Audio System Acura ZDX I

Entertainment Systems 329 illustrations ~35677 words

Scheme 1

Scheme 1: Component Location Index

Scheme 2

Scheme 2

Disconnecting

To disconnect the connector, pull the lever (A) while pushing the lock tab (B) down, then pull the connector (C).

Scheme 3

Scheme 3: Disconnecting

Connecting

To connect the connector, push the connector into the connector sleeve (A). As the connector is pressed in, the lever (B) moves to the locked position.

Scheme 4

Scheme 4: Connecting

With Navigation

SymptomDiagnostic ProcedureAlso Check for
Poor AM or FM radio reception or interferenceSymptom Troubleshooting (see POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (WITH NAVIGATION) )Antenna lead short or open in the wire
Audio unit power switch will not turn on (No information display and no sound)Symptom Troubleshooting (see AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH NAVIGATION) )
Audio unit power switch will not turn offSymptom Troubleshooting (see AUDIO UNIT POWER SWITCH WILL NOT TURN OFF (WITH NAVIGATION) )
No sound is heard from the speaker(s) (display is normal)Symptom Troubleshooting (see NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) (WITH NAVIGATION) )
Auxiliary input sound is low or cannot be heardSymptom Troubleshooting (see AUXILIARY INPUT SOUND IS LOW OR CANNOT BE HEARD (WITH NAVIGATION) )
Audio system sound is weak or distorted (display is normal)Symptom Troubleshooting (see AUDIO SYSTEM SOUND IS WEAK OR DISTORTED (DISPLAY IS NORMAL) (WITH NAVIGATION) )
Radio preset memory is lostSymptom Troubleshooting (see RADIO PRESET MEMORY IS LOST (WITH NAVIGATION) )
Volume does not changeSymptom Troubleshooting (see VOLUME DOES NOT CHANGE (WITH NAVIGATION) )
Volume does not increase with speedSymptom Troubleshooting (see VOLUME DOES NOT INCREASE WITH SPEED (WITH NAVIGATION) )
Volume is too high or too low when driving at freeway speedsSymptom Troubleshooting (see VOLUME IS TOO HIGH OR TOO LOW WHEN DRIVING AT FREEWAY SPEEDS (WITH NAVIGATION) )
Radio tuner does not change stationsSymptom Troubleshooting (see RADIO TUNER DOES NOT CHANGE STATIONS (WITH NAVIGATION) )
Audio-navigation and HVAC switch panel button illumination does not workSymptom Troubleshooting (see AUDIO-NAVIGATION AND HVAC SWITCH PANEL BUTTON ILLUMINATION DOES NOT WORK (WITH NAVIGATION) )
Audio remote switch does not work properlySymptom Troubleshooting (see AUDIO REMOTE SWITCH DOES NOT WORK PROPERLY (WITH NAVIGATION) )
Audio disc does not loadSymptom Troubleshooting (see AUDIO DISC DOES NOT LOAD (WITH NAVIGATION) )Damaged disc
Audio disc does not ejectSymptom Troubleshooting (see AUDIO DISC DOES NOT EJECT (WITH NAVIGATION) )Damaged disc Disc with a label
Audio disc does not playSymptom Troubleshooting (see AUDIO DISC DOES NOT PLAY (WITH NAVIGATION) )Foreign objects such coins or paper inserted into the audio disc changer/CD player
Audio disc skipsSymptom Troubleshooting (see AUDIO DISC SKIPS (WITH NAVIGATION) )Tire pressure (over-inflated), disc smudged, or scratched
Audio system button does not workSymptom Troubleshooting (see AUDIO SYSTEM BUTTON DOES NOT WORK (WITH NAVIGATION) )
Audio unit disc indicator does not workSymptom Troubleshooting (see AUDIO UNIT DISC INDICATOR DOES NOT WORK (WITH NAVIGATION) )
USB device does not functionSymptom Troubleshooting (see USB DEVICE DOES NOT FUNCTION (WITH NAVIGATION) )USB device compatibility (see the Owner's Manual)
USB input sound is low or cannot be heardSymptom Troubleshooting (see USB INPUT SOUND IS LOW OR CANNOT BE HEARD (WITH NAVIGATION) )USB device compatibility (see the Owner's Manual)
Booming sound while driving with audio unit on or offSymptom Troubleshooting (see BOOMING SOUND WHILE DRIVING WITH AUDIO UNIT ON OR OFF )
Error code: XM NO SIGNAL or XM LOADING is displayedSymptom Troubleshooting (see ERROR CODE: XM NO SIGNAL OR XM LOADING IS DISPLAYED (WITH NAVIGATION) )
Error code: XM ANTENNA or XM LOADING is displayed (with AcuraLink)Symptom Troubleshooting (see ERROR CODE: XM ANTENNA OR XM LOADING IS DISPLAYED (WITH ACURALINK) )
XM radio display is blank and no station information is displayed (USA models)Symptom Troubleshooting (see XM RADIO DISPLAY IS BLANK AND NO STATION INFORMATION IS DISPLAYED (USA MODELS WITH NAVIGATION) )Also refer to AUDIO UNIT POWER SWITCH WILL NOT TURN ON (No information display and no sound) (see )
XM radio display is blank and no station information is displayed (Canada models)Symptom Troubleshooting (see XM RADIO DISPLAY IS BLANK AND NO STATION INFORMATION IS DISPLAYED (CANADA MODELS WITH NAVIGATION) )Also refer to AUDIO UNIT POWER SWITCH WILL NOT TURN ON (No information display and no sound) (see )
XM radio preset memory is lost (USA models)Symptom Troubleshooting (see XM RADIO PRESET MEMORY IS LOST (USA MODELS WITH NAVIGATION) )
XM radio preset memory is lost (Canada models)Symptom Troubleshooting (see XM RADIO PRESET MEMORY IS LOST (CANADA MODELS WITH NAVIGATION) )
Poor or no sound with XM radio (Audio unit does display XM channels)Symptom Troubleshooting (see POOR OR NO SOUND WITH XM RADIO (AUDIO UNIT DOES DISPLAY XM CHANNELS) (USA MODELS WITH NAVIGATION) )
No sound when Bluetooth audio is usedHFL Symptom Troubleshooting (see NO SOUND WHEN BLUETOOTH AUDIO IS USED (WITH NAVIGATION) )Bluetooth cell phone GA-Net line open/short HandsFreeLink control unit Audio-navigation unit
Bluetooth audio does not workHFL Symptom Troubleshooting (see BLUETOOTH AUDIO DOES NOT WORK (WITH NAVIGATION) )Bluetooth cell phone GA-Net line open/short HandsFreeLink control unit
Bluetooth cell phone cannot be pairedHFL Symptom Troubleshooting (see BLUETOOTH CELL PHONE CANNOT BE PAIRED )Bluetooth cell phone compatibility HandsFreeLink control unit Audio-navigation unit
The communication with cell phone is interrupted or changesHFL Symptom Troubleshooting (see THE COMMUNICATION WITH CELL PHONE IS INTERRUPTED OR CHANGES (WITH NAVIGATION) )Electric wave interference HandsFreeLink control unit Audio-navigation unit Bluetooth cell phone Harness/connector
Bluetooth cell phone audio function SKIP and PAUSE/RESUME do not workHFL Symptom Troubleshooting (see BLUETOOTH CELL PHONE AUDIO FUNCTION SKIP AND PAUSE/RESUME DO NOT WORK (WITH NAVIGATION) )Bluetooth cell phone compatibility (Some Bluetooth cell phones do not support the function. For further information, please contact the cell phone carrier or the cell phone manufacturer)

Without Navigation

SymptomDiagnostic ProcedureAlso Check for
Poor AM or FM radio reception or interferenceSymptom Troubleshooting (see POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (WITHOUT NAVIGATION) )Antenna lead short or open in the wire
Audio unit power switch will not turn on (No information display and no sound)Symptom Troubleshooting (see AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITHOUT NAVIGATION) )
Audio unit power switch will not turn offSymptom Troubleshooting (see AUDIO UNIT POWER SWITCH WILL NOT TURN OFF (WITHOUT NAVIGATION) )
No sound is heard from the speaker(s) (display is normal)Symptom Troubleshooting (see NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) (WITHOUT NAVIGATION) )
Auxiliary input sound is low or cannot be heardSymptom Troubleshooting (see AUXILIARY INPUT SOUND IS LOW OR CANNOT BE HEARD (WITHOUT NAVIGATION) )
Audio system sound is weak or distorted (display is normal)Symptom Troubleshooting (see AUDIO SYSTEM SOUND IS WEAK OR DISTORTED (DISPLAY IS NORMAL) (WITHOUT NAVIGATION) )
Radio preset memory is lostSymptom Troubleshooting (see RADIO PRESET MEMORY IS LOST (WITHOUT NAVIGATION) )
Volume does not changeSymptom Troubleshooting (see VOLUME DOES NOT CHANGE (WITHOUT NAVIGATION) )
Volume does not increase with speedSymptom Troubleshooting (see VOLUME DOES NOT INCREASE WITH SPEED (WITHOUT NAVIGATION) )
Volume is too high or too low when driving at freeway speedsSymptom Troubleshooting (see VOLUME IS TOO HIGH OR TOO LOW WHEN DRIVING AT FREEWAY SPEEDS (WITH NAVIGATION) )
Radio tuner does not change stationsSymptom Troubleshooting (see RADIO TUNER DOES NOT CHANGE STATIONS (WITHOUT NAVIGATION) )
Audio system information does not display on the audio display unitSymptom Troubleshooting (see AUDIO SYSTEM INFORMATION DOES NOT DISPLAY ON THE AUDIO DISPLAY UNIT (WITHOUT NAVIGATION) )
Audio and HVAC switch panel button illumination does not workSymptom Troubleshooting (see AUDIO AND HVAC SWITCH PANEL BUTTON ILLUMINATION DOES NOT WORK (WITHOUT NAVIGATION) )
Audio remote switch does not work properlySymptom Troubleshooting (see AUDIO REMOTE SWITCH DOES NOT WORK PROPERLY (WITHOUT NAVIGATION) )
Audio disc does not loadSymptom Troubleshooting (see AUDIO DISC DOES NOT LOAD (WITH NAVIGATION) )Damaged disc
Audio disc does not ejectSymptom Troubleshooting (see AUDIO DISC DOES NOT EJECT (WITHOUT NAVIGATION) )Damaged disc Disc with a label
Audio disc changer does not load all six discsSymptom Troubleshooting (see AUDIO DISC CHANGER DOES NOT LOAD ALL SIX DISCS (WITHOUT NAVIGATION) )Tire pressure (over-inflated), disc smudged, or scratched
Audio disc changer does not move between discsSymptom Troubleshooting (see AUDIO DISC CHANGER DOES NOT MOVE BETWEEN DISCS (WITHOUT NAVIGATION) )
Audio disc does not playSymptom Troubleshooting (see AUDIO DISC DOES NOT PLAY (WITHOUT NAVIGATION) )Foreign objects such coins or paper inserted into the audio disc changer/CD player
Audio disc skipsSymptom Troubleshooting (see AUDIO DISC SKIPS (WITHOUT NAVIGATION) )Tire pressure (over-inflated), disc smudged, or scratched
Audio system button does not workSymptom Troubleshooting (see AUDIO UNIT BUTTON DOES NOT WORK (WITHOUT NAVIGATION) )
Audio unit disc indicator does not workSymptom Troubleshooting (see AUDIO UNIT DISC INDICATOR DOES NOT WORK (WITHOUT NAVIGATION) )
USB device does not functionSymptom Troubleshooting (see USB DEVICE DOES NOT FUNCTION (WITHOUT NAVIGATION) )USB device compatibility (see the Owner's Manual)
USB input sound is low or cannot be heardSymptom Troubleshooting (see USB INPUT SOUND IS LOW OR CANNOT BE HEARD (WITHOUT NAVIGATION) )USB device compatibility (see the Owner's Manual)
Booming sound while driving with audio unit on or offSymptom Troubleshooting (see BOOMING SOUND WHILE DRIVING WITH AUDIO UNIT ON OR OFF )
Error code: XM NO SIGNAL or XM LOADING is displayedSymptom Troubleshooting (see ERROR CODE: XM NO SIGNAL OR XM LOADING IS DISPLAYED (WITHOUT NAVIGATION) )
Error code: XM ANTENNA or XM LOADING is displayed (without AcuraLink)Symptom Troubleshooting (see ERROR CODE: XM ANTENNA OR XM LOADING IS DISPLAYED (WITHOUT ACURALINK) )
XM radio display is blank and no station information is displayedSymptom Troubleshooting (see XM RADIO DISPLAY IS BLANK AND NO STATION INFORMATION IS DISPLAYED (WITHOUT NAVIGATION) )Also refer to AUDIO SYSTEM INFORMATION DOES NOT DISPLAY ON THE AUDIO DISPLAY (see )
XM radio preset memory is lostSymptom Troubleshooting (see XM RADIO PRESET MEMORY IS LOST (WITHOUT NAVIGATION) )
Poor or no sound with XM radio (Audio unit does display XM channels)Symptom Troubleshooting (see POOR OR NO SOUND WITH XM RADIO (AUDIO UNIT DOES DISPLAY XM CHANNELS) (WITHOUT NAVIGATION) )
No sound when Bluetooth audio is usedHFL Symptom Troubleshooting (see NO SOUND WHEN BLUETOOTH AUDIO IS USED (WITHOUT NAVIGATION) )Bluetooth cell phone GA-Net line open/short HandsFreeLink control unit Audio unit
Bluetooth audio does not workHFL Symptom Troubleshooting (see BLUETOOTH AUDIO DOES NOT WORK (WITHOUT NAVIGATION) )Bluetooth cell phone GA AUDIO line open/short HandsFreeLink control unit
Bluetooth cell phone cannot be pairedHFL Symptom Troubleshooting (see BLUETOOTH CELL PHONE CANNOT BE PAIRED )Bluetooth cell phone compatibility HandsFreeLink control unit Audio unit
The communication with cell phone is interrupted or changesHFL Symptom Troubleshooting (see THE COMMUNICATION WITH CELL PHONE IS INTERRUPTED OR CHANGES (WITHOUT NAVIGATION) )Electric wave interference HandsFreeLink control unit Audio unit Bluetooth cell phone Harness/connector
Bluetooth cell phone audio function SKIP and PAUSE/RESUME do not workHFL Symptom Troubleshooting (see BLUETOOTH CELL PHONE AUDIO FUNCTION SKIP AND PAUSE/RESUME DO NOT WORK (WITHOUT NAVIGATION) )Bluetooth cell phone compatibility (Some Bluetooth cell phones do not support the function. For further information, please contact the cell phone carrier or the cell phone manufacturer)

Overview

The audio unit has a built in CD player. Audio units with navigation are referred to as audio-navigation units. These units combine the audio system, the navigation system, and the CD/DVD player into one unit.

The audio unit acts as the processor for all audio functions. Select audio functions from the audio switch panel buttons or the audio remote switch (on the steering wheel). The audio display provides the current audio status.

The audio unit has a built-in EEPROM (electrically erasable programmable read-only memory). This memory holds the audio presets (AM/FM radio frequency, sound settings, etc.) even when the battery is disconnected.

A security signal is daisy-chained between the audio and vehicle components for integration into the vehicle's security system.

There are two audio systems available for the Acura ZDX

  1. With navigation, it includes surround sound with 10 speakers.
  2. Without navigation, it includes 8 speakers. Disc Playback Types With Navigation Without Navigation CD (CD-DA) o o CD-R/RW (uncompressed) o o CD-R/RW (MP3/WMA) o o DVD-Audio o X DVD-Video X X DVD-R/RW (uncompressed) o X DTS CD o X o: Available X: Not available

HDD Recording

The navigation system uses a HDD (hard disc drive) and can store music. To record music to the HDD, you must use an original CD or uncompressed CD-R files. The music must be loaded on a CD using the CD player. You cannot load music through the USB adapter or the auxiliary jack.

Song By Voice™ (with navigation)

You can use the voice control to operate the audio system, including the Song By Voice™ feature. See the Navigation Manual for more information.

Speed-Sensitive Volume Compensation (SVC)

All audio systems are equipped with speed-sensitive volume compensation (SVC). The audio-navigation unit or the audio unit receives the vehicle speed pulse (VSP) from the PCM. The system processes the speed input and increases the navigation system or the audio system volume level as the vehicle speed increases to compensate for the interior noise that occurs at higher speeds. When the vehicle slows down, the volume returns to its normal level. The SVC has four settings: SVC OFF, SVC LOW, SVC MID, and SVC HIGH that can be adjusted using the audio-navigation unit or the audio unit. The factory default setting is SVC MID.

To change the audio unit SVC setting, press the tune folder sound knob repeatedly until the SVC is displayed, then rotate the knob to adjust the SVC to the desired setting (SVC OFF, SVC LOW, SVC MID, or SVC HIGH).

To change the audio-navigation unit SVC setting, press the AUDIO button, and then select the Sound Setup from the AUDIO MENU on the navigation display. Rotate the interface dial to select the desired setting (SVC OFF, SVC LOW, SVC MID, SVC HIGH).

Active Noise Cancellation (ANC)/Active Sound Control System

Both the active noise cancellation (ANC) and active sound control are built into the ANC/active sound control unit. Both systems help eliminate unwanted sound from entering the passenger compartment. There are two microphones mounted in the headliner, one just behind the front overhead console and the other just ahead of the overhead rear light module. The microphones listen for low frequencies entering the passenger compartment and send a signal to the ANC/active sound control unit. The ANC/active sound control unit then creates a sound wave that is sent out through the speakers to eliminate the unwanted sound.

Active Noise Cancellation (ANC) System

The ANC system works to cancel engine booming sound up to about 2, 000 rpm. The ANC/active sound control unit receives the engine speed pulse (NEP) from the PCM and outputs a sine-wave-sound through the audio speakers to cancel low-frequency noise from the engine. The ANC system also uses two microphones to detect and monitor low frequency noise in the passenger compartment. The microphones feed information back to the audio unit which adjusts the speaker output to reduce the noise. The ANC also receives input from the door open/close (INTR LT) signal from the MICU. Anytime a door is opened, the ANC system temporarily stops working.

Scheme 5

Scheme 5: Active Noise Cancellation (ANC) System

Active Sound Control System

The active sound control is the next generation of eliminating unwanted sound in the passenger compartment. The active sound control has a much broader range than the ANC system. In addition to the microphones in the headliner, the active sound control also receives input from the engine speed pulse (NEP) to provide various levels of sound cancelling depending on changes in the engine RPM.

Telematics Muting Logic

The navigation system provides voice control for the audio, the XM, and the CD player. The navigation system uses the GA-Net bus to communicate the voice control commands to the audio unit. When using the TALK/BACK buttons, the front and the rear speakers are muted and you hear the navigation instructions through the center speaker. When using the route guidance (RG), the center speaker provides the navigation sound and the front and the rear speakers continue to play the audio. When using the HFL/AcuraLink, the center speaker and the rear speakers are muted and the front speakers give the telephone sound. When using the HFL/AcuraLink and the RG or the talk back, the rear speakers are muted and you hear the telephone sound and navigation instructions through the front speakers. Muting commands are passed on the GA-Net bus. For more information, see the navigation service information. The outline of the audio interruption function is shown in the following table.

ContentsAudio Output
Center CHLeft Front CHRight Front CHRight Rear CHLeft Rear CH
Pressing TALK/BACK buttonsNavigation outputMutedMutedMutedMuted
Route guidanceNavigation output and audioAudioAudioAudioAudio
HFL/AcuraLinkMutedTelephone soundTelephone soundMutedMuted
HFL/AcuraLink and route guidance or talk backNavigation outputTelephone soundTelephone soundMutedMuted

Bluetooth Audio

Bluetooth audio allows approved Bluetooth cell phones equipped with music function to play music via a car audio system using Bluetooth technology. You can control the cell phone's music player remotely using the wireless connection.

  1. You can play music stored in your cell phone using the wireless connection *1 .
  2. You can choose next song, previous song and resume/pause via wireless *2 .

*1: Call phone must support AVRCP 1.0 for Bluetooth technology, and also be on the Acura approved HFL list at www.acura.com/handsfreelink.

*2: Not all phones support the Bluetooth audio function.

Supported Devices

  1. Bluetooth music phones that support AVRCP 1.0.
  2. Bluetooth adapters for portable music devices including iPod are not supported.

Note. Availability of the functions depends on the connected phone. The latest support information is updated through the website www.acura.com/handsfreelink.

Pairing a Cell Phone

To pair a cell phone, refer to PAIRING A CELL PHONE in the HandsFreeLink system (see NAVIGATION THROUGH HFL MENUS ). Once a cell phone is paired, the process does not have to be repeated for the cell phone.

Scheme 6

Scheme 6: Procedure

Scheme 7

Scheme 7

Scheme 8

Scheme 8

Scheme 9

Scheme 9

Scheme 10

Scheme 10

Scheme 11

Scheme 11
  1. Push the USB/AUX button (A) to select Bluetooth Audio source. NOTE: If you push the USB/AUX button when no cell phone is connected, NO CONNECT is displayed. If you see NO CONNECT when you are using the cell phone music function, check that the device is properly paired. If it is paired, the cell phone may not be compatible. See www.acura.com/handsfreelink for more information. Music titles and artist names are not displayed.
  2. Start playing the music in the paired cell phone. NOTE: Depending on the cell phone, the music may start automatically, or the user may need to select headset as an audio output.
  3. A user can select the next song or the previous song using the SKIP button (A).
  4. With navigation, using the interface dial (A) to select [Sound Setup] or [RESUME/PAUSE]. Without navigation, using the Setup button (B) to select audio settings (RESUME/PAUSE and sound settings).
  5. To turn the Bluetooth Audio mode off, select another audio mode (AM/FM, XM, CD/DVD, or USB).

Disc Handing and Cleaning

To avoid damaging or leaving fingerprints on a disc (CD, DVD, DVD-A, etc.), always handle it by the edges and place it in a jewel case whenever it is outside the audio or the audio-navigation unit. Deep scratches or fingerprints on the back of the disc can cause loading problems, poor sound quality, skipping, or other errors.

Scheme 12

Scheme 12: Disc Handing and Cleaning

Smudges and fingerprints can be carefully removed using a mild cleaner and tissues designed to clean eyeglasses. To clean a disc, use a clean soft cloth. Very gently wipe across the disc from the center to the outside edge, never in a circular motion.

Scheme 13

Scheme 13

Do not place stabilizer rings or labels on the disc.

Scheme 14

Scheme 14: With Navigation

Scheme 15

Scheme 15: Without Navigation

Audio Glossary

Note. All items may not apply to this vehicle. See the Owner's Manual for more information.

ItemDefinition
Active noise cancellationThe active noise cancellation system cancels some of the vehicle noise. This occurs in the 1, 500-2, 400 rpm range. Microphones detect the low frequency sound, and the system outputs a canceling sound from the audio speaker.
Active sound controlThe next generation of sound control that reduces unwanted sound in the passenger compartment.
AcuraLinkThis device receives information from the XM satellites and passes XM audio information to the audio unit. In addition, traffic and weather information is sent to the navigation unit.
AM (Amplitude Modulation)The type of transmission used in the standard radio broadcast band from 530 to 1, 710 kHz.
AmplifierA device that increases the level of a signal by increasing the current or voltage.
AntennaA device used to send or receive electromagnetic waves through the air.
ATA (PC Card)A type of card that has been tested for use in playing WMA and MP3 music files in the PC card slot.
Audio remote switchThe switches on the steering wheel that control the audio system.
Auxiliary jackAllows the client to use a portable audio device to input audio recordings.
BalanceA control that changes the relative volume of the left and right channels.
BandA range of frequencies between two definite limits. Bands are assigned by the Federal Communications Commission for specific uses.
BassAn adjustment for the low frequency sounds of around 160 Hz and below.
Bluetooth AudioAllows the client to play audio recordings stored on their cell phone through the audio system.
ByteA unit of storage for computer files and memory. A CD holds approximately 700 million bytes.
CassetteAudio or video magnetic tape container having two reels. Client can insert it for play back.
Compact flashA standard for small-size (3x4 cm), memory cards used in mobile computers, PDAs, and digital cameras. Compact flash memory cards are available in size of 32 MB up to 4 GB or more and can be played in the audio PC slot. Sizes above 1 GB have not been tested.
CD (Compact Disc)A 4.5-inch plastic disc containing digital audio recording that is played optically on a laser equipped player. Never use discs with a paper label. In a hot vehicle, labels can curl up and jam the unit.
CD (audio disc) changerCD player that can store and play more than one CD. Two types are available. Some units accept CDs fed into the changer one at a time, and others accept a magazine (with CDs stacked in a container).
CD playerA component designed to play compact disc recordings using a laser optical pickup. The signal from a CD player usually requires amplification.
CSF (Cold Start Fix) screensThese screens are displayed if the system requires a GPS initialization. The vehicle should be moved outside into an open area away from buildings/power lines.
DB (Decibels)A method of measuring sound or radio signal strength received by the audio unit antenna.
DistortionInexact reproduction of an audio signal caused by playing music at levels the audio system cannot handle, you will typically hear this as static, pops, or crackles.
Dolby (noise reduction)A processing system developed by Dolby Laboratories that reduces the background noise on recording media. The result is a cleaner playback from the audio system.
DUETA serial data communication line used for sub display.
DVD (Digital Versatile Disc)A 4.5-inch CD-like format used for storing movies with digital audio and video features. The DVD-A format is a DVD format designed for DVD audio systems. Some vehicles can play DVD and DVD-A formats.
EqualizerA device that changes the relative volume of individual frequency bands to suit personal tastes of the listener.
FaderThe control that adjusts the relative volume levels of front and rear speakers in a four-speaker system.
FormatTo prepare a PC card to receive files this function is done on a PC. Always choose either FAT or FAT32, as the NTFS format is not accepted by the system. Pick the default sectors for the format method selected.
FM (Frequency Modulation)The form of modulation used for radio and television sound transmission in most of the world. Less prone to interference than AM. The FM broadcast band in North America covers roughly 87.7 to 107.9 MHz.
GA-NetThe GA-Net allows the audio unit to communicate with all the audio and navigation components in a vehicle. If there is an open in the GA-Net or components, the entire audio and navigation system may appear inoperative.
GB (Gigabyte)A unit of memory or disc storage equal to one billion bytes (1, 000 million bytes).
HDDHard disc drive. The navigation does not use a DVD, but uses a hard drive to contain the navigation software. Can be updated with a CD or DVD that is inserted into the audio disc slot.
Hertz (Hz)The unit of frequency equal to one cycle per second (cps). One kilohertz (kHz) equals 1, 000 cps; one megahertz (MHz) equals 1 million cps.
Integrated amplifierA component that combines a pre amp and a power amp into a single unit. A receiver combines an integrated amp and a tuner into a single unit.
Jewel caseThe hard plastic case that contains a compact disc or DVD. Always use a jewel case to prevent scratches on the underside of a CD or DVD.
LCD (Liquid Crystal Display)A type of digital display that changes reflectance or transmittance when an electrical field is applied to it.
MemoryCircuitry or devices that hold information in electrical or magnetic form, such as the AM/FM radio presets.
MB (Megabyte)One million bytes. Written as 1 MB. Megabytes are used as a measure of digital storage space. For example, a CD can hold 650 MB.
MicAn abbreviation for microphone. For vehicles with navigation, the microphone accepts navigation voice commands to control audio and navigation functions.
MP3 music filesMP3 is an audio coding format. MP3 is a popular audio compression format on the Internet and computers. CDs and PC cards with these files can be played on some vehicle's audio system.
MuteWhen the navigation gives guidance, the front speakers are muted (no music). When you use the voice control system, all of the speakers are muted.
NoiseUnwanted random sounds like buzzing, hiss, pops, static, whine, etc.
PC cardThe slot used for playing MP3 and WMA music files. The PC card is usually a combination of a small flash card in a PCMCIA adaptor that slides into the slot. The ATA, SD, and compact flash types of cards have been tested up to 1 GB.
PCMCIAA computer standard for the slot that the PC card slides into. Another term for the PC card slot.
ProcessorThe part of an audio device that performs tasks/calculations. In the audio unit, the processor handles muting to allow the navigation system to speak its voice commands, and the decoding/playback of the sound files, etc.
RadioA head unit that combines a tuner, a preamplifier, and often a power-amplifier.
Route guidance (RG)Spoken voice used for turn-by-turn navigation from the audio speakers.
StereoA recording of at least two channels where you can hear sound or music from the left or right side.
SD (Secure Digital) cardThis compact type of memory card allows for fast data transfer and has built-in security functions. SD cards have a small write-protection switch on the side.
ShieldA metallic foil or braided wire layer surrounding conductors which are designed to prevent electrostatic or electromagnetic interference (noise) from external sources which you hear as buzzing or popping sounds which you hear on the speakers.
Speaker (Loudspeaker)A device that converts electrical energy into acoustical energy (sound).
Speed-sensitive volume compensation (SVC)The SVC increases the audio volume to compensate for increased interior noise when the vehicle is driven at freeway speeds.
SubwooferA loudspeaker made to reproduce the lowest audio frequencies, from about 25 Hz to 125 Hz.
TrackA sound recording on a CD, tape, or PC card.
TrebleAn adjustment to control the volume of the high frequency sounds.
TunerA component (or part of a component) that receives radio signals and selects one broadcast from many.
TweeterA speaker designed to reproduce the higher frequencies (treble) only.
USBUniversal serial bus. The USB is used for playing audio files (MP3, WMA, AAC, etc.) on the external device through the audio unit.
USB portAllows the clients to play data such as input audio recording from portable audio devices (such as iPod) or data from USB flash memory.
Voice coilA coil of wire wrapped around a tube and then attached to the speaker cone or diaphragm. When an audio signal is applied, the coil becomes an electromagnet and interacts with the permanent magnet causing the cone or diaphragm to vibrate. We interpret these vibrations as sound.
Volume controlAllows you to control the loudness of the music.
WMA music fileWindows Media Audio File. This is an accepted format for music files to be played on either a CD-R, a CD-RW, or a PC card.
WooferA speaker that is designed to reproduce low (bass) frequencies only.
XM radioSatellite based radio transmission, which also uses a ground based repeater network to ensure seamless reception. The channels originate from XM's broadcast center, in Washington DC, and uplink to two satellites. These satellites transmit the signal across the entire continental United States.
XM receiverThe external component that receives and processes the XM signals from the XM satellites, and terrestrial (land) stations. The audio unit communicates to the XM receiver over the GA-Net bus.

