Power Windows Acura ZDX I

Windows 43 illustrations ~6834 words

Scheme 1

Scheme 1: Component Location Index
Scheme 1: Component Location Index

Scheme 2

Scheme 2
Scheme 2

Auto Reverse Power Window Operation

The system is composed of the driver's MICU, the passenger's MICU unit, the door multiplex control unit (built into the power window master switch), the front passenger's power window control unit (built into the front passenger's power window switch), and the power window motors.

The driver's and front passenger's power window motors incorporate a Hall IC unit (pulser) which generates pulses during the motor's operation and sends pulses to the driver's and passenger's power window control units. As soon as the power window control units detect a change in the pulse frequency from the Hall IC unit (pulser), the power window control units make the power window motor stop and reverse. This prevents pinching your hand or fingers during auto-up operation. The auto reverse function does not work when the power window master switch is held in the closed position.

Scheme 3

Scheme 3: Auto Reverse Power Window Operation
Scheme 3: Auto Reverse Power Window Operation

Key Cylinder Operation

With the key inserted in the driver's door key cylinder, turn the key twice within 15 seconds and hold it to operate the windows and panoramic glass roof (clockwise to open, counterclockwise to close). The windows and panoramic glass roof stop moving when the key is released. The auto reverse operation is not active when closing the windows and panoramic glass roof with the key cylinder.

Keyless Operation

By pressing and holding the UNLOCK button of the keyless transmitter or remote twice within 15 seconds, the windows and panoramic glass roof open. The windows and panoramic glass roof stop moving when the UNLOCK button is released. The windows do not close with the LOCK button.

Resetting the Power Window Control Unit

Reset the power window control unit after doing any of the following

  1. Power window regulator replacement, removal/installation, or repair.
  2. Power window motor replacement, removal/installation, or repair.
  3. Glass run channel replacement or removal/installation.
  4. Front passenger's power window switch replacement or removal/installation.
  5. Door glass replacement, removal/installation, or repair.
  6. Power is disconnected from the driver's power window master switch or front passenger's power window switch while the power window timer is ON.

Note. If the front passenger's power window has lost power when the key off timer is ON, it cannot be operated from the driver's switch and must be reset from the front passenger's power window switch.

Using the HDS

  1. Connect the HDS to the data link connector (DLC).
  2. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode, then enter the vehicle's VIN and mileage at the prompts.
  3. Select BODY ELECTRICAL from the SYSTEM SELECTION MENU.
  4. From the BODY ELECTRICAL SYSTEM SELECT menu, select POWER WINDOWS.
  5. From the MODE MENU, select ADJUSTMENT.
  6. From the ADJUSTMENT MENU, select POWER WINDOW RESET for DRIVER SIDE (PASSENGER SIDE).
  7. Follow the prompts on the screen.
  8. Confirm that the power window control unit is reset by using the power window AUTO UP and AUTO DOWN function.

Without the HDS

Note. Do the manual reset from the power window switch of the affected window.

  1. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  2. Move the power window all the way down by using the power window DOWN switch.
  3. Open the door of the affected power window.
  4. Do the following four times before going to step 5 : NOTE: Do each bullet step within 5 seconds of each other. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode. Push and hold the power window DOWN switch. Turn the ignition switch to ON (II) or press the engine start/stop button to select the ON mode. Release the power window DOWN switch.
  5. Confirm that AUTO UP no longer works. If AUTO UP still works, repeat step 4 , paying close attention to the 5 second time limit.
  6. Move the power window all the way down using the power window DOWN switch.
  7. Pull up and hold the power window UP switch until the power window is all the way up, then continue to hold the switch for several seconds.
  8. Confirm that the power window control unit is reset by using the power window AUTO UP and AUTO DOWN function. If the power window still does not work in AUTO, repeat the procedure several times, paying close attention to the 5 seconds time limit between each bulleted step. If the window still does not work, troubleshoot the power window circuit.

Scheme 4

Scheme 4: Circuit Diagram
Scheme 4: Circuit Diagram

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

DTC B1125: Driver's Power Window Motor A-Pulse Malfunction; DTC B1126: Driver's Power Window Motor B-Pulse Malfunction

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ). Make sure you reset the power window control unit (see RESETTING THE POWER WINDOW CONTROL UNIT ) whenever you replace or substitute any power window parts.

