Fuel System - Removal, Replacement and Installation: Specifications Volvo S80 I

Tightening Torque

For tightening torques, see Tightening torque.

Scheme 5

Transfer the venting pipe, leak diagnostic pump, pump control module and cable harnesses.

Scheme 6

Removal

Remove the cover.

Use special tool 9995720.

Scheme 7

Remove the screw (1).

Scheme 8

Carefully turn the pump to access the fuel hose (1).

Remove

1. the hose (1)
2. the three connectors (2).

Carefully lift up the pump.

Note. Ensure that the level sensor arm is not obstructed. Do not bend the arm when removing the pump.

Installation

Lower the pump into the tank.

Install

1. the fuel hose
2. the three connectors.

Turn the pump to the installation position. Install the mounting bracket and screw. (M6)

Install the cover.

Use special tool 9995720.

For tightening torques, see Tightening torque.