Audio Unit Connector for Inputs and Outputs (with navigation)

Note. Refer to the navigation system service information for audio-navigation unit connector G and J inputs and outputs (see NAVIGATION UNIT CONNECTOR FOR INPUTS AND OUTPUTS ). The connector with the asterisk (*) mark is a lever-lock type (see LEVER-LOCKED CONNECTOR ).

Scheme 16

Scheme 16: AUDIO-NAVIGATION UNIT CONNECTOR A (24P)
CavityWire ColorTerminal NameConnects to
A3LT BLUK-LINEData link connector (DLC)
A4WHTSCTY2Navigation display unit
A5BRNREMOTE GNDAudio remote, navigation-HFL voice control switch ground
A6PURRR PREStereo amplifier
A7PNKRR PRE+Stereo amplifier
A10BLURL PREStereo amplifier
A11BRNRL PRE+Stereo amplifier
A12BLKGNDBody ground to G502
A14PURACCNo. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box
A15BLKVSPPCM, ECPS control unit
A16PNKREMOTEAudio remote switch
A17LT GRNSWD +BStereo amplifier
A18REDFR PREStereo amplifier
A19GRNFR PRE +Stereo amplifier
A22LT GRNFL PREStereo amplifier
A23WHTFL PRE +Stereo amplifier
A24WHT+ BNo. 15 (10 A) fuse in the under-hood fuse/relay box

AUDIO-NAVIGATION UNIT CONNECTOR A (24P)

Scheme 17

Scheme 17: AUDIO-NAVIGATION UNIT CONNECTOR B (24P)
CavityWire ColorTerminal NameConnects to
B1REDAUX LCHAuxiliary jack assembly
B2BLKAUX SIG GNDAuxiliary jack assembly
B3PURAUX DETAuxiliary jack assembly
B5BRNTELEM SIG +HandsFreeLink control unit
B9BLKCTR PREStereo amplifier
B10YELCTR PRE +Stereo amplifier
B12GRNSUBW PRE +Stereo amplifier
B13WHTAUX RCHAuxiliary jack assembly
B14YELAUX GNDAuxiliary jack assembly
B15GRY (1)AUX SH GNDShield for terminals No. 1, No. 2, and No. 13
B16YELTELEM SIGHandsFreeLink control unit
B17GRY (1)TELEM SIG SHShield for terminals No. 5 and No. 16
B18BLUGA-NET BUS2Navigation display unit
B19PNKGA-NET BUS2 +Navigation display unit
B21LT BLUCPM SWD + BAudio-navigation and HVAC switch panel
B22GRY (1)GA-NET BUS2 SHShield for terminals No. 18 and No. 19
B24LT GRNSUBW PREStereo amplifier
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

AUDIO-NAVIGATION UNIT CONNECTOR B (24P)

Scheme 18

Scheme 18: AUDIO-NAVIGATION UNIT CONNECTOR C (14P)
CavityWire ColorTerminal NameConnects to
C1 (3)WHT+BXM receiver
C2 (3)LT BLUSYS ACCXM receiver
C3GRY (1)GA-NET BUS SHShield for terminals No. 9 and No. 10
C4GRY (1)AUDIO SHShield for terminals No. 5, No. 6, No. 13, and No. 14
C5GRNAUDIO R+AcuraLink control unit (XM receiver) (2) , XM receiver (3) , HandsFreeLink control unit
C6BLKAUDIO L+AcuraLink control unit (XM receiver) (2) , XM receiver (3) , HandsFreeLink control unit
C9PNKGA-NET BUS+AcuraLink control unit (XM receiver) (2) , XM receiver (3) , HandsFreeLink control unit, Navigation display unit
C10BLUGA-NET BUSAcuraLink control unit (XM receiver) (2) , XM receiver (3) , HandsFreeLink control unit, Navigation display unit
C11 (3)BLKGNDXM receiver
C13WHTAUDIO RAcuraLink control unit (XM receiver) (2) , XM receiver (3) , HandsFreeLink control unit
C14REDAUDIO LAcuraLink control unit (XM receiver) (2) , XM receiver (3) , HandsFreeLink control unit
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram. (2) USA models (3) Canada models
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(2)USA models
(3)Canada models

AUDIO-NAVIGATION UNIT CONNECTOR C (14P)

AUDIO-NAVIGATION UNIT CONNECTOR D (20P)

Note. Refer to the navigation system section for the terminals inputs and outputs not shown (see AUDIO-NAVIGATION UNIT CONNECTOR D (20P) ).

Scheme 19

Scheme 19: AUDIO-NAVIGATION UNIT CONNECTOR D (20P)
CavityWire ColorTerminal NameConnects to
D1REDRS 485Stereo amplifier
D2GRNRS 485+Stereo amplifier
D6PNKB-CAN HB-CAN bus line
D11BRN (1)RS 485 SHShield for terminals No. 1 and No. 2
D15BLUB-CAN LB-CAN bus line
D17GRNRG L GNDStereo amplifier
D19REDRG L+Stereo amplifier
D20GRY (1)RG L SHShield for terminals No. 17 and No. 19
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

AUDIO-NAVIGATION UNIT CONNECTOR D (20P)

Scheme 20

Scheme 20: AUDIO-NAVIGATION UNIT CONNECTOR E (5P)
CavityWire ColorTerminal NameConnects to
E3ANT +BAM/FM/XM antenna
E4RF INAM/FM/XM antenna
E5RF SHShield for terminal No. 4

AUDIO-NAVIGATION UNIT CONNECTOR E (5P)

Scheme 21

Scheme 21: AUDIO-NAVIGATION UNIT CONNECTOR F (12P)
CavityWire ColorTerminal NameConnects to
F1YELDUET RXAudio-navigation and HVAC switch panel
F2GRY (1)DUET SHShield for terminals No. 1 and No. 7
F3REDOPERA RXAudio-navigation and HVAC switch panel
F4GRY (1)OPERA SHShield for terminals No. 3 and No. 9
F5BLUVOLAudio-navigation and HVAC switch panel
F6GRY (1)VOL SHShield for terminals No. 5, No. 11, and No. 12
F7BRNDUET TXAudio-navigation and HVAC switch panel
F8BLUDUET CONTAudio-navigation and HVAC switch panel
F9GRNOPERA TXAudio-navigation and HVAC switch panel
F10ORNOPERA CONTAudio-navigation and HVAC switch panel
F11PNKVOL+Audio-navigation and HVAC switch panel
F12GRNPWR SWAudio-navigation and HVAC switch panel
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

AUDIO-NAVIGATION UNIT CONNECTOR F (12P)

AUDIO-NAVIGATION UNIT CONNECTOR H (28P)

Note. Refer to the navigation system section for the terminals inputs and outputs not shown (see AUDIO-NAVIGATION UNIT CONNECTOR H (28P) )

Scheme 22

Scheme 22: AUDIO-NAVIGATION UNIT CONNECTOR H (28P)
CavityWire ColorTerminal NameConnects to
H21WHTANC CHK2ANC/active sound control unit

AUDIO-NAVIGATION UNIT CONNECTOR H (28P)

Scheme 23

Scheme 23: AUDIO-NAVIGATION UNIT CONNECTOR K (7P)
CavityWire ColorTerminal NameConnects to
K1USB VBUSUSB adapter
K2USB DATAUSB adapter
K3USB DATA+USB adapter
K4USB GNDUSB adapter
K5USB SHShield for terminals No. 1, No. 2, No. 3, and No. 4
K6USB DETConnect to terminal No. 7
K7USB DET GNDConnect to terminal No. 6

AUDIO-NAVIGATION UNIT CONNECTOR K (7P)

Audio Unit Connector for Inputs and Outputs (without navigation)

Note. The connector with the asterisk (*) mark is a lever-lock type (see LEVER-LOCKED CONNECTOR ).

Scheme 24

Scheme 24: Audio Unit Connector for Inputs and Outputs (without navigation)

Scheme 25

Scheme 25: AUDIO UNIT CONNECTOR A (24P)
CavityWire ColorTerminal NameConnects to
A3LT BLUK-LINEData link connector (DLC)
A4LT GRNSCTY2Passenger's under-dash fuse/relay box
A5BRNREMOTE GNDAudio remote-HFL switch ground
A6PURRR PREStereo amplifier
A7PNKRR PRE+Stereo amplifier
A10BLURL PREStereo amplifier
A11BRNRL PRE+Stereo amplifier
A12BLKGNDBody ground to G502
A14PURACCNo. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box
A16PNKREMOTEAudio remote switch
A17LT GRNSWD +BStereo amplifier
A18REDFR PREStereo amplifier
A19GRNFR PRE +Stereo amplifier
A22LT GRNFL PREStereo amplifier
A23WHTFL PRE +Stereo amplifier
A24WHT+BNo. 15 (10 A) fuse in the under-hood fuse/relay box

AUDIO UNIT CONNECTOR A (24P)

Scheme 26

Scheme 26: AUDIO UNIT CONNECTOR B (24P)
CavityWire ColorTerminal NameConnects to
B1REDAUX LCHAuxiliary jack assembly
B2BLKAUX SIG GNDAuxiliary jack assembly
B3PURAUX DETAuxiliary jack assembly
B5BRNTELEM SIG +HandsFreeLink control unit
B7WHTANC CHK2ANC/active sound control unit
B9BLKCTR PREStereo amplifier
B10YELCTR PRE +Stereo amplifier
B12GRNSUBW PRE+Stereo amplifier
B13WHTAUX RCHAuxiliary jack assembly
B14YELAUX GNDAuxiliary jack assembly
B15GRY (1)AUX SH GNDShield for terminals No. 1, No. 2, and No. 13
B16YELTELEM SIGHandsFreeLink control unit
B17GRY (1)TELEM SIG SHShield for terminals No. 5 and No. 16
B19LT BLUAMP MUTEStereo amplifier
B21LT BLUCPM SWD +BAudio and HVAC switch panel
B24LT GRNSUBW PREStereo amplifier
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

AUDIO UNIT CONNECTOR B (24P)

Scheme 27

Scheme 27: AUDIO UNIT CONNECTOR C (14P)
CavityWire ColorTerminal NameConnects to
C1WHT+ BXM receiver, USB adapter control unit
C2LT BLUSYS ACCXM receiver, USB adapter control unit
C3GRY (1)GA-NET BUS SHShield for terminals No. 9 and No. 10
C4GRY (1)AUDIO SHShield for terminals No. 5, No. 6, No. 13, and No. 14
C5GRNAUDIO R +XM receiver, HandsFreeLink control unit, USB adapter control unit
C6BLKAUDIO L+XM receiver, HandsFreeLink control unit, USB adapter control unit
C9PNKGA-NET BUS+XM receiver, HandsFreeLink control unit, USB adapter control unit
C10BLUGA-NET BUSXM receiver, HandsFreeLink control unit, USB adapter control unit
C11BLKGNDXM receiver, USB adapter control unit
C13WHTAUDIO RXM receiver, HandsFreeLink control unit, USB adapter control unit
C14REDAUDIO LXM receiver, HandsFreeLihk control unit, USB adapter control unit
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

AUDIO UNIT CONNECTOR C (14P)

Scheme 28

Scheme 28: AUDIO UNIT CONNECTOR D (20P)
CavityWire ColorTerminal NameConnects to
D6PNKB-CAN HB-CAN bus line
D15BLUB-CAN LB-CAN bus line

AUDIO UNIT CONNECTOR D (20P)

Scheme 29

Scheme 29: AUDIO UNIT CONNECTOR E (5P)
CavityWire ColorTerminal NameConnects to
E3ANT +BAM/FM/XM antenna
E4RF INAM/FM/XM antenna
E5RF SHShield for terminal No. 4

AUDIO UNIT CONNECTOR E (5P)

Scheme 30

Scheme 30: AUDIO UNIT CONNECTOR F (12P)
CavityWire ColorTerminal NameConnects to
F1YELDUET RXAudio display unit
F2GRY (1)DUET SHShield for terminals No. 1 and No. 7
F3REDOPERA RXAudio and HVAC switch panel
F4GRY (1)OPERA SHShield for terminals No. 3 and No. 9
F5BLUVOLAudio and HVAC switch panel
F6GRY (1)VOL SHShield for terminals No. 5, No. 11, and No. 12
F7BRNDUET TXAudio display unit
F8BLUDUET CONTAudio display unit
F9GRNOPERA TXAudio and HVAC switch panel
F10ORNOPERA CONTAudio and HVAC switch panel
F11PNKVOL+Audio and HVAC switch panel
F12GRNPWR SWAudio and HVAC switch panel
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

AUDIO UNIT CONNECTOR F (12P)

Scheme 31

Scheme 31: Audio-Navigation and HVAC Switch Panel Connector for Inputs and Outputs (with navigation)

Scheme 32

Scheme 32: AUDIO-NAVIGATION and HVAC SWITCH PANEL CONNECTOR A (20P)
CavityWire ColorTerminal NameConnects to
A1WHT+ BNo. 15 (10 A) fuse in the under-hood fuse/relay box
A3BLKGNDBody ground to G501
A4REDOPERA RXAudio-navigation unit
A5ORNOPERA CONTAudio-navigation unit
A6YELDUET RXAudio-navigation unit
A7GRY (1)DUET SHShield for terminals No. 6 and No. 16
A8GRNILLUMI-(CPM)Gauge control module
A9PNKVOL+Audio-navigation unit
A10GRYILLUMI+No. 6 (7.5 A) fuse in the passenger's under-dash fuse/relay box
A11LT GRNIG2No. 16 (7.5 A) fuse in the driver's under-dash fuse/relay box
A13GRY (1)OPERA SHShield for terminals No. 4, No. 5, and No. 14
A14GRNOPERA TXAudio-navigation unit
A15BLUDUET CONTAudio-navigation unit
A16BRNDUET TXAudio-navigation unit
A17GRNPWR SWAudio-navigation unit
A18BLUVOLAudio-navigation unit
A19LT BLUCPM SWD + BAudio-navigation unit
A20PURACCNo. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

AUDIO-NAVIGATION AND HVAC SWITCH PANEL CONNECTOR A (20P)

AUDIO-NAVIGATION and HVAC SWITCH PANEL CONNECTOR B (32P)

Note. Refer to the climate control circuit diagram for audio-navigation and HVAC switch panel connector B (32P) terminals (see CIRCUIT DIAGRAM ).

Scheme 33

Scheme 33: AUDIO-NAVIGATION and HVAC SWITCH PANEL CONNECTOR B (32P)
CavityWire ColorTerminal NameConnects to
B1GRYSYNC LEDClimate control unit
B2GRNFR DEF LEDClimate control unit
B6PURDISP-SOClimate control unit
B7REDDISP-CLKClimate control unit
B10BLUDR AUTO SWClimate control unit
B11WHTSYNC SWClimate control unit
B12GRNAC AN/OFF SWClimate control unit
B13BLKAS MODE SWClimate control unit
B14REDAS AUTO SWClimate control unit
B15GRYRR DEF SWClimate control unit
B16BLUAC SWClimate control unit
B17PNKRR DEF LEDClimate control unit
B18PURRECIRC LEDClimate control unit
B24LT BLUDR MODE SWClimate control unit
B25ORNDR T UP SWClimate control unit
B26LT GRNDR T DN SWClimate control unit
B27BRNFAN UP SWClimate control unit
B28YELFAN DN SWClimate control unit
B29WHTAS T UP SWClimate control unit
B30BRNAS T DN SWClimate control unit
B31LT GRNRECIRC SWClimate control unit
B32LT BLUFR DEF SWClimate control unit

AUDIO-NAVIGATION AND HVAC SWITCH PANEL CONNECTOR B (32P)

Scheme 34

Scheme 34: Audio and HVAC Switch Panel Connector for Inputs and Outputs (without navigation)

Scheme 35

Scheme 35: AUDIO and HVAC SWITCH PANEL CONNECTOR A (20P)
CavityWire ColorTerminal NameConnects to
A1WHT+ BNo. 15 (10 A) fuse in the under-hood fuse/relay box
A3BLKGNDBody ground to G501
A4REDOPERA RXAudio unit
A5ORNOPERA CONTAudio unit
A8GRNILLUMI- (CPM)Gauge control module
A9PNKVOL+Audio unit
A10GRYILLUMI+No. 6 (7.5 A) fuse in the passenger's under-dash fuse/relay box
A11LT GRNIG2No. 16 (7.5 A) fuse in the driver's under-dash fuse/relay box
A13GRY (1)OPERA SHShield for terminals No. 4, No. 5, and No. 14
A14GRNOPERA TXAudio unit
A17GRNPWR SWAudio unit
A18BLUVOLAudio unit
A19LT BLUCPM SWD +BAudio unit
A20PURACCNo. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

AUDIO AND HVAC SWITCH PANEL CONNECTOR A (20P)

AUDIO and HVAC SWITCH PANEL CONNECTOR B (32P)

Note. Refer to the climate control circuit diagram for audio and HVAC switch panel connector B (32P) terminals (see CIRCUIT DIAGRAM ).

Scheme 36

Scheme 36: AUDIO and HVAC SWITCH PANEL CONNECTOR B (32P)
CavityWire ColorTerminal NameConnects to
B1GRYSYNC LEDClimate control unit
B2GRNFR DEF LEDClimate control unit
B6PURDISP-SOClimate control unit
B7REDDISP-CLKClimate control unit
B10BLUDR AUTO SWClimate control unit
B11WHTSYNC SWClimate control unit
B12GRNAC AN/OFF SWClimate control unit
B13BLKAS MODE SWClimate control unit
B14REDAS AUTO SWClimate control unit
B15GRYRR DEF SWClimate control unit
B16BLUAC SWClimate control unit
B17PNKRR DEF LEDClimate control unit
B18PURRECIRC LEDClimate control unit
B24LT BLUDR MODE SWClimate control unit
B25ORNDR T UP SWClimate control unit
B26LT GRNDR T DN SWClimate control unit
B27BRNFAN UP SWClimate control unit
B28YELFAN DN SWClimate control unit
B29WHTAST UP SWClimate control unit
B30BRNAS T DN SWClimate control unit
B31LT GRNRECIRC SWClimate control unit
B32LT BLUFR DEF SWClimate control unit

AUDIO AND HVAC SWITCH PANEL CONNECTOR B (32P)

Scheme 37

Scheme 37: Stereo Amplifier Connector for Inputs and Outputs (with navigation)

Scheme 38

Scheme 38: STEREO AMPLIFIER CONNECTOR A (18P)
CavityWire ColorTerminal NameConnects to
A1PNKSUBWSubwoofer
A2YELCTR SPFront center speaker
A3PURRR SPRight rear door speaker
A4REDRL SPLeft rear door speaker
A5YELSR R SPRight satellite speaker
A6BRNFR SPFront passenger's door speaker, Right tweeter
A7BLUFL SPDriver's door speaker. Left tweeter
A8GRNSR L SPLeft satellite speaker
A9BLKGNDBody ground to G501
A10BLUSUBW+Subwoofer
A11BRNCTR SP+Front center speaker
A12PNKRR SP+Right rear door speaker
A13WHTRL SP+Left rear door speaker
A14BLKSR R SP+Right satellite speaker
A15GRYFRS P+Front passenger's door speaker, Right tweeter
A16LT GRNFL SP+Driver's door speaker, Left tweeter
A17REDSR L SP+Left satellite speaker
A18WHT+ BNo. 15 (20 A) fuse in the passenger's under-dash fuse/relay box

STEREO AMPLIFIER CONNECTOR A (18P)

Scheme 39

Scheme 39: STEREO AMPLIFIER CONNECTOR B (28P)
CavityWire ColorTerminal NameConnects to
B1REDRS 485Audio-navigation unit
B3LT GRNSWD +BAudio-navigation unit, ANC/active sound control unit
B4YELCTR PRE +Audio-navigation unit
B6GRNSUBW PRE +Audio-navigation unit
B9GRNRG L GNDAudio-navigation unit
B10WHTFL PRE +Audio-navigation unit
B11GRNFR PRE +Audio-navigation unit.
B13BRNRL PRE +Audio-navigation unit
B14PNKRR PRE +Audio-navigation unit
B15GRNRS 485+Audio-navigation unit
B18BLKCTR PREAudio-navigation unit
B19LT GRNSUBW PREAudio-navigation unit
B20WHTSUBW SWD +BSubwoofer
B21REDRG L+Audio-navigation unit
B24LT GRNFL PREAudio-navigation unit
B25REDFR PREAudio-navigation unit
B27BLURL PREAudio-navigation unit
B28PURRR PREAudio-navigation unit

STEREO AMPLIFIER CONNECTOR B (28P)

Scheme 40

Scheme 40: STEREO AMPLIFIER CONNECTOR C (5P)
CavityWire ColorTerminal NameConnects to
C1PURANC FR +ANC/active sound control unit
C2ORNANC FRANC/active sound control unit
C3BLUANC RR+ANC/active sound control unit
C4YELANC RRANC/active sound control unit

STEREO AMPLIFIER CONNECTOR C (5P)

Scheme 41

Scheme 41: Stereo Amplifier Connector for Inputs and Outputs (without navigation)

Scheme 42

Scheme 42: STEREO AMPLIFIER CONNECTOR A (18P)
CavityWire ColorTerminal NameConnects to
A1REDRL SPLeft rear door speaker
A2BLUFL SPDriver's door speaker, Left tweeter
A3GRNSR L SPSubwoofer
A5PURRL SPRight rear door speaker
A6BRNFR SPFront passenger's door speaker, Right tweeter
A7YELCTR SPFront center speaker
A8YELSR R SPSubwoofer
A9BLKGNDBody ground to G501
A10WHTRL SP+Left rear door speaker
A11LT GRNFL SP+Driver's door speaker. Left tweeter
A12REDSR L SP+Subwoofer
A14PNKRR SP+Right rear door speaker
A15GRYFR SP+Front passenger's door speaker, Right tweeter
A16BRNCTR SP+Front center speaker
A17BLKSR R SP+Subwoofer
A18WHT+ BNo. 15 (20 A) fuse in the passenger's under-dash fuse/relay box

STEREO AMPLIFIER CONNECTOR A (18P)

Scheme 43

Scheme 43: STEREO AMPLIFIER CONNECTOR B (20P)
CavityWire ColorTerminal NameConnects to
B1LT GRNSWD +BAudio unit, ANC/active sound control unit
B3YELCTR PRE +Audio unit
B4GRNSUBW PRE +Audio unit
B6WHTFL PRE +Audio unit
B7GRNFR PRE +Audio unit
B9BRNRL PRE +Audio unit
B10PNKRR PRE +Audio unit
B11LT BLUAMP MUTEAudio unit
B13BLKCTR PREAudio unit
B14LT GRNSUBW PREAudio unit
B16LT GRNFL PREAudio unit
B17REDFR PREAudio unit
B19BLURL PREAudio unit
B20PURRR PREAudio unit

STEREO AMPLIFIER CONNECTOR B (20P)

Scheme 44

Scheme 44: STEREO AMPLIFIER CONNECTOR C (5P)
CavityWire ColorTerminal NameConnects to
C1PURANC FR +ANC/active sound control unit
C2ORNANC FRANC/active sound control unit
C3BLUANC RR+ANC/active sound control unit
C4YELANC RRANC/active sound control unit

STEREO AMPLIFIER CONNECTOR C (5P)

Scheme 45

Scheme 45: XM Receiver Connector for Inputs and Outputs (without AcuraLink)

Scheme 46

Scheme 46: XM RECEIVER CONNECTOR A (14P)
CavityWire ColorTerminal NameConnects to
A1WHT+ BAudio-navigation unit
A2LT BLUSYS ACCAudio-navigation unit
A3GRY (1)GA-NET BUS SHShield for terminals No. 9 and No. 10
A5GRNAUDIO R +Audio-navigation unit, HandsFreeLink control unit
A6BLKAUDIO L+Audio-navigation unit, HandsFreeLink control unit
A9WHTGA-NET BUS+Audio-navigation unit, HandsFreeLink control unit
A10BLKGA-NET BUSAudio-navigation unit, HandsFreeLink control unit
A11BLKGNDAudio-navigation unit
A13WHTAUDIO RAudio-navigation unit, HandsFreeLink control unit
A14REDAUDIO LAudio-navigation unit, HandsFreeLink control unit
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

XM RECEIVER CONNECTOR A (14P) (CANADA MODELS WITH NAVIGATION)

CavityWire ColorTerminal NameConnects to
A1WHT+ BAudio unit, USB adapter control unit
A2LT BLUSYS ACCAudio unit, USB adapter control unit
A3GRY (1)GA-NET BUS SHShield for terminals No. 9 and No. 10
A5GRNAUDIO R +Audio unit, USB adapter control unit, HandsFreeLink control unit
A6BLKAUDIO L+Audio unit, USB adapter control unit, HandsFreeLink control unit
A9WHTGA-NET BUS+Audio unit, USB adapter control unit, HandsFreeLink control unit
A10BLKGA-NET BUSAudio unit, USB adapter control unit, HandsFreeLink control unit
A11BLKGNDAudio unit, USB adapter control unit
A13WHTAUDIO RAudio unit, USB adapter control unit, HandsFreeLink control unit
A14REDAUDIO LAudio unit, USB adapter control unit, HandsFreeLink control unit
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

XM RECEIVER CONNECTOR A (14P) (WITHOUT NAVIGATION)

Scheme 47

Scheme 47: XM RECEIVER CONNECTOR B (2P)
CavityWire ColorTerminal NameConnects to
B1SAT/TERAM/FM/XM antenna
B2GND SHShield for terminal No. 1

XM RECEIVER CONNECTOR B (2P)

Scheme 48

Scheme 48: USB Adapter Control Unit Connector for Inputs and Outputs (without navigation)

Scheme 49

Scheme 49: USB ADAPTER CONTROL UNIT CONNECTOR A (14P)
CavityWire ColorTerminal NameConnects to
A1WHT+BAudio unit, XM receiver
A2LT BLUSYS ACCAudio unit, XM receiver
A3GRY (1)GA-NET BUS SHShield for terminals No. 9 and No. 10
A4GRY (1)AUDIO SHShield for terminals No. 5, No. 6, No. 13, and No. 14
A5GRNAUDIO R +Audio unit, XM receiver, HandsFreeLink control unit
A6BLKAUDIO L+Audio unit, XM receiver, HandsFreeLink control unit
A9PNKGA-NET BUS +Audio unit, XM receiver, HandsFreeLink control unit
A10BLUGA-NET BUSAudio unit, XM receiver, HandsFreeLink control unit
A11BLKGNDAudio unit, XM receiver
A13WHTAUDIO RAudio unit, XM receiver, HandsFreeLink control unit
A14REDAUDIO LAudio unit, XM receiver, HandsFreeLink control unit
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

USB ADAPTER CONTROL UNIT CONNECTOR A (14P)

Scheme 50

Scheme 50: USB ADAPTER CONTROL UNIT CONNECTOR B (5P)
CavityWire ColorTerminal NameConnects to
B1USB VBUSUSB adapter
B2USB DATAUSB adapter
B3USB DATA+USB adapter
B4USB GNDUSB adapter
B5USB SHShield for terminals No. 1, No. 2, No. 3, and No. 4

USB ADAPTER CONTROL UNIT CONNECTOR B (5P)

Scheme 51

Scheme 51: ANC/Active Sound Control Unit Connector for Inputs and Outputs

Scheme 52

Scheme 52: ANC/ACTIVE SOUND CONTROL UNIT 16P CONNECTOR
CavityWire ColorTerminal NameConnects to
1BLUANC RR +Stereo amplifier
2PURANC FR +Stereo amplifier
3BLUANC F MIC +8VFront HFL-navigation-ANC/active sound control microphone (2) , Front ANC/active sound control microphone*3
4WHTANC R MIC +8VRear ANC/active sound control microphone
5BRN (1)SH ANCM R GNDShield for terminal No. 4
6LT GRNSWD+BStereo amplifier, Audio-navigation unit (2) , Audio unit (3)
7BLKGNDBody ground to G501
8WHT+ BNo. 15 (10 A) fuse in the under-hood fuse/relay box
9YELANC RRStereo amplifier
10ORNANC FRStereo amplifier
11BLK (1)SH ANCM F GNDShield for terminal No. 3
12WHTANC CHK2Audio-navigation unit (2) , Audio unit (3)
14GRY (1)SH ANC GNDShield for terminals No. 1, No. 2, No. 9, and No. 10
15BLUNEPPCM, ECPS control unit
16PNKINTR LTDriver's MICU
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram. (2) With navigation (3) Without navigation
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(2)With navigation
(3)Without navigation

ANC/ACTIVE SOUND CONTROL UNIT 16P CONNECTOR

Scheme 53

Scheme 53: Front HFL-Navigation-ANC/Active Sound Control Microphone or Front HFL-ANC/Active Sound Control Micro

Scheme 54

Scheme 54: Rear ANC/Active Sound Control Microphone

FRONT HFL-NAVIGATION-ANC/ACTIVE SOUND CONTROL MICROPHONE 7P CONNECTOR or FRONT HFL-ANC/ACTIVE SOUND CONTROL MICROPHONE 7P CONNECTOR

Note. Refer to the navigation system section (see FRONT HFL-NAVIGATION-ANC/ACTIVE SOUND CONTROL MICROPHONE CONNECTOR FOR INPUTS AND OUTPUTS ) or the HandsFreeLink system section (see WITHOUT NAVIGATION ) for the terminals inputs and outputs not shown.

