Connector Index
Identification numbers have been assigned to in-line connectors, junction connectors, and terminals. The number is preceded by the letter "C" for connectors, "G" for ground terminals, "T" for non-ground terminals, or "S" for thermal joints.
| Harness | Location | |||
|---|---|---|---|---|
| Engine Compartment | Dashboard | Others (Floor, Door, Tailgate, Steering Wheel, and Roof) | Notes | |
| A/C Wire Harness | C201, C408, C501 | Connector to Harness (see A/C Wire Harness ) | ||
| Audio wire harness | C405, C406, C407, C501 through C509 G501, G502 | Connector to Harness (see Audio Wire Harness ) | ||
| Battery ground cable | (-), G1 | Connector to Harness (see Battery Ground Cable ) | ||
| Cable reel subharness | T6 | Connector to Harness (see Cable Reel Subharness ) | ||
| Console light subharness | C471 | Connector to Harness (see Console Light Subharness ) | ||
| Console subharness | C409, C410, C471 | Connector to Harness (see Console Subharness ) | ||
| Dashboard wire harness (view of driver's side) | C301, C302, C401 through C404, C751, C752 G401, G402 | Connector to Harness (see Dashboard Wire Harness (View of Driver's Side) ) | ||
| Dashboard wire harness (view of middle to passenger's side) | C206, C207, C405 through C413, C421, C422, C423, C761, C762 G403, G404, G405 | Connector to Harness (see Dashboard Wire Harness (View of Middle to Passenger's Side) ) | ||
| Driver's door power mirror wire harness | C755 | Connector to Harness (see Driver's Door Power Mirror Wire Harness ) | ||
| Driver's door subharness | C753, C754, C755 | Connector to Harness (see Driver's Door Subharness ) | ||
| Driver's door wire harness | C751, C752 | C753, C754 | Connector to Harness (see Driver's Door Wire Harness ) | |
| Driver's seat wire harness (with seat ventilation) | C601 | Connector to Harness (see Driver's Seat Wire Harness (With Seat Ventilation) ) | ||
| Driver's seat wire harness (without seat ventilation) | C601 | Connector to Harness (see Driver's Seat Wire Harness (Without Seat Ventilation) ) | ||
| ECT sensor subharness | C351 | Connector to Harness (see ECT Sensor Subharness ) | ||
| Engine ground cable | T2, G2 | Connector to Harness (see Engine Ground Cable ) | ||
| Engine wire harness (engine section) | C101 through C106, C151 T101, T102, G101 | Connector to Harness (see Engine Wire Harness (Engine Section) ) | ||
| Engine wire harness (transmission section) | Connector to Harness (see Engine Wire Harness (Transmission Section) ) | |||
| Floor wire harness (left branch) | C303, C304, C401, C402 G601 | C601, C604, C606, C608, C609, C610, C651, C701, C771, C801, C802 G602, G603, G604 | Connector to Harness (see Floor Wire Harness (Left Branch) ) | |
| Floor wire harness (right branch) | C208, C209, C413, C508, C509 | C411, C412, C602, C603, C605, C607, C652, C781 G651, G652 | Connector to Harness (see Floor Wire Harness (Right Branch) ) | |
| Front passenger's door power mirror wire harness | C764 | Connector to Harness (see Front Passenger's Door Power Mirror Wire Harness ) | ||
| Front passenger's door subharness | C763, C764 | Connector to Harness (see Front Passenger's Door Subharness ) | ||
| Front passenger's door wire harness | C761, C762 | C763 | Connector to Harness (see Front Passenger's Door Wire Harness ) | |
| Front passenger's seat wire harness | C602 | Connector to Harness (see Front Passenger's Seat Wire Harness ) | ||
| Knock sensor subharness | C151 | Connector to Harness (see Knock Sensor Subharness ) | ||
| Left engine compartment wire harness | C102, C351, C361 G301, G302, G303 | C202, C203, C204, C205, C301 through C305 | Connector to Harness (see Left Engine Compartment Wire Harness ) | |
| Left front damper subharness (with integrated dynamics system) | C361 | Connector to Harness (see Left Front Damper Subharness (With Integrated Dynamics System) ) | ||
| Left rear damper subharness (with integrated dynamics system) | C609 | Connector to Harness (see Left Rear Damper Subharness (With Integrated Dynamics System) ) | ||
| Left rear door wire harness | C771 | Connector to Harness (see Left Rear Door Wire Harness ) | ||
| Left taillight wire harness | C651 | Connector to Harness (see Left Taillight Wire Harness ) | ||
| Rear seat heater switch subharness (with rear seat heater) | C603 | Connector to Harness (see Rear Seat Heater Switch Subharness (With Rear Seat Heater) ) | ||
| Rear subframe wire harness | C608 T7 | Connector to Harness (see Rear Subframe Wire Harness ) | ||
| Rear wire harness | C701 G701 | Connector to Harness (see Rear Wire Harness ) | ||
| Right engine compartment wire harness | C101, C210, C251 G201, G202, G203 | C201 through C209, C211, C212 | Connector to Harness (see Right Engine Compartment Wire Harness ) | |
| Right front damper subharness (with integrated dynamics system) | C251 | Connector to Harness (see Right Front Damper Subharness (With Integrated Dynamics System) ) | ||
| Right rear damper subharness (with integrated dynamics system) | C607 | Connector to Harness (see Right Rear Damper Subharness (With Integrated Dynamics System) ) | ||
| Right rear door wire harness | C781 | Connector to Harness (see Right Rear Door Wire Harness ) | ||
| Right taillight wire harness | C652 | Connector to Harness (see Right Taillight Wire Harness ) | ||
| Roof wire harness | C403, C404 | C451 S1 | Connector to Harness (see Roof Wire Harness ) | |
| Starter cable | (+), T1, T4, T5 | Connector to Harness (see Starter Cable ) | ||
| Tailgate subharness | C803, C804 | Connector to Harness (see Tailgate Subharness ) | ||
| Tailgate wire harness | C801 through C804 | Connector to Harness (see Tailgate Wire Harness ) | ||
| Transmission ground cable | T3, G3 | Connector to Harness (see Transmission Ground Cable ) | ||
Connector to Harness Index
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| T1 | 1 | Right side of engine compartment | Under-hood fuse/relay box (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | ||
| T4 | 8 | Left side of engine compartment | Starter motor | ||
| T5 | 5 | Left side of engine compartment | Auxiliary under-hood fuse/relay box (see FUSE TO COMPONENTS INDEX ) | ||
| (+) | 2 | Battery | Battery positive terminal |
STARTER CABLE
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| (-) | 4 | Left side of engine compartment | Battery negative terminal | ||
| G1 | 3 | Left side of engine compartment | Body ground, via battery ground cable |
BATTERY GROUND CABLE
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| T2 | 9 | Right side of engine compartment | Engine | ||
| G2 | 10 | Right side of engine compartment | Body ground, via engine ground cable |
ENGINE GROUND CABLE
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| T3 | 7 | Left side of engine compartment | Transmission housing | ||
| G3 | 6 | Left side of engine compartment | Body ground, via transmission ground cable |
TRANSMISSION GROUND CABLE
Scheme 1265
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| A/C compressor clutch | 42 | 1 | Right side of engine compartment | ||
| Alternator | 43 | 4 | Right side of engine compartment | ||
| CKP sensor | 26 | 3 | Left side of engine | ||
| CMP sensor | 41 | 3 | Right side of engine | ||
| Engine coolant temperature (ECT) sensor 1 | 29 | 2 | Left side of engine | ||
| Engine mount control solenoid | 19 | 2 | Left side of engine | ||
| EVAP canister purge valve | 20 | 2 | Left side of engine | ||
| Exhaust gas recirculation (EGR) valve and position sensor | 30 | 5 | Left side of engine | ||
| Front A/F sensor (Bank 2, Sensor 1) | 33 | 6 | Front of engine compartment | ||
| Front secondary heated oxygen sensor (secondary HO2S) (Bank 2, Sensor 2) | 32 | 4 | Front of engine compartment | ||
| Ignition coil No. 1 | 10 | 3 | Middle of engine | ||
| Ignition coil No. 2 | 13 | 3 | Middle of engine | ||
| Ignition coil No. 3 | 16 | 3 | Middle of engine | ||
| Ignition coil No. 4 | 40 | 3 | Middle of engine | ||
| Ignition coil No. 5 | 37 | 3 | Middle of engine | ||
| Ignition coil No. 6 | 34 | 3 | Middle of engine | ||
| Injector No. 1 | 8 | 2 | Middle of engine | ||
| Injector No. 2 | 11 | 2 | Middle of engine | ||
| Injector No. 3 | 15 | 2 | Middle of engine | ||
| Injector No. 4 | 38 | 2 | Middle of engine | ||
| Injector No. 5 | 35 | 2 | Middle of engine | ||
| Injector No. 6 | 31 | 2 | Middle of engine | ||
| Intake manifold tuning (IMT) actuator | 45 | 5 | Middle of engine | ||
| Manifold absolute pressure (MAP) sensor | 28 | 3 | Left side of engine | ||
