Oem Circuit Diagrams Acura ZDX I

Power Distribution

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Power Distribution Circuit Diagram (Page 10). Scheme 52

Power Distribution Circuit Diagram (Page 10-1). Scheme 53

Power Distribution Circuit Diagram (Page 10-2). Scheme 54

Power Distribution Circuit Diagram (Page 10-3). Scheme 55

Power Distribution Circuit Diagram (Page 10-4). Scheme 56

Power Distribution Circuit Diagram (Page 10-5). Scheme 57

Power Distribution Circuit Diagram (Page 10-6). Scheme 58

Power Distribution Circuit Diagram (Page 10-7). Scheme 59

Power Distribution Circuit Diagram (Page 10-8). Scheme 60

Power Distribution Circuit Diagram (Page 10-9). Scheme 61

Power Distribution Circuit Diagram (Page 10-10). Scheme 62

Power Distribution Circuit Diagram (Page 10-11). Scheme 63

Power Distribution Circuit Diagram (Page 10-12). Scheme 64

Power Distribution Circuit Diagram (Page 10-13). Scheme 65

Power Distribution Circuit Diagram (Page 10-14). Scheme 66

Power Distribution Circuit Diagram (Page 10-15). Scheme 67

Ground Distribution

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Ground Distribution Circuit Diagram - G1, G2 And G3 (Page 14). Scheme 68

Ground Distribution Circuit Diagram - G101 (Page 14-1). Scheme 69

Ground Distribution Circuit Diagram - G201 (Page 14-2). Scheme 70

Ground Distribution Circuit Diagram - G202 (Page 14-2). Scheme 71

Ground Distribution Circuit Diagram - G203 (Page 14-3). Scheme 72

Ground Distribution Circuit Diagram - G301 (Page 14-3). Scheme 73

Ground Distribution Circuit Diagram - G302 (Page 14-4). Scheme 74

Ground Distribution Circuit Diagram - G303 (Page 14-4). Scheme 75

Ground Distribution Circuit Diagram - G401 (Page 14-5). Scheme 76

Ground Distribution Circuit Diagram - G402 (Page 14-6). Scheme 77

Ground Distribution Circuit Diagram - G403 (Page 14-7). Scheme 78

Ground Distribution Circuit Diagram - G404 (Page 14-7). Scheme 79

Ground Distribution Circuit Diagram - G404 (Page 14-8). Scheme 80

Ground Distribution Circuit Diagram - G501, G502 (Page 14-9). Scheme 81

Ground Distribution Circuit Diagram - G601 (Page 14-9). Scheme 82

Ground Distribution Circuit Diagram - G602 (Page 14-10). Scheme 83

Ground Distribution Circuit Diagram - G603 (Page 14-11). Scheme 84

Ground Distribution Circuit Diagram - G604 (Page 14-12). Scheme 85

Ground Distribution Circuit Diagram - G651 (Page 14-13). Scheme 86

Ground Distribution Circuit Diagram - G652 (Page 14-14). Scheme 87

Ground Distribution Circuit Diagram - G701 (Page 14-14). Scheme 88

Splice and Junction Connector Details

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

A/T Park Position Circuit Diagram (Page 15). Scheme 89

A/T Reverse Position Circuit Diagram (Page 15). Scheme 90

Back-Up Lights Circuit Diagram (Page 15-1). Scheme 91

Parking Brake Position Circuit Diagram (Page 15-1). Scheme 92

Brake Pedal Position Circuit Diagram - Without ACC (Page 15-2). Scheme 93

Brake Pedal Position Circuit Diagram (Page 15-2). Scheme 94

PCM Controlled Power Source Circuit Diagram (Page 15-3). Scheme 95

Left Turn Signal Circuit Diagram (Page 15-3). Scheme 96

PCM Relay Control Circuit Diagram (Page 15-4). Scheme 97

Engine Speed Pulse Circuit Diagram (Page 15-4). Scheme 98

Reference Voltage For PCM Sensors (VCC6) Circuit Diagram (Page 15-5). Scheme 99

Ground For PCM Sensor (SG2) Circuit Diagram (Page 15-5). Scheme 100

Ground For PCM Sensor (SG4) Circuit Diagram (Page 15-6). Scheme 101

Ground For Climate Control Sensors Circuit Diagram (Page 15-7). Scheme 102

Illumination (Positive) Circuit (Page 15-8). Scheme 103

Illumination (Positive) Circuit (Page 15-9). Scheme 104

Illumination (Positive) Circuit (Page 15-10). Scheme 105

Illumination (Negative) Circuit Diagram - LED (Page 15-11). Scheme 106

Illumination (Negative) Circuit Diagram - LED (Page 15-12). Scheme 107

Illumination (Negative) Circuit Diagram - LED (Page 15-13). Scheme 108

Illumination (Negative) Circuit Diagram - LED (Page 15-14). Scheme 109

Power Source For PCM Circuit Diagram (Page 15-15). Scheme 110

Reference Voltage For Climate Control Sensors Circuit Diagram (Page 15-16). Scheme 111

Reference Voltage For PCM Sensors (VCC1) Circuit Diagram (Page 15-16). Scheme 112

Reference Voltage For PCM Sensors (VCC4) Circuit Diagram (Page 15-17). Scheme 113

Right Turn Signal Circuit Diagram (Page 15-18). Scheme 114

Switch Illumination Circuit Diagram (Page 15-18). Scheme 115

Power Tailgate Position Circuit Diagram (Page 15-19). Scheme 116

DLC (Data Link Connector)

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Data Link Connector Circuit Diagram (Page 16). Scheme 117

Data Link Connector Circuit Diagram (Page 16-1). Scheme 118

Data Link Connector Circuit Diagram (Page 16-2). Scheme 119

Data Link Connector Circuit Diagram (Page 16-3). Scheme 120

Ignition System

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Ignition System Circuit Diagram (Page 20). Scheme 121

Starting System

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Starting System Circuit Diagram - Without Keyless Access (Page 21). Scheme 122

Starting System Circuit Diagram - Without Keyless Access (Page 21-1). Scheme 123

Starting System Circuit Diagram - Keyless Access (Page 21-2). Scheme 124

Starting System Circuit Diagram - Keyless Access (Page 21-3). Scheme 125

Starting System Circuit Diagram - Keyless Access (Page 21-4). Scheme 126

Remote Starting System (Acura Accessory) - Without Keyless Access (Page 21-5). Scheme 127

Remote Starting System (Acura Accessory) - Without Keyless Access (Page 21-6). Scheme 128

Remote Starting System (Acura Accessory) - Without Keyless Access (Page 21-7). Scheme 129

Remote Starting System (Acura Accessory) - Without Keyless Access (Page 21-8). Scheme 130

Remote Starting System (Acura Accessory) - Without Keyless Access (Page 21-9). Scheme 131

Remote Starting System (Acura Accessory) - Without Keyless Access (Page 21-10). Scheme 132

Remote Starting System (Acura Accessory) - Without Keyless Access (Page 21-11). Scheme 133

Remote Starting System (Acura Accessory) - With Keyless Access (Page 21-12). Scheme 134

Remote Starting System (Acura Accessory) - With Keyless Access (Page 21-13). Scheme 135

Remote Starting System (Acura Accessory) - With Keyless Access (Page 21-14). Scheme 136

Remote Starting System (Acura Accessory) - With Keyless Access (Page 21-15). Scheme 137

Remote Starting System (Acura Accessory) - With Keyless Access (Page 21-16). Scheme 138

Remote Starting System (Acura Accessory) - With Keyless Access (Page 21-17). Scheme 139

Remote Starting System (Acura Accessory) - With Keyless Access (Page 21-18). Scheme 140

Remote Starting System (Acura Accessory) - With Keyless Access (Page 21-19). Scheme 141

How the Remote Starting System Circuit Works

The Remote Starting System is designed to remotely start the engine without using the ignition key. The ignition key must be utilized to drive the vehicle.

