Engine Control Module (ECM) Diagnostic Trouble Codes - 4 of 8: Other Volvo C30 I рестайлинг

Testing & Diagnostics 7 illustrations ~11032 words

FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

VERIFICATION

HINT: After carrying out the repair, check that the fault has been remedied.

Scheme 102

Scheme 102: VERIFICATION
Scheme 102: VERIFICATION

Scheme 103

Scheme 103
Scheme 103
  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Ignition on. Read off the fuel temperature sensor signal. Check that the signal is within its permitted range. The signal is measured in the fuel rail for the injectors.

Is the value OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S41949292602012091100000)

FAULT-TRACING INFORMATION

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL TOO HIGH

see SIGNAL TOO HIGH

CHECKING COMPONENTS

CAUTIONDo not apply rust solvent spray or grease to the heated oxygen sensor (HO2S) connector.

Check the connector for the center heated oxygen sensor (HO2S). Check for contact resistance and oxidation.

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Remedy as necessary.

Other information

  1. see «SIGNAL SPECIFICATION»(ref-500252-S40520643792012091100000)
  2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-500310-S09387820172012091100000)
  3. see «CHECKING WIRING AND TERMINALS»(ref-500249-S05296466302012091100000)

Scheme 104

Scheme 104
Scheme 104
  1. Continue Refer to «VERIFICATION»(ref-500317-S05333261672012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Test drive the car and ensure that there is a fuel shut-off. The easiest way to do this is to drive at approximately 80 km/h and abruptly release the accelerator pedal (AP) for at least 5 seconds
  2. Connect VCT2000 to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S07630955072012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

CHECKING THE STATUS

Check whether the fault is permanent or intermittent by reading the signals from the fuel, outside and engine temperature sensors.

  1. Start the engine.

Check that the fuel temperature is within its permitted range. The fuel temperature should not be lower than the outdoor temperature and a maximum of 40 °C above the engine temperature.

The fault is permanent if the signal is incorrect. The fault is intermittent if the signal is correct.

HINT: Remove the fuel temperature sensor, but let the connector remain connected. The fuel temperature sensor is integrated in the fuel pressure sensor. The sensor should then show the same temperature as the outdoor temperature.

  1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-500317-S10764026692012091100000)

Scheme 105

Scheme 105: CHECKING THE COMPONENT AND WIRING
Scheme 105: CHECKING THE COMPONENT AND WIRING

Scheme 106

Scheme 106
Scheme 106
  1. Ignition off.
  2. Disconnect the fuel temperature sensor connector.
  3. Check the connectors. Check for loose connections. Check for contact resistance. Check for oxidation. Check the resistance of the sensor between #1 and #2 (to the sensor). Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-500251-S16432032892012091100000) see «SIGNAL SPECIFICATION»(ref-500252-S36983929532012091100000) see «COMPONENT SPECIFICATIONS»(ref-500252-S01220863972012091100000) see «PRESSURE SENSOR, FUEL RAIL (FRP)»(ref-500254-S13073282302012091100000) see «CHECKING WIRING AND TERMINALS»(ref-500249-S05296466302012091100000)
  1. Continue Refer to «VERIFICATION»(ref-500317-S23107632772012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Ignition on. Read off the fuel temperature sensor signal. Check that the signal is within its permitted range.

Is the value OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S25471820042012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

  1. The ignition must be on to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING COMPONENTS»(ref-500317-S14057677262012091100000)
CAUTIONDo not apply rust solvent spray or grease to the heated oxygen sensor (HO2S) connector.

Check the heated oxygen sensor (HO2S) connector. Check for contact resistance and oxidation.

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Remedy as necessary.

