Engine Control Module (ECM) Diagnostic Trouble Codes - 5 of 8: Other Volvo C30 I рестайлинг

Testing & Diagnostics 6 illustrations ~7815 words

VERIFICATION

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 131

Scheme 131: VERIFICATION

Scheme 132

Scheme 132
  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Test drive the vehicle and perform a TRIP schedule. See «VERIFYING REPAIRS»(ref-520009-S39089577682012123100000)
  4. Connect VCT2000 to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the dynamic for the front heated oxygen sensor (HO2S). The value should be higher than 1.0.

Is the value OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S36749656832012091100000)

FAULT-TRACING INFORMATION

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING INFORMATION

INFORMATION

No fault-tracing has been developed for this diagnostic trouble code (DTC). The diagnostic trouble code (DTC) for this fault is stored first in the central electronic module (CEM), then in the engine control module (ECM). This diagnostic trouble code (DTC) can not be erased before the diagnostic trouble codes (DTC) in the central electronic module (CEM) has been remedied and erased.

First read off the diagnostic trouble codes (DTCs) in the central electronic module (CEM). Fault-trace and remedy as necessary. This diagnostic trouble code (DTC) can then be erased.

CHECKING CONNECTOR

Check the fuel level sensor connector and terminals. Check for contact resistance. Check for oxidation.

Remedy as necessary.

Other information

  1. see «LEVEL SENSOR FUEL TANK»(ref-500271-S35259088362012091100000)
  2. see «CONTENTS»(ref-500249-S15428429872012091100000)

Scheme 133

Scheme 133

Scheme 134

Scheme 134
  1. Continue Refer to «VERIFICATION»(ref-500319-S32259694102012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Read off the signal from the fuel level sensor (via the central electronic module (CEM)). Check that the signal is within its permitted range. The level should change if the car is rocked gently, before stabilizing to a reasonable level. A reasonable signal indicates that the fault has been remedied. HINT: If the tank is completely full, their may be no noticeable change in level if the car is rocked.

Is the signal within its permitted range?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S03327338942012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CHECKING COMPONENTS

Check the exhaust system for air leakage.

Remedy as necessary.

Note. Try a new catalytic converter if the above fault-tracing does not remedy the fault.

Other information

  1. see «AIR LEAKAGE EXHAUST SYSTEM, CHECK»(ref-520007-S29175372722012123100000)
  2. see «CATALYTIC CONVERTER»(ref-500310-S14847428532012091100000)
  1. Continue Refer to «VERIFICATION»(ref-500319-S10757160432012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Test drive the car and perform a TRIP schedule, see: «VERIFYING REPAIRS»(ref-520009-S39089577682012123100000)
  2. Connect VCT2000 to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S21864625272012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

OPEN

see OPEN

CHECKING THE COMPONENT

  1. Slacken off the evaporative emission system (EVAP) valve
  2. Connect a vacuum pump to the evaporative emission system (EVAP) valve terminal (B). Pump a vacuum. Check that there is no leakage through the evaporative emission system (EVAP) valve by listening to and checking via the pump gauge that the pressure is stable
  3. Connect the Evaporative emission system (EVAP) valve connector
  4. Ignition on
  5. Activate the evaporative emission system (EVAP) valve. When the Evaporative emission system (EVAP) valve is activated, the valve opens and clicks. Check on the pump gauge that the vacuum drops (the pressure evens out) when the evaporative emission system (EVAP) valve opens. If the function is OK, there must be no leakage when the evaporative emission system (EVAP) valve is closed (stable pressure on the pump gauge) and the vacuum must drop when the evaporative emission system (EVAP) valve opens (the pressure evens out). The evaporative emission system (EVAP) valve is damaged if the function is faulty. If the function of the Evaporative emission system (EVAP) valve is OK, check: The hose and hose terminals between the Evaporative emission system (EVAP) valve and the intake manifold. Check for leakage and blockages Check the hose and hose terminals between the EVAP canister and the Evaporative emission system (EVAP) valve. Check for leakage and blockages. Remedy as necessary. Other information see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-500307-S22083409362012091100000) see «CHARCOAL FILTER»(ref-500308-S13079047742012091100000)
  1. Continue Refer to «INFORMATION»(ref-500319-S14804563922012091100000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

