Oem Fuse/relay Boxes — Acura ZDX I (2009-2013)

Fuse-to-Components Index

Fuse Number	Fuse Name	Amps	See	Component or Circuit Protected	Notes
1	AVS BSI	7.5A	POWER DISTRIBUTION	BSI Control Unit (BSI), Driver's Seat Ventilation Switch (Ventilated Seats), Front Passenger's Seat Ventilation Switch (Ventilated Seats), Left BSI Radar Unit (BSI), Multi Switch (Park Assist), Park Assist Unit (Park Assist), Right BSI Radar Unit (BSI), Ventilation Seat Control Unit (Ventilated Seats)	BSA, Park Assist, Ventilated Seats
2	SH-AWD	7.5A	POWER DISTRIBUTION	ACC Unit (ACC), Active Damper Control Unit (IDS), Brake Light Relay (ACC), ECPS Control Unit (IDS), E-Pretensioner Unit (ACC), Millimeter Wave Radar (ACC), SH-AWD Control Unit
3	WASHER	20A	POWER DISTRIBUTION	Windshield Washer Relay
4	WIPER	7.5A	POWER DISTRIBUTION	Windshield Wiper Relay
5	ODS	7.5A	POWER DISTRIBUTION	Hazard Warning Switch/Passenger's Airbag Cutoff Indicator (USA, Canada), ODS Unit, SRS Unit
6	VSA	7.5A	POWER DISTRIBUTION	Steering Angle Sensor, VSA Modulator-Control Unit, Yaw Rate-Accelerator Sensor
7			POWER DISTRIBUTION	Not Used
8	STRLD	7.5A	POWER DISTRIBUTION	PCM
9	FUEL PUMP	20A	POWER DISTRIBUTION	Electronic Steering Lock (Keyless Access), Fuel Pump Relay, Immobilizer-Keyless Control Unit (without Keyless Access), Keyless Access Control Unit (Keyless Access), PCM, Remote Slot Control Unit (Keyless Access)
10	VB SOL	10A	POWER DISTRIBUTION	PCM
11	SRS	10A	POWER DISTRIBUTION	SRS Unit
12	METER	7.5A	POWER DISTRIBUTION	A/T Gear Position Indicator Panel, A/T Reverse Relay, AcuraLink Control Unit (XM Receiver) (AcuraLink), Driver's MICU, Gauge Control Module, Integrated Dynamics System Switch (IDS), Passenger's MICU, Power Mirror Control Unit, Power Seat Control Unit, Power Tailgate Control Unit, Power Tilt/Telescopic Steering Control Unit, TPMS Control Unit
13	ACG	15A	POWER DISTRIBUTION	Alternator, Brake Pedal Position Switch, ELD Unit, Engine Mount Control Solenoid Valve, EVAP Canister Purge Valve, PCM
14			POWER DISTRIBUTION	Not Used

Drivers Under-Dash Fuse/Relay Box (6-1). Scheme 360

Scheme 360: Drivers Under-Dash Fuse/Relay Box (6-1)

