Engine Control (2GR-FE) (Diagnostic Codes (P0010-P0230): Other Toyota Venza I

MONITOR STRATEGY

TYPICAL ENABLING CONDITIONS

TYPICAL MALFUNCTION THRESHOLDS

COMPONENT OPERATING RANGE

Scheme 452

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Wait 5 seconds [A].
7. Enter the following menus: Powertrain / Engine / Trouble Codes.
8. Read the DTCs [B].
9. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P0010 or P0020.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
13. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
14. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
15. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 453

ADVANCES CAMSHAFT TIMING

RETARD CAMSHAFT TIMING

Scheme 454

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more [B].
7. Drive the vehicle for 5 minutes or more [C].
8. Idle the engine for 30 seconds or more [D].
9. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
10. Read the pending DTCs [E].
11. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
12. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
13. Input the DTC: P0011, P0012, P0021 or P0022.
14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [F] through [H].
15. Drive the vehicle for 5 minutes or more [F].
16. Idle the engine for 30 seconds or more [G].
17. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
18. Input the DTC: P0011, P0012, P0021 or P0022.
19. Check the DTC judgment result again [H]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
20. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. If the difference between the target and actual camshaft timings is greater than the specified value, the ECM operates the VVT actuator.
2. Then, the ECM monitors the camshaft timing change for 5 seconds.

CONFIRMATION DRIVING PATTERN

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Wait 5 seconds [A].
7. Enter the following menus: Powertrain / Engine / Trouble Codes.
8. Read the DTC [B].
9. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P0013 or P0023.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
13. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
14. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
15. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 455

ADVANCED CAMSHAFT TIMING

RETARDED CAMSHAFT TIMING

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more [B].
7. Drive the vehicle for 5 minutes or more [C].
8. Idle the engine for 30 seconds or more [D].
9. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
10. Read the pending DTC [E].
11. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
12. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
13. Input the DTC: P0014, P0015, P0024 or P0025.
14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [F] through [H].
15. Drive the vehicle for 5 minutes or more [F].
16. Idle the engine for 30 seconds or more [G].
17. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
18. Input the DTC: P0014, P0015, P0024 or P0025.
19. Check the DTC judgment result again [H]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
20. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

ALL

Scheme 456

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more [B].
7. Idle the engine for 5 minutes or more [C].
8. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
9. Read the pending DTC [D].
10. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0016 or P0018.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] through [G].
14. Drive the vehicle for 2 to 3 minutes [E].
15. Idle the engine for 5 minutes or more [F].
16. Check the DTC judgment result [G]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
17. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more [B].
7. Idle the engine for 5 minutes or more [C].
8. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
9. Read the pending DTCs [D].
10. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0017 or P0019.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] through [G].
14. Drive the vehicle for 2 to 3 minutes [E].
15. Idle the engine for 5 minutes or more [F].
16. Check the DTC judgment result [G]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
17. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

ALL

P0031 AND P0051

P0032 AND P0052

P0031 AND P0051

P0032 AND P0052

P0031 AND P0051

Scheme 457

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and idle it for 5 minutes or more [B].
7. With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 rpm for 1 minute [C].
8. Idle the engine for 5 minutes or more [D].
9. Enter the following menus: Powertrain / Engine / Trouble Codes.
10. Read the DTC [E].
11. If a DTC is output, the system is malfunctioning. HINT: If a DTC is output, perform the following procedure.
12. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
13. Input the DTC: P0031, P0032, P0051 or P0052.
14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [D] again.
15. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
16. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
17. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

ALL

P0037 AND P0057 (CASE 1)

P0037 AND P0057 (CASE 2)

P0038 AND P0058 (CASE 1)

P0038 AND P0058 (CASE 2)

P0141 AND P0161

P0037 AND P0057 (CASE 1)

P0037 AND P0038 (CASE 2)

P0038 AND P0058

P0141 AND P0161

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and idle it for 5 minutes or more [B].
7. With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 rpm for 1 minute [C].
8. Idle the engine for 5 minutes or more [D].
9. Enter the following menus: Powertrain / Engine / Trouble Codes.
10. Read the DTC [E].
11. If a DTC is output, the system is malfunctioning. HINT: If a DTC is output, perform the following procedure.
12. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
13. Input the DTC: P0037, P0038, P0057, P0058, P0141, or P0161.
14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [D] again.
15. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
16. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
17. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 458

