Audio System (4-cyl) Acura TSX II

Entertainment Systems 286 illustrations ~34410 words

Scheme 636

Scheme 636: Sedan

Scheme 637

Scheme 637: Sedan

Scheme 638

Scheme 638: Sport Wagon

Scheme 639

Scheme 639: Sport Wagon

Disconnecting

To disconnect the connector, pull the lever (A) while pushing the lock tab (B) down, then pull the connector (C).

Scheme 640

Scheme 640: Disconnecting

Connecting

To connect the connector, push the connector into the connector sleeve (A). As the connector is pressed in, the lever (B) moves to the locked position.

Scheme 641

Scheme 641: Connecting

Symptom Troubleshooting Index

SymptomDiagnostic ProcedureAlso Check for
Poor AM or FM radio reception or interference (Sedan with ELS audio)Symptom Troubleshooting (see POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (SEDAN WITH ELS AUDIO) )Antenna lead short or open in the wire Aftermarket window tinting
Poor AM or FM radio reception or interference (Sport Wagon with ELS audio)Symptom Troubleshooting (see POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (SPORT WAGON WITH ELS AUDIO) )Antenna lead short or open in the wire Aftermarket window tinting
Poor AM or FM radio reception or interference (Sedan with premium audio)Symptom Troubleshooting (see POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (SEDAN WITH PREMIUM AUDIO) )Antenna lead short or open in the wire Aftermarket window tinting
Poor AM or FM radio reception or interference (Sport Wagon with premium audio)Symptom Troubleshooting (see POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (SPORT WAGON WITH PREMIUM AUDIO) )Antenna lead short or open in the wire Aftermarket window tinting
Audio unit power switch will not turn on (No information display and no sound) (with ELS audio)Symptom Troubleshooting (see AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH ELS AUDIO) )
Audio unit power switch will not turn on (No information display and no sound) (with premium audio)Symptom Troubleshooting (see AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH PREMIUM AUDIO) )
Audio unit power switch will not turn off (with ELS audio)Symptom Troubleshooting (see AUDIO UNIT POWER SWITCH WILL NOT TURN OFF (WITH ELS AUDIO) )
Audio unit power switch will not turn off (with premium audio)Symptom Troubleshooting (see AUDIO UNIT POWER SWITCH WILL NOT TURN OFF (WITH PREMIUM AUDIO) )
No sound is heard from the speaker(s) (display is normal) (with ELS audio)Symptom Troubleshooting (see NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) (WITH ELS AUDIO) )
No sound is heard from the speaker(s) (display is normal) (with premium audio)Symptom Troubleshooting (see NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) (WITH PREMIUM AUDIO) )
Auxiliary input sound is low or cannot be heard (with ELS audio)Symptom Troubleshooting (see AUXILIARY INPUT SOUND IS LOW OR CANNOT BE HEARD (WITH ELS AUDIO) )
Auxiliary input sound is low or cannot be heard (with premium audio)Symptom Troubleshooting (see AUXILIARY INPUT SOUND IS LOW OR CANNOT BE HEARD (WITH PREMIUM AUDIO) )
Audio system sound is weak or distorted (display is normal) (with ELS audio)Symptom Troubleshooting (see AUDIO SYSTEM SOUND IS WEAK OR DISTORTED (DISPLAY IS NORMAL) (WITH ELS AUDIO) )
Audio system sound is weak or distorted (display is normal) (with premium audio)Symptom Troubleshooting (see AUDIO SYSTEM SOUND IS WEAK OR DISTORTED (DISPLAY IS NORMAL) (WITH PREMIUM AUDIO) )
Radio preset memory is lost (with ELS audio)Symptom Troubleshooting (see RADIO PRESET MEMORY IS LOST (WITH ELS AUDIO) )
Radio preset memory is lost (with premium audio)Symptom Troubleshooting (see RADIO PRESET MEMORY IS LOST (WITH PREMIUM AUDIO) )
Volume does not change (with ELS audio)Symptom Troubleshooting (see VOLUME DOES NOT CHANGE (WITH ELS AUDIO) )
Volume does not change (with premium audio)Symptom Troubleshooting (see VOLUME DOES NOT CHANGE (WITH PREMIUM AUDIO) )
Volume does not increase with speed (with ELS audio)Symptom Troubleshooting (see VOLUME DOES NOT INCREASE WITH SPEED (WITH ELS AUDIO) )
Volume does not increase with speed (with premium audio)Symptom Troubleshooting (see VOLUME DOES NOT INCREASE WITH SPEED (WITH PREMIUM AUDIO) )
Volume is too high or too low when driving at freeway speeds (with ELS audio)Symptom Troubleshooting (see VOLUME IS TOO HIGH OR TOO LOW WHEN DRIVING AT FREEWAY SPEEDS (WITH ELS AUDIO) )
Volume is too high or too low when driving at freeway speeds (with premium audio)Symptom Troubleshooting (see VOLUME IS TOO HIGH OR TOO LOW WHEN DRIVING AT FREEWAY SPEEDS (WITH PREMIUM AUDIO) )
Radio tuner does not change stations (with ELS audio)Symptom Troubleshooting (see RADIO TUNER DOES NOT CHANGE STATIONS (WITH ELS AUDIO) )
Radio tuner does not change stations (with premium audio)Symptom Troubleshooting (see RADIO TUNER DOES NOT CHANGE STATIONS (WITH PREMIUM AUDIO) )
Audio system information does not display on the audio-HVAC display unit (with premium audio)Symptom Troubleshooting (see RADIO TUNER DOES NOT CHANGE STATIONS (WITH PREMIUM AUDIO) )
Security indicator does not work properly (with ELS audio)Symptom Troubleshooting (see SECURITY INDICATOR DOES NOT WORK PROPERLY (WITH ELS AUDIO) )
Security indicator does not work properly (with premium audio)Symptom Troubleshooting (see SECURITY INDICATOR DOES NOT WORK PROPERLY (WITH PREMIUM AUDIO) )
Audio-navigation switch panel button illumination does not work (with ELS audio)Symptom Troubleshooting (see AUDIO-NAVIGATION SWITCH PANEL BUTTON ILLUMINATION DOES NOT WORK (WITH ELS AUDIO) )
Audio switch panel button illumination does not work (with premium audio)Symptom Troubleshooting (see AUDIO SWITCH PANEL BUTTON ILLUMINATION DOES NOT WORK (WITH PREMIUM AUDIO) )
Audio remote switch does not work properly (with ELS audio)Symptom Troubleshooting (see AUDIO REMOTE SWITCH DOES NOT WORK PROPERLY (WITH ELS AUDIO) )
Audio remote switch does not work properly (with premium audio)Symptom Troubleshooting (see AUDIO REMOTE SWITCH DOES NOT WORK PROPERLY (WITH PREMIUM AUDIO) )
Audio disc does not load (with ELS audio)Symptom Troubleshooting (see AUDIO DISC DOES NOT LOAD (WITH ELS AUDIO) )Damaged disc
Audio disc does not load (with premium audio)Symptom Troubleshooting (see AUDIO DISC DOES NOT LOAD (WITH PREMIUM AUDIO) )Damaged disc
Audio disc does not eject (with ELS audio)Symptom Troubleshooting (see AUDIO DISC DOES NOT EJECT (WITH ELS AUDIO) )Damaged disc Disc with a label
Audio disc does not eject (with premium audio)Symptom Troubleshooting (see AUDIO DISC DOES NOT EJECT (WITH PREMIUM AUDIO) )Damaged disc Disc with a label
Audio disc does not play (with ELS audio)Symptom Troubleshooting (see AUDIO DISC DOES NOT PLAY (WITH ELS AUDIO) )Foreign objects such coins or paper inserted into the CD player
Audio disc does not play (with premium audio)Symptom Troubleshooting (see AUDIO DISC DOES NOT PLAY (WITH PREMIUM AUDIO) )Foreign objects such coins or paper inserted into the CD player
Audio disc skips (with ELS audio)Symptom Troubleshooting (see AUDIO DISC SKIPS (WITH ELS AUDIO) )Tire pressure (over-inflated), disc smudged, or scratched
Audio disc skips (with premium audio)Symptom Troubleshooting (see AUDIO DISC SKIPS (WITH PREMIUM AUDIO) )Tire pressure (over-inflated), disc smudged, or scratched
Audio system button does not work (with ELS audio)Symptom Troubleshooting (see AUDIO SYSTEM BUTTON DOES NOT WORK (WITH ELS AUDIO) )
Audio unit button does not work (with premium audio)Symptom Troubleshooting (see AUDIO UNIT BUTTON DOES NOT WORK (WITH PREMIUM AUDIO) )
Audio unit disc indicator does not work (with ELS audio)Symptom Troubleshooting (see AUDIO UNIT DISC INDICATOR DOES NOT WORK (WITH ELS AUDIO) )
Audio unit disc indicator does not work (with premium audio)Symptom Troubleshooting (see AUDIO UNIT DISC INDICATOR DOES NOT WORK (WITH PREMIUM AUDIO) )
USB device does not function (with ELS audio)Symptom Troubleshooting (see USB DEVICE DOES NOT FUNCTION (WITH ELS AUDIO) )USB device compatibility (see Owner's Manual)
USB device does not function (with premium audio)Symptom Troubleshooting (see USB DEVICE DOES NOT FUNCTION (WITH PREMIUM AUDIO) )USB device compatibility (see Owner's Manual)
USB input sound is low or cannot be heard (with ELS audio)Symptom Troubleshooting (see USB INPUT SOUND IS LOW OR CANNOT BE HEARD (WITH ELS AUDIO) )USB device compatibility (see Owner's Manual)
USB input sound is low or cannot be heard (with premium audio)Symptom Troubleshooting (see USB INPUT SOUND IS LOW OR CANNOT BE HEARD (WITH PREMIUM AUDIO) )USB device compatibility (see Owner's Manual)
Error code: XM NO SIGNAL or XM LOADING is displayed (with ELS audio)Symptom Troubleshooting (see ERROR CODE: XM NO SIGNAL OR XM LOADING IS DISPLAYED (WITH ELS AUDIO) )
Error code: XM NO SIGNAL or XM LOADING is displayed (with premium audio)Symptom Troubleshooting (see ERROR CODE: XM NO SIGNAL OR XM LOADING IS DISPLAYED (WITH PREMIUM AUDIO) )
Error code: XM ANTENNA or XM LOADING is displayed (with AcuraLink)Symptom Troubleshooting (see ERROR CODE: XM ANTENNA OR XM LOADING IS DISPLAYED (WITH ACURALINK) )
Error code: XM ANTENNA or XM LOADING is displayed (without AcuraLink)Symptom Troubleshooting (see ERROR CODE: XM ANTENNA OR XM LOADING IS DISPLAYED (WITHOUT ACURALINK) )
XM radio display is blank and no station information is displayed (with ELS audio, with AcuraLink)Symptom Troubleshooting (see XM RADIO DISPLAY IS BLANK AND NO STATION INFORMATION IS DISPLAYED (WITH ELS AUDIO, WITH ACURALINK) )Also refer to Audio unit power switch will not turn on (No information display and no sound) (see AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH ELS AUDIO) )
XM radio display is blank and no station information is displayed (with ELS audio, without AcuraLink)Symptom Troubleshooting (see XM RADIO DISPLAY IS BLANK AND NO STATION INFORMATION IS DISPLAYED (WITH ELS AUDIO, WITHOUT ACURALINK) )Also refer to Audio unit power switch will not turn on (No information display and no sound) (see AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH ELS AUDIO) )
XM radio display is blank and no station information is displayed (with premium audio)Symptom Troubleshooting (see XM RADIO DISPLAY IS BLANK AND NO STATION INFORMATION IS DISPLAYED (WITH PREMIUM AUDIO) )Also refer to Audio unit power switch will not turn on (No information display and no sound) (see AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH PREMIUM AUDIO) )
XM radio preset memory is lost (with ELS audio, with AcuraLink)Symptom Troubleshooting (see XM RADIO PRESET MEMORY IS LOST (WITH ELS AUDIO, WITH ACURALINK) )
XM radio preset memory is lost (with ELS audio, without AcuraLink)Symptom Troubleshooting (see XM RADIO PRESET MEMORY IS LOST (WITH ELS AUDIO, WITHOUT ACURALINK) )
XM radio preset memory is lost (with premium audio)Symptom Troubleshooting (see XM RADIO PRESET MEMORY IS LOST (WITH PREMIUM AUDIO) )
Poor or no sound with XM radio (Audio unit does display XM channels) (with ELS audio, with AcuraLink)Symptom Troubleshooting (see POOR OR NO SOUND WITH XM RADIO (AUDIO UNIT DOES DISPLAY XM CHANNELS) (WITH ELS AUDIO, WITH ACURALINK) )
Poor or no sound with XM radio (Audio unit does display XM channels) (with ELS audio, without AcuraLink)Symptom Troubleshooting (see POOR OR NO SOUND WITH XM RADIO (AUDIO UNIT DOES DISPLAY XM CHANNELS) (WITH ELS AUDIO, WITHOUT ACURALINK) )
Poor or no sound with XM radio (Audio unit does display XM channels) (with premium audio)Symptom Troubleshooting (see POOR OR NO SOUND WITH XM RADIO (AUDIO UNIT DOES DISPLAY XM CHANNELS) (WITH PREMIUM AUDIO) )
No sound when Bluetooth audio is used (with navigation)HFL Symptom Troubleshooting (see MEPC2342_0098.sgm: )Bluetooth phone GA-Net line open/short HandsFreeLink control unit Audio-navigation unit
No sound when Bluetooth audio is used (without navigation)HFL Symptom Troubleshooting (see THE HFL MESSAGES AND VOICE PROMPTS CANNOT BE HEARD OR ARE WEAK (WITHOUT NAVIGATION) )Bluetooth phone GA-Net line open/short HandsFreeLink control unit Audio unit
Bluetooth audio does not work (with navigation)HFL Symptom Troubleshooting (see BLUETOOTH AUDIO DOES NOT WORK (WITH NAVIGATION) )Bluetooth phone GA-Net line open/short HandsFreeLink control unit
Bluetooth audio does not work (without navigation)HFL Symptom Troubleshooting (see BLUETOOTH AUDIO DOES NOT WORK (WITHOUT NAVIGATION) )Bluetooth phone GA-Net line open/short HandsFreeLink control unit
Bluetooth cell phone cannot be pairedHFL Symptom Troubleshooting (see BLUETOOTH CELL PHONE CANNOT BE PAIRED )Bluetooth phone HandsFreeLink control unit Audio-navigation unit Audio unit
The communication with cell phone is interrupted or changes (with navigation)HFL Symptom Troubleshooting (see THE COMMUNICATION WITH CELL PHONE IS INTERRUPTED OR CHANGES (WITH NAVIGATION) )Electric wave interference HandsFreeLink control unit Audio-navigation unit Bluetooth phone Harness/connector
The communication with cell phone is interrupted or changes (without navigation)HFL Symptom Troubleshooting (see THE COMMUNICATION WITH CELL PHONE IS INTERRUPTED OR CHANGES (WITHOUT NAVIGATION) )Electric wave interference HandsFreeLink control unit Audio unit Bluetooth phone Harness/connector
Pairing instructions are not displayed on the screenHFL Symptom Troubleshooting (see PAIRING INSTRUCTIONS ARE NOT DISPLAYED ON THE SCREEN )Navigation display unit Bluetooth phone HandsFreeLink control unit The Bluetooth phone may not be compatible (Some Bluetooth phones do not support a part of the guide.)
Bluetooth cell phone audio function SKIP and PAUSE/RESUME do not work (with navigation)HFL Symptom Troubleshooting (see BLUETOOTH CELL PHONE AUDIO FUNCTION SKIP AND PAUSE/RESUME DO NOT WORK (WITH NAVIGATION) )Bluetooth phone (Some Bluetooth phones do not support the function. For more information, please contact the cell phone carrier or the cell phone manufacturer.)
Bluetooth cell phone audio function SKIP and PAUSE/RESUME do not work (without navigation)HFL Symptom Troubleshooting (see BLUETOOTH CELL PHONE AUDIO FUNCTION SKIP AND PAUSE/RESUME DO NOT WORK (WITHOUT NAVIGATION) )Bluetooth phone (Some Bluetooth phones do not support the function. For more information, please contact the cell phone carrier or the cell phone manufacturer.)

SYMPTOM TROUBLESHOOTING CHART

Overview

The audio unit has a built in CD player. Audio units with navigation are referred to as audio-navigation unit. These units combine the audio system, the navigation system, and the CD/DVD player into one unit.

The audio unit acts as the processor for all audio functions. Select audio functions from the audio unit buttons or the audio remote switch (on the steering wheel). The center display provides the current audio status.

The audio unit has a built-in EEPROM (electrically erasable programmable read-only memory). This memory holds the audio presets (AM/FM radio frequency, sound settings, etc.) even when the battery is disconnected.

A security signal is daisy-chained between the audio and vehicle components for integration into the vehicle's security system.

There are two audio systems available for the Acura TSX

  1. With navigation, it includes ELS audio system for surround sound with 10 speakers.
  2. Without navigation, it includes premium audio system with 7 speakers.
Disc Playback TypesWith NavigationWithout Navigation
CD (CD-DA)OO
CD-R/RW (uncompressed)OO
CD-R/RW (MP3/WMA)OO
DVD-AudioOX
DVD-VideoXX
DVD-R/RW (uncompressed)OX
DTS CDOX
O: Available X: Not available

DISC PLAYBACK TYPES REFERENCE CHART

HDD Recording

The navigation system uses a HDD (hard disc drive) and can store music. To record music to the HDD, you must use an original CD or uncompressed CD-R files. The music must be loaded on a CD using the CD player. You cannot load music through the USB adapter or the auxiliary jack.

Song By Voice™ (with navigation)

You can use the voice control to operate the audio system, including the Song By Voice™ feature. See the Navigation Manual for more information.

Speed-Sensitive Volume Compensation (SVC)

All audio systems are equipped with speed-sensitive volume compensation (SVC). The audio-navigation unit or audio unit receives the vehicle speed pulse (VSP) from B-CAN. The system processes the speed input and increases the navigation or audio system volume level as the vehicle speed increases to compensate for the interior noise that occurs at higher speeds. When the vehicle slows down, the volume returns to its normal level. The SVC has four settings: SVC OFF, SVC LOW, SVC MID, and SVC HIGH that can be adjusted using the audio-navigation unit or audio unit. The factory default setting is SVC MID.

To change the audio unit SVC setting, press the MENU button to display the sound settings menu, then rotate the knob to adjust the SVC to the desired setting (SVC OFF, SVC LOW, SVC MID, or SVC HIGH).

To change the audio-navigation unit SVC setting, press the AUDIO button, and then select the Sound Setup from the AUDIO MENU on the navigation display. Rotate the interface dial to select the desired setting (SVC OFF, SVC LOW, SVC MID, SVC HIGH).

Telematics Muting Logic

The navigation system provides voice control for the audio, the XM, and the CD player. Voice control commands are communicated through the GA-Net (audio unit). When using the TALK/BACK buttons or route guidance (RG), the center speaker is muted and you hear the navigation instructions through the front speakers. When using the HFL/AcuraLink, the center speaker, the rear speakers, and the subwoofer are muted and the front speakers give the telephone sound. When using the HFL/AcuraLink and the RG (Route Guidance) or the TALK/BACK buttons, the rear speakers are muted and you hear the telephone sound and navigation instructions through the front speakers. Muting commands are passed on the GA-Net bus. For more information, see the navigation section. The outline of the audio interruption function is shown in the following table.

ContentsAudio Output
Center CHLeft Front CHRight Front CHRight Rear CHLeft Rear CH
Pressing TALK/BACK buttonsNavigation outputMUTEMUTEMUTEMUTE
Route guidance (RG)Navigation output and audioAudioAudioAudioAudio
HFL/AcuraLinkMUTETelephone soundTelephone soundMUTEMUTE
HFL/AcuraLink and route guidance or talk backNavigation outputHFL outputHFL outputMUTEMUTE

TELEMATICS MUTING LOGIC REFERENCE CHART

Bluetooth Audio

Bluetooth audio allows approved Bluetooth cell phones equipped with music function to play music via a car audio system using Bluetooth technology. You can control the phone's music player remotely using the wireless connection.

  1. You can play music stored in your cell phone using the wireless connection *1 .
  2. You can choose next song, previous song and resume/pause via wireless *2 .

*1: Call phone must support AVRCP 1.0 for Bluetooth technology, and also be on the Acura approved HFL list at www.acura.com/handsfreelink.

*2: Not all phones support the Bluetooth audio function.

Supported Devices

  1. Bluetooth music phones that support AVRCP 1.0.
  2. Bluetooth adapters for portable music devices including iPod are not supported. NOTE: Availability of the functions depends on the connected phone. The latest support information is updated through the website www.acura.com/handsfreelink.

Pairing a Cell Phone

To pair a cell phone, refer to pairing a cell phone in the HandsFreeLink system (see NAVIGATION THROUGH HFL MENUS ). Once a cell phone is paired, the process does not have to be repeated for the phone.

Scheme 642

Scheme 642: Procedure

Scheme 643

Scheme 643

Scheme 644

Scheme 644

Scheme 645

Scheme 645

Scheme 646

Scheme 646

Scheme 647

Scheme 647
  1. Push the AUX button (A) to select Bluetooth Audio source. NOTE: If you push the AUX button when no cell phone is connected, NO CONNECT is displayed. If you see NO CONNECT when you are using the cell phone music function, check that the device is properly paired. If it is paired, the cell phone may not be compatible. See www.acura.com/handsfreelink for more information. Music titles and artist names are not displayed.
  2. Start playing the music in the paired cell phone. NOTE: Depending on the cell phone, the music may start automatically, or the user may need to select headset as an audio output.
  3. A user can select the next song or the previous song using the SKIP button (A).
  4. With navigation, using the interface dial (A) to select [Sound Setup] or [RESUME/PAUSE]. Without navigation, using the SELECTOR knob (B) to select audio settings (RESUME/PAUSE and sound settings).
  5. To turn the Bluetooth Audio mode off, select another audio mode (AM/FM, XM, CD/DVD, or USB).

Disc Handing and Cleaning

To avoid damaging or leaving fingerprints on a disc (CD, DVD, DVD-A, etc.), always handle it by the edges and place it in a jewel case whenever it is outside the audio or the audio-navigation unit. Deep scratches or fingerprints on the back of the disc can cause loading problems, poor sound quality, skipping, or other errors.

Scheme 648

Scheme 648: Disc Handing and Cleaning

Smudges and fingerprints can be carefully removed using a mild cleaner and tissues designed to clean eyeglasses. To clean a disc, use a clean soft cloth. Very gently wipe across the disc from the center to the outside edge, never in a circular motion.

Scheme 649

Scheme 649

Do not place stabilizer rings or labels on the disc.

Scheme 650

Scheme 650: With ELS Audio

Scheme 651

Scheme 651: With Premium Audio

Audio Glossary

Note. All items may not apply to this vehicle. See the Owner's Manual for more information.

ItemDefinition
Active noise cancellationThe active noise cancellation system cancels some of the vehicle noise. This occurs in the 1, 500-2, 400 RPM range. Microphones detect the low frequency sound, and the system outputs a canceling sound from the audio speaker.
Active sound controlThe next generation of sound control that reduces unwanted sound in the passenger compartment.
AcuraLinkThis device receives information from the XM satellites and passes XM audio information to the audio unit. In addition, traffic and weather information is sent to the navigation unit.
AM (Amplitude Modulation)The type of transmission used in the standard radio broadcast band from 530 to 1, 710 kHz.
AmplifierA device that increases the level of a signal by increasing the current or voltage.
AntennaA device used to send or receive electromagnetic waves through the air.
ATA (PC Card)A type of card that has been tested for use in playing WMA and MP3 music files in the PC card slot. Sizes of up to 1 GB have been tested.
Audio remote switchThe switches on the steering wheel that control the audio system.
Auxiliary jackAllows the client to use a portable audio device to input audio recordings.
BalanceA control that changes the relative volume of the left and right channels.
BandA range of frequencies between two definite limits. Bands are assigned by the Federal Communications Commission for specific uses.
BassAn adjustment for the low frequency sounds of around 160 Hz and below.
Bluetooth AudioAllows the client to play audio recordings stored on their cell phone through the audio system.
ByteA unit of storage for computer files and memory. A CD holds approximately 700 million bytes.
CassetteAudio or video magnetic tape container having two reels. Customer can insert it for play back.
Compact flashA standard for small-size (3x4 cm), memory cards used in mobile computers, PDAs, and digital cameras. Compact flash memory cards are available in size of 32 MB up to 4 GB or more and can be played in the audio PC slot. Sizes above 1 GB have not been tested.
CD (Compact Disc)A 4.5-inch plastic disc containing digital audio recording that is played optically on a laser equipped player. Never use discs with a paper label. In a hot vehicle, labels can curl up and jam the unit.
CD (audio disc) changerCD player that can store and play more than one CD. Two types are available. Some units accept CDs fed into the changer one at a time, and others accept a magazine (with CDs stacked in a container).
CD playerA component designed to play compact disc recordings using a laser optical pickup. The signal from a CD player usually requires amplification.
CSF (Cold Start Fix) screensThese screens are displayed if the system requires a GPS initialization. The vehicle should be moved outside into an open area away from buildings/power lines.
DB (Decibels)A method of measuring sound or radio signal strength received by the audio unit antenna.
DistortionInexact reproduction of an audio signal caused by playing music at levels the audio system cannot handle, you will typically hear this as static, pops, or crackles.
Dolby (noise reduction)A processing system developed by Dolby Laboratories that reduces the background noise on recording media. The result is a cleaner playback from the audio system.
DUETA serial data communication line used for sub display.
DVD (Digital Versatile Disc)A 4.5-inch CD-like format used for storing movies with digital audio and video features. The DVD-A format is a DVD format designed for DVD audio systems. Some vehicles can play DVD and DVD-A formats.
EqualizerA device that changes the relative volume of individual frequency bands to suit personal tastes of the listener.
FaderThe control that adjusts the relative volume levels of front and rear speakers in a four-speaker system.
FormatTo prepare a PC card to receive files this function is done on a PC. Always choose either FAT or FAT32, as the NTFS format is not accepted by the system. Pick the default sectors for the format method selected.
FM (Frequency Modulation)The form of modulation used for radio and television sound transmission in most of the world. Less prone to interference than AM. The FM broadcast band in North America covers roughly 87.7 to 107.9 MHz.
GA-NetThe GA-Net allows the audio unit to communicate with all the audio and navigation components in a vehicle. If there is an open in the GA-Net or components, the entire audio and navigation system may appear inoperative.
GB (Gigabyte)A unit of memory or disc storage equal to one billion bytes (1, 000 million bytes).
HDDHard disc drive. The navigation does not use a DVD, but uses a hard drive to contain the navigation software. Can be updated with a CD or DVD that is inserted into the audio disc slot.
Hertz (Hz)The unit of frequency equal to one cycle per second (cps). One kilohertz (kHz) equals 1, 000 cps; one megahertz (MHz) equals 1 million cps.
Integrated amplifierA component that combines a pre amp and a power amp into a single unit. A receiver combines an integrated amp and a tuner into a single unit.
Jewel caseThe hard plastic case that contains a compact disc or DVD. Always use a jewel case to prevent scratches on the underside of a CD or DVD.
LCD (Liquid Crystal Display)A type of digital display that changes reflectance or transmittance when an electrical field is applied to it.
MemoryCircuitry or devices that hold information in electrical or magnetic form, such as the AM/FM radio presets.
MB (Megabyte)One million bytes. Written as 1 MB. Megabytes are used as a measure of digital storage space. For example, a CD can hold 650 MB.
MicAn abbreviation for microphone. For vehicles with navigation, the microphone accepts navigation voice commands to control audio and navigation functions.
MP3 music filesMP3 is an audio coding format. MP3 is a popular audio compression format on the Internet and computers. CDs and PC cards with these files can be played on some vehicle's audio system.
MuteWhen the navigation gives guidance, the front speakers are muted (no music). When you use the voice control system, all of the speakers are muted.
NoiseUnwanted random sounds like buzzing, hiss, pops, static, whine, etc.
PC cardThe slot used for playing MP3 and WMA music files. The PC card is usually a combination of a small flash card in a PCMCIA adaptor that slides into the slot. The ATA, SD, and compact flash types of cards have been tested up to 1 GB.
PCMCIAA computer standard for the slot that the PC card slides into. Another term for the PC card slot.
ProcessorThe part of an audio device that performs tasks/calculations. In the audio unit, the processor handles muting to allow the navigation system to speak its voice commands, and the decoding/playback of the sound files, etc.
RadioA head unit that combines a tuner, a preamplifier, and often a power-amplifier.
Route guidance (RG)Spoken voice used for turn-by-turn navigation from the audio speakers.
StereoA recording of at least two channels where you can hear sound or music from the left or right side.
SD (Secure Digital) cardThis compact type of memory card allows for fast data transfer and has built-in security functions. SD cards have a small write-protection switch on the side.
ShieldA metallic foil or braided wire layer surrounding conductors which are designed to prevent electrostatic or electromagnetic interference (noise) from external sources which you hear as buzzing or popping sounds which you hear on the speakers.
Speaker (Loudspeaker)A device that converts electrical energy into acoustical energy (sound).
Speed-sensitive volume compensation (SVC)The SVC increases the audio volume to compensate for increased interior noise when the vehicle is driven at freeway speeds.
SubwooferA loudspeaker made to reproduce the lowest audio frequencies, from about 25 Hz to 125 Hz.
TrackA sound recording on a CD, tape, or PC card.
TrebleAn adjustment to control the volume of the high frequency sounds.
TunerA component (or part of a component) that receives radio signals and selects one broadcast from many.
TweeterA speaker designed to reproduce the higher frequencies (treble) only.
USBUniversal serial bus. The USB is used for playing audio files (MP3, WMA, AAC, etc.) on the external device through the audio unit.
USB portAllows the clients to play data such as input audio recording from portable audio devices (such as iPod) or data from USB flash memory.
Voice coilA coil of wire wrapped around a tube and then attached to the speaker cone or diaphragm. When an audio signal is applied, the coil becomes an electromagnet and interacts with the permanent magnet causing the cone or diaphragm to vibrate. We interpret these vibrations as sound.
Volume controlAllows you to control the loudness of the music.
WMA music fileWindows Media Audio File. This is an accepted format for music files to be played on either a CD-R, a CD-RW, or a PC card.
WooferA speaker that is designed to reproduce low (bass) frequencies only.
XM radioSatellite based radio transmission, which also uses a ground based repeater network to ensure seamless reception. The channels originate from XM's broadcast center, in Washington DC, and uplink to two satellites. These satellites transmit the signal across the entire continental United States.
XM receiverThe external component that receives and processes the XM signals from the XM satellites, and terrestrial (land) stations. The audio unit communicates to the XM receiver over the GA-Net bus.