Fuse Number	Fuse Name	Amps	See	Component or Circuit Protected	Notes
15	DRL	7.5A	POWER DISTRIBUTION	Driver's MICU
16	A/C	7.5A	POWER DISTRIBUTION	A/C Compressor Clutch Relay, A/C Condenser Fan Relay, Audio and HVAC Switch Panel (without Navigation), Audio-Navigation and HVAC Switch Panel (Navigation), Automatic Dimming Inside Mirror, Blower Motor Relay, Climate Control Unit, Driver's Seat Heater Switch (without Ventilated Seats), Fan Control Relay, Front Passenger's Seat Heater Switch (without Ventilated Seats), Left Rear Seat Heater Switch (Rear Seat Heaters), Power Mirror Switch, Power Window Master Switch, Rear Window Defogger Relay, Right Rear Seat Heater Switch (Rear Seat Heaters), Seat Ventilation Relay (Ventilated Seats)
17	ACC KEY	(7.5A)	POWER DISTRIBUTION	Driver's MICU	Without Keyless Access
18	ACC	7.5A	POWER DISTRIBUTION	AcuraLink Control Unit (XM Receiver) (AcuraLink), Audio and HVAC Switch Panel (without Navigation), Audio-Navigation and HVAC Switch Panel (Navigation), Audio-Navigation Unit (Navigation), Audio Unit (without Navigation), Console Accessory Power Socket Relay, Driver's MICU (Keyless Access), Front Accessory Power Socket Relay, Front HFL-ANC/Active Sound Control Microphone (without Navigation), Front HFL-Navigation-ANC/ Active Sound Control Microphone (Navigation), HandsFreeLink Control Unit, Interface Dial (Navigation), Keyless Access Control Unit (Keyless Access), Navigation Display Unit (Navigation), Remote Slot Control Unit (Keyless Access)
19	DR P/SEAT (SLIDE)	20A	POWER DISTRIBUTION	Power Seat Control Unit
20	SUNROOF	20A	POWER DISTRIBUTION	Panoramic Glass Roof Control Unit/Motor Unit
21	DR P/SEAT (REC)	20A	POWER DISTRIBUTION	Power Seat Control Unit
22	P/W REAR L	20A	POWER DISTRIBUTION	Left Rear Power Window Relay
23	FR ACC SOCKET	15A	POWER DISTRIBUTION	Console Accessory Power Socket Relay
24	P/W DR	20A	POWER DISTRIBUTION	Power Window Master Switch
25	DOOR LOCK DR	(15A)	POWER DISTRIBUTION	Driver's Door Unlock Relay, Door Lock Relay, Door Unlock Relay
26	FR FOG L	10A	POWER DISTRIBUTION	Driver's MICU
27	SMALL (EXTRA) L	10A	POWER DISTRIBUTION	Driver's MICU
28	H/L DRL L	10A	POWER DISTRIBUTION	Driver's MICU
29	TPMS	7.5A	POWER DISTRIBUTION	TPMS Control Unit
30	H/LL	15A	POWER DISTRIBUTION	Driver's MICU
31				Not Used

Drivers Under-Dash Fuse/Relay Box (6-3). Scheme 361

Scheme 361: Drivers Under-Dash Fuse/Relay Box (6-3)

Connector-to-Fuse/Relay Box Index

Ref	Socket	Cavities	Connects to	Notes
1	A		Not Used
2	B		Not Used
3	C	5	Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) )
4	Accessory Relay	4		Keyless Access without Keyless Access
4	Console Accessory Power Socket Relay	4
5	Starter Cut Relay 1	4
6	K (MICU Service Check Connector)	3
7	H (Option Connector)	12	PCM
8	G	13	Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS )
9	F	33	Left Engine Compartment Wire Harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS )
10	E	20	Floor Wire Harness (see FLOOR WIRE HARNESS (LEFT BRANCH) )
11	D	16	Floor Wire Harness (see FLOOR WIRE HARNESS (LEFT BRANCH) )
12	Fuel Pump Relay	4
13	M	4	Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) )
14	N	16	Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) )
15	P	20	Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) )
16	R	24	Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) )
17	Q	20	Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) )

Drivers Under-Dash Fuse/Relay Box (6-5). Scheme 362

Scheme 362: Drivers Under-Dash Fuse/Relay Box (6-5)

