Wheel camber, specifications
Note. For latest updated wheel camber specifications, see CAMBER ADJUSTMENT.
Scheme 53
The measurements are made so that the same camber angle can be obtained when installing.
Measure over the wheel spindle / spring strut at the upper screw as illustrated.
Before measuring clean off any dirt from the measuring surfaces.
Note the measurement.
Scheme 54
Install the spring strut on the wheel spindle. Use new screws and nuts .
Adjust in accordance with the measured values.
Tighten to 105 Nm . Angle-tighten 90° . Use bevel protractor 9512050 .
See also:
• Installing wheels
• 9512050
