Navigation System (4-cyl) Acura TSX II

Entertainment Systems 201 illustrations ~32084 words
Scheme 922: Sedan
Scheme 923: Sport Wagon
Scheme 924

Refer to the Navigation Manual for the navigation system operating procedures.

The navigation system has a coded theft protection circuit. Make sure you have the anti-theft security code before

  1. Disconnecting the battery.
  2. Disconnecting the audio-navigation unit connector A (24P).
  3. Removing the No. 15 (10 A) fuse from the under-hood fuse/relay box.

After service, reconnect power to the audio-navigation unit, and turn the ignition switch to ON (II). Enter the 5-digit anti-theft security code.

If the code card is lost or unavailable, you can get the code from the iN using the navigation system serial number. The system serial number can easily be obtained without removing the audio-navigation unit.

To get the serial number and the code, do this

  1. Press and hold the MENU, MAP/GUIDE, and CANCEL buttons at the same time.
  2. At the select diagnosis items screen, select Detail Information & Setting, select Unit Check, then ECU Info. The system runs a brief diagnosis, then the audio-navigation unit serial number is displayed at the bottom of the screen.
  3. Use the Anti-theft code inquiry option on the iN to look up the 5-digit anti-theft code. The iN may display more than one code for a given serial number. This is because serial numbers are not unique. You may have to try more than one 5-digit code. If no code is shown, or if the code(s) given do not work in the audio-navigation unit, contact the Automobile Warranty department.

Alternatively, you can find the serial number on the upper label which is located on the audio-navigation unit in the dash.

The HDD and audio-navigation unit are mated to each other and can only be mated to a new unit. If someone tried to put a stolen HDD in another audio-navigation unit, or insert their HDD in a stolen audio-navigation unit, the two components cannot mate and a HDD read error appears on the display.

When replacing the audio-navigation unit, be sure to give the client the new anti-theft security code.

Certain circumstances and system limitations may result in occasional vehicle positioning errors. Some clients may think this indicates a problem with the navigation system when, in fact, the system is normal. Keep the following items in mind when interviewing clients about symptoms of the navigation system.

The limitations of the self-inertial portion of the navigation system (the yaw rate sensor and the vehicle speed signal) can cause discrepancies between the vehicle's actual position and the indicated vehicle's position (GPS vehicle position).

The following circumstances may cause vehicle positioning errors

  1. Moving the vehicle with the engine stopped and the vehicle stopped, such as by ferry or tow truck, or if the vehicle is spun on a turn table.
  2. Tire slippage, changes in tire rolling diameters, and some driving situations may cause discrepancies in travel distances. Examples of this include: Continuous tire slippage on a slippery surface Driving with snow chains mounted Abnormal tire pressure - Incorrect tire size Frequent lane changes across a wide highway Continuous driving on a straight or gently curving highway Very bumpy roads
  3. Tolerances in the system and map inaccuracies sometimes limit how precisely the vehicle's position is indicated. Examples of this include: Driving on roads not shown on the map (map matching is not possible) Driving on a road that winds in one direction, such as a loop bridge, an interchange, or a spiral parking garage Driving on a road with a series of sharp hair-pin turns Driving near a gradual highway exit or transition Driving on one of two close parallel roads Making many 90 degree turns

The GPS cannot detect the vehicle's position or elevation during the following instances

  1. For the first 5 to 10 minutes after reconnecting the battery (this process can take as long as 45 minutes).
  2. When the satellite signals are blocked by tall buildings, mountains, tunnels, large trees, inside parking structures or large trucks.
  3. When the GPS antenna is blocked by metallic window tinting or by an object placed above it in the vehicle. The GPS antenna requires a clear unobstructed view of the sky.
  4. When there is no satellite signal output (signal output is sometimes stopped for satellite servicing).
  5. When the satellite signals are blocked by the operation of some electronic aftermarket accessories including, but not limited to non-OEM in-dash entertainment units (radio, CD players/changers, radar detectors and theft recovery systems) and cell phones placed near the navigation system.

The accuracy of the GPS is reduced during these instances

  1. Metallic window tinting above the GPS antenna.
  2. When only three or less satellite signals are received (Four satellite signals are required for accurate positioning).
  3. When driving near high tension power lines.
  4. When the satellite signals are blocked by the operation of some electronic aftermarket accessories including, but not limited to non-OEM in-dash entertainment units (radio, CD players/audio disc changers, radar detectors and theft recovery systems) and cell phones placed near the navigation system.
  5. When the satellite control centers are experiencing problems.

Whenever the navigation system is giving guidance, outputs of all the speakers except the center speaker are decreased. When the voice control system is being used, all of the speakers are muted. If the AcuraLink or HandsFreeLink™ is in use, the voice control system is unavailable and a message appears onscreen.

Note. The screen is not touch sensitive. Use the interface dial and buttons to select items on the screen.

  1. In cold temperatures, the display may stay dark for the first 1 minute until it warms up.
  2. When the display is too hot because of direct summer sunlight, it will remain dark until the temperature drops (you may see an error message displayed stating this fact).
  3. When the humidity is high and the interior temperature is low, the display may appear cloudy. The display will clear up after some use.
  4. Fingerprints on the screen may be noticeable. Clean the screen with a soft, damp cloth. You may use a mild cleaner intended for eye glasses or computer screens. To avoid scratching the panel, do not rub too hard or use abrasive cleaners or shop towels.
  1. When the symptom can be duplicated, verify that it is not a characteristic of the system, Review the Navigation Manual and compare it to a known-good vehicle (with the same software and database), under the same conditions. If the symptom is not the same as the known-good vehicle, follow the self-diagnostic procedures and the appropriate troubleshooting procedures.
  2. When the symptom does not reappear or only reappears intermittently, ask the client about the conditions when the symptom occurred. Always ask the client to demonstrate the problem Try to establish possible user error or misunderstanding of the system Try to establish if outside interference may have been the cause Try to duplication the symptom under the same conditions the client experienced Vibration, temperature extremes, and moisture (dew, humidity) are factors that are difficult to duplicate Inspect the vehicle for after-market electronic devices (vehicle locators, amps, radar detectors, etc.) that may be hidden NOTE: When troubleshooting navigation system problems, ensure that the known-good vehicle is the same software version year and model as the vehicle being serviced. Mixing incompatible navigation systems or other system components can delay the troubleshooting process by creating symptoms or issues unrelated to the original problem.

Contrary to previous generations of navigation units, the audio-navigation unit and the HDD cannot be substituted separately. You can substitute a combined audio-navigation unit and HDD with a known-good combined audio-navigation unit and HDD. When the audio-navigation unit and HDD are connected to a vehicle, and powered up for the first time, the audio-navigation unit and HDD go through a mating process where the HDD writes the audio-navigation unit's serial number to its memory. The audio-navigation unit and HDD are available separately.

When you get a replacement audio-navigation unit, the unit arrives able to mate one time to a HDD. When you connect the audio-navigation unit to the HDD and power it up for the first time, the two components are mated. Once the audio-navigation unit is mated, it does not accept an HDD that is already mated to another audio-navigation unit. It does accept a new HDD.

The HDD is removable from the audio-navigation unit. If the audio-navigation unit is replaced, install the original HDD into the new audio-navigation unit. When you transfer the HDD, all the client's settings, music, and photographs are transferred.

The HDD is able to mate more than once, allowing you to transfer the HDD with the client's information to a new audio-navigation unit. The HDD must mate to a new audio-navigation unit. It cannot mate to an audio-navigation unit that has been mated to another HDD.

If you need to replace the HDD, there is no way to transfer client data, music, or pictures to a new HDD. Explain to your client that their music and personal information is not transferable. The navigation system has the save users memory function available, but Acura does not recommend using it. If the HDD is OK, install it in the new audio-navigation unit and it will automatically transfer all the client's information and settings.

If you need to replace the HDD, you can try to back-up the navigation data (if possible) and transfer it to the new HDD. See Save Users Memory (see SAVE USERS MEMORY ). The save users memory function only copies client settings and phone information. There is no way to copy or transfer music and photographs that are saved on the HDD to a new HDD. Explain to your client that this information is not transferable and will be lost.

  1. When the battery is disconnected, the internal GPS clock resets to 0:00. The clock resets to the correct time after the system finishes GPS initialization.
  2. Before disconnecting the battery, make sure you have the anti-theft code for the navigation system. Also obtain any PGM-FI or A/T DTCs and freeze frame date (which are lost when the ECM/PCM loses power).
  3. After reconnecting the battery, you have to wait to get the initial signal from the satellite. It will take from 10 to 45 minutes.
  4. Adjust the setup clock settings (time zone and daylight savings) in the navigation system.
  5. Before returning the vehicle to the client, enter the anti-theft code for the navigation system.
  6. Enter the client's audio presets.
  7. Install any discs that were removed.

If the navigation system loses power (like the battery was disconnected), the navigation system requires initialization. Once completed, your system is ready to use.

This initialization requires the following

  1. Entering the 5-digit anti-theft security code to unlock the system.
  2. GPS initialization (may not be needed depending of the length of time the system was without power).
  3. Map matching aligns the GPS to a location on the map.

Any time the navigation system loses power, you need to enter the 5-digit anti-theft code on the navigation system display. This 5-digit code is located on a small code card that was given to the client. Enter the 5-digit code.

If the anti-theft code is missing, get the serial number from the audio-navigation unit and use the iN to look it up. You do not need to remove the audio-navigation unit. See Anti-Theft Feature.

When replacing the audio-navigation unit, make sure you give the client the new anti-theft security code.

Note. You must park the vehicle outside with a clear view of the sky.

Depending on the length of time the battery was disconnected, your system may require GPS initialization. If it does, the following screen appears

Scheme 925: GPS Initialization

If this procedure is not necessary, the system proceeds directly to the Disclaimer screen. During initialization, the system searches for all available GPS satellites, and obtains their orbital information. During this procedure the vehicle should be out in the open with a clear view of the sky.

If the navigation system finds the satellites properly, this box clears, and changes to the Disclaimer screen. If within 10 minutes the system fails to locate a sufficient number of satellites to locate your position, the following screen appears

Scheme 926

If this screen appears, turn off the engine, then restart the vehicle and move it to a different location. If the Disclaimer screen appears, the GPS initialization is complete.

Note. The average acquiring time is less than 10 minutes, but it can take as long as 45 minutes. If the system is still unable to acquire a signal, follow the instructions on the screen. If this screen appears again, go to GPS icon is white or not shown troubleshooting (see GPS ICON IS WHITE OR NOT SHOWN ). Skip to a CSF screen by pushing the MENU and INFO/PHONE buttons at the same time and can move to a System Links screen.

This part of the initialization matches the GPS coordinates with a road on the map screen. To do this part of the procedure, make sure that the navigation system displays a map, and drive the vehicle on a mapped road shown on the map screen. Do not enter a destination at this time. When the name of the current road you are driving on appears at the bottom of the screen, the entire procedure is complete. Your system is now ready to use.

If the client wants to purchase a yearly update for their HDD, there are two ways to purchase one. You can either call 888-549-3798, or order on-line at www.acuranavi.com.

When clients order an update DVD, they need

  1. VIN
  2. Device number (found on the INFO menu)
  3. Credit card

Update DVDs are available for purchase usually in the fall of each year. They may contain the following

  1. Enhanced maps and points of interest (POI) coverage
  2. Fixes for minor software bugs
  3. Additional features

The update DVD is mailed to the client along with the password.

When the client receives the update DVD, insert the disc into the CD/DVD player. The client is prompted to enter the password that is shipped with the update DVD. The navigation system automatically updates the HDD.

Note. The update DVD is designed to update the vehicle with the submitted VIN. If a client has more than one vehicle that needs updating, they need to order a separate update DVD for that vehicle.

Acura tracks the map software version purchased for the VIN. If you need to replace the HDD, the new HDD comes with the latest map version that the client loaded on the HDD.

Never promise your client future free updates. There are no free programs for updating the navigation HDD. Update DVDs are generally available for purchase each fall. The online DVD order site provides information when an update is available.

To disconnect the connector, pull the lever (A) while pushing the lock tab (B) down, then pull the connector (C).

Scheme 927: Disconnecting

To connect the connector, push the connector into the connector sleeve (A). As the connector is pressed in, the lever (B) moves to the locked position.

Scheme 928: Connecting

Some clients may ask questions regarding a city, address, or POI (point of interest) covered by the navigation system. It is better to verify a coverage question on an actual vehicle than to disappoint your client by promising coverage that may be incomplete or missing in their area. The following suggestions can be used to answer coverage inquiries from your client.

Is my address covered by the navigation system?

Using a current production vehicle (of the same model), and enter the client's address (street first) to see if their area is covered. Always enter the street first, because sometimes their city may be included in a neighboring township, or under some larger metropolitan city name. If the address is shown in a later year vehicle, but not your client's vehicle, you might recommend that your client purchase an update.

Is my city covered by the navigation system?

For general questions about whether a city is covered, view the map coverage link on the DVD order site. On the site, select a year, and select a model, then click on the Coverage link. You then select a state or province, and the cities are listed. This does not guarantee that the client's road or address is in the system. Verifying on an actual production vehicle is always the best guarantee that your information is accurate.

The gas station on my corner is now a restaurant. Why is it still incorrect in the navigation system?

For POI-related client questions, explain that businesses are constantly moving, and there can be a considerable lag in updating the millions of POIs in the system. The database is updated annually, and the best way to the verify whether the POI is accurate is verify the inquiry on a current production vehicle.

Answers to these and other questions regarding coverage can be found in these locations

  1. In the Frequently Asked Questions information of the Navigation Manual.
  2. At the online DVD order site, by clicking on the FAQs link.

How do I find the local address of a business that is part of a national chain (for example, Starbucks)?

There are three ways to find the local address to businesses

  1. If you know the phone number of the business, select Phone Number and enter the 10 digit phone number (area code plus seven digit number).
  2. Select Category, then Restaurant. Enter the keyword Star. The resulting list includes all restaurants that have the letters Star anywhere in the name.
  3. Select Name and enter Starbucks. For more common business names, like McDonalds, you may have to search through a list that includes other businesses like McDonalds Welding, McDonalds Automotive, etc.

Why are some features different or missing compared to my previous Acura vehicle?

Hardware and software continually go through updates and improvements. Features may change or disappear overtime based on the navigation system development.

Note. The navigation DTCs cannot be retrieved with the HDS.

The Error History feature is to record intermittent navigation issues that occur while the client is using the system. Sometimes the client complaint cannot be duplicated. The error history may record the information needed to diagnose the problem. To check the error history.

Scheme 929: How to Check Error History (Navigation DTCs)
Scheme 930
Scheme 931
Scheme 932
Scheme 933
  1. Start the engine.
  2. Press and hold the MAP/GUIDE, MENU, and CANCEL buttons for 3 seconds, or connect the SCS service connector to the navigation service check connector located by the front passenger's kick panel (see «FORCED STARTING OF THE AUDIO-NAVIGATION UNIT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__forced-starting-of-the-audio-navigation-unit) ).
  3. When the Select Diagnosis Items menu is displayed, select Detail Information & Setting.
  4. When the audio-navigation unit has hard error codes, the Error History icon appears yellow when the Self-Diagnosis mode (System Links) screen is displayed. When no hard error codes are stored, the icon appears gray. To view the errors with their navigation DTC, select the error history icon. With AcuraLink Without AcuraLink
  5. Select Hard Error. NOTE: Soft errors are for factory use only. Hardware Error History
  6. The Hard Error screen displays the following information for each error: The navigation DTC for the error. A brief description of the navigation DTC. The date and time when the error occurred. NOTE: To see additional errors/use the interface dial to select UP or DOWN. Select Clear to delete the error history. The Save feature is for factory use only. Write down the navigation DTCs and error history before deleting.
  7. Use the navigation DTC troubleshooting to troubleshoot the error.
  8. Clear the navigation DTCs.
  9. Select Return to exit the Error History. Software Error (Soft error) History Software errors are not available. They are for factory use only.
Scheme 934: How to Clear Error History
Scheme 935
Scheme 936
  1. Do the steps in How to check Error History.
  2. Select Clear in the error menu. NOTE: By selecting Clear, all software and hardware error codes stored in history are erased at the same time. Save is for factory use only. Write down the navigation DTCs and error history before deleting. Hard error history is displayed Soft error history is displayed (software errors are for factory use only)
  3. After selecting Clear, then selecting Yes on the confirmation screen, both Hard Error history and Soft Error history are cleared at the same time. Hard error history clear/Soft error history clear (Soft errors are for factory use only)
  4. Select Return to exit the error history.

To protect client information and data from theft, the audio-navigation unit and the HDD have a passcode that prevents the HDD from being accessed by any audio-navigation unit. When the HDD is first installed in an audio-navigation unit, and the ignition switch is turned to ON (II), the HDD writes the passcode from the audio-navigation unit to its memory, which is also known as mating. Every time the ignition switch is turned to ON (II), the audio-navigation unit and HDD confirm the passcode against the other component. If the audio-navigation unit has a different passcode than the HDD, the audio-navigation unit cannot access the HDD.

When you order a new audio-navigation unit, it arrives able to mate one time to a new or previously mated HDD. When you mate the two components, the new audio-navigation unit overwrites the HDD's original passcode with the new one. If you try to install the HDD back into the original audio-navigation unit, the passcode is different, and the audio-navigation unit cannot mate to the HDD.

When you order a new HDD, it arrives able to mate to a new or a previously mated audio-navigation unit. Once the HDD is mated, it then can only mate with a new audio-navigation unit.

For more information, refer to AUDIO-NAVIGATION UNIT AND HDD SERVICE PRECAUTIONS . The outline of the audio-navigation unit and the HDD replacement and substitution is shown in the following table.

Note. Original units are known-good units that have been mated at least one time, and new units have never been mated. You can substitute a mated audio-navigation unit and HDD into another vehicle, but you cannot substitute known-good components individually.

Audio-Navigation UnitHDDResult
NewNewOK
OriginalNewOK
NewOriginalOK
OriginalAn audio-navigation unit mated to a different HDDNG
An audio-navigation unit mated to a different HDDOriginalNG

AUDIO-NAVIGATION UNIT REFERENCE CHART

QuestionAnswer
Can you turn the ignition switch from ON (II) to LOCK (0) while the navigation system is updating?Yes, when the ignition switch is turn to LOCK (0) and then back to ON (II), the screen directs the client to remove and reinsert the update disc. The updating procedure continues automatically from the point where it stopped.
How long does the update take?Image Copy (full update mode): about 20 minutes (2 GB). Background update: about 8 hours (2 GB).
What is the difference between the two update modes? Can 1 use the audio system and the navigation system during the update?Image Copy (full update mode): You cannot use the navigation system or any function that uses the HDD You can use the audio system in the AM/FM, XM, and USB modes, but not the HDD or CD/DVD. The navigation screen is not available so you need to use the audio display to control the audio system Background update mode: Audio functions are the same as the full update mode. The navigation system does function, but it is limited during the update.
How many digits is the passcode, and what happens if 1 enter it incorrectly?The pass code is 16 digits which you need to manually enter. You cannot use the voice commands. There is no limit to the number of times you can attempt to enter the passcode.
Can the update DVD be inserted at any time?Yes, if the navigation screen has timed out, "OK" needs to be selected, then follow screen prompts.
Can the client see the navigation update progress?Image Copy (full update mode): a progress bar appears on the navigation display. Background update mode: The update progress can be confirmed on the Map Update data status screen.
Can music be transferred from one HDD to another?No. Music can only be ripped to a HDD.
Can music be recovered from a damaged HDD?If the HDD is damaged, there is no way to recover music, data, or personal information.
When transferring the HDD to a new audio-navigation unit, are the client settings also transferred?Yes. When the HDD is installed in a new unit, all the ripped music, client data and settings are automatically transferred with the HDD.

NAVIGATION UPDATE FAQS REFERENCE CHART

DTCDescriptionCircuitFailure DetectionAlso Check for
1001FROM System Info ErrorFlash ROM managementAudio-navigation unit internal data error.Low or weak battery
1101Media Bus Send ErrorMedia condition monitoringAudio-navigation unit internal media error.Low or weak battery
1102USB DiagUSBUSB circuit malfunction.Low or weak battery voltage Unsupported or defective USB device
1201DVD High TempDVD driveAudio-navigation unit temperature above the upper limit. Failure in audio-navigation unit internal cooling fan circuit.Low or weak battery voltage Excessively high or low passenger's compartment temperature Clogged audio-navigation unit cooling fan
1204HDD High TempHDDAudio-navigation unit temperature above the upper limit. Failure in audio-navigation unit internal cooling fan circuit.Low or weak battery Clogged audio-navigation unit cooling fan
1206HDD ErrorHDDMechanical malfunction in the HDD.Low or weak battery voltage
1301GPS Antenna ErrorGPS AntennaGPS antenna circuit malfunction.Low or weak battery voltage
1302GPS Receiver Error 1GPS ReceiverGPS antenna circuit malfunction. Audio-navigation unit internal GPS receiver malfunction.Low or weak battery voltage
1303GPS Receiver Error 2GPS ReceiverAudio-navigation unit internal GPS receiver malfunction.Low or weak battery voltage
1305Gyro Error 2: ECU Temp XX°CGyroAudio-navigation unit internal gyro malfunction.Low or weak battery voltage
1306Vehicle Speed PulseVehicle Speed PulseVSP circuit malfunction.Check for B-CAN or F-CAN DTCs
1402Audio Error 2 (CD Error)CDMechanical malfunction in the CD/DVD player.Low or weak battery voltage
1403Audio Error 3 (Display Error)DisplayMechanical malfunction with navigation display unit.Low or weak battery voltage
1404Audio Error 4 (DVD Error)DVDMechanical malfunction in the CD/DVD player (audio-navigation unit).Low or weak battery voltage
1405Audio Error 5 (HDD Error)HDDMechanical malfunction in the HDD.Low or weak battery voltage
1701R-Camera ErrorRear CameraCommunication error between rearview camera and navigation display unit (open/short).Rearview camera connector disconnected
1702XM Antenna ErrorXMXM antenna/circuit malfunction.Low or weak battery voltage
1801HIP ErrorHIPHIP communication error, open the wire, or HIP unconnected.Check for B-CAN DTCs
2601Display Diag: ConnectDisplayGA-Net bus circuit malfunction (open/short). ECU bus circuit malfunction (open/short).
2605H/U Diag: ConnectH/UGA-Net Bus circuit malfunction (open/short).
2607XM DiagXMGA-Net bus circuit malfunction (open/short). XM antenna circuit malfunction.
2608R-Camera DiagRear CameraRearview camera internal malfunction.
2610DRAM DiagECU DRAMAudio-navigation unit internal DRAM malfunction.
2611HDD DiagHDDHDD internal malfunction.Low or weak battery voltage
2612Sub Display DiagSubdisplaySubdisplay bus circuit malfunction (open/short).Low or weak battery voltage
2701GPS Diag: AntennaGPSGPS antenna malfunction.
2702GPS Diag: Receiver in Navi ECUGPSGPS antenna malfunction.
2703Aircon DiagAirconCommunication error between climate control unit and audio-navigation unit (open/short).Check for B-CAN DTCs
2704HIP DiagHIPHFL/HIP COMM1 thru HFL/HIP COMM4 bus circuit malfunction (open/short).Check for B-CAN DTCs
2705HFL DiagHFLHandsFreeLink™ control unit internal malfunction.Check for B-CAN DTCs
2706Gyro Diag: ECU Temp XX°CGyroAudio-navigation unit internal malfunction.Excessively high or low passenger's compartment temperature Clogged audio-navigation unit cooling fan
2707Mic DiagMicMic circuit malfunction (open/short).
2709FROM DiagECU FROMAudio-navigation unit internal FROM malfunction.
2710USB Cable DiagUSBUSB circuit malfunction.

