigation, the navigation must remain switched on for a specific time so that the system data of the respective satellites can be loaded. This procedure should be performed outdoors and can last up to 20 minutes. Only following this is the navigation useable.

Antennas in rear lid - overview

1 - Central Locking and Anti-theft Alarm System Antenna -R47

2 - Satellite Tuner Antenna -R172

1. Removing and installing. Refer to «Satellite tuner antenna, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet)

3 - Right Antenna Module -R109

1. Removing and installing. See «Right Antenna Module -R109-, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet)

4 - Navigation antenna (GPS) -R50

1. Removing and installing. See «Antenna for Navigation System (GPS) -R50-, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet__antenna-for-navigation-system-gps-r50)

5 - Left Antenna Module -R108

1. Removing and installing. See «Left Antenna Module -R108-, removing and installing»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet)

1. Remove rear lid trim.

Refer to 70 - INTERIOR TRIM

1. Unplug electrical connectors -2-.
2. Remove bolts -arrows- and remove left antenna module -1-.
3. Connect harness connectors according to the color coding.
4. Tighten connections of antenna module to 3.5 Nm.

1. Remove rear lid trim.

Refer to 70 - INTERIOR TRIM

1. Unplug electrical connector -2-.
2. Remove bolts -arrows- and remove right antenna module -1-.
3. Tighten connections of antenna module to 3.5 Nm.

Scheme 239

Antenna for Navigation System (GPS) -R50-, removing and installing

1. Remove rear lid trim.

Refer to 70 - INTERIOR TRIM

1. Unplug connector -1-.
2. Remove bolts -arrows- and remove GPS antenna -2-.
3. Tighten connections of GPS antenna to 3.5 Nm.

Removing

1. Remove rear lid trim.

Refer to 70 - INTERIOR TRIM

1. Disconnect harness connectors -3-.
2. Remove bolts -2- and remove base plate -1- with antenna.
3. Remove bolts -4- and remove antenna from base plate -1-.

Installing

Installation is performed in the reverse order of removal.

Steering Column Electronic Systems Control Module -J527

Note. Further measures after reconnecting power supply

Refer to

1. 24 MULTIPORT FUEL INJECTION (MFI) for 1.8 LITER 4-CYL. 5V TURBO FUEL INJECTION & IGNITION, ENGINE CODE(S): AMB
2. «24 - MULTIPORT FUEL INJECTION (MFI)»(ref-278889-S34101423592008020700000) for 2.0 LITER 4-CYL. 4V TURBO FUEL INJECTION IGNITION, ENGINE CODE(S): BPG, BWT
3. 24 MULTIPORT FUEL INJECTION (MFI) for 3.0 LITER 6-CYL. 5V FUEL INJECTION & IGNITION, ENGINE CODE(S): AVK, BGN
4. «24 - FUEL INJECTION SYSTEM»(ref-278893-S37153426882008020700000) for 3.2 V6 4V FUEL INJECTION IGNITION, ENGINE CODE(S): BKH
5. «24 - MULTIPORT FUEL INJECTION (MFI)»(ref-278897-S07807171762008020700000) for 4.2 LITER V8 4V FUEL INJECTION AND IGNITION, ENGINE CODE(S): BNS
6. «24 MULTIPORT FUEL INJECTION (MFI)»(ref-278895-S12545223132008020700000) for 4.2 LITER V8 5V FUEL INJECTION AND IGNITION, ENGINE CODE(S): BHF

Steering Column Electronic Systems Control Module -J527- is part of the complete system "steering column switch module" (SCSM). For example, it receives its signals from the steering column switch.

Use VAS 5051 tester to check Steering Column Electronic Systems Control Module -J527-.

Scheme 240

A - Cruise control system connector

1 - Ground (GND)

2 - Hold

3 - Distance

4 -12 V power supply

5 - Mount/Tip function "Off"

6 - Acceleration/Deceleration

7 - Engaged "Off"

B - Turn signal connector

1 - Ground (GND)

2 - Radio remote control (special vehicles)

3 - Alarm (special vehicles)

4 - Not used

5 - Headlight flasher/headlight switch

6 - Turn signal

C - Connector for multi-function steering wheel/tiptronic/heated steering wheel

7 - Push-button "-"

8 - Multi-function steering wheel "+"- power supply

9 - Multi-function steering wheel data

10 - Heat sensor/push - button "+"

11 - Multi-function steering wheel dimmer

12 - Tiptronic ground (GND)

13 - Steering wheel heating "+"

14 - Steering wheel heating "-"

D - Steering angle sensor

1 - Light barrier 5

2 - Light barrier 3

3 - Light barrier 1

4 -12 V voltage supply

5 - 5 V voltage supply

6 - Light barrier 6

7 - Light barrier 4

8 - Light barrier 2

9 - Steering angle sensor Ground (GND)