Scheme 55

Scheme 55: FRONT HFL-NAVIGATION-ANC/ACTIVE SOUND CONTROL MICROPHONE 7P CONNECTOR or FRONT HFL-ANC/ACTIVE SOUND
CavityWire ColorTerminal NameConnects to
1BLKGNDBody ground to G402
4BLUANC F MIC +8VANC/active sound control unit
6PURACCNo. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box
7WHT+ BNo. 15 (10 A) fuse in the under-hood fuse/relay box

FRONT HFL-NAVIGATION-ANC/ACTIVE SOUND CONTROL MICROPHONE 7P CONNECTOR OR FRONT HFL-ANC/ACTIVE SOUND CONTROL MICROPHONE 7P CONNECTOR

Scheme 56

Scheme 56: REAR ANC/ACTIVE SOUND CONTROL MICROPHONE 2P CONNECTOR
CavityWire ColorTerminal NameConnects to
1BRN (1)ANC R MIC SHShield for terminal No. 2
2WHTANC R MIC +8VANC/active sound control unit
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

REAR ANC/ACTIVE SOUND CONTROL MICROPHONE 2P CONNECTOR

Scheme 57

Scheme 57: Audio Display Unit Connector for Inputs and Outputs (without navigation)

Scheme 58

Scheme 58: AUDIO DISPLAY UNIT 12P CONNECTOR
CavityWire ColorTerminal NameConnects to
1YELDUET RXAudio unit
2BRNDUET TXAudio unit
4BLUDUET CONTAudio unit
6WHT+ BNo. 15 (10 A) fuse in the under-hood fuse/relay box
9BLKGNDBody ground to G501
10REDILLUMI-(LCD)Gauge control module
12GRYILLUMI +No. 6 (7.5 A) fuse in the passenger's under-dash fuse/relay box

AUDIO DISPLAY UNIT 12P CONNECTOR

Scheme 59

Scheme 59: Auxiliary Jack Assembly Connector for Inputs and Outputs

Scheme 60

Scheme 60: AUXILIARY JACK ASSEMBLY 5P CONNECTOR
CavityWire ColorTerminal NameConnects to
1PURAUX DETAudio-navigation unit
2YELAUX GNDAudio-navigation unit
3BLKAUX SIG GNDAudio-navigation unit
4REDAUX LCHAudio-navigation unit
5WHTAUX RCHAudio-navigation unit

AUXILIARY JACK ASSEMBLY 5P CONNECTOR (WITH NAVIGATION)

CavityWire ColorTerminal NameConnects to
1PURAUX DETAudio unit
2YELAUX GNDAudio unit
3BLKAUX SIG GNDAudio unit
4REDAUX LCHAudio unit
5WHTAUX RCHAudio unit

AUXILIARY JACK ASSEMBLY 5P CONNECTOR (WITHOUT NAVIGATION)

Scheme 61

Scheme 61: With Navigation

Scheme 62

Scheme 62

Scheme 63

Scheme 63

Scheme 64

Scheme 64

Scheme 65

Scheme 65

Scheme 66

Scheme 66

Scheme 67

Scheme 67: Without Navigation

Scheme 68

Scheme 68

Scheme 69

Scheme 69

Scheme 70

Scheme 70

Scheme 71

Scheme 71

Scheme 72

Scheme 72

How to Obtain the Audio Unit Serial Number

Note. This procedure can only be done after the power has been disconnected and reconnected to the audio unit, and the audio unit displays CODE when the audio unit is turned on.

Scheme 73

Scheme 73: How to Obtain the Audio Unit Serial Number

Scheme 74

Scheme 74

Scheme 75

Scheme 75
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode. Make sure the audio system is turned off.
  2. Push and hold the preset No. 1 and No. 6 buttons.
  3. While holding the buttons, push the VOLUME/POWER knob to on.
  4. Release the buttons, and the self-diagnosis begins.
  5. The display shows an 8 digit serial number. With navigation Without navigation
  6. Use all 8 numbers as the serial number when using the Interactive Network (iN) to retrieve the 5 digit anti-theft code.
  7. To end the self-diagnosis, turn the audio system off, or turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.

The audio system has a self-diagnostic function to help find problems with the audio system. To run the self-diagnostic function, do the following

Note. Not all self-diagnostic functions appear on all models. There may be other self-diagnostic functions that are for factory use only. The self-diagnostic function does not find every problem with the audio system. Check any official Honda service website for more information about the audio system.

Scheme 76

Scheme 76: How to Check the Audio System Condition

Scheme 77

Scheme 77
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode. Make sure the audio system is turned off.
  2. Push and hold the preset No. 1 and No. 6 buttons.
  3. While holding the buttons, push the VOLUME/POWER knob to on.
  4. Release the buttons, and the self-diagnosis begins.
  5. When you are in the self-diagnostic mode, pressing a preset button starts the diagnostic mode that is assigned to that preset button. NOTE: Any other diagnostic screens shown are for factory use only. No. 2 button Audio button, knob, and audio remote switch detection: Allows individual manual selection of all audio panel knobs, buttons, and remote switches to verify if they are functional. When properly detected, the selected knob, button, or audio remote switch name and/or value is displayed. To exit this mode, go to step 6. Once you exit this test, you must start again at step 1 . NOTE: When you test the USB/AUX button, the test result shows only USB. No. 3 button Entire LCD lighting/light-out mode: Turns on/off the entire LCD to show the presence (LCD stuck on) or absence (LCD dead) of an LCD segment. No. 4 button Duty indication mode (for the Illumination dim): Indicates the duty for the Illumination dim when the dash lights are on. No. 5 button Vehicle speed pulse (VSP) indication mode: Indicates the vehicle speed pulse. FM button (Push and hold 5 sec) Reception level indication mode: Indicates the reception level (dB). When entering the reception level check mode, the TITLE button (with navigation) and the A.SEL button (without navigation) turn the AM/FM antenna amplifier on and off.
  6. To end the self-diagnosis, turn the audio system off, or turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.

Display Specifications

Note. Any other diagnostic screens shown are for audio manufacturer's use only.

Entire LCD lighting/lights-outs mode (press No. 3 button)

This diagnostic screen checks for segments that may be dead (off) or stuck on.

All the display segments should be on. If any segments are dead (off), replace the audio-navigation and HVAC switch panel (see AUDIO-NAVIGATION AND HVAC SWITCH PANEL REMOVAL/INSTALLATION ) or the audio display unit (see AUDIO DISPLAY UNIT REMOVAL/INSTALLATION ). With all the segments on, press the No. 3 button a second time. The entire display must turn black. If any segments are stuck on, replace the audio-navigation and HVAC switch panel (see AUDIO-NAVIGATION AND HVAC SWITCH PANEL REMOVAL/INSTALLATION ), or the audio display unit (see AUDIO DISPLAY UNIT REMOVAL/INSTALLATION ).

When all the display icons are off, the backlight remains on. When you press preset No. 3 button a third time, the backlight turns off.

Note. If you hesitate too long after all the segments are on, the segments turn off automatically.

Scheme 78

Scheme 78: Entire LCD lighting/lights-outs mode (press No. 3 button)

Scheme 79

Scheme 79

Illumination level (for the gauge illumination) indication (press No. 4 button)

This diagnostic screen checks the gauge illumination input.

With the headlights on, you should see a values between 1 (max low) and 22 (max high).

When you dim and brighten the gauge with the dimmer knob, you should see this value change accordingly. If it does not, check for B-CAN DTCs.

Note. On vehicles without navigation system, the value changes from 1-10, then changes to 22 for maximum brightness.

Scheme 80

Scheme 80: Illumination level (for the gauge illumination) indication (press No. 4 button)

Scheme 81

Scheme 81

Vehicle speed pulse indication (press No. 5 button)

This diagnostic screen checks that the audio unit is receiving the VSP indication.

When you drive the vehicle, the VSP indicates the vehicle speed in km/h.

Scheme 82

Scheme 82: Vehicle speed pulse indication (press No. 5 button)

Scheme 83

Scheme 83

Reception level indication (Push and hold 5 sec AM/FM button)

This diagnostic screen checks the radio reception level. This level then can used in the diagnosis of radio reception quality. The reception level is displayed in decibels (dB).

Preparation

  1. Park the vehicle outdoors in a location with good radio reception.
  2. Tune to a powerful local FM radio station, then write down the radio station number.
  3. Tune to a powerful local AM radio station, then write down the radio station number.

Scheme 84

Scheme 84

Scheme 85

Scheme 85
  1. Enter the reception level indication mode in the self-diagnostic function. The AM/FM antenna amplifier is on and the character (A) is not displayed in the audio display.
  2. Tune to the FM radio station you wrote down in preparation using the TUNE button (with navigation) or the selector knob (without navigation), and note the decibel level of that station.
  3. Press and release the TITLE button (with navigation) or the A.SEL button (without navigation) to turn the AM/FM antenna amplifier off (A.SEL (with navigation) or A (without navigation) is now displayed in the audio display).
  4. Note the decibel level of that station.
  5. Press and release the TITLE button (with navigation) or the A.SEL button (without navigation) to turn the AM/FM antenna amplifier back on (A.SEL (with navigation) or A (without navigation) is not displayed in the audio display).
  6. Press and hold the AM/FM button for more than 5 seconds to enter the AM reception mode.
  7. Tune to the AM radio station you wrote down in preparation using the TUNE button (with navigation) or the selector knob (without navigation), and note the decibel level of that station.
  8. Press and release the TITLE button (with navigation) or the A.SEL button (without navigation) to turn the AM/FM antenna amplifier off (A.SEL (with navigation) or A (without navigation) is now displayed in the audio display).
  9. Note the decibel level of that station.
  10. Press and release the TITLE button (with navigation) or the A.SEL button (without navigation) to turn the AM/FM antenna amplifier back on (A.SEL (with navigation) or A (without navigation) is not displayed in the audio display).
  11. To end the self-diagnosis, turn the audio system off, or turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  12. Compare your results to a known-good vehicle, (make sure it is the same year and trim level) in the same location and direction, and under the same environmental conditions. If the reception level is within 10 % of the known-good vehicle, no repair is needed at this time. If the reception level is at least 10 % less than the known good vehicle, go to «POOR AM OR FM RADIO RECEPTION OR INTERFERENCE TROUBLESHOOTING; WITH NAVIGATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__poor-am-or-fm-radio-reception) (see ), «WITHOUT NAVIGATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__poor-am-or-fm-radio-reception) (see ).

Speaker Check Mode

Note. Not all self-diagnostic functions appear on all models. There may be other self-diagnostic functions that are for factory use only.

Scheme 86

Scheme 86: Speaker Check Mode

Scheme 87

Scheme 87
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode. Make sure the audio system is turned off.
  2. Push and hold the preset No. 1 and No. 3 buttons.
  3. While holding the buttons, push the VOLUME/POWER knob to on.
  4. Release the buttons and the speaker check mode begins. A tone should sound from one speaker.
  5. Each time you press the SKIP button, the test moves to the next speaker in the order listed in the table. NOTE: Adjust the volume level to a comfortable level. Display Specifications (-->) is pressed: (1)-->(2)-->(3)-->(4)-->(5)-->(6)-->(7) (<--) is pressed: (1)-->(7)-->(6)-->(5)-->(4)-->(3)-->(2) Speaker Displayed Segments Remarks (1) Driver's door speaker and left tweeter SPKR FR-L (1) SPK FR-L (2) You should hear a tone corresponding to the speaker (2) Front center speaker SPKR CENTER (1) SPK CTR (2) You should hear a tone corresponding to the speaker (3) Front passenger's door speaker and right tweeter SPKR FR-R (1) SPK FR-R (2) You should hear a tone corresponding to the speaker (4) Right rear door speaker and right satellite speaker (1) SPKR RR-R (1) SPK RR-R (2) You should hear a tone corresponding to the speaker (5) Subwoofer SPKR SUBWOOFER (1) SPK SUBW (2) You should hear a tone corresponding to the speaker (6) Left rear door speaker and left satellite speaker (1) SPKR RR-L (1) SPK RR-L (2) You should hear a tone corresponding to the speaker (7) All speakers SPKR ALL (1) SPK ALL (2) You should hear a tone corresponding to the speaker (1) With navigation (2) Without navigation NOTE: Any other diagnostic screens are for factory use only.
  6. To end the speaker check mode, turn the audio system off, or turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.

Scheme 88

Scheme 88: How to Check the ANC/Active Sound Control System in this Check Mode
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode. Make sure the audio system is turned off.
  2. Push and hold the preset No. 1 and No. 6 buttons.
  3. While holding the buttons, push the VOLUME/POWER knob to on.
  4. Release the buttons, and the self-diagnosis begins.
  5. With the engine stopped, and while in DIAG mode, turn the ANC ON to OFF by pressing the No. 1 button. A low frequency hum (50 Hz) should sound for about a minute. If the hum does not sound, check for an open in the wire between the ANC/active sound control unit and the audio unit. If the hum sounds for a second, check for an open in the wire between ANC/active sound control unit and the microphone. NOTE: The ANC/active sound control system is cancelled when any door is opened.

Scheme 89

Scheme 89: Screen indication ON

Scheme 90

Scheme 90

Scheme 91

Scheme 91: Screen indication OFF

Scheme 92

Scheme 92
  1. 6. To end the self-diagnosis, turn the audio system off, or turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.

XM Self-Diagnosis

Note. This diagnostic screen checks the audio unit's XM radio reception level. To check the XM reception, do the following

Scheme 93

Scheme 93: XM Self-Diagnosis
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Select XM1 mode.
  3. Turn off the audio system.
  4. Push and hold the preset No. 3 and No. 6 buttons.
  5. While holding the buttons, push the VOLUME/POWER knob to on.
  6. Continue holding the buttons for about 5 seconds, then release the buttons.
  7. Press and release preset No. 1 button to read the error code. Error Code No. Displayed Error Code Title Displayed Solution ERROR 00 NO ERROR System is normal. ERROR 04 NO SIGNAL Move the vehicle to an open area, and recheck. ERROR 05 NO XM ACTIVATION The subscription may have expired. Contact XM Radio at 800-852-9696. ERROR 06 NO XM AUTHORIZATION Contact XM Radio at 800-852-9696. ERROR 14 ANTENNA NOT CONNECTED / NO SIGNAL Refer to Error code: XM ANTENNA or XM LOADING is displayed; With AcuraLink (see «ERROR CODE: XM ANTENNA OR XM LOADING IS DISPLAYED (WITH ACURALINK)»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__error-code-xm-antenna-or-xm) ) Without AcuraLink (see «ERROR CODE: XM ANTENNA OR XM LOADING IS DISPLAYED (WITHOUT ACURALINK)»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__error-code-xm-antenna-or-xm) ) ERROR 24 ANTENNA SHORTED / NO SIGNAL Refer to Error code: XM ANTENNA or XM LOADING is displayed; With AcuraLink (see «ERROR CODE: XM ANTENNA OR XM LOADING IS DISPLAYED (WITH ACURALINK)»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__error-code-xm-antenna-or-xm) ) Without AcuraLink (see «ERROR CODE: XM ANTENNA OR XM LOADING IS DISPLAYED (WITHOUT ACURALINK)»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__error-code-xm-antenna-or-xm) ) ERROR 55 HARDWARE FAILURE (CONDITIONAL ACCESS FAILURE) There is an internal failure. Replace the AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ) or the XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). ERROR 65 HARDWARE FAILURE (CONDITIONAL ACCESS FAILURE) There is an internal failure. Replace the AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ) or the XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).
  8. To end the XM self-start/stop button to diagnosis, turn the audio system off, or turn the ignition switch to LOCK (0), or press the engine select the OFF mode.

XM Signal Reception Level Indication Mode

Note. When you receive any XM complaint, do the XM self-diagnosis to check for any XM error codes first. If there are no XM codes, check the XM signal reception level. To check the XM signal reception, do the following

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Select XM2 mode.
  3. Turn off the audio system.
  4. Push and hold the preset No. 3 and No. 6 buttons.
  5. While holding the buttons, push the VOLUME/POWER knob to on.
  6. Continue holding the buttons for about 5 seconds, then release the buttons.
  7. Press and release preset No. 1 button to read the XM signal reception. XM Signal Reception Solution SG NOSIG Move the vehicle to an open area, and recheck. If the signal does not improve, substitute a known-good AM/FM/XM antenna (see «AM/FM/XM ANTENNA REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. SG GOOD The XM signal is OK. SG MARG The XM signal is OK. SG WEAK Move the vehicle to an open area, and recheck. If the signal does not improve, substitute a known-good AM/FM/XM antenna (see «AM/FM/XM ANTENNA REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. SG VWEAK Move the vehicle to an open area, and recheck. If the signal does not improve, substitute a known-good AM/FM/XM antenna (see «AM/FM/XM ANTENNA REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck.
  8. To end the self-diagnosis, turn the audio system off, or turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.

Error Codes

The audio system can display a few error codes when some problems are detected with the audio disc player, the audio disc, the XM radio, the USB audio, or the anti-theft code. This is not a complete list of audio error codes. Refer to SYMPTOM TROUBLESHOOTING , or go to any official Honda service website for more service information.

Error Code DisplayedPossible CauseSolution
DISC ERRORThere is a problem with the disc player. A common problem is paper disc labels coming off the disc while in the player.Try to eject the disc and try another one. If there is still a problem, replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ), or the audio unit (see AUDIO UNIT REMOVAL/INSTALLATION ).
HEAT ERRORDisc player is hot. This can happen if the vehicle is parked out in the hot sun all day.Park the vehicle in a cooler place for a while and try the disc player again. If the error code is still present, try another disc. If the error code is still present, replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ), or the audio unit (see AUDIO UNIT REMOVAL/INSTALLATION ).
UNSUPPORTEDTrack/File format not supported.Current track is skipped. The next supported track or file plays automatically. Verify that CD file names end in CD-DA. Verify that CD-R or CD-RW with compressed music formats end in MP3 or WMA. Other file formats like iTunes (AAC) or Ogg are not recognized. WMA files may have (DRM) copy protection and cannot be read.
MECH ERRORCD label jammed in the mechanism. CD eject mechanism or motor is inoperative. CD spindle motor won't spin up the CD.Press the EJECT button and hold it for 5 seconds. If the CD does not eject, try again. If the CD still won't eject, replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ), or the audio unit (see AUDIO UNIT REMOVAL/INSTALLATION ).

CD ERROR CODES

Error Code DisplayedPossible CauseSolution
FILE ERRORThe audio unit cannot read the file(s).Check the files in the USB device. There is a possibility that the files have been damaged or are not supported.
MEDIA ERROR UNSUPPORTEDUnsupported USB device is connected.Connect the applicable USB device. (see Owner's Manual)
USB LOADINGData is being loaded from the USB device.Check the files in the USB device. There is a possibility that the files have been damaged, or are not supported.
USB NO SONGThere are no files or files that are not supported on the USB device.Check the files in the USB device. There is a possibility that the files have been damaged, or are not supported.
USB NO DATAUSB device is not connected.If the code appears when the USB devices is connected, go to USB device does not function troubleshooting: With navigation (see USB DEVICE DOES NOT FUNCTION (WITH NAVIGATION) ) Without navigation (see USB DEVICE DOES NOT FUNCTION (WITHOUT NAVIGATION) )

USB ERROR CODES

Error Code DisplayedPossible CauseSolution
CODE ERROR 1Anti-theft code mismatch (1st try).Enter the correct anti-theft code.
CODE ERROR EAnti-theft code mismatch (10th try).Remove the No. 15 (10 A) fuse in the under-hood fuse/relay box, then reinsert it. You will have 10 more tries to enter the correct anti-theft code.

AUDIO UNIT ERROR CODES

Error Code DisplayedPossible CauseSolution
LOADINGXM radio is acquiring audio or program information.Wait until the radio receives the information.
OFF AIRXM channel not in service.Try another XM channel.
NO SIGNALLoss of signal.Both terrestrial and satellite antennas have lost the signal. Park the vehicle outside with a clear view of the southern horizon.
UPDATINGXM radio is receiving information update from the network.This message disappears once the update finishes.
CHECK ANTENNAXM antenna error.Repair an open or a short in the satellite antenna. Substitute a known-good AM/FM/XM antenna (see AM/FM/XM ANTENNA REPLACEMENT ), and recheck. If the error is gone, replace the original AM/FM/XM antenna. If the error is still present, replace the antenna lead.
ANTENNA ERROR
No signal from XM.Check a known-good vehicle with XM radio. If the known-good vehicle has the same symptoms, contact XM Radio at 800-852-9696.
NOTE: Do these checks with the vehicle parked outside with a clear view of the southern horizon.
NOTE
Do these checks with the vehicle parked outside with a clear view of the southern horizon.

XM ERROR CODES

Poor AM or FM radio reception or interference (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check for aftermarket accessories including cell phones and chargers plugged into the vehicle accessory power sockets. Check the radio reception in an open area. Poor reception/interference can be caused by any of these conditions: The radio station is far away Atmospheric conditions are unfavorable A tall building, mountains, or high-voltage power lines are nearby Check the connectors for poor connections or loose terminals.

Scheme 94

Scheme 94: Poor AM or FM radio reception or interference (with navigation)

Scheme 95

Scheme 95

Scheme 96

Scheme 96

Scheme 97

Scheme 97

Scheme 98

Scheme 98

Scheme 99

Scheme 99

Scheme 100

Scheme 100
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Do the Seek Stop Test (see «SEEK STOP TEST»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__seek-stop-test) ) and the reception level indication in the Self-Diagnostic Function (see «RECEPTION LEVEL INDICATION (PUSH AND HOLD 5 SEC AM/FM BUTTON)»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__reception-level-indication-push-and-hold) ). Is the test vehicle within 10 % of the known-good vehicle? YES -Multipath interference or weak station. Operation is normal. NO -Go to step 3.
  3. Check the reception/interference is the same in several locations. Is the reception/interference the same? YES -Go to step 4. NO -Multipath interference or weak station. Operation is normal.
  4. Check that the reception/interference while the engine is running. Is there noise (static or whine) only with the engine running? YES -Check the antenna and radio grounds. If OK, check the charging system and the ignition system. NO -Go to step 5.
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  6. Disconnect the AM/FM/XM antenna 3P connector.
  7. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  8. Measure the voltage between AM/FM/XM antenna 3P connector terminal No. 3 and body ground. Is there battery voltage? YES -Go to step 13 . NO -Go to step 9.
  9. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  10. Disconnect audio-navigation unit connector E (5P).
  11. Check for continuity between audio-navigation unit connector E (5P) terminal No. 3 and AM/FM/XM antenna 3P connector terminal No. 3. Is there continuity? YES -Go to step 12. NO -Repair an open in the wire between the audio-navigation unit and the AM/FM/XM antenna. Also check the AM/FM antenna sublead/the main lead/the rear lead connector.
  12. Check for continuity between audio-navigation unit connector E (5P) terminal No. 3 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between the audio-navigation unit and the AM/FM/XM antenna. NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).
  13. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  14. Disconnect audio-navigation unit connector E (5P).
  15. Check for continuity between audio-navigation unit connector E (5P) terminal No. 4 and AM/FM/XM antenna 3P connector terminal No. 1. Is there continuity? YES -Go to step 16. NO -Replace the AM/FM antenna sublead and/or the main lead and/or the rear lead.
  16. Check for continuity between audio-navigation unit connector E (5P) terminal No. 4 and body ground. Is there continuity? YES -Replace the AM/FM antenna sublead and/or the main lead and/or the rear lead. NO -Go to step 17.
  17. Check for continuity between audio-navigation unit connector E (5P) terminal No. 5 and AM/FM/XM antenna 3P connector terminal No. 2. Is there continuity? YES -Go to step 18. NO -Replace the AM/FM antenna sublead and/or the main lead and/or the rear lead.
  18. Check for continuity between audio-navigation unit connector E (5P) terminals No. 4 and No. 5. Is there continuity? YES -Replace the AM/FM antenna sublead and/or the main lead and/or the rear lead. NO -Replace the AM/FM/XM antenna (see «AM/FM/XM ANTENNA REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the reception is still poor, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).

Poor AM or FM radio reception or interference (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check for aftermarket accessories including cell phones and chargers plugged into the vehicle accessory power sockets. Check the radio reception in an open area. Poor reception/interference can be caused by any of these conditions: The radio station is far away Atmospheric conditions are unfavorable A tall building, mountains, or high-voltage power lines are nearby Check the connectors for poor connections or loose terminals.

Scheme 101

Scheme 101: Poor AM or FM radio reception or interference (without navigation)

Scheme 102

Scheme 102

Scheme 103

Scheme 103

Scheme 104

Scheme 104

Scheme 105

Scheme 105

Scheme 106

Scheme 106

Scheme 107

Scheme 107
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Do the Seek Stop Test (see «SEEK STOP TEST»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__seek-stop-test) ) and the reception level indication in the Self-Diagnostic Function (see «RECEPTION LEVEL INDICATION (PUSH AND HOLD 5 SEC AM/FM BUTTON)»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__reception-level-indication-push-and-hold) ). Is the test vehicle within 10 % of the known-good vehicle? YES -Multipath interference or weak station. Operation is normal. NO -Go to step 3.
  3. Check that the reception/interference is the same in several locations. Is the reception/interference the same? YES -Go to step 4. NO -Multipath interference or weak station. Operation is normal.
  4. Check the reception/interference while the engine is running. Is there noise (static or whine) only with the engine running? YES -Check the antenna and radio grounds. If OK, check the charging system and the ignition system. NO -Go to step 5.
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  6. Disconnect the AM/FM/XM antenna 3P connector.
  7. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  8. Measure the voltage between AM/FM/XM antenna 3P connector terminal No. 3 and body ground. Is there battery voltage? YES -Go to step 13 . NO -Go to step 9.
  9. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  10. Disconnect audio unit connector E (5P).
  11. Check for continuity between audio unit connector E (5P) terminal No. 3 and AM/FM/XM antenna 3P connector terminal No. 3. Is there continuity? YES -Go to step 12. NO -Repair an open in the wire between the audio unit and the AM/FM/XM antenna. Also check the AM/FM antenna sublead/main lead/rear lead connector.
  12. Check for continuity between audio unit connector E (5P) terminal No. 3 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between the audio unit and the AM/FM/XM antenna. NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).
  13. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  14. Disconnect audio unit connector E (5P).
  15. Check for continuity between audio unit connector E (5P) terminal No. 4 and AM/FM/XM antenna 3P connector terminal No. 1. Is there continuity? YES -Go to step 16. NO -Replace the AM/FM antenna sublead and/or the main lead and/or the rear lead.
  16. Check for continuity between audio unit connector E (5P) terminal No. 4 and body ground. Is there continuity? YES -Replace the AM/FM antenna sublead and/or the main lead and/or the rear lead. NO -Go to step 17.
  17. Check for continuity between audio unit connector E (5P) terminal No. 5 and AM/FM/XM antenna 3P connector terminal No. 2. Is there continuity? YES -Go to step 18. NO -Replace the AM/FM antenna sublead and/or the main lead and/or the rear lead.
  18. Check for continuity between audio unit connector E (5P) terminals No. 4 and No. 5. Is there continuity? YES -Replace the AM/FM antenna sublead and/or the main lead and/or the rear lead. NO -Replace the AM/FM/XM antenna (see «AM/FM/XM ANTENNA REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the reception is still poor, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

Audio unit power switch will not turn on (No information display and no sound) (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ).