DTC TROUBLESHOOTING CHART

SymptomDiagnostic ProcedureAlso Check for
Navigation system stays on the GPS initialization screenSystem Initialization (see SYSTEM INITIALIZATION )Audio-navigation unit Internal defect in GPS antenna GPS antenna/cable is disconnected or damaged Aftermarket metallic window tint Software not up to date Harness/fuses/switches
Vehicle position icon constantly leaves road, moves erratically, or is displayed very far from actual vehicle positionSymptom Troubleshooting (see SYMPTOM TROUBLESHOOTING )Audio-navigation unit Internal defect in GPS antenna GPS antenna/cable Aftermarket metallic window tint ECM/PCM (vehicle speed pulse) Harness/fuses/switches
System always comes up in in-line diagnostic modeFactory diagnostic screen In Line Diag (see FACTORY DIAGNOSTIC SCREEN IN LINE DIAG )
Navigation system does not accept security codeSymptom Troubleshooting (see SYMPTOM TROUBLESHOOTING )Anti-theft code not matching
Navigation frequently asks for anti-theft code and/or needs GPS initializationSymptom Troubleshooting (see SYMPTOM TROUBLESHOOTING )Loss of voltage or poor ground (G651) Audio-navigation unit Software not up to date Low battery voltage Harness/fuses/switches
GPS icon is white or not shownSymptom Troubleshooting (see SYMPTOM TROUBLESHOOTING )Audio-navigation unit Internal defect in GPS antenna Aftermarket accessories connected to the system GPS antenna/cable Aftermarket metallic window tint Harness/fuses/switches
Vehicle position icon wanders across the map when driving (does not follow a displayed road) or map or vehicle ICON spinsSymptom Troubleshooting (see SYMPTOM TROUBLESHOOTING )Audio-navigation unit GPS antenna/cable Aftermarket metallic window tint ECM/PCM (vehicle speed pulse) Internal defect in GPS antenna
No picture is displayedSymptom Troubleshooting (see SYMPTOM TROUBLESHOOTING )Software not up to date Audio-navigation unit Navigation display unit Harness/fuses/switches
Picture has lines, rolls, or is blurrySymptom Troubleshooting (see SYMPTOM TROUBLESHOOTING )Aftermarket accessories connected to the system Audio-navigation unit Navigation display unit Harness/fuses/switches
Picture is missing a color or tone or is an odd colorSymptom Troubleshooting (see SYMPTOM TROUBLESHOOTING )Software not up to date Audio-navigation unit Navigation display unit Aftermarket accessories connected to the system Harness/fuses/switches
Traffic or Weather information is not shown on map screenSymptom Troubleshooting (see SYMPTOM TROUBLESHOOTING )AcuraLink (XM) Audio-navigation unit Low or weak battery Harness Client account status Area outage Area not covered
Display day/night mode does not work or does not work properlySymptom Troubleshooting (see SYMPTOM TROUBLESHOOTING )Audio-navigation unit The gauge brightness level is set to High in day or night mode Navigation display unit Gauge control module The navigation display brightness is not set to Auto mode Harness/fuses/switches
System locks up or freezes constantlySymptom Troubleshooting (see SYMPTOM TROUBLESHOOTING )Audio-navigation unit Software not up to date Harness/fuses/switches
Voice guidance cannot be heard, is broken up, or there is staticSymptom Troubleshooting (see SYMPTOM TROUBLESHOOTING )Volume or voice feedback setting (see Navigation Manual) Audio-navigation unit Stereo amplifier Harness/fuses/switches
Voice control does not work/respondSymptom Troubleshooting (see SYMPTOM TROUBLESHOOTING )Audio-navigation unit Microphone Harness/switches HandsFreeLink™ control unit
Navigation cannot control HVAC by voice commandSymptom Troubleshooting (see SYMPTOM TROUBLESHOOTING )Software not up to date Harness/fuses/switches Wrong audio-navigation unit (model code) B-CAN DTCs
Navigation cannot control XM radioSymptom Troubleshooting (see SYMPTOM TROUBLESHOOTING )Software not up to date Audio-navigation unit AcuraLink control unit (XM receiver) (with AcuraLink) or XM receiver (without Acura Link) Harness
Navigation cannot control audio systemSymptom Troubleshooting (see SYMPTOM TROUBLESHOOTING )Audio-navigation unit Harness Software not up to date
Interface dial buttons do not workSymptom Troubleshooting (see SYMPTOM TROUBLESHOOTING )Audio-navigation unit Navigation display unit Interface dial Harness/fuses/switches
Today's Destinations button is dim and not selectable in the Enter destination by screen (grayed-out)The client has not entered a group of locations for Today's Destinations. This is normal. The button is only selectable if the client is using this functionSee Navigation Manual
Previous Destinations button is dim and not selectable in the Enter destination by screen (grayed-out)The vehicle may be new, or the client deleted the destination. Without a stored previous destination, the system cannot route to a previous destination. Enter a destination, and allow the system to route to it. After the trip, the Previous Destinations button will be selectable
Address cannot be found or system gives poor routingVerify proper operation and system limitations using the Navigation Manual See Answering Client Questions about Navigation Coverage (see HOW TO ANSWER CLIENT QUESTIONS ABOUT NAVIGATION COVERAGE )Database limitations (address not in database) Software not up to date Older database
Rearview camera image does not come on or work properlySymptom Troubleshooting (see SYMPTOM TROUBLESHOOTING )Check software for latest up-dates No backup signal Wrong disc installed in navigation unit
The map will not display the Southern portion of the U.S. or the Northern parts of CanadaNorth American coverage is different for U.S./Canada markets. See the Version diagnostic screen (see VERSION ) for details on coverage differencesSoftware not up to date
Navigation display stays on with the ignition switch in LOCK (0)Symptom Troubleshooting (see SYMPTOM TROUBLESHOOTING )Harness/fuses/switches Aftermarket accessories connected to the system
Navigation system will not go beyond the disclaimer screen and displays the OK buttonAlso see Interface dial buttons do not workSoftware not up to date Audio-navigation unit
The navigation anti-theft code card is lost or missingSee Anti-Theft Feature (see ANTI-THEFT FEATURE )
The vehicle icon lags behind when the vehicle turnsSee Self-Inertial Navigation Limitations (see SELF-INERTIAL NAVIGATION LIMITATIONS )Aftermarket accessories connected to the system GPS antenna/cable Aftermarket metallic window tint
Navigation screen is darker than normal or takes time to brighten when it is coldSee LCD UNIT LIMITATIONSCompare to a known-good vehicle
The navigation clock is off by 1 to 3 hours after replacing the audio-navigation unitSee Service Precautions (see AUDIO-NAVIGATION UNIT AND HDD SERVICE PRECAUTIONS )Do Map Matching (see MAP MATCHING ) GPS antenna/cable Aftermarket metallic window tint Check and adjust the clock settings Check the keyless remote linking
Time is not correctReset Time Adjustment in set-up See Service Precautions (see AUDIO-NAVIGATION UNIT AND HDD SERVICE PRECAUTIONS )Software not up to date Reset Time Adjustment in set-up A defective GPS receiver in the audio-navigation unit
A POI cannot be foundSee How to Answer Client Questions about Navigation Coverage (see HOW TO ANSWER CLIENT QUESTIONS ABOUT NAVIGATION COVERAGE )Software not up to date The database may be out of date. Confirm the POI exists in a current production vehicle
A specific city cannot be foundSee How to Answer Client Questions about Navigation Coverage (see HOW TO ANSWER CLIENT QUESTIONS ABOUT NAVIGATION COVERAGE )Software not up to date The database may be out of date. Confirm the address exists in a current production vehicle
Error messages are displayedSee Error Message Table (see ERROR MESSAGE TABLE )Software not up to date HDD not transferred during an audio-navigation unit replacement The database may be out of date. Confirm the address exists in a current production vehicle

SYMPTOM TROUBLESHOOTING CHART

The navigation system is a highly-sophisticated, hybrid locating system that uses satellites and a map database to show you where you are and to help guide you to a desired destination.

The navigation system receives signals from the global positioning system (GPS), a network of 24 satellites in orbit around the earth. By receiving signals from several of these satellites, the navigation system can determine the latitude, longitude, and elevation of the vehicle. In addition, signals from the system's yaw rate sensor and the ECM/PCM (vehicle speed pulse) enable the system to keep track of the vehicle's direction and speed of travel.

This hybrid system has advantages over a system that is either entirely self-contained or one that relies totally on the GPS. For example, the self-contained portion of the system can keep track of vehicle position even when satellite signals cannot be received. When the navigation system is on, the GPS can keep track of the vehicle position even when the vehicle is transported by ferry.

The navigation system applies all location, direction, and speed information to maps and calculates a route to the destination entered. As you drive to that destination, the system provides both visual and audio guidance.

The navigation system also uses dynamic route guidance to help avoid traffic delays and incidents. Clients need to subscribe to real-time traffic for this function to work.

This navigation system also has voice recognition that allows voice control of most of the navigation functions. The TALK and BACK buttons on the steering wheel activate the voice control. The voice control also allows control of the audio and climate functions.

The illumination signal (headlights ON) is used by the audio-navigation unit to automatically switch the display between Night and Day brightness modes. When the gauge control module brightness control is set to full brightness, the navigation system stays in the day mode, even with the headlights on.

The GA-Net II communication bus passes information back and forth between the navigation display, the audio-navigation unit, AcuraLink control unit (XM receiver), and the audio system. The information passed on this bus is audio settings directed by the audio-navigation unit.

The Comm. Bus connects the HFL, XM (HIP) (AcuraLink), and audio-navigation units. This bus supports these functions

  1. The audio-navigation unit receives traffic, weather, and AcuraLink message information from the AcuraLink control unit (XM receiver).
  2. If a POI phone number is available, the audio-navigation unit sends the phone number (on the Calculate route to screen) to the HandsFreeLink™ control unit for dialing.
  3. If vehicle problems are detected, and the client's cellular contract includes data service (the vehicle must also have an approved blue tooth phone paired and configured correctly), then the AcuraLink control unit (XM receiver) can send vehicle data to the HandsFreeLink™ control unit for transmitting back to the AcuraLink servers.
  4. The AcuraLink server can pass additional problem details back through the HandsFreeLink™ control unit, to the AcuraLink control unit (XM receiver), and finally to the audio-navigation unit for display.

The Acura TSX uses a HDD (hard disc drive) instead of a navigation DVD. The HDD system improves route calculation and POI searching time, as well as these additional functions

  1. Ripping music to the HDD with on-board CDDB (CD database) information provided by Gracenote.
  2. Clients can save their personal pictures to the HDD and use the images as wallpaper when they are not using the navigation system.
  3. See the Owner's Manual or Navigation Manual for more information.

There are two software programs that run on the navigation system

  1. Navigation system software - This software comes pre-loaded on the HDD and runs the navigation system. It can be updated when a client orders a navigation update disc, or as directed by any official Acura service information like a service bulletin.
  2. Map software - This is commonly referred to as update navigation DVD that clients can order to update their map info, POI DB, and CDDB information. This also comes pre-loaded on the HDD, but the client can choose to update it yearly.

When you order a reman HDD, the latest navigation system software is loaded on the HDD, along with the latest Map software that the client had installed on their HDD.

If a client wants to order an update, see Ordering an Update Navigation DVD (see ORDERING AN UPDATE NAVIGATION DVD ).

The Gracenote CDDB is updated quarterly. Clients can visit www.acura.com and download the latest update.

The HDD shuts down to protect itself from damage, if the audio-navigation unit internal temperature is 183°F (84°C) or higher.

Warning of extreme temperatures in the audio-navigation unit is displayed on the navigation screen as an error message.

The USB module is built into the audio-navigation unit. Clients can load images (which can be used as wallpaper), music, and the CDDB. Not all USB devices and devices functions work with the USB adapter. Please see the Owner's Manual for more information.

Scheme 937: With AcuraLink
Scheme 938: Without AcuraLink

The navigation system is composed of the audio-navigation unit, the ECM/PCM (vehicle speed pulse), the AcuraLink control unit (XM receiver) (traffic and weather information), the HandsFreeLink™ control unit (to send a POI phone number or place a call), the GPS antenna, the microphone, the voice control switch, the navigation display unit, the interface dial, and the rearview camera.

Scheme 939: Function Diagram

The GA-Net bus passes audio, navigation, and HFL commands throughout the audio, navigation, and HFL components. These commands include navigation audio/XM selections by voice, and XM station and music title names. Because the entire bus is interconnected between components, an open or short in the GA-Net bus harness may cause any or all of these functions to become inoperative.

Scheme 940: GA-Net Bus Configuration

The vehicle speed pulse is sent by the ECM/PCM. The ECM/PCM receives a signal from the output shaft (countershaft) speed sensor, then processes the signal and transmits it to the speedometer and other systems.

Scheme 941: Vehicle Speed Pulse

The yaw rate sensor (located in the audio-navigation unit) detects the direction change (angular speed) of the vehicle. The sensor is an oscillation gyro built into the audio-navigation unit.

The sensor element is shaped like a tuning fork, and it consists of the piezoelectric parts, the metal block, and the support pin. There are four piezoelectric parts: one to drive the oscillators, one to monitor and maintain the oscillation at a regular frequency, and two to detect angular velocity. The two oscillators, which have a 90-degree twist in the center, are connected at the bottom by the metal block and supported by the support pin. A detection piezoelectric part is attached to the top of each oscillator. The driving piezoelectric part is attached to the bottom of one oscillator, and the monitoring piezoelectric part is attached to the bottom of the other oscillator.

The piezoelectric parts have electric/mechanical transfer characteristics. They bend vertically when voltage is applied to both sides of the parts, and voltage is generated between both sides of the piezoelectric parts when they are bent by an external force. The oscillation gyro functions by utilizing this characteristic of the piezoelectric parts and Coriolis force. (Coriolis force deflects moving objects as a result of the earth's rotation.) In the oscillation gyro, this force moves the sensor element when angular velocity is applied.

Scheme 942: Operation
  1. The driving piezoelectric part oscillates the oscillator by repeatedly bending and returning when an AC voltage of 6 kHz is applied to the part. The monitoring-side oscillator resonates because it is connected to the driving-side oscillator by the metal block.
  2. The monitoring piezoelectric part bends in proportion to the oscillation and outputs voltage (the monitor signal). The navigation unit control circuit controls the drive signal to stabilize the monitor signal.
  3. When the vehicle is stopped, the detecting piezoelectric parts oscillate right and left with the oscillators, but no signal is output because the parts are not bent (no angular force).
  4. When the vehicle turns to the right, the sensor element moves in a circular motion with the right oscillator bending forward and the left oscillator bending rearward. The amount of forward/rearward bend varies according to the angular velocity of the vehicle.
  5. The detecting piezoelectric parts output voltage (the yaw rate signal) according to the amount of bend. The amount of vehicle direction change is determined by measuring this voltage.

The global positioning system (GPS) enables the navigation system to determine the current position of the vehicle by using the signals transmitted from the satellites in orbit around the earth. The satellites transmit the satellite identification signal, orbit information, transmission time signal, and other information. When the GPS receiver receives a signal from four or more satellites simultaneously, it calculates the current position of the vehicle based on the distance to each satellite and the satellite's position in its respective orbit.

Scheme 943: Position Detection Image with GPS Satellite

The precision of the GPS varies according to the number of satellites from which signals are received and the view of the sky. The accuracy is indicated by the color of the GPS icon shown on the display.

GPS Icon ColorNumber of SatellitesConditionDescription
No GPS iconNoneFaulty receptionThe GPS cannot be utilized due to a faulty GPS receiver, open in the wire, or other fault or interference.
2 or lessImpossible to detect vehicle positionGPS function is normal. The satellite signals received by the GPS are too few to detect the vehicle position.
White GPS icon3Vehicle position detectable in 2 dimensionsThe longitude and latitude of the vehicle position can be detected (less precise than detection in three dimensions).
Green GPS icon4 or moreVehicle position detectable in 3 dimensions (elevation displayed)The longitude, latitude and the altitude of the vehicle position can be detected (more precise than detection in two dimensions).

GPS REFERENCE CHART

The GPS antenna amplifies and transmits the signals received from the satellites to the GPS receiver.

The GPS receiver is built into the audio-navigation unit. It calculates the vehicle position by receiving the signal from the GPS antenna. The current time, vehicle position and signal reception condition is transmitted from the GPS receiver to the audio-navigation unit to adjust vehicle position and the clock in the audio-navigation switch panel display.

The audio-navigation unit calculates the vehicle position and guides you to the destination. The unit performs map matching correction, GPS correction, and distance tuning. It also controls the menu functions and the HDD, and interprets voice commands. With control of all these items, the audio-navigation unit makes the navigation picture signal, then it transmits the signal to the navigation display unit.

The audio-navigation unit calculates the vehicle position (the driving direction and the current position) by receiving the directional change signals from the yaw rate sensor and the travel distance signals from vehicle speed pulse (VSP) signal of the ECM/PCM.

The map matching tuning is accomplished by indicating the vehicle position on the roads on the map. The map data transmitted from the HDD is checked against the vehicle position data, and the vehicle position is indicated on the nearest road. Map matching tuning does not occur when the vehicle travels on a road not shown on the map, or when the vehicle position is far away from a road on the map.

The GPS tuning is accomplished by indicating the vehicle position as the GPS's vehicle position. The audio-navigation unit compares its calculated vehicle position data with the GPS vehicle position data. If there is large difference between the two, the indicated vehicle position is adjusted to the GPS vehicle position.

The distance tuning reduces the difference between the travel distance signal from the VSP and the distance data on the map. The audio-navigation unit compares its calculated vehicle position data with the GPS vehicle position data. The audio-navigation unit then decreases the tuning value when the vehicle position is always ahead of the GPS vehicle position, and it increases the tuning value when the vehicle position is always behind the GPS vehicle position.

The Acura navigation system's real-time traffic feature helps you avoid traffic delays by providing up to the minute traffic information in many metropolitan areas across the contiguous USA. Color coded freeways appear on the navigation screen, displaying current traffic flow, and/or the locations of accidents and traffic conditions affected by construction and weather. Real-time traffic data services are offered on a subscription basis for a nominal fee following the 90-day free trial period.

The Acura navigation system's weather information option allows you to view the weather forecast, warning list, warning map, and weather radar. The weather information is available in a subscription basis for a fee following the 90-day free trial period.

The audio-navigation unit can calculate different routes to a selected destination. You have five options

  1. Direct Route-Calculate a route that is the most direct.
  2. Easy Route-Calculate a route that minimizes the number of turns needed.
  3. Minimize Freeways-Calculate a route that avoids freeway travel. If that is not possible, keep the amount of freeway travel to a minimum. This is not selectable (button grayed out) for trips greater than 100 miles.
  4. Minimize Toll Roads-Calculate a route that avoids, or minimizes travel on toll roads. This is not selectable (button grayed out) for trips greater than 100 miles.
  5. Maximize Freeways-Calculate a route that uses freeways as much as possible.

The audio-navigation unit transmits audio driving instructions before entering an intersection or passing a junction. The audio instructions come through the stereo amplifier to the front speakers.

Note. The front speakers are muted whenever the navigation system is giving guidance commands, and all of the speakers when the voice control system is being used.

The audio muting logic is orchestrated by the audio-navigation unit. The audio-navigation unit determines what audio source has priority to use the speakers.

The priority of the audio sources is as follows

HFL has the highest priority, followed by navigation, and finally the radio/CD-DVD player. The priority is passed by HFL to the audio-navigation unit by dedicated mute wires. The navigation mute signal is passed to the stereo amplifier.

The audio-navigation unit temporarily disables the voice control buttons, but allows guidance to be heard. In addition, the audio-navigation unit suppresses the output from the audio system, the XM receiver, the disc player, or other audio accessories.

When the navigation system sends out a voice route guidance command, the audio front speaker is muted, and the navigation voice is heard in the front speakers.

When the navigation voice control system is in use, all of the speakers are muted, and the navigation voice prompts are heard from the front speakers.

The climate control unit uses the sun's angle, along with the sunlight sensor to control the driver/passenger A/C air flow.

Off road tracking dots that can be followed on the map retrace your route back to a mapped (digitized) road.

The clock set up allows you to set daylight savings time, auto time zone and time adjustment.

Scheme 944: Control Interface

The display unit uses a liquid crystal display (LCD). The LCD is an 8-inch diagonal, thin film transistor (TFT), strip type with 336, 960 picture elements. The color film and fluorescent light are laid out on the back of the liquid crystal film.

Activates the voice control system in the audio-navigation unit to accept voice commands.

Note. If the navigation volume and/or voice feedback is turned off, this feature is disabled.

Returns the display to the previous screen (similar function as the CANCEL button).

This button is used to answer incoming calls or to make outgoing calls. You can also go directly to the Cellular Phone screen by pressing this button.

This button is used to end a call.

The navigation voice control switch is combined with the HFL switch. Navigation TALK/BACK commands are sent to the audio-navigation unit via the HandsFreeLink™ control unit.

Scheme 945: HFL-Navigation Voice Control Switch
Scheme 946: Audio-Navigation Switch Panel
  1. The navigation hard buttons and interface dial are used to input commands.
  2. The display mode button switches the display between Day mode. Night mode, and off. NOTE: When you activate this button, the navigation auto dimming is turned off until you turn the ignition switch to LOCK (0).
  3. The audio button displays the audio system information.

Receives voice commands and transmits them to the audio-navigation unit or HandsFreeLink™ control unit. The microphone unit consist of two microphones. The microphones detects the driver's voice and passenger's voice separately.

Scheme 947: HFL-Navigation Microphone

The following is a glossary of terms pertaining to the navigation system.

Note. All items may not apply to this vehicle. See the Navigation Manual for more information.

ItemDefinition
Active Sound ControlSee audio information.
AcuraLinkThis device receives information from the XM satellites and passes XM audio information to the audio unit. In addition, traffic and weather information is sent to the navigation unit.
ANC (Active Noise Cancellation)See audio information.
Address BookThe HFL system can import a copy of the phone book from and approved HFL compatible phone and display the imported phone book on the navigation screen as the address book. See the Navigation Manual for more information.
Auxiliary jackAllows the client to use a portable audio device to input audio recordings.
B-CANBody CAN Bus (see CAN)
BluetoothBluetooth is a short-range wireless technology intended to replace cables connecting portable devices (like cell phones) to the audio system (Bluetooth audio) or the HFL (Hands free phone use).
Bluetooth audioSee audio information.
Bread-crumbs (White dots)Off road tracking dots that can be followed on the map to retrace your route back to a mapped (digitized) road. This function can be turned on/off in Setup screen 1.
CANController Area Network. This communication network allows processors in the vehicle to send/receive information. The fuel pulses used by the MID trip computer are received from the ECM/PCM using the F-CAN (Fast Controller Area Network) bus.
CPUCentral Processing Unit. The main device within the navigation unit that coordinates the rest of the electronic functions.
CSSOutput shaft (Countershaft) Speed Sensor. This sensor reads the output shaft speed at the transmission and provides a speed pulse to the ECM/PCM.
DatabaseThis consists of the Map data, and the POI (Points Of Interest) data stored on the navigation DVD or navigation HDD.
DBWDrive By Wire. Allows electrical control of the throttle without the need of a mechanical linkage.
DCADetailed Coverage Area. Main metropolitan areas in the lower 48 states, and Canada are mapped to this level. See the Navigation Manual for a list of these areas.
DTCDiagnostic Trouble Codes. Use the HDS tablet to obtain, and troubleshoot the cause of these codes.
Dead ReckoningThe use of the speed signal, and yaw rate sensor to position the vehicle on the map even when tall buildings, or driving in a tunnel obscures the GPS signal.
Digitized RoadA road that appears on the navigation screen. The road name will appear at the bottom of the navigation screen. If the user drives off road the navigation system displays "Not on a digitized road", and after 1/2 mile (0.8 km), the breadcrumbs appear.
Disclaimer ScreenScreen containing cautionary information. It is meant to be read carefully, and acknowledged by the client when using the navigation system.
DVD or DVD-ROMDigital Versatile Disc. The navigation program and database resides on this disc. See the Navigation Manual for information on how to order a replacement or an navigation update DVD.
Dynamic Route GuidanceUses real-time traffic to change your driving route to help avoid extended traffic delays and incidents. Requires a data package subscription.
ECMEngine Control Module. Typically referred to as the ECM.
FAQFrequently Asked Questions. See the Navigation Manual for a list of the client FAQs, and troubleshooting information.
F-CANFast CAN Bus (see CAN)
GA-NetThe GA-Net allows the audio unit to communicate with all the audio and navigation components in a vehicle. If there is an open in the GA-Net, components or the entire audio and navigation system may appear inoperative.
GPSGlobal Positioning System. A network of 24 satellites in orbit around the earth. The navigation system can simultaneously receive signals from up to 12 satellites to accurately position the vehicle on the map.
HDDHard disc drive. The HDD navigation system does not use a navigation DVD, but uses a hard drive to contain the navigation software. Can be updated with a CD or DVD that is inserted into the audio disc slot.
HDSHonda Diagnostic System. A hand held tablet PC used for in diagnosing vehicle problems.
HIP (AcuraLink)This device receives information from the XM satellites and passes XM audio information to the audio unit. In addition, traffic and weather information is sent to the navigation unit.
HFLHandsFreeLink™ uses Bluetooth technology as a wireless link between it and an approved Bluetooth compatible cell phone. See the vehicle Owner's Manual or Quick Start Guide for more information.
HFTHands Free Telephone (see HFL)
H/UHead Unit. The navigation system display assembly in the dash.
InitializationThis refers to the period needed to re-acquire the GPS satellite orbital information whenever the navigation system power has been disconnected. This can take from 10 to 45 minutes.
Interface DialThis control device consists of a rotating knob and the buttons surrounding it. This device allows control of the navigation and the audio system on the screen.
Jog DialSee interface dial.
LCDLiquid Crystal Display (the navigation screen)
Map MatchingThe received GPS information allows the navigation system to position the vehicle on the map. Map matching has occurred if the map screen displays the current street name in the bottom-shaded area.
MatedThe process where the navigation unit electronically writes its passcode to the HDD.
MicAbbreviation for the microphone used for receiving voice commands. The active noise cancellation unit may also use it to check its tuning (if equipped). It is located near the map light in the ceiling.
MIDMulti-Information Display
MP3 music filesMP3 is an audio coding formal. MP3 is a popular audio compression format on the internet and computers. CDs and PC cards mid three files can be played on some vehicle audio system.
MWManeuver Window. While on-route to a destination, this window displays information about the next maneuver.
NaviAbbreviation for the Navigation System.
Off-Road TrackingSee Breadcrumbs.
Off RouteThis occurs when the user leaves mapped roads. Off road tracking dots (breadcrumbs) are displayed if the option is enabled in the setup menu. The user can use them to return to a mapped road. The bottom of the navigation screen displays "Not on a digitized road".
Outlying AreasThese are rural areas that typically have only their main roads mapped. All other roads are shown in light brown for reference only, since they have not been verified.
PairedLinking your cell phone to the HFL.
PC Card SlotThe PC card (PCMCIA, type II) slot is for factory use only. Make sure that the sliding door is closed at all items, if opened, an error message is displayed on the screen (if equipped).
PCMPowertrain Control Module. This unit supplies the navigation system speed signal, and charge signal via the F-CAN network. Also referred to as ECM.
PCMCIAA computer industry defined term referring to the PC card slot standard.
PINPersonal Identification Number, a random 4 digit number created by the client to protect personal information.
POIPoint Of Interest. These are the businesses, schools, etc. found under the places option on the main menu.
PolygonColored areas on the map screen denoting parks, schools, etc. Refer to the Navigation Manual "Driving to Your Destination" for a list of the assigned colors.
QWERTYKeyboard layout resembling the typewriter keys. The keyboard layout can be changed to an alphabetical layout in the Setup mode.
SCS service connectorThe service check signal 2-pin connector used to put the navigation system into the diagnostic mode.
Security CodeCode needed to activate the navigation system. You can get the security code from the iN by entering the navigation unit serial number. You can find the serial number on the diagnostic screens (Unit Check, ECU Info) or on the underside of the navigation unit.
TuningA continual update of internal navigation system scaling factors. See the individual sensor tuning discussions under either System Description, or System Diagnostic Mode.
Unverified StreetsThese streets have not been verified for turn restrictions, one-way, etc. They appear light brown on the map. You can enter address destinations in these areas, but depending on your Unverified Routing choice in setup, voice guidance may end at the last verified street closest to your destination.
USB portAllows the client to play data such as input audio recording from portable audio devices (such as iPod) or data from USB flash memory.
Verified StreetsThese streets consist of the detailed metropolitan coverage areas, and all other inter-town connection roads. These roads are shown in black on the map.
VPVehicle Position. When in map mode, this circular icon shows the vehicle position on the map. Touch this icon to show the latitude, longitude, and elevation of your current position.
VRVoice Recognition. This allows voice control of many of the navigation functions. The hardware consists of the microphone, voice control switch (navigation Talk/Back buttons), and the front speakers. See the overview for more information.
VSPVehicle Speed Pulse. This pulse signal coming from the ECM/PCM (via the CSS) is used to update the Vehicle position on the map. These pulses do not indicate direction (forward or backward). When vehicle is in R position, the navigation receives a signal and directs the VP to move backwards on the map.
Weather InformationThe navigation system receives and displays weather information.
XMThis device receives information from the XM satellites and passes XM audio information to the audio unit. In addition, traffic and weather information is sent to the navigation unit (see AcuraLink).
Yaw Rate SensorThis device is located in the navigation unit and senses the side-to-side twisting force generated when the vehicle turns. See a detailed description of how this sensor works.

