MONITOR STRATEGY
| Related DTCs | P0500: Vehicle Speed Sensor "A" Pulse Input Error |
| Required Sensors / Components (Main) | Vehicle speed sensor, combination meter and skid control ECU |
| Required Sensors / Components (Related) | Park/neutral position switch, engine coolant temperature sensor, crankshaft position sensor, throttle position sensor |
| Frequency of Operation | Continuous |
| Duration | 2 seconds: Intake air temperature is -10°C (14°F) or more 8 seconds: Intake air temperature is less than -10°C (14°F) |
| MIL Operation | Immediate |
| Sequence of Operation | None |
TYPICAL ENABLING CONDITIONS
| The monitor will run whenever these DTCs are not present | None |
| Time after ignition switch off to ON | 3 seconds or more |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
| Either of the following conditions is met | Condition 1 or 2 |
| 1. Both of the following conditions are met | Condition (a) or (b) |
| (a) Engine coolant temperature | 20°C (68°F) or more |
| (b) Engine coolant temperature sensor fail (P0115, P0117, P0118, P0125) | Not detected |
| (c) Time after park/neutral position switch ON to OFF | 10 seconds or more |
| 2. Both of the following conditions are met | Conditions (a) and (b) |
| (a) Engine coolant temperature | Less than 20°C (68°F) |
| (b) Engine coolant temperature sensor fail (P0115, P0117, P0118, P0125) | Detected |
| (c) Time after park/neutral position switch ON to OFF | 30 seconds or more |
| Engine speed with throttle position sensor voltage is below 0.52 V | 2300 rpm or more |
| Engine speed with throttle position sensor voltage is below 0.84 V | 2700 rpm or more |
| Engine speed with throttle position sensor voltage is below 1.2 V | 2900 rpm or more |
| Engine speed with throttle position sensor voltage is 1.2 V or more | 3250 rpm or more |
| Throttle position sensor fail (P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135) | Not detected |
TYPICAL MALFUNCTION THRESHOLDS
| Vehicle speed sensor signal | No signal |
Scheme 149
Scheme 149: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Drive the vehicle at 15 mph (24 km/h) or more for a total of 30 seconds or more [B].
- Stop the vehicle.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0500.
- Check the DTC judgment result [C]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 150
Scheme 150: WIRING DIAGRAM
| Related DTCs | P0505: Idle Speed Control Function |
| Required Sensors/Components (Main) | Electronic throttle control system |
| Required Sensors/Components (Related) | Crankshaft position sensor Engine coolant temperature sensor Vehicle speed sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 minutes (Idling after warming up) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010 (Camshaft Timing Oil Control Valve) P0011 (VVT System - Advance) P0012 (VVT System - Retard) P0016 (VVT System - Misalignment) P0013 (Exhaust Camshaft Timing Oil Control Valve) P0014 (Exhaust VVT System - Advance) P0015 (Exhaust VVT System - Retard) P0017 (Exhaust VVT System - Misalignment) P0031, P0032, P101D (Air Fuel Ratio Sensor Heater) P2195, P2196, P2237, P2238, P2239, P2252, P2253, P2A00 (Air Fuel Ratio Sensor) P0102, P0103 (Mass Air Flow Meter) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0171, P0172 (Fuel System) P0301 - P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340, P0342, P0343 (Camshaft Position Sensor) P0365, P0367, P0368 (Exhaust Camshaft Position Sensor) P0351 - P0354 (Igniter) P0451, P0452, P0453 (EVAP System) P0500 (Vehicle Speed Sensor) P0705 (Shift Lever Position Switch) |
| Engine | Running |
| Either of the following conditions is met | Condition 1 or 2 |
| 1. Frequency that both of the following conditions (a) and (b) are met | 5 times or more |
| (a) Either of the following conditions is met | Condition A or B |
| A. Engine speed - target engine speed | Less than -100 rpm, or 150 rpm or more (A/C off and NSW off) |
| B. Engine speed - target engine speed | Less than -100 rpm, or 200 rpm or more (A/C on or NSW on) |
| (b) Vehicle condition | Stop after vehicle was driven by 6.25 mph (10 km/h) or more |
| 2. Frequency that both of the following conditions (a) and (b) are met | Once |
| Either of the following conditions is met | Condition A or B |
| A, Engine speed - target engine speed | Less than -100 rpm, or 150 rpm or more (A/C off and NSW off) |
| B, Engine speed - target engine speed | Less than -100 rpm, or 200 rpm or more (A/C on or NSW on) |
| (b) Idle air control flow rate learning valve | 0.9 L/sec. or less, or 6 L/sec. or more |
Scheme 151
Scheme 151: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or more) with all the accessories switched off [B].
- Idle the engine for 10 minute or more [C].
- Accelerate the vehicle to 6.25 mph (10 km/h) or more, and then idle the engine [D].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0505.
- Check the DTC judgment result [E]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, repeat step [D] 4 times, allowing 20 seconds or more between each repetition, and then check the DTC judgment result [F].
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
PROCEDURE
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0505) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0505 is output A DTC P0505 and other DTCs are output B HINT: If any DTCs other than P0505 are output, troubleshoot those DTCs first. B --> See step 5 A: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. Refer to «ON-VEHICLE INSPECTION»(ref-394784-S19590026252011040800000) . OK PCV hose is connected correctly and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leakage. Refer to «ON-VEHICLE INSPECTION»(ref-394784-S19590026252011040800000) . OK No leakage from the intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
- INSPECT THROTTLE BODY (THROTTLE VALVE) Check the throttle valve condition. OK Throttle valve is not contaminated with foreign objects and moves smoothly. NG --> See step 6 OK --> See step 7
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-394618-S20895286482011040800000)
- REPLACE THROTTLE BODY. Refer to «REMOVAL»(ref-394781-S01701351132011040800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000)
| Related DTCs | P050A: Cold Start Idle Air Speed Control System |
| Required Sensors/Components (Main) | Throttle body |
| Required Sensors/Components (Related) | Mass air flow meter Engine coolant temperature sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010 (Camshaft Timing Oil Control Valve) P0011 (VVT System - Advance) P0012 (VVT System - Retard) P0016 (VVT System - Misalignment) P0013 (Exhaust Camshaft Timing Oil Control Valve) P0014 (Exhaust VVT System - Advance) P0015 (Exhaust VVT System - Retard) P0017 (Exhaust VVT System - Misalignment) P2195, P2196, P2237, P2238, P2239, P2252, P2253, P2A00 (Air Fuel Ratio Sensor) P0102, P0103 (Mass Air Flow Meter) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0171, P0172 (Fuel System) P0301 - P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340, P0342, P0343 (Camshaft Position Sensor) P0365, P0367, P0368 (Exhaust Camshaft Position Sensor) P0351 - P0354 (Igniter) P0500 (Vehicle Speed Sensor) P0705 (Shift Lever Position Switch) |
| Battery voltage | 8 V or higher |
| Time after engine start | 3 seconds or more |
| Starter | OFF |
| Engine coolant temperature at engine start | 10°C (14°F) or higher |
| Engine coolant temperature | 10 to 50°C (14 to 122°F) |
| Engine idling time | 3 seconds or more |
| Fuel-cut | OFF |
| Vehicle speed | Less than 1.875 mph (3 km/h) |
| Time after shift position changed | 1 second or more |
| Atmospheric pressure | 76 kPa-a (570 mmHg-a) or higher |
| Accumulated mass air flow | Varies with ECT (Example: Less than 21.9 g) |
Scheme 152
Scheme 152: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp.
- Check that "Coolant Temp" in the Data List are within the range of -10 to 50°C (14 to 122°F).
- Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
- Idle the engine for 1 minute or more [B].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P050A.
- Check the DTC judgment result [C]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [C].
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P050A) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P050A is output A DTC P050A and other DTCs are output B HINT: If any DTCs other than P050A are output, troubleshoot those DTCs first. B --> See step 16 A: Go to next step
- READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Short FT #1 and Long FT #1. Read the values displayed on the Techstream. Add together the Short FT #1 and Long FT #1 values to obtain the total fuel trim. OK Total of Short FT #1 and Long FT #1 values is between -20% and 20%. NG --> See step 5 OK: Go to next step
- INSPECT THROTTLE BODY Check that there are no deposits around the throttle valve. OK No deposits around the throttle valve. NG --> See step 10 OK: Go to next step
- REPLACE ECM Replace the ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000) . NEXT --> See step 15
- PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE OIL CONTROL VALVE) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT System (Bank 1). Check the engine speed while operating the camshaft timing oil control valve assembly using the Techstream. OK Techstream Operation Specified Condition OFF Normal engine speed ON Engine idles roughly or stalls (soon after camshaft timing oil control valve assembly switched from OFF to ON) NG --> See step 11 OK: Go to next step
- CHECK PCV SYSTEM Start the engine. Pinch the PCV hose. Check the engine speed. OK The engine speed rises when the PCV hose is pinched. NG --> See step 12 OK: Go to next step
- INSPECT AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element is not excessively contaminated with dirt or oil. OK The air cleaner filter element is not excessively contaminated with dirt or oil. NG --> See step 13 OK: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leakage. Refer to «ON-VEHICLE INSPECTION»(ref-394784-S19590026252011040800000) . OK No leakage from the intake system. NG --> See step 14 OK: Go to next step
- REPLACE MASS AIR FLOW METER Replace the mass air flow meter. Refer to «REMOVAL»(ref-394781-S30673330062011040800000) . NEXT --> See step 15
- REPAIR OR REPLACE THROTTLE BODY Repair or replace the throttle body. Refer to «REMOVAL»(ref-394781-S01701351132011040800000) . NEXT --> See step 15
- CHECK AND REPAIR VVT SYSTEM HINT: Refer to DTC P0011 Inspection Procedure. Refer to «DTC P0011: Camshaft Position "A" - Timing Over-Advanced or System Performance (Bank 1); DTC P0012: Camshaft Position "A" - Timing Over-Retarded (Bank 1)»(ref-394782-S15479226162011040800000) . NEXT --> See step 15
- REPAIR OR REPLACE PCV SYSTEM NEXT --> See step 15
- REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY NEXT --> See step 15
- REPAIR OR REPLACE INTAKE SYSTEM NEXT --> See step 15
- CHECK WHETHER DTC OUTPUT RECURS (DTC P050A) NOTE: For this operation, the engine must be cold (the same temperature as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Start the engine and idle it for 1 minute. OK Stable fast idle. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. OK No pending DTC is output. NEXT --> REPAIR COMPLETED
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-394618-S20895286482011040800000)
| Related DTCs | P050B: Cold Start Ignition Timing Performance |
| Required Sensors/Components (Main) | Throttle body |
| Required Sensors/Components (Related) | Mass air flow meter Engine coolant temperature sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010 (Camshaft Timing Oil Control Valve) P0011 (VVT System - Advance) P0012 (VVT System - Retard) P0016 (VVT System - Misalignment) P0013 (Exhaust Camshaft Timing Oil Control Valve) P0014 (Exhaust VVT System - Advance) P0015 (Exhaust VVT System - Retard) P0017 (Exhaust VVT System - Misalignment) P2195, P2196, P2237, P2238, P2239, P2252, P2253, P2A00 (Air Fuel Ratio Sensor) P0102, P0103 (Mass Air Flow Meter) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0171, P0172 (Fuel System) P0301 - P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340, P0342, P0343 (Camshaft Position Sensor) P0365, P0367, P0368 (Exhaust Camshaft Position Sensor) P0351 - P0354 (Igniter) P0500 (Vehicle Speed Sensor) P0705 (Shift Lever Position Switch) |
| Battery voltage | 8 V or higher |
| Time after engine start | 3 seconds or more |
| Starter | OFF |
| Engine coolant temperature at engine start | 10°C (14°F) or higher |
| Engine coolant temperature | 10 to 50°C (14 to 122°F) |
| Engine idling time | 3 seconds or more |
| Fuel-cut | OFF |
| Vehicle speed | Less than 1.875 mph (3 km/h) |
| Atmospheric pressure | 76 kPa-a (570 mmHg-a) or higher |
| Accumulated time when ignition timing retard value is cut off | 5 seconds or more |
CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp.
