2.0L - Ignition/glow Plug System - Engine Code(s): Bpy: Overview Volkswagen Passat B6

IGNITION COMPONENTS OVERVIEW

Note. The engine speed sensor -G28- is located on the cylinder block. See item 14 under CYLINDER BLOCK AND COMPONENTS

Scheme 1

1. Knock Sensor 1 -G61- It is necessary to remove the thermostat first, in order to remove the knock sensor 1. Refer to «COOLANT THERMOSTAT HOUSING WITH THERMOSTAT»(ref-460557-S31157692702012032900000) . The contacts are gold plated.
2. Knock Sensor 2 -G66- It is necessary to remove the oil filter bracket first, in order to remove the knock sensor 2. Refer to «OIL FILTER BRACKET»(ref-460642-S36408979162012032900000) . The contacts are gold plated.
3. Ignition Coil with Power Output Stage -N70, N127, N291, N292- Removing and installing, refer to «IGNITION COIL WITH POWER OUTPUT STAGE»(ref-460536-S36867722032012032900000) .
4. Spark Plug 25 Nm If the spark plug is replaced, grease the ignition coil with power output stage. Refer to «INSTALLING»(ref-460536-S37529960522012032900000) . Type and electrode gap, refer to «SPARK PLUG TECHNICAL DATA»(ref-460536-S15850698202012032900000) . Remove and install using the spark plug removal tool -3122 B
5. Bolt 20 Nm Tightening specification affects the function of the knock sensor.
6. Bolt 10 Nm
7. Camshaft Position Sensor -G40- Contacts are gold plated.
8. O-ring