Fuse Number	Fuse Name	Amps	See	Component or Circuit Protected	Notes
1	H/L DRL R	10A	POWER DISTRIBUTION	Passenger's MICU
2	SMALL (EXTRA) R	10A	POWER DISTRIBUTION	Passenger's MICU
3	FR FOG R	10A	POWER DISTRIBUTION	Passenger's MICU
4	H/L R	15A	POWER DISTRIBUTION	Passenger's MICU
5			POWER DISTRIBUTION	Not Used
6	SMALL (INTR)	7.5A	POWER DISTRIBUTION	ACC Combination Switch/Distance Switch (ACC), A/T Gear Position Indicator Panel Light, Audio and HVAC Switch Panel (without Navigation), Audio-HVAC Display Unit (without Navigation), Audio-Navigation and HVAC Switch Panel (Navigation), Audio Remote Switch, Climate Control Unit, Console Box Light, Cruise Control Combination Switch (without ACC), Dashlights Brightness Controller Switch, Door Inner Handle Lights (Inner Handle Lights), Driver's Footwell Light, Driver's Seat Heater Switch (without Ventilated Seats), Driver's Seat Ventilation Switch (Ventilated Seats), Front Passenger's Airbag Cutoff Indicator (Ventilated Seats), Front Passenger's Footwell Light, Front Passenger's Seat Heater Switch (without Ventilated Seats), Front Passenger's Seat Ventilation Switch (Ventilated Seats), Glove Box Light, Hazard Warning Switch, Integrated Dynamics System Switch, Left Rear Seat Heater Switch (Rear Seat Heaters), Multi Switch, Panoramic Glass Roof/Sunshade Switch, Paddle Shifter +, Paddle Shifter -, Power Mirror Switch, Rear Individual Map Light, Right Rear Seat Heater Switch (Rear Seat Heaters), Roof Console, Seat Ventilation Control Unit (Ventilated Seats)
7			10	Not Used
8	AS P/SEAT (REC)	20A	10	Front Passenger's Power Seat Adjustment Switch (Recline Motor and Rear Up-down Motor)
9	AS P/SEAT (SLIDE)	20A	10	Front Passenger's Power Seat Adjustment Switch (Front Up-down Motor and Slide Motor)
10	DOOR LOCK R	10A	10	Door Lock Relay, Door Unlock Relay
11	P/W REAR R	20A	10	Right Rear Power Window Relay
12	SMART	10A	10	Electric Steering Lock, Engine Start/Stop Switch, Power Control Unit, Remote Slot, Remote Slot Control Unit	Keyless Access
13	P/W AS	20A	10	Front Passenger's Power Window Switch
14		7.5A	POWER DISTRIBUTION	Not Used (Passenger's MICU)
15	AMP	20A	POWER DISTRIBUTION	Stereo Amplifier
16	CONSOLE ACC SOCKET	15A	POWER DISTRIBUTION	Console Power Socket Relay
17			POWER DISTRIBUTION	Not Used
18	LUMBAR	7.5A	POWER DISTRIBUTION	Driver's Power Lumbar Support Switch
19	AS SEAT HEATER	20A	POWER DISTRIBUTION	Driver's Seat Heater Relays (without Ventilated Seats), Front Passenger's Seat Heater Relays (without Ventilated Seats), Seat Ventilation Relay (Ventilated Seats)
20			10	Not Used
21			10	Not Used
22			POWER DISTRIBUTION	Not Used

Passengers Under-Dash Fuse/Relay Box (6-7). Scheme 363

Scheme 363: Passengers Under-Dash Fuse/Relay Box (6-7)

Ref	Socket	Cavities	Connects to
1	A	38	Dashboard Wire Harness (see DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE) )
2	D	28	Audio Wire Harness (see AUDIO WIRE HARNESS )
3	G	16	Not Used
4	H	38	Floor Wire Harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) )
5	F	2	Right Engine Compartment Wire Harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS )
6	E	18	Right Engine Compartment Wire Harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS )
7	C	12	Not Used
8	B	1	Right Engine Compartment Wire Harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS )

Passengers Under-Dash Fuse/Relay Box (6-9). Scheme 364

Scheme 364: Passengers Under-Dash Fuse/Relay Box (6-9)