AUDIO GLOSSARY REFERENCE CHART

Audio Unit Connector for Inputs and Outputs (with ELS audio)

Note. Refer to the navigation system section for audio-navigation unit connector G, H, and J inputs and outputs (see NAVIGATION UNIT CONNECTOR FOR INPUTS AND OUTPUTS ).

Scheme 652

Scheme 652: Audio Unit Connector for Inputs and Outputs (with ELS audio)

AUDIO-NAVIGATION UNIT CONNECTOR A (24P)

Note. Refer to the navigation system section for the terminals inputs and outputs not shown (see NAVIGATION UNIT CONNECTOR FOR INPUTS AND OUTPUTS ).

Scheme 653

Scheme 653: AUDIO-NAVIGATION UNIT CONNECTOR A (24P)
CavityWire ColorTerminal NameConnects to
A3LT BLUK-LINEData link connector (DLC)
A4BRNSCTY2Navigation display unit
A5BRNREMOTE GNDAudio remote switch ground
A6ORNRR PREStereo amplifier
A7BLURR PRE +Stereo amplifier
A8GRY (1)SH RR-RL GNDShield for terminals No. 6, No. 7, No. 10, and No. 11
A10YELRL PREStereo amplifier
A11PURRL PRE +Stereo amplifier
A12BLKMAIN GNDBody ground to G651
A14PURACCNo. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box
A16PNKREMOTEAudio remote switch
A17WHTSWD +BStereo amplifier
A18GRNFR PREStereo amplifier
A19BLKFR PRE +Stereo amplifier
A20GRY (1)SH FR-FL GNDShield for terminals No. 18, No. 19, No. 22, and No. 23
A22WHTFL PREStereo amplifier
A23REDFL PRE +Stereo amplifier
A24WHT+ BNo. 15 (10 A) fuse in the under-hood fuse/relay box
(1) The shielded wires have a heat-shrink tube insulating the out side of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the out side of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

CONNECTOR TERMINAL REFERENCE CHART

AUDIO-NAVIGATION UNIT CONNECTOR B (24P)

Note. Refer to the navigation system section for the terminals inputs and outputs not shown (see NAVIGATION UNIT CONNECTOR FOR INPUTS AND OUTPUTS ).

Scheme 654

Scheme 654: AUDIO-NAVIGATION UNIT CONNECTOR B (24P)
CavityWire ColorTerminal NameConnects to
B1REDAUX LCHAuxiliary jack assembly
B2BLKAUX SIG GNDAuxiliary jack assembly
B3GRYAUX DETAuxiliary jack assembly
B5GRNTELM SIG +HandsFreeLink control unit
B9WHTCTR PREStereo amplifier
B10REDCTR PRE+Stereo amplifier
B11GRY (1)SH CTR-SUBW GNDShield for terminals No. 9, No. 10, No. 12, and No. 24
B12BLKSUBW PRE +Stereo amplifier
B13WHTAUX RCHAuxiliary jack assembly
B14YELAUX GNDAuxiliary jack assembly
B15GRY (1)AUX SH GNDShield for terminals No. 1, No. 2, and No. 13
B16REDTELM SIGHandsFreeLink control unit
B17GRY (1)TELM SIG SHShield for terminals No. 5 and No. 16
B24GRNSUBW PREStereo amplifier
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

CONNECTOR TERMINAL REFERENCE CHART

Scheme 655

Scheme 655: AUDIO-NAVIGATION UNIT CONNECTOR C (14P)

Audio-Navigation Unit Connector C (14P)

CavityWire ColorTerminal NameConnects to
C1 (2)WHT+ BXM receiver
C2 (2)LT BLUSYS ACCXM receiver
C3GRY (1)GA-NET BUS SHShield for terminals No. 9 and No. 10
C4GRY (1)AUDIO SHShield for terminals No. 5, No. 6, No. 13, and No. 14
C5GRNAUDIO R+AcuraLink control unit (XM receiver) (2) , XM receiver (3) , HandsFreeLink control unit
C6BLKAUDIO L+AcuraLink control unit (XM receiver) (2) , XM receiver (3) , HandsFreeLink control unit
C9REDGA-NET BUS +AcuraLink control unit (XM receiver) (2) , XM receiver (3) , HandsFreeLink control unit, navigation display unit
C10GRNGA-NET BUSAcuraLink control unit (XM receiver) (2) , XM receiver (3) , HandsFreeLink control unit, navigation display unit
C11 (2)BLKGNDXM receiver
C13WHTAUDIO RAcuraLink control unit (XM receiver) (2) , XM receiver (3) , HandsFreeLink control unit
C14REDAUDIO LAcuraLink control unit (XM receiver) (2) , XM receiver (3) , HandsFreeLink control unit
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram. (2) With AcuraLink (3) Without AcuraLink
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(2)With AcuraLink
(3)Without AcuraLink

CONNECTOR TERMINAL REFERENCE CHART

AUDIO-NAVIGATION UNIT CONNECTOR D (20P)

Note. Refer to the navigation system section for the terminals inputs and outputs not shown (see NAVIGATION UNIT CONNECTOR FOR INPUTS AND OUTPUTS ).

Scheme 656

Scheme 656: AUDIO-NAVIGATION UNIT CONNECTOR D (20P)
CavityWire ColorTerminal NameConnects to
D1REDRS 485Stereo amplifier
D2GRNRS 485+Stereo amplifier
D6PNKB-CAN HB-CAN bus line
D11GRY (1)RS 485 SHShield for terminals No. 1 and No. 2
D15BLUB-CAN LB-CAN bus line
D17GRNRG L GNDStereo amplifier
D19REDRG L+Stereo amplifier
D20BLK (1)RG L SHShield for terminals No. 17 and No. 19
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

CONNECTOR TERMINAL REFERENCE CHART

Scheme 657

Scheme 657: AUDIO-NAVIGATION UNIT CONNECTOR E (5P)

Audio-Navigation Unit Connector E (5P)

CavityWire ColorTerminal NameConnects to
E3ANT +BAM/FM antenna amplifier (1) , AM/FM/XM antenna (2)
E4RF INAM/FM antenna amplifier (1) , AM/FM/XM antenna (2)
E5RF SHShield for terminal No. 4
(1) Sedan (2) Sport Wagon
(1)Sedan
(2)Sport Wagon

CONNECTOR TERMINAL REFERENCE CHART

Scheme 658

Scheme 658: AUDIO-NAVIGATION UNIT CONNECTOR F (12P)

Audio-Navigation Unit Connector F (12P)

CavityWire ColorTerminal NameConnects to
F1GRNDUET RX (UART)Audio-navigation switch panel
F2GRY (1)DUET SHShield for terminals No. 1 and No. 7
F3REDOPERA RXAudio-navigation switch panel
F4GRY (1)OPERA SHShield for terminals No. 3, No. 5, No. 9, and No. 11
F5GRNENCAudio-navigation switch panel
F7REDDUET TX (UART)Audio-navigation switch panel
F8BLUDUET CONTAudio-navigation switch panel
F9WHTOPERA TXAudio-navigation switch panel
F10PNKOPERA CONTAudio-navigation switch panel
F11BLKENC+Audio-navigation switch panel
F12BLUPWR SWAudio-navigation switch panel
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

CONNECTOR TERMINAL REFERENCE CHART

Scheme 659

Scheme 659: AUDIO-NAVIGATION UNIT CONNECTOR K (7P)

Audio-Navigation Unit Connector K (7P)

CavityWire ColorTerminal NameConnects to
K1USB VBUSUSB adapter
K2USB DATAUSB adapter
K3USB DATA+USB adapter
K4USB GNDUSB adapter
K5USB SHShield for terminals No. 1, No. 2, No. 3, and No. 4
K6USB DETConnect to terminal No. 7
K7USB DET GNDConnect to terminal No. 6

CONNECTOR TERMINAL REFERENCE CHART

Scheme 660

Scheme 660: Audio Unit Connector for Inputs and Outputs (with premium audio)

Scheme 661

Scheme 661: AUDIO UNIT CONNECTOR A (24P)

Audio Unit Connector A (24P)

CavityWire ColorTerminal NameConnects to
A1REDILL-BULBDashlights brightness controller
A3LT BLUK-LINEData link connector (DLC)
A4GRNSCTYPassenger's MICU
A5BRNREMOTE GNDAudio remote switch ground
A6BLURR PREStereo amplifier
A7PNKRR PRE +Stereo amplifier
A8GRY (1)SH RR GNDShield for terminals No. 6 and No. 7
A9GRY (1)SH RL GNDShield for terminals No. 10 and No. 11
A10YELRL PREStereo amplifier
A11BRNRL PRE +Stereo amplifier
A12BLKMAIN GNDBody ground to G401
A13GRYILL+No. 6 (7.5 A) fuse in the passenger's under-dash fuse/relay box
A14PURACCNo. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box
A16PNKREMOTEAudio remote switch
A17WHTSWD +BStereo amplifier
A18REDFR PREStereo amplifier
A19GRNFR PRE +Stereo amplifier
A20GRY (1)SH FR GNDShield for terminals No. 18 and No. 19
A21GRY (1)SH FL GNDShield for terminals No. 22 and No. 23
A22REDFL PREStereo amplifier
A23GRNFL PRE +Stereo amplifier
A24WHT+ BNo. 15 (10 A) fuse in the under-hood fuse/relay box
(1) The shielded wires have a heat-shrink tube insulating the out side of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the out side of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

CONNECTOR TERMINAL REFERENCE CHART

Scheme 662

Scheme 662: AUDIO UNIT CONNECTOR B (20P)

Audio Unit Connector B (20P)

CavityWire ColorTerminal NameConnects to
B1REDCOMPASS TXElectrical compass unit
B2ORNCOMPASS TX+Electrical compass unit
B3BLKAUX SIG GNDAuxiliary jack assembly
B4GRY (1)AUX SH GNDShield for terminals No. 3, No. 13, and No. 14
B5YELAUX GNDAuxiliary jack assembly
B6REDDUET TX (UART)Audio-HVAC display unit
B7GRNDUET RX (UART)Audio-HVAC display unit
B8BLUB-CAN LB-CAN bus line
B9REDTELM SIGHandsFreeLink control unit
B10GRY (1)TELM SIG SHShield for terminals No. 9 and No. 19
B11PNKCOMPASS RXElectrical compass unit
B12LT BLUCOMPASS RX +Electrical compass unit
B13REDAUX LCHAuxiliary jack assembly
B14WHTAUX RCHAuxiliary jack assembly
B15GRYAUX DETAuxiliary jack assembly
B16GRY (1)SH DUET GNDShield for terminals No. 6 and No. 7
B17BLUDUET CONTAudio-HVAC display unit
B18PNKB-CAN HB-CAN bus line
B19GRNTELM SIG +HandsFreeLink control unit
B20PURHFL MUTEHandsFreeLink control unit
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

CONNECTOR TERMINAL REFERENCE CHART

Scheme 663

Scheme 663: AUDIO UNIT CONNECTOR D (8P)

Audio Unit Connector D (8P)

CavityWire ColorTerminal NameConnects to
D5LT GRNAMP MUTEStereo amplifier
D6REDSUBW PREStereo amplifier
D7GRY (1)SH SUBW GNDShield for terminals No. 6 and No. 8
D8GRNSUBW PRE +Stereo amplifier
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

CONNECTOR TERMINAL REFERENCE CHART

Scheme 664

Scheme 664: AUDIO UNIT CONNECTOR E (14P)

Audio Unit Connector E (14P)

CavityWire ColorTerminal NameConnects to
E1WHT+ BUSB adapter control unit, XM receiver
E2LT BLUSYS ACCUSB adapter control unit, XM receiver
E3GRY (1)GA-NET BUS SHShield for terminals No. 9 and No. 10
E4GRY (1)AUDIO SHShield for terminals No. 5, No. 6, No. 13, and No. 14
E5GRNAUDIO R+USB adapter control unit, HandsFreeLink control unit, XM receiver
E6BLKAUDIO L+USB adapter control unit, HandsFreeLink control unit, XM receiver
E9REDGA-NET BUS +USB adapter control unit, HandsFreeLink control unit, XM receiver
E10GRNGA-NET BUSUSB adapter control unit, HandsFreeLink control unit, XM receiver
E11BLKGNDUSB adapter control unit, XM receiver
E13WHTAUDIO RUSB adapter control unit, HandsFreeLink control unit, XM receiver
E14REDAUDIO LUSB adapter control unit, HandsFreeLink control unit, XM receiver
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

CONNECTOR TERMINAL REFERENCE CHART

Scheme 665

Scheme 665: AUDIO UNIT CONNECTOR F (3P)

Audio Unit Connector F (3P)

CavityWire ColorTerminal NameConnects to
F1RF INAM/FM antenna amplifier (1) , AM/FM/XM antenna (2)
F2RF SHShield for terminal No. 1
F3ANT +BAM/FM antenna amplifier (1) , AM/FM/XM antenna (2)
(1) Sedan (2) Sport Wagon
(1)Sedan
(2)Sport Wagon

CONNECTOR TERMINAL REFERENCE CHART

Scheme 666

Scheme 666: Audio-Navigation Switch Panel for Inputs and Outputs (with ELS audio)

Scheme 667

Scheme 667: AUDIO-NAVIGATION SWITCH PANEL 24P CONNECTOR

Audio-Navigation Switch Panel 24P Connector

CavityWire ColorTerminal NameConnects to
1GRNENCAudio-navigation unit
3BLUDUET CONTAudio-navigation unit
6WHTOPERA TXAudio-navigation unit
7REDDISP-CLKClimate control unit
10BLKGNDBody ground to G401
11REDILL-LEDDashlights brightness controller
12REDILL-BULBDashlights brightness controller
13BLKENC+Audio-navigation unit
14BLUPWR SWAudio-navigation unit
15GRNDUET RX (UART)Audio-navigation unit
16REDDUET TX (UART)Audio-navigation unit
17PNKOPERA CONTAudio-navigation unit
18REDOPERA RXAudio-navigation unit
19PURDISP-SIClimate control unit
21LT GRNIG2No. 16 (7.5 A) fuse in the driver's under-dash fuse/relay box
22WHT+ BNo. 15 (10 A) fuse in the under-hood fuse/relay box
23GRYILL+No. 6 (7.5 A) fuse in the passenger's under-dash fuse/relay box

CONNECTOR TERMINAL REFERENCE CHART

Scheme 668

Scheme 668: Stereo Amplifier Connector for Inputs and Outputs (with ELS audio)

Scheme 669

Scheme 669: STEREO AMPLIFIER CONNECTOR A (18P)

Stereo Amplifier Connector A (18P)

CavityWire ColorTerminal NameConnects to
A1LT BLU (1) WHT (2)SUBWSubwoofer
A2BLUCTR SPFront center speaker
A3BLURR SPRight rear door speaker
A4GRNRL SPLeft rear door speaker
A5ORNSAT R SPRight rear speaker (1) , Right satellite speaker (2)
A6GRNFR SPFront passenger's door speaker. Front passenger's door tweeter
A7BLUFL SPDriver's door speaker. Driver's door tweeter
A8BRNSAT L SPLeft rear speaker (1) , Left satellite speaker (2)
A9BLKGNDBody ground to G651
A10GRY (1) RED (2)SUBW+Subwoofer
A11YELCTR SP+Front center speaker
A12REDRR SP+Right rear door speaker
A13WHTRL SP+Left rear door speaker
A14BLUSAT R SP+Right rear speaker (1) , Right satellite speaker (2)
A15REDFR SP+Front passenger's door speaker. Front passenger's door tweeter
A16BLKFL SP+Driver's door speaker. Driver's door tweeter
A17YELSAT L SP+Left rear speaker (1) , Left satellite speaker (2)
A18WHT (1) LT BLU (2)+ BNo. 15 (20 A) fuse in the passenger's under-dash fuse/relay box
(1) Sedan (2) Sport Wagon
(1)Sedan
(2)Sport Wagon

CONNECTOR TERMINAL REFERENCE CHART

Scheme 670

Scheme 670: STEREO AMPLIFIER CONNECTOR B (28P)

Stereo Amplifier Connector B (28P)

CavityWire ColorTerminal NameConnects to
B1REDRS 485Audio-navigation unit
B3WHTSWD +BAudio-navigation unit
B4BLKCTR PRE +Audio-navigation unit
B5GRY (1)SH CTR-SUBW GNDShield for terminals No. 4, No. 6, No. 18, and No. 19
B6REDSUBW PRE+Audio-navigation unit
B8GRY (1)RG L SHShield for terminals No. 9 and No. 21
B9WHTRG L GNDAudio-navigation unit
B10BLKFL PRE +Audio-navigation unit
B11GRNFR PRE +Audio-navigation unit
B12GRY (1)SH FR-FL GNDShield for terminals No. 10, No. 11, No. 24, and No. 25
B13REDRL PRE +Audio-navigation unit
B14WHTRR PRE +Audio-navigation unit
B15GRNRS 485+Audio-navigation unit
B16GRY (1)RS 485 SHShield for terminals No. 1 and No. 15
B18WHTCTR PREAudio-navigation unit
B19GRNSUBW PREAudio-navigation unit
B21BLKRG L +Audio-navigation unit
B24WHTFL PREAudio-navigation unit
B25REDFR PREAudio-navigation unit
B26GRY (1)SH RR-RL GNDShield for terminals No. 13, No. 14, No. 27, and No. 28
B27GRNRL PREAudio-navigation unit
B28BLKRR PREAudio-navigation unit
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

CONNECTOR TERMINAL REFERENCE CHART

Scheme 671

Scheme 671: Stereo Amplifier Connector for Inputs and Outputs (with premium audio)

Scheme 672

Scheme 672: STEREO AMPLIFIER CONNECTOR A (18P)
CavityWire ColorTerminal NameConnects to
A1LT BLUSUBW SPSubwoofer
A3ORNRR SPRight rear speaker (1) , Right rear door speaker (2)
A4BRNRL SPLeft rear speaker (1) , Left rear door speaker (2)
A5YELFR TW SPFront passenger's door tweeter
A6GRNFR SPFront passenger's door speaker
A7BLUFL SPDriver's door speaker
A8PURFL TW SPDriver's door tweeter
A9BLKGNDBody ground to G651
A10GRYSUBW SP+Subwoofer
A12BLURR SP+Right rear speaker (1) , Right rear door speaker (2)
A13YELRL SP+Left rear speaker (1) , Left rear door speaker (2)
A14WHTFR TW SP+Front passenger's door tweeter
A15REDFR SP+Front passenger's door speaker
A16BLKFL SP+Driver's door speaker
A17PNKFL TW SP+Driver's door tweeter
A18WHT (1) LT BLU (2)+ BNo. 15 (20 A) fuse in the passenger's under-dash fuse/relay box
(1) Sedan (2) Sport Wagon
(1)Sedan
(2)Sport Wagon

CONNECTOR TERMINAL REFERENCE CHART

Scheme 673

Scheme 673: STEREO AMPLIFIER CONNECTOR B (24P)

Stereo Amplifier Connector B (24P)

CavityWire ColorTerminal NameConnects to
B2WHTFL PREAudio unit
B3GRY (1)SH FL GNDShield for terminals No. 2 and No. 14
B4GRNRL PREAudio unit
B5REDFR PREAudio unit
B6GRY (1)SH FR GNDShield for terminals No. 5 and No. 17
B7BLKRR PREAudio unit
B8REDSUBW PREAudio unit
B9GRY (1)SH SUBW GNDShield for terminals No. 8 and No. 20
B13PURAMP MUTEAudio unit
B14BLKFL PRE +Audio unit
B15GRY (1)SH RL GNDShield for terminals No. 4 and No. 16
B16REDRL PRE +Audio unit
B17GRNFR PRE+Audio unit
B18GRY (1)SH RR GNDShield for terminals No. 7 and No. 19
B19WHTRR PRE +Audio unit
B20GRNSUBW PRE +Audio unit
B24WHTSWD +BAudio unit
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

CONNECTOR TERMINAL REFERENCE CHART

Scheme 674

Scheme 674: XM Receiver Connector for Inputs and Outputs (without AcuraLink)

Scheme 675

Scheme 675: XM RECEIVER CONNECTOR A (14P)

XM Receiver Connector A (14P)

CavityWire ColorTerminal NameConnects to
A1WHT+ BAudio-navigation unit (2) , Audio unit (3) , USB adapter control unit (3)
A2LT BLUSYS ACCAudio-navigation unit (2) , Audio unit (3) , USB adapter control unit (3)
A3GRY (1)GA-NET BUS SHShield for terminals No. 9 and No. 10
A4GRY (1)AUDIO SHShield for terminals No. 5, No. 6, No. 13, and No. 14
A5GRNAUDIO R+Audio-navigation unit (2) , Audio unit (3) , HandsFreeLink control unit, USB adapter control unit (3)
A6BLKAUDIO L+Audio-navigation unit (2) , Audio unit (3) , HandsFreeLink control unit, USB adapter control unit (3)
A9REDGA-NET BUS +Audio-navigation unit (2) , Audio unit (3) , HandsFreeLink control unit, USB adapter control unit (3) , Navigation display unit (1)
A10GRNGA-NET BUSAudio-navigation unit (2) , Audio unit (3) , HandsFreeLink control unit, USB adapter control unit (3) , Navigation display unit (1)
A11BLKGNDAudio-navigation unit (2) , Audio unit (3) , USB adapter control unit (3)
A13WHTAUDIO RAudio-navigation unit (2) , Audio unit (3) , HandsFreeLink control unit, USB adapter control unit
A14REDAUDIO LAudio-navigation unit (2) , Audio unit (3) , HandsFreeLink control unit, USB adapter control unit (3)
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram. (2) With ELS audio (3) With premium audio
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(2)With ELS audio
(3)With premium audio

CONNECTOR TERMINAL REFERENCE CHART

Scheme 676

Scheme 676: XM RECEIVER CONNECTOR B (2P)

XM Receiver Connector B (2P)

CavityWire ColorTerminal NameConnects to
B1SAT/TERXM antenna (1) , AM/FM/XM antenna (2)
B2SAT/TER SH GNDShield for terminal No. 1
(1) Sedan (2) Sport Wagon
(1)Sedan
(2)Sport Wagon

CONNECTOR TERMINAL REFERENCE CHART

Scheme 677

Scheme 677: USB Adapter Control Unit Connector for Inputs and Outputs (with premium audio)

Scheme 678

Scheme 678: USB ADAPTER CONTROL UNIT CONNECTOR A (14P)

USB Adapter Control Unit Connector A (14P)

CavityWire ColorTerminal NameConnects to
A1WHT+ BAudio unit, XM receiver
A2LT BLUSYS ACCAudio unit, XM receiver
A3GRY (1)GA-NET BUS SHShield for terminals No. 9 and No. 10
A4GRY (1)AUDIO SHShield for terminals No. 5, No. 6, No. 13, and No. 14
A5GRNAUDIO R+Audio unit, XM receiver, HandsFreeLink control unit
A6BLKAUDIO L+Audio unit, XM receiver, HandsFreeLink control unit
A9REDGA-NET BUS+Audio unit, XM receiver, HandsFreeLink control unit
A10GRNGA-NET BUSAudio unit, XM receiver, HandsFreeLink control unit
A11BLKGNDAudio unit, XM receiver
A13WHTAUDIO RAudio unit, XM receiver, HandsFreeLink control unit
A14REDAUDIO LAudio unit, XM receiver, HandsFreeLink control unit
(1) The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.
(1)The shielded wires have a heat-shrink tube insulating the outside of the wire. The color of the insulating tube, typically black or dark gray, may not match the color of the wire listed on the circuit diagram.

CONNECTOR TERMINAL REFERENCE CHART

Scheme 679

Scheme 679: USB ADAPTER CONTROL UNIT CONNECTOR B (5P)

USB Adapter Control Unit Connector B (5P)

CavityWire ColorTerminal NameConnects to
B1USB VBUSUSB adapter
B2USB DATAUSB adapter
B3USB DATA+USB adapter
B4USB GNDUSB adapter
B5USB SHShield for terminals No. 1, No. 2, No. 3, and No. 4

CONNECTOR TERMINAL REFERENCE CHART

Scheme 680

Scheme 680: Audio-HVAC Display Unit Connector for Inputs and Outputs (with premium audio)

Scheme 681

Scheme 681: AUDIO-HVAC DISPLAY UNIT 12P CONNECTOR

Audio-HVAC Display Unit 12P Connector

CavityWire ColorTerminal NameConnects to
1GRNDUET RX (UART)Audio unit
2REDDUET TX (UART)Audio unit
4BLUDUET CONTAudio unit
5LT GRNIG2No. 16 (7.5 A) fuse in the driver's under-dash fuse/relay box
6WHT+ BNo. 15 (10 A) fuse in the under-hood fuse/relay box
7REDDISP-CLKClimate control unit
8PURDISP-SIClimate control unit
9BLKGNDBody ground to G401
10REDILL-BULBDashlights brightness controller
12GRYILL+No. 6 (7.5 A) fuse in the passenger's under-dash fuse/relay box

CONNECTOR TERMINAL REFERENCE CHART

Scheme 682

Scheme 682: Auxiliary Jack Assembly Connector for Inputs and Outputs

Scheme 683

Scheme 683: AUXILIARY JACK ASSEMBLY 5P CONNECTOR

Auxiliary Jack Assembly 5P Connector

CavityWire ColorTerminal NameConnects to
1GRYAUX DETAudio-navigation unit (1) , Audio unit (2)
2YELAUX GNDAudio-navigation unit (1) , Audio unit (2)
3BLKAUX SIG GNDAudio-navigation unit (1) , Audio unit (2)
4REDAUX LCHAudio-navigation unit (1) , Audio unit (2)
5WHTAUX RCHAudio-navigation unit (1) , Audio unit (2)
(1) With ELS audio (2) With premium audio
(1)With ELS audio
(2)With premium audio

CONNECTOR TERMINAL REFERENCE CHART

Scheme 684

Scheme 684: With ELS Audio

Scheme 685

Scheme 685

Scheme 686

Scheme 686: With ELS Audio

Scheme 687

Scheme 687

Scheme 688

Scheme 688: With ELS Audio

Scheme 689

Scheme 689

Scheme 690

Scheme 690: With Premium Audio

Scheme 691

Scheme 691

Scheme 692

Scheme 692: With Premium Audio

Scheme 693

Scheme 693

Scheme 694

Scheme 694: With Premium Audio

Self-Diagnostic Function

The audio system has a self-diagnostic function.

Note. Not all self-diagnostic functions appear on all models. There may be other self-diagnostic functions that are for factory use only.

How to Obtain the Audio Unit Serial Number

Note. This procedure can only be done after the power has been disconnected and reconnected to the audio unit, and the audio unit displays CODE when the audio unit is turned on.

Scheme 695

Scheme 695: How to Obtain the Audio Unit Serial Number

Scheme 696

Scheme 696

Scheme 697

Scheme 697

Scheme 698

Scheme 698
  1. Turn the ignition switch to ON (II). Make sure the audio system is turned off.
  2. Push and hold the preset No. 1 and No. 6 buttons.
  3. While holding the buttons, push the VOLUME/POWER knob to on.
  4. Release the buttons, and the self-diagnosis begins. With ELS audio With premium audio
  5. The display shows an 8 digit serial number. With ELS audio With premium audio
  6. Use all 8 numbers as the serial number when using the Interactive Network (iN) to retrieve the 5 digit anti-theft code.
  7. To end the self-diagnostic function, turn the audio system off, or turn the ignition switch to LOCK (0).

Scheme 699

Scheme 699: How to Use the Audio System Self-Diagnostic Function

Scheme 700

Scheme 700
  1. Turn the ignition switch to ON (II).
  2. Make sure the audio system is turned off.
  3. Push and hold the preset No. 1 and No. 6 buttons.
  4. While holding the buttons, push the VOLUME/POWER knob to on.
  5. Release the buttons, and the self-diagnosis begins. With ELS audio With premium audio
  6. When you are in the self-diagnostic mode, pressing a preset button starts the diagnostic mode that is assigned to that preset button. NOTE: Any other diagnostic screens shown are for factory use only. No. 2 button Audio button, knob, and audio remote switch detection: Allows individual manual selection of all audio panel knobs, buttons, and remote switches to verify if they are functional. When properly detected, the selected knob, button, or audio remote switch name and/or value is displayed. To exit this mode, go to step 7 . Once you exit this test, you must start again at step 1 . No. 3 button Entire LCD lighting/light-out mode: Turns on/off the entire LCD to show the presence (LCD stuck on) or absence (LCD dead) of an LCD segment. No. 4 button Duty indication mode (for the Illumination dim): Indicates the duty for the Illumination dim when the dash lights are on. No. 5 button Vehicle speed pulse (VSP) indication mode: Indicates the vehicle speed pulse. FM/AM or FM button (Push and hold 5 sec) Reception level indication mode: Indicates the reception level (dB). When entering the reception level check mode, the A.SEL button turn the AM/FM antenna amplifier on and off.
  7. The self-diagnostic function ends when you turn the audio unit off, or turn the ignition switch to LOCK (0).

Entire LCD lighting/lights-outs mode (press No. 3 button)

This diagnostic screen checks for segments that may be dead (off) or stuck on.

All the display segments should be on. If any segments are dead (off), replace the audio-navigation switch panel (see AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION ) or audio-HVAC display unit (see AUDIO-HVAC DISPLAY UNIT REMOVAL/INSTALLATION ). With all the segments on, press the No. 3 button a second time. The entire display must turn black. If any segments are stuck on, replace the audio-navigation switch panel (see AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION ) or audio-HVAC display unit (see AUDIO-HVAC DISPLAY UNIT REMOVAL/INSTALLATION ).

Entire LCD lighting mode

With ELS audio

Scheme 701

Scheme 701: Entire LCD lighting mode

With premium audio

Scheme 702

Scheme 702

Entire LCD lights-outs mode

With ELS audio

Scheme 703

Scheme 703: Entire LCD lights-outs mode

With premium audio

Scheme 704

Scheme 704

Reception level indication (Push and hold 5 sec FM/AM or FM button)

This diagnostic screen checks the radio reception level. This level then can used in the diagnosis of radio reception quality. The reception level is displayed in decibels (dB).

Preparation

  1. Park the vehicle outdoors in a location with good radio reception.
  2. Tune to a powerful local FM radio station, then write down the radio station number.
  3. Tune to a powerful local AM radio station, then write down the radio station number.

