Connector Index
Identification numbers have been assigned to in-line connectors. The number is preceded by the letter "C" for connectors, "G" for ground terminals or "T" for non-ground terminals.
| Harness | Location |
|---|
| Engine Compartment | Dashboard | Others (Floor, Door, Trunk, and Roof) | Notes |
| Battery ground cable | (-) G1 | | | (see BATTERY GROUND CABLE ) |
| Engine ground cable A | T1 G2 | | | (see ENGINE GROUND CABLE A ) |
| Engine ground cable B | T2 G3 | | | (see CONNECTOR TO HARNESS INDEX ) |
| Starter cable | T3 and (+) T101 | | | (see STARTER CABLE ) |
| Engine wire harness | C101 through C105 C151 through C155 T102 and T103 G101 and G102 | | | (see ENGINE WIRE HARNESS (M/T) ) |
| CKP sensor subharness | C155 | | | (see CKP SENSOR SUBHARNESS ) |
| A/T subharness | C151 G151 | | | (see A/T SUBHARNESS ) |
| Transmission range switch subharness | C152 | | | (see TRANSMISSION RANGE SWITCH SUBHARNESS (A/T) ) |
| Knock sensor subharness | C154 | | | (see KNOCK SENSOR SUBHARNESS ) |
| ECM/PCM wire harness | C101, C102, C103 | C171 and C251 | | (see ECM/PCM WIRE HARNESS (DASHBOARD BRANCH) ) |
| Throttle actuator control module subharness | | C251 | | (see THROTTLE ACTUATOR CONTROL MODULE SUBHARNESS ) |
| Cable reel subharness | | C451 | | (see CABLE REEL SUBHARNESS ) |
| Front engine compartment wire harness (left branch) | C301 and C305 G301 | | | (see FRONT ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ) |
| Front engine compartment wire harness (right branch) | G201 | | | (see FRONT ENGINE COMPARTMENT WIRE HARNESS (RIGHT BRANCH) ) |
| Engine compartment wire harness (left branch) | C153 and C301 G302 | C302, C303, C304 | | (see ENGINE COMPARTMENT WIRE HARNESS (M/T) (LEFT BRANCH) ) |
| Engine compartment wire harness (right branch) | G202 and G203 | | | (see ENGINE COMPARTMENT WIRE HARNESS (RIGHT BRANCH) ) |
| Dashboard wire harness (left branch) | | C302, C303, C304, C451, C501, C502, C521, C634, C651, C851, G501, G502 | | (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) |
| Dashboard wire harness (right branch) | | C171, C503, C504, C505, C514, C731, C732 G503 through G506 | | (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) |
| Floor wire harness (left branch) | | C501, C502, C521 | C701, C751, C901 G601 and G603 | (see FLOOR WIRE HARNESS (LEFT BRANCH) ) |
| Floor wire harness (right branch) | | C503, C504, C505, C601 | C781, C801, C951 G602 and G604 | (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) |
| Rear wire harness | | | C701 G701 | (see REAR WIRE HARNESS ) |
| Rear window defogger ground wire | | | G801 | (see REAR WINDOW DEFOGGER GROUND WIRE ) |
| Roof wire harness | | C601 and C651 | | (see ROOF WIRE HARNESS ) |
| Driver's door wire harness A | | | C631, C632, C633 | (see DRIVER'S DOOR WIRE HARNESS A ) |
| Driver's door subharness | | C634 | C631 and C632 | (see DRIVER'S DOOR SUBHARNESS ) |
| Driver's door wire harness B | | | C633 | (see DRIVER'S DOOR WIRE HARNESS B ) |
| Front passenger's door wire harness | | | C733 and C734 | (see FRONT PASSENGER'S DOOR WIRE HARNESS ) |
| Front passenger's door subharness | | C731 and C732 | C733 and C734 | (see FRONT PASSENGER'S DOOR SUBHARNESS ) |
| Left rear door wire harness | | | C751 | (see LEFT REAR DOOR WIRE HARNESS ) |
| Right rear door wire harness | | | C781 | (see RIGHT REAR DOOR WIRE HARNESS ) |
| Driver's seat wire harness | | | C901 and C902 | (see DRIVER'S SEAT WIRE HARNESS ) |
| Driver's seat subharness | | | C902 | (see DRIVER'S SEAT SUBHARNESS ) |
| Front passenger's seat wire harness | | | C951 and C952 | (see FRONT PASSENGER'S SEAT WIRE HARNESS ) |
| Front passenger's seat subharness | | | C952 | (see FRONT PASSENGER'S SEAT SUBHARNESS ) |
| OPDS unit harness | | | C801 | (see OPDS UNIT HARNESS ) |
| Side curtain airbag harness | | | | (see SIDE CURTAIN AIRBAG HARNESS ) |
| A/C wire harness | | C851 | | (see A/C WIRE HARNESS ) |
Starter Cable
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| T3 | 7 | | Left side of engine compartment | Starter motor | |
| T101 | 2 | | Left side of engine compartment | Under-hood fuse/relay box | |
| (+) | 4 | | Battery | Battery positive terminal | |
CONNECTOR TO HARNESS INDEX (STARTER CABLE)
Battery Ground Cable
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| G1 | 6 | | Left side of engine compartment | Body ground, via battery ground cable | |
| (-) | 5 | | Battery | Battery negative terminal | |
CONNECTOR TO HARNESS INDEX (BATTERY GROUND CABLE)
Engine Ground Cable A
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| T1 | 8 | | Right side of engine compartment | Body ground, via battery ground cable | |
| G2 | 9 | | Right side of engine compartment | Body ground, via engine ground cable A | |
CONNECTOR TO HARNESS INDEX (ENGINE GROUND CABLE A)
Engine Ground Cable B
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| T2 | 1 | | Left side of engine compartment | Transmission housing | |
| G3 | 3 | | Left side of engine compartment | Body ground, via engine ground cable B | |
CONNECTOR TO HARNESS INDEX (ENGINE GROUND CABLE B)
Scheme 24
