TEST SEQUENCE
| Procedure | Expected result | Remarks |
|---|---|---|
| 1. Insert the key and turn on the ignition. | The lighting in the screen's button illuminates and the system is set to standby mode. | |
| 2. Activate the DVD device on the driver's side using the remote control by first pressing and then. | Only the DVD device on the driver's side is activated and the Volvo emblem appears on the screen. | If the DVD device on the passenger side is activated, the DVD device must be recoded. See: DESIGN - Service menu for changing DRIVER/PASSENGER settings |
| 3. Activate the DVD device on the passenger side using the remote control by first pressing and then. | Only the DVD device on the passenger side is activated and the Volvo emblem appears on the screen. | If the DVD device on the driver's side is activated, the DVD device must be recoded. See: DESIGN - Service menu for changing DRIVER/PASSENGER settings |
| 4. Ensure that the correct DVD region is coded in. This is done manually on each DVD device. | See: DESIGN - Changing the region code in the DVD device | |
| 5. Ensure that the system is in standby and then switch off the ignition. |
Scheme 36
Two headsets are supplied with the system as standard. The number of headsets that can be used is unlimited as long as they are within range of the IR transmitters. Transfer of audio between DVD devices and the wireless headsets is via infrared signals. There must not be any obstacles blocking the transmitter, which is located at the top of the screen, and the receivers, which are on the side of the headsets. If the path is blocked, the signal will be interrupted and the sound quality affected. Select sound source, or, via control button: and (channel B).
The headsets are activated using a button on one side of the headsets. The headsets switch off automatically if an IR signal is not received within 3-4 minutes.
DIAGNOSTIC SYSTEM
The control module has a built-in diagnostic system, Volvo Diagnostic, which continuously monitors internal functions as well as input and output signals.
DIAGNOSTIC TROUBLE CODES (DTCS)
A diagnostic trouble code (DTC) is stored if the control module detects a fault.
If a fault disappears for any reason after the diagnostic trouble code (DTC) has been permanently stored in the control module, information about the fault remains in the control module.
READING AND ERASING DIAGNOSTIC TROUBLE CODES (DTCS)
Stored diagnostic trouble codes (DTCs) can be read off and erased using this function. Diagnostic trouble codes (DTCs) can only be erased once all the diagnostic trouble codes (DTCs) have been read off at least once.
TEST SEQUENCE AFTER INSTALLATION
| Handling | Expected result | Remarks |
|---|---|---|
| Insert the key and turn on the ignition. | RSE in standby mode, power-button lights up. | The RSE-system has a "last memory handling", that is, if the monitor was down the last time the vehicle was turned off, the monitor will be lowered when the ignition is activated again. |
| Activate RSE by pressing on the power-button. | The monitor is lowered and remaining buttons on the control panel light up. | |
| Engage reverse. | The monitor comes up. | The signal comes from the left back-up light. |
| Disengage reverse. | The monitor goes down. | |
| Remove the key. | The dialogue box on the monitor shows: "CHOOSE YES TO CONTINUE 1 HOUR" | |
| Choose "NO". | The RSE-system is inactivated and the monitor is lowered. | |
| Insert the key again and turn on the ignition. | The RSE-system is activated and the monitor is lowered. | |
| Turn off the system with the power-button. | The monitor comes up again. | This is only done so that the system shall be in stand-by the next time that the ignition is turned on. |
| Remove the key. | The RSE-system is inactivated. |
TROUBLESHOOTING INFORMATION
The roof-mounted system for rear seat entertainment (RSE) does not include any diagnostic functions and is not connected to the vehicle's CAN-net.
This means, e. g., that no diagnostic trouble codes can be read out from the unit. All troubleshooting must take place using symptom troubleshooting.
The following is troubleshooting information that may facilitate when troubleshooting in the system.
