Lighting - Installation: Removal & Installation Volvo V70 II

Installation Kit For Auxiliary Lights

Note. Auxiliary lamps Alpha 175 (P/N 9166090) are recommended for this installation kit.

Scheme 100

Applies to cars with manual gearboxes

1. Turn the ignition key to position "0", and take the key from the ignition switch.

Applies to cars with automatic gearboxes

1. Turn the ignition key to position "I".

Applies to all cars

1. Disconnect the battery negative lead. NOTE: Wait at least five minutes before disconnecting the connectors or removing other electrical equipment.

Scheme 101

1. Press in the centers of the six clips until a click is heard. Remove the clips.
2. Pull the top edge of the front forward.
3. Put your hand into the inside and press the four catches, which are evenly spaced along the top edge - up. Use a weatherstrip tool if necessary.
4. Pull the front grille at the top until the catches release.

Scheme 102

1. Detach the front grille at the bottom by inserting a small screwdriver between the openings and pressing the three catches down.
2. Remove the front grille and place it to one side.

Scheme 103

1. Remove the intake manifold (1).

Scheme 104

1. Lift up the air cleaner (ACL) module by detaching it from its three mountings: one at the rear, one in the front and one at the left-hand end face. Use a small socket with an extension to press the four catches together, and detach the air cleaner (ACL) module.

Scheme 105

1. Move the air cleaner (ACL) module aside and affix it using a cord for example, as illustrated.

Scheme 106

1. Move the rubber seal (1) aside, on the left-hand side behind the front grille. Take the cable harness (2) from the kit and position it in the engine compartment. Following which, route the cable harness to the left of the headlamp at the top and through the cut-out in the body at the rubber seal.
2. Move the rubber seal back, and make sure that it seals firmly.

Scheme 107

1. Grip the front grille (1) and guide the cable harness (2) through the sixth hole (3), counting from the left-hand headlamp.
2. Reinstall the front grille and the clips which hold the front at the top.

Scheme 108

Remove

1. the number plate
2. the screws (1) for the number plate, and detach it.

Scheme 109

1. Take the auxiliary lights bracket (1) from the kit and secure it in the holes (2) for the number plate holder. Use the lower holes in the bracket. Applies to cars up to and including model year -2004 V70: approx. 52 mm (2.05") behind the cover NOTE: Hold the drill horizontally.
2. Drill with a ø7 mm (9/32") diameter drill bit right in the center of the holes (3) through the bumper cover and the bumper rail (which is located at different depths, depending on model): Applies to cars up to and including model year -2004 V70: approx. 52 mm (2.05") behind the cover NOTE: Hold the drill horizontally.
3. Remove the screws and auxiliary lights bracket.

Scheme 110

1. Drill the holes (1) with a drill bit (P/N 8633152), through the plastic with the thicker section of the drill bit, and through the bumper rail (2) with the thinner section of the drill bit, which has the dimension ø7.3 mm (19/64") . NOTE: It is important that the tip of the drill bit meets the hole that was previously drilled into the bumper rail.
2. The flat surface on the drill bit shall drill out all plastic up to the bumper rail. NOTE: Hold the drill horizontally. Use a torch to check that there is no plastic shavings in the holes.

Illustration A

Scheme 111

Applies to cars up to and including model year -2004

1. Check that the surface (1), which the socket shall support against, is free from plastic. V70: Length approx. 53.5 mm (2.11")
2. Install the two spacer sleeves in the holes. V70: Length approx. 53.5 mm (2.11") NOTE: The spacer sleeves must protrude from the bumper cover at different lengths, depending on car model: V70: approx. 1 mm (0.04") from the bumper cover

Illustration B

Scheme 112

Applies to cars from model year 2005

1. Check that the surface (1), which the socket shall support against, is free from plastic. V70: Length approx. 63.5 mm (2.5")
2. Install the two spacer sleeves in the holes. V70: Length approx. 63.5 mm (2.5") NOTE: The spacer sleeves must protrude approx. 2 mm (0.08") from the bumper cover on all car models.

Scheme 113

1. Drill two new holes in the number plate holder.

Scheme 114

1. Affix tie straps (1) in the holes in the auxiliary lights bracket, but do not tighten.
2. Install the auxiliary lights bracket on the bumper using the screws (2) from the kit. Tighten loosely. The screws create their own threads in the drilled holes, which means that they may screw in stiffly.

Scheme 115

1. Guide in the two cable ends (1) in the three tie straps (2). Route the cables as illustrated.
2. Adapt the length of the cable to the lamps. Press back any excess length of the cable outside of the front grille in through the front grille.
3. Tighten the tie straps. NOTE: Tighten the two screws for the auxiliary lights bracket.
4. Install a spacer washer (3) between the auxiliary lights bracket (4) and the expander nut (5) on both sides.
5. Install the number plate and tighten it with the two screws.

Scheme 116

Use auxiliary lights which are recommended by Volvo dealers.

