Accessory Power Sockets Acura TL III

Body Electrical 8 illustrations ~421 words

Scheme 64

Scheme 64: Component Location Index

Scheme 65

Scheme 65: Circuit Diagram

Scheme 66

Scheme 66: Front Accessory Power Socket Test/Replacement

Scheme 67

Scheme 67

Scheme 68

Scheme 68
  1. Remove the center console panel (see «CENTER CONSOLE PANEL REMOVAL/ INSTALLATION»(/acura/tl/iii-2003-2006/remont/gauges-instrument-panels/#consoles__center-console-panel-removal-installation) ).
  2. Disconnect the 2P connector from the front accessory power socket.
  3. Inspect the connector terminals to be sure they are all making good contact. If the terminals are bent, loose, or corroded, repair them as necessary, and recheck the system. If the terminals look OK, go to step 4.
  4. Turn the ignition switch to ACC (I), and check for voltage between the No. 1 terminal and body ground. There should be battery voltage. If there is battery voltage, go to step 5. If there is no battery voltage, check for: Blown No. 9 (15 A) or No. 32 (7.5 A) fuse in the under-dash fuse/relay box. Faulty accessory power socket relay. Poor ground (G503, G601). An open in the wire.
  5. Check for continuity between the No. 2 terminal and body ground. There should be continuity. If there is continuity, go to step 6. If there is no continuity, check for: Poor ground (G503, G601). An open in the wire.
  6. Remove the housing (A) and socket (B).
  7. Remove the ring (A).
  8. Install the power socket in the reverse order of removal.

Scheme 69

Scheme 69: Rear Accessory Power Socket Test/Replacement

Scheme 70

Scheme 70

Scheme 71

Scheme 71