The transmitter can start the engine provided all of the following conditions are met

1. The gearshift lever is in the "P" (Park) position. (See «INTERLOCK SYSTEM»(/acura/zdx/i-2009-2013/remont/body-electrical/#oem-circuit-diagrams__interlock-system) )
2. The brake pedal is not depressed. (See «INTERLOCK SYSTEM»(/acura/zdx/i-2009-2013/remont/body-electrical/#oem-circuit-diagrams__interlock-system) )
3. The ignition key is not inserted into the ignition switch. (See «Keyless Entry System/Power Door Lock System/Security System»(/acura/zdx/i-2009-2013/remont/body-electrical/#oem-circuit-diagrams__keyless-entry-systempower-door-lock-systemsecurity) )
4. The remote slot is not inserted into the remote slot control unit. (See «KEYLESS ACCESS SYSTEM»(/acura/zdx/i-2009-2013/remont/body-electrical/#oem-circuit-diagrams__keyless-access-system) )
5. The hood is securely closed. (See «Keyless Entry System/Power Door Lock System/Security System»(/acura/zdx/i-2009-2013/remont/body-electrical/#oem-circuit-diagrams__keyless-entry-systempower-door-lock-systemsecurity) )
6. All of the doors are closed and locked. (See «Keyless Entry System/Power Door Lock System/Security System»(/acura/zdx/i-2009-2013/remont/body-electrical/#oem-circuit-diagrams__keyless-entry-systempower-door-lock-systemsecurity) )
7. The trunk is closed. (See «Keyless Entry System/Power Door Lock System/Security System»(/acura/zdx/i-2009-2013/remont/body-electrical/#oem-circuit-diagrams__keyless-entry-systempower-door-lock-systemsecurity) )
8. The security system has not been triggered. (See «Keyless Entry System/Power Door Lock System/Security System»(/acura/zdx/i-2009-2013/remont/body-electrical/#oem-circuit-diagrams__keyless-entry-systempower-door-lock-systemsecurity) )
9. The panic warning system is not activated. (See «Keyless Entry System/Power Door Lock System/Security System»(/acura/zdx/i-2009-2013/remont/body-electrical/#oem-circuit-diagrams__keyless-entry-systempower-door-lock-systemsecurity) )

The engine automatically stops when any of the following conditions is satisfied after starting the engine with the transmitter

1. A specified engine running time has expired.
2. The gearshift lever is in any position but "P" (Park). (See «INTERLOCK SYSTEM»(/acura/zdx/i-2009-2013/remont/body-electrical/#oem-circuit-diagrams__interlock-system) )
3. The brake pedal is pressed. (See «INTERLOCK SYSTEM»(/acura/zdx/i-2009-2013/remont/body-electrical/#oem-circuit-diagrams__interlock-system) )
4. The ignition key is inserted into the ignition switch. (See «Keyless Entry System/Power Door Lock System/Security System»(/acura/zdx/i-2009-2013/remont/body-electrical/#oem-circuit-diagrams__keyless-entry-systempower-door-lock-systemsecurity) )
5. The hood is opened. (See «Keyless Entry System/Power Door Lock System/Security System»(/acura/zdx/i-2009-2013/remont/body-electrical/#oem-circuit-diagrams__keyless-entry-systempower-door-lock-systemsecurity) )
6. Any of the doors is opened or unlocked. (See «Keyless Entry System/Power Door Lock System/Security System»(/acura/zdx/i-2009-2013/remont/body-electrical/#oem-circuit-diagrams__keyless-entry-systempower-door-lock-systemsecurity) )
7. The trunk is opened. (See «Keyless Entry System/Power Door Lock System/Security System»(/acura/zdx/i-2009-2013/remont/body-electrical/#oem-circuit-diagrams__keyless-entry-systempower-door-lock-systemsecurity) )
8. The security system has been triggered. (See «Keyless Entry System/Power Door Lock System/Security System»(/acura/zdx/i-2009-2013/remont/body-electrical/#oem-circuit-diagrams__keyless-entry-systempower-door-lock-systemsecurity) )
9. The panic warning system is activated. (See «Keyless Entry System/Power Door Lock System/Security System»(/acura/zdx/i-2009-2013/remont/body-electrical/#oem-circuit-diagrams__keyless-entry-systempower-door-lock-systemsecurity) )
10. The engine speed rises to 4, 000 rpm or more. (See «GAUGES AND INDICATORS»(/acura/zdx/i-2009-2013/remont/body-electrical/#oem-circuit-diagrams__gauges-and-indicators) )
11. The engine malfunction indicator comes on. (See «GAUGES AND INDICATORS»(/acura/zdx/i-2009-2013/remont/body-electrical/#oem-circuit-diagrams__gauges-and-indicators) )
12. The low oil pressure indicator comes on. (See «LOW OIL PRESSURE INDICATOR»(/acura/zdx/i-2009-2013/remont/body-electrical/#oem-circuit-diagrams__reminder-systems-key-light-timer-and) )

Refer to the Remote Starting System User's Information manual for system function and safety guidelines.

Charging System

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Charging System Circuit Diagram (Page 22). Scheme 142

Fuel and Emissions

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

PCM Power And Ground Circuit Diagram (Page 23). Scheme 143

MIL Circuit Diagram (Page 23-1). Scheme 144

PGM-FI System Circuit Diagram (Page 23-2). Scheme 145

PGM-FI System Circuit Diagram (Page 23-3). Scheme 146

PGM-FI System Circuit Diagram (Page 23-4). Scheme 147

PGM-FI System Circuit Diagram (Page 23-5). Scheme 148

PGM-FI System Circuit Diagram (Page 23-6). Scheme 149

Electronic Throttle Control System Circuit Diagram (Page 23-7). Scheme 150

Idle Control System Circuit Diagram (Page 23-8). Scheme 151

Fuel Supply System Circuit Diagram (Page 23-9). Scheme 152

EVAP System Circuit Diagram (Page 23-10). Scheme 153

EGR System Circuit Diagram (Page 23-11). Scheme 154

Intake Air System Circuit Diagram (Page 23-11). Scheme 155

Engine Mount Control System

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Engine Mount Control System Circuit Diagram (Page 30). Scheme 156

VTEC System

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

VTEC System Circuit Diagram (Page 31). Scheme 157

Cruise Control

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Cruise Control Circuit Diagram - Without ACC (Page 34). Scheme 158

Cruise Control Circuit Diagram - Without ACC (Page 34-1). Scheme 159

Cruise Control Circuit Diagram - Without ACC (Page 34-2). Scheme 160

How the Circuit Works

The vehicle does not use a throttle cable or cruise control actuator to maintain the vehicle speed during the cruise control mode. A throttle actuator control motor, located on the side of the throttle housing, is used to open and close the throttle plate for routine driving and cruise conditions.

Power Supply

Battery voltage is supplied at all times through fuse 18 (in the under-hood fuse/relay box) to the ETCS control relay contacts, and through fuse 10 (in the under-hood fuse/relay box) to the horn relay and brake pedal position switch. Battery voltage is also supplied at all times through fuse 15 (in the under-hood fuse/relay box) to the gauge control module.

With the ignition switch in ON (II) or START (III) or the engine start/stop switch pressed to select ON or START mode, battery voltage is supplied through fuse 13 (in the driver's under-dash fuse/relay box) to the brake pedal position switch and then to the PCM and through fuse 5 (in the driver's under-dash fuse/relay box) to the gauge control module and then to the main switch of the cruise control combination switch.

System Description

When the main switch is pressed, a battery voltage input is removed from the gauge control module, and the cruise control main switch indicator LED illuminates. With the shift lever in D or S, a path to ground is provided for the drive input to the PCM. The PCM detects that the shift lever is in D or S through this input, which enables the cruise control.

When the set switch is pressed, a voltage signal is sent to the gauge control module. The gauge control module grounds the cruise control indicator LED, illuminating it. The gauge control module communicates the set signal via multiplex communication lines to the PCM. Using the vehicle speed input obtained from the output shaft (countershaft) speed sensor, the PCM sends signals to, and receives signals from, the TP sensor/throttle actuator, which opens and closes the throttle to maintain the set speed.

When the brake pedal is pressed, a battery voltage input is sent to the PCM through fuse 10 (in the under-hood fuse/relay box) and the battery voltage input through fuse 13 (in the driver's under-dash fuse/relay box) is removed. The PCM communicates the brake pedal pressed information via multiplex communication lines to the gauge control module, which removes ground from the cruise control indicator LED, turning it off. The information is also used by the PCM to remove the cruise control system's control of the throttle.

When the resume switch is pressed, a voltage signal is sent to the gauge control module. The gauge control module grounds the cruise control indicator LED, illuminating it. The gauge control module communicates the resume signal via multiplex communication lines to the PCM. Using the vehicle speed input obtained from the output shaft (countershaft) speed sensor, the PCM sends signals to, and receives signals from, the TP sensor/throttle actuator, which opens and closes the throttle to resume and maintain the previously set speed.

When the cancel switch is pressed, two voltage signals are sent to the gauge control module. The gauge control module removes ground from the cruise control indicator LED, turning it off. The gauge control module communicates the cancel signal via multiplex communication lines to the PCM. The information is also used by the PCM to remove the cruise control system's control of the throttle.

Refer to the CRUISE CONTROL for specific tests or troubleshooting procedures.

