Under-hood Fuse/Relay Box
| Fuse Number | Amps | Wire Color | Component(s) or Circuit(s) Protected |
|---|---|---|---|
| 41 | 120 A | Battery, Power distribution | |
| 42 | 50 A | WHT | Ignition switch (BAT), Optional connector U |
| 43 | 20 A | RED/GRN | Daytime running lights control unit (Canada), Headlight (right), Fog light relay |
| 44 | Not used | ||
| 45 | 20 A | RED/YEL | Daytime running lights control unit (Canada), Dimmer relay, Headlight (left), High beam indicator |
| 46 | 15 A | WHT/GRN | Data link connector (DLC), Injectors, PGM-FI main relay 1, CMP sensor, CKP sensor A, CKP sensor B |
| 47 | 20 A | WHT/YEL | Brake lights, Driver's multiplex control unit, Horn (high), Ignition key switch, No. 90 fuse (in the auxiliary fuse holder 1), PCM, Trailer lighting connector, VSA modulator-control unit |
| 48 | 20 A | WHT | Audio unit (without rear entertainment system), Front stereo amplifier (1) , Rear stereo amplifier (3) , Stereo amplifier (2) |
| 49 | 15 A | WHT/GRN | Hazard warning lights |
| 50 | 20 A | BLK/GRN | Fog lights |
| 51 | 40 A | WHT/BLU | No. 1, 7, 8, 15, and 16 fuses (in the passenger's under-dash fuse/relay box), Power window relay |
| 52 | 30 A | RED | Rear blower motor |
| 53 | 30 A | WHT/GRN | Rear window defogger |
| 54 | 40 A | YEL | No. 9, 10, 11, 12 and 13 fuses (in the passenger's under-dash fuse/relay box) |
| 55 | 40 A | YEL/GRN | No. 2, 3, 4, 5, 6 and 14 fuses (in the passenger's under-dash fuse/relay box) |
| 56 | 40 A | YEL/BLK | Blower motor relay |
| 57 | 30 A | BLU/BLK | Radiator fan motor |
| 58 | 30 A | BLU/YEL | A/C condenser fan motor |
| 59 | 7.5 A | RED | A/C compressor clutch |
| (1) '03 model (2) '04-06 models (3) All '03 models and '04-06 models without BOSE | |||
| (1) | '03 model |
| (2) | '04-06 models |
| (3) | All '03 models and '04-06 models without BOSE |
FUSE TO COMPONENTS INDEX UNDER-HOOD FUSE/RELAY BOX
Scheme 63
Under-hood Subfuse Box
| Fuse Number | Amps | Wire Color | Component(s) or Circuit(s) Protected |
|---|---|---|---|
| 1 | 20 A | WHT/BLU (4) | Audio unit (with rear entertainment system), Rear controller and screen (with rear entertainment system), DVD player unit (with rear entertainment system) |
| WHT/RED (1) , (2) | VTM-4 control unit | ||
| 2 | 40 A | WHT/GRN | VSA modulator-control unit (+B FSR) |
| 3 | 30 A | WHT | VSA modulator-control unit (+B MTR) |
| 4 | 20 A | WHT/RED (4) | VTM-4 control unit |
| WHT/BLU (1) , (2) | Audio unit (with rear entertainment system), Rear controller and screen (with rear entertainment system), DVD player unit (with rear entertainment system) | ||
| 5 | Not used | ||
| 6 | 20 A | BLU/ORN | Rear accessory power socket |
| 7 | 15 A | WHT/GRN (1) , (2) , (5) | Throttle actuator control module |
| WHT/BLK (3) | |||
| 8 | 15 A | BLU/ORN | Ignition coils |
| 9 | 15 A | WHT/RED | A/F sensors (Bank 1, Bank 2), A/F sensor relay, Radiator fan relay, Engine mount control solenoid, EVAP canister purge valve, Secondary heated oxygen sensors (Bank 1, Bank 2), ELD unit (4) |
| 10 | 7.5 A | WHT/GRN | PCM (VBU), TPMS control unit (3) , HandsFreeLink control unit (3) |
| 11 | 20 A | WHT/BLU (1) , (3) , (5) | Power window control unit |
| WHT/BLK (2) | |||
| (1) '03 model (2) '04 model (3) '05 model (4) '04-06 models (5) '06 model | |||
| (1) | '03 model |
| (2) | '04 model |
| (3) | '05 model |