GLOSSARY REFERENCE CHART

This diagram below shows all of the navigation diagnostic features available for system troubleshooting. The diagram starts at the center, and works outward in layers.

Access to the diagnostic features begins by starting the vehicle. This is necessary so the system can check the other systems connected by various busses. After starting the vehicle you can enter the diagnostic mode either by pressing and holding MENU, MAP/GUIDE, and CANCEL, or by connecting the 2-PIN SCS service connector.

The main menu screen allows 2 checking modes - one automatic, and one manual

Scheme 948: Diagnostic System Diagram
  1. The automatic diagnostic check starts when you select SELF DIAGNOSTIC MODE. The system runs for several seconds, and reports any issues with Red icons. Rotate the interface dial and select the icon you wish obtain the problem details.
  2. The manual diagnostic check is selected from the main menu by selecting DETAIL INFORMATION AND SETTING. The traditional diagnostic menu is displayed. This allows you to obtain additional details as instructed in the troubleshooting procedures. NOTE: Do not clear or change settings unless specified by either the Service Manual troubleshooting procedures or by the factory.

Note. Refer to the audio information for the connectors B, C, E, F, and K inputs and outputs (see AUDIO UNIT CONNECTOR FOR INPUTS AND OUTPUTS (WITH ELS AUDIO) ).

Scheme 949: Navigation Unit Connector for Inputs and Outputs

Note. Refer to the audio system information for the terminals inputs and outputs not shown (see AUDIO UNIT CONNECTOR FOR INPUTS AND OUTPUTS (WITH ELS AUDIO) ).

Scheme 950: AUDIO-NAVIGATION UNIT CONNECTOR A (24P)

Audio-Navigation Unit Connector A (24P)

CavityWire ColorTerminal NameDescriptionVoltage (about)Symptom
4BRIMSCTY2Security signal to navigation display unit0 VIf open: The security system sets, and does not trip when navigation display unit is removed. If short to ground: The security system sets, and does not trip when navigation display unit is removed.
12BLKMAIN GND (Ground)Ground for audio-navigation unit (G651)0 VIf open: Possible erratic system operation. If short to ground: No effect on system.
14PURACC (Accessory)Power source for accessoriesBattery voltage at ACC (I)If open: Display picture goes out (display back light still on). If short to ground: Blows the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box.
15BLUVSP (Vehicle speed pulse)Vehicle speed pulse signal from ECM/PCM0 - 5 V pulses average 2.5 V (Depending on bus traffic)If open: No vehicle speed pulse. Diagnostic screen Car Status, VSP=0. If short to ground: No vehicle speed pulses. Diagnostic screen Car Status, VSP=0.
24WHT+ B (+ B Power source)Continuous power sourceBattery voltageIf open: Navigation display picture goes out (display back light still on). NOTE: System reboots to enter code screen. If short to ground: Blows the No. 15 (10 A) fuse in the under-hood fuse/relay box.
NOTE
System reboots to enter code screen.

TERMINAL DESCRIPTION CHART

Note. Refer to the audio system information for the terminals inputs and outputs not shown (see AUDIO UNIT CONNECTOR FOR INPUTS AND OUTPUTS (WITH ELS AUDIO) ).

Scheme 951: AUDIO-NAVIGATION UNIT CONNECTOR D (20P)

Audio-Navigation Unit Connector D (20P)

CavityWire ColorTerminal NameDescriptionVoltage (about)Symptom
4ORNNAVI-SI (Air conditioner serial in)Communication signal for climate control unitIf open/short: HVAC will not respond to navigation commands.
5PURNAVI-SO (Air conditioner serial out)Communication signal for climate control unitIf open/short: HVAC will not respond to navigation commands.
14BRNNAVI-CLK (Air conditioner clock)Check signal for climate control unitIf open/short: HVAC will not respond to navigation commands.
17GRNRG L GND (Route guidance ground)Ground for voice guidance, and Voice Recognition (VR) prompts0 VIf short to ground: No effect on voice output. If open: No effect on voice output.
19REDRG L+ (Route guidance voice positive)Front audio signal of voice guidance, and Voice Recognition (VR) promptsAudio signal 0.004-0.04 VIf short to ground: If voice activated, front center speaker buzz; if voice off, no effect. If open: If voice activated, front center speaker buzz; if voice off, no effect.
20BLK (1)RG L SH (Route guidance shield)Shield for terminals No. 17 and No. 190 VIf short to ground: No effect on voice output. If open: No effect on voice output.
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

TERMINAL DESCRIPTION CHART

Scheme 952: AUDIO-NAVIGATION UNIT CONNECTOR G (8P)

Audio-Navigation Unit Connector G (8P)

CavityWire ColorTerminal NameDescriptionVoltage (about)Symptom
2BRNC-SIG (Composite signal)Composite video (vertical / horizontal) Synchronizing signal0.2 V AC average in RGB color diagnostic modeIf open: Picture rolls horizontally, colors still visible. If short to ground: Picture rolls horizontally, colors still visible.
3REDG-SIG (Green signal)Green color signal0.7 V AC average in RGB color diagnostic modeIf open: Green color missing (see RGB color diagnosis). If short to ground: Green color missing (see RGB color diagnosis).
4BLUGND SIG (Ground signal)Ground for color signal0 VIf open: No effect on system. If short to ground: No change to display.
6GRY (1)SH SIG (Shield signal)Shield for terminals No. 2, No. 3, No. 4, No. 7, and No. 80 VIf open: No change to display. If short to ground: No effect on system.
7YELB-SIG (Blue signal)Blue color signal0.7 V AC average in RGB color diagnosisIf open: Blue color missing (see RGB color diagnosis). If short to ground: Blue color missing (see RGB color diagnosis).
8WHTR-SIG (Red signal)Red color signal0.7 V AC average in RGB color diagnosisIf open: Red color missing (see RGB color diagnosis). If short to ground: Red color missing (see RGB color diagnosis).
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

TERMINAL DESCRIPTION CHART

Scheme 953: AUDIO-NAVIGATION UNIT CONNECTOR H (28P)

Audio-Navigation Unit Connector H (28P)

CavityWire ColorTerminal NameDescriptionVoltage (about)Symptom
4GRYILL+ (Illumination positive)Parking light on signalLights on: battery voltage, Lights off: 0 VIf open: When brightness=Auto, night mode for the display is inoperative when lights on. If short to ground: Auto, night mode for the display is inoperative when lights on.
5YELDIAG- (Diagnostic negative)Ground for service check signal0 VIf open: The system will not go into diagnostic mode when using the SCS service connector. If short to ground: No effect on system.
9RED (2)HFL/HIP COMM2 (HFL communication 2)Communication signal for HFL4.5 V DCSolid red HFL icon in System Links. Phone icon in the Route To screen is grayed out.
GRN (3)HFL COMM2 (HFL communication 2)Communication signal for HFL4.5 V DCPhone icon in the Route To screen is grayed out. Solid red HFL icon in System Links.
10WHT (2)HFL/HIP COMM1 (HFL communication 1)Communication signal for HFL4.5 V DCPhone icon in the Route To screen is grayed out. HFL icon in System Links changes between red and green.
BLK (3)HFL COMM1 (HFL communication 1)Communication signal for HFL4.5 V DCHFL icon in System Links changes between red and green. Phone icon in the Route To screen is grayed out.
13GRY (1)JOG SH (Interface dial Shield jog)Shield for terminal No. 26
14GRY (1)MIC SIG SH (HFL mic signal shield)Shield for terminals No. 27 and No. 280 VIf open: No effect on voice control. If short to ground: No effect on voice control.
18WHTDIAG+ (Diagnostic positive)Service check signal for navigation system5-6 VIf open: No effect on system. If short to ground: System goes into diagnostic mode at ACC (I) or ON (II).
20LT BLUBACK LT (Back light or reverse signal)Reverse signal of select lever from reverse relayIn R position: battery voltage, Otherwise 0 VIf open: Navigation never sees reverse. Diagnostic screen Car Status, Back=0. If short to ground: Blows the No. 5 (7.5 A) fuse in the driver's under-dash fuse/relay box.
22BLK (2)HFL/HIP COMM4 (HFL communication 4)Communication signal for HFL5 V DCPhone icon in the Route To screen is grayed out. Solid red HFL icon in System Links.
WHT (3)HFL COMM4 (HFL communication 4)Communication signal for HFL5 V DCSolid red HFL icon in System Links. Phone icon in the Route To screen is grayed out.
23GRN (2)HFL/HIP COMM3 (HFL communication 3)Communication signal for HFL5 V DCPhone icon in the Route To screen is grayed out. HFL icon in System Links changes between red and green.
RED (3)HFL COMM3 (HFL communication 3)Communication signal for HFL5 V DCHFL icon in System Links changes between red and green. Phone icon in the Route To screen is grayed out.
24GRY (1)HFL/HIP COMM SH (shield HFL) (2)Shield for terminals No. 9, No. 10, No. 22, and No. 230 V
HFL COMM SH (shield HFL) (3)Shield for terminals No. 9, No. 10, No. 22, and No. 230 V
26WHTJOG (Interface dial Jog)Interface dial operation signal0-5 V pulsesIf open: You cannot operate navigation system. If short to ground: You cannot operate navigation system.
27REDMIC SIG- (HFL mic signal negative)Ground for microphone signal0 VIf open: microphone signal shown as red in diagnostics: System Links and Functional Setup Mic Level. If short to ground: No effect on voice recognition.
28GRNMIC SIG + (HFL mic signal positive)Microphone output signal positive4-5 V (TALK button pressed)If open: microphone signal shown as red in diagnostic screens: System Links and Functional Setup Mic Level. If short to ground: microphone signal shown as red in diagnostic screens: System Links and Functional Setup Mic Level.
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram. (2) With AcuraLink (3) Without AcuraLink
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(2)With AcuraLink
(3)Without AcuraLink

TERMINAL DESCRIPTION CHART

Scheme 954: AUDIO-NAVIGATION UNIT CONNECTOR J (2P)

Audio-Navigation Unit Connector J (2P)

CavityWire ColorTerminal NameDescriptionVoltage (about)Symptom
1GPS SIGGPS signal5 VIf open: GPS icon on screen is not shown, System Links screen GPS Ant. shown as red. If short to body ground: Same as open.
2GPS SH GNDGround for GPS signal0 VIf open: GPS icon on screen is not shown. System Links screen GPS Ant. shown as red. If short to body ground: No effect on system.

TERMINAL DESCRIPTION CHART

Scheme 955: Navigation Display Unit Connector for Inputs and Outputs
Scheme 956: NAVIGATION DISPLAY UNIT 28P CONNECTOR

Navigation Display Unit 28P Connector

CavityWire ColorTerminal NameDescriptionVoltage (about)Symptom
3BRNC-SIG (Composite signal)Composite video (vertical / horizontal) synchronizing signal0.7 AC averageIf short to ground: Picture rolls horizontally, colors still visible. If open: Picture rolls horizontally, colors still visible.
4WHTR-SIG (Red signal)Red color signal0.7 AC averageIf open: Red color missing (see RGB color diagnosis). If short to ground: Red color missing (see RGB color diagnosis).
5REDG-SIG (Green signal)Green color signal0.7 AC averageIf short to ground: Green color missing (see RGB color diagnosis). If open: Green color missing (see RGB color diagnosis).
6YELB-SIG (Blue signal)Blue color signal0.7 AC averageIf open: Blue color missing (see RGB color diagnosis). If short to ground: Blue color missing (see RGB color diagnosis).
8BLUB-CAN LCommunication signalIgnition switch ON (II): 2.5-6 V pulses, 2.5 V average (depends on bus traffic)If open: When brightness=Auto, night mode for the display is inoperative when lights on. No change to rearview camera image. If short: Same conditions as when open, and also sets the U1280 (B-CAN BUS OFF).
9PNKB-CAN HCommunication signalIgnition switch ON (II): 2.5-6 V pulses, 2.5 V average (depends on bus traffic)If open: When brightness=Auto, night mode for the display is inoperative when lights on. No change to rearview camera image. If short: Same conditions as when open, and also sets the U1280 (B-CAN BUS OFF).
10BLKVCC GND (Ground camera)Ground for camera signal0 VIf short to ground: No change to rearview camera image. If open: No change to rearview camera image.
11GRNCAMERA VCC (VCC supply)Power source for rearview camera8 VIf open: When put into reverse, the navigation screen goes back (backlight still operates). If short to ground: When put into reverse, the navigation screen goes back (backlight still operates).
12PURACC (Accessory)Power source for accessoryBattery voltage at ACC (I)If open: Display and buttons do not work. If short to ground: Blows the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box.
14WHT+ B (+B power source)Continuous power sourceBattery voltageIf short to ground: Blows the No. 15 (10 A) fuse in the under-hood fuse/relay box. If open: Screen completely off (no backlight visible).
15GRY (1)SH SIG (Shield signal)Shield for terminals No. 3, No. 4, No. 5, No. 6, and No. 160 VIf short to ground: No effect on system. If open: No change to display.
16BLUGND SIG (Ground signal)Ground for display unit0 VIf open: No change to display. If short to ground: No change to display.
18BRNSCTY2 (Security)Security signal to audio-navigation unit0 VIf short to ground: The security system sets, and does not trip when navigation display unit is removed. If open: The security system sets, and does not trip when navigation display unit is removed.
19GRNSCTY (Security)Security signal from passenger's MICU0 VIf open: The security system sets, and does not trip when the screen is removed. If short to ground: The security system sets, and does not trip when the screen is removed.
20GRY (1)GA-NET BUS SH (GA-Net bus shield)Shield for terminals No. 21 and No. 220 VIf open: No change to display. If short to ground: No change to display.
21REDGA-NET BUS+ (GA-Net bus positive)Data bus (+) GA-Net0-5 V pulses average 2.5 V depends on bus trafficIf short to ground: GA-Net related system do not work. If open: Navigation buttons do not work.
22GRNGA-NET BUS-(GA-Net bus negative)Data bus (-) GA-Net0-5 V pulses average 2.5 V depends on bus trafficIf short to ground: GA-Net related system do not work. If open: Navigation buttons do not work.
23REDCAMERA GND (Ground)Ground for rearview camera0 VIf open: No change to rearview camera image. If short to ground: No change to rearview camera image.
24WHTCAMERA V (NTSC signal)Video signal from rearview camera1 V ACIf open: No change to rearview camera image. If short to ground: No change to rearview camera image.
25YELCAMERA ADAPT (Adaptive camera)Control signal for rearview camera0 VIf short to ground: No change to rearview camera image. If open: No change to rearview camera image.
26GRY (1)CAMERA SH (Camera shield)Shield for terminals No. 10, No. 11, No. 23, and No. 240 VIf open: No rearview camera image. If short to ground: No change to rearview camera image.
27BLKGND (Ground)Ground for navigation display unit (G651)0 VIf open: No change to display. If short to ground: No change to display.
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

TERMINAL DESCRIPTION CHART

Scheme 957: Interface Dial Connector for Inputs and Outputs
Scheme 958: INTERFACE DIAL 5P CONNECTOR

Interface Dial 5P Connector

CavityWire ColorTerminal NameDescriptionVoltage (about)Symptom
1WHTJOG (jog)Interface dial operation signal0-5 V pulsesIf open: You can not operate the navigation system. If short to ground: You can not operate the navigation system.
2GRY (1)JOG SH (Shield jog)Shield for terminal No. 1
3BLKGND (Ground)Ground for interface dial (G401)0 VIf open: You can not operate the navigation system. If short to ground: You can not operate the navigation system.
4PURACC (Accessory)Power source for interface dialBattery voltage at ACC (I)If open: You can not operate the navigation system. If short to ground: Blows the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box.
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

TERMINAL DESCRIPTION CHART

Scheme 959: HFL-Navigation Microphone Connector for Inputs and Outputs
Scheme 960: HFL-NAVIGATION MICROPHONE 7P CONNECTOR

HFL-Navigation Microphone 7P Connector

CavityWire ColorTerminal NameDescriptionVoltage (about)Symptom
2BRNMIC- (HFL mic signal negative)Ground for microphone signal0 VIf open: microphone signal shown as red in diagnostics: System Links and Functional Setup Mic Level. If short to ground: No effect on voice recognition.
3YELMIC+ (HFL mic signal positive)Microphone output signal positive8 VIf open: microphone signal shown as red in diagnostics: System Links and Functional Setup Mic Level. If short to ground: Microphone signal shown as red in diagnostic screens: System Links and Functional Setup Mic Level.
5LT GRNHFL MUTEHFL MUTE signal0-5 VIf open: You can not operate HFL sound. If short to ground: You can not operate audio sound.
6PURACC (Accessory)Power source for accessoryBattery voltage at ACC (1)If open: You can not operate voice control. If short to ground: Blows the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box.
7WHT+ B (+ B Power source)Continuous power sourceBattery voltageIf open: You can not operate HFL and voice control. If short to ground: Blows the No. 15 (10 A) fuse in the under-hood fuse/relay box.

TERMINAL DESCRIPTION CHART

Scheme 961: Rearview Camera Connector for Inputs and Outputs
Scheme 962: REARVIEW CAMERA 6P CONNECTOR (Sedan)

Rearview Camera 6P Connector

CavityWire ColorTerminal NameDescriptionVoltage (about)Symptom
1GRNCAMERA VCC (VCC supply)Power source for rearview camera8 VIf open: No rearview camera image. If short to ground: When put into reverse, the navigation screen goes black (display backlight still operative).
2BLKCAMERA GND (Ground)Ground for rearview camera0 VIf short to ground: No change to rearview camera image. If open: No change to rearview camera image.
3REDVCC GND (Ground camera)Ground for camera signal0 VIf short to ground: No change to rearview camera image. If open: No change to rearview camera image.
4WHTCAMERA V (Video camera)Video signal for rearview camera0.3 VIf short to ground: No change to rearview camera image. If open: No change to rearview camera image.
5GRY (1)CAMERA SH (Shield)Shield for terminals No. 1, No. 2, No. 3, No. 4, and No. 60 VIf short to ground: No change to rearview camera image. If open: No change to rearview camera image.
6BRNCAMERA ADPT (Adaptive camera)Control signal for rearview camera0 VIf short to ground: No change to rearview camera image. If open: No change to rearview camera image.
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

TERMINAL DESCRIPTION CHART

Scheme 963: REARVIEW CAMERA 6P CONNECTOR (Sport Wagon)

Rearview Camera 6P Connector

CavityWire ColorTerminal NameDescriptionVoltage (about)Symptom
1YELCAMERA ADPT (Adaptive camera)Control signal for rearview cameraConnected: 0 V Disconnected: 3.5 VIf short to ground: No change to rearview camera image. If open: No change to rearview camera image.
2GRY (1)CAMERA SH (Shield)Shield for terminals No. 1, No. 3, No. 4, No. 5, and No. 60 VIf short to ground: No change to rearview camera image. If open: No change to rearview camera image.
3BLKCAMERA V (Video camera)Video signal for rearview camera0.3 VIf short to ground: No change to rearview camera image. If open: No change to rearview camera image.
4REDCAMERA GND (Ground)Ground for rearview camera0 VIf short to ground: No change to rearview camera image. If open: No change to rearview camera image.
5GRNVCC GND (Ground camera)Ground for camera signal0 VIf short to ground: No change to rearview camera image. If open: No change to rearview camera image.
6WHTCAMERA VCC (VCC supply)Power source for rearview cameraConnected with shift lever in R: 8 V Disconnected: 0 VIf open: No rearview camera image. If short to ground: When put into reverse, the navigation screen goes black (display backlight still operative).
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

TERMINAL DESCRIPTION CHART

Scheme 964: Circuit Diagram
Scheme 965
Scheme 966
Scheme 967
Scheme 968
Scheme 969

There are two ways to enter the diagnostic mode

Mode 1

Start the vehicle, and at the disclaimer screen use the navigation hard buttons

Press and hold the MENU, MAP/GUIDE, and CANCEL, buttons for about 3 seconds. The display screen goes directly to the Select Diagnosis Items menu shown.

Scheme 970: Start-Up Procedure and Diagnostic Menu
  1. Self-Diagnosis Mode (runs the automatic diagnosis of the navigation system)
  2. Detail Information & Setting (Can help you to manually diagnose the navigation system)

Mode 2

Start the vehicle. When the globe screen appears, connect the SCS service connector (see FORCED STARTING OF THE AUDIO-NAVIGATION UNIT ) to the navigation service check connector located by the front passenger's kick panel. The screen changes to the System Links screen, and automatically begins running the self diagnosis. See the System Links information for more information.

Note. When finished troubleshooting, make sure to remove the SCS service connector.

