Engine Control System (Diagnostics - Introduction): Diagnosis Toyota Yaris II рестайлинг

HOW TO PROCEED WITH TROUBLESHOOTING

HINT

*: Use a Techstream.

1. VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
2. CUSTOMER PROBLEM ANALYSIS NEXT: Go to next step
3. CONNECT TECHSTREAM TO DLC3* HINT: If the display indicates a communication fault in the Techstream, inspect the DLC3. NEXT: Go to next step
4. CHECK DTC AND FREEZE FRAME DATA* HINT: Record or print DTCs and freeze frame data, if necessary. NEXT: Go to next step
5. CLEAR DTC AND FREEZE FRAME DATA* NEXT: Go to next step
6. CONDUCT VISUAL INSPECTION NEXT: Go to next step
7. SET CHECK MODE DIAGNOSIS* NEXT: Go to next step
8. CONFIRM PROBLEM SYMPTOMS HINT: If the engine does not start, perform steps 10 and 12 first. Result Proceed to Malfunction does not occur A Malfunction occurs B B --> GO TO STEP 10 A: Go to next step
9. SIMULATE SYMPTOMS NEXT: Go to next step
10. CHECK DTC* Result Proceed to Malfunction code A No code B B --> GO TO STEP 12 A: Go to next step
11. REFER TO DTC CHART «ENGINE CONTROL SYSTEM DTCS»(/toyota/yaris/ii-2009-2012/remont/dtc-index/#dtc-index) NEXT --> GO TO STEP 14
12. CONDUCT BASIC INSPECTION Result Proceed to Malfunctioning parts not confirmed A Malfunctioning parts confirmed B B --> GO TO STEP 17 A: Go to next step
13. REFER TO PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-394513-S40102418182011040800000) Result Proceed to Malfunctioning circuit confirmed A Malfunctioning parts confirmed B B --> GO TO STEP 17 A: Go to next step
14. CHECK ECM POWER SOURCE CIRCUIT NEXT: Go to next step
15. CONDUCT CIRCUIT INSPECTION Result Proceed to Malfunction not confirmed A Malfunction confirmed B B --> GO TO STEP 18 A: Go to next step
16. CHECK FOR INTERMITTENT PROBLEMS NEXT --> GO TO STEP 18
17. CONDUCT PARTS INSPECTION NEXT: Go to next step
18. IDENTIFY PROBLEM NEXT: Go to next step
19. ADJUST AND/OR REPAIR NEXT: Go to next step
20. CONDUCT CONFIRMATION TEST* NEXT --> END

BASIC INSPECTION

When a malfunction is not confirmed by the DTC check, troubleshooting should be carried out in all circuits considered to be possible causes of the problem. In many cases, by carrying out the basic engine check shown in the following flowchart, the location of the problem can be found quickly and efficiently. Therefore, using this check is essential when engine troubleshooting.

1. CHECK BATTERY VOLTAGE NOTE: Conduct this check with the engine stopped and ignition switch off. Result Proceed to 11 V or more OK Below 11 V NG NG --> CHARGE OR REPLACE BATTERY OK: Go to next step
2. CHECK WHETHER ENGINE WILL CRANK NG --> PROCEED TO PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-394513-S40102418182011040800000) OK: Go to next step
3. CHECK WHETHER ENGINE STARTS NG --> GO TO STEP 6 OK: Go to next step
4. CHECK AIR FILTER Visually check that the air filter is not excessively contaminated with dirt or oil. NG --> REPLACE AIR FILTER. Refer to «REMOVAL - Step 24»(/toyota/yaris/ii-2009-2012/remont/mechanical/#engine-mechanical-service-information) OK: Go to next step
5. CHECK IDLING SPEED NG --> TROUBLESHOOT IDLING SPEED AND PROCEED TO NEXT STEP OK: Go to next step
6. CHECK FUEL PRESSURE NG --> TROUBLESHOOT FUEL PRESSURE AND PROCEED TO NEXT STEP OK: Go to next step
7. CHECK FOR SPARK NG --> TROUBLESHOOT SPARK AND PROCEED TO NEXT STEP OK --> PROCEED TO PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-394513-S40102418182011040800000)

PROBLEM SYMPTOMS TABLE

HINT

Use the table below to help determine the cause of the problem symptom. The potential causes of the symptoms are listed in order of probability in the Suspected Area column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.

SFI SYSTEM

Scheme 1

HINT

The standard normal voltage between each pair of ECM terminals is shown in the table below. The appropriate conditions for checking each pair of terminals are also indicated. The result of checks should be compared with the standard normal voltage for that pair of terminals, displayed in the Specified Condition column. The illustration above can be used as a reference to identify the ECM terminal locations.

HINT

*: The ECM terminal voltage is constant regardless of the output voltage from the sensor.

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

1. WAVEFORM 1 CAMSHAFT TIMING OIL CONTROL VALVE (OCV) ECM Terminal Names Between OC1+ and OC1- Tester Ranges 5 V/DIV, 1 msec./DIV Conditions Idling
2. WAVEFORM 2 AIR-FUEL RATIO SENSOR HEATER ECM Terminal Names Between HA1A and E04 Tester Ranges 5 V/DIV, 10 msec./DIV Conditions Idling with warm engine HINT: The wavelength varies in accordance with the engine operating condition.
3. WAVEFORM 3 HEATED OXYGEN SENSOR ECM Terminal Names Between OX1B and EX1B Tester Ranges 0.2 V/DIV, 200 msec./DIV Conditions Engine speed maintained at 2,500 rpm for 2 minutes after warming up sensor HINT: In DATA LIST, item O2S B1S2 shows the ECM input values from the heated oxygen sensor.
4. WAVEFORM 4 FUEL INJECTOR NO. 1 (TO NO. 4) INJECTION SIGNAL ECM Terminal Names Between #10 (to #40) and E01 Tester Ranges 20 V/DIV, 20 msec./DIV Conditions Idling HINT: The wavelength becomes shorter as the engine rpm increases.
5. WAVEFORM 5 KNOCK SENSOR ECM Terminal Names Between KNK1 and EKNK Tester Ranges 500 mV/DIV, 1 msec./DIV Conditions Engine speed maintained at 4,000 rpm after warming up engine HINT: The waveforms and amplitudes displayed differ slightly depending on the vehicle.
6. WAVEFORM 6 CRANKSHAFT POSITION SENSOR AND CAMSHAFT POSITION SENSOR ECM Terminal Names CH1: Between G2+ and NE- CH2: Between NE+ and NE- Tester Ranges 5 V/DIV, 20 msec./DIV Conditions Idling HINT: The wavelength becomes shorter as the engine rpm increases.
7. WAVEFORM 7 IGNITER IGT SIGNAL (FROM ECM TO IGNITER) AND IGNITER IGF SIGNAL (FROM IGNITER TO ECM) ECM Terminal Names Between IGT (1 to 4) and E1 Between IGF1 and E1 Tester Ranges 2 V/DIV, 20 msec./DIV Conditions Idling HINT: The wavelength becomes shorter as the engine rpm increases.
8. WAVEFORM 8 PURGE VSV ECM Terminal Names Between PRG and E01 Tester Ranges 10 V/DIV, 20 msec./DIV Conditions Idling, during purge control HINT: If the waveform is not similar to the illustration, check the waveform again after idling for 10 minutes or more.
9. WAVEFORM 9 VEHICLE SPEED SIGNAL ECM Terminal Names Between SPD and E1 Tester Ranges 2 V/DIV, 20 msec./DIV Conditions Driving at 12 mph (20 km/h) HINT: The wavelength becomes shorter as the vehicle speed increases.
10. WAVEFORM 10 THROTTLE ACTUATOR POSITIVE TERMINAL ECM Terminal Names Between M+ and ME01 Tester Ranges 5 V/DIV, 1 msec./DIV Conditions Idling with warm engine HINT: The duty ratio varies depending on the throttle actuator operation.
11. WAVEFORM 11 THROTTLE ACTUATOR NEGATIVE TERMINAL ECM Terminal Names Between M- and ME01 Tester Ranges 5 V/DIV, 1 msec./DIV Conditions Idling with warm engine HINT: The duty ratio varies depending on the throttle actuator operation.
12. WAVEFORM 12 ENGINE SPEED SIGNAL ECM Terminal Names Between TACH and E1 Tester Ranges 5 V/DIV, 10 msec./DIV Conditions Idling HINT: The wavelength becomes shorter as the engine rpm increases.
13. WAVEFORM 13 REFERENCE: CAN COMMUNICATION SIGNAL ECM Terminal Names Between CANH and E1 Tester Ranges 1 V/DIV, 10 μs/DIV Conditions Engine stops and ignition switch ON HINT: The waveform varies depending on the CAN communication signal.
14. WAVEFORM 14 REFERENCE: CAN COMMUNICATION SIGNAL ECM Terminal Names Between CANL and E1 Tester Ranges 1 V/DIV, 10 μs/DIV Conditions Engine stops and ignition switch ON HINT: The waveform varies depending on the CAN communication signal.

Scheme 16

Scheme 17

1. DESCRIPTION When troubleshooting OBD II (On-Board Diagnostics) vehicles, a Techstream (complying with SAE J1987) must be connected to the DLC3 (Data Link Connector 3) of the vehicle. Various data in the vehicle's ECM (Engine Control Module) can be then read. OBD II regulations require that the vehicle's on-board computer illuminate the MIL (Malfunction Indicator Lamp) on the instrument panel when the computer detects a malfunction in: The emission control system components. The power train control components (which affect vehicle emissions). The computer itself. In addition, if the applicable DTCs (Diagnostic Trouble Codes) prescribed by SAE J2012 are not recorded on 3 consecutive trips, the MIL turns off automatically but the DTCs remain recorded in the ECM memory. To check DTCs, connect the Techstream to the DLC3. The Techstream displays DTCs, freeze frame data, and a variety of the engine data. The DTCs and freeze frame data can be erased with the Techstream. Refer to «DTC CHECK / CLEAR»(ref-394513-S17742279252011040800000). In order to enhance OBD function on vehicles and develop the Off-Board diagnosis system, CAN communication is introduced in this system (CAN: Controller Area Network). It minimizes the gap between technician skills and vehicle technology. CAN is a network, which uses a pair of data transmission lines, spanning multiple computers and sensors. It allows high speed communication between the systems and simplifies the wire harness connection.
2. NORMAL MODE AND CHECK MODE The diagnosis system operates in normal mode during normal vehicle use. In normal mode, 2 trip detection logic is used to ensure accurate detection of malfunctions. Check mode is also available as an option for technicians. In check mode, 1 trip detection logic is used for simulating malfunction symptoms and increasing the system's ability to detect malfunctions, including intermittent problems (Techstream only). Refer to «CHECK MODE PROCEDURE»(ref-394513-S19948725612011040800000).
3. 2 TRIP DETECTION LOGIC When a malfunction is first detected, the malfunction is temporarily stored in the ECM memory (1st trip). If the same malfunction is detected during the next subsequent drive cycle, the MIL is illuminated (2nd trip).
4. FREEZE FRAME DATA Freeze frame data record the engine conditions (fuel system, calculated engine load, engine coolant temperature, fuel trim, engine speed, vehicle speed, etc.) when malfunctions are detected. When troubleshooting, freeze frame data can help determine if the vehicle was moving or stationary, if the engine was warmed up or not, if the air-fuel ratio was lean or rich, and other data, from the time the malfunction occurred.
5. DLC3 (Data Link Connector 3) The ECM uses ISO 15765-4 for communication. The terminal arrangement of the DLC3 complies with SAE J1962 and matches the ISO 15765-4 format. Symbol (Terminal No.) Terminal Description Condition Specified Condition SIL (7) - SG (5) Bus "+" line During transmission Pulse generation CG (4) - Body ground Chassis ground Always Below 1 ohms SG (5) - Body ground Signal ground Always Below 1 ohms BAT (16) - Body ground Battery positive Always 11 to 14 V CANH (6) - CANL (14) CAN bus line Ignition switch off * 54 to 69 ohms CANH (6) - CG (4) HIGH-level CAN bus line Ignition switch off * 200 ohms or higher CANL (14) - CG (4) LOW-level CAN bus line Ignition switch off * 200 ohms or higher CANH (6) - BAT (16) HIGH-level CAN bus line Ignition switch off * 6 kohms or higher CANL (14) - BAT (16) LOW-level CAN bus line Ignition switch off * 6 kohms or higher NOTE: *: Before measuring the resistance, leave the vehicle as is for at least 1 minute and do not operate the ignition switch, any other switches or the doors. HINT: The DLC3 is the interface prepared for reading various data from the vehicle's ECM. After connecting the cable of a Techstream, turn the ignition switch to ON and turn the Techstream on. If the display indicates that a communication error has occurred, there is a problem either the vehicle or tester. In order to identify the location of the problem, connect the Techstream to another vehicle. If communication is normal: Inspect the DLC3 on the original vehicle. If communication is still not possible: The problem is probably in the Techstream itself. Consult the Service Department listed in the instruction manual for the Techstream.
6. BATTERY VOLTAGE Standard voltage 11 to 14 V If the voltage is below 11 V, replace or recharge the battery before proceeding
7. MIL (Malfunction Indicator Lamp) The MIL is illuminated when the ignition switch is first turned to ON (the engine is not running). The MIL should turn off when the engine is started. If the MIL remains illuminated, the diagnosis system has detected a malfunction or abnormality in the system. HINT: If the MIL is not illuminated when the ignition switch is first turned to ON, check the MIL circuit. Refer to «MIL Circuit»(ref-394517-S09952225892011040800000).
8. ALL READINESS HINT: With All Readiness you can check whether or not the DTC judgment has been completed by using the Techstream. You should check All Readiness after simulating malfunction symptoms or for validation after finishing repairs. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-394513-S17742279252011040800000). Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Perform the DTC judgment driving pattern to run the DTC judgment. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTCs to be confirmed. Check the DTC judgment result. TECHSTREAM Tester Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit

