Engine Block (4-cyl) — Acura TSX II (2008-2014)

Special Tools

Engine Block

Ref. No.	Tool Number	Description	Qty
1	07746-0010700	Attachment, 24 x 26 mm	1
2	07749-0010000	Driver Handle, 15 x135L	1
3	07ZAD-PNAA100	Oil Seal Driver Attachment, 96 mm	1

SPECIAL TOOLS CHART

Scheme 600

Scheme 601

Scheme 601: Component Location Index

Scheme 602

Scheme 603

Scheme 603: Connecting Rod and Crankshaft End Play Inspection

Scheme 604

Remove the oil pump (see «OIL PUMP REMOVAL»(/acura/tsx/ii-2008-2014/remont/lubrication-system/#engine-lubrication-4-cyl) ).
Remove the baffle plate (see step 10 on «CRANKSHAFT AND PISTON REMOVAL»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ).
Measure the connecting rod end play with a feeler gauge (A) between the connecting rod (B) and the crankshaft (C). Connecting Rod End Play Standard (New): 0.15-0.35 mm (0.0059-0.0138 in) Service Limit: 0.40 mm (0.0157 in)
If the connecting rod end play is beyond the service limit, install a new connecting rod, and recheck. If it is still beyond the service limit; replace the crankshaft (see «CRANKSHAFT AND PISTON REMOVAL»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ).
Push the crankshaft firmly away from the dial indicator by prying, and zero the dial against the end of the crankshaft. Then pull the crankshaft firmly back toward the indicator by prying; the dial reading should not exceed the service limit. Crankshaft End Play Standard (New): 0.10-0.35 mm (0.0039-0.0138 in) Service Limit: 0.45 mm (0.0177 in)
If the crankshaft end play is beyond the service limit, replace the thrust washers and recheck, if it is still beyond the service limit, replace the crankshaft (see «CRANKSHAFT AND PISTON REMOVAL»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ).

Scheme 605

Scheme 605: Main Bearing Clearance Inspection

Scheme 606

To check main bearing-to-journal oil clearance, remove the lower block and the bearing halves (see «CRANKSHAFT AND PISTON REMOVAL»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ).
Clean each main journal and the bearing half with a clean shop towel.
Place one strip of plastigage across each main journal.
Reinstall the main bearings and the lower block, then torque the bolts to 29 N.m (3.0 kgf.m, 22 lbf.ft). NOTE: Apply new engine oil to the bolt threads and flanges. Do not rotate the crankshaft during inspection.
Tighten the bearing cap bolts an additional 48°.
Remove the lower block and the main bearings again, and measure the widest part of the plastigage. Main Bearing-to-Journal Oil Clearance No. 1, 2, 4, 5 Journals: Standard (New): 0.017-0.041 mm (0.00067-0.00161 in) Service Limit: 0.050 mm (0.00197 in) No. 3 Journal: Standard (New): 0.025-0.049 mm (0.00098-0.00193 in) Service Limit: 0.055 mm (0.00217 in)
If the plastigage measures too wide or too narrow, remove the crankshaft, and remove the upper half of the bearing. Install a new, complete bearing with the appropriate color code(s), and recheck the clearance. Do not file, shim, or scrape the bearings or the caps to adjust clearance.
If the plastigage shows the clearance is still incorrect, try the next larger or smaller bearing (the color listed above or below the current one), and check again. If the proper clearance cannot be obtained by using the appropriate larger or smaller bearings, replace the crankshaft and start over (see «CRANKSHAFT AND PISTON REMOVAL»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ).

Scheme 607

Scheme 607: Crankshaft Bore Code Location

Numbers, letters, or bars have been stamped on the end of the lower block as a code for the size of each of the five main journal bores. Write down the block bore codes. If you cannot read the codes because of accumulated dirt and dust, do not scrub them with a wire brush or scraper. Clean them only with solvent or detergent.