Engine Wire Harness (M/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/F sensor (bank 1, sensor 1) | 12 | 8 | Rear side of exhaust manifold | | |
| A/F sensor (bank 2, sensor 1) | 33 | 8 | Front side of exhaust manifold | | |
| Alternator | 38 | 4 | Right side of engine compartment | | |
| Back-up light switch | 28 | 2 | On the transmission housing | | |
| CMP sensor | 43 | 3 | Left side of engine | | |
| EGR valve and EGR valve position sensor | 31 | 6 | Left side of engine | | |
| Engine coolant temperature (ECT) sensor | 25 | 2 | Left side of engine | | |
| Engine mount control solenoid valve | 10 | 2 | Middle of engine compartment | | |
| Engine oil pressure switch | 45 | 1 | Right side of engine | | |
| EVAP canister purge valve | 14 | 2 | Left side of engine compartment | | |
| Ignition coil No. 1 | 4 | 3 | Middle of engine compartment | | |
| Ignition coil No. 2 | 6 | 3 | Middle of engine compartment | | |
| Ignition coil No. 3 | 11 | 3 | Middle of engine compartment | | |
| Ignition coil No. 4 | 39 | 3 | Middle of engine compartment | | |
| Ignition coil No. 5 | 36 | 3 | Middle of engine compartment | | |
| Ignition coil No. 6 | 34 | 3 | Middle of engine compartment | | |
| Injector No. 1 | 5 | 2 | Middle of engine compartment | | |
| Injector No. 2 | 7 | 2 | Middle of engine compartment | | |
| Injector No. 3 | 9 | 2 | Middle of engine compartment | | |
| Injector No. 4 | 41 | 2 | Middle of engine compartment | | |
| Injector No. 5 | 37 | 2 | Middle of engine compartment | | |
| Injector No. 6 | 35 | 2 | Middle of engine compartment | | |
| Input shaft (mainshaft) speed sensor | 29 | 3 | On the transmission housing | | |
| Intake air temperature (IAT) sensor | 24 | 2 | Left side of engine | | |
| Intake manifold tuning (IMT) actuator | 44 | 5 | Right side of engine | | |
| MAP sensor | 23 | 3 | Left side of engine | | |
| Output shaft (countershaft) speed sensor | 30 | 3 | On the transmission housing | | |
| Reverse lockout solenoid | 26 | 2 | On the transmission housing | | |
| Secondary HO2S (bank 1, sensor 2) | 13 | 4 | Rear side of exhaust manifold | | |
| Secondary HO2S (bank 2, sensor 2) | 32 | 4 | Front side of exhaust manifold | | |
| Starter solenoid | 27 | 1 | Left side of engine compartment | | |
| Throttle actuator and throttle position sensor | 21 | 6 | Left side of engine | | |
| Rocker arm oil pressure switch (VTEC oil pressure switch) | 46 | 2 | Right side of engine | | |
| Rocker arm oil control solenoid (VTEC solenoid valve) | 1 | 1 | Right side of engine | | |
CONNECTOR TO HARNESS INDEX (ENGINE WIRE HARNESS (M/T))
Scheme 25
CONNECTOR TO HARNESS INDEX (ENGINE WIRE HARNESS (M/T))
Scheme 26
Engine Wire Harness (A/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/F sensor (bank 1, sensor 1) | 12 | 8 | Rear side of exhaust manifold | | |
| A/F sensor (bank 2, sensor 1) | 41 | 8 | Front side of exhaust manifold | | |
| Alternator | 45 | 4 | Right side of engine compartment | | |
| A/T clutch pressure control solenoid valve A | 31 | 2 | On the transmission housing | | |
| A/T clutch pressure control solenoid valve B | 29 | 2 | On the transmission housing | | |
| A/T clutch pressure control solenoid valve C | 33 | 2 | On the transmission housing | | |
| CMP sensor | 51 | 3 | Left side of engine | | |
| EGR valve and EGR valve position sensor | 38 | 6 | Left side of engine | | |
| Engine coolant temperature (ECT) sensor | 39 | 2 | Left side of engine | | |
| Engine mount control solenoid valve | 10 | 2 | Middle of engine compartment | | |
| Engine oil pressure switch | 53 | 1 | Right side of engine | | |
| EVAP canister purge valve | 13 | 2 | Left side of engine compartment | | |
| Ignition coil No.1 | 5 | 3 | Middle of engine compartment | | |
| Ignition coil No. 2 | 7 | 3 | Middle of engine compartment | | |
| Ignition coil No. 3 | 11 | 3 | Middle of engine compartment | | |
| Ignition coil No. 4 | 46 | 3 | Middle of engine compartment | | |
| Ignition coil No. 5 | 44 | 3 | Middle of engine compartment | | |
| Ignition coil No. 6 | 42 | 3 | Middle of engine compartment | | |
| Injector No. 1 | 4 | 2 | Middle of engine compartment | | |
| Injector No. 2 | 6 | 2 | Middle of engine compartment | | |
| Injector No. 3 | 8 | 2 | Middle of engine compartment | | |
| Injector No. 4 | 49 | 2 | Middle of engine compartment | | |
| Injector No. 5 | 48 | 2 | Middle of engine compartment | | |
| Injector No. 6 | 43 | 2 | Middle of engine compartment | | |
| Input shaft (mainshaft) speed sensor | 30 | 3 | On the transmission housing | | |
| Intake air temperature (IAT) sensor | 15 | 2 | Left side of engine | | |
| Intake manifold tuning (IMT) actuator | 52 | 5 | Right side of engine | | |
| MAP sensor | 16 | 3 | Left side of engine | | |
| Output shaft (countershaft) speed sensor | 25 | 3 | On the transmission housing | | |
| Secondary HO2S (bank 1, sensor 2) | 14 | 4 | Rear side of exhaust manifold | | |
| Secondary HO2S (bank 2, sensor 2) | 40 | 4 | Front side of exhaust manifold | | |
| Shift solenoid valve A | 36 | 2 | On the transmission housing | | |
| Shift solenoid valve B | 37 | 2 | On the transmission housing | | |