CLOSED

see CLOSED

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the evaporative emission system (EVAP) valve. A click should be heard when the evaporative emission system (EVAP) valve is activated.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S04507115562012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL MISSING

see SIGNAL MISSING

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the evaporative emission system (EVAP) valve. A click should be heard when the evaporative emission system (EVAP) valve is activated.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S42560711392012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL TOO HIGH

see SIGNAL TOO HIGH

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on
  4. Activate the evaporative emission system (EVAP) valve. A click should be heard when the evaporative emission system (EVAP) valve is activated.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S24850666232012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL TOO LOW

see SIGNAL TOO LOW

After this fault tracing, verification is carried out by starting the quick tank system test under DIAGNOSTICS/VEHICLE COMMUNICATION.

The information can be displayed again or fault-tracing this fault can be interrupted.

FUEL TANK FILLER CAP MISSING

see FUEL TANK FILLER CAP MISSING

CHECKING SOFTWARE

  1. Ignition on. Click on the VCT2000 symbol to start the read out and check the software version in the Engine control module (ECM).
  1. Continue Refer to «CHECKING THE WIRING»(ref-500319-S42177224282012091100000)

After this fault tracing, verification is carried out by starting the quick tank system test under DIAGNOSTICS/VEHICLE COMMUNICATION.

The information can be displayed again or fault-tracing this fault can be interrupted.

  1. Ignition on. Click on the VCT2000 symbol to start the read out and check the software version in the Engine control module (ECM).
  1. Continue Refer to «CHECKING THE WIRING»(ref-500319-S16862676562012091100000)

After this fault tracing, verification is carried out by starting the quick tank system test under DIAGNOSTICS/VEHICLE COMMUNICATION.

The information can be displayed again or fault-tracing this fault can be interrupted.

  1. Ignition on. Click on the VCT2000 symbol to start the read out and check the software version in the Engine control module (ECM).
  1. Continue Refer to «CHECKING THE WIRING»(ref-500319-S37813322612012091100000)

After this fault tracing, verification is carried out by starting the quick tank system test under DIAGNOSTICS/VEHICLE COMMUNICATION.

The information can be displayed again or fault-tracing this fault can be interrupted.

  1. Ignition on. Click on the VCT2000 symbol to start the read out and check the software version in the Engine control module (ECM).
  1. Continue Refer to «CHECKING THE WIRING»(ref-500319-S18681063792012091100000)

After this fault tracing, verification is carried out by starting the quick tank system test under DIAGNOSTICS/VEHICLE COMMUNICATION.

The information can be displayed again or fault-tracing this fault can be interrupted.

  1. Ignition on. Click on the VCT2000 symbol to start the read out and check the software version in the Engine control module (ECM). NOTE: More instructions follow together with the read out.
  1. Continue Refer to «INFORMATION»(ref-500319-S42822615062012091100000)

After this fault tracing, verification is carried out by starting the quick tank system test under DIAGNOSTICS/VEHICLE COMMUNICATION.

The information can be displayed again or fault-tracing this fault can be interrupted.

Fault-tracing is not followed by verification for this fault.

HINT: After the diagnostic trouble codes (DTCs) are erased, the function of the leak diagnostic unit can be checked by running a quick test of the fuel tank system in the vehicle communication socket. If there is a fault, the fault status will be "FAULT FOUND" on the leak diagnostic unit.

The information can be displayed again or fault-tracing this fault can be interrupted.

see SIGNAL MISSING

Fault-tracing is not followed by verification for this fault.

HINT: After the diagnostic trouble codes (DTCs) are erased, the function of the leak diagnostic unit can be checked by running a quick test of the fuel tank system in the vehicle communication socket. If there is a fault, the fault status will be "FAULT FOUND" on the leak diagnostic unit.

The information can be displayed again or fault-tracing this fault can be interrupted.

see SIGNAL TOO HIGH

Fault-tracing is not followed by verification for this fault.

HINT: After the diagnostic trouble codes (DTCs) are erased, the function of the leak diagnostic unit can be checked by running a quick test of the fuel tank system in the vehicle communication socket. If there is a fault, the fault status will be "FAULT FOUND" on the leak diagnostic unit.