Scheme 608

Scheme 608: Main Journal Code Location

The main journal codes are stamped on the crankshaft in either location

Scheme 609

Use the block bore codes and the main journal codes to select the appropriate replacement bearings from the following table. NOTE: Color code is on the edge of the bearing. When using bearing halves of different colors, it does not matter which color is used in the top or bottom.

Scheme 610

Scheme 610: Connecting Rod Bearing Clearance Inspection

Remove the oil pump (see «OIL PUMP REMOVAL»(/acura/tsx/ii-2008-2014/remont/lubrication-system/#engine-lubrication-4-cyl) ).
Remove the baffle plate (see step 10 on «CRANKSHAFT AND PISTON REMOVAL»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ).
Remove the connecting rod cap and the bearing half (see «CRANKSHAFT AND PISTON REMOVAL»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ).
Clean the connecting rod journal and the bearing half with a clean shop towel.
Place plastigage across the connecting rod journal.
Reinstall the bearing half and the connecting rod cap, then torque the bolts to 41 N.m (4.2 kgf.m, 30 lbf.ft) + 120°. NOTE: Apply new engine oil to the bolt threads and flanges. Do not rotate the crankshaft during inspection.
Remove the connecting, rod cap and the bearing half, and measure the widest part of the plastigage. Connecting Rod Bearing-to-Journal Oil Clearance Standard (New): 0.032-0.066 mm (0.00126-0.00260 in) Service Limit: 0.077 mm (0.00303 in)
If the plastigage measures too wide or too narrow, remove the cap, and the upper half of the bearing. Install a new, complete bearing with the appropriate color code(s), and recheck the clearance. Do not file, shim, or scrape the bearings or the caps to adjust clearance.
If the plastigage shows the clearance is still incorrect, try the next larger or smaller bearing (the color listed above or below the current one), and check the clearance again. If the proper clearance cannot be obtained by using the appropriate larger or smaller bearings, replace the crankshaft and start over (see «CRANKSHAFT AND PISTON REMOVAL»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ).

Scheme 611

Scheme 611: Connecting Rod Bearing Selection

Scheme 612

Inspect each connecting rod for cracks and heat damage. Big End Bore Code Locations
Each connecting rod has a tolerance range from 0 to 0.024 mm (0.00094 in), in 0.006 mm (0.00024 in) increments, depending on the size of its big end bore. It's then stamped with a number or bar (1, 2, 3, or 4/1, II, III, or IIII) indicating the range. You may find any combination of numbers and bars in any engine. (Half the number or bar is stamped on the rod cap, the other half is on the connecting rod.) If you cannot read the code because of an accumulation of oil and varnish, do not scrub it with a wire brush or scraper. Clean it only with solvent or detergent. Big End Bore Size: 51.0 mm (2.008 in) Connecting Rod Journal Code Location
The connecting rod journal codes are stamped on the crankshaft in either location.
Use the big end bore codes and the rod journal codes to select appropriate replacement bearings from the following table.

Note. Color code is on the edge of the bearing. When using bearing halves of different colors, it does not matter which color is used in the top or bottom.

Scheme 613

Scheme 613: Oil Pan Removal

Scheme 614

Scheme 615

Scheme 616

Scheme 617

Scheme 618

Scheme 619

If the engine is already out of the vehicle, go to step 13 .
Disconnect the vacuum hose (A) and remove the front engine mount stop (B), then remove the front engine mount bolt (C).
Raise the vehicle on the lift.
Remove the left front wheel.
Remove the front splash shield (see step 22 on «ENGINE INSTALLATION»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-assembly-4-cyl__engine-installation) ).
Drain the engine oil (see «ENGINE OIL REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/lubrication-system/#engine-lubrication-4-cyl) ).
Remove the left side damper fork (see step 4 on «LOWER ARM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/suspension-front/#front-suspension-4-cyl__lower-arm-removalinstallation) ).
Separate the left side knuckle from the lower arm (see step 6 on «COMPLIANCE BUSHING REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/suspension-front/#front-suspension-4-cyl) ).
Remove the left side driveshaft (see step 9 on «DRIVESHAFT DISASSEMBLY»(/acura/tsx/ii-2008-2014/remont/axle-shafts/#drivelineaxle-4-cyl__driveshaft-disassembly) ). Coat all precision-finished surface with new engine oil. Tie a plastic bag over the driveshaft end.
Remove the lower transmission mount bracket mounting bolts and nuts. M/T model A/T model
A/T model: Remove the shift cable cover.
Use a transmission jack to lift the transmission 30-40 mm (1.18-1.57 in).
Remove the clutch case cover (A) and the transmission mounting bolts (B).
Remove the bolts securing the oil pan.
Using a flat blade screwdriver, separate the oil pan from the engine block in the places shown.
Remove the oil pan.