Other information

  1. see «SIGNAL SPECIFICATION»(ref-500252-S08653660702012091100000)
  2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-500310-S09387820172012091100000)
  3. see «CHECKING WIRING AND TERMINALS»(ref-500249-S05296466302012091100000)
  1. Continue Refer to «VERIFICATION»(ref-500317-S36382825452012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. The ignition must be on to perform the diagnostic. NOTE: The battery voltage must be between 11-16 V in order to obtain a correct reading. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S26564732232012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. The ignition must be on to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING COMPONENTS»(ref-500317-S10921910872012091100000)
CAUTIONDo not apply rust solvent spray or grease to the heated oxygen sensor (HO2S) connector.

Check the heated oxygen sensor (HO2S) connector. Check for contact resistance and oxidation.

Try a new heated oxygen sensor (HO2S) if the above fault-tracing does not remedy the fault.

Remedy as necessary.

Other information

  1. see «SIGNAL SPECIFICATION»(ref-500252-S40520643792012091100000)
  2. see «OXYGEN SENSOR (CATALYST MONITOR SENSOR)»(ref-500310-S09387820172012091100000)
  3. see «CHECKING WIRING AND TERMINALS»(ref-500249-S05296466302012091100000)
  1. Continue Refer to «VERIFICATION»(ref-500317-S39659079702012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. The ignition must be on to perform the diagnostic. NOTE: The battery voltage must be between 11-16 V in order to obtain a correct reading. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S12710559902012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. The ignition must be on to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-500317-S39525399722012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. The ignition must be on to perform the diagnostic. NOTE: The battery voltage must be between 11-16 V in order to obtain a correct reading. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S10652407842012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. The ignition must be on to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-500317-S23509378702012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. The ignition must be on to perform the diagnostic. NOTE: The battery voltage must be between 11-16 V in order to obtain a correct reading. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S05537730882012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. The ignition must be on to perform the diagnostic. Check whether the fault is permanent or intermittent by reading off the fault status of the diagnostic trouble code (DTC) when the status of the diagnostic is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING FUSES»(ref-500317-S16333795252012091100000)

CHECKING FUSES

All heated oxygen sensors are supplied with voltage with the same lead. If the lead is damaged, e. g., fuse on the lead, then diagnostic code for heating for all heated oxygen sensors will be stored.

Therefore, check first if diagnostic trouble codes for heating are also stored for other heated oxygen sensors.

HINT: Brake vacuum pump is supplied with voltage via the same lead as the heated oxygen sensors. A damaged brake vacuum contact can lead to the pump running continuously and in the long-term be overheated and damaged. In turn, this leads to damaged fuse.

HINT: Therefore, check the brake vacuum switch and pump before any continued troubleshooting is done on the heated oxygen sensors.

  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-500317-S22469155732012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. The ignition must be on to perform the diagnostic. NOTE: The battery voltage must be between 11-16 V in order to obtain a correct reading. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S11182205902012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. The ignition must be on to perform the diagnostic. Check whether the fault is permanent or intermittent by reading off the fault status of the diagnostic trouble code (DTC) when the status of the diagnostic is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING FUSES»(ref-500317-S29407973522012091100000)

All heated oxygen sensors are supplied with voltage with the same lead. If the lead is damaged, e. g., fuse on the lead, then diagnostic code for heating for all heated oxygen sensors will be stored.

Therefore, check first if diagnostic trouble codes for heating are also stored for other heated oxygen sensors.

HINT: Brake vacuum pump is supplied with voltage via the same lead as the heated oxygen sensors. A damaged brake vacuum contact can lead to the pump running continuously and in the long-term be overheated and damaged. In turn, this leads to damaged fuse.

HINT: Therefore, check the brake vacuum switch and pump before any continued troubleshooting is done on the heated oxygen sensors.

  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-500317-S36646724962012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. The ignition must be on to perform the diagnostic. NOTE: The battery voltage must be between 11-16 V in order to obtain a correct reading. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S00171032922012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

Check whether the fault is permanent or intermittent by reading the signals from the fuel, outside and engine temperature sensors.

Note. In order for the correct values to be shown, reading of the temperatures must take place at the moment of start.