Scheme 108

Scheme 108: Audio unit power switch will not turn on (No information display and no sound) (with navigation)

Scheme 109

Scheme 109

Scheme 110

Scheme 110

Scheme 111

Scheme 111

Scheme 112

Scheme 112

Scheme 113

Scheme 113

Scheme 114

Scheme 114

Scheme 115

Scheme 115

Scheme 116

Scheme 116

Scheme 117

Scheme 117

Scheme 118

Scheme 118

Scheme 119

Scheme 119

Scheme 120

Scheme 120
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Push the VOLUME/POWER knob on to see if the audio system turns on. Does the audio display operate properly, and does the audio-navigation unit sound normal? YES -Intermittent failure, the system is OK at this time. NO -Go to step 3.
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  4. Check the No. 15 (10 A) fuse in the under-hood fuse/relay box and the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box. Are the fuses OK? YES -Go to step 5. NO -Replace the fuse(s), and recheck. If the fuse(s) blows again, check for a short in the No. 15 (10 A) fuse and/or the No. 18 (7.5 A) fuse circuit(s).
  5. Check for poor connections or loose terminals at the audio-navigation unit. Are there connections or terminals OK? YES -Go to step 6. NO -Repair poor connections or loose terminals, and recheck.
  6. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  7. Measure the voltage between body ground and audio-navigation unit connector A (24P) terminals No. 14 and No. 24 individually. Is there battery voltage? YES -Go to step 8. NO -If the +B wire does not have voltage, repair an open in the wire between the No. 15 (10 A) fuse in the under-hood fuse/relay box and the audio-navigation unit. If the ACC wire does not have voltage, repair an open in the wire between the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box and the audio-navigation unit.
  8. Measure the voltage between audio-navigation unit connector A (24P) terminal No. 12 and body ground. Is there less than 0.2 V? YES -Go to step 9. NO -Repair an open or high resistance in the wire between the audio-navigation unit and body ground (G502) (see «CONNECTOR TO FUSE/RELAY BOX INDEX»(/acura/zdx/i-2009-2013/remont/body-electrical/#fuserelay-boxes__connector-to-fuserelay-box-index) ).
  9. Measure the voltage between body ground and audio-navigation and HVAC switch panel connector A (20P) terminals No. 1 and No. 20 individually. Is there battery voltage? YES -Go to step 10. NO -If the +B wire does not have voltage, repair an open in the wire between the No. 15 (10 A) fuse in the under-hood fuse/relay box and the audio-navigation and HVAC switch panel. If the ACC wire does not have voltage, repair an open in the wire between the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box and the audio-navigation and HVAC switch panel.
  10. Measure the voltage between audio-navigation and HVAC switch panel connector A (20P) terminal No. 3 and body ground. Is there less than 0.2 V? YES -Go to step 11. NO -Repair an open or high resistance in the wire between the audio-navigation and HVAC switch panel and body ground (G501) (see «CONNECTOR TO FUSE/RELAY BOX INDEX»(/acura/zdx/i-2009-2013/remont/body-electrical/#fuserelay-boxes__connector-to-fuserelay-box-index) ).
  11. Measure the voltage between audio-navigation and HVAC switch panel connector A (20P) terminal No. 5 and body ground. Is there battery voltage? YES -Go to step 12. NO -Repair an open or a short in the wire between the audio-navigation and HVAC switch panel and the audio-navigation unit.
  12. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  13. Disconnect audio-navigation unit connector F (12P) and audio-navigation and HVAC switch panel connector A (20P).
  14. Check for continuity between audio-navigation and HVAC switch panel connector A (20P) terminal No. 17 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between the audio-navigation and HVAC switch panel and the audio-navigation unit. NO -Go to step 15.
  15. Check for continuity between audio-navigation unit connector F (12P) terminal No. 12 and audio-navigation and HVAC switch panel connector A (20P) terminal No. 17. Is there continuity? YES -Go to step 16. NO -Repair an open in the wire between the audio-navigation and HVAC switch panel and the audio-navigation unit.
  16. Reconnect audio-navigation and HVAC switch panel connector A (20P).
  17. Check for continuity between audio-navigation and HVAC switch panel connector A (20P) terminal No. 17 and body ground. Is there continuity? YES -Replace the audio-navigation and HVAC switch panel (see «AUDIO-NAVIGATION AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Go to step 18.
  18. While press and holding the VOLUME/POWER knob, check for continuity between audio-navigation and HVAC switch panel connector A (20P) terminal No. 17 and body ground. Is there continuity? YES -Go to step 19. NO -Replace the audio-navigation and HVAC switch panel (see «AUDIO-NAVIGATION AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).
  19. Disconnect audio-navigation and HVAC switch panel connector A (20P).
  20. Check for continuity between audio-navigation unit connector F (12P) and audio-navigation and HVAC switch panel connector A (20P) according to the table. Audio-navigation unit connector Audio-navigation and HVAC switch panel connector Wire color F1 A6 YEL F7 A16 BRN F8 A15 BLU Is there continuity? YES -Go to step 21. NO -There is an open in the wire(s) between the audio-navigation unit and the audio-navigation and HVAC switch panel. Repair or replace the affected harness.
  21. Check for continuity between audio-navigation and HVAC switch panel connector A (20P) and body ground according to the table. Audio-navigation and HVAC switch panel connector Wire color A6 YEL A15 BLU A16 BRN Is there continuity? YES -There is a short in the wire(s) between the audio-navigation unit and the audio-navigation and HVAC switch panel. Repair or replace the affected harness. NO -Go to step 22.
  22. Check for continuity between the terminals of audio-navigation and HVAC switch panel connector A (20P) according to the table. From terminal To terminals A6 (YEL) A7 (GRY), A16 (BRN) A7 (GRY) A16 (BRN) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio-navigation unit and the audio-navigation and HVAC switch panel. Replace the affected shielded harness. NO -Substitute a known-good audio-navigation and HVAC switch panel (see «AUDIO-NAVIGATION AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation and HVAC switch panel (see «AUDIO-NAVIGATION AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). If the symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).

Audio unit power switch will not turn on (No information display and no sound) (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ).

Scheme 121

Scheme 121: Audio unit power switch will not turn on (No information display and no sound) (without navigation)

Scheme 122

Scheme 122

Scheme 123

Scheme 123

Scheme 124

Scheme 124

Scheme 125

Scheme 125

Scheme 126

Scheme 126

Scheme 127

Scheme 127

Scheme 128

Scheme 128

Scheme 129

Scheme 129

Scheme 130

Scheme 130
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Push the VOLUME/POWER knob on to see if the audio unit turns on. Does the audio unit display operate properly, and does the audio unit sound normal? YES -Intermittent failure, the system is OK at this time. NO -Go to step 3.
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  4. Check the No. 15 (10 A) fuse in the under-hood fuse/relay box and the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box. Are the fuses OK? YES -Go to step 5. NO -Replace the fuse(s), and recheck. If the fuse(s) blows again, check for a short in the No. 15 (10 A) fuse and/or the No. 18 (7.5 A) fuse circuit(s).
  5. Check for poor connections or loose terminals at the audio unit. Are there connections or terminals OK? YES -Go to step 6. NO -Repair poor connections or loose terminals, and recheck.
  6. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  7. Measure the voltage between body ground and audio unit connector A (24P) terminals No. 14 and No. 24 individually. Is there battery voltage? YES -Go to step 8. NO -If the +B wire does not have voltage, repair an open in the wire between the No. 15 (10 A) fuse in the under-hood fuse/relay box and the audio unit. If the ACC wire does not have voltage, repair an open in the wire between the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box and the audio unit.
  8. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  9. Measure the voltage between audio unit connector A (24P) terminal No. 12 and body ground. Is there less than 0.2 V? YES -Go to step 10. NO -Repair an open or high resistance in the wire between the audio unit and body ground (G502) (see «CONNECTOR TO FUSE/RELAY BOX INDEX»(/acura/zdx/i-2009-2013/remont/body-electrical/#fuserelay-boxes__connector-to-fuserelay-box-index) ).
  10. Measure the voltage between body ground and audio and HVAC switch panel connector A (20P) terminals No. 1 and No. 20 individually. Is there battery voltage? YES -Go to step 11. NO -If the +B wire does not have voltage, repair an open in the wire between the No. 15 (10 A) fuse in the under-hood fuse/relay box and the audio and HVAC switch panel. If the ACC wire does not have voltage, repair an open in the wire between the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box and the audio and HVAC switch panel.
  11. Measure the voltage between audio and HVAC switch panel connector A (20P) terminal No. 3 and body ground. Is there less than 0.2 V? YES -Go to step 12. NO -Repair an open or high resistance in the wire between the audio and HVAC switch panel and body ground (G501) (see «CONNECTOR TO FUSE/RELAY BOX INDEX»(/acura/zdx/i-2009-2013/remont/body-electrical/#fuserelay-boxes__connector-to-fuserelay-box-index) ).
  12. Measure the voltage between audio and HVAC switch panel connector A (20P) terminal No. 5 and body ground. Is there battery voltage? YES -Go to step 13. NO -Repair an open or a short in the wire between the audio and HVAC switch panel and the audio unit.
  13. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  14. Disconnect audio unit connector F (12P) and audio and HVAC switch panel connector A (20P).
  15. Check for continuity between audio and HVAC switch panel connector A (20P) terminal No. 17 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between the audio and HVAC switch panel and the audio unit. NO -Go to step 16.
  16. Check for continuity between audio unit connector F (12P) terminal No. 12 and audio and HVAC switch panel connector A (20P) terminal No. 17. Is there continuity? YES -Go to step 17. NO -Repair an open in the wire between the audio and HVAC switch panel and the audio unit.
  17. Reconnect audio and HVAC switch panel connector A (20P).
  18. Check for continuity between audio and HVAC switch panel connector A (20P) terminal No. 17 and body ground. Is there continuity? YES -Replace the audio and HVAC switch panel (see «AUDIO AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Go to step 19.
  19. While press and holding the VOLUME/POWER knob, check for continuity between audio and HVAC switch panel connector A (20P) terminal No. 17 and body ground. Is there continuity? YES -Go to step 20. NO -Replace the audio and HVAC switch panel (see «AUDIO AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).
  20. Reconnect audio unit connector F (12P).
  21. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  22. While repeating ON and OFF of the VOLUME/POWER knob, measure the voltage between audio and HVAC switch panel connector A (20P) terminal No. 19 and body ground. Does the voltage change from 0 V to 12 V? YES -Replace the audio and HVAC switch panel (see «AUDIO AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Repair an open in the wire between audio unit connector B (24P) terminal No. 21 and audio and HVAC switch panel connector A (20P) terminal No. 19. If the wire and the pin fits are OK, substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

Audio unit power switch will not turn off (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check for aftermarket accessories plugged info the vehicle's accessory power sockets. Check the connectors for poor connections or loose terminals.

Scheme 131

Scheme 131: Audio unit power switch will not turn off (with navigation)

Scheme 132

Scheme 132

Scheme 133

Scheme 133

Scheme 134

Scheme 134

Scheme 135

Scheme 135
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Push the VOLUME/POWER knob on to see if the audio system turns off. Does the audio system turn off? YES -Operation is normal. NO -Go to step 3.
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode. Does the audio-navigation unit turn off? YES -Go to step 5 . NO -Go to step 4.
  4. Measure the voltage between audio-navigation unit connector A (24P) terminal No. 14 and body ground. Is there battery voltage? YES -Check for short to power on the PUR wire. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).
  5. Disconnect audio-navigation unit connector F (12P) and audio-navigation and HVAC switch panel connector A (20P).
  6. Check for continuity between audio-navigation and HVAC switch panel connector A (20P) terminal No. 17 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between the audio-navigation and HVAC switch panel and the audio-navigation unit. NO -Go to step 7.
  7. Check for continuity between audio-navigation unit connector F (12P) terminal No. 12 and audio-navigation and HVAC switch panel connector A (20P) terminal No. 17. Is there continuity? YES -Go to step 8. NO -Repair an open in the wire between the audio-navigation and HVAC switch panel and the audio-navigation unit.
  8. Reconnect audio-navigation and HVAC switch panel connector A (20P).
  9. Check for continuity between audio-navigation and HVAC switch panel connector A (20P) terminal No. 17 and body ground. Is there continuity? YES -Replace the audio-navigation and HVAC switch panel (see «AUDIO-NAVIGATION AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Go to step 10.
  10. While press and holding the VOLUME/POWER knob, check for continuity between audio-navigation and HVAC switch panel connector A (20P) terminal No. 17 and body ground. Is there continuity? YES -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ). NO -Replace the audio-navigation and HVAC switch panel (see «AUDIO-NAVIGATION AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

Audio unit power switch will not turn off (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check for aftermarket accessories plugged info the vehicle's accessory power sockets. Check the connectors for poor connections or loose terminals.

Scheme 136

Scheme 136: Audio unit power switch will not turn off (without navigation)

Scheme 137

Scheme 137

Scheme 138

Scheme 138

Scheme 139

Scheme 139

Scheme 140

Scheme 140
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Push the VOLUME/POWER knob on to see if the audio unit turns off. Does the audio unit turn off? YES -Operation is normal. NO -Go to step 3.
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode. Does the audio unit turn off? YES -Go to step 5 . NO -Go to step 4.
  4. Measure the voltage between audio unit connector A (24P) terminal No. 14 and body ground. Is there battery voltage? YES -Check for short to power on the PUR wire. NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).
  5. Disconnect audio unit connector F (12P) and audio and HVAC switch panel connector A (20P).
  6. Check for continuity between audio and HVAC switch panel connector A (20P) terminal No. 17 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between the audio and HVAC switch panel and the audio unit. NO -Go to step 7.
  7. Check for continuity between audio unit connector F (12P) terminal No. 12 and audio and HVAC switch panel connector A (20P) terminal No. 17. Is there continuity? YES -Go to step 8. NO -Repair an open in the wire between the audio and HVAC switch panel and the audio unit.
  8. Reconnect audio and HVAC switch panel connector A (20P).
  9. Check for continuity between audio and HVAC switch panel connector A (20P) terminal No. 17 and body ground. Is there continuity? YES -Replace the audio and HVAC switch panel (see «AUDIO AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Go to step 10.
  10. While press and holding the VOLUME/POWER knob, check for continuity between audio and HVAC switch panel connector A (20P) terminal No. 17 and body ground. Is there continuity? YES -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Replace the audio and HVAC switch panel (see «AUDIO AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

No sound is heard from the speaker(s) (display is normal) (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Set the fader and the balance positions to the center. Before doing the troubleshooting, go to AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) TROUBLESHOOTING (see ). Check the connectors for poor connections or loose terminals.

Scheme 141

Scheme 141: No sound is heard from the speaker(s) (display is normal) (with navigation)

Scheme 142

Scheme 142

Scheme 143

Scheme 143

Scheme 144

Scheme 144

Scheme 145

Scheme 145

Scheme 146

Scheme 146

Scheme 147

Scheme 147

Scheme 148

Scheme 148

Scheme 149

Scheme 149

Scheme 150

Scheme 150

Scheme 151

Scheme 151

Scheme 152

Scheme 152

Scheme 153

Scheme 153

Scheme 154

Scheme 154

Scheme 155

Scheme 155

Scheme 156

Scheme 156

Scheme 157

Scheme 157

Scheme 158

Scheme 158

Scheme 159

Scheme 159
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio system, and make sure the volume button is not set to the MIN level. Is it at the MIN level? YES -Raise the volume level, and recheck the function. NO -Go to step 3.
  3. Check for sound in each mode (AM/FM, XM, USB, and CD or DVD). Is the sound OK in each mode? YES -Intermittent failure, the system is OK at this time. Check for loose connections at the audio-navigation unit and speaker(s). NO - If there is no sound in all modes, go to step 4. If there is no sound in AM/FM mode, go to «POOR AM OR FM RADIO RECEPTION INTERFERENCE TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__poor-am-or-fm-radio-reception) (see ). If the sound quality is poor only with XM radio, or the XM radio does not function, go to «POOR OR NO SOUND WITH XM RADIO (AUDIO UNIT DOES DISPLAY XM CHANNELS) TROUBLESHOOTING; USA MODELS WITH NAVIGATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__poor-or-no-sound-with-xm) (see ), «CANADA MODELS WITH NAVIGATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__poor-or-no-sound-with-xm) (see ). If sound quality is poor only with USB mode, go to «USB INPUT SOUND IS LOW OR CANNOT BE HEARD TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__usb-input-sound-is-low-or) (see ). If there is no sound in CD or DVD mode, go to «AUDIO DISC DOES NOT PLAY TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__audio-disc-does-not-play-with) (see ).
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  5. Disconnect the HandsFreeLink control unit 28P connector.
  6. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode, and recheck the audio system for sound. Did the sound return? YES -Replace the HandsFreeLink control unit (see «HANDSFREELINK CONTROL UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#handsfreelink-system__handsfreelink-control-unit-removalinstallation) ). NO -Go to step 7.
  7. Do the Speaker Check Mode with the Self-Diagnostic Function (see «SPEAKER CHECK MODE»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__speaker-check-mode) ). Do all speakers produce a tone? YES -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ). NO -Go to step 8.
  8. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  9. Check the No. 15 (20 A) fuse in the passenger's under-dash fuse/relay box. Is the fuse OK? YES -Go to step 10. NO -Replace the fuse, and recheck. If the fuse blows again, check for a short in the No. 15 (20 A) fuse circuit.
  10. Measure the voltage between stereo amplifier connector A (18P) terminal No. 18 and body ground. Is there battery voltage? YES -Go to step 11. NO -Repair an Open in the wire between the No. 15 (20 A) fuse in the passenger's under-dash fuse/relay box and the stereo amplifier.
  11. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  12. Measure the voltage between stereo amplifier connector B (28P) terminal No, 3 and body ground. Is there battery voltage? YES -Go to step 14 . NO -Go to step 13.
  13. Measure the voltage between audio-navigation unit connector A (24P) terminal No. 17 and body ground. Is there battery voltage? YES -Repair an open in the wire between stereo amplifier connector B (28P) terminal No. 3 and audio-navigation unit connector A (24P) terminal No. 17. NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).
  14. Measure the voltage between stereo amplifier connector A (18P) terminal No. 9 and body ground. Is there less than 0.2 V? YES -Go to step 15. NO -Repair an open or high resistance in the wire between the stereo amplifier and body ground (G501) (see «CONNECTOR TO FUSE/RELAY BOX INDEX»(/acura/zdx/i-2009-2013/remont/body-electrical/#fuserelay-boxes__connector-to-fuserelay-box-index) ).
  15. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  16. Check the faulty speaker(s) for damage. Is there any damage? YES -Replace the speaker, and recheck. NO -Go to step 17.
  17. Remove the speaker(s) with no sound (see «ANC/ACTIVE SOUND CONTROL MICROPHONE REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and disconnect its connector.
  18. Check the speaker connectors for a loose or poor connection. Reconnect the speaker connector, and recheck the symptom; is the condition still present? YES -Go to step 19. NO -Intermittent failure. Operation is normal.
  19. Test the speaker(s) (see «SPEAKER TEST/REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). Is the speaker(s) OK? YES -Go to step 20. NO -Replace the speaker(s) (see «SPEAKER TEST/REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).
  20. Reconnect the speaker connector(s).
  21. Disconnect stereo amplifier connector A (18P).
  22. Check for continuity between stereo amplifier connector A (18P) and body ground according to the table. Speaker Stereo amplifier connector Wire color Driver's door speaker, Left tweeter A16 LT GRN A7 BLU Front passenger's door speaker, Right tweeter A15 GRY A6 BRN Front center speaker A11 BRN A2 YEL Left rear door speaker A13 WHT A4 RED Right rear door speaker A12 PNK A3 PUR Left satellite speaker A17 RED A8 GRN Right satellite speaker A14 BLK A5 YEL Subwoofer A10 BLU A1 PNK Is there continuity? YES -Repair a short to body ground in the wire(s) between the stereo amplifier and the speaker(s). NO -Go to step 23.
  23. Disconnect the left tweeter 2P connector and the right tweeter 2P connector.
  24. Measure the resistance between each pair of speaker terminals at stereo amplifier connector A (18P) according to the table. Speaker Stereo amplifier connector Wire color Resistance Driver's door speaker A16 LT GRN About 2 ohms A7 BLU Front passenger's door speaker A15 GRY About 2 ohms A6 BRN Front center speaker A11 BRN About 2 ohms A2 YEL Left rear door speaker A13 WHT About 2 ohms A4 RED Right rear door speaker A12 PNK About 2 ohms A3 PUR Left satellite speaker A17 RED About 4 ohms A8 GRN Right satellite speaker A14 BLK About 4 ohms A5 YEL Is the resistance OK? YES -Go to step 25. NO -Repair an open or a short in the wire(s) between the stereo amplifier and the speaker(s).
  25. Disconnect these items: Driver's door speaker 2P connector Front passenger's door speaker 2P connector Subwoofer 8P connector
  26. Connect stereo amplifier connector A (18P) terminals with jumper wires as shown in illustration.
  27. Check for continuity between the terminals of speaker connector according to the table. Speaker Terminal Wire color Left tweeter 1 LT GRN 2 BLU Right tweeter 1 GRY 2 BRN Subwoofer 3 BLU 8 PNK Is there continuity? YES -Go to step 28. NO -Repair an open in the wire(s) between the stereo amplifier and the speaker(s).
  28. Remove the jumper wires.
  29. Disconnect stereo amplifier connector B (28P).
  30. Disconnect audio-navigation unit connector D (20P).
  31. Check for continuity between body ground and audio-navigation unit connector D (20P) terminals No. 1 and No. 2 individually. Is there continuity? YES -There is a short to body ground in the wire(s) between the audio-navigation unit and the stereo amplifier. Replace the affected shielded harness. NO -Go to step 32.
  32. Check for continuity between the terminals of audio-navigation unit connector D (20P) according to the table. From terminal To terminals D1 (RED) D2 (GRN), D11 (BRN) D2 (GRN) D11 (BRN) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio-navigation unit and the stereo amplifier. Replace the affected shielded harness. NO -Go to step 33.
  33. Check for continuity between audio-navigation unit connector D (20P) and stereo amplifier connector B (28P) according to the table. Audio-navigation unit connector Stereo amplifier connector Wire color D1 B1 RED D2 B15 GRN Is there continuity? YES -Go to step 34. NO -There is an open in the wire(s) between the audio-navigation unit and the stereo amplifier. Replace the affected shielded harness.
  34. Disconnect audio-navigation unit connector A (24P) and connector B (24P). NOTE: Eject all the disc(s) before disconnecting the audio-navigation unit to prevent damaging the CD/DVD player's load mechanism.
  35. Check for continuity between audio-navigation unit connector A (24P), connector B (24P), and stereo amplifier connector B (28P) according to the table. Audio-navigation unit connector Stereo amplifier connector Wire color A6 B28 PUR A7 B14 PNK A10 B27 BLU A11 B13 BRN A18 B25 RED A19 B11 GRN A22 B24 LT GRN A23 B10 WHT B9 B18 BLK B10 B4 YEL B12 B6 GRN B24 B19 LT GRN Is there continuity? YES -Go to step 36. NO -There is an open in the wire(s) between the stereo amplifier and the audio-navigation unit. Replace the affected shielded harness.
  36. Check for continuity between body ground and audio-navigation unit connector A (24P) and connector B (24P) according to the table. Audio-navigation unit connector Wire color A6 PUR A7 PNK A10 BLU A11 BRN A18 RED A19 GRN A22 LT GRN A23 WHT B9 BLK B10 YEL B12 GRN B24 LT GRN Is there continuity? YES -There is a short to body ground in the wire(s) between the stereo amplifier and the audio-navigation unit. Replace the affected shielded harness. NO -Substitute a known-good stereo amplifier (see «STEREO AMPLIFIER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original stereo amplifier (see «STEREO AMPLIFIER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). If the symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).

No sound is heard from the speaker(s) (display is normal) (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Set the fader and the balance positions to the center. Before doing the troubleshooting, go to AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) TROUBLESHOOTING (see ). Check the connectors for poor connections or loose terminals.

Scheme 160

Scheme 160: No sound is heard from the speaker(s) (display is normal) (without navigation)

Scheme 161

Scheme 161

Scheme 162

Scheme 162

Scheme 163

Scheme 163

Scheme 164

Scheme 164

Scheme 165

Scheme 165

Scheme 166

Scheme 166

Scheme 167

Scheme 167

Scheme 168

Scheme 168

Scheme 169

Scheme 169

Scheme 170

Scheme 170

Scheme 171

Scheme 171

Scheme 172

Scheme 172
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio unit, and make sure the volume button is not set to the MIN level. Is it at the MIN level? YES -Raise the volume level, and recheck the function. NO -Go to step 3.
  3. Check for sound in each mode(AM/FM, XM, USB, and CDs). Is the sound OK in each mode? YES -Intermittent failure, the system is OK at this time. Check for loose connections at the audio-navigation unit and speaker(s). NO - If there is no sound in all modes, go to step 4. If there is no sound in AM/FM mode, go to «POOR AM OR FM RADIO RECEPTION INTERFERENCE TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__poor-am-or-fm-radio-reception) (see ). If the sound quality is poor only with XM radio, or the XM radio does not function, go to «POOR OR NO SOUND WITH XM RADIO (AUDIO UNIT DOES DISPLAY XM CHANNELS) TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__poor-or-no-sound-with-xm) (see ). If sound quality is poor only with USB mode, go to «USB INPUT SOUND IS LOW OR CANNOT BE HEARD TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__usb-input-sound-is-low-or) (see ). If there is no sound in CD mode, go to «AUDIO DISC DOES NOT PLAY TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__audio-disc-does-not-play-without) (see ).
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  5. Disconnect the HandsFreeLink control unit 28P connector.
  6. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode, and recheck the audio system for sound. Did the audio system sound return? YES -Replace the HandsFreeLink control unit (see «HANDSFREELINK CONTROL UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#handsfreelink-system__handsfreelink-control-unit-removalinstallation) ). NO -Go to step 7.
  7. Do the Speaker Check Mode with the Self-Diagnostic Function (see «SPEAKER CHECK MODE»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__speaker-check-mode) ). Do all speakers produce a tone? YES -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Go to step 8.
  8. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  9. Check the No. 15 (20 A) fuse in the passenger's under-dash fuse/relay box. Is the fuse OK? YES -Go to step 10. NO -Replace the fuse, and recheck. If the fuse blows again, check for a short in the No. 15 (20 A) fuse circuit.
  10. Measure the voltage between stereo amplifier connector A (18P) terminal No. 18 and body ground. Is there battery voltage? YES -Go to step 11. NO -Repair an open in the wire between the No. 15 (20 A) fuse in the passenger's under-dash fuse/relay box and the stereo amplifier.
  11. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  12. Measure the voltage between stereo amplifier connector B (20P) terminal No. 1 and body ground. Is there battery voltage? YES -Go to step 14 . NO -Go to step 13.
  13. Measure the voltage between audio unit connector A (24P) terminal No. 17 and body ground. Is there battery voltage? YES -Repair an open in the wire between stereo amplifier connector B (20P) terminal No. 1 and audio unit connector A (24P) terminal No. 17. NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).
  14. Measure the voltage between stereo amplifier connector A (18P) terminal No. 9 and body ground. Is there less than 0.2 V? YES -Go to step 15. NO -Repair an open or high resistance in the wire between the stereo amplifier and body ground (G501) (see «CONNECTOR TO FUSE/RELAY BOX INDEX»(/acura/zdx/i-2009-2013/remont/body-electrical/#fuserelay-boxes__connector-to-fuserelay-box-index) ).
  15. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  16. Check the faulty speaker(s) for damage (see «SPEAKER TEST/REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). Is there any damage? YES -Replace the speaker (see «SPEAKER TEST/REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. NO -Go to step 17.
  17. Remove the speaker(s) with no sound (see «SPEAKER TEST/REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and disconnect its connector.
  18. Check the speaker connectors for a loose or poor connection. Reconnect the speaker connector, and recheck the symptom; is the condition still present? YES -Go to step 19. NO -Intermittent failure. Operation is normal.
  19. Test the speaker(s) (see «SPEAKER TEST/REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). Is the speaker OK? YES -Go to step 20. NO -Replace the speaker(s) (see «SPEAKER TEST/REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).
  20. Reconnect the speaker connector(s).
  21. Disconnect stereo amplifier connector A (18P).
  22. Check for continuity between stereo amplifier connector A (18P) and body ground according to the table. Speaker Stereo amplifier connector Wire color Driver's door speaker. Left tweeter A11 (+) LT GRN A2 (-) BLU Front passenger's door speaker, Right tweeter A15 (+) GRY A6 (-) BRN Front center speaker A16 (+) BRN A7 (-) YEL Left rear door speaker A10 (+) WHT A1 (-) RED Right rear door speaker A14 (+) PNK A5 (-) PUR Subwoofer A12 (+) RED A3 (-) GRN Subwoofer A17 (+) BLK A8 (-) YEL Is there continuity? YES -Repair a short to body ground in the wire(s) between the stereo amplifier and the speaker(s). NO -Go to step 23.
  23. Disconnect the left tweeter 2P connector and the right tweeter 2P connector.
  24. Measure the resistance between each pair of speaker terminals at stereo amplifier connector A (18P) according to the table. Speaker Stereo amplifier connector Wire color Resistance Driver's door speaker A11 LT GRN About 2 ohms A2 BLU Front passenger's door speaker A15 GRY About 2 ohms A6 BRN Front center speaker A16 BRN About 2 ohms A7 YEL Left rear door speaker A10 WHT About 2 ohms A1 RED Right rear door speaker A14 PNK About 2 ohms A5 PUR Subwoofer A12 RED About 2 ohms A3 GRN Subwoofer A17 BLK About 2 ohms A8 YEL Is the resistance OK? YES -Go to step 25. NO -Repair an open or a short in the wire(s) between the stereo amplifier and the speaker(s).
  25. Connect stereo amplifier connector A (18P) terminals with jumper wires as shown in illustration.
  26. Check for continuity between the terminals of tweeter 2P connector according to the table. Speaker Terminal Wire color Left tweeter 1 LT GRN 2 BLU Right tweeter 1 GRY 2 BRN Is there continuity? YES -Go to step 27. NO -Repair an open in the wire between the stereo amplifier and the tweeter.
  27. Remove the jumper wires.
  28. Disconnect these items: Audio unit connector A (24P) Audio unit connector B (24P) Stereo amplifier connector B (20P) NOTE: Eject all the disc(s) before disconnecting the audio unit to prevent damaging the CD player's load mechanism.
  29. Check for continuity between audio unit connectors A (24P), B (14P), and stereo amplifier connector B (28P) according to the table. Audio unit connector Stereo amplifier connector Wire color A6 B20 PUR A7 B10 PNK A10 B19 BLU A11 B9 BRN A18 B17 RED A19 B7 GRN A22 B16 LT GRN A23 B6 WHT B9 B13 BLK B10 B3 YEL B12 B4 GRN B24 B14 LT GRN Is there continuity? YES -Go to step 30. NO -There is ah open in the wire(s) between the stereo amplifier and the audio unit. Replace the affected shielded harness.
  30. Check for continuity between audio unit connectors A (24P) and B (24P) and body ground according to the table. Audio unit connector Wire color A6 PUR A7 PNK A10 BLU A11 BRN A18 RED A19 GRN A22 LT GRN A23 WHT B9 BLK B10 YEL B12 GRN B24 LT GRN Is there continuity? YES -There is a short to body ground in the wire(s) between the stereo amplifier and the audio unit. Replace the affected shielded harness. NO -Substitute a known-good stereo amplifier (see «STEREO AMPLIFIER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original stereo amplifier (see «STEREO AMPLIFIER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). If the symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

Auxiliary input sound is low or cannot be heard (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Use auxiliary stereo cables with 3.5 mm ends only. Auxiliary accessories may be played on the audio unit using the auxiliary input. Check the connectors for poor connections or loose terminals.