| Mass air flow (MAF) sensor/Intake air temperature (IAT) sensor | 22 | 5 | Left side of engine compartment | ||
| Oil pressure switch | 7 | 1 | Right side of engine | ||
| PCM connector B | 2 | 49 | Right side of engine compartment | ||
| PCM connector C | 3 | 49 | Right side of engine compartment | ||
| Rear A/F sensor (Bank 1, Sensor 1) | 17 | 6 | Rear of engine compartment | ||
| Rear secondary heated oxygen sensor (secondary HO2S) (Bank 1, Sensor 2) | 18 | 4 | Rear of engine compartment | ||
| Rocker arm oil control solenoid | 5 | 1 | Right side of engine | ||
| Rocker arm oil pressure switch | 6 | 2 | Right side of engine | ||
| Throttle position sensor/Throttle actuator | 27 | 6 | Left side of engine | ||
| Transmission fluid pressure switch A (2nd clutch) | 24 | 1 | Transmission housing | ||
| Transmission fluid pressure switch D (5th clutch) | 25 | 1 | Transmission housing |
ENGINE WIRE HARNESS (ENGINE SECTION)
Scheme 1266
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| C101 | 1 | 23 | Right side of engine compartment | Right engine compartment wire harness (see Right Engine Compartment Wire Harness ) | |
| C102 | 23 | 1 | Left side of engine compartment | Left engine compartment wire harness (see Left Engine Compartment Wire Harness ) | |
| C103 (junction connector) | 9 | 24 | Middle of engine | ||
| C104 (junction connector) | 12 | 24 | Middle of engine | ||
| C105 (junction connector) | 14 | 24 | Middle of engine | ||
| C106 (junction connector) | 21 | 12 | Left side of engine | ||
| C151 | 39 | 1 | Middle of engine | Knock sensor subharness | |
| T101 | 4 | Right side of engine compartment | Under-hood fuse/relay box (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | ||
| T102 | 44 | Right side of engine compartment | Alternator | ||
| G101 | 46 | Right side of engine | Body ground, via engine wire harness |
ENGINE WIRE HARNESS (ENGINE SECTION)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Knock sensor | 36 | 1 | Middle of engine | ||
| C151 | 39 | 1 | Middle of engine | Engine wire harness (engine section) |
KNOCK SENSOR SUBHARNESS
Scheme 1267
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| A/T clutch pressure control solenoid valve A | 9 | 2 | Transmission housing | ||
| A/T clutch pressure control solenoid valve B | 10 | 2 | Transmission housing | ||
| A/T clutch pressure control solenoid valve C | 11 | 2 | Transmission housing | ||
| A/T clutch pressure control solenoid valve D | 8 | 2 | Transmission housing | ||
| ATF temperature sensor | 12 | 2 | Transmission housing | ||
| Input shaft (mainshaft) speed sensor | 14 | 3 | Transmission housing | ||
| Line pressure solenoid valve A | 2 | 2 | Transmission housing | ||
| Line pressure switch | 13 | 1 | Transmission housing | ||
| Output shaft (countershaft) speed sensor | 15 | 3 | Transmission housing | ||
| Shift solenoid valve A | 4 | 2 | Transmission housing | ||
| Shift solenoid valve B | 3 | 2 | Transmission housing | ||
| Shift solenoid valve C | 1 | 2 | Transmission housing | ||
| Starter solenoid | 17 | 1 | Left side of engine | ||
| Transmission fluid pressure switch B (3rd clutch) | 7 | 1 | Transmission housing | ||
| Transmission fluid pressure switch C (4th clutch) | 16 | 1 | Transmission housing | ||
| Transmission fluid pressure switch E (6th clutch) | 6 | 1 | Transmission housing | ||
| Transmission range switch | 5 | 10 | Transmission housing |
ENGINE WIRE HARNESS (TRANSMISSION SECTION)
Scheme 1268
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| ACC unit | 23 | 20 | Under left side of dash | () | |
| Battery sensor | 47 | 2 | Left side of engine compartment | ||
| Brake fluid level switch | 8 | 2 | Left side of engine compartment | ||
| Brake light relay | 2 | 5 | In the auxiliary under-hood fuse/relay box | () | |
| Driver's under-dash fuse/relay box connector F (see FUSE TO COMPONENTS INDEX ) | 20 | 33 | Under left side of dash | ||
| Driver's under-dash fuse/relay box connector G (see FUSE TO COMPONENTS INDEX ) | 21 | 13 | Under left side of dash | ||
| ECPS control unit | 24 | 12 | Under left side of dash | () | |
| ECPS valve | 4 | 6 | Left side of engine compartment | () | |
| Headlight high/low beam switching solenoid relay | 3 | 4 | In the auxiliary under-hood fuse/relay box | ||
| Horn (High) | 43 | 1 | Front of engine compartment | ||
| Left daytime running light | 38 | 2 | Behind left headlight | ||
| Left fog light | 36 | 2 | Behind left side of front bumper | ||
| Left front brake fluid pressure sensor | 6 | 3 | Left side of engine compartment | () | |
| Left front impact sensor | 32 | 2 | Behind left side of front bumper | ||
| Left front parking/turn signal light | 37 | 3 | Behind left headlight | ||
| Left front side marker light | 29 | 2 | Behind left headlight | ||
| Left front TPMS initiator | 31 | 3 | Behind left side of front bumper | ||
| Left front wheel speed sensor | 27 | 2 | Left side of engine compartment | ||
| Left HID unit | 34 | 2 | Under left headlight | ||
| Left high/low beam switching solenoid | 35 | 3 | Behind left headlight | ||
| Left-front suspension stroke sensor | 33 | 3 | Left side of engine compartment | () | |
| Millimeter wave radar | 44 | 5 | Front of engine compartment | () | |
| Outside air temperature sensor | 41 | 2 | Front of engine compartment | ||
| Parking brake switch | 15 | 1 | Under left side of dash | ||
| Radiator fan motor | 46 | 2 | Front of engine compartment | ||
| Right front brake fluid pressure sensor | 5 | 3 | Left side of engine compartment | () | |
| Security hood switch | 45 | 2 | Front of engine compartment | ||
| Starter cut relay 2 | 1 | 5 | In the auxiliary under-hood fuse/relay box | ||
| VSA modulator-control unit | 7 | 46 | Left side of engine compartment | ||
| Windshield wiper motor | 13 | 5 | Left side of engine compartment |
LEFT ENGINE COMPARTMENT WIRE HARNESS
Scheme 1269
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| C102 | 14 | 1 | Left side of engine compartment | Engine wire harness (engine section) (see Engine Wire Harness (Engine Section) ) | |
| C202 | 11 | 14 | Under left side of dash | Right engine compartment wire harness (see Right Engine Compartment Wire Harness ) | |
| C203 | 9 | 34 | Under left side of dash | Right engine compartment wire harness (see Right Engine Compartment Wire Harness ) | |
| C204 | 12 | 3 | Under left side of dash | Right engine compartment wire harness (see Right Engine Compartment Wire Harness ) | |
| C205 | 10 | 2 | Under left side of dash | Right engine compartment wire harness (see Right Engine Compartment Wire Harness ) | |
| C301 | 22 | 28 | Under left side of dash | Dashboard wire harness (view of driver's side) (see Dashboard Wire Harness (View of Driver's Side) ) | |
| C302 | 19 | 4 | Under left side of dash | Dashboard wire harness (view of driver's side) (see Dashboard Wire Harness (View of Driver's Side) ) | |
| C303 | 18 | 12 | Under left side of dash | Floor wire harness (left branch) (see Floor Wire Harness (Left Branch) ) | |
| C304 | 17 | 8 | Under left side of dash | Floor wire harness (left branch) (see Floor Wire Harness (Left Branch) ) | |
| C305 (junction connector) | 16 | 8 | Under left side of dash | ||
| C351 | 42 | 2 | Front of engine compartment | ECT sensor subharness | |
| C361 | 26 | 2 | Left side of engine compartment | Left front damper subharness (with integrated dynamics system) | (1) |
| G301 | 39 | Behind left side of front bumper | Body ground, via left engine compartment wire harness | ||
| G302 | 30 | Left side of engine compartment | Body ground, via left engine compartment wire harness | ||
| G303 | 25 | Left side of engine compartment | Body ground, via left engine compartment wire harness | ||
| (1) With ACC (2) With integrated dynamics system | |||||
| (1) | With ACC |
| (2) | With integrated dynamics system |
LEFT ENGINE COMPARTMENT WIRE HARNESS
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Engine coolant temperature (ECT) sensor 2 | 40 | 2 | Front of engine compartment | ||
| C351 | 42 | 2 | Front of engine compartment | Left engine compartment wire harness |
ECT SENSOR SUBHARNESS
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Left front damper coil | 28 | 2 | Left side of engine compartment | ||
| C361 | 26 | 2 | Left side of engine compartment | Left engine compartment wire harness |
LEFT FRONT DAMPER SUBHARNESS (WITH INTEGRATED DYNAMICS SYSTEM)
Scheme 1270
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| A/C condenser fan motor | 20 | 2 | Front of engine compartment | ||