DTC CHECK / CLEAR

Note. When the diagnosis system is changed from normal mode to check mode or vice versa, all DTCs and freeze frame data recorded in normal mode are erased. Before changing modes, always check and make a note of DTCs and freeze frame data.

HINT

1. DTCs which are stored in the ECM can be displayed on the Techstream. The Techstream can display the current, pending and permanent DTCs.
2. If a malfunction is detected during the current driving cycle, current and permanent DTCs are stored.
3. Some DTCs are not stored if the ECM does not detect the same malfunction again during a second consecutive driving cycle. However, such malfunctions, detected on only one occasion, are stored as pending DTCs.
4. Current and pending DTCs can be cleared by using the Techstream or by disconnecting the cable from the negative battery terminal. However, permanent DTCs cannot be cleared using either of these two methods.
5. After clearing current DTCs using the Techstream (or by disconnecting the cable from the negative battery terminal), permanent DTCs can be cleared when the system is determined to be normal for the relevant DTCs and then the universal trip is performed. The driving pattern to obtain a normal judgment is described under the "CONFIRMATION DRIVING PATTERN" for the respective DTC.

2 TRIP DETECTION EXAMPLES

Scheme 18

Scheme 19

HINT

1. Obtaining a normal judgment and performing a universal trip driving pattern can be done in the same driving cycle or in different driving cycles.
2. It is unnecessary to obtain a normal judgment if the DTCs are misfire or fuel system DTCs.

Scheme 20

1. CHECK DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check DTCs and freeze frame data, and then write them down. Check the details of DTCs. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-394513-S31071923012011040800000).
2. CLEAR DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Clear DTCs.
3. CLEAR DTC (Without using Techstream) Perform either of the following operations: Disconnect the cable from the negative battery terminal for more than 1 minute. Remove the EFI and ETCS fuses from the engine room relay block located inside the engine compartment for more than 1 minute.
4. CLEAR PERMANENT DTC HINT: Even if the following procedure is not performed, permanent DTCs are cleared by obtaining a normal judgment during 3 consecutive driving cycles. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check if permanent DTCs are stored. HINT: If permanent DTCs are not output, it is not necessary to continue this procedure. Clear DTCs. Perform the respective confirmation driving patterns in order to obtain a normal judgment for the output DTCs. HINT: Confirmation driving patterns do not need to be performed for misfire and fuel system DTCs. For the confirmation driving pattern, refer to the procedures for the relevant DTC. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-394513-S31071923012011040800000). Perform the universal trip. HINT: The driving pattern to obtain a normal judgment and the universal trip driving pattern can be performed consecutively in the same driving cycle. Idle the engine for 30 seconds or more. Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more. HINT: It is possible to complete the drive pattern even if the vehicle decelerates to less than 40 km/h (25 mph) during the driving cycle provided that the vehicle is driven at 40 km/h (25 mph) or more for a total of 5 minutes. Allow 10 minutes or more to elapse from the time the engine is started. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Check that the permanent DTCs have been cleared. HINT: The permanent DTCs are cleared when the universal trip is completed.