ACC System (Adaptive Cruise Control)

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

ACC System Circuit Diagram (Page 35). Scheme 161

ACC System Circuit Diagram (Page 35-1). Scheme 162

ACC System Circuit Diagram (Page 35-2). Scheme 163

VSA

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

VSA Circuit Diagram (Page 36). Scheme 164

VSA Circuit Diagram (Page 36-1). Scheme 165

SH-AWD (Super Handling All-wheel Drive)

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Super Handling All-wheel Drive Circuit Diagram (Page 37). Scheme 166

Super Handling All-wheel Drive Circuit Diagram (Page 37-1). Scheme 167

A/T Controls

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

A/T Controls Circuit Diagram (Page 39). Scheme 168

A/T Controls Circuit Diagram (Page 39-1). Scheme 169

A/T Controls Circuit Diagram (Page 39-2). Scheme 170

A/T Controls Circuit Diagram (Page 39-3). Scheme 171

Horns

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Horns Circuit Diagram (Page 40). Scheme 172

ADS (Active Damping System)

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Active Damping System (IDS) Circuit Diagram (Page 42). Scheme 173

Active Damping System (IDS) Circuit Diagram (Page 42-1). Scheme 174

Active Damping System (IDS) Circuit Diagram (Page 42-2). Scheme 175

Active Damping System (IDS) Circuit Diagram (Page 42-3). Scheme 176

ECPS

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

ECPS (IDS) Circuit Diagram (Page 45). Scheme 177

SRS

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

SRS Circuit Diagram (Page 47). Scheme 178

SRS Circuit Diagram (Page 47-1). Scheme 179

SRS Circuit Diagram (Page 47-2). Scheme 180

SRS Circuit Diagram (Page 47-3). Scheme 181

SRS Circuit Diagram (Page 47-4). Scheme 182

E-Pretensioner

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

E-Pretensioner (ACC) Circuit Diagram (Page 48). Scheme 183

Collision Mitigation Brake System (ACC) Circuit Diagram (Page 49). Scheme 184

Power, Grounds, And Diagnostics Circuit Diagram (Page 50). Scheme 185

Power, Grounds, And Diagnostics Circuit Diagram (Page 50-1). Scheme 186

B-CAN Communication Line Circuit Diagram - High (Page 50-2). Scheme 187

B-CAN Communication Line Circuit Diagram - Low (Page 50-3). Scheme 188

F-CAN Communication Line Circuit Diagram - High (Page 50-4). Scheme 189

F-CAN Communication Line Circuit Diagram - Low (Page 50-5). Scheme 190

Secondary F-CAN Communication Line Circuit Diagram - High And Low (Page 50-6). Scheme 191

K-line Communication Line Circuit Diagram (Page 50-7). Scheme 192

UART Communication Line Circuit Diagram (Page 50-8). Scheme 193

GA-NET Circuit Diagram (Page 50-9). Scheme 194

The multiplex integrated control system sends digital signals between control units through shared wires to reduce the number of wires in order to make harnesses lighter.

The input signals from each switch are converted to digital signals within the receiving control unit. The digital signals are sent from one control unit to another as serial data over dedicated communication lines. When the appropriate control unit receives the digital signal, it converts the signal back to an operational command, such as operating a relay. The multiplex integrated control system schematic shows its power, grounds, and communication lines.

There are two different networks within the multiplex integrated control system

1. Body Controller Area Network (B-CAN)
2. Fast Controller Area Network (F-CAN)

The body controller area network (B-CAN) and fast controller area network (F-CAN) share information between multiple electronic control units and work together to form the multiplex integrated control system. The gauge control module translates information from B-CAN to F-CAN and from F-CAN to B-CAN to allow the networks to share information.

B-CAN Network

B-CAN information is transmitted across the communication lines at a slower speed for convenience related operations that do not require a high process speed. The following systems are related to the B-CAN network

1. Audio System
2. Battery Management System
3. Blind Spot Information System
4. Collision Mitigation Brake System
5. Driving Position Memory System
6. Entry Light Control System
7. Exterior Lights
8. Gauges and Indicators
9. Horns
10. HVAC
11. Immobilizer System
12. Interior Lights
13. Interlock System
14. Navigation System
15. Panoramic Roof Glass
16. Parking Sensor System
17. Keyless Entry System/Power Door Lock System/Security System
18. Power Tailgate
19. Power Windows
20. Rear Window Defogger
21. Reminder Systems
22. Safety Indicator
23. Wiper/Washer

F-CAN Network

F-CAN information is transmitted across the communication lines at a faster speed for "real time" functions such as fuel, emissions, and traction control data. The following control units operate on the F-CAN network

1. ACC Unit
2. Active Damper Control Unit
3. AcuraLink Control Unit
4. E-pretensioner Unit
5. PCM
6. Gauge Control Module
7. SH-AWD Control Unit
8. SRS Unit
9. Steering Angle Sensor
10. TPMS Control Unit
11. VSA Modulator-Control Unit
12. Yaw Rate-Lateral Longitudinal Acceleration Sensor

Refer to the MULTIPLEX INTEGRATED CONTROL SYSTEM for testing and troubleshooting procedures.

HVAC Circuit Diagram (Page 60). Scheme 195

HVAC Circuit Diagram (Page 60-1). Scheme 196

HVAC Circuit Diagram (Page 60-2). Scheme 197

HVAC Circuit Diagram (Page 60-3). Scheme 198

HVAC Circuit Diagram (Page 60-4). Scheme 199

Fans Circuit Diagram (Page 63). Scheme 200

Battery voltage is supplied at all times through Multi-fuse 3 (in the under-hood fuse/relay box) to the contacts of the A/C Condenser Fan Relay and Radiator Fan Relay. With the ignition switch in ON (II) or the engine start/stop switch in ON, battery voltage is supplied through fuse 16 (in the driver's under-dash fuse/relay box) to the coils of the A/C Condenser Fan Relay and Fan Control Relay. With the engine running, battery voltage is supplied through fuse 21 (in the under-hood fuse/relay box) to the Radiator Fan Relay coil.

Extremely High Coolant Temperatures

In extremely high coolant temperature conditions (Above 206°F (97°C)), the PCM provides ground to the coils of the A/C Condenser Fan Relay, the Radiator Fan Relay, and the Fan Control Relay, energizing them. Battery voltage is supplied to the A/C Condenser Fan Motor and Radiator Fan Motor through their respective energized relays, which activates the motors at high speed.

A/CON

The PCM detects that the A/C is ON through an input from the A/C Pressure Sensor. Upon receiving the A/C ON information, the PCM provides ground to the coil of the A/C Condenser Fan Relay, energizing it. Battery voltage is supplied to the A/C Condenser Fan Motor and Radiator Fan Motor in series through the energized relay, which activates the motors at low speed.

If the refrigerant pressure rises above 1470 kPa (213 psi), the A/C Pressure Sensor signals the PCM to run the fans at high speed. The PCM provides ground to the coils of the A/C Condenser Fan Relay, the Radiator Fan Relay, and the Fan Control Relay, energizing them. Battery voltage is supplied to the A/C Condenser Fan Motor and Radiator Fan Motor through their respective energized relays, which activates the motors at high speed.

Refrigerant at Low Pressure

If the refrigerant pressure drops below 196 kPa (28 psi), the A/C Pressure Sensor signals the PCM to turn off the fans. Upon receiving the signal to turn off the fans, the PCM removes ground from the coil of the A/C Condenser Fan Relay, de-energizing it. This removes battery voltage from the A/C Condenser Fan Motor and Radiator Fan Motor, which deactivates the motors.

Refrigerant at High Pressure

If the refrigerant pressure rises above 3138 kPa (455 psi), the A/C Pressure Sensor signals the PCM to turn off the fans. Upon receiving the signal to turn off the fans, the PCM removes ground from the coils of the A/C Condenser Fan Relay, the Radiator Fan Relay, and the Fan Control Relay, de-energizing them. This removes battery voltage from the A/C Condenser Fan Motor and Radiator Fan Motor, which deactivates the motors.

Refer to the FAN CONTROLS for specific tests and troubleshooting procedures.

Rear Window/Power Mirror Defoggers Circuit Diagram (Page 64). Scheme 201

Rear Window/Power Mirror Defoggers Circuit Diagram (Page 64-1). Scheme 202

Rear Window Defogger

Battery voltage is supplied at all times to the Rear Window Defogger Relay contacts through fuse 8 (in the under-hood fuse/relay box). With the ignition switch in ON (II) or the engine start/stop switch in ON, battery voltage is supplied to the Rear Window Defogger Relay coil and to the Climate Control Unit through fuse 16 (in the driver's under-dash fuse/relay box).

When the Rear Window Defogger Switch/Mirror Defogger Switch (in the Audio-Navigation and HVAC Switch Panel, or the Audio and HVAC Switch Panel) is pressed, the defog signal is sent to the Driver's MICU. The Driver's MICU provides ground to the Rear Window Defogger Relay coil, energizing the relay. Battery voltage is supplied to the Rear Window Defogger through the energized relay.

The Rear Window Defogger is turned off by pressing the Rear Window Defogger/Mirror Defogger Switch a second time or by turning the ignition switch to LOCK (0) or the engine start/stop switch to OFF.

Power Mirror Defoggers

Battery voltage is supplied at all times to the Front Passenger's Power Window Switch through fuse 13 (in the passenger's under-dash fuse/relay box). With the ignition switch in ON (II) or the engine start/stop switch ON, battery voltage is supplied to the Power Window Master Switch and to the HVAC Control Unit or Climate Control Unit through fuse 16 (in the driver's under-dash fuse/relay box).