| A/C pressure sensor | 8 | 3 | Right side of engine compartment | ||
| Accelerator pedal position sensor | 9 | 6 | Under left side of dash | ||
| Brake pedal position switch | 15 | 4 | Under left side of dash | ||
| Front vertical acceleration sensor | 10 | 3 | Under left side of dash | (1) | |
| Headlight washer motor | 28 | 2 | Behind right side of front bumper | (2) | |
| Horn (Low) | 23 | 1 | Behind right headlight | ||
| Passenger's under-dash fuse/relay box connector B (see FUSE TO COMPONENTS INDEX ) | 43 | 1 | Under right side of dash | ||
| Passenger's under-dash fuse/relay box connector E (see FUSE TO COMPONENTS INDEX ) | 41 | 18 | Under right side of dash | ||
| Passenger's under-dash fuse/relay box connector F (see FUSE TO COMPONENTS INDEX ) | 42 | 2 | Under right side of dash | ||
| PCM connector A | 18 | 49 | Right side of engine compartment | ||
| Power steering pressure (PSP) switch | 17 | 2 | Right side of engine compartment | ||
| Right daytime running light | 22 | 2 | Behind right headlight | ||
| Right fog light | 27 | 2 | Behind right side of front bumper | ||
| Right front impact sensor | 33 | 2 | Behind right side of front bumper | ||
| Right front parking/turn signal light | 21 | 3 | Behind right headlight | ||
| Right front side marker light | 34 | 2 | Behind right headlight | ||
| Right front TPMS initiator | 32 | 3 | Behind right side of front bumper | ||
| Right front wheel speed sensor | 35 | 2 | Right side of engine compartment | ||
| Right HID unit | 26 | 2 | Under right headlight | ||
| Right high/low beam switching solenoid | 25 | 3 | Behind right headlight | ||
| Right-front suspension stroke sensor | 30 | 3 | Right side of engine compartment | (1) | |
| Under-hood fuse/relay box connector A (electrical load detector) (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 7 | 3 | Right side of engine compartment | ||
| Under-hood fuse/relay box connector B (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 5 | 14 | Right side of engine compartment | ||
| Under-hood fuse/relay box connector C (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 6 | 5 | Right side of engine compartment | ||
| Washer fluid level switch | 31 | 2 | Behind right side of front bumper | ||
| Windshield washer motor | 29 | 2 | Behind right side of front bumper | ||
| (1) With integrated dynamics system (2) With headlight washer | |||||
| (1) | With integrated dynamics system |
| (2) | With headlight washer |
RIGHT ENGINE COMPARTMENT WIRE HARNESS
Scheme 1271
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| C101 | 19 | 23 | Right side of engine compartment | Engine wire harness (engine section) (see Engine Wire Harness (Engine Section) ) | |
| C201 | 4 | 2 | Under right side of dash | A/C wire harness (see A/C Wire Harness ) | |
| C202 | 13 | 14 | Under left side of dash | Left engine compartment wire harness (see Left Engine Compartment Wire Harness ) | |
| C203 | 14 | 34 | Under left side of dash | Left engine compartment wire harness (see Left Engine Compartment Wire Harness ) | |
| C204 | 12 | 3 | Under left side of dash | Left engine compartment wire harness (see Left Engine Compartment Wire Harness ) | |
| C205 | 11 | 2 | Under left side of dash | Left engine compartment wire harness (see Left Engine Compartment Wire Harness ) | |
| C206 | 44 | 28 | Under right side of dash | Dashboard wire harness (view of middle to passenger's side) (see Dashboard Wire Harness (View of Middle to Passenger's Side) ) | |
| C207 | 45 | 4 | Under right side of dash | Dashboard wire harness (view of middle to passenger's side) (see Dashboard Wire Harness (View of Middle to Passenger's Side) ) | |
| C208 | 40 | 18 | Under right side of dash | Floor wire harness (right branch) (see Floor Wire Harness (Right Branch) ) | (1) |
| C209 | 39 | 5 | Under right side of dash | Floor wire harness (right branch) (see Floor Wire Harness (Right Branch) ) | (1) |
| C209 | 39 | 12 | Under right side of dash | Floor wire harness (right branch) (see Floor Wire Harness (Right Branch) ) | (2) |
| C210 (junction connector) | 38 | 12 | Right side of engine compartment | (3) | |
| C211 (junction connector) | 2 | 12 | Under right side of dash | ||
| C212 (junction connector) | 3 | 12 | Under right side of dash | ||
| C251 | 37 | 2 | Right side of engine compartment | Right front damper subharness (with integrated dynamics system) | (4) |
| G201 | 24 | Behind right side of front bumper | Body ground, via right engine compartment wire harness | ||
| G202 | 16 | Right side of engine compartment | Body ground, via right engine compartment wire harness | ||
| G203 | 1 | Under right side of dash | Body ground, via right engine compartment wire harness | ||
| (1) With ACC (2) Without ACC (3) '10-11 models (4) With integrated dynamics system | |||||
| (1) | With ACC |
| (2) | Without ACC |
| (3) | '10-11 models |
| (4) | With integrated dynamics system |
RIGHT ENGINE COMPARTMENT WIRE HARNESS
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Right front damper coil | 36 | 2 | Right side of engine compartment | ||
| C251 | 37 | 2 | Right side of engine compartment | Right engine compartment wire harness |
RIGHT FRONT DAMPER SUBHARNESS (WITH INTEGRATED DYNAMICS SYSTEM)
Scheme 1272
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| ACC cut relay | 15 | 5 | Behind gauge | (2) | |
| Auxiliary under-dash fuse holder | 63 | 2 | Under left side of dash | (2) | |
| Cable reel connector A | 28 | 20 | In steering column | ||
| Cable reel connector B | 29 | 4 | In steering column | Driver's airbag inflator via cable reel | |
| Combination light switch | 40 | 12 | In steering column | ||
| Console accessory power socket relay | 14 | 4 | Behind gauge | (1) | |
| Dashlights brightness controller switch | 48 | 6 | Left side of dash | ||
| Data link connector (DLC) | 39 | 16 | Under left side of dash | ||
| Driver's footwell light | 49 | 2 | Under left side of dash | ||
| Driver's junction box connector A | 20 | 6 | Behind gauge | ||
| Driver's junction box connector B | 21 | 6 | Behind gauge | ||
| Driver's junction box connector C | 22 | 8 | Behind gauge | ||
| Driver's junction box connector D | 27 | 4 | Behind gauge | ||
| Driver's junction box connector E | 23 | 10 | Behind gauge | ||
| Driver's junction box connector F | 24 | 8 | Behind gauge | ||
| Driver's junction box connector G | 26 | 10 | Behind gauge | ||
| Driver's junction box connector H | 25 | 10 | Behind gauge | ||
| Driver's under-dash fuse/relay box connector C (see FUSE TO COMPONENTS INDEX ) | 53 | 5 | Under left side of dash | ||
| Driver's under-dash fuse/relay box connector M (see FUSE TO COMPONENTS INDEX ) | 12 | 4 | Under left side of dash | ||
| Driver's under-dash fuse/relay box connector N (see FUSE TO COMPONENTS INDEX ) | 52 | 16 | Under left side of dash | ||
| Driver's under-dash fuse/relay box connector P (see FUSE TO COMPONENTS INDEX ) | 62 | 20 | Under left side of dash | ||
| Driver's under-dash fuse/relay box connector Q (see FUSE TO COMPONENTS INDEX ) | 54 | 20 | Under left side of dash | ||
| Driver's under-dash fuse/relay box connector R (see FUSE TO COMPONENTS INDEX ) | 55 | 24 | Under left side of dash | ||
| Electric steering lock | 43 | 12 | In steering column | (1) | |
| Front accessory power socket relay | 47 | 4 | Behind gauge | ||
| Gauge control module connector A | 18 | 32 | Behind gauge | ||
| Gauge control module connector B | 19 | 20 | Behind gauge | (3) | |
| IG2 cut relay | 45 | 5 | Behind gauge | (2) | |
| Ignition switch | 38 | 5 | In steering column | (2) | |
| Immobilizer-keyless control unit | 34 | 7 | In steering column | (2) | |
| Keyless access junction box connector A | 1 | 6 | Under left side of dash | (1) | |
| Keyless access junction box connector B | 2 | 6 | Under left side of dash | (1) | |
| Keyless access junction box connector C | 3 | 8 | Under left side of dash | (1) | |
| Keyless access junction box connector D | 8 | 4 | Under left side of dash | (1) | |
| Keyless access junction box connector E | 4 | 10 | Under left side of dash | (1) | |
| Keyless access junction box connector F | 5 | 8 | Under left side of dash | (1) | |
| Keyless access junction box connector G | 7 | 10 | Under left side of dash | (1) | |
| Keyless access junction box connector H | 6 | 10 | Under left side of dash | (1) | |
| (1) With keyless access system (2) Without keyless access system (3) With integrated dynamics system | |||||
| (1) | With keyless access system |