| Shift solenoid valve C | 34 | 2 | On the transmission housing | | |
| Starter solenoid | 35 | 1 | Left side of engine compartment | | |
| Throttle actuator and throttle position sensor | 26 | 6 | Left side of engine | | |
| Torque converter clutch solenoid valve | 32 | 2 | On the transmission housing | | |
| Rocker arm oil pressure switch (VTEC oil pressure switch) | 54 | 2 | Right side of engine | | |
| Rocker arm oil control solenoid (VTEC solenoid valve) | 1 | 1 | Right side of engine | | |
| 4th clutch transmission fluid pressure switch | 27 | 1 | On the transmission housing | | |
CONNECTOR TO HARNESS INDEX (ENGINE WIRE HARNESS (A/T))
Scheme 27
CONNECTOR TO HARNESS INDEX (ENGINE WIRE HARNESS (A/T))
Scheme 28
A/T Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/T fluid temperature sensor | 4 | 2 | On transmission housing | | |
| 3rd clutch transmission fluid pressure switch | 3 | 1 | On transmission housing | |
| C151 | 6 | 6 | On transmission housing | Engine wire harness (see ENGINE WIRE HARNESS (M/T) ) | |
| G151 | 5 | | On transmission housing | | |
CONNECTOR TO HARNESS INDEX (A/T SUBHARNESS)
Transmission Range Switch Subharness (A/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Transmission range switch | 2 | 10 | On transmission housing | | |
| C152 | 1 | 10 | On transmission housing | Engine wire harness (see ENGINE WIRE HARNESS (M/T) ) | |
CONNECTOR TO HARNESS INDEX (TRANSMISSION RANGE SWITCH SUBHARNESS (A/T))
Scheme 29
Knock Sensor Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Knock sensor | 4 | 1 | Middle of engine compartment | | |
| C154 | 3 | 1 | Right side of engine | Engine wire harness (see ENGINE WIRE HARNESS (M/T) ) | |
CONNECTOR TO HARNESS INDEX (KNOCK SENSOR SUBHARNESS)
CKP Sensor Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| CKP sensor | 2 | 6 | Behind crankshaft pulley | | |
| C155 | 1 | 6 | Right side of engine | Engine wire harness (see ENGINE WIRE HARNESS (M/T) ) | |
CONNECTOR TO HARNESS INDEX (CKP SENSOR SUBHARNESS)
Scheme 30
ECM/PCM Wire Harness (Dashboard Branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| ECM/PCM connector A | 4 | 31 | Under middle of dash | | |
| ECM/PCM connector B | 5 | 24 | Under middle of dash | | |
| ECM/PCM connector C | 6 | 22 | Under middle of dash | | () |
| ECM/PCM connector D | 7 | 17 | Under middle of dash | | () |
| PCM connector C | 6 | 31 | Under middle of dash | | () |
| C171 | 3 | 17 | Under middle of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | () |
| C171 | 3 | 21 | Under middle of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | () |
| C251 | 2 | 13 | Under middle of dash | Throttle actuator control module subharness | () |
CONNECTOR TO HARNESS INDEX (ECM/PCM WIRE HARNESS (DASHBOARD BRANCH))
Throttle Actuator Control Module Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Throttle actuator control module | 1 | 16 | Under right side of dash | | |
| C251 | 2 | 13 | Under middle of dash | ECM/PCM wire harness | |
CONNECTOR TO HARNESS INDEX (THROTTLE ACTUATOR CONTROL MODULE SUBHARNESS)
Cable Reel Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Cruise control main switch and set/resume/cancel switch | 12 | 7 | Steering column | | |
| HFL switch/HFL-voice control switch | 9 | 5 | Steering column | | |
| Horn switch | 8 | 1 | Steering column | | |
| Radio remote switch | 10 | 7 | Steering column | | |
| C451 | 11 | 13 | Steering column | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | |
| (1) '06 model (2) '04-05 models |
CONNECTOR TO HARNESS INDEX (CABLE REEL SUBHARNESS)
Scheme 31
ECM/PCM Wire Harness (Engine Compartment Branch)
CONNECTOR TO HARNESS INDEX (ECM/PCM WIRE HARNESS (ENGINE COMPARTMENT BRANCH))
Scheme 32
Front Engine Compartment Wire Harness (Right Branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/C compressor clutch | 3 | 1 | Front of engine compartment | | |
| A/C condenser fan motor | 1 | 2 | Front of engine compartment | | |
| A/C pressure switch | 2 | 4 | Front of engine compartment | | |
| Horn (low) | 9 | 1 | Right of engine compartment | | |
| Right fog light | 4 | 2 | Behind right headlight | | |
| Right front turn signal/parking light | 8 | 3 | Behind right headlight | | |
| Right headlight (ignitor unit) | 6 | 2 | Behind right headlight | | |
| Right headlight (high/low switching solenoid) | 7 | 3 | Behind right headlight | | |
| G201 | 5 | | Right front fenderwell | Body ground, via front engine compartment wire harness | |
CONNECTOR TO HARNESS INDEX (FRONT ENGINE COMPARTMENT WIRE HARNESS (RIGHT BRANCH))
Scheme 33
Front Engine Compartment Wire Harness (Left Branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Fan control relay | 2 | 5 | Left side of engine compartment | | |
| Fog light relay/DRL relay | 1 | 4 | Left side of engine compartment | | |
| Hood switch | 15 | 2 | Front of engine compartment | | |
| Horn (high) | 5 | 1 | Left of engine compartment | | |
| Left fog light | 12 | 2 | Behind left headlight | | |
| Left front turn signal/parking light | 8 | 3 | Behind left headlight | | |