Scheme 173

Scheme 173: Auxiliary input sound is low or cannot be heard (with navigation)

Scheme 174

Scheme 174

Scheme 175

Scheme 175

Scheme 176

Scheme 176
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio system, and connect an auxiliary accessory to the auxiliary input jack.
  3. Check the volume operation. Is the sound normal? YES -Operation is normal at this time. NO -Go to step 4.
  4. Make sure the auxiliary accessory volume is set to high. Is the volume set to high? YES -Go to step 5. NO -Raise the auxiliary accessory volume to high. Make sure the audio-navigation unit volume is turned down before retesting.
  5. Substitute a known-good auxiliary audio accessory and/or auxiliary stereo cable, and recheck. Does the auxiliary audio accessory operate properly? YES -Original auxiliary audio accessory or auxiliary stereo cable is faulty. NO -Go to step 6.
  6. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  7. Check for poor connection or loose terminals at the auxiliary jack assembly 5P connector. Are there connection or terminals OK? YES -Go to step 8. NO -Repair poor connection or loose terminals, and recheck.
  8. Disconnect the auxiliary jack assembly 5P connector.
  9. Disconnect audio-navigation unit connector B (24P).
  10. Check for continuity between audio-navigation unit connector B (24P) and body ground according to the table. Audio-navigation unit connector Wire color B1 RED B2 BLK B3 PUR B13 WHT Is there continuity? YES -There is a short to body ground in the wire(s) between the audio-navigation unit and the auxiliary jack assembly. Repair or replace the affected harness. NO -Go to step 11.
  11. Check for continuity between the terminals of audio-navigation unit connector B (24P) according to the table. From terminal To terminals B1 (RED) B2 (BLK), B13 (WHT), B15 (GRY) B2 (BLK) B13 (WHT), B15 (GRY) B13 (WHT) B15 (GRY) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio-navigation unit and the auxiliary jack assembly. Replace the affected shielded harness. NO -Go to step 12.
  12. Check for continuity between audio-navigation unit connector B (24P) and the auxiliary jack assembly 5P connector according to the table. Audio-navigation unit connector Auxiliary jack assembly connector Wire color B1 4 RED B2 3 BLK B3 1 PUR B13 5 WHT B14 2 YEL Is there continuity? YES -Substitute a known-good USB adapter holder/auxiliary jack assembly (see «USB ADAPTER HOLDER/AUXILIARY JACK ASSEMBLY REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original USB adapter holder/auxiliary jack assembly (see «USB ADAPTER HOLDER/AUXILIARY JACK ASSEMBLY REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). If the symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ). NO -There is an open in the wire(s) between the audio-navigation unit and the auxiliary jack assembly. Repair or replace the affected harness.

Auxiliary input sound is low or cannot be heard (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Use auxiliary stereo cables with 3.5 mm ends only. Auxiliary accessories may be played on the audio unit using the auxiliary input. Check the connectors for poor connections or loose terminals.

Scheme 177

Scheme 177: Auxiliary input sound is low or cannot be heard (without navigation)

Scheme 178

Scheme 178

Scheme 179

Scheme 179

Scheme 180

Scheme 180
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio unit, and connect an auxiliary accessory to the auxiliary input jack.
  3. Check the volume operation. Is the sound normal? YES -Operation is normal at this time. NO -Go to step 4.
  4. Make sure the auxiliary accessory volume is set to high. Is the volume set to high? YES -Go to step 5. NO -Raise the auxiliary accessory volume to high. Make sure the audio unit volume is turned down before retesting.
  5. Substitute a known-good auxiliary audio accessory and/or auxiliary stereo cable, and recheck. Does the auxiliary audio accessory operate properly? YES -Original auxiliary audio accessory or auxiliary stereo cable is faulty. NO -Go to step 6.
  6. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  7. Check for poor connection or loose terminals at the auxiliary jack assembly 5P connector. Are there connection or terminals OK? YES -Go to step 8. NO -Repair poor connection or loose terminals, and recheck.
  8. Disconnect the auxiliary jack assembly 5P connector.
  9. Disconnect audio unit connector B (24P).
  10. Check for continuity between audio unit connector B (24P) and body ground according to the table. Audio unit connector Wire color B1 RED B2 BLK B3 PUR B13 WHT Is there continuity? YES -There is a short to body ground in the wire(s) between the audio unit and the auxiliary jack assembly. Repair or replace the affected harness. NO -Go to step 11.
  11. Check for continuity between the terminals of audio unit connector B (24P) according to the table. From terminal To terminals B1 (RED) B2 (BLK), B13 (WHT), B15 (GRY) B2 (BLK) B13 (WHT), B15 (GRY) B13 (WHT) B15 (GRY) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio unit and the auxiliary jack assembly. Replace the affected shielded harness. NO -Go to step 12.
  12. Check for continuity between audio unit connector B (24P) and auxiliary jack assembly 5P connector according to the table. Audio unit connector Auxiliary jack assembly connector Wire color B1 4 RED B2 3 BLK B3 1 PUR B13 5 WHT B14 2 YEL Is there continuity? YES -Substitute a known-good USB adapter holder/auxiliary jack assembly (see «USB ADAPTER HOLDER/AUXILIARY JACK ASSEMBLY REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original USB adapter holder/auxiliary jack assembly (see «USB ADAPTER HOLDER/AUXILIARY JACK ASSEMBLY REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). If the symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -There is an open in the wire(s) between the audio unit and the auxiliary jack assembly. Repair or replace the affected harness.

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio system, and check for sound in each mode (AM/FM and CD or DVD). Is there sound from the speakers, and is the sound quality normal in each mode? YES -Intermittent failure, the system is OK at this time. Check for loose connections at the audio-navigation unit, the stereo amplifier, and each speaker. NO -The speakers all work, but the sound quality is poor: If the sound quality is poor only with AM or FM, go to «POOR AM OR FM RADIO RECEPTION OR INTERFERENCE TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__poor-am-or-fm-radio-reception) (see ). If there is no sound in CD or DVD mode, do the Audio disc does not play troubleshooting (see «AUDIO DISC DOES NOT PLAY (WITH NAVIGATION)»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__audio-disc-does-not-play-with) ). If the sound is poor in all modes, go to «SOUND QUALITY DIAGNOSIS»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__sound-quality-diagnosis) (see ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio unit, and check for sound in each mode (AM/FM and CDs). Is there sound from the speakers, and is the sound quality normal in each mode? YES -Intermittent failure, the system is OK at this time. Check for loose connections at the audio unit, the stereo amplifier, and each speaker. NO -The speakers all work, but the sound quality is poor: If the sound quality is poor only with AM or FM, go to «POOR AM OR FM RADIO RECEPTION OR INTERFERENCE TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__poor-am-or-fm-radio-reception) (see ). If there is no sound in CD mode, do the Audio disc does not play troubleshooting (see «AUDIO DISC DOES NOT PLAY (WITHOUT NAVIGATION)»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__audio-disc-does-not-play-without) ). If the sound is poor in all modes, go to «SOUND QUALITY DIAGNOSIS»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__sound-quality-diagnosis) (see ).

Radio preset memory is lost (with navigation)

Note. If only XM stations are lost, go to XM RADIO PRESET MEMORY IS LOST TROUBLESHOOTING; WITH ACURALINK (see ), WITHOUT ACURALINK (see ).

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio system, and set each of the radio station preset buttons. Do each of the buttons set properly? YES -Go to step 3. NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode for 1 minute, then back to ON (II), or the ON mode.
  4. Test the preset buttons for proper recall operation. Do the preset buttons recall the set radio stations? YES -Intermittent failure, the system is OK at this time. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).

Radio preset memory is lost (without navigation)

Note. If only XM stations are lost, go to XM RADIO PRESET MEMORY IS LOST TROUBLESHOOTING (see ).

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio unit, and set each of the radio station preset buttons. Do each of the buttons set properly? YES -Go to step 3. NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode for 1 minute, then turn it back to ON (II), or the ON mode.
  4. Test the preset buttons for proper recall operation. Do the preset buttons recall the set radio stations? YES -Intermittent failure, the system is OK at this time. NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

Volume does not change (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Set the fader and the balance positions to the center. Check the connectors for poor connections or loose terminals.

Scheme 181

Scheme 181: Volume does not change (with navigation)

Scheme 182

Scheme 182

Scheme 183

Scheme 183

Scheme 184

Scheme 184
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio system, and check for sound in each mode (AM/FM and CD or DVD). Is the sound normal? YES -Go to step 3. NO -Go to «SOUND QUALITY DIAGNOSIS»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__sound-quality-diagnosis) (see ) or «NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__no-sound-is-heard-from-the) (see ).
  3. Operate the volume knob to see if the volume changes. Does the volume change? YES -Operation is normal. NO -Go to step 4.
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  5. Disconnect audio-navigation and HVAC switch panel connector A (20P) and audio-navigation unit connector F (12P).
  6. Check for continuity between audio-navigation and HVAC switch panel connector A (20P) and audio-navigation unit connector F (12P) according to the table. Audio-navigation and HVAC switch panel connector Audio-navigation unit connector Wire color A9 F11 PNK A18 F5 BLU Is there continuity? YES -Go to step 7. NO -There is an open in the wire(s) between the audio-navigation unit and the audio-navigation and HVAC switch panel. Replace the affected shielded harness.
  7. Check for continuity between audio-navigation and HVAC switch panel connector A (20P) and body ground according to the table. Audio-navigation and HVAC switch panel connector Wire color A9 PNK A18 BLU Is there continuity? YES -There is a short to body ground in the wire(s) between the audio-navigation unit and the audio-navigation and HVAC switch panel. Replace the affected shielded harness. NO -Go to step 8.
  8. Check for continuity between the terminals of audio-navigation unit connector F (12P) according to the table. From terminal To terminals F5 (BLU) F6 (GRY), F11 (PNK) F6 (GRY) F11 (PNK) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio-navigation unit and the audio-navigation and HVAC switch panel. Replace the affected shielded harness. NO -Substitute a known-good audio-navigation and HVAC switch panel (see «AUDIO-NAVIGATION AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation and HVAC switch panel (see «AUDIO-NAVIGATION AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). If the symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).

Volume does not change (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Set the fader and the balance positions to the center. Check the connectors for poor connections or loose terminals.

Scheme 185

Scheme 185: Volume does not change (without navigation)

Scheme 186

Scheme 186

Scheme 187

Scheme 187

Scheme 188

Scheme 188
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio unit, and check for sound in each mode (AM/FM and CDs). Is the sound normal? YES -Go to step 3. NO -Go to «SOUND QUALITY DIAGNOSIS»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__sound-quality-diagnosis) (see ) or «NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__no-sound-is-heard-from-the) (see ).
  3. Operate the volume knob to see if the volume changes. Does the volume change? YES -Operation is normal. NO -Go to step 4.
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  5. Disconnect audio and HVAC switch panel connector A (20P) and audio unit connector F (12P).
  6. Check for continuity between audio and HVAC switch panel connector A (20P) and audio unit connector F (12P) according to the table. Audio and HVAC switch panel connector Audio unit connector Wire color A9 F11 PNK A18 F5 BLU Is there continuity? YES -Go to step 7. NO -There is an open in the wire(s) between the audio unit and the audio and HVAC switch panel. Replace the affected shielded harness.
  7. Check for continuity between audio and HVAC switch panel connector A (20P) and body ground according to the table. Audio and HVAC switch panel connector Wire color A9 PNK A18 BLU Is there continuity? YES -There is a short to body ground in the wire(s) between the audio unit and the audio and HVAC switch panel. Replace the affected shielded harness. NO -Go to step 8.
  8. Check for continuity between the terminals of audio unit connector F (12P) according to the table. From terminal To terminals F5 (BLU) F6 (GRY), F11 (PNK) F6 (GRY) F11 (PNK) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio unit and the audio and HVAC switch panel. Replace the affected shielded harness. NO -Substitute a known-good audio and HVAC switch panel (see «AUDIO AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio and HVAC switch panel (see «AUDIO AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). If the symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

Volume does not increase with speed (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 189

Scheme 189: Volume does not increase with speed (with navigation)

Scheme 190

Scheme 190

Scheme 191

Scheme 191
  1. Test-drive the vehicle at highway speeds, and monitor if the volume increases. Does the volume increase? YES -Intermittent failure, the system is OK at this time. NO -Go to step 2.
  2. Verify SVC mode setting in audio-navigation unit sound adjustment set-up. Is the SVC set to off? YES -Change setting to SVC MID, and recheck. NO -Go to step 3.
  3. Do the Self-Diagnostic Function for the vehicle speed pulse indication (see «HOW TO CHECK THE AUDIO SYSTEM CONDITION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). Does self-diagnostic function indicate a VSP signal? YES -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ). NO -Go to step 4.
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  5. Jump the SCS line with the HDS.
  6. Disconnect PCM connector A (49P).
  7. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  8. Measure the voltage between PCM connector A (49P) terminal No. 30 and body ground. Is there about 5 V? YES -Go to step 10 . NO -Go to step 9.
  9. Measure the voltage between audio-navigation unit connector A (24P) terminal No. 15 and body ground. Is there about 5 V? YES -Repair an open or a short in the wire between the audio-navigation unit and the PCM. NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).
  10. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  11. Reconnect PCM connector A (49P).
  12. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  13. Raise the vehicle on a lift, and rotate the wheels while measuring the voltage between audio-navigation unit connector A (24P) terminal No. 15 and body ground. Does the voltage pulse between 0 V and 5V as you rotate the wheels? YES -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ). NO -Update the PCM (see «PCM UPDATE»(/acura/zdx/i-2009-2013/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ) if it does not have the latest software or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/zdx/i-2009-2013/remont/testing-diagnostics/#fuel-and-emissions-systems__substituting-the-pcm) ).

Volume does not increase with speed (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

  1. Test-drive the vehicle at highway speeds, and monitor if the volume increases. Does the volume increase? YES -Intermittent failure, the system is OK at this time. NO -Go to step 2.
  2. Verify SVC mode setting in audio unit sound adjustment set-up. Is the SVC set to off? YES -Change setting to SVC MID, and recheck. NO -Go to step 3.
  3. Do the Self-Diagnostic Function for the vehicle speed pulse indication (see «HOW TO CHECK THE AUDIO SYSTEM CONDITION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). Does self-diagnostic function indicate a VSP signal? YES -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Check for B-CAN DTCs (communication BUS Line Error) with the HDS and go to the indicated DTC's troubleshooting. If no B-CAN DTCs or communication bus line errors are found, substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

Volume is too high or too low when driving at freeway speeds (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

  1. Test-drive the vehicle at highway speeds, and monitor volume level. Is the volume level too high, or too low? YES -Go to step 2. NO -Intermittent failure, the system is OK at this time.
  2. Change SVC mode setting in sound adjustment set-up to SVC MID, and recheck. Is the volume level still too high or too low? YES -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ). NO -Improper SVC setting for client's sound taste.

Volume is too high or too low when driving at freeway speeds (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

  1. Test-drive the vehicle at highway speeds, and monitor volume level. Is the volume level too high, or too low? YES -Go to step 2. NO -Intermittent failure, the system is OK at this time.
  2. Change SVC mode setting in sound adjustment set-up to SVC MID, and recheck. Is the volume level still too high or too low? YES -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Improper SVC setting for client's sound taste.

Radio tuner does not change stations (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connection or loose terminals.

Scheme 192

Scheme 192: Radio tuner does not change stations (with navigation)

Scheme 193

Scheme 193

Scheme 194

Scheme 194

Scheme 195

Scheme 195
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio system, and check the audio information on the display panel. Does the audio information display properly? YES -Go to step 3. NO -Go to «AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__audio-unit-power-switch-will-not) (see ).
  3. Operate the tuning knob to see if the radio station changes. Does the radio station change? YES -Intermittent failure, the tuning knob is OK at this time. NO -Go to step 4.
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  5. Disconnect audio-navigation and HVAC switch panel connector A (20P) and audio-navigation unit connector F(12P).
  6. Check for continuity between audio-navigation unit connector F (12P) and audio-navigation and HVAC switch panel connector A (20P) according to the table. Audio-navigation unit connector Audio-navigation and HVAC switch panel connector Wire color F3 A4 RED F9 A14 GRN Is there continuity? YES -Go to step 7. NO -There is an open in the wire(s) between the audio-navigation unit and the audio-navigation and HVAC switch panel. Replace the affected shielded harness.
  7. Check for continuity between audio-navigation and HVAC switch panel connector A (20P) and body ground according to the table. Audio-navigation and HVAC switch panel connector Wire color A4 RED A14 GRN Is there continuity? YES -There is a short to body ground in the wire(s) between audio-navigation unit and audio-navigation and HVAC switch panel. Replace the affected shielded harness. NO -Go to step 8.
  8. Check for continuity between the terminals of audio-navigation unit connector F (12P) according to the table. From terminal To terminals F3 (RED) F4 (GRY), F9 (GRN) F4 (GRY) F9 (GRN) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio-navigation unit and the audio-navigation and HVAC switch panel. Replace the affected shielded harness. NO -Substitute a known-good audio-navigation and HVAC switch panel (see «AUDIO-NAVIGATION AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation and HVAC switch panel (see «AUDIO-NAVIGATION AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). If the symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).

Radio tuner does not change stations (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connection or loose terminals.

Scheme 196

Scheme 196: Radio tuner does not change stations (without navigation)

Scheme 197

Scheme 197

Scheme 198

Scheme 198

Scheme 199

Scheme 199
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio unit, and check the audio information on the display panel. Does the audio information display properly? YES -Go to step 3. NO -Go to «AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__audio-unit-power-switch-will-not) (see ).
  3. Operate the tuning knob to see if the radio station changes. Does the radio station change? YES -Intermittent failure, the tuning knob is OK at this time. NO -Go to step 4.
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  5. Disconnect audio and HVAC switch panel connector A (20P) and audio unit connector F (12P).
  6. Check for continuity between audio unit connector F (12P) and audio and HVAC switch panel connector A (20P) according to the table. Audio unit connector Audio and HVAC switch panel connector Wire color F3 A4 RED F9 A14 GRN Is there continuity? YES -Go to step 7. NO -There is an open in the wire(s) between the audio unit and the audio and HVAC switch panel. Replace the affected shielded harness.
  7. Check for continuity between audio and HVAC switch panel connector A (20P) and body ground according to the table. Audio and HVAC switch panel connector Wire color A4 RED A14 GRN Is there continuity? YES -There is a short to body ground in the wire(s) between the audio unit and the audio and HVAC switch panel. Replace the affected shielded harness. NO -Go to step 8.
  8. Check for continuity between the terminals of audio unit connector F (12P) according to the table. From terminal To terminals F3 (RED) F4 (GRY), F9 (GRN) F4 (GRY) F9 (GRN) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio unit and the audio and HVAC switch panel. Replace the affected shielded harness. NO -Substitute a known-good audio and HVAC switch panel (see «AUDIO AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio and HVAC switch panel (see «AUDIO AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). If the symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ).

Scheme 200

Scheme 200: Audio system information does not display on the audio display unit (without navigation)

Scheme 201

Scheme 201

Scheme 202

Scheme 202

Scheme 203

Scheme 203

Scheme 204

Scheme 204

Scheme 205

Scheme 205
  1. Check for poor connections or loose terminals at the audio display unit 12P connector and audio unit connector F(12P). Are there connections or terminals OK? YES -Go to step 2. NO -Repair poor connections or loose terminals, and recheck.
  2. Measure the voltage between audio display unit 12P connector terminal No. 6 and body ground. Is there battery voltage? YES -Go to step 3. NO -Repair an open in the wire between the No. 15 (10 A) fuse in the under-hood fuse/relay box and the audio display unit.
  3. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  4. Measure the voltage between audio display unit 12P connector terminal No. 9 and body ground. Is there less than 0.2 V? YES -Go to step 5. NO -Repair an open or high resistance in the wire between the audio display unit and body ground (G501) (see «CONNECTOR TO FUSE/RELAY BOX INDEX»(/acura/zdx/i-2009-2013/remont/body-electrical/#fuserelay-boxes__connector-to-fuserelay-box-index) ).
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  6. Disconnect audio unit connector F(12P) and the audio display unit 12P connector.
  7. Check for continuity between audio unit connector F (12P) and the audio display unit 12P connector according to the table. Audio unit connector Audio display unit connector Wire color F1 1 YEL F7 2 BRN F8 4 BLU Is there continuity? YES -Go to step 8. NO -There is an open in the wire(s) between the audio unit and the audio display unit. Repair or replace the affected shielded harness.
  8. Check for continuity between audio unit connector F (12P) and body ground according to the table. Audio unit connector Wire color F1 YEL F7 BRN F8 BLU Is there continuity? YES -There is a short to body ground in the wire(s) between the audio unit and the audio display unit. Repair or replace the affected shielded harness. NO -Go to step 9.
  9. Check for continuity between the terminals of audio unit connector F (12P) according to the table. From terminal To terminals F1 (YEL) F2 (GRY), F7 (BRN) F2 (GRY) F7 (BRN) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio unit and the audio display unit. Replace the affected shielded harness. NO -Substitute a known-good audio display unit (see «AUDIO DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio display unit (see «AUDIO DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). If the symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

Audio-navigation and HVAC switch panel button illumination does not work (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 206

Scheme 206: Audio-navigation and HVAC switch panel button illumination does not work (with navigation)

Scheme 207

Scheme 207
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn the combination lighting switch to the parking light position.
  3. Check the illumination of the audio-navigation and HVAC switch panel buttons. Are the buttons illuminated? YES -Intermittent failure, the audio-navigation and HVAC switch panel is OK at this time. Check for loose or poor connections at the audio-navigation and HVAC switch panel. NO -Go to step 4.
  4. Check the illumination of several other buttons not related to the audio system. Are the buttons illuminated? YES -Go to step 5. NO -Troubleshoot the interior lights. Start by checking the No. 6 (7.5 A) fuse in the passenger's under-dash fuse/relay box. If the fuse is OK, check for an open in the wire between passenger's under-dash fuse/relay box and the related system.
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  6. Disconnect audio-navigation and HVAC switch panel connector A (20P) and gauge control module connector A (32P).
  7. Check for continuity between audio-navigation and HVAC switch panel connector A (20P) terminal No. 8 and gauge control module connector A (32P) terminal No. 19. Is there continuity? YES -Go to step 8. NO -Repair an open in the wire between the gauge control module and the audio-navigation and HVAC switch panel.
  8. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  9. With the headlight switch on, measure the voltage between audio-navigation and HVAC switch panel connector A (20P) terminal No. 10 and body ground. Is there battery voltage? YES -Check the connections at the audio-navigation and HVAC switch panel connector A (20P). If all connections are OK, replace the audio-navigation and HVAC switch panel (see «AUDIO-NAVIGATION AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Repair an open in the wire between the passenger's under-dash fuse/relay box and the audio-navigation and HVAC switch panel.

Audio and HVAC switch panel button illumination does not work (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 208

Scheme 208: Audio and HVAC switch panel button illumination does not work (without navigation)

Scheme 209

Scheme 209
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn the combination lighting switch to the parking light position.
  3. Check the illumination of the audio and HVAC switch panel buttons. Are the buttons illuminated? YES -Intermittent failure, the audio and HVAC switch panel is OK at this time. Check for loose or poor connections at the audio and HVAC switch panel. NO -Go to step 4.
  4. Check the illumination of several other buttons not related to the audio system. Are the buttons illuminated? YES -Go to step 5. NO -Troubleshoot the interior lights. Start by checking the No. 6 (7.5 A) fuse in the passenger's under-dash fuse/relay box. If the fuse is OK, check for an open in the wire between the passenger's under-dash fuse/relay box and the related system.
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  6. Disconnect audio and HVAC switch panel connector A (20P) and gauge control module connector A (32P).
  7. Check for continuity between audio and HVAC switch panel connector A (20P) terminal No. 8 and gauge control module connector A (32P) terminal No. 19. Is there continuity? YES -Go to step 8. NO -Repair an open in the wire between the gauge control module and the audio and HVAC switch panel.
  8. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  9. With the headlight switch on, measure the voltage between audio and HVAC switch panel connector A (20P) terminal No. 10 and body ground. Is there battery voltage? YES -Check the connections at audio and HVAC switch panel connector A (20P). If all connections are OK, replace the audio and HVAC switch panel (see «AUDIO AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Repair an open in the wire between the passenger's under-dash fuse/relay box and the audio and HVAC switch panel.

Audio remote switch does not work properly (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 210

Scheme 210: Audio remote switch does not work properly (with navigation)

Scheme 211

Scheme 211
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio system, and check the audio remote switch operation (volume up, volume down, CH (UP), CH (DOWN), MODE). Is the audio system operation OK? YES -Intermittent failure, the audio remote switch is OK at this time. Check for loose or poor connections at the audio remote, HFL-navigation voice control switch. NO -Go to step 3.
  3. Do the Audio Remote Switch Test (see «AUDIO REMOTE SWITCH TEST»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). Is the audio remote switch OK? YES -Go to step 4. NO -Replace the audio remote, HFL-navigation voice control switch (see «STEERING WHEEL DISASSEMBLY/REASSEMBLY»(/acura/zdx/i-2009-2013/remont/manual-power-steering/#power-steering-system) ).
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  5. Disconnect audio-navigation unit connector A (24P). NOTE: Eject all the disc(s) before disconnecting the audio-navigation unit to prevent damaging the CD/DVD player's load mechanism.
  6. Reconnect the audio remote switch, and measure the resistance between audio-navigation unit connector A (24P) terminals No. 5 and No. 16 as specified in the table. AUDIO REMOTE SWITCH TABLE Button held down VOL DOWN VOL UP CH (-) CH (+) MODE No button pressed Resistance about 100 ohms about 357 ohms about 775 ohms about 1.7 kohms about 3.7 kohms about 10 kohms Is the resistance OK? YES -Go to step 7. NO -Repair a short or high resistance in the wire(s) between the audio-navigation unit and the audio remote switch. If the wires are OK, replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/zdx/i-2009-2013/remont/airbag/#srs-supplemental-restraint-system) ).
  7. Disconnect the audio remote, HFL-navigation voice control switch 12P connector.
  8. Check for continuity between body ground and audio-navigation unit connector A (24P) terminals No. 5 and No. 16 individually. Is there continuity? YES -Repair a short to body ground in the wire(s) between the audio-navigation unit and the audio remote switch. If the wires are OK, replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/zdx/i-2009-2013/remont/airbag/#srs-supplemental-restraint-system) ). NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).

Audio remote switch does not work properly (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 212

Scheme 212: Audio remote switch does not work properly (without navigation)

Scheme 213

Scheme 213
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio unit, and check the audio remote switch operation (volume up, volume down, CH (UP), CH (DOWN), MODE). Is the audio system operation OK? YES -Intermittent failure, the audio remote switch is OK at this time. Check for loose or poor connections at the audio remote-HFL switch. NO -Go to step 3.
  3. Do the Audio Remote Switch Test (see «AUDIO REMOTE SWITCH TEST»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). Is the audio remote switch OK? YES -Go to step 4. NO -Replace the audio remote-HFL switch (see «STEERING WHEEL DISASSEMBLY/REASSEMBLY»(/acura/zdx/i-2009-2013/remont/manual-power-steering/#power-steering-system) ).
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  5. Disconnect audio unit connector A (24P). NOTE: Eject all the disc(s) before disconnecting the audio unit to prevent damaging the CD player's load mechanism.
  6. Reconnect the audio remote switch, and measure the resistance between audio unit connector A (24P) terminals No. 5 and No. 16 as specified in the table. AUDIO REMOTE SWITCH TABLE Button held down VOL DOWN VOL UP CH (-) CH (+) MODE No button pressed Resistance about 100 ohms about 357 ohms about 775 ohms about 1.7 kohms about 3.7 kohms about 10 kohms Is the resistance OK? YES -Go to step 7. NO -Repair a short or high resistance in the wire(s) between the audio unit and the audio remote switch. If the wires are OK, replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/zdx/i-2009-2013/remont/airbag/#srs-supplemental-restraint-system) ).
  7. Disconnect the audio remote-HFL switch 12P connector.
  8. Check for continuity between body ground and audio unit connector A (24P) terminals No. 5 and No. 16 individually. Is there continuity? YES -Repair a short to body ground in the wire(s) between the audio unit and the audio remote switch. If the wires are OK, replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/zdx/i-2009-2013/remont/airbag/#srs-supplemental-restraint-system) ). NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

Audio disc does not load (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Disc labels should not be used in the audio-navigation unit. They may jam and damage the player mechanism. Make sure the audio disc is compatible with the system (see the Owner's Manual for more information). Check the connectors for poor connections or loose terminals.

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Insert a known-good disc to see if the symptom can be duplicated. Does the disc load? YES -Operation is normal. If the disc loads normally, but will not play, go to «AUDIO DISC DOES NOT PLAY TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__audio-disc-does-not-play-with) (see ). NO -Go to step 3.
  3. Insert another disc. Does the disc load? YES -The original disc is faulty. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).

Audio disc does not load (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Disc labels should not be used in the audio unit. They may jam and damage the player mechanism. Make sure the audio disc is compatible with the system (see the Owner's Manual for more information). Check the connectors for poor connections or loose terminals.

