Control Modules - Signal Specifications: Other Volvo XC90 I

Entertainment Systems 5 illustrations ~143 words

Connector C

Breakout box terminalControl module terminalSignal typeIgnition onIgnition offOther
#C-1Output, optical
#C-2Input, optical

SIGNAL TABLE

Connector C2

Breakout box terminalControl module terminalSignal typeIgnition onMiscellaneous
#C2-1MOST input signalOptical input signal when the MOST network is activated
#C2-2MOST output signalOptical output signal when the MOST network is activated

CONNECTOR C2

All the values given below are between the terminals stated in column 1 and terminal #1 in column 2 (signal ground). This applies unless otherwise indicated in brackets.

Note. It is important to connect the breakout box and check the ground terminals before taking readings.

U=DC voltage in volts (V)U AC =AC voltage in volts (V)
U bat =Battery voltage (V)F =Frequency in Hertz (Hz)
U low =Voltage approximately 0 VT =Time in seconds
PWM =Pulse width modulated signal as a %

Scheme 263

Scheme 263
Scheme 263
Control module terminalSignal typeIgnition onIdleOther
#1GroundU low
#230 supply In the XC90, the handsfree box is powered via the infotainment relay.U bat
#3
#4Loudspeaker signal (+)Alternating current when there is sound in the loudspeaker
#515 supplyU= 12 V
#6Radio mute signalDuring a call U=U low U= 12 V otherwise
#7Loudspeaker signal (-)Alternating current when there is sound in the loudspeaker
#8

CONNECTOR HANDSFREE BOX

Scheme 264

Scheme 264
Scheme 264
Control module terminalSignal typeIgnition onIdleOther
#1Handsfree antennaHandsfree antenna signal
#2Antenna groundU low

ANTENNA CONNECTOR

Scheme 265

Scheme 265
Scheme 265
Control module terminalSignal typeIgnition onIdleOther
#1MicrophoneAlternating current when there is sound in the microphone
#2Signal ground, microphoneU low

MICROPHONE CONNECTOR

Note. It is important to connect the breakout box and check ground terminals before taking readings.

There may be several connections and connectors between the control module and components.

For further information about

  1. connecting the breakout box, see "Connecting the breakout box, phone module (PHM)".
  2. checking the ground terminal, see "Checking the ground terminal, Phone module (PHM)".
U=DC voltage in volts (V)U AC =AC voltage in volts (V)
U bat =Battery voltage (V)F =Frequency in Hertz (Hz)
U low =Voltage approximately 0 VT =Time in seconds
PWM =Pulse width modulated signal as a %

CONNECTOR A, PHONE MODULE (PHM)

Control module terminalBreakout box terminalSignal typeIgnition onOther
A1#1Power groundU low
A2#2+30 supplyU bat
A3#3
A4#4CAN (L)Digital signal
A5#5
A6#6
A7#7Power supply, SIM cardU= 2.8 V
A8#8Signal ground, SIM cardUlow
A9#9Clock signal to the SIM cardQuadratic signal
A10#10
A11#11
A12#12
A13#13
A14#14CAN (H)Digital signal
A15#15
A16#16
A17#17
A18#18
A19#19Control signal, SIM cardPulsed signal
A20#20Diagnostic lead, SIM card
A21#21Communication cable, SIM cardPulsed signal
A22#22

Scheme 266

Scheme 266: CONNECTOR B, PHONE MODULE (PHM)
Scheme 266: CONNECTOR B, PHONE MODULE (PHM)
Control module terminalBreakout box terminalSignal typeIgnition onOther
B1#43
B2#44
B3#45
B4#46
B5#47
B6#48Handset, groundU low
B7#49
B8#50
B9#51
B10#52
B11#53Handset, power supplyU= 12 V when the handset is in use, otherwise U= 0 V
B12#54Handset, cradle signalU= 2.9-3.7 V when the handset is in use, otherwise U= 1.6-2.1 V
B13#55Handset, microphoneAlternating current when there is sound from the microphoneDifficult to measure
B14#56Handset, speakerAlternating current when there is sound to the loudspeakerDifficult to measure

Scheme 267

Scheme 267: CONNECTOR C, PHONE MODULE (PHM)
Scheme 267: CONNECTOR C, PHONE MODULE (PHM)
Control module terminalBreakout box terminalSignal typeIgnition onOther
AAntennaAntenna signal carphone
BGND (shield)Shield ground antenna signal

CONNECTOR D, PHONE MODULE (PHM)

TerminalBreakout box terminalSignal typeIgnition onOther
#D1MOST input signalOptical input signal when the MOST network is activated
#D2MOST output signalOptical output signal when the MOST network is activated
