Acuralink (v6) Acura TSX II

Scheme 589

Scheme 590

1. Make sure the ignition switch is in LOCK (0).
2. Connect the HDS to the data link connector (DLC) (A) located under the driver's side of the dashboard.
3. Turn the ignition switch to ON (II).
4. Make sure the HDS communicates with the vehicle and the AcuraLink control unit (XM receiver). If it does not, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__dlc-circuit-troubleshooting) ).
5. Select XM/HIP in the BODY ELECTRICAL menu.
6. Select DTCs in the XM/HIP menu.
7. Check for DTCs. If any DTCs are indicated, write down the DTCs, then go to the «INDICATED DTC TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#acuralink-v6) . If no DTCs are indicated, refer to «SYMPTOM TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#acuralink-v6) . NOTE: After troubleshooting, clear the DTCs with the HDS. For specific operations, refer to the user's manual that came with the HDS.

DTC Troubleshooting Index

AcuraLink Control Unit

DTC TROUBLESHOOTING DESCRIPTION

Symptom Troubleshooting Index

SYMPTOM TROUBLESHOOTING

System Description

AcuraLink® Satellite Communication System uses the client's cell phone or XM radio to transmit and receive information about the vehicle. In addition, the AcuraLink system is also able to initiate voice or data calls with the HandsFreeLink control unit.

The AcuraLink control unit (XM receiver) is very similar in design to an XM receiver that has additional communication features. The main functions include

Scheme 591

1. Receiving and playing XM stations. Displaying station, song title and other information on the audio unit using the GA-Net bus.
2. Receiving XM traffic channel data.
3. Receiving weather data.
4. Gives Feature Guide tips.
5. Receiving AcuraLink messages and displaying them in the navigation display.
6. Processing DTC (diagnostic trouble code) error messages from the PCM, the gauge control module and other systems and displaying them on the navigation display.
7. Sending DTC information to the AcuraLink servers using the client's cell phone (only if the client has set up and enabled this option).

Service Application

1. Malfunction indicator lamp (MIL) explanation (from server message and vehicle message)
2. Service information message
3. Recall Information
4. Quick tips
5. Place to provide feedback/view cautions that were not available when vehicle was initially sold
6. Correction of address and full name that is registered
7. Real time traffic information
8. Maintenance information message
9. Feature guide (90 days)
10. Weather information

How to Delete Stored AcuraLink Messages

The AcuraLink Satellite Communication System displays and stores these types of messages on the navigation system display screen

1. Feature Guide info
2. System malfunction info
3. Driver warnings
4. DTCs
5. Quick tips NOTE: To delete any stored AcuraLink messages, follow these procedures. The first procedure is for your client. It lets him or her delete certain types of messages. The second procedure is for service techs only. It lets you delete all stored messages. Some Important Words: The diagnostic menu includes a DATA RESET function. Select this only at TQI and when the vehicle changes ownership. It deletes all AcuraLink messages, log data, and AcuraLink registration. If you select DATA RESET during the 45 days activation period, the AcuraLink Feature Guide repeats the first message. AcuraLink messages related to a repair should be deleted after that repair is done. If you do not delete these messages, they stay in your client's AcuraLink message log.

Client

1. Turn the ignition switch to ON (II).
2. Touch OK on the disclaimer screen.
3. Press the INFO/PHONE button to bring up the Information screen.
4. Use the interface dial to select # 1 All Messages.
5. Select the item number you want to delete, then select Delete (if you do not see Delete on the display screen, you cannot remove this message).
6. Select Yes to confirm your choice.

Scheme 592

Scheme 593

1. Turn the ignition switch to ON (II).
2. Touch OK on the disclaimer screen.
3. Press and hold the MAP/GUIDE, CANCEL and MENU buttons at the same time for 3 seconds more, and the self-diagnosis begins.
4. Using the interface dial, select the XM (HIP) from the Detail Information & Setting. Press the interface dial. Select XM (HIP), then select XM (HIP) ECU.
5. Select Diagnostic Info.
6. Select the item you want to delete. After the message and date come up, select Delete.
7. Select Yes to confirm your choice.
8. Repeat step 6 and 7 for each message you want to delete.

Scheme 594

Scheme 595

AcuraLink Control Unit (XM Receiver) Connector A (32P)

ACURALINK CONTROL UNIT (XM RECEIVER) CONNECTOR TERMINAL REFERENCE

AcuraLink Control Unit (XM Receiver) Connector A (32P)

ACURALINK CONTROL UNIT (XM RECEIVER) CONNECTOR TERMINAL REFERENCE

ACURALINK CONTROL UNIT (XM RECEIVER) CONNECTOR B (2P)

Scheme 596

AcuraLink Control Unit (XM Receiver) Connector B (2P)

ACURALINK CONTROL UNIT (XM RECEIVER) CONNECTOR TERMINALS REFERENCE

Scheme 597

Scheme 598

Scheme 599

Scheme 600

Self-Diagnostic Function

Note. Only select DATA RESET from the XM (HIP) ECU screen when instructed. Selecting DATA RESET clears the AcuraLink registration, and the AcuraLink service resets to the factory default. If the vehicle was already registered for the AcuraLink service, it will have to be reactivated by calling Acura Client Services before all features are available.