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Insert a known-good disc to see if the symptom can be duplicated. Does the disc load? YES -Operation is normal. If the disc loads normally, but will not play, go to «AUDIO DISC DOES NOT PLAY TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__audio-disc-does-not-play-without) (see ). NO -Go to step 3.
  3. Insert another disc. Does the disc load? YES -The original disc is faulty. NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

Audio disc does not eject (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Disc labels should not be used in the audio-navigation unit. They may jam and damage the player mechanism. Check the connectors for poor connections or loose terminals.

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio system. Does the system turn on? YES -Go to step 3. NO -Go to «AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__audio-unit-power-switch-will-not) (see ).
  3. Check to see if the disc ejects correctly with no binding when you push the EJECT button. Does the disc eject properly? YES -Operation is normal. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).

Audio disc does not eject (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Disc labels should not be used in the audio unit. They may jam and damage the player mechanism. Check the connectors for poor connections or loose terminals.

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio unit. Does the system turn on? YES -Go to step 3. NO -Go to «AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__audio-unit-power-switch-will-not) (see ).
  3. Check to see if the disc ejects correctly with no binding when you push the EJECT button. Does the disc eject properly? YES -Operation is normal. NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

Audio disc changer does not load all six discs (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Disc labels should not be used in the audio unit. They may jam and damage the player mechanism. Check the connectors for poor connections or loose terminals.

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio unit, and try loading six discs into the audio unit (in-dash disc changer). Does the audio unit accept all six discs? YES -Intermittent failure, the audio unit is OK at this time. NO -Go to step 3.
  3. Insert six known-good discs into the audio unit. Does the audio unit (in-dash disc changer) accept all six discs? YES -At least one of the original discs is faulty. NO -Substitute a known-good audio unit (in-dash disc changer) (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio unit (in-dash disc changer) (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

Audio disc changer does not move between discs (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Disc labels should not be used in the audio unit. They may jam and damage the player mechanism. Check the connectors for poor connections or loose terminals.

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Insert six discs into the audio unit (in-dash disc changer), and see if the changer moves between discs. Does the changer operate normally? YES -Intermittent failure, the disc changer is OK at this time. NO -Go to step 3.
  3. Insert six known-good discs into the audio unit. Does the changer operate normally? YES -At least one of the original discs is faulty. NO -Substitute a known-good audio unit (in-dash disc changer) (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio unit (in-dash disc changer) (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

Special Tools Required

Diagnostic CD 07AAZ-SDBA100

Audio disc does not play (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Disc labels should not be used in the audio-navigation unit. They may jam and damage the player mechanism. Check the connectors for poor connections or loose terminals.

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Insert a disc into the audio-navigation unit. Does the disc load? YES -Go to step 3. NO -Go to «AUDIO DISC DOES NOT LOAD TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__audio-disc-does-not-load-with) (see ).
  3. Insert a known-good disc to see if the symptom can be duplicated. Does the disc play? YES -Operation is normal. NO -Go to step 4.
  4. Insert audio diagnostic CD (T/N 07AAZ-SDBA100) in the audio-navigation unit. Does the disc play? YES -The original disc is faulty or has an unreadable format. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).

Special Tools Required

Diagnostic CD 07AAZ-SDBA100

Audio disc does not play (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Disc labels should not be used in the audio unit. They may jam and damage the player mechanism. Check the connectors for poor connections or loose terminals.

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Insert a disc into the audio unit. Does the disc load? YES -Go to step 3. NO -Go to «AUDIO DISC DOES NOT LOAD TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__audio-disc-does-not-load-without) (see ).
  3. Insert a known-good disc to see if the symptom can be duplicated. Does the disc play? YES -Operation is normal. NO -Go to step 4.
  4. Insert audio diagnostic CD (T/N 07AAZ-SDBA100) in the audio unit. Does the disc play? YES -The original disc is faulty or has an unreadable format. NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

Special Tools Required

  1. Diagnostic CD 07AAZ-SDBA100
  2. Skip Test CD 07AAZ-SDBA200
  3. Skip Test CD 07AAZ-SDBA300

Audio disc skips (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Disc labels should not be used in the audio-navigation unit. They may jam and damage the player mechanism. Check the connectors for poor connections or loose terminals.

  1. Confirm the vehicles tires are properly inflated.
  2. Check the client's disc for scratches and fingerprints. NOTE: The following test should be done with the audio system bass and treble set to the client's listening settings. When comparing to known-good vehicles, do the comparison on the same model and trim level.
  3. Test-drive the vehicle to identify when the client's disc skips. The audio diagnostic CD (T/N 07AAZ-SDBA100) can be used if the client's CD is not available; use tracks 10-12. Does the disc skip? YES -Go to step 4. NO -Operation is normal.
  4. Compare the client's CD that skips to a known-good vehicle under the same conditions. Does the disc skip in the known-good vehicle under the same conditions? YES -The disc player operation is normal, the problem is with the client's disc. NO -Go to step 5. NOTE: Do the following test with vehicle parked and the engine running.
  5. Insert the diagnostic skip test CD (T/N 07AAZ-SDBA300). Play tracks 2-11, and note on which track number(s) the disc starts skipping. Do the same test on a known-good vehicle. Does the disc skip on the same track(s) as the known-good vehicle? YES -Operation is normal. NO -Go to step 6.
  6. Insert the diagnostic skip test CD (T/N 07AAZ-SDBA200). Play tracks 7-11 and tracks 13 -15, and note on which track number(s) the disc starts skipping. Do the same test on a known-good vehicle. Does the disc skip on the same track number(s) as the known-good vehicle? YES -Operation is normal. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).

Special Tools Required

  1. Diagnostic CD 07AAZ-SDBA100
  2. Skip Test CD 07AAZ-SDBA200
  3. Skip Test CD 07AAZ-SDBA300

Audio disc skips (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Disc labels should not be used in the audio unit. They may jam and damage the player mechanism. Check the connectors for poor connections or loose terminals.

  1. Confirm the vehicles tires are properly inflated.
  2. Check the client's disc for scratches and fingerprints. NOTE: The following test should be done with the audio system bass and treble set to the client's listening settings. When comparing to known-good vehicles, do the comparison on the same model and trim level.
  3. Test-drive the vehicle to identify when the client's disc skips. The audio diagnostic CD (T/N 07AAZ-SDBA100) can be used if the client's CD is not available; use tracks 10-12. Does the disc skip? YES -Go to step 4. NO -Operation is normal.
  4. Compare the client's CD that skips to a known-good vehicle under the same conditions. Does the disc skip in the known-good vehicle under the same conditions? YES -The disc player operation is normal, the problem is with the client's disc. NO -Go to step 5. NOTE: Do the following test with vehicle parked and the engine running.
  5. Insert the diagnostic skip test CD (T/N 07AAZ-SDBA300). Play tracks 2-11, and note on which track number(s) the disc starts skipping. Do the same test on a known-good vehicle. Does the disc skip on the same track(s) as the known-good vehicle? YES -Operation is normal. NO -Go to step 6.
  6. Insert the diagnostic skip test CD (T/N 07AAZ-SDBA200). Play tracks 7-11 and tracks 13-15, and note on which track number(s) the disc starts skipping. Do the same test on a known-good vehicle. Does the disc skip on the same track number(s) as the known-good vehicle? YES -Operation is normal. NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). In order to troubleshoot the POWER ( ) button, go to AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) TROUBLESHOOTING (see ). In order to troubleshoot the VOLUME knob, go to VOLUME DOES NOT CHANGE TROUBLESHOOTING (see ). Check the connectors for poor connections or loose terminals.

  1. Go to the «AUDIO BUTTON AND KNOB DETECTION MODE»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) in the Self-Diagnostic Function (see ).
  2. Operate all items in the switch list. SWITCH LIST Button Name AM/FM SKIP (-->) XM SKIP (<--) DISC CATEGORY+ AUDIO/ (SOUND) CATEGORY- HDD TUNE UP USB/AUX TUNE DOWN Preset buttons (1-6) SCAN VOLUME (UP/DOWN) TITLE Do all the items in the switch list work properly? YES -Operation is normal. NO -Substitute a known-good audio-navigation and HVAC switch panel (see «AUDIO-NAVIGATION AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation and HVAC switch panel (see «AUDIO-NAVIGATION AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). If the symptom/indication still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).

Audio unit button does not work (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). In order to troubleshoot the POWER ( ) button, go to AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) TROUBLESHOOTING (see ). In order to troubleshoot the VOLUME knob, go to VOLUME DOES NOT CHANGE TROUBLESHOOTING (see ). Check the connectors for poor connections or loose terminals.

  1. Go to the «AUDIO BUTTON AND KNOB DETECTION MODE»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) in the Self-Diagnostic Function (see ).
  2. Operate all items in the switch list. SWITCH LIST Button Name AM/FM SKIP (-->) XM SKIP (<--) TITLE CATEGORY+ CLOCK CATEGORY- DISC TUNE UP USB/AUX TUNE DOWN Preset buttons (1-6) SCAN VOL (UP/DOWN) A.SEL Do all the items in the switch list work properly? YES -Operation is normal. NO -Substitute a known-good audio and HVAC switch panel (see «AUDIO AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio and HVAC switch, panel (see «AUDIO AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). If the symptom/indication still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

Audio unit disc indicator does not work (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Discs with labels should not be used in the audio-navigation unit. They may jam and damage the player mechanism. Check the connectors for poor connections or loose terminals.

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Insert a known-good disc or press the EJECT button. Is the DISC indicator (LED) indicated? YES -The audio-navigation unit is OK at this time. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).

Audio unit disc indicator does not work (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Discs with labels should not be used in the audio unit. They may jam and damage the player mechanism. Check the connectors for poor connections or loose terminals.

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Insert a known-good disc or press the EJECT button. Is the DISC indicator (LED) indicated? YES -The audio unit is OK at this time. NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

USB device does not function (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the USB's specifications: Mass-storage class ready digital audio player with USB 2.0 port More than 256 MB of RAM Supports MP3, WMA, and AAC (encoded with the iTunes) files, DRM files are not supported Not all players and player functions work with the USB adapter. Please see the Owner's Manual for more information. Always test the client's USB device in a known-good vehicle of the same year and trim (if possible). Technologies change and are updated frequently which may result that USB devices may work in newer vehicles, but not in order vehicles of the same model. If UNSUPPORTED appears on the display, the vehicle is OK, there is a software problem with the USB device. Check the connectors for poor connections or loose terminals.

Scheme 214

Scheme 214: USB device does not function (with navigation)

Scheme 215

Scheme 215

Scheme 216

Scheme 216

Scheme 217

Scheme 217
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio system.
  3. Press the USB/AUX button, and check if it changes to USB mode. NOTE: Do not connect the USB device. Is USB NO DATA displayed in the audio display? YES -Go to step 4. NO -Go to navigation DTC 2710 troubleshooting (see «DTC 2709: FLASH-ROM DIAG»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__dtc-2709-flash-rom-diag) ).
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  5. Connect the client's USB device to a known-good vehicle (same year/trim) that is equipped with a USB adapter, and check the USB device operation. Is the USB device working properly in the known-good vehicle? YES -Go to step 6. NO -If the audio display displays UNSUPPORTED or MEDIA ERROR, the USB device may not be supported or is defective. If the audio display displays USB NO MUSIC, the USB device may have no music files or wrong type music files are on the device. See the Owner's Manual for details on USB device requirements and approved file types.
  6. On the client's vehicle, connect the client's USB device to the USB port.
  7. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  8. Turn on the audio system.
  9. Check the USB device operation in the client's vehicle. Does the USB device work properly in the client's vehicle? YES -The system is OK at this time. Inspect the connectors of the USB device, USB port and USB adapter for wear. NO -Go to step 10.
  10. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  11. On the client's vehicle, remove the USB device.
  12. Disconnect audio-navigation unit connector K (7P).
  13. Check for continuity between audio-navigation unit connector K (7P) and the USB port 5P connector according to the table. Audio-navigation unit connector USB port connector K1 4 K2 3 K3 2 K4 1 K5 5 Is there continuity? YES -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ). NO -Go to step 14.
  14. Disconnect the USB adapter 5P connector.
  15. Check for continuity between the USB adapter 5P connector and the USB port 5P connector according to the table. USB adapter connector USB port connector 1 4 2 3 3 2 4 1 5 5 Is there continuity? YES -Replace the USB main harness and/or the subharness, then recheck. NO -Replace the USB adapter, then recheck.

USB device does not function (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the USB's specifications: Mass-storage class ready digital audio player with USB 2.0 port More than. 256 MB of RAM Supports MP3, WMA, and AAC (encoded with the iTunes) files, DRM files are not supported Not all players and player functions work with the USB adapter. Please see the Owner's Manual for more information. Always test the client's USB device in a known-good vehicle of the same year and trim (if possible). Technologies change and are updated frequently which may result that USB devices may work in newer vehicles, but not in order vehicles of the same model. If UNSUPPORTED appears on the display, the vehicle is OK, there is a software problem with the USB device. Check the connectors for poor connections or loose terminals.

Scheme 218

Scheme 218: USB device does not function (without navigation)

Scheme 219

Scheme 219

Scheme 220

Scheme 220

Scheme 221

Scheme 221

Scheme 222

Scheme 222

Scheme 223

Scheme 223

Scheme 224

Scheme 224

Scheme 225

Scheme 225

Scheme 226

Scheme 226

Scheme 227

Scheme 227

Scheme 228

Scheme 228

Scheme 229

Scheme 229

Scheme 230

Scheme 230
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio unit.
  3. Press the USB/AUX button to select USB mode. NOTE: Do not connect the USB device. Is USB NO DATA displayed in the audio display? YES -Go to step 4. NO -Go to step 16 .
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  5. Connect the client's USB device to a known-good vehicle (same year/trim) that is equipped with a USB adapter, and check the USB device operation. Is the USB device working properly in the known-good vehicle? YES -Go to step 6. NO -If the audio display displays UNSUPPORTED or MEDIA ERROR, the USB device may not be unsupported or is defective. If the audio display displays USB NO MUSIC, the USB device may have no music files or wrong type music files are on the device. See the Owner's Manual for details on USB device requirements and approved file types.
  6. On the client's vehicle, connect the client's USB device to the USB port.
  7. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  8. Turn on the audio unit.
  9. Check the USB device operation in the client's vehicle. Does the USB device work properly in the client's vehicle? YES -The system is OK at this time. Inspect the connectors of the USB device, USB port and USB adapter for wear. NO -Go to step 10.
  10. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  11. On the client's vehicle, remove the USB device.
  12. Disconnect USB adapter control unit connector B (5P).
  13. Check for continuity between USB adapter control unit connector B (5P) and the USB port 5P connector according to the table. USB adapter control unit connector USB port connector B1 4 B2 3 B3 2 B4 1 B5 5 Is there continuity? YES -Replace the USB adapter control unit (see «USB ADAPTER CONTROL UNIT REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), then recheck. NO -Go to step 14.
  14. Disconnect the USB adapter 5P connector.
  15. Check for continuity between the USB adapter 5P connector and the USB port 5P connector according to the table. USB adapter connector USB port connector 1 4 2 3 3 2 4 1 5 5 Is there continuity? YES -Replace the USB main harness, then recheck. NO -Replace the USB adapter, then recheck.
  16. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  17. Measure the voltage between USB adapter control unit connector A (14P) terminal No. 1 and body ground. Is there battery voltage? YES -Go to step 19 . NO -Go to step 18.
  18. Measure the voltage between audio unit connector C (14P) terminal No. 1 and body ground. Is there battery voltage? YES -Repair an open or high resistance in the wire between USB adapter control unit connector A (14P) terminal No. 1 and audio unit connector C (14P) terminal No. 1. NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).
  19. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  20. Measure the voltage between USB adapter control unit connector A (14P) terminal No. 11 and body ground. Is there less than 0.2 V? YES -Go to step 21. NO -Repair an open or high resistance in the wire between USB adapter control unit connector A (14P) terminal No. 11 and audio unit connector C (14P) terminal No. 11.
  21. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  22. Disconnect these items: Audio unit connector C (14P) USB adapter control unit connector A (14P) XM receiver connector A (14P)
  23. Check for continuity between USB adapter control unit connector A (14P) terminal No. 2 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between USB adapter control unit connector A (14P) terminal No. 2 and audio unit connector C (14P) terminal No. 2. NO -Go to step 24.
  24. Check for continuity between audio unit connector C (14P) terminal No. 2 and USB adapter control unit connector A (14P) terminal No. 2. Is there continuity? YES -Go to step 25. NO -Repair an open in the wire between the audio unit and the USB adapter control unit.
  25. Check for continuity between USP adapter control unit connector A (14P) and audio unit connector C (14P) according to the table. USB adapter control unit connector Audio unit connector Wire color A9 C9 PNK A10 C10 BLU Is there continuity? YES -Go to step 26. NO -There is an open in the wire(s) between the audio unit and the USB adapter control unit. Replace the affected shielded harness.
  26. Disconnect the HandsFreeLink control unit 28P connector.
  27. Check for continuity between audio unit connector C (14P) and body ground according to the table. Audio unit connector Wire color C9 PNK C10 BLU Is there continuity? YES -There is a short to body ground in the wire(s) between the audio unit and the USB adapter control unit. Replace the affected shielded harness. NO -Go to step 28.
  28. Check for continuity between the terminals of audio unit connector C (14P) according to the table. From terminal To terminals C3 (GRY) C9(PNK), C10(BLU) C9 (PNK) C10(BLU) Is there continuity between any of the terminals? YES -There is a short in the wires between the USB adapter control unit and the audio unit. Replace the affected shielded harness. NO -Go to step 29.
  29. Reconnect these items: Audio unit connector C (14P) HandsFreeLink control unit 28P connector XM receiver connector A (14P)
  30. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  31. Turn on the audio unit.
  32. Press the USB/AUX button several times. Is the display changed to other mode? YES -Replace the USB adapter control unit (see «USB ADAPTER CONTROL UNIT REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Go to step 33.
  33. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  34. Disconnect XM receiver connector A (14P).
  35. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  36. Turn on the audio unit.
  37. Press the USB/AUX button several times. Is the display changed to other mode? YES -Replace the XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Go to step 38.
  38. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  39. Reconnect XM receiver connector A (14P).
  40. Disconnect the HandsFreeLink control unit 28P connector.
  41. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  42. Turn on the audio unit.
  43. Press the USB/AUX button several times. Is the display changed to other mode? YES -Replace the HandsFreeLink control unit (see «CONTROL UNIT INPUT TEST»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#handsfreelink-system) ). NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

USB input sound is low or cannot be heard (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Not all players and player functions work with the USB adapter. Please see the Owner's Manual for more information. Always test the client's USB device in a known-good vehicle of the same year and trim (if possible). Technologies change and are updated frequently which may result in that USB devices may work in newer vehicles, but not in older vehicles of the same model. Check the connectors for poor connections or loose terminals.

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Do the Speaker Check Mode with the Self-Diagnostic Mode (see «HOW TO CHECK THE AUDIO SYSTEM CONDITION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). Do all speakers make a sound? YES -Go to step 3. NO -Go to «NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__no-sound-is-heard-from-the) (see ).
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  4. On the client's vehicle, connect the client's USB device to the USB port.
  5. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  6. Turn on the audio system.
  7. Press the USB/AUX button until USB appears on the audio display.
  8. Check if the USB device can be operated with the audio-navigation unit (Folders or Files UP/DOWN, etc.). Can you operate the USB device, but there is no sound heard? YES -Go to step 9. NO -If the sound is normal, the USB device is OK at this time. If the USB device cannot be operated, go to «USB DEVICE DOES NOT FUNCTION TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__usb-device-does-not-function-with) (see ).
  9. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  10. Connect the client's USB device to a known-good vehicle (same year/trim) that is equipped with a USB adapter, and check the USB device operation. Is the USB device working properly in the known-good vehicle? YES -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ). NO -USB device is faulty or not compatible. Also check the USB adapter and USB adapter connector condition.

USB input sound is low or cannot be heard (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Not all players and player functions work with the USB adapter. Please see the Owner's Manual for more information. Check the connectors for poor connections or loose terminals.

Scheme 231

Scheme 231: USB input sound is low or cannot be heard (without navigation)

Scheme 232

Scheme 232

Scheme 233

Scheme 233

Scheme 234

Scheme 234

Scheme 235

Scheme 235

Scheme 236

Scheme 236

Scheme 237

Scheme 237
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Do the Speaker Check Mode with the Self-Diagnostic Mode (see «SPEAKER CHECK MODE»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__speaker-check-mode) ). Do all speakers make a sound? YES -Go to step 3. NO -Go to «NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__no-sound-is-heard-from-the) (see ).
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  4. On the client's vehicle, connect the client's USB device to the USB port.
  5. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  6. Turn on the audio unit.
  7. Press the USB/AUX button until USB appears on the audio display.
  8. Check if the USB device can be operated with the audio unit (Folders or Files UP/DOWN, etc.). Can you operate the USB device, but there is no sound heard? YES -Go to step 9. NO -If the sound is normal, the USB device is OK at this time. If the USB device cannot be operated, go to «USB DEVICE DOES NOT FUNCTION TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__usb-device-does-not-function-without) (see ).
  9. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  10. Connect the client's USB device to a known-good vehicle (same year/trim) that is equipped with a USB adapter, and check the USB device operation. Is the USB device working properly in the known-good vehicle? YES -Go to step 11. NO -USB device is faulty. Also check the USB adapter and USB adapter connector condition.
  11. Return to the client's vehicle.
  12. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  13. Turn on the audio unit, and check for sound in each mode (XM and Bluetooth audio). Is the sound normal? YES -Go to step 14. NO -Go to XM or HFL troubleshooting.
  14. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  15. Measure the voltage between USB adapter control unit connector A (14P) terminal No. 1 and body ground. Is there battery voltage? YES -Go to step 17 . NO -Go to step 16.
  16. Measure the voltage between audio unit connector C (14P) terminal No. 1 and body ground. Is there battery voltage? YES -Repair an open or high resistance in the wire between USB adapter control unit connector A (14P) terminal No. 1 and audio Unit connector C (14P) terminal No. 1. NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).
  17. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  18. Measure the voltage between USB adapter control unit connector A (14P) terminal No. 11 and body ground. Is there less than 0.2 V? YES -Go to step 19. NO -Repair an open or high resistance in the wire between USB adapter control unit connector A (14P) terminal No. 11 and audio unit connector C (14P) terminal No. 11.
  19. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  20. Disconnect these items: Audio unit connector C (14P) USB adapter control unit connector A (14P) XM receiver connector A (14P)
  21. Check for continuity between USB adapter control unit connector A (14P) terminal No. 2 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between USB adapter control unit connector A (14P) terminal No. 2 and audio unit connector C (14P) terminal No. 2. NO -Go to step 22.
  22. Check for continuity between audio unit connector C (14P) terminal No. 2 and USB adapter control unit connector A (14P) terminal No. 2. Is there continuity? YES -Go to step 23. NO -Repair an open in the wire between the audio unit and the USB adapter control unit.
  23. Check for continuity between audio unit connector C (14P) and USB adapter control unit connector A (14P) according to the table. Audio unit connector USB adapter control unit connector Wire color C5 A5 GRN C6 A6 BLK C13 A13 WHT C14 A14 RED Is there continuity? YES -Substitute a known-good USB adapter control unit (see «USB ADAPTER CONTROL UNIT REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), then reconnect all of the connectors, and recheck. If the symptom/indication goes away, replace the original USB adapter control unit (see «USB ADAPTER CONTROL UNIT REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). If the symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -There is an open in the wire(s) between the audio unit and the USB adapter control unit. Replace the affected shielded harness.

