SUBFRAME MOUNT, CHECKING ADJUSTMENT

Check following dimensions at engine/right transmission mounting

Scheme 428

Scheme 428: SUBFRAME MOUNT, CHECKING ADJUSTMENT
Scheme 428: SUBFRAME MOUNT, CHECKING ADJUSTMENT
  1. Both bolts -2- must be parallel to edge of support arm -3-.
  2. A distance of -x- = 16 mm must be present between engine mount -1- and engine support -4-.

Note. Distance -x- = 16 mm can also be checked with a suitable cylindrical rod.

If dimension is too small or large, engine mount must be adjusted. Refer to SUBFRAME MOUNT, ADJUSTING .