The AcuraLink control unit (XM receiver) has a self-diagnostic function. To run the self-diagnostic function, do the following

How to Enter the Self-Diagnostic Function

Note. Always check for and repair any CAN DTCs before troubleshooting the AcuraLink system.

Scheme 601

Scheme 602

Scheme 603

Scheme 604

1. Turn the ignition switch to ON (II).
2. Select OK on the disclaimer screen.
3. Press and hold the MAP/GUIDE, CANCEL, and MENU buttons at the same time for 3 seconds more, and the self-diagnosis begins.
4. Using the interface dial, select the Select Diagnosis Items from the Detail Information & Setting. Press the interface dial.
5. Using the interface dial, select the XM (HIP) from the Detail Information & Setting menu. Press the interface dial.
6. The display indicates XM(HIP) System Link, and does an AcuraLink connection check for each device. If a connection is faulty, the location of the fault is indicated with NG (red).
7. When red (NG) is indicated, check the continuity between the AcuraLink control unit (XM receiver) and the device indicated in red. CONTINUITY REFERENCE CHART Device Indicated in Red Test Condition Test: Desired Result Possible Cause if Result is not Obtained F-CAN Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Yaw rate-acceleration sensor 4P connector Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 7 and yaw rate acceleration sensor 4P connector terminal No. 3: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 6 and yaw rate acceleration sensor 4P connector terminal No. 2: There should be continuity. An open in the wire Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) PCM connector A (49P) Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 7 and PCM connector A (49P) terminal No. 48: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 6 and PCM connector A (49P) terminal No. 49: There should be continuity. An open in the wire Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Gauge control module 32P connector Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 7 and gauge control module 32P connector terminal No. 22: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 6 and gauge control module 32P connector terminal No. 21: There should be continuity. An open in the wire Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) TPMS control unit 20P connector Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 7 and TPMS control unit 20P connector terminal No. 1: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 6 and TPMS control unit 20P connector terminal No. 11: There should be continuity. An open in the wire Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) EPS control unit connector D (28P) Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 7 and EPS control unit connector D (28P) terminal No. 1: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 6 and EPS control unit connector D (28P) terminal No. 15: There should be continuity. An open in the wire Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) VSA modulator-control unit 46P connector Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 7 and VSA modulator-control unit 47P connector terminal No. 10: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 6 and VSA modulator-control unit 47P connector terminal No. 11: There should be continuity. An open in the wire Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) SRS unit connector A (39P) Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 7 and SRS unit connector A (39P terminal No. 17: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 6 and SRS unit connector A (39P) terminal No. 16: There should be continuity. An open in the wire Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Yaw rate-acceleration sensor 4P connector PCM connector A (49P) Gauge control module 32P connector TPMS control unit 20P connector EPS control unit connector D (28P) VSA modulator-control unit 47P connector SRS unit connector A (39P) Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 6 and No. 7 individually: There should be no continuity. A short in the wire Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 1 and No. 7 individually: There should be no continuity. A short to power in the wire Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 1 and No. 6 individually: There should be no continuity. A short to power in the wire Disconnect these items: Yaw rate-acceleration sensor 4P connector PCM connector A (49P) Gauge control module 32P connector TPMS control unit 20P connector EPS control unit connector D (28P) VSA modulator-control unit 47P connector SRS unit connector A (39P) Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 6 and No. 7 individually: There should be no continuity. A short in the AcuraLink control unit (XM receiver) Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) PCM connector A (49P) Gauge control module 32P connector TPMS control unit 20P connector EPS control unit connector D (28P) VSA modulator-control unit 47P connector SRS unit connector A (39P) Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 6 and No. 7 individually: There should be no continuity. A short in the yaw rate-acceleration sensor Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Yaw rate-acceleration sensor 4P connector Gauge control module 32P connector TPMS control unit 20P connector EPS control unit connector D (28P) VSA modulator-control unit 47P connector SRS unit connector A (39P) Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 6 and No. 7 individually: There should be no continuity. A short in the PCM Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Yaw rate-acceleration sensor 4P connector PCM connector A (49P) TPMS control unit 20P connector EPS control unit connector D (28P) VSA modulator-control unit 47P connector SRS unit connector A (39P) Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 6 and No. 7 individually: There should be no continuity. A short in the gauge control module Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Yaw rate-acceleration sensor 4P connector PCM connector A (49P) Gauge control module 32P connector EPS control unit connector D (28P) VSA modulator-control unit 47P connector SRS unit connector A (39P) Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 6 and No. 7 individually: There should be no continuity. A short in the TPMS control unit Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Yaw rate-acceleration sensor 4P connector PCM connector A (49P) Gauge control module 32P connector TPMS control unit 20P connector VSA modulator-control unit 47P connector SRS unit connector A (39P) Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 6 and No. 7 individually: There should be no continuity. A short in the EPS control unit Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Yaw rate-acceleration sensor 4P connector PCM connector A 49P) Gauge control module 32P connector TPMS control unit 20P connector EPS control