| Left headlight (igniter unit) | 11 | 2 | Behind left headlight | | |
| Left headlight (high/low switching solenoid) | 10 | 3 | Behind left headlight | | |
| Outside air temperature sensor | 14 | 2 | Front of engine compartment | | |
| Radiator fan motor | 13 | 2 | Front of engine compartment | | |
| Under-hood fuse/relay box connector F (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 3 | 20 | Left side of engine compartment | | |
| Under-hood fuse/relay box connector H (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | 4 | 14 | Left side of engine compartment | | |
| C301 | 6 | 1 | Left side of engine compartment | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (M/T) (LEFT BRANCH) ) | USA |
| C301 | 6 | 2 | Left front fenderwell | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (M/T) (LEFT BRANCH) ) | Canada |
| C305 (Junction connector) | 7 | 5 | Left side of engine compartment | | Canada |
| G301 | 9 | | Left front fenderwell | Body ground, via front engine compartment wire harness | |
CONNECTOR TO HARNESS INDEX (FRONT ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH))
Scheme 34
Engine Compartment Wire Harness (Right Branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Right front wheel sensor | 9 | 2 | Right side of engine compartment | | |
| Power steering pressure (PSP) switch | 7 | 2 | Right side of engine compartment | | |
| Right front impact sensor | 4 | 2 | Right side of engine compartment | | |
| VSA modulator-control unit | 6 | 47 | Right side of engine compartment | | |
| Washer fluid level switch | 2 | 2 | Right side of engine compartment | | Canada |
| Windshield washer motor | 3 | 2 | Right side of engine compartment | | |
| G202 | 1 | | Right front fenderwell | Body ground, via engine compartment wire harness | |
| G203 | 5 | | Right side of engine compartment | Body ground, via engine compartment wire harness | |
CONNECTOR TO HARNESS INDEX (ENGINE COMPARTMENT WIRE HARNESS (RIGHT BRANCH))
Right TPMS Subharness ('06 Model)
CONNECTOR TO HARNESS INDEX (RIGHT TPMS SUBHARNESS (06 MODEL))
Scheme 35
Engine Compartment Wire Harness (M/T) (Left Branch)
CONNECTOR TO HARNESS INDEX (ENGINE COMPARTMENT WIRE HARNESS (M/T) (LEFT BRANCH))
Left TPMS Subharness ('06 Model)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Left front initiator | 22 | 3 | Left side of engine compartment | | |
| Left side marker light | 21 | 2 | Left side of engine compartment | | |
| C306 | 18 | 6 | Under left side of dash | Engine compartment wire harness | |
CONNECTOR TO HARNESS INDEX (LEFT TPMS SUBHARNESS (06 MODEL))
Scheme 36
Engine Compartment Wire Harness (A/T) (Left Branch)
CONNECTOR TO HARNESS INDEX (ENGINE COMPARTMENT WIRE HARNESS (A/T) (LEFT BRANCH))
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Left front initiator | 22 | 3 | Left side of engine compartment | | |
| Left side marker light | 21 | 2 | Left side of engine compartment | | |
| C306 | 18 | 6 | Under left side of dash | Engine compartment wire harness | |
CONNECTOR TO HARNESS INDEX (LEFT TPMS SUBHARNESS (06 MODEL))
Scheme 37
Dashboard Wire Harness (Left branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Brake pedal position switch | 36 | 4 | Under left side of dash | | |
| Clutch interlock switch | 41 | 2 | Under left side of dash | | |
| Clutch pedal position switch | 42 | 3 | Under left side of dash | | |
| Combination switch control unit | 28 | 8 | In steering column cover | | |
| Dash lights brightness controller | 35 | 6 | Under left side of dash | | |
| Data link connector (DLC) | 12 | 16 | Under left side of dash | | |
| Driver's airbag inflator | 34 | 4 | In steering column cover | | |
| Gauge control module connector A | 22 | 30 | Behind gauge assembly | | |
| Gauge control module connector B | 24 | 18 | Behind gauge assembly | | |
| Ignition key switch | 30 | 6 | In steering column cover | | |
| Ignition switch | 32 | 7 | In steering column cover | | |
| Immobilizer control unit-receiver | 29 | 7 | In steering column cover | | |
| In-car temperature sensor | 33 | 2 | Under left side of dash | | |
| Keyless receiver unit | 18 | 5 | Under left side of dash | | |
| Power mirror control unit | 37 | 26 | Under left side of dash | | |
| Power mirror switch | 38 | 13 | Under left side of dash | | |
| Select/reset/information switch | 27 | 6 | Under left side of dash | | |
| Steering angle sensor | 23 | 5 | In steering column cover | | |
| Trunk lid opener switch | 43 | 5 | Under left side of dash | | |
| Tweeter (left side) | 17 | 2 | Left side of dash | | |
| Under-dash fuse/relay box connector A (see UNDER-DASH FUSE/RELAY BOX ) | 4 | 6 | Left kick panel | | |
| Under-dash fuse/relay box connector N (see UNDER-DASH FUSE/RELAY BOX ) | 5 | 45 | Left kick panel | | |
| Under-dash fuse/relay box connector P (MICU) (see UNDER-DASH FUSE/RELAY BOX ) | 1 | 30 | Left kick panel | | |
| Under-dash fuse/relay box connector Q (MICU) (see UNDER-DASH FUSE/RELAY BOX ) | 2 | 14 | Left kick panel | | |
| Under-dash fuse/relay box connector R (MES connector) (see UNDER-DASH FUSE/RELAY BOX ) | 6 | 2 | Left kick panel | | |