Scheme 21

1. DESCRIPTION Freeze frame data record the engine conditions (fuel system, calculated load, engine coolant temperature, fuel trim, engine speed, vehicle speed, etc.) when a malfunction is detected. When troubleshooting, it can help determine if the vehicle was running or stopped, the engine was warmed up or not, the air-fuel ratio was Lean or Rich, and other data, from the time the malfunction occurred. HINT: If it is impossible to duplicate the problem even though a DTC is detected, confirm the freeze frame data. The ECM records engine conditions in the form of freeze frame data every 0.5 seconds. Using a Techstream, five separate sets of freeze frame data, including the data values at the time when the DTC was set, can be checked. 3 data sets before the DTC was set. 1 data set when the DTC was set. 1 data set after the DTC was set. These data sets can be used to simulate the condition of the vehicle around the time of the occurrence of the malfunction. The data may assist in identifying the cause of the malfunction, and in judging whether it was temporary or not.
2. LIST OF FREEZE FRAME DATA Tester Display Measurement Item Diagnostic Note Vehicle Speed Vehicle speed Speed indicated on speedometer Engine Speed Engine speed - Calculate Load Calculated load by ECM - Vehicle Load Vehicle load - MAF Air flow rate from Mass Air Flow (MAF) meter If value approximately 0.0 g/sec: MAF meter power source circuit open VG circuit open or short If value 271.0 g/sec or more: E2G circuit open Atmosphere Pressure Atmospheric pressure - Coolant Temp Engine coolant temperature If -40°C (-40°F): sensor circuit open If 140°C (284°F) or more: sensor circuit shorted Intake Air Intake air temperature If -40°C (-40°F): sensor circuit open If 140°C (284°F) or more: sensor circuit shorted Ambient Temperature Ambient air temperature - Engine Run Time Engine run time - Initial Engine Coolant Temp Engine coolant temperature at engine start - Initial Intake Air Temp Intake air temperature at engine start - Battery Voltage Battery voltage - Accel Sens. No. 1 Volt % Absolute Accelerator Pedal Position (APP) No. 1 Read value with ignition switch ON (Do not start engine) Accel Sens. No. 2 Volt % Absolute APP No. 2 Read value with ignition switch ON (Do not start engine) Throttle Sensor Volt % Throttle position sensor Calculated value based on VTA1 Read value with ignition switch ON (Do not start engine) Throttle Sensor #2 Volt % Throttle position No. 2 sensor Calculated value based on VTA2 Read value with ignition switch ON (Do not start engine) Throttle Sensor Position Throttle position Recognition value for throttle opening angle on ECM Read value with ignition switch ON (Do not start engine) Throttle Motor DUTY Throttle actuator - Throttle Position Throttle valve opening angle Reference: Check the value when the engine stalls, is difficult to start, or idles roughly ISC Flow Flow rate calculated using information from each sensor Reference: Check the value when the engine stalls, is difficult to start, or idles roughly ISC Position Requested opening amount calculated using ISC control Reference: Check the value when the engine stalls, is difficult to start, or idles roughly ISC Feedback Value ISC feedback compensation amount Reference: Check the value when the engine stalls, is difficult to start, or idles roughly ISC Learning Value ISC learned compensation amount Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Electric Load Feedback Val Compensation flow rate according to electrical load Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Air Conditioner FB Val Compensation flow rate according to air conditioner load Reference: Check the value when the engine stalls, is difficult to start, or idles roughly PS Feedback Val Compensation flow rate according to power steering load Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Low Revolution Control Low engine speed control operation state Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Neutral Control Neutral control operation state Reference: Check the value when the engine stalls, is difficult to start, or idles roughly N Range Status Shift lever N status Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Eng Stall Control FB Flow Intake air compensation flow rate Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Deposit Loss Flow Flow loss due to deposits Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Injector (Port) Injection period of No. 1 cylinder - Injection Volum (Cylinder1) Injection volume (Cylinder 1) Quantity of fuel injection volume for 10 times Fuel Pump/Speed Status Fuel pump status Active Test support data Vacuum Pump Key-off EVAP system leak detection pump status Active Test support data Refer to «EVAP System»(ref-394517-S14308387642011040800000) EVAP (Purge) VSV EVAP (PURGE) VSV control duty Order signal from ECM Evap Purge Flow Ratio of evaporative purge flow to intake air volume - Purge Density Learn Value Learning value of purge density - EVAP System Vent Valve Key-off EVAP system vent valve status Active Test support data EVAP Purge VSV Purge VSV status Active Test support data Purge Cut VSV Duty Purge VSV actuate duty Active Test support data Target Air-Fuel Ratio Ratio compared to stoichiometric level - AF Lambda B1S1 Short-term fuel trim associated with sensor 1 - AFS Voltage B1S1 A/F sensor output voltage for sensor 1 Performing the Control the Injection Volume or Control the Injection Volume for A/F Sensor function of the Active Test enables the technician to check voltage output of the sensor. AFS Current B1S1 A/F sensor output current for sensor 1 Performing the Control the Injection Volume or Control the Injection Volume for A/F Sensor function of the Active Test enables the technician to check voltage output of the sensor. A/F Heater Duty #1 A/F heater duty ratio (for Bank 1) - O2S B1S2 Heated oxygen sensor output voltage for sensor 2 Performing the Control the Injection Volume or Control the Injection Volume for A/F Sensor function of the Active Test enables the technician to check voltage output of the sensor. O2S Impedance B1S2 Sub heated oxygen sensor impedance (sensor 2) - O2 Heater B1S2 Heated oxygen sensor heater (for Bank 1 Sensor 2) - O2 Heater Curr Val B1S2 Heated oxygen sensor current (for Bank 1 Sensor 2) - Short FT #1 Short-term fuel trim Short-term fuel compensation used to maintain air-fuel ratio at stoichiometric air-fuel ratio Long FT #1 Long-term fuel trim Overall fuel compensation carried out in long-term to compensate continual deviation of short-term fuel trim from central value Total FT #1 Total fuel trim value for fuel system - Fuel System Status #1 Fuel system status bank 1 OL (Open Loop): Has not yet satisfied conditions to go closed loop CL (Closed Loop): Using A/F sensor as feedback for fuel control OLDrive: Open loop due to driving conditions (fuel enrichment) OLFault: Open loop due to detected system fault CLFault: Closed loop but A/F sensor, which used for fuel control malfunctioning Fuel System Status #2 Fuel system status bank 2 IGN Advance Ignition timing advance for No. 1 cylinder - Knock Feedback Value Knock feedback value Service data Knock Correct Learn Value Knock correction learning value Service data Idle Spark Advn Ctrl #1 Individual cylinder timing advance compensation amount (No. 1) Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Idle Spark Advn Ctrl #2 Individual cylinder timing advance compensation amount (No. 2) Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Idle Spark Advn Ctrl #3 Individual cylinder timing advance compensation amount (No. 3) Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Idle Spark Advn Ctrl #4 Individual cylinder timing advance compensation amount (No. 4) Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Actual VVT Angle #1 Actual VVT displacement angle (bank 1) This item is used for freeze frame data only. VVT Control Status #1 VVT control #1 status - VVT Advance Fail VVT control failure status - Catalyst Temp B1S1 Estimated catalyst temperature (sensor 1) - Catalyst Temp B1S2 Estimated catalyst temperature (sensor 2) - Starter Signal Starter relay (STA) signal status - Starter Control Starter switch (STSW) signal status - Power Steering Signal Power steering signal status - Starter Relay Starter control (STAR) signal status - ACC Relay ACC CUT relay status - Neutral Position SW Signal PNP switch status - Clutch Switch Clutch switch status Clutch switch (upper) signal status for Cruise Control System Clutch Start SW Clutch switch status Clutch start switch (lower) signal status for engine cranking Stop Light Switch Stop light switch status - A/C Signal A/C signal status - Closed Throttle Position SW Closed throttle position switch - Fuel Cut Condition Fuel cut condition - Immobiliser Communication Immobiliser communication OFF: Communication malfunctioning, or engine immobiliser system set ON: Communication normal TC Terminal TC terminal status - # Codes (Include History) Number of detected DTCs - Time after DTC Cleared Time after DTC cleared - Distance from DTC Cleared Distance traveled since DTCs cleared - Warm up Cycle Cleared DTC Warm-up cycle after DTC cleared - Dist Batt Cable Disconnect Distance after battery cable disconnected - IG OFF Elapsed Time Time after ignition switch off - TC and TE1 TC and CG (TE1) terminal of DLC3 Active Test support data Ignition Trig. Count Ignition counter - Cylinder #1 Misfire Count Misfire count of cylinder 1 - Cylinder #2 Misfire Count Misfire count of cylinder 2 - Cylinder #3 Misfire Count Misfire count of cylinder 3 - Cylinder #4 Misfire Count Misfire count of cylinder 4 - All Cylinders Misfire Count All cylinders misfire - Misfire RPM Engine speed when misfire occur - Misfire Load Engine load when misfire occur - Misfire Margin Margin to detect engine misfire Misfire detecting margin Catalyst OT MF F/C Catalyst over temperature misfire prevention F/C - Cat OT MF F/C History Catalyst over temperature misfire prevention F/C history - Cat OT MF F/C Cylinder #1 Display of fuel cut operation in No. 1 cylinder (if certain level of misfire malfunction is detected) - Cat OT MF F/C Cylinder #2 Display of fuel cut operation in No. 2 cylinder (if certain level of misfire malfunction is detected) - Cat OT MF F/C Cylinder #3 Display of fuel cut operation in No. 3 cylinder (if certain level of misfire malfunction is detected) - Cat OT MF F/C Cylinder #4 Display of fuel cut operation in No. 4 cylinder (if certain level of misfire malfunction is detected) - Engine Speed (Starter Off) Engine speed when starter off Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Starter Count Number of times starter turned on after ignition switch turned to ON Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Run Dist of Previous Trip Distance driven during previous trip Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Engine Starting Time Time elapsed after engine started (interval between ignition switch ON and off) Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Previous Trip Coolant Temp Engine coolant temperature during previous trip Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Previous Trip Intake Temp Intake air temperature during previous trip Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Engine Oil Temperature Engine oil temperature (estimated temperature) Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Previous Trip Eng Oil Temp Engine oil temperature during previous trip Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Ambient Temp for A/C Ambient temperature for A/C Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Previous Trip Ambient Temp Ambient temperature during previous trip Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Engine Start Hesitation History of hesitation during engine start Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Low Rev for Eng Start History of low engine speed after engine start Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Minimum Engine Speed Minimum engine speed Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Electric Fan Motor Electric fan motor - Idle Fuel Cut Prohibit Idle fuel cut control prohibition status Active Test support data See Active Test item "Control the Idle Fuel Cut Prohibit" Idle Fuel Cut Fuel cut idle Idle Fuel Cut = "ON" when throttle valve fully closed and engine speed over 3500 rpm FC TAU Fuel cut TAU (Fuel cut during very light load) Fuel cut being performed under very light load to prevent engine combustion from becoming incomplete Immobiliser Fuel Cut Status of the immobiliser fuel cut - Electrical Load Signal 1 Electrical load signal (ELS terminal input) - Electrical Load Signal 2 Electrical load signal (ELS3 terminal input) - SPD (NT) Input shaft speed (inside the transaxle) Only for A/T models Shift SW Status (P Range) PNP switch status (P Range) Only for A/T models: When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect Shift SW Status (R Range) PNP switch status (R Range) Only for A/T models: When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect Shift SW Status (2 Range) PNP switch status (2nd Range) Only for A/T models: When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect Shift SW Status (L Range) PNP switch status (L Range) Only for A/T models: When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect Shift SW Status (N Range) PNP switch status (N Range) Only for A/T models: When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect Shift SW Status (D Range) PNP switch status (D Range) Only for A/T models: When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect Shift SW Status (3 Range) PNP switch status (3rd Range) Only for A/T models: When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect A/T Oil Temperature 1 No. 1 ATF temperature sensor value If value is -40°C (-40°F) or 215°C (419°F), No. 1 ATF temperature sensor circuit is open or shorted Lock Up Transaxle lock-up status - ST Solenoid Status Shift Solenoid ST Status - Shift Status ECM Gearshift Command - SLT Solenoid Status Shift Solenoid SLT Status - SLU Solenoid Status Shift Solenoid SLU Status - AT Fluid Flex lock-up judder judgment - FOR MEXICO MODELS Tester Display Measure Item Diagnostic Note Vehicle Speed Vehicle speed Speed indicated on speedometer Engine Speed Engine speed - Calculate Load Calculated load Calculated load by ECM Vehicle Load Vehicle load - MAF Mass air flow volume If approximately 0.0 g/sec: Mass air flow meter power source circuit open or short VG circuit open or short If 271.0 g/sec or more: E2G circuit open Atmosphere Pressure Atmospheric pressure Equivalent to atmospheric pressure Coolant Temp Engine coolant temperature If -40°C, sensor circuit open If 140°C or more, sensor circuit shorted Intake Air Intake air temperature If -40°C, sensor circuit open If 140°C or more, sensor circuit shorted Engine Run Time Accumulated engine running time - Initial Engine Coolant Temp Engine coolant temperature at engine start - Initial Intake Air Temp Intake air temperature at engine start - Battery Voltage Battery voltage - Accel Sens. No. 1 Volt % Absolute Accelerator Pedal Position (APP) No. 1 - Accel Sens. No. 2 Volt % Absolute APP No. 2 - Throttle Sensor Volt % Throttle sensor positioning - Throttle Sensor #2 Volt % Throttle sensor positioning #2 - Throttle Sensor Position Throttle position - Throttle Motor DUTY Throttle motor - Injector (Port) Injection period of No. 1 cylinder - Injection Volum (Cylinder1) Injection volume - Fuel Pump/Speed Status Fuel pump status - Vacuum Pump Key-off EVAP system leak detection pump status Active Test support data Refer to «EVAP System»(ref-394517-S14308387642011040800000) EVAP (Purge) VSV EVAP purge VSV duty ratio - Evap Purge Flow Ratio of evaporative purge flow to intake air volume - Purge Density Learn Value Learning value of purge density - EVAP System Vent Valve Key-off EVAP system vent valve status - EVAP Purge VSV EVAP Purge VSV - Target Air-Fuel Ratio Ratio compared to stoichiometric level - AF Lambda B1S1 Fuel trim at A/F sensor - AFS Voltage B1S1 A/F sensor output Performing Control the Injection Volume or Control the Injection Volume for A/F Sensor function of Active Test enables technician to check output voltage of sensor. AFS Current B1S1 A/F sensor output current for sensor 1 Performing Control the Injection Volume or Control the Injection Volume for A/F Sensor function of Active Test enables technician to check output voltage of sensor. O2S B1S2 Heated oxygen sensor output Performing Control the Injection Volume or Control the Injection Volume for A/F Sensor function of Active Test enables technician to check output voltage of sensor. O2S Impedance B1S2 Sub oxygen sensor impedance (sensor 2) - Short FT #1 Short-term fuel trim Short-term fuel compensation used to maintain air-fuel ratio at stoichiometric air-fuel ratio Long FT #1 Long-term fuel trim Overall fuel compensation carried out in long-term to compensate a continual deviation of short-term fuel trim from central value Total FT #1 Total fuel trim - Fuel System Status #1 Fuel system status #1 OL (Open Loop): Has not yet satisfied conditions to go closed loop CL (Closed Loop): Using A/F sensor as feedback for fuel control OLDrive: Open loop due to driving conditions (fuel enrichment) OLFault: Open loop due to detected system fault CLFault: Closed loop but A/F sensor, which used for fuel control malfunctioning Fuel System Status #2 Fuel system status #2 IGN Advance Ignition advance - Knock Feedback Value Feedback value of knocking - Knock Correct Learn Value Correction learning value of knocking - VVT Control Status #1 VVT control status - Catalyst Temp (B1S1) Estimated catalyst temperature (sensor 1) - Catalyst Temp (B1S2) Estimated catalyst temperature (sensor 2) - Starter Signal Starter switch (STSW) signal status - Starter Control Starter control (STAR) signal - Power Steering Signal Power steering signal - Starter Relay Starter relay (STA) signal - Power Steer. Sig. Record Power steering signal (history) Signal status usually ON until ignition switch turned off ACC Relay ACC CUT relay status - Neutral Position SW Signal Park/Neutral Position (PNP) switch signal status - Stop Light Switch Stop light switch status - A/C Signal A/C signal status - Closed Throttle Position SW Closed throttle position switch - Fuel Cut Condition Fuel cut condition ON: Any fuel cut operation executed Immobiliser Communication Immobiliser communication OFF: Communication malfunctioning, or engine immobiliser system set ON: Communication normal Electrical Load Signal Electrical load signal - Time after DTC Cleared Cumulative time after DTC cleared - Distance from DTC Cleared Accumulated distance from DTC cleared - Warm up Cycle Cleared DTC Warm-up cycle after DTC cleared - TC and TE1 TC and CG (TE1) terminals of DLC3 - Ignition Trig. Count Ignition counter - Cylinder #1 Misfire Count Cylinder #1 misfire count - Cylinder #2 Misfire Count Cylinder #2 misfire count - Cylinder #3 Misfire Count Cylinder #3 misfire count - Cylinder #4 Misfire Count Cylinder #4 misfire count - All Cylinders Misfire Count All cylinders misfire count - Misfire RPM Engine speed when misfire occurred - Misfire Load Engine load when misfire occurred - Misfire Margin Margin to detect engine misfire - Catalyst OT MF F/C Catalyst over temperature Misfire prevention fuel cut - Cat OT MF F/C History Catalyst over temperature Misfire prevention fuel cut history: - Cat OT MF F/C Cylinder #1 Display of fuel cut operation in No. 1 cylinder (if certain level of misfire malfunction is detected) - Cat OT MF F/C Cylinder #2 Display of fuel cut operation in No. 2 cylinder (if certain level of misfire malfunction is detected) - Cat OT MF F/C Cylinder #3 Display of fuel cut operation in No. 3 cylinder (if certain level of misfire malfunction is detected) - Cat OT MF F/C Cylinder #4 Display of fuel cut operation in No. 4 cylinder (if certain level of misfire malfunction is detected) - Electric Fan Motor Electric fan motor - Idle Fuel Cut Fuel cut idle ON: when throttle valve fully closed and engine speed over 3,500 rpm FC TAU Fuel cut during very light load Fuel cut being performed under very light load to prevent engine combustion from becoming incomplete