| (4) | '04-06 models |
| (5) | '06 model |
FUSE TO COMPONENTS INDEX UNDER-HOOD SUBFUSE BOX
Scheme 64
Driver's Under-dash Fuse/Relay Box
| Fuse Number | Amps | Wire Color | Component(s) or Circuit(s) Protected |
|---|---|---|---|
| 1 | 15A | RED/WHT | Fuel pump, SRS unit (VA) |
| 2 | 10A | BLK/WHT | SRS unit (VB) |
| 3 | 7.5 A | BLK/YEL | A/C compressor clutch relay, Blower motor relay, Climate control panel, Climate control unit, A/C condenser fan relay, Fan control relay, Rear blower motor relay, Rear heater-A/C control panel-unit, Rear mode control motor, Rear window defogger relay, Recirculation control motor |
| 4 | 7.5 A | ORN | Automatic inside dimming mirror, Automatic lighting control unit, Electrical compass unit (without navigation system), Multi-information display unit (without navigation system), Optional connector R, Power mirror actuator, Power mirror defogger, Seat heater relay |
| 5 | 10A | YEL/RED | Daytime running lights control unit (Canada) |
| 6 | 15A | BLK/YEL | PCM, VTM-4 relay (1) , Shift lock relay (3) |
| 7 | 7.5 A | YEL/GRN | OPDS unit, Seat weight sensor unit |
| 8 | 7.5 A | YEL/BLK | Accessory power socket relay, Optional connectors, Shift lock solenoid, Rear accessory power socket relay |
| 9 | 10A | YEL | Automatic lighting control unit, Brake light failure sensor, Cruise control main switch indicator, Driver's multiplex control unit, Driver's power seat control unit, Gauge assembly, Shift lock relay (4) , Keyless receiver unit, Passenger multiplex control unit, Passenger's airbag cutoff indicator, Rain sensor (with Auto wiper), Reverse relay, VTM-4 control unit, VTM-4 relay (5) , VTM-4 lock switch, Windshield washer motor (with Auto wiper), TPMS control unit (5) |
| 10 | 7.5 A | YEL/RED | Turn signal/hazard relay |
| 11 | 10A | BLK/YEL | Rear window intermittent wiper control unit, Rear window wiper motor, Rear window washer motor |
| 12 | 30 A | GRN/BLK | Intermittent wiper relay, Windshield washer motor, Windshield wiper motor (with Auto wiper), Automatic wiper relay (with Auto wiper) |
| 13 | Not used | ||
| (1) '03 model (2) '04 model (3) '05-06 models (4) '03-04 models (5) '04-06 models | |||
| (1) | '03 model |
| (2) | '04 model |
| (3) | '05-06 models |
| (4) | '03-04 models |
| (5) | '04-06 models |
FUSE TO COMPONENTS INDEX DRIVER'S UNDER-DASH FUSE/RELAY BOX
Scheme 65
Passenger's Under-dash Fuse/Relay Box
| Fuse Number | Amps | Wire Color | Component(s) or Circuit(s) Protected |
|---|---|---|---|
| 1 | 30 A | GRN | Moonroof motor |
| 2 | 20 A | RED | Driver's power seat rear up-down motor, Driver's power seat recline motor, Driver's power seat control unit (with DPMS) |
| 3 | 20 A | GRY | Front passenger's power seat front up-down motor, Front passenger's power seat slide motor |
| 4 | 20 A | BLU | Driver's power seat front up-down motor, Driver's power seat slide motor, Driver's power seat control unit (with DPMS) |
| 5 | 20 A | BRN | Front passenger's power seat rear up-down motor, Front passenger's power seat recline motor, Passenger's multiplex control unit |
| 6 | 10 A | RED/BLU | Daytime running lights control unit (Canada), OnStar control unit (4) |
| 7 | 20 A | WHT/YEL | Left rear window motor, Moonroof open relay () , Moonroof close relay () |
| 8 | 20 A | BLU/BLK | Front passenger's window motor |