unit connector D (28P) SRS unit connector A (39P) Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 6 and No. 7 individually: There should be no continuity. A short in the VSA modulator-control unit Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Yaw rate-acceleration sensor 4P connector PCM connector A (49P) Gauge control module 32P connector TPMS control unit 20P connector EPS control unit connector D (28P) VSA modulator-control unit 47P connector Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 6 and No. 7 individually: There should be no continuity. A short in the SRS unit B-CAN Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Driver's under-dash fuse/relay box connector P (20P) Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 9 and driver's under-dash fuse/relay box connector P (20P) terminal No. 6: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 8 and driver's under-dash fuse/relay box connector P (20P) terminal No. 5: There should be continuity. An open in the wire Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Passenger's under-dash fuse/relay box connector A (38P) Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 9 and passenger's under-dash fuse/relay box connector A (38P) terminal No. 11: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 8 and passenger's under-dash fuse/relay box connector A (38P) terminal No. 29: There should be continuity. An open in the wire Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Power window master switch 37P connector Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 9 and power window master switch 37P connector terminal No. 35: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 8 and power window master switch 37P connector terminal No. 33: There should be continuity. An open in the wire Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Gauge control module 32P connector Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 9 and gauge control module 32P connector terminal No. 24: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 8 and gauge control module 32P connector terminal No. 23: There should be continuity. An open in the wire Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) HandsFreeLink control unit 28P connector Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 9 and HandsFreeLink control unit 28P connector terminal No. 18: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 8 and HandsFreeLink control unit 28P connector terminal No. 17: There should be continuity. An open in the wire Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Power seat control unit connector A (40P) Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 9 and power seat control unit connector A (40P) terminal No. 40: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 8 and power seat control unit connector A (40P) terminal No. 39: There should be continuity. An open in the wire Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Climate control unit connector B (12P) Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 9 and climate control unit connector B (12P) terminal No. 1: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 8 and climate control unit connector B (12P) terminal No. 2: There should be continuity. An open in the wire Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Audio-navigation unit connector D (20P) Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 9 and audio-navigation unit connector D (20P) terminal No. 6: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 8 and audio-navigation unit connector D (20P) terminal No. 15: There should be continuity. An open in the wire Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Immobilizer-keyless control unit 7P connector Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 9 and immobilizer-keyless control unit 7P connector terminal No. 4: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 8 and immobilizer-keyless control unit 7P connector terminal No. 3: There should be continuity. An open in the wire Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Navigation display unit 28P connector Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 9 and navigation display unit 28P connector terminal No. 9: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 8 and navigation display unit 28P connector terminal No. 8: There should be continuity. An open in the wire Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Driver's under-dash fuse/relay box connector P (20P) Passenger's under-dash fuse/relay box connector A (38P) Power window master switch, 37P connector Gauge control module 32P connector HandsFreeLink control unit 28P connector Power seat control unit connector A (40P) Climate control unit connector B (12P) Audio-navigation unit connector D (20P) Immobilizer-keyless control unit 7P connector Navigation display unit 28P connector Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 8 and No. 9 individually: There should be no continuity. A short in the wire Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 1 and No. 8 individually: There should be no continuity. A short to power in the wire Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 1 and No. 9 individually: There should be no continuity. A short to power in the wire Disconnect these items: Driver's under-dash fuse/relay box connector P (20P) Passenger's under-dash fuse/relay box connector A (38P) Power window master switch 37P connector Gauge control module 32P connector HandsFreeLink control unit 28P connector Power seat control unit connector A (40P) Climate control unit connector B (12P) Audio-navigation unit connector D (20P) Immobilizer-keyless control unit 7P connector Navigation display unit 28P connector Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 8 and No. 9 individually: There should be no continuity. A short in the AcuraLink control unit (XM receiver) Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Passenger's under-dash fuse/relay box connector A (38P) Power window master switch 37P connector Gauge control module 32P connector HandsFreeLink control unit 28P connector Power seat control unit connector A (40P) Climate control unit connector B (12P) Audio-navigation unit connector D (20P) Immobilizer-keyless control unit 7P connector Navigation display unit 28P connector Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 8 and No. 9 individually: There should be no continuity. A short in the driver's under-dash fuse/relay box Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Driver's under-dash fuse/relay box connector P (20P) Power window master switch 37P connector Gauge control module 32P connector HandsFreeLink control unit 28P connector Power seat control unit connector A (40P) Climate control unit connector B (12P) Audio-navigation unit connector D (20P) Immobilizer-keyless control unit 7P connector Navigation display unit 28P connector Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 