Scheme 7

Scheme 7: DTC B1125: Driver's Power Window Motor A-Pulse Malfunction; DTC B1126: Driver's Power Window Motor B
Scheme 7: DTC B1125: Driver's Power Window Motor A-Pulse Malfunction; DTC B1126: Driver's Power Window Motor B

Scheme 8

Scheme 8
Scheme 8
  1. Clear the DTCs with the HDS.
  2. Turn the ignition switch to LOCK (0), and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode.
  3. Open and close the driver's power window by using the power window master switch manually.
  4. Check for DTCs with the HDS. Are DTCs B1125 and/or B1126 indicated? YES -Go to step 5 NO -Intermittent failure, the system is OK at this time. Check for loose or poor connections between the door multiplex control unit and the driver's power window motor.
  5. Select the POWER WINDOWS from the BODY ELECTRICAL SYSTEM SELECT menu, and enter the DATA LIST.
  6. Check the DETECT/NONE information of the DRIVER'S P/W MOTOR PULSE A and PULSE B signal in the DATA LIST. Does the information indicator display DETECT while the window is moving, and display NONE when the window is stopped? YES -Replace the power window master switch (see «REAR POWER WINDOW SWITCH TEST/REPLACEMENT»(/acura/zdx/i-2009-2013/remont/windows/#power-windows) ). NO -Go to step 7.
  7. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  8. Disconnect the power window master switch 37P connector.
  9. Disconnect the driver's power window motor 6P connector.
  10. Check for continuity between power window master switch 37P terminals No. 3, No. 20, and No. 22, and driver's power window motor 6P connector terminals No. 5, No. 3, and No. 6 respectively. Is there continuity? YES -Go to step 11. NO -Repair an open or high resistance in the wire(s) between the door multiplex control unit and the driver's power window motor.
  11. Check for continuity between driver's power window motor 6P connector terminals No. 3, No. 5, and No. 6 and body ground individually. Is there continuity? YES -Repair a short to ground in the wire(s). NO -Go to step 12.
  12. Test the driver's power window motor hall IC (pulser) test (see «FRONT PASSENGER'S POWER WINDOW MOTOR TEST»(/acura/zdx/i-2009-2013/remont/windows/#power-windows) ). Is the motor OK? YES -Replace the power window master switch (see «REAR POWER WINDOW SWITCH TEST/REPLACEMENT»(/acura/zdx/i-2009-2013/remont/windows/#power-windows) ). NO -Faulty driver's power window motor; replace the driver's door regulator (see «FRONT DOOR GLASS AND REGULATOR REPLACEMENT»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#doors__front-door-glass-and-regulator-replacement) ).

DTC B1130: Front Passenger's Power Window Motor A-Pulse Malfunction; DTC B1131: Front Passenger's Power Window Motor B-Pulse Malfunction

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ). Make sure you reset the power window control unit (see RESETTING THE POWER WINDOW CONTROL UNIT ) whenever you replace or substitute any power window parts.

Scheme 9

Scheme 9: DTC B1130: Front Passenger's Power Window Motor A-Pulse Malfunction; DTC B1131: Front Passenger's Po
Scheme 9: DTC B1130: Front Passenger's Power Window Motor A-Pulse Malfunction; DTC B1131: Front Passenger's Po

Scheme 10

Scheme 10
Scheme 10
  1. Clear the DTCs with the HDS.
  2. Turn the ignition switch to LOCK (0), and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode.
  3. Open and close the front passenger's power window by using the front passenger's power window switch manually.
  4. Check for DTCs with the HDS. Are DTCs B1130 and/or B1131 indicated? YES -Go to step 5. NO -Intermittent failure, the system is OK at this time. Check for loose or poor connections between the front passenger's power window switch and the passenger's power window motor.
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  6. Disconnect the front passenger's power window switch 37P connector.
  7. Disconnect the front passenger's power window motor 6P connector.
  8. Check for continuity between front passenger's power window switch 37P connector terminals No. 26, No. 27, and No. 28 and passenger's power window motor 6P connector terminals No. 5, No. 6, and No. 3 respectively. Is there continuity? YES -Go to step 9. NO -Repair an open or high resistance in the wire(s) between the front passenger's window switch and the front passenger's power window motor.
  9. Check for continuity front passenger's window motor 6P connector between terminals No. 3, No. 5, and No. 6 and body ground individually. Is there continuity? YES -Repair a short to ground in the wire(s). NO -Go to step 10.
  10. Test the front passenger's power window motor hall IC (pulser) test (see «REAR POWER WINDOW MOTOR TEST»(/acura/zdx/i-2009-2013/remont/windows/#power-windows) ). Is the motor OK? YES -Replace the front passenger's power window switch (see «FRONT PASSENGER'S POWER WINDOW SWITCH REPLACEMENT»(/acura/zdx/i-2009-2013/remont/windows/#power-windows) ). NO -Faulty front passenger's power window motor; replace the front passenger's door regulator (see «FRONT DOOR GLASS AND REGULATOR REPLACEMENT»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#doors__front-door-glass-and-regulator-replacement) ).

DTC B1140: Driver's Power Window Position Detect Circuit Malfunction

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ). Make sure you reset the power window control unit (see RESETTING THE POWER WINDOW CONTROL UNIT ) whenever you replace or substitute any power window parts.