  1. Start the engine.

Check that the fuel temperature is within its permitted range. The fuel temperature should not be lower than the outdoor temperature and a maximum of 40 °C above the engine temperature.

The fault is permanent if the signal is incorrect. The fault is intermittent if the signal is correct.

HINT: Remove the fuel temperature sensor, but let the connector remain connected. The fuel temperature sensor is integrated in the fuel pressure sensor. The sensor should then show the same temperature as the outdoor temperature.

  1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-500317-S27996562092012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Ignition on. Read off the fuel temperature sensor signal. Check that the signal is within its permitted range.

Is the value OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S02813115482012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING

see FAULT-TRACING

see FAULT-TRACING

  1. Start the engine and run it to normal operating temperature. Check whether the fault is permanent or intermittent. Read off the signal from the fuel temperature sensor. Check that the signal is within its permitted range. The signal is measured in the fuel rail for the injectors. The fault is permanent if the signal is incorrect. The fault is intermittent if the signal is correct.
  1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-500317-S42938442622012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Read off the fuel temperature sensor signal. Check that the signal is within its permitted range. The signal is measured in the fuel rail for the injectors.

Is the value OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S01748181452012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine and run it to normal operating temperature. Check whether the fault is permanent or intermittent. Read off the signal from the fuel temperature sensor. Check that the signal is within its permitted range. The signal is measured in the fuel rail for the injectors. The fault is permanent if the signal is incorrect. The fault is intermittent if the signal is correct.
  1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-500317-S16093294452012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Read off the fuel temperature sensor signal. Check that the signal is within its permitted range. The signal is measured in the fuel rail for the injectors.

Is the value OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S11114185742012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine and run it to normal operating temperature. Check whether the fault is permanent or intermittent. Read off the signal from the fuel temperature sensor. Check that the signal is within its permitted range. The signal is measured in the fuel rail for the injectors. The fault is permanent if the signal is incorrect. The fault is intermittent if the signal is correct.
  1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-500317-S12953414672012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Read off the fuel temperature sensor signal. Check that the signal is within its permitted range. The signal is measured in the fuel rail for the injectors.

Is the value OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S29889269602012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine and run it to normal operating temperature. Check whether the fault is permanent or intermittent. Read off the signal from the fuel temperature sensor. Check that the signal is within its permitted range. The signal is measured in the fuel rail for the injectors. The fault is permanent if the signal is incorrect. The fault is intermittent if the signal is correct.
  1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-500317-S29348980462012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Read off the fuel temperature sensor signal. Check that the signal is within its permitted range. The signal is measured in the fuel rail for the injectors.

Is the value OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S35180719952012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

REPLACING THE THERMOSTAT

Note. This diagnostic trouble code (DTC) is stored if the engine coolant temperature (ECT) sensor freezes. This may happen if the coolant level is low or there is too little glycol in the coolant. Check the engine coolant level and its freezing point. Remedy as necessary.

The engine control module (ECM) has registered that the actual temperature increase has deviated from the calculated temperature increase. This deviation is due to a damaged thermostat.

Other information

  1. see «ENGINE COOLANT TEMPERATURE SENSOR (ECT)»(ref-500254-S41916200992012091100000)
  2. see «THERMOSTAT»(ref-500312-S31768479912012091100000)
  1. Continue Refer to «INFORMATION»(ref-500317-S12871307302012091100000)

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

FAULTY SIGNAL

see FAULTY SIGNAL

CHECKING THE CONNECTOR

HINT: The fuel temperature sensor is integrated in the fuel pressure sensor.

Check the connector and terminals for the fuel temperature sensor. Check for contact resistance. Check for oxidation.

Remedy as necessary.

Other information

  1. To access or replace the fuel temperature sensor, see «PRESSURE SENSOR, FUEL RAIL (FRP)»(ref-500254-S13073282302012091100000)
  2. see «CONTENTS»(ref-500249-S15428429872012091100000)

Scheme 107

Scheme 107
Scheme 107
  1. Continue Refer to «VERIFICATION»(ref-500317-S26129264942012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Read off the fuel temperature sensor signal. Check that the signal is within its permitted range. The signal is measured in the fuel rail for the injectors.