The information can be displayed again or fault-tracing this fault can be interrupted.

see SIGNAL TOO LOW

  1. Ignition on. Click on the VCT2000 symbol to start the read out and check the software version in the Engine control module (ECM).
  1. Continue Refer to «CHECKING THE STATUS»(ref-500319-S11248111582012091100000)

CHECKING THE STATUS

  1. Ignition on. Activate the valve in the leak diagnostic unit. Check if the fault is permanent or intermittent. The valve clicks when it is activated. The fault is permanent if the valve does not activate. If the valve is activated, this is an indication that the fault was present previously but that it is not active at the moment, intermittent fault.
  1. Continue Refer to «CHECKING THE WIRING»(ref-500319-S42738498452012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Click the VCT2000 symbol to activate the valve in the leak diagnostic unit. The valve must click. Check that the function is OK.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S14488651922012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Ignition on. Click on the VCT2000 symbol to start the read out and check the software version in the Engine control module (ECM).
  1. Continue Refer to «CHECKING THE STATUS»(ref-500319-S35882643162012091100000)
  1. Ignition on. Activate the valve in the leak diagnostic unit. Check if the fault is permanent or intermittent. The valve clicks when it is activated. The fault is permanent if the valve does not activate. If the valve is activated, this is an indication that the fault was present previously but that it is not active at the moment, intermittent fault.
  1. Continue Refer to «CHECKING THE WIRING»(ref-500319-S13629194542012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Click the VCT2000 symbol to activate the valve in the leak diagnostic unit. The valve must click. Check that the function is OK.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S37753716412012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Ignition on. Click on the VCT2000 symbol to start the read out and check the software version in the Engine control module (ECM).
  1. Continue Refer to «CHECKING THE STATUS»(ref-500319-S12326906092012091100000)
  1. Ignition on. Activate the valve in the leak diagnostic unit. Check if the fault is permanent or intermittent. The valve clicks when it is activated. The fault is permanent if the valve does not activate. If the valve is activated, this is an indication that the fault was present previously but that it is not active at the moment, intermittent fault.
  1. Continue Refer to «CHECKING THE WIRING»(ref-500319-S13777920242012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Click the VCT2000 symbol to activate the valve in the leak diagnostic unit. The valve must click. Check that the function is OK.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S23726063772012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Ignition on. Click on the VCT2000 symbol to start the read out and check the software version in the Engine control module (ECM).
  1. Continue Refer to «CHECKING THE STATUS»(ref-500319-S27831472192012091100000)
  1. Ignition on. Activate the valve in the leak diagnostic unit. Check if the fault is permanent or intermittent. The valve clicks when it is activated. The fault is permanent if the valve does not activate. If the valve is activated, this is an indication that the fault was present previously but that it is not active at the moment, intermittent fault.
  1. Continue Refer to «CHECKING THE WIRING»(ref-500319-S40730586262012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Click the VCT2000 symbol to activate the valve in the leak diagnostic unit. The valve must click. Check that the function is OK.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S18017836492012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

FAULTY SIGNAL

see FAULTY SIGNAL

  1. Ignition on. Activate the valve in the leak diagnostic unit to check whether the fault is permanent or intermittent. The valve clicks when activated. The fault is permanent if the valve does not activate. The fault is intermittent if the valve activates.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-500319-S18488382622012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition on. Activate the valve in the leak diagnostic unit. The valve must click.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S22487081682012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL MISSING

  1. Ignition on. Activate the valve in the leak diagnostic unit to check whether the fault is permanent or intermittent. The valve clicks when activated. The fault is permanent if the valve does not activate. The fault is intermittent if the valve activates.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-500319-S36754665652012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition on. Activate the valve in the leak diagnostic unit. The valve must click.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S06629744212012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL TOO HIGH

  1. Ignition on. Activate the valve in the leak diagnostic unit to check whether the fault is permanent or intermittent. The valve clicks when activated. The fault is permanent if the valve does not activate. The fault is intermittent if the valve activates.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-500319-S32823240152012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition on. Activate the valve in the leak diagnostic unit. The valve must click.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S04595931672012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL TOO LOW

Fault-tracing is not followed by verification for this fault.

HINT: After the diagnostic trouble codes (DTCs) are erased, the function of the leak diagnostic unit can be checked by running a quick test of the fuel tank system in the vehicle communication socket. If there is a fault, the fault status will be "FAULT FOUND" on the leak diagnostic unit.

The information can be displayed again or fault-tracing this fault can be interrupted.

see SIGNAL MISSING

Fault-tracing is not followed by verification for this fault.