8 and No. 9 individually: There should be no continuity. A short in the passenger's under-dash fuse/relay box Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Driver's under-dash fuse/relay box connector P (20P) Passenger's under-dash fuse/relay box connector A (38P) Gauge control module 32P connector HandsFreeLink control unit 28P connector Power seat control unit connector A (40P) Climate control unit connector B (12P) Audio-navigation unit connector D (20P) Immobilizer-keyless control unit 7P connector Navigation display unit 28P connector Check for continuity between body ground and AcuraLink control unit(XM receiver) connector A (32P) terminals No. 8 and No. 9 individually: There should be no continuity. A short in the door multiplex control unit Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Driver's under-dash fuse/relay box connector P (20P) Passenger's under-dash fuse/relay box connector A (38P) Power window master switch 37P connector HandsFreeLink control unit 28P connector Power seat control unit connector A (40P) Climate control unit connector B (12P) Audio-navigation unit connector D (20P) Immobilizer-keyless control unit 7P connector Navigation display unit 28P connector Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 8 and No. 9 individually: There should be no continuity. A short in the gauge control module Disconnect these items: AcuraLink control unit(XM receiver) connector A (32P) Driver's under-dash fuse/relay box connector P (20P) Passenger's under-dash fuse/relay box connector A (38P) Power window master switch 37P connector Gauge control module 32P connector Power seat control unit connector A (40P) Climate control unit connector B (12P) Audio-navigation unit connector D (20P) Immobilizer-keyless control unit 7P connector Navigation display unit 28P connector Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 8 and No. 9 individually: There should be no continuity. A short in the HandsFreeLink control unit Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Driver's under-dash fuse/relay box connector P (20P) Passenger's under-dash fuse/relay box connector A (38P) Power window master switch 37P connector Gauge control module 32P connector HandsFreeLink control unit 28P connector Climate control unit connector B (12P) Audio-navigation unit connector D (20P) Immobilizer-keyless control unit 7P connector Navigation display unit 28P connector Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 8 and No. 9 individually: There should be no continuity. A short in the power seat control unit Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Driver's under-dash fuse/relay box connector P (20P) Passenger's under-dash fuse/relay box connector A (38P) Power window master switch 37P connector Gauge control module 32P connector HandsFreeLink control unit 28P connector Power seat control unit connector A (40P) Audio-navigation unit connector D (20P) Immobilizer-keyless control unit 7P connector Navigation display unit 28P connector Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 8 and No. 9 individually: There should be no continuity. A short in the climate control unit Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Driver's under-dash fuse/relay box connector P (20P) Passenger's under-dash fuse/relay box connector A (38P) Power window master switch 37P connector Gauge control module 32P connector Power seat control unit connector A (40P) Climate control unit connector B (12P) Audio-navigation unit connector D (20P) Immobilizer-keyless control unit 7P connector Navigation display unit 28P connector Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 8 and No. 9 individually: There should be no continuity. A short in the HandsFreeLink control unit Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Driver's under-dash fuse/relay box connector P (20P) Passenger's under-dash fuse/relay box connector A (38P) Power window master switch 37P connector Gauge control module 32P connector HandsFreeLink control unit 28P connector Climate control unit connector B (12P) Audio-navigation unit connector D (20P) Immobilizer-keyless control unit 7P connector Navigation display unit 28P connector Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 8 and No. 9 individually: There should be no continuity. A short in the power seat control unit Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Driver's under-dash fuse/relay box connector P (20P) Passenger's under-dash fuse/relay box connector A (38P) Power window master switch 37P connector Gauge control module 32P connector HandsFreeLink control unit 28P connector Power seat control unit connector A (40P) Audio-navigation unit connector D (20P) Immobilizer-keyless control unit 7P connector Navigation display unit 28P connector Check for continuity between body ground and AcuraLink control unit (XM receiver) connector A (32P) terminals No. 8 and No. 9 individually: There should be no continuity. A short in the climate control unit Navi Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Audio-navigation unit connector H (28P) Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 19 and audio-navigation unit connector H (28P) terminal No. 23: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 20 and audio-navigation unit connector H (28P) terminal No. 22: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 17 and audio-navigation unit connector H (28P) terminal No. 10: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 18 and audio-navigation unit connector H (28P) terminal No. 9: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 19 and body ground: There should be no continuity. A short in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminals No. 1 and No. 19: There should be no continuity. A short to power in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 20 and body ground: There should be no continuity. A short in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminals No. 1 and No. 20: There should be no continuity. A short to power in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 17 and body ground: There should be no continuity. A short in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminals No. 1 and No. 17: There should be no continuity. A short to power in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 18 and body ground: There should be no continuity. A short in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminals No. 1 and No. 18: There should be no continuity. A short to power in the wire Disconnect audio-navigation unit connector H (28P) Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 19 and body ground: There should be no continuity. A short in the AcuraLink control unit (XM receiver) Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 20 and body ground: There should be no continuity. A short in the AcuraLink control unit (XM receiver) Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 