Is the value OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S25867547052012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine. Read off the fault status from the camshaft position (CMP) sensor to check whether the fault is permanent or intermittent. The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-500317-S28652398322012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Read off the fault status of the camshaft position (CMP) sensor. If the function is correct, the camshaft position (CMP) sensor fault status must be "No fault detected".

Has the fault been remedied?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S04484114452012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine. Read off the fault status from the camshaft position (CMP) sensor to check whether the fault is permanent or intermittent. The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-500317-S32934328382012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Read off the fault status of the camshaft position (CMP) sensor. If the function is correct, the camshaft position (CMP) sensor fault status must be "No fault detected".

Has the fault been remedied?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S26967201392012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine. Read off the fault status from the camshaft position (CMP) sensor to check whether the fault is permanent or intermittent. The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-500317-S27369230722012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Read off the fault status of the camshaft position (CMP) sensor. If the function is correct, the camshaft position (CMP) sensor fault status must be "No fault detected".

Has the fault been remedied?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S24609651342012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine. Read off the fault status from the camshaft position (CMP) sensor to check whether the fault is permanent or intermittent. The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-500317-S41855237882012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Read off the fault status of the camshaft position (CMP) sensor. If the function is correct, the camshaft position (CMP) sensor fault status must be "No fault detected".

Has the fault been remedied?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S03011101812012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine. Read off the fault status from the camshaft position (CMP) sensor to check whether the fault is permanent or intermittent. The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-500317-S02548215542012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Read off the fault status of the camshaft position (CMP) sensor. If the function is correct, the camshaft position (CMP) sensor fault status must be "No fault detected".

Has the fault been remedied?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S06664608742012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine. Read off the fault status from the camshaft position (CMP) sensor to check whether the fault is permanent or intermittent. The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-500317-S28488804722012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Read off the fault status of the camshaft position (CMP) sensor. If the function is correct, the camshaft position (CMP) sensor fault status must be "No fault detected".

Has the fault been remedied?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S24035117732012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: If the diagnostic trouble code (DTC) for incorrect camshaft position is stored, fault-tracing for this diagnostic trouble code (DTC) must be carried out first.

  1. Start the engine. Read off the fault status from the camshaft position (CMP) sensor to check whether the fault is permanent or intermittent. The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-500317-S38316784122012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Read off the fault status of the camshaft position (CMP) sensor. If the function is correct, the camshaft position (CMP) sensor fault status must be "No fault detected".

Has the fault been remedied?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S34364757902012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: If the diagnostic trouble code (DTC) for incorrect camshaft position is stored, fault-tracing for this diagnostic trouble code (DTC) must be carried out first.

  1. Start the engine. Read off the fault status from the camshaft position (CMP) sensor to check whether the fault is permanent or intermittent. The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-500317-S08552295242012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Read off the fault status of the camshaft position (CMP) sensor. If the function is correct, the camshaft position (CMP) sensor fault status must be "No fault detected".

Has the fault been remedied?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S22963891852012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine and run it to normal operating temperature
  4. Run the engine to 3500 RPM. Read off the value of the knock sensor (KS) signal. The value must be between 2-6.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S21094237982012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL TOO HIGH

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine and run it to normal operating temperature
  4. Run the engine to 3500 RPM. Read off the value of the knock sensor (KS) signal. The value must be between 2-6.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S28165768212012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL TOO LOW

see SIGNAL TOO LOW

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine and run it to normal operating temperature
  4. Run the engine to 3500 RPM. Read off the value of the knock sensor (KS) signal. The value must be between 2-6.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S33877824752012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL TOO HIGH

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine and run it to normal operating temperature
  4. Run the engine to 3500 RPM. Read off the value of the knock sensor (KS) signal. The value must be between 2-6.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S18654097122012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL TOO LOW

INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

see INTERNAL FAULT

  1. Start the engine to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-500317-S39141301762012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. The engine must be at idle speed to perform the diagnostic. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S01510465852012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-500317-S42466239702012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. The engine must be at idle speed to perform the diagnostic. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S22533127912012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

  1. Start the engine to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-500317-S09899156652012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. The engine must be at idle speed to perform the diagnostic. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S10752221502012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

SIGNAL FAULTY/INTERMITTENT FAULT

see SIGNAL FAULTY/INTERMITTENT FAULT

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

CHECKING THE FUEL INJECTION SYSTEM, IGNITION SYSTEM AND COMPONENTS

Note. In the event of diagnostic trouble codes (DTCs), that affect camshaft control or camshaft reset valve, these must be fault-traced first.

HINT: In certain cases, the engine control module (ECM) can determine which cylinder has misfired.

Check the fuel level in the fuel tank.

Check that the engine oil level is correct.

Look for moisture in the electrical terminals for the ignition coils and in the spark plug wells.

Check the spark plugs. Search for damage in the insulation and other damage.

Check the engine intake system for leakage.

Check the crankcase ventilation. Check for blockage.

Check the fuel pressure and residual pressure.

Check the compression of the engine.

Remedy as necessary.

Other information

  1. see «AIR LEAKS IN THE INTAKE SYSTEM, CHECKING»(ref-520006-S19657292492012123100000)
  2. see «FUEL SYSTEM PRESSURE, CHECKING»(ref-500313-S30269329262012091100000)
  3. see «LEAK DETECTING CYLINDER»(ref-520006-S12017404942012123100000)
  1. Continue Refer to «VERIFICATION»(ref-500317-S04979114342012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Check that the misfire counter is not counting upwards. Check that the engine is firing on all cylinders. NOTE: Misfire can occur at different engine speeds and loads.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S11780285852012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

EMISSIONS IMPACT / CATALYTIC CONVERTER DAMAGE / START UP

see EMISSIONS IMPACT / CATALYTIC CONVERTER DAMAGE / START UP

see EMISSIONS IMPACT / CATALYTIC CONVERTER DAMAGE / START UP

see EMISSIONS IMPACT / CATALYTIC CONVERTER DAMAGE / START UP

see EMISSIONS IMPACT / CATALYTIC CONVERTER DAMAGE / START UP

see EMISSIONS IMPACT / CATALYTIC CONVERTER DAMAGE / START UP

see FAULT-TRACING INFORMATION

  1. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". HINT: In some cases several functions of the component will be diagnosed. This affects the amount of time taken to run the diagnostic. The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-500317-S25783472772012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S31427981412012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

SIGNAL MISSING

see SIGNAL MISSING

see SIGNAL MISSING

see SIGNAL MISSING

  1. Start the engine. Check that the engine is firing on all cylinders.
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-500317-S20814622192012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Check that the engine is firing on all cylinders.

Is the engine running on all cylinders?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S19287891852012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine. Check that the engine is firing on all cylinders.
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-500317-S12008523072012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Check that the engine is firing on all cylinders.

Is the engine running on all cylinders?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S25563821092012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". HINT: In some cases several functions of the component will be diagnosed. This affects the amount of time taken to run the diagnostic. The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-500317-S26915386952012091100000)

Scheme 108

Scheme 108: CHECKING COMPONENTS AND WIRING
Scheme 108: CHECKING COMPONENTS AND WIRING
  1. Check the connector for the camshaft position (CMP) sensor. Check for contact resistance and oxidation.
  2. Check that the camshaft position (CMP) sensor is correctly installed. Check that neither the camshaft position (CMP) sensor nor the housing is damaged. Damage may affect the position of the sensor in relation to the camshaft rotor.
  3. Check the angle position of the camshafts, i. e. that the camshafts are at the correct position in relation to the crankshaft. HINT: This diagnostic trouble code (DTC) may be caused by a damaged camshaft position (CMP) sensor. Remedy as necessary. Other information see «CONNECTING THE BREAKOUT BOX»(ref-500251-S16432032892012091100000) see «SIGNAL SPECIFICATION»(ref-500252-S36983929532012091100000) see «VVT UNIT»(ref-500318-S32080088292012091100000) see «CONTENTS»(ref-500249-S15428429872012091100000)
  1. Continue Refer to «VERIFICATION»(ref-500317-S23287145702012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S37625739632012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