Scheme 705

Scheme 705

Scheme 706

Scheme 706
  1. Enter the reception level indication mode in the self-diagnostic function. The AM/FM antenna amplifier is on and the character (A) is not displayed in the audio display. With ELS audio With premium audio
  2. Tune to the FM radio station you wrote down in preparation using the TUNE button (with ELS audio) or selector knob (with premium audio), and note the decibel level (B) of that station.
  3. Press and release the A.SEL button to turn the AM/FM antenna amplifier off (A is now displayed in the audio display).
  4. Note the decibel level of that station.
  5. Press and release the A.SEL button to turn the AM/FM antenna amplifier back on (A is not displayed in the audio display).
  6. Press and hold the FM/AM button (with ELS audio) or AM button (with premium audio) for more than 5 seconds to enter the AM reception mode.
  7. Tune to the AM radio station you wrote down in preparation using the TUNE button (with ELS audio) or selector knob (with premium audio), and note the decibel level of that station.
  8. Press and release the A.SEL button to turn the antenna amplifier off.
  9. Note the decibel level of that station.
  10. Press and release the A.SEL button to turn the AM/FM antenna amplifier back on.
  11. Turn the ignition switch to LOCK (0), or audio system off to exit the test mode.
  12. Compare your results to a known-good vehicle, (make sure it is the same year and trim level) in the same location and direction, and under the same environmental conditions.

Speaker Check Mode

Note. Not all self-diagnostic functions appear on all models. There may be other self-diagnostic functions that are for factory use only. In some cases, you may not be able to enter a mode even if the designated button is pressed. In that case, try again.

Scheme 707

Scheme 707: Speaker Check Mode

Scheme 708

Scheme 708
  1. Turn the ignition switch to ON (II).
  2. Make sure the audio system is turned off.
  3. Push and hold the preset No. 1 and No. 3 buttons.
  4. While holding the buttons, push the VOLUME/POWER knob to on.
  5. Release the buttons and the speaker check mode begins, the FM default frequency should sound from one speaker.
  6. Each time you press the SKIP button, the test moves to the next speaker in the order listed in the table. NOTE: Adjust the volume level to a comfortable level. With ELS audio With premium audio Display Specifications (with ELS audio) The speakers are checked in this order when you press the SKIP ( ) button: (1)-->(2)-->(3)-->(4)-->(5)-->(6)-->(7)-->(8)-->(9) The speakers are checked in this order when you press the SKIP ( ) button: (1)-->(9)-->(8)-->(7)-->(6)-->(5)-->(4)-->(3)-->(2) DISPLAY SPECIFICATION CHART Speaker Displayed Segments Remarks (1) Driver's door speaker and driver's door tweeter SPK FR-L You should hear the received audio of the FM default frequency (2) Front center speaker SPK CNTR You should hear the received audio of the FM default frequency (3) Front passenger's door speaker and front passenger's door tweeter SPK FR-R You should hear the received audio of the FM default frequency (4) Right rear door speaker SPK RR-R You should hear the received audio of the FM default frequency (5) Right rear speaker (1) , Right satellite speaker (2) SPK ST-R You should hear the received audio of the FM default frequency (6) Subwoofer SPK SUBW You should hear the received audio of the FM default frequency (7) Left rear speaker (1) , Left satellite speaker (2) SPK ST-L You should hear the received audio of the FM default frequency (8) Left rear door speaker SPK RR-L You should hear the received audio of the FM default frequency (9) ALL speakers SPK ALL You should hear the received audio of the FM default frequency The subwoofer does not sound a tone (1) Sedan (2) Sport Wagon Display Specifications (with premium audio) The speakers are checked in this order when you press the SKIP ( ) button: (1)-->(2)-->(3)-->(4)-->(5)-->(6) The speakers are checked in this order when you press the SKIP ( ) button: (1)-->(6)-->(5)-->(4)-->(3)-->(2) DISPLAY SPECIFICATION CHART Speaker Displayed Segments Remarks (1) Driver's door speaker and driver's door tweeter SPK FR-L You should hear the received audio of the FM default frequency (2) Front passenger's door speaker and front passenger's door tweeter SPK FR-R You should hear the received audio of the FM default frequency (3) Right rear speaker (1) , Right rear door speaker (2) SPK RR-R You should hear the received audio of the FM default frequency (4) Subwoofer SPK SUBW You should hear the received audio of the FM default frequency (5) Left rear speaker (1) , Left rear door speaker (2) SPK RR-L You should hear the received audio of the FM default frequency (6) All speakers SPK ALL You should hear the received audio of the FM default frequency The subwoofer does not sound a tone (1) Sedan (2) Sport Wagon NOTE: Any other diagnostic screens are shown for factory use only.
  7. The speaker check mode ends when you turn the audio unit off, or turn the ignition switch to LOCK (0).

XM Self-Diagnosis

Note. This diagnostic screen checks the audio unit's XM radio reception level. To check the XM reception, do the following

Scheme 709

Scheme 709: XM Self-Diagnosis

Scheme 710

Scheme 710
  1. Turn the ignition switch to ON (II).
  2. Select XM1 mode.
  3. Turn off the audio system.
  4. Push and hold the preset No. 3 and No. 6 buttons.
  5. While holding the buttons, push the VOLUME/POWER knob to on.
  6. Continue holding the buttons for about 5 seconds, then release the buttons.
  7. Press and release preset No. 1 button to read the error code. With ELS audio With premium audio DISPLAY SPECIFICATION CHART Error Code No. Displayed Error Code Title Displayed Solution ERROR 00 NO ERROR System is normal. ERROR 04 NO SIGNAL Move the vehicle to an open area, and recheck. ERROR 05 NO XM ACTIVATION The subscription may have expired. Contact XM Radio at 800-852-9696. ERROR 06 NO XM AUTHORIZATION Contact XM Radio at 800-852-9696. ERROR 14 ANTENNA NOT CONNECTED / NO SIGNAL Refer to Error code: XM ANTENNA or XM LOADING is displayed; With AcuraLink (see «ERROR CODE: XM ANTENNA OR XM LOADING IS DISPLAYED (WITH ACURALINK)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__error-code-xm-antenna-or-xm) ) Without AcuraLink (see «ERROR CODE: XM ANTENNA OR XM LOADING IS DISPLAYED (WITHOUT ACURALINK)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__error-code-xm-antenna-or-xm) ) ERROR 24 ANTENNA SHORTED / NO SIGNAL Refer to Error code: XM ANTENNA or XM LOADING is displayed; With AcuraLink (see «ERROR CODE: XM ANTENNA OR XM LOADING IS DISPLAYED (WITH ACURALINK)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__error-code-xm-antenna-or-xm) ) Without AcuraLink (see «ERROR CODE: XM ANTENNA OR XM LOADING IS DISPLAYED (WITHOUT ACURALINK)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__error-code-xm-antenna-or-xm) ) ERROR 55 HARDWARE FAILURE (CONDITIONAL ACCESS FAILURE) There is an internal failure. Replace the AcuraLink control unit (XM receiver); Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ) or the XM receiver; Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). ERROR 65 HARDWARE FAILURE (CONDITIONAL ACCESS FAILURE) There is an internal failure. Replace the AcuraLink control unit (XM receiver); Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ) or the XM receiver; Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  8. To end the XM self-diagnosis, turn the ignition switch to LOCK (0).

XM Signal Reception Level Indication Mode

Note. When you receive any XM complaint, do the XM self-diagnosis to check for any XM error codes first. If there are no XM codes, check the XM signal reception level. To check the XM signal reception, do the following

  1. Turn the ignition switch to ON (II).
  2. Select XM2 mode.
  3. Turn off the audio system.
  4. Push and hold the preset No. 3 and No. 6 buttons.
  5. While holding the buttons, push the VOLUME/POWER knob to on.
  6. Continue holding the buttons for about 5 seconds, then release the buttons.
  7. Press and release preset No. 1 button to read the XM signal reception. XM SIGNAL RECEPTION REFERENCE CHART XM Signal Reception Solution SG NOSIG Move the vehicle to an open area, and recheck. If the signal does not improve, substitute a known-good XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ) or AM/FM/XM antenna (see «AM/FM/XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. SG GOOD The XM signal is OK. SG MARG The XM signal is OK. SG WEAK Move the vehicle to an open area, and recheck. If the signal does not improve, substitute a known-good XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ) or AM/FM/XM antenna (see «AM/FM/XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. SG VWEAK Move the vehicle to an open area, and recheck. If the signal does not improve, substitute a known-good XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ) or AM/FM/XM antenna (see «AM/FM/XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck.
  8. To end the XM self-diagnosis, turn the ignition switch to LOCK (0).

Error Codes

The audio system can display a few error codes when some problems are detected with the audio disc player, the audio disc, the XM radio, the USB, or the anti-theft code. This is not a complete list of audio error codes. Refer to symptom troubleshooting, or go to any official Honda service website for more service information.

CD Error Codes

Error Code DisplayedPossible CauseSolution
DISC ERRORThere is a problem with the disc player. A common problem is paper disc labels coming off the disc while in the player.Try to eject the disc and try another one. If there is still a problem, replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ) or audio unit (see AUDIO UNIT REMOVAL/INSTALLATION ).
HEAT ERRORDisc player is hot. This can happen if the vehicle is parked out in the hot sun all day.Park the vehicle in a cooler place for a while and try the disc player again. If the error code is still present, try another disc. If the error code is still present, replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ) or audio unit (see AUDIO UNIT REMOVAL/INSTALLATION ).
UNSUPPORTEDTrack/File format not supported.Current track is skipped. The next supported track or file plays automatically. Verify that CD file names end in CD-DA. Verify that CD-R or CD-RW with compressed music formats end in MP3 or WMA. Other file formats like iTunes (AAC) or Ogg are not recognized. WMA files may have (DRM) copy protection and cannot be read.
MECH ERRORCD label jammed in the mechanism. CD eject mechanism or motor is inoperative. CD spindle motor won't spin up the CD.Press the EJECT button and hold it for 5 seconds. If the CD does not eject, try again. If the CD still won't eject, replace the audio-navigation unit (see AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION ) or audio unit (see AUDIO UNIT REMOVAL/INSTALLATION ).

ERROR CODES DISPLAY CHART

USB Error Codes

Error Code DisplayedPossible CauseSolution
FILE ERRORThe audio unit cannot read the file(s).Check the files in the USB device. There is a possibility that the files have been damaged or are not supported.
MEDIA ERROR UNSUPPORTEDUnsupported USB device is connected.Connect the applicable USB device (see Owner's Manual).
USB LOADINGData is being loaded from the USB device.Check the files in the USB device. There is a possibility that the files have been damaged, or are not supported.
USB NO SONGThere are no files or files that are not supported on the USB device.Check the files in the USB device. There is a possibility that the files have been damaged, or are not supported.
USB NO DATAUSB device is not connected.If the code appears when the USB devices is connected, go to USB DEVICE DOES NOT FUNCTION TROUBLESHOOTING; WITH ELS AUDIO , with premium audio (see USB INPUT SOUND IS LOW OR CANNOT BE HEARD (WITH PREMIUM AUDIO) ).

ERROR CODES DISPLAY CHART

Audio Unit Error Codes

Error Code DisplayedPossible CauseSolution
CODE ERROR 1Anti-theft code mismatch (1 st try).Enter the correct anti-theft code.
CODE ERROR EAnti-theft code mismatch (10 th try).Remove the No. 15(10 A) fuse in the under-hood fuse/relay box, then reinsert it. You will have 10 more tries to enter the correct anti-theft code.

ERROR CODES DISPLAY CHART

XM Error Codes

Error Code DisplayedPossible CauseSolution
LOADINGXM radio is acquiring audio or program information.Wait until the radio receives the information. Refer to the XM SELF-DIAGNOSIS .
OFF AIRXM channel not in service.Try another XM channel. Refer to the XM SELF-DIAGNOSIS .
NO SIGNALLoss of signal.Both terrestrial and satellite antennas have lost the signal. Park the vehicle outside with a clear view of the southern horizon. Refer to the XM SELF-DIAGNOSIS .
UPDATINGXM radio is receiving information update from the network.This message disappears once the update finishes.
CHECK ANTENNAXM antenna error.Repair an open or a short in the satellite antenna. Substitute a known-good XM antenna (see XM ANTENNA REPLACEMENT ) or AM/FM/XM antenna (see XM ANTENNA REPLACEMENT ), and recheck. If the error is gone, replace the original XM antenna (see XM ANTENNA REPLACEMENT ) or AM/FM/XM antenna (see XM ANTENNA REPLACEMENT ). If the error is still present, replace the antenna lead.
ANTENNA ERROR
No signal from XM.Check a known-good vehicle with XM radio. If the known-good vehicle has the same symptoms, contact XM Radio at 800-852-9696.

ERROR CODES DISPLAY CHART

Note. Do these checks with the vehicle parked outside with a clear view of the southern horizon.

Poor AM or FM radio reception or interference (Sedan with ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Check for aftermarket accessories including cell phones and chargers plugged into the vehicle accessory power sockets. Check the radio reception in an open area. Poor reception/interference can be caused by any of these conditions

  1. The radio station is far away
  2. Atmospheric conditions are unfavorable
  3. Aftermarket metallic window tint
  4. A tall building, mountains, or high-voltage power lines are nearby

Scheme 711

Scheme 711

Scheme 712

Scheme 712

Scheme 713

Scheme 713

Scheme 714

Scheme 714

Scheme 715

Scheme 715

Scheme 716

Scheme 716

Scheme 717

Scheme 717

Scheme 718

Scheme 718
  1. Turn the ignition switch to ON (II).
  2. Do the Seek Stop Test (see «SEEK STOP TEST»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__seek-stop-test) ) and the reception level indication in the Self-Diagnostic Function (see «RECEPTION LEVEL INDICATION (PUSH AND HOLD 5 SEC FM/AM OR FM BUTTON)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__reception-level-indication-push-and-hold) ). Is the test vehicle within 10 % of the known-good vehicle? YES -Multipath interference or weak station. Operation is normal. NO -Go to step 3.
  3. Check the reception/interference is the same in several locations. Is the reception/interference the same? YES -Go to step 4. NO -Multipath interference or weak station. Operation is normal.
  4. Check the reception/interference while the engine is running. Is there noise (static or whine) only with the engine running? YES -Check the antenna and radio grounds. If OK, check the charging system and the ignition system. NO -Go to step 5.
  5. Turn the ignition switch to LOCK (0).
  6. Remove the right C-pillar trim (see «C-PILLAR TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__c-pillar-trim) ).
  7. Check the connections from the AM/FM antenna amplifier to the window antenna. Are there any loose or damaged connections? YES -Repair the connections, or substitute a known-good AM/FM antenna amplifier (see «AM/FM ANTENNA AMPLIFIER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/condition goes away, replace the original AM/FM antenna amplifier (see «AM/FM ANTENNA AMPLIFIER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -Go to step 8.
  8. With the help of an assistant inside the vehicle, have the assistant shine a strong flashlight (A) along each antenna wire (B). Check from the outside of the vehicle for any breaks or openings in the antenna wires (the light shines through any breaks or cuts). NOTE: It is easier to see the breaks if you do this test in a dark or shaded area. Are there any breaks or cuts in the antenna? YES -Repair the window antenna. Go to «AM/FM ANTENNA REPAIR»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__amfm-antenna-repair) , or replace the rear window (see «REAR WINDOW REPLACEMENT - SEDAN»(/acura/tsx/ii-2008-2014/remont/windows/#glass-4-cyl__rear-window-replacement-sedan) ) if the damaged section is too long. NO -Go to step 9.
  9. Disconnect the AM/FM antenna amplifier 3P connector.
  10. Turn the ignition switch to ON (II).
  11. Measure the voltage between AM/FM antenna amplifier 3P connector terminal No. 3 and body ground. AM/FM ANTENNA AMPLIFIER 3P CONNECTOR Is there battery voltage? YES -Go to step 17 . NO -Go to step 12.
  12. Turn the ignition switch to LOCK (0).
  13. Remove the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  14. Disconnect audio-navigation unit connector E (5P).
  15. Check for continuity between audio-navigation unit connector E (5P) terminal No. 3 and AM/FM antenna amplifier 3P connector terminal No. 3. Is there continuity? YES -Go to step 16. NO -Repair an open in the wire between the audio-navigation unit and the AM/FM antenna amplifier. Also check the AM/FM antenna lead/sublead connector.
  16. Check for continuity between audio-navigation unit connector E (5P) terminal No. 3 and body ground. AUDIO-NAVIGATION UNIT CONNECTOR E (5P) Is there continuity? YES -Repair a short to body ground in the wire between the audio-navigation unit and the AM/FM antenna amplifier. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  17. Turn the ignition switch to LOCK (0).
  18. Remove the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  19. Disconnect audio-navigation unit connector E (5P).
  20. Check for continuity between audio-navigation unit connector E (5P) terminal No. 4 and AM/FM antenna amplifier 3P connector terminal No. 1. Is there continuity? YES -Go to step 21. NO -Replace the AM/FM antenna lead and/or the sublead.
  21. Check for continuity between audio-navigation unit connector E (5P) terminal No. 4 and body ground. AUDIO-NAVIGATION UNIT CONNECTOR E (5P) Is there continuity? YES -Replace the AM/FM antenna lead and/or the sublead. NO -Go to step 22.
  22. Check for continuity between audio-navigation unit connector E (5P) terminal No. 5 and AM/FM antenna amplifier 3P connector terminal No. 2. Is there continuity? YES -Go to step 23. NO -Replace the AM/FM antenna lead and/or the sublead.
  23. Check for continuity between audio-navigation unit connector E (5P) terminals No. 4 and No. 5. AUDIO-NAVIGATION UNIT CONNECTOR E (5P) Is there continuity? YES -Replace the AM/FM antenna lead and/or the sublead. NO -Replace the AM/FM antenna amplifier (see «AM/FM ANTENNA AMPLIFIER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the reception is still poor, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Poor AM or FM radio reception or interference (Sport Wagon with ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Check for aftermarket accessories including cell phones and chargers plugged into the vehicle accessory power sockets. Check the radio reception in an open area. Poor reception/interference can be caused by any of these conditions

  1. The radio station is far away
  2. Atmospheric conditions are unfavorable
  3. A tall building, mountains, or high-voltage power lines are nearby

Scheme 719

Scheme 719

Scheme 720

Scheme 720

Scheme 721

Scheme 721

Scheme 722

Scheme 722

Scheme 723

Scheme 723

Scheme 724

Scheme 724

Scheme 725

Scheme 725
  1. Turn the ignition switch to ON (II).
  2. Do the Seek Stop Test (see «SEEK STOP TEST»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__seek-stop-test) ) and the reception level indication in the Self-Diagnostic Function (see «RECEPTION LEVEL INDICATION (PUSH AND HOLD 5 SEC FM/AM OR FM BUTTON)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__reception-level-indication-push-and-hold) ). Is the test vehicle within 10 % of the known-good vehicle? YES -Multipath interference or weak station. Operation is normal. NO -Go to step 3.
  3. Check the reception/interference is the same in several locations. Is the reception/interference the same? YES -Go to step 4. NO -Multipath interference or weak station. Operation is normal.
  4. Check that the reception/interference while the engine is running. Is there noise (static or whine) only with the engine running? YES -Check the antenna and radio grounds. If OK, check the charging system and the ignition system. NO -Go to step 5.
  5. Turn the ignition switch to LOCK (0).
  6. Disconnect the AM/FM/XM antenna 3P connector.
  7. Turn the ignition switch to ON (II).
  8. Measure the voltage between AM/FM/XM antenna 3P connector terminal No. 3 and body ground. AM/FM/XM ANTENNA 3P CONNECTOR Is there battery voltage? YES -Go to step 14 . NO -Go to step 9.
  9. Turn the ignition switch to LOCK (0).
  10. Remove the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  11. Disconnect audio-navigation unit connector E (5P).
  12. Check for continuity between audio-navigation unit connector E (5P) terminal No. 3 and AM/FM/XM antenna 3P connector terminal No. 3. Is there continuity? YES -Go to step 13. NO -Repair an open in the wire between the audio-navigation unit and the AM/FM/XM antenna. Also check the AM/FM antenna sublead/main lead/rear lead connector.
  13. Check for continuity between audio-navigation unit connector E (5P) terminal No. 3 and body ground. AUDIO-NAVIGATION UNIT CONNECTOR E (5P) Is there continuity? YES -Repair a short to body ground in the wire between the audio-navigation unit and the AM/FM/XM antenna. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  14. Turn the ignition switch to LOCK (0).
  15. Remove the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  16. Disconnect audio-navigation unit connector E (5P).
  17. Check for continuity between audio-navigation unit connector E (5P) terminal No. 4 and AM/FM/XM antenna 3P connector terminal No. 1. Is there continuity? YES -Go to step 18. NO -Replace the AM/FM antenna sublead and/or the main lead and/or the rear lead.
  18. Check for continuity between audio-navigation unit connector E (5P) terminal No. 4 and body ground. AUDIO-NAVIGATION UNIT CONNECTOR E (5P) Is there continuity? YES -Replace the AM/FM antenna sublead and/or the main lead and/or the rear lead. NO -Go to step 19.
  19. Check for continuity between audio-navigation unit connector E (5P) terminal No. 5 and AM/FM/XM antenna 3P connector terminal No. 2. Is there continuity? YES -Go to step 20. NO -Replace the AM/FM antenna sublead and/or the main lead and/or the rear lead.
  20. Check for continuity between audio-navigation unit connector E (5P) terminals No. 4 and No. 5. AUDIO-NAVIGATION UNIT CONNECTOR E (5P) Is there continuity? YES -Replace the AM/FM antenna sublead and/or the main lead and/or the rear lead. NO -Replace the AM/FM/XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the reception is still poor, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Poor AM or FM radio reception or interference (Sedan with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Check for aftermarket accessories including cell phones and chargers plugged into the vehicle accessory power sockets. Check the radio reception in an open area. Poor reception/interference can be caused by any of these conditions

  1. The radio station is far away
  2. Atmospheric conditions are unfavorable
  3. Aftermarket metallic window tint
  4. A tall building, mountains, or high-voltage power lines are nearby

Scheme 726

Scheme 726

Scheme 727

Scheme 727

Scheme 728

Scheme 728

Scheme 729

Scheme 729

Scheme 730

Scheme 730

Scheme 731

Scheme 731

Scheme 732

Scheme 732

Scheme 733

Scheme 733
  1. Turn the ignition switch to ON (II).
  2. Do the Seek Stop Test (see «SEEK STOP TEST»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__seek-stop-test) ) and the reception level indication in the Self-Diagnostic Function (see «RECEPTION LEVEL INDICATION (PUSH AND HOLD 5 SEC FM/AM OR FM BUTTON)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__reception-level-indication-push-and-hold) ). Is the test vehicle within 10 % of the known-good vehicle? YES -Multipath interference or weak station. Operation is normal. NO -Go to step 3.
  3. Check the reception/interference is the same in several locations. Is the reception/interference the same? YES -Go to step 4. NO -Multipath interference or weak station. Operation is normal.
  4. Check the reception/interference while the engine is running. Is there noise (static or whine) only with the engine running? YES -Check the antenna and radio grounds. If OK, check the charging system and the ignition system. NO -Go to step 5.
  5. Turn the ignition switch to LOCK (0).
  6. Remove the right C-pillar trim (see «C-PILLAR TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__c-pillar-trim) ).
  7. Check the connections from the AM/FM antenna amplifier to the window antenna. Are there any loose or damaged connections? YES -Repair the connections, or substitute a known-good AM/FM antenna amplifier (see «AM/FM ANTENNA AMPLIFIER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and retest. If the symptom/condition goes away, replace the original AM/FM antenna amplifier. NO -Go to step 8.
  8. With the help of an assistant inside the vehicle, have the assistant shine a strong flashlight (A) along each antenna wire (B). Check from the outside of the vehicle for any breaks or openings in the antenna wires (the light shines through any breaks or cuts). NOTE: It is easier to see the breaks if you do this test in a dark or shaded area. Are there any breaks or cuts in the antenna? YES -Repair the window antenna. Go to «AM/FM ANTENNA REPAIR»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__amfm-antenna-repair) , or replace the rear window (see «REAR WINDOW REPLACEMENT - SEDAN»(/acura/tsx/ii-2008-2014/remont/windows/#glass-4-cyl__rear-window-replacement-sedan) ) if the damaged section is too long. NO -Go to step 9.
  9. Disconnect AM/FM antenna amplifier 3P connector.
  10. Turn the ignition switch to ON (II).
  11. Measure the voltage between AM/FM antenna amplifier 3P connector terminal No. 3 and body ground. AM/FM ANTENNA AMPLIFIER 3P CONNECTOR Is there battery voltage? YES -Go to step 17 . NO -Go to step 12.
  12. Turn the ignition switch to LOCK (0).
  13. Remove the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  14. Disconnect audio unit connector F (3P).
  15. Check for continuity between audio unit connector F (3P) terminal No. 3 and AM/FM antenna amplifier 3P connector terminal No. 3. Is there continuity? YES -Go to step 16. NO -Repair an open in the wire between the audio unit and the AM/FM antenna amplifier. Also check the AM/FM antenna lead/sublead connector.
  16. Check for continuity between audio unit connector F (3P) terminal No. 3 and body ground. AUDIO UNIT CONNECTOR F (3P) Is there continuity? YES -Repair a short to body ground in the wire between the audio unit and the AM/FM antenna amplifier. NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  17. Turn the ignition switch to LOCK (0).
  18. Remove the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  19. Disconnect audio unit connector F (3P).
  20. Check for continuity between audio unit connector F (3P) terminal No. 1 and AM/FM antenna amplifier 3P connector terminal No. 1. Is there continuity? YES -Go to step 21. NO -Replace the AM/FM antenna lead and/or the sublead.
  21. Check for continuity between audio unit connector F (3P) terminal No. 1 and body ground. AUDIO UNIT CONNECTOR F (3P) Is there continuity? YES -Replace the AM/FM antenna lead and/or the sublead. NO -Go to step 22.
  22. Check for continuity between audio unit connector F (3P) terminal No. 2 and AM/FM antenna amplifier 3P connector terminal No. 2. Is there continuity? YES -Go to step 23. NO -Replace the AM/FM antenna lead and/or the sublead.
  23. Check for continuity between audio unit connector F (3P) terminals No. 1 and No. 2. AUDIO UNIT CONNECTOR F (3P) Is there continuity? YES -Replace the AM/FM antenna lead and/or the sublead. NO -Replace the AM/FM antenna amplifier (see «AM/FM ANTENNA AMPLIFIER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the reception is still poor, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).

Poor AM or FM radio reception or interference (Sport Wagon with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Check for aftermarket accessories including cell phones and chargers plugged into the vehicle accessory power sockets. Check the radio reception in an open area. Poor reception/interference can be caused by any of these conditions

  1. The radio station is far away
  2. Atmospheric conditions are unfavorable
  3. A tall building, mountains, or high-voltage power lines are nearby

Scheme 734

Scheme 734

Scheme 735

Scheme 735

Scheme 736

Scheme 736

Scheme 737

Scheme 737

Scheme 738

Scheme 738

Scheme 739

Scheme 739

Scheme 740

Scheme 740
  1. Turn the ignition switch to ON (II).
  2. Do the Seek Stop Test (see «SEEK STOP TEST»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__seek-stop-test) ) and the reception level indication in the Self-Diagnostic Function (see «RECEPTION LEVEL INDICATION (PUSH AND HOLD 5 SEC FM/AM OR FM BUTTON)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__reception-level-indication-push-and-hold) ). Is the test vehicle within 10 % of the known-good vehicle? YES -Multipath interference or weak station. Operation is normal. NO -Go to step 3.
  3. Check that the reception/interference is the same in several locations. Is the reception/interference the same? YES -Go to step 4. NO -Multipath interference or weak station. Operation is normal.
  4. Check the reception/interference while the engine is running. Is there noise (static or whine) only with the engine running? YES -Check the antenna and radio grounds. If OK, check the charging system and the ignition system. NO -Go to step 5.
  5. Turn the ignition switch to LOCK (0).
  6. Disconnect the AM/FM/XM antenna 3P connector.
  7. Turn the ignition switch to ON (II).
  8. Measure the voltage between AM/FM/XM antenna 3P connector terminal No. 3 and body ground. AM/FM/XM ANTENNA 3P CONNECTOR Is there battery voltage? YES -Go to step 14 . NO -Go to step 9.
  9. Turn the ignition switch to LOCK (0).
  10. Remove the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  11. Disconnect audio unit connector F (3P).
  12. Check for continuity between audio unit connector F (3P) terminal No. 3 and AM/FM/XM antenna 3P connector terminal No. 3. Is there continuity? YES -Go to step 13. NO -Repair an open in the wire between the audio unit and the AM/FM/XM antenna. Also check the AM/FM antenna sublead/main lead/rear lead connector.
  13. Check for continuity between audio unit connector F (3P) terminal No. 3 and body ground. AUDIO UNIT CONNECTOR F (3P) Is there continuity? YES -Repair a short to body ground in the wire between the audio unit and the AM/FM/XM antenna. NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  14. Turn the ignition switch to LOCK (0).
  15. Remove the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  16. Disconnect audio unit connector F (3P).
  17. Check for continuity between audio unit connector F (3P) terminal No. 1 and AM/FM/XM antenna 3P connector terminal No. 1. Is there continuity? YES -Go to step 18. NO -Replace the AM/FM antenna sublead and/or the main lead and/or the rear lead.
  18. Check for continuity between audio unit connector F (3P) terminal No. 1 and body ground. AUDIO UNIT CONNECTOR F (3P) Is there continuity? YES -Replace the AM/FM antenna sublead and/or the main lead and/or the rear lead. NO -Go to step 19.
  19. Check for continuity between audio unit connector F (3P) terminal No. 2 and AM/FM/XM antenna 3P connector terminal No. 2. Is there continuity? YES -Go to step 20. NO -Replace the AM/FM antenna sublead and/or the main lead and/or the rear lead.
  20. Check for continuity between audio unit connector F (3P) terminals No. 1 and No. 2. AUDIO UNIT CONNECTOR F (3P) Is there continuity? YES -Replace the AM/FM antenna sublead and/or the main lead and/or the rear lead. NO -Replace the AM/FM/XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the reception is still poor, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).