- Check that "Coolant Temp" in the Data List are within the range of -10 to 50°C (14 to 122°F).
- Start the engine and warm it up until the coolant temperature is the same as the coolant temperature in the freeze frame data.
- Idle the engine for 1 minute or more [B].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P050B.
- Check the DTC judgment result [C]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 3 minutes, let the engine cool down, and then perform steps [A] through [C].
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P050B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P050B is output A DTC P050B and other DTCs are output B HINT: If any DTCs other than P050B are output, troubleshoot those DTCs first. B --> See step 16 A: Go to next step
- READ VALUE USING TECHSTREAM (FUEL TRIM) HINT: Calculate the total fuel trim values to check the characteristic deviation of the mass air flow meter. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Short FT #1 and Long FT #1. Read the values displayed on the Techstream. Add together the Short FT #1 and Long FT #1 values to obtain the total fuel trim. OK Total of Short FT #1 and Long FT #1 values is between -20% and 20%. NG --> See step 5 OK: Go to next step
- INSPECT THROTTLE BODY Check that there are no deposits around the throttle valve. OK No deposits around the throttle valve. NG --> See step 10 OK: Go to next step
- REPLACE ECM Replace the ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000) . NEXT --> See step 15
- PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE OIL CONTROL VALVE) Connect the Techstream to the DLC3. Start the engine and turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT System (Bank 1). Check the engine speed while operating the camshaft timing oil control valve using the Techstream. OK Techstream Operation Specified Condition OFF Normal engine speed ON Engine idles roughly or stalls (soon after camshaft timing oil control valve assembly switched from OFF to ON) NG --> See step 11 OK: Go to next step
- CHECK PCV SYSTEM Start the engine. Pinch the PCV hose. Check the engine speed. OK The engine speed rises when the PCV hose is pinched. NG --> See step 12 OK: Go to next step
- INSPECT AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Visually check that the air cleaner filter element is not excessively contaminated with dirt or oil. OK The air cleaner filter element is not excessively contaminated with dirt or oil. NG --> See step 13 OK: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leakage. Refer to «ON-VEHICLE INSPECTION»(ref-394784-S19590026252011040800000) . OK No leakage from the intake system. NG --> See step 14 OK: Go to next step
- REPLACE MASS AIR FLOW METER Replace the mass air flow meter. Refer to «REMOVAL»(ref-394781-S30673330062011040800000) . NEXT --> See step 15
- REPAIR OR REPLACE THROTTLE BODY Repair or replace the throttle body. Refer to «REMOVAL»(ref-394781-S01701351132011040800000) . NEXT --> See step 15
- CHECK AND REPAIR VVT SYSTEM HINT: Refer to DTC P0011 Inspection Procedure. Refer to «DTC P0011: Camshaft Position "A" - Timing Over-Advanced or System Performance (Bank 1); DTC P0012: Camshaft Position "A" - Timing Over-Retarded (Bank 1)»(ref-394782-S15479226162011040800000) . NEXT --> See step 15
- REPAIR OR REPLACE PCV SYSTEM NEXT --> See step 15
- REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY NEXT --> See step 15
- REPAIR OR REPLACE INTAKE SYSTEM NEXT --> See step 15
- CHECK WHETHER DTC OUTPUT RECURS (DTC P050B) NOTE: For this operation, the engine must be cold (the same temperature as the engine coolant temperature recorded in the freeze frame data). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Start the engine and idle it for 1 minute. OK Stable fast idle. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. OK No pending DTC is output. NEXT --> REPAIR COMPLETED
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-394618-S20895286482011040800000)
| Related DTCs | P0560: ECM System Voltage |
| Required Sensors / Components (Main) | ECM |
| Required Sensors / Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediately (MIL illuminated after next engine start) |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Stand-by RAM | Initialized |
| ECM power source | Less than 3.5 V |
Scheme 153
Scheme 153: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 5 seconds or more.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0560.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 154
Scheme 154: WIRING DIAGRAM
- CHECK HARNESS AND CONNECTOR (EFI NO. 1 FUSE - ECM) Disconnect the ECM connector. Remove the EFI NO. 1 fuse from the engine room relay block. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition 2 (EFI NO. 1 fuse) - A49-20 (BATT) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition 2 (EFI NO. 1 fuse) or A49-20 (BATT) - Body ground Always 10 kohms or higher Reconnect the ECM connector. Reinstall the EFI NO. 1 fuse. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (EFI NO. 1 FUSE - ECM) OK: Go to next step
- INSPECT BATTERY Check the battery voltage. Battery voltage 11 to 14 V NG --> REPLACE BATTERY OK: Go to next step
- CHECK BATTERY TERMINAL Check that the battery terminals are not loose or corroded. OK Battery terminals are not loose or corroded. NG --> REPAIR OR REPLACE BATTERY TERMINAL OK --> See step 4
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-394618-S26532322762011040800000)
| Related DTCs | P0604: ECM RAM Error |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | None |
| Frequency of Operation | Continuous |
| Duration | 6 times |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Main CPU and sub CPU mirroring | Fail |
Scheme 155
Scheme 155: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0604.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P0604) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0604 is output B B --> See step 3 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-394618-S26532322762011040800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000)
| Related DTC | P0606: ECM Range Check |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | Within 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| DMA communication | No response |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0606.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P0606) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0606 is output B B --> See step 3 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-394618-S26532322762011040800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000)
| Related DTCs | P0607: Control Module Performance |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | Heated oxygen sensor |
| Frequency of Operation | Continuous |
| Duration | 60 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| Engine | Running |
| Estimated heated oxygen sensor temperature | 450 to 800°C (842 to 1472°F) |
| Heated oxygen sensor transistors | Fail |
Scheme 156
Scheme 156: CONFIRMATION DRIVING PATTERN
- Stop the engine for 30 minutes or more [A].
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [B].
- Start the engine, and wait 2 minutes [C].
- Warm up the engine until the engine coolant temperature is 75°C (167°F) or higher [D].
- Idle the engine for 1 minute [E].
- Accelerate the vehicle to 50 mph (80 km/h) and stop the vehicle [F].
- Drive the vehicle at 35 to 50 mph (56 to 80 km/h) for 5 minutes or more [G].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0607, P0136, P0137 or P0138.
- Check the DTC judgment result [H]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [D] through [H].