10 - Light barrier 7

E - Signal horn

1 - Horn Ground (GND)

2 - Horn

F - Wiper system

1 - Ground (GND)

2 - Wiper delay potentiometer

3 - Trip computer

4 - Not Used

5 - Washer

6 - Wipers

Terminal assignment at Steering Column Electronic Systems Control Module -J527- (rear)

Multi-pin connector, 16-pin

Scheme 241

1 - Ground (GND)

2 - Terminal 30

3 - Screening for CAN bus

4 - Not assigned

5 - Cruise Control System engages in Off position

6 - Alarm (special vehicles)

7 - Radio remote control (special vehicles)

8 - Comfort system databus Low

9 - Comfort system databus High

10 - Data bus drive (screened) High

11 - Data bus drive (screened) Low

12 - Ignition lock terminal 75

13 - Ignition lock terminal 15

14 - Ignition lock S-contact

15 - Ignition lock terminal 50

16 - Ignition lock terminal P

Multi-function steering wheel

Note. Further measures after reconnecting power supply

Refer to

1. 24 MULTIPORT FUEL INJECTION (MFI) for 1.8 LITER 4-CYL. 5V TURBO FUEL INJECTION & IGNITION, ENGINE CODE(S): AMB
2. «24 - MULTIPORT FUEL INJECTION (MFI)»(ref-278889-S34101423592008020700000) for 2.0 LITER 4-CYL. 4V TURBO FUEL INJECTION IGNITION, ENGINE CODE(S): BPG, BWT
3. 24 MULTIPORT FUEL INJECTION (MFI) for 3.0 LITER 6-CYL. 5V FUEL INJECTION & IGNITION, ENGINE CODE(S): AVK, BGN
4. «24 - FUEL INJECTION SYSTEM»(ref-278893-S37153426882008020700000) for 3.2 V6 4V FUEL INJECTION IGNITION, ENGINE CODE(S): BKH
5. «24 - MULTIPORT FUEL INJECTION (MFI)»(ref-278897-S07807171762008020700000) for 4.2 LITER V8 4V FUEL INJECTION AND IGNITION, ENGINE CODE(S): BNS
6. «24 MULTIPORT FUEL INJECTION (MFI)»(ref-278895-S12545223132008020700000) for 4.2 LITER V8 5V FUEL INJECTION AND IGNITION, ENGINE CODE(S): BHF

Function description

Six function buttons are integrated into the steering wheel for better operation of the radio system. In addition, the multi-function steering wheel is electrically heated (optional).

The electronics integrated in the steering wheel take over the transmission of the six function buttons to CAN-bus and dimming of the function buttons. On vehicles with automatic transmission, 2 additional buttons can be installed for Tiptronic shifting function. The electronics in the steering wheel cannot be replaced individually, the entire steering wheel must be replaced in case of a fault.

The multi-function steering wheel is part of the complete system "switch module-steering column (SMSC) and transmits its data to the Steering Column Electronic Systems Control Module -J527-.

Scheme 242

1 - Multi-function steering wheel

1. With integrated control switches
2. With steering wheel-integrated electronics

2 - Instrument cluster

3 - Radio

1. In center console

4 - Steering Column Electronic Systems Control Module -J527

1. Terminal assignment of Steering Column Electronic Systems Control Module -J527-. Refer to «Terminal assignment at Steering Column Electronic Systems Control Module -J527- (front)»(/audi/a4/b6-2000-2006/remont/accessories-control-systems/#communication-cabriolet)

Operating switch on multi-function steering wheel, removing and installing

Removing

1. Remove driver's side airbag unit.

Refer to 69 - PASSENGER PROTECTION - AIRBAGS, SEAT BELTS

Scheme 243

1. Remove bolts -3-.
2. Unplug the connector -4-.
3. Slide operating switch -1- out of airbag unit -2- toward front.

Installing

Installation is the reverse of removal, paying attention to the following

Note. When installing, make sure the connecting wires of connector -4- are reinserted into the guides.

1. Tighten bolts -3- of operating switch to 1.1 Nm.

See also:
• 70 - INTERIOR TRIM
• CD changer, removing and installing
• Check wire connection between radio and CD changer
• Center treble speaker, removing and installing
• "Concert ll" radio, removing and installing
• "Symphony ll" radio, removing and installing
• Amplifier for the rear speakers or BOSE amplifier, removing and installing
• Antennas in rear lid - overview
• Removing
• Front treble speaker, removing and installing
• Speakers in front doors, removing and installing
• Speaker in instrument panel, removing and installing
• Satellite radio, removing and installing
• Satellite tuner antenna, removing and installing
• Right Antenna Module -R109- removing and installing
• Left Antenna Module -R108- removing and installing
• Function Selector Switch II -E272-, removing and installing
• Control module for navigation with CD-mechanism -J401-, removing and installing
• Antenna for Navigation System (GPS) -R50-, removing and installing