1. Remove the screw (1) and the cover.
2. Press lightly on the lens (2).
3. Fit a screwdriver (3) between the insert and the lamp housing, and prize carefully.

Scheme 117

1. Install the lamp housing on the auxiliary lights mounting with screw and nut. Tighten manually.

Scheme 118

1. Route the cable harness (1) with rubber grommet (1) into the holes in the lamp housing.
2. Press the rubber grommet into the hole.

Scheme 119

1. Connect the blue (BL) cable to the lamp's cable, with a connector socket housing in between.
2. Connect the black (SB) cable to ground on the light insert.

Scheme 120

1. Assemble the auxiliary light, as illustrated.

Scheme 121

1. Take the previously routed cable harness (1) and route it as illustrated.
2. Plug the connector (2) into the pre-routed connector.
3. Press in the relay (3) at the edge of the plate.
4. Detach the existing screw (4) in the air cleaner (ACL) module bracket and connect the ground cable. Pull any excess length of the cable through the front grille and clamp it with the existing cables behind the headlamp using tie straps from the kit.
5. Reinstall the air cleaner (ACL) module and the intake manifold. NOTE: Ensure that the wiring does not rub against sharp edges. If the wiring is rubbing, re-secure the wiring.

Illustration A

Scheme 122

Applies to cars up to model year -2005

1. Remove the cover from the fuse box in the engine compartment. Install a 20A fuse in position 2 (1).
2. Reinstall the cover.

Illustration B

Scheme 123

Applies to cars from model year 2006

1. Remove the cover from the fuse box in the engine compartment. Install a 20A fuse in position 5.
2. Reinstall the cover.

Scheme 124

1. Remove the panel in front of the gear selector lever. Pry off the panel using a plastic weatherstrip tool.
2. Apply the handbrake, and move the gear selector lever as far back as possible.

Scheme 125

1. Remove the two screws from the dashboard environment panel.

Scheme 126

1. Carefully angle the dashboard environment panel using a plastic weatherstrip tool, so that the short side of the dashboard environment panel can be gripped with a couple of fingers.
2. Remove the dashboard environment panel by pulling it straight down while maintaining the angle. The panel is fitted securely, so some force is required to detach it.
3. Disconnect the connectors on the reverse of the dashboard environment panel. Place the dashboard environment panel to one side. NOTE: If any of the outer hooks fail then this must be rectified. See the section on the dashboard in the appropriate article.

Scheme 127

1. Remove the cigarette lighter.
2. Fit the dashboard environment panel as illustrated.
3. Detach the surround (1) by carefully pressing the three catches (2) down in the holes (3) with a small screwdriver while prizing out the surround with a thin plastic weatherstrip tool. Start at the 12V socket (4) and prize up one corner. The surround is secured firmly so take care of the components. NOTE: The surround with three button places must be replaced with a surround with seven button places if necessary. This can be purchased separately.

Scheme 128

1. Remove the cover plug to the 12V socket.

Scheme 129

1. Carefully remove the panel for the keypad using a scriber with angled tip. Pull out one corner of the panel using the scriber until the catches release. It is secured with three catches on each long side. Continue to pull along the panel until all catches have released.

Scheme 130

1. Remove the dummy button and install the new switch (1) in any available position.
2. Reinstall the surround and the cover plug.

Preparations And Installation

1. Move the left front seat to the rearmost position.

Scheme 131

1. Raise the car
2. Cut out the embossed covers (1) on the left and right-hand sides of the bumper cover. NOTE: Cut around the outer (2) marking.
3. Score around the marking
4. Carefully cut through the material
5. Remove the cut-out section. Sand the edges if necessary.

Applies to cars with air baffles on the left and right-hand sides

Scheme 132

Remove

1. the screw (1) in the air baffle (2) on both sides
2. the air baffle by pulling backwards.

Scheme 133

1. Remove the screws (1). Slacken off the air baffle (2)
2. Release the catches (3). Pull the air baffle backward
3. Remove the air baffle.

Applies to model year 01

Scheme 134

Remove

1. the pre-routed connector (1) from the parking connector in the fog lamp mounting
2. the parking connector from the fog lamp mounting. This will not be reused.

1. Repeat the operation on the other side.

Scheme 135

1. Install the spring nuts (1) in the holes on the left and right-hand sides.

Scheme 136

1. Install a fog lamp on the right and left-hand sides. Use the screws (1) (from the kit).

Scheme 137

Scheme 138

1. Take the cable harness from the kit. Connect the short cable end (1) to the left-hand fog lamp. Connect the long cable end to the right-hand fog lamp
2. Press the cable into the two clamps (2)
3. Connect the connector (3) to the pre-routed connector at the left-hand wing liner
4. Press the cable harness for the right-hand fog lamp into place under the air intake. Use the existing clamps (1). See illustration B.