Fuse Number	Fuse Name	Amps	See	Component or Circuit Protected	Notes
1	BATTERY	120A	POWER DISTRIBUTION	Battery, Power Supply
1	AS F/B STD	40A	POWER DISTRIBUTION	Fuses 8, 9, 10, 11, 12, and 13 in the Passenger's Under-dash Relay Box
2		70A	POWER DISTRIBUTION	Not Used
		40A	POWER DISTRIBUTION	Not Used	Canada, Mexico
	H/L WASHER	30A	POWER DISTRIBUTION	Headlight Washer Relay
	AS F/B OPTION	40A	POWER DISTRIBUTION	Fuses 15, 16, 17, 18, and 19 in the Passenger's Under-dash Fuse/Relay Box
	EPT R	30A	POWER DISTRIBUTION	E-Pretensioner Unit	ACC
	EPT L	30A	POWER DISTRIBUTION	E-Pretensioner Unit	ACC
3	IG MAIN	50A	POWER DISTRIBUTION	Ignition Switch (without Keyless Access), Power Control Unit (Keyless Access), Starter Cut Relay 1, Starter Cut Relay 2
	SUB FAN MOTOR	40A	POWER DISTRIBUTION	A/C Condenser Fan Relay
		50A	POWER DISTRIBUTION	Not Used
	DR F/B STD	60A	POWER DISTRIBUTION	Fuses 19, 20, 21, 22, 23, 24, and 25 in the Driver's Under-dash Fuse/Relay Box
	MAIN FAN MOTOR	40A	POWER DISTRIBUTION	Radiator Fan Relay
	DR LIGHT MAIN	30A	POWER DISTRIBUTION	Fuses 26, 27, 28, 29, and 30 in the Driver's Under-dash Fuse/Relay Box
	WIPER MOTOR	30A	POWER DISTRIBUTION	Windshield Wiper Relay
		30A	POWER DISTRIBUTION	Not Used
4	HEATER MOTOR	40A	POWER DISTRIBUTION	Blower Motor Relay
5	AS LIGHT MAIN	30A	POWER DISTRIBUTION	Fuses 1, 2, 3, and 4 in the Passenger's Under-dash Fuse/Relay Box
6			POWER DISTRIBUTION	Not Used
7			POWER DISTRIBUTION	Not Used
8	RR DEFROSTER	40A	POWER DISTRIBUTION	Rear Window Defogger Relay
9	TRAILER TURN/STOP	7.5A	POWER DISTRIBUTION	Optional Connector for Trailer
10	STOP & HORN	15A	POWER DISTRIBUTION	Brake Light Relay, Brake Pedal Position Switch, Horn Relay
11	TRAILER SMALL	7.5A	POWER DISTRIBUTION	Optional Connector for Trailer
12	ADS	30A	POWER DISTRIBUTION	Active Damper Control Unit	IDS
13	IG COIL	15A	POWER DISTRIBUTION	Ignition Coil Relay

Under-Hood Fuse/Relay Box (6-11). Scheme 365

Scheme 365: Under-Hood Fuse/Relay Box (6-11)

Fuse Number	Fuse Name	Amps	See	Component or Circuit Protected	Notes
14	FI SUB	15A	POWER DISTRIBUTION	PGM-FI Sub-Relay, Fuse 21 in the Under-hood Fuse/Relay Box
15	BACK UP	10A	POWER DISTRIBUTION	ACC Unit (ACC), AcuraLink Control Unit (XM Receiver) (AcuraLink), ANC/Active Sound Control Unit, Audio and HVAC Switch Panel (without Navigation), Audio Display Unit (without Navigation), Audio-Navigation and HVAC Switch Panel (Navigation), Audio-Navigation Unit (Navigation), Audio Unit (without Navigation), DLC, Door Courtesy Lights, Driver's MICU, Front HFL-Navigation-ANC/Active Sound Control Microphone, Gauge Control Module, HandsFreeLink Control Unit, Immobilizer-Keyless Control Unit (without Keyless Access), Keyless Access Control Unit (Keyless Access), Navigation Display Unit (Navigation), Passenger's MICU, Power Control Unit (Keyless Access), Power Mirror Control Unit, Power Seat Control Unit, Power Tailgate Control Unit, Power Tilt/Telescopic Steering Control Unit, Power Window Master Switch, Remote Slot Control Unit (Keyless Access)
16	INTR LT	7.5A	POWER DISTRIBUTION	Ignition Key Switch (without Keyless Access), Optional Running Board Lights, Power Tailgate Inside Switch, Rear Individual Map Light, Roof Console, Tailgate Light, Vanity Mirror Lights
17	FI MAIN	15A	POWER DISTRIBUTION	Fuel Pump Relay, PGM-FI Main Relay
18	DBW	15A	POWER DISTRIBUTION	ETCS Control Relay
19	WOOFER	15A	POWER DISTRIBUTION	Subwoofer	Navigation
20	MG CLUTCH	7.5A	POWER DISTRIBUTION	A/C Compressor Clutch Relay
21	BAD FAN TIMER	7.5A	POWER DISTRIBUTION	A/C Diode B, Radiator Fan Relay