17 and body ground: There should be no continuity. A short in the AcuraLink control unit (XM receiver) Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 18 and body ground: There should be no continuity. A short in the AcuraLink control unit (XM receiver) Disconnect AcuraLink control unit (XM receiver) connector A (32P) Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 19 and body ground: There should be no continuity. A short in the audio-navigation unit Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 20 and body ground: There should be no continuity. A short in the audio-navigation unit Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 17 and body ground: There should be no continuity. A short in the audio-navigation unit Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 18 and body ground: There should be no continuity. A short in the audio-navigation unit HFL Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) HandsFreeLink control unit 28P connector Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 24 and HandsFreeLink control unit 28P connector terminal No. 20: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 25 and HandsFreeLink control unit 28P connector terminal No. 21: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 22 and HandsFreeLink control unit 28P connector terminal No. 7: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 23 and HandsFreeLink control unit 28P connector terminal No. 6: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 24 and body ground: There should be no continuity. A short in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminals No. 1 and No. 24: There should be no continuity. A short to power in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 25 and body ground: There should be no continuity. A short in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminals No. 1 and No. 25: There should be no continuity. A short to power in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 22 and body ground: There should be no continuity. A short in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminals No. 1 and No. 22: There should be no continuity. A short to power in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 23 and body ground: There should be no continuity. A short in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminals No. 1 and No. 23: There should be no continuity. A short to power in the wire Disconnect HandsFreeLink control unit 28P connector Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 24 and body ground: There should be no continuity. A short in the AcuraLink control unit (XM receiver) Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 25 and body ground: There should be no continuity. A short in the AcuraLink control unit (XM receiver) Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 22 and body ground: There should be no continuity. A short in the AcuraLink control unit (XM receiver) Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 23 and body ground: There should be no continuity. A short in the AcuraLink control unit (XM receiver) Disconnect AcuraLink control unit (XM receiver) connector A (32P) Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 24 and body ground: There should be no continuity. A short in the HandsFreeLink control unit Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 25 and body ground: There should be no continuity. A short in the HandsFreeLink control unit Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 22 and body ground: There should be no continuity. A short in the HandsFreeLink control unit Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 23 and body ground: There should be no continuity. A short in the HandsFreeLink control unit Audio Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Audio-navigation unit connector C (14P) Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 30 and audio-navigation unit connector C (14P) terminal No. 9: There should be continuity. An open in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 31 and audio-navigation unit connector C (14P) terminal No. 10: There should be continuity. An open in the wire Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Audio-navigation unit connector C (14P) HandsFreeLink control unit 28P connector Navigation display unit 28P connector Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 30 and body ground: There should be no continuity. A short in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminals No. 1 and No. 30: There should be no continuity. A short to power in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 31 and body ground: There should be no continuity. A short in the wire Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminals No. 1 and No. 31: There should be no continuity. A short to power in the wire Disconnect these items: Audio-navigation unit connector C (14P) HandsFreeLink control unit 28P connector Navigation display unit 28P connector Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 30 and body ground: There should be no continuity. A short in the AcuraLink control unit (XM receiver) Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 31 and body ground: There should be no continuity. A short in the AcuraLink control unit (XM receiver) Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) HandsFreeLink control unit 28P connector Navigation display unit 28P connector Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 30 and body ground: There should be no continuity. A short in the audio-navigation unit Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 31 and body ground: There should be no continuity. A short in the audio-navigation unit Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Audio-navigation unit connector C (14P) Navigation display unit 28P connector Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 30 and body ground: There should be no continuity. A short in the HandsFreeLink control unit Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 31 and body ground: There should be no continuity. A short in the HandsFreeLink control unit Disconnect these items: AcuraLink control unit (XM receiver) connector A (32P) Audio-navigation unit connector C (14P) HandsFreeLink control unit 28P connector Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 30 and body ground: There should be no continuity. A short in the navigation display unit Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 31 and body ground: There should be no continuity. A short in the navigation display unit NOTE: If the XM antenna connection condition is faulty, XM ANTENNA is indicated on the audio display.
8. If the indication does not go a way, confirm DTCs, and refer to the relevant system troubleshooting and input tests. Canceling the Self-Diagnostic Function Use the interface dial, select the Exit Diag. Press the interface dial to cancel the self-diagnostic function.