| Under-dash fuse/relay box connector S (see UNDER-DASH FUSE/RELAY BOX ) | 7 | 2 | Left kick panel | | |
| Under-dash fuse/relay box connector X (see UNDER-DASH FUSE/RELAY BOX ) | 3 | 39 | Left kick panel | | |
| VSA OFF switch | 39 | 5 | Under left side of dash | | |
CONNECTOR TO HARNESS INDEX (DASHBOARD WIRE HARNESS (LEFT BRANCH))
Scheme 38
CONNECTOR TO HARNESS INDEX (DASHBOARD WIRE HARNESS (LEFT BRANCH))
Scheme 39
Dashboard Wire Harness (Right branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/T shift lock solenoid | 39 | 2 | Under console panel | | |
| Audio amplifier connector A | 21 | 14 | Under right side of dash | | |
| Audio amplifier connector B | 20 | 20 | Under right side of dash | | |
| Audio-HVAC subdisplay unit | 9 | 10 | Middle of dash | | (1) |
| Clock | 9 | 5 | Middle of dash | | (2) |
| Audio unit connector A | 4 | 20 | Middle of dash | | |
| Audio unit connector B | 3 | 14 | Middle of dash | | |
| Audio unit connector C | 2 | 26 | Middle of dash | | |
| Display panel control unit connector A | 6 | 14 | Under middle of dash | | |
| Display panel control unit connector B | 7 | 6 | Under middle of dash | | |
| Display panel control unit connector E | 5 | 22 | Under middle of dash | | |
| Cigarette lighter light (optional) | 36 | 2 | Middle of dash | | |
| Driver's seat heater switch | 43 | 6 | Under console panel | | |
| ECM/PCM connector D | 32 | 17 | Under console panel | | '06 model |
| ECM/PCM connector E | 32 | 31 | Under console panel | | |
| Front accessory power socket | 35 | 2 | Under console panel | | |
| Front center speaker | 10 | 2 | Under console panel | | |
| Front passenger's airbag inflator | 30 | 4 | Under right side of dash | | |
| Front passenger's seat heater switch Glove box light | 42 | 6 | Under console panel | | |
| Glove box light | 17 | 2 | Under console panel | | |
| Hazard warning switch | 8 | 5 | Middle of dash | | |
| Parking brake switch | 44 | 1 | Behind rear console | | |
| Rear accessory power socket | 46 | 2 | Behind rear console | | |
| Seat heater relay | 13 | 4 | Under right side of dash | | |
| Shift lock relay | 29 | 5 | Under right side of dash | | |
| SRS unit connector A | 37 | 28 | Under console panel | | |
| Sunlight sensor | 14 | 2 | Middle of dash | | |
| Transmission gear selection switch/Park pin switch | 41 | 8 | Under console panel | | |
| Throttle actuator control module relay | 15 | 4 | Under right side of dash | | |
| Trunk lid opener main switch | 16 | 2 | Under right side of dash | | |
| Tweeter (right) | 18 | 2 | Right side of dash | | |
| Yaw rate-lateral acceleration sensor | 38 | 5 | Under console panel | | |
| (1) With navigation system (2) Without navigation system |
| (1) | With navigation system |
| (2) | Without navigation system |
CONNECTOR TO HARNESS INDEX (DASHBOARD WIRE HARNESS (RIGHT BRANCH))
Scheme 40
CONNECTOR TO HARNESS INDEX (DASHBOARD WIRE HARNESS (RIGHT BRANCH))
Console Light Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Console box light | 47 | | Behind rear console | | |
| C514 | 45 | 2 | Behind rear console | Dashboard wire harness | |
CONNECTOR TO HARNESS INDEX (CONSOLE LIGHT SUBHARNESS)
Scheme 41
Floor Wire Harness (Left Branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Left rear wheel sensor | 19 | 2 | Under left side of vehicle | | |
| Driver's door switch | 28 | 1 | Left B-pillar | | |
| Driver's seat belt tensioner | 25 | 2 | Left B-pillar | | |
| Driver's seat belt tension reducer solenoid | 26 | 2 | Left B-pillar | | |
| Driver's side airbag inflator | 23 | 2 | Under driver's seat | | |
| EVAP canister vent shut valve | 22 | 2 | Under left side of vehicle | | |
| Fuel pump/fuel gauge sending unit | 17 | 5 | Fuel tank | | |
| Fuel tank pressure (FTP) sensor | 21 | 3 | Under left side of vehicle | | |
| Left rear door switch | 18 | 1 | Left C-pillar | | |
| Left rear initiator | 20 | 3 | Under left side of vehicle | | '06 model |
| Left rear speaker | 15 | 2 | Left side of rear shelf | | |
| Left side impact sensor | 29 | 2 | Under driver's seat | | |
| TPMS control unit connector A | 13 | 14 | Middle of rear shelf | | '06 model |
| TPMS control unit connector B | 14 | 20 | Middle of rear shelf | | '06 model |
| Trunk light | 11 | 2 | Middle of rear shelf | | |
| Under-dash fuse/relay box connector E (see UNDER-DASH FUSE/RELAY BOX ) | 2 | 16 | Under left side of dash | | |
| Under-dash fuse/relay box connector F (see UNDER-DASH FUSE/RELAY BOX ) | 1 | 14 | Under left side of dash | | |
| Under-dash fuse/relay box connector G (see UNDER-DASH FUSE/RELAY BOX ) | 4 | 6 | Under left side of dash | | |
| Under-dash fuse/relay box connector H (see UNDER-DASH FUSE/RELAY BOX ) | 3 | 14 | Under left side of dash | | |
| Window antenna amplifier connector A | 8 | 1 | Left C-pillar | | |
| Window antenna amplifier connector B | 9 | 1 | Left C-pillar | | |
| Woofer speaker | 12 | 2 | Middle of rear shelf | | |
| C501 | 6 | 20 | Under left side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | |
| C502 | 5 | 8 | Under left side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | |
| C521 | 30 | 13 | Under left side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | '06 model |
| C701 | 16 | 8 | Left C-pillar | Rear wire harness (see REAR WIRE HARNESS ) | |
| C751 | 27 | 8 | Left B-pillar | Left rear door wire harness (see LEFT REAR DOOR WIRE HARNESS ) | |
| C901 | 24 | 16 | Under driver's seat | Driver's seat wire harness (see DRIVER'S SEAT WIRE HARNESS ) | |
| G601 | 7 | | Under driver's seat | Body ground, via floor wire harness | |
| G603 | 7 | | Beside of fuel pump connector | Body ground, via floor wire harness | |
CONNECTOR TO HARNESS INDEX (FLOOR WIRE HARNESS (LEFT BRANCH))
Scheme 42
Floor Wire Harness (Right branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Right rear wheel sensor | 19 | 2 | Under right side of vehicle | | |
| Front passenger's door switch | 12 | 1 | Right B-pillar | | |
| Front passenger's seat belt tensioner | 17 | 4 | Right B-pillar | | |
| Front passenger's seat belt tension reducer solenoid | 16 | 2 | Right B-pillar | | |
| Front passenger's side airbag inflator | 6 | 2 | Under front passenger's seat | | |
| Navigation inspection connector | 29 | 2 | Right side of trunk | | |
| Navigation unit connector A | 24 | 20 | Right side of trunk | | |
| Navigation unit connector B | 26 | 8 | Right side of trunk | | |
| Navigation unit connector C | 23 | 14 | Right side of trunk | | |
| Navigation unit connector D | 25 | 5 | Right side of trunk | | |
| Right brake/taillight | 30 | 3 | Right side of trunk | | |
| Right rear door switch | 18 | 1 | Right C-pillar | | '06 model |
| Right rear door initiator | 20 | 3 | Under right side of vehicle | | |
| Right rear speaker | 32 | 2 | Right side of rear shelf | | |
| Right rear side marker light | 27 | 2 | Right side of trunk | | |
| Right rear turn signal light | 31 | 2 | Right side of trunk | | |
| Right side impact sensor | 13 | 2 | Under front passenger's seat | | |
| XM receiver | 22 | 14 | Right side of trunk | | |
| XM receiver feeder cable A | 21 | | Right side of trunk | | |
| XM receiver feeder cable B | 2 | | Roof | | |
| SRS unit connector B | 4 | 28 | Under middle of dash | | |
| C503 | 8 | 12 | Under right side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) | Without Navigation |
| C504 | 10 | 17 | Under right side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) | |
| C505 | 9 | 3 | Under right side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) | |
| C601 | 11 | 13 | Under right side of dash | Roof wire harness (see ROOF WIRE HARNESS ) | With Navigation |
| C602 (Junction connector) | 15 | 24 | Under front passenger's seat | | |
| C781 | 14 | 8 | Right B-pillar | Right rear door wire harness (see RIGHT REAR DOOR WIRE HARNESS ) | |
| C801 | 5 | 4 | Under front passenger's seat | OPDS unit harness (see OPDS UNIT HARNESS ) | |
| C951 | 3 | 10 | Under front passenger's seat | Front passenger's seat wire harness (see FRONT PASSENGER'S SEAT WIRE HARNESS ) | |
| G602 | 7 | | Under front passenger's seat | Body ground, via floor wire harness | |
| G604 | 28 | Right side of trunk | Body ground, via floor wire harness | | |
CONNECTOR TO HARNESS INDEX (FLOOR WIRE HARNESS (RIGHT BRANCH))
Rear Window Defogger Ground Wire
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Rear window defogger connector B (-) | 33 | 1 | Right C-pillar | | |
| G801 | 1 | | Right C-pillar | Body ground, via rear window defogger ground wire | |
CONNECTOR TO HARNESS INDEX (REAR WINDOW DEFOGGER GROUND WIRE)
Scheme 43
Roof Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Automatic dimming inside mirror | 12 | 3 | Behind rear view mirror | | |
| Driver's vanity mirror light | 11 | 2 | Driver's sunvisor | | |
| Driver's vanity mirror light switch | 10 | 2 | Driver's sunvisor | | |
| Front passenger's vanity mirror light | 4 | 2 | Front passenger's sunvisor | | |
| Front passenger's vanity mirror light switch | 3 | 2 | Front passenger's sunvisor | | |
| Hands Free Link control unit | 5 | 22 | Roof | | |
| High mount brake light | 7 | 2 | Roof | | |
| Moonroof switch | 6 | 7 | Roof | | |
| Moonroof control unit | 9 | 10 | Roof | | |
| Noise condenser (for high mount brake light) | 15 | 2 | Roof | | |
| Rear map light | 8 | 3 | Roof | | |
| Roof console | 2 | 20 | Roof | | |
| Under-dash fuse/relay box connector W (see UNDER-DASH FUSE/RELAY BOX ) | 14 | 5 | Under left side of dash | | |
| C601 | 1 | 13 | Under right side of dash | Floor wire harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) | (1) |
| C651 | 13 | 16 | Under right side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | |
| (1) With navigation |
CONNECTOR TO HARNESS INDEX (ROOF WIRE HARNESS)
Scheme 44
Rear Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Left back-up light | 5 | 2 | Left side of trunk | | |
| Left license plate light | 4 | 2 | Middle of trunk | | |
| Left rear side marker light | 9 | 2 | Left side of trunk | | |
| Left rear turn signal light | 7 | 2 | Left side of trunk | | |
| Left taillight/brake light | 6 | 3 | Left side of trunk | | |
| Right back-up light | 1 | 2 | Right side of trunk | | |
| Right license plate light | 2 | 2 | Middle of trunk | | |