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) .
5. Turn the ignition switch off and wait for at least 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on.
7. Start the engine and warm it up until the engine coolant temperature reaches 70°C (158°F) or more [A].
8. Drive the vehicle at approximately 50 mph (80 km/h) to 70 mph (112 km/h) for 5 minutes or more [B]. HINT: Drive while keeping the engine load as stable as possible.
9. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
10. Read the pending DTC [C].
11. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
12. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
13. Input the DTC: P0101.
14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [C] again.
15. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
16. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
17. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

PROCEDURE

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0101) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0101 is output A DTC P0101 and other DTCs are output B HINT: If any DTCs other than P0101 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
2. CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-394802-S30272393672011040800000) . OK No leaks from intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
3. CHECK PCV HOSE (HOSE CONNECTIONS) Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-394803-S02526785672011040800000) . OK PCV hose is connected correctly and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK --> See step 5
4. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-394619-S37978292982011040800000)
5. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL»(ref-394792-S26454467962011040800000)

P0102

P0103

Scheme 459

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine.
7. Idle the engine for 5 seconds [B].
8. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending [C].
9. Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
10. Run the engine at an engine speed of 4000 rpm or more for 5 seconds [D].
11. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending [E].
12. Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
13. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
14. Input the DTC: P0102 or P0103.
15. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [D] again.
16. If the no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 460

ALL

AFTER ENGINE STOP

AFTER COLD ENGINE START

AFTER ENGINE STOP

AFTER COLD ENGINE START

Scheme 461

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. Idle the engine for 5 minutes or more [C]. HINT: During steps [A] through [C], if the change in the intake air temperature is less than 1°C (1.8°F), the intake air temperature sensor (mass air flow meter sub-assembly) is malfunctioning. It is not necessary to continue this procedure.
8. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
9. Read the pending DTC [D].
10. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0111.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] and [F].
14. Drive the vehicle at 25 mph (40 km/h) or more for a total of 5 minutes or more [E].
15. Check the DTC judgment result again [F].
16. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
17. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
18. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0111) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0111 and other DTCs are output A DTC P0111 is output B HINT: If any DTCs other than P0111 are output, troubleshoot those DTCs first. B --> See step 3 A --> See step 2
2. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-394619-S37978292982011040800000)
3. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL»(ref-394792-S26454467962011040800000)

P0112

P0113

Scheme 462

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Wait 0.5 seconds or more [A].
7. Enter the following menus: Powertrain / Engine / Trouble Codes.
8. Read the DTC [B].
9. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P0112 or P0113.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
13. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
14. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
15. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 463

P0115

P0117

P0118

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Wait 0.5 seconds or more [A].
7. Enter the following menus: Powertrain / Engine / Trouble Codes.
8. Read the DTC [B].
9. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P0115, P0117 or P0118.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
13. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
14. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
15. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 464

ENGINE COOLANT TEMPERATURE SENSOR COLD START MONITOR

ENGINE COOLANT TEMPERATURE SENSOR SOAK MONITOR

ENGINE COOLANT TEMPERATURE SENSOR COLD START MONITOR

ENGINE COOLANT TEMPERATURE SENSOR SOAK MONITOR

Scheme 465

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp.
4. Check that the coolant temperature is 60°C (140°F) or less.
5. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) .
6. Turn the ignition switch off and wait for at least 30 seconds.
7. Turn the ignition switch to ON and turn the Techstream on [A].
8. Start the engine and idle it for 5 minutes or more [B]. HINT: If the engine coolant temperature does not change by 5°C (9°F) or more, the engine coolant temperature sensor is malfunctioning. It is not necessary to continue this procedure.
9. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
10. Read the pending DTC [C].
11. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
12. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
13. Input the DTC: P0116.
14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [D] and [E].
15. Drive the vehicle at 25 mph (40 km/h) or more for a total of 5 minutes or more [D]. HINT: In the event of the drive pattern being interrupted (possibly due to factors such as traffic conditions), the drive pattern can be resumed.
16. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
17. Check the DTC judgment result again [E]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
18. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTC OUTPUT (IN ADDITION TO DTC P0116) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0116 is output A DTC P0116 and other DTCs are output B HINT: If any DTCs other than P0116 are output, troubleshoot those DTCs first. B --> See step 3 A: Go to next step
2. INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-394766-S23121296872011040800000) . Check the valve opening temperature of the thermostat. Standard 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-394766-S17947583672011040800000) . NG --> See step 4 OK --> See step 5
3. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-394619-S37978292982011040800000)
4. REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-394766-S23121296872011040800000)
5. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-394792-S01476926432011040800000)