Booming sound while driving with audio unit on or off

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 238

Scheme 238: Booming sound while driving with audio unit on or off

Scheme 239

Scheme 239

Scheme 240

Scheme 240

Scheme 241

Scheme 241

Scheme 242

Scheme 242

Scheme 243

Scheme 243

Scheme 244

Scheme 244

Scheme 245

Scheme 245

Scheme 246

Scheme 246

Scheme 247

Scheme 247

Scheme 248

Scheme 248

Scheme 249

Scheme 249

Scheme 250

Scheme 250

Scheme 251

Scheme 251

Scheme 252

Scheme 252

Scheme 253

Scheme 253

Scheme 254

Scheme 254

Scheme 255

Scheme 255

Scheme 256

Scheme 256

Scheme 257

Scheme 257

Scheme 258

Scheme 258

Scheme 259

Scheme 259

Scheme 260

Scheme 260

Scheme 261

Scheme 261

Scheme 262

Scheme 262
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Operate the audio system, and the speakers function normally. Is a booming sound or a low-frequency hum heard from speakers? YES -Go to step 3. NO -Operation is normal.
  3. Open the driver's door, with the booming sound present. Is the booming sound still present? YES -Go to step 62 . NO -Go to step 4.
  4. Turn the audio system off.
  5. Do the ANC/active sound control Self-Diagnostic Function (see «HOW TO CHECK THE ANC/ACTIVE SOUND CONTROL SYSTEM IN THIS CHECK MODE»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).
  6. Press the No. 1 button. Is the low-frequency hum sound heard? YES -Go to step 7. NO -Go to step 29 .
  7. Check that the low-frequency hum sound continues sounding for about 1 minute. Does the low-frequency hum sound continue sounding for about 1 minute? YES -Go to step 52 . NO -Go to step 8.
  8. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  9. Check the No. 15 (10 A) fuse in the under-hood fuse/relay box. Is the fuse OK? YES -Go to step 10. NO -Replace the fuse, and recheck. If the fuse blows again, check for a short in the No. 15 (10 A) fuse circuit.
  10. Connect a voltmeter between ANC/active sound control unit 16P connector terminals No. 3 and No. 11. NOTE: Use the voltmeter in AC range.
  11. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  12. Make a loud noise in front of the microphone. Does the voltage change when making a loud noise in front of the microphone? YES -Replace the ANC/active sound control unit (see «USB ADAPTER CONTROL UNIT REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Go to step 13.
  13. Measure the voltage between body ground and front HFL-navigation-ANC/active sound control microphone 7P connector or front HFL-ANC/active sound control microphone 7P connector terminals No. 6 and No. 7 individually. Is there battery voltage? YES -Go to step 14. NO -If the +B wire does not have voltage, repair an open in the wire between the No. 15 (10 A) fuse in the under-hood fuse/relay box and the front HFL-navigation-ANC/active sound control microphone or the front HFL-ANC/active sound control microphone. If the ACC wire does not have voltage, repair an open in the wire between the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box and the front HFL-navigation-ANC/active sound control microphone or the front HFL-ANC/active sound control microphone.
  14. Measure the voltage between front HFL-navigation-ANC/active sound control microphone 7P connector or front HFL-ANC/active sound control microphone 7P connector terminal No. 1 and body ground. Is there less than 0.2 V? YES -Go to step 15. NO -Repair open or high resistance in the wire between the front HFL-navigation-ANC/active sound control microphone or the front HFL-ANC/active sound control microphone and body ground (G402) (see «CONNECTOR TO FUSE/RELAY BOX INDEX»(/acura/zdx/i-2009-2013/remont/body-electrical/#fuserelay-boxes__connector-to-fuserelay-box-index) ).
  15. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  16. Disconnect these items: ANC/active sound control unit 16P connector Front HFL-navigation-ANC/active sound control microphone 7P connector (with navigation) Front HFL-ANC/active sound control microphone 7P connector (without navigation)
  17. Check for continuity between ANC/active sound control unit 16P connector terminal No. 3 and the front HFL-navigation-ANC/active sound control microphone 7P connector or front HFL-ANC/active sound control microphone 7P connector terminal No. 4. Is there continuity? YES -Go to step 18. NO -There is an open in the wire between ANC/ active sound control unit and the front HFL-navigation-ANC/active sound control microphone or the front HFL-ANC/active sound control microphone. Replace the affected shielded harness.
  18. Check for continuity between ANC/active sound control unit 16P connector terminal No. 3 and body ground. Is there continuity? YES -There is a short to body ground in the wire between the ANC/active sound control unit and the front HFL-navigation-ANC/active sound control microphone or the front HFL-ANC/active sound control microphone. Replace the affected shielded harness. NO -Go to step 19.
  19. Connect a voltmeter between ANC/active sound control unit 16P connector terminals No. 4 and No. 5. NOTE: Use the voltmeter in AC range.
  20. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  21. Make a loud noise in front of the rear ANC/active sound control microphone. Does the voltage change when making a loud noise in front of the microphone? YES -Replace the ANC/active sound control unit (see «USB ADAPTER CONTROL UNIT REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Go to step 22.
  22. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  23. Disconnect the rear ANC/active sound control microphone 2P connector.
  24. Connect rear ANC/active sound control microphone 2P connector terminals No. 1 and No. 2 with a jumper wire.
  25. Check for continuity between ANC/active sound control unit 16P connector terminals No. 4 and No. 5. Is there continuity? YES -Go to step 26. NO -There is an open in the wire(s) between the ANC/active sound control unit and the rear ANC/active sound control microphone. Replace the affected shielded harness.
  26. Remove the jumper wire.
  27. Check for continuity between ANC/active sound control unit 16P connector terminals No. 4 and No. 5. Is there continuity? YES -There is a short in the wires between the ANC/ active sound control unit and the rear ANC/active sound control microphone. Replace the affected shielded harness. NO -Go to step 28.
  28. Check for continuity between ANC/active sound control unit 16P connector terminal No. 4 and body ground. Is there continuity? YES -There is a short to body ground in the wire between the ANC/active sound control unit and the rear ANC/active sound control microphone. Replace the affected shielded harness. NO -Replace the front HFL-navigation-ANC/active sound control microphone (see «FRONT HFL-NAVIGATION-ANC/ACTIVE SOUND CONTROL MICROPHONE REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__front-hfl-navigation-ancactive-sound-control-microphone-remo) ) or the front HFL-ANC/active sound control microphone (see «FRONT HFL-ANC/ACTIVE SOUND CONTROL MICROPHONE REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#handsfreelink-system) ) and the rear ANC/active sound control microphone (see «ANC/ACTIVE SOUND CONTROL MICROPHONE REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ) at once, and recheck. If the symptom/indication still present, replace the ANC/active sound control unit (see «USB ADAPTER CONTROL UNIT REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).
  29. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  30. Check the No. 15 (10 A) fuse in the under-hood fuse/relay box. Is the fuse OK? YES -Go to step 31. NO -Replace the fuse, and recheck. If the fuse blows again, check for a short in the No. 15 (10 A) fuse circuit.
  31. Measure the voltage between ANC/active sound control unit 16P connector terminal No. 8 and body ground. Is there battery voltage? YES -Go to step 32. NO -Repair an open in the wire between the No. 15 (10 A) fuse in the under-hood fuse/relay box and the ANC/active sound control unit.
  32. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  33. Measure the voltage between ANC/active sound control unit 16P connector terminal No. 6 and body ground. Is there battery voltage? YES -Go to step 34. NO -Repair an open in the wire between ANC/active sound control unit 16P connector terminal No. 6 and audio-navigation unit connector A (24P) or audio unit connector A (24P) terminal No. 17.
  34. Measure the voltage between ANC/active sound control unit 16P connector terminal No. 7 and body ground. Is there less than 0.2 V? YES -Go to step 35. NO -Repair an open or high resistance in the wire between the ANC/active sound control unit and body ground (G501) (see «CONNECTOR TO FUSE/RELAY BOX INDEX»(/acura/zdx/i-2009-2013/remont/body-electrical/#fuserelay-boxes__connector-to-fuserelay-box-index) ).
  35. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  36. Do the ANC/active sound control Self-Diagnostic Function (see «HOW TO CHECK THE ANC/ACTIVE SOUND CONTROL SYSTEM IN THIS CHECK MODE»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).
  37. Press the No. 1 button.
  38. Measure the voltage between ANC/active sound control unit 16P connector terminal No. 12 and body ground. Is there about 5.0 V? YES -Go to step 44 . NO -Go to step 39.
  39. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  40. Disconnect these items: ANC/active sound control unit 16P connector Audio-navigation unit connector H (28P) (with navigation) Audio unit connector B (24P) (without navigation)
  41. Check for continuity between ANC/active sound control unit 16P connector terminal No. 12 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between the ANC/active sound control unit and the audio unit. NO - With navigation, go to step 42. Without navigation, go to step 43 .
  42. Check for continuity between ANC/active sound control unit 16P connector terminal No. 12 and audio-navigation unit connector H (28P) terminal No. 21. Is there continuity? YES -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ). NO -Repair an open in the wire between the ANC/active sound control unit and the audio-navigation unit.
  43. Check for continuity between ANC/active sound control unit 16P connector terminal No. 12 and audio unit connector B (24P) terminal No. 7. Is there continuity? YES -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Repair an open in the wire between the ANC/active sound control unit and the audio unit.
  44. Do the ANC/active sound control Self-Diagnostic Function (see «HOW TO CHECK THE ANC/ACTIVE SOUND CONTROL SYSTEM IN THIS CHECK MODE»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).
  45. Press the No. 1 button.
  46. Measure the voltage between ANC/active sound control unit 16P connector terminal No. 2 and body ground. Is there about 2.5 V? YES -Replace the stereo amplifier (see «STEREO AMPLIFIER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Go to step 47.
  47. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  48. Disconnect the ANC/active sound control unit 16P connector and stereo amplifier connector C (5P).
  49. Check for continuity between body ground and the ANC/active sound control unit 16P connector according to the table. ANC/active sound control unit connector Wire color 1 BLU 2 PUR 9 YEL 10 ORN Is there continuity? YES -There is a short to body ground in the wire(s) between the ANC/active sound control unit and the stereo amplifier. Replace the affected shielded harness. NO -Go to step 50.
  50. Check for continuity between the terminals of the ANC/active sound control unit 16P connector according to the table. From terminal To terminals 1 (BLU) 2 (PUR), 9 (YEL), 10 (ORN), 14 (GRY) 2 (PUR) 9 (YEL), 10 (ORN), 14 (GRY) 9 (YEL) 10 (ORN), 14 (GRY) 10 (ORN) 14 (GRY) Is there continuity between any of the terminals? YES -There is a short in the wires between the ANC/active sound control unit and the stereo amplifier. Replace the affected shielded harness. NO -Go to step 51.
  51. Check for continuity between the ANC/active sound control unit 16P connector and stereo amplifier connector C (5P) according to the table. ANC/active sound control unit connector Stereo amplifier connector Wire color 1 C3 BLU 2 C1 PUR 9 C4 YEL 10 C2 ORN Is there continuity? YES -Replace the ANC/active sound control unit (see «USB ADAPTER CONTROL UNIT REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -There is an open in the wire(s) between the ANC/active sound control unit and the stereo amplifier. Replace the affected shielded harness.
  52. Start the engine, and let the vehicle idle.
  53. Do the ANC/active sound control Self-Diagnostic Function (see «HOW TO CHECK THE ANC/ACTIVE SOUND CONTROL SYSTEM IN THIS CHECK MODE»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).
  54. Press the No. 1 button. Can you hear the low-frequency hum? YES -Go to step 55. NO -The system is OK.
  55. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  56. Disconnect the ANC/active sound control unit 16P connector.
  57. Jump the SCS line with the HDS.
  58. Disconnect PCM connector A (49P).
  59. Check for continuity between ANC/active sound control unit 16P connector terminal No. 15 and PCM connector A (49P) terminal No. 33. Is there continuity? YES -Go to step 60. NO -Repair an open in the wire between the ANC/ active sound control unit and the PCM.
  60. Disconnect the ECPS control unit 12P connector.
  61. Check for continuity between ANC/active sound control unit 16P connector terminal No. 15 and body ground. Is there continuity? YES -Repair a short in the wire between the ANC/active sound control unit and the PCM. NO -Substitute a known-good ANC/active sound control unit (see «USB ADAPTER CONTROL UNIT REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original ANC/active sound control unit (see «USB ADAPTER CONTROL UNIT REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). If symptom/indication is still present, update the PCM (see «PCM UPDATE»(/acura/zdx/i-2009-2013/remont/testing-diagnostics/#pgm-fi-system__pcm-update) ) if it does not have the latest software or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(/acura/zdx/i-2009-2013/remont/testing-diagnostics/#fuel-and-emissions-systems__substituting-the-pcm) ).
  62. Measure the voltage between ANC/active sound control unit 16P connector terminal No. 16 and body ground while the door is opening. Is there about 5.0 V? YES -Replace the ANC/active sound control unit (see «USB ADAPTER CONTROL UNIT REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Repair an open in the wire between the ANC/active sound control unit and driver's under-dash fuse/relay box connector P (20P) terminal No. 4.

Error code: XM NO SIGNAL or XM LOADING is displayed (with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check XM radio reception in an open area. Poor reception/interference can be caused by tall buildings, mountains, or high-voltage power lines.

  1. Park the vehicle outside with a clear view of the southern horizon.
  2. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  3. Do the XM Self-Diagnosis (see «XM SELF-DIAGNOSIS»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__xm-self-diagnosis) ). Are there XM error codes displayed? YES -Refer to «SOLUTION FOR TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__xm-self-diagnosis) (see ). NO -Go to step 4.
  4. Turn on the audio system, and press the XM button to select the XM radio. Does the XM radio receive a signal? YES -Reception interference operation is normal. NO -Go to step 5.
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  6. Check the AM/FM/XM antenna 2P connector and AcuraLink control unit (XM receiver) connector B (2P). Are the connectors connected? YES -Go to step 7. NO -Reconnect the AM/FM/XM antenna 2P connector and AcuraLink control unit (XM receiver) connector B (2P), and recheck XM radio operation. If the signal is restored, the system is OK. If the signal is not restored, go to step 7.
  7. Substitute a known-good AM/FM/XM antenna (see «AM/FM/XM ANTENNA REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). Does the XM radio receive a signal? YES -Replace the original AM/FM/XM antenna (see «AM/FM/XM ANTENNA REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO - USA models: Substitute a known-good XM antenna lead. If the AcuraLink control unit (XM receiver) receives a signal, replace the original XM antenna lead, and recheck. If the AcuraLink control unit (XM receiver) does not receive a signal, replace the AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). Canada models: Substitute a known-good XM antenna lead. If the XM receiver receives signal, replace the original XM antenna lead, and recheck. If the XM receiver does not receive signal, replace the XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

Error code: XM NO SIGNAL or XM LOADING is displayed (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check XM radio reception in an open area. Poor reception/interference can be caused by tall buildings, mountains, or high-voltage power lines.

  1. Park the vehicle outside with a clear view of the southern horizon.
  2. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  3. Do the XM Self-Diagnosis (see «XM SELF-DIAGNOSIS»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__xm-self-diagnosis) ). Are there XM error codes displayed? YES -Refer to «SOLUTION FOR TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__xm-self-diagnosis) (see ). NO -Go to step 4.
  4. Turn on the audio unit, and press the XM button to select the XM radio. Does the XM radio receive a signal? YES -Reception interference operation is normal. NO -Go to step 5.
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  6. Check the AM/FM/XM antenna 2P connector and XM receiver connector B (2P). Are the connectors connected? YES -Go to step 7. NO -Reconnect the AM/FM/XM antenna 2P connector and XM receiver connector B (2P), and recheck the XM radio operation. If the signal is restored, the system is OK. If the signal is not restored, go to step 7.
  7. Substitute a known-good AM/FM/XM antenna (see «AM/FM/XM ANTENNA REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). Does the XM radio receive a signal? YES -Replace the original AM/FM/XM antenna (see «AM/FM/XM ANTENNA REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Substitute a known-good XM antenna lead, and recheck. If the XM receiver receives signal, replace the original XM antenna lead. If the XM receiver does not receive a signal, replace the XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). If you replace the AcuraLink control unit(XM receiver), the AcuraLink must be reactivated by Acura Client Services. Check XM radio reception in an open area. Poor reception/interference can be caused by tall buildings, mountains, or high-voltage power lines.

  1. Park vehicle outside with a clear view of the southern horizon.
  2. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  3. Do the XM Self-Diagnosis (see «XM SELF-DIAGNOSIS»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__xm-self-diagnosis) ). Are there XM error codes displayed? YES -Refer to «SOLUTION FOR TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__xm-self-diagnosis) (see ). If ERROR 14 or ERROR 24 is displayed, go to step 4. NO -Go to see step 4 .
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  5. Check the connector at the AcuraLink control unit (XM receiver). Is the connector connected? YES -Go to step 6. NO -Reconnect the connector(s). If the error message does not go away, go to step 6.
  6. Check the AM/FM/XM antenna 2P connector. Is the connector connected? YES -Go to step 7. NO -Reconnect the connector(s). If the error message does not go away, go to step 7.
  7. Substitute a known-good AM/FM/XM antenna (see «AM/FM/XM ANTENNA REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. Is the error message gone? YES -Replace the original AM/FM/XM antenna (see «AM/FM/XM ANTENNA REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Go to step 8.
  8. Substitute a known-good AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. Is the error message gone? YES -Update the AcuraLink control unit (see «ACURALINK CONTROL UNIT UPDATE»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#acuralink) ). if it does not have the latest software, then recheck. If the software is the latest, substitute a known-good XM antenna lead, and recheck. If the AcuraLink control unit (XM receiver) receives a signal, replace the original XM antenna lead. If the symptom/indication is still present, replace the original AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Replace the XM antenna lead.

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check XM radio reception in an open area. Poor reception/interference can be caused by tall buildings, mountains, or high-voltage power lines.

  1. Park vehicle outside with a clear view of the southern horizon.
  2. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  3. Do the XM Self-Diagnosis (see «XM SELF-DIAGNOSIS»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__xm-self-diagnosis) ). Are there XM error codes displayed? YES -Refer to «SOLUTION FOR TROUBLESHOOTING»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__xm-self-diagnosis) (see ). If ERROR 14 or ERROR 24 is displayed, go to step 4. NO -Go to step 4.
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  5. Check the connector at the XM receiver. Is the connector connected? YES -Go to step 6. NO -Reconnect the connector(s). If the error message does not go away, go to step 6.
  6. Check the AM/FM/XM antenna 2P connector. Is the connector connected? YES -Go to step 7. NO -Reconnect the connector(s). If the error message does not go away, go to step 7.
  7. Substitute a known-good AM/FM/XM antenna (see «AM/FM/XM ANTENNA REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. Is the error message gone? YES -Replace the original AM/FM/XM antenna (see «AM/FM/XM ANTENNA REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Go to step 8.
  8. Substitute a known-good XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. Is the error message gone? YES -Substitute a known-good XM antenna lead, and recheck. If the XM receiver receives a signal, replace the original XM antenna lead. If the symptom/indication is still present, replace the original XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Replace the XM antenna lead.

XM radio display is blank and no station information is displayed (USA models with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). If you replace the AcuraLink control unit (XM receiver), the AcuraLink must be reactivated by Acura Client Services. Check the connectors for poor connections or loose terminals.

Scheme 263

Scheme 263: XM radio display is blank and no station information is displayed (USA models with navigation)

Scheme 264

Scheme 264

Scheme 265

Scheme 265

Scheme 266

Scheme 266

Scheme 267

Scheme 267
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Check for the audio-navigation unit hard error code. Is DTC 2601 (Display Diag: Connect) indicated? YES -Do the DTC 2601 troubleshooting (see «DTC 2601: DISPLAY DIAG: CONNECT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__dtc-2601-display-diag-connect) ). NO -Go to step 3.
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  4. Measure the voltage between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 1 and body ground. Is there battery voltage? YES -Go to step 5. NO -Repair an open in the wire between No. 15 (10 A) fuse in the under-hood fuse/relay box and the AcuraLink control unit (XM receiver).
  5. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  6. Measure the voltage between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 2 and No. 3 individually. Is there battery voltage? YES -Go to step 7. NO -If the IG1 wire does not have voltage, repair an open in the wire between the No. 12 (7.5 A) fuse in the driver's under-dash fuse/relay box and the AcuraLink control unit (XM receiver). If the ACC wire does not have voltage, repair an open in the wire between the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box and the AcuraLink control unit (XM receiver).
  7. Measure the voltage between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 28 and body ground. Is there less than 0.2 V? YES -Go to step 8. NO -Repair an open or high resistance in the wire between the AcuraLink control unit (XM receiver) and body ground (G651) (see «CONNECTOR TO FUSE/RELAY BOX INDEX»(/acura/zdx/i-2009-2013/remont/body-electrical/#fuserelay-boxes__connector-to-fuserelay-box-index) ).
  8. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  9. Disconnect Audio-navigation unit connector C (14P) and AcuraLink control unit (XM receiver) connector A (32P).
  10. Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) and audio-navigation unit connector C (14P) according to the table. AcuraLink control unit (XM receiver) connector Audio-navigation unit connector Wire color A30 C9 WHT (1) PNK (2) A31 C10 BLK (1) BLU (2) (1) AcuraLink control unit(XM receiver) connector (2) Audio-navigation unit connector Is there continuity? YES -Go to step 11. NO -There is an open in the wire(s) between the audio-navigation unit and the AcuraLink control unit (XM receiver). Replace the affected shielded harness.
  11. Reconnect audio-navigation unit connector C (14P).
  12. Substitute a known-good AcuraLink control unit(XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. Is the symptom/indication go away? YES -Update the AcuraLink control unit (see «ACURALINK CONTROL UNIT UPDATE»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#acuralink) ) if it does not have the latest software. If the software is the latest, replace the original AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).

XM radio display is blank and no station information is displayed (Canada models with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 268

Scheme 268: XM radio display is blank and no station information is displayed (Canada models with navigation)

Scheme 269

Scheme 269

Scheme 270

Scheme 270

Scheme 271

Scheme 271

Scheme 272

Scheme 272

Scheme 273

Scheme 273

Scheme 274

Scheme 274
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Check for the audio-navigation unit hard error code. Is DTC 2601 (Display Diag: Connect) indicated? YES -Do the DTC 2601 troubleshooting (see «DTC 2601: DISPLAY DIAG: CONNECT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__dtc-2601-display-diag-connect) ). NO -Go to step 3.
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  4. Measure the voltage between XM receiver connector A (14P) terminal No. 1 and body ground. Is there battery voltage? YES -Go to step 6 . NO -Go to step 5.
  5. Measure the voltage between audio-navigation unit connector C (14P) terminal No. 1 and body ground. Is there battery voltage? YES -Repair an open or high resistance in the wire between XM receiver connector A (14P) terminal No. 1 and audio-navigation unit connector C (14P) terminal No. 1. NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).
  6. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  7. Measure the voltage between XM receiver connector A (14P) terminal No. 11 and body ground. Is there less than 0.2 V? YES -Go to step 8. NO -Repair an open or high resistance in the wire between XM receiver connector A (14P) terminal No. 11 and audio-navigation unit connector C (14P) terminal No. 11.
  8. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  9. Disconnect audio-navigation unit connector C (14P) and XM receiver connector A (14P).
  10. Check for continuity between XM receiver connector A (14P) terminal No. 2 and body ground. Is there continuity? YES -Repair a shot to body ground in the wire between XM receiver connector A (14P) terminal No. 2 and audio-navigation unit connector C (14P) terminal No. 2. NO -Go to step 11.
  11. Check for continuity between audio-navigation unit connector C (14P) terminal No. 2 and XM receiver connector A (14P) terminal No. 2. Is there continuity? YES -Go to step 12. NO -Repair an open in the wire between the audio-navigation unit and the XM receiver.
  12. Check for continuity between XM receiver connector A (14P) and audio-navigation unit connector C (14P) according to the table. XM receiver connector Audio-navigation unit connector Wire color A9 C9 WHT (1) PNK (2) A10 C10 BLK (1) BLU (2) (1) XM receiver connector (2) Audio-navigation unit connector Is there continuity? YES -Substitute a known-good XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), and recheck. If the symptom/indication goes away, replace the original XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). If the symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ). NO -There is an open in the wire(s) between the audio-navigation unit and the XM receiver. Replace the affected shielded harness.

XM radio display is blank and no station information is displayed (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 275

Scheme 275: XM radio display is blank and no station information is displayed (without navigation)

Scheme 276

Scheme 276

Scheme 277

Scheme 277

Scheme 278

Scheme 278

Scheme 279

Scheme 279

Scheme 280

Scheme 280

Scheme 281

Scheme 281

Scheme 282

Scheme 282

Scheme 283

Scheme 283
  1. Measure the voltage between XM receiver connector A (14P) terminal No. 1 and body ground. Is there battery voltage? YES -Go to step 3 . NO -Go to step 2.
  2. Measure the voltage between audio unit connector C (14P) terminal No. 1 and body ground. Is there battery voltage? YES -Repair an open or high resistance in the wire between XM receiver connector A (14P) terminal No. 1 and audio unit connector C (14P) terminal No. 1. NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).
  3. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  4. Measure the voltage between XM receiver connector A (14P) terminal No. 11 and body ground. Is there less than 0.2 V? YES -Go to step 5. NO -Repair an open or high resistance in the wire between XM receiver connector A (14P) terminal No. 11 and audio unit connector C (14P) terminal No. 11.
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  6. Disconnect these items: Audio unit connector C (14P) USB adapter control unit connector A (14P) XM receiver connector A (14P)
  7. Check for continuity between XM receiver connector A (14P) terminal No. 2 and body ground. Is there continuity? YES -Repair a short to body ground in the wire between XM receiver connector A (14P) terminal No. 2 and audio unit connector C (14P) terminal No. 2. NO -Go to step 8.
  8. Check for continuity between audio unit connector C (14P) terminal No. 2 and XM receiver connector A (14P) terminal No. 2. Is there continuity? YES -Go to step 9. NO -Repair an open in the wire between the audio unit and the XM receiver.
  9. Check for continuity between XM receiver connector A (14P) and audio unit connector C (14P) according to the table. XM receiver connector Audio unit connector Wire color A9 C9 WHT (1) PNK (2) A10 C10 BLK (1) BLU (2) (1) XM receiver connector (2) Audio-navigation unit connector Is there continuity? YES -Go to step 10. NO -There is an open in the wire(s) between the audio unit and the XM receiver. Replace the affected shielded harness.
  10. Disconnect the HandsFreeLink control unit 28P connector.
  11. Check for continuity between audio unit connector C (14P) and body ground according to the table. Audio unit connector Wire color C9 PNK C10 BLU Is there continuity? YES -There is a short to body ground in the wire(s) between the audio unit and the XM receiver. Replace the affected shielded harness. NO -Go to step 12.
  12. Check for continuity between the terminals of audio unit connector C (14P) according to the table. From terminal To terminals C3 (GRY) C9(PNK), C10(BLU) C9 (PNK) C10(BLU) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio unit and the XM receiver. Replace the affected shielded harness. NO -Go to step 13.
  13. Reconnect these items: Audio unit connector C(14P) HandsFreeLink control unit 28P connector USB adapter control unit connector A (14P)
  14. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  15. Turn on the audio unit.
  16. Press the USB/AUX button several times. Is the display changed to other mode? YES -Replace the XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Go to step 17.
  17. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  18. Disconnect USB adapter control unit connector A (14P).
  19. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  20. Turn on the audio unit.
  21. Press the USB/AUX button several times. Is the display changed to other mode? YES -Replace the USB adapter control unit (see «USB ADAPTER CONTROL UNIT REPLACEMENT»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Go to step 22.
  22. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  23. Reconnect USB adapter control unit connector A (14P).
  24. Disconnect the HandsFreeLink control unit 28P connector.
  25. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  26. Turn on the audio unit.
  27. Press the USB/AUX button several times. Is the display changed to other mode? YES -Replace the HandsFreeLink control unit (see «HANDSFREELINK CONTROL UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#handsfreelink-system__handsfreelink-control-unit-removalinstallation) ). NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

XM radio preset memory is lost (USA models with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Make sure the remotes are linked. If you can only tune to channel 000, 001, 174, and 247, make sure the audio-navigation unit is set to channel mode (see the Owner's Manual), if it is set to channel mode, call XM Radio client support, and check the account activation status. If you replace the AcuraLink control unit(XM receiver), the AcuraLink must be reactivated by Acura Client Services. Check the connectors for poor connections or loose terminals.

Scheme 284

Scheme 284: XM radio preset memory is lost (USA models with navigation)

Scheme 285

Scheme 285

Scheme 286

Scheme 286
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio system, and set each of the XM radio channel preset buttons. Do each of the XM radio channel preset buttons set properly? YES -Go to step 3. NO -Go to step 5 .
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode for 1 minute, then back to ON (II), or the ON mode.
  4. Test all of the XM radio channel preset buttons for proper recall operation. Do the preset buttons recall the set radio stations? YES -The system is OK at this time. Check connections at the audio-navigation unit. NO -Go to step 5.
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  6. Measure the voltage between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 1 and body ground. Is there battery voltage? YES -Go to step 7. NO -Repair an open in the wire between No. 15 (10 A) fuse in the under-hood fuse/relay box and the AcuraLink control unit(XM receiver).
  7. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  8. Measure the voltage between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 2 and No. 3 individually. Is there battery voltage? YES -Go to step 9. NO -If the IG1 wire does not have voltage, repair an open in the wire between the No. 12 (7.5 A) fuse in the driver's under-dash fuse/relay box and the AcuraLink control unit (XM receiver). If the ACC wire does not have voltage, repair an open in the wire between the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box and the AcuraLink control unit (XM receiver).
  9. Measure the voltage between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 28 and body ground. Is there less than 0.2 V? YES -Replace the AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Repair an open or high resistance in the wire between the AcuraLink control unit (XM receiver) and body ground (G651) (see «CONNECTOR TO FUSE/RELAY BOX INDEX»(/acura/zdx/i-2009-2013/remont/body-electrical/#fuserelay-boxes__connector-to-fuserelay-box-index) ).

XM radio preset memory is lost (Canada models with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Make sure the remotes are linked. If you can only tune to channel 000, 001, 174, and 247, make sure the audio-navigation unit is set to channel mode (see the Owner's Manual), if it is set to channel mode, call XM Radio client support, and check the account activation status. Check the connectors for poor connections or loose terminals.

Scheme 287

Scheme 287: XM radio preset memory is lost (Canada models with navigation)

Scheme 288

Scheme 288

Scheme 289

Scheme 289
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio system, and set each of the XM radio channel preset buttons. Do each of the XM radio channel preset buttons set properly? YES -Go to step 3. NO -Go to step 5 .
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode for 1 minute, then back to ON (II), or the ON mode.
  4. Test all of the XM radio channel preset buttons for proper recall operation. Do the preset buttons recall the set radio stations? YES -The system is OK at this time. Check connections at the audio-navigation unit. NO -Go to step 5.
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  6. Measure the voltage between XM receiver connector A (14P) terminal No. 1 and body ground. Is there battery voltage? YES -Go to step 8 . NO -Go to step 7.
  7. Measure the voltage between audio-navigation unit connector C (14P) terminal No. 1 and body ground. Is there battery voltage? YES -Repair an open or high resistance in the wire between XM receiver connector A (14P) terminal No. 1 and audio-navigation unit connector C (14P) terminal No. 1. NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).
  8. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  9. Measure the voltage between XM receiver connector A (14P) terminal No. 11 and body ground. Is there less than 0.2 V? YES -Replace the XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Repair an open or high resistance in the wire between XM receiver connector A (14P) terminal No. 11 and audio-navigation unit connector C (14P) terminal No. 11.

XM radio preset memory is lost (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Make sure the remotes are linked. If you can only tune to channel 000, 001, 174, and 247, make sure the audio unit is set to channel mode (see the Owner's Manual), if it is set to channel mode, call XM Radio client support, and check the account activation status. Check the connectors for poor connections or loose terminals.

Scheme 290

Scheme 290: XM radio preset memory is lost (without navigation)

Scheme 291

Scheme 291

Scheme 292

Scheme 292
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio unit, and set each of the XM radio channel preset buttons. Do each of the XM radio channel preset buttons set properly? YES -Go to step 3. NO -Go to step 5 .
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode for 1 minute, then back to ON (II), or the ON mode.
  4. Test all of the XM radio channel preset buttons for proper recall operation. Do the preset buttons recall the set radio stations? YES -The system is OK at this time. Check connections at the audio-navigation unit. NO -Go to step 5.
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  6. Measure the voltage between XM receiver connector A (14P) terminal No. 1 and body ground. Is there battery voltage? YES -Go to step 8 . NO -Go to step 7.
  7. Measure the voltage between audio unit connector C (14P) terminal No. 1 and body ground. Is there battery voltage? YES -Repair an open or high resistance in the wire between XM receiver connector A (14P) terminal No. 1 and audio unit connector C (14P) terminal No. 1. NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).
  8. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  9. Measure the voltage between XM receiver connector A (14P) terminal No. 11 and body ground. Is there less than 0.2 V? YES -Replace the XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). NO -Repair an open or high resistance in the wire between audio unit connector C (14P) terminal No. 11 and XM receiver connector A (14P) terminal No. 11.

Poor or no sound with XM radio (Audio unit does display XM channels) (USA models with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the radio reception in an open area. Poor reception/interference can be caused by tall buildings, mountains, or high-voltage power lines are nearby. If you can only tune to channel 000, 001, 174, and 247, make sure the audio-navigation unit is set to channel mode (see the Owner's Manual), if it is set to channel mode, call XM Radio client support, and check the account activation status. If you replace the AcuraLink control unit(XM receiver), the AcuraLink must be reactivated by Acura Client Services. Check the connector for poor connections or loose terminals.

Scheme 293

Scheme 293: Poor or no sound with XM radio (Audio unit does display XM channels) (USA models with navigation)

Scheme 294

Scheme 294

Scheme 295

Scheme 295

Scheme 296

Scheme 296
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio system, and press the XM button to select the XM radio.
  3. Check for an error message on the display. Are there any messages displayed? YES -Go to «ERROR CODES»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__error-codes) (see ). NO -Go to step 4.
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  5. Disconnect audio-navigation unit connector C (14P) and AcuraLink control unit (XM receiver) connector A (32P).
  6. Check for continuity between audio-navigation unit connector C (14P) and AcuraLink control unit (XM receiver) connector A (32P) according to the table. Audio-navigation unit connector AcuraLink control unit (XM receiver) connector Wire color C5 A13 GRN C6 A15 BLK C13 A14 WHT C14 A16 RED Is there continuity? YES -Go to step 7. NO -There is an open in the wire(s) between the audio-navigation unit and the AcuraLink control unit (XM receiver). Replace the affected shielded harness.
  7. Disconnect the HandsFreeLink control unit 28P connector.
  8. Check for continuity between audio-navigation unit connector C (14P) and body ground according to the table. Audio-navigation unit connector Wire color C5 GRN C6 BLK C13 WHT C14 RED Is there continuity? YES -There is a short to body ground in the wires between the audio-navigation unit and the AcuraLink control unit (XM receiver). Replace the affected shielded harness. NO -Go to step 9.
  9. Check for continuity between the terminals of audio-navigation unit connector C (14P) according to the table. From terminal To terminals C4 (GRY) C5 (GRN), C6 (BLK), C13 (WHT), C14 (RED) C5 (GRN) C6 (BLK), C13 (WHT), C14 (RED) C6 (BLK) C13 (WHT), C14 (RED) C13 (WHT) C14 (RED) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio-navigation unit and the AcuraLink control unit (XM receiver). Replace the affected shielded harness. NO -Substitute a known-good AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), then reconnect all connectors, and recheck. If the symptom/indication goes away, update the AcuraLink control unit (see «ACURALINK CONTROL UNIT UPDATE»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#acuralink) ) if it does not have the latest software, then recheck. If the software is the latest, replace the AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). If symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).