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 157
- CHECK ANY OTHER DTCS OUTPUT Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to P0607 and P0136, P0137 or P0138 are output A P0607 is output B B --> See step 3 A: Go to next step
- INSPECT DTC (P0136, P0137 OR P0138) Refer to the P0136, P0137 or P0138 flowchart. HINT: If P0136 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-394782-S20277389042011040800000) . Then proceed to "INSPECT ECM". If P0137 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-394782-S20277389042011040800000) . Then proceed to "INSPECT ECM". If P0138 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-394782-S20277389042011040800000) . Then proceed to "INSPECT ECM". If DTC P0607 and P0136, P0137 or P0138 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or higher). NEXT --> See step 6
- CHECK FOR EXHAUST GAS LEAK Allow the engine to idle and rev the engine. Check for exhaust gas leaks around the heated oxygen sensor. If any exhaust gas leaks are present, repair them and proceed to "PERFORM CONFIRMATION DRIVING PATTERN". If no exhaust gas leaks are present, proceed to "PERFORM CONFIRMATION DRIVING PATTERN". HINT: If no exhaust gas leaks are present, a malfunction in the heated oxygen sensor circuit is suspected. If any exhaust gas leaks are present around the heated oxygen sensor, noise appears in the output voltage of the heated oxygen sensor. NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Connect the Techstream to the DLC3. Start the engine. Switch the ECM from normal mode to check mode. Warm up the engine until the engine coolant temperature is 75°C (167°F) or higher. Perform the driving pattern. Accelerate the vehicle to 50 mph (80 km/h) and stop the vehicle. Drive the vehicle between 35 and 50 mph (56 and 80 km/h) for 5 minutes. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to P0136, P0137, P0138 and/or P0607 A Only P0607 B No DTC output C C --> See step 6 B --> See step 7 A: Go to next step
- INSPECT DTC (P0136, P0137 OR P0138) Refer to the P0136, P0137 or P0138 flowchart. HINT: If P0136 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-394782-S20277389042011040800000) . Then proceed to "INSPECT ECM". If P0137 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-394782-S20277389042011040800000) . Then proceed to "INSPECT ECM". If P0138 is output, troubleshoot for that DTC first. Refer to «DTC P0136: Oxygen Sensor Circuit Malfunction (Bank 1 Sensor 2); DTC P0137: Oxygen Sensor Circuit Low Voltage (Bank 1 Sensor 2); DTC P0138: Oxygen Sensor Circuit High Voltage (Bank 1 Sensor 2); DTC P0139: Oxygen Sensor Circuit Slow Response (Bank 1 Sensor 2)»(ref-394782-S20277389042011040800000) . Then proceed to "INSPECT ECM". If DTC P0607 and P0136, P0137 or P0138 are output, the output voltage of the heated oxygen sensor may remain close to 0 V or become high (around 1 V or higher). NEXT: Go to next step
- INSPECT ECM Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Stop the engine and wait for 30 minutes. Connect the Techstream to the DLC3. Start the engine and allow it to idle for 2 minutes. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Check the DTCs. Result Result Proceed to DTC is not output A P0607 is output B B --> See step 8 A --> END
- REPLACE ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000)
| Related DTCs | P060A: ECM CPU Error |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | Within 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| When either condition below is met | Condition 1 or 2 |
| 1. When all conditions below are met | |
| CPU reset | 1 time or more |
| Learned throttle position - Learned accelerator pedal position | 0.4 V or higher |
| Electronic throttle actuator | OFF |
| 2. CPU reset | 2 times or more |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P060A.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P060A) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P060A is output B B --> See step 3 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-394618-S26532322762011040800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000)
| Related DTCs | P060B: ECM main CPU communication error |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 2 Times: AD converter is fail 30 Time: Knock sensor circuit is fail |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| When one of the following conditions is met | |
| AD converter | Fail |
| Knock sensor circuit | Fail |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P060B.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P060B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the battery negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P060B is output B DTC P060B and P0327, P0328 are output C C --> See step 4 B --> See step 3 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-394618-S26532322762011040800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000)
- GO TO DTC (P0327, P0328). Refer to «DTC P0327: Knock Sensor 1 Circuit Low Input (Bank 1 or Single Sensor); DTC P0328: Knock Sensor 1 Circuit High Input (Bank 1 or Single Sensor)»(ref-394782-S28598630252011040800000)
| Related DTCs | P060D: Internal control module, Accelerator pedal position |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Difference of main accelerator pedal position and sub accelerator pedal position | 0.3 V or higher |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P060D.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P060D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P060D is output B B --> See step 3 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-394618-S26532322762011040800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000)
| Related DTCs | P060E: Internal Control Module, Throttle Position |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second: Throttle sensor fail 13 times: Brake switch signal fail |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| DMA communication error | Not detected |
| When one of following conditions is met | Condition 1 or 2 |
| 1. Difference of main throttle position and sub throttle position | 0.3 V or higher |
| 2. Value of main brake switch signal and sub brake switch signal | Different |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P060E.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P060E) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P060E is output B B --> See step 3 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-394618-S26532322762011040800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000)
| Related DTCs | P0617: Starter Signal |
| Required Sensors/Components (Main) | ST relay Park/neutral position switch Ignition switch |
| Required Sensors/Components (Related) | Vehicle speed sensor Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 20 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 10.5 V or higher |
| Vehicle speed | 12.43 mph (20 km/h) or more |
| Engine speed | 1000 rpm or more |
Scheme 158
Scheme 158: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Idle the engine for 5 minutes or more [B].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0617.
- Check the DTC judgment result [C]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [D] and [E].
- Drive the vehicle at 15 mph (24 km/h) or more for 20 seconds or more [D].
- Check the DTC judgment result [E].
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 159
Scheme 159: WIRING DIAGRAM
Scheme 160
- READ VALUE USING TECHSTREAM (STARTER SIGNAL) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Starter Signal. Check the value displayed on the Techstream when the vehicle is driven at 12.43 mph (20 km/h) or more. Result Condition Starter Signal Proceed to Driving at 12.43 mph (20 km/h) or more Close (Starter signal OFF) A Open (Starter signal ON) B B --> See step 2 A --> See step 7
- INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY Inspect the park/neutral position switch assembly. Refer to «INSPECTION»(ref-394780-S10452163842011040800000) . Result Result Proceed to NG A OK B B --> See step 5 A: Go to next step
- REPLACE PARK/NEUTRAL POSITION SWITCH ASSEMBLY Replace the park/neutral position switch assembly. Refer to «REMOVAL»(ref-394780-S14907756672011040800000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0617 is output A DTC is not output B B --> REPAIR COMPLETED A: Go to next step
- REPAIR OR REPLACE HARNESS OR CONNECTOR (STARTER SIGNAL CIRCUIT) NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0617 is output B B --> See step 8 A --> REPAIR COMPLETED
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-394618-S26532322762011040800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000)
| Related DTCs | P062F: Internal Control Module EEPROM Error |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 3 times |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Time after engine start | 10 seconds or more |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Starter | OFF |
| Permanent fault code data | Mismatch (3 times or more) |
Scheme 161
Scheme 161: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 30 seconds or more.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P062F.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P062F) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P062F is output B B --> See step 2 A --> See step 3
- REPLACE ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-394618-S26532322762011040800000)
| Related DTCs | P0630: VIN Not Programmed |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.325 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Starter | OFF |
COMPONENT OPERATING RANGE
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 5 seconds or more.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0630.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0630) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0630 is output A DTC P0630 and other DTCs are output B If any DTCs other than P0630 are output, troubleshoot those DTCs first. NOTE: If P0630 is output, the VIN must be input into the ECM using the Techstream. However, all DTCs are cleared automatically by the Techstream when inputting the VIN. If DTCs other than P0630 are output, check them first. B --> See step 3 A: Go to next step
- INPUT VIN Input the VIN. Refer to «REGISTRATION»(ref-394618-S05293319372011040800000) . NEXT --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-394618-S20895286482011040800000)
| Related DTCs | P0657: ETCS Power Supply |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | Throttle actuator |
| Frequency of Operation | Once per driving cycle |
| Duration | 1 second or more |
| MIL Operation | Once per driving cycle |
| Sequence of Operation | None |
| Throttle actuator power supply voltage | 7 V or higher |
| Electronic throttle actuator power supply | ON |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 5 seconds or more.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0657.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P0657) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Turn the ignition switch to ON for 10 seconds. Turn the ignition switch off. Turn the ignition switch to ON. Connect the Techstream to the DLC3. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0657 is output B B --> See step 3 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-394618-S26532322762011040800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000)
| Related DTCs | P0705: Park/Neutral Position Switch Assembly/Verify Switch Input |
| Required sensors/Components | Park/neutral position switch assembly |
| Frequency of operation | Continuous |
| Duration | Condition (A) and (B): 2 seconds Condition (C): 60 seconds |
| MIL operation | 2 driving cycles |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Ignition switch | ON |
| Battery voltage | 10.5 V or more |
| Starter | OFF |
| One of the following conditions is met | Condition (a), (b), (c) or (d) |
| (a) Park/neutral position switch | ON |
| (b) Park position switch | ON |
| (c) Neutral position switch | ON |
| (d) R range position switch | ON |
- One of the following conditions is met: Condition (A), (B) and (C) CONDITION (A) Any two of the following conditions are met: Conditions A , B and C A. One of the following conditions is met: Condition (a), (b) or (c) (a). Park position switch ON (b). Neutral position switch ON (c). Park/neutral position switch ON B. R range position switch ON C. D range position switch ON CONDITION (B) "S" range position switch ON CONDITION (C) All of the following conditions are met - Park position switch OFF Neutral position switch OFF Park neutral position switch OFF R range position switch OFF D range position switch OFF
| Park/neutral position switch assembly | The park/neutral position switch assembly sends only one signal to the ECM. |
Scheme 162
Scheme 162: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 10 minutes or more.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0705.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 163
Scheme 163: WIRING DIAGRAM
| Related DTCs | P0724: Stop Light Switch/Range Check/Rationality |
| Required Sensors/Components (Main) | Stop light switch |
| Required Sensors/Components (Related) | Speed sensor |
| Frequency of Operation | Continuous |
| Duration | 5 times |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
The stop light switch remains ON during STOP and GO 5 times.
| Monitor runs whenever following DTCs not stored | None |
| GO: Vehicle speed | 18.65 mph (30 km/h) or more |
| STOP: Vehicle speed | Less than 1.86 mph (3 km/h) |
GO AND STOP ARE DEFINED AS FOLLOWS
| Stop light switch status | Stuck ON |
Scheme 164
Scheme 164: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 5 seconds after clear DTCs.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0724.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [C] through [E].
- Start the engine [C].
- Accelerate the vehicle to 18.65 mph (30 km/h) or more, depress the brake pedal and decelerate the vehicle to 1.86 mph (3 km/h) or less [D]. Repeat step [D] 5 times.
- Check the DTC judgment result [E].
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ VALUE USING TECHSTREAM (STOP LIGHT SWITCH) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Stop Light Switch. Read the values displayed on the Techstream. OK Item Measurement Item/Range (display) Normal Condition Stop Light Switch Stop light switch status: ON or OFF ON: Brake pedal depressed OFF: Brake pedal released NG --> See step 2 OK --> See step 4
- INSPECT STOP LIGHT SWITCH ASSEMBLY Inspect the stop light switch assembly. Refer to «INSPECTION»(ref-394791-S20483180282011040800000) . NG --> See step 5 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (STOP LIGHT SWITCH - ECM) Disconnect the ECM connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A49-39 (ST1-) - Body ground Brake pedal released 7.5 to 14 V Brake pedal depressed Below 1.5 V A49-29 (STP) - Body ground Brake pedal released Below 1.5 V Brake pedal depressed 7.5 to 14 V Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 6
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-394618-S26532322762011040800000)
- REPLACE STOP LIGHT SWITCH. Refer to «REMOVAL»(ref-394791-S02787810022011040800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000)
| Related DTC | P1607: Internal Control Module Range Check |
| Required sensors/Components (Main) | ECM |
| Required sensors/Components (Related) | Cruise control |
| Frequency of Operation | Continuous |
| Duration | 0.3 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Cruise control | Forbiddance |
| When either condition below is met | |
| Cruise control | Operating |
| Low speed control | Operating |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 16 seconds or more.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P1607.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ OUTPUT DTC (DTC P1607) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Turn the ignition switch off and turn the Techstream off. Disconnect the Techstream. Disconnect the cable from the negative (-) battery terminal and wait for 1 minute. Connect the cable to the negative (-) battery terminal. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P1607 is output B B --> See step 3 A --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-394618-S26532322762011040800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000)
| Related DTCs | P2004: Tumble Control Valve Stuck Open P2006: Tumble Control Valve Stuck Closed |
| Required Sensors/Components (Main) | Tumble control valve |
| Required Sensors/Components (Related) | Intake air temperature sensor, Engine coolant temperature sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | Approximately 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence Operation | None |
| The monitor will run whenever these DTCs are not stored | None |
| Engine coolant temperature | 10°C (14°F) or higher |
| Intake air temperature | 10°C (14°F) or higher |
| Control valve half-open operation | Not operated |
| Ignition switch | ON |
| Control valve | Not operated by scan tool |
| Battery voltage during close operation | 8 V or higher |
| When either condition below is met | Condition A or B |
| A. When both conditions below are met | |
| Engine coolant temperature at engine start | 5°C (41°F) or higher |
| Intake air temperature at engine start | 5°C (41°F) or higher |
| B. When both conditions below are met | |
| Engine coolant temperature | 70°C (158°F) or higher |
| Vehicle speed | Less than 47 mph (75 km/h) |
| Command to control valve | Closed |
| Command to control valve | Open |
| Control valve angle | 17 deg or more |
| Control valve angle | Less than 35 deg |
| Control valve angle | 0 to 70 deg |
Scheme 165
Scheme 165: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear the DTCs.
