ADJUSTING HEIGHT AND PARALLEL ALIGNMENT
Note. Side window height adjustment is OK when upper edge of door window and upper edge of side window are the same height.
Scheme 1
- The rear lid is adjusted.
Remove side trim. Refer to Removal and Installation
Loosen nuts -2- and lock nut -3-.
Adjust side window with window regulator in elongated holes.
Tighten nuts -2- and lock nut -3-. Tightening specification: 10 Nm.
Perform a function check and check adjustment with roof open and closed.
Check adjustment dimension of side window with roof closed. Refer to SIDE WINDOW ADJUSTMENT DIMENSIONS .
If adjustment ability at window regulator connection is not sufficient, there are adjustment possibilities on side window to window regulator connection.