| (2) | Without keyless access system |
| (3) | With integrated dynamics system |
DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE)
Scheme 1273
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Multi switch | 13 | 12 | Left side of dash | ||
| Optional connector (for remote engine start) | 64 | 6 | Under left side of dash | ||
| Power control unit connector A | 31 | 1 | Under left side of dash | (1) | |
| Power control unit connector B | 33 | 4 | Under left side of dash | (1) | |
| Power control unit connector C | 32 | 36 | Under left side of dash | (1) | |
| Power mirror control unit | 50 | 24 | Under left side of dash | ||
| Power mirror switch | 51 | 13 | Left side of dash | ||
| Power telescopic motor/position sensor | 44 | 6 | In steering column | ||
| Power tilt motor/position sensor | 42 | 8 | In steering column | ||
| Power tilt/telescopic steering control unit connector A | 36 | 16 | Under left side of dash | ||
| Power tilt/telescopic steering control unit connector B | 35 | 8 | Under left side of dash | ||
| Power tilt/telescopic steering switch | 46 | 13 | In steering column | ||
| Seat ventilation relay | 15 | 4 | Behind gauge | (2) | |
| Steering angle sensor | 41 | 5 | In steering column | ||
| Steering lock (ignition switch/ignition key light/key interlock solenoid) | 37 | 6 | In steering column | (2) | |
| TPMS control unit | 16 | 20 | Behind gauge | ||
| Wiper/washer switch | 30 | 8 | In steering column | ||
| C301 | 57 | 28 | Under left side of dash | Left engine compartment wire harness (see Left Engine Compartment Wire Harness ) | |
| C302 | 56 | 4 | Under left side of dash | Left engine compartment wire harness (see Left Engine Compartment Wire Harness ) | |
| C401 | 60 | 23 | Under left side of dash | Floor wire harness (left branch) (see Floor Wire Harness (Left Branch) ) | |
| C402 | 61 | 6 | Under left side of dash | Floor wire harness (left branch) (see Floor Wire Harness (Left Branch) ) | |
| C403 | 10 | 28 | Under left side of dash | Roof wire harness (see Roof Wire Harness ) | |
| C404 | 9 | 2 | Under left side of dash | Roof wire harness (see Roof Wire Harness ) | (3) |
| C751 | 59 | 23 | Under left side of dash | Driver's door wire harness (see Driver's Door Wire Harness ) | |
| C752 | 58 | 16 | Under left side of dash | Driver's door wire harness (see Driver's Door Wire Harness ) | |
| G401 | 11 | Under left side of dash | Body ground, via dashboard wire harness | ||
| G402 | 17 | Under left side of dash | Body ground, via dashboard wire harness | ||
| (1) With keyless access system (2) With seat ventilation (3) Without navigation | |||||
| (1) | With keyless access system |
| (2) | With seat ventilation |
| (3) | Without navigation |
DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE)
Scheme 1274
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Automatic lighting/sunlight sensor | 9 | 5 | Middle of dash | ||
| Driver's seat heater switch | 62 | 6 | Under center console | (2) | |
| Driver's seat ventilation switch | 62 | 16 | Under center console | (1) | |
| Engine start/stop switch | 6 | 10 | Middle of dash | (3) | |
| Front accessory power socket | 53 | 2 | Under center console | ||
| Front center speaker | 10 | 2 | Middle of dash | ||
| Front interior LF antenna | 54 | 2 | Middle of dash | (3) | |
| Front passenger's airbag inflator | 19 | 4 | Under right side of dash | ||
| Front passenger's seat heater switch | 52 | 7 | Under center console | (2) | |
| Front passenger's seat ventilation switch | 52 | 12 | Under center console | (1) | |
| Hazard warning switch/passenger's airbag cutoff indicator | 11 | 6 | Middle of dash | ||
| Humidity/in-car temperature sensor | 2 | 4 | Middle of dash | ||
| Integrated dynamics system switch | 51 | 12 | Middle of dash | (4) | |
| Keyless access control unit connector A | 13 | 36 | Middle of dash | (3) | |
| Keyless access control unit connector B | 12 | 32 | Middle of dash | (3) | |
| Keyless access control unit connector C | 7 | 5 | Middle of dash | (3) | |
| Optional connector (for remote engine start) (female connector) | 60 | 2 | Under center console | ||
| Optional connector (for remote engine start) (male connector) | 61 | 2 | Under center console | ||
| Optional connector (for right running board light) | 42 | 2 | Under right side of dash | ||
| Passenger's junction box 1 connector A | 21 | 6 | Under right side of dash | ||
| Passenger's junction box 1 connector B | 22 | 6 | Under right side of dash | ||
| Passenger's junction box 1 connector C | 23 | 8 | Under right side of dash | ||
| Passenger's junction box 1 connector D | 20 | 4 | Under right side of dash | ||
| Passenger's junction box 1 connector E | 24 | 10 | Under right side of dash | ||
| Passenger's junction box 1 connector F | 25 | 8 | Under right side of dash | ||
| Passenger's junction box 1 connector G | 27 | 10 | Under right side of dash | ||
| Passenger's junction box 1 connector H | 26 | 10 | Under right side of dash | ||
| Passenger's junction box 2 connector A | 39 | 4 | Under right side of dash | ||
| Passenger's junction box 2 connector B | 30 | 4 | Under right side of dash | ||
| Passenger's junction box 2 connector C | 31 | 4 | Under right side of dash | ||
| Passenger's junction box 2 connector D | 32 | 6 | Under right side of dash | ||
| Passenger's junction box 2 connector E | 38 | 6 | Under right side of dash | ||
| Passenger's junction box 2 connector F | 33 | 6 | Under right side of dash | ||
| Passenger's junction box 2 connector G | 34 | 6 | Under right side of dash | ||
| Passenger's junction box 2 connector H | 37 | 4 | Under right side of dash | ||
| Passenger's junction box 2 connector J | 36 | 8 | Under right side of dash | ||
| Passenger's junction box 2 connector K | 35 | 10 | Under right side of dash | ||
| Passenger's under-dash fuse/relay box connector A (see FUSE TO COMPONENTS INDEX ) | 45 | 38 | Under right side of dash | ||
| Rear ANC/active sound control microphone | 29 | 2 | Under right side of dash | ||
| (1) With seat ventilation (2) Without seat ventilation (3) With keyless access system (4) With integrated dynamics system | |||||
| (1) | With seat ventilation |
| (2) | Without seat ventilation |
| (3) | With keyless access system |
| (4) | With integrated dynamics system |
DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE)
Scheme 1275
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Remote slot | 5 | 16 | Middle of dash | (1) | |
| Remote slot control unit | 8 | 40 | Middle of dash | (1) | |
| Right tweeter | 28 | 2 | |||
| Seat ventilation control unit | 60 | 37 | Under center console | (2) | |
| SRS unit connector A | 4 | 39 | Middle of dash | ||
| Yaw rate-acceleration sensor | 3 | 4 | Middle of dash | ||
| C206 | 46 | 28 | Under right side of dash | Right engine compartment wire harness (see Right Engine Compartment Wire Harness ) | |
| C207 | 48 | 4 | Under right side of dash | Right engine compartment wire harness | |
| C405 | 18 | 34 | Under right side of dash | Audio wire harness (see Audio Wire Harness ) | |
| C406 | 16 | 12 | Under right side of dash | Audio wire harness (see Audio Wire Harness ) | (3) |
| C407 | 17 | 8 | Under right side of dash | Audio wire harness (see Audio Wire Harness ) | |
| C408 | 50 | 12 | Under middle of dash | A/C Wire harness (see A/C Wire Harness ) | |
| C409 | 56 | 12 | Under center console | Console subharness (see Console Subharness ) | |
| C410 | 55 | 12 | Under center console | Console subharness (see Console Subharness ) | (3) |
| C411 | 58 | 20 | Under center console | Floor wire harness (right branch) (see Floor Wire Harness (Right Branch) ) | |
| C412 | 57 | 13 | Under center console | Floor wire harness (right branch) (see Floor Wire Harness (Right Branch) ) | |
| C413 | 47 | 12 | Under right side of dash | Floor wire harness (right branch) (see Floor Wire Harness (Right Branch) ) | |
| C421 (junction connector) | 15 | 12 | Under right side of dash | ||
| C422 (junction connector) | 14 | 12 | Under right side of dash | ||
| C423 (junction connector) | 41 | 20 | Under right side of dash | ||
| C761 | 43 | 23 | Under right side of dash | Front passenger's door wire harness (see Front Passenger's Door Wire Harness ) | |
| C762 | 44 | 6 | Under right side of dash | Front passenger's door wire harness (see Front Passenger's Door Wire Harness ) | (1) |
| G403 | 49 | Middle of dash | Body ground, via dashboard wire harness | ||
| G404 | 1 | Middle of dash | Body ground, via dashboard wire harness | ||
