Supplemental Restraint System (SRS) - Specifications, Electrical/electronic: Overview Volvo S80 I

Passive Restraints 1 illustration

Scheme 12

Scheme 12: Signal Specification

Note. It is important to connect the breakout box and check the ground terminals before taking readings.

Two breakout boxes are required to take readings from the SRS control module.

Note. The terminals for connector C are split between breakout boxes 1 and 2. From model year 2003, the connectors are numbered 1-84.

  1. Terminals #1A-#28A correspond to terminals #1-#28
  2. Terminals #1B-#28B correspond to terminals #29-#56
  3. #1C-#28C correspond to #57-#84
Breakout boxTerminal control module -02Terminal control module 03FunctionOther
1#1A#1Signal ground
2#2A#2Signal ground
3#3A#3Front left side impact protection (SIPS) bag (-)Monitoring signal at normal status. Ignition pulse on deployment.
4#4A#4Front left side impact protection (SIPS) bag (+)Monitoring signal at normal status. Ignition pulse on deployment.
5#5A#5Front left seat belt tensioner (+)Monitoring signal at normal status. Ignition pulse on deployment.
6#6A#6Belt tensioner, front left (-)Monitoring signal at normal status. Ignition pulse on deployment.
7#7A#7
8#8A#8Side impact sensor, left front
9#9A#9Side impact sensor, left front
10#10A#10
11#11A#11
12#12A#12
13#13A#13
14#14A#14
15#15A#15Belt tensioner, rear left (-)Monitoring signal at normal status. Ignition pulse on deployment.
16#16A#16Belt tensioner, rear left (+)Monitoring signal at normal status. Ignition pulse on deployment.
17#17A#17Rear center seat belt tensioner (+)Monitoring signal at normal status. Ignition pulse on deployment. Replaced by pin 24C from VIN 116811.
18#18A#18Rear center seat belt tensioner (-)Monitoring signal at normal position. Ignition pulse on deployment. Replaced by pin 23C from chassis number 116811 inclusive.
19#19A#19
20#20A#20
21#21A#21Left inflatable curtain (+)Monitoring signal at normal status. Ignition pulse on deployment.
22#22A#22Left inflatable curtain (-)Monitoring signal at normal status. Ignition pulse on deployment.
23#23A#23
24#24A#24
25#25A#25
26#26A#26
27#27A#27Side impact sensor, rear left
28#28A#28Side impact sensor, rear left
29#1B#29
30#2B#30Collision signalSignal to the central electronic module (CEM)
31#3B#31
32#4B#32SRS warning lampActivated
33#5B#33SRS warning lampDeactivated
34#6B#34Switch (+)
35#7B#35Driver airbag, stage 1 (-)Monitoring signal at normal status. Ignition pulse on deployment.
36#8B#36Driver airbag, stage 1 (+)Monitoring signal at normal status. Ignition pulse on deployment.
37#9B#37Driver airbag, stage 2 (+)Monitoring signal at normal status. Ignition pulse on deployment.
38#10B#38Driver airbag, stage 2 (-)Monitoring signal at normal status. Ignition pulse on deployment.
39#11B#39Passenger airbag, stage 1 (-)Monitoring signal at normal status. Ignition pulse on deployment.
40#12B#40Passenger airbag, stage 1 (+)Monitoring signal at normal status. Ignition pulse on deployment.
41#13B#41Passenger airbag, stage 2 (+)Monitoring signal at normal status. Ignition pulse on deployment.
42#14B#42Passenger airbag, stage 2 (-)Monitoring signal at normal status. Ignition pulse on deployment.
43#15B#43Switch (-)
44#16B#44
45#17B#45
46#18B#46
47#19B#47
48#20B#48
49#21B#49
50#22B#50
51#23B#51Control modules communication cable (CAN H)U=2.5-3.5 V
52#24B#52Control modules communication cable (CAN H)U=2.5-3.5 V
53#25B#53Control modules communication cable (CAN L)U=1.5-2.5 V
54#26B#54Control modules communication cable (CAN L)U=1.5-2.5 V
55#27B#55X-feed voltage from the ignition switch (ignition switch pos. I and II)Battery voltage approximately 12 V
56#28B#5615-feed voltage (ignition switch pos. II and III)Battery voltage approximately 12 V
57#1C#57
58#2C#58
59#3C#59Side airbag, front right (-)Monitoring signal at normal status. Ignition pulse on deployment.
60#4C#60Front right side impact protection (SIPS) bag (+)Monitoring signal at normal status. Ignition pulse on deployment.

Breakout box 1

Breakout boxTerminal control module -02Terminal control module 03FunctionOther
1#5C#61Front right seat belt tensioner (+)Monitoring signal at normal status. Ignition pulse on deployment.
2#6C#62Front right seat belt tensioner (-)
3#7C#63
4#8C#64Side impact sensor, right front
5#9C#65Side impact sensor, right front
6#10C#66
7#11C#67
8#12C#68
9#13C#69
10#14C#70
11#15C#71Rear right seat belt tensioner (-)Monitoring signal at normal status. Ignition pulse on deployment.
12#16C#72Rear right seat belt tensioner (+)Monitoring signal at normal status. Ignition pulse on deployment.
13#17C#73
14#18C#74
15#19C#75
16#20C#76
17#21C#77Right inflatable curtain (+)Monitoring signal at normal status. Ignition pulse on deployment.
18#22C#78Right inflatable curtain (-)Monitoring signal at normal status. Ignition pulse on deployment.
19#23C#79Rear center seat belt tensioner (-)Monitoring signal at normal status. Ignition pulse on deployment. Replaces pin 18A from VIN 116811.
20#24C#80Rear center seat belt tensioner (+)Monitoring signal at normal status. Ignition pulse on deployment. Replaces pin 17A from VIN 116811.
21#25C#81
22#26C#82
23#27C#83Side impact sensor, right rear
24#28C#84Side impact sensor, right rear

Breakout box 2
