WIRING DIAGRAM

Refer to DTC P0010. Refer to WIRING DIAGRAM .

Refer to DTC P0010. Refer to WIRING DIAGRAM .

Refer to DTC P0031. Refer to WIRING DIAGRAM .

Refer to DTC P0102. Refer to WIRING DIAGRAM .

Scheme 355

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch ON.
3. Turn the Techstream on.
4. Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure).
5. Turn the ignition switch off and wait for at least 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on.
7. Start the engine and warm it up until the engine coolant temperature reaches 70°C (158°F) or higher [A].
8. Drive the vehicle at approximately 80 km/h (50 mph) to 112 km/h (70 mph) for 5 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive while keeping the engine load as stable as possible.
9. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
10. Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
12. Input the DTC: P0101.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] and [C] again.
14. If no pending DTC is output, perform a universal trip and check for permanent DTC. Refer to «DTC CHECK / CLEAR»(ref-554492-S07547393792013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Refer to DTC P0112. Refer to WIRING DIAGRAM .

Refer to DTC P0115. Refer to WIRING DIAGRAM .

Refer to DTC P0115. Refer to WIRING DIAGRAM .

Refer to DTC P0031. Refer to WIRING DIAGRAM .

Refer to DTC P0031. Refer to WIRING DIAGRAM .

Refer to DTC P0335. Refer to WIRING DIAGRAM .

Refer to DTC P0412. Refer to WIRING DIAGRAM .