FAULTY SIGNAL OR SIGNAL MISSING

see FAULTY SIGNAL OR SIGNAL MISSING

  1. Start the engine and let it idle for approximately 30 seconds to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-500317-S39269629342012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine and let it idle for approximately 30 seconds to perform the diagnostic. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S21629807792012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine and let it idle for approximately 30 seconds to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-500317-S41753548052012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine and let it idle for approximately 30 seconds to perform the diagnostic. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S05369720712012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine and let it idle for approximately 30 seconds to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-500317-S05841252502012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine and let it idle for approximately 30 seconds to perform the diagnostic. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S21949974532012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Start the engine and let it idle for approximately 30 seconds to perform the diagnostic. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENTS AND WIRING»(ref-500317-S24055413622012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine and let it idle for approximately 30 seconds to perform the diagnostic. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S22065778462012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

In case of this defect, troubleshooting is not followed by verification.

The information can be displayed again or the fault-tracing for this fault can be interrupted.

see FAULTY SIGNAL OR SIGNAL MISSING

see FAULTY SIGNAL OR SIGNAL MISSING

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S39002878282012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL TOO HIGH

  1. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". HINT: In some cases several functions of the component will be diagnosed. This affects the amount of time taken to run the diagnostic. The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-500317-S00348054872012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S04417079732012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL TOO LOW

  1. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". HINT: In some cases several functions of the component will be diagnosed. This affects the amount of time taken to run the diagnostic. The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-500317-S27736975722012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S07884273962012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see FAULTY SIGNAL OR SIGNAL MISSING

see FAULTY SIGNAL OR SIGNAL MISSING

see FAULTY SIGNAL OR SIGNAL MISSING

  1. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". HINT: In some cases several functions of the component will be diagnosed. This affects the amount of time taken to run the diagnostic. The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-500317-S25130841582012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S13182254942012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL TOO HIGH

  1. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". HINT: In some cases several functions of the component will be diagnosed. This affects the amount of time taken to run the diagnostic. The fault is permanent if the fault status is "Fault found". If the fault status is "No fault found" the fault is intermittent and not presently active.
  1. Continue Refer to «CHECKING COMPONENTS AND WIRING»(ref-500317-S42351063812012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Start the engine. Read off the diagnostic status and fault status for the diagnostic trouble code (DTC) by selecting the relevant diagnostic trouble code (DTC) from the list. Increase the engine speed to 2500 RPM until the diagnostic is "Complete". Check the fault status for the diagnostic trouble code (DTC) when the diagnostic is "Complete". If the function is correct, the fault status must be "No fault found" when the diagnostic is complete.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S39285438102012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL TOO LOW

see FAULT-TRACING INFORMATION

see FAULT-TRACING INFORMATION

Note. In the event of diagnostic trouble codes (DTCs), that affect camshaft control or camshaft reset valve, these must be fault-traced first.

HINT: In certain cases, the engine control module (ECM) can determine which cylinder has misfired.

Check the fuel level in the fuel tank.

Check that the engine oil level is correct.

Check for moisture in the electrical terminals for the ignition coils and in the spark plug well.

Check the spark plugs. Search for damage in the insulation and other damage.

Check the engine intake system for air leakage.

Check the crankcase ventilation. Check for blockage.

Check the fuel pressure and residual pressure.

Check the compression of the engine.

Remedy as necessary.