Scheme 620

Scheme 620: Crankshaft and Piston Removal

Scheme 621

Scheme 622

Scheme 623

Scheme 624

Scheme 625

Scheme 626

Scheme 627

Remove the engine/transmission (see «ENGINE REMOVAL»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-assembly-4-cyl__engine-removal) ).
Remove the transmission: Manual transmission (see «TRANSMISSION REMOVAL»(ref-475400-S16147244732012052300000) ) Automatic transmission (see «TRANSMISSION REMOVAL»(/acura/tsx/ii-2008-2014/remont/automatic-trans/#automatic-transmission-4-cyl) )
M/T model: Remove the pressure plate, the clutch disc, and the flywheel (see «CLUTCH REPLACEMENT»(ref-475402-S25382859502012052300000) ).
A/T model: Remove the drive plate (see «DRIVE PLATE REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-trans/#automatic-transmission-4-cyl) ).
Remove the CKP sensor cover (A), then disconnect the CKP sensor connector (B).
Remove the harness holder (C).
Remove the oil pan (see «OIL PAN REMOVAL»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ).
Remove the oil pump (see «OIL PUMP REMOVAL»(/acura/tsx/ii-2008-2014/remont/lubrication-system/#engine-lubrication-4-cyl) ).
Remove the cylinder head (see «CYLINDER HEAD REMOVAL»(/acura/tsx/ii-2008-2014/remont/mechanical/#cylinder-head-4-cyl__cylinder-head-removal) ).
Remove the baffle plate
Remove the 8 mm bolts.
Remove the bearing cap bolts. To prevent warpage, loosen the bolts in sequence 1/3 turn at a time; repeat the sequence until all bolts are loosened.
Remove the lower block and the bearings. Keep all the bearings in order.
Remove the rod caps/bearings. Keep all the caps/bearings in order.
Lift the crankshaft (A) out of the engine. Be careful not to damage the journals and the CKP pulse plate (B).
Remove the CKP pulse plate from the crankshaft.
Remove the thrust washers (C).
Remove the upper bearing halves from the connecting rods, and set them aside with their respective caps.
If you can feel a ridge of metal or hard carbon around the top of each cylinder, remove it with a ridge reamer (A). Follow the reamer manufacturer's instructions. If the ridge is not removed, it may damage the piston as it is pushed out.
Use the wooden handle of a hammer (A) to drive out the piston/connecting rod assembly (B).
Reinstall the lower block and the bearings on the engine block in the proper order.
Reinstall the connecting rod bearings and the caps after removing each piston/connecting rod assembly.
Mark each piston/connecting rod assembly with its cylinder number to make sure they are reinstalled in the original order.

Note. The existing number on the connecting rod does not indicate its position in the engine, it indicates the rod bore size.

Scheme 628

Scheme 628: Out-of-Round and Taper

Remove the crankshaft from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ).
Remove the CKP pulse plate from the crankshaft (see «CKP PULSE PLATE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ).
Clean the crankshaft oil passages with pipe cleaners or a suitable brush.
Check the keyway slot and the threaded holes for damage.
Measure the out-of-round at the middle of each rod and the main journal in two places. The difference between measurements on each journal must not be more than the service limit. Journal Out-of-Round Standard (New): 0.004 mm (0.00016 in) max. Service Limit: 0.010 mm (0.00039 in)
Measure the taper at the edges of each rod and the main journal. The difference between measurements on each journal must not be more than the service limit. Journal Taper Standard (New): 0.005 mm (0.00020 in) max. Service Limit: 0.010 mm (0.00039 in) Straightness
Place the V-blocks on a flat surface.
Check the total runout with the crankshaft supported on V-blocks.
Measure the runout on all of the main journals. Rotate the crankshaft two complete revolutions. The difference between measurements on each journal must not be more than the service limit.