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp. HINT: Check DTC P2004 at a coolant temperature of 30°C (86°F) or less. Check DTC P2006 at a coolant temperature of 80°C (176°F) or higher.
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON, wait approximately 10 seconds, and then turn the ignition switch off. Repeat this procedure 3 times [B].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P2004 or P2006.
- Check the DTC judgment result [C]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 166
Scheme 166: WIRING DIAGRAM
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2004 OR P2006) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P2004 or P2006 is output A P2004 or P2006 and other DTCs are output B HINT: If any DTCs other than P2004 or P2006 are output, troubleshoot those DTCs first. B --> See step 6 A: Go to next step
- INSPECT INTAKE AIR CONTROL VALVE ACTUATOR (FOR TUMBLE CONTROL VALVE) Inspect the intake air control valve actuator. Refer to «INSPECTION»(ref-394789-S23654676462011040800000) . NG --> See step 10 OK: Go to next step
- INSPECT INTAKE MANIFOLD (TUMBLE CONTROL VALVE OPERATION) Inspect the intake manifold. Refer to «INSPECTION»(ref-394789-S28092136222011040800000) . NG --> See step 7 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (ECM - INTAKE AIR CONTROL ACTUATOR) Disconnect the ECM connector. Disconnect the intake air control valve actuator connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B58-3 (IA1-) - U3-4 (M-) Always Below 1 ohms B58-4 (IA1+) - U3-5 (M+) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B58-3 (IA1-) or U3-4 (M-) - Body ground Always 10 kohms or higher B58-4 (IA1+) or U3-5 (M+) - body ground Always 10 kohms or higher Reconnect the ECM connector. Reconnect the intake air control valve actuator connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P2004 OR P2006) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to DTC P2004 or P2006 is output A DTC is not output B B --> See step 8 A --> See step 9
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-394618-S20895286482011040800000)
- REPLACE INTAKE MANIFOLD. Refer to «REMOVAL»(ref-394789-S08621706042011040800000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-394618-S26532322762011040800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000)
- REPLACE INTAKE AIR CONTROL VALVE ACTUATOR (FOR TUMBLE CONTROL VALVE). Refer to «REMOVAL»(ref-394789-S38375711352011040800000)
| Related DTCs | P2009: DC Motor for Tumble Control Valve Range Check (Low Current) P2010: DC Motor for Tumble Control Valve Range Check (High Current) |
| Required Sensors/Components (Main) | Tumble control valve (actuator) |
| Required Sensors/Components (Related) | None |
| Frequency of Operation | Continuous |
| Duration | DC motor for tumble control valve range check (low current): 1 second DC motor for tumble control valve range check (high current): 6 times |
| MIL Operation | Immediate |
| Sequence Operation | None |
| The monitor will run whenever these DTCs are not stored | None |
| Battery voltage | 8 V or higher |
| Starter | OFF |
| Output signal duty | 100% |
| Difference between motor current and previous motor current | Below 0.2 A |
| The monitor will run whenever these DTCs are not stored | None |
| Battery voltage | 8 V or higher |
| Starter | OFF |
| DC motor for tumble control valve current | Below 0.35 A |
| Motor drive IC high current limiter port | Fail |
| DC motor for tumble control valve current | More than 0.35 A |
| Motor drive IC high current limiter port | Pass |
Scheme 167
Scheme 167: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear the DTCs.
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp.
- Check that the coolant temperature is 60°C (140°F) or higher.
- Wait approximately 10 seconds [A].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P2009 or P2010.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- INSPECT INTAKE AIR CONTROL VALVE ACTUATOR (FOR TUMBLE CONTROL VALVE) Inspect the intake air control valve actuator. Refer to «INSPECTION»(ref-394789-S23654676462011040800000) . NG --> See step 8 OK: Go to next step
- INSPECT INTAKE MANIFOLD (TUMBLE CONTROL VALVE OPERATION) Inspect the intake manifold. Refer to «INSPECTION»(ref-394789-S28092136222011040800000) . NG --> See step 5 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (ECM - INTAKE AIR CONTROL VALVE ACTUATOR) Disconnect the ECM connector. Disconnect the intake air control valve actuator connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B58-3 (IA1-) - U3-4 (M-) Always Below 1 ohms B58-4 (IA1+) - U3-5 (M+) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B58-3 (IA1-) or U3-4 (M-) - Body ground Always 10 kohms or higher B58-4 (IA1+) or U3-5 (M+) - body ground Always 10 kohms or higher Reconnect the ECM connector. Reconnect the intake air control valve actuator connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P2009 OR P2010) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P2009 or P2010 is output A DTC is not output B B --> See step 6 A --> See step 7
- REPLACE INTAKE MANIFOLD. Refer to «REMOVAL»(ref-394789-S08621706042011040800000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-394618-S26532322762011040800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000)
- REPLACE INTAKE AIR CONTROL VALVE ACTUATOR (FOR TUMBLE CONTROL VALVE). Refer to «REMOVAL»(ref-394789-S38375711352011040800000)
| Related DTCs | P2014: Tumble control valve position sensor range check (chattering) P2016: Tumble control valve position sensor range check (low voltage) P2017: Tumble control valve position sensor range check (high voltage) |
| Required Sensors/Components (Main) | Tumble control valve position sensor |
| Required Sensors/Components (Related) | None |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence Operation | None |
| The monitor will run whenever these DTCs are not stored | None |
| Tumble control valve position sensor voltage | Below 0.2 V or higher than 4.8 V |
| Tumble control valve position sensor voltage | Below 0.2 V |
| Tumble control valve position sensor voltage | Higher than 4.8 V |
| Tumble control valve position sensor voltage | 0.2 to 4.8 V |
Scheme 168
Scheme 168: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs.
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Allow 0.5 seconds or more to elapse [A].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P2014, P2016 or P2017.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P2102: Throttle Actuator Current (Low Current) P2103: Throttle Actuator Current (High Current) |
| Required Sensors/Components (Main) | Throttle actuator (throttle body) |
| Required Sensors/Components (Related) | None |
| Frequency of Operation | Continuous |
| Duration | P2102: 2 seconds P2103: 25 times |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Throttle actuator | ON |
| Duty-cycle ratio to open throttle actuator | 80% or more |
| Throttle actuator power supply | 8 V or higher |
| Motor current change during last 0.016 seconds | Below 0.2 A |
| Throttle actuator | ON |
| Either of the following conditions 1 or 2 is met | |
| 1. Throttle actuator power supply | 8 V or higher |
| 2. Throttle actuator power | ON |
| Throttle actuator current | Below 0.5 A |
| Either of following conditions is met | A or B |
| A. Hybrid IC diagnosis signal | Fail |
| B. Hybrid IC current limiter port | Fail |
Scheme 169
Scheme 169: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- With the vehicle stationary, fully depress the accelerator pedal and quickly release it [B].
- Check that 16 seconds or more have elapsed from the instant when the accelerator pedal is first depressed.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P2102 or P2103.
- Check the DTC judgment result [C]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [C] again.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
FAIL-SAFE
When either of these DTCs, as well as other DTCs relating to ETCS (Electronic Throttle Control System) malfunctions, is stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue running at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.
Scheme 170
Scheme 170: WIRING DIAGRAM
| Related DTCs | P2111: Throttle Actuator Stuck Open P2112: Throttle Actuator Stuck Closed |
| Required Sensors/Components (Main) | Throttle actuator (throttle body) |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| All of following conditions set | |
| System guard* judge condition | ON |
| Throttle actuator current | 2 A or higher |
| Duty-cycle to close throttle | 80% or more |
P2111 (THROTTLE ACTUATOR STUCK OPEN)
| All of following conditions set | |
| System guard* judge condition | ON |
| Throttle actuator current | 2 A or higher |
| Duty-cycle to open throttle | 80% or more |
| *: System guard is on when the following conditions set | |
| Throttle actuator | ON |
| Throttle actuator duty calculation | Executing |
| Throttle position sensor fail | Not detected |
| Throttle actuator current-cut operation | Not executing |
| Throttle actuator power supply | 4 V or higher |
| Throttle actuator fail | Not detected |
P2112 (THROTTLE ACTUATOR STUCK CLOSED)
| Throttle position sensor voltage change | No change |
P2111 (THROTTLE ACTUATOR STUCK OPEN)
| Throttle position sensor voltage change | No change |
P2112 (THROTTLE ACTUATOR STUCK CLOSED)
Scheme 171
Scheme 171: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and fully depress and release the accelerator pedal quickly (to fully open and close the throttle valve).
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P2111 or P2112.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
When either of these DTCs, as well as other DTCs relating to Electronic Throttle Control System (ETCS) malfunctions, is stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue running at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.