When the Rear Window Defogger Switch/Mirror Defogger Switch (in the Audio-Navigation and HVAC Switch Panel, or the Audio and HVAC Switch Panel) is pressed, the defog signal is sent to the Power Window Master Switch via B-CAN and then to the Front Passenger's Power Window Switch via UART. The Power Window Master Switch supplies battery voltage to the Left Power Mirror Defogger and the Front Passenger's Power Window Switch supplies battery voltage to the Right Power Mirror Defogger.

The Power Mirror Defoggers are turned off by pressing the Rear Window Defogger Switch/Mirror Defogger Switch a second time or by turning the ignition switch to LOCK (0) or the engine start/stop switch to OFF.

Refer to the REAR WINDOW DEFOGGER for specific tests and troubleshooting procedures.

Reminder Systems, Key Light Timer, and Low Oil Pressure Indicator

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Reminder Systems, Key Light Timer And Low Oil Pressure Indicator Circuit Diagram (Page 73). Scheme 203

Reminder Systems, Key Light Timer And Low Oil Pressure Indicator Circuit Diagram (Page 73-1). Scheme 204

Reminder Systems, Key Light Timer And Low Oil Pressure Indicator Circuit Diagram (Page 73-2). Scheme 205

Reminder Systems, Key Light Timer And Low Oil Pressure Indicator Circuit Diagram (Page 73-3). Scheme 206

Reminder Systems, Key Light Timer And Low Oil Pressure Indicator Circuit Diagram (Page 73-4). Scheme 207

Gauges and Indicators

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Gauges And Indicators Circuit Diagram (Page 80). Scheme 208

Gauges And Indicators Circuit Diagram (Page 80-1). Scheme 209

Gauges And Indicators Circuit Diagram (Page 80-2). Scheme 210

Gauges And Indicators Circuit Diagram (Page 80-3). Scheme 211

Gauges And Indicators Circuit Diagram (Page 80-4). Scheme 212

Gauges And Indicators Circuit Diagram (Page 80-5). Scheme 213

The gauges and indicators are part of the multiplex integrated control system. Some indicators are controlled by conditions in their specific systems. Information for these indicators is communicated from control unit to control unit across multiplex communication lines. The following indicators are communicated to the gauge control module through the multiplex integrated control system

1. ABS Indicator
2. ACC Indicator
3. A/T Indicator
4. Charging System Indicator
5. CMBS Indicator
6. Cruise Control Indicator
7. Cruise Main Switch ON Indicator
8. Differential Oil Temperature Indicator
9. DRL Indicator
10. EBD Indicator
11. ECPS Indicator
12. Fog Light Indicator
13. High Beam Indicator
14. Keyless Access Indicator
15. Low Fuel Warning Indicator
16. Low Oil Pressure Indicator
17. Maintenance Minder Indicator
18. Maintenance Minder Change Oil Indicator
19. Maintenance Required Indicator
20. Master Warning Indicator
21. MIL Indicator
22. Open Door Indicator
23. Parking Light ON Indicator
24. Seat Belt Indicator
25. Security Indicator
26. SH-AWD Indicator
27. Side Airbag Cut-off Indicator
28. SRS Indicator
29. Starter Relay Indicator
30. Tailgate Open Indicator
31. Tire Pressure Warning Indicator
32. VSA/TCS System Indicator
33. VSA/TCS Activation Indicator
34. Washer Fluid Level Indicator

Refer to each individual system for more information. Also refer to the Multiplex Integrated Control System for more multiplex information.

Engine Coolant Temperature Gauge

The 5V stabilizer circuit/controller area network controller built-into the gauge control module controls the engine coolant temperature gauge. The PCM provides engine coolant temperature information to the 5V stabilizer circuit/controller area network controller through the fast controller area network (F-CAN) data lines. The PCM receives engine coolant temperature information from ECT sensor 1 and ECT sensor 2.

Fuel Gauge and Low Fuel Indicator

The fuel gauge and low fuel indicator are controlled by the 5V stabilizer circuit/controller area network controller in the gauge control module. When the resistance of the fuel gauge sending unit changes, the 5V stabilizer circuit/controller area network controller in the gauge control module sends a signal through a dedicated data line to the fuel gauge in the gauge control module to display fuel level. When it is determined that the fuel level is low, the low fuel level indicator is activated.

Speedometer

The speedometer is controlled by the 5V stabilizer circuit/controller area network controller in the gauge control module. The 5V stabilizer circuit/controller area network controller in the gauge control module receives vehicle speed information from the PCM through the fast controller area network (F-CAN) data lines. The 5V stabilizer circuit/controller area network controller sends vehicle speed information through a dedicated data line to the speedometer in the gauge control module, which displays the vehicle speed.

Tachometer

The tachometer is controlled by the 5V stabilizer circuit/controller area network controller in the gauge control module. The 5V stabilizer circuit/controller area network controller in the gauge control module receives engine speed information from the PCM through the fast controller area network (F-CAN) data lines. The 5V stabilizer circuit/controller area network controller controls the tachometer display.

Safety Indicator

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Safety Indicator Circuit Diagram (Page 84). Scheme 214

Safety Indicator Circuit Diagram (Page 84-1). Scheme 215

Safety Indicator Circuit Diagram (Page 84-2). Scheme 216

TPMS (Tire Pressure Monitoring System)

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Tire Pressure Monitoring System Circuit Diagram (Page 85). Scheme 217

Tire Pressure Monitoring System Circuit Diagram (Page 85-1). Scheme 218

BSI System (Blind Spot Information)

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Blind Spot Information System Circuit Diagram (Page 86). Scheme 219

Battery Management System

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Battery Management System Circuit Diagram (Page 87). Scheme 220

A/T Gear Position Indicator

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

A/T Gear Position Indicator (Page 89). Scheme 221

Wiper/Washer

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Wiper/Washer Circuit Diagram (Page 91). Scheme 222

Wiper/Washer Circuit Diagram (Page 91-1). Scheme 223

Wiper/Washer Circuit Diagram (Page 91-2). Scheme 224

The wiper/washer system is part of the multiplex integrated control system. The Driver's MICU, Passenger's MICU, and the Windshield Wiper/Washer Switch are the main operation controls of the wiper/washer system. The Wiper Motor Relay, Wiper Intermittent Relay, and Wiper High/Low Relay are incorporated in the Under-hood Fuse/Relay Box.

Testing of the multiplex components and reading Diagnostic Trouble Codes (DTCs) can be done by using an HDS Tester. The Windshield Wiper Motor and Windshield Washer Motor also can be tested manually without an HDS Tester.

Refer to the WIPER SYSTEM / WASHER SYSTEM for specific tests and troubleshooting procedures.

Battery voltage is supplied at all times to the Wiper Motor Relay contacts through Multi-fuse 3 (in the under-hood fuse/relay box). With the ignition switch in ON (II) or START (III) or the engine start/stop switch in ON or START, battery voltage is supplied to the Driver's MICU and the Passenger's MICU through fuse 12 (in the driver's under-dash fuse/relay box). With the ignition switch in ON (II) or START (III) or the engine start/stop switch in ON or START, battery voltage is also supplied to the Wiper Motor Relay coil through fuse 4 (in the driver's under-dash fuse/relay box) and to the Windshield Washer Relay through fuse 3 (in the driver's under-dash fuse/relay box).

Mist

Then the Windshield Wiper Switch is moved to MIST, the signal for mist is communicated to the Driver's MICU. The Driver's MICU provides ground to the Wiper Intermittent Relay coil, energizing the relay. Battery voltage is supplied through the energized Wiper Intermittent Relay and the static Wiper High/Low Relay to the high winding of the Windshield Wiper Motor, causing the motor to run in high. As soon as the motor starts running, the mechanical park/run switch built into the motor will move from PARK to RUN. With the motor running, the mechanical park/run switch is in RUN, removing ground from the motor input to the Driver's MICU. If the switch is held in MIST for multiple wiper cycles, the PARK/RUN switch will alternate between PARK and RUN, indicating what position the wipers are in to the Driver's MICU.

Intermittent

When the Windshield Wiper Switch is moved to INTERMITTENT, the signal for intermittent and the signal for the intermittent dwell time controller are input to the Driver's MICU. The Driver's MICU provides ground to the Wiper Intermittent Relay coil and the Wiper High/Low Relay coil, energizing the relays. Battery voltage is supplied through the energized Wiper Intermittent Relay and the energized Wiper High/Low Relay to the low winding of the Windshield Wiper Motor, causing the motor to run in low. As soon as the motor starts running, the mechanical park/run switch built into the motor will move from PARK to RUN. With the motor running, the mechanical park/run switch is in RUN, removing ground from the motor input to the Driver's MICU. If the switch is in INTERMITTENT for multiple wiper cycles, the PARK/RUN switch will alternate between PARK and RUN, indicating what position the wipers are in to the Driver's MICU.