Audio unit power switch will not turn on (No information display and no sound) (with ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 741

Scheme 741: Audio unit power switch will not turn on (No information display and no sound) (with ELS audio)

Scheme 742

Scheme 742

Scheme 743

Scheme 743

Scheme 744

Scheme 744

Scheme 745

Scheme 745

Scheme 746

Scheme 746

Scheme 747

Scheme 747

Scheme 748

Scheme 748

Scheme 749

Scheme 749

Scheme 750

Scheme 750

Scheme 751

Scheme 751

Scheme 752

Scheme 752

Scheme 753

Scheme 753
  1. Turn the ignition switch to ON (II).
  2. Push the VOLUME/POWER knob on to see if the audio system turns on. Does the audio display operate properly, and does the audio system sound normal? YES -Intermittent failure, the system is OK at this time. NO -Go to step 3.
  3. Turn the ignition switch to LOCK (0).
  4. Check the No. 15(10 A) fuse in the under-hood fuse/relay box and the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box. Are the fuses OK? YES -Go to step 5. NO -Replace the fuse(s), and recheck. If the fuse(s) blows again, check for a short in the No. 15 (10 A) fuse and/or the No. 18 (7.5 A) fuse circuits.
  5. Remove the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). Check that the audio-navigation unit connectors are properly connected. Are the connectors properly connected? YES -Go to step 6. NO -Repair poor connections and reconnect the connectors, and recheck the function.
  6. Turn the ignition switch to ON (II).
  7. Measure the voltage between body ground and audio-navigation unit connector A (24P) terminals No. 14 and No. 24 individually. AUDIO-NAVIGATION UNIT CONNECTOR A (24P) Is there battery voltage? YES -Go to step 8. NO -If the +B wire does not have voltage, repair an open in the wire between the No. 15 (10 A) fuse in the under-hood fuse/relay box and audio-navigation unit connector A (24P) terminal No. 24. If the ACC wire does not have voltage, repair an open in the wire between the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box and audio-navigation unit connector A (24P) terminal No. 14.
  8. Measure the voltage between audio-navigation unit connector A (24P) terminal No. 12 and body ground. AUDIO-NAVIGATION UNIT CONNECTOR A (24P) Is there less than 0.2 V? YES -Go to step 9. NO -Repair an open or high resistance in the wire between audio-navigation unit connector A (24P) terminal No. 12 and body ground (G651); Sedan (see «RIGHT SIDE WIRE HARNESS (SEDAN)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-4-cyl__right-side-wire-harness-sedan) ), Sport Wagon (see «RIGHT SIDE WIRE HARNESS (SPORT WAGON)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-4-cyl__right-side-wire-harness-sport-wagon) ).
  9. Measure the voltage between audio-navigation switch panel 24P connector terminal No. 22 and body ground. AUDIO-NAVIGATION SWITCH PANEL 24P CONNECTOR Is there battery voltage? YES -Go to step 10. NO -Repair an open in the wire(s) between the No. 15 (10 A) fuse in the under-hood fuse/relay box and audio-navigation switch panel 24P connector terminal No. 22.
  10. Measure the voltage between audio-navigation switch panel 24P connector terminal No. 10 and body ground. AUDIO-NAVIGATION SWITCH PANEL 24P CONNECTOR Is there less than 0.2 V? YES -Go to step 11. NO -Repair an open or high resistance in the wire between audio-navigation switch panel 24P connector terminal No. 10 and body ground (G401) (see «AUDIO WIRE HARNESS (WITH NAVIGATION)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-4-cyl__audio-wire-harness-with-navigation) ).
  11. Measure the voltage between audio-navigation switch panel 24P connector terminal No. 17 and body ground. AUDIO-NAVIGATION SWITCH PANEL 24P CONNECTOR Is there battery voltage? YES -Go to step 12. NO -Repair an open or a short in the wire between the audio-navigation switch panel and the audio-navigation unit.
  12. Turn the ignition switch to LOCK (0).
  13. Disconnect audio-navigation unit connector F (12P) and the audio-navigation switch panel 24P connector.
  14. Check for continuity between audio-navigation switch panel 24P connector terminal No. 14 and body ground. AUDIO-NAVIGATION SWITCH PANEL 24P CONNECTOR Is there continuity? YES -Repair a short to body ground in the wire between the audio-navigation switch panel and the audio-navigation unit. NO -Go to step 15.
  15. Check for continuity between audio-navigation unit connector F (12P) terminal No. 12 and audio-navigation switch panel 24P connector terminal No. 14. Is there continuity? YES -Go to step 16. NO -Repair an open in the wire between the audio-navigation switch panel and the audio-navigation unit.
  16. Reconnect the audio-navigation switch panel 24P connector.
  17. Check for continuity between audio-navigation switch panel 24P connector terminal No. 14 and body ground. AUDIO-NAVIGATION SWITCH PANEL 24P CONNECTOR Is there continuity? YES -Replace the audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -Go to step 18.
  18. While press and holding the VOLUME/POWER knob, check for continuity between audio-navigation switch panel 24P connector terminal No. 14 and body ground. AUDIO-NAVIGATION SWITCH PANEL 24P CONNECTOR Is there continuity? YES -Go to step 19. NO -Replace the audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  19. Disconnect the audio-navigation switch panel 24P connector.
  20. Check for continuity between audio-navigation unit connector F (12P) and the audio-navigation switch panel 24P connector according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio-navigation unit connector Audio-navigation switch panel connector Wire color F1 15 GRN F7 16 RED F8 3 BLU AUDIO-NAVIGATION UNIT CONNECTOR F (12P) AUDIO-NAVIGATION SWITCH PANEL 24P CONNECTOR Is there continuity? YES -Go to step 21. NO -There is an open in the wire(s) between the audio-navigation unit and the audio-navigation switch panel. Repair or replace the affected harness.
  21. Check for continuity between body ground and audio-navigation unit connector F (12P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio-navigation unit connector Wire color F1 GRN F7 RED F8 BLU AUDIO-NAVIGATION UNIT CONNECTOR F (12P) Is there continuity? YES -There is a short in the wire(s) between the audio-navigation unit and the audio-navigation switch panel. Repair or replace the affected harness. NO -Go to step 22.
  22. Check for continuity between the terminals of audio-navigation unit connector F (12P) according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals F1 (GRN) F2 (GRY), F7 (RED) F2 (GRY) F7 (RED) AUDIO-NAVIGATION UNIT CONNECTOR F (12P) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio-navigation unit and the audio-navigation switch panel. Replace the affected shielded harness. NO -Substitute a known-good audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If the symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Audio unit power switch will not turn on (No information display and no sound) (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 754

Scheme 754: Audio unit power switch will not turn on (No information display and no sound) (with premium audio)

Scheme 755

Scheme 755
  1. Turn the ignition switch to ON (II).
  2. Push the VOLUME/POWER knob on to see if audio unit turns on. Does the audio unit display operate properly, and does the audio unit sound normal? YES -Intermittent failure, the system is OK at this time. NO -Go to step 3.
  3. Turn the ignition switch to LOCK (0).
  4. Check the No. 15 (10 A) fuse in the under-hood fuse / relay box and the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box. Are the fuses OK? YES -Go to step 5. NO -Replace the fuse(s), and recheck. If the fuse(s) blows again, check for a short in the No. 15 (10 A) fuse and/or the No. 18 (7.5 A) fuse circuits.
  5. Remove the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). Check that the audio unit connectors are properly connected. Are they connected properly? YES -Go to step 6. NO -Repair poor connections and reconnect the connectors, and recheck the function.
  6. Turn the ignition switch to ON (II).
  7. Measure the voltage between body ground and audio unit connector A (24P) terminals No. 14 and No. 24 individually. AUDIO UNIT CONNECTOR A (24P) Is there battery voltage? YES -Go to step 8. NO -If the +B wire does not have voltage, repair an open in the wire between the No. 15 (10 A) fuse in the under-hood fuse/relay box and audio unit connector A (24P) terminal No. 24. If the ACC wire does not have voltage, repair an open in the wire between the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box and audio unit connector A (24P) terminal No. 14.
  8. Measure the voltage between audio unit connector A (24P) terminal No. 12 and body ground. AUDIO UNIT CONNECTOR A (24P) Is there less than 0.2 V? YES -Substitute a known-good audio switch panel (see «AUDIO SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio switch panel (see «AUDIO SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If the symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -Repair an open or high resistance in the wire between audio unit and body ground (G401) (see «AUDIO WIRE HARNESS (WITH NAVIGATION)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-4-cyl__audio-wire-harness-with-navigation) ).

Audio unit power switch will not turn off (with ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Check for aftermarket accessories plugged info the vehicle's accessory power sockets.

Scheme 756

Scheme 756: Audio unit power switch will not turn off (with ELS audio)

Scheme 757

Scheme 757

Scheme 758

Scheme 758

Scheme 759

Scheme 759

Scheme 760

Scheme 760
  1. Turn the ignition switch to ON (II).
  2. Push the VOLUME/POWER knob on to see if the audio system turns off. Does the audio system turn off? YES -Operation is normal. NO -Go to step 3.
  3. Turn the ignition switch to LOCK (0). Does the audio-navigation unit turn off? YES -Go to step 5. NO -Go to step 4.
  4. Measure the voltage between audio-navigation unit connector A (24P) terminal No. 14 and body ground. AUDIO-NAVIGATION UNIT CONNECTOR A (24P) Is there battery voltage? YES -Check for short to power on the PUR wire. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  5. Disconnect audio-navigation unit connector F (12P) and the audio-navigation switch panel 24P connector.
  6. Check for continuity between audio-navigation switch panel 24P connector terminal No. 14 and body ground. AUDIO-NAVIGATION SWITCH PANEL 24P CONNECTOR Is there continuity? YES -Repair a short to body ground in the wire between the audio-navigation switch panel and the audio-navigation unit. NO -Go to step 7.
  7. Check for continuity between audio-navigation unit connector F (12P) terminal No. 12 and audio-navigation switch panel 24P connector terminal No. 14. Is there continuity? YES -Go to step 8. NO -Repair an open in the wire between the audio-navigation switch panel and the audio-navigation unit.
  8. Reconnect the audio-navigation switch panel 24P connector.
  9. Check for continuity between audio-navigation switch panel 24P connector terminal No. 14 and body ground. AUDIO-NAVIGATION SWITCH PANEL 24P CONNECTOR Is there continuity? YES -Replace the audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -Go to step 10.
  10. While press and holding the VOLUME/POWER knob, check for continuity between audio-navigation switch panel 24P connector terminal No. 14 and body ground. AUDIO-NAVIGATION SWITCH PANEL 24P CONNECTOR Is there continuity? YES -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Replace the audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).

Audio unit power switch will not turn off (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Check for aftermarket accessories plugged into the vehicle's accessory power sockets.

Scheme 761

Scheme 761: Audio unit power switch will not turn off (with premium audio)
  1. Turn the ignition switch to ON (II).
  2. Push the VOLUME/POWER knob off to see if the audio unit turns off. Does the audio unit turn off? YES -Go to step 3. NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  3. Turn the ignition switch to LOCK (0). Does the audio unit turn off? YES -Operation is normal. NO -Go to step 4.
  4. Measure the voltage between audio unit connector A (24P) terminal No. 14 and body ground.

Is there battery voltage?

YES -Check for short to power on the PUR wire.

NO -Substitute a known-good audio switch panel (see AUDIO SWITCH PANEL REMOVAL/INSTALLATION ), and recheck. If the symptom/indication goes away, replace the original audio switch panel (see AUDIO SWITCH PANEL REMOVAL/INSTALLATION ). If the symptom/indication is still present, replace the audio unit (see AUDIO UNIT REMOVAL/INSTALLATION ).

No sound is heard from the speaker(s) (display is normal) (with ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Set the fader and balance positions to the center. Before doing the troubleshooting, do the Audio unit power switch will not turn on (No information display and no sound) troubleshooting (see AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH ELS AUDIO) ).

Scheme 762

Scheme 762: No sound is heard from the speaker(s) (display is normal) (with ELS audio)

Scheme 763

Scheme 763

Scheme 764

Scheme 764

Scheme 765

Scheme 765

Scheme 766

Scheme 766

Scheme 767

Scheme 767

Scheme 768

Scheme 768

Scheme 769

Scheme 769

Scheme 770

Scheme 770

Scheme 771

Scheme 771

Scheme 772

Scheme 772

Scheme 773

Scheme 773

Scheme 774

Scheme 774

Scheme 775

Scheme 775

Scheme 776

Scheme 776

Scheme 777

Scheme 777

Scheme 778

Scheme 778
  1. Turn the ignition switch to ON (II).
  2. Turn on the audio system, and make sure the volume button is not set to the MIN level. Is it at the MIN level? YES -Raise the volume level, and recheck the function. NO -Go to step 3.
  3. Check for sound in each mode (AM/FM, XM, USB, and CD or DVD). Is the sound OK in each mode? YES -Intermittent failure, the system is OK at this time. Check for loose connections at the audio-navigation unit and speaker(s). NO - If there is no sound in all modes, go to step 4. If there is no sound in AM/FM mode, go to AM or FM radio reception interference troubleshooting; Sedan (see «POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (SEDAN WITH ELS AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__poor-am-or-fm-radio-reception) ), Sport Wagon (see «POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (SPORT WAGON WITH ELS AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__poor-am-or-fm-radio-reception) ). If the sound quality is poor only with XM radio, or the XM radio does not function, go to «POOR OR NO SOUND WITH XM RADIO»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__poor-or-no-sound-with-xm) (Audio unit does display XM channels) troubleshooting; with AcuraLink , without AcuraLink (see «POOR OR NO SOUND WITH XM RADIO (AUDIO UNIT DOES DISPLAY XM CHANNELS) (WITH ELS AUDIO, WITHOUT ACURALINK)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__poor-or-no-sound-with-xm) ). If sound quality is poor only with USB mode, go to USB input sound is low or cannot be heard troubleshooting (see «USB INPUT SOUND IS LOW OR CANNOT BE HEARD (WITH ELS AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__usb-input-sound-is-low-or) ). If there is no sound in CD or DVD mode, go to Audio disc does not play troubleshooting (see «AUDIO DISC DOES NOT PLAY (WITH ELS AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__audio-disc-does-not-play-with) ).
  4. Turn the ignition switch to LOCK (0).
  5. Disconnect the HandsFreeLink control unit 28P connector.
  6. Turn the ignition switch to ON (II), and recheck the audio system for sound. Did the sound return? YES -Replace the HandsFreeLink control unit (see «HANDSFREELINK CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#handsfreelink-system-4-cyl__handsfreelinktm-control-unit-removalinstallation) ). NO -Go to step 7.
  7. Do the Speaker Check Mode with the Self-Diagnostic Function (see «SPEAKER CHECK MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__speaker-check-mode) ). Do all speakers produce a tone? YES -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Go to step 8.
  8. Turn the ignition switch to LOCK (0).
  9. Check the No. 15 (20 A) fuse in the passenger's under-dash fuse/relay box. Is the fuse OK? YES -Go to step 10. NO -Replace the fuse, and recheck. If the fuse blows again, check for a short in the No. 15 (20 A) fuse circuit.
  10. Measure the voltage between stereo amplifier connector A (18P) terminal No. 18 and body ground. STEREO AMPLIFIER CONNECTOR A (18P) Is there battery voltage? YES -Go to step 11. NO -Repair an open in the wire between the No. 15 (20 A) fuse in the passenger's under-dash fuse/relay box and stereo amplifier connector A (18P) terminal No. 18.
  11. Turn the ignition switch to ON (II).
  12. Measure the voltage between stereo amplifier connector B (28P) terminal No. 3 and body ground. STEREO AMPLIFIER CONNECTOR B (28P) Is there battery voltage? YES -Go to step 13. NO -Repair an open in the wire between stereo amplifier connector B (28P) terminal No. 3 and audio-navigation unit connector A (24P) terminal No. 17. If the wire and the pin fits are OK, substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  13. Measure the voltage between stereo amplifier connector A (18P) terminal No. 9 and body ground. STEREO AMPLIFIER CONNECTOR A (18P) Is there less than 0.2 V? YES -Go to step 14. NO -Repair an open or high resistance in the wire between the stereo amplifier connector A (18P) terminal No. 9 and body ground (G651); Sedan (see «RIGHT SIDE WIRE HARNESS (SEDAN)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-4-cyl__right-side-wire-harness-sedan) ), Sport Wagon (see «RIGHT SIDE WIRE HARNESS (SPORT WAGON)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-4-cyl__right-side-wire-harness-sport-wagon) ).
  14. Turn the ignition switch to LOCK (0).
  15. Check the faulty speaker(s) for damage. Is there any damage? YES -Replace the speaker, and recheck. NO -Go to step 16.
  16. Remove the speaker(s) with no sound (see «SPEAKER TEST/REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and disconnect its connector.
  17. Check the speaker connectors for a loose or poor connection. Reconnect the speaker connector, and recheck the symptom; is the condition still present? YES -Go to step 18. NO -Intermittent failure. Operation is normal.
  18. Test the speaker(s) (see «SPEAKER TEST/REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). Is the speaker(s) OK? YES -Go to step 19. NO -Replace the speaker(s) (see «SPEAKER TEST/REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  19. Reconnect the speaker connector(s).
  20. Disconnect stereo amplifier connector A (18P).
  21. Check for continuity between body ground and stereo amplifier connector A (18P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Speaker Stereo amplifier connector Wire color Driver's door speaker, Driver's door tweeter A16(+) BLK A7(-) BLU Front passenger's door speaker. Front passenger's door tweeter A15(+) RED A6(-) GRN Left rear door speaker A13(+) WHT A4(-) GRN Right rear door speaker A12(+) RED A3 (-) BLU Subwoofer A10(+) GRY (1) RED (2) A1 (-) LT BLU (1) WHT (2) Front center speaker A11 (+) YEL A2(-) BLU Left rear speaker (1) , Left satellite speaker (2) A17(+) YEL A8(-) BRN Right rear speaker (1) , Right satellite speaker (2) A14(+) BLU A5 (-) ORN (1) Sedan (2) Sport Wagon STEREO AMPLIFIER CONNECTOR A (18P) Is there continuity? YES -Repair a short to body ground in the wire(s) between the stereo amplifier and the speaker(s). NO -Go to step 22.
  22. Disconnect the driver's door tweeter 2P connector and the front passenger's door tweeter 2P connector.
  23. Measure the resistance between each pair of speaker terminals at stereo amplifier connector A (18P) according to the table. TERMINAL RESISTANCE REFERENCE CHART Speaker Stereo amplifier connector Wire color Resistance Driver's door speaker A16 BLK About 2 ohms A7 BLU Front passenger's door speaker A15 RED About 2 ohms A6 GRN Left rear door speaker A13 WHT About 2 ohms A4 GRN Right rear door speaker A12 RED About 2 ohms A3 BLU Subwoofer (1) A10 GRY About 2 ohms A1 LT BLU Front center speaker A11 YEL About 4 ohms A2 BLU Left rear speaker (1) , Left satellite speaker (2) A17 YEL About 2 ohms (1) About 4 ohms (2) A8 BRN Right rear speaker (1) , Right satellite speaker (2) A14 BLU About 2 ohms (1) About 4 ohms (2) A5 ORN (1) Sedan (2) Sport Wagon STEREO AMPLIFIER CONNECTOR A (18P) Is the resistance OK? YES -Go to step 24. NO -Repair an open or a short in the wire(s) between the stereo amplifier and the speaker(s).
  24. Disconnect these items: Driver's door speaker 2P connector Front passenger's door speaker 2P connector Subwoofer 8P connector (Sport Wagon)
  25. Connect stereo amplifier connector A (18P) terminals with jumper wires as shown. STEREO AMPLIFIER CONNECTOR A (18P) Sport Wagon
  26. Check for continuity between the terminals of speaker connector according to the table. TERMINAL CONTINUITY REFERENCE CHART Speaker Terminal Wire color Driver's door tweeter 1 LT GRN 2 PNK Front passenger's door tweeter 1 GRY 2 RED Subwoofer (Sport Wagon) 3 RED 8 WHT DRIVERS DOOR TWEETER 2P CONNECTOR FRONT PASSENGER'S DOOR TWEETER 2P CONNECTOR Sport Wagon SUBWOOFER 8P CONNECTOR Is there continuity? YES -Go to step 27. NO -Repair an open in the wire(s) between the stereo amplifier and the speaker(s).
  27. Remove the jumper wires.
  28. Disconnect stereo amplifier connector B (28P).
  29. Disconnect audio-navigation unit connector D (20P).
  30. Check for continuity between body ground and audio-navigation unit connector D (20P) terminals No. 1 and No. 2 individually. AUDIO-NAVIGATION UNIT CONNECTOR D (20P) Is there continuity? YES -There is a short to body ground in the wire(s) between the audio-navigation unit and the stereo amplifier. Replace the affected shielded harness. NO -Go to step 31.
  31. Check for continuity between the terminals of audio-navigation unit connector D (20P) according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals D1 (RED) D2 (GRN), D11 (GRY) D2 (GRN) D11 (GRY) AUDIO-NAVIGATION UNIT CONNECTOR D (20P) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio-navigation unit and the stereo amplifier. Replace the affected shielded harness. NO -Go to step 32.
  32. Check for continuity between audio-navigation unit connector D (20P) and stereo amplifier connector B (28P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio-navigation unit connector Stereo amplifier connector Wire color D1 B1 RED D2 B15 GRN AUDIO-NAVIGATION UNIT CONNECTOR D (20P) STEREO AMPLIFIER CONNECTOR B (28P) Is there continuity? YES -Go to step 33. NO -There is an open in the wire(s) between the audio-navigation unit and the stereo amplifier. Replace the affected shielded harness.
  33. Disconnect audio-navigation unit connector A (24P) and connector B (24P). NOTE: Eject all the disc(s) before disconnecting the audio-navigation unit to prevent damaging the CD/DVD player's load mechanism.
  34. Check for continuity between audio-navigation unit connector A (24P), connector B (24P), and stereo amplifier connector B (28P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio-navigation unit connector Stereo amplifier connector A6 (ORN) B28 (BLK) A7 (BLU) B14 (WHT) A8 (GRY) B26 (GRY) A10 (YEL) B27 (GRN) A11 (PUR) B13 (RED) A18 (GRN) B25 (RED) A19 (BLK) B11 (GRN) A20 (GRY) B12 (GRY) A22 (WHT) B24 (WHT) A23 (RED) B10 (BLK) B9 (WHT) B18 (WHT) B10 (RED) B4 (BLK) B11 (GRY) B5 (GRY) B12 (BLK) B6 (RED) B24 (GRN) B19(GRN) AUDIO-NAVIGATION UNIT CONNECTOR A (24P) AUDIO-NAVIGATION UNIT CONNECTOR B (24P) STEREO AMPLIFIER CONNECTOR B (28P) Is there continuity? YES -Go to step 35. NO -There is an open in the wire(s) between the stereo amplifier and the audio-navigation unit. Replace the affected shielded harness.
  35. Check for continuity between body ground and stereo amplifier connector B (28P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Stereo amplifier connector Wire color B4 BLK B5 GRY B6 RED B10 BLK B11 GRN B12 GRY B13 RED B14 WHT B18 WHT B19 GRN B24 WHT B25 RED B26 GRY B27 GRN B28 BLK STEREO AMPLIFIER CONNECTOR B (28P) Is there continuity? YES -There is a short to body ground in the wire(s) between the stereo amplifier and the audio-navigation unit. Replace the affected shielded harness. NO -Substitute a known-good stereo amplifier; Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original stereo amplifier; Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If the symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

No sound is heard from the speaker(s) (display is normal) (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Set the fader and balance positions to the center. Before doing the troubleshooting, do the Audio unit power switch will not turn on (No information display and no sound) troubleshooting (see AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH PREMIUM AUDIO) ).

Scheme 779

Scheme 779: No sound is heard from the speaker(s) (display is normal) (with premium audio)

Scheme 780

Scheme 780

Scheme 781

Scheme 781

Scheme 782

Scheme 782

Scheme 783

Scheme 783

Scheme 784

Scheme 784

Scheme 785

Scheme 785

Scheme 786

Scheme 786

Scheme 787

Scheme 787
  1. Turn the ignition switch to ON (II)
  2. Turn on the audio unit and make sure the volume button is not set to the MIN level. Is it at the MIN level? YES -Raise the volume level, and recheck the function. NO -Go to step 3.
  3. Check for sound in each mode (AM/FM, XM, USB, and CD). Is the sound OK in each mode? YES -Intermittent failure, the system is OK at this time. Check for loose connections at the audio-navigation unit and speaker(s). NO - If there is no sound in all modes, go to step 4. If there is no sound in AM/FM mode, go to AM or FM radio reception interference troubleshooting; Sedan (see «POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (SEDAN WITH PREMIUM AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__poor-am-or-fm-radio-reception) ), Sport Wagon (see «POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (SPORT WAGON WITH PREMIUM AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__poor-am-or-fm-radio-reception) ). If the sound quality is poor only with XM radio, or the XM radio does not function, go to «POOR OR NO SOUND WITH XM RADIO (AUDIO UNIT DOES DISPLAY XM CHANNELS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__poor-or-no-sound-with-xm) troubleshooting . If sound quality is poor only with USB mode, go to USB input sound is low or cannot be heard troubleshooting (see «USB INPUT SOUND IS LOW OR CANNOT BE HEARD (WITH PREMIUM AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__usb-input-sound-is-low-or) ). If there is no sound in CD mode, go to Audio disc does not play troubleshooting (see «AUDIO DISC DOES NOT PLAY (WITH ELS AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__audio-disc-does-not-play-with) ).
  4. Turn the ignition switch to LOCK (0).
  5. Disconnect the HandsFreeLink control unit 28P connector.
  6. Turn the ignition switch to ON (II), and recheck the audio system for sound. Did the audio system sound return? YES -Replace the HandsFreeLink control unit (see «HANDSFREELINK CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#handsfreelink-system-4-cyl__handsfreelinktm-control-unit-removalinstallation) ). NO -Go to step 7.
  7. Do the Speaker Check Mode with the Self-Diagnostic Function (see «SPEAKER CHECK MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__speaker-check-mode) ). Do all speakers produce a tone? YES -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -Go to step 8.
  8. Turn the ignition switch to LOCK (0).
  9. Check the No. 15 (20 A) fuse in the passenger's under-dash fuse/relay box. Is the fuse OK? YES -Go to step 10. NO -Replace the fuse, and recheck. If the fuse blows again, check for a short in the No. 15 (20 A) fuse circuit.
  10. Measure the voltage between stereo amplifier connector A (18P) terminal No. 18 and body ground. STEREO AMPLIFIER CONNECTOR A (18P) *1: Sedan *2: Sport Wagon Wire side of female terminals Is there battery voltage? YES -Go to step 11. NO -Repair an open in the wire between the No. 15 (20 A) fuse in the passenger's under-dash fuse/relay box and stereo amplifier connector B (18P) terminal No. 18.
  11. Turn the ignition switch to ON (II).
  12. Measure the voltage between stereo amplifier connector B (24P) terminal No. 24 and body ground. STEREO AMPLIFIER CONNECTOR B (24P) Is there battery voltage? YES -Go to step 13. NO -Repair an open in the wire between the stereo amplifier and the audio unit. If the wire and the pin fits are OK, substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  13. Measure the voltage between stereo amplifier connector A (18P) terminal No. 9 and body ground. STEREO AMPLIFIER CONNECTOR A (18P) Is there less than 0.2 V? YES -Go to step 14. NO -Repair an open or high resistance in the wire between the stereo amplifier connector A (18P) terminal No. 9 and body ground (G651); Sedan (see «RIGHT SIDE WIRE HARNESS (SEDAN)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-4-cyl__right-side-wire-harness-sedan) ), Sport Wagon (see «RIGHT SIDE WIRE HARNESS (SPORT WAGON)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-4-cyl__right-side-wire-harness-sport-wagon) ).
  14. Turn the ignition switch to LOCK (0).
  15. Check the faulty speaker(s) for damage (see «SPEAKER TEST/REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). Is there any damage? YES -Replace the speaker (see «SPEAKER TEST/REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. NO -Go to step 16.
  16. Remove the speaker(s) with no sound (see «SPEAKER TEST/REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and disconnect its connector.
  17. Check the speaker connectors for a loose or poor connection. Reconnect the speaker connector, and recheck the symptom; is the condition still present? YES -Go to step 18. NO -Intermittent failure. Operation is normal.
  18. Test the speaker(s) (see «SPEAKER TEST/REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). Is the speaker OK? YES -Go to step 19. NO -Replace the speaker(s) (see «SPEAKER TEST/REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  19. Reconnect the speaker connector(s).
  20. Disconnect stereo amplifier connector A (18P).
  21. Check for continuity between body ground and stereo amplifier connector A (18P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Speaker Stereo amplifier connector Wire color Driver's door speaker A16(+) BLK A7(-) BLU Driver's door tweeter A17(+) PNK A8(-) PUR Front passenger's door speaker A15(+) RED A6(-) GRN Front passenger's door tweeter A14(+) WHT A5(-) YEL Left rear speaker (1) , Left rear door speaker (2) A13(+) YEL A4(-) BRN Right rear speaker (1) , Right rear door speaker (2) A12(+) BLU A3(-) ORN Subwoofer A10 (+) GRY A1 (-) LT BLU (1) Sedan (2) Sport Wagon STEREO AMPLIFIER CONNECTOR A (18P) Is there continuity? YES -Repair a short to body ground in the wire(s) between the stereo amplifier and the speaker(s). NO -Go to step 22.
  22. Disconnect the driver's door tweeter 2P connector and the front passenger's door tweeter 2P connector.
  23. Measure the resistance between each pair of speaker terminals at stereo amplifier connector A (18P) according to the table. TERMINAL RESISTANCE REFERENCE CHART Speaker Stereo amplifier connector Wire color Resistance Driver's door speaker A16(+) BLK About 4 ohms A7(-) BLU Driver's door tweeter A17(+) PNK About 3.3 ohms A8(-) PUR Front passenger's door speaker A15(+) RED About 4 ohms A6(-) GRN Front passenger's door tweeter A14(+) WHT About 3.3 ohms A5(-) YEL Left rear speaker (1) , Left rear door speaker (2) A13(+) YEL About 4 ohms A4(-) BRN Right rear speaker (1) , Right rear door speaker (2) A12(+) BLU About 4 ohms A3(-) ORN Subwoofer A10(+) GRY About 2 ohms A1 (-) LT BLU (1) Sedan (2) Sport Wagon STEREO AMPLIFIER CONNECTOR A (18P) Is the resistance OK? YES -Go to step 24. NO -Repair an open or a short in the wire(s) between the stereo amplifier and the speaker(s).
  24. Disconnect these items: Audio unit connector A (24P) Audio unit connector D (8P) Stereo amplifier connector B (24P) NOTE: Eject all the disc(s) before disconnecting the audio unit to prevent damaging the CD player's load mechanism.
  25. Check for continuity between audio unit connector A (24P), connector D (8P), and stereo amplifier connector B (24P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio unit connector Stereo amplifier connector A6 (BLU) B7 (BLK) A7 (PNK) B19 (WHT) A8 (GRY) B18 (GRY) A9 (GRY) B15 (GRY) A10 (YEL) B4 (GRN) A11 (BRN) B16 (RED) A18 (RED) B5 (RED) A19 (GRN) B17 (GRN) A20 (GRY) B6 (GRY) A21 (GRY) B3 (GRY) A22 (RED) B2 (WHT) A23 (GRN) B14 (BLK) D6 (RED) B8 (RED) D7 (GRY) B9 (GRY) D8 (GRN) B20 (GRN) AUDIO UNIT CONNECTOR A (24P) AUDIO UNIT CONNECTOR D (8P) STEREO AMPLIFIER CONNECTOR B (24P) Is there continuity? YES -Go to step 26. NO -There is an open in the wire(s) between the stereo amplifier and the audio unit. Replace the affected shielded harness.
  26. Check for continuity between stereo amplifier connector B (24P) and body ground according to the table. TERMINAL CONTINUITY REFERENCE CHART Stereo amplifier connector Wire color B2 WHT B4 GRN B5 RED B6 GRY B7 BLK B8 RED B9 GRY B14 BLK B15 GRY B16 RED B17 GRN B18 GRY B19 WHT B20 GRN STEREO AMPLIFIER CONNECTOR B (24P) Is there continuity? YES -There is a short to body ground in the wire(s) between the stereo amplifier and the audio unit. Replace the affected shielded harness. NO -Substitute a known-good stereo amplifier; Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original stereo amplifier; Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If the symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).