- INSPECT THROTTLE BODY (VISUALLY CHECK THROTTLE VALVE) Check for contamination between the throttle valve and the housing. If necessary, clean the throttle body. And check that the throttle valve moves smoothly. OK Throttle valve is not contaminated with foreign objects and moves smoothly. NG --> See step 3 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P2111 OR P2112) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Start the engine. Fully Depress and release the accelerator pedal quickly (to fully open and close the throttle valve). Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P2111 or P2112 is output B B --> See step 4 A --> See step 5
- REPLACE THROTTLE BODY. Refer to «REMOVAL»(ref-394781-S01701351132011040800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-394618-S26532322762011040800000)
| Related DTCs | P2118: Throttle Actuator Power Supply |
| Required Sensors/Components (Main) | Throttle actuator, throttle valve (throttle body) ETCS fuse |
| Required Sensors/Components (Related) | None |
| Frequency of Operation | Continuous |
| Duration | 0.8 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 8 V or higher |
| Electronic throttle actuator power | ON |
| Throttle actuator power supply voltage (+BM) | Below 4 V |
| Throttle actuator power supply voltage (+BM) | 11 to 14 V |
Scheme 172
Scheme 172: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Slowly depress the accelerator pedal, raise the engine speed to approximately 3000 rpm for approximately 5 seconds, and then idle the engine [B].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P2118.
- Check the DTC judgment result [C]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [C] again.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
When this DTC or other DTCs relating to Electronic Throttle Control System (ETCS) malfunctions, are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.
Scheme 173
Scheme 173: WIRING DIAGRAM
- READ VALUE USING TECHSTREAM (+BM VOLTAGE) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / +BM Voltage. Read the value displayed on the Techstream. Standard voltage 11 to 14 V NG --> See step 2 OK --> See step 3
- CHECK HARNESS AND CONNECTOR (BATTERY - ECM, ECM - BODY GROUND) Disconnect the ECM connectors. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A49-3 (+BM) - Body ground Always 11 to 14 V Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B58-19 (ME01) - Body ground Always Below 1 ohms B58-104 (E1) - Body ground Always Below 1 ohms Reconnect the ECM connectors. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 4
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-394618-S26532322762011040800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000)
| Related DTCs | P2119: Electronic Throttle Control System Malfunction |
| Required Sensors/Components (Main) | Throttle actuator (throttle body) |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | Closed: 1 second Open: 0.6 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| System guard* judge condition | ON |
| *: System guard is on when the following conditions set | |
| Throttle actuator | ON |
| Throttle actuator duty calculation | Executing |
| Throttle position sensor fail | Not detected |
| Throttle actuator current-cut operation | Not executing |
| Throttle actuator power supply | 4 V or higher |
| Throttle actuator fail | Not detected |
| Either of following conditions A or B is met | |
| A. Commanded closed throttle position - current closed throttle position | 0.3 V or higher |
| B. Commanded open throttle position - current open throttle position | 0.3 V or higher |
Scheme 174
Scheme 174: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 20 seconds.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P2119.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, fully depress and release the accelerator pedal 3 times, and then check the DTC judgment result at step [C].
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
When this DTC, as well as other DTCs relating to Electronic Throttle Control System (ETCS) malfunctions, is stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue running at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2119) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P2119 is output A DTC P2119 and other DTCs are output B HINT: If any DTCs other than P2119 are output, troubleshoot those DTCs first. B --> See step 5 A: Go to next step
- INSPECT THROTTLE BODY (RESISTANCE OF THROTTLE ACTUATOR) Disconnect the throttle body connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 2 (M+) - 1 (M-) 20°C (68°F) 0.3 to 100 ohms TEXT IN ILLUSTRATION *1 Component without harness connected (Throttle Body) Reconnect the throttle body connector. NG --> See step 6 OK: Go to next step
- REPLACE ECM Replace the ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P2119) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Start the engine. Allow the engine to idle for 15 seconds or more. Fully depress and release the accelerator pedal several times quickly. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P2119 is output B HINT: The output voltage of the throttle position sensor can be checked using the Techstream. Variations in the output voltage indicate that the throttle actuator is in operation. To check the output voltage using the Techstream, enter the following menus: Powertrain / Engine / ETCS / Throttle Position No. 1 and Throttle Position No. 2. B --> See step 6 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-394618-S20895286482011040800000)
- REPLACE THROTTLE BODY. Refer to «REMOVAL»(ref-394781-S01701351132011040800000)
| Related DTCs | P2120: Accelerator Pedal Position Sensor 1 Range Check (Fluctuating) P2122: Accelerator Pedal Position Sensor 1 Range Check (Low Voltage) P2123: Accelerator Pedal Position Sensor 1 Range Check (High Voltage) P2125: Accelerator Pedal Position Sensor 2 Range Check (Fluctuating) P2127: Accelerator Pedal Position Sensor 2 Range Check (Low Voltage) P2128: Accelerator Pedal Position Sensor 2 Range Check (High Voltage) P2138: Accelerator Pedal Position Sensor Range Check (Correlation) |
| Required Sensors/Components (Main) | Accelerator pedal position sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds: P2120, P2122, P2125 and P2127 2.0 seconds: P2123, P2128 and P2138 |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Either of following conditions met | |
| 1. Ignition switch | ON (0.012 seconds or more) |
| 2. Throttle actuator power | ON |
| Either of following conditions met | |
| 1. VPA voltage when VPA2 voltage 0.04 V or higher | 0.4 V or less |
| 2. VPA voltage | 4.8 V or higher |
| VPA voltage when VPA2 voltage 0.04 V or higher | 0.4 V or less |
| VPA voltage | 4.8 V or higher |
| Either of following conditions met | |
| 1. VPA2 voltage when VPA voltage 0.04 V or higher | 1.2 V or less |
| 2. VPA2 voltage when VPA voltage 0.4 to 3.45 V | 4.8 V or higher |
| VPA2 voltage when VPA voltage 0.04 V or higher | 1.2 V or less |
| VPA2 voltage when VPA voltage 0.4 to 3.45 V | 4.8 V or higher |
| Either of following conditions met | |
| Condition A | |
| Difference between VPA and VPA 2 voltages | 0.02 V or less |
| Condition B | |
| VPA voltage | 0.4 V or less |
| VPA2 voltage | 1.2 V or less |
| VPA voltage | 0.4 to 4.8 V |
| VPA2 voltage | 1.2 to 4.8 V |
| Difference between VPA and VPA2 voltages | Higher than 0.02 V |
Scheme 175
Scheme 175: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Fully depress and release the accelerator pedal [B].
- Check that 5 seconds or more have elapsed since the DTCs were cleared.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P2120, P2122, P2123, P2125, P2127, P2128 or P2138.
- Check the DTC judgment result [C]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [C] again.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
When any of DTCs P2120, P2121, P2122, P2123, P2125, P2127, P2128 and P2138 is stored, the ECM enters fail-safe mode. If either of the 2 sensor circuits malfunctions, the ECM uses the remaining circuit to calculate the accelerator pedal position to allow the vehicle to continue driving. If both of the circuits malfunction, the ECM regards the accelerator pedal as being released. As a result, the throttle valve is closed and the engine idles.
Fail-safe mode continues until a pass condition is detected, and the ignition switch is turned off.
Scheme 176
Scheme 176: WIRING DIAGRAM
| Related DTCs | P2121: Accelerator Pedal Position Sensor Rationality |
| Required Sensors/Components (Main) | Accelerator pedal position sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Either of following conditions met | |
| 1. Ignition switch | ON (0.012 seconds or more) |
| 2. Electronic throttle actuator power | ON |
| Difference between VPA voltage (learned value) and VPA2 voltage (learned value) | Below 0.4 V, or higher than 1.2 V |
Scheme 177
Scheme 177: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream ON.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Fully depress and release the accelerator pedal [B].
- Check that 20 seconds or more have elapsed since the DTCs were cleared.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P2121.
- Check the DTC judgment result [C]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [C] again.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
The accelerator pedal sensor assembly has 2 (main and sub) sensor circuits. If a malfunction occurs in either of the sensor circuits, the ECM detects the abnormal signal voltage difference between the 2 sensor circuits and switches to limp mode. In limp mode, the functioning circuit is used to calculate the accelerator pedal angle to allow the vehicle to continue driving. If both circuits malfunction, the ECM regards of the accelerator pedal angle as being fully closed. In this case, the throttle valve remains closed as if the engine is idling.
If a pass condition is detected and then the ignition switch is turned off, the fail-safe operation stops and the system returns to normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2121) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P2121 is output A DTC P2121 and other DTCs are output B HINT: If any DTCs other than P2121 are output, troubleshoot those DTCs first. B --> See step 7 A: Go to next step
- READ VALUE USING TECHSTREAM (ACCELERATOR PEDAL SENSOR ASSEMBLY) See step 1 NG --> See step 3 OK --> See step 6
- REPLACE ACCELERATOR PEDAL ASSEMBLY Replace the accelerator pedal assembly. Refer to «REMOVAL»(ref-394781-S37613641072011040800000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (ACCELERATOR PEDAL SENSOR ASSEMBLY DTCS) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P2121 is output A DTC is not output B B --> REPAIR COMPLETED A --> See step 5
- REPLACE ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-394618-S20895286482011040800000)
| Related DTCs | P2195: Air Fuel Ratio Sensor (Bank 1 Sensor 1) Signal Stuck Lean P2196: Air Fuel Ratio Sensor (Bank 1 Sensor 1) Signal Stuck Rich |
| Required Sensors/Components (Main) | Air fuel ratio sensor |
| Required Sensors/Components (Related) | Heated oxygen sensor |
| Frequency of Operation | Continuous: Sensor voltage detection monitor Once per driving cycle: Sensor current detection monitor |
| Duration | 5 seconds: Sensor voltage detection monitor 3 seconds: Sensor current detection monitor |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0016 (VVT System - Misalignment) P0017 (Exhaust VVT System - Misalignment) P0031, P0032, P101D (Air Fuel Ratio Sensor Heater) P0102, P0103 (Mass Air Flow Meter) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0128 (Thermostat) P0171, P0172 (Fuel System) P0301 - P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) P0451, P0452, P0453 (EVAP System) P0500 (Vehicle Speed Sensor) P0505 (Idle Speed Control) |
| Time after engine start | 30 seconds or more |
| Fuel system status | Closed loop |
SENSOR VOLTAGE DETECTION MONITOR (P2195, P2196)
| Battery voltage | 11 V or higher |
| Atmospheric pressure | 76 kPa-a (570 mmHg-a) or higher |
| Air fuel ratio sensor status | Activated |
| Engine coolant temperature | 75°C (167°F) or higher |
| Continuous time of fuel cut | 3 to 10 seconds |
SENSOR CURRENT DETECTION MONITOR (P2195, P2196)
| Rear heated oxygen sensor voltage | Rises from below 0.21 V to 0.59 V or higher |
| Air fuel ratio sensor voltage | Higher than 3.8 V |
SENSOR VOLTAGE DETECTION MONITOR (LEAN SIDE MALFUNCTION P2195)
| Rear heated oxygen sensor voltage | Falls from 0.59 V or higher to below 0.21 V |
| Air fuel ratio sensor voltage | Below 2.8 V |
SENSOR VOLTAGE DETECTION MONITOR (RICH SIDE MALFUNCTION P2196)
| Air fuel ratio sensor current | 3.6 mA or higher |
SENSOR CURRENT DETECTION MONITOR (HIGH SIDE MALFUNCTION P2195)
| Air fuel ratio sensor current | Below 1.0 mA |
SENSOR CURRENT DETECTION MONITOR (LOW SIDE MALFUNCTION P2196)
MONITOR RESULT
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Scheme 178
Scheme 178: WIRING DIAGRAM
This confirmation driving pattern is used in the "Perform Confirmation Driving Pattern" procedure of the following diagnostic troubleshooting procedure.