Low Speed

When the Windshield Wiper Switch is moved to LOW, the signal for low is communicated to the Driver's MICU. The Driver's MICU provides ground to the Wiper Intermittent Relay coil and the Wiper High/Low Relay coil, energizing the relays. Battery voltage is supplied through the energized Wiper Intermittent Relay and the energized Wiper High/Low Relay to the low winding of the Windshield Wiper Motor, causing the motor to run in low. As soon as the motor starts running, the mechanical park/run switch built into the motor will move from PARK to RUN. With the motor running, the mechanical park/run switch is in RUN, removing ground from the motor input to the Driver's MICU. If the switch is in LOW for multiple wiper cycles, the PARK/RUN switch will alternate between PARK and RUN, indicating what position the wipers are in to the Driver's MICU.

When the Windshield Wiper Switch is moved to OFF, the signal for off is communicated to the Driver's MICU. Once the wipers reach the PARK position, the Driver's MICU removes the ground from the Wiper Intermittent Relay, de-energizing the relay. De-energizing the Wiper Intermittent Relay removes battery voltage from the Windshield Wiper Motor.

High Speed

When the Windshield Wiper Switch is moved to HIGH, the signal for high is communicated to the Driver's MICU. The Driver's MICU provides ground to the Wiper Intermittent Relay coil, energizing the relay. Battery voltage is supplied through the energized Wiper Intermittent Relay and the static Wiper High/Low Relay to the high winding of the Windshield Wiper Motor, causing the motor to run in high. As soon as the motor starts running, the mechanical park/run switch built into the motor will move from PARK to RUN. With the motor running, the mechanical park/run switch is in RUN, removing ground from the motor input to the Driver's MICU. If the switch is in HIGH for multiple wiper cycles, the PARK/RUN switch will alternate between PARK and RUN, indicating what position the wipers are in to the Driver's MICU.

When the Windshield Wiper Switch is moved to OFF, the signal for off is communicated to the Driver's MICU. Once the wipers reach the PARK position, the Driver's MICU removes the ground from the Wiper Intermittent Relay, de-energizing the relay. De-energizing the Wiper Intermittent Relay removes battery voltage from the Windshield Wiper Motor.

Washer

When the Windshield Washer Switch is moved to WASH, the signal for wash is communicated to the Driver's MICU. The Driver's MICU communicates the wash signal via B-CAN to the Passenger's MICU. The Passenger's MICU provides ground to the Windshield Washer Relay coil, energizing the relay. Battery voltage is supplied through the energized Windshield Washer Relay to the Windshield Washer Motor, causing the motor to pump washer fluid onto the windshield. Meanwhile, the Driver's MICU provides ground to the Intermittent Wiper Relay coil and the Wiper High/Low Relay coil, energizing the relays. Battery voltage is supplied through the energized Wiper Intermittent Relay and the Wiper High/Low Relay to the low winding of the Windshield Wiper Motor, causing the motor to run in low. As soon as the motor starts running, the mechanical park/run switch built into the motor will move from PARK to RUN.

Refer to the WIPER SYSTEM / WASHER SYSTEM for specific tests and troubleshooting procedures.

Headlight Washer

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Headlight Washer Circuit Diagram (Page 93). Scheme 225

Exterior Lights

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Headlights Circuit Diagram (Page 110). Scheme 226

Headlights Circuit Diagram (Page 110-1). Scheme 227

Headlights Circuit Diagram (Page 110-2). Scheme 228

Headlights Circuit Diagram (Page 110-3). Scheme 229

How the Headlights Circuit Works

The Headlights circuit is composed of the Driver's MICU, the Passenger's MICU, the Headlight Switch, the Dimmer/Flash-to-Pass Switch, the Left and Right Headlights, and the High Beam Indicator. The Driver's MICU and Passenger's MICU control the Headlights with built-in Low and High Beam Control Circuits based upon the position of the Headlight Switch and the Dimmer/Flash-to-Pass Switch. The Driver's MICU and the Passenger's MICU communicate Headlights information directly between each other and via B-CAN.

Low Beams

When the Headlight Switch is moved to the ON position with the Dimmer/Flash-to-Pass Switch in the LOW position, a ground signal is supplied to terminal R8 of the Driver's MICU. The Driver's MICU activates the Low Beam Control Circuit, supplying battery voltage to the Low Beam of the Left Headlight, causing it to come on. The Driver's MICU also sends a message to the Passenger's MICU via the B-CAN communication lines. The Passenger's MICU then activates the Low Beam Control Circuit, supplying battery voltage to the Low Beam of the Right Headlight, causing it to come on.

High Beams

When the Headlight Switch is moved to the ON position with the Dimmer/Flash-to-Pass Switch in the HIGH position, ground signals are supplied to terminals R8 and R22 of the Driver's MICU. The Driver's MICU and the Passenger's MICU activate their Low and High Beam Control Circuits, supplying battery voltage to the Low and High Beam Headlights, causing them to come on.

Flash-to-Pass

When the Dimmer/Flash-to-Pass Switch is moved to the PASSING position, a ground signal is supplied to terminal R21 of the Driver's MICU. The Driver's MICU and the Passenger's MICU activate their Low and High Beam Control Circuits for as long as the switch is held, supplying battery voltage to the Low and High Beam Headlights, causing them to come on.

Daytime Running Lights (DRL)

The DRL circuit is composed of the Driver's MICU, the Passenger's MICU, the Left and Right Daytime Running Lights (built into the Headlights), the Parking Brake Switch, and the DRL Indicator. The DRL circuit operates with the Ignition Switch in ON (II) or the Engine Start/Stop Switch is pressed to select the ON mode, the Headlights off (Headlight Switch in OFF or in PARKING position), and the Parking Brake released.

When the DRL circuit is on, the Driver's MICU and the Passenger's MICU activate their Daytime Running Lights Control Circuits on and off (duty cycle), which provides a reduced voltage (approximately 6-8 volts) to the Daytime Running Lights through Fuse 28 (in the Driver's Under-dash Fuse/Relay Box and Fuse 1 (in the Passenger's Under-dash Fuse/Relay Box). This reduced voltage causes the Daytime Running Lights to come on. The DRL Indicator also illuminates.

Note. The DRL circuit is disabled when the Ignition Switch is turned to OFF (0) or the Engine Start/Stop switch is pressed to select OFF mode. To keep the DRL circuit from coming on, apply the Parking Brake while the Ignition Switch is in OFF (0) or the Engine Start/Stop Switch in OFF. When the Ignition Switch is turned back to ON (II) or the Engine Start/Stop Switch is in ON, the DRL circuit will not come on until the Parking Brake is released. The Headlights revert back to normal operation when the Headlight Switch is moved to the ON position.

Automatic Lighting (Automatic Lighting)

When the Headlight Switch is in the AUTO position, the Driver's MICU and Passenger's MICU receive an automatic lighting signal. When the Automatic Lighting Sensor detects low ambient light, a lights-on signal is transmitted to the Driver's MICU and the Passenger's MICU. The Driver's MICU and the Passenger's MICU activate their Low Beam Control Circuits, supplying battery voltage to the Low Beam Headlights, causing them to come on.

Refer to the EXTERIOR LIGHTS for specific tests and troubleshooting procedures.

Back-up Lights Circuit Diagram (Page 110-5). Scheme 230

License Plate, Parking, Side Marker Lights And Taillights Circuit Diagram (Page 110-6). Scheme 231

License Plate, Parking, Side Marker Lights And Taillights Circuit Diagram (Page 110-7). Scheme 232

License Plate, Parking, Side Marker Lights And Taillights Circuit Diagram (Page 110-8). Scheme 233

License Plate, Parking, Side Marker Lights And Taillights Circuit Diagram (Page 110-9). Scheme 234

Brake Lights (Without ACC) Circuit Diagram (Page 110-10). Scheme 235

Brake Lights (ACC) Circuit Diagram (Page 110-11). Scheme 236

Fog Lights Circuit Diagram (Page 110-12). Scheme 237

Fog Lights Circuit Diagram (Page 110-13). Scheme 238

Turn Signal And Hazard Warning Lights Circuit Diagram (Page 110-14). Scheme 239

Turn Signal And Hazard Warning Lights Circuit Diagram (Page 110-15). Scheme 240

Turn Signal And Hazard Warning Lights Circuit Diagram (Page 110-16). Scheme 241

Interior Lights

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Ambient Lights, Front Individual Map Lights And Ignition Key Light Circuit Diagram (Page 114). Scheme 242

Ambient Lights, Front Individual Map Lights And Ignition Key Light Circuit Diagram (Page 114-1). Scheme 243

Ambient Lights, Front Individual Map Lights And Ignition Key Light Circuit Diagram (Page 114-2). Scheme 244