Crankshaft Total Runout

Standard (New): 0.03 mm (0.0012 in) max.

Service Limit: 0.04 mm (0.0016 in)

Scheme 629

Scheme 630

Scheme 630: Block and Piston Inspection

Scheme 631

Scheme 632

Scheme 633

Scheme 634

Remove the pistons from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ).
Check the pistons for distortion or cracks.
Measure the piston diameter at a point 13 mm (0.51 in) from the bottom of the skirt. There are two standard-size pistons (No Letter or A, and B). The letter is stamped on the top of the piston. Letters are also stamped on the engine block as the cylinder bore sizes. Piston Skirt Diameter Standard (New): No Letter (or A): 86.980-86.990 mm (3.42440-3.42480 in) B: 86.970-86.980 mm (3.42401-3.42440 in) Service Limit: No Letter (or A): 86.930 mm (3.42243 in) B: 86.920 mm (3.42204 in) Oversize Piston Skirt Diameter 0.25: 87.230-87.240 mm (3.43425-3.43464 in)
Measure the wear and taper in direction X and Y at three levels inside each cylinder as shown. If measurements in any cylinder are beyond the oversize bore service limit, replace the engine block. If the engine block is being rebored, refer to step 7 after reboring. Cylinder Bore Size Standard (New): A or I: 87.010-87.020 mm (3.42558-3.42598 in) B or II: 87.000-87.010 mm (3.42519-3.42558 in) Service Limit: 87.070 mm (3.42795 in) Oversize Bore 0.25: 87.250-87.260 mm (3.43503-3.43543 in) Reboring Limit: 0.25 mm (0.0098 in) max. Bore Taper Limit (Difference between first and third measurement): 0.05 mm (0.0020 in)
Hone any scored or scratched cylinder bores (see «CYLINDER BORE HONING»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ).
Check the top of the engine block for warpage. Measure along the edges and across the center as shown. Engine Block Warpage Standard (New): 0.07 mm (0.0028 in) max.
Calculate the difference between the cylinder bore diameter and the piston diameter. If the clearance is near or exceeds the service limit, inspect the piston and the cylinder bore for excessive wear.

Piston-to-Cylinder Bore Clearance

Standard (New): 0.020-0.040 mm (0.00079-0.00157 in)

Service Limit: 0.05 mm (0.0020 in)

Scheme 635

Scheme 636

Scheme 636: Cylinder Bore Honing

Measure the cylinder bores (see «BLOCK AND PISTON INSPECTION»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ). If the engine block is to be reused, hone the cylinders, and remeasure the bores. Only a scored or scratched cylinder bore must be honed.
Remove the oil jets (see «OIL JET REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/lubrication-system/#engine-lubrication-4-cyl) ).
Hone the cylinder bores with honing oil and a fine (400 grit) stone in a 60 degree cross-hatch pattern (A). NOTE: Use only a rigid hone with 400 grit or finer stone such as Sunnen, Ammco, or equivalent. Do not use stones that are worn or broken.
When honing is complete, thoroughly clean the engine block of all metal particles. Wash the cylinder bores with hot soapy water, then dry and oil them immediately to prevent rusting. NOTE: Never use solvent, it will only redistribute the grit on the cylinder walls.
If scoring or scratches are still present in the cylinder bores after honing to the service limit, rebore the engine block. Some light vertical scoring and scratching is acceptable if it is not deep enough to catch your fingernail, and does not run the full length of the bore.
Install the oil jets (see «OIL JET REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/lubrication-system/#engine-lubrication-4-cyl) ).