Scheme 466

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) [A].
4. Turn the ignition switch off and wait for 30 seconds.
5. With the engine stopped, leave the vehicle as is for 7.5 hours or more [B].
6. Start the engine and wait 60 seconds or more [C].
7. Turn the ignition switch off and wait for at least 30 seconds.
8. Turn the ignition switch to ON and turn the Techstream on.
9. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
10. Read the pending DTC [D].
11. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
12. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
13. Input the DTC: P011B.
14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] through [C] again.
15. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
16. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
17. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO P011B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P011B is output A DTC P011B and other DTCs are output B HINT: If any DTCs other than P011B are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
2. READ VALUE USING TECHSTREAM (INTAKE AIR) Leave the vehicle for 7 hours or more. HINT: It is necessary to leave the vehicle for 7 hours or more to allow conditions similar to the DTC detection conditions. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Intake Air. Read the value displayed on the Techstream. OK Difference between the intake air temperature and the actual outside air temperature is within 10°C (18°F). HINT: Intake air temperature readings on the vehicle outside temperature gauge (if equipped) are not suitable for comparing to the intake air temperature reading. The outside temperature gauge has a significant delay built in to prevent temperature swings from being displayed on its display. Use an accurate thermometer to determine the outside air temperature. NG --> See step 5 OK: Go to next step
3. READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp. Read the value displayed on the Techstream. OK Difference between the coolant temperature and the actual outside air temperature is within 10°C (18°F). HINT: If the result is not as specified, check if there are heat sources such as a block heater in the engine compartment. NG --> See step 7 OK --> See step 6
4. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-394619-S37978292982011040800000)
5. REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL»(ref-394792-S26454467962011040800000)
6. REPLACE ECM. Refer to «REMOVAL»(ref-394792-S25581811582011040800000)
7. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-394792-S01476926432011040800000)

P0120, P0122, P0123, P0220, P0222, P0223, P2135

P0121

P0120

P0121

P0122

P0123

P0220

P0222

P0223

P2135 CASE 1

P2135 CASE 2

Scheme 467

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine.
7. With the vehicle stationary, fully depress and release the accelerator pedal [B].
8. Idle the engine for 2 seconds or more [C].
9. Enter the following menus: Powertrain / Engine / Trouble Codes.
10. Read the DTC [D].
11. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
12. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
13. Input the DTC: P0120, P0121, P0122, P0123, P0220, P0222, P0223 or P2135.
14. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [C] again.
15. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
16. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
17. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

FAIL-SAFE

When any of these DTCs, as well as other DTCs relating to electronic throttle control system malfunctions are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.

Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.

Scheme 468

Scheme 469

1. Leave the vehicle outside overnight.
2. Connect the Techstream to the DLC3.
3. Turn the ignition switch to ON and turn the Techstream on.
4. Enter the following menus: Powertrain / Engine / Data List / Coolant Temp.
5. Check that the engine coolant temperature is 5°C (41°F) or less.
6. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) .
7. Turn the ignition switch off and wait for at least 30 seconds.
8. Turn the ignition switch to ON and turn the Techstream on [A].
9. Start the engine.
10. After starting the engine, wait 21 minutes or more [B].
11. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
12. Read the pending DTC [C].
13. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Input the DTC: P0125.
16. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] again.
17. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
18. Check the judgment result [C]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
19. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0125) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0125 is output A DTC P0125 and other DTCs are output B HINT: If any DTCs other than P0125 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
2. INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-394766-S23121296872011040800000) . Check the valve opening temperature of the thermostat. Standard 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-394766-S17947583672011040800000) . NG --> See step 5 OK: Go to next step
3. CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK --> See step 6
4. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-394619-S37978292982011040800000)
5. REPLACE THERMOSTAT. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-394794-S33899863722011040800000)
6. REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-394792-S01476926432011040800000)