Tailgate Light Circuit Diagram (Page 114-3). Scheme 245

Door Courtesy Lights Circuit Diagram (Page 114-4). Scheme 246

Vanity Mirror Lights Circuit Diagram (Page 114-5). Scheme 247

Dash And Console Lights Circuit Diagram (Page 114-6). Scheme 248

Dash And Console Lights Circuit Diagram (Page 114-7). Scheme 249

Dash And Console Lights Circuit Diagram (Page 114-8). Scheme 250

Dash And Console Lights Circuit Diagram (Page 114-9). Scheme 251

Dash And Console Lights Circuit Diagram (Page 114-10). Scheme 252

Dash And Console Lights Circuit Diagram (Page 114-11). Scheme 253

Dash And Console Lights Circuit Diagram (Page 114-12). Scheme 254

Dash And Console Lights Circuit Diagram (Page 114-13). Scheme 255

Dash And Console Lights Circuit Diagram (Page 114-14). Scheme 256

Entry Light Control System

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Entry Light Control System Circuit Diagram (Page 115). Scheme 257

Entry Light Control System Circuit Diagram (Page 115-1). Scheme 258

Entry Light Control System Circuit Diagram (Page 115-2). Scheme 259

Trailer Lighting Connector

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Acura Accessory Circuit Diagram (Page 118). Scheme 260

Acura Accessory Circuit Diagram (Page 118-1). Scheme 261

Acura Accessory Circuit Diagram (Page 118-2). Scheme 262

Acura Accessory Circuit Diagram (Page 118-3). Scheme 263

Acura Accessory Circuit Diagram (Page 118-4). Scheme 264

Acura Accessory Circuit Diagram (Page 118-5). Scheme 265

Power Windows

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Power Windows Circuit Diagram (Page 120). Scheme 266

Power Windows Circuit Diagram (Page 120-1). Scheme 267

Power Windows Circuit Diagram (Page 120-2). Scheme 268

Power Windows Circuit Diagram (Page 120-3). Scheme 269

Power Windows Circuit Diagram (Page 120-4). Scheme 270

Battery voltage is supplied at all times to the power window master switch through fuses 15 (in the under-hood fuse/relay box) and 24 (in the driver's under-dash fuse/relay box) and to the front passenger's power window switch through fuse 13 (in the passenger's under-dash fuse/relay box). Battery voltage is also supplied at all times to the left and right rear power window relays through fuse 22 (in the driver's under-dash fuse/relay box) and fuse 11 (in the passenger's under-dash fuse/relay box) respectively. With the ignition switch in ON (II) or the engine start/stop switch is in ON, battery voltage is supplied to the power window master switch through fuse 16 (in the driver's under-dash fuse/relay box).

When the main switch is ON, the left and right rear power window relays are energized providing battery voltage to the left and right rear power window switches

Driver's Window

When the driver's switch of the power window master switch is pushed to DOWN or pulled to UP, the signal for down or up is sent to the control unit. The control unit provides power and ground to the driver's power window motor, lowering or raising the window until the switch is released.

When the driver's switch is pushed to AUTO DOWN or pulled to AUTO UP, the signal for auto down or auto up is sent to the control unit. The control unit provides power and ground to the driver's power window motor, lowering or raising the window. As the window descends or ascends, the pulser in the driver's power window motor sends pulsing signals to the control unit. When the window reaches the fully down or fully up position, the pulsing signal stops, and the control unit removes power and ground from the driver's power window motor. If something obstructs the window during the AUTO UP operation, the control unit will detect no pulses from the pulser. For safety reasons, the control unit will make the driver's power window motor stop immediately and reverse.

All Passenger Windows

All windows can be opened and closed by the power window master switch. The passenger windows are disabled when the main switch is OFF. The driver's power window motor remains operable when the main switch is OFF.

Front Passenger's Window

When the front passenger's power window switch is pushed to DOWN or pulled to UP, the signal for down or up is sent to the control unit. The control unit provides power and ground to the front passenger's power window motor lowering or raising the window until the switch is released.

When the front passenger's power window switch is pushed to AUTO DOWN or pulled to AUTO UP, the signal for auto down or auto up is sent to the control unit. The control unit provides power and ground to the front passenger's power window motor, lowering or raising the window. As the window descends or ascends, the pulser in the front passenger's power window motor sends pulsing signals to the control unit. When the window reaches the fully down or fully up position, the pulsing signal stops, and the control unit removes power and ground from the front passenger's power window motor. If something obstructs the window during the AUTO UP operation, the control unit will detect no pulses from the pulser. For safety reasons, the control unit will make the front passenger's power window motor stop immediately and reverse.

When the front passenger's window is opened or closed from the power window master switch, the control unit communicates that command via a multiplexed signal to the front passenger's power window switch.

Left Rear Window

When the left rear power window switch is pushed to DOWN, power is supplied to the coil of the left rear power window switch down relay, energizing it. Battery voltage is supplied to the left rear power window motor through the energized relay. A path to ground for the motor is provided by the left rear power window switch up relay, lowering the window until the switch is released or the window is fully lowered.

When the left rear power window switch is pulled to UP, power is supplied to the coil of the left rear power window switch up relay, energizing it. Battery voltage is supplied to the left rear power window motor through the energized relay. A path to ground for the motor is provided by the left rear power window switch down relay, raising the window until the switch is released or the window is fully lowered.

When the left rear window is opened or closed from the power window master switch, the control unit sends signals to the relays within the left rear power window switch.

Right Rear Window

When the right rear power window switch is pushed to DOWN, power is supplied to the coil of the right rear power window switch down relay, energizing it. Battery voltage is supplied to the right rear power window motor through the energized relay. A path to ground for the motor is provided by the right rear power window switch up relay, lowering the window until the switch is released or the window is fully lowered.

When the right rear power window switch is pulled to UP, power is supplied to the coil of the right rear power window switch up relay, energizing it. Battery voltage is supplied to the right rear power window motor through the energized relay. A path to ground for the motor is provided by the right rear power window switch down relay, raising the window until the switch is released or the window is fully lowered.

When the right rear window is opened or closed from the power window master switch, the control unit sends signals to the relays within the right rear power window switch.

Remote Transmitter Operation

The windows can be opened with the remote transmitter. By pressing the UNLOCK button twice and then holding it, all four windows and the panoramic glass roof will open. The windows and panoramic glass roof cannot be closed with the remote transmitter.

Ignition Key Operation

The windows can be opened and closed with the ignition key. By inserting the key into the driver's door key cylinder switch and turning the key clockwise twice and then holding it, all four windows and the panoramic glass roof will open. By inserting the key into the driver's door key cylinder switch and turning the key counterclockwise twice and then holding it, all four windows and the panoramic glass roof will close.

Refer to the POWER WINDOWS for specific tests and troubleshooting procedures.

Panoramic Glass Roof

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Panoramic Glass Roof Circuit Diagram (Page 122). Scheme 271

Panoramic Glass Roof Circuit Diagram (Page 122-1). Scheme 272

The panoramic glass roof is controlled by the panoramic glass roof control unit/motor, the panoramic glass roof/sunshade switch, the power window master switch, Driver's MICU, and the Immobilizer-Keyless Control Unit. The panoramic glass roof control unit/motor contains the panoramic glass roof close relay, panoramic glass roof open relay, panoramic glass roof motor, the hall sensor, and the CPU.

Normal Operation

Battery voltage is supplied at all times through fuse 20 (in the driver's under-dash fuse/relay box) to the contacts of the panoramic glass roof open and close relays. With the ignition switch in ON (II) or START (III) or the engine start/stop switch in ON or START mode, battery voltage is supplied through fuse 12 (in the driver's under-dash fuse/relay box) to the Driver's MICU. The CPU uses input from the panoramic glass roof/sunshade switch to provide ground for the relays. When one of the relays is energized, battery voltage is provided to the panoramic glass roof motor. In this condition, the other relay provides a path to ground for the panoramic glass roof motor.

The panoramic glass roof has a key-off delay, which allows the panoramic glass roof to be operated for up to 10 minutes after the ignition is turned off. Opening one of the front doors cancels the key-off delay.

The panoramic glass roof can be opened with the remote transmitter. By pressing the UNLOCK button twice and then holding it, the panoramic glass roof and all four windows will open. The panoramic glass roof and windows cannot be closed with the remote transmitter.

The panoramic glass roof can be opened and closed with the ignition key. By inserting the key into the driver's door key cylinder switch and turning the key clockwise twice and then holding it, the panoramic glass roof and all four windows will open. By inserting the key into the driver's door key cylinder switch and turning the key counterclockwise twice and then holding it, the panoramic glass roof and all four windows will close.

Refer to the PANORAMIC GLASS ROOF for specific tests and troubleshooting procedures.