Poor or no sound with XM radio (Audio unit does display XM channels) (Canada models with navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the radio reception in an open area. Poor reception/interference can be caused by tall buildings, mountains, or high-voltage power lines are nearby. If you can only tune to channel 000, 001, 174, and 247, make sure the audio-navigation unit is set to channel mode (see the Owner's Manual), if it is set to channel mode, call XM Radio client support, and check the account activation status. Check the connector for poor connections or loose terminals.

Scheme 297

Scheme 297: Poor or no sound with XM radio (Audio unit does display XM channels) (Canada models with navigation)

Scheme 298

Scheme 298

Scheme 299

Scheme 299

Scheme 300

Scheme 300
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio system, and press the XM button to select the XM radio.
  3. Check for an error message on the display. Are there any messages displayed? YES -Go to «ERROR CODES»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__error-codes) (see ). NO -Go to step 4.
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  5. Disconnect audio-navigation unit connector C (14P) and XM receiver connector A (14P).
  6. Check for continuity between audio-navigation unit connector C (14P) and XM receiver connector A (14P) according to the table. Audio-navigation unit connector XM receiver connector Wire color C5 A5 GRN C6 A6 BLK C13 A13 WHT C14 A14 RED Is there continuity? YES -Go to step 7. NO -There is an open in the wire(s) between the audio-navigation unit and the XM receiver. Replace the affected shielded harness.
  7. Disconnect the HandsFreeLink control unit 28P connector.
  8. Check for continuity between audio-navigation unit connector C (14P) and body ground according to the table. Audio-navigation unit connector Wire color C5 GRN C6 BLK C13 WHT C14 RED Is there continuity? YES -There is a short to body ground in the wires between the audio-navigation unit and the XM receiver. Replace the affected shielded harness. NO -Go to step 9.
  9. Check for continuity between the terminals of audio-navigation unit connector C (14P) according to the table. From terminal To terminals C4 (GRY) C5(GRN), C6(BLK), C13 (WHT), C14(RED) C5 (GRN) C6(BLK), C13(WHT), C14 (RED) C6(BLK) C13(WHT), C14(RED) C13(WHT) C14(RED) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio-navigation unit and the XM receiver. Replace the affected shielded harness. NO -Substitute a known-good XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), then reconnect all connectors, and recheck. If the symptom/indication goes away, replace the XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). If symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__audio-navigation-unit-removalinstallation) ).

Poor or no sound with XM radio (Audio unit does display XM channels) (without navigation)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the radio reception in an open area. Poor reception/interference can be caused by tall buildings, mountains, or high-voltage power lines are nearby. If you can only tune to channel 000, 001, 174, and 247, make sure the audio unit is set to channel mode (see the Owner's Manual), if it is set to channel mode, call XM Radio client support, and check the account activation status. Check the connector for poor connections or loose terminals.

Scheme 301

Scheme 301: Poor or no sound with XM radio (Audio unit does display XM channels) (without navigation)

Scheme 302

Scheme 302

Scheme 303

Scheme 303

Scheme 304

Scheme 304
  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Turn on the audio system, and press the XM button to select the XM radio.
  3. Check for an error message on the display. Are there any messages displayed? YES -Go to «ERROR CODES»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__error-codes) (see ). NO -Go to step 4.
  4. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  5. Disconnect audio unit connector C (14P) and XM receiver connector A (14P).
  6. Check for continuity between XM receiver connector A (14P) and audio unit connector C (14P) according to the table. Audio unit connector XM receiver connector Wire color C5 A5 GRN C6 A6 BLK C13 A13 WHT C14 A14 RED Is there continuity? YES -Go to step 7. NO -There is an open in the wire(s) between the audio unit and the XM receiver. Replace the affected shielded harness.
  7. Disconnect the HandsFreeLink control unit 28P connector and USB adapter control unit connector A (14P).
  8. Check for continuity between audio unit connector C (14P) and body ground according to the table. Audio unit connector Wire color C5 GRN C6 BLK C13 WHT C14 RED Is there continuity? YES -There is a short to body ground in the wires between the audio unit and the XM receiver. Replace the affected shielded harness. NO -Go to step 9.
  9. Check for continuity between the terminals of audio unit connector C (14P) according to the table. From terminal To terminals C4 (GRY) C5(GRN), C6(BLK), C13 (WHT), C14(RED) C5 (GRN) C6 (BLK), C13 (WHT), C14 (RED) C6 (BLK) C13(WHT), C14(RED) C13(WHT) C14(RED) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio unit and the XM receiver. Replace the affected shielded harness. NO -Substitute a known-good XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ), then reconnect all connectors, and recheck. If the symptom/indication goes away, replace the original XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ). If symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).

Sound Quality Diagnosis

Special Tools Required

Diagnostic CD 07AAZ-SDBA100

Use the following tests to check sound quality.

Note. Before beginning the following tests, write down the client's bass, treble, fader and balance settings, then set them to their center positions for the testing.

Left/Right Channel ID

Do this test to confirm proper channel routing.

  1. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit.
  2. Play track No. 1 (left, both, right channel ID) at a normal, or slightly higher than normal, volume level.
  3. The voice should be audible only from the channel or channels when indicated. If the channel ID is correct for each side, go to «PHASE TEST»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__phase-test) . If the channel ID is not correct, check for. Shorted speaker wire Faulty stereo amplifier Faulty audio unit

Phase Test

Do this test to confirm proper speaker phasing.

  1. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit.
  2. Play track No. 2 (phase) at a normal, or slightly higher than normal, volume level.
  3. The voice should sound centered and focused when it is in-phase.
  4. The voice should sound diffused, and have less bass when it is out of phase. If the voice changes from in-phase to out of phase as indicated by the prompt, the phasing is correct. Go to «ELECTRICAL NOISE TEST»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__electrical-noise-test) . If the voice always sounds out of phase, phasing is not correct. Check for: Crossed speaker wire Faulty stereo amplifier Faulty audio unit

Electrical Noise Test

Do this test to check for electrical noise being induced into the audio system.

Note. Electrical noise may be caused by outside sources that cannot be handled by the audio system. Make sure you remove any cell phones and/or turn off any aftermarket devices before beginning this test.

  1. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit.
  2. Play track No. 4 (digital zero) at a normal, or slightly higher than normal, volume level.
  3. Operate any electrical device that may create electrical noise in the audio system, including starting the engine.
  4. Play track No. 5 (near digital zero) at a normal, or slightly higher than normal, volume level.
  5. Operate any electrical device that may create electrical noise in the audio system, including starting the engine.
  6. Play track No. 6 (SNR) at a normal, or slightly higher than normal, volume level.
  7. Operate any electrical device that may create electrical noise in the audio system, including starting the engine. If no abnormal noise is heard, go to «INDIVIDUAL SPEAKER TEST»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__individual-speaker-test) . If the noise is present only during the SNR track, replace the audio unit. If the noise is heard during the digital zero or near digital zero track, check for: Poor ground at the audio unit, stereo amplifier, engine, or battery cable Pinched or shorted speaker or stereo amplifier wire Faulty stereo amplifier Faulty audio unit Other faulty components causing excessive electrical noise (ignition coils, alternator, door lock actuators, etc.). Disconnect any suspect components, and then replay the tracks that were originally noisy. If the noise is gone, check the component's circuit and the component

Individual Speaker Test

Do this test to identify a faulty speaker.

  1. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit.
  2. Play track No. 30 (steady 300 Hz tone) at a normal, or slightly higher than normal, volume level.
  3. Listen to each speaker for poor sound compared to the other channels. Use the audio unit's fader and balance settings to help isolate the channel with the problem. If the sound quality produced by a specific speaker is poor, substitute it with a known-good speaker. If the poor sound quality continues, go to Sound Balance Test. If the sound quality is OK, go to Sound Balance Test.

Sound Balance Test

Do this test to identify a faulty channel or speaker.

  1. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit.
  2. Confirm the bass and treble are set to the center positions.
  3. Play track No. 3 (pink noise) at a normal, or slightly higher than normal, volume level.
  4. A static type sound should be heard through all speakers.
  5. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit of a known-good vehicle.
  6. Set the bass and treble to the center positions.
  7. Play track No. 3 (pink noise) all the same level as was played in step 3 .
  8. Compare the sounds made by the two vehicles. If the sound does not have as much bass, check the subwoofer and circuit. If the sound does not have enough hiss, check the tweeters and their circuits.

Frequency Sweep

Do this test to find rattles or reverberations that may cause a perception of poor sound quality.

  1. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit.
  2. Play track No. 13 (sweep from 500 Hz to 35 Hz) at a normal, or slightly higher than normal, volume level.
  3. Listen to each speaker for poor sound quality or reverberations caused by specific frequencies. Use the voice-over to estimate the frequency that causes the vibration. Use the audio unit's fader and balance settings to help isolate the channel with the problem. If vibrations or poor sound quality are heard, go to step 4. If no vibrations or poor sound quality are heard, go to Sound Judging.
  4. Choose the appropriate track from No. 14 to 25 (small range frequency sweep) or 26 to 53 (single frequencies) to recreate the frequency that caused the poor sound quality or vibration witnessed in step 3 ; this aids in diagnosis of the cause. NOTE: When you get to the track that recreates the problem, select the repeat function on the audio unit, this will help you isolate the cause.
  5. Replace or insulate the source of the vibration or, if the speaker is the source of the poor sound quality, replace it.

Sound Judging

Do this test to compare overall sound quality, imaging, and dynamics between the client's vehicle and a known-good vehicle. Only use a vehicle of the same model and trim level for this test.

  1. In the client's vehicle, set the bass, treble, fader, and balance settings to the client's normal settings that were written down before beginning the test.
  2. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit.
  3. Play tracks No. 7 to 12 (sound quality, midland, dynamics, and imaging demonstration tracks) at a normal, or slightly higher than normal, volume level. Write down the volume setting being used.
  4. Listen to areas of the track that stand out as being either very clear or poorer than other areas of the track.
  5. In a known-good vehicle, insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit.
  6. Play the tracks at the same volume level and the same bass, treble, balance, and fader settings as used in step 3 in the client's vehicle.
  7. Listen to the same area of the track that stood out as being either very clear or poorer than other areas of the track.
  8. Compare the client's vehicle's sound quality results the known-good vehicle's results. If the sound quality in the client's vehicle is comparable to the sound quality in the known-good vehicle, then the client's vehicle is operating as designed. If the sound quality is not comparable, check these items in order: Loose or improperly installed speakers or other hardware that may create interference from the vibrations generated by the speakers Poor power or ground to the stereo amplifier Damaged speaker(s) Faulty stereo amplifier Faulty audio unit

Seek Stop Test

Do this test to check the performance of the audio unit's AM and FM reception 3. Refer to SYMPTOM TROUBLESHOOTING: AUDIO SOUND WEAK OR DISTORTED (DISPLAY IS NORMAL); WITH NAVIGATION (see ), WITHOUT NAVIGATION , or NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL); WITH NAVIGATION (see ), WITHOUT NAVIGATION (see ) before continuing with this test.

Note. Window tint, aftermarket theft-recovery devices and other aftermarket devices may affect reception. Changes in cloud cover and other atmospheric conditions will affect the ability of the audio unit to receive radio signals.

  1. Park the client's vehicle in an open area away from buildings or other obstructions.
  2. Park a known-good vehicle (same year, model, and trim level) next to the client's vehicle, facing the same direction.
  3. Start the engine in the client's vehicle, and turn on the radio.
  4. Set the FM receiver to 87.7 MHz.
  5. Press the Seek + button, and record the first station that the audio unit locks onto.
  6. Press the Seek + button repeatedly, and write down each station that the audio unit locks onto until the station recorded in step 5 is reached again.
  7. Set the AM receiver to 530 kHz.
  8. Press the Seek + button, and record the first station that the audio unit locks onto.
  9. Press the Seek + button repeatedly, and write down each station that the audio unit locks onto until the station recorded in step 8 is reached again.
  10. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  11. Start the engine in the known-good vehicle, and then do steps 4 thru 10 on the known-good vehicle.
  12. Compare the number of stations received in steps 6 and 9 in the client's vehicle with the number of stations received in the known-good vehicle. If the number of stations received is the same, or within 10 %, the audio unit's tuner performance is OK. The problem may be atmospheric conditions, multi-path interference, or other obstructions to the radio signal. If the client's vehicle receives fewer stations by at least 10 %, go to step 2 of «POOR AM OR FM RADIO RECEPTION OR INTERFERENCE TROUBLESHOOTING; WITH NAVIGATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__poor-am-or-fm-radio-reception) (see ), «WITHOUT NAVIGATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system__poor-am-or-fm-radio-reception) (see ).

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. Take care not to scratch the dashboard and related parts. Lay a shop towel under the parts when working on them to protect the face panel from scratches or other damage. Eject all the disc(s) before removing the audio unit to prevent damaging the CD player's load mechanism. If you are replacing the audio unit, write down the audio presets (if possible), then enter them into the new audio unit.

Scheme 305

Scheme 305: Without Navigation

Scheme 306

Scheme 306

Scheme 307

Scheme 307
  1. Make sure you have the anti-theft code for the audio system.
  2. Remove these items: Driver's inner dashboard trim (see «DRIVER'S OUTER DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard) ) Passenger's dashboard trim (see «PASSENGER'S DASHBOARD TRIM PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard) ) Center console panel (see «CENTER CONSOLE PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#consoles__center-console-panel-removalinstallation) ) Audio and HVAC switch panel (see «AUDIO AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) )
  3. Carefully remove the bolts (A) and bolts (B), then pull out the audio unit (C). NOTE: There is a lever lock on connector A (see «LEVER-LOCKED CONNECTOR»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ).
  4. Disconnect the connectors, and detach the clip (D).
  5. Remove the bolts (A) and the brackets (B).
  6. Remove the self-tapping screws, then disconnect the connector (A), and remove the front panel (B) from the audio unit (C).
  7. Install the audio unit in the reverse order of removal, and note these items: Make sure all the connectors and the antenna lead are secure. Enter the anti-theft code for the audio system.
  8. Give the new anti-theft code to the client if the audio unit is replaced.

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. Take care not to scratch the dashboard and related parts. Lay a shop towel under the parts when working on them to protect the face panel from scratches or other damage.

Scheme 308

Scheme 308: With Navigation
  1. Pull the audio-navigation and HVAC switch panel (A) out, then disconnect the connectors (B) from the audio-navigation and HVAC switch panel.
  2. Remove the interface dial (see «INTERFACE DIAL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#navigation-system__interface-dial-removalinstallation) ).
  3. Install the switch panel in the reverse order of removal.

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. Take care not to scratch the dashboard and related parts. Lay a shop towel under the parts when working on them to protect the face panel from scratches or other damage.

Scheme 309

Scheme 309: Without Navigation
  1. Pull the audio and HVAC switch panel (A) out, then disconnect the connectors (B) from the audio and HVAC switch panel.
  2. Install the switch panel in the reverse order of removal.

Note. Put on gloves to protect your hands. Take care not to scratch the dashboard and related parts. Lay a shop towel under the parts when working on them to protect the face panel from scratches or other damage.

Scheme 310

Scheme 310: Without Navigation

Scheme 311

Scheme 311

Scheme 312

Scheme 312
  1. Remove these items: Front center speaker (see «FRONT CENTER SPEAKER»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) ) Audio and HVAC switch panel (see «AUDIO AND HVAC SWITCH PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#audio-system) )
  2. Remove the tray (A).
  3. Remove the self-tapping screws (A) from the audio display unit (B).
  4. From the speaker hole, push out the audio display unit (A). Then disconnect the connector (B) from the audio display unit, and remove it.
  5. Install the audio display unit in the reverse order of removal.

Scheme 313

Scheme 313: Stereo Amplifier Removal/Installation
  1. Remove the passenger's dashboard undercover (see «GLOVE BOX DAMPER REPLACEMENT»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard__glove-box-damper-replacement) ), and the glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard__glove-box-removalinstallation) ).
  2. Loosen the bolt (A), and remove the bolts (B).
  3. Disconnect the connectors from the stereo amplifier (C), and remove it.
  4. Install the stereo amplifier in the reverse order of removal.

Note. The AcuraLink must be reactivated by Acura Client Services when

  1. The AcuraLink control unit (XM receiver) is replaced.
  2. DATA RESET was selected while in the self-diagnostic function.
  3. Vehicle ownership changes.

Scheme 314

Scheme 314
  1. Remove the passenger's rear side trim panel (see «TRIM REMOVAL/INSTALLATION - REAR SIDE AREA»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-rear-side-area) ).
  2. Loosen the nuts (A).
  3. Pull the AcuraLink control unit (XM receiver) (B) out, then disconnect the connectors from the AcuraLink control unit (XM receiver), and remove it.
  4. Install the AcuraLink control unit (XM receiver) in the reverse order of removal. NOTE: If you replaced the AcuraLink control unit (XM receiver) make sure it has the latest software (see «ACURALINK CONTROL UNIT UPDATE»(/acura/zdx/i-2009-2013/remont/entertainment-systems/#acuralink) ).
  5. Call XM Radio 800-852-9696 to update the client's account with the new XM/HIP serial number. Also call Acura Client Services 800-382-2238 to reactivate the AcuraLink.

Scheme 315

Scheme 315: Without AcuraLink
  1. Remove the passenger's rear side trim panel (see «TRIM REMOVAL/INSTALLATION - REAR SIDE AREA»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-rear-side-area) ).
  2. Loosen the nuts (A).
  3. Pull the XM receiver (B) out, then disconnect the connectors from the XM receiver, and remove it.
  4. Install the XM receiver in the reverse order of removal.
  5. Register the new XM receiver I.D. number with XM Radio, call 800-852-9696.

Scheme 316

Scheme 316: Without Navigation
  1. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#consoles__center-console-removalinstallation) ).
  2. Remove the bolts (A) and the USB adapter control unit (B), then remove the bolts (C) and brackets (D) from the USB adapter control unit.
  3. Install the USB adapter control unit in the reverse order of removal.

Scheme 317

Scheme 317: ANC/Active Sound Control Unit Removal/Installation
  1. Remove the passenger's dashboard undercover (see «GLOVE BOX DAMPER REPLACEMENT»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#dashboard__glove-box-damper-replacement) ).
  2. Remove the passenger's center console trim (see step 6 under «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#consoles__center-console-removalinstallation) ).
  3. Remove the bolt (A), and disconnect the connector (B) from the ANC/active sound control unit (C), and remove it.
  4. Install the unit in the reverse order of removal.

Scheme 318

Scheme 318: Rear
  1. Remove the headliner (see «HEADLINER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__headliner-removalinstallation) ).
  2. Disconnect the connector (A), then remove the self-tapping screws and the rear ANC/active sound control microphone (B) and the cap (C).
  3. Install the microphone in the reverse order of removal.

Scheme 319

Scheme 319: Door Speaker
  1. Remove the door panel: Front (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#doors__front-door-panel-removalinstallation) ) Rear (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#doors__rear-door-panel-removalinstallation) )
  2. Remove the bolt (A). Then lift the speaker (B) straight up to release the lower clips (C). NOTE: If you pull the speaker out too far from the door, you will damage the lower clips.
  3. Disconnect the 2P connector (D), and remove the speaker.
  4. Measure the resistance between terminals No. 1 and No. 2. There should be 2 ohms.
  5. If the resistance is not as specified, replace the door speaker.

Scheme 320

Scheme 320: Front Center Speaker

Scheme 321

Scheme 321
  1. Remove the speaker lid (A), and disconnect the sunlight sensor connector (B).
  2. Remove the self-tapping screws and the front center speaker (A).
  3. Measure the resistance between terminals No. 1 and No. 2. There should be about 2 ohms.
  4. If the resistance is not as specified, replace the front center speaker.

Tweeter

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Scheme 322

Scheme 322: Tweeter

Scheme 323

Scheme 323
  1. Remove the A-pillar trim (see «TRIM REMOVAL/INSTALLATION - PILLAR AREAS»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-pillar-areas) ).
  2. Release the hooks, and remove the tweeter (A).
  3. Check the capacitor (B) condition. If any malfunction is found, replace the tweeter.
  4. Measure the resistance between the tweeter (A) terminal No. 2 and the outside terminal of the capacitor. There should be about 6 ohms.
  5. If the resistance is not as specified, replace the tweeter.

Satellite Speaker (with navigation)

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Scheme 324

Scheme 324: Satellite Speaker (with navigation)
  1. Remove the quarter pillar trim (see «QUARTER PILLAR TRIM»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__quarter-pillar-trim) ).
  2. Detach the clip (A), and remove the self-tapping screws and the satellite speaker (B).
  3. Measure the resistance between terminals No. 1 and No. 2. There should be about 4 ohms.
  4. If the resistance is not as specified, replace the speaker.

Scheme 325

Scheme 325: Subwoofer (with navigation)
  1. Remove the rear cargo support beam (see «REAR CARGO SUPPORT BEAM REPLACEMENT»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#frame__rear-cargo-support-beam-replacement) ).
  2. Disconnect the connector (A), then remove the bolts (B) and the subwoofer (C). Input Test
  3. With the subwoofer 8P connector is connected, make the input tests at the connector according to the table. Terminal Test 4 Measure the voltage to body ground with all conditions: There should be less than 0.2 V. 5 Measure the voltage to body ground with all conditions: There should be battery voltage. 6 Measure the voltage to body ground with audio system on: There should be battery voltage.
  4. If the input test proves OK and the subwoofer has no sound, replace the subwoofer.

Scheme 326

Scheme 326: Subwoofer (without navigation)
  1. Remove the rear cargo support beam (see «REAR CARGO SUPPORT BEAM REPLACEMENT»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#frame__rear-cargo-support-beam-replacement) ).
  2. Disconnect the connector (A), then remove the bolts (B) and the subwoofer (C).
  3. Measure the resistance between the terminals No. 2 and No. 7 and between terminals No. 3 and No. 8. There should be about 2 ohms.
  4. If the resistance is not as specified, replace the subwoofer.

Scheme 327

Scheme 327: Audio Remote Switch Test
  1. Remove the audio remote, HFL-navigation voice control switch or the audio remote-HFL switch (see «STEERING WHEEL DISASSEMBLY/REASSEMBLY»(/acura/zdx/i-2009-2013/remont/manual-power-steering/#power-steering-system) ).
  2. Measure the resistance between terminals No. 11 and No. 12 in each switch position according to the table. Position Resistance No button pressed About 10 kohms MODE About 3.7 kohms CH (+) About 1.7 kohms CH (-) About 775 ohms ↑ (VOL. UP) About 357 ohms ↓ (VOL. DOWN) About 100 ohms
  3. If the resistance is not as specified, replace the switch.

Scheme 328

Scheme 328: AM/FM/XM Antenna Replacement
  1. Remove the headliner (see «HEADLINER REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/exteriorinterior-trim/#interior-trim__headliner-removalinstallation) ).
  2. Disconnect the connectors (A).
  3. Remove the nut (B) and the AM/FM/XM antenna (C).
  4. Install the antenna in the reverse order of removal.

Scheme 329

Scheme 329: USB Adapter Holder/Auxiliary Jack Assembly Replacement
  1. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#consoles__center-console-removalinstallation) ).
  2. Remove the cover (A), and disconnect the USB adapter connector (B).
  3. Carefully pull out the USB adapter holder/auxiliary jack assembly (C) from the center console box, then disconnect the 5P connector (D) and remove the USB adapter connector (E).
  4. Install the USB adapter holder/auxiliary jack assembly in the reverse order of removal.

See also:
NO SOUND WHEN BLUETOOTH AUDIO IS USED (WITH NAVIGATION)
BLUETOOTH AUDIO DOES NOT WORK (WITH NAVIGATION)
BLUETOOTH CELL PHONE CANNOT BE PAIRED
THE COMMUNICATION WITH CELL PHONE IS INTERRUPTED OR CHANGES (WITH NAVIGATION)
BLUETOOTH CELL PHONE AUDIO FUNCTION SKIP AND PAUSE/RESUME DO NOT WORK (WITH NAVIGATION)
BLUETOOTH AUDIO DOES NOT WORK (WITHOUT NAVIGATION)
NAVIGATION THROUGH HFL MENUS
NAVIGATION UNIT CONNECTOR FOR INPUTS AND OUTPUTS
AUDIO-NAVIGATION UNIT CONNECTOR D (20P)
AUDIO-NAVIGATION UNIT CONNECTOR H (28P)
CIRCUIT DIAGRAM
WITHOUT NAVIGATION
AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION
BATTERY TEST
CONNECTOR TO FUSE/RELAY BOX INDEX
HANDSFREELINK CONTROL UNIT REMOVAL/INSTALLATION
PCM UPDATE
SUBSTITUTING THE PCM
STEERING WHEEL DISASSEMBLY/REASSEMBLY
CABLE REEL REPLACEMENT
DTC 2709: FLASH-ROM DIAG
FRONT HFL-NAVIGATION-ANC/ACTIVE SOUND CONTROL MICROPHONE REMOVAL/INSTALLATION
ACURALINK CONTROL UNIT UPDATE
DTC 2601: DISPLAY DIAG: CONNECT
DRIVER'S OUTER DASHBOARD TRIM REMOVAL/INSTALLATION
CENTER CONSOLE PANEL REMOVAL/INSTALLATION
INTERFACE DIAL REMOVAL/INSTALLATION
GLOVE BOX DAMPER REPLACEMENT
GLOVE BOX REMOVAL/INSTALLATION
TRIM REMOVAL/INSTALLATION - REAR SIDE AREA
CENTER CONSOLE REMOVAL/INSTALLATION
HEADLINER REMOVAL/INSTALLATION
FRONT DOOR PANEL REMOVAL/INSTALLATION
REAR DOOR PANEL REMOVAL/INSTALLATION
TRIM REMOVAL/INSTALLATION - PILLAR AREAS
QUARTER PILLAR TRIM
REAR CARGO SUPPORT BEAM REPLACEMENT
POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (WITH NAVIGATION)
AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH NAVIGATION)
NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) (WITH NAVIGATION)
AUXILIARY INPUT SOUND IS LOW OR CANNOT BE HEARD (WITH NAVIGATION)
AUDIO SYSTEM SOUND IS WEAK OR DISTORTED (DISPLAY IS NORMAL) (WITH NAVIGATION)
RADIO PRESET MEMORY IS LOST (WITH NAVIGATION)
VOLUME DOES NOT CHANGE (WITH NAVIGATION)
VOLUME DOES NOT INCREASE WITH SPEED (WITH NAVIGATION)
VOLUME IS TOO HIGH OR TOO LOW WHEN DRIVING AT FREEWAY SPEEDS (WITH NAVIGATION)
RADIO TUNER DOES NOT CHANGE STATIONS (WITH NAVIGATION)
AUDIO-NAVIGATION AND HVAC SWITCH PANEL BUTTON ILLUMINATION DOES NOT WORK (WITH NAVIGATION)
AUDIO REMOTE SWITCH DOES NOT WORK PROPERLY (WITH NAVIGATION)
AUDIO DISC DOES NOT LOAD (WITH NAVIGATION)
AUDIO DISC DOES NOT EJECT (WITH NAVIGATION)
AUDIO DISC DOES NOT PLAY (WITH NAVIGATION)
AUDIO DISC SKIPS (WITH NAVIGATION)
AUDIO UNIT DISC INDICATOR DOES NOT WORK (WITH NAVIGATION)
USB DEVICE DOES NOT FUNCTION (WITH NAVIGATION)
USB INPUT SOUND IS LOW OR CANNOT BE HEARD (WITH NAVIGATION)
BOOMING SOUND WHILE DRIVING WITH AUDIO UNIT ON OR OFF
ERROR CODE: XM NO SIGNAL OR XM LOADING IS DISPLAYED (WITH NAVIGATION)
ERROR CODE: XM ANTENNA OR XM LOADING IS DISPLAYED (WITH ACURALINK)
XM RADIO DISPLAY IS BLANK AND NO STATION INFORMATION IS DISPLAYED (USA MODELS WITH NAVIGATION)
XM RADIO PRESET MEMORY IS LOST (USA MODELS WITH NAVIGATION)
POOR OR NO SOUND WITH XM RADIO (AUDIO UNIT DOES DISPLAY XM CHANNELS) (USA MODELS WITH NAVIGATION)
RADIO PRESET MEMORY IS LOST (WITHOUT NAVIGATION)
VOLUME DOES NOT CHANGE (WITHOUT NAVIGATION)
AUDIO AND HVAC SWITCH PANEL BUTTON ILLUMINATION DOES NOT WORK (WITHOUT NAVIGATION)
AUDIO DISC DOES NOT EJECT (WITHOUT NAVIGATION)
AUDIO DISC CHANGER DOES NOT LOAD ALL SIX DISCS (WITHOUT NAVIGATION)
AUDIO DISC CHANGER DOES NOT MOVE BETWEEN DISCS (WITHOUT NAVIGATION)
AUDIO DISC DOES NOT PLAY (WITHOUT NAVIGATION)
AUDIO DISC SKIPS (WITHOUT NAVIGATION)
AUDIO UNIT BUTTON DOES NOT WORK (WITHOUT NAVIGATION)
USB DEVICE DOES NOT FUNCTION (WITHOUT NAVIGATION)
PAIRING A CELL PHONE
SEEK STOP TEST
RECEPTION LEVEL INDICATION (PUSH AND HOLD 5 SEC AM/FM BUTTON)
SPEAKER CHECK MODE
SOUND QUALITY DIAGNOSIS
AUDIO DISC DOES NOT LOAD TROUBLESHOOTING
XM SELF-DIAGNOSIS
ERROR CODES
PHASE TEST
ELECTRICAL NOISE TEST
INDIVIDUAL SPEAKER TEST