Auxiliary input sound is low or cannot be heard (with ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Use auxiliary stereo cables with 3.5 mm ends only. Auxiliary accessories may be played on the audio unit using the auxiliary input. Check the connectors for poor connections or loose terminals.

Scheme 788

Scheme 788: Auxiliary input sound is low or cannot be heard (with ELS audio)

Scheme 789

Scheme 789

Scheme 790

Scheme 790

Scheme 791

Scheme 791
  1. Turn the ignition switch to ON (II).
  2. Turn on the audio system and connect an auxiliary accessory to the auxiliary input jack.
  3. Check the volume operation. Is the sound normal? YES -Operation is normal at this time. NO -Go to step 4.
  4. Make sure the auxiliary accessory volume is set to high. Is the volume set to high? YES -Go to step 5. NO -Raise the auxiliary accessory volume to high. Make sure the audio-navigation unit volume is turned down before retesting.
  5. Substitute a known-good auxiliary audio accessory and/or auxiliary stereo cable, and recheck. Does the auxiliary audio accessory operate properly? YES -Original auxiliary audio accessory or auxiliary stereo cable is faulty. NO -Go to step 6.
  6. Turn the ignition switch to LOCK (0).
  7. Remove the auxiliary jack assembly (see «AUXILIARY JACK ASSEMBLY REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and check that the auxiliary jack assembly is properly connected. Is the auxiliary jack assembly connected properly? YES -Go to step 8. NO -Reconnect the connector, and recheck the function.
  8. Disconnect the auxiliary jack assembly 5P connector.
  9. Disconnect audio-navigation unit connector B (24P).
  10. Check for continuity between body ground and audio-navigation unit connector B (24P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio-navigation unit connector Wire color B1 RED B2 BLK B3 GRY B13 WHT AUDIO-NAVIGATION UNIT CONNECTOR B (24P) Is there continuity? YES -There is a short to body ground in the wire(s) between the audio-navigation unit and the auxiliary jack assembly. Repair or replace the affected harness. NO -Go to step 11.
  11. Check for continuity between the terminals of audio-navigation unit connector B (24P) according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals B1 (RED) B2 (BLK), B13 (WHT), B15 (GRY) B2 (BLK) B13 (WHT), B15 (GRY) B13 (WHT) B15 (GRY) AUDIO-NAVIGATION UNIT CONNECTOR B (24P) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio-navigation unit and the auxiliary jack assembly. Replace the affected shielded harness. NO -Go to step 12.
  12. Check for continuity between audio-navigation unit connector B (24P) and the auxiliary jack assembly 5P connector according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio-navigation unit connector Auxiliary jack assembly connector Wire color B1 4 RED B2 3 BLK B3 1 GRY B13 5 WHT B14 2 YEL AUDIO-NAVIGATION UNIT CONNECTOR B (24P) AUXILIARY JACK ASSEMBLY 5P CONNECTOR Is there continuity? YES -Substitute a known-good auxiliary jack assembly (see «AUXILIARY JACK ASSEMBLY REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original auxiliary jack assembly (see «AUXILIARY JACK ASSEMBLY REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If the symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -There is an open in the wire(s) between the audio-navigation unit and the auxiliary jack assembly. Repair or replace the affected harness.

Auxiliary input sound is low or cannot be heard (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Use auxiliary stereo cables with 3.5 mm ends only. Auxiliary accessories may be played on the audio unit using the auxiliary input. Check the connectors for poor connections or loose terminals.

Scheme 792

Scheme 792: Auxiliary input sound is low or cannot be heard (with premium audio)

Scheme 793

Scheme 793

Scheme 794

Scheme 794

Scheme 795

Scheme 795
  1. Turn the ignition switch to ON (II).
  2. Turn on the audio system and connect an auxiliary accessory to the auxiliary input jack.
  3. Check the volume operation. Is the sound normal? YES -Operation is normal at this time. NO -Go to step 4.
  4. Make sure the auxiliary accessory volume is set to high. Is the volume set to high? YES -Go to step 5. NO -Raise the auxiliary accessory volume to high. Make sure the audio unit volume is turned down before retesting.
  5. Substitute a known-good auxiliary audio accessory and/or auxiliary stereo cable, and recheck. Does the auxiliary audio accessory operate properly? YES -Original auxiliary audio accessory or auxiliary stereo cable is faulty. NO -Go to step 6.
  6. Turn the ignition switch to LOCK (0).
  7. Remove the auxiliary jack assembly (see «AUXILIARY JACK ASSEMBLY REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and check that the auxiliary jack assembly is properly connected. Is the auxiliary jack assembly connected properly? YES -Go to step 8. NO -Reconnect the connector, and recheck the function.
  8. Disconnect the auxiliary jack assembly 5P connector.
  9. Disconnect audio unit connector B (20P).
  10. Check for continuity between body ground and audio unit connector B (20P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio unit connector Wire color B3 BLK B13 RED B14 WHT B15 GRY AUDIO UNIT CONNECTOR B (20P) Is there continuity? YES -There is a short to body ground in the wire(s) between the audio unit and the auxiliary jack assembly. Repair or replace the affected harness. NO -Go to step 11.
  11. Check for continuity between the terminals of audio unit connector B (20P) according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals B3 (BLK) B4 (GRY), B13 (RED), B14 (WHT) B4 (GRY) B13 (RED), B14 (WHT) B13 (RED) B14 (WHT) AUDIO UNIT CONNECTOR B (20P) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio unit and the auxiliary jack assembly. Replace the affected shielded harness. NO -Go to step 12.
  12. Check for continuity between audio unit connector B (20P) and the auxiliary jack assembly 5P connector according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio unit connector Auxiliary jack assembly connector Wire color B3 3 BLK B5 2 YEL B13 4 RED B14 5 WHT B15 1 GRY AUDIO UNIT CONNECTOR B (20P) AUXILIARY JACK ASSEMBLY 5P CONNECTOR Is there continuity? YES -Substitute a known-good auxiliary jack assembly (see «AUXILIARY JACK ASSEMBLY REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original auxiliary jack assembly (see «AUXILIARY JACK ASSEMBLY REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If the symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -There is an open in the wire(s) between the audio unit and the auxiliary jack assembly. Repair or replace the affected harness.

Audio system sound is weak or distorted (display is normal) (with ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

  1. Turn the ignition switch to ON (II).
  2. Turn on the audio-navigation unit, and check for sound in each mode (AM/FM and CD or DVD). Is there sound from the speakers, and is the sound quality normal in each mode? YES -Intermittent failure, the system is OK at this time. Check for loose connections at the audio unit, the amplifier, and each speaker. NO -Speakers all work, sound quality is poor: If there is no sound in AM/FM mode, go to AM or FM radio reception interference troubleshooting; Sedan (see «POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (SEDAN WITH ELS AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__poor-am-or-fm-radio-reception) ), Sport Wagon (see «POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (SPORT WAGON WITH ELS AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__poor-am-or-fm-radio-reception) ). If there is no sound in CD or DVD mode, go to Audio disc does not play troubleshooting (see «AUDIO DISC DOES NOT PLAY (WITH ELS AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__audio-disc-does-not-play-with) ). If the sound is poor in all modes, go to «SOUND QUALITY DIAGNOSIS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__sound-quality-diagnosis) .

Audio system sound is weak or distorted (display is normal) (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

  1. Turn the ignition switch to ON (ID
  2. Turn on the audio unit, and check for sound in each mode (AM/FM and CD). Is there sound from the speakers, and is the sound quality normal in each mode? YES -Intermittent failure, the system is OK at this time. Check for loose connections at the audio unit, the stereo amplifier, and each speaker. NO -The speakers all work, but the sound quality is poor: If there is no sound in AM/FM mode, go to AM or FM radio reception interference troubleshooting; Sedan (see «POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (SEDAN WITH PREMIUM AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__poor-am-or-fm-radio-reception) ), Sport Wagon (see «POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (SPORT WAGON WITH PREMIUM AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__poor-am-or-fm-radio-reception) ). If there is no sound in CD mode, go to Audio disc does not play troubleshooting (see «AUDIO DISC DOES NOT PLAY (WITH ELS AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__audio-disc-does-not-play-with) ). If the sound is poor in all modes, go to «SOUND QUALITY DIAGNOSIS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__sound-quality-diagnosis) .

Radio preset memory is lost (with ELS audio)

  1. Turn the ignition switch to ON (II).
  2. Turn on the audio system, and set each of the radio station preset buttons. Do each of the buttons set properly? YES -Go to step 3. NO -Substitute a known-good audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If the symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  3. Turn the ignition switch to LOCK (0) for 1 minute, then back to ON (II).
  4. Test the preset buttons for proper recall operation. Do the preset buttons recall the set radio stations? YES -System is OK at this time. Check connections at the audio-navigation unit. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Radio preset memory is lost (with premium audio)

Note. If only XM stations are lost, go to XM RADIO PRESET MEMORY IS LOST TROUBLESHOOTING .

  1. Turn the ignition switch to ON (II).
  2. Turn on the audio unit, and set each of the radio station preset buttons. Do each of the buttons set properly? YES -Go to step 3. NO -Substitute a known-good audio switch panel (see «AUDIO SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio switch panel (see «AUDIO SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If the symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  3. Turn the ignition switch to LOCK (0) for 1 minute, then back to ON (II).
  4. Test the preset buttons for proper recall operation. Do the preset buttons recall the set radio stations? YES -System is OK at this time. Check connections at the audio unit. NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).

Volume does not change (with ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Set the fader and balance positions to the center.

Scheme 796

Scheme 796: Volume does not change (with ELS audio)

Scheme 797

Scheme 797

Scheme 798

Scheme 798

Scheme 799

Scheme 799
  1. Turn the ignition switch to ON (II).
  2. Turn on the audio-navigation unit, and check for sound in each mode (AM/FM and CD or DVD). Is the sound normal? YES -Go to step 3. NO -Go to «SOUND QUALITY DIAGNOSIS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__sound-quality-diagnosis) or «NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__no-sound-is-heard-from-the) .
  3. Operate the volume knob to see if the volume changes. Does the volume change? YES -Operation is normal. NO -Go to step 4.
  4. Turn the ignition switch to LOCK (0).
  5. Disconnect the audio-navigation switch panel 24P connector and audio-navigation unit connector F (12P).
  6. Check for continuity between the audio-navigation switch panel 24P connector and audio-navigation unit connector F (12P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio-navigation switch panel connector Audio-navigation unit connector Wire color 1 F5 GRN 13 F11 BLK AUDIO-NAVIGATION SWITCH PANEL 24P CONNECTOR AUDIO-NAVIGATION UNIT CONNECTOR F (12P) Is there continuity? YES -Go to step 7. NO -There is an open in the wire(s) between the audio-navigation unit and the audio-navigation switch panel. Replace the affected shielded harness.
  7. Check for continuity between audio-navigation unit connector F (12P) and body ground according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio-navigation unit connector Wire color F5 GRN F11 BLK AUDIO-NAVIGATION UNIT CONNECTOR F (12P) Is there continuity? YES -There is a short to body ground in the wire(s) between the audio-navigation unit and the audio-navigation switch panel. Replace the affected shielded harness. NO -Go to step 8.
  8. Check for continuity between the terminals of audio-navigation unit connector F (12P) according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals F4 (GRY) F5 (GRN), F11 (BLK) F5 (GRN) F11 (BLK) AUDIO-NAVIGATION UNIT CONNECTOR F (12P) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio-navigation unit and the audio-navigation switch panel. Replace the affected shielded harness. NO -Substitute a known-good audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If the symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Volume does not change (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Set the fader and the balance positions to the center.

  1. Turn the ignition switch to ON (II).
  2. Turn on the audio unit, and check for sound in each mode (AM/FM and CD). Is the sound normal? YES -Go to step 3. NO -Go to «SOUND QUALITY DIAGNOSIS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__sound-quality-diagnosis) or «NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__no-sound-is-heard-from-the) .
  3. Operate the volume knob to see if the volume changes. Does the volume change? YES -Operation is normal. NO -Substitute a known-good audio switch panel (see «AUDIO SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio switch panel (see «AUDIO SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If the symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).

Volume does not increase with speed (with ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 800

Scheme 800: Volume does not increase with speed (with ELS audio)

Scheme 801

Scheme 801

Scheme 802

Scheme 802
  1. Test-drive the vehicle at highway speeds, and monitor if the volume increases. Does the volume increase? YES -Intermittent failure, the system is OK at this time. NO -Go to step 2.
  2. Verify SVC mode setting in audio-navigation unit sound adjustment set-up. Is the SVC set to off? YES -Change setting to SVC MID, and recheck. NO -Go to step 3.
  3. Do the Self-Diagnostic Function for the vehicle speed pulse indication (see «HOW TO USE THE AUDIO SYSTEM SELF-DIAGNOSTIC FUNCTION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). Does the self-diagnostic function indicate a VSP signal? YES -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Go to step 4.
  4. Turn the ignition switch to lock (0).
  5. Jump the SCS line with the HDS.
  6. Disconnect ECM/PCM connector A (49P).
  7. Turn the ignition switch to ON (II).
  8. Measure the voltage between ECM/PCM connector A (49P) terminal No. 30 and body ground. Is there about 5V? YES -Go to step 10. NO -Go to step 9.
  9. Measure the voltage between the audio-navigation unit connector A (24P) terminal No. 15 and body ground. Is there about 5V? YES -Repair an open or a short in the wire between the audio-navigation unit and the ECM/PCM. • NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) .)
  10. Turn the ignition switch to LOCK (0).
  11. Reconnect ECM/PCM connector A (49P).
  12. Turn the ignition switch to ON (II).
  13. Raise the vehicle on a lift, and rotate the wheels while measuring the voltage between audio-navigation unit connector A (24P) terminal No. 15 and body ground. Does the voltage pulse between 0V and 5V as you rotate the wheels? YES -Substitute a known good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). • NO -Update the ECM/PCM (see «ECM/PCM UPDATE»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-4-cyl__ecmpcm-update) ), if it does not have the latest software, or substitute a known good ECM/PCM (see «ECM/PCM REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-4-cyl__ecmpcm-replacement) ), and recheck.

Volume does not increase with speed (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

  1. Test-drive the vehicle at highway speeds, and monitor if the volume increases. Does the volume increase? YES -Intermittent failure, the system is OK at this time. NO -Go to step 2.
  2. Verify SVC mode setting in audio unit sound adjustment set-up. Is the SVC set to off? YES -Change setting to SVC MID, and recheck. NO -Go to step 3.
  3. Do the Self-Diagnostic Function for the vehicle speed pulse indication (see «HOW TO USE THE AUDIO SYSTEM SELF-DIAGNOSTIC FUNCTION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). Does the self-diagnostic function indicate a VSP signal? YES -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -Check for B-CAN DTCs (communication BUS Line Error) with the HDS and go to the indicated DTC's troubleshooting. If no B-CAN DTCs or communication bus line errors are found, substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).

Volume is too high or too low when driving at freeway speeds (with ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

  1. Test-drive the vehicle at highway speeds, and monitor volume level. Is the volume level too high, or too low? YES -Go to step 2. NO -Intermittent failure, the system is OK at this time.
  2. Change SVC mode setting in sound adjustment set-up to SVC MID, and recheck. Is the volume level still too high or too low? YES -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Improper SVC setting for client's sound taste.

Volume is too high or too low when driving at freeway speeds (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

  1. Test-drive the vehicle at highway speeds, and monitor volume level. Is the volume level too high, or too low? YES -Go to step 2. NO -Intermittent failure, the system is OK at this time.
  2. Change SVC mode setting in sound adjustment set-up to SVC MID, and recheck. Is the volume level still too high or too low? YES -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -Improper SVC setting for client's sound taste.

Radio tuner does not change stations (with ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connection or loose terminals.

Scheme 803

Scheme 803: Radio tuner does not change stations (with ELS audio)

Scheme 804

Scheme 804

Scheme 805

Scheme 805

Scheme 806

Scheme 806
  1. Turn the ignition switch to ON (II).
  2. Turn on the audio system, and check the audio information on the display panel. Does the audio information display properly? YES -Go to step 3. NO -Go to Audio unit power switch will not turn on (No information display and no sound) troubleshooting (see «AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH ELS AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__audio-unit-power-switch-will-not) ).
  3. Operate the TUNE button to see if the radio station changes. Does the radio station change? YES -Intermittent failure, the TUNE button is OK at this time. NO -Go to step 4.
  4. Turn the ignition switch to LOCK (0).
  5. Disconnect the audio-navigation switch panel 24P connector and audio-navigation unit connector F (12P).
  6. Check for continuity between audio-navigation unit connector F (12P) and the audio-navigation switch panel 24P connector according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio-navigation unit connector Audio-navigation switch panel connector Wire color F3 18 RED F9 6 WHT AUDIO-NAVIGATION UNIT CONNECTOR F (12P) AUDIO-NAVIGATION SWITCH PANEL 24P CONNECTOR Is there continuity? YES -Go to step 7. NO -There is an open in the wire(s) between the audio-navigation unit and the audio-navigation switch panel. Replace the affected shielded harness.
  7. Check for continuity between audio-navigation unit connector F (12P) and body ground according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio-navigation unit connector Wire color F3 RED F9 WHT AUDIO-NAVIGATION UNIT CONNECTOR F (12P) Is there continuity? YES -There is a short to body ground in the wire(s) between audio-navigation unit and audio-navigation switch panel. Replace the affected shielded harness. NO -Go to step 8.
  8. Check for continuity between the terminals of audio-navigation unit connector F (12P) according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals F3 (RED) F4 (GRY), F9 (WHT) F4 (GRY) F9 (WHT) AUDIO-NAVIGATION UNIT CONNECTOR F (12P) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio-navigation unit and the audio-navigation switch panel. Replace the affected shielded harness. NO -Substitute a known-good audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If the symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Radio tuner does not change stations (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connection or loose terminals.

  1. Turn the ignition switch to ON (II).
  2. Turn on the audio unit, and check the audio information on the display panel. Does the audio information display properly? YES -Go to step 3. NO -Go to Audio unit power switch will not turn on (No information display and no sound) troubleshooting (see «AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH PREMIUM AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__audio-unit-power-switch-will-not) ).
  3. Operate the SELECTOR knob to see if the radio station changes. Does the radio station change? YES -Intermittent failure, the SELECTOR knob is OK at this time. NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).

Audio system information does not display on the audio-HVAC display unit (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 807

Scheme 807: Audio system information does not display on the audio-HVAC display unit (with premium audio)

Scheme 808

Scheme 808

Scheme 809

Scheme 809

Scheme 810

Scheme 810

Scheme 811

Scheme 811

Scheme 812

Scheme 812
  1. Remove the audio-HVAC display unit (see «AUDIO-HVAC DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  2. Check for connections at audio unit connector B (20P) and the audio-HVAC display unit 12P connector. Are the connectors and terminals connected properly? YES -Go to step 3. NO -Repair the connection, and recheck.
  3. Measure the voltage between audio-HVAC display unit 12P connector terminal No. 6 and body ground. AUDIO-HVAC DISPLAY UNIT 12P CONNECTOR Is there battery voltage? YES -Go to step 4. NO -Repair an open in the wire between the No. 15 (10 A) fuse in the under-hood fuse/relay box and audio-HVAC display unit 12P connector terminal No. 6.
  4. Turn the ignition switch to ON (II).
  5. Measure the voltage between audio-HVAC display unit 12P connector terminal No. 9 and body ground. AUDIO-HVAC DISPLAY UNIT 12P CONNECTOR Is there less than 0.2 V? YES -Go to step 6. NO -Repair an open or high resistance in the wire between audio-HVAC display unit 12P connector terminal No. 9 and body ground (G401) (see «AUDIO WIRE HARNESS (WITH NAVIGATION)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-4-cyl__audio-wire-harness-with-navigation) ).
  6. Turn the ignition switch to LOCK (0).
  7. Disconnect audio unit connector B (20P) and the audio-HVAC display unit 12P connector.
  8. Check for continuity between audio unit connector B (20P) and the audio-HVAC display unit 12P connector according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio unit connector Audio-HVAC display unit connector Wire color B6 2 RED B7 1 GRN B17 4 BLU AUDIO UNIT CONNECTOR B (20P) AUDIO-HVAC DISPLAY UNIT 12P CONNECTOR Is there continuity? YES -Go to step 9. NO -There is an open in the wire(s) between the audio unit and the audio-HVAC display unit. Repair or replace the affected shielded harness.
  9. Check for continuity between audio unit connector B (20P) and body ground according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio unit connector Wire color B6 RED B7 GRN B17 BLU AUDIO UNIT CONNECTOR B (20P) Is there continuity? YES -There is a short to body ground in the wire(s) between the audio unit and the audio-HVAC display unit. Repair or replace the affected shielded harness. NO -Go to step 10.
  10. Check for continuity between the terminals of audio unit connector B (20P) according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals B6 (RED) B7 (GRN), B16 (GRY) B7 (GRN) B16 (GRY) AUDIO UNIT CONNECTOR B (20P) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio unit and the audio-HVAC display unit. Replace the affected shielded harness. NO -Substitute a known-good audio-HVAC display unit (see «AUDIO-HVAC DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio-HVAC display unit (see «AUDIO-HVAC DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If the symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).

Security indicator does not work properly (with ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. The security system operates without the 5-digit security (anti-theft) code. Before troubleshooting, make sure you have the 5-digit security (anti-theft) code.

  1. Turn the ignition switch to ON (II).
  2. Turn off the audio system. Is the security indicator (LED) on (blink)? YES -Go to step 3. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  3. Turn the ignition switch to ON (II).
  4. Turn on the audio system.
  5. Enter the 5-digit security (anti-theft) code. Is the security indicator (LED) off? YES -The audio-navigation unit is OK at this time. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Security indicator does not work properly (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. The security system operates without the 5-digit security (anti-theft) code. Before troubleshooting, make sure you have the 5-digit security (anti-theft) code.

  1. Turn the ignition switch to ON (II).
  2. Turn off the audio unit. Is the security indicator (LED) on (blink)? YES -Go to step 3. NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  3. Turn on the audio unit. Is the security indicator (LED) off? YES -The audio unit is OK at this time. NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  4. Enter the 5-digit security (anti-theft) code. Is the security indicator (LED) off? YES -The audio-navigation unit is OK at this time. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Audio-navigation switch panel button illumination does not work (With ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 813

Scheme 813: Audio-navigation switch panel button illumination does not work (With ELS audio)

Scheme 814

Scheme 814
  1. Turn the ignition switch to ON (II).
  2. Turn the combination lighting switch to the parking light position.
  3. Check the illumination of the audio-navigation switch panel buttons. Are the buttons illuminated? YES -Intermittent failure, the audio-navigation switch panel is OK at this time. Check for loose or poor connections at the audio-navigation switch panel 24P connector. NO -Go to step 4.
  4. Check the illumination of several other buttons not related to the audio system. Are the buttons illuminated? YES -Go to step 5. NO -Troubleshoot the interior lights. Start by checking the No. 6 (7.5 A) fuse in the passenger's under-dash fuse/relay box. If the fuse is OK, check for an open in the wire between passenger's under-dash fuse/relay box and the audio-navigation switch panel.
  5. Turn the ignition switch to LOCK (0).
  6. Disconnect the audio-navigation switch panel 24P connector and the gauge control module 32P connector.
  7. Check for continuity between audio-navigation switch panel 24P connector terminals No. 11 and No. 12 and gauge control module 32P connector terminals No. 3 and No. 2 respectively. Is there continuity? YES -Go to step 8. NO -Repair an open in the wire between the audio-navigation switch panel and the gauge control module.
  8. Turn the ignition switch to ON (II).
  9. With the combination lighting switch in the parking light position, measure the voltage between audio-navigation switch panel 24P connector terminal No. 23 and body ground. AUDIO-NAVIGATION SWITCH PANEL 24P CONNECTOR Is there battery voltage? YES -Check the connections at the audio-navigation switch panel 24P connector. If all connections are OK, substitute a known-good audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -Repair an open in the wire between the passenger's under-dash fuse/relay box and the audio-navigation switch panel.

Audio switch panel button illumination does not work (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 815

Scheme 815: Audio switch panel button illumination does not work (with premium audio)

Scheme 816

Scheme 816
  1. Turn the ignition switch to ON (II).
  2. Turn the combination lighting switch to the parking light position.
  3. Check the illumination of the audio unit buttons. Are the buttons illuminated? YES -Intermittent failure, the audio unit is OK at this time. Check for loose or poor connections at the audio unit connector A (24P). NO -Go to step 4.
  4. Check the illumination of several other buttons not related to the audio system. Are the buttons illuminated? YES -Go to step 5. NO -Troubleshoot the interior lights. Start by checking the No. 6 (7.5 A) fuse in the passenger's under-dash fuse/relay box. If the fuse is OK, check for an open in the wire between the passenger's under-dash fuse/relay box and the audio unit.
  5. Turn the ignition switch to LOCK (0).
  6. Disconnect audio unit connector A (24P). NOTE: Eject all the disc(s) before disconnecting the audio unit to prevent damaging the CD player's load mechanism.
  7. Disconnect the gauge control module 32P connector.
  8. Check for continuity between audio unit connector A (24P) terminal No. 1 and gauge control module 32P connector terminal No. 2. Is there continuity? YES -Go to step 9. NO -Repair an open in the wire between the audio unit and the gauge control module.
  9. Turn the ignition switch to ON (II).
  10. With the combination lighting switch in the parking light position, measure the voltage between audio unit connector A (24P) terminal No. 13 and body ground. AUDIO UNIT CONNECTOR A (24P) Is there battery voltage? YES -Check the connections at audio unit connector A (24P). If all connections are OK, substitute a known-good audio switch panel (see «AUDIO SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio switch panel (see «AUDIO SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If the symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -Repair an open in the wire between the passenger's under-dash fuse/relay box and the audio unit.

Audio remote switch does not work properly (with ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 817

Scheme 817: Audio remote switch does not work properly (with ELS audio)

Scheme 818

Scheme 818
  1. Turn the ignition switch to ON (II).
  2. Turn on the audio system, and check the audio remote switch operation (volume up, volume down, CH (UP), CH (DOWN), MODE). Is the audio unit operation OK? YES -Intermittent failure, the audio remote switch is OK at this time. Check for loose connections. NO -Go to step 3.
  3. Do the Audio Remote Switch Test (see «AUDIO REMOTE SWITCH TEST»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__audio-remote-switch-test) ). Is the audio remote switch OK? YES -Go to step 4. NO -Replace the audio remote switch (see «AUDIO REMOTE SWITCH TEST»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__audio-remote-switch-test) ).
  4. Turn the ignition switch to LOCK (0).
  5. Disconnect audio-navigation unit connector A (24P). NOTE: Eject all the disc(s) before disconnecting the audio-navigation unit to prevent damaging the CD/DVD player's load mechanism.
  6. Reconnect the audio remote switch, and measure the resistance between audio-navigation unit connector A (24P) terminals No. 5 and No. 16 as specified in the table. AUDIO-NAVIGATION UNIT CONNECTOR A (24P) AUDIO REMOTE SWITCH TABLE TERMINAL RESISTANCE REFERENCE CHART Button held down VOL DOWN VOL UP CH (-) CH (+) MODE No button pressed Resistance about 100 ohms about 357 ohms about 775 ohms about 1.7 kohms about 3.7 kohms about 10 kohms Is the resistance OK? YES -Go to step 7. NO -Repair a short or high resistance in the circuit between the audio-navigation unit and the audio remote switch. If the wires are OK, replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl) ).
  7. Disconnect the audio remote switch 12P connector.
  8. Check for continuity between body ground and audio-navigation unit connector A (24P) terminals No. 5 and No. 16 individually. AUDIO-NAVIGATION UNIT CONNECTOR A (24P) Is there continuity? YES -Repair a short to body ground in the circuit between the audio-navigation unit and the audio remote switch. If the wires are OK, replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl) ). NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Audio remote switch does not work properly (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 819

Scheme 819: Audio remote switch does not work properly (with premium audio)

Scheme 820

Scheme 820
  1. Turn the ignition switch to ON (II).
  2. Turn on the audio unit, and check the audio remote switch operation (volume up, volume down, CH (UP), CH (DOWN), MODE). Is the audio unit operation OK? YES -Intermittent failure, the audio remote switch is OK at this time. Check for loose connections. NO -Go to step 3.
  3. Do the Audio Remote Switch Test (see «AUDIO REMOTE SWITCH TEST»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__audio-remote-switch-test) ). Is the audio remote switch OK? YES -Go to step 4. NO -Replace the audio remote switch (see «AUDIO REMOTE SWITCH TEST»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__audio-remote-switch-test) ).
  4. Turn the ignition switch to LOCK (0).
  5. Disconnect audio unit connector A (24P). NOTE: Eject all the disc(s) before disconnecting the audio unit to prevent damaging the CD player's load mechanism.
  6. Reconnect the audio remote switch, and measure the resistance between audio unit connector A (24P) terminals No. 5 and No. 16 as specified in the table. AUDIO UNIT CONNECTOR A (24P) AUDIO REMOTE SWITCH TABLE TERMINAL RESISTANCE REFERENCE CHART Button held down VOL DOWN VOL UP CH (-) CH (+) MODE No button pressed Resistance about 100 ohms about 357 ohms about 775 ohms about 1.7 kohms about 3.7 kohms about 10 kohms Is the resistance OK? YES -Go to step 7. NO -Repair a short or high resistance in the circuit between the audio unit and the audio remote switch. If the wires are OK, replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl) ).
  7. Disconnect the audio remote switch 12P connector.
  8. Check for continuity between body ground and audio unit connector A (24P) terminals No. 5 and No. 16 individually. AUDIO UNIT CONNECTOR A (24P) Is there continuity? YES -Repair a short to body ground in the circuit between the audio unit and the audio remote switch. If the wires are OK, replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl) ). NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).