  1. Clear the DTCs with the HDS.
  2. Turn the ignition switch to LOCK (0), and then back to ON (II), or press the engine start/stop button to select the OFF mode, and then the ON mode.
  3. Open and close the driver's power window by using the driver's switch manually.
  4. Check for DTCs with the HDS. Is DTC B1125 or B1126 indicated? YES -Troubleshoot DTC B1125 (see «DTC B1125: DRIVER'S POWER WINDOW MOTOR A-PULSE MALFUNCTION; DTC B1126: DRIVER'S POWER WINDOW MOTOR B-PULSE MALFUNCTION»(/acura/zdx/i-2009-2013/remont/windows/#power-windows__dtc-b1125-drivers-power-window-motor) ) or B1126 (see «DTC B1125: DRIVER'S POWER WINDOW MOTOR A-PULSE MALFUNCTION; DTC B1126: DRIVER'S POWER WINDOW MOTOR B-PULSE MALFUNCTION»(/acura/zdx/i-2009-2013/remont/windows/#power-windows__dtc-b1125-drivers-power-window-motor) ). NO -Go to step 5.
  5. Reset the power window control unit (see «RESETTING THE POWER WINDOW CONTROL UNIT»(/acura/zdx/i-2009-2013/remont/windows/#power-windows__resetting-the-power-window-control-unit) ).
  6. Check for DTCs again with the HDS. Is DTC B1140 indicated? YES -Go to step 7. NO -The system has recovered at this time.
  7. Substitute a known-good power window master switch.
  8. Open and close the driver's power window by using the driver's switch manually.
  9. Check for DTCs with the HDS. Is DTC B1140 indicated? YES -Faulty driver's power window motor; replace the driver's door regulator (see «FRONT DOOR GLASS AND REGULATOR REPLACEMENT»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#doors__front-door-glass-and-regulator-replacement) ). NO -Faulty door multiplex control unit; replace the power window master switch (see «REAR POWER WINDOW SWITCH TEST/REPLACEMENT»(/acura/zdx/i-2009-2013/remont/windows/#power-windows) ).

DTC B1142: Door Multiplex Control Unit Lost Communication With Other Units (UART communication error)

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ). Before troubleshooting, make sure the No. 12 (7.5 A), No. 16 (7.5 A) and No. 24 (20 A) fuses in the driver's under-dash fuse/relay box are OK.

Scheme 11

Scheme 11: DTC B1142: Door Multiplex Control Unit Lost Communication With Other Units (UART communication error
Scheme 11: DTC B1142: Door Multiplex Control Unit Lost Communication With Other Units (UART communication error

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14
  1. Clear the DTCs with the HDS.
  2. Turn the ignition switch to LOCK (0), and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode.
  3. Open and close all power windows by using the power window master switch.
  4. Check for DTCs with the HDS. Is DTC B1142 indicated? YES -Go to step 5. NO -Intermittent failure, the system is OK at this time. Check for loose or poor connections.
  5. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  6. Disconnect these items. Power window master switch 37P connector Panoramic glass roof control unit 10P connector Front passenger's power window switch 37P connector
  7. Check for continuity between power window master switch 37P connector terminal No. 27 and front passenger's power windows switch 37P connector terminal No. 29. Is there continuity? YES -Go to step 8. NO -Repair an open or high resistance in the wire.
  8. Check for continuity between power window master switch 37P connector terminal No. 27 and panoramic glass roof control unit/motor 10P connector terminal No. 7. Is there continuity? YES -Go to step 9. NO -Repair an open or high resistance in the wire.
  9. Check for continuity between power window master switch 37P connector terminal No. 27 and body ground. Is there continuity? YES -Repair a short to ground in the wire. NO -Go to step 10.
  10. Reconnect the power window master switch 37P connector.
  11. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  12. Measure the voltage between power window master switch 37P connector terminal No. 27 and body ground. Is there less than 0.2 V? YES -Go to the «FRONT PASSENGER'S POWER WINDOW SWITCH INPUT TEST, AND DO THE POWER AND GROUND INPUT TESTS»(/acura/zdx/i-2009-2013/remont/windows/#power-windows) (see ). If the tests prove OK, substitute a known good front passenger's power window switch. If the DTC goes away, replace the original front passenger's power window switch (see «FRONT PASSENGER'S POWER WINDOW SWITCH REPLACEMENT»(/acura/zdx/i-2009-2013/remont/windows/#power-windows) ). If the DTC is still present, replace the power window master switch (see «REAR POWER WINDOW SWITCH TEST/REPLACEMENT»(/acura/zdx/i-2009-2013/remont/windows/#power-windows) ). NO -Repair a short to power in the wire.

DTC B1145: Front Passenger's Power Window Position Detect Circuit Malfunction

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ). Make sure you reset the power window control unit (see RESETTING THE POWER WINDOW CONTROL UNIT ) whenever you replace or substitute any power window parts.