DATA LIST / ACTIVE TEST

1. DATA LIST HINT: By reading the Data List displayed on a Techstream, values can be checked, including those of the switches, sensors, and actuators, without removing any parts. Reading the Data List as the first step of troubleshooting is one method of shortening diagnostic time. NOTE: In the table below, the values listed under Normal Condition are for reference only. Do not depend solely on these values when determining whether or not a part is faulty. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List. Check the values by referring to the table below. Tester Display Measurement Item/Range Normal Condition *1 Diagnostic Note Vehicle Speed Vehicle speed: Min.: 0 mph (0 km/h), Max.: 158.4 mph (255 km/h) Actual vehicle speed Speed indicated on speedometer Engine Speed Engine speed: Min.: 0 rpm, Max.: 16383.75 rpm 550 to 650 rpm: Idling (M/T) 650 to 750 rpm: Idling (A/T) - Calculate Load Calculated load by ECM: Min.: 0 %, Max.: 100 % 15 to 35 %: Idling 15 to 35 %: Running without load at 2500 rpm - Vehicle Load Vehicle load: Min.: 0 %, Max.: 25700 % Actual vehicle load - MAF Air flow rate from Mass Air Flow (MAF) meter: Min.: 0 g/sec, Max.: 655.35 g/sec 1 to 3 g/sec: Idling 2 to 6 g/sec: Running without load at 2500 rpm If value approximately 0.0 g/sec: MAF meter power source circuit open VG circuit open or short If value 271.0 g/sec or more: E2G circuit open Atmosphere Pressure Atmospheric pressure: Min.: 0 kPa, Max.: 255 kPa Approximately 100 kPa: Ignition switch ON - Coolant Temp Engine coolant temperature: Min.: -40°C, Max.: 140°C 80 to 100°C (176 to 212°F): After warming up If -40°C (-40°F): sensor circuit open If 140°C (284°F) or more: sensor circuit shorted Intake Air Intake air temperature: Min.: -40°C, Max.: 140°C Equivalent to ambient air temperature If -40°C (-40°F): sensor circuit open If 140°C (284°F) or more: sensor circuit shorted Ambient Temperature Ambient air temperature Min.: -40°C, Max.: 215°C Equivalent to ambient air temperature: Ignition switch ON - Engine Run Time Engine run time: Min.: 0 second, Max.: 65535 seconds Time after engine start - Initial Engine Coolant Temp Engine coolant temperature at engine start: Min.: -40°C, Max.: 119.3°C Close to ambient air temperature - Initial Intake Air Temp Intake air temperature at engine start: Min.: -40°C, Max.: 119.3°C Close to ambient air temperature - Battery Voltage Battery voltage: Min.: 0 V, Max.: 65.535 V 11 to 14 V: Ignition switch ON - Accelerator Position Accelerator pedal position: Min.: 0%, Max.: 399.9% Actual accelerator pedal position - Accel Sens. No. 1 Volt % Absolute Accelerator Pedal Position (APP) No. 1: Min.: 0 %, Max.: 100 % 10 to 22 %: Accelerator pedal released 52 to 90 %: Accelerator pedal fully depressed Read value with ignition switch ON (Do not start engine) Accel Sens. No. 2 Volt % Absolute APP No. 2: Min.: 0 %, Max.: 100 % 24 to 40 %: Accelerator pedal released 68 to 100 %: Accelerator pedal fully depressed Read value with ignition switch ON (Do not start engine) Accel Sensor Out No. 1 APP sensor No. 1 voltage: Min.: 0 V, Max.: 4.98 V 0.5 to 1.1 V: Accelerator pedal released 2.6 to 4.5 V: Accelerator pedal fully depressed Read value with ignition switch ON (Do not start engine) Accel Sensor Out No. 2 APP sensor No. 2 voltage: Min.: 0 V, Max.: 4.98 V 1.2 to 2.0 V: Accelerator pedal released 3.4 to 4.7 V: Accelerator pedal fully depressed Read value with ignition switch ON (Do not start engine) Accelerator Idle Position Whether or not accelerator pedal position sensor detecting idle: ON or OFF ON: Idling - Accel Fully Close Learn #1 Accelerator fully closed learning value No. 1: Min.: 0 deg, Max.: 124.512 deg - ETCS service data Accel Fully Close Learn #2 Accelerator fully closed learning value No. 2: Min.: 0 deg, Max.: 124.512 deg - ETCS service data Throttle Sensor Volt % Throttle position sensor: Min.: 0%, Max.: 100 % 10 to 22 %: Throttle fully closed 64 to 96 %: Throttle fully open Calculated value based on VTA1 Read value with ignition switch ON (Do not start engine) Throttle Sensor #2 Volt % Throttle position No. 2 sensor: Min.: 0 %, Max.: 100 % 42 to 62 %: Throttle fully closed 92 to 100 %: Throttle fully open Calculated value based on VTA2 Read value with ignition switch ON (Do not start engine) ST1 Brake pedal signal: ON or OFF ON: Brake pedal depressed - System Guard System guard: ON or OFF - ETCS service data Open Side Malfunction Open side malfunction: ON or OFF - ETCS service data Throttle Idle Position Whether or not throttle position sensor detecting idle: ON or OFF ON: Idling - Throttle Require Position Throttle requirement position: Min.: 0 V, Max.: 4.98 V 0.5 to 1.1 V: Idling - Throttle Sensor Position *2 Throttle position: Min.: 0 %, Max.: 100 % 0 %: Throttle fully closed 50 to 80 %: Throttle fully open Recognition value for throttle opening angle on ECM Read value with ignition switch ON (Do not start engine) Throttle Position No. 1 Throttle position sensor No. 1 output voltage: Min.: 0 V, Max.: 4.98 V 0.5 to 1.1 V: Throttle fully closed 3.2 to 4.8 V: Throttle fully open 0.6 to 1.4 V: Fail-safe operating Read value with ignition switch ON (Do not start engine) Throttle Position No. 2 Throttle position sensor No. 2 output voltage: Min.: 0 V, Max.: 4.98 V 2.1 to 3.1 V: Throttle fully closed 4.6 to 5.0 V: Throttle fully open 2.1 to 3.1 V: Fail-safe operating Read value with ignition switch ON (Do not start engine) Throttle Position Command Throttle position command value: Min.: 0 V, Max.: 4.98 V 0.5 to 4.8 V Read value with ignition switch ON (Do not start engine) Throttle Sens Open Pos #1 Throttle sensor opener position No. 1: Min.: 0 V, Max.: 4.98 V 0.6 to 1.4 V ETCS service data Throttle Sens Open Pos #2 Throttle sensor opener position No. 2: Min.: 0 V, Max.: 4.98 V 1.7 to 2.5 V ETCS service data Throttle Motor Current Throttle actuator current: Min.: 0 A, Max.: 19.92 A 0 to 3.0 A: Idling - Throttle Motor DUTY Throttle actuator: Min.: 0 %, Max.: 100 % 0.5 to 40 %: Idling - Throttle Motor Duty (Open) Throttle actuator duty ratio (open): Min.: 0 %, Max.: 255 % 0 to 40 %: During idling ETCS service data Throttle Motor Duty (Close) Throttle actuator duty ratio (closed): Min.: 0 %, Max.: 255 % 0 to 40 %: During idling ETCS service data Throttle Fully Close Learn Throttle valve fully closed (learned value): Min.: 0 V, Max.: 4.98 V 0.4 to 1.0 V: Accelerator pedal released - +BM Voltage +BM voltage: Min.: 0 V, Max.: 79.998 V 11 to 14 (V): Ignition switch ON and system normal ETCS service data Actuator Power Supply Actuator power supply: ON or OFF ON: Idling ETCS service data Throttle Position Throttle valve opening angle: Min.: 0 deg, Max.: 499.99 deg - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly ISC Flow Flow rate calculated using information from each sensor: Min.: 0 L/s, Max.: 79.99 L/s - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly ISC Position Requested opening amount calculated using ISC control: Min.: 0 deg, Max.: 499.99 deg - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly ISC Feedback Value ISC feedback compensation amount: Min.: -40 L/s, Max.: 39.99 L/s - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly ISC Learning Value ISC learned compensation amount: Min.: -40 L/s, Max.: 39.99 L/s - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Electric Load Feedback Val Compensation flow rate according to electrical load: Min.: -40 L/s, Max.: 39.99 L/s - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Air Conditioner FB Val Compensation flow rate according to air conditioner load: Min.: -40 L/s, Max.: 39.99 L/s - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly PS Feedback Val Compensation flow rate according to power steering load: Min.: -40 L/s, Max.: 39.99 L/s - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Low Revolution Control Low engine speed control operation state: ON or OFF - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Neutral Control Neutral control operation state: ON or OFF - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly N Range Status Shift lever N status: ON or OFF - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Eng Stall Control FB Flow Intake air compensation flow rate: Min.: -40 L/s, Max.: 39.99 L/s - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Deposit Loss Flow Flow loss due to deposits: Min.: -40 L/s, Max.: 39.99 L/s - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Injector (Port) Injection period of No. 1 cylinder: Min.: 0 μs, Max.: 65535 μs 1000 to 3000 μs: Idling - Injection Volum (Cylinder1) Injection volume (Cylinder 1): Min.: 0 ml, Max.: 2.047 ml 0 to 0.15 ml: Idling Quantity of fuel injection volume for 10 times Fuel Pump/Speed Status Fuel pump status: ON or OFF ON: Engine running Active Test support data Vacuum Pump Key-off EVAP system leak detection pump status: ON or OFF - Active Test support data EVAP (Purge) VSV EVAP (PURGE) VSV control duty: Min.: 0 %, Max.: 100 % 10 to 50 %: Idling Order signal from ECM Evap Purge Flow Ratio of evaporative purge flow to intake air volume: Min.: 0 %, Max.: 399.9 % 0 to 10 %: Idling - Purge Density Learn Value Learning value of purge density: Min.: -200, Max.: 199.993 -40 to 10: Idling - Vapor Pressure Pump Vapor pressure: Min.: 0 kPa (0 mmHg), Max.: 1441.77 kPa (10814.17 mmHg) Nearly atmospheric pressure: Fuel tank cap removed EVAP system pressure monitored by canister pressure sensor Vapor pressure (calculated) Vapor pressure (calculated): Min.: -720.896 kPa (-5407.167 mmHg), Max.: 720.874 kPa (5407.002 mmHg) Nearly atmospheric pressure: Fuel tank cap removed EVAP system pressure monitored by canister pressure sensor EVAP System Vent Valve Key-off EVAP system vent valve status: ON or OFF - Active Test support data EVAP Purge VSV Purge VSV status: ON or OFF - Active Test support data Purge Cut VSV Duty Purge VSV actuate duty: Min.: 0 %, Max.: 399.9 % - Active Test support data Target Air-Fuel Ratio Ratio compared to stoichiometric level: Min.: 0, Max.: 1.999 0.8 to 1.2: Idling - AF Lambda B1S1 Short-term fuel trim associated with sensor 1: Min.: 0, Max.: 1.999 Value less than 1 (0.000 to 0.999) = Rich Stoichiometric air-fuel ratio=1 Value greater than 1 (1.001 to 1.999) = Lean - AFS Voltage B1S1 A/F sensor output voltage for sensor 1: Min.: 0 V Max.: 7.999 V 2.8 to 3.8 V: Idling Performing the Control the Injection Volume or Control the Injection Volume for A/F Sensor function of the Active Test enables the technician to check voltage output of the sensor. AFS Current B1S1 A/F sensor output current for sensor 1: Min.: -128 mA, Max.: 127.99 mA - Performing the Control the Injection Volume or Control the Injection Volume for A/F Sensor function of the Active Test enables the technician to check voltage output of the sensor. A/F Heater Duty #1 A/F heater duty ratio (for Bank 1): Min.: 0 %, Max.: 399.9 % 0 to 100% - O2S B1S2 Heated oxygen sensor output voltage for sensor 2: Min.: 0 V Max.: 1.275 V 0.1 to 0.9 V: Driving at 44 mph (70 km/h) Performing the Control the Injection Volume or Control the Injection Volume for A/F Sensor function of the Active Test enables the technician to check voltage output of the sensor. O2S Impedance B1S2 Sub heated oxygen sensor impedance (sensor 2): Min.: 0 ohm, Max.: 21247.68 ohm 5 to 15,000 ohm: While vehicle is driving and