Under-Hood Fuse/Relay Box (6-13). Scheme 366

Scheme 366: Under-Hood Fuse/Relay Box (6-13)

Ref	Socket	Cavities	Connects to	Notes
1	Rear Window Defogger Relay	4
2	A/C Condenser Fan Relay	4
3	PGM-FI Main Relay	4
4	PGM-FI Sub-Relay	4
5	Ignition Coil Relay	4
6	ETCS Control Relay	4
7	Headlight Washer Relay	4		Canada, Mexico
8	Blower Motor Relay	4
9	T1		Starter Cable (see CONNECTOR TO HARNESS INDEX )
10	T101		Engine Wire Harness (see ENGINE WIRE HARNESS (ENGINE SECTION) )
11	A (ELD Unit)	3	Right Engine Compartment Wire Harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS )
12	C	5	Right Engine Compartment Wire Harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS )
13	B	14	Right Engine Compartment Wire Harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS )
14	Relay Circuit Board		Connector B (14 pins), Connector C (5 pins)
15	A/C Compressor Clutch Relay	4

Under-Hood Fuse/Relay Box (6-15). Scheme 367

Scheme 367: Under-Hood Fuse/Relay Box (6-15)

Fuse Number	Fuse Name	Amps	See	Component or Circuit Protected	Notes
1	VSA	40A	POWER DISTRIBUTION	VSA Modulator-Control Unit
2	VSA	20A	POWER DISTRIBUTION	VSA Modulator-Control Unit
3			POWER DISTRIBUTION	Not Used
4			POWER DISTRIBUTION	Not Used
5	SVTM-4	30A	POWER DISTRIBUTION	SH-AWD Relay
6	PTG	40A	POWER DISTRIBUTION	Power Tailgate Control Unit
7	ETS	20A	POWER DISTRIBUTION	Power Tilt/Telescopic Steering Control Unit
8	ETS	20A	POWER DISTRIBUTION	Power Tilt/Telescopic Steering Control Unit
9	F/B DR, HAZ SW	15A	POWER DISTRIBUTION	Driver's MICU, Hazard Warning Switch
10	H/L HI/LO SOL	7.5A	POWER DISTRIBUTION	Headlight High/Low Beam Switching Solenoid Relay
11	BATTERY	7.5A	POWER DISTRIBUTION	Battery Sensor
12	F/B DR	(7.5A)	POWER DISTRIBUTION	Accessory Relay	Keyless Access
13	RR/SEAT	(20A)	POWER DISTRIBUTION	Rear Seat Heater Relays	Rear Seat Heaters
14	S/R	20A	POWER DISTRIBUTION	Power Sunshade Control Unit/Motor
15	PTG	20A	POWER DISTRIBUTION	Power Tailgate Control Unit
16			POWER DISTRIBUTION	Not Used
17			POWER DISTRIBUTION	Not Used
18			POWER DISTRIBUTION	Not Used
19			POWER DISTRIBUTION	Not Used
20			POWER DISTRIBUTION	Not Used
21			POWER DISTRIBUTION	Not Used
22			POWER DISTRIBUTION	Not Used

Auxiliary Under-Hood Fuse/Relay Box (6-17). Scheme 368

Scheme 368: Auxiliary Under-Hood Fuse/Relay Box (6-17)

Ref	Socket	Cavities	Connects to	Notes
1	T5		Starter Cable
2	Starter Cut Relay 2	5
3	Brake Light Relay	5		ACC
4	Headlight High/Low Beam Switching Solenoid Relay	4

Auxiliary Under-Hood Fuse/Relay Box (6-17). Scheme 369

Scheme 369: Auxiliary Under-Hood Fuse/Relay Box (6-17)