  1. Clear the DTCs with the HDS.
  2. Turn the ignition switch to LOCK (0), and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode.
  3. Open and close the front passenger's power window by using the front passenger's switch manually.
  4. Check for DTCs with the HDS. Is DTC B1130 or B1131 indicated? YES -Troubleshoot DTC B1130 (see «DTC B1130: FRONT PASSENGER'S POWER WINDOW MOTOR A-PULSE MALFUNCTION; DTC B1131: FRONT PASSENGER'S POWER WINDOW MOTOR B-PULSE MALFUNCTION»(/acura/zdx/i-2009-2013/remont/windows/#power-windows__dtc-b1130-front-passengers-power-window) ) or B1131 (see «DTC B1130: FRONT PASSENGER'S POWER WINDOW MOTOR A-PULSE MALFUNCTION; DTC B1131: FRONT PASSENGER'S POWER WINDOW MOTOR B-PULSE MALFUNCTION»(/acura/zdx/i-2009-2013/remont/windows/#power-windows__dtc-b1130-front-passengers-power-window) ). NO -Go to step 5.
  5. Reset the power window control unit and the front passenger's power window control unit (see «RESETTING THE POWER WINDOW CONTROL UNIT»(/acura/zdx/i-2009-2013/remont/windows/#power-windows__resetting-the-power-window-control-unit) ).
  6. Check for DTCs again with the HDS. Is DTC B1145 indicated? YES -Go to step 7. NO -The system has recovered at this time.
  7. Substitute a known-good passenger's power window switch.
  8. Open and close the front passenger's power window by using the front passenger's switch manually.
  9. Check for DTCs with the HDS. Is DTC B1145 indicated? YES -Faulty front passenger's power window motor; replace the front passenger's door regulator (see «FRONT DOOR GLASS AND REGULATOR REPLACEMENT»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#doors__front-door-glass-and-regulator-replacement) ). NO -Replace the front passenger's power window switch (see «FRONT PASSENGER'S POWER WINDOW SWITCH REPLACEMENT»(/acura/zdx/i-2009-2013/remont/windows/#power-windows) ).

DTC U0155: Door Multiplex Control Unit Lost Communication With Gauge Control Module

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).

Scheme 15

Scheme 15: DTC U0155: Door Multiplex Control Unit Lost Communication With Gauge Control Module
Scheme 15: DTC U0155: Door Multiplex Control Unit Lost Communication With Gauge Control Module

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17
  1. Clear the DTCs with the HDS.
  2. Turn the ignition switch to LOCK (0), and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode.
  3. Wait for at least 6 seconds.
  4. Check for DTCs with the HDS. Is DTC U0155 indicated? YES -Go to step 5. NO -Intermittent failure, the system is OK at this time. Check for loose or poor connections between the door multiplex control unit and the gauge control module.
  5. From the BODY ELECTRICAL SYSTEM SELECT menu, select B-CAN CONTROL UNITS INFORMATION, and then select CHECK CONNECTED CONTROL UNITS. Is the gauge control module detected? YES -Go to step 10 . NO -Go to step 6.
  6. Measure the voltage between body ground and gauge control module connector A (32P) terminals No. 15 and No. 16 individually. Is there battery voltage? YES -Go to step 9 . NO -Go to step 7.
  7. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  8. Check the No. 15 (10 A) fuse in the under-hood fuse/relay box and the No. 12 (7.5 A) fuse in the driver's under-dash fuse/relay box. Are the fuses OK? YES -Repair an open or high resistance in the No. 15 (10 A) and/or No. 12 (7.5 A) fuse circuit. NO -Replace the fuse(s). If the fuse blows again, repair a short to ground on the No. 15 (10 A) and/or No. 12 (7.5 A) fuse circuit.
  9. Measure the voltage between body ground and gauge control module connector A (32P) terminals No. 1 and No. 17 individually. Is there less than 0.2 V? YES -Go to step 10. NO -Repair an open or high resistance in the ground wire(s) or poor ground (G401) and/or (G402).
  10. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  11. Disconnect gauge control module connector A (32P).
  12. Disconnect the power window master switch 37P connector.
  13. Check for continuity between gauge control module connector A (32P) terminals No. 29 and No. 30 and power window master switch 37P connector terminals No. 33 and No. 35 respectively. Is there continuity? YES -Replace the gauge control module (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/zdx/i-2009-2013/remont/gauges-instrument-panels/#gauges__gauge-control-module-replacement) ). NO -Repair an open or poor connection in the B-CAN wire(s) between the door multiplex control unit and the gauge control module.

DTC U0164: Door Multiplex Control Unit Lost Communication With Climate Control Unit

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).