Other information

  1. see «AIR LEAKS IN THE INTAKE SYSTEM, CHECKING»(ref-520006-S29898930442012123100000)
  2. see «FUEL SYSTEM PRESSURE, CHECKING»(ref-500313-S31398457522012091100000)
  3. see «LEAK DETECTING CYLINDER»(ref-520006-S12017404942012123100000)
  1. Continue Refer to «VERIFICATION»(ref-500317-S27744611532012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Check the misfire counter for the cylinder indicated by the diagnostic trouble code (DTC). All cylinders must be checked if the engine control module (ECM) has not detected a misfire in any specific cylinder (misfire in at least one cylinder). The misfire counter must not count upwards and the engine must fire on all cylinders. NOTE: Misfire can occur at different engine speeds and loads.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S34533768362012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

Note. In the event of diagnostic trouble codes (DTCs), that affect camshaft control or camshaft reset valve, these must be fault-traced first.

HINT: In certain cases, the engine control module (ECM) can determine which cylinder has misfired.

Check the fuel level in the fuel tank.

Check that the engine oil level is correct.

Check for moisture in the electrical terminals for the ignition coils and in the spark plug well.

Check the spark plugs. Search for damage in the insulation and other damage.

Check the engine intake system for air leakage.

Check the crankcase ventilation. Check for blockage.

Check the fuel pressure and residual pressure.

Check the compression of the engine.

Remedy as necessary.

Other information

  1. see «AIR LEAKS IN THE INTAKE SYSTEM, CHECKING»(ref-520006-S29898930442012123100000)
  2. see «FUEL SYSTEM PRESSURE, CHECKING»(ref-500313-S31398457522012091100000)
  3. see «LEAK DETECTING CYLINDER»(ref-520006-S12017404942012123100000)
  1. Continue Refer to «VERIFICATION»(ref-500317-S31454109832012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Start the engine. Check the misfire counter for the cylinder indicated by the diagnostic trouble code (DTC). All cylinders must be checked if the engine control module (ECM) has not detected a misfire in any specific cylinder (misfire in at least one cylinder). The misfire counter must not count upwards and the engine must fire on all cylinders. NOTE: Misfire can occur at different engine speeds and loads.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S27823739442012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

MISFIRE CYL X

see MISFIRE CYL X

MISFIRE, AT LEAST ONE CYLINDER

see MISFIRE, AT LEAST ONE CYLINDER

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Reinstall the connectors, components etc.
  2. Start the engine. Allow the engine to idle. Check that the engine is firing on all cylinders. If the engine idles unevenly, it is not running on all cylinders

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S16387510972012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL MISSING

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Reinstall the connectors, components etc.
  2. Start the engine. Allow the engine to idle. Check that the engine is firing on all cylinders. If the engine idles unevenly, it is not running on all cylinders

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S28191179662012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL TOO HIGH

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Reinstall the connectors, components etc.
  2. Start the engine. Allow the engine to idle. Check that the engine is firing on all cylinders. If the engine idles unevenly, it is not running on all cylinders

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S24340602162012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

see SIGNAL TOO LOW

INFORMATION

The diagnostic trouble code (DTC) is an information trouble code and never occurs alone. Therefore fault-trace for another diagnostic trouble code (DTC).

  1. Ignition on. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-500317-S20976691562012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S42948083882012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Ignition on. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-500317-S00850369172012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S34340633702012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Ignition on. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-500317-S29204631582012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S04487482732012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. Ignition on. Check whether the fault is permanent or intermittent. Read off the diagnostic trouble code (DTC) fault status when the diagnostic status is "Completed". The fault is permanent if the fault status is "Fault found". The fault is intermittent if the fault status is "No fault detected".
  1. Continue Refer to «CHECKING THE COMPONENT AND WIRING»(ref-500317-S29109934632012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Ignition on. Read off the diagnostic status and the fault status for the diagnostic trouble code (DTC). Check that the diagnostic is "Completed" and that the fault status is "No fault detected". The function is faulty if the fault status is "Fault found".