Scheme 179
Scheme 179: CONFIRMATION DRIVING PATTERN
Scheme 180
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine, and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [A].
- Using the Techstream, enter the following menus to check the fuel-cut status: Powertrain / Engine / Data List / All Data / Idle Fuel Cut.
- Drive the vehicle at between 37 and 75 mph (60 and 120 km/h) for at least 10 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Shift the transmission to 2nd gear [C].
- Accelerate the vehicle to 40 mph (64 km/h) or more by depressing the accelerator pedal for at least 10 seconds [D].
- Soon after performing step [D] above, release the accelerator pedal for at least 4 seconds without depressing the brake pedal in order to execute fuel-cut control [E]. HINT: Fuel-cut is performed when the following conditions are met: Accelerator pedal is fully released. Engine speed is 2500 rpm or more (fuel injection returns at 1000 rpm).
- Allow the vehicle to decelerate until the vehicle speed decreases to less than 6 mph (10 km/h).
- Repeat steps [C] through [E] above at least 3 times in one driving cycle.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P2195 or P2196.
- Check the DTC judgment result [F]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] through [F].
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P2237: Air Fuel Ratio Sensor Open Circuit Between A1A+ and A1A- P2238: Air Fuel Ratio Sensor Short Circuit Between A1A+ and A1A- P2238: Air Fuel Ratio Sensor Short Circuit Between A1A+ and GND P2238: Air Fuel Ratio Sensor Low Impedance P2239: Air Fuel Ratio Sensor Short Circuit Between A1A+ and +B P2252: Air Fuel Ratio Sensor Short Circuit Between A1A- and GND P2253: Air Fuel Ratio Sensor Short Circuit Between A1A- and +B |
| Required Sensors/Components (Main) | Air fuel ratio sensor |
| Required Sensors/Components (Related) | Engine coolant temperature sensor Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | P2237: 10 seconds P2238 (air fuel ratio sensor low admittance): 10 seconds Other: 5 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0016 (VVT System - Misalignment) P0017 (Exhaust VVT System - Misalignment) P0031, P0032, P101D (Air Fuel Ratio Sensor Heater) P0102, P0103 (Mass Air Flow Meter) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0128 (Thermostat) P0171, P0172 (Fuel System) P0301 - P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) P0451, P0452, P0453 (EVAP System) P0500 (Vehicle Speed Sensor) P0505 (Idle Speed Control) |
| Estimated sensor temperature | 450 to 550°C (842 to 1022°F) |
| Engine | Running |
| Battery voltage | 11 V or higher |
P2237 (AIR FUEL RATIO SENSOR OPEN CIRCUIT BETWEEN A1A+ AND A1A-)
| Estimated sensor temperature | 700 to 800°C (1292 to 1472°F) |
| Engine coolant temperature | 10°C (50°F) or higher |
| Fuel cut | Not executed |
P2238 (AIR FUEL RATIO SENSOR LOW IMPEDANCE)
| Battery voltage | 11 V or higher |
| Ignition switch | ON |
| Time after ignition switch is turned from off to ON | 5 seconds or more |
P2238 (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND A1A-, GND)
| Battery voltage | 11 V or higher |
| Ignition switch | ON |
| Time after ignition switch is turned from off to ON | 5 seconds or more |
| Air fuel ratio sensor admittance | Below 0.002 1/ohms |
P2237 (AIR FUEL RATIO SENSOR OPEN CIRCUIT BETWEEN A1A+ AND A1A-)
| Air fuel ratio sensor admittance | Below 0.015 1/ohms |
P2238 (AIR FUEL RATIO SENSOR LOW IMPEDANCE)
| A1A+ terminal voltage | 0.5 V or less |
P2238 (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND GND)
| A1A+ terminal voltage | Higher than 4.5 V |
P2239 (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND +B)
| A1A- terminal voltage | 0.5 V or less |
P2252 (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A- AND GND)
| A1A- terminal voltage | Higher than 4.5 V |
P2253 (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A- AND +B)
| Difference between A1A+ terminal and A1A- terminal voltage | 0.1 V or less |
P2238 (AIR FUEL RATIO SENSOR SHORT CIRCUIT BETWEEN A1A+ AND A1A-)
| Air fuel ratio sensor admittance | 0.015 1/ohms or higher |
| A1A+ terminal voltage | 0.5 to 4.5 V |
| A1A- terminal voltage | 0.5 to 4.5 V |
| Difference between A1A+ and A1A- terminal voltages | 0.1 to 0.8 V |
Scheme 181
Scheme 181: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and wait 2 minutes.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P2237, P2238, P2239, P2252 or P2253.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 3 minutes and check the DTC judgment result again [C].
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Disconnect the air fuel ratio sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B7-1 (HA1A) - B58-18 (HA1A) Always Below 1 ohms B7-3 (A1A+) - B58-103 (A1A+) Always Below 1 ohms B7-4 (A1A-) - B58-126 (A1A-) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B7-1 (HA1A) or B58-18 (HA1A) - Body ground Always 10 kohms or higher B7-3 (A1A+) or B58-103 (A1A+) - Body ground Always 10 kohms or higher B7-4 (A1A-) or B58-126 (A1A-) - Body ground Always 10 kohms or higher Reconnect the air fuel ratio sensor connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-394781-S34213589082011040800000) . NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P2237, P2238, P2239, P2252 or P2253. Check the DTC judgment result. Result Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P2237, P2238, P2239, P2252 or P2253 is output) B B --> See step 5 A --> REPAIR COMPLETED
- REPLACE ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000)
| Required Sensors/Components | Purge VSV and canister pump module |
| Frequency of Operation | Once per driving cycle |
| Duration | Within 3 minutes (varies with amount of fuel in tank) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| EVAP key-off monitor runs when all of following conditions met | |
| Atmospheric pressure | 70 to 110 kPa-a (525 to 825 mmHg-a) |
| Battery voltage | 10.5 V or higher |
| Vehicle speed | Less than 2.5 mph (4 km/h) |
| Ignition switch | Off |
| Time after key-off | 5, 7 or 9.5 hours |
| Canister pressure sensor malfunction (P0452, P0453) | Not detection |
| Purge VSV | Not operated by scan tool |
| Vent valve | Not operated by scan tool |
| Leak detection pump | Not operated by scan tool |
| Both of following conditions met before key-off | Conditions 1 and 2 |
| 1. Duration that vehicle is driven | 5 minutes or more |
| 2. EVAP purge operation | Performed |
| Engine coolant temperature | 4.4 to 35°C (40 to 95°F) |
| Intake air temperature | 4.4 to 35°C (40 to 95°F) |
| EVAP pressure change after EVAP canister vent valve ON | Less than 0.3 kPa (2.25 mmHg) |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Scheme 182
Scheme 182: CONFIRMATION DRIVING PATTERN
Note. The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or higher, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode.
- After the "Evaporative System Check" is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P2420.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Required Sensors/Components | ECM |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 minutes |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTC not stored | None |
| Ignition switch | ON |
| Engine | Running |
| Battery voltage | 8 V or higher |
| Starter | OFF |
| Soak timer measurement when ECM CPU clock counts 10 minutes | Less than 7 minutes, or more than 13 minutes |
Scheme 183
Scheme 183: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 10 minutes or more.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P2610.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- REPLACE ECM Replace the ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P2610) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Start the engine and wait for 10 minutes or more. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. HINT: If no pending DTCs are output to the Techstream, the repair has been successfully completed. NEXT --> END
| Related DTCs | P2A00: Air Fuel Ratio Sensor (Bank 1 Sensor 1) Slow Response |
| Required Sensors/Components (Main) | Air fuel ratio sensor |
| Required Sensors/Components (Related) | Vehicle speed sensor, Crankshaft position sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 to 15 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0016 (VVT System - Misalignment) P0017 (Exhaust VVT System - Misalignment) P0031, P0032, P101D (Air Fuel Ratio Sensor Heater) P0102, P0103 (Mass Air Flow Meter) P0112, P0113 (Intake Air Temperature Sensor) P0115, P0117, P0118 (Engine Coolant Temperature Sensor) P0125 (Insufficient Coolant Temperature for Closed Loop Fuel Control) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle Position Sensor) P0128 (Thermostat) P0171, P0172 (Fuel System) P0301 - P0304 (Misfire) P0335 (Crankshaft Position Sensor) P0340 (Camshaft Position Sensor) P0451, P0452, P0453 (EVAP System) P0500 (Vehicle Speed Sensor) P0505 (Idle Speed Control) |
| Active air fuel ratio control | Performing |
| Active air fuel ratio control performed when following conditions met | |
| Battery voltage | 11 V or higher |
| Engine coolant temperature | 75°C (167°F) or higher |
| Idling | OFF |
| Engine speed | Less than 4000 rpm |
| Air fuel ratio sensor status | Activated |
| Fuel-cut | OFF |
| Engine load | 10 to 70% |
| Shift position | 2 or more |
| Catalyst monitor | Not yet |
| Intake air amount | 4 to 16 g/sec. |
| Response rate deterioration level | Below 0.12 V |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Performing this confirmation pattern will activate the air fuel ratio sensor response monitor.
Scheme 184
Scheme 184: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine / Monitor / O2 Sensor / Details.
- Check that the RES RATE B1S1 is Fail.
- Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) [A].
- Drive the vehicle at a constant speed of between 47 and 62 mph (75 and 100 km/h) for 10 minutes [B].
- Check the monitor result values on the Techstream by entering the following menus: Powertrain / Engine / Monitor / O2 Sensor / Details / RES RATE B1S1.
- If the values indicated on the Techstream do not change, perform Readiness Monitor Drive Pattern for the air fuel ratio sensor and heated oxygen sensor. Refer to «READINESS MONITOR DRIVE PATTERN»(ref-394618-S33900748092011040800000) .
- Note the value of the RES RATE B1S1.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P2A00.
- Check the DTC judgment result [C]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P2A00) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P2A00 is output A DTC P2A00 and other DTCs are output B HINT: If any DTCs other than P2A00 are output, troubleshoot those DTCs first. B --> See step 9 A: Go to next step
- INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE). Refer to «PROCEDURE - Step 1»(ref-394782-S31469268692011040800000) NG --> See step 10 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) See step 1 NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P2A00) Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P2A00. Check the DTC judgment result. Result Result Proceed to ABNORMAL (DTC P2A00 is output) A NORMAL (DTC is not output) B B --> See step 11 A: Go to next step
- REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-394781-S34213589082011040800000) . NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P2A00) Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P2A00. Check the DTC judgment result. Result Result Proceed to ABNORMAL (DTC P2A00 is output) A NORMAL (DTC is not output) B B --> END A --> See step 12
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-394618-S20895286482011040800000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-394781-S34213589082011040800000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-394618-S26532322762011040800000)
- CHECK ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO. Refer to «INSPECTION PROCEDURE»(ref-394782-S05364400692011040800000)
| Related DTCs | U0101: Verify communication |
| Required Sensors/Components (Main) | ECM |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1.25 seconds |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 10.5 V or more (More than 1 second) |
| Ignition switch | ON |
| Starter | OFF |
| Communication signal | Lost communication with TCM |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Wait 5 seconds or more.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: U0101.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-394618-S22943830982011040800000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 185
Scheme 185: WIRING DIAGRAM
RELATED DTCS
| DTC | Monitoring Item | Refer To |
| P043E | Reference orifice clogged (built into canister pump module) | Refer to DTC P043E: Evaporative Emission System Leak Detection Reference Orifice Low Flow; DTC P043F: Evaporative Emission System Reference Orifice High Flow; DTC P2401: Evaporative Emission Leak Detection Pump Stuck OFF; DTC P2402: Evaporative Emission Leak Detection Pump Stuck ON; DTC P2419: Evaporative Emission System Switching Valve Control Circuit Low |
| P043F | Reference orifice high-flow (built into canister pump module) |
| P0441 | Purge VSV (Vacuum Switching Valve) stuck closed Purge VSV stuck open Purge flow | Refer to DTC P0441: Evaporative Emission Control System Incorrect Purge Flow |
| P0451 | Canister pressure sensor (built into canister pump module) signal noise Canister pressure sensor (built into canister pump module) signal becomes fixed/flat | Refer to DTC P0451: Evaporative Emission Control System Pressure Sensor Range / Performance; DTC P0452: Evaporative Emission Control System Pressure Sensor / Switch Low Input; DTC P0453: Evaporative Emission Control System Pressure Sensor / Switch High Input |
| P0452 | Canister pressure sensor (built into canister pump module) voltage low |
| P0453 | Canister pressure sensor (built into canister pump module) voltage high |
| P0455 | EVAP gross leak | Refer to DTC P0455: Evaporative Emission Control System Leak Detected (Gross Leak); DTC P0456: Evaporative Emission Control System Leak Detected (Very Small Leak) |
| P0456 | EVAP small leak |
| P2401 | Leak detection pump stuck off (built into canister pump module) | Refer to DTC P043E: Evaporative Emission System Leak Detection Reference Orifice Low Flow; DTC P043F: Evaporative Emission System Reference Orifice High Flow; DTC P2401: Evaporative Emission Leak Detection Pump Stuck OFF; DTC P2402: Evaporative Emission Leak Detection Pump Stuck ON; DTC P2419: Evaporative Emission System Switching Valve Control Circuit Low |
| P2402 | Leak detection pump stuck on (built into canister pump module) |
| P2419 | Vent valve stuck closed (built into canister pump module) |
| P2420 | Vent valve stuck open (vent) (built into canister pump module) | Refer to DTC P2420: Evaporative Emission System Switching Valve Control Circuit High |
| P2610 | Soak timer (built into ECM) | Refer to DTC P2610: ECM / PCM Internal Engine Off Timer Performance |
If any EVAP system DTCs are set, the malfunctioning area can be determined using the table below.
Scheme 186
Note. If the reference pressure difference between the first and second checks is greater than the specification, all the DTCs relating to the reference pressure (P043E, P043F, P2401, P2402 and P2419) are stored.
Scheme 187
| *1 | Location of EVAP (Evaporative Emission) System | *2 | Purge VSV |
| *3 | EVAP Hose (to Intake Manifold) | *4 | EVAP Hose (from Canister) |
| *5 | Canister Pump Module | *6 | Canister |
| *7 | Air Filter | *8 | Air Inlet Port |
| *9 | Fuel Cap | *10 | Fuel Tank |
| *11 | Purge Line | *12 | Refueling Valve |
The canister pressure sensor, the leak detection pump and the vent valve are built into the canister pump module.
Scheme 188
Note. In this vehicle's EVAP system, turning on the vent valve does not seal off the EVAP system. To check for leaks in the EVAP system, disconnect the air inlet vent hose and apply pressure from the atmospheric side of the canister.
While the engine is running, if a predetermined condition (closed-loop, etc.) is met, the purge VSV is opened by the ECM and stored fuel vapors in the canister are purged into the intake manifold. The ECM changes the duty cycle of the purge VSV to control purge flow volume.
The purge flow volume is also determined by the intake manifold pressure. Atmospheric pressure is allowed into the canister through the vent valve to ensure that the purge flow is maintained when negative pressure (vacuum) is applied to the canister.
The following 2 monitors run to confirm the appropriate EVAP system operation.
Scheme 189
Scheme 190
Scheme 191
Scheme 192
- Key-off monitor This monitor checks for EVAP (Evaporative Emission) system leaks and canister pump module malfunctions. The monitor starts 5 hours* after the ignition switch is turned off. At least 5 hours are required for the fuel to cool down to stabilize the EVAP pressure, thus making the EVAP system monitor more accurate. The leak detection pump creates negative pressure (vacuum) in the EVAP system and the pressure is measured. Finally, the ECM monitors for leaks from the EVAP system, and malfunctions in both the canister pump module and purge VSV based on the EVAP pressure. HINT: *: If the engine coolant temperature is not below 35°C (95°F) 5 hours after the ignition switch is turned off, the monitor check starts 2 hours later. If it is still not below 35°C (95°F) 7 hours after the ignition switch is turned off, the monitor check starts 2.5 hours later.
- Purge flow monitor The purge flow monitor consists of the 2 monitors. The 1st monitor is conducted every time and the 2nd monitor is activated if necessary. The 1st monitor While the engine is running and the purge VSV is on (open), the ECM monitors the purge flow by measuring the EVAP pressure change. If negative pressure is not created, the ECM begins the 2nd monitor. The 2nd monitor The vent valve is turned off (open) and the EVAP pressure is measured. If the variation in the pressure is less than 0.4 kPa (3.0 mmHg), the ECM interprets this as the purge VSV being stuck closed, and illuminates the MIL and sets DTC P0441 (2 trip detection logic). Atmospheric pressure check: In order to ensure reliable malfunction detection, the variation between the atmospheric pressures, before and after conduction of the purge flow monitor, is measured by the ECM. Component Operation Canister Contains activated charcoal to absorb EVAP (Evaporative Emissions) generated in fuel tank. Cut-off valve Located in fuel tank. Valve floats and closes when fuel tank is 100% full. Purge VSV (Vacuum Switching Valve) Opens or closes line between canister and intake manifold. ECM uses purge VSV to control EVAP purge flow. In order to discharge EVAP absorbed by canister to intake manifold, ECM opens purge VSV. EVAP discharge volume to intake manifold controlled by purge VSV duty cycle (current-carrying time) (Open: on; Closed: off). Refueling valve Controls EVAP pressure from fuel tank to canister. Valve consists of diaphragm, spring and restrictor (diameter: 0.08 inch.). When fuel vapor and pressure inside fuel tank increase, valve opens. While EVAP purged, valve closes and restrictor prevents large amount of vacuum from affecting pressure in fuel tank. Valve opens while refueling. Roll-over valve Located in fuel tank. Valve closes by its own weight when vehicle overturns to prevent fuel from spilling out. Soak timer Built into ECM. To ensure accurate EVAP monitor, measures 5 hours (+/- 15 min) after ignition switch is turned off. This allows fuel to cool down, stabilizing EVAP pressure. When approximately 5 hours elapsed, ECM activates see scheme 86 Canister pump module Consists of (a) to (d) below. Canister pump module cannot be disassembled. (a) Vent valve Vents and closes EVAP system. When ECM turns valve on, EVAP system is closed. When ECM turns valve off, EVAP system is vented. Negative pressure (vacuum) is created in EVAP system to check for EVAP leaks by closing purge VSV, turning on vent valve (closing it) and operating leak detection pump (Scheme 184) (b) Canister pressure sensor Indicates pressure as voltage. ECM supplies regulated 5 V to canister pressure sensor, and uses feedback from sensor to monitor EVAP system pressure see scheme 85 (c) Leak detection pump Creates negative pressure (vacuum) in EVAP system for leak check. (d) Reference orifice Has opening with 0.02 inch diameter. Vacuum is produced through orifice by closing purge VSV, turning off vent valve and operating leak detection pump to monitor reference pressure. Reference pressure indicates small leak of EVAP.
Scheme 193
Scheme 193: WIRING DIAGRAM
After a repair, check Monitor Status by performing the Key-Off Monitor Confirmation and Purge Flow Monitor Confirmation described below.