Scheme 637

Scheme 637: Disassembly

Scheme 638

Remove the piston from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ).
Apply new engine oil to the piston pin snap rings (A), and turn them in the ring grooves until the end gaps are lined up with the cutouts in the piston pin bores (B). NOTE: Take care not to damage the ring grooves.
Remove the snap rings (A) from both sides of each piston. Start at the cutout in the piston pin bore. Remove the snap rings carefully so they do not go flying or get lost. Wear eye protection.
Heat the piston and the connecting rod assembly to about 158°F (70°C), then remove the piston pin.

Scheme 639

Inspection

Note. Inspect the piston, the piston pin, and the connecting rod when they are at room temperature.

Scheme 640

Scheme 640: Inspection

Scheme 641

Scheme 642

Measure the diameter of the piston pin. Piston Pin Diameter Standard (New): 21.961-21.965 mm (0.86460-0.86476 in) Service Limit: 21.953 mm (0.86429 in)
Zero the dial indicator to the piston pin diameter.
Check the difference between the piston pin diameter and the piston pin hole diameter in the piston. Piston Pin-to-Piston Clearance Standard (New): -0.005-0.002 mm (-0.00020-0.00008 in) Service Limit: 0.005 mm (0.00020 in)
Measure the piston pin-to-connecting rod clearance.

Piston Pin-to-Connecting Rod Clearance Standard (New): 0.005-0.015 mm (0.00020-0.00059 in)

Service Limit: 0.02 mm (0.0008 in)

Scheme 643

Scheme 644

Scheme 644: Reassembly

Scheme 645

Scheme 646

Install a piston pin snap ring (A) only on one side.
Coat the piston pin bore in the piston, the bore in the connecting rod, and the piston pin with new engine oil.
Heat the piston to about 158°F (70°C).
Assemble the piston (A) and the connecting rod (B) with the arrow (C) and the embossed mark (D) on the same side. Install the piston pin (E).
Install the remaining snap ring (F).
Turn the snap rings in the ring grooves until the end gaps are positioned at the bottom of the piston.

Scheme 647

Scheme 647: Piston Ring Replacement

Scheme 648

Scheme 649

Scheme 650

Remove the piston from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ).
Using a ring expander (A), remove the old piston rings (B).
Clean all ring grooves thoroughly with a squared-off broken ring or a ring groove cleaner with a blade to fit the piston grooves. The top and second ring grooves are 1.2 mm (0.047 in) wide. The oil ring groove is 2.0 mm (0.079 in) wide. The top ring groove is 1.2 mm (0.047 in) wide. The second ring groove is 1.0 mm (0.039 in) wide. The oil ring groove is 2.0 mm (0.079 in) wide. File down a blade if necessary. Do not use a wire brush to clean the ring grooves, or cut the ring grooves deeper with the cleaning tools. NOTE: If the piston is to be separated from the connecting rod, do not install the new rings yet.
Using a piston that has its rings removed, push a new ring (A) into the cylinder bore 15-20 mm (0.59-0.79 in) from the bottom.
Measure the piston ring end-gap (B) with a feeler gauge: If the gap is too small, check to see if you have the proper rings for your engine. If the gap is too large, recheck the cylinder bore diameter against the wear limits (see «BLOCK AND PISTON INSPECTION»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ). If the bore is beyond the service limit, the engine block must be rebored. Piston Ring End-Gap Top Ring: Standard (New): 0.20-0.30 mm (0.0079-0.0118 in) Service Limit: 0.55 mm (0.0217 in) Second Ring: Standard (New): 0.20-0.32 mm (0.0079-0.0126 in) Service Limit: 0.42 mm (0.0165 in) Oil Ring (RIKEN): Standard (New): 0.20-0.50 mm (0.0079-0.0197 in) Service Limit: 0.55 mm (0.0217 in)
Install the top ring and the second ring as shown. The top ring (A) has a 1R mark, and the second ring (B) has a 2R mark. The manufacturing marks (C) must face upward.
After installing a new set of rings, measure the ring-to-groove clearances. Top Ring Clearance Standard (New): 0.060-0.085 mm (0.00236-0.00335 in) Service Limit: 0.13 mm (0.0051 in) Second Ring Clearance Standard (New): 0.020-0.045 mm (0.00079-0.00177 in) Service Limit: 0.13 mm (0.0051 in)
Rotate the rings in their grooves to make sure they do not bind.
Position the ring end gaps as shown.

