Under-Dash Fuse/relay Box Acura TL III

Body Electrical 1 illustration ~268 words

Removal and Installation

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before performing repairs or servicing.

Scheme 61

Scheme 61: Removal
  1. Make sure you have the anti-theft codes for the radio and the navigation system, then write down the channels for the XM radio presets. Make sure the ignition switch is OFF.
  2. Disconnect the battery negative cable, then disconnect the positive cable, and wait at least 3 minutes.
  3. Remove the left front door sill trim and left kick panel (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/tl/iii-2003-2006/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-door-areas) ).
  4. Disconnect the connectors from the fuse side of the underdash fuse/relay box (A).
  5. Remove the two mounting bolts and pull the fuse/relay box away from the body.
  6. Disconnect the connectors and remove the underdash fuse/relay box. NOTE: Some SRS harness connectors are spring-loaded lock type (see «BACKPROBING SPRING-LOADED LOCK CONNECTORS»(/acura/tl/iii-2003-2006/remont/airbag/#air-bag-srs-supplemental-restraint-system__backprobing-spring-loaded-lock-connectors) ).
  7. If replacing the fuse/relay box, carefully remove the relays by prying under the base of the relay. NOTE: Do not use pliers to remove the relays.

Installation

  1. Install the relays and connect the connectors to the underdash fuse/relay box, then install the underdash fuse/relay box in the reverse order of removal.
  2. Install the removed parts in the reverse order of removal.
  3. Connect both the positive cable and negative cable to the battery.
  4. Enter the anti-theft codes for the radio and navigation system, then enter the customer's XM radio channel presets.
  5. Confirm that all systems work properly.