| Symptom | Malfunction cause | Malfunction investigation |
|---|---|---|
| The system does not start. | No ignition Reverse gear is engaged Poor batteries in remote control Low voltage on the car battery Blown fuse Poor connection | Switch on the ignition. Disengage reverse gear Replace batteries in remote control Start car engine Check fuse Check connections |
| Monitor does not turn off. | Poor batteries in remote control Blown fuse | Replace batteries in remote control Check fuse |
| No contact with DVD-player. | DVD-player is not selected as media source No or defect disc in DVD-player System is off Blown fuse | Select DVD-player as media source Change DVD-disc Switch on the system Check fuse |
| DVD-player does not eject disc. | System is off Blocking No or defect disc in player Blown fuse | Switch on the system Remove blocking Wait 20 seconds and try to eject disc again. If nothing happens, try inserting a disc to, see if the DVD-player is empty. Check fuse |
| System does not react to signals from remote control. | No ignition Poor batteries in remote control Blown fuse | Switch on the ignition. Replace batteries in remote control Check fuse |
| No or poor sound in headphones. | Poor batteries (only IR-headphones) Headphones not on (only IR-headphones) Headphones not correctly connected (only wired headphones) System is off Volume too low No or defect disc in DVD-player Headphones are outside IR-coverage (only IR-headphones) Incorrect media source selected | Change batteries in headphones Turn on headphones Unplug and plug in headphone cable in correct outlet Switch on the system Increase volume Eject disc. If nothing happens, try inserting a disc to, see if the DVD-player is empty. Test headphones closer to IR-transmitter Select correct media source |
| No or poor picture on monitor. | Disc cannot be copied Disc has unknown format System is not on No or defect disc in DVD-player Incorrect media source selected | Contact dealer who sold disc Use a disc with correct format Switch on the system Eject disc. If nothing happens, try inserting a disc to, see if the DVD-player is empty. Select correct media source |
| No or poor sound in loudspeakers. | Sound is off Volume too low System is not on No or defect disc in DVD-player Incorrect media source selected | Turn on sound Increase volume Switch on the system Eject disc. If nothing happens, try inserting a disc to, see if the DVD-player is empty. Select correct media source |
Scheme 37
The system can either be switched on with the POWER button or with the POWER button on the remote control.
If the system is on when the ignition is turned off, a question appears on the monitor if you want to continue using the system for another hour. Within that time, the ignition has to be turned on again, so that the system is not turned off automatically when time is up.
If the system is to be turned on with the remote control, the ignition must be on and the remote control pointed at the monitor/DVD-player.
System start-up
When the ignition is turned on, lighting is turned on in the POWER-button and the system will go to standby mode. When the POWER-button is pressed in, the system is activated and the monitor closes automatically.
The remote control can be used to turn on/off the system and navigate in the menu system
- Switch between audio/video source (DVD and AUX).
- Image adjustment (image color, brightness, contrast and aspect ratio).
- Audio settings (bass, treble, volume and balance).
- Language selection for on-screen instructions.
A permanent memory stores the shown instruction language used as well as current settings for audio and video. These settings are loaded at start with exception of the volume which is set to low level as standard.
The system is powered via X-feed and directly from the battery. If the system is operating when the ignition is switched of, a question will appear on the monitor as to whether continued play is permitted.
If the user answers YES, the system will continue playing for another 1 hour. Then the system will be turned off.
If there is no answer to the question, the system will be turned off in 1 minute.
To prevent the battery from being discharged, it is not possible to extend playing time without turning on the ignition again. There is also a voltage monitor that turns off the system if the battery voltage is too low.
When a DVD is inserted in the opening, DVD play-back starts automatically unless the DVD has a disc menu. DVD play-back can be restarted from a resting position, e. g., if the ignition is turned off when a film is playing. In this case, the film continues playing from where it stopped the last time when the ignition is turned on again.
DIAGNOSTIC SERVICES
After the software has been downloaded, diagnostic services are run if necessary, for example, programming of codes or initialisation of windows.
A diagnostic trouble code (DTC) is stored if the control module detects a fault. If a fault disappears for any reason after the diagnostic trouble code (DTC) has been permanently stored in the control module, information about the fault remains stored in the control module.
Diagnostic trouble codes (DTCs) stored in the control module can be read off using this function.
Diagnostic trouble codes (DTCs) must be read off at least once before they can be erased.
A diagnostic trouble code (DTC) is stored if the control module detects a fault. 35 diagnostic trouble codes (DTCs) can be stored. A fault which is detected in the most recent operating cycle is defined as permanent. Other faults which are detected are defined as intermittent.
Stored diagnostic trouble codes (DTCs) can be read off and erased using this function.
Diagnostic trouble codes (DTCs) can only be erased once all the diagnostic trouble codes (DTCs) have been read off at least once.
READING OFF EXTENDED DIAGNOSTIC TROUBLE CODE (DTC) INFORMATION
This function can be used to read parameters, status identifiers and counters stored at the same time as a diagnostic trouble code (DTC). These are called frozen values.
For further information, see FROZEN VALUES STEERING WHEEL MODULE, DESCRIPTION .
A diagnostic trouble code (DTC) is stored if the control module detects a fault. A fault which is detected in the most recent operating cycle is defined as permanent. Other faults are defined as intermittent.
Should a fault disappear for any reason after being permanently stored in the control module as a diagnostic trouble code (DTC), the information remains stored in the control module.
If a fault is no longer permanent, the diagnostic trouble code (DTC) remains as intermittent.