| 9 | 15 A | WHT/RED | Audio unit, Console accessory power socket, DVD player unit (with rear entertainment system), Front accessory power socket, Headphone jack assembly (with rear entertainment system), Multi-information display unit (without navigation system), Navigation display unit, Navigation unit, Optional cigarette lighter connector, Rear controller and screen (with rear entertainment system), Rearview camera control unit (with navigation system) |
| 10 | 15 A | RED/GRN | A/T gear position indicator panel light, Audio unit light, Climate control unit light, Cruise control main switch light, Dash lights brightness controller, Driving position memory switch light, Driver's multiplex control unit, DVD player unit, Glove box light, Fog light switch light, Gauge assembly light, Hazard warning light switch light, Interior light switch light, Front parking lights, Left taillight, License plate light (left and right), Moonroof switch light, Multi-information display unit light, Navigation display unit light, Navigation unit, Optional connector T, Passenger's airbag cutoff indicator, Front side marker light, Right taillight, Seat heater switches light, Select/reset switch light, Taillight relay, Trailer lighting connector, VTM-4 lock switch light, Ambient lights (5) |
| 11 | 10 A | WHT/BLU | Cargo area light, Courtesy light, Multi-information display unit (without navigation system), Navigation display unit, Vanity mirror lights, Rear individual map light, Front individual map light/ HomeLink, Footwell lights (5) , TPMS control unit (3) |
| 12 | 20 A | Fuse/relay box socket | Passenger's multiplex control unit |
| 13 | 7.5 A | WHT/YEL | Automatic lighting control unit, Door multiplex control unit, Driver's power seat control unit (with DPMS), Driver's multiplex control unit, Driving position memory switch indicator, Gauge assembly, Immobilizer control unit-receiver, Immobilizer indicator, Keyless receiver unit, Navigation unit, Passenger's multiplex control unit, Rearview camera control unit (with navigation), Security indicator |
| 14 | 20 A | WHT/GRN | Seat heaters |
| 15 | 7.5 A | GRN/WHT | Door multiplex control unit, Power window control unit, Moonroof open relay (5) , Moonroof close relay (5) |
| 16 | 20 A | WHT/BLK | Right rear window motor |
| (1) '03 model (2) '03-04 models (3) '04 model (4) '05-06 models (5) '04-06 models | |||
| (1) | '03 model |
| (2) | '03-04 models |
| (3) | '04 model |
| (4) | '05-06 models |
| (5) | '04-06 models |
FUSE TO COMPONENTS INDEX PASSENGER'S UNDER-DASH FUSE/RELAY BOX
Scheme 66
Auxiliary Fuse Holder 1
| Fuse Number | Amps | Wire Color | Component(s) or Circuit(s) Protected |
|---|---|---|---|
| 90 | 7.5 A | BLU/RED | Horn relay |
| BLU | Horn (low) |
AUXILIARY FUSE HOLDER 1
Auxiliary Fuse Holder 3
| Fuse Number | Amps | Wire Color | Component(s) or Circuit(s) Protected |
|---|---|---|---|
| 91 | 7.5 A | BLU/WHT | Automatic wiper control unit |
| BLU/WHT | Windshield wiper motor (with automatic wiper) |
AUXILIARY FUSE HOLDER 3
Auxiliary Fuse Holder 2
| Fuse Number | Amps | Wire Color | Component(s) or Circuit(s) Protected |
|---|---|---|---|
| 92 | 7.5 A | BLK/YEL | No. 6 fuse (in the driver's under-dash fuse/relay box) |
| GRN/WHT | Alternator, ELD unit ('03 model), Immobilizer control unit-receiver, VSA modulator-control unit |
AUXILIARY FUSE HOLDER 2
