Installing engine compartment components
Install the air cleaner (ACL) housing, including all hoses and electrical terminals.
Ignition off.
Remove the air cleaner housing ACL assembly with the intake pipe.
Scheme 195
Remove the gear selector from the lever and the cable mounting from the transmission.
Unhook the mounting with the connector for the transmission from the bracket for the air cleaner (ACL) housing.
Remove the tie straps for the cable harness and the mounting in the cover for the control system.
Separate the connector for the gear-shift position sensor. Remove the gear-shift position sensor from the mounting.
Scheme 196
Remove
- the lever for the gear shift linkage rod
- the nut, locking washer and rubber seal securing the gear-shift position sensor to the gear shift linkage rod
- the 2 screws
- the gear-shift position sensor.