HINT: After the diagnostic trouble codes (DTCs) are erased, the function of the leak diagnostic unit can be checked by running a quick test of the fuel tank system in the vehicle communication socket. If there is a fault, the fault status will be "FAULT FOUND" on the leak diagnostic unit.

The information can be displayed again or fault-tracing this fault can be interrupted.

see SIGNAL TOO HIGH

Fault-tracing is not followed by verification for this fault.

HINT: After the diagnostic trouble codes (DTCs) are erased, the function of the leak diagnostic unit can be checked by running a quick test of the fuel tank system in the vehicle communication socket. If there is a fault, the fault status will be "FAULT FOUND" on the leak diagnostic unit.

The information can be displayed again or fault-tracing this fault can be interrupted.

see SIGNAL TOO LOW

HINT: For vehicles of model year 2004-2008, the software in engine control module (ECM) should be checked before fault tracing of the fault relating to the leak from the tank system is carried out.

  1. Ignition on. Click on the VCT2000 symbol to start the read out and check the software version in the Engine control module . NOTE: More instructions follow together with the read out.

Has the latest software been downloaded to the control module?

  1. YES Refer to «PERFORM QUICK-TEST TANK SYSTEM»(ref-500319-S03766008732012091100000)

Scheme 135

Scheme 135
  1. Activate the test by pressing on the symbol for VCT2000.
  2. Read off initial parameters and check them according to start conditions for performing the test.
  3. Press the button "Start" to start the quick-test.
  4. Check that the test has started. Parameters run status shall go to "In progress" and the test phase shall go to "Reference". NOTE: If the test does not start, check that the start conditions are fulfilled. When the reference phase is finished, check of the tank system starts. The pressure in the tank starts to increase. Within 15 minutes the Engine control module makes a decision as to whether there is leakage in the tank system or not. The test is finished.
  5. Check parameters for test result and follow relevant instructions below. NOTE: In the event of a the results from the estimated leakage must be entered in NOTE: Estimated leakage shall be used to get an idea of the proximity to the diagnostic trouble code limit. If the estimated leakage is very near the diagnostic trouble code limit (greater than 0.3mm), troubleshooting should probably be performed despite the Tank system, test result shows "No leakage found", especially if a diagnostic trouble code for leakage has been stored earlier. NOTE: Use diagnostic trouble code counter to see the frequency of the problem. Also use frozen values to get an idea if external conditions may have affected the result. Compare with current conditions in the workshop. Conditions for starting the quick test of the fuel tank system No DTCs related to EVAP purge valve or ambient air pressure sensor set. Battery voltage 11-15 V. Atmospheric pressure higher than 750 hPa, appr. 2500 m (8200 ft). Fuel level 0-85 %. Ambient air temperature 4-35 °C . NOTE: The battery voltage must be correct throughout the entire test. The test can take up to 15 minutes, depending on the quantity of fuel in the fuel tank. It is highly recommended to use the constant voltage charger, Midtronics PSC-550, during the test. Other information see «DESCRIPTION OF PARAMETERS, QUICK TEST OF THE FUEL TANK SYSTEM»(ref-520008-S26936353662012123100000) see «TEST PHASES, QUICK TEST FUEL TANK SYSTEM»(ref-520010-S31198942512012123100000) see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-500307-S22083409362012091100000) see «FUEL TANK SYSTEM, CHECK»(ref-500319-S13998346972012091100000) see «TEST PRESSURIZING THE TANK SYSTEM»(ref-500319-S34286560552012091100000) Select alternative according to relevant test results: DMTL, test result = "Problem found" Refer to «DMTL, TEST RESULT = "PROBLEM FOUND"»(ref-500319-S15281423712012091100000) Tank system, test result = "No leakage found" Refer to «TANK SYSTEM, TEST RESULT = "NO LEAKAGE FOUND"»(ref-500319-S18231860302012091100000) Tank system, test result = "Minor leakage found" Refer to «TANK SYSTEM, TEST RESULT = "MINOR LEAKAGE FOUND"»(ref-500319-S18410933462012091100000) Tank system, test result = "Major leakage found" Refer to «TANK SYSTEM, TEST RESULT = "MAJOR LEAKAGE FOUND"»(ref-500319-S01170134722012091100000) DMTL, test result and Tank system, test result = "Unknown" Refer to «DMTL, TEST RESULT AND TANK SYSTEM, TEST RESULT = "UNKNOWN"»(ref-500319-S28118393142012091100000) Cancel fault-tracing. FAULT NOT FOUND: Troubleshooting has been completed.