engine is warmed up - O2 Heater B1S2 Heated oxygen sensor heater (for Bank 1 Sensor 2): Active or Not Act - - O2 Heater Curr Val B1S2 Heated oxygen sensor current (for Bank 1 Sensor 2): Min.: 0 A, Max.: 4.9 A - - Short FT #1 Short-term fuel trim: Min.: -100 %, Max.: 99.2 % -20 to 20 % Short-term fuel compensation used to maintain air-fuel ratio at stoichiometric air-fuel ratio Long FT #1 Long-term fuel trim: Min.: -100 %, Max.: 99.2 % -20 to 20 % Overall fuel compensation carried out in long-term to compensate continual deviation of short-term fuel trim from central value Total FT #1 Total fuel trim value for fuel system: Min.: -0.5, Max.: 0.496 -0.2 to 0.2 - Fuel System Status #1 Fuel system status bank 1: OL, CL, OLDrive, OLFault or CLFault CL: Idling after warming up OL (Open Loop): Has not yet satisfied conditions to go closed loop CL (Closed Loop): Using A/F sensor as feedback for fuel control OLDrive: Open loop due to driving conditions (fuel enrichment) OLFault: Open loop due to detected system fault CLFault: Closed loop but A/F sensor, which used for fuel control malfunctioning Fuel System Status #2 Fuel system status bank 2 Unused IGN Advance Ignition timing advance for No. 1 cylinder: Min.: -64 deg, Max.: 63.5 deg BTDC 0 to 14 deg: Idling - Knock Feedback Value Knock feedback value: Min.: -1024° CA, Max.: 1023.9° CA -20 to 0°CA: Driving at 44 mph (70 km/h) Service data Knock Correct Learn Value Knock correction learning value: Min.: -1024° CA, Max.: 1023.9° CA 0 to 20°CA: Driving at 44 mph (70 km/h) Service data Idle Spark Advn Ctrl #1 Individual cylinder timing advance compensation amount (No. 1): Min.: 0° CA, Max.: 15.93° CA - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Idle Spark Advn Ctrl #2 Individual cylinder timing advance compensation amount (No. 2): Min.: 0° CA, Max.: 15.93° CA - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Idle Spark Advn Ctrl #3 Individual cylinder timing advance compensation amount (No. 3): Min.: 0° CA, Max.: 15.93° CA - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Idle Spark Advn Ctrl #4 Individual cylinder timing advance compensation amount (No. 4): Min.: 0° CA, Max.: 15.93° CA - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Actual VVT Angle #1 Actual VVT displacement angle (bank 1): Min.: 0°FR, Max.: 639.99°FR - This item is used for freeze frame data only. VVT Control Status #1 VVT control #1 status: ON or OFF - - VVT Advance Fail VVT control failure status: ON or OFF ON: VVT control failure - VVT Aim Angle #1*3 VVT aim angle (bank 1): Min.: 0 %, Max.: 399.9 % 0 to 100 % VVT duty signal value during intrusive operation VVT Change Angle #1*3 VVT change angle (bank 1): Min.: 0° FR, Max.: 639.9° FR 0 to 56° FR Displacement angle during intrusive operation VVT OCV Duty #1*3 VVT OCV operation duty: Min.: 0 %, Max.: 399.9 % 0 to 100 % Requested duty value for intrusive operation VN Turbo Type VN turbo type Not Avl, Commo, Vacuum or CAN Com Not Avl - Catalyst Temp B1S1 Estimated catalyst temperature (sensor 1): Min.: -40°C, Max.: 6513.5°C - - Catalyst Temp B1S2 Estimated catalyst temperature (sensor 2): Min.: -40°C, Max.: 6513.5°C - - Starter Signal Starter relay (STA) signal: ON or OFF ON: Cranking - Starter Control Starter switch (STSW) signal: ON or OFF ON: Cranking - Power Steering Signal Power steering signal: ON or OFF ON: Power steering operation - Starter Relay Starter control (STAR) signal: ON or OFF ON: Cranking - ACC Relay ACC CUT relay status: ON or OFF ON: Cranking - Neutral Position SW Signal PNP switch status: ON or OFF ON: P or N position - Clutch Switch Clutch switch status: ON or OFF ON: Clutch pedal depressed Clutch switch (upper) signal status for Cruise Control System Clutch Start SW Clutch switch status: ON or OFF ON: Clutch pedal fully depressed Clutch start switch (lower) signal status for engine cranking Stop Light Switch Stop light switch: ON or OFF ON: Brake pedal depressed - A/C Signal A/C signal: ON or OFF ON: A/C ON - Closed Throttle Position SW Closed throttle position switch: ON or OFF ON: Throttle fully closed OFF: Throttle open - Fuel Cut Condition Fuel cut condition: ON or OFF ON: Any fuel cut operation executed - Immobiliser Communication Immobiliser communication: ON or OFF - OFF: Communication malfunctioning, or engine immobiliser system set ON: Communication normal Check Mode Check mode: ON or OFF ON: Check mode ON Refer to «CHECK MODE PROCEDURE»(ref-394513-S19948725612011040800000) SPD Test Result Check mode result for vehicle speed sensor: Compl or Incmpl - - Misfire Test Result Check mode result for misfire monitor: Compl or Incmpl - - OXS1 Test Result Check mode result for HO2 sensor: Compl or Incmpl - - A/F Test Results #1 Check mode result for air-fuel ratio sensor: Compl or Incmpl - - Complete Parts Monitor Comprehensive component monitor: Not Avl or Avail - - Fuel System Monitor Fuel system monitor: Not Avl or Avail - - Misfire Monitor Misfire monitor: Not Avl or Avail - - EGR/VVT Monitor EGR/VVT Monitor: Not Avl or Avail - - EGR/VVT Monitor EGR/VVT Monitor: Compl or Incmpl - - O2S(A/FS) Heater Monitor O2S (A/FS) heater monitor: Not Avl or Avail - - O2S(A/FS) Heater Monitor O2S (A/FS) heater monitor: Compl or Incmpl - - O2S(A/FS) Monitor O2S (A/FS) monitor: Not Avl or Avail - - O2S(A/FS) Monitor O2S (A/FS) monitor: Compl or Incmpl - - A/C Monitor A/C monitor: Not Avl or Avail - - A/C Monitor A/C monitor: Compl or Incmpl - - 2nd Air Monitor 2nd air monitor: Not Avl or Avail - - 2nd Air Monitor 2nd air monitor: Compl or Incmpl - - EVAP Monitor EVAP monitor: Not Avl or Avail - - EVAP Monitor EVAP monitor: Compl or Incmpl - - Heated Catalyst Monitor Heated catalyst monitor: Not Avl or Avail - - Heated Catalyst Monitor Heated catalyst monitor: Compl or Incmpl - - Catalyst Monitor Catalyst monitor: Not Avl or Avail - - Catalyst Monitor Catalyst monitor: Compl or Incmpl - - Component Monitor ENA Comprehensive component monitor: Unable or Enable - - Component Monitor CMPL Comprehensive component monitor: Compl or Incmpl - - Fuel System Monitor ENA Fuel system monitor: Unable or Enable - - Fuel System Monitor CMPL Fuel system monitor: Compl or Incmpl - - Misfire Monitor ENA Misfire monitor: Unable or Enable - - Misfire Monitor CMPL Misfire monitor: Compl or Incmpl - - EGR/VVT Monitor ENA EGR monitor: Unable or Enable - - EGR/VVT Monitor CMPL EGR monitor: Compl or Incmpl - - Heater Monitor ENA O2S (A/FS) heater monitor: Unable or Enable - - Heater Monitor CMPL O2S (A/FS) heater monitor: Compl or Incmpl - - O2S(A/FS) Monitor ENA O2S (A/FS) monitor: Unable or Enable - - O2S(A/FS) Monitor CMPL O2S (A/FS) monitor: Compl or Incmpl - - A/C Monitor ENA A/C monitor: Unable or Enable - - A/C Monitor CMPL A/C monitor: Compl or Incmpl - - 2nd Air Monitor ENA 2nd air monitor: Unable or Enable - - 2nd Air Monitor CMPL 2nd air monitor: Compl or Incmpl - - EVAP Monitor ENA EVAP monitor: Unable or Enable - - EVAP Monitor CMPL EVAP monitor: Compl or Incmpl - - Heated Cat Monitor ENA Heated catalyst monitor: Unable or Enable - - Heated Cat Monitor CMPL Heated catalyst monitor: Compl or Incmpl - - Catalyst Monitor ENA Catalyst monitor: Unable or Enable - - Catalyst Monitor CMPL Catalyst monitor: Compl or Incmpl - - TC Terminal TC terminal status: ON or OFF OFF: TC and CG terminals of the DLC3 are unconnected - # Codes (Include History) Number of detected DTCs: Min.: 0, Max.: 255 - - MIL MIL status: ON or OFF ON: MIL ON - MIL ON Run Distance MIL ON Run Distance: Min.: 0 km, Max.: 65535 km Distance after DTC detected - Running Time from MIL ON Running time from MIL ON: Min.: 0 minute, Max.: 65535 minutes Equivalent to running time after MIL ON - Time after DTC Cleared Time after DTC cleared: Min.: 0 minute, Max.: 65535 minutes Equivalent to time after DTCs erased - Distance from DTC Cleared Distance traveled since DTCs cleared: Min.: 0 km, Max.: 65535 km Equivalent to drive distance after DTCs erased - Warm up Cycle Cleared DTC Warm-up cycle after DTC cleared: Min.: 0, Max.: 255 - - Dist Batt Cable Disconnect Distance after battery cable disconnected: Min.: 0 km, Max.: 65535 km Total distance vehicle driven after battery cable disconnected - IG OFF Elapsed Time Time after ignition switch off: Min.: 0 minutes, Max.: 655350 minutes Cumulative time after ignition switch off - OBD Requirements OBD requirement OBD2 - Number of Emission DTC Number of emission-related DTCs - - TC and TE1 TC and CG (TE1) terminal of DLC3: ON or OFF - Active Test support data Ignition Trig. Count Ignition counter: Min.: 0, Max.: 800 0 to 400 - Cylinder #1 Misfire Count Misfire count of cylinder 1: Min.: 0, Max.: 255 0 - Cylinder #2 Misfire Count Misfire count of cylinder 2: Min.: 0, Max.: 255 0 - Cylinder #3 Misfire Count Misfire count of cylinder 3: Min.: 0, Max.: 255 0 - Cylinder #4 Misfire Count Misfire count of cylinder 4: Min.: 0, Max.: 255 0 - All Cylinders Misfire Count All cylinders misfire: Min.: 0, Max.: 255 0 - Misfire RPM Engine speed when misfire occur: Min.: 0 rpm, Max.: 6375 rpm - - Misfire Load Engine load when misfire occur: Min.: 0 g/rev, Max.: 3.98 g/rev - - Misfire Margin Margin to detect engine misfire: Min.: -128 %, Max.: 127 % -100 to 99.22 % Misfire detecting margin Catalyst OT MF F/C Catalyst over temperature misfire prevention F/C: Not Avl or Avail Avail: Cat OT MF F/C available Not Avl: Cat OT MF F/C not available - Cat OT MF F/C History Catalyst over temperature misfire prevention F/C history: ON or OFF ON: Fuel cut operation history exists - Cat OT MF F/C Cylinder #1 Display of fuel cut operation in No. 1 cylinder (if certain level of misfire malfunction is detected): ON or OFF ON: Fuel cut is operating - Cat OT MF F/C Cylinder #2 Display of fuel cut operation in No. 2 cylinder (if certain level of misfire malfunction is detected): ON or OFF ON: Fuel cut is operating - Cat OT MF F/C Cylinder #3 Display of fuel cut operation in No. 3 cylinder (if certain level of misfire malfunction is detected): ON or OFF ON: Fuel cut is operating - Cat OT MF F/C Cylinder #4 Display of fuel cut operation in No. 4 cylinder (if certain level of misfire malfunction is detected): ON or OFF ON: Fuel cut is operating - Engine Speed (Starter Off) Engine speed when starter off: Min.: 0 rpm, Max.: 51199 rpm - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Starter Count Number of times starter turned on after ignition switch turned to ON: Min.: 0, Max.: 255 - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Run Dist of Previous Trip Distance driven during previous trip: Min.: 0 km, Max.: 655.35 km - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Engine Starting Time Time elapsed after engine started (interval between ignition switch ON and off): Min.: 0 ms, Max.: 655350 ms - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Previous Trip Coolant Temp Engine coolant temperature during previous trip: Min.: -40°C, Max.: 215°C - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Previous Trip Intake Temp Intake air temperature during previous trip: Min.: -40°C, Max.: 215°C - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Engine Oil Temperature Engine oil temperature (estimated temperature): Min.: -40°C, Max.: 215°C - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Previous Trip Eng Oil Temp Engine oil temperature during previous trip: Min.: -40°C, Max.: 215°C - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Ambient Temp for A/C Ambient temperature for A/C: Min.: -40°C, Max.: 215°C - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Previous Trip Ambient Temp Ambient temperature during previous trip: Min.: -40°C, Max.: 215°C - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Engine Start Hesitation History of hesitation during engine start: ON or OFF - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Low Rev for Eng Start History of low engine speed after engine start: ON or OFF - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Minimum Engine Speed Minimum engine speed: Min.: 0 rpm, Max.: 51199 rpm - Reference: Check the value when the engine stalls, is difficult to start, or idles roughly Electric Fan Motor Electric fan motor: ON or OFF ON: Electric fan motor operating - Idle Fuel Cut Prohibit Idle fuel cut control prohibition status: ON or OFF OFF: Normal engine operation Active Test support data See Active Test item "Control the Idle Fuel Cut Prohibit" Idle Fuel Cut Fuel cut idle: ON or OFF ON: Fuel cut operation Idle Fuel Cut = "ON" when throttle valve fully closed and engine speed over 3500 rpm FC TAU Fuel cut TAU (Fuel cut during very light load): ON or OFF ON: Fuel cut operating Fuel cut being performed under very light load to prevent engine combustion from becoming incomplete Immobiliser Fuel Cut Status of the immobiliser fuel cut: ON or OFF OFF: Engine running - Electrical Load Signal 1 Electrical load signal (ELS terminal input): ON or OFF ON: Tail light switch ON - Electrical Load Signal 2 Electrical load signal (ELS3 terminal input): ON or OFF ON: Defogger switch ON - Model Code Identifying model code NCP9# - Engine Type Identifying engine type 1NZFE - Cylinder Number Identifying cylinder number: Min.: 0, Max.: 255 4 - Transmission Type Identifying transmission type MT or ECT 4th - Destination Identifying destination A (America) - Model Year Identifying model year: Min.: 1900, Max.: 2155 20## - System Identification System identification Gasoline (gasoline engine) - Engine Speed of Cyl #1 Engine RPM for cylinder 1: Min.: 0 rpm, Max.: 51199 rpm - Output only when Check the Cylinder Compression performed using Active Test 51199 rpm: Not performed Active Test Engine Speed of Cyl #2 Engine RPM for cylinder 2: Min.: 0 rpm, Max.: 51199 rpm - Output only when Check the Cylinder Compression performed using Active Test 51199 rpm: Not performed Active Test Engine Speed of Cyl #3 Engine RPM for cylinder 3: Min.: 0 rpm, Max.: 51199 rpm - Output only when Check the Cylinder Compression performed using Active Test 51199 rpm: Not performed Active Test Engine Speed of Cyl #4 Engine RPM for cylinder 4: Min.: 0 rpm, Max.: 51199 rpm - Output only when Check the Cylinder Compression performed using Active Test 51199 rpm: Not performed Active Test Av Engine Speed of All Cyl Engine RPM for all cylinders: Min.: 0 rpm, Max.: 51199 rpm - Output only when Check the Cylinder Compression performed using Active Test 51199 rpm: Not performed Active Test SPD (NT) Input shaft speed (inside the transaxle): Min.: 0 rpm, Max.: 12750 rpm Equal to engine speed: Lock-Up ON (After warming up engine) Nearly equal to engine speed: Lock-Up OFF (Idling at P or N position) 0 rpm: Vehicle stopped in D position Only for A/T models Shift SW Status (P Range) PNP switch status (P Range): ON or OFF Shift lever is: In P: ON Not in P: OFF Only for A/T models When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect Shift SW Status (R Range) PNP switch status (R Range): ON or OFF Shift lever is: In R: ON Not in R: OFF Only for A/T models When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect Shift SW Status (2 Range) PNP switch status (2nd Range): ON or OFF Shift lever is: In 2: ON Not in 2: OFF Only for A/T models When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect Shift SW Status (L Range) PNP switch status (L Range): ON or OFF Shift lever is: In L: ON Not in L: OFF Only for A/T models When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect Shift SW Status (N Range) PNP switch status (N Range): ON or OFF Shift lever is: In N: ON Not in N: OFF Only for A/T models When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect Shift SW Status (D Range) PNP switch status (D Range): ON or OFF Shift lever is: In D: ON Not in D: OFF Only for A/T models When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect Shift SW Status (3 Range) PNP switch status (3rd Range): ON or OFF Shift lever is: In 3: ON Not in 3: OFF Only for A/T models When shift lever position displayed on Techstream differs from actual position, adjustment of PNP switch or shift cable may be incorrect A/T Oil Temperature 1 No. 1 ATF temperature sensor value: Min.: -40°C, Max.: 215°C Equal to ambient temperature while engine is cold If value is -40°C (-40°F) or 215°C (419°F), No. 1 ATF temperature sensor circuit is open or shorted Lock Up Transaxle lock-up status: ON or OFF Lock-up is: Operating: ON Not operating: OFF - ST Solenoid Status Shift Solenoid ST Status ON or OFF OFF --> ON --> OFF: Up-shifting and down-shifting between 3rd and 4th gears while driving - Shift Status ECM Gearshift Command: 1st, 2nd, 3rd or 4th Shift lever position; L: 1st 2: 1st or 2nd 3: 1st, 2nd or 3rd D: 1st, 2nd, 3rd or 4th - SLT Solenoid Status Shift Solenoid SLT Status: ON or OFF OFF: Accelerator pedal is depressed ON: Accelerator pedal is released - SLU Solenoid Status Shift Solenoid SLU Status: ON or OFF Lock Up: ON Except Lock Up: OFF - AT Fluid Flex lock-up judder judgment: ON or OFF ON: Judder judgment occurs OFF: Judder judgment does not occur - HINT: *1: If no idling conditions are specified, the transmission gear selector lever should be in the N or P position (neutral), and the A/C switch and all accessory switches should be OFF. *2: Excluding throttle valve opening percentage due to Idle Speed Control (ISC). *3: Data List values are only displayed when performing the following Active Tests: Control the VVT Linear (Bank1), and Control the VVT System (Bank1). For other Active Tests, the Data List value will be 0. FOR MEXICO MODELS Tester Display Measurement Item/Range Normal Condition *1 Diagnostic Note Vehicle Speed Vehicle speed: Min.: 0 mph (0 km/h), Max.: 158.4 mph (255 km/h) Actual vehicle speed Speed indicated on speedometer Engine Speed Engine speed: Min.: 0 rpm, Max.: 16383.75 rpm 550 to 650 rpm: Idling (M/T) 650 to 750 rpm: Idling (A/T) - Calculate Load Calculated load by ECM: Min.: 0 %, Max.: 100 % 15 to 35 %: Idling 15 to 35 %: Running without load at 2500 rpm - Vehicle Load Vehicle load: Min.: 0 %, Max.: 25700 % Actual vehicle load - MAF Air flow rate from Mass Air Flow (MAF) meter: Min.: 0 g/sec, Max.: 655.35 g/sec 1 to 3 g/sec: Idling 2 to 6 g/sec: Running without load at 2500 rpm If value approximately 0.0 g/sec: MAF meter power source circuit open VG circuit open or short If value 271.0 g/sec or more: E2G circuit open Atmosphere Pressure Atmospheric pressure: Min.: 0 kPa, Max.: 255 kPa Approximately 100 kPa: Ignition switch ON - Coolant Temp Engine coolant temperature: Min.: -40°C, Max.: 140°C 80 to 100°C (176 to 212°F): After warming up If -40°C (-40°F): sensor circuit open If 140°C (284°F) or more: sensor circuit shorted Intake Air Intake air temperature: Min.: -40°C, Max.: 140°C Equivalent to ambient air temperature If -40°C (-40°F): sensor circuit open If 140°C (284°F) or more: sensor circuit shorted Engine Run Time Engine run time: Min.: 0 second, Max.: 65535 seconds Time after engine start - Initial Engine Coolant Temp Engine coolant temperature at engine start: Min.: -40°C, Max.: 120°C Close to ambient air temperature - Initial Intake Air Temp Intake air temperature at engine start: Min.: -40°C, Max.: 120°C Close to ambient air temperature - Battery Voltage Battery voltage: Min.: 0 V, Max.: 65.535 V 11 to 14 V: Ignition switch ON - Accel Sens. No. 1 Volt % Absolute Accelerator Pedal Position (APP) No. 1: Min.: 0 %, Max.: 100 % 10 to 22 %: Accelerator pedal released 52 to 90 %: Accelerator pedal fully depressed Read value with ignition switch ON (Do not start engine) Accel Sens. No. 2 Volt % Absolute APP No. 2: Min.: 0 %, Max.: 100 % 24 to 40 %: Accelerator pedal released 68 to 100 %: Accelerator pedal fully depressed Read value with ignition switch ON (Do not start engine) Accel Sensor Out No. 1 APP sensor No. 1 voltage: Min.: 0 V, Max.: 4.98 V - ETCS freeze data Accel Sensor Out No. 2 APP sensor No. 2 voltage: Min.: 0 V, Max.: 4.98 V - ETCS freeze data Accel Sensor Out No. 1 APP sensor No. 1 voltage: Min.: 0 V, Max.: 4.98 V 0.5 to 1.1 V: Accelerator pedal released 2.6 to 4.5 V: Accelerator pedal fully depressed Read value with ignition switch ON (Do not start engine) Accel Sensor Out No. 2 APP sensor No. 2 voltage: Min.: 0 V, Max.: 4.98 V 1.2 to 2.0 V: Accelerator pedal released 3.4 to 4.7 V: Accelerator pedal fully depressed Read value with ignition switch ON (Do not start engine) Accelerator Idle Position Whether or not accelerator pedal position sensor detecting idle: ON or OFF ON: Idling - Accel Fully Close #1 (AD) APP sensor No. 1 voltage (AD): Min.: 0 V, Max.: 4.98 V - ETCS service data Accel Fully Close Learn #1 Accelerator fully closed learning value No. 1: Min.: 0 deg, Max.: 124.5 deg - ETCS service data Accel Fully Close Learn #2 Accelerator fully closed learning value No. 2: Min.: 0 deg, Max.: 124.5 deg - ETCS service data Throttle Sensor Volt % Throttle position sensor: Min.: 0%, Max.: 100 % 10 to 22 %: Throttle fully closed 64 to 96 %: Throttle fully open Calculated value based on VTA1 Read value with ignition switch ON (Do not start engine) Throttle Sensor #2 Volt % Throttle position No. 2 sensor: Min.: 0 %, Max.: 100 % 42 to 62 %: Throttle fully closed 92 to 100 %: Throttle fully open Calculated value based on VTA2 Read value with ignition switch ON (Do not start engine) ST1 Brake pedal signal: ON or OFF ON: Brake pedal depressed - System Guard System guard: ON or OFF - ETCS service data Open Side Malfunction Open side malfunction: ON or OFF - ETCS service data Throttle Idle Position Whether or not throttle position sensor detecting idle: ON or OFF ON: Idling - Throttle Require Position Throttle requirement position: Min.: 0 V, Max.: 4.98 V 0.5 to 1.1 V: Idling - Throttle Sensor Position Throttle position: Min.: 0 %, Max.: 100 % 0 %: Throttle fully closed 50 to 80 %: Throttle fully open Recognition value for throttle opening angle on ECM Read value with ignition switch ON (Do not start engine) Throttle Position No. 1 Throttle position sensor No. 1 output voltage: Min.: 0 V, Max.: 4.98 V - ETCS freeze data Throttle Position No. 2 Throttle position sensor No. 2 output voltage: Min.: 0 V, Max.: 4.98 V - ETCS freeze data Throttle Position No. 1 Throttle position sensor No. 1 output voltage: Min.: 0 V, Max.: 4.98 V 0.5 to 1.1 V: Throttle fully closed 3.2 to 4.8 V: Throttle fully open 0.6 to 1.4 V: Fail-safe operating Read value with ignition switch ON (Do not start engine) Throttle Position No. 2 Throttle position sensor No. 2 output voltage: Min.: 0 V, Max.: 4.98 V 2.1 to 3.1 V: Throttle fully closed 4.6 to 5.0 V: Throttle fully open 2.1 to 3.1 V: Fail-safe operating Read value with ignition switch ON (Do not start engine) Throttle Position Command Throttle position command value: Min.: 0 V, Max.: 4.9804 V 0.5 to 4.8 V Read