Scheme 651

Piston Installation

If the Crankshaft is Already Installed

Scheme 652

Scheme 652: Piston Installation

Scheme 653

Set the crankshaft to bottom dead center (BDC) for each cylinder as its piston is installed.
Remove the connecting rod caps, then install the ring compressor, and check that the bearing is securely in place.
Apply new engine oil to the piston, the inside of the ring compressor, and the cylinder bore, then attach the ring compressor to the piston/connecting rod assembly.
Position the mark (A) to face the cam chain side of the engine block.
Position the piston in the cylinder, and tap it in using the wooden handle of a hammer (A). Push down on the ring compressor (B) to prevent the rings from expanding before entering the cylinder bore.
Stop after the ring compressor pops free, and check the connecting rod-to-rod journal alignment before pushing the piston into place.
Check the connecting rod bearing clearance with plastigage (see «CONNECTING ROD BEARING REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ).
Inspect the connecting rod bolts (see «CONNECTING ROD BOLT INSPECTION»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ).
Apply new engine oil to the bolt threads, then install the connecting rod caps with bearings. Torque the bolts to 41 N.m (4.2 kgf.m, 30 lbf.ft).
Tighten the connecting rod bolts an additional 120°.

Note. Remove the connecting rod bolt if you tightened it beyond the specified angle, and go back to step 8 of the procedure. Do not loosen it back to the specified angle. Repeat steps 1 to 10 for the remaining cylinders.

Scheme 654

If the Crankshaft is Not Installed

Scheme 655

Scheme 656

Remove the connecting rod caps, then install the ring compressor, and check that the bearing is securely in place.
Apply new engine oil to the piston, the inside of the ring compressor, and the cylinder bore, then attach the ring compressor to the piston/connecting rod assembly.
Position the mark (A) to face the cam chain side of the engine block.
Position the piston in the cylinder, and tap it in using the wooden handle of a hammer (A). Push down on the ring compressor (B) to prevent the rings from expanding before entering the cylinder bore.
Position all pistons at top dead center (TDC).

Scheme 657

Scheme 657: Connecting Rod Bolt Inspection

Measure the diameter of each connecting rod bolt at point A and point B.
Calculate the difference in diameter between point A and point B. Point A-Point B = Difference in Diameter Difference in Diameter Specification: 0-0.1 mm (0-0.004 in)
If the difference in diameter is out of specification, replace the connecting rod bolt.

Crankshaft Installation

Special Tools Required

Driver Handle, 15 x 135L 07749-0010000
Bearing Driver Attachment, 24 x 26 mm 07746-0010700
Oil Seal Driver Attachment, 96 mm 07ZAD-PNAA100