FUEL TANK SYSTEM, CHECK

Note. This instruction is deliberately written for use with different types of leak detecting equipment. Therefore certain components may differ on different equipment.

SAFETY

First read, see SAFETY REGULATIONS FOR HANDLING FUEL .

Note. Follow the safety precautions for the equipment. Follow the instructions for connecting, disconnecting, use and maintenance.

HINT: Be aware of the risks of igniting the fuel. Do not let the temperature of the tank fall below 0 °C when carrying out checks.

CAUTIONNever leave the car unattended with the tank system pressurized

PREPARATION

Ignition off.

Seal the intake air hose for the carbon filter container. (A rubber plug is sufficient on certain models.)

Expose the evaporative emission system (EVAP) valve.

Disconnect the hose (1) between the carbon filter container and the evaporative emission system (EVAP) valve.

DETERMINE THE SIZE OF THE LEAK

Calibrate the equipment in relation to the definition of a major or minor leak for the relevant vehicle. See the instructions provided by the equipment supplier.

Connect the leak detecting equipment hose for gas to the detached hose.

Pressurize the fuel tank system. Check the result against the default value to determine the size of the leak.

HINT: The supplier's instructions often contain useful tips to facilitate carrying out checks.

Complete pressurization.

LOCATING LEAKAGE

Connect the leak detecting equipment hose for smoke to the detached hose.

Fill the tank system with smoke. The time taken to fill the system depends on the size and volume of the system, and the performance of the equipment.

Visually check the evaporative emission (EVAP) system, using a halogen and / or UV lamp.

HINT: The supplier's instructions often contain useful tips to facilitate leak tracing.

Stop filling with smoke.

RESETTING

Reinstall the hose between the carbon filter container and evaporative emission system (EVAP) valve.

Install the evaporative emission system (EVAP) valve.

Remove the seal at the intake air hose for the carbon filter container.

LEAKAGE

see LEAKAGE

  1. Ignition on. Click on the VCT2000 symbol to start the read out and check the software version in the Engine control module (ECM).
  1. Continue Refer to «CHECKING THE WIRING»(ref-500319-S42885643842012091100000)

After this fault tracing, verification is carried out by starting the quick tank system test under DIAGNOSTICS/VEHICLE COMMUNICATION.

The information can be displayed again or fault-tracing this fault can be interrupted.

  1. Ignition on. Click on the VCT2000 symbol to start the read out and check the software version in the Engine control module (ECM).
  1. Continue Refer to «CHECKING THE WIRING»(ref-500319-S28959570662012091100000)

After this fault tracing, verification is carried out by starting the quick tank system test under DIAGNOSTICS/VEHICLE COMMUNICATION.

The information can be displayed again or fault-tracing this fault can be interrupted.

  1. Ignition on. Click on the VCT2000 symbol to start the read out and check the software version in the Engine control module (ECM).
  1. Continue Refer to «CHECKING THE WIRING»(ref-500319-S13517924922012091100000)

After this fault tracing, verification is carried out by starting the quick tank system test under DIAGNOSTICS/VEHICLE COMMUNICATION.

The information can be displayed again or fault-tracing this fault can be interrupted.

  1. Ignition on. Click on the VCT2000 symbol to start the read out and check the software version in the Engine control module (ECM).
  1. Continue Refer to «CHECKING THE WIRING»(ref-500319-S42890859292012091100000)

After this fault tracing, verification is carried out by starting the quick tank system test under DIAGNOSTICS/VEHICLE COMMUNICATION.

The information can be displayed again or fault-tracing this fault can be interrupted.

HINT: For vehicles of model year 2004-2008, the software in engine control module (ECM) should be checked before fault tracing of the fault relating to the leak from the tank system is carried out.

  1. Ignition on. Click on the VCT2000 symbol to start the read out and check the software version in the Engine control module . NOTE: More instructions follow together with the read out.

Has the latest software been downloaded to the control module?