With AcuraLink

Scheme 971

Without AcuraLink

Scheme 972
Scheme 973: System Links
Scheme 974
  1. Enter this screen by selecting Self Diagnosis Mode from the Select Diagnosis Items main menu or by connecting the SCS service connector. The message at the bottom of the screen flashes indicating the diagnosis is running. Make sure you enter the anti-theft code. NOTE: The system cannot complete a full diagnosis unless the engine is running. With AcuraLink Without AcuraLink
  2. Rotate the interface dial to select the icon you want to diagnose. Press the interface dial to see the details of that diagnostic function. The System Links function runs automatically and displays a flashing message at the bottom of the screen reminding you to have the engine running for the test. The diagnosis tests the following: Most of the wires connecting the navigation components that are shown in the block diagram. The results from the various components shown in the block diagram. The audio-navigation unit tests the microphone by listening to the bong sound produced by the audio-navigation unit from the speakers when the diagnosis is started. This requires that the audio system be operating normally. When the diagnosis finishes, the icons turn different colors based on their test status. The color definitions are shown below and can also be seen by selecting Help on the System Links screen. The indication on the screen may not change until you exit and reenter the Self-Diagnosis mode. In some cases, you may have to restart the engine for the indication to change. After you repair the affected component or harness, repeat this diagnosis. Each icon color is explained in the table. ICON COLORS DESCRIPTION CHART Icon Colors Description Green The system ran a diagnosis and the results are OK. Red Errors that may require replacement of hardware or harness. Examples are connection error or memory diagnosis errors. Troubleshoot for navigation DTCs. Yellow Errors that do not require hardware replacement, such as an open display cover, leaving the ignition switch in ACC (I), or because of a missing accessory. White The diagnosis is running. The screen functions are locked out while the diagnosis runs. Gray The system cannot automatically check this function. You have to select the diagnosis item and manually do additional testing, like checking the navigation buttons in the Hard Key test. When you complete the Hard Key test and return to the System Links menu, the gray icon turns green. NOTE: By selecting the HELP icon, you can see a description for each color.
IconIcon Color
GREENREDYELLOWWHITEGRAY
DisplayResult of "Connection" under the "Display" diagnosis menu is OK.Result of "Connection" under the "Display" diagnosis menu is NG.Executing (Not completed)
RadioResult of "Connection" under the "Radio" diagnosis menu is OK.Result of "Connection" under the "Radio" diagnosis menu is NG.Executing (Not completed)
XM (HIP) (1)Result of AcuraLink control unit (XM receiver) and Audio-navigation unit connection is OK.Result of AcuraLink control unit (XM receiver) and Audio-navigation unit connection is NG.Executing (Not completed)
XMResult of "Connection" under the "XM" diagnosis menu is OK.Result of "Connection" under the "XM" diagnosis menu is NG.Executing (Not completed)
GPS Ant.All result of "Antenna" and "Receiver in NAVI ECU" is OK.Any result of "Antenna" and "Receiver in NAVI ECU" is NG.Executing (Not completed)
Rear-CameraResult of "Connection" under the "Rear-Camera" diagnosis menu is OK.Result of "Connection" under the "Rear-Camera" diagnosis menu is NG.Executing (Not completed)
A/CResult of "Connection" under the "Aircon" diagnosis menu is OK while "Ignition" is ON.Result of "Connection" under the "Aircon" diagnosis menu is NG while "Ignition" is ON.Executing (Not completed)
B-CANAll result of B-CAN related units are OK.Any result of B-CAN related units are NG.Executing (Not completed)
HFLResult of "Connection" under the "HFL" diagnosis menu is OK.Result of "Connection" under the "HFL" diagnosis menu is NG.Executing (Not completed)
MicThe microphone detects the sound "Pi-Pi-Pon" at the system link menu.The microphone could not detect the sound "Pi-Pi-Pon" at the system link menu.Executing (Not completed)
ECU InfoBoth V-RAM and D-RAM are OK, and all "Program Flash", "Serial No.", "Model" are available.Either the V-RAM or D-RAM is NG, or any of the "Program Flash", "Serial No.", "Model" is unavailable.Executing (Not completed)
Hard KeyAll buttons are pressed and are detected under "Hard key" menu.All buttons are not pressed or pressed but not detected under "Hard key" menu, or exit from "Hard key" menu without the button not detected.Until changing to "Hard key" menu.
Error History"Hard Error" or "Soft Error" is detected under "Error History" menu."Hard Error" or "Soft Error" is not detected under "Error History" menu.
HDDResult of "Connection" under the "HDD" diagnosis menu is OK.Result of "Connection" under the "HDD" diagnosis menu is NG.Executing (Not completed)
Yaw SensorResult of "Zero Point Output" under the "Yaw Sensor" diagnosis menu is OK.Result of "Zero Point Output" under the "Yaw Sensor" diagnosis menu is NG.Result of the "Zero Point Output" under the "Yaw Sensor" diagnosis menu is NO CHECK.Executing (Not completed)
Car StatusCheck these systems manually.
Sub DisplayResult of connection under the "Sub Display" diagnosis menu is OK.Result of connection under the "Sub Display" diagnosis menu is NG.Executing (Not completed)
USBAudio-navigation unit connector K (7P) is connected.Audio-navigation unit connector K (7P) is connected.Executing (Not completed)
(1) With AcuraLink
(1)With AcuraLink

ICON COLOR INFORMATION CHART

Note. If the vehicle left the factory in the factory diagnostic mode, you will see this screen every time you turn the ignition switch to ON (II). You may also see this screen if you recently replaced the audio-navigation unit.

When the audio-navigation unit is powered up for the first time at the factory or sometimes when a remanufactured audio-navigation unit is installed, the factory diagnostic screen (In Line Diag) appears. Normally the factory does the steps necessary to verify proper operation and terminate the factory diagnosis. Until the proper confirmation sequence is done, the screen appears every time the vehicle is started.

Scheme 975: Factory Diagnostic Screen In Line Diag

Follow these steps to prevent the screen from showing up in the future

Scheme 976
  1. Press and hold the MENU, MAP/GUIDE, and CANCEL buttons at the same time until the Select Diagnosis Items screen comes up. Then release the buttons.
  2. Press and hold the MAP/GUIDE button until the In Line Diag Setting screen appears.
  3. Set the In Line Diag Setting to Complete, then select Return twice to exit the diagnostic mode.

These sections allow you to run a specific diagnosis and allows additional setting choices for some screens that are not shown when selecting an icon from the System Links screen.

When you select the Detail Information & Setting menu, the main diagnosis menu is displayed.

Scheme 977: Detailed Information & Setting

After the display changes to the Diagnostic Menu, select the item you want to check, and the test begins. To return to the previous screen, select Return.

Scheme 978

Overview of the navigation display unit

  1. The navigation display unit communicates with the audio-navigation unit over its own GA-Net bus. Information sent by the audio-navigation unit to the navigation display unit includes commands to control the LCD back light.
  2. The security system protects the navigation display unit by daisy-chaining the security signal through the components.

These screens allow you to troubleshoot the navigation display unit. Select the item you want to troubleshoot, and follow the diagnostic instructions.

Scheme 979

RGB Color

This screen verifies that the display unit is receiving the video (R, G, B and Composite sync) signals properly. The three primary colors should all appear without distortion. The combination of all three should produce a central white section. If any of the colors are missing, troubleshoot for the color signal (see PICTURE IS MISSING A COLOR OR TONE OR IS AN ODD COLOR ). if the picture has lines in it or scrolls horizontally, or vertically, troubleshoot for a Composite sync problem (see PICTURE HAS LINES, ROLLS, OR IS BLURRY ).

Scheme 980

Gray Tone

This screen diagnoses problems with contrast. You should be able to see the changes from bar to bar across the scale. It is normal for the two bars on either side to appear the same. If you cannot see changes from bar to bar, replace the navigation display unit (see NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION ).

Scheme 981

Black Raster

This diagnostic screen checks for pixels that may be stuck on. The entire display must be black. If pixels are stuck on, replace the navigation display unit (see NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION ).

Scheme 982

Color Pattern

The diagnostic screen shows the colors being used for the map and menu screens. This is for factory use only. To check the color signal, use the RGB Color diagnosis found under the Monitor Check.

Scheme 983

White Raster

This diagnostic screen checks for pixels that may be dead (off). The entire display must be white. If there are dead pixels, replace the navigation display unit (see NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION ).

Scheme 984

Monitor Adjustment

This is for factory use only. The Default button will reset the display position to factory specifications.

Scheme 985

Some of the tests and screens that are displayed under the Unit Check are different from the other detailed checks.

To start the test, select the item you want to check starts.

  1. Display
  2. Radio
  3. GPS
  4. Aircon
  5. HFL
  6. HDD
  7. DVD Mech
  8. Hard Key
  9. Yaw Sensor
  10. ECU Info.
  11. Rear Camera
  12. XM (Without AcuraLink)
  13. USB Memory Information
  14. Sub Display

With AcuraLink

Scheme 986

Without AcuraLink

Scheme 987
Scheme 988

Display

This diagnosis does additional checks on the communication bus between the audio-navigation unit and the navigation display. This test also checks the internal electronic functions.

Scheme 989
  1. When the connection is NG, first check for loose terminals at the audio-navigation unit and the navigation display unit connections. Next check for an open or short in the communication line between the audio-navigation unit and the navigation display unit. If the line has an open or short, replace the affected shielded harness.
  2. The version represents the software version in the display.

Radio

This diagnostic screen checks the audio-navigation unit internal radio tuner and CD/DVD player. If connection is NG, replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ).

Note. If the XM link appears red, but the radio link appears green in the System Links, refer to audio system symptom troubleshooting.

Scheme 990

GPS

This diagnosis tests the GPS antenna connection and the GPS receiver condition.

Scheme 991
  1. In the GPS menu, if the Antenna indicates NG, then check the entire GPS antenna wire from the audio-navigation unit to the GPS antenna. If the wire is crushed or damaged, substitute a known-good GPS antenna (see «GPS ANTENNA REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). If this diagnosis reads OK, replace the original GPS antenna (see «GPS ANTENNA REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). If the diagnosis still reads NG (Antenna), then replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  2. Select Information to see the GPS satellite details.

Aircon

This diagnosis tests the climate bus connection (NAVI-SI and NAVI-SO) between the audio-navigation unit and the climate control unit. Make sure the engine is running for this test.

When the connection appears NG, go to Navigation cannot control HVAC by voice command troubleshooting (see NAVIGATION CANNOT CONTROL HVAC BY VOICE COMMAND ).

Scheme 992

HFL

This checks the 4 wire communication bus between the HandsFreeLink™ control unit and the audio-navigation unit.

When connection is shown with NG, check the HFL function and go to appropriate troubleshooting in HandsFreeLink™ System.

Scheme 993

HDD

This screen shows the HDD mount error and the temperature.

The screen shows a list of total and free capacities of each partition.

Select the Error History will display the error history that occurred while reading or writing the data to HDD.

  1. When the HDD Status is OK, the connection between the HDD pins and the audio-navigation unit are good.
  2. When the HDD Status is NG*, there is a connection problem between the HDD pins and the audio-navigation unit.

* When the HDD Status is NG, the screen does not show the free and total capacities of each partition, however, it shows the temperature.

Scheme 994

DVD Mech

Do this procedure only when directed by the factory or other Honda service information (like a service bulletin).

This diagnostic screen checks the audio-navigation unit internal DVD player mechanism.

Scheme 995
  1. The screen shows DVD Mech version. When the audio-navigation unit can read the version, the screen shows Connection OK. If the version number cannot be read, the screen shows the connection as NG.
  2. Inserting the disc that contains a DVD Mech update program allows you to select Download. Otherwise it is grayed out.
  3. To update the DVD Mech, you must insert the update disc before selecting this screen. If you insert the update disc when you are on this screen, the DownLoad button stays grayed out. If this happens, exit the DVD Mech screen and start the procedure again.

Hard Key

This diagnosis tests the interface dial, the buttons that surround it, the audio remote switch, and the HFL-navigation voice control switch. For this model, the interface dial and buttons use the serial bus for communications.

To complete the test, touch each button on the vehicle's control panel, and move the interface dial to each indicated position. As each function is tested, the corresponding button on the display should highlight.

To exit, push in and hold the interface dial.

Note. You cannot use the onscreen return button to exit this function.

Scheme 996

Select Steering Key

Scheme 997

Select Audio Key

Scheme 998

Select Navi Key

Scheme 999

Yaw Sensor

This screen gives a quick test of the yaw rate sensor functionality based on the two voltages Sensor and Offset. For more information see the Yaw Rate Diagnosis.

Scheme 1000

ECU Info

This screen looks for problems in the audio-navigation unit. When you initiate this diagnosis, the audio-navigation unit may freeze or delay up to a minute while the diagnosis runs.

Scheme 1001
  1. D-RAM is NG, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  2. Program Flash: Displays the version of the navigation software in memory.
  3. Program on HDD: If displayed, this value represents the version of the navigation software on the audio-navigation unit HDD.
  4. Program on DVD: If displayed, this value represents the version of the navigation software on the audio-navigation unit DVD player.
  5. Serial No. should be the same as the serial number found on the upper side of the audio-navigation unit. You need this number to obtain the security code from the Interactive Network (iN) system.
  6. DB Version: Displays the version of the database on the audio-navigation unit HDD.
  7. HDD Version: Display the version of the audio-navigation unit HDD.
  8. D-RAM check is for factory use only.

Rear Camera

This test checks whether the rearview camera is connected to the navigation display unit.

When connection is shown NG, check the rearview camera signal line.

Scheme 1002

XM (Without AcuraLink)

This checks the GA-Net Bus line to the XM receiver.

When connection is shown with NG, check the connection between the XM receiver and the audio-navigation unit.

Scheme 1003

USB Memory Information

If the USB memory is connected to the USB port, the screen displays the USB memory size, the Product ID, Vender ID, and connection status.

Scheme 1004

Sub Display

This test checks the internal connection between the audio-navigation switch panel and the audio display. If NG is indicated, check the serial bus line between the audio-navigation switch panel and the audio-navigation unit.

Scheme 1005

Select the item you want to check.

Scheme 1006: Functional Setup
  1. Save User's Memory
  2. Demo Mode
  3. All Clear
  4. Mic Level
  5. HDD Rec. Deterrent

Note. If the audio-navigation unit HDD is OK, transfer the HDD to the new audio-navigation unit. Do this procedure only when replacing the HDD (if possible). Since the HDD is NG, it is unlikely you will be able to recover any information.

When replacing the audio-navigation unit, this function allows the technician to transfer the client's personal data to the new audio-navigation unit. The transferred information includes their setup settings and personal addresses. The Save Users Memory cannot copy music or photographs that are saved on the old HDD. The dealer inserts a USB device into the USB port, and then selects the Save Users Memory function. The two functions in this diagnostic screen are EXPORT and IMPORT. EXPORT saves the client's data to the USB device, and IMPORT moves the USB device files to the new audio-navigation unit.

Scheme 1007: Save Users Memory

This function does not start (the EXPORT and IMPORT buttons are grayed out) until you connect a USB device.

Scheme 1008
Scheme 1009
  1. Select EXPORT button to move the client's data from the original audio-navigation unit to the USB device. Select YES on the Export User Data Confirmation screen. The process takes only a couple of seconds. The system stores. DAT files on the USB device. NOTE: If the EXPORT button is grayed out, check the USB port.
  2. After replacing the new audio-navigation unit, allow the system to boot up. Insert the USB device into the USB port and enter the Save Users Memory in the navigation system diagnostic mode.
  3. Select the IMPORT button to move the two files stored by the Export process from the USB device to the new audio-navigation unit. Select YES on the Import User Data Confirmation screen. When the transfer is finished (a few seconds) the system automatically reboots. After the system reboots, remove the USB device from the USB port. NOTE: If the IMPORT button is grayed out, check if the Model and the Program Flash shown on the Version screen are the same.

This screen is for factory use only, and should always be set to OFF. Occasionally the DEMO setting is turned ON when vehicles are being used at auto shows or similar events. Turning this feature on, allows the navigation system to automatically follow a route to a destination when the vehicle is stationary. The Speed Rate changes the speed of the demo mode.

Scheme 1010: Demo Mode

All Clear

The all clear function deletes all ripped music, images, cell phone information, previous destinations, and the phonebook from the audio-navigation unit HDD.

When All Clear is selected, the system restarts after performing the All Clear process. After the restart, a normal start-up process occurs and needs GPS initialization.

Scheme 1011

If you select YES, the second confirmation screen appears.

Scheme 1012

Mic Level

This diagnostic allows you to independently test the microphone and the TALK and BACK buttons. They are used to activate the voice control system. The microphone is located near the map light in the roof console. The microphone can now isolate the driver's voice even when there is noise or other conversations in the vehicle. To properly check the microphones, make sure you are sitting in the driver's seat.

Scheme 1013
  1. Press the TALK button on the steering wheel, wait unit you hear a beep, and in a normal voice say "testing". The TALK indicator on the screen should momentarily turn green, and the text Now Recording... should appear in yellow. If the talk indicator shown on the screen does not briefly turn green when you press the TALK button, check the wiring from the steering wheel TALK button to the HandsFreeLink™ control unit. If there is no Mic Level movement when you speak, then you should check the wires running from the microphone in the roof console to the HandsFreeLink™ control unit and the audio-navigation unit. If the wires are OK, the microphone must be faulty; replace the microphone located in the roof console (see «HFL-NAVIGATION MICROPHONE REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__hfl-navigation-microphone-removalinstallation) ).
  2. Press the BACK button on the steering wheel. This should cause the BACK indicator on the screen to momentarily turn green. If it does not briefly turn to green, then check the wiring from the steering Wheel BACK button to the HandsFreeLink™ control unit. NOTE: The Mic level should reach the 6th bar.

HDD Rec. Deterrent

This setting allows you to enable or disable recording CDs to the audio-navigation unit HDD. Refer to the Owner's Manual for more information about ripping music to the HDD.

Note. If the HDD Rec. Deterrent is set to on, and the client tries to rip a CD to the HDD, an error message appears on the screen. Refer to the Navigation Manual.

HDD Record Deterrent Setting

Scheme 1014

Deterrent Setting to OFF

Scheme 1015

Deterrent Setting to ON

Scheme 1016

This diagnosis tests the wire connections between the XM (HIP) components.

Scheme 1017: XM (HIP)

You can check the XM status in this screen. For problems with XM signal reception, refer to the audio information.

ItemsCondition Indicated
XM receptionReceiving Check Antenna No Signal Loading Expired
Traffic Signal ReceptionReceiving Check Antenna No Signal Loading Expired
Traffic IndicatorTRF (green icon): Traffic information is available. TRF (white icon): Flow or incident data is not available. TRF (red icon): No traffic available (flow and incident).
Traffic DataOK Invalid
Traffic Last UpdateLast update time and date indicated.
Weather Signal ReceptionReceiving Check Antenna No Signal Loading Expired
Weather DataOK Invalid
Weather Last UpdateLast update time and date indicated.

XM STATUS CHART

Scheme 1018

This diagnosis checks Whether the audio-navigation unit is receiving B-CAN data properly.

B-CAN (Body Controller Area Network) passes information between processors on the network. The B-CAN network uses a communication protocol that transmits data at 125 Kbps.

Scheme 1019: B-CAN
  1. This diagnosis must have the engine running.
  2. If any icon colors red, check for B-CAN DTCs with the HDS.
  3. The data displayed in the ID boxes is for factory use only.

This screen displays the current version information for the navigation system software. In addition, this screen allows the loading of updated software if requested by the factory, or instructed by a service bulletin. Software may be loaded from a DVD or a USB device.

  1. Flash: Displays the version of the navigation software in memory.
  2. HDD: Displays the version of the navigation software in the navigation HDD.
  3. USB: If displayed, this value represents the version of the USB software in the USB device.
  4. Disc: If displayed, this value represents the version of the navigation software on the navigation DVD.
  5. DSP: Displays the version of the DSP firmware.
  6. IPL, APP, DBOOT, HDD, and DSP, are all for factory use.
  7. Model: For this model, the field should begin with TP1.
  8. Download: Do not touch, unless instructed by the factory or any other official Honda service information (like a service bulletin).

Check any official Honda service website for more service information about the navigation system.

Scheme 1020

This screen shows the current status of GPS reception. The circular diagram shows the current location of the GPS satellites (yellow numbers) as they would appear in the sky. The outer circle represents the horizon (0 degrees elevation). The middle and inner circles represents 30 and 60 degrees respectively. The very center of the diagram (90 degrees elevation) is directly overhead. Nearby obstructions, like tall buildings will block satellites in that direction. That is why it is necessary to be in an open area to effectively troubleshoot GPS reception issues. The satellite numbers shown on the diagram correspond to the PRN number in the GPS Details screen. There are always at least 24 active GPS satellites in orbit. Because satellites fail, and have to be removed from service, spares are always parked in orbit, ready to be activated. This is why the PRN (satellite ID number) can be greater than 24.

Note. When you use this screen for troubleshooting, park the vehicle outside, away from buildings, tall trees, and high-tension wires for at least 10 minutes with the engine running.

Scheme 1021: GPS Information
  1. The Number of Satellites box shows the number of acquired satellites (maximum of 12). It should contain four or more icons. If not, go to GPS icon is white or not shown troubleshooting (see «GPS ICON IS WHITE OR NOT SHOWN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__gps-icon-is-white-or-not) ).
  2. The Current Position shows latitude, longitude, and elevation (in feet). If there are less than four satellites, the elevation can be grossly inaccurate.
  3. The Date/Time field shows the current date, and also GMI time. NOTE: Pressing the map/guide button displays the satellite number on each circle.

By pressing and holding the MENU button for 2 seconds, a GPS Detail screen appears. This screen displays real time incoming satellite positional data when the vehicle is outside in the open. The information shown on this screen is for factory use.

Note. The data shown is an example only.

Scheme 1022: GPS Detail
  1. The box TS/AS and H Dop (horizontal dilution of precision)/V Dop (vertical dilution of precision) is for factory use.
  2. The Speed and Direction information is updated in real time when driving.
  3. The Date/Time Information is the same as in Setup screen 2 Adjust Time Zone/Clock.
  4. If the 3D icon is shown above the yellow dots, this implies that at least four satellites are available for map positioning, and the GPS indicator on the map screen will be green. See the Global Positioning System detailed explanation in the System Description.
  5. If the row of data in the table below begins with a yellow dot, the AZI and EL fields can be used to locate each satellite on the circular GPS diagram (see prior screen).

The table of values shown below define the terms at the top of the columns in the GPS detail screen.

ColumnDescriptionProblem indication
ActiveActive satellites (Yellow Dot)If 3D or 2D is missing when the vehicle is parked outside, go to GPS icon is white or not shown troubleshooting (see GPS ICON IS WHITE OR NOT SHOWN )
PRNThe satellite ID number
STThe status: 0 = cannot view or searching, 2 = acquiringIf all 0, go to GPS icon is white or not shown troubleshooting (see GPS ICON IS WHITE OR NOT SHOWN )
AZIAzimuth, the angle (0-360) clockwise from north
ELElevation from the horizon (90 deg is overhead)
C/NReceiver sensitivityNormal signal is 49-52, no signal: 27-33
ACCSatellite accuracy
↑ 1/3 to 3/3 ↓Shows view of all satellites in three screen views 1/3, 2/3 or 3/3

PROBLEM INDICATION CHART

This diagnosis checks the yaw rate sensor in the audio-navigation unit. This device detects when the vehicle turns, and repositions the vehicle position icon on the map screen. For more detailed information, see the yaw rate sensor theory of operation under System Description (see YAW RATE SENSOR ).

  1. Sensor indicates the voltage output from the yaw rate sensor. It should indicate about 2.500 V when the vehicle is stopped.
  2. Offset is the reference voltage or standard within the yaw rate sensor. It also should indicate about 2.500 V when the vehicle is stopped.
  3. A sensor output voltage LOWER than the Offset voltage indicates that the vehicle is turning to the right.
  4. A sensor output voltage HIGHER than the Offset voltage indicates that the vehicle is turning to the left.
  5. The yaw rate offset, and sensor should both indicate about 2.500 V when the vehicle is stopped. If either reads zero, or 5.000 V, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  6. The yaw rate offset and sensor should be within +/-0.01 V of each other when the vehicle is stopped. The sensor value should change relative to the offset as the vehicle turns while driving. If not, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Example: Car stopped

Normal Abnormal

Offset 2.526 V Offset 2.526 V

Sensor 2.516-2.536 V Sensor 2.623 V

Example: Car turning

Normal Abnormal

Offset 2.526 V Offset 2.526 V

Sensor 2.678 V (left turn) 2.478 V (right turn) Sensor 2.623 V (no change on turns)

Scheme 1023
  1. The settings CCW Cal Factor, CW Cal Factor, and Set are for factory use only. THIS SHOULD NEVER BE ADJUSTED.
  2. For detailed analysis of the yaw rate select tuning.

This diagnosis allows you to graphically display problems with the yaw rate sensor.

  1. The ANG-Disp value accumulates any differences between the offset, and sensor voltages (see Yaw Rate diagnostic). When the sensor functions normally, the random changes in these two voltages generally cancels out, so the value is 0. However if one voltage is consistently higher than the other, then the ANG-Disp value accumulates the constant change.
  2. The Reset button temporarily clears the angular accumulation (ANG-Disp), and clears the display dots.
  3. Do not touch the CCW, CW, or Set buttons. These are used for factory setup only.

Two tests are explained below. For gross problems with the sensor, the stationary test usually confirms whether the sensor is defective. For yaw rate issues related to driving, do the road test described below.

Scheme 1024
  1. Stationary test: If the VP icon spins with the vehicle parked and the engine running and the ANG-Disp value slowly increases or decreases, the yaw rate sensor is defective. Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  2. Road test: Drive the vehicle on a very straight, smooth road. Enter the diagnostic mode, select Yaw rate, and touch the Tuning button. While driving down a straight road, the white dots should trace a straight line across the screen. However, if you are driving on a straight road, and you notice the dots constantly dropping down or heading up as you drive, the audio-navigation unit's yaw sensor is defective. To run the test again, touch Reset to clear ANG-Disp, and the dotted lines. If either test above fails, please enter Yaw rate sensor defective for the problem description, on the audio-navigation unit return form. NOTE: The CCW, CW and Set buttons are disabled and cannot be activated.

Use this screen to confirm that the audio-navigation unit is properly receiving input signals. Signals equal to (0) are OFF, and signals equal to (1) are ON. If the value on the display does not match the actual vehicle status, then check the wire carrying the signal.

  1. VSP-Vehicle Speed Pulse from ECM/PCM (audio-navigation unit connector A (24P) terminal No. 15) OFF (0) when vehicle is not moving ON (1) when vehicle is moving

The VSP comes from the ECM/PCM as a dedicated signal. Internally, the audio-navigation unit compares the actual VP on the map against street data to adjust the pulse to speed scaling factor. As this scaling factor becomes more accurate, the Level gradually increases from 0 to 10.

  1. BACK-Reverse indication from taillight relay (audio-navigation unit connector H (28P) terminal No. 20) OFF (0) when the shift lever is in any position other than reverse ON (1) when the shift lever is in R position

The Back signal is used by the audio-navigation unit to allow the map screen to show the VP moving backwards when the vehicle is in R position. This signal is needed because the Speed Pulse has no direction indication.

Scheme 1025
  1. ILL-Illumination Indication (audio-navigation unit connector H (28P) terminal No. 4) OFF (0) when parking lights, or headlights are off ON (1) when parking lights, or headlights are on

The navigation uses the signal to determine whether to put the navigation screen into the Day or Night brightness mode. (Setup screen 1)

Note. The PARK on this diagnostic screen in this models always shows [-]. You will not see this display when you shift into R because the screen displays the rearview camera image.