| G405 | 40 | Under right side of dash | Body ground, via dashboard wire harness | ||
| (1) With keyless access system (2) With seat ventilation (3) Without navigation | |||||
| (1) | With keyless access system |
| (2) | With seat ventilation |
| (3) | Without navigation |
DASHBOARD WIRE HARNESS (VIEW OF MIDDLE TO PASSENGER'S SIDE)
Scheme 1276
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Auxiliary jack assembly | 4 | 5 | Under center console | ||
| Console accessory power socket | 5 | 2 | Under center console | ||
| USB adapter control unit | 3 | 14 | Under center console | (1) | |
| C409 | 1 | 12 | Under center console | Dashboard wire harness (view of middle to passenger's side) (see Dashboard Wire Harness (View of Middle to Passenger's Side) ) | |
| C410 | 2 | 12 | Under center console | Dashboard wire harness (view of middle to passenger's side) (see Dashboard Wire Harness (View of Middle to Passenger's Side) ) | (1) |
| C471 | 7 | 2 | Under center console | Console light subharness | |
| (1) Without navigation | |||||
| (1) | Without navigation |
CONSOLE SUBHARNESS
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Console box light | 6 | 2 | Under center console | ||
| C471 | 7 | 2 | Under center console | Console subharness |
CONSOLE LIGHT SUBHARNESS
Scheme 1277
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| ANC/active sound control unit | 22 | 16 | Under middle of dash | ||
| Audio and HVAC switch panel connector A | 33 | 20 | Under middle of dash | (2) | |
| Audio and HVAC switch panel connector B | 34 | 32 | Under middle of dash | (2) | |
| Audio unit connector A | 26 | 24 | Under middle of dash | (2) | |
| Audio unit connector B | 27 | 24 | Under middle of dash | (2) | |
| Audio unit connector C | 29 | 15 | Under middle of dash | (2) | |
| Audio unit connector D | 30 | 20 | Under middle of dash | (2) | |
| Audio unit connector F | 28 | 12 | Under middle of dash | (2) | |
| Audio display unit | 2 | 12 | Under middle of dash | (2) | |
| Audio-navigation and HVAC switch panel connector A | 33 | 20 | Under middle of dash | (1) | |
| Audio-navigation and HVAC switch panel connector B | 34 | 32 | Under middle of dash | (1) | |
| Audio-navigation unit connector A | 26 | 24 | Under middle of dash | (1) | |
| Audio-navigation unit connector B | 27 | 24 | Under middle of dash | (1) | |
| Audio-navigation unit connector C | 29 | 15 | Under middle of dash | (1) | |
| Audio-navigation unit connector D | 30 | 20 | Under middle of dash | (1) | |
| Audio-navigation unit connector F | 28 | 12 | Under middle of dash | (1) | |
| Audio-navigation unit connector G | 31 | 8 | Under middle of dash | (1) | |
| Audio-navigation unit connector H | 25 | 28 | Under middle of dash | (1) | |
| Glove box light | 10 | 2 | Glove box | ||
| HandsFreeLink control unit | 23 | 28 | Under middle of dash | ||
| Interface dial | 32 | 5 | Under middle of dash | (1) | |
| Keyless access system mode switch | 20 | 2 | Glove box | (3) | |
| Navigation display unit | 2 | 28 | Under middle of dash | (1) | |
| Navigation service check connector | 19 | 2 | Under right side of dash | (1) | |
| Passenger's under-dash fuse/relay box connector D (see FUSE TO COMPONENTS INDEX ) | 16 | 28 | Under right side of dash | ||
| Stereo amplifier connector A | 14 | 18 | Under right side of dash | ||
| Stereo amplifier connector B | 15 | 28 | Under right side of dash | (1) | |
| Stereo amplifier connector B | 15 | 20 | Under right side of dash | (2) | |
| Stereo amplifier connector C | 13 | 5 | Under right side of dash | ||
| C405 | 5 | 34 | Under right side of dash | Dashboard wire harness (view of middle to passenger's side) (see Dashboard Wire Harness (View of Middle to Passenger's Side) ) | |
| C406 | 4 | 12 | Under right side of dash | Dashboard wire harness (view of middle to passenger's side) (see Dashboard Wire Harness (View of Middle to Passenger's Side) ) | (2) |
| C407 | 6 | 8 | Under right side of dash | Dashboard wire harness (view of middle to passenger's side) (see Dashboard Wire Harness (View of Middle to Passenger's Side) ) | |
| C501 | 21 | 34 | Under middle of dash | A/C wire harness (see A/C Wire Harness ) | |
| C502 (junction connector) | 7 | 12 | Under right side of dash | ||
| C503 (junction connector) | 3 | 12 | Under right side of dash | ||
| C504 (junction connector) | 8 | 12 | Under right side of dash | ||
| C505 (junction connector) | 11 | 12 | Under right side of dash | ||
| C506 (junction connector) | 12 | 12 | Under right side of dash | ||
| C507 (junction connector) | 9 | 12 | Under right side of dash | ||
| C508 | 17 | 34 | Under right side of dash | Floor wire harness (right branch) (see Floor Wire Harness (Right Branch) ) | |
| C509 | 18 | 14 | Under right side of dash | Floor wire harness (right branch) (see Floor Wire Harness (Right Branch) ) | |
| G501 | 1 | Under middle of dash | Body ground, via audio wire harness | ||
| G502 | 24 | Under middle of dash | Body ground, via audio wire harness | ||
| (1) With navigation (2) Without navigation (3) With keyless access system | |||||
| (1) | With navigation |
| (2) | Without navigation |
| (3) | With keyless access system |
AUDIO WIRE HARNESS
Scheme 1278
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Active clamper control unit connector A | 46 | 20 | Left side of cargo area | (1) | |
| Active damper control unit connector B | 30 | 14 | Left side of cargo area | (1) | |
| BSI control unit | 9 | 16 | Under left side of dash | (2) | |
| Driver's door switch | 64 | 1 | Left B-pillar | ||
| Driver's seat belt tensioner | 62 | 4 | Left B-pillar | ||
| Driver's side airbag inflator | 10 | 2 | Under Driver's seat | ||
| Driver's under-dash fuse/relay box connector D (see FUSE TO COMPONENTS INDEX ) | 5 | 16 | Under left side of dash | ||
| Driver's under-dash fuse/relay box connector E (see FUSE TO COMPONENTS INDEX ) | 6 | 20 | Under left side of dash | ||
| EVAP canister vent shut valve | 13 | 2 | Fuel tank | ||
| Fuel fill door lock actuator | 49 | 2 | Left side of cargo area | ||
| Fuel pump control module | 54 | 10 | Under left side of floor | ||
| Fuel tank pressure (FTP) sensor | 14 | 3 | Fuel tank | ||
| Fuel tank unit (Fuel pump/fuel gauge sending unit) | 18 | 4 | Fuel tank | ||
| Left rear door switch | 57 | 1 | Left C-pillar | ||
| Left rear seat heater | 59 | 3 | Under left rear seat | (3) | |
| Left rear TPMS initiator | 56 | 3 | Under left rear floor | ||
| Left rear vertical acceleration sensor | 51 | 3 | Left side of cargo area | (1) | |
| Left satellite speaker | 19 | 2 | Left C-pillar | (4) | |
| Left second row seat heater relay (high) | 15 | 4 | Under left rear seat | (3) | |
| Left second row seat heater relay (low) | 60 | 5 | Under left rear seat | (3) | |
| Left side curtain airbag inflator | 22 | 2 | Left C-pillar | ||
| Left side E-pretensioner motor | 61 | 2 | Left B-pillar | (5) | |
| Left side impact sensor (1st) | 63 | 4 | Left B-pillar | ||
| Left side impact sensor (2nd) | 55 | 2 | Left C-pillar | ||
| Middle interior LF antenna | 17 | 2 | Under rear seat | (6) | |
| Optional connector (for left running board light) | 1 | 2 | Under left side of dash | ||
| Power tailgate control unit connector A | 28 | 5 | Left side of cargo area | ||
| Power tailgate control unit connector B | 27 | 20 | Left side of cargo area | ||
| Power tailgate control unit connector C | 25 | 14 | Left side of cargo area | ||
| Power tailgate drive unit connector A | 50 | 2 | Left D-pillar | ||
| Power tailgate drive unit connector B | 24 | 8 | Left D-pillar | ||
| Power tailgate inside beeper | 47 | 2 | Left side of cargo area | ||
| Rear individual map light | 23 | 10 | Rear of roof | ||
| Rear interior LF antenna | 33 | 2 | Left side of cargo area | (6) | |
| RF unit 2 | 26 | 3 | Under rear seat | (6) | |
| SH-AWD control unit connector A | 39 | 20 | Left side of cargo area | ||
| SH-AWD control unit connector B | 40 | 8 | Left side of cargo area | ||
| SH-AWD relay | 2 | 4 | Under left side of dash | ||
| C303 | 3 | 12 | Under left side of dash Left engine compartment wire harness (see Left Engine Compartment Wire Harness ) | ||
| C304 | 4 | 8 | Under left side of dash Left engine compartment wire harness (see Left Engine Compartment Wire Harness ) | ||
| (1) With integrated dynamics system (2) With BSI (3) With rear seat heater (4) With navigation (5) With ACC (6) With keyless access system | |||||
| (1) | With integrated dynamics system |
| (2) | With BSI |
| (3) | With rear seat heater |
