FASTENER TIGHTENING SPECIFICATIONS
| Component | Bolt Size | Nm |
|---|
| Bolts/Nuts |
| M6 | 10 |
| M7 | 15 |
| M8 | 22 |
| M10 | 40 |
| M12 | 65 |
| Bracket to engine mount 1 | | 20 + 90° |
| Engine Mount 1, 2 |
| | 40 + 90° |
| | 60 + 90° |
| Engine Support 1 | | 40 Nm +180° |
| 1 Always replace 2 For bolt tightening clarification, refer to SUBFRAME ASSEMBLY OVERVIEW and see items -6, 10 and 11 |
Secures the Manual Transmission to the Engine
Scheme 341
| Item | Bolt | Nm |
|---|
| 1, 2 | M12x65 | 80 |
| 3 1)2) | M12x150 | 80 |
| 4 1)2) | M12x165 | 80 |
| 5 | M10x50 | 40 |
| 6 | M12x85 | 80 |
| A | Alignment sleeves for centering |
| 1) Bolt with threaded Pin M8. 2) Also starter to transmission. |
Mounting, Automatic Transmission to Engine
Scheme 342
| Item | Bolt | Nm |
|---|
| 1, 3, 10 | M12x55 | 80 |
| 5, 9 | M12x70 | 80 |
| 6, 7, 8 | M10x50 | 40 |
| A | Alignment sleeves for centering |
| Bolts -2 and 4- : secures the starter to the transmission. Refer to REMOVAL AND INSTALLATION . |