Stored diagnostic trouble codes (DTCs) can be read off and erased using this function.
Diagnostic trouble codes (DTCs) can only be erased once all the diagnostic trouble codes (DTCs) have been read off at least once.
Note. Certain functions are unavailable until the diagnostic trouble codes (DTCs) have been erased.
A diagnostic trouble code (DTC) is stored if the control module detects a fault. The control module can store up to 10 diagnostic trouble codes (DTCs).
Should a fault disappear for any reason after being stored in the control module as a diagnostic trouble code (DTC), the information remains stored in the control module. If a fault is no longer permanent, the diagnostic trouble code (DTC) remains as intermittent.
Stored diagnostic trouble codes (DTCs) can be read off and erased using this function.
This function can also be used to read off whether the fault is still present (permanent) or whether it has now ceased (intermittent) after the diagnostic trouble code (DTC) has been stored.
Diagnostic trouble codes (DTCs) can only be erased once all the diagnostic trouble codes (DTCs) have been read off at least once.
The control module will store a diagnostic trouble code (DTC) if it detects a fault. The control module can store up to 10 diagnostic trouble codes (DTCs).
If a fault disappears for any reason after the diagnostic trouble code (DTC) has been stored in the control module, information about the fault remains in the control module. If a fault is no longer permanent the diagnostic trouble code (DTC) remains as intermittent.
Stored diagnostic trouble codes (DTCs) can be read off and erased using this function.
After the diagnostic trouble code (DTC) is stored it can also be read off if the fault is still present (permanent fault), or if the fault has disappeared for any reason (intermittent fault).
Diagnostic trouble codes (DTCs) can only be erased when all diagnostic trouble codes (DTCs) have been read at least once.
DIAGNOSTIC TROUBLE CODES
If the control unit detects a fault, it stores a diagnostic trouble code. If, for any reason, a fault disappears after the diagnostic trouble code has been permanently stored in the control unit, information about the trouble code still remains in the control unit.
READING AND ERASING DIAGNOSTIC TROUBLE CODES
Stored diagnostic trouble codes can be read and erased using this facility.
Erasing diagnostic trouble codes can only be done when all the diagnostic trouble codes have been read at least once.
TCM DIAGNOSTIC TROUBLE CODES (DTCS) STATUS
The value indicates whether there are any diagnostic trouble codes (DTCs) stored in the transmission control module (TCM).
- At least one diagnostic trouble code (DTC) stored
- No diagnostic trouble code (DTC) stored
TCM DIAGNOSTIC CHECK STATUS
The value indicates whether the transmission control module (TCM) has carried out a complete diagnosis.
- At least one diagnostic test not completed
- All diagnostic tests complete
TRANSMISSION CONTROL MODULE (TCM) DIAGNOSTIC FUNCTIONS
GENERAL
The control module has a built-in diagnostic system, the Volvo on-board diagnostic (OBD) system. This system continuously monitors its own system and the input and output signals.
The control module will store a diagnostic trouble code (DTC) if it detects a fault. If a fault disappears for any reason after the diagnostic trouble code (DTC) has been permanently stored in the control module, information about the fault remains stored in the control module.
Stored diagnostic trouble codes (DTCs) can be read off and erased using this function.
Diagnostic trouble codes (DTCs) can only be erased when all diagnostic trouble codes (DTCs) have been read at least once.
DIAGNOSTIC FUNCTIONS
GENERAL
The control modules have a built-in diagnostic system, Volvo Diagnostics, which continuously monitors its own system as well as the input and output signals.
If the control module detects a fault then it stores a diagnostic trouble code. If a fault disappears for any reason after a diagnostic trouble code has been permanently stored in the control module then the information on the diagnostic trouble code remains in the control module.
Stored diagnostic trouble codes can be read off and erased using this function.
Diagnostic trouble codes can only be erased once all the diagnostic trouble codes have been read off at least once.
see DIAGNOSTIC FUNCTIONS
GENERAL
The upper electronic module (UEM) has a built-in diagnostic system, the Volvo on-board diagnostic (OBD) system, which continuously monitors itself and the input and output signals.
A diagnostic trouble code (DTC) is stored if the control module detects a fault. The control module can store up to 15 diagnostic trouble codes (DTCs).
If a fault disappears for any reason after the diagnostic trouble code (DTC) has been permanently stored in the control module, information about the fault remains in the control module.
Stored diagnostic trouble codes (DTCs) can be read off and erased using this function.
Diagnostic trouble codes (DTCs) can only be erased once all the diagnostic trouble codes (DTCs) have been read off at least once.
Note. Certain functions cannot be carried out before diagnostic trouble codes (DTCs) have been erased.
see DIAGNOSTIC FUNCTIONS