Scheme 658

Scheme 659

Scheme 660

Scheme 661

Scheme 662

Scheme 663

Scheme 664

Scheme 665

Scheme 666

Scheme 667

Scheme 668

Scheme 669

M/T model: Install the crankshaft end bushing when replacing the crankshaft. Using the driver, handle, 15 x 135L and the bearing driver attachment, 24 x 26 mm, drive in the crankshaft end bushing until the driver handle and the bearing driver attachment bottom against the crankshaft.
Check the main bearing clearance with plastigage (see «CRANKSHAFT MAIN BEARING REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ).
Check the connecting rod bearing clearance with plastigage (see «CONNECTING ROD BEARING REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ).
Install the bearing halves in the engine block and the connecting rods.
Apply a coat of new engine oil to the main bearings and the connecting rod bearings.
Install the CKP pulse plate (A) to the crankshaft.
Hold the crankshaft (B) so rod journal No. 2 and rod journal No. 3 are straight up, and lower the crankshaft into the engine block. Be careful not to damage the journals and the CKP pulse plate.
Apply new engine oil to the thrust washer surfaces. Install the thrust washers (A) in the No. 4 journal of the engine block.
Inspect the connecting rod bolts (see «CONNECTING ROD BOLT INSPECTION»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ).
Apply new engine oil to the threads of the connecting rod bolts.
Seat the rod journals into connecting rod No. 1 and connecting rod No. 4. Line up the mark (B) on the connecting rod and the cap, then install the caps and bolts finger-tight.
Rotate the crankshaft clockwise, and seat the journals into connecting rod No. 2 and connecting rod No. 3. Line up the mark on the connecting rod and the cap, then install the caps and bolts finger-tight.
Torque the connecting rod bolts to 41 N.m (4.2 kgf.m, 30 Lbf.ft).
Tighten the connecting rod bolts an additional 120°. NOTE: Remove the connecting rod bolt if you tightened it beyond the specified angle, and go back to step 9 of the procedure. Do not loosen it back to the specified angle.
Remove all of the old liquid gasket from the lower block mating surfaces, the bolts, and the bolt holes.
Clean and dry the lower block mating surfaces.
Apply liquid gasket (P/N 08717-0004, 08718-0003, or 08718-0009) to the engine block mating surface of the lower block and to the inside edge of the threaded bolt holes. Install the component within 5 minutes of applying the liquid gasket. NOTE: Apply a 2.5 mm (0.098 in) diameter bead of liquid gasket along the broken line (A). If too much time has passed after applying the liquid gasket, remove the old liquid gasket and residue, then reapply new liquid gasket.
Put the lower block on the engine block.
Apply new engine oil to the threads of the bearing cap bolts. Torque the bearing cap bolts in sequence, to 29 N.m (3.0 kgf.m, 22 lbf.ft).
Tighten the bearing cap bolts an additional 48°.
Torque the 8 mm bolts in sequence to 22 N.m (2.2 kgf.m, 16 lbf.ft). NOTE: Wait at least 30 minutes before filling the engine with oil. Do not run the engine for at least 3 hours after installing the lower block.
Apply a light coat of new engine oil to the lip of the crankshaft oil seal.
Use the driver handle, 15 x 135L and the oil seal driver attachment, 96 mm to drive a new crankshaft oil seal (A) squarely into the engine block to the specified installed height.
Clean the excess oil off the crankshaft, and check that the oil seal lip is not distorted.
Measure the distance between the engine block (A) and the crankshaft oil seal (B). Crankshaft Oil Seal Installed Height 0.2-1.2 mm (0.008-0.047 in)
Install the baffle plate.
Install the oil pump (see «OIL PUMP INSTALLATION»(/acura/tsx/ii-2008-2014/remont/lubrication-system/#engine-lubrication-4-cyl) ).
Install the oil pan (see «CKP PULSE PLATE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ).
Install the cylinder head (see «CYLINDER HEAD INSTALLATION»(/acura/tsx/ii-2008-2014/remont/mechanical/#cylinder-head-4-cyl) ).
install the harness holder
Connect the CKP sensor connector (B), then install the CKP sensor cover (C).
M/T model: Install the flywheel, the clutch disc, and the pressure plate (see «CLUTCH REPLACEMENT»(ref-475402-S25382859502012052300000) ).
A/T model: Install the drive plate (see «DRIVE PLATE REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-trans/#automatic-transmission-4-cyl) ).
Install the transmission: Manual transmission (see «TRANSMISSION INSTALLATION»(ref-475400-S31595137952012052300000) ) Automatic transmission (see «TRANSMISSION INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-trans/#automatic-transmission-4-cyl) )
Install the engine/transmission (see «ENGINE INSTALLATION»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-assembly-4-cyl__engine-installation) ). NOTE: Whenever any crankshaft or connecting rod bearing is replaced, run the engine at idle until it reaches normal operating temperature, then continue to run it for about 15 minutes.