| (4) | With navigation |
| (5) | With ACC |
| (6) | With keyless access system |
FLOOR WIRE HARNESS (LEFT BRANCH)
Scheme 1279
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| C401 | 8 | 23 | Under left side of dash | Dashboard wire harness (view of Driver's side) (see Dashboard Wire Harness (View of Driver's Side) ) | |
| C402 | 7 | 6 | Under left side of dash | Dashboard wire harness (view of Driver's side) (see Dashboard Wire Harness (View of Driver's Side) ) | |
| C601 | 11 | 23 | Under Driver's seat | Driver's seat wire harness | |
| With seat ventilation (see Driver's Seat Wire Harness (With Seat Ventilation) ) Without seat ventilation (see Driver's Seat Wire Harness (Without Seat Ventilation) ) | |||||
| C604 (junction connector) | 16 | 12 | Under rear seat | ||
| C606 (junction connector) | 58 | 12 | Under rear seat | ||
| C608 | 45 | 23 | Under rear of floor | Rear subframe wire harness (see Rear Subframe Wire Harness ) | |
| C609 | 48 | 2 | Under left rear floor | Left rear damper subharness (with integrated dynamics system) | (1) |
| C610 (junction connector) | 41 | 12 | Left side of cargo area | (1) | |
| C651 | 31 | 4 | Left side of cargo area Left taillight wire harness | ||
| C701 | 42 | 12 | Left side of cargo area | Rear wire harness | (2) |
| C701 | 42 | 2 | Left side of cargo area | Rear wire harness | (3) |
| C771 | 12 | 18 | Left B-pillar | Left rear door wire harness (see Left Rear Door Wire Harness ) | |
| C801 | 20 | 24 | Left rear side of roof | Tailgate wire harness (see Tailgate Wire Harness ) | |
| C802 | 21 | 8 | Left rear side of roof | Tailgate wire harness (see Tailgate Wire Harness ) | |
| G601 | 66 | Under left side of dash | Body ground, via floor wire harness | ||
| G602 | 65 | Under Driver's seat | Body ground, via floor wire harness | ||
| G603 | 53 | Left C-pillar | Body ground, via floor wire harness | ||
| G604 | 38 | Left side of cargo area | Body ground, via floor wire harness | ||
| (1) With integrated dynamics system (2) With keyless access system (3) Without keyless access system | |||||
| (1) | With integrated dynamics system |
| (2) | With keyless access system |
| (3) | Without keyless access system |
FLOOR WIRE HARNESS (LEFT BRANCH)
Scheme 1280
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Keyless buzzer/power tailgate buzzer | 37 | 2 | Behind middle of rear bumper | ||
| Left BSI radar unit | 43 | 6 | Behind left side of rear bumper | (1) | |
| Rear bumper LF antenna | 36 | 2 | Behind middle of rear bumper | (2) | |
| Right BSI radar unit | 35 | 6 | Behind right side of rear bumper | (1) | |
| C701 | 42 | 12 | Left side of cargo area | Floor wire harness (left branch) | (2) |
| C701 | 42 | 2 | Left side of cargo area | Floor wire harness (left branch) | (3) |
| G701 | 34 | Left side of cargo area | Body ground, via rear wire harness | ||
| (1) With BSI (2) With keyless access system (3) Without keyless access system | |||||
| (1) | With BSI |
| (2) | With keyless access system |
| (3) | Without keyless access system |
REAR WIRE HARNESS
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Left rear damper coil | 52 | 2 | Left rear damper | ||
| C609 | 48 | 2 | Under left rear floor | Floor wire harness (left branch) |
LEFT REAR DAMPER SUBHARNESS (WITH INTEGRATED DYNAMICS SYSTEM)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Left brake light/taillight | 32 | 3 | Left taillight | ||
| Left rear side marker light | 29 | 2 | Left taillight | ||
| Left rear turn signal light | 44 | 2 | Left taillight | ||
| C651 | 31 | 4 | Left side of cargo area | Floor wire harness (left branch) |
LEFT TAILLIGHT WIRE HARNESS
Scheme 1281
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| AcuraLink connector (Female connector) | 5 | 5 | Right side of cargo area | (1) | |
| AcuraLink connector (Male connector) | 4 | 5 | Right side of cargo area | (1) | |
| AcuraLink control unit (XM receiver) connector A | 47 | 32 | Right side of cargo area | (1) | |
| A/T shift lock solenoid/park-pin switch/A/T gear position indicator panel light | 21 | 6 | Under center console | ||
| E-pretensioner unit connector A | 18 | 5 | Under center console | (3) | |
| E-pretensioner unit connector B | 17 | 14 | Under center console | (3) | |
| Front passenger's door switch | 31 | 1 | Right B-pillar | ||
| Front passenger's seat belt tensioner | 34 | 4 | Right B-pillar | ||
| Front passenger's side airbag inflator | 22 | 2 | Under front passenger's seat | ||
| Optional connector (for trailer) | 43 | 8 | Right C-pillar | ||
| Passenger's under-dash fuse/relay box connector H (see FUSE TO COMPONENTS INDEX ) | 24 | 38 | Under right side of dash | ||
| Rear safing sensor | 13 | 2 | Under rear seat | ||
| RF unit 1 | 20 | 3 | Under center console | (5) | |
| Right rear door switch | 40 | 1 | Right C-pillar | ||
| Right rear seat heater | 38 | 3 | Under right rear seat | (6) | |
| Right rear TPMS initiator | 42 | 3 | Under right side of floor | ||
| Right rear vertical acceleration sensor | 8 | 3 | Right side of cargo area | (8) | |
| Right satellite speaker | 44 | 2 | Right C-pillar | (7) | |
| Right second row seat heater relay (high) | 36 | 4 | Under right rear seat | (6) | |
| Right second row seat heater relay (low) | 37 | 5 | Under right rear seat | (6) | |
| Right side curtain airbag inflator | 9 | 2 | Right C-pillar | ||
| Right side E-pretensioner motor | 33 | 2 | Right B-pillar | (3) | |
| Right side impact sensor (1st) | 32 | 4 | Right B-pillar | ||
| Right side impact sensor (2nd) | 39 | 2 | Right C-pillar | ||
| SRS unit connector B | 19 | 39 | Under middle of dash | ||
| Subwoofer | 7 | 8 | Right side of cargo area | ||
| XM receiver | 47 | 14 | Right side of cargo area | (2) | |
| C208 | 25 | 18 | Under right side of dash | Right engine compartment wire harness (see Right Engine Compartment Wire Harness ) | (3) |
| C209 | 26 | 5 | Under right side of dash | Right engine compartment wire harness (see Right Engine Compartment Wire Harness ) | (3) |
| C209 | 26 | 12 | Under right side of dash | Right engine compartment wire harness (see Right Engine Compartment Wire Harness ) | (4) |
| (1) With AcuraLink (2) Without AcuraLink (3) With ACC (4) Without ACC (5) With keyless access system (6) With rear seat heater (7) With navigation (8) With integrated dynamics system | |||||
| (1) | With AcuraLink |
| (2) | Without AcuraLink |
| (3) | With ACC |
| (4) | Without ACC |
| (5) | With keyless access system |
| (6) | With rear seat heater |
| (7) | With navigation |
| (8) | With integrated dynamics system |
FLOOR WIRE HARNESS (RIGHT BRANCH)
Scheme 1282
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| C411 | 15 | 20 | Under center console | Dashboard wire harness (view of middle to passenger's side) (see Dashboard Wire Harness (View of Middle to Passenger's Side) ) | |
| C412 | 14 | 13 | Under center console | Dashboard wire harness (view of middle to passenger's side) (see Dashboard Wire Harness (View of Middle to Passenger's Side) ) | |
| C413 | 23 | 12 | Under right side of dash | Dashboard wire harness (view of middle to passenger's side) (see Dashboard Wire Harness (View of Middle to Passenger's Side) ) | |
| C508 | 28 | 34 | Under right side of dash | Audio wire harness (see Audio Wire Harness ) | |
| C509 | 27 | 14 | Under right side of dash | Audio wire harness (see Audio Wire Harness ) | |
| C602 | 29 | 18 | Under front passenger's seat | Front passenger's seat wire harness (see Front Passenger's Seat Wire Harness ) | |
| C603 | 12 | 12 | Under center console | Rear seat heater switch subharness (with rear seat heater) | (1) |
| C605 (junction connector) | 16 | 12 | Under right rear seat | ||
| C607 | 46 | 2 | Under right rear floor | Right rear damper subharness (with integrated dynamics system) | (2) |
| C652 | 6 | 4 | Right side of cargo area | Right taillight wire harness | |
| C781 | 35 | 18 | Right B-pillar | Right rear door wire harness (see Right Rear Door Wire Harness ) | |
| G651 | 30 | Under front passenger's seat | Body ground, via floor wire harness | ||
| G652 | 41 | Right C-pillar | Body ground, via floor wire harness | ||
| (1) With rear seat heater (2) With integrated dynamics system | |||||
| (1) | With rear seat heater |
| (2) | With integrated dynamics system |
FLOOR WIRE HARNESS (RIGHT BRANCH)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Left rear seat heater switch | 10 | 6 | Rear of center console | ||
| Right rear seat heater switch | 11 | 7 | Rear of center console | ||