Refer to How to Check for Error History (see HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS) ) to use this diagnosis.

Scheme 1026: Error History

This diagnosis adjusts the guide line of the rearview camera image. This is for factory use only.

Note. Do not change the shift lever to R while this diagnosis runs.

Select Normal View mode in the Guideline Setup menu.

Scheme 1027: Guideline Setup
Scheme 1028
Scheme 1029
  1. If the ALL Points is selected, all guide lines can be adjusted at the same time.
  2. If the Default is selected, all guide lines can be reset for the factory settings.
  3. For returns to the previous screen, select the CANCEL or push the CANCEL button. Using the interface dial to adjust the point(s)

If you want to keep the setting, select Save. Each coordinates of the guide line is displayed.

Scheme 1030

Select the Exit and the guide line adjust ends (returns to the Guideline Setup menu screen).

Screen Error MessageSolution
System temp is too high. System will shut down until it cools down.This message appears briefly when the audio-navigation unit temperature is too high, and then the display turns off until the temperature cools down. The system turns back on when the audio-navigation unit cools down.
System reset.This message appears five seconds after the display of system high temp error.
HDD access error. System reset.This message appears when the system is failed to read from HDD or write to HDD or the HDD was not transferred when the navigation unit was replaced.
HDD access error. Please consult your dealer.This message appears when the system detects the HDD is not connected, not inserted, or there is a HDD connecting error. The HDD data management area (file system) is damaged or the password is incorrect. Check any official Honda service website for more service information about the navigation system.
Display temp is too high. System will shut down until display cools down.This message appears briefly when the display temperature is too high, and then the display turns off until the temperature cools down. The system turns back on when the display cools down.

SCREEN ERROR MESSAGE REFERENCE CHART

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when there is an internal problem with the Flash-ROM. Check any official Honda service website for more service information about the navigation system. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Turn the ignition switch to LOCK (0) and then back to ON (II).
  2. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is DTC 1001 indicated? YES -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Intermittent failure, the system is OK at this time. If the vehicle repeatedly comes back with the navigation DTC, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when there is an internal error in BUS sending. Check any official Honda service website for more service information about the navigation system. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0) and then back to ON (II).
  3. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is DTC 1101 indicated? YES -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Intermittent failure, the system is OK at this time. If the vehicle repeatedly comes back with the navigation DTC, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when a problem is detected with the USB. Check any official Honda service website for more information about the navigation system. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0), and make sure the USB device is disconnect from the USB port.
  3. Turn the ignition switch to ON (II).
  4. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is DTC 1102 indicated? YES -Go to step 5. NO -Intermittent failure, the system is OK at this time. The client's USB device could be defective or not compatible. Try the client's USB device in a known-good vehicle. If it does not work, the USB device is defective or not compatible.
  5. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  6. Turn the ignition switch to LOCK (0).
  7. Disconnect audio-navigation unit connector K (7P).
  8. Turn the ignition switch to ON (II).
  9. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Are DTC 1102 and 2710 indicated at the same time? YES -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Substitute a known-good USB adapter, and recheck. If the symptom/indication goes away, replace the original USB adapter. If the symptom/indication is still present, replace the USB main harness or USB subharness.

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when the internal temperature of the navigation ECU rises above 158°F (70°C). The unit is designed to shut down to protect the navigation ECU. This could be caused by an inoperative audio-navigation unit cooling fan or if the vehicle cabin temperature exceeds the maximum. Do the troubleshooting when the audio-navigation unit is within the allowable temperature range. Check any official Honda service website for more service information about the navigation system. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Check that the temperature is below 158°F (70°C) in the dash.
  2. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  3. Turn the ignition switch to LOCK (0) and then back to ON (II).
  4. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is DTC 1201 indicated? YES -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Intermittent failure, the system is OK at this time. If the vehicle repeatedly comes back with the navigation DTC, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when the internal temperature of the navigation ECU rises above 158°F (70°C). The unit is designed to shut down to protect the navigation ECU. This could be caused by an inoperative audio-navigation unit cooling fan or if the vehicle cabin temperature exceeds the maximum. Do the troubleshooting when the audio-navigation unit is within the allowable temperature range. Check any official Honda service website for more service information about the navigation system. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Check that the temperature is below 158°F (70°C) in the dash.
  2. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  3. Turn the ignition switch to LOCK (0) and then back to ON (II).
  4. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is DTC 1204 indicated? YES -Replace the HDD (see «HDD REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__hdd-removalinstallation) ). NO -Intermittent failure, the system is OK at this time. If the vehicle repeatedly comes back with the navigation DTC, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when there is a problem with the HDD. Check any official Honda service website for more information about the navigation system. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0) and then back to ON (II).
  3. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is DTC 1206 indicated? YES -Replace the HDD (see «HDD REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__hdd-removalinstallation) ). NO -Intermittent failure, the system is OK at this time. If the vehicle repeatedly comes back with the navigation DTC, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when there is poor connectors or loose terminals at the GPS antenna connector or an open in GPS antenna lead. Check any official Honda service website for more service information about the navigation system. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ). Make sure the vehicle is parked outside, away from buildings. Aftermarket electronic devices located near the audio-navigation unit or GPS antenna can potentially interfere with the operation of the navigation system.

  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0).
  3. Turn the ignition switch to ON (II), and wait at least 1 minute.
  4. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is DTC 1301 indicated? YES -Go to step 5. NO -Intermittent failure, the system is OK at this time.
  5. Turn the ignition switch to LOCK (0).
  6. Check for poor connections or loose terminals at audio-navigation unit connector J (2P). Are the connections OK? YES -Replace the GPS Antenna (see «GPS ANTENNA REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). NO -Repair poor connections or loose terminals, and recheck. If the code continues to reset intermittently, replace the GPS antenna (see «GPS ANTENNA REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when there is an internal GPS receiver problem. Check any official Honda service website for more service information about the navigation system. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ). Make sure the vehicle is parked outside, away from buildings. Aftermarket electronic devices located near the audio-navigation unit or GPS antenna can potentially interfere with the operation of the navigation system.

  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0).
  3. Turn the ignition switch to ON (II), and wait at least 1 minute.
  4. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is DTC 1302 indicated? YES -Go to step 5. NO -Intermittent failure, the system is OK at this time.
  5. Turn the ignition switch to LOCK (0).
  6. Check for poor connections or loose terminals at audio-navigation unit connector J (2P). Is the connection OK? YES -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Repair poor connections or loose terminals, and recheck. If the code continues to reset intermittently, replace the GPS antenna (see «GPS ANTENNA REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when there is an internal GPS receiver problem. Check any official Honda service website for more service information about the navigation system. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ). Make sure the vehicle is parked outside, away from buildings. Aftermarket electronic devices located near the audio-navigation unit or GPS antenna can potentially interfere with the operation of the navigation system.

  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0).
  3. Turn the ignition switch to ON (II), and wait at least 30 seconds.
  4. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is DTC 1303 indicated? YES -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Intermittent failure, the system is OK at this time. If the vehicle repeatedly comes back with the navigation DTC, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when there is a problem with the internal yaw rate sensor. Check any official Honda service website for more service information about the navigation system. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ). Make sure the vehicle is parked outside, away from buildings. Aftermarket electronic devices located near the audio-navigation unit or GPS antenna can potentially interfere with the operation of the navigation system. Do this test only when the dash temperature is between -4°F (-20°C) and 158°F (70°C).

  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0) and then back to ON (II).
  3. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  4. Check the System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). Is the Yaw Sensor icon red? YES -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Intermittent failure, the system is OK at this time. If the vehicle repeatedly comes back with the navigation DTC, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when there is a problem with the VSP circuit. Check any official Honda service website for more service information about the navigation system. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ). This navigation DTC may be caused by electrical interference. Check for aftermarket devices installed in the vehicle.

Scheme 1031: DTC 1306: Vehicle Speed Pulse
Scheme 1032
  1. Check the MIL on the gauge. Is the MIL on? YES -Go to the PGM-FI system's general troubleshooting information (see «GENERAL TROUBLESHOOTING INFORMATION»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#fuel-and-emissions-systems-4-cyl) ). NO -Go to step 2.
  2. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  3. Turn the ignition switch to LOCK (0), then start the engine.
  4. Receiving the GPS signal, test drive the vehicle for several minutes.
  5. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is DTC 1306 indicated? YES -Go to step 6. NO -Intermittent failure, the system is OK at this time.
  6. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  7. Select the Car Status in the System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ) to check the vehicle speed pulse.
  8. With the help of an assistant drive the vehicle, arid watch the VSP signal. Does the VSP signal change from [0] to [1] as you drive? YES -Update the ECM/PCM (see «ECM/PCM UPDATE»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-4-cyl__ecmpcm-update) ), if it does not have the latest software, or substitute a known good ECM/PCM (see «ECM/PCM REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-4-cyl__ecmpcm-replacement) ), and recheck. • NO -Go to step 9.
  9. Turn the ignition switch to LOCK (0).
  10. Jump the SCS line with the HDS.
  11. Disconnect the ECM/PCM connector A (49P).
  12. Turn the ignition switch to ON (II).
  13. Raise the vehicle on a lift, and rotate the tires while measuring the voltage between audio-navigation unit connector A (24P) terminal No. 15 and body ground. Is there about 5V? YES -Go to step 15. NO -Go to step 14.
  14. Measure the voltage between the audio-navigation unit connector A (24P) terminal No. 15 and body ground. Is there about 5V? YES -Repair an open or a short in the wire between the audio-naviagtion unit and the ECM/PCM. • NO -Replace the audio-navigation unit (see «Audio-Navigation Unit Removal/Installation»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  15. Turn the ignition switch to LOCK (0).
  16. Reconnect ECM/PCM connector A (49P).
  17. Turn the ignition switch to ON (II).
  18. Raise the vehicle on a lift, and rotate the wheels while measuring the voltage between audio-navigation unit connector A (24P) terminal No. 15 and body ground. Does the voltage pulse between 0V and 5V as you rotate the wheels? YES -Substitute a known good audio-navigation unit (including the HDD) (see «Audio-Navigation Unit Removal/Installation»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «Audio-Navigation Unit Removal/Installation»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). • NO -Update the ECM/PCM (see «ECM/PCM UPDATE»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-4-cyl__ecmpcm-update) ), if it does not have the latest software, or substitute a known good ECM/PCM (see «ECM/PCM REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-4-cyl__ecmpcm-replacement) ), and recheck.

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when the audio-navigation unit detects a mechanical malfunction in the CD/DVD player. Check any official Honda service website for more service information about the navigation system. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Check that the temperature is between -4°F (-20°C), below 158°F (70°C) in the dash.
  2. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  3. Turn the ignition switch to LOCK (0) and then back to ON (II).
  4. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is DTC 1402 indicated? YES -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Intermittent failure, the system is OK at this time. If the vehicle repeatedly comes back with the navigation DTC, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when a mechanical malfunction in the navigation display is detected. Check any official Honda service website for more service information about the navigation system. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Check that the temperature is between -4°F (-20°C), below 158°F (70°C) in the dash.
  2. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  3. Turn the ignition switch to LOCK (0) and then back to ON (II).
  4. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is DTC 1403 indicated? YES -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Intermittent failure, the system is OK at this time. If the vehicle repeatedly comes back with the navigation DTC, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when there is a problem with the DVD player. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Check that the temperature is between -4°F (-20°C), below 158°F (70°C) in the dash.
  2. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  3. Turn the ignition switch to LOCK (0) and then back to ON (II).
  4. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is DTC 1404 indicated? YES -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Intermittent failure, the system is OK at this time. If the vehicle repeatedly comes back with the navigation DTC, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when the internal temperature of the HDD rises above 158°F (70°C). The unit is designed to shut down to protect the HDD. This could be caused by an inoperative audio-navigation unit cooling fan or if the vehicle cabin temperature exceeds the maximum. Do the troubleshooting when the audio-navigation unit is within the allowable temperature range. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Check that the temperature is between -4°F (-20°C), below 158°F (70°C) in the dash.
  2. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  3. Turn the ignition switch to LOCK (0) and then back to ON (II).
  4. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is DTC 1405 indicated? YES -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Intermittent failure, the system is OK at this time. If the vehicle repeatedly comes back with the navigation DTC, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). These navigation DTCs set when a communication error between the rearview camera and the navigation display unit (open or short) is detected. Check any official Honda service website for more service information about the navigation system. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 1033: DTC 1701: Rear Camera Error; DTC 2608: Rear Camera Diag
Scheme 1034
Scheme 1035
  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0) and then back to ON (II).
  3. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  4. Check the System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). Is the Rear camera icon red? YES -Go to step 5. NO -Intermittent failure, the system is OK at this time.
  5. Turn the ignition switch to LOCK (0).
  6. Check for poor connections or loose terminals at rearview camera 6P connector. Are there connections OK? YES -Go to step 7. NO -Repair poor connection or loose terminal.
  7. Disconnect the rearview camera 6P connector.
  8. Turn the ignition switch to ON (II).
  9. Measure the voltage between rearview camera 6P connector terminal No. 6 (Sedan) or No. 1 (Sport Wagon) and body ground. Sedan Sport Wagon Is there 3-9 V? YES -Replace the rearview camera; Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). NO -Go to step 10.
  10. Measure the voltage between navigation display unit 28P connector terminal No. 25 and body ground. NAVIGATION DISPLAY UNIT 28P CONNECTOR Is there 3-9 V? YES -There is an open in the wire between the navigation display unit and the rearview camera. Repair or replace the affected harness. NO -Replace the navigation display unit (see «NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__navigation-display-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when a problem is detected in the XM antenna connection. Check any official Honda service website for more service information about the navigation system. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ). Make sure the vehicle is parked outside, away from buildings. Aftermarket electronic devices located near the audio-navigation unit or XM antenna can potentially interfere with the operation of the navigation system.

  1. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is DTC 1801 or 2704 indicated? YES -Do the DTC 1801 (see «DTC 1801: HIP ERROR»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ) or DTC 2704 (see «DTC 2704: XM (HIP) DIAG»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ) troubleshooting. NO -Go to step 2.
  2. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  3. Turn the ignition switch to LOCK (0) and then back to ON (II).
  4. Turn on the audio system, and press the XM button to select XM mode.
  5. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is DTC 1702 indicated? YES -Go to step 6. NO -Intermittent failure, the system is OK at this time.
  6. Turn the ignition switch to LOCK (0).
  7. Check for poor connections or loose terminals at AcuraLink control unit (XM receiver) connector B (2P). Is the connection OK? YES - Sedan: Replace the XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). Sport Wagon: Replace the AM/FM/XM antenna (see «AM/FM/XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -Repair poor connections or loose terminals, and recheck.

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when a problem is detected in the XM antenna connection. Check any official Honda service website for more service information about the navigation system. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ). Make sure the vehicle is parked outside, away from buildings. Aftermarket electronic devices located near the audio-navigation unit or XM antenna can potentially interfere with the operation of the navigation system.

  1. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is DTC 2607 indicated? YES -Do the DTC 2607 troubleshooting (see «DTC 2607: XM DIAG»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__dtc-2607-xm-diag) ). NO -Go to step 2.
  2. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  3. Turn the ignition switch to LOCK (0) and then back to ON (II).
  4. Turn on the audio system, and press the XM button to select XM mode.
  5. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is DTC 1702 indicated? YES -Go to step 6. NO -Intermittent failure, the system is OK at this time.
  6. Turn the ignition switch to LOCK (0).
  7. Check for poor connections or loose terminals at XM receiver connector B (2P). Is the connection OK? YES -Replace the XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -Repair poor connections or loose terminals, and recheck.

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when a problem (open or short) is detected in the COMM BUS. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ). Check for and resolve any B-CAN DTCs before troubleshooting. Check any official Honda service website for any service information about the AcuraLink

Scheme 1036: With AcuraLink
Scheme 1037
Scheme 1038
Scheme 1039
  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0) and then back to ON (II).
  3. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  4. Check the System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). Is the XM (HIP) icon red? YES -Go to step 6 . NO -Go to step 5.
  5. Check the System Links. Is the HFL icon red? YES -Do the DTC 2705 troubleshooting (see «DTC 2705: HFL DIAG»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). NO -Intermittent failure, the system is OK at this time.
  6. Select the XM (HIP), then check the XM (HIP) System Link. Are the XM (HIP). ECU and Navi icons red? YES -Go to step 7. NO -Do the DTC 2704 troubleshooting (see «DTC 2704: XM (HIP) DIAG»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  7. Turn the ignition switch to LOCK (0).
  8. Connect the HDS to the DLC (see «GENERAL TROUBLESHOOTING INFORMATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#acuralink-4-cyl) ).
  9. Turn the ignition switch to ON (II).
  10. Clear the DTCs with the HDS.
  11. Turn the ignition switch to LOCK (0) and then back to ON (II).
  12. Check for DTCs with the HDS. Are any AcuraLink DTCs indicated? YES -Troubleshoot the indicated DTC(s). NO -Go to step 13.
  13. Do the B-CAN System Diagnosis Test Mode A (see «TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A»(/acura/tsx/ii-2008-2014/remont/communication-devices/#multiplex-integrated-control-system-4-cyl__troubleshooting-b-can-system-diagnosis-test) ), and check the communication with the AcuraLink control unit (XM receiver). Does the AcuraLink control unit (XM receiver) communicate with the HDS? YES -Go to step 14. NO -Go to the AcuraLink control unit troubleshooting.
  14. Turn the ignition switch to LOCK (0).
  15. Disconnect AcuraLink control unit (XM receiver) connector A (32P) and audio-navigation unit connector H (28P).
  16. Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) according to the table. TERMINAL CONTINUITY REFERENCE CHART AcuraLink control unit (XM receiver) connector Wire color A17 WHT A18 RED A19 GRN A20 BLK ACURALINK™ CONTROL UNIT (XM RECEIVER) CONNECTOR A (32P) Is there continuity? YES -There is a short to body ground in the wire(s) between the AcuraLink control unit (XM receiver) and the audio-navigation unit. Replace the affected shielded harness. NO -Go to step 17.
  17. Check for continuity between the terminals of AcuraLink control unit (XM receiver) connector A (32P) according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals A17 (WHT) A18(RED), A19 (GRN), A20 (BLK), A21 (GRY) A18 (RED) A19 (GRN), A20 (BLK), A21 (GRY) A19 (GRN) A20 (BLK), A21 (GRY) A20 (BLK) A21 (GRY) ACURALINK™ CONTROL UNIT (XM RECEIVER) CONNECTOR A (32P) Is there continuity between any of the terminals? YES -There is a short in the wires between the AcuraLink control unit (XM receiver) and the audio-navigation unit. Replace the affected shielded harness. NO -Go to step 18.
  18. Check for continuity between audio-navigation unit connector H (28P) and AcuraLink control unit (XM receiver) connector A (32P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio-navigation unit connector AcuraLink control unit (XM receiver) connector Wire color H9 A18 RED H10 A17 WHT H22 A20 BLK H23 A19 GRN AUDIO-NAVIGATION UNIT CONNECTOR H (28P) ACURALINK™ CONTROL UNIT (XM RECEIVER) CONNECTOR A (32P) Is there continuity? YES -Replace the AcuraLink control unit (XM receiver); Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -There is an open in the wire(s) between the AcuraLink control unit (XM receiver) and the audio-navigation unit. Replace the affected shielded harness.

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when a mechanical malfunction in the navigation display is detected, sets when a GA-IMet bus problem is detected (open or short), or an internal ECU BUS circuit problem is detected (open or short). Check any official Honda service website for more service information about the navigation system. Check for B-CAN DTCs and resolve them before troubleshooting. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 1040: DTC 2601: Display Diag: Connect
Scheme 1041
Scheme 1042
Scheme 1043
Scheme 1044
  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0) and then back to ON (II).
  3. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  4. Check the System Links. Is the Display icon red? YES -Go to step 5. NO -Intermittent failure, the system is OK at this time.
  5. Turn the ignition switch to LOCK (0).
  6. Check for poor connections or loose terminals at these items: Audio-navigation unit connector C (14P) HandsFreeLink™ control unit 28P connector AcuraLink control unit (XM receiver) connector A (32P) (with AcuraLink) XM receiver connector A (14P) (without AcuraLink) Navigation display unit 28P connector Are the connections OK? YES -Go to step 7. NO -Repair poor connections or loose terminals, and recheck the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  7. Disconnect audio-navigation unit connector C (14P) and the navigation display unit 28P connector.
  8. Connect audio-navigation unit connector C (14P) terminals No. 9 and No. 10 with a jumper wire. AUDIO-NAVIGATION UNIT CONNECTOR C (14P)
  9. Check for continuity between navigation display unit 28P connector terminals No. 21 and No. 22. NAVIGATION DISPLAY UNIT 28P CONNECTOR Is there continuity? YES -Go to step 10. NO -There is an open in the wire(s) between the navigation display unit and the audio-navigation unit. Replace the affected shielded harness.
  10. Remove the jumper wire.
  11. Disconnect these items: HandsFreeLink™ control unit 28P connector AcuraLink control unit connector A (32P) (with AcuraLink) XM receiver connector A (14P) (without AcuraLink)
  12. Check for continuity between navigation display unit 28P connector terminals No. 21 and No. 22. NAVIGATION DISPLAY UNIT 28P CONNECTOR Is there continuity? YES -There is a short in the wires between the navigation display unit and the audio-navigation unit. Replace the affected shielded harness. NO -Go to step 13.
  13. Check for continuity between body ground and navigation display unit 28P connector terminals No. 21 and No. 22 individually. NAVIGATION DISPLAY UNIT 28P CONNECTOR Is there continuity? YES -There is a short to body ground in the wire(s) between the navigation display unit and the audio-navigation unit. Replace the affected shielded harness. NO -Go to step 14.
  14. Check for continuity between the terminals of the navigation display unit 28P connector according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals 20 (GRY) 21 (RED), 22 (GRIN) NAVIGATION DISPLAY UNIT 28P CONNECTOR Is there continuity between any of the terminals? YES -There is a short in wires between the navigation display unit and the audio-navigation unit. Replace the affected shielded harness. NO -Go to step 15.
  15. Reconnect the all connectors.
  16. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  17. Check the System Links. Is the Display icon red? YES -Go to step 18. NO -Intermittent failure, the system is OK at this time.
  18. Turn the ignition switch to LOCK (0).
  19. Disconnect AcuraLink control unit (XM receiver) connector A (32P) (with AcuraLink) or XM receiver connector A (14P) (without AcuraLink).
  20. Turn the ignition switch to ON (II).
  21. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  22. Check the System Links. Is the Display icon red? YES -Go to step 23. NO - With AcuraLink: Replace the AcuraLink control unit (XM receiver); Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). Without AcuraLink: Replace the XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  23. Turn the ignition switch to LOCK (0).
  24. Disconnect the HandsFreeLink™ control unit 28P connector.
  25. Turn the ignition switch to ON (II).
  26. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  27. Check the System Links. Is the Display icon red? YES -Go to step 28. NO -Replace the HandsFreeLink™ control unit (see «HANDSFREELINK CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#handsfreelink-system-4-cyl__handsfreelinktm-control-unit-removalinstallation) ).
  28. Turn the ignition switch to LOCK (0).
  29. Substitute a know-good navigation display unit (see «NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__navigation-display-unit-removalinstallation) ).
  30. Turn the ignition switch to ON (II).
  31. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  32. Check the System Links. Is the Display icon red? YES -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Replace the original navigation display unit (see «NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__navigation-display-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when a problem (open or short) is detected in the GA-Net BUS. Check any official Honda service website for more service information about the navigation system. Check for B-CAN DTCs and resolve them before troubleshooting. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0) and then back to ON (II).
  3. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  4. Select the Radio in the System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). Is Connection NG indicated? YES -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Intermittent failure, the system is OK at this time. If the vehicle repeatedly comes back with the navigation DTC, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Without AcuraLink

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when a problem (open or short) is detected in the GA-Net BUS. Check any official Honda service website for more service information about the navigation system. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0) and then back to ON (II).
  3. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  4. Check the System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). Is the XM icon red? YES -Go to XM radio display is blank and no station information is displayed (with ELS audio, without AcuraLink) troubleshooting (see «XM RADIO DISPLAY IS BLANK AND NO STATION INFORMATION IS DISPLAYED (WITH ELS AUDIO, WITHOUT ACURALINK™)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__xm-radio-display-is-blank-and) ). NO -Intermittent failure, the system is OK at this time.

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when a problem with the audio-navigation unit internal DRAM is detected. Check any official Honda service website for more service information about the navigation system. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0) and then back to ON (II).
  3. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  4. Select the ECU Info in the System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). Is D-RAM OK indicated? YES -Intermittent failure, the system is OK at this time. If the vehicle repeatedly comes back with the navigation DTC, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when there is a problem with the HDD. Check any official Honda service website for more service information about the navigation system. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ). Check for B-CAN DTCs and resolve them before troubleshooting.

  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0) and then back to ON (II).
  3. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  4. Select the HDD in the System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). Is HDD status OK indicated? YES -Intermittent failure, the system is OK at this time. If the vehicle repeatedly comes back with the navigation DTC, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Replace the HDD (see «HDD REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__hdd-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when there is a problem with the audio display. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Turn the ignition switch to LOCK (0) and then back to ON (II).
  2. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  3. Check the System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). Is the Subdisplay icon red? YES -Audio unit power switch will not turn on (No information display and no sound) troubleshooting (see «AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH ELS AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__audio-unit-power-switch-will-not) ). NO -Intermittent failure, the system is OK at this time.