Scheme 18

Scheme 18: DTC U0164: Door Multiplex Control Unit Lost Communication With Climate Control Unit
Scheme 18: DTC U0164: Door Multiplex Control Unit Lost Communication With Climate Control Unit

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20
  1. Clear the DTCs with the HDS.
  2. Turn the ignition switch to LOCK (0), and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode.
  3. Wait for at least 6 seconds.
  4. Check for DTCs with the HDS. Is DTC U0164 indicated? YES -Go to step 5. NO -Intermittent failure, the system is OK at this time. Check for loose or poor connections between the door multiplex control unit and the climate control unit.
  5. From the BODY ELECTRICAL SYSTEM SELECT menu, select B-CAN CONTROL UNITS INFORMATION, and then select CHECK CONNECTED CONTROL UNITS. Is the climate control unit detected? YES -Go to step 10 . NO -Go to step 6.
  6. Measure the voltage between body ground and climate control unit connector A (32P) terminal No. 15. Is there battery voltage? YES -Go to step 9 . NO -Go to step 7.
  7. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  8. Check the No. 16 (7.5 A) fuse in the driver's under-dash fuse/relay box. Is the fuse OK? YES -Repair an open or high resistance in the No. 16 (7.5 A) fuse circuit. NO -Replace the fuse. If the fuse blows again, repair a short to ground on the No. 16 (7.5 A) fuse circuit.
  9. Measure the voltage between body ground and climate control unit connector A (32P) terminal No. 1. Is there less than 0.2 V? YES -Go to step 10. NO -Repair an open or high resistance in the ground wire or poor ground (G403).
  10. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  11. Disconnect climate control unit connector C (20P).
  12. Disconnect the power window master switch 37P connector.
  13. Check for continuity between climate control unit connector C (20P) terminals No. 7 and No. 8 and power window master switch 37P connector terminals No. 33 and No. 35 respectively. Is there continuity? YES -Replace the climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/automatic-hvac-system/#climate-control) ). NO -Repair an open or poor connection in the B-CAN wire(s) between the door multiplex control unit and the climate control unit.

DTC U1282: Door Multiplex Control Unit Lost Communication With Driver's MICU

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).

  1. Clear the DTCs with the HDS.
  2. Turn the ignition switch to LOCK (0), and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode.
  3. Wait for at least 6 seconds.
  4. Check for DTCs with the HDS. Is DTC U1282 indicated? YES -Replace the power window master switch (see «REAR POWER WINDOW SWITCH TEST/REPLACEMENT»(/acura/zdx/i-2009-2013/remont/windows/#power-windows) ). NO -Intermittent failure, the system is OK at this time. Check for loose or poor connections between the door multiplex control unit and the driver's MICU.

DTC U1283: Door Multiplex Control Unit Lost Communication With Passenger's MICU

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).

Scheme 21

Scheme 21: DTC U1283: Door Multiplex Control Unit Lost Communication With Passenger's MICU
Scheme 21: DTC U1283: Door Multiplex Control Unit Lost Communication With Passenger's MICU

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24
  1. Clear the DTCs with the HDS.
  2. Turn the ignition switch to LOCK (0), and then back to ON (II), or press the engine start/stop button to select the OFF mode and then the ON mode.
  3. Wait for at least 6 seconds.
  4. Check for DTCs with the HDS. Is DTC U1283 indicated? YES -Go to step 5. NO -Intermittent failure, the system is OK at this time. Check for loose or poor connections between the door multiplex control unit and the passenger's MICU.
  5. From the BODY ELECTRICAL SYSTEM SELECT menu, select B-CAN CONTROL UNITS INFORMATION, and then select CHECK CONNECTED CONTROL UNITS. Is the passenger's MICU detected? YES -Go to step 10 . NO -Go to step 6.
  6. Measure the voltage between body ground and passenger's under-dash fuse/relay box connector A (38P) terminals No. 14 and No. 35 individually. Is there battery voltage? YES -Go to step 9 . NO -Go to step 7.
  7. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  8. Check the No. 15 (10 A) fuse in the under-hood fuse/relay box and the No. 12 (7.5 A) fuse in the driver's under-dash fuse/relay box. Are the fuses OK? YES -Repair an open or high resistance in the No. 15 (10 A) and/or No. 12 (7.5 A) fuse circuit. NO -Replace the fuse(s). If the fuse blows again, repair a short to ground on the No. 15 (10 A) and/or No. 12 (7.5 A) fuse circuit.
  9. Measure the voltage between body ground and passenger's under-dash fuse/relay box connector A (38P) and E (18P) terminals as shown in illustration. Passenger's under-dash fuse/relay box connector A36 Body ground A37 E15 E16 Is there less than 0.2 V? YES -Go to step 10. NO -Repair an open or high resistance in the ground wire(s) or poor ground (G203), (G402), and/or (G405).
  10. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  11. Disconnect passenger's under-dash fuse/relay box connector A (38P).
  12. Disconnect the power window master switch 37P connector.
  13. Check for continuity between passenger's under-dash fuse/relay box connector A (38P) terminals No. 11 and No. 29 and power window master switch 37P connector terminals No. 35 and No. 33 respectively. Is there continuity? YES -Replace the power window master switch (see «REAR POWER WINDOW SWITCH TEST/REPLACEMENT»(/acura/zdx/i-2009-2013/remont/windows/#power-windows) ). NO -Repair an open or poor connection in the B-CAN wire(s) between the door multiplex control unit and the passenger's MICU.

Power Window Master Switch Input Test

Note. Before testing, troubleshoot the multiplex integrated control unit first, using B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).

