ENGINE, SECURING ON ASSEMBLY STAND
Special tools and workshop equipment required
- Engine Sling 2024 A
- Shop Crane VAS 6100
- Engine and Transmission Holder VAS 6095
- Engine-/Gearbox Jack V.A.G 1383 A
Procedure
- The transmission is separated from the engine. Refer to «ENGINE AND MANUAL TRANSMISSION, SEPARATING»(ref-496115-S07389129922012082100000) or «ENGINE AND AUTOMATIC TRANSMISSION, SEPARATING»(ref-496115-S32706291682012082100000) .
Remove the engine cover.
Hook 2024 A to engine and to VAS 6100.
Scheme 343
Note. To be aligned to the center of gravity of the engine assembly, the hole rails of the lifting Hook must be inserted as shown in the illustration.
| WARNING | Loose engine Support bridge components could cause an accident. Secure the mounting Hooks and Pins on the engine Support bridge using securing Pins -arrows-. |
Lower the engine from the engine/transmission jack V.A.G 1383 A using the VAS 6100.
Secure the transmission side of the engine to the VAS 6095 as illustrated.