| Trunk lid latch switch/opener solenoid | 3 | 3 | Middle of trunk | | |
| C701 | 10 | 8 | Left side of trunk Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) | | |
| G701 | 8 | | Left side of trunk | Body ground, via rear wire harness | |
CONNECTOR TO HARNESS INDEX (ROOF WIRE HARNESS)
Scheme 45
Driver's Door Wire Harness A
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Left power mirror | 7 | 13 | Driver's door | | |
| Left speaker | 13 | 2 | Driver's door | | |
| Door multiplex control unit connector A | 2 | 22 | Driver's door | | |
| Door multiplex control unit connector B | 3 | 14 | Driver's door | | |
| Driver's door key cylinder switch | 15 | 3 | Driver's door | | |
| Driver's door lock actuator | 17 | 2 | Driver's door | | |
| Driver's door lock knob switch | 18 | 3 | Driver's door | | |
| Driver's door lock switch | 4 | 5 | Driver's door | | |
| Driver's power window motor | 14 | 6 | Driver's door | | |
| Driving position memory switch | 5 | 10 | Driver's door | | |
| C631 | 8 | 20 | Driver's door | | |
| C632 | 12 | 14 | Driver's door | Driver's door subharness | |
| C633 | 1 | 4 | Driver's door | Driver's door subharness | |
| C635 (Junction connector) | 6 | 20 | Driver's door | Driver's door wire harness B | |
CONNECTOR TO HARNESS INDEX (DRIVER'S DOOR WIRE HARNESS A)
Driver's Door Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Under-dash fuse/relay box connector J (see UNDER-DASH FUSE/RELAY BOX ) | 10 | 21 | Under left side of dash | | |
| Under-dash fuse/relay box connector K (see UNDER-DASH FUSE/RELAY BOX ) | 11 | 12 | Under left side of dash | | |
| C631 | 8 | 20 | Driver's door | Driver's door wire harness A | |
| C632 | 12 | 14 | Driver's door | Driver's door wire harness A | |
| C634 | 9 | 12 | Under left side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | |
CONNECTOR TO HARNESS INDEX (DRIVER'S DOOR SUBHARNESS)
Driver's Door Wire Harness B
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's door courtesy light | 16 | 2 | Driver's door | | |
| Security indicator | 19 | 2 | Driver's door | | |
| C633 | 1 | 4 | Driver's door | Driver's door wire harness A | |
CONNECTOR TO HARNESS INDEX (DRIVER'S DOOR WIRE HARNESS B)
Scheme 46
Front Passenger's Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Front passenger's door courtesy light | 9 | 2 | Front passenger's door | | |
| Front passenger's door lock actuator | 8 | 2 | Front passenger's door | | |
| Front passenger's door lock knob switch | 7 | 3 | Front passenger's door | | |
| Front passenger's door lock switch | 5 | 5 | Front passenger's door | | |
| Front passenger's power window switch | 6 | 14 | Front passenger's door | | |
| Front passenger's power window motor | 4 | 6 | Front passenger's door | | |
| Right power mirror | 3 | 13 | Front passenger's door | | |
| Right speaker | 10 | 2 | Front passenger's door | | |
| C733 | 2 | 20 | Front passenger's door | Front passenger's door subharness | |
| C734 | 11 | 14 | Front passenger's door | Front passenger's door subharness | |
CONNECTOR TO HARNESS INDEX (FRONT PASSENGER'S DOOR WIRE HARNESS)
Front Passenger's Door Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Right side marker light | 1 | 2 | Right fender | | (1) |
| C731 | 12 | 13 | Under right side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | |
| C732 | 13 | 14 | Under right side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | |
| C733 | 2 | 20 | Front passenger's door | Front passenger's door wire harness | |
| C734 | 11 | 14 | Front passenger's door | Front passenger's door wire harness | |
| (1) '04-05 models |
CONNECTOR TO HARNESS INDEX (FRONT PASSENGER'S DOOR SUBHARNESS)
Scheme 47
Left Rear Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Left rear door lock actuator | 4 | 2 | Left rear door | | |
| Left rear door lock knob switch | 5 | 3 | Left rear door | | |
| Left rear power window switch | 1 | 6 | Left rear door | | |
| Left rear power window motor | 2 | 6 | Left rear door | | |
| C751 | 3 | 8 | Left B-pillar | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) | |
CONNECTOR TO HARNESS INDEX (LEFT REAR DOOR WIRE HARNESS)
Scheme 48
Right Rear Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Right rear door lock actuator | 4 | 2 | Right rear door | | |
| Right rear door lock knob switch | 3 | 3 | Right rear door | | |
| Right rear power window switch | 2 | 6 | Right rear door | | |
| Right rear power window motor | 1 | 6 | Right rear door | | |
| C781 | 5 | 8 | Right B-pillar | Floor wire harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) | |
CONNECTOR TO HARNESS INDEX (RIGHT REAR DOOR WIRE HARNESS)
Scheme 49
Front Passenger's Seat Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Front passenger's power seat adjustment switch | 5 | 12 | Right side of front passenger's seat | | |
| Front passenger's power seat slide motor | 2 | 2 | Under front passenger's seat | | |
| Front passenger's seat belt buckle switch | 1 | 3 | Front passenger's seat | | |
| Front passenger's seat heater | 3 | 3 | Front passenger's seat | | |
| C951 | 4 | 10 | Under front passenger's seat | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) | |