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when a problem is detected in the GPS antenna. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ). Make sure the vehicle is parked outside, away from buildings. Check for electronic aftermarket accessories (possibly hidden) mounted near the GPS antenna or the audio-navigation unit. Check for aftermarket metallic window tint.

  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0) and then back to ON (II).
  3. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  4. Select the GPS Ant in the System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). Is Antenna OK indicated? YES -Intermittent failure, the system is OK at this time. NO -Go to step 5.
  5. Turn the ignition switch to LOCK (0).
  6. Check for poor connections or loose terminals at audio-navigation unit connector J (2P). Is the connection OK? YES -Replace the GPS antenna (see «GPS ANTENNA REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). NO -Repair poor connections or loose terminals, and recheck.

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when a problem is detected in the GPS antenna. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ). Check for B-CAN DTCs and resolve them before troubleshooting. Make sure the vehicle is parked outside, away from buildings. Check for electronic aftermarket accessories (possibly hidden) mounted near the GPS antenna or the audio-navigation unit. Check for aftermarket metallic window tint.

  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0) and then back to ON (II).
  3. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  4. Select the GPS Ant in the System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). Is Receiver in Navi ECU OK indicated? YES -Intermittent failure, the system is OK at this time. NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC set when a communication error between the climate control unit and the audio-navigation unit (open or short) is detected. Check any official Honda service website for more service information about the navigation system. Check for B-CAN DTCs and resolve them before troubleshooting. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ). If the A/C system does not work properly, do the A/C system troubleshooting.

Scheme 1045: DTC 2703: Aircon Diag
Scheme 1046
Scheme 1047
Scheme 1048
Scheme 1049
  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0) and then back to ON (II).
  3. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  4. Check the System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). Is the A/C icon red? YES -Go to step 5. NO -Intermittent failure, the system is OK at this time.
  5. Turn the ignition switch to LOCK (0).
  6. Disconnect audio-navigation unit connector D (20P) and climate control unit connector B (12P).
  7. Connect audio-navigation unit connector D (20P) terminals No. 4 and No. 5 with a jumper wire, then connect terminals No. 4 and No. 14 with a jumper wire. AUDIO-NAVIGATION UNIT CONNECTOR D (20P) JUMPER WIRE
  8. Press and hold both the AUTO button of the climate control unit and the ON/OFF button of the climate control unit, then turn the ignition switch to ON (II). Are both HEAT/VENT indicators solid with the remaining icons blinking? YES -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Go to step 9.
  9. Turn the ignition switch to LOCK (0).
  10. Remove the jumper wires.
  11. Disconnect climate control unit connector B (12P).
  12. Check for continuity between body ground and audio-navigation unit connector D (20P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio-navigation unit connector Wire color D4 ORN D5 PUR D14 BRN AUDIO-NAVIGATION UNIT CONNECTOR D (20P) Are there continuity? YES -Repair a short to body ground in the wire(s) between the audio-navigation unit and the climate control unit. NO -Go to step 13.
  13. Check for continuity between the terminals of audio-navigation unit connector D (20P) according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals D4 (ORN) D5 (PUR), D14 (BRN) D5 (PUR) D14 (BRN) AUDIO-NAVIGATION UNIT CONNECTOR D (20P) Is there continuity between any of the terminals? YES -Repair a short in the wires between the audio-navigation unit and the climate control unit. NO -Go to step 14.
  14. Check for continuity between audio-navigation unit connector D (20P) and climate control unit connector B (12P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio-navigation unit connector Climate control unit connector Wire color D4 B8 ORN D5 B7 PUR D14 B9 BRN CLIMATE CONTROL UNIT CONNECTOR C (20P) CLIMATE CONTROL UNIT CONNECTOR B (12P) Is there continuity? YES -Replace the climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-4-cyl) ), and recheck. • NO -Repair an open in the wire(s) between the audio-navigation unit and the climate control unit.

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when a problem is detected in the COMM BUS (open or short) or in the AcuraLink control unit (XM receiver). Check any official Honda service website for more service information about the navigation system. Check for and resolve and CAN DTCs before troubleshoot the DTC 2704. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 1050: With AcuraLink
Scheme 1051
Scheme 1052
Scheme 1053
  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0) and then back to ON (II).
  3. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  4. Check the System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). Is the XM (HIP) icon red? YES -Go to step 5. NO -Intermittent failure, the system is OK at this time.
  5. Select the XM (HIP), then check the XM (HIP) System Link (see «XM (HIP)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__xm-hip) ). Is the Navi icon red? YES -Go to step 8 . NO -Go to step 6.
  6. Check the XM (HIP) System Link. Is the HFL icon red? YES -Do the DTC 2705 troubleshooting (see «DTC 2705: HFL DIAG»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). NO -Go to step 7.
  7. Check the XM (HIP) System Link. Is the Audio icon red? YES -Go to XM radio display is blank and no station information is displayed (with ELS audio, with AcuraLink) troubleshooting (see «XM RADIO DISPLAY IS BLANK AND NO STATION INFORMATION IS DISPLAYED (WITH ELS AUDIO, WITH ACURALINK™)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__xm-radio-display-is-blank-and) ). NO -Go to step 8.
  8. Turn the ignition switch to LOCK (0).
  9. Connect the HDS to the DLC (see «GENERAL TROUBLESHOOTING INFORMATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#acuralink-4-cyl) ).
  10. Turn the ignition switch to ON (II).
  11. Clear the DTCs with the HDS.
  12. Turn the ignition switch to LOCK (0) and then back to ON (II).
  13. Check for DTCs with the HDS. Are any AcuraLink DTCs indicated? YES -Troubleshoot the indicated DTCs. NO -Go to step 14.
  14. Do the B-CAN System Diagnosis Test Mode A (see «TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A»(/acura/tsx/ii-2008-2014/remont/communication-devices/#multiplex-integrated-control-system-4-cyl__troubleshooting-b-can-system-diagnosis-test) ), and check the communication with the AcuraLink control unit (XM receiver). Does the AcuraLink control unit (XM receiver) communicate with the HDS? YES -Go to step 15. NO -Go to AcuraLink services does not work troubleshooting (see «SYMPTOM TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#acuralink-4-cyl) ).
  15. Turn the ignition switch to LOCK (0).
  16. Disconnect AcuraLink control unit (XM receiver) connector A (32P) and audio-navigation unit connector H (28P).
  17. Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) according to the table. TERMINAL CONTINUITY REFERENCE CHART AcuraLink control unit (XM receiver) connector Wire color A17 WHT A18 RED A19 GRN A20 BLK ACURALINK™ CONTROL UNIT (XM RECEIVER) CONNECTOR A (32P) Is there continuity? YES -There is a short to body ground in the wire(s) between the AcuraLink control unit (XM receiver) and the audio-navigation unit. Replace the affected shielded harness. NO -Go to step 18.
  18. Check for continuity between the terminals of AcuraLink control unit (XM receiver) connector A (32P) according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals A17(WHT) A18(RED), A19(GRN), A20(BLK), A21 (GRY) A18(RED) A19 (GRIM), A20 (BLK), A21 (GRY) A19(GRN) A20(BLK), A21 (GRY) A20 (BLK) A21 (GRY) ACURALINK™ CONTROL UNIT (XM RECEIVER) CONNECTOR A (32P) Is there continuity between any of the terminals? YES -There is a short in the wires between the AcuraLink control unit (XM receiver) and the audio-navigation unit. Replace the affected shielded harness. NO -Go to step 19.
  19. Check for continuity between audio-navigation unit connector H (28P) and AcuraLink control unit (XM receiver) connector A (32P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio-navigation unit connector AcuraLink control unit (XM receiver) connector Wire color H9 A18 RED H10 A17 WHT H22 A20 BLK H23 A19 GRN AUDIO-NAVIGATION UNIT CONNECTOR H (28P) ACURALINK™ CONTROL UNIT (XM RECEIVER) CONNECTOR A (32P) Is there continuity? YES -Replace the AcuraLink control unit (XM receiver); Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -There is an open in the wire(s) between the AcuraLink control unit (XM receiver) and the audio-navigation unit. Replace the affected shielded harness.

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when a problem is detected in the COMM BUS (open or short) or in the HandsFreeLink™ control unit. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 1054: With AcuraLink
Scheme 1055
Scheme 1056
Scheme 1057
  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0) and then back to ON (II).
  3. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  4. Select the XM (HIP) (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ), then check the XM (HIP) System Link (see «XM (HIP)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__xm-hip) ). Are the XM (HIP). ECU and Navi icons red? YES -Do the DTC 1801 troubleshooting (see «DTC 1801: HIP Error»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). NO -Go to step 5.
  5. Check the XM (HIP) System Link. Is the HFL icon red? YES -Go to step 6. NO -Intermittent failure, the system is OK at this time.
  6. Turn the ignition switch to LOCK (0) and the back to ON (II).
  7. Do the HandsFreeLink™ system Self Diagnostic Function (see «SELF-DIAGNOSTIC FUNCTION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#handsfreelink-system-4-cyl__self-diagnostic-function) ). Do you hear "The hands free system is OK"? YES -Go to step 8. NO -Check for HFL DTCs (see «DTC TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#handsfreelink-system-4-cyl) ). If the HFL does not respond, do the HandsFreeLink™ control unit input test (see «CONTROL UNIT INPUT TEST»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#handsfreelink-system-4-cyl) ).
  8. Turn the ignition switch to LOCK (0).
  9. Disconnect the HandsFreeLink™ control unit 28P connector and AcuraLink control unit (XM receiver) connector A (32P).
  10. Check for continuity between body ground and the HandsFreeLink™ control unit 28P connector according to the table. TERMINAL CONTINUITY REFERENCE CHART HandsFreeLink™ control unit connector Wire color 6 WHT 7 RED 20 BLK 21 GRN HANDSFREELINK CONTROL UNIT 28P CONNECTOR Is there continuity? YES -There is a short to body ground in the wire(s) between the AcuraLink control unit (XM receiver) and the HandsFreeLink™ control unit. Replace the affected shielded harness. NO -Go to step 11.
  11. Check for continuity between the terminals of the HandsFreeLink™ control unit 28P connector according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals 6 (WHT) 7 (RED), 8 (GRY), 20 (BLK), 21 (GRN) 7 (RED) 8 (GRY), 20 (BLK), 21 (GRN) 8 (GRY) 20 (BLK), 21 (GRN) 20 (BLK) 21 (GRN) HANDSFREELINK CONTROL UNIT 28P CONNECTOR Is there continuity between any of the terminals? YES -There is a short in the wires between the HandsFreeLink™ control unit and the AcuraLink control unit (XM receiver). Replace the affected shielded harness. NO -Go to step 12.
  12. Check for continuity between the HandsFreeLink™ control unit 28P connector and AcuraLink control unit (XM receiver) connector A (32P) according to the table. TERMINAL CONTINUITY REFERENCE CHART HandsFreeLink™ control unit connector AcuraLink control unit (XM receiver) connector Wire color 6 A23 WHT 7 A22 RED 20 A24 BLK 21 A25 GRN HANDSFREELINK CONTROL UNIT 28P CONNECTOR ACURALINK™ CONTROL UNIT (XM RECEIVER) CONNECTOR A (32P) Is there continuity? YES -Replace the HandsFreeLink™ control unit (see «HANDSFREELINK CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#handsfreelink-system-4-cyl__handsfreelinktm-control-unit-removalinstallation) ). NO -There is an open in the wire(s) between the AcuraLink control unit (XM receiver) and the HandsFreeLink™ control unit. Replace the affected shielded harness.

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when a problem is detected in the COMM BUS (open or short) or in the HandsFreeLink™ control unit. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 1058: Without AcuraLink
Scheme 1059
Scheme 1060
Scheme 1061
  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0) and then back to ON (II).
  3. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  4. Check the System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). Is the HFL icon red? YES -Go to step 5. NO -Intermittent failure, the system is OK at this time.
  5. Turn the ignition switch to LOCK (0) and then back to ON (II).
  6. Do the HandsFreeLink™ system Self Diagnostic Function (see «SELF-DIAGNOSTIC FUNCTION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#handsfreelink-system-4-cyl__self-diagnostic-function) ). Do you hear "The hands free system is OK"? YES -Go to step 7 NO -Check for HFL DTCs (see «DTC TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#handsfreelink-system-4-cyl) ). If the HFL does not respond, do the HandsFreeLink™ control unit input test (see «CONTROL UNIT INPUT TEST»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#handsfreelink-system-4-cyl) ).
  7. Turn the ignition switch to LOCK (0).
  8. Disconnect the HandsFreeLink™ control unit 28P connector and audio-navigation unit connector H (28P).
  9. Check for continuity between body ground and the HandsFreeLink™ control unit 28P connector according to the table. TERMINAL CONTINUITY REFERENCE CHART HandsFreeLink™ control unit connector Wire color 6 WHT 7 RED 20 BLK 21 GRN HANDSFREELINK CONTROL UNIT 28P CONNECTOR Is there continuity? YES -There is a short to body ground in the wire(s) between the audio-navigation unit and the HandsFreeLink™ control unit. Replace the affected shielded harness. NO -Go to step 10.
  10. Check for continuity between the terminals of the HandsFreeLink™ control unit 28P connector according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals 6 (WHT) 7 (RED), 8 (GRY), 20 (BLK), 21 (GRN) 7 (RED) 8 (GRY), 20 (BLK), 21 (GRN) 8 (GRY) 20 (BLK), 21 (GRN) 20 (BLK) 21 (GRN) HANDSFREELINK CONTROL UNIT 28P CONNECTOR Is there continuity between any of the terminals? YES -There is a short in the wires between the HandsFreeLink™ control unit and the audio-navigation unit. Replace the affected shielded harness. NO -Go to step 11.
  11. Check for continuity between the HandsFreeLink™ control unit 28P connector and audio-navigation unit connector H (28P) according to the table. TERMINAL CONTINUITY REFERENCE CHART HandsFreeLink™ control unit connector Audio-navigation unit connector Wire color 6 H22 WHT 7 H23 RED 20 H10 BLK 21 H9 GRN HANDSFREELINK CONTROL UNIT 28P CONNECTOR AUDIO-NAVIGATION UNIT CONNECTOR H (28P) Is there continuity? YES -Replace the HandsFreeLink™ control unit (see «HANDSFREELINK CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#handsfreelink-system-4-cyl__handsfreelinktm-control-unit-removalinstallation) ). NO -There is an open in the wire(s) between the audio-navigation unit and the HandsFreeLink™ control unit. Replace the affected shielded harness.

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when the audio-navigation unit yaw rate sensor's temperature is out of its specified range. Check any official Honda service website for more service information about the navigation system. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ). Do this test only when the vehicle dash temperature is between -4°F (-20°C) and 158°F (70°C).

  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0) and then back to ON (II).
  3. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  4. Check the System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). Is the Yaw Sensor icon red? YES -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Intermittent failure, the system is OK at this time. If the vehicle repeatedly comes back with the navigation DTC, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when a problem is detected in the microphone circuit. Check any official Honda service website for more service information about the navigation system. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 1062: DTC 2707: MIC Diag
Scheme 1063
Scheme 1064
Scheme 1065
Scheme 1066
Scheme 1067
  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0) and then back to ON (II).
  3. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  4. Check the System Links. Is the Mic icon red? YES -Go to step 5. NO -Go to step 12 .
  5. Turn the ignition switch to LOCK (0).
  6. Check for poor connections or loose terminals at the HandsFreeLink™ control unit 28P connector and the HFL-navigation microphone 7P connector. Are the connections OK? YES -Go to step 7. NO -Repair poor connections or loose terminals, and recheck.
  7. Connect the HDS to the DLC (see «GENERAL TROUBLESHOOTING INFORMATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#handsfreelink-system-4-cyl) ).
  8. Turn the ignition switch to ON (II).
  9. Clear the DTCs with the HDS.
  10. Turn the ignition switch to LOCK (0) and then back to ON (II).
  11. Check for DTCs with the HDS. Is DTC B1775 or B1776 indicated? YES -Troubleshoot the indicated DTC(s). NO -Go to step 15 .
  12. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  13. Select the Mic in the System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  14. Check the Mic Level (see «FUNCTIONAL SETUP»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__functional-setup) ) by pressing the TALK button on the voice control switch, then say "Testing" in front of the microphone. Is the microphone level OK? YES -Intermittent failure, the system is OK at this time. NO -Replace the HFL-navigation microphone (see «HFL-NAVIGATION MICROPHONE REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__hfl-navigation-microphone-removalinstallation) ).
  15. Measure the voltage between body ground and HFL-navigation microphone 7P connector terminals No. 6 and No. 7 individually. HFL-NAVIGATION MICROPHONE 7P CONNECTOR Is there battery voltage? YES -Go to step 16. NO -If the +B wire does not have voltage, repair an open in the wire between the No. 15 (10 A) fuse under-hood fuse/relay box and HFL-navigation microphone 7P connector terminal No. 7. If the ACC wire does not have voltage, repair an open in the wire between the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box and HFL-navigation microphone 7P connector terminal No. 6.
  16. Turn the ignition switch to LOCK (0).
  17. Disconnect the HFL-navigation microphone 7P connector.
  18. Check for continuity between HFL-navigation microphone 7P connector terminal No. 2 and body ground. HFL-NAVIGATION MICROPHONE 7P CONNECTOR Is there continuity? YES -Replace the HFL-navigation microphone (see «HFL-NAVIGATION MICROPHONE REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__hfl-navigation-microphone-removalinstallation) ). NO -Go to step 19.
  19. Check for continuity between HandsFreeLink™ control unit 28P connector terminal No. 14 and body ground. HANDSFREELINK CONTROL UNIT 28P CONNECTOR Is there continuity? YES -There is an open in the wire between the HFL-navigation microphone and the HandsFreeLink™ control unit. Replace the affected shielded harness. NO -Go to step 20.
  20. Disconnect the HandsFreeLink™ control unit 28P connector.
  21. Check for continuity between HandsFreeLink™ control unit 28P connector terminal No. 28 and body ground. HANDSFREELINK CONTROL UNIT 28P CONNECTOR Is there continuity? YES -Replace the HandsFreeLink™ control unit (see «HANDSFREELINK CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#handsfreelink-system-4-cyl__handsfreelinktm-control-unit-removalinstallation) ). NO -Go to step 22.
  22. Check for continuity between audio-navigation unit connector H (28P) terminal No. 27 and body ground. AUDIO-NAVIGATION UNIT CONNECTOR H (28P) Is there continuity? YES -There is an open in the wire between the audio-navigation unit and the HandsFreeLink™ control unit. Replace the affected shielded harness. NO -Go to step 23.
  23. Disconnect audio-navigation unit connector A (24P). NOTE: Eject all the disc(s) before disconnecting the audio-navigation unit to prevent damaging the CD/DVD player's load mechanism.
  24. Check for continuity between audio-navigation unit connector A (24P) terminal No. 12 and body ground. AUDIO-NAVIGATION UNIT CONNECTOR A (24P) Is there continuity? YES -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Repair an open or high resistance in the wire between the audio-navigation unit and body ground (G651); Sedan (see «RIGHT SIDE WIRE HARNESS (SEDAN)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-4-cyl__right-side-wire-harness-sedan) ), Sport Wagon (see «RIGHT SIDE WIRE HARNESS (SPORT WAGON)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-4-cyl__right-side-wire-harness-sport-wagon) ).
  25. Disconnect the audio-navigation unit connector H (28P) and the HandsFreeLink™ control unit 28P connector.
  26. Check for continuity between HandsFreeLink™ control unit 28P connector terminal No. 27 and audio-navigation unit connector H (28P) terminal No. 28. Is there continuity? YES -Substitute a known good HFL control unit (see «HANDSFREELINK CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#handsfreelink-system-4-cyl__handsfreelinktm-control-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original HFL control unit (see «HANDSFREELINK CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#handsfreelink-system-4-cyl__handsfreelinktm-control-unit-removalinstallation) ). If the symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). • NO -There is an open in the wire between the HFL control unit and the audio-navigation unit. Replace the affected shielded harness.

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when a problem with the audio-navigation unit internal flash-ROM is detected. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0) and then back to ON (II).
  3. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  4. Select the ECU Info in the System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). Is Flash OK indicated? YES -Intermittent failure, the system is OK at this time. If the vehicle repeatedly comes back with the navigation DTC, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). This navigation DTC sets when a problem is detected in the USB circuit. Before you troubleshoot, make sure to follow the General Troubleshooting Information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 1068: DTC 2710: USB Cable Diag
  1. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  2. Turn the ignition switch to LOCK (0) and then back to ON (II).
  3. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  4. Select the USB in the System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). Is Connection OK indicated? YES -Intermittent failure, the system is OK at this time. Check for loose connections at the USB adapter. NO -Go to step 5.
  5. Turn the ignition switch to LOCK (0).
  6. Check for poor connections or loose terminals at audio-navigation unit connector K (7P), and the USB adapter 5P connector. Are the connections OK? YES -Go to step 7. NO -Repair poor connections or loose terminals, and recheck.
  7. Disconnect audio-navigation unit connector K (7P)
  8. Check for continuity between audio-navigation unit connector K (7P) terminals No. 6 and No. 7. Is there continuity? YES -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). • NO -Replace the USB main harness.

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check if Day/Night ( ) button has been pressed, and turned off the display (see Navigation Manual for more information). Check the connectors for poor connections or loose terminals. Before troubleshooting, make sure you have the anti-theft code. Check any official Honda service website for more service information about the navigation system.

Scheme 1069: No picture is displayed
Scheme 1070
Scheme 1071
Scheme 1072
  1. Check the No. 15 (10 A) fuse in the under-hood fuse/relay box and the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box. Are the fuses OK? YES -Go to step 2. NO -Replace the fuse(s), and recheck. If the fuse(s) blows again, check for a short in the No. 15 (10 A) fuse and/or the No. 18 (7.5 A) fuse circuits.
  2. Do the Forced Starting of the Audio-Navigation Unit (see «FORCED STARTING OF THE AUDIO-NAVIGATION UNIT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__forced-starting-of-the-audio-navigation-unit) ). Is the diagnosis menu of the picture diagnosis displayed? YES -Go to step 5 . NO -Go to step 3.
  3. Turn the ignition switch to ON (II).
  4. Shield the display unit from the sun with your hand, and check that the display is back lit (only the back light is ON). Can you see the back light? YES -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). If the symptom/indication is still present, replace the navigation display unit (see «NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__navigation-display-unit-removalinstallation) ). NO -Go to step 6 .
  5. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Are there hard error codes set? YES -Troubleshoot the navigation DTC(s) and recheck. If there are no navigation DTCs, substitute a known-good navigation display unit (see «NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__navigation-display-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original navigation display unit (see «NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__navigation-display-unit-removalinstallation) ). If the symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Go to step 6.
  6. Measure the voltage between body ground and audio-navigation unit connector A (24P) terminals No. 14 and No. 24 individually. AUDIO-NAVIGATION UNIT CONNECTOR A (24P) Is there battery voltage? YES -Go to step 7. NO -If the +B wire does not have voltage, repair an open in the wire between the No. 15 (10 A) fuse in the under-hood fuse/relay box and audio-navigation unit connector A (24P) terminal No. 24. If the ACC wire does not have voltage, repair an open in the wire between the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box and audio-navigation unit connector A (24P) terminal No. 14.
  7. Measure the voltage between audio-navigation unit connector A (24P) terminal No. 12 and body ground. AUDIO-NAVIGATION UNIT CONNECTOR A (24P) Is there less than 0.2 V? YES -Go to step 8. NO -Repair an open or high resistance in the wire between the audio-navigation unit and body ground (G651); Sedan (see «RIGHT SIDE WIRE HARNESS (SEDAN)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-4-cyl__right-side-wire-harness-sedan) ), Sport Wagon (see «RIGHT SIDE WIRE HARNESS (SPORT WAGON)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-4-cyl__right-side-wire-harness-sport-wagon) ).
  8. Measure the voltage between body ground and navigation display unit 28P connector terminals No. 12 and No. 14 individually. NAVIGATION DISPLAY UNIT 28P CONNECTOR Is there battery voltage? YES -Go to step 9. NO -If the +B wire does not have voltage, repair an open in the wire between the No. 15(10 A) fuse in the under-hood fuse/relay box and navigation display unit 28P connector terminal No. 14. If the ACC wire does not have voltage, repair an open in the wire between the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box and navigation display unit 28P connector terminal No. 12.
  9. Measure the voltage between navigation display unit 28P connector terminal No. 27 and body ground. NAVIGATION DISPLAY UNIT 28P CONNECTOR Is there less than 0.2 V? YES -Substitute a known-good navigation display unit (see «NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__navigation-display-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original navigation display unit (see «NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__navigation-display-unit-removalinstallation) ). If the symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Repair an open or high resistance in the wire between the navigation display unit and body ground (G651); Sedan (see «RIGHT SIDE WIRE HARNESS (SEDAN)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-4-cyl__right-side-wire-harness-sedan) ), Sport Wagon (see «RIGHT SIDE WIRE HARNESS (SPORT WAGON)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-4-cyl__right-side-wire-harness-sport-wagon) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check that the GPS antenna is plugged in. This is not the same condition as when driving off-road (or on a fire or logging road). This condition is caused by a loss of map matching from a bad sensor input. Check for aftermarket metallic window tinting or other objects that can block the GPS signal. Always do the Map Matching (see MAP MATCHING ) before proceeding with the troubleshooting. Make sure that the latest navigation software is installed. Check any official Honda service website for more service information about the navigation system. Check the GPS signal reception in an open area.