| C603 | 12 | 12 | Under center console | Floor wire harness (right branch) |
REAR SEAT HEATER SWITCH SUBHARNESS (WITH REAR SEAT HEATER)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Right rear damper coil | 45 | 2 | Right rear damper | ||
| C607 | 46 | 2 | Under right rear floor | Floor wire harness (right branch) |
RIGHT REAR DAMPER SUBHARNESS (WITH INTEGRATED DYNAMICS SYSTEM)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Right brake light/taillight | 2 | 3 | Right taillight | ||
| Right rear side marker light | 3 | 2 | Right taillight | ||
| Right rear turn signal light | 1 | 2 | Right taillight | ||
| C652 | 6 | 4 | Right side of cargo area | Floor wire harness (right branch) |
RIGHT TAILLIGHT WIRE HARNESS
Scheme 1283
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| C801 | 1 | 24 | Left rear side of roof | Floor wire harness (left branch) (see Floor Wire Harness (Left Branch) ) | |
| C802 | 2 | 8 | Left rear side of roof | Floor wire harness (left branch) (see Floor Wire Harness (Left Branch) ) | |
| C803 | 5 | 24 | Center of tailgate | Tailgate subharness | |
| C804 | 18 | 8 | Center of tailgate | Tailgate subharness |
TAILGATE WIRE HARNESS
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| High mount brake light | 7 | 2 | Center of tailgate | ||
| Left back-up light | 20 | 2 | Left side of tailgate | ||
| Left license plate light | 9 | 2 | Center of tailgate | ||
| Left power tailgate pinch sensor | 21 | 2 | Left side of tailgate | ||
| Lower rear window defogger (-) | 8 | 1 | Right side of tailgate | ||
| Lower rear window defogger (+) | 4 | 1 | Left side of tailgate | ||
| Power tailgate closer motor | 16 | 2 | Center of tailgate | ||
| Power tailgate closer unit/latch and ratchet switch | 17 | 6 | Center of tailgate | ||
| Power tailgate inside switch | 19 | 5 | Left side of tailgate | ||
| Rearview camera | 12 | 16 | Center of tailgate | (1) | |
| Rearview camera | 12 | 12 | Center of tailgate | (2) | |
| Right back-up light | 11 | 2 | Right side of tailgate | ||
| Right license plate light | 14 | 2 | Center of tailgate | ||
| Right power tailgate pinch sensor | 10 | 2 | Right side of tailgate | ||
| Tailgate light | 13 | 3 | Right side of tailgate | ||
| Tailgate outer handle switch | 15 | 3 | Center of tailgate | ||
| Upper rear window defogger (-) | 6 | 1 | Right side of tailgate | ||
| Upper rear window defogger (+) | 3 | 1 | Left side of tailgate | ||
| C803 | 5 | 24 | Center of tailgate | Tailgate wire harness | |
| C804 | 18 | 8 | Center of tailgate | Tailgate wire harness | |
| (1) With navigation (2) Without navigation | |||||
| (1) | With navigation |
| (2) | Without navigation |
TAILGATE SUBHARNESS
Scheme 1284
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Left clutch electromagnetic coil/left search coil | 8 | 4 | Rear differential | ||
| Left rear suspension stroke sensor | 1 | 3 | Under left side of vehicle | (1) | |
| Left rear wheel speed sensor | 2 | 2 | Under left side of vehicle | ||
| Rear differential fluid temperature sensor | 7 | 2 | Rear differential | ||
| Right clutch electromagnetic coil/right search coil | 4 | 4 | Rear differential | ||
| Right rear suspension stroke sensor | 6 | 3 | Under right side of vehicle | (1) | |
| Right rear wheel speed sensor | 5 | 2 | Under right side of vehicle | ||
| C608 | 9 | 23 | Under rear of floor | Floor wire harness (left branch) (see Floor Wire Harness (Left Branch) ) | |
| T7 | 3 | Rear differential | Rear differential | ||
| (1) With integrated dynamics system | |||||
| (1) | With integrated dynamics system |
REAR SUBFRAME WIRE HARNESS
Scheme 1285
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Automatic dimming inside mirror | 3 | 7 | Front of roof | (1) | |
| Driver's vanity mirror light | 11 | 2 | Left front side of roof | ||
| Front HFL-ANC/active sound control microphone | 8 | 7 | Front center of roof | (2) | |
| Front HFL-navigation-ANC/active sound control microphone | 8 | 7 | Front center of roof | (1) | |
| Panoramic glass roof control unit/motor | 5 | 10 | Middle of roof | ||
| Panoramic glass roof/sunshade switch | 7 | 7 | Front center of roof | ||
| Passenger's vanity mirror light | 4 | 2 | Right front side of roof | ||
| Power sunshade control unit/motor | 9 | 10 | Middle of roof | ||
| Rearview mirror with rearview camera display/automatic dimming inside mirror | 3 | 12 | Front of roof | (2) | |
| Right tweeter | 2 | 2 | Left A-pillar | ||
| Roof console | 6 | 20 | Front center of roof | ||
| C403 | 1 | 28 | Under left side of dash | Dashboard wire harness (view of Driver's side) (see Dashboard Wire Harness (View of Driver's Side) ) | |
| C404 | 13 | 2 | Under left side of dash | Dashboard wire harness (view of Driver's side) (see Dashboard Wire Harness (View of Driver's Side) ) | (2) |
| C451 (junction connector) | 10 | 12 | Left front side of roof | ||
| S1 (Thermal joint) | 12 | 1 | Middle of roof | ||
| (1) With navigation (2) Without navigation | |||||
| (1) | With navigation |
| (2) | Without navigation |
ROOF WIRE HARNESS
Scheme 1286
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Driver's door lock actuator/knob switch/key cylinder switch | 19 | 10 | Driver's door | ||
| Driver's door outer handle/lock switch/touch sensor/LF antenna | 1 | 8 | Driver's door | (1) | |
| Driver's door speaker | 15 | 2 | Driver's door | ||
| Driver's power window motor | 17 | 6 | Driver's door | ||
| C751 | 13 | 23 | Under left side of dash | Dashboard wire harness (view of Driver's side) (see Dashboard Wire Harness (View of Driver's Side) ) | |
| C752 | 14 | 16 | Under left side of dash | Dashboard wire harness (view of Driver's side) (see Dashboard Wire Harness (View of Driver's Side) ) | |
| C753 | 16 | 28 | Driver's door | Driver's door subharness | |
| C754 | 12 | 12 | Driver's door | Driver's door subharness | |
| (1) With keyless access system | |||||
| (1) | With keyless access system |
DRIVER'S DOOR WIRE HARNESS
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Driver's door courtesy light | 18 | 2 | Driver's door | ||
| Driver's door inner handle light | 3 | 2 | Driver's door | ||
| Driving position memory switch | 4 | 7 | Driver's door | ||
| Left BSI alert indicator | 11 | 2 | Driver's door | (1) | |
| Power window master switch (door multiplex control unit) | 2 | 37 | Driver's door | ||
| C753 | 16 | 28 | Driver's door | Driver's door wire harness | |
| C754 | 12 | 12 | Driver's door | Driver's door wire harness | |
| C755 | 10 | 16 | Driver's door | Driver's door power mirror wire harness | |
| (1) With BSI | |||||
| (1) | With BSI |
DRIVER'S DOOR SUBHARNESS
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Left power mirror actuator | 5 | 4 | Driver's door mirror | ||
| Left power mirror defogger connector A | 8 | 1 | Driver's door mirror | ||
| Left power mirror defogger connector B | 9 | 1 | Driver's door mirror | ||
| Left power mirror position sensor | 6 | 4 | Driver's door mirror | ||
| Left side turn signal light | 7 | 2 | Driver's door mirror | ||
| C755 | 10 | 16 | Driver's door | Driver's door subharness |
DRIVER'S DOOR POWER MIRROR WIRE HARNESS
Scheme 1287
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Front passenger's door lock actuator/knob switch | 11 | 10 | Front passenger's door | ||
| Front passenger's door outer handle/lock switch/touch sensor/LF antenna | 10 | 8 | Front passenger's door | (1) | |
| Front passenger's door speaker | 14 | 2 | Front passenger's door | ||
| Front passenger's power window motor | 13 | 6 | Front passenger's door | ||
| C761 | 17 | 23 | Under right side of dash | Dashboard wire harness (view of middle to passenger's side) (see Dashboard Wire Harness (View of Middle to Passenger's Side) ) | |
| C762 | 16 | 6 | Under right side of dash | Dashboard wire harness (view of middle to passenger's side) (see Dashboard Wire Harness (View of Middle to Passenger's Side) ) | |
| C763 | 15 | 28 | Front passenger's door | Front passenger's door subharness | |
| (1) With keyless access system | |||||
| (1) | With keyless access system |
FRONT PASSENGER'S DOOR WIRE HARNESS
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Front passenger's door courtesy light | 12 | 2 | Front passenger's door | ||
| Front passenger's door inner handle light | 8 | 2 | Front passenger's door | ||
| Front passenger's power window switch | 9 | 37 | Front passenger's door | ||
| Right BSI alert indicator | 1 | 2 | Front passenger's door | (1) | |
| C763 | 15 | 28 | Front passenger's door | Front passenger's door wire harness | |