Scheme 670

Scheme 670: CKP Pulse Plate Replacement

Remove the crankshaft from the engine block (see «CRANKSHAFT AND PISTON REMOVAL»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-block-4-cyl) ).
Remove the CKP pulse plate (A) from the crankshaft (B). NOTE: Be careful not to damage the journal and the CKP pulse plate.
Install the CKP pulse plate in the reverse order of removal.

Note. When installing the crankshaft, refer to the crankshaft installation procedure (see CRANKSHAFT INSTALLATION ).

Scheme 671

Scheme 671: Oil Pan Installation

Scheme 672

Scheme 673

Scheme 674

Scheme 675

Scheme 676

Scheme 677

Scheme 678

Scheme 679

Scheme 680

Scheme 681

Scheme 682

Remove all of the old liquid gasket from the oil pan mating surfaces, the bolts, and the bolt holes.
Clean and dry the oil pan mating surfaces.
Apply liquid gasket (P/N 08717-0004, 08718-0003, or 08718-0009) to the engine block mating surface of the oil pan and to the inside edge of the threaded bolt holes. Install the component within 5 minutes of applying the liquid gasket. NOTE: Apply a 2.5 mm (0.098 in) diameter bead of liquid gasket along the broken line (A). If too much time has passed after applying the liquid gasket, remove the old liquid gasket and residue, then reapply new liquid gasket.
Install the oil pan on the engine block.
Tighten the bolts in three steps. In the final step, torque all bolts, in sequence, to 12 N.m (1.2 kgf.m, 8.7 lbf.ft). Wipe off the excess liquid gasket on the each side of crankshaft pulley and the flywheel/drive plate. NOTE: Wait at least 30 minutes before filling the engine with oil. Do not run the engine for at least 3 hours after installing the oil pan.
Install the clutch case cover (A) and the transmission mounting bolts (B).
If the engine is still in the vehicle, do steps 8 through 27.
Lower the transmission jack from the transmission.
A/T model: Install the shift cable cover.
Tighten the new lower transmission mount bracket mounting bolts and nuts. M/T model A/T model
Install a new set ring on the end of driveshaft, then install the driveshaft (see «DRIVESHAFT INSTALLATION»(/acura/tsx/ii-2008-2014/remont/axle-shafts/#drivelineaxle-4-cyl__driveshaft-installation) ). Make sure the ring "clicks" into place in the differential.
Connect the lower arm to the left side knuckle (see step 6 on «COMPLIANCE BUSHING REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/suspension-front/#front-suspension-4-cyl) ).
Install the left side damper fork (see step 4 on «LOWER ARM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/suspension-front/#front-suspension-4-cyl__lower-arm-removalinstallation) ).
Install the front splash shield (see step 43 on «ENGINE MOUNT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mechanical/#engine-assembly-4-cyl) ).
Install the left front wheel.
Lower the vehicle on the lift.
Remove the strut brace (see «STRUT BRACE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#frame-4-cyl) ).
Do the battery removal procedure (see «BATTERY REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-4-cyl__battery-removal-and-installation) ).
Remove the air cleaner (see «AIR CLEANER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/mechanical/#intake-air-system-4-cyl) ).
Tighten the new front engine mount bolt (A), then install the front engine mount stop (B) using new nuts (C), and connect the vacuum hose (D).
Loosen the rear engine mount mounting bolts, then retighten the bolts to specified torque. M/T model A/T model
Loosen the side engine mount bracket mounting bolts, then retighten the bolts in the numbered sequence shown.
Loosen the upper transmission mount bracket mounting bolts, then retighten the bolts to the specified torque. M/T model A/T model
Install the air cleaner (see «AIR CLEANER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/mechanical/#intake-air-system-4-cyl) ).
Do the battery installation procedure (see «BATTERY REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-4-cyl__battery-removal-and-installation) ).
Install the strut brace (see «STRUT BRACE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#frame-4-cyl) ).
Refill the engine with engine oil (see step 5 on «ENGINE OIL REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/lubrication-system/#engine-lubrication-4-cyl) ).

Transmission End Crankshaft Oil Seal Installation - In Car