  1. Turn the ignition switch to ON (II).
  2. Check the GPS icon on the navigation screen. Is the GPS icon white? YES -Do the GPS icon is white or not shown troubleshooting (see «GPS ICON IS WHITE OR NOT SHOWN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__gps-icon-is-white-or-not) ). NO -Go to step 3.
  3. Check for the hard error code (see «How to Check Error History (Navigation DTCs)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is any navigation DTCs indicated? YES -Troubleshoot the indicated DTCs. NO -Go to step 4.
  4. Turn the ignition switch to LOCK (0).
  5. Substitute a known good audio-navigation unit (see «Audio-Navigation Unit Removal/Installation»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and check to see if the problem occurs in the same place. Does the problem occur in the same location each time? YES -Try to replicate the problem in a known good vehicle. If the problem can be duplicated, the problem is in the database. Report the problem according to the Navigation Manual under Reporting Errors. • NO -Replace the original audio-navigation unit (see «Audio-Navigation Unit Removal/Installation»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Check any official Honda service website for more service information about the navigation system. Check the navigation screen settings for brightness, contrast, and black level, and check the color screen for map color and menu color. Before troubleshooting, make sure you have the anti-theft code. After troubleshooting, enter the anti-theft code. Check for aftermarket accessories that may interfere with the navigation system.

Scheme 1073: Picture is missing a color or tone or is an odd color
Scheme 1074
Scheme 1075
Scheme 1076
  1. Turn the ignition switch to ON (II).
  2. Go into the System Diagnostic Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ), and use the RGB Color test under Monitor Check (see «MONITOR CHECK»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__monitor-check) ). Are the red, green, and blue colored circles shown? YES -The system is OK at this time. NO -Go to step 3.
  3. Turn the ignition switch to LOCK (0).
  4. Disconnect audio-navigation unit connector G (8P) and the navigation display unit 28P connector.
  5. Check for poor connections or loose terminals at audio-navigation unit connector G (8P) and the navigation display unit 28P connector. Is the connection OK? YES -Go to step 6. NO -Repair poor connections or loose terminals, and recheck.
  6. Check for continuity between the terminals of audio-navigation unit connector G (8P) according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals G3 (RED) G4 (BLU), G7 (YEL), G8 (WHT) G4 (BLU) G7 (YEL), G8 (WHT) G7 (YEL) G8 (WHT) AUDIO-NAVIGATION UNIT CONNECTOR G (8P) Is there continuity between any of the terminals? YES -Go to step 7. NO -There is a short in the wires between the audio-navigation unit and the navigation display unit. Replace the affected shielded harness.
  7. Check for continuity between audio-navigation unit connector G (8P) and body ground according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio-navigation unit connector Wire color G3 RED G7 YEL G8 WHT AUDIO-NAVIGATION UNIT CONNECTOR G (8P) Is there continuity? YES -There is a short to body ground in the wire(s) between the audio-navigation unit and the navigation display unit. Replace the affected shielded harness. NO -Go to step 8.
  8. Check for continuity between the appropriate terminals of audio-navigation unit connector G (8P) and the navigation display unit 28P connector based on the missing color(s). TERMINAL CONTINUITY REFERENCE CHART Missing color Audio-navigation unit connector Navigation display unit connector Wire color Green G3 5 RED Blue G7 6 YEL Red G8 4 WHT AUDIO-NAVIGATION UNIT CONNECTOR G (8P) NAVIGATION DISPLAY UNIT 28P CONNECTOR Is there continuity? YES -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). If the symptom/indication is still present, replace the navigation display unit (see «NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__navigation-display-unit-removalinstallation) ). NO -There is an open in the wire(s) between the audio-navigation unit and the navigation display unit. Replace the affected shielded harness.

Note. Check the vehicle battery condition first (see BATTERY TEST ). Always compare the screen image to a known-good vehicle. If the screen looks the same, inform the client that it is a characteristic of the system. Check the connectors for poor connections or loose terminals. Make sure that the latest navigation software is installed. Check any official Honda service website for more service information about the navigation system. Check the navigation screen settings for brightness, contrast, and black level, and check the color screen for map color and menu color. Before troubleshooting, make sure you have the anti-theft code. After troubleshooting, enter the anti-theft code.

Scheme 1077: Picture has lines, rolls, or is blurry
Scheme 1078
Scheme 1079
  1. Check for electronic aftermarket accessories (possibly hidden) mounted near the navigation display unit or the audio-navigation unit. Are there any electronic accessories? YES -Remove the accessories, and recheck. NO -Go to step 2.
  2. Turn the ignition switch to ON (II), and start up the navigation system (screen). Is the picture scrolling horizontally (left to right or right to left)? YES -Go to step 3. NO -Intermittent failure, the system is OK at this time.
  3. Turn the ignition switch to LOCK (0).
  4. Check for poor connections or loose terminals at audio-navigation unit connector G (8P) and the navigation display unit 28P connector. Is the connection OK? YES -Go to step 6. NO -Repair poor connections or loose terminals, and recheck.
  5. Disconnect audio-navigation unit connector G (8P) and the navigation display 28P connector.
  6. Check for continuity between audio-navigation unit connector G (8P) terminal No. 2 and body ground. AUDIO-NAVIGATION UNIT CONNECTOR 6 (8P) Is there continuity? YES -There is a short to body ground in the wire between the audio-navigation unit and the navigation display unit. Replace the affected shielded harness. NO -Go to step 7.
  7. Check for continuity between the terminals of audio-navigation unit connector G (8P) according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals G2(BRN) G3 (RED), G4 (BLU), G7 (YEL), G8 (WHT) AUDIO-NAVIGATION UNIT CONNECTOR G (8P) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio-navigation unit and the navigation display unit. Replace the affected shielded harness. NO -Go to step 8.
  8. Check for continuity between audio-navigation unit connector G (8P) terminal No. 2 and navigation display unit 28P connector terminal No. 3. AUDIO-NAVIGATION UNIT CONNECTOR G (8P) NAVIGATION DISPLAY UNIT 28P CONNECTOR Wire side of female terminals Is there continuity? YES -Substitute a known-good navigation display unit (see «NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__navigation-display-unit-removalinstallation) ), and recheck. If the symptom indication goes away, replace the original navigation display unit (see «NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__navigation-display-unit-removalinstallation) ). If the symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). • NO -There is an open in the wire between the audio-navigation unit and the navigation display unit. Replace the affected shielded harness.

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors at the interface dial 13P connector for poor connections or loose terminals. Check any official Honda service website for more service information about the navigation system. Before troubleshooting, make sure you have anti-theft code. After troubleshooting, enter the anti-theft code.

Scheme 1080: Interface dial buttons do not work
Scheme 1081
Scheme 1082
Scheme 1083
  1. Turn the ignition switch to ON (II).
  2. Go into the System Diagnostic Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ), and use Hard Key test under Unit Check (see «UNIT CHECK (QUICK CHECK)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__unit-check-quick-check) ). Do the interface dial buttons work properly? YES -The system is OK at this time. NO -Go to step 3.
  3. Measure the voltage between the interface dial 5P connector terminal No. 4 and body ground. INTERFACE DIAL 5P CONNECTOR Is there battery voltage? YES -Go to step 4. NO -Repair an open in the wire between the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box and interface dial 5P connector terminal No. 4.
  4. Measure the voltage between interface dial 5P connector terminal No. 3 and body ground. INTERFACE DIAL 5P CONNECTOR Is there less than 0.2 V? YES -Go to step 5. NO -Repair an open or high resistance in the wire between interface dial 5P connector terminal No. 3 and body ground (G401) (see «AUDIO WIRE HARNESS (WITH NAVIGATION)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-4-cyl__audio-wire-harness-with-navigation) ).
  5. Turn the ignition switch to LOCK (0).
  6. Disconnect audio-navigation unit connector H (28P).
  7. Disconnect the interface dial 5P connector.
  8. Check for continuity between audio-navigation unit connector H (28P) terminal No. 26 and interface dial 5P connector terminal No. 1. AUDIO-NAVIGATION UNIT CONNECTOR H (28P) Is there continuity? YES -Go to step 9. NO -There is an open in the wire between the interface dial and the audio-navigation unit. Replace the affected shielded harness.
  9. Check for continuity between audio-navigation unit connector H (28P) terminals No. 13 and No. 26. AUDIO-NAVIGATION UNIT CONNECTOR H (28P) Is there continuity? YES -There is a short in the wires between the audio-navigation unit and the interface dial. Replace the affected shielded harness. NO -Go to step 10.
  10. Substitute a known-good interface dial (see «INTERFACE DIAL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ), and recheck. Is the system OK? YES -Replace the original interface dial (see «INTERFACE DIAL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). With good reception, the icon is normally green. Make sure the GPS antenna is plugged in. Check for any aftermarket accessories or metallic window tinting that may be interfering with the GPS signal. Make sure the vehicle is parked outside, away from buildings. Go into the System Diagnostic Mode (see SYSTEM DIAGNOSTIC MODE ), and use GPS Information (see GPS INFORMATION ) for real-time satellite reception display.

  1. Check for aftermarket metallic window tint on the front window and electronic aftermarket accessories (possibly hidden) mounted near the GPS antenna or the audio-navigation unit. Is there aftermarket metallic window tint or electronic accessories? YES -Remove tint or the accessories, and recheck. NO -Go to step 2.
  2. Turn the ignition switch to ON (II).
  3. Go into the System Diagnostic Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ), and use the System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ) to check the GPS antenna, Is the GPS Ant icon red? YES -Check for a kinked, crushed, or disconnected GPS antenna wire. If icon is still red, replace the GPS antenna (see «GPS ANTENNA REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). NO -Check that nothing is blocking the GPS antenna located under the package shelf, and recheck. Substitute a known-good GPS antenna (see «GPS ANTENNA REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original GPS antenna (see «GPS ANTENNA REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). If the symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). The navigation system uses the center speaker for voice response. Check the navigation volume level (see Navigation Manual). Check the connectors for poor connections or loose terminals. If the hard error code stored, check the hard error code troubleshooting first. Before troubleshooting, make sure you have the anti-theft code. After troubleshooting, enter the anti-theft code.

Scheme 1084: Voice guidance cannot be heard, is broken up, or there is static
Scheme 1085
Scheme 1086
  1. Turn the ignition switch to ON (II).
  2. Press the INFO/PHONE button.
  3. Check the volume and voice feedback setting for the navigation system in SETUP screen. Is either set to OFF? YES -Set the voice feedback to ON, and select an audible level for the volume. NO -Go to step 4.
  4. Check the audio system operation. Can you hear the audio system? YES -Go to step 5. NO -Troubleshoot the audio system.
  5. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  6. Turn the ignition switch to LOCK (0) and then back to ON (II).
  7. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is there a hard error code stored? YES -Refer to the hard error code troubleshooting. NO -Go to step 8.
  8. Turn the ignition switch to LOCK (0).
  9. Disconnect audio-navigation unit connector D (20P) and stereo amplifier connector B (28P).
  10. Check for continuity between body ground and audio-navigation unit connector D (20P) terminals No. 17 and No. 19 individually. AUDIO-NAVIGATION UNIT CONNECTOR D (20P) Is there continuity? YES -There is a short to body ground in the wire(s) between the audio-navigation unit and the stereo amplifier. Replace the affected shielded harness. NO -Go to step 11.
  11. Check for continuity between the terminals of audio-navigation unit connector D (20P) according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals D17 (GRN) D19 (RED), D20 (BLK) D19 (RED) D20 (BLK) AUDIO-NAVIGATION UNIT CONNECTOR D (20P) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio-navigation unit and the stereo amplifier. Replace the affected shielded harness. NO -Go to step 12.
  12. Check for continuity between audio-navigation unit connector D (20P) terminals No. 17 and No. 19 and stereo amplifier connector B (28P) terminals No. 9 and No. 21 respectively. AUDIO-NAVIGATION UNIT CONNECTOR D (20P) Wire side of female terminals STEREO AMPLIFIER CONNECTOR B (28P) Wire side of female terminals Is there continuity? YES -Go to step 13. NO -There is an open in the wire between the audio-navigation unit and the stereo amplifier. Replace the affected shielded harness.
  13. Substitute a known-good stereo amplifier; Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. Is the system OK? YES -Replace the original stereo amplifier; Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). Make sure that the latest navigation software is installed. Check any official Honda service website for more service information about the navigation system. Before assuming that a voice complaint is hardware related, ensure that the voice control system is being operated correctly. Make sure you are on the correct screen when trying to issue a voice command. For instance, the command "Find the nearest Italian Restaurant" only works on Map screen. (See the Navigation Manual for a complete list of allowed voice commands for the information being displayed) Close the windows and moonroof Set the fan speed to low (1 or 2) Adjust the air flow from the air conditioning vents so that they do not blow against the microphone on the ceiling Pause after pressing the TALK button then give a voice command clearly in a natural speaking voice. If the system cannot recognize your command, speak louder If you speak a command with something in your mouth, or your voice is too husky, or high pitched, the system may misunderstand your command Check the connectors for poor connections or loose terminals. Check for a loose roof console microphone; if it's loose, tighten it. Before troubleshooting, make sure you have the anti-theft code. After troubleshooting, enter the anti-theft code. Determine if the problem only happens to one person, or everyone who uses the system. If the system only has a problem with one person's voice, this should be considered a system limitation.

  1. Turn ignition switch to ON (0).
  2. Check for the hard error code (see «How to Check Error History (Navigation DTCs)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Are there any DTCs indicated? YES -Troubleshoot the indicated navigation DTCs. • NO -Go to step 3.
  3. Do the HandsFreeLink™ system Self Diagnostic Function (see «SELF-DIAGNOSTIC FUNCTION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#handsfreelink-system-4-cyl__self-diagnostic-function) ). Do you hear "The hands free system is OK"? YES -Substitute a known good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). • NO -Check for HFL DTCs (see «DTC TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#handsfreelink-system-4-cyl) ). If the HFL does not respond, do the HFL control unit input tests (see «CONTROL UNIT INPUT TEST»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#handsfreelink-system-4-cyl) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ). If the hard error code stored, check the hard error code troubleshooting first. Before troubleshooting, make sure you have the anti-theft code. After troubleshooting, enter the anti-theft code. Verify that the correct audio-navigation unit is installed for this model. Go into the System Diagnostic Mode (see SYSTEM DIAGNOSTIC MODE ), and use Version (see VERSION ). Check any official Honda service website for more service information about the navigation system.

  1. Connect the HDS to the DLC (see «GENERAL TROUBLESHOOTING INFORMATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#handsfreelink-system-4-cyl) ).
  2. Turn the ignition switch to ON (II).
  3. Check for Climate Control DTCs with the HDS. Are there any DTCs present? YES -Troubleshoot the indicated DTC, then recheck. NO -Go to step 4.
  4. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Are there any hard error codes stored? YES -Troubleshoot the indicated Navigation DTCs. • NO -Go to step 5.
  5. Substitute a known-good climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-4-cyl) ), and recheck. Does the symptom go away? YES -Replace the original climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-4-cyl) ). • NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  1. Turn the headlight on, and check that the dash brightness setting is not set to high.
  2. Check the connectors for poor connections or loose terminals.
  3. Verify that the correct audio-navigation unit is installed for this model. Go into the System Diagnostic Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ), and use Version (see «VERSION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__version) ).
  4. Before troubleshooting, make sure you have the anti-theft code.
  5. After troubleshooting, enter the anti-theft code.
  6. Check any official Honda service website for more service information about the navigation system.
Scheme 1087
  1. Turn the ignition switch to ON (II).
  2. Press the Day/Night (Sun/Moon Symbols ) button to see if the display changes to day and night modes. Does the display change to day and night modes when pressing the Day/Night button? YES -Go to step 3. NO -Go to «INTERFACE DIAL BUTTONS DO NOT WORK»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__interface-dial-buttons-do-not-work) troubleshooting (see «INTERFACE DIAL BUTTONS DO NOT WORK»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__interface-dial-buttons-do-not-work) ).
  3. Turn the headlights on, and adjust the dash brightness up and down, then to the middle range. Does the display change to day and night modes when turning the headlights on and off? YES -Intermittent failure, the system is OK at this time. NO -Go to step 4.
  4. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Are there any navigation DTCs indicated? YES -Troubleshoot the indicated DTCs. NO -Go to step 5.
  5. Turn the ignition switch to LOCK (0).
  6. Disconnect audio-navigation unit connector H (28P).
  7. Turn the ignition switch to ON (II).
  8. With the headlight switch on, measure the voltage between body ground and audio-navigation unit connector H (28P) terminal No. 4. AUDIO-NAVIGATION UNIT CONNECTOR H (28P) Is there battery voltage? YES -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), then reconnect all of the connectors, and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). If the symptom/indication is still present, replace the navigation display unit (see «NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__navigation-display-unit-removalinstallation) ). • NO -Repair an open in the wire between the passenger's under-dash fuse/relay box and the audio-navigation unit.

Note. Check the vehicle battery condition first (see BATTERY TEST ). Always check for and resolve all CAN DTCs before troubleshooting the navigation system. Verify that the correct audio-navigation unit is installed for this model. Go into the System Diagnostic Mode (see SYSTEM DIAGNOSTIC MODE ), and use Version (see VERSION ). Make sure that the latest navigation software is installed. Check any official Honda service website for more service information about the navigation system. Before troubleshooting, make sure you have the anti-theft code. After troubleshooting, enter the anti-theft code. Check the connectors for poor connections or loose terminals.

  1. Turn the ignition switch to ON (II). Does the system reboot, lock up, or freeze? YES -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -The system is OK at this time. Go into the System Diagnostic Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ), and use the Unit Check diagnosis (see «UNIT CHECK (QUICK CHECK)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__unit-check-quick-check) ) to check the audio-navigation unit and the navigation display unit status. If any status are NG, substitute the affected unit with a known-good unit, and recheck.

Note. Check the vehicle battery condition first (see BATTERY TEST ). This is not the same condition as when driving off-road (or on a fire or logging road). This condition is caused by a loss of map matching from a bad sensor input. Check for aftermarket or other objects that can block the GPS signal. Always perform Map Matching (see MAP MATCHING ) before proceeding with the troubleshooting. Always check for and resolve all CAN DTCs before troubleshooting the navigation system. Verify that the correct audio-navigation unit is installed for this model. Go into the System Diagnostic Mode (see SYSTEM DIAGNOSTIC MODE ), and use Version (see VERSION ). Check for aftermarket metallic window tinting. Check any official Honda service website for more service information about the navigation system. Before troubleshooting, make sure you have the anti-theft code. After troubleshooting, enter the anti-theft code. Check the connectors for poor connections or loose terminals.

Scheme 1088: Vehicle position icon wanders across the map when driving (does not follow a displayed road) or map
  1. Turn the ignition switch to ON (II).
  2. Check the GPS icon on the navigation screen. Is the GPS icon white or missing? YES -Do the GPS icon is white or not shown troubleshooting (see «GPS ICON IS WHITE OR NOT SHOWN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__gps-icon-is-white-or-not) ). NO -Go to step 3.
  3. Check for the hard error code (see «How to Check Error History (Navigation DTCs)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ) Are there any navigation DTCs indicated? YES -Troubleshoot the indicated navigation DTCs. • NO -Go to step 4.
  4. Go into the System Diagnostic Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ), and use the Car Status diagnosis (see «CAR STATUS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__car-status) ) to check the BACK signal. Does the BACK signal change from [0] to [1] when the shift lever position is changed from P or N to R? YES -Go to step 9. NO -Go to step 5.
  5. Turn the ignition switch to LOCK (0).
  6. Disconnect the navigation unit connector H (28P).
  7. Turn the ignition switch to ON (II).
  8. Measure the voltage between audio-navigation unit connector H (28P) terminal No. 20 and body ground. AUDIO-NAVIGATION UNIT CONNECTOR H (28P) Is there battery voltage? YES -Repair a short to power in the wire between the audio-navigation unit and the driver's under-dash fuse/relay box. • NO -Replace the audio-navigation unit (see «Audio-Navigation Unit Removal/Installation»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  9. Turn the ignition switch to LOCK (0).
  10. Substitute a known good audio-navigation unit (including HDD) (see «Audio-Navigation Unit Removal/Installation»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. Does the problem occur in the same place? YES -The problem is in the database and should be considered a characteristic of the system. Report the problem according to the Navigation Manual under Error Reporting. • NO -Replace the original audio-navigation unit (see «Audio-Navigation Unit Removal/Installation»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). The system will not operate without the 5-digit security (anti-theft) code. Follow the this procedure. (After 10 consecutive tries, you must cycle the key to continue trying) The Navigation System Diagnosis and Core Return Form is available on ISIS, under Job aids, and can be printed out for recording this information. This information will help the reman facility determine what caused the failure. Always check for and resolve all CAN DTCs before troubleshooting the navigation system. Check the connectors for poor connections or loose terminals. Before troubleshooting, make sure you have anti-theft code. Check any official Honda service website for more service information about the navigation system.

  1. Go into the System Diagnostic Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ), and use the ECU Info under the Unit Check (see «UNIT CHECK (QUICK CHECK)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__unit-check-quick-check) ). A brief diagnostic runs for 20 seconds, and the serial number is displayed. Is the serial number displayed? YES -Go to step 5 . NO -Go to step 2.
  2. Turn the ignition switch to LOCK (0).
  3. Remove the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  4. Check the serial number on the label on the upper side of the audio-navigation unit. Is the serial number con firmed on the upper side of the audio-navigation unit? YES -Go to step 5. NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  5. Using the serial number, look up the navigation security code in the Interactive Network (iN) (click: Service, Vehicle Information, Anti-Theft code Inquiry, and then select Navigation from the "product" dropdown box). Enter the serial number. Is a 5-digit code displayed on the screen? YES -Go to step 6. NO -Call the Warranty Department to obtain the code (the telephone number is in the PDI service bulletin). Do not call Tech Line. Then go to step 6.
  6. Check that the obtained code works to bypass the code screen in the navigation system. Does the code work? YES -The system is OK at this time. Return the vehicle to the client and give them the anti-theft code. NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and enter "Won't take security code" in the Problem description field of the core return form; (as proof, enclose the sticker that contains the Serial number and the Code).

Note. Check for aftermarket accessories that may interfere with the navigation system. Check the connectors for poor connections or loose terminals. Before troubleshooting, make sure you have the anti-theft code. After troubleshooting, enter the anti-theft code. The vehicle may have been used for a show event. Check for a short jumper harness in-line with the audio-navigation unit connector A (24P). If a jumper harness is present, remove it, and return it to Tech Line.

Scheme 1089: Navigation display stays on with the ignition switch in LOCK (0)
  1. Mare sure turn the ignition switch to LOCK (0). Does the navigation screen stay on? YES -Go to step 2. NO -The system is OK at this time.
  2. Measure the voltage between audio-navigation unit connector A (24P) terminal No. 14 and body ground. AUDIO-NAVIGATION UNIT CONNECTOR A (24P) Is there battery voltage? YES -Troubleshoot a short to power on the ACC circuit. NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). Verify that the correct navigation unit is installed for this model. Go into the System Diagnostic Mode (see SYSTEM DIAGNOSTIC MODE ), and use Version (see VERSION ). Check the connectors for poor connections or loose terminals. Check any official Honda service website for more service information about the navigation system.

  1. Turn the ignition switch to ON (II).
  2. Make sure the anti-theft code is entered.
  3. Turn on the audio system, and check for sound in each mode (AM/FM and CD). Is the sound normal? YES -Go to step 4. NO -Go to Sound Quality Diagnosis (see «SOUND QUALITY DIAGNOSIS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__sound-quality-diagnosis) ) or No sound is heard from the speaker(s) (display is normal) troubleshooting.
  4. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  5. Turn the ignition switch to LOCK (0) and then back to ON (II).
  6. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is there a hard error code stored? YES -Refer to the hard error code troubleshooting. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check any official Honda service website for more service information about the navigation system.

  1. Turn the ignition switch to ON (II).
  2. Make sure the anti-theft code is entered.
  3. Turn on the audio system, and check for XM radio sound. Is the sound normal? YES -Go to step 4. NO -Go to XM radio troubleshooting.
  4. Clear the hard error code (see «HOW TO CLEAR ERROR HISTORY»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  5. Turn the ignition switch to LOCK (0) and then back to ON (II).
  6. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is there a hard error code stored? YES -Refer to the hard error code troubleshooting. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. This is often caused by a loss of battery power, a low or poor battery condition, or a poor ground. Make sure that the latest navigation software is installed. Before troubleshooting, make sure you have the anti-theft code. After troubleshooting, enter the anti-theft code. Check any official Honda service website for more service information about the navigation system.

