3.6L - Ignition/glow Plug System - Engine Code(s): Blv: Overview Volkswagen Passat B6

Ignition System 1 illustration ~313 words

IGNITION COMPONENTS OVERVIEW

Note. The engine speed sensor -G28- is on the cylinder block.

Scheme 7

Scheme 7: IGNITION COMPONENTS OVERVIEW
Scheme 7: IGNITION COMPONENTS OVERVIEW
  1. Ignition Coil with Power Output Stage -N70, N127, N291, N292, N323, N324- Remove and install using the ignition coil puller T10095 A.
  2. Connector Black Use the assembly tool T10118 to disconnect.
  3. Bracket For the harness connector for the knock sensor 1.
  4. Bolt 20 Nm
  5. Connector Black, 3 pin Sensor contacts and connector contacts are gold plated.
  6. Knock Sensor (KS) 1 -G61- Installed location - exhaust side of the cylinder block.
  7. Bolt 20 Nm Tightening specification affects the function of the knock sensor.
  8. Exhaust Camshaft Adjuster Identification: 32A With the sensor wheel for the Camshaft Position (CMP) sensor 2. Removing and installing, refer to «CAMSHAFT ADJUSTER WITH TIMING CHAIN, INSTALLING»(ref-460534-S41683700152012032900000) .
  9. Cover
  10. Connector Black, 3 pin Sensor contacts and connector contacts are gold plated. Mark the connector before disconnecting.
  11. Bolt 10 Nm
  12. Camshaft Position (CMP) Sensor 2 -G163- For the exhaust camshaft. Sensor contacts and connector contacts are gold plated.
  13. Seal Always replace
  14. Camshaft Position (CMP) Sensor -G40- For the intake camshaft. Sensor contacts and connector contacts are gold plated.
  15. Knock Sensor (KS) 2 -G66- Installed location - intake side of the cylinder block. Sensor contacts and connector contacts are gold plated.
  16. Connector Black, 2 pin Sensor contacts and connector contacts are gold plated.
  17. Intake Camshaft Adjuster Identification: 24E With the sensor wheel for the CMP sensor. Removing and installing, refer to «CAMSHAFT ADJUSTER WITH TIMING CHAIN, INSTALLING»(ref-460534-S41683700152012032900000) .
  18. Spark Plug 18 Nm If the spark plug is replaced, grease the ignition coil with power output stage. Refer to «IGNITION COILS WITH POWER OUTPUT STAGES»(ref-460538-S23243722272012032900000) . Remove and install using the spark plug removal tool 3122B. Type and electrode gap, refer to «TECHNICAL DATA»(ref-460538-S26412878422012032900000) .
  19. Control Housing For the camshaft adjustment. Removing and installing, refer to «CAMSHAFTS»(ref-460534-S20041425912012032900000) .