Scheme 470

1. Stop the engine and allow it to cool down.
2. Connect the Techstream to the DLC3.
3. Turn the ignition switch to ON and turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) [A].
5. Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp and Intake Air.
6. Check if "Coolant Temp" is 56°C (133°F) or less and "Intake Air" is between 0 and 35°C (32 and 95°F).
7. Set the heater to MAX HOT with fresh air mode selected and turn the A/C off.
8. Start the engine and drive the vehicle at 50 mph (80 km/h) for 15 minutes [B]. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Enter the following menus: Data List / Function / Snap-shot configuration / Record time / 5 min. Data capture can be started by using the target point. For example, setting the target point to an engine speed of 4000 rpm and then racing the engine, etc. to raise the engine speed to a speed of 4000 rpm or more will cause data capture to start.
9. After driving the vehicle at 50 mph (80 km/h) and "Coolant Temp" stabilizes, check that "Coolant Temp" is 75°C (167°F) or higher [C]. HINT: If "Coolant Temp" is below 75°C (167°F) while driving the vehicle at 50 mph (80 km/h), inspect the cooling system and thermostat.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0128) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0128 is output A DTC P0128 and other DTCs are output B HINT: If any DTCs other than P0128 are output, troubleshoot those DTCs first. B --> See step 5 A: Go to next step
2. CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK: Go to next step
3. INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-394766-S23121296872011040800000) . Check the valve opening temperature of the thermostat. Standard 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-394766-S17947583672011040800000) . NG --> See step 6 OK --> See step 4
4. REPLACE ECM. Refer to «REMOVAL»(ref-394792-S25581811582011040800000)
5. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-394619-S37978292982011040800000)
6. REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-394766-S23121296872011040800000)

All

HEATED OXYGEN SENSOR OUTPUT VOLTAGE (OUTPUT VOLTAGE, HIGH VOLTAGE AND LOW VOLTAGE)

HEATED OXYGEN SENSOR IMPEDANCE (LOW)

HEATED OXYGEN SENSOR IMPEDANCE (HIGH)

HEATED OXYGEN SENSOR OUTPUT VOLTAGE (EXTREMELY HIGH)

HEATED OXYGEN SENSOR VOLTAGE DURING FUEL CUT

HEATED OXYGEN SENSOR OUTPUT VOLTAGE (OUTPUT VOLTAGE)

HEATED OXYGEN SENSOR OUTPUT VOLTAGE (LOW OUTPUT VOLTAGE)

HEATED OXYGEN SENSOR OUTPUT VOLTAGE (HIGH OUTPUT VOLTAGE)

HEATED OXYGEN SENSOR IMPEDANCE (LOW)

HEATED OXYGEN SENSOR IMPEDANCE (HIGH)

HEATED OXYGEN SENSOR OUTPUT VOLTAGE (EXTREMELY HIGH)

HEATED OXYGEN SENSOR VOLTAGE DURING FUEL CUT

P0136, P0137, P0138, P0156, P0157 and P0158

Scheme 471

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. With the transmission in 4th gear or more, drive the vehicle at 38 to 75 mph (60 to 120 km/h) for 10 minutes or more [C].
8. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
9. Read the pending DTC [D].
10. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0136, P0137, P0138, P0156, P0157, or P0158.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [C] again.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
16. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

P0139 and P0159

Scheme 472

1. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) .
2. Turn the ignition switch off and wait for at least 30 seconds.
3. Turn the ignition switch to ON and turn the Techstream on [A].
4. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more [B].
5. Drive the vehicle at 40 mph (60 km/h), and then decelerate the vehicle by releasing the accelerator pedal for 7 seconds or more to perform the fuel cut [C].
6. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
7. Read the pending DTC [D].
8. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
9. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
10. Input the DTC: P0139, or P0159.
11. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, move the shift lever to 2nd and then perform step [C] again.
12. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
13. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
14. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

MONITOR RESULT

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

Scheme 473

FUEL TRIM

FUEL TRIM

Scheme 474

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394619-S02527777542011040800000) .
4. Turn the ignition switch off and wait for at least 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or more) with all the accessories switched off [B].
7. With the engine warmed up, idle the engine for 2 minutes or more [C].
8. Drive the vehicle at between 38 mph and 75 mph (60 km/h and 120 km/h) and at an engine speed of between 1400 rpm and 3200 rpm for 5 minutes or more [D].
9. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
10. Read the pending DTC [E].
11. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, the system is malfunctioning.
