Installing the receiver unit Volvo S80 I

Installing the receiver unit

1. Remove the Velcro from the kit and cut it in the center.

1. Press the Velcro pieces together.

1. Clean the flat surface of the receiver unit using isopropanol P/N 1161721. Wipe dry.

Scheme 933

1. Remove the protective backing tape from one of the Velcro pieces.

1. Press the Velcro onto the receiver unit.

1. Remove the protective backing tape from the other Velcro piece.

Scheme 934

1. Move the floor and insulating mat out of the way.
2. Scrape away any sealant from the flat surface at the lower edge of the A-post where the receiver unit for the remote start is to be located.
3. Clean the surface using isopropanol P/N 1161721. Wipe dry.

Scheme 935

1. Press the receiver unit securely onto the panel surface, 10 mm (25/64") under the cable lead-in for the side door.

Scheme 936

1. Locate the connector for the blower fan and disconnect the connector.
2. Connect the cable from the kit.

1. Carefully loosen the secondary catch of the black 6-pin connector using a small screwdriver.

Scheme 937

1. Connect the red (R) cable from the timer relay to terminal 3, and the black (BK) cable to terminal 6 in the 6-pin connector.
2. Press the secondary catch together on the connector.

Scheme 938

1. Connect the battery's negative lead.
2. Install batteries in the transmitter battery compartment.
3. Connect the connector and antenna cable to the receiver unit.
4. Within 5 seconds, press the "OFF" button on the transmitter until the LED goes out. Synchronization has been carried out.

1. Press the receiver unit onto the Velcro on the body plate if it has loosened.
2. Tape up any cable excess from the timer relay and place it next to the receiver unit under the insulation mat.

Scheme 939

1. Install a new safety clip in the A pillar panel. NOTE: It is important to use a new safety clip when installing.
2. Press the A-pillar panel into place.

Reinstall

1. the dashboard end panel
2. insulation and floor carpet.
3. the sound proofing.
4. Turn the ignition key to position II.