Scheme 25

Scheme 25: Power Window Master Switch Input Test
Scheme 25: Power Window Master Switch Input Test
  1. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  2. Open and close the driver's door, then open the door and remove the driver's door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#doors__front-door-panel-removalinstallation) ).
  3. Disconnect the power window master switch 37P connector (A) from the power window master switch (B).
  4. Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 5.
  5. Reconnect the driver's door harness to driver's door subharness.
  6. With the power window master switch 37P connector still disconnected from the power window master switch, do the following input tests: If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 7. Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 12 YEL Connect terminals No. 25 and No. 24 (or No. 12), and terminals No. 12 (or No. 24) and No. 37 with jumper wires Check driver's power window motor operation: The driver's power window should open (or close). Faulty driver's power window motor An open or high resistance in the wire 24 GRN 23 YEL Turn the ignition switch ON (II) or power mode ON, connect terminals No. 25 and No. 36 (or No. 23), and terminals No. 23 (or No. 36) and No. 37 with jumper wires Check left rear power window motor operation: The left rear power window should open (or close). Faulty left rear power window switch Faulty left rear power window motor Poor ground(G601)or an open in the ground wire An open or high resistance in the wire 36 PUR 21 LT BLU Turn the ignition switch ON (II) or power mode ON, connect terminals No. 25 and No. 34 (or No. 21), and terminals No. 21 (or No. 34) and No. 37 with jumper wires Check right rear power window motor operation: The right rear power window should open (or close). Faulty passenger's under-dash fuse/relay box Faulty right rear power window switch Faulty right rear power window motor Poor ground(G652)or an open in the ground wire An open or high resistance in the wire 34 RED 26 LT GRN Connect terminals No. 25 and No. 26 with a jumper wire Check left and right rear power window switch lights: The left and right rear power window switch lights should come on. Faulty left or right rear power window switch Faulty LED Poor ground (G601, G652) or an open in the ground wire An open or high resistance in the wire A short to ground in the wire 27 GRY Disconnect the front passenger's power window switch 37P connector and the panoramic glass roof control unit 10P connector Check for continuity between terminal No. 27 and front passenger's power window switch 37P connector terminal No. 29: There should be continuity. An open in the UART wire Check for continuity between terminal No. 27 and the panoramic glass roof control unit 10P connector terminal No. 7: There should be continuity. An open in the UART wire Check for continuity to ground: There should be no continuity- A short to ground in the UART wire
  7. Reconnect the door multiplex control unit connector to the power window master switch, and do the following input tests: If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, the door multiplex control unit is faulty; replace the power window master switch (see «REAR POWER WINDOW SWITCH TEST/REPLACEMENT»(/acura/zdx/i-2009-2013/remont/windows/#power-windows) ). NOTE: After replacing the power window master switch, reset the power window control unit (see «RESETTING THE POWER WINDOW CONTROL UNIT»(/acura/zdx/i-2009-2013/remont/windows/#power-windows__resetting-the-power-window-control-unit) ). Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 13 WHT Under all conditions Measure the voltage to ground: There should be battery voltage. Blown No. 15 (10 A) fuse in the under-hood fuse/relay box An open or high resistance in the wire 14 LT GRN Ignition switch ON (II), or power mode ON Measure the voltage to ground: There should be battery voltage. Blown No. 16 (7.5 A) fuse in the driver's under-dash fuse/relay box Faulty driver's under-dash fuse/relay box An open or high resistance in the wire 25 WHT Under all conditions Measure the voltage to ground: There should be battery voltage. Blown No. 24 (20 A) fuse in the driver's under-dash fuse/relay box Faulty driver's under-dash fuse/relay box An open or high resistance in the wire 32 BLK In all ignition switch positions or all power modes Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G402) An open or high resistance in the ground wire 37 BLK In all ignition switch positions or all power modes Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G401) An open or high resistance in the ground wire 3 PUR Ignition switch ON (II), or power mode ON Measure the voltage to ground: There should be at least about 10V. Faulty power window master switch A short to ground in the wire 20 ORN Ignition switch ON (II) or power mode ON, and driver's power window moving up or down Measure the voltage between terminals No. 20 and No. 32: An analog meter should alternate between 0 V and about 5 V (a digital voltmeter should read about 2.5 V while the window moves). Faulty power window master switch Faulty driver's power window motor An open or high resistance in the wire A short to ground in the wire 22 PNK Ignition switch ON (II) or power ON, and driver's power window moving up or down Measure the voltage between the terminals No. 22 and No. 32: An analog meter should alternate between 0 V and about 5 V (a digital voltmeter should read about 2.5 V while the window moves). Faulty power window master switch Faulty driver's power window motor An open or high resistance in the wire A short to ground in the wire