Keyless Entry System/Power Door Lock System/Security System

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Keyless Entry System/Power Door Lock System/Security System Circuit Diagram (Page 130). Scheme 273

Keyless Entry System/Power Door Lock System/Security System Circuit Diagram (Page 130-1). Scheme 274

Keyless Entry System/Power Door Lock System/Security System Circuit Diagram (Page 130-2). Scheme 275

Keyless Entry System/Power Door Lock System/Security System Circuit Diagram (Page 130-3). Scheme 276

Keyless Entry System/Power Door Lock System/Security System Circuit Diagram (Page 130-4). Scheme 277

Keyless Entry System/Power Door Lock System/Security System Circuit Diagram (Page 130-5). Scheme 278

Keyless Entry System/Power Door Lock System/Security System Circuit Diagram (Page 130-6). Scheme 279

Keyless Entry System/Power Door Lock System/Security System Circuit Diagram (Page 130-7). Scheme 280

The power door locks, keyless entry, and security system are part of the multiplex integrated control system. The use of multiplexing incorporates all three systems together. The following multiplex control units operate the three systems

1. Driver's MICU
2. Front Passenger's Power
3. Window Switch
4. Gauge Control Module
5. Immobilizer-Keyless Control Unit
6. Passenger's MICU
7. Power Window Master Switch

Battery voltage is supplied at all times to the Driver's MICU, the Passenger's MICU, and the Power Window Master Switch through fuse 15 (in the under-hood fuse/relay box). Battery voltage is also supplied at all times to the Power Window Master Switch through fuse 24 (in the driver's under-dash fuse/relay box) and to the Front Passenger's Power Window Switch through fuse 13 (in the passenger's under-dash fuse/relay box). With the ignition switch in ON (II) or START (III) or the engine start/stop switch in ON or START mode, battery voltage is supplied to the Driver's MICU and the Passenger's MICU through fuse 12 (in the driver's under-dash fuse/relay box). With the ignition switch in ON (II) or the engine start/stop switch in the ON mode, battery voltage is supplied to the Power Window Master Switch through fuse 16 (in the driver's under-dash fuse/relay box).

Door Locks (Switch Operation)

All lock and unlock commands from the Driver's and Front Passenger's Door Lock Switches are communicated across multiplex communication lines to the Driver's MICU and Passenger's MICU. The following lock or unlock signals are also communicated to the Driver's MICU and Passenger's MICU

1. Door Lock Knob Switches
2. Driver's Key Cylinder Switch
3. Full Latch Switch inside the Power Tailgate Closer Unit

According to the switch request, the Driver's MICU and Passenger's MICU control a series of relays that provide power and ground to the reversible electric door lock motors for lock and unlock modes.

Inserting the key into the Driver's Door Key Cylinder Switch and turning the key one time will command the Driver's MICU to unlock the driver's door. Turning the key a second time will command the Driver's MICU and Passenger's MICU to unlock the remaining doors.

Door Locks (Keyless Transmitter Operation)

The doors can be locked and unlocked with the Keyless Transmitter. All lock and unlock commands are received by the Immobilizer-Keyless Control Unit. The Immobilizer-Keyless Control Unit communicates the lock and unlock commands to the Driver's MICU and Passenger's MICU via B-CAN.

According to the switch request, the Driver's MICU and Passenger's MICU control a series of relays which provide power and ground to the reversible electric door lock motors for lock and unlock modes.

Pressing the UNLOCK button one time will command the Driver's MICU to unlock the driver's door. Pressing the unlock button a second time will command the Driver's MICU and Passenger's MICU to unlock the remaining doors.

Pressing the LOCK button will command the Driver's MICU and Passenger's MICU to lock all of the doors.

Panic Mode

Pressing and holding the PANIC button on the Keyless Transmitter for 2 seconds will activate the panic mode feature. The panic mode command is received by the Immobilizer-Keyless Control Unit. The Immobilizer-Keyless Control Unit communicates the panic mode command to the Driver's MICU and Passenger's MICU via B-CAN.

According to the request, the Driver's MICU and Passenger's MICU sound the horns and flash the exterior lights for approximately 20 seconds. The panic mode can be cancelled by pressing any button on the Keyless Transmitter or by turning the ignition switch to the ON (II) position or the engine start/stop switch to ON. If the ignition switch is in the ON (II) position or the engine start/stop switch is in ON mode, the panic mode cannot be activated.

Security System

The security system will arm automatically when the tailgate and hood are closed, the key is removed from the ignition switch or the remote is removed from the remote slot, and all of the doors are closed and locked.

The security system monitors the following signals

1. B-CAN Communication Lines
2. Door Lock Knob Switches
3. Engine Start/Stop Switch
4. Hood Switch
5. Ignition Switch
6. Power Tailgate Closer Unit Full Latch Switch

When the security system is activated, the Driver's MICU and Passenger's MICU sound the horns and flash the exterior lights for approximately 2 minutes. The security system can be deactivated by unlocking the driver's door with the key or by pressing the UNLOCK button on the Keyless Transmitter, or by grabbing either the driver's or front passenger's door handle with the keyless access remote in range.

Refer to the KEYLESS/POWER DOOR LOCKS/SECURITY SYSTEM for specific tests and troubleshooting procedures.

Keyless Access System

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Keyless Access System Circuit Diagram (Page 131). Scheme 281

Keyless Access System Circuit Diagram (Page 131-1). Scheme 282

Keyless Access System Circuit Diagram (Page 131-2). Scheme 283

Keyless Access System Circuit Diagram (Page 131-3). Scheme 284

Keyless Access System Circuit Diagram (Page 131-4). Scheme 285

Keyless Access System Circuit Diagram (Page 131-5). Scheme 286

Keyless Access System Circuit Diagram (Page 131-6). Scheme 287

Keyless Access System Circuit Diagram (Page 131-7). Scheme 288

Keyless Access System Circuit Diagram (Page 131-8). Scheme 289

Keyless Access System Circuit Diagram (Page 131-9). Scheme 290

Keyless Access System Circuit Diagram (Page 131-10). Scheme 291

Immobilizer System

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Immobilizer System Circuit Diagram - Without Keyless Access (Page 132). Scheme 292

Immobilizer System Circuit Diagram - Without Keyless Access (Page 132-1). Scheme 293

Immobilizer System Circuit Diagram - Without Keyless Access (Page 132-2). Scheme 294

The immobilizer system is designed to prevent the vehicle from being started without the owner's ignition key. If an attempt is made to start the vehicle with any other key, the immobilizer system disables it from starting.

If the proper ignition key is used, the immobilizer-keyless control unit sends a coded signal to the PCM and Driver's MICU and quickly flashes the immobilizer system indicator LED. The coded signal informs the PCM that the proper ignition key is being used. The PCM grounds the Fuel Pump Relay, energizing it to provide power to the fuel pump. Following the first 2 seconds after the ignition switch is turned to ON (II) with the proper ignition key, the immobilizer system indicator LED turns off, and the engine will run under normal operating conditions.

Battery voltage is supplied at all times through fuse 15 (in the under-hood fuse/relay box) to the immobilizer-keyless control unit and the gauge control module. With the ignition switch in ON (II) or START (III), the immobilizer-keyless control unit and the PCM receive battery voltage through fuse 9 (in the driver's under-dash fuse/relay box).

1. When the ignition switch is turned ON (II) and a programmed immobilizer code is identified, the immobilizer indicator quickly flashes once.
2. The immobilizer system will allow the engine to start normally.
3. When the ignition switch is turned OFF (0), the immobilizer indicator does not come on.

Immobilizer System Detects a Problem

1. When the ignition switch is turned ON (II), and a programmed immobilizer code is not identified, the immobilizer indicator quickly flashes once and then blinks continuously.
2. The immobilizer system results will vary depending on how quickly the key is turned. If the key is turned quickly from the OFF (0) position to the START (III) position, the engine will start and run for approximately 1 second and shut off. If the key is turned to the ON (II) position, delayed there, and then turned to START (III) position, the starter will turn the motor over, but it will not start.
3. When the ignition switch is turned OFF (0), the immobilizer indicator will blink ten times then go off to indicate the system is correctly reset.

Refer to the IMMOBILIZER SYSTEM for specific tests and troubleshooting procedures.

Power Tailgate

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Power Tailgate Circuit Diagram (Page 136). Scheme 295

Power Tailgate Circuit Diagram (Page 136-1). Scheme 296

Interlock System

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Interlock System Circuit Diagram (Page 138). Scheme 297

Interlock System Circuit Diagram (Page 138-1). Scheme 298

Key Interlock

When the Ignition Key is inserted into the Ignition Switch, a ground signal is provided to the Driver's MICU. The Driver's MICU detects the insertion of the Ignition Key through this input. If the shift lever is out of PARK, a ground signal is provided to the Driver's MICU. The Driver's MICU detects that the shift lever is out of PARK through this input. The Driver's MICU provides ground to the Key Interlock Solenoid. The Key Interlock Solenoid is then energized, which prevents the Ignition Switch from being turned to LOCK (0).

Shift Position Interlock

Battery voltage is supplied at all times through Fuse 10 (in the under-hood fuse/relay box) to the Brake Pedal Position Switch. With the Ignition Switch in ON (II) or START (III), battery voltage is supplied through Fuse 18 (in the driver's under-dash fuse/relay box) to the Shift Lock Solenoid. When the brake pedal is pressed, a battery voltage input is supplied to the PCM and the Driver's MICU. If, at the same time, the accelerator pedal is not pressed, the PCM provides ground to the Shift Lock Solenoid. The Shift Lock Solenoid is then energized, allowing the shift lever to be moved from the PARK position.