| C764 | 2 | 16 | Front passenger's door | Front passenger's door power mirror wire harness | |
| (1) With BSI | |||||
| (1) | With BSI |
FRONT PASSENGER'S DOOR SUBHARNESS
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Right power mirror actuator | 6 | 4 | Front passenger's door mirror | ||
| Right power mirror defogger connector A | 3 | 1 | Front passenger's door mirror | ||
| Right power mirror defogger connector B | 7 | 1 | Front passenger's door mirror | ||
| Right power mirror position sensor | 5 | 4 | Front passenger's door mirror | ||
| Right side turn signal light | 4 | 2 | Front passenger's door mirror | ||
| C764 | 2 | 16 | Front passenger's door | Front passenger's door subharness |
FRONT PASSENGER'S DOOR POWER MIRROR WIRE HARNESS
Scheme 1288
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Left rear door courtesy light | 7 | 2 | Left rear door | ||
| Left rear door inner handle light | 3 | 2 | Left rear door | ||
| Left rear door lock actuator/knob switch | 1 | 10 | Left rear door | ||
| Left rear door speaker | 6 | 2 | Left rear door | ||
| Left rear power window motor | 4 | 2 | Left rear door | ||
| Left rear power window switch | 2 | 14 | Left rear door | ||
| C771 | 5 | 18 | Left B-pillar | Floor wire harness (left branch) (see Floor Wire Harness (Left Branch) ) |
LEFT REAR DOOR WIRE HARNESS
Scheme 1289
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Right rear door courtesy light | 4 | 2 | Right rear door | ||
| Right rear door inner handle light | 1 | 2 | Right rear door | ||
| Right rear door lock actuator/knob switch | 3 | 10 | Right rear door | ||
| Right rear door speaker | 6 | 2 | Right rear door | ||
| Right rear power window motor | 5 | 2 | Right rear door | ||
| Right rear power window switch | 2 | U | Right rear door | ||
| C781 | 7 | 18 | Right B-pillar | Floor wire harness (right branch) (see Floor Wire Harness (Right Branch) ) |
RIGHT REAR DOOR WIRE HARNESS
Scheme 1290
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Driver's lumbar support motor | 15 | 2 | Right side of Driver's seat-back | ||
| Driver's power lumbar support switch | 4 | 5 | Left side of Driver's seat | ||
| Driver's power seat adjustment switch | 7 | 12 | Left side of Driver's seat | ||
| Driver's seat-back blower motor | 1 | 3 | Left side of Driver's seat-back | ||
| Driver's seat belt buckle switch | 13 | 2 | Under Driver's seat | ||
| Driver's seat cushion blower motor | 11 | 3 | Under Driver's seat | ||
| Driver's seat cushion heater | 8 | 5 | Under Driver's seat | ||
| Driver's seat front up-down motor/position sensor | 14 | 5 | Under Driver's seat | ||
| Driver's seat position sensor | 3 | 2 | Under Driver's seat | ||
| Driver's seat rear up-down motor/position sensor | 6 | 5 | Under Driver's seat | ||
| Driver's seat recline motor/position sensor | 2 | 5 | Left side of Driver's seat-back | ||
| Driver's seat slide motor/position sensor | 5 | 5 | Under Driver's seat | ||
| Driver's seat-back heater | 16 | 2 | Right side of Driver's seat-back | ||
| Power seat control unit connector A | 9 | 18 | Under Driver's seat | ||
| Power seat control unit connector B | 12 | 40 | Under Driver's seat | ||
| C601 | 10 | 23 | Under Driver's seat | Floor wire harness (left branch) (see Floor Wire Harness (Left Branch) ) |
DRIVER'S SEAT WIRE HARNESS (WITH SEAT VENTILATION)
Scheme 1291
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Driver's lumbar support motor | 16 | 2 | Right side of Driver's seat-back | ||
| Driver's power lumbar support switch | 4 | 5 | Left side of Driver's seat | ||
| Driver's power seat adjustment switch | 7 | 12 | Left side of Driver's seat | ||
| Driver's seat belt buckle switch | 11 | 2 | Under Driver's seat | ||
| Driver's seat cushion heater | 8 | 3 | Under Driver's seat | ||
| Driver's seat front up-down motor/position sensor | 15 | 5 | Under Driver's seat | ||
| Driver's seat heater relay (high) | 14 | 4 | Under Driver's seat | ||
| Driver's seat heater relay (low) | 13 | 5 | Under Driver's seat | ||
| Driver's seat position sensor | 3 | 2 | Under Driver's seat | ||
| Driver's seat rear up-down motor/position sensor | 6 | 5 | Under Driver's seat | ||
| Driver's seat recline motor/position sensor | 2 | 5 | Left side of Driver's seat-back | ||
| Driver's seat slide motor/position sensor | 5 | 5 | Under Driver's seat | ||
| Driver's seat-back heater | 1 | 2 | Right side of Driver's seat-back | ||
| Power seat control unit connector A | 9 | 18 | Under Driver's seat | ||
| Power seat control unit connector B | 12 | 40 | Under Driver's seat | ||
| C601 | 10 | 23 | Under Driver's seat | Floor wire harness (left branch) (see Floor Wire Harness (Left Branch) ) |
DRIVER'S SEAT WIRE HARNESS (WITHOUT SEAT VENTILATION)
Scheme 1292
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Front passenger's power seat adjustment switch | 11 | 12 | Right side of front passenger's seat | ||
| Front passenger's seat belt buckle switch | 6 | 2 | Under front passenger's seat | ||
| Front passenger's seat cushion blower motor | 3 | 3 | Under front passenger's seat | (1) | |
| Front passenger's seat cushion heater | 5 | 5 | Under front passenger's seat | (1) | |
| Front passenger's seat cushion heater | 5 | 4 | Under front passenger's seat | (2) | |
| Front passenger's seat front up-down motor | 2 | 2 | Under front passenger's seat | ||
| Front passenger's seat heater relay (high) | 7 | 4 | Under front passenger's seat | (2) | |
| Front passenger's seat heater relay (low) | 9 | 5 | Under front passenger's seat | (2) | |
| Front passenger's seat rear up-down motor | 13 | 2 | Under front passenger's seat | ||
| Front passenger's seat recline motor | 14 | 2 | Right side of front passenger's seat-back | ||
| Front passenger's seat slide motor | 10 | 5 | Under front passenger's seat | ||
| Front passenger's weight sensor (inner side) | 4 | 2 | Under front passenger's seat | ||
| Front passenger's weight sensor (outer side) | 12 | 3 | Under front passenger's seat | ||
| Front passenger's seat-back blower motor | 15 | 3 | Right side of front passenger's seat-back | (1) | |
| ODS unit | 1 | 18 | Left side of front passenger's seat-back | ||
| C602 | 8 | 18 | Under front passenger's seat | Floor wire harness (right branch) (see Floor Wire Harness (Right Branch) ) | |
| (1) With seat ventilation (2) Without seat ventilation | |||||
| (1) | With seat ventilation |
| (2) | Without seat ventilation |
FRONT PASSENGER'S SEAT WIRE HARNESS
Scheme 1293
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| ACC combination/select/reset/information/distance switch | 6 | 12 | Steering wheel | (1) | |
| Audio remote switch, HFL-navigation voice control switch | 1 | 12 | Steering wheel | ||
| Cable reel connector C | 3 | 20 | Steering wheel | ||
| Cruise control combination/select/reset/information switch | 6 | 12 | Steering wheel | (2) | |
| Horn switch | 7 | 1 | Steering wheel | ||
| Paddle shifter- (downshift switch) | 2 | 4 | Steering wheel | ||
| Paddle shifter (upshift switch) | 5 | 4 | Steering wheel | ||
| T6 | 4 | Steering wheel | Steering wheel | ||
| (1) With ACC (2) Without ACC | |||||
| (1) | With ACC |
| (2) | Without ACC |
CABLE REEL SUBHARNESS
Scheme 1294
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|---|---|---|---|---|
| Blower motor | 5 | 2 | Under right side of dash | ||
| Climate control unit connector A | 10 | 32 | Under right side of dash | ||
| Climate control unit connector B | 8 | 24 | Under right side of dash | ||
| Climate control unit connector C | 7 | 20 | Under right side of dash | ||
| Driver's air mix control motor | 13 | 7 | Under middle of dash | ||
| Driver's mode control motor | 14 | 7 | Under middle of dash | ||
| Evaporator temperature sensor | 15 | 2 | Under middle of dash | ||
| Passenger's air mix control motor | 11 | 7 | Under middle of dash | ||
| Passenger's footwell light | 6 | 2 | Under right side of dash | ||
| Passenger's mode control motor | 3 | 7 | Under middle of dash | ||
| Power transistor | 1 | 5 | Under middle of dash | ||
| Recirculation control motor | 2 | 7 | Under middle of dash | ||
| C201 | 4 | 2 | Under right side of dash | Right engine compartment wire harness (see Right Engine Compartment Wire Harness ) | |
| C408 | 12 | 12 | Under middle of dash | Dashboard wire harness (view of middle to passenger's side) (see Dashboard Wire Harness (View of Middle to Passenger's Side) ) | |
| C501 | 9 | 34 | Under middle of dash | Audio wire harness (see Audio Wire Harness ) |
A/C WIRE HARNESS