DTC B2240: XM Antenna line failure

1. Connect the HDS to the DLC (see «HOW TO CHECK FOR DTCS WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#acuralink-v6) ).
2. Clear the DTC with the HDS.
3. Turn the ignition switch to LOCK (0) and then back to ON (II) and wait 30 seconds or more.
4. Check for DTC with the HDS. Is DTC B2240 indicated? YES -Go to step 5 . NO -Intermittent failure, the XM antenna is OK at this time. Check for poor connections or loose terminals at the AcuraLink control unit (XM receiver) and the XM antenna.
5. Check the XM antenna lead connection at the XM antenna 2P connector and XM receiver connector B (2P). Are the connectors connected? YES -Substitute a known-good XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6) ), and recheck. If the symptom/indication goes away, replace the original XM antenna (see «XM ANTENNA REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6) ). If the symptom/indication is still present, update the AcuraLink control unit (see «ACURALINK CONTROL UNIT UPDATE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#acuralink-v6__acuralink-control-unit-update) ) if it does not have the latest software, then recheck. If the software is the latest, replace the AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6__acuralink-control-unit-xm-receiver-removalinstallation) ). NO -Reconnect the connector, and recheck the DTC.

Scheme 605

1. Connect the HDS to the DLC (see «HOW TO CHECK FOR DTCS WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#acuralink-v6) ).
2. Clear the DTC with the HDS.
3. Turn the ignition switch to LOCK (0) and then back to ON (II).
4. Check for DTC with the HDS. Is DTC U0100 indicated? YES -Go to step 5 . NO -Intermittent failure, the F-CAN communication line is OK at this time. Check for poor connections or loose terminals at the AcuraLink control unit (XM receiver).
5. Turn the ignition switch to LOCK (0).
6. Disconnect AcuraLink control unit (XM receiver) connector A (32P).
7. Jump the SCS line with the HDS.
8. Disconnect PCM connector A (49P).
9. Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminals No. 6 and No. 7 and PCM connector A (49P) terminals No. 49 and No. 48 respectively. Is there continuity? YES -Check for poor connections or loose terminals at the AcuraLink control unit(XM receiver). If all connections are OK, replace the AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6__acuralink-control-unit-xm-receiver-removalinstallation) ). NO -Repair an open in the wire(s) between the AcuraLink control unit (XM receiver) and the PCM.

Scheme 606

1. Connect the HDS to the DLC (see «HOW TO CHECK FOR DTCS WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#acuralink-v6) ).
2. Turn the ignition switch to ON (II).
3. Check for DTCs with the HDS and DTC log data in the navigation System Diagnostic Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-v6) ). Is DTC U0155 indicated with HDS and on the navigation display? YES -Go to step 4 . NO -Intermittent failure, the F-CAN communication line is OK at this time. Check for poor connections or loose terminals at the AcuraLink control unit (XM receiver).
4. Turn the ignition switch to LOCK (0).
5. Disconnect AcuraLink control unit (XM receiver) connector A (32P) and the gauge control module 32P connector.
6. Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminals No. 6 and No. 7 and gauge control module 32P connector terminals No. 21 and No. 22 respectively. Is there continuity? YES -Check for poor connections or loose terminals at the AcuraLink control unit (XM receiver). If all connections are OK, update the AcuraLink control unit (see «ACURALINK CONTROL UNIT UPDATE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#acuralink-v6__acuralink-control-unit-update) ) if it does not have the latest software, then recheck. If the software is the latest, replace the AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6__acuralink-control-unit-xm-receiver-removalinstallation) ). NO -Repair an open in the wire(s) between the AcuraLink control unit (XM receiver) and the gauge control module.

DTC U128D: Lost Communication with Gauge Control Module

Note. If you are troubleshooting multiple DTCs, be sure to follow the instructions in B-CAN system diagnosis test mode A (see TROUBLESHOOTING - B-CAN SYSTEM DIAGNOSIS TEST MODE A ).