| C952 | 6 | 2 | Under front passenger's seat | Front passenger's seat subharness | |
CONNECTOR TO HARNESS INDEX (FRONT PASSENGER'S SEAT WIRE HARNESS)
Front Passenger's Seat Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Front passenger's power seat recline motor | 7 | 2 | Front passenger's seat | | |
| C952 | 6 | 2 | Front passenger's seat | Front passenger's seat wire harness | |
CONNECTOR TO HARNESS INDEX (FRONT PASSENGER'S SEAT SUBHARNESS)
Scheme 50
Driver's Seat Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's power seat adjustment switch | 4 | 12 | Left side of driver's seat | | |
| Driver's power seat front up-down motor | 16 | 5 | Under driver's seat | | |
| Driver's power seat rear up-down motor | 3 | 5 | Under driver's seat | | |
| Driver's power seat slide gear box | 13 | 3 | Under driver's seat | | |
| Driver's power seat slide motor | 6 | 2 | Under driver's seat | | |
| Driver's seat belt buckle switch | 12 | 3 | Driver's seat | | |
| Driver's seat heater | 9 | 3 | Driver's seat | | |
| Driver's seat lumbar switch | 2 | 5 | Under driver's seat | | |
| Power seat control unit connector A | 15 | 20 | Under driver's seat | | |
| Power seat control unit connector B | 11 | 8 | Under driver's seat | | |
| Power seat control unit connector C | 14 | 12 | Under driver's seat | | |
| Power seat control unit connector D | 10 | 6 | Under driver's seat | | |
| C901 | 8 | 16 | Under driver's seat | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) | |
| C902 | 7 | 8 | Under driver's seat | Driver's seat subharness | |
CONNECTOR TO HARNESS INDEX (DRIVER'S SEAT WIRE HARNESS)
Driver's Seat Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Lumbar motor | 18 | 2 | Driver's seat | | |
| Recline motor | 1 | 5 | Driver's seat | | |
| Seat back heater connector A | 5 | 2 | Driver's seat | | |
| Seat back heater connector B | 17 | 2 | Driver's seat | | |
| C902 | 7 | 8 | Under driver's seat | Driver's seat wire harness | |
CONNECTOR TO HARNESS INDEX (DRIVER'S SEAT SUBHARNESS)
Scheme 51
Dashboard Wire Harness (SRS Branch)
CONNECTOR TO HARNESS INDEX (DASHBOARD WIRE HARNESS (SRS BRANCH))
Floor Wire Harness (SRS Branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's seat belt tensioner | 12 | 4 | Left B-pillar | | |
| Driver's side airbag | 15 | 2 | Under left side of dash | | |
| Front passenger's seat belt tensioner | 7 | 4 | Right B-pillar | | |
| Front passenger's side airbag | 10 | 2 | Under front passenger's seat | | |
| Left side impact sensor (1st) | 14 | 2 | Under driver's seat | | |
| Right side impact sensor (1st) | 8 | 2 | Under front passenger's seat | | |
| SRS unit connector B | 4 | 28 | Under middle of dash | | |
| C501 | 18 | 20 | Under light side dash | | |
| C801 | 11 | 4 | Under front passenger's seat. | Dashboard wire harness OPDS unit harness | |
CONNECTOR TO HARNESS INDEX (FLOOR WIRE HARNESS (SRS BRANCH))
OPDS Unit Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| OPDS unit connector D | 9 | 8 | In front passenger's seat | | |
| C801 | 11 | 4 | Under front passenger's seat | Floor wire harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) | |
CONNECTOR TO HARNESS INDEX (OPDS UNIT HARNESS)
Side Curtain Airbag Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| SRS unit connector C | 5 | 16 | Under middle of dash | | |
CONNECTOR TO HARNESS INDEX (SIDE CURTAIN AIRBAG HARNESS)
Scheme 52
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| SRS unit connector A | 1 | 28 | Under middle of dash | | |
CONNECTOR TO HARNESS INDEX (DASHBOARD WIRE HARNESS (SRS BRANCH))
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| SRS unit connector B | 2 | 28 | Under middle of dash | | |
CONNECTOR TO HARNESS INDEX (FLOOR WIRE HARNESS (SRS BRANCH))
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Left side impact sensor (2nd) | 6 | 2 | Left quarter panel | | |
| Left side curtain airbag | 7 | 2 | Left C-pillar | | |
| Right side curtain airbag | 4 | 2 | Right quarter panel | | |
| Right side impact sensor (2nd) | 5 | 2 | Right C-pillar | | |
| SRS unit connector C | 3 | 16 | Under middle of dash | | |
CONNECTOR TO HARNESS INDEX (SIDE CURTAIN AIRBAG HARNESS)
Scheme 53
A/C Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Blower motor | 7 | 2 | Under middle of dash | | |
| Climate control unit connector A | 8 | 20 | Under middle of dash | | |
| Climate control unit connector B | 9 | 16 | Under middle of dash | | |
| Driver's air mix control motor | 1 | 5 | Under middle of dash | | |
| Driver's mode control motor | 2 | 10 | Under middle of dash | | |
| Evaporator temperature sensor | 3 | 2 | Under middle of dash | | |
| Front passenger's air mix control motor | 4 | 5 | Under middle of dash | | |
| Front passenger's mode control motor | 5 | 10 | Under middle of dash | | |
| Power transistor | 10 | 4 | Under middle of dash | | |
| Recirculation control motor | 6 | 5 | Under middle of dash | | |
| C851 | 11 | 14 | Under middle of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | |
CONNECTOR TO HARNESS INDEX (A/C WIRE HARNESS)
Scheme 54
