Bumpers — Acura ZDX I (2009-2013)

Scheme 32

Scheme 32: Front

Scheme 33

Scheme 33: Rear

Front Bumper Removal/Installation

Note. Have an assistant help you when removing and installing the front bumper. Put on gloves to protect your hands. Take care not to scratch the front bumper or the body. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage.

Scheme 34

Scheme 34: Front Bumper Removal/Installation

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Remove the front bulkhead cover (see «FRONT BULKHEAD COVER REPLACEMENT»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#exterior-trim__front-bulkhead-cover-replacement) ).
Remove the bolts (A, B, C), the screws (D), and the clips (E, F, G) securing the front bumper (H). NOTE: To release the clips E, pry up on the center pin at the notch (I).
Release the front bumper strake (A) from the front air guide plate (B) on both sides.
Pull out the front bumper (A) at both wheel arch areas to release it from the hooks (B) on both side spacers (C).
With the help of an assistant, pull both sides of the front bumper (A) away from the side spacers (B). Then pull out the bumper to release the hooks (C) from the upper beams (D).
Remove the front bumper (A). While holding up the bumper with the help of an assistant, disconnect the fog light connectors (B). For some models: Disconnect the headlight washer tube (C). Release the projection (D).
If necessary, release the hooks (A), then remove the front bumper absorber (B) from the front bumper beam (C).
Install the bumper in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Make sure each connector is plugged in properly, and if equipped, the headlight washer tube is connected properly. Make sure the front bumper engages the hooks (on the upper beams and the side spacers) on each side securely. Push the clips and the hooks into place securely.

Front Bumper Lower Mesh Replacement

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Take care not to scratch the front bumper. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage.

Scheme 40

Scheme 40: Front Bumper Lower Mesh Replacement

Scheme 41

Remove the fog light (see «FOG LIGHT REPLACEMENT»(/acura/zdx/i-2009-2013/remont/exterior-lights/#exterior-lights) ).
For some models: Remove the headlight washer tube as needed (see «HEADLIGHT WASHER»(/acura/zdx/i-2009-2013/remont/wiperwasher-systems/#wiper-system-washer-system) ).
Remove the screws from back of the front bumper (A), and release the hooks (B) (nine places) and the tabs (C), then remove the front bumper lower mesh (D) and the front bumper lower housing (E) as an assembly.
Release the hooks (A) (10 places), then remove the front bumper lower mesh (B) from the front bumper lower housing (C).
Install the lower mesh in the reverse order of removal, and push the hooks and the tabs into place securely.

Rear Bumper Removal/Installation

Note. Have an assistant help you when removing and installing the rear bumper. Put on gloves to protect your hands. Take care not to scratch the rear bumper or the body. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage.

Scheme 42

Scheme 42: Rear Bumper Removal/Installation

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Remove the taillight (see «TAILLIGHT REPLACEMENT»(/acura/zdx/i-2009-2013/remont/exterior-lights/#exterior-lights) ).
From the rear wheel arches on both sides, remove the screws securing the rear bumper (A).
Remove the caps (A). Remove the bolts (B) and clips (C, D) securing the rear bumper (E).
Pull on the rear bumper (A) at both wheel arch areas to release it from the hooks (B) on both side spacers (C).
With the help of an assistant, pull out the rear bumper (A) to release the bumper from the hooks (B) on the upper brackets (C).
If necessary, release the hooks (A), then remove the rear bumper spacer (B) from the rear bumper (C).
Install the bumper in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Make sure the rear bumper engages the hooks (of both the side spacers) on each side securely. Push the clips and the hooks into place securely.

Rear Bumper Lower Face Replacement

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Take care not to scratch the rear bumper. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage.

Scheme 47

Scheme 47: Rear Bumper Lower Face Replacement

Remove the rear bumper (see «REAR BUMPER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#bumpers__rear-bumper-removalinstallation) ).
Remove the bolts and the clips. Pry up the hooks (A) (14 places) with a trim tool, then remove the rear bumper lower face (B) from the rear bumper (C).
Install the lower face in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips and the hooks into place securely.

Rear Bumper Finisher Replacement

Note. Put on gloves to protect your hands. Take care not to scratch the rear bumper.

Scheme 48

Scheme 48: Rear Bumper Finisher Replacement

Remove the rear bumper (see «REAR BUMPER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#bumpers__rear-bumper-removalinstallation) ).
Remove the nuts, then remove the rear bumper finisher (A) from the rear bumper (B).
Install the finisher in the reverse order of removal.

Rear Bumper Reflector Replacement