- KEY-OFF MONITOR CONFIRMATION Preconditions The monitor will not run unless: The vehicle has been driven for 10 minutes or more (in a city area or on a freeway). The fuel tank is less than 90% full. The altitude is less than 8000 ft. (2400 m). The engine coolant temperature is between 4.4°C and 35°C (40°F and 95°F). The intake air temperature is between 4.4°C and 35°C (40°F and 95°F). The vehicle remains stationary (the vehicle speed is 0 mph [0 km/h]). Monitor Conditions Allow the engine to idle for at least 5 minutes. Turn the ignition switch off and wait for 6 hours (8 or 10.5 hours). HINT: Do not start the engine until checking Monitor Status. If the engine is started, the steps described above must be repeated. Monitor Status Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Monitor / Evaporative System. Check the Monitor Status displayed on the Techstream. HINT: If Incomplete is displayed, the monitor is not completed. Make sure that the preconditions have been met, and perform the Monitor Conditions again.
- PURGE FLOW MONITOR CONFIRMATION (P0441) HINT: Perform this monitor confirmation after the Key-Off Monitor Confirmation shows complete. Preconditions The monitor will not run unless: The vehicle has been driven for 10 minutes or more (in a city area or on a freeway). The engine coolant temperature is between 4.4°C and 35°C (40°F and 95°F). The intake air temperature is between 4.4°C and 35°C (40°F and 95°F). Monitor Conditions Release the pressure from the fuel tank by removing and reinstalling the fuel cap. Warm the engine up until the engine coolant temperature reaches more than 75°C (167°F). Increase the engine speed to 3000 rpm once. Allow the engine to idle and turn the A/C switch on for 1 minute. Monitor Status Turn the ignition switch off (if ON or if the engine is running). Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Monitor / Evaporative System. Check the Monitor Status displayed on the Techstream. HINT: If Incomplete is displayed, the monitor is not completed. Make sure that the preconditions have been met, and perform the Monitor Conditions again.
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
- CHECK MIL Check that the Malfunction Indicator Lamp (MIL) turns on when turning the ignition switch to ON. OK MIL turns on. NG --> See step 2 OK --> PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE
- CHECK COMMUNICATION BETWEEN TECHSTREAM AND ECM Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Check the communication between the Techstream and ECM. Result Result Proceed to Communication is not possible A Communication is possible B B --> See step 10 A: Go to next step
- CHECK MIL (THROTTLE POSITION SENSOR) Disconnect the throttle body connector. Turn the ignition switch to ON. Check the MIL. Result Result Proceed to MIL does not illuminate A MIL illuminates B Reconnect the throttle body connector. B --> See step 11 A: Go to next step
- CHECK MIL (ACCELERATOR PEDAL SENSOR ASSEMBLY) Disconnect the accelerator pedal sensor assembly connector. Turn the ignition switch to ON. Check the MIL. Result Result Proceed to MIL does not illuminate A MIL illuminates B Reconnect the accelerator pedal sensor assembly connector. B --> See step 12 A: Go to next step
- CHECK MIL (CANISTER PUMP MODULE) Disconnect the canister pump module connector. Turn the ignition switch to ON. Check the MIL. Result Result Proceed to MIL does not illuminate A MIL illuminates B Reconnect the canister pump module connector. B --> See step 13 A: Go to next step
- CHECK MIL (CAMSHAFT POSITION SENSOR FOR INTAKE CAMSHAFT) Disconnect the camshaft position sensor for intake side connector. Turn the ignition switch to ON. Check the MIL. Result Result Proceed to MIL does not illuminate A MIL illuminates B Reconnect the camshaft position sensor for intake side connector. B --> See step 14 A: Go to next step
- CHECK MIL (CAMSHAFT POSITION SENSOR FOR EXHAUST CAMSHAFT) Disconnect the camshaft position sensor for exhaust side connector. Turn the ignition switch to ON. Check the MIL. Result Result Proceed to MIL does not illuminate A MIL illuminates B Reconnect the camshaft position sensor for exhaust side connector. B --> See step 15 A: Go to next step
- CHECK MIL (INTAKE AIR CONTROL VALVE ACTUATOR) Disconnect the intake air control valve actuator connector. Turn the ignition switch to ON. Check the MIL. Result Result Proceed to MIL does not illuminate A MIL illuminates B Reconnect the intake air control valve actuator connector. B --> See step 16 A: Go to next step
- CHECK HARNESS AND CONNECTOR (VC CIRCUIT) Disconnect the throttle body connector. Disconnect the accelerator pedal sensor assembly connector. Disconnect the canister pump module connector. Disconnect the camshaft position sensor for intake side connector. Disconnect the camshaft position sensor for exhaust side connector. Disconnect the intake air control valve actuator connector. Disconnect the ECM connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Short) Tester Connection Condition Specified Condition A49-57 (VCPA) - Body ground Always 10 kohms or higher A49-58 (VCP2) - Body ground Always 10 kohms or higher B58-73 (VCIA) - Body ground Always 10 kohms or higher B58-88 (VCTA) - Body ground Always 10 kohms or higher B58-98 (VCE1) - Body ground Always 10 kohms or higher B58-99 (VCV1) - Body ground Always 10 kohms or higher B58-113 (VCPP) - Body ground Always 10 kohms or higher Reconnect the throttle body connector. Reconnect the accelerator pedal sensor assembly connector. Reconnect the canister pump module connector. Reconnect the camshaft position sensor for intake side connector. Reconnect the camshaft position sensor for exhaust side connector. Reconnect the intake air control valve actuator connector. Reconnect the ECM connectors. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 17
- GO TO MIL CIRCUIT. Refer to «MIL Circuit»(ref-394778-S05181248592011040800000)
- REPLACE THROTTLE BODY. Refer to «REMOVAL»(ref-394781-S01701351132011040800000)
- REPLACE ACCELERATOR PEDAL SENSOR ASSEMBLY. Refer to «REMOVAL»(ref-394781-S37613641072011040800000)
- REPLACE CHARCOAL CANISTER ASSEMBLY. Refer to «REMOVAL»(ref-394773-S40470060312011040800000)
- REPLACE CAMSHAFT POSITION SENSOR. Refer to «REMOVAL»(ref-394781-S00494618902011040800000)
- REPLACE CAMSHAFT POSITION SENSOR. Refer to «REMOVAL»(ref-394781-S00494618902011040800000)
- REPLACE INTAKE AIR CONTROL VALVE ACTUATOR. Refer to «REMOVAL»(ref-394789-S38375711352011040800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000)
Scheme 194
Scheme 195
- w/o Smart Key System When the engine is cranked, the starter relay drive signal output from the ignition switch is input into the STA terminal of the ECM, and the NE signal generated by the crankshaft position sensor is also input into the NE+ terminal. When the ECM interprets that the engine is cranked, it turns transistor Tr1 in the ECM internal circuit on. The current flows to the C/OPN (Circuit Opening) relay when Tr1 is turned on. Then, the fuel pump operates. While the NE signal is input into the ECM when the engine is running, the ECM turns Tr1 on continuously.
- w/ Smart Key System When the engine is cranked, the starter relay drive signal output from the STAR terminal of the power management control ECU is input into the STA terminal of the ECM, and the NE signal generated by the crankshaft position sensor is also input into the NE+ terminal. When the ECM interprets that the engine is cranked, it turns transistor Tr1 in the ECM internal circuit on. The current flows to the C/OPN (Circuit Opening) relay when Tr1 is turned on. Then, the fuel pump operates. While the NE signal is input into the ECM when the engine is running, the ECM turns Tr1 on continuously.
Scheme 196
Scheme 196: WIRING DIAGRAM
Scheme 197
- PERFORM ACTIVE TEST USING TECHSTREAM (ACTIVE THE FUEL PUMP SPEED CONTROL) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the Fuel Pump / Speed. Check whether the fuel pump operating sound occurs when performing the Active Test on the Techstream. OK Fuel pump operating sound occurs. NG --> See step 2 OK --> See step 8
- INSPECT ENGINE ROOM JUNCTION BLOCK ASSEMBLY (C/OPN RELAY) Inspect the C/OPN relay. Refer to «INSPECTION»(ref-394787-S04051205062011040800000) . NG --> See step 9 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (C/OPN RELAY - ECM) Disconnect the ECM connector. Remove the engine room junction block assembly from the engine room relay block. Disconnect the engine room junction block assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition 1F-3 - A49-8 (FC) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition 1F-3 or A49-8 (FC) - Body ground Always 10 kohms or higher Reconnect the ECM connector. Reconnect the engine room junction block assembly connector. Reinstall the engine room junction block assembly. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (C/OPN RELAY - ECM) OK: Go to next step
- INSPECT ENGINE ROOM RELAY BLOCK (IG2 RELAY - C/OPN RELAY) Remove the IG2 relay from the engine room relay block. Remove the engine room junction block assembly from the engine room relay block. Disconnect the engine room junction block assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition 1F-2 - 5 (IG2 relay terminal) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition 1F-2 or 5 (IG2 relay terminal) - Body ground Always 10 kohms or higher Reinstall the IG2 relay. Reconnect the engine room junction block assembly connector. Reinstall the engine room junction block assembly. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (IG2 RELAY - C/OPN RELAY) OK: Go to next step
- CHECK HARNESS AND CONNECTOR (C/OPN RELAY - FUEL PUMP) Remove the engine room junction block assembly from the engine room relay block. Disconnect the engine room junction block assembly connector. Disconnect the fuel pump connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition 1F-10 - L12-4 Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition 1F-10 or L12-4 - Body ground Always 10 kohms or higher Reconnect the engine room junction block assembly connector. Reinstall the engine room junction block assembly. Reconnect the fuel pump connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (C/OPN RELAY - FUEL PUMP) OK: Go to next step
- CHECK HARNESS AND CONNECTOR (FUEL PUMP - BODY GROUND) Disconnect the fuel pump connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition L12-5 - Body ground Always Below 1 ohms Reconnect the fuel pump connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (FUEL PUMP - BODY GROUND) OK: Go to next step
- INSPECT FUEL PUMP Inspect the fuel pump. Refer to «INSPECTION»(ref-394783-S26889183712011040800000) . NG --> See step 10 OK --> See step 11
- PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-394618-S11141036502011040800000)
- REPLACE ENGINE ROOM JUNCTION BLOCK ASSEMBLY. Refer to «REMOVAL»(ref-394787-S17959955042011040800000)
- REPLACE FUEL SUCTION WITH PUMP AND GAGE TUBE ASSEMBLY. Refer to «REMOVAL»(ref-394783-S09090633722011040800000)
- REPLACE ECM. Refer to «REMOVAL»(ref-394781-S33405130152011040800000)