  1. YES Refer to «PERFORM QUICK-TEST TANK SYSTEM»(ref-500319-S10441326452012091100000)

HINT: For vehicles of model year 2004-2008, the software in engine control module (ECM) should be checked before fault tracing of the fault relating to the leak from the tank system is carried out.

  1. Ignition on. Click on the VCT2000 symbol to start the read out and check the software version in the Engine control module . NOTE: More instructions follow together with the read out.

Has the latest software been downloaded to the control module?

  1. YES see «PERFORM QUICK-TEST TANK SYSTEM»(ref-500319-S03766008732012091100000)

FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see LEAKAGE

see LEAKAGE

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Activate reading off the position of the throttle. Check that both sensors indicate values within the permitted range at different deployments.

Are these values within their permitted ranges?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S13924099782012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 136

Scheme 136
  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Read off the signal from the mass air flow (MAF) sensor. Check that the signal is between 0.5 - 4.5 V.

Is the signal within its permitted range?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S13924099782012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CHECKING THE THROTTLE UNIT

Note. Dirt, ice build-up or objects can cause the throttle disc to jam momentarily. This may cause the diagnostic trouble code (DTC) to be stored.

Check that the throttle module throttle is not dirty, blocked or sticking. Clean as necessary.

HINT: A film of oil covering the throttle may mean that the flame trap is not functioning correctly.

Check the throttle unit and engine control module (ECM) connectors. Check for contact resistance and oxidation.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-500251-S16432032892012091100000)
  2. see «SIGNAL SPECIFICATION»(ref-500252-S40520643792012091100000)
  3. see «THROTTLE BODY, CLEANING (NON-TURBO)»(ref-500328-S05057680462012091100000)
  4. see «THROTTLE BODY»(ref-500310-S03113243912012091100000)
  5. see «CHECKING WIRING AND TERMINALS»(ref-500249-S05296466302012091100000)

Was a fault detected?

  1. YES Refer to «VERIFICATION»(ref-500319-S24867391772012091100000)
  2. NO Refer to «CHECKING INTAKE SYSTEM AND MASS AIR FLOW SENSOR»(ref-500319-S25596579032012091100000)

CHECKING INTAKE SYSTEM AND MASS AIR FLOW SENSOR

Check the intake system for blockages.

Check the connector and terminals for the mass air flow (MAF) sensor. Check for contact resistance. Check for oxidation.

Other information

  1. see «CONNECTING THE BREAKOUT BOX»(ref-500251-S16432032892012091100000)
  2. see «SIGNAL SPECIFICATION»(ref-500252-S40520643792012091100000)
  3. see «MASS AIR FLOW (MAF) SENSOR»(ref-500308-S32939954662012091100000)
  4. see «CHECKING WIRING AND TERMINALS»(ref-500249-S05296466302012091100000)

Was a fault detected?

  1. YES Refer to «VERIFICATION»(ref-500319-S26608338112012091100000)
  2. NO Refer to «INFORMATION»(ref-500319-S37551804132012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Activate reading off the position of the throttle. Check that both sensors indicate values within the permitted range at different deployments.

Are these values within their permitted ranges?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S37551804132012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Read off the signal from the mass air flow (MAF) sensor. Check that the signal is between 0.5 - 4.5 V.

Is the signal within its permitted range?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S37551804132012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. The fault has not been remedied if the engine does not start. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S33310948212012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

FAULTY SIGNAL OR SIGNAL MISSING

see FAULTY SIGNAL OR SIGNAL MISSING

  1. Engine idling
  2. A/C on. Check whether the fault is permanent or intermittent. Read off the signal from the air conditioning (A/C) pressure sensor. Check that the signal is within its permitted range and that the pressure increases in the air conditioning (A/C) system when the air conditioning (A/C) compressor engages. The fault is permanent if the signal is incorrect. The fault is intermittent if the signal is correct.
  1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-500319-S14223390492012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine
  4. Read off the air conditioning (A/C) pressure
  5. A/C on
  6. Blower fan on. Check that the pressure increases in the air conditioning (A/C) system when the air conditioning (A/C) compressor engages. Also check that cold air blows out of the blower when at the coolest setting.