Scheme 139

1. Connect the pre-routed connectors to the fog lamps on the right and left-hand sides.

1. Move the left front seat to the rearmost position
2. Turn the ignition key to position 0.

1. Raise the car.

Applies to cars with air baffles on the left and right-hand sides

1. Remove the screw (1) in the air baffle (2) on both sides
2. Remove the air baffle. Pull the air baffle backwards.

1. Remove the screws (1). Slacken off the center air baffle (2)
2. Release the catches (3). Pull the air baffle backwards
3. Remove the air baffle.

Scheme 140

1. Remove the covers (1) on the right and left-hand sides.

Scheme 141

1. Install the spring nuts (1) from the kit in the hole for the mounting for the fog lamps
2. Disconnect the pre-routed connector (2) from its location
3. Repeat the operation on the other side.

1. Install the fog lamp. Tighten using the three screws (1) from the kit
2. Repeat the operation on the other side.

1. Connect the pre-routed connector to the fog lamp on the right and left-hand sides
2. Reinstall the center air baffle.

Illustration A applies only to the USA

Scheme 142

Illustration B applies to other markets

1. Remove the cover (1) on the lighting control panel
2. Install the fibre optic (2) and the button (3) from the kit. Press the button into place
3. Program the software. See the appropriate service information
4. Check the function. Align the lamps
5. Reinstall the air baffles at the sides (if applicable).

1. Move the front seat to its rearmost position.

1. Raise the car
2. Cut out the embossed covers (1) on the left and right-hand side of the bumper.

Note. Cut around the outer (2) marking.

1. Score around the marking
2. Carefully cut through the material
3. Remove the cover. Sand the edges if necessary.

1. Remove the screw (1) from the air baffle (2) for the front brake
2. Remove the air baffle. Pull it backward.

1. Remove the screws (1). Slacken off the air baffle (2)
2. Release the catches (3). Pull the air baffle backward
3. Remove the air baffle.

1. Install the spring nuts (1) in the holes.

1. Install the fog lamp with the screws (1) from the kit.

Installation Kit, Auxiliary Lights

Note. The Alpha 175 (part no. 9166090) auxiliary lights are recommended for this installation kit.

Installation, Auxiliary Lights

1. Take the auxiliary lights bracket (1) from the kit and secure it in the holes (2) for the number plate holder. V70: Use the lower holes in the bracket. Applies to cars up to and including model year -2004 V70: approx. 52 mm (2.05') behind the cover
2. Drill with a ø7 mm (9/32') diameter drill bit right in the center of the holes (3) through the bumper cover and the bumper rail (which is located at different depths, depending on model): Applies to cars up to and including model year -2004 V70: approx. 52 mm (2.05') behind the cover
3. Remove the screws and auxiliary lights bracket.

1. Drill the holes (1) with a drill bit (part no. 8633152), through the plastic with the thicker section of the drill bit, and through the bumper rail (2) with the thinner section of the drill bit, which has the dimension ø7.3 mm (19/64') . NOTE: It is vital that the tip aligns with the previously drilled holes in the bumper rail.
2. The flat surface on the drill bit shall drill out all plastic up to the bumper rail. NOTE: Hold the drill horizontal. Check that the drill holes are free from plastic residue by shining a torch into the holes.

Illustration A

Applies to cars up to and including model year -2004

1. Check that the surface (1), which the socket shall support against, is free from plastic. V70: Length approx. 53.5 mm (2.11')
2. Install the two spacer sleeves in the holes. V70: Length approx. 53.5 mm (2.11')
3. NOTE: The spacer sleeves must protrude from the bumper cover at different lengths, depending on car model: V70: approx. 1 mm (0.04') from the bumper cover

Illustration B

Applies to cars from model year 2005

1. Check that the surface (1), which the socket shall support against, is free from plastic. V70: Length approx. 63.5 mm (2.5')
2. Install the two spacer sleeves in the holes. V70: Length approx. 63.5 mm (2.5')
3. NOTE: The spacer sleeves must protrude approx. 2 mm (0.08") from the bumper cover on all car models.

1. Drill two new holes in the number plate holder, as illustrated.

1. Affix tie straps (1) in the holes in the auxiliary lights bracket, but do not tighten.
2. Install the auxiliary lights bracket on the bumper using the screws (2) from the kit. Tighten loosely. The screws create their own threads in the drilled holes, which means that they may screw in stiffly.

1. Guide in the two cable ends (1) in the three tie straps (2). Route the cables as illustrated.
2. Adapt the length of the cable to the lamps. Press back any excess length of the cable outside of the front grille in through the front grille.
3. Tighten the tie straps. NOTE: Tighten the two screws to the auxiliary lights bracket.
4. Install a spacer washer (3) between the auxiliary lights bracket (4) and the expander nut (5) on both sides.
5. Install the number plate and tighten it with the two screws.

Use auxiliary lights which are recommended by Volvo dealers.

1. Remove the screw (1) and the cover.
2. Press lightly on the lens (2).
3. Fit a screwdriver (3) between the insert and the lamp housing, and prize carefully.
