Power Relay Test
Use this chart to identify the type of relay, then do the test listed for it.
Note. For the turn signal/hazard relay input test (see TURN SIGNAL/HAZARD RELAY INPUT TEST ).
| Relay | Test |
|---|---|
| Accessory power socket relay | Normally-open type A |
| A/C compressor clutch relay | |
| A/C condenser fan relay | |
| A/F (air fuel ratio) sensor relay | |
| Dimmer relay | |
| Fog light relay | |
| Headlight relay 1 | |
| Headlight relay 2 | |
| High beam cut relay (Canada) | |
| Horn relay | |
| Ignition coil relay | |
| PGM-FI main relay 1 | |
| PGM-FI main relay 2 | |
| Power window relay | |
| Radiator fan relay | |
| Reverse relay | |
| Rear accessory power socket relay | |
| Rear stereo amplifier relay ('03 model) | |
| Seat heater relay | |
| Starter cut relay | |
| Taillight relay | |
| Throttle actuator control module relay | |
| VTM-4 relay | |
| Blower motor relay | Normally-open type B |
| Rear blower motor relay | |
| Rear window defogger relay | |
| Automatic wiper relay | Five-terminal type |
| Fan control relay | |
| Intermittent wiper relay | |
| Key interlock relay ('05-06 models) | |
| Moonroof open relay | |
| Moonroof close relay | |
| Shift lock relay |
RELAY POWER TEST
Normally-open Type A
Check for continuity between the terminals.
Scheme 69
- There should be continuity between the No. 1 and No. 2 terminals when power and ground are connected to the No. 3 and No. 4 terminals.
- There should be no continuity between the No. 1 and No. 2 terminals when power is disconnected.
Normally-open type B
Check for continuity between the terminals.
Scheme 70
Scheme 71
Scheme 72
Scheme 73
Scheme 74
Scheme 75
- There should be continuity between the No. 1 and No. 3 terminals when power and ground are connected to the No. 2 and No. 4 terminals.
- There should be no continuity between the No. 1 and No. 3 terminals when power is disconnected.
Five-terminal Type
Check for continuity between the terminals.
Scheme 76
- There should be continuity between the No. 1 and No. 2 terminals and no continuity between the No. 4 and No. 2 terminals when power and ground are connected to the No. 3 and No. 5 terminals.
- There should be continuity between the No. 2 and No. 4 terminals and no continuity between the No. 1 and No. 2 terminals when power is disconnected.