Scheme 26

Scheme 26: Front Passenger's Power Window Switch Input Test
Scheme 26: Front Passenger's Power Window Switch Input Test
  1. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  2. Open and close the driver's door, then remove the front passenger's door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#doors__front-door-panel-removalinstallation) ).
  3. Disconnect the front passenger's power window switch 37P connector (A) from the front passenger's power window switch (B).
  4. Inspect the connector and socket terminals to be sure they are all making good contact. If the terminals are bent, loose or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 5.
  5. Reconnect the front passenger's door harness to the front passenger's door subharness.
  6. With the connector still disconnected, do the following input tests: If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, go to step 7. Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 12 RED Connect terminals No. 25 and No. 24 (or No. 12), and terminals No. 12 (or No. 24) and No. 37 with jumper wires Check front passenger's power window motor operation: The front passenger's power window should open (or close). Faulty front passenger's power window motor An open or high resistance in the wire 24 BLU 29 GRY Disconnect the power window master switch 37P connector and the panoramic glass roof control unit 10P connector Check for continuity between terminal No. 29 and power window master switch 37P connector terminal No. 27: There should be continuity. An open in the UART wire Check for continuity between terminal No. 29 and the panoramic glass roof control unit 10P connector terminal No. 7: There should be continuity. An open in the UART wire Check for continuity to ground: There should be no continuity. A short to ground in the UART wire
  7. Reconnect the front passenger's power window switch connector to the front passenger's power window switch, and do the following input tests: If any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, replace the front passenger's power window switch (see «FRONT PASSENGER'S POWER WINDOW SWITCH REPLACEMENT»(/acura/zdx/i-2009-2013/remont/windows/#power-windows) ). NOTE: After replacing the front passenger's power window switch, reset the power window control unit (see «RESETTING THE POWER WINDOW CONTROL UNIT»(/acura/zdx/i-2009-2013/remont/windows/#power-windows__resetting-the-power-window-control-unit) ). Cavity Wire Test condition Test: Desired result Possible cause if desired result is not obtained 25 GRN Under all conditions Measure the voltage to ground: There should be battery voltage. Blown No. 1-2 (AS F/B STD) (40 A) fuse in the under-hood fuse/relay box Blown No. 13 (20 A) fuse in the passenger's under-dash fuse/relay box Faulty under-hood fuse/relay box Faulty passenger's under-dash fuse/relay box An open or high resistance in the wire 36 BLK In all ignition switch positions or all power modes, disconnect the front passenger's power window motor 6P connector Measure the voltage to ground: There should be less than 0.2 V. Poor ground (G405) An open or high resistance in the ground wire 37 BLK In all ignition switch positions or all power modes Measure the voltage to ground: There should be less than 0.2 V. Poor ground(G405) An open or high resistance in the ground wire 26 PUR Ignition switch ON (II), or power mode ON Measure the voltage to ground: There should be at least about 10V. Faulty front passenger's power window switch A short to ground in the wire 27 PNK Ignition switch ON (II) or power mode ON, and front passenger's power window switch moving up or down Measure the voltage between terminals No. 27 and No. 36: An analog meter should alternate between 0 V and about 5 V (a digital voltmeter should read about 2.5 V while the window moves). Faulty front passenger's power window switch Faulty front passenger's power window motor An open or high resistance in the wire A short to ground in the wire 28 ORN Ignition switch ON (II) or power mode ON, and front passenger's power window switch moving up or down Measure the voltage between terminals No. 28 and No. 36: An analog meter should alternate between 0 V and about 5 V (a digital voltmeter should read about 2.5 V while the window moves). Faulty front passenger's power window switch Faulty front passenger's power window motor An open or high resistance in the wire A short to ground in the wire

Scheme 27

Scheme 27: Motor Test
Scheme 27: Motor Test

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31
  1. Remove the driver's door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#doors__front-door-panel-removalinstallation) ).
  2. Disconnect the driver's door wire harness connectors (A) from the driver's door subharness.
  3. At the driver's door wire harness 28P connector, test the driver's power window motor in each direction by connecting battery power and ground according to the table. When the motor stops running, disconnect one lead immediately.
  4. If the motor does not run or fails to run smoothly, go to step 5; if the motor runs smoothly, go to step 8 .
  5. Disconnect the 6P connector (A) from the driver's power window motor (B).
  6. Check for continuity between driver's door harness 28P connector terminals No. 2 and No. 15, and driver's power window motor 6P connector terminals No. 1 and No. 4 respectively. There should be continuity. DRIVER'S DOOR HARNESS 28P CONNECTOR DRIVER'S POWER WINDOW MOTOR 6P CONNECTOR No. 2 No. 1 No. 15 No. 4
  7. If there is no continuity, repair an open or high resistance in the wire(s). If the wire harness is OK, the driver's power window motor is faulty, replace the driver's door regulator (see «FRONT DOOR GLASS AND REGULATOR REPLACEMENT»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#doors__front-door-glass-and-regulator-replacement) ).
  8. Check for continuity between driver's power window motor 6P connector terminal No. 2 and body ground. There should be continuity. If there is continuity, go to step 9. If there is no continuity, check for an open or high resistance in the BLK wire or poor ground (G402).
  9. Do the power window master switch input test terminals No. 3, No. 20, and No. 22 (see «POWER WINDOW MASTER SWITCH INPUT TEST»(/acura/zdx/i-2009-2013/remont/windows/#power-windows__power-window-master-switch-input-test) ).