Scheme 1090: Navigation frequently asks for anti-theft code and/or needs GPS initialization
Scheme 1091
  1. Turn the ignition switch to LOCK (0).
  2. Disconnect audio-navigation unit connector A (24P).
  3. Check for poor connections or loose terminals at audio-navigation unit connector A (24P) terminals. Is the connection OK? YES -Repair poor connections or loose terminals, and recheck. NO -Go to step 4.
  4. Turn the ignition switch to ON (II).
  5. Measure the voltage between body ground and audio-navigation unit connector A (24P) terminals No. 14 and No. 24 individually. AUDIO-NAVIGATION UNIT CONNECTOR A (24P) Is there battery voltage? YES -Go to step 6. NO -If the +B wire does not have voltage, repair an open in the wire between the No. 15 (10 A) fuse in the under-hood fuse/relay box and audio-navigation unit connector A (24P) terminal No. 24. If the ACC wire does not have voltage, repair an open in the wire between the No. 18(7.5 A) fuse in the driver's under-dash fuse/relay box and audio-navigation unit connector A (24P) terminal No. 14.
  6. Measure the voltage between audio-navigation unit connector A (24P) terminal No. 12 and body ground. AUDIO-NAVIGATION UNIT CONNECTOR A (24P) Is there less than 0.2 V? YES -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Repair an open or high resistance in the wire between audio-navigation unit connector A (24P) and body ground (G651); Sedan (see «RIGHT SIDE WIRE HARNESS (SEDAN)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-4-cyl__right-side-wire-harness-sedan) ), Sport Wagon (see «RIGHT SIDE WIRE HARNESS (SPORT WAGON)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-4-cyl__right-side-wire-harness-sport-wagon) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN System Diagnosis Test Mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ). Check any official Honda service website for more service information about the navigation system.

Scheme 1092: Rearview camera image does not come on or work properly
Scheme 1093
Scheme 1094
Scheme 1095
Scheme 1096
Scheme 1097
Scheme 1098
  1. Turn the ignition switch to ON (II). Does the navigation screen come on and show an image when the vehicle is started? YES -Go to step 2. NO -Go to No picture is displayed troubleshooting (see «NO PICTURE IS DISPLAYED»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__no-picture-is-displayed) ).
  2. Go into the System Diagnostic Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ), and use the System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ) to check the connection between the navigation display unit and the rearview camera. Is the R-camera link on the screen? YES -Go to step 3. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  3. Confirm the system connection. Is the R-camera link green on the screen? YES -Go to step 4. NO -Do the DTC 1701: Rear Camera Error troubleshooting (see «DTC 1701: REAR CAMERA ERROR; DTC 2608: REAR CAMERA DIAG»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__dtc-1701-rear-camera-error-dtc) ).
  4. Turn the ignition switch to LOCK (0).
  5. Disconnect the navigation display unit 28P connector and driver's under-dash fuse/relay box connector P (20P).
  6. Check for continuity between navigation display unit 28P connector terminals No. 8 and No. 9 and driver's under-dash fuse/relay box connector P (20P) terminals No. 5 and No. 6 respectively. NAVIGATION DISPLAY UNIT 28P CONNECTOR Is there continuity? YES -Go to step 7. NO -Repair an open in the wire between the navigation display unit and the driver's under-dash fuse/relay box.
  7. Disconnect the rearview camera 6P connector.
  8. Check for poor connections or loose terminals at the navigation display unit 28P connector and the rearview camera 6P connector terminals. Are the connections OK? YES -Go to step 9. NO -Repair poor connections or loose terminals, and recheck.
  9. Check for continuity between the navigation display unit 28P connector and the rearview camera 6P connector according to the table. Sedan TERMINAL CONTINUITY REFERENCE CHART Navigation display unit connector Rearview camera connector Wire color 10 3 BLK (1) RED (2) 11 1 GRN 23 4 RED (1) BLK (2) 24 5 WHT 26 6 GRY (1) Navigation display unit connector (2) Rearview camera connector Sport Wagon CONNECTOR TERMINAL REFERENCE CHART Navigation display unit connector Rearview camera connector Wire color 10 5 BLK (1) GRN (2) 11 6 GRN (1) WHT (2) 23 4 RED 24 3 WHT (1) BLK (2) 26 2 GRY (1) Navigation display unit connector (2) Rearview camera connector NAVIGATION DISPLAY UNIT 28P CONNECTOR Sedan REARVIEW CAMERA 6P CONNECTOR Sport Wagon REARVIEW CAMERA 6P CONNECTOR Is there continuity? YES -Go to step 10. NO -There is an open in the wire(s) between the navigation display unit and the rearview camera. Replace the affected shielded harness.
  10. Check for continuity between the terminals of the navigation display unit 28P connector according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals 10 (BLK) 11 (GRN), 23 (RED), 24 (WHT), 26 (GRY) 11 (GRN) 23 (RED), 24 (WHT), 26 (GRY) 23 (RED) 24 (WHT), 26 (GRY) 24 (WHT) 26 (GRY) NAVIGATION DISPLAY UNIT 28P CONNECTOR Is there continuity between any of the terminals? YES -There is a short in the wires between the navigation display unit and the rearview camera. Replace the affected shielded harness. NO -Go to step 11.
  11. Check for continuity between the navigation display unit 28P connector and body ground according to the table. TERMINAL CONTINUITY REFERENCE CHART Navigation display unit connector Wire color 10 BLK 11 GRN 23 RED 24 WHT 26 GRY NAVIGATION DISPLAY UNIT 28P CONNECTOR Is there continuity? YES -There is a short in the wire(s) between the navigation display unit and the rearview camera. Replace the affected shielded harness. NO -Go to step 12.
  12. Turn the ignition switch to ON (II).
  13. Measure the voltage between the navigation display unit 28P connector and body ground according to the table. TERMINAL VOLTAGE REFERENCE CHART Navigation display unit connector Wire color 10 BLK 11 GRN 23 RED 24 WHT 26 GRY NAVIGATION DISPLAY UNIT 28P CONNECTOR Is there 0.2 V or more? YES -There is a short to power in the wire(s) between the navigation display unit and the rearview camera. Replace the affected shielded harness. NO -Go to step 14.
  14. Turn the ignition switch to LOCK (0).
  15. Reconnect navigation display unit 28P connector.
  16. Substitute a known-good rearview camera; Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  17. Turn the ignition switch to ON (II), and check the rearview camera image in shift lever position is R. Is the rearview image OK? YES -Replace the original rearview camera; Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). • NO -Replace the navigation display unit (see «NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__navigation-display-unit-removalinstallation) ).

If your client complains that traffic and/or weather is not displayed, it could be because a traffic and/or weather setting is not correct.

Note. Always check for and resolve all CAN DTCs before troubleshooting the navigation system. Check the connectors for poor connections or loose terminals. Before troubleshooting, make sure you have the anti-theft code. After troubleshooting, enter the anti-theft code. Check any official Honda service website for more service information about the navigation system. A marginal battery or poorly performing charging system may cause the AcuraLink control unit (XM receiver) to malfunction.

Scheme 1099: Traffic or Weather information is not shown on map screen
Scheme 1100
Scheme 1101
Scheme 1102
Scheme 1103
Scheme 1104
  1. Test the vehicle battery condition (see «BATTERY TEST»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-4-cyl__battery-test) ). Is the battery in good condition? YES -Go to step 2. NO -Troubleshoot the battery and/or charging system, and recheck.
  2. Park the vehicle outside where you have a clear view of the southern sky.
  3. Turn the ignition switch to ON (II).
  4. Check to see if the vehicle is receiving an XM signal. Select Setup, then select more, then select Traffic/Weather.
  5. Make sure that you are receiving the applicable signal that you are troubleshooting. For example, if the client complains that they do not receive real-time traffic and account is Expired, you need to contact XM to confirm the account is active. Refer to the table for the message status and action. NOTE: This check confirms the client account, but does not check the XM signal reception. The XM radio continues to tune XM channels 000, 001, 174, or 247, even if the XM account is expired. MESSAGE DESCRIPTION CHART Message Description Action Receiving The system is receiving XM signal. Traffic information and/or weather information. The system is OK. For traffic information, go to step 7. For weather information, go to step 9. No signal The signal is not being received. Make sure you are outside with a clear view of the sky. Go into the System Diagnostic Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ) to check System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). Expired The account is expired. Go to step 6. Loading The system is searching for the signal or receiving an update. Give the system a few minutes to finish loading. If the loading message does not go away, Go into the System Diagnostic Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ) to check System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ). Check antenna There is a problem with the XM antenna. Check the XM antenna for damage or loose connections, then Go into the System Diagnostic Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ) to check System Links (see «SYSTEM LINKS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl) ).
  6. Make sure the client's XM NavTraffic and/or XM weather information account status is active. These accounts are separate from the regular XM radio subscription, and they have separate fees. NOTE: For the Acura TSX, real-time traffic and weather are free for the first three months. To check the XM NavTraffic and XM weather account status: Call XM Radio at 800-852-9696. Make sure you have: The VIN The XM radio ID (shown on channel 000) From the automated phone menu, select tech support. Tell the agent that you are working on an Acura vehicle, and ask them to check the XM NavTraffic and XM weather account(s) status. Have the agent confirm that the XM NavTraffic and XM weather subscription(s) applies to the vehicle VIN you are working on. NOTE: A client may own more than one vehicle capable of displaying real-time traffic and XM weather. Is the XM NavTraffic and XM weather account(s) status active? YES - For traffic information, go to step 7. For weather information, go to step 9 . NO -If the free trial period is expired, return the vehicle to the client, and inform them how to renew their XM NavTraffic and XM weather subscription(s) by calling XM Radio at 800-852-9696. If the free trial period has not expired, call XM Radio at 800-852-9696 and reactivate the account for the remainder of the free trial period, then request rapid refresh. To do a rapid refresh: Park the vehicle outside, in a clear area, with the engine running. Turn the audio system on, and tune to an XM radio channel. Wait 30 minutes. If the vehicle now receives real-time traffic information and/or XM weather, return it to the client, otherwise go to step 7.
  7. Make sure the navigation map is set to any scale from 1/20 mile of a mile to 5 miles. If the scale is not set within this range, rotate the interface dial knob, or use the zoom in buttons to adjust the map to proper scale. NOTE: XM weather is available on all scales. Do you see real-time traffic on the navigation display? YES -Return the vehicle to the client, and explain the proper settings. NO -Go to step 8.
  8. Make sure the real-time traffic settings are correct. Press the map/guide button, then select the map menu by pressing in the selector button. Select Show Icon on Map by turning the interface dial, then pressing in the selector button. Select the TRAFFIC icon (A) from the Icon selection bar at the bottom of the navigation display. Select ICON OPTION (B) by pushing the selector to the right. From the Select Category for Icon settings menu, select the TRAFFIC. Make sure both Traffic Speeds and Traffic Icons are solid blue. If they are not, select Traffic Speeds by pressing in the selector on the Select Traffic Info screen. It should turn solid blue. Turn the interface dial to select TRAFFIC Icons, and press in the selector again. It should turn solid blue. Push the selector to the right (DONE) to complete the process. Do you see real-time traffic on the navigation display? YES -Return the vehicle to the client, and explain the proper settings. NO -Go to step 9.
  9. Make sure the XM weather settings are correct. From the Show Icon on Map menu, select the WEATHER icon (A) from the Icon selection bar at the bottom of the navigation display. Select ICON OPTION (B) by pushing the selector to the right. From the Select Category for Icon settings menu, select the WEATHER. Make sure both Weather Warning Icons and WEATHER Icons are solid blue. If they are not, select Weather Warning Icon by pressing in the selector on the Select Weather Info screen. It should turn solid blue. Turn the interface dial to select WEATHER Icons, and press in the selector again. It should turn solid blue. Push the selector to the right (DONE) to complete the process. Do you see XM weather on the navigation display? YES -Return the vehicle to the client, and explain the proper settings. NO -Go to step 10.
  10. Do the diagnostic mode checks: Start the vehicle, and enter the System Diagnostic Mode by pressing and holding the Menu, Map/Guide, and Cancel buttons. Go into the System Diagnostic Mode, and select the Self-Diagnosis Mode, and verify that all the icons are green. If any links/icons are red, refer to the applicable service manual section for repair information, then go to step 11. Return to the Detail Information & Setting menu and select XM (HIP), then select XM (HIP) System Link, and verify that the links/icons are green. If any links/icons are red, refer to the applicable service manual section for repair information, then go to step 11.
  11. Do a VIN status inquiry, updating the AcuraLink control unit software. Are there any applicable product updates or service bulletins? YES -Do the applicable product updates and service bulletins, then recheck the vehicle. If real-time traffic does not work, go to step 12. NO -Go to step 12.
  12. Reset the AcuraLink control unit. NOTE: Make sure you have the anti-theft codes for the navigation system. To reset the AcuraLink control unit: Disconnect AcuraLink control unit (XM receiver) connector B (2P) from the AcuraLink control unit (XM receiver). Enter the System Diagnostic Mode, select XM (HIP), then select XM (HIP) ECU. Select Data Reset to do the reset. When the reset is done, press cancel twice to return to the XM (HIP) diagnostic menu. Select Return to fully exit the diagnostic mode. Turn the ignition switch to LOCK (0). Reconnect AcuraLink control unit (XM receiver) connector B (2P). Start the vehicle. Enter the anti-theft code. Let the navigation system boot, then select one of the traffic scales (5, 1, 1/4, 1/20 miles). Park the vehicle outside with a clear view of the southern sky, and verify you are receiving an XM radio signal (see step 4 ). Do you see real-time traffic on the navigation display? YES -Call Acura Client Services to ask for an AcuraLink reactivation. Return the vehicle to the client. NO -Go to step 13.
  13. Substitute a known-good AcuraLink control unit (XM receiver); Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck the vehicle. Park the vehicle outside with a clear view of the southern sky, and verify you are receiving an XM radio signal (see step 4 ). Do you see real-time traffic on the navigation display? YES -Replace the original AcuraLink control unit (XM receiver); Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). Register the new AcuraLink control unit with XM radio and Acura Client Services. Return the vehicle to the client. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the problem goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Special Tools Required

SCS Service Connector 07PAZ-001010A

Scheme 1105: Forced Starting of the Audio-Navigation Unit
  1. Turn the ignition switch to LOCK (0).
  2. Remove the right side kick panel (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__trim-removalinstallation-door-areas) ).
  3. Connect the SCS service connector (A) to the navigation service check connector (B) located by the passenger's kick panel.
  4. Turn the ignition switch to ON (II).
  5. Check that the diagnosis menu for the picture diagnosis starts up, and then changes to the System Links menu. NOTE: If the display fails to display the System Links screen, refer to no picture is displayed troubleshooting (see «NO PICTURE IS DISPLAYED»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__no-picture-is-displayed) ).

Note. The audio-navigation unit and HDD are mated and cannot be substituted separately. If you need to substitute a known-good unit for testing, substitute a complete known-good audio-navigation unit and HDD. Check any official Honda service website for more service information about the navigation system. Static electricity can damage the HDD. Always follow proper handling procedures. Always use the anti-static mat (ESD) and wrist strap when removing the HDD. Before you open the audio-navigation unit or handle the replacement HDD, attach the wrist strap around one of your wrists, and attach the alligator clip to the ESD mat. Make sure you use the screws in the same holes. The HDD can be damaged if the wrong screws are used. You do not have to peel off the plastic cover to remove the screws or the HDD. Do not force the HDD. If it does not slide in smoothly, check the alignment of the HDD and the pins. If the pins are bent, replace the HDD. Make sure the HDD screws are not loose. If they are, the HDD can be damaged. Handle the HDD by its edges. Do not touch the pins.

Scheme 1106: HDD Removal/Installation
Scheme 1107
  1. Remove the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  2. Remove the bolts (A) and the passenger's side bracket (B).
  3. Remove the mounting screws (A).
  4. Lift the plastic tab (B), and use it to pull out the HDD (C).
  5. Install the HDD in the reverse order of removal. NOTE: Make sure the HDD is properly aligned when installing the HDD.

Note. Put on gloves to protect your hands. Take care not to scratch the dashboard and related parts. Lay a shop towel under the parts when working on them to protect the face panel from scratches or other damage. Eject the disc before removing the audio-navigation unit to prevent damaging the CD/DVD player's load mechanism. If you are replacing the audio-navigation unit, write down the audio presets (if possible), then enter them into the new audio-navigation unit. If the audio-navigation unit is replaced or disconnected, a Map Matching must be done (see MAP MATCHING ).

Scheme 1108: Audio-Navigation Unit Removal/Installation
Scheme 1109
Scheme 1110
  1. Make sure you have the 5-digit anti-theft code.
  2. Remove the driver's center trim (see «CENTER TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__center-trim-removalinstallation) ) and the passenger's dashboard trim (see «PASSENGER'S DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__passengers-dashboard-trim-removalinstallation) ).
  3. Remove the passenger's center trim (see «CENTER TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__center-trim-removalinstallation) ) and the center console panel (see «CENTER CONSOLE PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#consoles-4-cyl__center-console-panel-removalinstallation) ).
  4. Remove the climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-4-cyl) ).
  5. Carefully remove the bolts (A) and bolts (B), then pull the audio-navigation unit (C) out.
  6. Disconnect the audio-navigation unit connectors, and remove the audio-navigation unit. NOTE: If you are replacing the audio-navigation unit, remove the HDD (see «HDD REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__hdd-removalinstallation) ). Some of the audio-navigation connectors have lever locks. Release the locks before the disconnecting the connectors (see «GENERAL TROUBLESHOOTING INFORMATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  7. Remove the bolts (A) and brackets (B) from the audio-navigation unit.
  8. Remove the screws and the front panel (A) from the audio-navigation unit (B).
  9. Install the audio-navigation unit in the reverse order of removal. NOTE: Check any official Honda service website for more service information about patches for the navigation system. Apply any prescribed patches to the new audio-navigation unit.
  10. Enter the new 5-digit anti-theft code.
  11. Park the vehicle outside, and do the GPS Initialization (see «SYSTEM INITIALIZATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__system-initialization) ).
  12. Give the new navigation anti-theft code to the client.

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Take care not to scratch the dashboard and display visor. When prying components, use the applicable KTC trim tool or equivalent. Put on gloves to protect your hands.

Scheme 1111: Navigation Display Unit Removal/Installation
  1. Remove the speaker cover (see «SPEAKER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__speaker-cover-removalinstallation) ).
  2. Carefully push out the navigation display unit (A).
  3. Disconnect the connectors (B), and remove the navigation display unit.
  4. Install the navigation display unit in the reverse order of removal.

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Do this procedure in a clean place free from dirt. Wear latex or vinyl gloves when doing this procedure (Do not use fabric gloves). When removing the navigation display visor, do not touch the scale plate. If there is dirt on the scale plate, clean it using compressed air. When installing the navigation display visor onto the LCD assembly, be careful not to touch the scale plate. Check that the navigation display visor and the LCD assembly are properly installed. Since the LCD assembly and the navigation display visor are installed at an angle, be sure that the screws are properly seated. If not properly seated, tighten the screws. Check that the navigation display unit assembly has no damage.

Scheme 1112: Navigation Display Visor Removal/Installation
Scheme 1113
  1. Remove the navigation display unit (see «NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__navigation-display-unit-removalinstallation) ).
  2. Remove the passenger's airbag cutoff indicator (see «INSTALLATION»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl) ).
  3. Remove the screws (A) from the LCD assembly (B).
  4. Remove the display visor (A) from the LCD assembly (B).
  5. Install the navigation display visor in the reverse order of removal.

Note. Put on gloves to protect your hands. Take care not to scratch the dashboard and related parts. Lay a workshop towel under the parts when working on them to protect the face panel from scratches or other damage.

Scheme 1114: HFL-Navigation Microphone Removal/Installation
  1. Remove the roof console; Sedan (see step 6 on «HEADLINER REMOVAL/INSTALLATION - SEDAN»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__headliner-removalinstallation-sedan) ), Sport Wagon (see step 4 on «HEADLINER REMOVAL/INSTALLATION - SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__headliner-removalinstallation-sport-wagon) ), and disconnect the connector (A) from the HFL-navigation microphone (B).
  2. Remove the screws and the HFL-navigation microphone.
  3. Install the HFL-navigation microphone in the reverse order of removal.
Scheme 1115: Interface Dial Removal/Installation
Scheme 1116
  1. Remove the audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  2. Remove the screw and harness cover (A).
  3. Disconnect the interface dial connector (A). Remove the screws and interface dial (B). Carefully pry off the knob (C) with a small screwdriver, then apply slow and steady pressure with your thumbs to push out the interface dial until the dial (D) pops off.
  4. Install the dial in the reverse order of removal. NOTE: If the hard buttons do not work, but the jog dial does, recheck the interface dial connector connection.
Scheme 1117: GPS Antenna Removal/Installation
  1. Remove these items: Gauge control module (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#gauges-4-cyl__gauge-control-module-replacement) ) Audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ) Audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) )
  2. Remove the bolts (A) and detach the clips (B).
  3. Carefully pull out the GPS antenna (C) from the dashboard, and remove it.
  4. Install the GPS antenna in the reverse order of removal.

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Scheme 1118: Voice Control Switch Test
  1. Remove the voice control switch (see «VOICE CONTROL SWITCH REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__voice-control-switch-replacement) ).
  2. Measure the resistance between terminals No. 4 and No. 5 in each switch position according to the table. TERMINAL RESISTANCE REFERENCE CHART Position Resistance No button pressed About 10 kohms TALK button pressed About 2.2 kohms BACK button pressed About 652 ohms
  3. If the resistance is not as specified, replace the voice control switch (see «VOICE CONTROL SWITCH REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__voice-control-switch-replacement) ).

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Scheme 1119: Voice Control Switch Replacement
Scheme 1120
  1. Remove the driver's airbag assembly (see «REMOVAL»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl__removal) ).
  2. Remove the covers (A) and screws from the steering wheel (B).
  3. Disconnect the connectors from the steering switches, then remove the steering wheel trim (C).
  4. Remove the screws (A) and the voice control switch (B).
  5. Install the voice control switch in the reverse order of removal.
Scheme 1121: Sedan
  1. Remove the trunk lid trim panel (see «TRIM REMOVAL/INSTALLATION - TRUNK LID»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__trim-removalinstallation-trunk-lid) ).
  2. Disconnect the connector (A), and detach the clip (B).
  3. Pull the rearview camera (C) out, and remove it.
  4. Install the rearview camera in the reverse order of removal.
Scheme 1122: Sport Wagon
  1. Remove the tailgate lower trim panel (see «REAR FLOOR LID HANDLE»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl) ).
  2. Disconnect the connector (A), then pull the rearview camera (B) out, and remove it.
  3. Install the rearview camera in the reverse order of removal.

See also:
AUDIO UNIT CONNECTOR FOR INPUTS AND OUTPUTS (WITH ELS AUDIO)
BATTERY TEST
GENERAL TROUBLESHOOTING INFORMATION
ECM/PCM UPDATE
ECM/PCM REPLACEMENT
XM ANTENNA REPLACEMENT
GENERAL TROUBLESHOOTING INFORMATION
TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A
HANDSFREELINK CONTROL UNIT REMOVAL/INSTALLATION
XM RADIO DISPLAY IS BLANK AND NO STATION INFORMATION IS DISPLAYED (WITH ELS AUDIO, WITHOUT ACURALINK™)
AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH ELS AUDIO)
CLIMATE CONTROL UNIT REMOVAL/INSTALLATION
SELF-DIAGNOSTIC FUNCTION
DTC TROUBLESHOOTING
RIGHT SIDE WIRE HARNESS (SEDAN)
RIGHT SIDE WIRE HARNESS (SPORT WAGON)
AUDIO WIRE HARNESS (WITH NAVIGATION)
SOUND QUALITY DIAGNOSIS
TRIM REMOVAL/INSTALLATION - DOOR AREAS
CENTER TRIM REMOVAL/INSTALLATION
PASSENGER'S DASHBOARD TRIM REMOVAL/INSTALLATION
CENTER CONSOLE PANEL REMOVAL/INSTALLATION
COMPONENT LOCATION INDEX
SPEAKER COVER REMOVAL/INSTALLATION
HEADLINER REMOVAL/INSTALLATION - SEDAN
HEADLINER REMOVAL/INSTALLATION - SPORT WAGON
GAUGE CONTROL MODULE REPLACEMENT
REMOVAL
TRIM REMOVAL/INSTALLATION - TRUNK LID
REAR FLOOR LID HANDLE
SAVE USERS MEMORY
GPS ICON IS WHITE OR NOT SHOWN
FORCED STARTING OF THE AUDIO-NAVIGATION UNIT
AUDIO-NAVIGATION UNIT AND HDD SERVICE PRECAUTIONS
1001
1101
1102
1201
1204
1206
1301
1302
1303
1305
1306
1402
1403
1404
1405
1701
1702
2601
2605
2607
2610
2611
2612
2701
2702
2703
2706
2707
2709
2710
SYSTEM INITIALIZATION
FACTORY DIAGNOSTIC SCREEN IN LINE DIAG
HOW TO ANSWER CLIENT QUESTIONS ABOUT NAVIGATION COVERAGE
VERSION
ANTI-THEFT FEATURE
SELF-INERTIAL NAVIGATION LIMITATIONS
LCD UNIT LIMITATIONS
MAP MATCHING
ORDERING AN UPDATE NAVIGATION DVD
PICTURE IS MISSING A COLOR OR TONE OR IS AN ODD COLOR
PICTURE HAS LINES, ROLLS, OR IS BLURRY
NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION
AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION
NAVIGATION CANNOT CONTROL HVAC BY VOICE COMMAND
HFL-NAVIGATION MICROPHONE REMOVAL/INSTALLATION
YAW RATE SENSOR
HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)
HDD REMOVAL/INSTALLATION
XM (HIP)
FUNCTIONAL SETUP
MONITOR CHECK
UNIT CHECK (QUICK CHECK)
GPS INFORMATION
INTERFACE DIAL BUTTONS DO NOT WORK
CAR STATUS
NO PICTURE IS DISPLAYED
VOICE CONTROL SWITCH REPLACEMENT