Audio disc does not load (with ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Disc labels should not be used in the audio-navigation unit. They may jam and damage the player mechanism. Make sure the audio disc is compatible with the system (see Owner's Manual for more information).

  1. Turn the ignition switch to ON (II).
  2. Insert a known-good disc to see if the symptom can be duplicated. Does the disc load? YES -Operation is normal. If the disc loads normally, but will not play, go to Audio disc does not play troubleshooting (see «AUDIO DISC DOES NOT PLAY (WITH ELS AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__audio-disc-does-not-play-with) ). NO -Go to step 3.
  3. Insert another disc. Does the disc load? YES -The original disc is faulty. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Audio disc does not load (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Disc labels should not be used in the audio unit. They may jam and damage the player mechanism. Make sure the audio disc is compatible with the system (see Owner's Manual for more information).

  1. Turn the ignition switch to ON (II).
  2. Insert a known-good disc to see if the symptom can be duplicated. Does the disc load? YES -Operation is normal. If the disc loads normally, but will not play, go to Audio disc does not play troubleshooting (see «AUDIO DISC DOES NOT PLAY (WITH ELS AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__audio-disc-does-not-play-with) ). NO -Go to step 3.
  3. Insert another disc. Does the disc load? YES -The original disc is faulty. NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).

Audio disc does not eject (with ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Disc labels should not be used in the audio-navigation unit. They may jam and damage the player mechanism. Check the connectors for poor connections or loose terminals.

  1. Turn the ignition switch to ON (II).
  2. Turn on the audio system. Does the system turn on? YES -Go to step 3. NO -Go to Audio unit power switch will not turn on (No information display and no sound) troubleshooting (see «AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH ELS AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__audio-unit-power-switch-will-not) ).
  3. Check to see if the disc ejects correctly with no binding when you push the EJECT button. Does the disc eject properly? YES -Operation is normal. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Audio disc does not eject (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Disc labels should not be used in the audio unit. They may jam and damage the player mechanism. Check the connectors for poor connections or loose terminals.

  1. Turn the ignition switch to ON (II).
  2. Turn on the audio unit. Does the system turn on? YES -Go to step 3. NO -Go to Audio unit power switch will not turn on (No information display and no sound) troubleshooting (see «AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH PREMIUM AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__audio-unit-power-switch-will-not) ).
  3. Check to see if the disc ejects correctly with no binding when you push the EJECT button. Does the disc eject properly? YES -Operation is normal. NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).

Special Tools Required

Diagnostic CD 07AAZ-SDBA100

Audio disc does not play (with ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Disc labels should not be used in the audio-navigation unit. They may jam and damage the player mechanism.

  1. Turn the ignition switch to ON (II).
  2. Insert a disc into the audio-navigation unit. Does the disc load? YES -Go to step 3. NO -Go to Audio disc does not load troubleshooting (see «AUDIO DISC DOES NOT LOAD (WITH ELS AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__audio-disc-does-not-load-with) ).
  3. Insert a known-good disc to see if the symptom can be duplicated. Does the disc play? YES -Operation is normal. NO -Go to step 4.
  4. Insert audio diagnostic CD (T/N 07AAZ-SDBA100) in the audio-navigation unit. Does the disc play? YES -The original disc is faulty or has an unreadable format. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Special Tools Required

Diagnostic CD 07AAZ-SDBA100

Audio disc does not play (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Disc labels should not be used in the audio unit. They may jam and damage the player mechanism.

  1. Turn the ignition switch to ON (II).
  2. Insert a disc into the audio unit. Does the disc load? YES -Go to step 3. NO -Go to «AUDIO DISC DOES NOT LOAD TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__audio-disc-does-not-load-with) .
  3. Insert a known-good disc to see if the symptom can be duplicated. Does the disc play? YES -Operation is normal. NO -Go to step 4.
  4. Insert audio diagnostic CD (T/N 07AAZ-SDBA100) in the audio unit. Does the disc play? YES -The original disc is faulty or has an unreadable format. NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).

Special Tools Required

  1. Diagnostic CD 07AAZ-SDBA100
  2. Skip Test CD 07AAZ-SDBA200
  3. Skip Test CD 07AAZ-SDBA300

Audio disc skips (with ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Disc labels should not be used in the audio-navigation unit. They may jam and damage the player mechanism.

  1. Confirm the vehicles tires are properly inflated.
  2. Check the client's disc for scratches and fingerprints. NOTE: The following test should be done with the audio system bass and treble set to the client's listening settings. When comparing to known-good vehicles, do the comparison on the same model and trim level.
  3. Test-drive the vehicle to identify when the client's disc skips. The audio diagnostic CD (T/N 07AAZ-SDBA100) can be used if the client's CD is not available; use tracks 10-12. Does the disc skip? YES -Go to step 4. NO -Operation is normal.
  4. Compare the client's CD that skips to a known-good vehicle under the same conditions. Does the disc skip in the known-good vehicle under the same conditions? YES -The disc player operation is normal, the problem is with the client's disc. NO -Go to step 5. NOTE: Do the following test with vehicle parked and the engine running.
  5. Insert the diagnostic skip test CD (T/N 07AAZ-SDBA300). Play tracks 2-11, and note on which track number(s) the disc starts skipping. Do the same test on a known-good vehicle. Does the disc skip on the same track(s) as the known-good vehicle? YES -Operation is normal. NO -Go to step 6.
  6. Insert the diagnostic skip test CD (T/N 07AAZ-SDBA200). Play tracks 7-11 and tracks 13-15, and note on which track number(s) the disc starts skipping. Do the same test on a known-good vehicle. Does the disc skip on the same track number(s) as the known-good vehicle? YES -Operation is normal. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Special Tools Required

  1. Diagnostic CD 07AAZ-SDBA100
  2. Skip Test CD 07AAZ-SDBA200
  3. Skip Test CD 07AAZ-SDBA300

Audio disc skips (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Disc labels should not be used in the audio unit. They may jam and damage the player mechanism.

  1. Confirm the vehicles tires are properly inflated.
  2. Check the client's disc for scratches and fingerprints. NOTE: The following test should be done with the audio system bass and treble set to the client's listening settings. When comparing to known-good vehicles, do the comparison on the same model and trim level.
  3. Test-drive the vehicle to identify when the client's disc skips. The audio diagnostic CD (T/N 07AAZ-SDBA100) can be used if the client's CD is not available; use tracks 10-12. Does the disc skip? YES -Go to step 4. NO -Operation is normal.
  4. Compare the client's CD that skips to a known-good vehicle under the same conditions. Does the disc skip in the known-good vehicle under the same conditions? YES -The disc player operation is normal, the problem is with the client's disc. NO -Go to step 5. NOTE: Do the following test with vehicle parked and the engine running.
  5. Insert the diagnostic skip test CD (T/N 07AAZ-SDBA300). Play tracks 2-11, and note on which track number(s) the disc starts skipping. Do the same test on a known-good vehicle. Does the disc skip on the same track(s) as the known-good vehicle? YES -Operation is normal. NO -Go to step 6.
  6. Insert the diagnostic skip test CD (T/N 07AAZ-SDBA200). Play tracks 7-11 and tracks 13-15, and note on which track number(s) the disc starts skipping. Do the same test on a known-good vehicle. Does the disc skip on the same track number(s) as the known-good vehicle? YES -Operation is normal. NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).

Audio system button does not work (with ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. In order to troubleshoot the POWER (Circle w/Line Out Of Top ) button, go to Audio unit power switch will not turn on (No information display and no sound) troubleshooting (see AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH ELS AUDIO) ). In order to troubleshoot the VOLUME knob, go to VOLUME DOES NOT CHANGE TROUBLESHOOTING .

  1. Go to the audio button and knob detection mode in the Self-Diagnostic Function (see «HOW TO USE THE AUDIO SYSTEM SELF-DIAGNOSTIC FUNCTION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  2. Operate all items in the switch list. Switch list SWITCH REFERENCE CHART Button name FM/AM SKIP (2 Arrows Right then verticle line) XM SKIP (verticle line then 2 Arrows Left) TITLE CATEGORY+ Music Note/Speaker (SOUND) CATEGORY- DISC/HDD TUNE UP AUX TUNE DOWN Preset buttons (1-6) SCAN VOLUME (UP/DOWN) A.SEL Do all the items in the switch list work properly? YES -Operation is normal. NO -Substitute a known-good audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If the symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Audio unit button does not work (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. In order to troubleshoot the POWER (Circle w/Line Out Of Top ) button, go to Audio unit power switch will not turn on (No information display and no sound) troubleshooting (see AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH PREMIUM AUDIO) ).

  1. Go to the audio button and knob detection mode in the Self-Diagnostic Function (see «HOW TO USE THE AUDIO SYSTEM SELF-DIAGNOSTIC FUNCTION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  2. Operate all items in the switch list. Switch list SWITCH REFERENCE CHART Button name TITLE SKIP (2 Arrows Right then verticle line) FM SKIP (verticle line then 2 Arrows Left) AM CATEGORY+ XM CATEGORY- CD RETURN AUX MENU CLOCK SEL PUSH ENTER Preset buttons (1-6) SCAN VOLUME (UP/DOWN) A.SEL Do all the items in the switch list work properly? YES -Operation is normal. NO -Substitute a known-good audio switch panel (see «AUDIO SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio switch panel (see «AUDIO SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If the symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).

Audio unit disc indicator does not work (with ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Discs with labels should not be used in the audio-navigation unit. They may jam and damage the player mechanism.

  1. Turn the ignition switch to ON (II).
  2. Turn on the audio system.
  3. Insert a known-good disc or press the EJECT button. Is the DISC indicator (LED) indicated? YES -The audio-navigation unit is OK at this time. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Audio unit disc indicator does not work (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Discs with labels should not be used in the audio unit. They may jam and damage the player mechanism.

  1. Turn the ignition switch to ON (II).
  2. Turn on the audio unit.
  3. Insert a known-good disc or press the EJECT button. Is the DISC indicator (LED) indicated? YES -The audio unit is OK at this time. NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).

USB device does not function (with ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Check the USB device requirement: Mass-storage class ready digital audio player with USB 2.0 port More than 256 MB of RAM Support MP3, WMA, and AAC (encoded with the iTunes) files, DRM files are not supported Not all players and player functions work with the USB adapter. Please see the Owner's Manual for more information. Always test the customers USB device in a known-good vehicle of the same year and trim (if possible). Technologies change and are updated frequently which may result that USB devices may work in newer vehicles, but not in order vehicles of the same model. If UNSUPPORTED appears on the display, the vehicle is OK, there is a software problem with the USB device.

Scheme 821

Scheme 821: USB device does not function (with ELS audio)

Scheme 822

Scheme 822
  1. Turn the ignition switch to ON (II).
  2. Turn on the audio system.
  3. Press the AUX button, and check if it changes to USB mode. NOTE: Do not connect the USB device. Is USB NO DATA displayed in the audio display? YES -Go to step 4. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  4. Turn the ignition switch to LOCK (0).
  5. Connect the client's USB device to a known-good vehicle (same year/trim) that is equipped with a USB adapter, and check the USB device operation. Is the USB device working properly in the known-good vehicle? YES -Go to step 6. NO -If the audio display displays UNSUPPORTED or MEDIA ERROR, the USB device may not be supported or is defective. If the audio display displays USB NO MUSIC, the USB device may have no music files or wrong type music files are on the device. See the Owner's Manual for details on USB device requirements and approved file types.
  6. On the client's vehicle, connect the customer's USB device to the USB port.
  7. Turn the ignition switch to ON (II).
  8. Turn on the audio system.
  9. Check the USB device operation in the client's vehicle. Does the USB device work properly in the client's vehicle? YES -The system is OK at this time. Inspect the connectors of the USB device, USB port and USB adapter for wear. Go to step 10.
  10. Turn the ignition switch to LOCK (0).
  11. On the client's vehicle, remove the USB device.
  12. Disconnect audio-navigation unit connector K (7P).
  13. Check for continuity between audio-navigation unit connector K (7P) and the USB port 5P connector according to the image below. Is there continuity? YES -Substitute a known good audio-navigation unit (including HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -Go to step 14.
  14. Disconnect the USB adapter 5P connector.
  15. Check for continuity between the USB adapter 5P connector and the USB port 5P connector according to the image below.

USB device does not function (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Check the USB device requirement: Mass-storage class ready digital audio player with USB 2.0 port More than 256 MB of RAM Support MP3, WMA, and AAC (encoded with the iTunes) files, DRM files are not supported Not all players and player functions work with the USB adapter. Please see the Owner's Manual for more information. Always test the customers USB device in a known-good vehicle of the same year and trim (if possible). Technologies change and are updated frequently which may result that USB devices may work in newer vehicles, but not in order vehicles of the same model. If UNSUPPORTED appears on the display, the vehicle is OK, there is a software problem with the USB device.

Scheme 823

Scheme 823: USB device does not function (with premium audio)

Scheme 824

Scheme 824

Scheme 825

Scheme 825

Scheme 826

Scheme 826

Scheme 827

Scheme 827

Scheme 828

Scheme 828

Scheme 829

Scheme 829

Scheme 830

Scheme 830

Scheme 831

Scheme 831

Scheme 832

Scheme 832

Scheme 833

Scheme 833

Scheme 834

Scheme 834

Scheme 835

Scheme 835
  1. Turn the ignition switch to ON (II).
  2. Turn on the audio unit.
  3. Press the AUX button to select USB mode. NOTE: Do not connect the USB device. Is USB NO DATA displayed in the audio display? YES -Go to step 4. NO -Go to step 16 .
  4. Turn the ignition switch to LOCK (0).
  5. Connect the client's USB device to a known-good vehicle (same year/trim) that is equipped with a USB adapter, and check the USB device operation. Is the USB device working properly in the known-good vehicle? YES -Go to step 6. NO -If the audio display displays UNSUPPORTED or MEDIA ERROR, the USB device may not be unsupported or is defective. If the audio display displays USB NO MUSIC, the USB device may have no music files or wrong type music files are on the device. See the Owner's Manual for details on USB device requirements and approved file types.
  6. On the client's vehicle, connect the client's USB device to the USB port.
  7. Turn the ignition switch to ON (II).
  8. Turn on the audio unit.
  9. Check the USB device operation in the client's vehicle. Does the USB device work properly in the client's vehicle? YES -The system is OK at this time. Inspect the connectors of the USB device, USB port and USB adapter for wear. NO -Go to step 10.
  10. Turn the ignition switch to LOCK (0).
  11. On the client's vehicle, remove the USB device.
  12. Disconnect USB adapter control unit connector B (5P).
  13. Check for continuity between USB adapter control unit connector B (5P) and the USB port 5P connector according to the table. TERMINAL CONTINUITY REFERENCE CHART USB adapter control unit connector USB port connector B1 4 B2 3 B3 2 B4 1 B5 5 USB ADAPTER CONTROL UNIT CONNECTOR B (5P) USB PORT 5P CONNECTOR Is there continuity? YES -Replace the USB adapter control unit (see «USB ADAPTER CONTROL UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), then recheck. NO -Go to step 14.
  14. Disconnect the USB adapter 5P connector.
  15. Check for continuity between the USB adapter 5P connector and the USB port 5P connector according to the table. TERMINAL CONTINUITY REFERENCE CHART USB adapter connector USB port connector 1 4 2 3 3 2 4 1 5 5 USB ADAPTER 5P CONNECTOR USB PORT 5P CONNECTOR Is there continuity? YES -There is an open in the wire(s) between the USB adapter control unit and the USB adapter. Replace the affected shielded harness. NO -Replace the USB adapter, then recheck.
  16. Turn the ignition switch to LOCK (0).
  17. Measure the voltage between USB adapter control unit connector A (14P) terminal No. 1 and body ground. USB ADAPTER CONTROL UNIT CONNECTOR A (14P) Is there battery voltage? YES -Go to step 19 . NO -Go to step 18.
  18. Measure the voltage between audio unit connector E (14P) terminal No. 1 and body ground. AUDIO UNIT CONNECTOR E (14P) Is there battery voltage? YES -Repair an open or high resistance in the wire between the USB adapter control unit connector A (14P) terminal No. 1 and audio unit connector E (14P) terminal No. 1. NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  19. Turn the ignition switch to ON (II).
  20. Measure the voltage between USB adapter control unit connector A (14P) terminal No. 11 and body ground. USB ADAPTER CONTROL UNIT CONNECTOR A (14P) Is there less than 0.2 V? YES -Go to step 21. NO -Repair an open or high resistance in the wire between USB adapter control unit connector A (14P) terminal No. 11 and audio unit connector E (14P) terminal No. 11.
  21. Turn the ignition switch to LOCK (0).
  22. Disconnect these items: Audio unit connector E (14P) USB adapter control unit connector A (14P) XM receiver connector A (14P)
  23. Check for continuity between USB adapter control unit connector A (14P) terminal No. 2 and body ground. USB ADAPTER CONTROL UNIT CONNECTOR A (14P) Is there continuity? YES -Repair a short to body ground in the wire between USB adapter control unit connector A (14P) terminal No. 2 and audio unit connector E (14P) terminal No. 2. NO -Go to step 24.
  24. Check for continuity between audio unit connector E (14P) terminal No. 2 and USB adapter control unit connector A (14P) terminal No. 2. Is there continuity? YES -Go to step 25. NO -Repair an open in the wire between audio unit connector E (14P) terminal No. 2 and USB adapter control unit connector A (14P) terminal No. 2.
  25. Check for continuity between USB adapter control unit connector A (14P) and audio unit connector E (14P) according to the table. TERMINAL CONTINUITY REFERENCE CHART USB adapter control unit connector Audio unit connector Wire color A9 E9 RED A10 E10 GRN USB ADAPTER CONTROL UNIT CONNECTOR A (14P) AUDIO UNIT CONNECTOR E (14P) Is there continuity? YES -Go to step 26. NO -There is an open in the wire(s) between the audio unit and the USB adapter control unit. Replace the affected shielded harness.
  26. Disconnect the HandsFreeLink control unit 28P connector.
  27. Check for continuity between body ground and audio unit connector E (14P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio unit connector Wire color E9 RED E10 GRN AUDIO UNIT CONNECTOR E (14P) Is there continuity? YES -There is a short to body ground in the wire(s) between the audio unit and the USB adapter control unit. Replace the affected shielded harness. NO -Go to step 28.
  28. Check for continuity between the terminals of audio unit connector E (14P) according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals E3 (GRY) E9 (RED), E10 (GRN) E9 (RED) E10 (GRN) AUDIO UNIT CONNECTOR E (14P) Is there continuity between any of the terminals? YES -There is a short in the wires between the USB adapter control unit and the audio unit. Replace the affected shielded harness. NO -Substitute a known-good USB adapter control unit (see «USB ADAPTER CONTROL UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original USB adapter control unit (see «USB ADAPTER CONTROL UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If the symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  29. Reconnect these items: Audio unit connector E (14P) HandsFreeLink control unit 28P connector XM receiver connector A (14P)
  30. Turn the ignition switch to ON (II).
  31. Turn on the audio unit.
  32. Press the AUX button several times Is the display changed to other mode? YES -Replace the USB adapter control unit (see «USB Adapter Control Unit Replacement»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -Go to step 33.
  33. Turn the ignition switch to LOCK (0).
  34. Disconnect XM receiver connector A (14P).
  35. Turn the ignition switch to ON (II).
  36. Turn on the audio unit.
  37. Press the AUX button several times. Is the display changed to other mode? YES -Replace the XM receiver (see «XM Receiver Removal/Installation»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -Go to step 38
  38. Turn the ignition switch to LOCK (0).
  39. Reconnect XM receiver connector A (14P).
  40. Disconnect the HandsFreeLink control unit 28P connector.
  41. Turn the ignition switch to ON (II).
  42. Turn on the audio unit.
  43. Press the AUX button several times. Is the display changed to other mode? YES -Replace the HandsFreeLink control unit (see «HANDSFREELINK CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#handsfreelink-system-4-cyl__handsfreelinktm-control-unit-removalinstallation) ). NO -Replace the audio unit (see «Audio Unit Removal/Installation»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).

USB input sound is low or cannot be heard (with ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Not all players and player functions work with the USB adapter. Please see the Owner's Manual for more information. Always test the clients USB device in a known-good vehicle of the same year and trim (if possible). Technologies change and are updated frequently which may result in that USB devices may work in newer vehicles, but not in older vehicles of the same model.

  1. Turn the ignition switch to ON (II).
  2. Do the Speaker Check Mode with the Self-Diagnostic Mode (see «SPEAKER CHECK MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__speaker-check-mode) ). Do all speakers make a sound? YES -Go to step 3. NO -Go to No sound is heard from the speaker(s) (display is normal) troubleshooting (see «NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) (WITH ELS AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__no-sound-is-heard-from-the) ).
  3. Turn the ignition switch to LOCK (0).
  4. On the client's vehicle, connect the client's USB device to the USB port.
  5. Turn the ignition switch to ON (II).
  6. Turn on the audio system.
  7. Press the AUX button until USB appears on the audio display.
  8. Check if the USB device can be operated with the audio-navigation unit (Folders or Files UP/DOWN, etc.). Can you operate the USB device, but there is no sound heard? YES -Go to step 9. NO -If the sound is normal, the USB device is OK at this time. If the USB device cannot be operated, go to USB device does not function troubleshooting (see «USB DEVICE DOES NOT FUNCTION (WITH ELS AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__usb-device-does-not-function-with) ).
  9. Turn the ignition switch to LOCK (0).
  10. Connect the client's USB device to a known-good vehicle (same year/trim) that is equipped with a USB adapter, and check the USB device operation. Is the USB device working properly in the known-good vehicle? YES -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). NO -USB device is faulty or not compatible. Also check the USB adapter and USB adapter connector condition.

USB input sound is low or cannot be heard (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. Not all players and player functions work with the USB adapter. Please see the Owner's Manual for more information.

Scheme 836

Scheme 836: USB input sound is low or cannot be heard (with premium audio)

Scheme 837

Scheme 837

Scheme 838

Scheme 838

Scheme 839

Scheme 839

Scheme 840

Scheme 840

Scheme 841

Scheme 841

Scheme 842

Scheme 842
  1. Turn the ignition switch to ON (II).
  2. Do the Speaker Check Mode with the Self-Diagnostic Mode (see «SPEAKER CHECK MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__speaker-check-mode) ). Do all speakers make a sound? YES -Go to step 3. NO -Go to No sound is heard from the speaker(s) (display is normal) troubleshooting (see «NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) (WITH PREMIUM AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__no-sound-is-heard-from-the) ).
  3. Turn the ignition switch to LOCK (0).
  4. On the client's vehicle, connect the client's USB device to the USB port.
  5. Turn the ignition switch to ON (II).
  6. Turn on the audio unit.
  7. Press the AUX button until USB appears on the audio display.
  8. Check if the USB device can be operated with the audio unit (Folders or Files UP/DOWN, etc.). Can you operate the USB device, but there is no sound heard? YES -Go to step 9. NO -If the sound is normal, the USB device is OK at this time. If the USB device cannot be operated, go to «USB DEVICE DOES NOT FUNCTION TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__usb-device-does-not-function-with) .
  9. Turn the ignition switch to LOCK (0).
  10. Connect the client's USB device to a known-good vehicle (same year/trim) that is equipped with a USB adapter, and check the USB device operation. Is the USB device working properly in the known-good vehicle? YES -Go to step 11. NO -USB device is faulty. Also check the USB adapter and USB adapter connector condition.
  11. Return to the client's vehicle.
  12. Turn the ignition switch to ON (II).
  13. Turn on the audio unit, and check for sound in each mode (XM and Bluetooth audio). Is the sound normal? YES -Go to step 14. NO -Go to XM or HFL troubleshooting.
  14. Turn the ignition switch to LOCK (0).
  15. Measure the voltage between USB adapter control unit connector A (14P) terminal No. 1 and body ground. USB ADAPTER CONTROL UNIT CONNECTOR A (14P) Is there battery voltage? YES -Go to step 17 . NO -Go to step 16.
  16. Measure the voltage between audio unit connector E (14P) terminal No. 1 and body ground. AUDIO UNIT CONNECTOR E (14P) Is there battery voltage? YES -Repair an open or high resistance in the wire between the USB adapter control unit connector A (14P) terminal No. 1 and audio unit connector E (14P) terminal No. 1. NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  17. Turn the ignition switch to ON (II).
  18. Measure the voltage between USB adapter control unit connector A (14P) terminal No. 11 and body ground. USB ADAPTER CONTROL UNIT CONNECTOR A (14P) Is there less than 0.2 V? YES -Go to step 19. NO -Repair an open or high resistance in the wire between USB adapter control unit connector A (14P) terminal No. 11 and audio unit connector E (14P) terminal No. 11.
  19. Turn the ignition switch to LOCK (0).
  20. Disconnect these items: Audio unit connector E (14P) USB adapter control unit connector A (14P) XM receiver connector A (14P)
  21. Check for continuity between USB adapter control unit connector A (14P) terminal No. 2 and body ground. USB ADAPTER CONTROL UNIT CONNECTOR A (14P) Is there continuity? YES -Repair a short to body ground in the wire between USB adapter control unit connector A (14P) terminal No. 2 and audio unit connector E (14P) terminal No. 2. NO -Go to step 22.
  22. Check for continuity between audio unit connector E (14P) terminal No. 2 and USB adapter control unit connector A (14P) terminal No. 2. Is there continuity? YES -Go to step 23. NO -Repair an open in the wire between audio unit connector E (14P) terminal No. 2 and USB adapter control unit connector A (14P) terminal No. 2.
  23. Check for continuity between audio unit connector E (14P) and USB adapter control unit connector A (14P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio unit connector USB adapter control unit connector Wire color E5 A5 GRN E6 A6 BLK E13 A13 WHT E14 A14 RED AUDIO UNIT CONNECTOR E (14P) USB ADAPTER CONTROL UNIT CONNECTOR A (14P) Is there continuity? YES -Substitute a known-good USB adapter control unit (see «USB ADAPTER CONTROL UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), then reconnect all of the connectors, and recheck. If the symptom/indication goes away, replace the original USB adapter control unit (see «USB ADAPTER CONTROL UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If the symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -There is an open in the wire(s) between the audio unit and the USB adapter control unit. Replace the affected shielded harness.

Error code: XM NO SIGNAL or XM LOADING is displayed (with ELS audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connection or loose terminals. Check for other error codes (see ERROR CODES ), and check the XM Antenna Signal Reception Level (see XM SIGNAL RECEPTION LEVEL INDICATION MODE ).

  1. Park the vehicle outside with a clear view of the southern horizon.
  2. Turn the ignition switch to ON (II).
  3. Check for other XM error codes. Are there other XM error codes displayed? YES -Go to «ERROR CODES»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__error-codes) . NO -Go to step 4.
  4. Turn on the audio system, and press the XM button to select the XM radio. Does the XM radio receive a signal? YES -Reception interference operation is normal. NO -Go to step 5.
  5. Turn the ignition switch to LOCK (0).
  6. Check the XM antenna lead connection at the XM antenna or AM/FM/XM antenna 2P connector and AcuraLink control unit (XM receiver) connector B (2P) or XM receiver connector B (2P). Are the connectors connected? YES -Go to step 7. NO -Reconnect the XM antenna or AM/FM/XM antenna 2P connector and AcuraLink control unit (XM receiver) or XM receiver connector B (2P), and recheck XM radio operation. If the signal is restored, the system is OK. If the signal is not restored, go to step 7.
  7. Substitute a known-good XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ) or AM/FM/XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). Does the XM radio receive a signal? YES -Replace the original XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ) or AM/FM/XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO - With AcuraLink: Substitute a known-good XM antenna lead, and recheck. If the AcuraLink control unit (XM receiver) receives a signal, replace the original XM antenna lead. If the AcuraLink control unit (XM receiver) does not receive a signal, replace the AcuraLink control unit (XM receiver); Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). Without AcuraLink: Substitute a known-good XM antenna lead, and recheck. If the XM receiver receives signal, replace the original XM antenna lead. If the XM receiver does not receive signal, replace the XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).

Error code: XM NO SIGNAL or XM LOADING is displayed (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connection or loose terminals. Check for other error codes (see ERROR CODES ), and check the XM Antenna Signal Reception Level (see XM SIGNAL RECEPTION LEVEL INDICATION MODE ).

  1. Park the vehicle outside with a clear view of the southern horizon.
  2. Turn the ignition switch to ON (II).
  3. Check for other XM error codes. Are there other XM error codes displayed? YES -Go to «ERROR CODES»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__error-codes) . NO -Go to step 4.
  4. Turn on the audio unit, and press the XM button to select the XM radio. Does the XM radio receive a signal? YES -Reception interference operation is normal. NO -Go to step 5.
  5. Turn the ignition switch to LOCK (0).
  6. Check the XM antenna lead connection at the XM antenna or AM/FM/XM antenna 2P connector and XM receiver connector B (2P). Are the connectors connected? YES -Go to step 7. NO -Reconnect the XM antenna or AM/FM/XM antenna 2P connector and XM receiver connector B (2P), and recheck XM radio operation. If the signal is restored, the system is OK. If the signal is not restored, go to step 7.
  7. Substitute a known-good XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ) or AM/FM/XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). Does the XM radio receive a signal? YES -Replace the original XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ) or AM/FM/XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -Substitute a known-good XM antenna lead, and recheck. If the XM receiver receives signal, replace the original XM antenna lead. If the XM receiver does not receive a signal, replace the XM receiver; Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connection or loose terminals. If you replace the AcuraLink control unit (XM receiver), the AcuraLink must be reactivated by Acura Client Services. Check for other error codes (see ERROR CODES ), and check the XM Antenna Signal Reception Level (see XM SIGNAL RECEPTION LEVEL INDICATION MODE ).

  1. Check the connectors at the AcuraLink control unit (XM receiver). Are the connectors connected? YES -Go to step 2. NO -Reconnect the connector(s), and recheck. If the error message does not go away, go to step 2.
  2. Check the XM antenna or AM/FM/XM antenna 2P connector. Is the connector connected? YES -Go to step 3. NO -Reconnect the connector, and recheck. If the error message does not go away, go to step 6 .
  3. Turn the ignition switch to ON (II).
  4. Check for other XM error codes. Are there other XM error codes displayed? YES -Go to «ERROR CODES»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__error-codes) . NO -Go to step 5.
  5. Turn the ignition switch to LOCK (0).
  6. Substitute a known-good XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ) or AM/FM/XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck the error code. Is the error message gone? YES -Replace the original XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ) or AM/FM/XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -Go to step 7.
  7. Substitute a known-good AcuraLink control unit (XM receiver); Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck the error code. Is the error message gone? YES -Update the AcuraLink control unit (see «ACURALINK CONTROL UNIT UPDATE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#acuralink-4-cyl__acuralinktm-control-unit-update) ). if it does not have the latest software, then recheck. If the software is the latest, substitute a known-good XM antenna lead, and recheck. If the AcuraLink control unit (XM receiver) receives a signal, replace the original XM antenna lead. If the symptom/indication is still present, replace the original AcuraLink control unit (XM receiver); Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -Replace the XM antenna lead.

