Engine & Fuel - Sensors & Component Locations: Component Locations Volvo S60 I

Component location (B5234T3; B5244T3; B5204T5; naturally aspirated engines)

1. For 6 cylinder naturally aspirated engines -2001, see «Location of components -2001»(ref-445807-S33265557752012010600000)
2. For 6 cylinder naturally aspirated engines 2002, see «Location of components, engine compartment»(ref-415300-S24119145442011081500000)
3. For 6 cylinder naturally aspirated engines 2003-, see «Location of components, engine compartment»(ref-415300-S18702523382011081500000) .

Scheme 7

1. Engine coolant temperature (ECT) sensor
2. Ground terminal
3. Coolant level sensor
4. Camshaft reset valve
5. Camshaft position sensor (CMP)
6. Brake pedal sensor
7. Engine speed (RPM) sensor
8. Outer temperature sensor
9. Power supply terminal
10. Fusebox
11. Relay box
12. Mass air flow (MAF) sensor
13. Injector
14. Canister purge (CP) valve
15. Ignition coil
16. Knock sensor (KS)
17. Engine cooling fan (FC) control module
18. Throttle unit
19. A/C pressure sensor
20. Engine control module (ECM).

Component location (B5234T3; B5244T3; B5204T5, turbocharged engines)

S60

1. For 6 cylinder turbocharged engines -2001, see «Location of components -2001»(ref-445807-S28951664592012010600000)
2. For 6 cylinder turbocharged engines 2002, see «Location of components, engine compartment»(ref-415300-S24119145442011081500000)
3. For 6 cylinder turbocharged engines 2003-, see «Location of components, engine compartment»(ref-415300-S18702523382011081500000) .

Scheme 8

1. Engine coolant temperature (ECT) sensor
2. Ground terminal
3. Coolant level sensor
4. Camshaft reset valve
5. Turbocharger (TC) control valve
6. Camshaft position sensor (CMP)
7. Brake pedal sensor
8. Engine speed (RPM) sensor
9. Outer temperature sensor
10. Power supply terminal
11. Fusebox
12. Relay box
13. Mass air flow (MAF) sensor
14. Intake air temperature sensor
15. Boost pressure sensor
16. Canister purge (CP) valve
17. Ignition coil
18. Injector
19. Throttle unit
20. Knock sensor (KS)
21. Engine cooling fan (FC) control module
22. A/C pressure sensor
23. Engine control module (ECM).

Component location (B5234T3; B5244T3; B5204T5; 2001-2007)

1. For 5 cylinder turbocharged engines -2001, see «Location of components (B5234T3; B5244T3; 2001)»(ref-415300-S37482210272011081500000)
2. For 5 cylinder turbocharged engines 2002, see «Location of components, engine compartment»(ref-415300-S24119145442011081500000)
3. For 5 cylinder turbocharged engines 2003-, see «Location of components, engine compartment»(ref-415300-S18702523382011081500000)
4. For B5254T4 2004-, see «Location of components, engine compartment»(ref-415300-S00279643772011081500000) .