While the vehicle is in forward motion, the PCM removes ground from the Shift Lock Solenoid. The Shift Lock Solenoid is then de-energized, which disables the shift lever from being moved to REVERSE or PARK.

Refer to the A/T INTERLOCK SYSTEM for specific tests and troubleshooting procedures.

Power Seats

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Front Passengers Power Seat Circuit Diagram (Page 140). Scheme 299

Drivers Power Lumbar Support Circuit Diagram (Page 140-1). Scheme 300

Battery voltage is supplied at all times through fuse 18 (in the passenger's under-dash fuse/relay box) to the driver's power lumbar support switch.

Raise Lumbar Support

When the lumbar support switch is moved to FORWARD, battery voltage is supplied to the lumbar support motor through the lumbar support switch. The lumbar support motor is grounded through the opposite contact of the lumbar support switch. The motor will run until the switch is released or the lumbar support reaches the full forward position.

Lower Lumbar Support

When the lumbar support switch is moved to BACKWARD, battery voltage is supplied to the lumbar support motor through the lumbar support switch. The lumbar support motor is grounded through the opposite contact of the lumbar support switch. The motor will run until the switch is released or the lumbar support reaches the full backward position.

Refer to the POWER SEATS for specific tests and troubleshooting procedures.

Battery voltage is provided at all times through fuses 8 and 9 (in the passenger's under-dash fuse/relay box) to the front passenger's power seat adjustment switch.

Front Up-Down

When the front up-down switch is moved to DOWN, battery voltage is supplied to the front up-down motor through the driver's power seat adjustment switch. The front up-down motor is grounded through the UP contact of the front up-down switch. The motor will run until the switch is released or the seat reaches the full front down position. The contacts for UP operation of the front up-down switch are wired the opposite way of the DOWN contacts, causing the motor to run in the opposite direction.

Slide

Slide operation is similar to the front up-down operation.

Recline

Recline operation is similar to the front up-down operation.

Refer to the POWER SEATS for specific tests and troubleshooting procedures.

Automatic Dimming Inside Mirror

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Automatic Dimming Inside Mirror Circuit Diagram - Without Navigation (Page 142). Scheme 301

Automatic Dimming Inside Mirror Circuit Diagram - Navigation (Page 142-1). Scheme 302

DPMS

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

DPMS Circuit Diagram (Page 143). Scheme 303

DPMS Circuit Diagram (Page 143-1). Scheme 304

DPMS Circuit Diagram (Page 143-2). Scheme 305

DPMS Circuit Diagram (Page 143-3). Scheme 306

DPMS Circuit Diagram (Page 143-4). Scheme 307

DPMS Circuit Diagram (Page 143-5). Scheme 308

DPMS Circuit Diagram (Page 143-6). Scheme 309

In the driving position memory system, the driver's seat, the tilt/telescopic steering, and the power mirrors have a memory feature. The four driver's seat adjustments (forward and back, front up and down, rear up and down, and seat back angle), the steering tilt and telescopic adjustments, and the power mirror adjustments can be regulated separately. All of the adjustments can be memorized at the same time by pressing the SET button of the driving position memory switch, and then (within 5 seconds) pressing one of the two position buttons. If the same position button is pressed after the adjustments are memorized, the seat, the steering, and the mirrors will move to the memorized positions.

Note. Disconnecting the battery will cancel the memorized positions.

The driving position memory system is directly connected to the remote transmitters 1 and 2. When the doors are unlocked using either the remote transmitter 1 or remote transmitter 2, the corresponding memory position 1 or 2 is activated.

Power Seat Position Sensors

Each driver's power seat motor has a corresponding sensor, which sends a pulse to the power seat control unit when the motor rotates. The power seat control unit then stores the number of pulses for that seat position in its memory.

Power Tilt/Telescopic Steering Position Sensors

The power tilt/telescopic steering control unit uses input from a tilt position sensor and a telescopic position sensor to detect voltage changes caused by the movements of the steering. The power tilt/telescopic steering control unit stores the voltage changes for each driving position in its memory.

Power Mirror Position Sensors

Each power mirror has a tilt position sensor and a swing position sensor to detect the changes in voltage caused by the movements of the mirror. The power mirror control unit then stores the voltage changes for that mirror's position in its memory.

Reverse Mirror Control

When the transmission is shifted into reverse with the mirror selection switch in LEFT or RIGHT, the corresponding mirror tilts down automatically. If the mirror selection switch is in the neutral position, the reverse mirror control is disabled. When the transmission is shifted out of reverse, the tilted mirror will return to its previous position.

Refer to the DRIVER POSITION MEMORY SYSTEM (DPMS) for specific tests and troubleshooting procedures.

Seat Heaters

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Front Seat Heaters Circuit Diagram - Without Ventilated Seats (Page 147). Scheme 310

Front Seat Heaters Circuit Diagram - Without Ventilated Seats (Page 147-1). Scheme 311

Front Seat Heaters Circuit Diagram - Without Ventilated Seats (Page 147-2). Scheme 312

Rear Seat Heaters Circuit Diagram (Page 147-3). Scheme 313

Rear Seat Heaters Circuit Diagram (Page 147-4). Scheme 314

Rear Seat Heaters Circuit Diagram (Page 147-5). Scheme 315

Ventilated Seats

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Ventilated Seats Circuit Diagram (Page 147-6). Scheme 316

Ventilated Seats Circuit Diagram (Page 147-7). Scheme 317

Ventilated Seats Circuit Diagram (Page 147-8). Scheme 318

Audio System

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Audio System Circuit Diagram - Without Navigation (Page 150). Scheme 319

Audio System Circuit Diagram - Without Navigation (Page 150-1). Scheme 320

Audio System Circuit Diagram - Without Navigation (Page 150-2). Scheme 321

Audio System Circuit Diagram - Without Navigation (Page 150-3). Scheme 322

Audio System Circuit Diagram - Without Navigation (Page 150-4). Scheme 323

Audio System Circuit Diagram - Without Navigation (Page 150-5). Scheme 324

Audio System Circuit Diagram - Without Navigation (Page 150-6). Scheme 325

Audio System Circuit Diagram - Without Navigation (Page 150-7). Scheme 326

Audio System Circuit Diagram - Without Navigation (Page 150-8). Scheme 327

Audio System Circuit Diagram - Without Navigation (Page 150-9). Scheme 328

Audio System Circuit Diagram - Navigation (Page 150-10). Scheme 329

Audio System Circuit Diagram - Navigation (Page 150-11). Scheme 330

Audio System Circuit Diagram - Navigation (Page 150-12). Scheme 331

Audio System Circuit Diagram - Navigation (Page 150-13). Scheme 332

Audio System Circuit Diagram - Navigation (Page 150-14). Scheme 333

Audio System Circuit Diagram - Navigation (Page 150-15). Scheme 334

Audio System Circuit Diagram - Navigation (Page 150-16). Scheme 335

Audio System Circuit Diagram - Navigation (Page 150-17). Scheme 336

Audio System Circuit Diagram - Navigation (Page 150-18). Scheme 337

Audio System Circuit Diagram - Navigation (Page 150-19). Scheme 338

Audio System Circuit Diagram - Navigation (Page 150-20). Scheme 339

HFL System (HandsFreeLink)

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

HFL System Circuit Diagram - HandsFreeLink (Page 152). Scheme 340

HFL System Circuit Diagram - HandsFreeLink (Page 152-1). Scheme 341

HFL System Circuit Diagram - HandsFreeLink (Page 152-2). Scheme 342

HFL System Circuit Diagram - HandsFreeLink (Page 152-3). Scheme 343

HFL System Circuit Diagram - HandsFreeLink (Page 152-4). Scheme 344

HFL System Circuit Diagram - HandsFreeLink (Page 152-5). Scheme 345

AcuraLink

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

AcuraLink Circuit Diagram (Page 153). Scheme 346

AcuraLink Circuit Diagram (Page 153-1). Scheme 347

AcuraLink Circuit Diagram (Page 153-2). Scheme 348

AcuraLink Circuit Diagram (Page 153-3). Scheme 349

Accessory Power Sockets

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Accessory Power Sockets Circuit Diagram - Without Keyless Access (Page 155). Scheme 350

Accessory Power Sockets Circuit Diagram - Keyless Access (Page 155-1). Scheme 351

Navigation System

Note. For connector or component location "PHOTO", see OEM COMPONENT LOCATION . For connector "VIEW", see OEM CONNECTOR END VIEWS .

Navigation System Circuit Diagram (Page 156). Scheme 352

Navigation System Circuit Diagram (Page 156-1). Scheme 353

Navigation System Circuit Diagram (Page 156-2). Scheme 354

Navigation System Circuit Diagram (Page 156-3). Scheme 355

Navigation System Circuit Diagram (Page 156-4). Scheme 356

Navigation System Circuit Diagram (Page 156-5). Scheme 357

Navigation System Circuit Diagram (Page 156-6). Scheme 358

Navigation System Circuit Diagram (Page 156-7). Scheme 359