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connection or loose terminals. Check for other error codes (see ERROR CODES ), and check the XM Antenna Signal Reception Level (see XM SIGNAL RECEPTION LEVEL INDICATION MODE ).

  1. Check the connectors at the XM receiver. Are the connectors connected? YES -Go to step 2. NO -Reconnect the connector(s), and recheck. If the error message does not go away, go to step 2.
  2. Check the XM antenna or AM/FM/XM antenna 2P connector. Is the connector connected? YES -Go to step 3. NO -Reconnect the connector, and recheck. If the error message does not go away, go to step 6 .
  3. Turn the ignition switch to ON (II).
  4. Check for other XM error codes. Are there other XM error codes displayed? YES -Go to «ERROR CODES»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__error-codes) . NO -Go to step 5.
  5. Turn the ignition switch to LOCK (0).
  6. Substitute a known-good XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ) or AM/FM/XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck the error code. Is the error message gone? YES -Replace the original XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ) or AM/FM/XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -Go to step 7.
  7. Substitute a known-good XM receiver; Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck the error code. Is the error message gone? YES -Substitute a known-good XM antenna lead, and recheck. If the XM receiver receives a signal, replace the original XM antenna lead. If the symptom/indication is still present, replace the original XM receiver; Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -Replace the XM antenna lead.

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals. If you replace the AcuraLink control unit (XM receiver), the AcuraLink must be reactivated by Acura Client Services.

Scheme 843

Scheme 843: XM radio display is blank and no station information is displayed (with ELS audio, with AcuraLink)

Scheme 844

Scheme 844

Scheme 845

Scheme 845

Scheme 846

Scheme 846

Scheme 847

Scheme 847
  1. Turn the ignition switch to ON (II).
  2. Check for the hard error code (see «HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__how-to-check-error-history-navigation) ). Is DTC 2601 (Display Diag: Connect) indicated? YES -Do the DTC 2601 troubleshooting (see «DTC 2601: DISPLAY DIAG: CONNECT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__dtc-2601-display-diag-connect) ). NO -Go to step 3.
  3. Turn the ignition switch to LOCK (0).
  4. Measure the voltage between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 1 and body ground. ACURALINK CONTROL UNIT (XM RECEIVER) CONNECTOR A (32P) Is there battery voltage? YES -Go to step 5. NO -Repair an open in the wire between No. 15 (10 A) fuse in the under-hood fuse/relay box and AcuraLink control unit (XM receiver) connector A (32P) terminal No. 1.
  5. Turn the ignition switch to ON (II).
  6. Measure the voltage between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No, 2 and No. 3 individually. ACURALINK CONTROL UNIT (XM RECEIVER) CONNECTOR A (32P) Is there battery voltage? YES -Go to step 7. NO -If the IG1 wire does not have voltage, repair an open in the wire between the No. 5 (7.5 A) fuse in the driver's under-dash fuse/relay box and AcuraLink control unit (XM receiver) connector A (32P) terminal No. 2. If the ACC wire does not have voltage, repair an open in the wire between the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box and AcuraLink control unit (XM receiver) connector A (32P) terminal No. 3.
  7. Measure the voltage between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 28 and body ground. ACURALINK CONTROL UNIT (XM RECEIVER) CONNECTOR A (32P) Is there less than 0.2 V? YES -Go to step 8. NO -Repair an open or high resistance in the wire between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 28 and body ground (G651); Sedan (see «RIGHT SIDE WIRE HARNESS (SEDAN)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-4-cyl__right-side-wire-harness-sedan) ), Sport Wagon (see «RIGHT SIDE WIRE HARNESS (SPORT WAGON)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-4-cyl__right-side-wire-harness-sport-wagon) ).
  8. Turn the ignition switch to LOCK (0).
  9. Disconnect audio-navigation unit connector C (14P) and AcuraLink control unit (XM receiver) connector A (32P).
  10. Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) and audio-navigation unit connector C (14P) according to the table. TERMINAL CONTINUITY REFERENCE CHART AcuraLink control unit (XM receiver) connector Audio-navigation unit connector Wire color A30 C9 RED A31 C10 GRN ACURALINK CONTROL UNIT (XM RECEIVER) CONNECTOR A (32P) AUDIO-NAVIGATION UNIT CONNECTOR C (14P) Is there continuity? YES -Go to step 11. NO -There is an open in the wire(s) between the audio-navigation unit and the AcuraLink control unit (XM receiver). Replace the affected shielded harness.
  11. Reconnect audio-navigation unit connector C (14P).
  12. Substitute a known good AcuraLink control unit (XM receiver); Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. Is the symptom/indication gone away? YES -Update the AcuraLink control unit (see «ACURALINK CONTROL UNIT UPDATE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#acuralink-4-cyl__acuralinktm-control-unit-update) ) if it does not have the latest software. If the software is the latest, replace the original AcuraLink control unit (XM receiver); Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). • NO -Substitute a known good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 848

Scheme 848: XM radio display is blank and no station information is displayed (with ELS audio, without AcuraLink

Scheme 849

Scheme 849

Scheme 850

Scheme 850

Scheme 851

Scheme 851

Scheme 852

Scheme 852

Scheme 853

Scheme 853

Scheme 854

Scheme 854

Scheme 855

Scheme 855

Scheme 856

Scheme 856
  1. Measure the voltage between XM receiver connector A (14P) terminal No. 1 and body ground. XM RECEIVER CONNECTOR A (14P) Is there battery voltage? YES -Go to step 3 . NO -Go to step 2.
  2. Measure the voltage between audio-navigation unit connector C (14P) terminal No. 1 and body ground. AUDIO-NAVIGATION UNIT CONNECTOR C (14P) Is there battery voltage? YES -Repair an open or high resistance in the wire between the XM receiver connector A (14P) terminal No. 1 and audio-navigation unit connector C (14P) terminal No. 1. NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  3. Turn the ignition switch to ON (II).
  4. Measure the voltage between XM receiver connector A (14P) terminal No. 11 and body ground. XM RECEIVER CONNECTOR A (14P) Is there less than 0.2 V? YES -Go to step 5. NO -Repair an open or high resistance in the wire between XM receiver connector A (14P) terminal No. 11 and audio-navigation unit connector C (14P) terminal No. 11.
  5. Turn the ignition switch to LOCK (0).
  6. Disconnect audio-navigation unit connector C (14P) and XM receiver connector A (14P).
  7. Check for continuity between XM receiver connector A (14P) terminal No. 2 and body ground. XM RECEIVER CONNECTOR A (14P) Is there continuity? YES -Repair a shot to body ground in the wire between XM receiver connector A (14P) terminal No. 2 and audio-navigation unit connector C (14P) terminal No. 2. NO -Go to step 8.
  8. Check for continuity between audio-navigation unit connector C (14P) terminal No. 2 and XM receiver connector A (14P) terminal No. 2. Is there continuity? YES -Go to step 9. NO -Repair an open in the wire between audio-navigation unit connector C (14P) terminal No. 2 and XM receiver connector A (14P) terminal No. 2.
  9. Check for continuity between XM receiver connector A (14P) and audio-navigation unit connector C (14P) according to the table. TERMINAL CONTINUITY REFERENCE CHART XM receiver connector Audio-navigation unit connector Wire color A9 C9 RED A10 C10 GRN XM RECEIVER CONNECTOR A (14P) AUDIO-NAVIGATION UNIT CONNECTOR C (14P) Is there continuity? YES -Go to step 10. NO -There is an open in the wire(s) between the audio-navigation unit and the XM receiver. Replace the affected shielded harness.
  10. Disconnect the HandsFreeLink control unit 28P connector and the navigation display unit 28P connector.
  11. Check for continuity between body ground and audio-navigation unit connector C (14P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio-navigation unit connector Wire color C9 RED C10 GRN AUDIO-NAVIGATION UNIT CONNECTOR C (14P) Is there continuity? YES -There is a short to body ground in the wire(s) between the audio-navigation unit and the XM receiver. Replace the affected shielded harness. NO -Go to step 12.
  12. Check for continuity between the terminals of audio-navigation unit connector C (14P) according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals C3 (GRY) C9 (RED), C10 (GRN) C9 (RED) C10 (GRN) AUDIO-NAVIGATION UNIT CONNECTOR C (14P) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio-navigation unit and the XM receiver. Replace the affected shielded harness. NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ). If the symptom/indication is still present, replace the XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).

XM radio display is blank and no station information is displayed (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connectors for poor connections or loose terminals.

Scheme 857

Scheme 857: XM radio display is blank and no station information is displayed (with premium audio)

Scheme 858

Scheme 858

Scheme 859

Scheme 859

Scheme 860

Scheme 860

Scheme 861

Scheme 861

Scheme 862

Scheme 862

Scheme 863

Scheme 863

Scheme 864

Scheme 864

Scheme 865

Scheme 865
  1. Measure the voltage between XM receiver connector A (14P) terminal No. 1 and body ground. XM RECEIVER CONNECTOR A (14P) Is there battery voltage? YES -Go to step 3 . NO -Go to step 2.
  2. Measure the voltage between audio unit connector E (14P) terminal No. 1 and body ground. AUDIO UNIT CONNECTOR E (14P) Is there battery voltage? YES -Repair an open or high resistance in the wire between the XM receiver connector A (14P) terminal No. 1 and audio unit connector E (14P) terminal No. 1. NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  3. Turn the ignition switch to ON (II).
  4. Measure the voltage between XM receiver connector A (14P) terminal No. 11 and body ground. XM RECEIVER CONNECTOR A (14P) Is there less than 0.2 V? YES -Go to step 5. NO -Repair an open or high resistance in the wire between XM receiver connector A (14P) terminal No. 11 and audio unit connector E (14P) terminal No. 11.
  5. Turn the ignition switch to LOCK (0).
  6. Disconnect these items: Audio unit connector E (14P) USB adapter control unit connector A (14P) XM receiver connector A (14P)
  7. Check for continuity between XM receiver connector A (14P) terminal No. 2 and body ground. XM RECEIVER CONNECTOR A (14P) Is there continuity? YES -Repair a short to body ground in the wire between XM receiver connector A (14P) terminal No. 2 and audio unit connector E (14P) terminal No. 2. NO -Go to step 8.
  8. Check for continuity between audio unit connector E (14P) terminal No. 2 and XM receiver connector A (14P) terminal No. 2. Is there continuity? YES -Go to step 9. NO -Repair an open in the wire between audio unit connector E (14P) terminal No. 2 and XM receiver connector A (14P) terminal No. 2.
  9. Check for continuity between XM receiver connector A (14P) and audio unit connector E (14P) according to the table. TERMINAL CONTINUITY REFERENCE CHART XM receiver connector Audio unit connector Wire color A9 E9 RED A10 E10 GRN XM RECEIVER CONNECTOR A (14P) AUDIO UNIT CONNECTOR E (14P) Is there continuity? YES -Go to step 10. NO -There is an open in the wire(s) between the audio unit and the XM receiver. Replace the affected shielded harness.
  10. Disconnect the HandsFreeLink control unit 28P connector.
  11. Check for continuity between body ground and audio unit connector E (14P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio unit connector Wire color E9 RED E10 GRN AUDIO UNIT CONNECTOR E (14P) Is there continuity? YES -There is a short to body ground in the wire(s) between the audio unit and the XM receiver. Replace the affected shielded harness. NO -Go to step 12.
  12. Check for continuity between the terminals of audio unit connector E (14P) according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals E3 (GRY) E9 (RED), E10 (GRN) E9 (RED) E10 (GRN) AUDIO UNIT CONNECTOR E (14P) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio unit and the XM receiver. Replace the affected shielded harness. NO -Substitute a known-good audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), and recheck. If the symptom/indication goes away, replace the original audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If the symptom/indication is still present, replace the XM receiver; Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). Make sure the remotes are linked. Check the connectors for poor connections or loose terminals. If you replace the AcuraLink control unit (XM receiver), the AcuraLink must be reactivated by Acura Client Services. If you can only tune to channel 000, 001, 174, and 247, make sure the audio-navigation unit is set to channel mode (see Owner's Manual), if it is set to channel mode, call XM Radio client support, and check the account activation status.

Scheme 866

Scheme 866: XM radio preset memory is lost (with ELS audio, with AcuraLink)

Scheme 867

Scheme 867

Scheme 868

Scheme 868
  1. Turn the ignition switch to ON (II).
  2. Turn on the audio system, and set each of the XM radio channel preset buttons. Do each of the XM radio channel preset buttons set properly? YES -Go to step 3. NO -Go to step 5 .
  3. Turn the ignition switch to LOCK (0) for 1 minute, then back to ON (II).
  4. Test all of the XM radio channel preset buttons for proper recall operation. Do the preset buttons recall the set radio stations? YES -The system is OK at this time. Check connections at the audio-navigation unit. NO -Go to step 5.
  5. Turn the ignition switch to LOCK (0).
  6. Measure the voltage between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 1 and body ground. ACURALINK CONTROL UNIT (XM RECEIVER) CONNECTOR A (32P) Is there battery voltage? YES -Go to step 7. NO -Repair an open in the wire between the No. 15 (10 A) fuse in the under-hood fuse/relay box and AcuraLink control unit (XM receiver) connector A (32P) terminal No. 1.
  7. Turn the ignition switch to ON (II).
  8. Measure the voltage between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 2 and No. 3 individually. Is there battery voltage? YES -Go to step 9. NO -If the IG1 wire does not have voltage, repair an open in the wire between the No. 5 (7.5 A) fuse in the driver's under-dash fuse/relay box and AcuraLink control unit (XM receiver) connector A (32P) terminal No. 2. If the ACC wire does not have voltage, repair an open in the wire between the No. 18(7.5 A) fuse in the driver's under-dash fuse/relay box and AcuraLink control unit (XM receiver) connector A (32P) terminal No. 3.
  9. Measure the voltage between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 28 and body ground. ACURALINK CONTROL UNIT (XM RECEIVER) CONNECTOR A (32P) Is there less than 0.2 V? YES -Replace the AcuraLink control unit (XM receiver); Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -Repair an open or high resistance in the wire between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 28 and body ground (G651); Sedan (see «RIGHT SIDE WIRE HARNESS (SEDAN)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-4-cyl__right-side-wire-harness-sedan) ), Sport Wagon (see «RIGHT SIDE WIRE HARNESS (SPORT WAGON)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-4-cyl__right-side-wire-harness-sport-wagon) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). Make sure the remotes are linked. Check the connectors for poor connections or loose terminals. If you can only tune to channel 000, 001, 174, and 247, make sure the audio-navigation unit is set to channel mode (see Owner's Manual), if it is set to channel mode, call XM Radio client support, and check the account activation status.

Scheme 869

Scheme 869: XM radio preset memory is lost (with ELS audio, without AcuraLink)

Scheme 870

Scheme 870

Scheme 871

Scheme 871
  1. Turn the ignition switch to ON (II).
  2. Turn on the audio system, and set each of the XM radio channel preset buttons. Do each of the XM radio channel preset buttons set properly? YES -Go to step 3. NO -Go to step 5.
  3. Turn the ignition switch to LOCK (0) for 1 minute, then back to ON (II).
  4. Test all of the XM radio channel preset buttons for proper recall operation. Do the preset buttons recall the set radio stations? YES -The system is OK at this time. Check connections at the audio-navigation unit. NO -Go to step 5.
  5. Turn the ignition switch to LOCK (0).
  6. Measure the voltage between XM receiver connector A (14P) terminal No. 1 and body ground. XM RECEIVER CONNECTOR A (14P) Is there battery voltage? YES -Go to step 8 . NO -Go to step 7.
  7. Measure the voltage between audio-navigation unit connector C (14P) terminal No. 1 and body ground. AUDIO-NAVIGATION UNIT CONNECTOR C (14P) Is there battery voltage? YES -Repair an open or high resistance in the wire between the XM receiver connector A (14P) terminal No. 1 and audio-navigation unit connector C (14P) terminal No. 1. NO -Replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).
  8. Turn the ignition switch to ON (II).
  9. Measure the voltage between XM receiver connector A (14P) terminal No. 11 and body ground. XM RECEIVER CONNECTOR A (14P) Is there less than 0.2 V? YES -Replace the XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -Repair an open or high resistance in the wire between XM receiver connector A (14P) terminal No. 11 and audio-navigation unit connector C (14P) terminal No. 11.

XM radio preset memory is lost (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Make sure the remotes are linked. Check the connectors for poor connections or loose terminals. If you can only tune to channel 000, 001, 174, and 247, make sure the audio unit is set to channel mode (see Owner's Manual), if it is set to channel mode, call XM Radio client support, and check the account activation status.

Scheme 872

Scheme 872: XM radio preset memory is lost (with premium audio)

Scheme 873

Scheme 873

Scheme 874

Scheme 874
  1. Turn the ignition switch to ON (II).
  2. Turn on the audio unit, and set each of the XM radio channel preset buttons. Do each of the XM radio channel preset buttons set properly? YES -Go to step 3. NO -Go to step 5 .
  3. Turn the ignition switch to LOCK (0) for 1 minute, then back to ON (II).
  4. Test all of the XM radio channel preset buttons for proper recall operation. Do the preset buttons recall the set radio stations? YES -The system is OK at this time. Check connections at the audio-navigation unit. NO -Go to step 5.
  5. Turn the ignition switch to LOCK (0).
  6. Measure the voltage between XM receiver connector A (14P) terminal No. 1 and body ground. XM RECEIVER CONNECTOR A (14P) Is there battery voltage? YES -Go to step 8 . NO -Go to step 7.
  7. Measure the voltage between audio unit connector E (14P) terminal No. 1 and body ground. AUDIO UNIT CONNECTOR E (14P) Is there battery voltage? YES -Repair an open or high resistance in the wire between the XM receiver connector A (14P) terminal No. 1 and audio unit connector E (14P) terminal No. 1. NO -Replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).
  8. Turn the ignition switch to ON (II).
  9. Measure the voltage between XM receiver connector A (14P) terminal No. 11 and body ground. XM RECEIVER CONNECTOR A (14P) Is there less than 0.2 V? YES -Replace the XM receiver; Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). NO -Repair an open or high resistance in the wire between audio unit connector E (14P) terminal No. 11 and XM receiver connector A (14P) terminal No. 11.

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connector for poor connections or loose terminals. Check the radio reception in an open area. Poor reception/interference can be caused by tall buildings, mountains, or high-voltage power lines are nearby. If you can only tune to channel 000, 001, 174, and 247, make sure the audio-navigation unit is set to channel mode (see Owner's Manual), if it is set to channel mode, call XM Radio client support, and check the account activation status. If you replace the AcuraLink control unit (XM receiver), the AcuraLink must be reactivated by Acura Client Services. Check for other error codes (see ERROR CODES ), and check the XM Antenna Signal Reception Level (see XM SIGNAL RECEPTION LEVEL INDICATION MODE ).

Scheme 875

Scheme 875: Poor or no sound with XM radio (Audio unit does display XM channels) (with ELS audio, with AcuraLink

Scheme 876

Scheme 876

Scheme 877

Scheme 877

Scheme 878

Scheme 878
  1. Turn the ignition switch to ON (II).
  2. Turn on the audio system, and press the XM button to select the XM radio.
  3. Check for an error message on the display. Are there any messages displayed? YES -Go to «ERROR CODES»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__error-codes) . NO -Go to step 4.
  4. Disconnect audio-navigation unit connector C (14P) and AcuraLink control unit (XM receiver) connector A (32P).
  5. Check for continuity between audio-navigation unit connector C (14P) and AcuraLink control unit (XM receiver) connector A (32P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio-navigation unit connector AcuraLink control unit (XM receiver) connector Wire color C5 A13 GRN C6 A15 BLK C13 A14 WHT C14 A16 RED AUDIO-NAVIGATION UNIT CONNECTOR C (14P) ACURALINK CONTROL UNIT (XM RECEIVER) CONNECTOR A (32P) Is there continuity? YES -Go to step 6. NO -There is an open in the wire(s) between the audio-navigation unit and the AcuraLink control unit (XM receiver). Replace the affected shielded harness.
  6. Disconnect the HandsFreeLink control unit 28P connector.
  7. Check for continuity between body ground and audio-navigation unit connector C (14P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio-navigation unit connector Wire color C5 GRN C6 BLK C13 WHT C14 RED AUDIO-NAVIGATION UNIT CONNECTOR C (14P) Is there continuity? YES -There is a short to body ground in the wire(s) between the audio-navigation unit and the AcuraLink control unit (XM receiver). Replace the affected shielded harness. NO -Go to step 8.
  8. Check for continuity between the terminals of audio-navigation unit connector C (14P) according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals C4 (GRY) C5 (GRN), C6 (BLK), C13 (WHT), C14 (RED) C5 (GRN) C6 (BLK), C13 (WHT), C14 (RED) C6 (BLK) C13 (WHT), C14 (RED) C13 (WHT) C14 (RED) AUDIO-NAVIGATION UNIT CONNECTOR C (14P) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio-navigation unit and the AcuraLink control unit (XM receiver). Replace the affected shielded harness. NO -Substitute a known-good AcuraLink control unit (XM receiver); Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), then reconnect all connectors, and recheck. If the symptom/indication goes away, update the AcuraLink control unit (see «ACURALINK CONTROL UNIT UPDATE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#acuralink-4-cyl__acuralinktm-control-unit-update) ) if it does not have the latest software, then recheck. If the software is the latest, replace the original AcuraLink control unit (XM receiver); Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connector for poor connections or loose terminals. Check the radio reception in an open area. Poor reception/interference can be caused by tall buildings, mountains, or high-voltage power lines are nearby. If you can only tune to channel 000, 001, 174, and 247, make sure the audio-navigation unit is set to channel mode (see Owner's Manual), if it is set to channel mode, call XM Radio client support, and check the account activation status. Check for other error codes (see ERROR CODES ), and check the XM Antenna Signal Reception Level (see XM SIGNAL RECEPTION LEVEL INDICATION MODE ).

Scheme 879

Scheme 879: Poor or no sound with XM radio (Audio unit does display XM channels) (with ELS audio, without AcuraL

Scheme 880

Scheme 880

Scheme 881

Scheme 881

Scheme 882

Scheme 882
  1. Turn the ignition switch to ON (II).
  2. Turn on the audio system, and press the XM button to select the XM radio.
  3. Check for an error message on the display. Are there any messages displayed? YES -Go to «ERROR CODES»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__error-codes) . NO -Go to step 4.
  4. Disconnect audio-navigation unit connector C (14P) and XM receiver connector A (14P).
  5. Check for continuity between audio-navigation unit connector C (14P) and XM receiver connector A (14P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio-navigation unit connector XM receiver connector Wire color C5 A5 GRN C6 A6 BLK C13 A13 WHT C14 A14 RED AUDIO-NAVIGATION UNIT CONNECTOR C (14P) XM RECEIVER CONNECTOR A (14P) Is there continuity? YES -Go to step 6. NO -There is an open in the wire(s) between the audio-navigation unit and the XM receiver. Replace the affected shielded harness.
  6. Disconnect the HandsFreeLink control unit 28P connector.
  7. Check for continuity between body ground and audio-navigation unit connector C (14P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio-navigation unit connector Wire color C5 GRN C6 BLK C13 WHT C14 RED AUDIO-NAVIGATION UNIT CONNECTOR C (14P) Is there continuity? YES -There is a short to body ground in the wire(s) between the audio-navigation unit and the XM receiver. Replace the affected shielded harness. NO -Go to step 8.
  8. Check for continuity between the terminals of audio-navigation unit connector C (14P) according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals C4 (GRY) C5 (GRIM), C6 (BLK), C13 (WHT), C14 (RED) C5 (GRN) C6 (BLK), C13 (WHT), C14 (RED) C6 (BLK) C13 (WHT), C14 (RED) C13 (WHT) C14 (RED) AUDIO-NAVIGATION UNIT CONNECTOR C (14P) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio-navigation unit and the XM receiver. Replace the affected shielded harness. NO -Substitute a known-good XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), then reconnect all connectors, and recheck. If the symptom/indication goes away, replace the XM receiver (see «XM RECEIVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If symptom/indication is still present, replace the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__audio-navigation-unit-removalinstallation) ).

Poor or no sound with XM radio (Audio unit does display XM channels) (with premium audio)

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check the connector for poor connections or loose terminals. Check the radio reception in an open area. Poor reception/interference can be caused by tall buildings, mountains, or high-voltage power lines are nearby. If you can only tune to channel 000, 001, 174, and 247, make sure the audio unit is set to channel mode (see Owner's Manual), if it is set to channel mode, call XM Radio client support, and check the account activation status. Check for other error codes (see ERROR CODES ), and check the XM Antenna Signal Reception Level (see XM SIGNAL RECEPTION LEVEL INDICATION MODE ).

Scheme 883

Scheme 883: Poor or no sound with XM radio (Audio unit does display XM channels) (with premium audio)

Scheme 884

Scheme 884

Scheme 885

Scheme 885

Scheme 886

Scheme 886
  1. Turn the ignition switch to ON (II).
  2. Turn on the audio unit, and press the XM button to select the XM radio.
  3. Check for an error message on the display. Are there any messages displayed? YES -Go to «ERROR CODES»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__error-codes) . NO -Go to step 4.
  4. Disconnect audio unit connector E (14P) and XM receiver connector A (14P).
  5. Check for continuity between XM receiver connector A (14P) and audio unit connector E (14P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio unit connector XM receiver connector Wire color E5 A5 GRN E6 A6 BLK E13 A13 WHT E14 A14 RED AUDIO UNIT CONNECTOR E (14P) XM RECEIVER CONNECTOR A (14P) Is there continuity? YES -Go to step 6. NO -There is an open in the wire(s) between the audio unit and the XM receiver. Replace the affected shielded harness.
  6. Disconnect the HandsFreeLink control unit 28P connector and USB adapter control unit connector A (14P).
  7. Check for continuity between body ground and audio unit connector E (14P) according to the table. TERMINAL CONTINUITY REFERENCE CHART Audio unit connector Wire color E5 GRN E6 BLK E13 WHT E14 RED AUDIO UNIT CONNECTOR E (14P) Is there continuity? YES -There is a short to body ground in the wire(s) between the audio unit and the XM receiver. Replace the affected shielded harness. NO -Go to step 8.
  8. Check for continuity between the terminals of audio unit connector E (14P) according to the table. TERMINAL CONTINUITY REFERENCE CHART From terminal To terminals E4 (GRY) E5 (GRN), E6 (BLK), E13 (WHT), E14 (RED) E5 (GRN) E6 (BLK), E13 (WHT), E14 (RED) E6 (BLK) E13 (WHT), E14 (RED) E13 (WHT) E14 (RED) AUDIO UNIT CONNECTOR E (14P) Is there continuity between any of the terminals? YES -There is a short in the wires between the audio unit and the XM receiver. Replace the affected shielded harness. NO -Substitute a known-good XM receiver; Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), then reconnect all connectors, and recheck. If the symptom/indication goes away, replace the original XM receiver; Sedan (see «SEDAN»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ), Sport Wagon (see «SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ). If symptom/indication is still present, replace the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ).

Sound Quality Diagnosis

Special Tools Required

Diagnostic CD 07AAZ-SDBA100

Use the following tests to check sound quality.

Note. Before beginning the following tests, write down the client's bass, treble, fader and balance settings, then set them to their center positions for the testing.

Left/Right Channel ID

Do this test to confirm proper channel routing.

  1. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit.
  2. Play track No. 1 (left, both, right channel ID) at a normal, or slightly higher than normal, volume level.
  3. The voice should be audible only from the channel or channels when indicated. If the channel ID is correct for each side, go to «PHASE TEST»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__phase-test) . If the channel ID is not correct, check for: Shorted speaker wire Faulty stereo amplifier Faulty audio unit

Phase Test

Do this test to confirm proper speaker phasing.

  1. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit.
  2. Play track No. 2 (phase) at a normal, or slightly higher than normal, volume level.
  3. The voice should sound centered and focused when it is in-phase.
  4. The voice should sound diffused, and have less bass when it is out of phase. If the voice changes from in-phase to out of phase as indicated by the prompt, the phasing is correct. Go to «ELECTRICAL NOISE TEST»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__electrical-noise-test) . If the voice always sounds out of phase, phasing is not correct. Check for: Crossed speaker wire Faulty stereo amplifier Faulty audio unit

Electrical Noise Test

Do this test to check for electrical noise being induced into the audio system.

Note. Electrical noise may be caused by outside sources that cannot be handled by the audio system. Make sure you remove any cell phones and/or turn off any aftermarket devices before beginning this test.

  1. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit.
  2. Play track No. 4 (digital zero) at a normal, or slightly higher than normal, volume level.
  3. Operate any electrical device that may create electrical noise in the audio system, including starting the engine.
  4. Play track No. 5 (near digital zero) at a normal, or slightly higher than normal, volume level.
  5. Operate any electrical device that may create electrical noise in the audio system, including starting the engine.
  6. Play track No. 6 (SNR) at a normal, or slightly higher than normal, volume level.
  7. Operate any electrical device that may create electrical noise in the audio system, including starting the engine. If no abnormal noise is heard, go to «INDIVIDUAL SPEAKER TEST»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__individual-speaker-test) . If the noise is present only during the SNR track, replace the audio unit. If the noise is heard during the digital zero or near digital zero track, check for: Poor ground at the audio unit, stereo amplifier, engine, or battery cable Pinched or shorted speaker or stereo amplifier wire Faulty stereo amplifier Faulty audio unit Other faulty components causing excessive electrical noise (ignition coils, alternator, door lock actuators, etc.). Disconnect any suspect components, and then replay the tracks that were originally noisy. If the noise is gone, check the component's circuit and the component

Individual Speaker Test

Do this test to identify a faulty speaker.

  1. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit.
  2. Play track No. 30 (steady 300 Hz tone) at a normal, or slightly higher than normal, volume level.
  3. Listen to each speaker for poor sound compared to the other channels. Use the audio unit's fader and balance settings to help isolate the channel with the problem. If the sound quality produced by a specific speaker is poor, substitute it with a known-good speaker. If the poor sound quality continues, go to Sound Balance Test. If the sound quality is OK, go to Sound Balance Test.