Scheme 607

1. Connect the HDS to the DLC (see «HOW TO CHECK FOR DTCS WITH THE HDS»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#acuralink-v6) ).
2. Turn the ignition switch to ON (II).
3. Check for DTCs with the HDS and DTC log data in the navigation System Diagnostic Mode (see «SYSTEM DIAGNOSTIC MODE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-v6) ). Is DTC U128D indicated with HDS and on the navigation display? YES -Go to step 4 . NO -Intermittent failure, the B-CAN communication line is OK at this time. Check for poor connections or loose terminals at the AcuraLink control unit (XM receiver).
4. Turn the ignition switch to LOCK (0).
5. Disconnect AcuraLink control unit (XM receiver) connector A (32P) and the gauge control module 32P connector.
6. Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) terminals No. 8 and No. 9 and gauge control module 32P connector terminals No. 23 and No. 24 respectively. Is there continuity? YES -Check for poor connections or loose terminals at the AcuraLink control unit (XM receiver). If all connections are OK, update the AcuraLink control unit (see «ACURALINK CONTROL UNIT UPDATE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#acuralink-v6__acuralink-control-unit-update) ) if it does not have the latest software, then recheck. If the software is the latest, replace the AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6__acuralink-control-unit-xm-receiver-removalinstallation) ). NO -Repair open in the wire(s) between the AcuraLink control unit (XM receiver) and the gauge control module.

AcuraLink services do not work

Note. In order for the AcuraLink service to work, the client must have an activated account with XM (receives at least channels, 000,001,174, and 247). Verify the client account status by calling XM Radio at 800-852-9696.

Scheme 608

Scheme 609

Scheme 610

1. Check the No. 15 (10 A) fuse in the under-hood fuse/relay box. Then check the No. 5 (7.5 A) fuse and the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box. Are the fuses OK? YES -Go to step 2 . NO -Replace the fuse(s), and recheck. If the fuse(s) blows again, check for a short in the No. 15 (10 A) fuse and/or the No. 5 (7.5 A) fuse and/or the No. 18 (7.5 A) fuse circuits.
2. Turn the ignition switch to ACC (I).
3. Measure the voltage between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 3 and body ground. Is there battery voltage? YES -Go to step 4 . NO -Repair an open in the wire between the No. 18 (7.5 A) fuse in the driver's under-dash fuse/relay box and AcuraLink control unit (XM receiver) connector A (32P) terminal No. 3.
4. Turn the ignition switch to ON (II).
5. Measure the voltage between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 2 and body ground. Is there battery voltage? YES -Go to step 6 . NO -Repair an open in the wire between the No. 5 (7.5 A) fuse in the driver's under-dash fuse/relay box and AcuraLink control unit (XM receiver) connector A (32P) terminal No. 2.
6. Measure the voltage between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 28 and body ground. Is there less than 0.2 V? YES -Check for loose terminals or poor connections at the AcuraLink control unit (XM receiver) connector A (32P). If the connections are good, substitute a known-good AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6__acuralink-control-unit-xm-receiver-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6__acuralink-control-unit-xm-receiver-removalinstallation) ). NO -Repair an open or high resistance in the wire between AcuraLink control unit (XM receiver) connector A (32P) terminal No. 28 and body ground (G651) (see «RIGHT SIDE WIRE HARNESS»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-v6__right-side-wire-harness) ).

AcuraLink messages cannot be heard or are weak

Note. Check the vehicle battery condition first (see BATTERY TEST ). Check for F-CAN or B-CAN DTCs and resolve them before troubleshooting.