Is the function within its permitted range?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S24277954202012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Engine idling
  2. A/C on. Check whether the fault is permanent or intermittent. Read off the signal from the air conditioning (A/C) pressure sensor. Check that the signal is within its permitted range and that the pressure increases in the air conditioning (A/C) system when the air conditioning (A/C) compressor engages. The fault is permanent if the signal is incorrect. The fault is intermittent if the signal is correct.
  1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-500319-S31738287262012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine
  4. Read off the air conditioning (A/C) pressure
  5. A/C on
  6. Blower fan on. Check that the pressure increases in the air conditioning (A/C) system when the air conditioning (A/C) compressor engages. Also check that cold air blows out of the blower when at the coolest setting.

Is the function within its permitted range?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S18613076512012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Engine idling
  2. A/C on. Check whether the fault is permanent or intermittent. Read off the signal from the air conditioning (A/C) pressure sensor. Check that the signal is within its permitted range and that the pressure increases in the air conditioning (A/C) system when the air conditioning (A/C) compressor engages. The fault is permanent if the signal is incorrect. The fault is intermittent if the signal is correct.
  1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-500319-S15142849022012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine
  4. Read off the air conditioning (A/C) pressure
  5. A/C on
  6. Blower fan on. Check that the pressure increases in the air conditioning (A/C) system when the air conditioning (A/C) compressor engages. Also check that cold air blows out of the blower when at the coolest setting.

Is the function within its permitted range?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S33172921152012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Engine idling
  2. A/C on. Check whether the fault is permanent or intermittent. Read off the signal from the air conditioning (A/C) pressure sensor. Check that the signal is within its permitted range and that the pressure increases in the air conditioning (A/C) system when the air conditioning (A/C) compressor engages. The fault is permanent if the signal is incorrect. The fault is intermittent if the signal is correct.
  1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-500319-S18753212042012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine
  4. Read off the air conditioning (A/C) pressure
  5. A/C on
  6. Blower fan on. Check that the pressure increases in the air conditioning (A/C) system when the air conditioning (A/C) compressor engages. Also check that cold air blows out of the blower when at the coolest setting.

Is the function within its permitted range?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S02203951792012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine
  4. Read off the air conditioning (A/C) pressure
  5. A/C on
  6. Blower fan on. Check that the pressure increases in the air conditioning (A/C) system when the air conditioning (A/C) compressor engages. Also check that cold air blows out of the blower when at the coolest setting.

Is the function within its permitted range?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S16427014452012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine
  4. Read off the air conditioning (A/C) pressure
  5. A/C on
  6. Blower fan on. Check that the pressure increases in the air conditioning (A/C) system when the air conditioning (A/C) compressor engages. Also check that cold air blows out of the blower when at the coolest setting.

Is the function within its permitted range?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S40220863412012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULTY SIGNAL OR SIGNAL MISSING

see FAULTY SIGNAL OR SIGNAL MISSING

Check that the engine speed (RPM) sensor is correctly installed.

Check the engine speed (RPM) sensor. Check that it is not damaged or dirty.

HINT: The diagnostic trouble code (DTC) can be caused by damage in the flywheel / carrier plate. Look for damage to the flywheel / carrier plate.

Other information

  1. see «CRANKSHAFT POSITION SENSOR (CKP)»(ref-500254-S09648082822012091100000)
  1. Continue Refer to «VERIFICATION»(ref-500319-S36857965422012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. The fault has not been remedied if the engine does not start. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S41659399822012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL TOO HIGH / SIGNAL TOO LOW

see SIGNAL TOO HIGH / SIGNAL TOO LOW

No fault-tracing has been developed for this diagnostic trouble code (DTC). The diagnostic trouble code (DTC) for this fault is stored first in the transmission control module (TCM), then in the engine control module (ECM). This diagnostic trouble code (DTC) can not be erased before the diagnostic trouble code (DTC) in the transmission control module (TCM) has been remedied and erased.

First read off the diagnostic trouble codes (DTCs) in the transmission control module (TCM). Fault-trace and remedy as necessary. This diagnostic trouble code (DTC) can then be erased.

see FAULT-TRACING INFORMATION

No fault-tracing has been developed for this diagnostic trouble code (DTC). The diagnostic trouble code (DTC) for this fault is stored first in the brake control module (BCM), then in the engine control module (ECM). This diagnostic trouble code (DTC) cannot be erased before the diagnostic trouble code (DTC) in the brake control module (BCM) has been remedied and erased.

First read off the diagnostic trouble codes (DTCs) in the brake control module (BCM). Fault-trace and remedy as necessary. This diagnostic trouble code (DTC) can then be erased.