Sound Balance Test

Do this test to identify a faulty channel or speaker.

  1. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit.
  2. Confirm the bass and treble are set to the center positions.
  3. Play track No. 3 (pink noise) at a normal, or slightly higher than normal, volume level.
  4. A static type sound should be heard through all speakers.
  5. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit of a known-good vehicle.
  6. Set the bass and treble to the center positions.
  7. Play track No. 3 (pink noise) all the same level as was played in step 3 .
  8. Compare the sounds made by the two vehicles. If the sound does not have as much bass, check the subwoofer and circuit. If the sound does not have enough hiss, check the tweeters and their circuits.

Frequency Sweep

Do this test to find rattles or reverberations that may cause a perception of poor sound quality.

  1. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit.
  2. Play track No. 13 (sweep from 500 Hz to 35 Hz) at a normal, or slightly higher than normal, volume level.
  3. Listen to each speaker for poor sound quality or reverberations caused by specific frequencies. Use the voice-over to estimate the frequency that causes the vibration. Use the audio unit's fader and balance settings to help isolate the channel with the problem. If vibrations or poor sound quality are heard, go to step 4. If no vibrations or poor sound quality are heard, go to Sound Judging.
  4. Choose the appropriate track from No. 14 to 25 (small range frequency sweep) or 26 to 53 (single frequencies) to recreate the frequency that caused the poor sound quality or vibration witnessed in step 3 ; this aids in diagnosis of the cause. NOTE: When you get to the track that recreates the problem, select the repeat function on the audio unit, this will help you isolate the cause.
  5. Replace or insulate the source of the vibration or, if the speaker is the source of the poor sound quality, replace it.

Sound Judging

Do this test to compare overall sound quality, imaging, and dynamics between the client's vehicle and a known-good vehicle. Only use a vehicle of the same model and trim level for this test.

  1. In the client's vehicle, set the bass, treble, fader, and balance settings to the client's normal settings that were written down before beginning the test.
  2. Insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit.
  3. Play tracks No. 7 to 12 (sound quality, midland, dynamics, and imaging demonstration tracks) at a normal, or slightly higher than normal, volume level. Write down the volume setting being used.
  4. Listen to areas of the track that stand out as being either very clear or poorer than other areas of the track.
  5. In a known-good vehicle, insert the audio diagnostic CD (T/N 07AAZ-SDBA100) into the audio unit.
  6. Play the tracks at the same volume level and the same bass, treble, balance, and fader settings as used in step 3 in the client's vehicle.
  7. Listen to the same area of the track that stood out as being either very clear or poorer than other areas of the track.
  8. Compare the client's vehicle's sound quality results the known-good vehicle's results. If the sound quality in the client's vehicle is comparable to the sound quality in the known-good vehicle, then the client's vehicle is operating as designed. If the sound quality is not comparable, check these items in order: Loose or improperly installed speakers or other hardware that may create interference from the vibrations generated by the speakers Poor power or ground to the stereo amplifier Damaged speaker(s) Faulty stereo amplifier Faulty audio unit

Seek Stop Test

Do this test to check the performance of the audio unit's AM and FM reception. Refer to SYMPTOM TROUBLESHOOTING: AUDIO SOUND WEAK OR DISTORTED (DISPLAY IS NORMAL); WITH ELS AUDIO , with premium audio (see AUDIO SYSTEM SOUND IS WEAK OR DISTORTED (DISPLAY IS NORMAL) (WITH PREMIUM AUDIO) ), or No sound is heard from the speaker(s) (display is normal); with ELS audio (see NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) (WITH ELS AUDIO) ), with premium audio (see NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) (WITH PREMIUM AUDIO) ) before continuing with this test.

Note. Window tint, aftermarket theft-recovery devices and other aftermarket devices may affect reception. Changes in cloud cover and other atmospheric conditions will affect the ability of the audio unit to receive radio signals.

  1. Park the client's vehicle in an open area away from buildings or other obstructions.
  2. Park a known-good vehicle (same year, model, and trim level) next to the client's vehicle, facing the same direction.
  3. Start the engine in the client's vehicle, and turn on the radio.
  4. Set the FM receiver to 87.7 MHz.
  5. Press the Seek + button, and record the first station that the audio unit locks onto.
  6. Press the Seek + button repeatedly, and write down each station that the audio unit locks onto until the station recorded in step 5 is reached again.
  7. Set the AM receiver to 530 kHz.
  8. Press the Seek + button, and record the first station that the audio unit locks onto.
  9. Press the Seek + button repeatedly, and write down each station that the audio unit locks onto until the station recorded in step 8 is reached again.
  10. Turn the ignition switch to LOCK (0).
  11. Start the engine in the known-good vehicle, and then do steps 4 thru 10 on the known-good vehicle.
  12. Compare the number of stations received in steps 6 and 9 in the client's vehicle with the number of stations received in the known-good vehicle. If the number of stations received is the same, or within 10 %, the audio unit's tuner performance is OK. The problem may be atmospheric conditions, multi-path interference, or other obstructions to the radio signal. If the client's vehicle receives fewer stations by at least 10 %, go to step 4 of Poor AM or FM radio reception or interference troubleshooting; Sedan with ELS audio (see «POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (SEDAN WITH ELS AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__poor-am-or-fm-radio-reception) ) Sport Wagon with ELS audio (see «POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (SPORT WAGON WITH ELS AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__poor-am-or-fm-radio-reception) ) Sedan with premium audio (see «POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (SEDAN WITH PREMIUM AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__poor-am-or-fm-radio-reception) ) Sport Wagon with premium audio (see «POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (SPORT WAGON WITH PREMIUM AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__poor-am-or-fm-radio-reception) )

With Premium Audio

Note. Put on gloves to protect your hands. Take care not to scratch the dashboard and related parts. Lay a shop towel under the parts when working on them to protect the face panel from scratches or other damage. Eject all the discs before removing the audio unit to prevent damaging the CD player's load mechanism. If you are replacing the audio unit, write down the audio presets (if possible), then enter them into the new audio unit.

Scheme 887

Scheme 887: With Premium Audio

Scheme 888

Scheme 888
  1. Make sure you have the anti-theft codes for the audio system.
  2. Remove the driver's center trim (see «CENTER TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__center-trim-removalinstallation) ) and the passenger's dashboard trim (see «PASSENGER'S DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__passengers-dashboard-trim-removalinstallation) ).
  3. Remove the passenger's center trim (see «CENTER TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__center-trim-removalinstallation) ) and the center console panel (see «CENTER CONSOLE PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#consoles-4-cyl__center-console-panel-removalinstallation) ).
  4. Remove the climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-4-cyl) ) and the center pocket (see «CENTER POCKET REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__center-pocket-removalinstallation) ).
  5. Remove the bolts (A), then pull out the audio unit (B).
  6. Disconnect the connectors (C), then remove the audio unit.
  7. Remove the dashboard center vent (see «CENTER TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__center-trim-removalinstallation) ).
  8. Remove the screws and bolts (A) from the audio unit (B), then remove the audio unit from the audio switch panel (C).
  9. Install the audio unit in the reverse order of removal, and note these items: Make sure all the connectors and the antenna lead are secure. Enter the anti-theft codes for the audio system.
  10. Give the new anti-theft codes to the client if the audio unit is replaced.

With ELS Audio

Note. Put on gloves to protect your hands. Take care not to scratch the dashboard and related parts. Lay a workshop towel under the parts when working on them to protect the face panel from scratches or other damage. Do not work in a dusty or dirty place. Discharge static electricity from your body before and during the work. Do not work with dirty hands. Do not touch the circuit board with your bare hands. Be careful not to fold the flat plate cable. Do not touch the terminal connector of the flat plate cable with your bare hands. (If you have touched it, wipe it off thoroughly.)

Scheme 889

Scheme 889: With ELS Audio

Scheme 890

Scheme 890
  1. Remove the driver's center trim (see «CENTER TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__center-trim-removalinstallation) ) and the passenger's dashboard trim (see «PASSENGER'S DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__passengers-dashboard-trim-removalinstallation) ).
  2. Remove the passenger's center trim (see «CENTER TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__center-trim-removalinstallation) ).
  3. Remove the climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-4-cyl) ).
  4. Pull out the audio-navigation switch panel (A).
  5. Disconnect the connectors (B), and remove the audio-navigation switch panel.
  6. Remove the dashboard center vent (see «DASHBOARD CENTER VENT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__dashboard-center-vent-removalinstallation) ).
  7. Remove the interface dial (see «HFL-NAVIGATION MICROPHONE REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__hfl-navigation-microphone-removalinstallation) ) and the hazard warning switch (see «HAZARD WARNING SWITCH TEST/REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-lights/#turn-signalhazard-warning-lights-4-cyl) ) from the audio-navigation switch panel (A).
  8. Install the audio-navigation switch panel in the reverse order of removal.

Note. Put on gloves to protect your hands. Take care not to scratch the dashboard and related parts. Lay a workshop towel under the parts when working on them to protect the face panel from scratches or other damage. Do not work in a dusty or dirty place. Discharge static electricity from your body before and during the work. Do not work with dirty hands. Do not touch the circuit board with your bare hands. Be careful not on fold the flat plate cable. Do not touch the terminal connector of the flat plate cable with your bare hands. (If you have touched it, wipe it off thoroughly.)

Scheme 891

Scheme 891: With Premium Audio
  1. Remove the audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl) ) and the hazard warning switch (see «HAZARD WARNING SWITCH TEST/REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-lights/#turn-signalhazard-warning-lights-4-cyl) ) from the audio switch panel (A).
  2. Install the audio switch panel in the reverse order of removal, and note these items: Make sure all the connectors and the antenna lead are secure. Enter the anti-theft codes for the audio system.

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. Take care not to scratch the dashboard.

Scheme 892

Scheme 892: With Premium Audio
  1. Remove the speaker cover (see «SPEAKER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__speaker-cover-removalinstallation) ).
  2. Carefully push out the audio-HVAC display unit (A).
  3. Disconnect the connectors (B), and remove the audio-HVAC display unit.
  4. Remove the passenger's airbag cutoff indicator (see «INSTALLATION»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl) ) from the audio-HVAC display unit.
  5. Install the audio-HVAC display unit in the reverse order of removal.

Scheme 893

Scheme 893: Sedan
  1. Remove the right trunk side trim panel (see «TRUNK SIDE TRIM PANEL»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__trunk-side-trim-panel) ).
  2. Disconnect the connectors (A) from the stereo amplifier (B).
  3. Loosen the mounting bolts (C), then pull out the stereo amplifier.
  4. Install the stereo amplifier in the reverse order of removal.

Scheme 894

Scheme 894: Sport Wagon
  1. Remove the tonneau cover (see step 1 on «REAR PARCEL SHELF DYNAMIC DAMPER»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__rear-parcel-shelf-dynamic-damper) ).
  2. Fold down both rear seat-backs, and pull back the rear floor mat (see step 3 on «TRIM REMOVAL/INSTALLATION - CARGO AREA»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__trim-removalinstallation-cargo-area) ).
  3. Disconnect the connectors (A) from the stereo amplifier (B).
  4. Remove the bolts (C) from the stereo amplifier, and remove it.
  5. Install the stereo amplifier in the reverse order of removal.

Sedan

Note. The AcuraLink must be reactivated by Acura Client Services when

  1. The AcuraLink control unit (XM receiver) is replaced.
  2. DATA RESET was selected while in the self-diagnostic function.
  3. Vehicle ownership changes.

Scheme 895

Scheme 895
  1. Remove the right rear seat side bolster (see «SEAT SIDE BOLSTER»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__seat-side-bolster) ).
  2. Disconnect the connectors (A) from the AcuraLink control unit (XM receiver) (B).
  3. Remove the nuts (C) and the AcuraLink control unit XM receiver).
  4. Install the AcuraLink control unit (XM receiver) in the reverse order of removal. NOTE: If you replaced the AcuraLink control unit (XM receiver), make sure it has the latest software (see «ACURALINK CONTROL UNIT UPDATE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#acuralink-4-cyl__acuralinktm-control-unit-update) ).
  5. Call XM Radio at 800-852-9696 to update the client's account with the new XM/HIP serial number. Also call Acura Client Services to reactivate the AcuraLink.

Sport Wagon

Note. The AcuraLink must be reactivated by Acura Client Services when

  1. The AcuraLink control unit (XM receiver) is replaced.
  2. DATA RESET was selected while in the self-diagnostic function.
  3. Vehicle ownership changes.

Scheme 896

Scheme 896
  1. Remove the tonneau cover (see step 1 on «REAR PARCEL SHELF DYNAMIC DAMPER»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__rear-parcel-shelf-dynamic-damper) ).
  2. Fold down both rear seat-backs, and pull back the rear floor mat (see step 3 on «TRIM REMOVAL/INSTALLATION - CARGO AREA»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__trim-removalinstallation-cargo-area) ).
  3. Disconnect the connectors (A) from the AcuraLink control unit (XM receiver) (B).
  4. Remove the bolts (C) from the AcuraLink control unit (XM receiver), and remove it.
  5. Install the AcuraLink control unit (XM receiver) in the reverse order of removal. NOTE: If you replaced the AcuraLink control unit (XM receiver), make sure it has the latest software (see «ACURALINK CONTROL UNIT UPDATE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#acuralink-4-cyl__acuralinktm-control-unit-update) ).
  6. Call XM Radio at 800-852-9696 to update the client's account with the new XM/HIP serial number. Also call Acura Client Services to reactivate the AcuraLink.

Scheme 897

Scheme 897: Sedan
  1. Remove the right rear seat side bolster (see «SEAT SIDE BOLSTER»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__seat-side-bolster) ).
  2. Disconnect the connectors (A) from the XM receiver (B).
  3. Remove the nuts (C) and the XM receiver.
  4. Install the XM receiver in the reverse order of removal.
  5. Register the new XM receiver I.D. number with XM Radio by calling 800-852-9696.

Scheme 898

Scheme 898: Sport Wagon
  1. Remove the tonneau cover (see step 1 on «REAR PARCEL SHELF DYNAMIC DAMPER»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__rear-parcel-shelf-dynamic-damper) ).
  2. Fold down both rear seat-backs, and pull back the rear floor mat (see step 3 on «TRIM REMOVAL/INSTALLATION - CARGO AREA»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__trim-removalinstallation-cargo-area) ).
  3. Disconnect the connectors (A) from the XM receiver (B).
  4. Remove the bolts (C) from the XM receiver, and remove it.
  5. Install the XM receiver in the reverse order of removal.
  6. Register the new XM receiver I.D. number with XM Radio by calling 800-852-9696.

Scheme 899

Scheme 899: With Premium Audio
  1. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#consoles-4-cyl__center-console-removalinstallation) ).
  2. Disconnect the connectors (A) from the USB adapter control unit (B).
  3. Remove the bolts (C) and the USB adapter control unit.
  4. Install the USB adapter control unit in the reverse order of removal.

Scheme 900

Scheme 900: Front Door Speaker
  1. Remove the front door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__front-door-panel-removalinstallation) ).
  2. Remove the bolt (A), then lift the speaker (B) straight up to release the lower clips (C). NOTE: If you pull the speaker out too far from the door, you will damage the lower clips.
  3. Disconnect the 2P connector (D), and remove the speaker.
  4. Measure the resistance between terminals No. 1 and No. 2. With ELS audio, there should be about 2 ohms. With premium audio, there should be about 4 ohms.
  5. If the resistance is not as specified, replace the door speaker.

Scheme 901

Scheme 901: Front Center Speaker (with ELS audio)
  1. Remove the speaker cover (see «SPEAKER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__speaker-cover-removalinstallation) ).
  2. Remove the bolts (A), then pull out the front center speaker (B).
  3. Disconnect the connector (C), and remove the front center speaker.
  4. Measure the resistance between terminals No. 1 and No. 2. There should be about 4 ohms.
  5. If the resistance is not as specified, replace the front center speaker.

Scheme 902

Scheme 902: Front Door Tweeter

Scheme 903

Scheme 903

Scheme 904

Scheme 904

Scheme 905

Scheme 905
  1. Detach the clips (A) and remove the front door tweeter cover (B). Then disconnect the connector (C).
  2. Remove the tweeter (A) from the front door tweeter cover (B). With ELS audio, check the capacitor (C) condition. If any problems are found, replace the front door tweeter.
  3. Measure the resistance between the tweeter (A) terminals as shown: With ELS audio, measure the resistance between front door tweeter 2P connector terminal No. 2 and the outside terminal of the capacitor. There should be about 6 ohms. With premium audio, measure the resistance between front door tweeter 2P connector terminal No. 1 and No. 2. There should be about 3.3 ohms. With ELS audio With premium audio
  4. If the resistance is not as specified, replace the front door tweeter.

Scheme 906

Scheme 906: Rear Speaker (Sedan)
  1. Remove the rear speaker grille (see «REAR SHELF»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__rear-shelf) ).
  2. Remove the mounting bolt (A), then tilt the speaker (B) forward to release the front clips (C). NOTE: If you pull the speaker out too far from the rear bulkhead, you will damage the lower clips.
  3. Disconnect the connector (D), and remove the rear speaker.
  4. Measure the resistance between terminals No. 1 and No. 2. With ELS audio, there should be about 2 ohms. With premium audio, there should be about 4 ohms.
  5. If the resistance is not as specified, replace the rear speaker.

Scheme 907

Scheme 907: Rear Door Speaker (with ELS audio, Sport Wagon with premium audio)
  1. Remove the rear door panel (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#doors-4-cyl__rear-door-panel-removalinstallation) ).
  2. Remove the bolt (A). Then lift the speaker (B) straight up to release the lower clips (C). NOTE: If you pull the speaker out too far from the door, you will damage the lower clips.
  3. Disconnect the connector (D), and remove the speaker.
  4. Measure the resistance between terminals No. 1 and No. 2. With ELS audio, there should be about 2 ohms. With premium audio, there should be about 4 ohms.
  5. If the resistance is not as specified, replace the door speaker.

Satellite Speaker (Sport Wagon)

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Scheme 908

Scheme 908: Satellite Speaker (Sport Wagon)
  1. Remove the quarter pillar trim (see «QUARTER PILLAR TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__quarter-pillar-trim) ).
  2. Remove the bolts (A) from the satellite speaker (B).
  3. Disconnect the connector (C), and remove the satellite speaker.
  4. Measure the resistance between terminals No. 1 and No. 2. There should be about 4 ohms.
  5. If the resistance is not as specified, replace the satellite speaker.

Scheme 909

Scheme 909: Subwoofer (Sedan)
  1. Remove the rear shelf (see «REAR SHELF»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__rear-shelf) ).
  2. Remove the bolts (A) from the subwoofer (B).
  3. Disconnect the connector (C), and remove the subwoofer.
  4. Measure the resistance between terminals No. 1 and No. 2. There should be about 2 ohms.
  5. If the resistance is not as specified, replace the subwoofer.

Scheme 910

Scheme 910: Subwoofer (Sport Wagon with ELS audio)
  1. Remove the right cargo area side trim panel (see «REAR PARCEL SHELF DYNAMIC DAMPER»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__rear-parcel-shelf-dynamic-damper) ).
  2. Remove the bolts (A) from the subwoofer (B).
  3. Disconnect the connector (C), and remove the subwoofer. Input Test
  4. With the subwoofer 8P connector is connected, make the input tests at the connector according to the table. CONNECTOR TERMINAL REFERENCE CHART Terminal Test 4 Measure the voltage to body ground with all conditions: There should be less than 0.2 V. 5 Measure the voltage to body ground with all conditions: There should be battery voltage. 6 Measure the voltage to body ground with audio system on: There should be battery voltage.
  5. If the input test proves OK and the subwoofer has no sound, replace the subwoofer.

Scheme 911

Scheme 911: Subwoofer (Sport Wagon with premium audio)
  1. Remove the right cargo area side trim panel (see «REAR PARCEL SHELF DYNAMIC DAMPER»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__rear-parcel-shelf-dynamic-damper) ).
  2. Remove the bolts (A) from the subwoofer (B).
  3. Disconnect the connector (C), and remove the subwoofer.
  4. Measure the resistance between the terminals No. 3 and No. 8. There should be about 2 ohms.
  5. If the resistance is not as specified, replace the subwoofer.

Audio Remote Switch Test

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Scheme 912

Scheme 912: Audio Remote Switch Test
  1. Remove the audio remote switch (see «AUDIO REMOTE SWITCH TEST»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__audio-remote-switch-test) ).
  2. Measure the resistance between terminals No. 1 and No. 7 in each switch position according to the table. TERMINAL RESISTANCE REFERENCE CHART Position Resistance No button pressed About 10 kohms. MODE About 3.7 kohms. CH (+) About 1.7 kohms. CH (-) About 775 ohms (VOL UP) About 357 ohms (VOL. DOWN) About 100 ohms
  3. If the resistance is not as specified, replace the audio remote switch (see «AUDIO REMOTE SWITCH TEST»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-4-cyl__audio-remote-switch-test) ).

Audio Remote Switch Replacement

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Scheme 913

Scheme 913: Audio Remote Switch Replacement

Scheme 914

Scheme 914
  1. Remove the driver's airbag assembly (see «REMOVAL»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl__removal) ).
  2. Remove the covers (A) and screws from the steering wheel (B).
  3. Disconnect the connectors from the steering switches, then remove the steering wheel trim (C).
  4. Remove the HFL-navigation voice control switch (see «VOICE CONTROL SWITCH REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-4-cyl__voice-control-switch-replacement) ) or HFL switch (see «HFL SWITCH REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#handsfreelink-system-4-cyl__hfl-switch-replacement) ).
  5. Remove the screw and audio remote switch (A) from the steering wheel trim (B).
  6. Install the audio remote switch in the reverse order of removal.

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Scheme 915

Scheme 915: Sedan
  1. Remove the C-pillar trim (see «C-PILLAR TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__c-pillar-trim) ).
  2. Disconnect the connectors (A) from the AM/FM antenna amplifier (B).
  3. Remove the bolt (C) and the AM/FM antenna amplifier.
  4. Install the AM/FM antenna amplifier in the reverse order of removal.

AM/FM Antenna Repair

Note. To make an effective repair, the broken section must be no longer than one inch.

Scheme 916

Scheme 916: AM/FM Antenna Repair

Scheme 917

Scheme 917
  1. Lightly rub the area around the broken section (A) with fine steel wool, then clean it with isopropyl alcohol.
  2. Carefully mask above and below the broken portion of the window antenna wire (B) with cellophane tape (C).
  3. Using a commercially available rear window defogger repair kit, apply a heavy coat of paint (A) extending about 1/8" on both sides of the break. Allow 30 minutes to dry.
  4. Check for continuity in the repaired wire.
  5. Apply a second coat of paint in the same way. Let it dry 3 hours before removing the tape.

Scheme 918

Scheme 918: Sedan
  1. Pull down the rear portion of the headliner (see «HEADLINER REMOVAL/INSTALLATION - SEDAN»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__headliner-removalinstallation-sedan) ). Take care not to damage the headliner.
  2. Disconnect the connector (A).
  3. Remove the nut (B) from the XM antenna (C), and remove it.
  4. Install the XM antenna in the reverse order of removal.

Scheme 919

Scheme 919: Sport Wagon
  1. Remove the headliner (see «HEADLINER REMOVAL/INSTALLATION - SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__headliner-removalinstallation-sport-wagon) ).
  2. Disconnect the connectors (A) and detach the harness clip (B).
  3. Remove the nut (C) from the AM/FM/XM antenna (D).
  4. Remove the AM/FM/XM antenna and the antenna mast (E).
  5. Install the AM/FM/XM antenna in the reverse order of removal.

Scheme 920

Scheme 920: Auxiliary Jack Assembly Replacement
  1. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#consoles-4-cyl__center-console-removalinstallation) ).
  2. Disconnect the connector (A), and carefully pull out the auxiliary jack assembly (B) from the center console box.
  3. Install the auxiliary jack assembly in the reverse order of removal.

Scheme 921

Scheme 921: USB Adapter Holder Replacement
  1. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#consoles-4-cyl__center-console-removalinstallation) ).
  2. Pull out the USB adapter holder (A) from the center console, then disconnect the USB adapter connector (B).
  3. Install the USB adapter holder in the reverse order of removal.

See also:
THE HFL MESSAGES AND VOICE PROMPTS CANNOT BE HEARD OR ARE WEAK (WITHOUT NAVIGATION)
BLUETOOTH AUDIO DOES NOT WORK (WITH NAVIGATION)
BLUETOOTH AUDIO DOES NOT WORK (WITHOUT NAVIGATION)
BLUETOOTH CELL PHONE CANNOT BE PAIRED
THE COMMUNICATION WITH CELL PHONE IS INTERRUPTED OR CHANGES (WITH NAVIGATION)
PAIRING INSTRUCTIONS ARE NOT DISPLAYED ON THE SCREEN
BLUETOOTH CELL PHONE AUDIO FUNCTION SKIP AND PAUSE/RESUME DO NOT WORK (WITH NAVIGATION)
NAVIGATION THROUGH HFL MENUS
NAVIGATION UNIT CONNECTOR FOR INPUTS AND OUTPUTS
AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION
BATTERY TEST
C-PILLAR TRIM
REAR WINDOW REPLACEMENT - SEDAN
RIGHT SIDE WIRE HARNESS (SEDAN)
RIGHT SIDE WIRE HARNESS (SPORT WAGON)
AUDIO WIRE HARNESS (WITH NAVIGATION)
HANDSFREELINK CONTROL UNIT REMOVAL/INSTALLATION
ECM/PCM UPDATE
ECM/PCM REPLACEMENT
CABLE REEL REPLACEMENT
ACURALINK CONTROL UNIT UPDATE
HOW TO CHECK ERROR HISTORY (NAVIGATION DTCS)
DTC 2601: DISPLAY DIAG: CONNECT
CENTER TRIM REMOVAL/INSTALLATION
PASSENGER'S DASHBOARD TRIM REMOVAL/INSTALLATION
CENTER CONSOLE PANEL REMOVAL/INSTALLATION
CLIMATE CONTROL UNIT REMOVAL/INSTALLATION
CENTER POCKET REMOVAL/INSTALLATION
DASHBOARD CENTER VENT REMOVAL/INSTALLATION
HFL-NAVIGATION MICROPHONE REMOVAL/INSTALLATION
HAZARD WARNING SWITCH TEST/REPLACEMENT
SPEAKER COVER REMOVAL/INSTALLATION
TRUNK SIDE TRIM PANEL
REAR PARCEL SHELF DYNAMIC DAMPER
TRIM REMOVAL/INSTALLATION - CARGO AREA
SEAT SIDE BOLSTER
CENTER CONSOLE REMOVAL/INSTALLATION
FRONT DOOR PANEL REMOVAL/INSTALLATION
REAR SHELF
REAR DOOR PANEL REMOVAL/INSTALLATION
QUARTER PILLAR TRIM
REMOVAL
VOICE CONTROL SWITCH REPLACEMENT
HFL SWITCH REPLACEMENT
HEADLINER REMOVAL/INSTALLATION - SEDAN
HEADLINER REMOVAL/INSTALLATION - SPORT WAGON
POOR AM OR FM RADIO RECEPTION OR INTERFERENCE (SEDAN WITH ELS AUDIO)
AUDIO UNIT POWER SWITCH WILL NOT TURN ON (NO INFORMATION DISPLAY AND NO SOUND) (WITH ELS AUDIO)
NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) (WITH ELS AUDIO)
AUXILIARY INPUT SOUND IS LOW OR CANNOT BE HEARD (WITH ELS AUDIO)
AUDIO SYSTEM SOUND IS WEAK OR DISTORTED (DISPLAY IS NORMAL) (WITH ELS AUDIO)
RADIO PRESET MEMORY IS LOST (WITH ELS AUDIO)
VOLUME DOES NOT CHANGE (WITH ELS AUDIO)
VOLUME DOES NOT CHANGE (WITH PREMIUM AUDIO)
VOLUME DOES NOT INCREASE WITH SPEED (WITH ELS AUDIO)
VOLUME IS TOO HIGH OR TOO LOW WHEN DRIVING AT FREEWAY SPEEDS (WITH ELS AUDIO)
RADIO TUNER DOES NOT CHANGE STATIONS (WITH ELS AUDIO)
SECURITY INDICATOR DOES NOT WORK PROPERLY (WITH ELS AUDIO)
AUDIO-NAVIGATION SWITCH PANEL BUTTON ILLUMINATION DOES NOT WORK (WITH ELS AUDIO)
AUDIO SWITCH PANEL BUTTON ILLUMINATION DOES NOT WORK (WITH PREMIUM AUDIO)
AUDIO REMOTE SWITCH DOES NOT WORK PROPERLY (WITH ELS AUDIO)
AUDIO DISC DOES NOT LOAD (WITH ELS AUDIO)
AUDIO DISC DOES NOT EJECT (WITH ELS AUDIO)
AUDIO DISC DOES NOT PLAY (WITH ELS AUDIO)
AUDIO DISC SKIPS (WITH ELS AUDIO)
AUDIO DISC SKIPS (WITH PREMIUM AUDIO)
AUDIO SYSTEM BUTTON DOES NOT WORK (WITH ELS AUDIO)
AUDIO UNIT BUTTON DOES NOT WORK (WITH PREMIUM AUDIO)
AUDIO UNIT DISC INDICATOR DOES NOT WORK (WITH ELS AUDIO)
USB DEVICE DOES NOT FUNCTION (WITH ELS AUDIO)
USB INPUT SOUND IS LOW OR CANNOT BE HEARD (WITH ELS AUDIO)
ERROR CODE: XM NO SIGNAL OR XM LOADING IS DISPLAYED (WITH ELS AUDIO)
ERROR CODE: XM ANTENNA OR XM LOADING IS DISPLAYED (WITH ACURALINK)
XM RADIO DISPLAY IS BLANK AND NO STATION INFORMATION IS DISPLAYED (WITH ELS AUDIO, WITH ACURALINK)
XM RADIO PRESET MEMORY IS LOST (WITH ELS AUDIO, WITH ACURALINK)
POOR OR NO SOUND WITH XM RADIO (AUDIO UNIT DOES DISPLAY XM CHANNELS) (WITH ELS AUDIO, WITH ACURALINK)
AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION
XM SELF-DIAGNOSIS
SEEK STOP TEST
RECEPTION LEVEL INDICATION (PUSH AND HOLD 5 SEC FM/AM OR FM BUTTON)
AM/FM ANTENNA REPAIR
SPEAKER CHECK MODE
SOUND QUALITY DIAGNOSIS
AUDIO REMOTE SWITCH TEST
ERROR CODES
XM SIGNAL RECEPTION LEVEL INDICATION MODE
PHASE TEST
ELECTRICAL NOISE TEST
INDIVIDUAL SPEAKER TEST