Scheme 32

Scheme 32: Motor Test
Scheme 32: Motor Test

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36
  1. Remove the front passenger's door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#doors__front-door-panel-removalinstallation) ).
  2. At the front passenger's door wire harness 28P connector, test the front passenger's power window motor in each direction by connecting battery power and ground according to the table. When the motor stops running, disconnect one lead immediately.
  3. If the motor does not run or fails to run smoothly, go to step 4; if the motor runs smoothly, go to step 7 .
  4. Disconnect the 6P connector (A) from the front passenger's power window motor (B).
  5. Check for continuity between front passenger's door harness 28P connector terminals No. 15 and No. 16, and front passenger's power window motor 6P connector terminals No. 4 and No. 1 respectively. There should be continuity. FRONT PASSENGERS DOOR HARNESS 28P CONNECTOR FRONT PASSENGER'S POWER WINDOW MOTOR 6P CONNECTOR No. 15 No. 4 No. 16 No. 1
  6. If there is no continuity, repair an open or high resistance in the wire(s). If the wire harness is OK, the front passenger's power window motor is faulty, replace the front passenger's door regulator (see «FRONT DOOR GLASS AND REGULATOR REPLACEMENT»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#doors__front-door-glass-and-regulator-replacement) ). Hall IC Unit (Pulser) Test
  7. Check for continuity between front passenger's power window motor 6P connector terminal No. 2 and body ground. There should be continuity. If there is continuity, go to step 8. If there is no continuity, check for an open or high resistance in the BLK wire or poor ground (G405).
  8. Do the front passenger's power window switch input test terminals No. 26, No. 27, and No. 28 (see «FRONT PASSENGER'S POWER WINDOW SWITCH INPUT TEST»(/acura/zdx/i-2009-2013/remont/windows/#power-windows) ).

Scheme 37

Scheme 37: Rear Power Window Motor Test
Scheme 37: Rear Power Window Motor Test

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40
  1. Remove the rear door panel (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#doors__rear-door-panel-removalinstallation) ).
  2. Test the rear power window motor in each direction by connecting battery power and ground to the rear power window switch 14P connector (A) according to the table.
  3. If the motor does not run or fails to run smoothly, go to step 4.
  4. Disconnect the 2P connector (A) from the rear power window motor (B).
  5. Check for continuity between rear power window switch 14P connector terminals No. 1 and No. 7, and rear power window motor 2P connector terminals No. 1 and No. 2 respectively. There should be continuity. REAR POWER WINDOW SWITCH 14P CONNECTOR REAR POWER WINDOW MOTOR 2P CONNECTOR No. 1 No. 1 No. 7 No. 2
  6. If there is no continuity, repair an open or high resistance in the wire(s). If the wire harness is OK, the rear power window motor is faulty, replace the rear door regulator (see «REAR DOOR GLASS AND REGULATOR REPLACEMENT»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#doors__rear-door-glass-and-regulator-replacement) ).

Scheme 41

Scheme 41: Rear Power Window Switch Test/Replacement
Scheme 41: Rear Power Window Switch Test/Replacement
  1. Remove the rear door panel (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#doors__rear-door-panel-removalinstallation) ).
  2. Remove the three screws (A) and rear power window switch (B) from the armrest assembly (C).
  3. Swap the rear power window switch with another known-good power window switch and test. If the original power window switch is faulty; replace it.
  4. Install the switch in the reverse order of removal.

Scheme 42

Scheme 42: Power Window Master Switch Replacement
Scheme 42: Power Window Master Switch Replacement
  1. Remove the driver's power window switch panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#doors__front-door-panel-removalinstallation) ).
  2. Remove the four screws (A), then remove the power window master switch (B) from the power window switch panel assembly (C).
  3. Install the switch in the reverse order of removal.
  4. After replacement, reset the power window control unit (see «RESETTING THE POWER WINDOW CONTROL UNIT»(/acura/zdx/i-2009-2013/remont/windows/#power-windows__resetting-the-power-window-control-unit) ).

Scheme 43

Scheme 43: Front Passenger's Power Window Switch Replacement
Scheme 43: Front Passenger's Power Window Switch Replacement
  1. Remove the front passenger's power window switch panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/zdx/i-2009-2013/remont/exterior-body-panels/#doors__front-door-panel-removalinstallation) ).
  2. Remove the four screws (A), then remove the front passenger's power window switch (B) from the power window switch panel assembly (C).
  3. Install the switch in the reverse order or removal.
  4. After replacement, reset the power window control unit (see «RESETTING THE POWER WINDOW CONTROL UNIT»(/acura/zdx/i-2009-2013/remont/windows/#power-windows__resetting-the-power-window-control-unit) ).

More articles — Accessories & Equipment
