Power Seats Acura ZDX I

Seats 5 illustrations ~410 words

Component Location Index

For the driver's power seat, refer to the Driving Position Memory System (DPMS) section

Scheme 250

Scheme 250: Component Location Index
Scheme 250: Component Location Index
  1. «COMPONENT LOCATION INDEX»(/acura/zdx/i-2009-2013/remont/seats/#driver-position-memory-system-dpms)
  2. «CIRCUIT DIAGRAM»(/acura/zdx/i-2009-2013/remont/seats/#driver-position-memory-system-dpms)

Scheme 251

Scheme 251: Circuit Diagram - Front Passenger's Power Seat
Scheme 251: Circuit Diagram - Front Passenger's Power Seat

Front Passenger's Seat

Note. SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or servicing.

Scheme 252

Scheme 252: Front Passenger's Seat
Scheme 252: Front Passenger's Seat

Scheme 253

Scheme 253
Scheme 253
  1. Remove the front passenger's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/seats/#seats__front-seat-removalinstallation) ).
  2. Remove the power seat adjustment switch knobs (A) and the recline cover from the front passenger's seat (see «FRONT SEAT RECLINE COVER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/seats/#seats__front-seat-recline-cover-removalinstallation) ), then remove the two screws and the power seat adjustment switch (B).
  3. Disconnect the 12P connector from the power seat adjustment switch.
  4. Reinstall the adjustment switch knobs to the switch.
  5. Check for continuity between the terminals in each switch position according to the table. *: There is continuity without operating a switch.
  6. If the continuity is not as specified, replace the switch.
  7. Install the switch in the reverse order of removal.

Front Passenger's Power Seat Motor Test

Note. SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or servicing.

Scheme 254

Scheme 254: Front Passenger's Power Seat Motor Test
Scheme 254: Front Passenger's Power Seat Motor Test
  1. Remove the front passenger's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/seats/#seats__front-seat-removalinstallation) ).
  2. Disconnect the connector from each power seat motor. NOTE: All connectors are terminal side of male terminals.
  3. Test each motor by connecting power and ground according to the table. When the motor stops running, disconnect battery power immediately. Terminal 1 5 Position SLIDE MOTOR Forward (+) (-) Backward (-) (+) Terminal 1 2 Position RECLINE MOTOR Forward (-) (+) Backward (-) (+) Terminal 1 2 Position FRONT UP-DOWN MOTOR UP (+) (-) DOWN (-) (+) Terminal 1 2 Position REAR UP-DOWN MOTOR UP (-) (+) DOWN (+) (-)
  4. If the motor does not run or fails to run smoothly, replace: Slide motor (see «FRONT SEAT SLIDE MOTOR REPLACEMENT»(/acura/zdx/i-2009-2013/remont/seats/#seats__front-seat-slide-motor-replacement) ) Front up-down motor/seat frame (see «FRONT SEAT FRAME REPLACEMENT»(/acura/zdx/i-2009-2013/remont/seats/#seats__front-seat-frame-replacement) ) Rear up-down motor/seat frame (see «FRONT SEAT FRAME REPLACEMENT»(/acura/zdx/i-2009-2013/remont/seats/#seats__front-seat-frame-replacement) ) Recline motor (see «FRONT SEAT RECLINE MOTOR REPLACEMENT»(/acura/zdx/i-2009-2013/remont/seats/#seats__front-seat-recline-motor-replacement) ) NOTE: The front and rear up-down motors are part of the seat frame.