Scheme 611

Scheme 612

Scheme 613

Scheme 614

Scheme 615

1. Turn the ignition switch to ON (II).
2. Turn on the audio system, and check for sound in each mode (AM/FM and CD). Is the sound normal? YES -Go to step 3 . NO -Go to Sound Quality Diagnosis (see «SPECIAL TOOLS REQUIRED»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6__special-tools-required) ) or No sound is heard from the speaker(s) (display is normal) troubleshooting (see «NO SOUND IS HEARD FROM THE SPEAKER(S) (DISPLAY IS NORMAL) (WITH ELS AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6__no-sound-is-heard-from-the) ).
3. Check the audio system when AcuraLink messages are played. Does the audio system mute when AcuraLink messages are being played? YES -If audio system mutes and plays the messages at a normal volume, the system is OK at this time. If the messages are weaker than normal, go to step 4 . NO -Check for B-CAN codes. Repair any B-CAN codes, then recheck. If there are no B-CAN codes, substitute a known-good AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6__acuralink-control-unit-xm-receiver-removalinstallation) ), and recheck.
4. Turn the ignition switch to LOCK (0).
5. Disconnect AcuraLink control unit (XM receiver) connector A (32P) and audio-navigation unit connector H (28P).
6. Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) and audio-navigation unit connector H (28P) according to the table. CONTINUITY REFERENCE CHART AcuraLink control unit (XM receiver) connector Audio-navigation unit connector Wire color A17 H10 WHT A18 H9 RED A19 H23 GRN A20 H22 BLK Is there continuity? YES -Go to step 7 . NO -There is an open in the wire(s) between the AcuraLink control unit (XM receiver) and the audio-navigation unit. Replace the affected shielded harness.
7. Check for continuity between AcuraLink control unit (XM receiver) connector A (32P) and body ground according to the table. CONTINUITY REFERENCE CHART AcuraLink control unit (XM receiver) connector Wire color A17 WHT A18 RED A19 GRN A20 BLK Is there continuity? YES -There is a short to body ground in the wire(s) between the AcuraLink control unit (XM receiver) and the audio-navigation unit. Replace the affected shielded harness. NO -Go to step 8 .
8. Check for continuity between the terminal of AcuraLink control unit (XM receiver) connector A (32P) according to the table. CONTINUITY REFERENCE CHART From terminal To terminals A17 (WHT) A18 (RED), A19 (GRN), A20 (BLK), A21 (GRY) A18 (RED) A19 (GRN), A20 (BLK), A21 (GRY) A19 (GRN) A20 (BLK), A21 (GRY) A20 (BLK) A21 (GRY) Is there continuity between any of the terminals? YES -There is a short in the wires between the AcuraLink control unit (XM receiver) and the audio-navigation unit. Replace the affected shielded harness. NO -Go to step 9 .
9. Turn the ignition switch to ON (II).
10. Measure the voltage between the AcuraLink control unit(XM receiver) connector A (32P) and body ground according to the table. VOLTAGE REFERENCE CHART AcuraLink control unit (XM receiver) connector Wire color A17 WHT A18 RED A19 GRN A20 BLK Is there less than 0.1 V? YES -Go to step 11 . NO -There is a short to power in the wire(s) between the AcuraLink control unit (XM receiver) and the audio-navigation unit. Replace the affected shielded harness.
11. Substitute a known-good AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6__acuralink-control-unit-xm-receiver-removalinstallation) ), and recheck the function. Does the problem go away? YES -Update the AcuraLink control unit (see «ACURALINK CONTROL UNIT UPDATE»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#acuralink-v6__acuralink-control-unit-update) ) if it does not have the latest software, then recheck. If the software is the latest, replace the original AcuraLink control unit (XM receiver) (see «ACURALINK CONTROL UNIT (XM RECEIVER) REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6__acuralink-control-unit-xm-receiver-removalinstallation) ). NO -Substitute a known-good audio-navigation unit (including the HDD) (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-v6__audio-navigation-unit-removalinstallation) ), and recheck. If the symptom/indication goes away, replace the original audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-v6__audio-navigation-unit-removalinstallation) ).

AcuraLink Control Unit Update

Special Tools Required

1. GNA600 Kit and an iN workstation with AcuraLink update software
2. 256MB PCMCIA Memory Card
3. AcuraLink Reprogramming Cable

Note. Whenever you install a new AcuraLink control unit, you must update the control unit with the latest software. The GNA600 is the only tool currently available to update the AcuraLink control unit. If you are updating a control unit in a new vehicle, make sure all the fuses are installed. Make sure the iN workstation has the latest HDS software installed (The AcuraLink update software is contained in the HDS update CD.). The update may take up to 60 minutes. You cannot update an AcuraLink control unit with its current or previous software versions. If will only accept a new software version. Before you update the AcuraLink control unit, test the vehicle battery (see BATTERY TEST ), and only proceed if the results are good. Make sure the battery is connected to a battery booster (not a battery charger) while updating the control unit. If the battery is not in good condition, or it dies during the updating procedure, you may damage the AcuraLink control unit. If you encounter errors in the software, follow the on-screen instructions, or if necessary, reboot the iN workstation, and try again. There are five process involved in updating the AcuraLink control unit: Setting up the GNA600 Capturing the current program ID from the AcuraLink control unit Download the new software to the GNA600 Update the software in the vehicle's AcuraLink control unit Confirm the AcuraLink self-diagnosis Do the update with the ignition switch turned to LOCK (0). To prevent damage to the AcuraLink control unit, do not operate anything electrical (brakes, head lights, etc.) during the update. Check any official Honda service website for more service information about updating the AcuraLink control unit. To update the AcuraLink control unit, you must connect the GNA600 to the AcuraLink connector (A), not the DLC. Before you update an AcuraLink control unit, read the procedure. The order of connecting and disconnecting connectors is critical, and some steps must be done within a specified period of time. If the steps are not followed exactly, you may have to repeat the procedure from the start, and in some cases, you may damage the GNA600 or the AcuraLink control unit.

1. Make sure the ignition switch is turned to LOCK (0).
2. Remove the right seat-back (see «REAR SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6) ).
3. Remove the seat side bolster (see «SEAT SIDE BOLSTER»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__seat-side-bolster) ).
4. Launch the AcuraLink Update program, and follow the on-screen instructions to complete the update. NOTE: If the software in the AcuraLink control unit is the latest, disconnect the update tool from the AcuraLink connector. If the update is part of a troubleshooting or a repair procedure, return to that procedure and continue troubleshooting or repairing the vehicle.