Is the fault status "No fault detected"?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S07932731072012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

CHECKING COMPONENTS AND CONNECTIONS

  1. The status of the valve can be determined by activating the quick test for the EVAP valve. The test sends pressure pulses through the valve so that the functionality of the valves can be checked. The fault is permanent if a fault is detected in the evaporative emission system (EVAP) valve when running the quick test
  2. Engine idling during the entire test. Activate the evaporative emission system (EVAP) valve quick test. The test takes a few seconds to carry out. The tool displays the ranking value as a value between 0 and 255. The functionality is poor if the value is 128 or higher. Check the hose/hose connectors between the evaporative emission system (EVAP) valve and canister. Check for damage, blockage or pinching. The valve may need to be cleaned or replaced. The functionality is good if the value is below 128. If this is the case, check the hose/hose connectors between the EVAP valve and the intake manifold. Check for damage, blockage or pinching. Note the read ranking value. Remedy as necessary. Other information see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-500307-S24795875862012091100000)
  1. Continue Refer to «VERIFICATION»(ref-500317-S28144018832012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Restart the quick test of the EVAP valve and check the ranking values to establish if the work carried out has remedied the problem
  4. Engine idling during the entire test. Activate the evaporative emission system (EVAP) valve quick test. The test takes a few seconds to carry out. Check that the ranking value is lower than 128, and that it is significantly lower than the previous value. A value below 128 indicates that the fault has been remedied and the function is OK.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S11100040902012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

  1. The status of the valve can be determined by activating the quick test for the EVAP valve. The test sends pressure pulses through the valve so that the functionality of the valves can be checked. The fault is permanent if a fault is detected in the evaporative emission system (EVAP) valve when running the quick test
  2. Engine idling during the entire test. Activate the evaporative emission system (EVAP) valve quick test. The test takes a few seconds to carry out. The tool displays the ranking value as a value between 0 and 255. The functionality is poor if the value is 128 or higher. Check the hose/hose connectors between the evaporative emission system (EVAP) valve and canister. Check for damage, blockage or pinching. The valve may need to be cleaned or replaced. The functionality is good if the value is below 128. If this is the case, check the hose/hose connectors between the EVAP valve and the intake manifold. Check for damage, blockage or pinching. Note the read ranking value. Remedy as necessary. Other information see «LOCATION OF COMPONENTS, ENGINE COMPARTMENT»(ref-500307-S27787116702012091100000)
  1. Continue Refer to «VERIFICATION»(ref-500317-S25924574032012091100000)

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reinstall the connectors, components etc.
  3. Restart the quick test of the EVAP valve and check the ranking values to establish if the work carried out has remedied the problem
  4. Engine idling during the entire test. Activate the evaporative emission system (EVAP) valve quick test. The test takes a few seconds to carry out. Check that the ranking value is lower than 128, and that it is significantly lower than the previous value. A value below 128 indicates that the fault has been remedied and the function is OK.

Is the function OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S40258446362012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

HINT: After carrying out the repair, check that the fault has been remedied.

  1. Ignition off
  2. Reconnect the connectors, reinstall components etc.
  3. Test drive the vehicle and perform a TRIP schedule. See «VERIFYING REPAIRS»(ref-520009-S39089577682012123100000)
  4. Connect VCT2000 to the data link connector (DLC) without switching off the engine. NOTE: If the engine is switched off, the stored fault status will be erased and the test drive will have to be repeated. Read off the dynamic for the front heated oxygen sensor (HO2S). The value should be higher than 1.0.

Is the value OK?

  1. YES VERIFIED: Troubleshooting has been completed.
  2. NO Refer to «INFORMATION»(ref-500317-S38658900872012091100000)

The fault should have been detected and remedied. As this is not the case fault-tracing has failed.

Exit fault-tracing for this diagnostic trouble code (DTC) or make another attempt.

More articles — Engine Control Module (ECM) Diagnostic Trouble Codes - 4 of 8