No fault-tracing has been developed for this diagnostic trouble code (DTC). A diagnostic trouble code for CAN communication can also be generated in the Central Electronic Module (CEM). This diagnostic trouble code shall not be cleared until the trouble code in the central electronic module (CEM) and in other affected control modules has been remedied and cleared. Therefore, first read the diagnostic trouble codes in the Central Electronic Module (CEM) and other affected control modules, perform fault tracing and remedy as necessary. This diagnostic trouble code (DTC) can then be erased.

Other information

  1. See «GENERAL INFORMATION ABOUT FAULT-TRACING IN THE CAN NETWORK»(ref-500319-S10842881262012091100000)

see FAULTY SIGNAL

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

see FAULTY SIGNAL

The engine control module (ECM) receives information on vehicle speed from the transmission control module (TCM) via the CAN network. The diagnostic trouble code is generated when the signal on gear selector position has a reliability that is too low (quality factor too low).

This could be due to a fault in the transmission control module (TCM) or intermittent faults in the CAN network.

Check and remedy any diagnostic trouble codes in the transmission control module (TCM).

Check the diagnostic trouble codes in the central electronic module (CEM) for CAN network faults.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Read the position of the ignition key. Check that the ignition setting position is OFF when the ignition key is in position 2 (ignition on) and ON when the ignition key is in position 3 (start). Check that the value read for the ignition key position is correct.

Is the value correct?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S38101974522012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Read the position of the ignition key. Check that the ignition setting position is OFF when the ignition key is in position 2 (ignition on) and ON when the ignition key is in position 3 (start). Check that the value read for the ignition key position is correct.

Is the value correct?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S21378841762012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Read the position of the ignition key. Check that the ignition setting position is OFF when the ignition key is in position 2 (ignition on) and ON when the ignition key is in position 3 (start). Check that the value read for the ignition key position is correct.

Is the value correct?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S22576655232012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Read the position of the ignition key. Check that the ignition setting position is OFF when the ignition key is in position 2 (ignition on) and ON when the ignition key is in position 3 (start). Check that the value read for the ignition key position is correct.

Is the value correct?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S35653403892012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine
  4. Read off the air conditioning (A/C) pressure
  5. A/C on
  6. Blower fan on. Check that the pressure increases in the air conditioning (A/C) system when the air conditioning (A/C) compressor engages. Also check that cold air blows out of the blower when at the coolest setting.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S35309130212012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULTY SIGNAL

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine
  4. Read off the air conditioning (A/C) pressure
  5. A/C on
  6. Blower fan on. Check that the pressure increases in the air conditioning (A/C) system when the air conditioning (A/C) compressor engages. Also check that cold air blows out of the blower when at the coolest setting.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S32820563482012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL MISSING

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine
  4. Read off the air conditioning (A/C) pressure
  5. A/C on
  6. Blower fan on. Check that the pressure increases in the air conditioning (A/C) system when the air conditioning (A/C) compressor engages. Also check that cold air blows out of the blower when at the coolest setting.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S33689445032012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL TOO HIGH

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine
  4. Read off the air conditioning (A/C) pressure
  5. A/C on
  6. Blower fan on. Check that the pressure increases in the air conditioning (A/C) system when the air conditioning (A/C) compressor engages. Also check that cold air blows out of the blower when at the coolest setting.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S15617662872012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL TOO LOW

No fault-tracing has been developed for this diagnostic trouble code (DTC). The diagnostic trouble code (DTC) for this fault is stored first in the transmission control module (TCM), then in the engine control module (ECM). This diagnostic trouble code (DTC) can not be erased before the diagnostic trouble code (DTC) in the transmission control module (TCM) has been remedied and erased.

First read off the diagnostic trouble codes (DTCs) in the transmission control module (TCM). Fault-trace and remedy as necessary. This diagnostic trouble code (DTC) can then be erased.

see FAULTY SIGNAL

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition on or engine running
  2. Click on the VCT2000 symbol to activate the tool for reading off the ranking values. Check the read off ranking values against previous readings. Check that "Latest" is now lower. A lower ranking value indicates that the fault has been remedied. The same or a higher value indicates that the fault remains.

Do the ranking values indicate that the fault has been remedied?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500319-S42635637152012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.