value with ignition switch ON (Do not start engine) Throttle Sens Open Pos #1 Throttle sensor opener position No. 1: Min.: 0 V, Max.: 4.9804 V 0.6 to 1.4 V ETCS service data Throttle Sens Open Pos #2 Throttle sensor opener position No. 2: Min.: 0 V, Max.: 4.9804 V 1.7 to 2.5 V ETCS service data Throttle Sens Open #1(AD) Throttle position sensor No. 1 output voltage (AD): Min.: 0 V, Max.: 4.9804 V 0.5 to 4.9 V Read value with ignition switch ON (Do not start engine) Throttle Motor Whether or not throttle actuator control permitted: ON or OFF ON: Idling Read value with ignition switch ON (Do not start engine) Throttle Motor Current Throttle actuator current: Min.: 0 A, Max.: 19.9 A 0 to 3.0 A: Idling - Throttle Motor DUTY Throttle actuator: Min.: 0 %, Max.: 100 % 0.5 to 40 %: Idling - Throttle Motor Current Throttle actuator current: Min.: 0 A, Max.: 19.92 A 0 to 3.0 A: Idling - Throttle Motor Open Duty Throttle actuator opening duty ratio: Min.: 0 %, Max.: 100 % 0 to 40 %: During idling When accelerator pedal depressed, duty ratio increased Read value with ignition switch ON (Do not start engine) Throttle Motor Close Duty Throttle actuator closed duty ratio: Min.: 0 %, Max.: 100 % 0 to 40 %: During idling When accelerator pedal released quickly, duty ratio increased Read value with ignition switch ON (Do not start engine) Throttle Motor Duty (Open) Throttle actuator duty ratio (open): Min.: 0 %, Max.: 100 % 0 to 40 %: During idling ETCS service data Throttle Motor Duty (Close) Throttle actuator duty ratio (closed): Min.: 0 %, Max.: 100 % 0 to 40 %: During idling ETCS service data Throttle Fully Close Learn Throttle valve fully closed (learned value): Min.: 0 V, Max.: 4.98 V 0.4 to 1.0 V: Accelerator pedal released - ETCS Actuator Power Whether or not electric throttle control system power inputted: ON or OFF ON: Ignition switch ON and system normal - +BM Voltage +BM voltage: Min.: 0, Max.: 19.9 11 to 14 (V): Ignition switch ON and system normal ETCS service data Actuator Power Supply Actuator power supply: ON or OFF ON: Idling ETCS service data Clutch Current Clutch current: Min.: 0 A, Max.: 2.49 A - - Fail Safe Drive Whether or not fail-safe function executed: ON or OFF ON: ETCS has failed - Fail Safe Drive (Main CPU) Whether or not fail-safe function executed: ON or OFF ON: ETCS has failed - Injector (Port) Injection period of No. 1 cylinder: Min.: 0 ms, Max.: 32.64 ms 1.0 to 3.0 ms: Idling - Injection Volum (Cylinder1) Injection volume (Cylinder 1): Min.: 0 ml, Max.: 2.047 ml 0 to 0.15 ml: Idling Quantity of fuel injection volume for 10 times Fuel Pump/Speed Status Fuel pump status: ON or OFF ON: Engine running Active Test support data Vacuum Pump Key-off EVAP system leak detection pump status: ON or OFF - Active Test support data EVAP (Purge) VSV EVAP (PURGE) VSV control duty: Min.: 0 %, Max.: 100 % 10 to 50 %: Idling Order signal from ECM Evap Purge Flow Ratio of evaporative purge flow to intake air volume: Min.: 0 %, Max.: 102.3 % 0 to 10 %: Idling - Purge Density Learn Value Learning value of purge density: Min.: -50, Max.: 349.99 -40 to 10: Idling - Vapor Pressure Pump Vapor pressure: Min.: 33.853 kPa (253.91 mmHg), Max.: 125.596 kPa (942.04 mmHg) Nearly atmospheric pressure: Fuel tank cap removed EVAP system pressure monitored by canister pressure sensor Vapor pressure (calculated) Vapor pressure (calculated): Min.: -5.632 kPa (-42.24 mmHg), Max.: 7153.264 kPa (53653.89 mmHg) Nearly atmospheric pressure: Fuel tank cap removed EVAP system pressure monitored by canister pressure sensor EVAP System Vent Valve Key-off EVAP system vent valve status: ON or OFF - Active Test support data EVAP Purge VSV Purge VSV status: ON or OFF - - Target Air-Fuel Ratio Ratio compared to stoichiometric level: Min.: 0, Max.: 1.998 0.8 to 1.2: Idling - AF Lambda B1S1 Short-term fuel trim associated with sensor 1: Min.: 0, Max.: 1.999 Value less than 1 (0.000 to 0.999) = Rich Stoichiometric air-fuel ratio=1 Value greater than 1 (1.001 to 1.999) = Lean - AFS Voltage B1S1 A/F sensor output voltage for sensor 1: Min.: 0 V Max.: 7.999 V 2.8 to 3.8 V: Idling Performing the Control the Injection Volume or Control the Injection Volume for A/F Sensor function of the Active Test enables the technician to check voltage output of the sensor. AFS Current B1S1 A/F sensor output current for sensor 1: Min.: -128 mA, Max.: 127.99 mA - Performing the Control the Injection Volume or Control the Injection Volume for A/F Sensor function of the Active Test enables the technician to check voltage output of the sensor. O2S B1S2 Heated oxygen sensor output voltage for sensor 2: Min.: 0 V Max.: 1.275 V 0.1 to 0.9 V: Driving at 44 mph (70 km/h) Performing the Control the Injection Volume or Control the Injection Volume for A/F Sensor function of the Active Test enables the technician to check voltage output of the sensor. O2S Impedance B1S2 Sub oxygen sensor impedance (sensor 2): Min.: 0 ohm, Max.: 21247.68 ohm 5 to 15,000 ohm: While vehicle is driving and engine is warmed up - Short FT #1 Short-term fuel trim: Min.: -100 %, Max.: 99.2 % -20 to 20 % Short-term fuel compensation used to maintain air-fuel ratio at stoichiometric air-fuel ratio Long FT #1 Long-term fuel trim: Min.: -100 %, Max.: 99.2 % -20 to 20 % Overall fuel compensation carried out in long-term to compensate continual deviation of short-term fuel trim from central value Total FT #1 Total fuel trim value for fuel system: Min.: -0.5, Max.: 0.496 -0.2 to 0.2 - Fuel System Status #1 Fuel system status (bank 1): OL or CL or OLDrive or OLFault or CLFault CL: Idling after warming up OL (Open Loop): Has not yet satisfied conditions to go closed loop CL (Closed Loop): Using A/F sensor as feedback for fuel control OLDrive: Open loop due to driving conditions (fuel enrichment) OLFault: Open loop due to detected system fault CLFault: Closed loop but A/F sensor, which used for fuel control malfunctioning Fuel System Status #2 Fuel system status (bank 2) Unused IGN Advance Ignition timing advance for No. 1 cylinder: Min.: -64 deg, Max.: 63.5 deg BTDC 0 to 14 deg: Idling - Knock Feedback Value Knock feedback value: Min: -64 °CA, Max.: 1983.9 °CA -20 to 0°CA: Driving at 44 mph (70 km/h) Service data Knock Correct Learn Value Knock correction learning value: Min: -64 °CA, Max.: 1983.9 °CA 0 to 20°CA: Driving at 44 mph (70 km/h) Service data VVT Control Status #1 VVT control #1 status: ON or OFF - - VVT Aim Angle #1*2 VVT aim angle (bank 1): Min.: 0 %, Max.: 100 % 0 to 80 % VVT duty signal value during intrusive operation VVT Change Angle #1*2 VVT change angle (bank 1): Min.: 0°FR, Max.: 60°FR 0 to 56° FR Displacement angle during intrusive operation VVT OCV Duty #1*2 VVT OCV operation duty: Min.: 0 %, Max.: 100 % 0 to 100 % Requested duty value for intrusive operation Catalyst Temp B1S1 Estimated catalyst temperature (sensor 1): Min.: -40°C, Max.: 6513.5°C - - Catalyst Temp B1S2 Estimated catalyst temperature (sensor 2): Min.: -40°C, Max.: 6513.5°C - - Starter Signal Starter relay (STA) signal: ON or OFF ON: Cranking - Starter Control Starter switch (STSW) signal: ON or OFF ON: Cranking - Power Steering Signal Power steering signal: ON or OFF ON: Power steering operation - Starter Relay Starter control (STAR) signal: ON or OFF ON: Cranking - Power Steer. Sig. Record Power steering signal (history): ON or OFF ON: When steering wheel first turned after battery terminals connected Signal status usually ON until battery terminals disconnected ACC Relay ACC CUT relay: ON or OFF ON: Cranking - Neutral Position SW Signal PNP switch status: ON or OFF ON: P or N position - Stop Light Switch Stop light switch: ON or OFF ON: Brake pedal depressed - A/C Signal A/C signal: ON or OFF ON: A/C ON - Closed Throttle Position SW Closed throttle position switch: ON or OFF ON: Throttle fully closed OFF: Throttle open - Fuel Cut Condition Fuel cut condition: ON or OFF ON: Any fuel cut operation executed - Immobiliser Communication Immobiliser communication: ON or OFF - OFF: Communication malfunctioning, or engine immobiliser system set ON: Communication normal Electrical Load Signal Electrical load signal: ON or OFF ON: Headlights or defogger turned ON - Check Mode Check mode: ON or OFF ON: Check mode ON Refer to «CHECK MODE PROCEDURE»(ref-394513-S19948725612011040800000) SPD Test Result Check mode result for vehicle speed sensor: Compl or Incmpl - - Misfire Test Result Check mode result for misfire monitor: Compl or Incmpl - - OXS1 Test Result Check mode result for HO2 sensor: Compl or Incmpl - - A/F Test Results #1 Check mode result for air-fuel ratio sensor: Compl or Incmpl - - Complete Parts Monitor Comprehensive component monitor: Not Avl or Avail - - Fuel System Monitor Fuel system monitor: Not Avl or Avail - - Misfire Monitor Misfire monitor: Not Avl or Avail - - O2S(A/FS) Heater Monitor O2S (A/FS) heater monitor: Not Avl or Avail - - O2S(A/FS) Heater Monitor O2S (A/FS) heater monitor: Compl or Incmpl - - O2S(A/FS) Monitor O2S (A/FS) monitor: Not Avl or Avail - - O2S(A/FS) Monitor O2S (A/FS) monitor: Compl or Incmpl - - EVAP Monitor EVAP monitor: Not Avl or Avail - - EVAP Monitor EVAP monitor: Compl or Incmpl - - Catalyst Monitor Catalyst monitor: Not Avl or Avail - - Catalyst Monitor Catalyst monitor: Compl or Incmpl - - Component Monitor ENA Comprehensive component monitor: Unable or Enable - - Component Monitor CMPL Comprehensive component monitor: Compl or Incmpl - - Fuel System Monitor ENA Fuel system monitor: Unable or Enable - - Fuel System Monitor CMPL Fuel system monitor: Compl or Incmpl - - Misfire Monitor ENA Misfire monitor: Unable or Enable - - Misfire Monitor CMPL Misfire monitor: Compl or Incmpl - - EGR/VVT Monitor ENA EGR monitor: Unable or Enable - - EGR/VVT Monitor CMPL EGR monitor: Compl or Incmpl - - Heater Monitor ENA O2S (A/FS) heater monitor: Unable or Enable - - Heater Monitor CMPL O2S (A/FS) heater monitor: Compl or Incmpl - - O2S(A/FS) Monitor ENA O2S (A/FS) monitor: Unable or Enable - - O2S(A/FS) Monitor CMPL O2S (A/FS) monitor: Compl or Incmpl - - A/C Monitor ENA A/C monitor: Unable or Enable - - A/C Monitor CMPL A/C monitor: Compl or Incmpl - - 2nd Air Monitor ENA 2nd air monitor: Unable or Enable - - 2nd Air Monitor CMPL 2nd air monitor: Compl or Incmpl - - EVAP Monitor ENA EVAP monitor: Unable or Enable - - EVAP Monitor CMPL EVAP monitor: Compl or Incmpl - - Heated Cat Monitor ENA Heated catalyst monitor: Unable or Enable - - Heated Cat Monitor CMPL Heated catalyst monitor: Compl or Incmpl - - Catalyst Monitor ENA Catalyst monitor: Unable or Enable - - Catalyst Monitor CMPL Catalyst monitor: Compl or Incmpl - - # Codes (Include History) Number of detected DTCs: Min.: 0, Max.: 255 - - MIL MIL status: ON or OFF ON: MIL ON - MIL ON Run Distance MIL ON Run Distance: Min.: 0 km, Max.: 65535 km Distance after DTC detected - Running Time from MIL ON Running time from MIL ON: Min.: 0 minute, Max.: 65535 minutes Equivalent to running time after MIL ON - Time after DTC Cleared Time after DTC cleared: Min.: 0 minute, Max.: 65535 minutes Equivalent to time after DTCs erased - Distance from DTC Cleared Distance traveled since DTCs cleared: Min.: 0 km, Max.: 65535 km Equivalent to drive distance after DTCs erased - Warm up Cycle Cleared DTC Warm-up cycle after DTC cleared: Min.: 0, Max.: 255 - - OBD Requirements OBD requirement OBD2 - Number of Emission DTC Number of emission-related DTCs Min.: 0, Max.: 127 - - TC and TE1 TC and CG (TE1) terminal of DLC3: ON or OFF - Active Test support data Ignition Trig. Count Ignition counter: Min.: 0, Max.: 800 0 to 400 - Cylinder #1 Misfire Count Misfire count of cylinder 1: Min.: 0, Max.: 255 0 - Cylinder #2 Misfire Count Misfire count of cylinder 2: Min.: 0, Max.: 255 0 - Cylinder #3 Misfire Count Misfire count of cylinder 3: Min.: 0, Max.: 255 0 - Cylinder #4 Misfire Count Misfire count of cylinder 4: Min.: 0, Max.: 255 0 - All Cylinders Misfire Count All cylinders misfire count: Min.: 0, Max.: 255 0 - Misfire RPM Engine speed when misfire occur: Min.: 0 rpm, Max.: 6375 rpm - - Misfire Load Engine load when misfire occur: Min.: 0 g/rev, Max.: 3.98 g/rev - - Misfire Margin Margin to detect engine misfire: Min.: -100 %, Max.: 99.22 % -100 to 99.22 % Misfire detecting margin Catalyst OT MF F/C Catalyst over temperature misfire prevention F/C: Not Avl or Avail Avail: Cat OT MF F/C available Not Avl: Cat OT MF F/C not available - Cat OT MF F/C History Catalyst over temperature misfire prevention F/C history: ON or OFF ON: Fuel cut operation history exists - Cat OT MF F/C Cylinder #1 Display of fuel cut operation in No. 1 cylinder (if certain level of misfire malfunction is detected): ON or OFF ON: Fuel cut is operating - Cat OT MF F/C Cylinder #2 Display of fuel cut operation in No. 2 cylinder (if certain level of misfire malfunction is detected): ON or OFF ON: Fuel cut is operating - Cat OT MF F/C Cylinder #3 Display of fuel cut operation in No. 3 cylinder (if certain level of misfire malfunction is detected): ON or OFF ON: Fuel cut is operating - Cat OT MF F/C Cylinder #4 Display of fuel cut operation in No. 4 cylinder (if certain level of misfire malfunction is detected): ON or OFF ON: Fuel cut is operating - Electric Fan Motor Electric fan motor: ON or OFF ON: Electric fan motor operating - Idle Fuel Cut Fuel cut idle: ON or OFF ON: Fuel cut operation Idle Fuel Cut = "ON" when throttle valve fully closed and engine speed over 3,500 rpm FC TAU Fuel cut TAU (Fuel cut during very light load): ON or OFF ON: Fuel cut operating Fuel cut being performed under very light load to prevent engine combustion from becoming incomplete Model Code Identifying model code NCP9# - Engine Type Identifying engine type 1NZFE - Cylinder Number Identifying cylinder number: Min.: 0, Max.: 255 4 - Transmission Type Identifying transmission type MT or ECT 4th - Destination Identifying destination A (America) - Model Year Identifying model year: Min.: 1900, Max.: 2155 20## - System Identification System identification Gasoline - Engine Speed of Cyl #1 Engine RPM for cylinder 1: Min.: 0 rpm, Max.: 25600 rpm - Output only when Check the Cylinder Compression performed using Active Test 51199 rpm: Not performed Active Test Engine Speed of Cyl #2 Engine RPM for cylinder 2: Min.: 0 rpm, Max.: 25600 rpm - Output only when Check the Cylinder Compression performed using Active Test 51199 rpm: Not performed Active Test Engine Speed of Cyl #3 3 Engine RPM for cylinder 3: Min.: 0 rpm, Max.: 25600 rpm - Output only when Check the Cylinder Compression performed using Active Test 51199 rpm: Not performed Active Test Engine Speed of Cyl #4 Engine RPM for cylinder 4: Min.: 0 rpm, Max.: 25600 rpm - Output only when Check the Cylinder Compression performed using Active Test 51199 rpm: Not performed Active Test Av Engine Speed of All Cyl Engine RPM for all cylinders: Min.: 0 rpm, Max.: 25600 rpm - Output only when Check the Cylinder Compression performed using Active Test 51199 rpm: Not performed Active Test HINT: *1: If no idling conditions are specified, the transmission gear selector lever should be in the N or P position (neutral), and the A/C switch and all accessory switches should be OFF. *2: Data List values are only displayed when performing the following Active Tests: Control the VVT Linear (Bank1), and Control the VVT System (Bank1). For other Active Tests, the Data List value will be 0.
2. ACTIVE TEST HINT: Performing an Active Test enables components including the relays, VSV (Vacuum Switching Valve) and actuators, to be operated without removing any parts. The Active Test can be performed with a Techstream. Performing an Active Test as the first step of troubleshooting is one method of shortening diagnostic time. Data List can be displayed during Active Test. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test. Perform the Active Test by referring to the table below. Tester Display Test Part Control Range Diagnostic Note Control the Injection Volume Change injection volume Between -12.5 and 24.8 % All injectors tested at same time Perform test at less than 3,000 rpm Injection volume can be changed in 0.1or 0.2 % graduations within control range Control the Injection Volume for A/F Sensor Change injection volume Decrease by 12.5 % or increase by 25 % Perform test at less than 3,000 rpm Control the Injection Volume for A/F Sensor enables checking and graphing of A/F (Air-Fuel Ratio) sensor and HO2 (Heated Oxygen) sensor voltage outputs To conduct test, enter the following menus: Active Test / Control the Injection Volume for A/F Sensor / Data List / A/ F Control System / AFS Voltage B1S1 / O2S B1S2 Activate the VSV for Evap Control Activate purge VSV control ON/OFF - Control the Fuel Pump / Speed Activate fuel pump (C/OPN Relay) ON/OFF Test possible when engine stopped Connect the TC and TE1 Turn on and off TC and CG (TE1) connection ON/OFF ON: TC and CG (TE1) connected OFF: TC and CG (TE1) disconnected Control the Idle Fuel Cut Prohibit Prohibit idling fuel cut control ON/OFF Idling fuel cut turned ON when throttle valve fully closed and engine speed over 2800 rpm Prohibit the Catalyst OT Misfire Prevent F/C Prohibit catalyst overheat malfunction prevention fuel cut operation during misfire ON/OFF Confirm that the vehicle is stopped and engine speed is 3000 rpm or less Control the Electric Cooling Fan Control Electric Cooling Fan ON/OFF - Activate the Starter Relay Starter ON/OFF Test possible when engine stopped Activate the ACC Cut Relay Active ACC (Accessory) relay ON/OFF Test possible when engine stopped Control the ETCS Open/Close Slow Speed Throttle actuator Close/Open Test possible when following conditions met: Engine stopped Shift position in P Fully depressing accelerator pedal (APP: 59 degrees or more) Control the ETCS Open/Close Fast Speed Throttle actuator Close/Open Open: Throttle valve opens quickly Same as above. Control the VVT Linear (Bank1) Control VVT (bank 1) -128 to 127 % This value added to present OCV control duty 100 %: Maximum advance -100 %: Maximum retard Engine stall or rough idle when VVT actuator operated by 100 %. Test possible while vehicle stopped and engine idling Control the VVT System (Bank1) Turn on and off OCV (Oil Control Valve) ON/OFF Engine stalls or idles roughly when OCV turned ON Normal engine running or idling when OCV OFF Test possible while vehicle stopped and engine idling Activate the Vacuum Pump Leak detection pump (built into canister assembly) ON/OFF - Activate the VSV for Vent Valve Vent valve (built into canister assembly) ON/OFF - Control the Cylinder #1 Fuel Cut Cylinder #1 injector fuel cut ON/OFF Test possible during vehicle stopping and engine idling*1 Control the Cylinder #2 Fuel Cut Cylinder #2 injector fuel cut ON/OFF Control the Cylinder #3 Fuel Cut Cylinder #3 injector fuel cut ON/OFF Control the Cylinder #4 Fuel Cut Cylinder #4 injector fuel cut ON/OFF Control the All Cylinders Fuel Cut All cylinder fuel cut ON/OFF Check the Cylinder Compression*2 Check the cylinder compression pressure (measuring engine speed for each cylinder) ON/OFF Both fuel injection and ignition stopped in all cylinders NOTE: *1: If the display of the Data List's Catalyst OT MF F/C item is Not Avl, perform this Active Test with the vehicle stopped and the engine idling. If the display of the Data List's Catalyst OT MF F/C item is Avail, perform this Active Test as described below. Stop the engine, turn the ignition switch to ON and turn Control the Cylinder #1 Fuel Cut (to Control the Cylinder #4 Fuel Cut) ON. Start the engine. HINT: *2: When performing the Active Test item Check the Cylinder Compression and then cranking the engine, the ECM stops the fuel injection and ignition, and measures the engine speed for each cylinder. If one cylinder's speed is higher than the others, that cylinder's compression pressure can be concluded to be lower than the others. Warm up the engine. Turn the ignition switch off. Connect a Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Check the Cylinder Compression. Select the following monitor items: Compression / Engine Speed of Cyl #1 to #4, Av Engine Speed of All Cyl Press the RIGHT or LEFT button to change the Check the Cylinder Compression to ON. HINT: Fuel injection and ignition for all cylinders are prohibited at this time, and each cylinder's engine speed measurement will enter standby mode. Crank the engine until the monitor item values Engine speed of Cyl #1 to #4 and Av Engine Speed of All Cyl change. Monitor the engine speed (Engine Speed of Cyl #1 to #4, Av Engine Speed of All Cyl) displayed on the Techstream. HINT: The Techstream displays extremely high values before cranking the engine. Each cylinder's engine speed is measured while cranking the engine and then the Techstream displays the actual engine speed values. NOTE: The Active Test item Check the Cylinder Compression will automatically turn off 255 seconds after the Active Test is turned on. When the Check the Cylinder Compression is OFF and the engine is cranked, the engine will start. If the Check the Cylinder Compression test needs to be performed again after each cylinder's engine speed measurement has been performed once, press EXIT to return to the Active Test menu screen. Then perform the Check the Cylinder Compression test again. Use a fully-charged battery.
3. SYSTEM CHECK HINT: Performing a System Check in the Utility menu enables the system, which consists of multiple actuators, to be operated without removing any parts. In addition, it can show whether or not any DTCs are set, and can detect potential malfunctions in the system. Connect the Techstream to the DLC3. Turn the ignition switch to ON Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility. Perform the System Check by referring to the table below. Tester Display Test Part Control Range Diagnostic Note Evaporative System Check (Automatic Mode) EVAP key-off monitor Perform 5 steps in order to operate EVAP key-off monitor automatically Recommended Fuel Temperature: 35°C (95°F) or less If no DTCs in PENDING CODE after performing this test, system functioning normally Refer to EVAP system. Refer to «EVAP System»(ref-394517-S14308387642011040800000) Evaporative System Check (Manual Mode) EVAP key-off monitor Perform 5 steps in order to operate EVAP key-off monitor manually Recommended Fuel Temperature: 35°C (95°F) or less Used to detect malfunctioning parts Refer to EVAP system. Refer to «EVAP System»(ref-394517-S14308387642011040800000)

DIAGNOSTIC TROUBLE CODE CHART

HINT

1. *1: MIL flashes when a catalyst damaging misfire is detected.
2. *2: A/T denotes Automatic Transaxle models and M/T denotes Manual Transaxle models.
3. *3: Only for Mexico models
